Quick Start Guide
VVX 500 and VVX 600
® ®
VVX 600
VVX 500
®
Note: For more information on your Polycom VVX 500 or VVX 600
Business Media Phone, including Quick User Guides and User Guides, navigate to
your phone’s Support page from Polycom Voice Support:
® ®
http://support.polycom.com/PolycomService/support/us/support/voice/index.html
Package Contents
VVX 500 or VVX 600 Phone
Optional Accessories
For more information, contact your reseller.
AC power cord and adapter (may vary by region)
BETA DRAFT
Features
Connect Cables
AC power connection (optional accessory)
Use if Power over Ethernet (PoE) is unavailable
Passthrough ethernet connection to PC
(optional; extra cable not included)
Cable groove
(Press headset cable
into groove)
Cable groove
(Press straight part
of handset cable
into groove)
Speaker
Dialpad
Hookswitch
Reversible tab
(for wallmount
installation)
Security slot
(on side)
Mute key
Volume keys
Speakerphone key
Headset key
Message Waiting
Indicator
Microphone
Home/Lines key
Touchscreen
USB ports (on back)
Auxiliary port
(for future use)
AUX
AUX
Connect Optional Headset
Connect Optional USB Devices
Insert a USB flash drive into one of the
USB ports to record calls, use your phone
as a Digital Picture Frame, or to change
the background picture on your phone.
Or, insert a USB headset into one of the
USB ports. To learn more, see your
phone’s User Guide.
Note: Your phone supports
and wireless headsets, including
electronic hookswitch (EHS)
headsets. VVX 600 phones also
support Bluetooth headsets.
For connection directions, refer to
your headset documentation.
Standard headsets typically use
the RJ-9 or USB port, while
EHS headsets use the RJ-9 and
serial port.
wired
RJ-9 port
Serial port
USB ports
USB port Press and slide the
cover up and off
Connect Stand*
Fully insert the stand into one of
the slots on the back of the phone.
The slot you choose determines
the angle of the phone.
*For wallmount installation, an optional accessory is available. For more information, contact your reseller.
AUX
USB port
Polycom (UK) Ltd tímto prohlašuje, že tento Polycom je ve shodě se základními požadavky a dalšími
příslušnými ustanoveními směrnice 1999/5/ES. VVX 500/VVX 600
Undertegnede Polycom (UK) Ltd erklærer herved, at følgende udstyr Polycom
overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF. VVX 500/VVX 600
Käesolevaga kinnitab Polycom (UK) Ltd seadme Polycom vastavust direktiivi
1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
VVX 500/VVX 600
Por medio de la presente Polycom (UK) Ltd declara que el Polycom cumple con los
requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
VVX 500/VVX 600
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Polycom (UK) Ltd ΔΗΛΩΝΕΙ ΟΤΙ Polycom ΣΥΜΜΟΡΦΩΝΕΤΑΙ
ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
VVX 500/VVX 600
Par la présente Polycom (UK) Ltd déclare que l’appareil Polycom est conforme aux
exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
VVX 500/VVX 600
Con la presente Polycom (UK) Ltd dichiara che questo Polycom è conforme ai requisiti essenziali ed
alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
VVX 500/VVX 600
Hér með lýsir Polycom (UK) Ltd yfir því að Polycom er í samræmi við grunnkröfur og aðrar kröfur,
sem gerðar eru í tilskipun 1999/5/EC VVX 500/VVX 600
Ar šo Polycom (UK) Ltd deklarē, ka Polycom atbilst Direktīvas 1999/5/EK būtiskajām prasībām un
citiem ar to saistītajiem noteikumiem. VVX 500/VVX 600
Šiuo Polycom (UK) Ltd deklaruoja, kad šis Polycom atitinka esminius reikalavimus ir kitas 1999/5/EB
Direktyvos nuostatas. VVX 500/VVX 600
Hierbij verklaart Polycom (UK) Ltd dat het toestel Polycom in overeenstemming is met de essentiële
eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
VVX 500/VVX 600
Hawnhekk, Polycom (UK) Ltd, jiddikjara li dan Polycom jikkon-forma mal-ħtiġijiet essenzjali u ma
provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
VVX 500/VVX 600
Alulírott, Polycom (UK) Ltd nyilatkozom, hogy a Polycom megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
VVX 500/VVX 600
Polycom (UK) Ltd erklærer herved at utstyret Polycom er i samsvar med de grunnleggende krav og
øvrige relevante krav i direktiv 1999/5/EF. VVX 500/VVX 600
Niniejszym Polycom (UK) Ltd oświadcza, że Polycom jest zgodne z zasadniczymi
wymaganiami oraz innymi stosownymi postanowieniami Dyrektywy 1999/5/WE
VVX 500/VVX 600
Polycom (UK) Ltd declara que este Polycom está conforme com os requisitos essenciais e outras
disposições da Directiva 1999/5/CE. VVX 500/VVX 600
Polycom (UK) Ltd izjavlja, da je ta Polycom v skladu z bistvenimi zahtevami in ostalimi relevantnimi
določili direktive 1999/5/ES. VVX 500/VVX 600
Polycom (UK) Ltd týmto vyhlasuje, že Polycom spĺňa základné požiadavky a všetky
príslušné ustanovenia Smernice 1999/5/ES. VVX 500/VVX 600
Polycom (UK) Ltd vakuuttaa täten että Polycom tyyppinen laite on direktiivin 1999/5/EY oleellisten
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
VVX 500/VVX 600
Härmed intygar Polycom (UK) Ltd att denna Polycom står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
VVX 500/VVX 600
CE Mark R & TTE Directive (EU Only)
Hiermit erklärt Polycom (UK) Ltd, dass sich das Gerät Polycom in Übereinstimmung
mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
VVX 500/VVX 600
http://www.polycom.com
Polycom, Inc. 4750 Willow Road, Pleasanton, CA 94588-2708 USA
Hereby, Polycom (UK) Ltd. declares that this is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Polycom VVX 500/VVX 600
Contact Information:
Please contact your .Polycom Authorized Reseller for assistance
SAFETY AND REGULATORY INFORMATION. This device complies with Part 15 of the FCC Installation must be performed in accordance with all relevant national wiring rules. L’Installation doit
Operation is subject to the following two conditions: être exécutée conformément à tous les règlements nationaux applicable au filage électrique.
(1) This device may not cause harmful interference, and (2) This device must accept any interferences The outlet to which this apparatus is connected must be installed near the equipment and must always
received, including interference that may cause undesired operation. be readily accessible. La prise électrique à laquelle l’appareil est branché doit être installée près de
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, l’équipement et doit toujours être facilement accessible.
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against This Class [B] digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe
harmful interference in a residential installation. This equipment generates, uses and can radiate radio [B] sera conforme à la norme NMB-003 du Canada.
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful To avoid electric shock, do not connect safety extra low voltage (SELV) circuits to teleconference station
interference to radio communications. However, there is no guarantee that interference will not occur in a network (TNV) circuits. LAN ports contain SELV circuit, and WAN ports contain TNV circuits. Some LAN
particular installation. If this equipment does cause harmful interference to radio or television reception, and WAN ports both use RJ-45 connectors. Use caution when connecting cables. This product is rated
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the 48Vdc, 0.38A. When used with the optional external power supply (PSC18U-480, or similar rated PSU),
interference by one or more of the following measures: the power supply shall be a Listed power supply with a LPS output, rated 48V, min. 0.38A.
ŸReorient or relocate the receiving antenna. Hearing Aid Compatibility (HAC):
ŸIncrease the separation between the equipment and receiver. This device is hearing aid compatible.
ŸConnect the equipment into an outlet on a circuit different from that to which the receiver is Radiation Exposure Statement (VVX 600 phones only):
connected. IMPORTANT—The antenna used for this transmitter must be installed to provide a separation
ŸConsult the dealer or an experienced radio/TV technician for help. distance of at least 20 centimeters from all persons and must not be co‐located or operating in
Hereby, Polycom, Inc. declares that the products in this manual are CE marked and in compliance with all EU conjunction with any other antenna or transmitter.
directives and regulations that apply to them including: R&TTE Directive 1995/5/EC. A full copy of the Australia:
Declaration of Conformity can be obtained from Polycom Ltd., 270 Bath Road, Slough, Berkshire, SL1 4DX, Warning—This equipment will be inoperable when mains power fails.
UK. Japan:
In accordance with Part 15 of the FCC Rules, the user is cautioned that any changes or modifications not
expressly approved by Polycom, Inc. could void the user’s authority to operate the equipment.
Operating Ambient Conditions:
ŸOperating temperature: +32 to 104°F (0 to 40°C)
ŸRelative humidity: 5% to 95%, noncondensing
ŸStorage temperature: -40 to +160°F (-40 to +70°C)
Rules.
LIMITED WARRANTY. Polycom warrants to the end user (“Customer”) that this product will be free The product software is the current major version or the next preceding major version (software
from defects in workmanship and materials, under normal use and service, for one year from the revisions are labeled as “x.y.z,” with the first two digits designating major versions).
date of purchase from Polycom or its authorized reseller. Polycom’s sole obligation under this The product software comes with 90-day software warranty, providing for software updates
express warranty shall be, at Polycom’s option and expense, to repair the defective product or part, (minor releases/bug fixes). To continue to receive support, purchasing a maintenance contract is
deliver to Customer an equivalent product or part to replace the defective item, or if neither of the the most economical solution.
two foregoing options are reasonably available, Polycom may, on its sole discretion, refund to Requests for software support should be made through the Polycom Reseller from whom the
Customer the purchase price paid for the defective product. All products that are replaced will product was purchased.
become the property of Polycom. Replacement products or parts may be new or reconditioned. LIMITATION OF LIABILITY. TO THE FULL EXTENT ALLOWED BY LAW, POLYCOM EXCLUDES FOR ITSELF
Polycom warrants any replaced or repaired product or part for ninety (90) days from shipment, or AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING
the remainder of the initial warranty period, whichever is longer. Products returned to Polycom NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF
must be sent prepaid and packaged appropriately for safe shipment, and it is recommended that ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR
they be insured or sent by a method that provides for tracking of the package. Responsibility for DATA, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE,
loss or damage does not transfer to Polycom until the returned item is received by Polycom. The INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS PRODUCTS,
repaired or replaced item will be shipped to Customer, at Polycom’s expense, not later than thirty EVEN IF POLYCOM OR ITS AUTHORIZED RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
(30) days after Polycom receives the defective product, and Polycom will retain risk of loss or DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE
damage until the item is delivered to Customer. PRICE PAID, AT POLYCOM’S OPTION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE
EXCLUSIONS. Polycom will not be liable under this limited warranty if its testing and examination AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
disclose that the alleged defect or malfunction in the product does not exist or results from: DISCLAIMER. Some countries, states, or provinces do not allow the exclusion or limitation of implied
Failure to follow Polycom’s installation, operation, or maintenance instructions. warranties or the limitation of incidental or consequential damages for certain products supplied to
Unauthorized product modification or alteration. consumers, or the limitation of liability for personal injury, so the above limitations and exclusions
Unauthorized use of common carrier communication services accessed through the product. may be limited in their application to you. When the implied warranties are not allowed to be
Abuse, misuse, negligent acts or omissions of Customer and persons under Customer’s control; excluded in their entirety, they will be limited to the duration of the applicable written warranty.
or This warranty gives you specific legal rights which may vary depending on local law.
Acts of third parties, acts of God, accident, fire, lightening, power surges or outages, or other GOVERNING LAW. This Limited Warranty and Limitation of Liability shall be governed by the laws of
hazards. the State of California, U.S.A., and by the laws of the United States, excluding their conflicts of laws
WARRANTY EXCLUSIVE. IF A POLYCOM PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, principles. The United Nations Convention on Contracts for the International Sale of Goods is hereby
CUSTOMER’S SOLE REMEDY FOR BREACH OF THAT WARRANTY SHALL BE REPAIR, REPLACEMENT, OR excluded in its entirety from application to this Limited Warranty and Limitation of Liability. All
REFUND OF THE PURCHASE PRICE PAID, AT POLYCOM’S OPTION. TO THE FULL EXTENT ALLOWED BY rights reserved under International and Pan‐American Copyright Conventions. No part of the
LAW, THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER contents of this manual may be copied, reproduced, or transmitted in any form or by any means, or
WARRANTIES, TERMS, OR CONDITIONS, EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION OF translated into another language or format, in whole or part, without written consent from Polycom,
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES, TERMS, OR CONDITIONS OF Inc. Do not remove (or allow anybody else to remove) any product identification, copyright or other
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, SATISFACTORY QUALITY, notices. Polycom, the Polycom logo design, and Polycom VVX 500 and Polycom VVX 600 are
CORRESPONDENCE WITH DESCRIPTION, AND NON-INFRINGEMENT, ALL OF WHICH ARE EXPRESSLY trademarks of Polycom, Inc. in the U.S. and various other countries.
DISCLAIMED. POLYCOM NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR COPYRIGHT. All rights reserved under International and Pan-American Copyright Conventions. No
IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF part of the contents of this manual may be copied, reproduced, or transmitted in any form or by
ITS PRODUCTS. any means, or translated into another language or format, in whole or part, without written consent
®
SERVICE AGREEMENTS. Please contact your Polycom Authorized Reseller for information about of Polycom, Inc. Polycom and the logo design are registered trademarks and Polycom
service agreements applicable to your product. and Polycom are trademarks of Polycom, Inc. in the United States, and various countries.
SOFTWARE SUPPORT. Polycom will provide support for software running on the Product if all of the Do not remove (or allow any third party to remove) any product identification, copyright or other
following conditions are satisfied: notices.
The product is under warranty or is covered by a Polycom service contract;
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
VVX 500
VVX 600
Copyright, Safety Notices
1725-44645-001 Rev.A
