Polygroup CW002 Remote Controller User Manual
Polygroup Trading Limited Remote Controller
Contents
- 1. 2AABT-CW002_User Manual
- 2. User Manual
User Manual
![](/img.php?id=4194316&img=bg1.png)
US, CAN, MX, TW
(TS-48W29V)
FR, SP, ICE(K25V290083G)
UK(K25V290083B)
JP(K25C290083J)
KR(K25C290083K)
AU(K25V290083A)
Section 1
Section 2
Section 3
Section 4
Tree Top
2.7 m / 9 ft EZ Connect™ Pre-lit Aspen Micro Dot LED Tree
ITM. / ART. 279939, 2002052
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
This tree comes with EZ Connect™ and Simple Shape™ technology, allowing you to set up and light your tree in less
than 10 minutes! Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Choose an appropriate location near a wall outlet.
2. Assemble the tree stand on a level surface. (See Fig. A)
TREE ASSEMBLY INSTRUCTIONS
Page: 1 of 6
For assistance with assembly, parts and customer service, call (US & Canada only): 1-888-919-0070 (English, Spanish,
French) at 10am-6pm, Mon-Fri, Eastern Time, email: warranty@polygroup.com, or visit www.polygroupstore.com.
Please note if you are calling outside of USA & Canada, international toll fees may apply.
Customer Service Hotline Hours: 8am-4pm, Mon-Fri, MST.
(For Indoor Use Only)
Fig. B - Tree and Light Assembly
Control box Foot Pedal
On/O Switch
Plug Adaptor
Into Wall
Outlet
Do Not Tamper
Internal Parts
Open the
protective
cap
Do Not Tamper
Internal Parts
Open the
protective
cap
1. Pull apart tree stand legs until they
snap and form an ‘X’ shape.
2. Insert the tree bottom into the
assembled stand. Insert and tighten
the eye bolt into the stand until
rmly secured.
3. To close the stand, press the metal
button and fold the legs together.
Eye Bolt
Click
Eye Bolt
Fig. A - Tree Stand Assembly
![](/img.php?id=4194316&img=bg2.png)
1. Unplug adaptor from the wall outlet. Then remove all ornaments and decorations.
2. Disassemble the tree from the top to the bottom. Gently lift the center pole straight up to remove from the section
below , and fold all branches toward the pole. Continue until the lowest tree section is removed from the tree stand.
3. Close the protective caps on the poles to avoid damaging the internal parts. (See Fig. D)
4. Carefully place all tree sections into the shipping box and tape (not included) it shut.
5. Store your tree in a cool, dry place away from sunlight. Exposure to excessive heat or
humidity may damage your tree.
STORAGE INSTRUCTIONS
If Tree Does Not Illuminate / Some Bulbs Do Not Light or Flicker
1.
2. Turn the poles gently to ensure pole-to-pole connection is secured.
Loose Hinge Pin
1. Place the branch into the slot of the bracket.
2. Insert a new hinge pin (included) through the hole and secure with
a retainer washer (included). (See Fig. E)
TROUBLESHOOTING TIPS
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top (See Fig. B). Remove protection cap, and insert the center pole into
the stand. Then slot together the remaining poles securely until the tree top is installed. Be sure that all cords are
free from branch hinges.
5. Plug the adaptor into the wall outlet (See Fig. B). Your entire tree should now be lit.
6. This is a Simple Shape™ tree and no shaping is required. Just slightly upsweep all tips (See Fig. C) and shift branches
Top view Side view
Fig. C
Fig. D
Fig. E
Page: 2 of 6
This tree includes hinge pins/washers. If extra parts are needed, please contact our customer service center.
SPARE PARTS
Simply press the selector button to select from the following light
functions: 1. Clear Steady 2. Clear Fading 3. Multicolor Steady
4. Multicolor Fading 5. Clear / Multicolor Alternating
6. Clear / Multicolor Fading 7. Demo
DUAL COLOR LIGHT CONTROLLER INSTRUCTIONS
Remote Control
Selector
Button
BATTERY REPLACEMENT
1. Remove the insultation tab.
2. Loosen the screw of the battery cover with a screwdriver (not included).
Insulation Tab
![](/img.php?id=4194316&img=bg3.png)
Page: 3 of 6
AUSTRALIA: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Hereby, Polygroup declares that the Christmas Tree is in compliance with RED 2014/53/EU.
DISPOSAL OF USED BATTERIES
Battery may contain hazardous substances which could endanger the environment and human
health.
This symbol marked on the battery and/ or packaging indicates that used battery shall not be
treated as municipal waste. Batteries should be disposed of at an appropriate collection point for
recycling. By ensuring the used batteries are disposed of correctly, you will help preventing
potential negative consequences for the environment and human health. The recycling of
materials will help to conserve natural resources. For more information about recycling of used
batteries, please contact your local municipality waste disposal service.
1. Use only the power adaptor supplied with this product. Using a dierent adaptor can damage the lights and will cause
re or electrical shock hazards.
2. For indoor use only.
3. This product contains a CR2032 button cell battery. If swallowed, it could cause severe injury or death in just 2 hours
due to chemical burns and potential perforation of the oesophagus – seek medical attention immediately.
4. Keep batteries out of reach of children.
5. If you suspect your child has swallowed or inserted a button cell battery, immediately seek urgent medical assistance.
6. Make sure the battery compartment is correctly secured (e.g. the screw or other mechanical fastener is tightened), and
do not use if the compartment is not secured.
7. Dispose of used button cell batteries immediately and safely. Flat batteries can still be dangerous.
8. Inform others about the risk associated with button cell batteries and how to keep their children safe.
9. Do not expose the lights to moisture.
10. Remove the batteries when the controllers are left unused, and are not expected to be used for an extended period
of time, or when depleted.
11. Dispose of the used battery properly as per the directions on batteries, and local laws and regulations regarding the
disposal of hazardous waste.
12. Clean the battery contact surfaces prior to battery installation.
13. Do not dispose of batteries in re – batteries may leak or rupture.
WARNING
3. Replace the used battery with a new CR2032 button cell battery (not included). Make sure that the battery is installed
with the correct polarity (+ and -).
4. Retighten the screw to close and secure the battery cover.
Cover
Battery
CR2032
Page: 4 of 6
MADE IN CHINA / FABRIQUÉ EN CHINE / HECHO EN CHINA
Distributed by:
Costco Wholesale Corporation
P.O. Box 34535
Seattle, WA 98124-1535
USA
1-800-774-2678
www.costco.com
Distributed by:
Costco Wholesale Iceland ehf.
Kauptún 3-7, 210 Gardabaer
Iceland
www.costco.is
Distribué par :
Costco France
1 avenue de Bréhat
91140 Villebon-sur-Yvette
France
01 80 45 01 10
www.costco.fr
Imported by:
Costco Wholesale Japan Ltd.
3-1-4 Ikegami-Shincho
Kawasaki-ku, Kawasaki-shi,
Kanagawa 210-0832 Japan
044-281-2600
www.costco.co.jp
Imported and Distributed by:
Costco Wholesale Korea, Ltd.
40, Iljik-ro
Gwangmyeong-si
Gyeonggi-do, 14347, Korea
1899-9900
www.costco.co.kr
Imported by / Manufactured for:
Costco President Taiwan, Inc.
No. 656 Chung-Hwa 5th Road
Kaohsiung, Taiwan
Company Tax ID: 96972798
449-9909 or 02-449-9909 (if cellphone)
www.costco.com.tw
Imported by / Distributed by:
Costco (Shanghai) Trading Co., Ltd.
Room 2105, No. 2299 Yanan West Road
Changning District, Shanghai, China
+86-21-62577065
Imported by / Importé par :
Costco Wholesale Canada Ltd.*
415 W. Hunt Club Road
Ottawa, Ontario
K2E 1C5, Canada
1-800-463-3783
www.costco.ca
* faisant aaire au Québec sous
le nom Les Entrepôts Costco
Importado por:
Importadora Primex S.A. de C.V.
Blvd. Magnocentro No. 4
San Fernando La Herradura
Huixquilucan, Estado de México
C.P. 52765
RFC: IPR-930907-S70
(55)-5246-5500
www.costco.com.mx
Imported by:
Costco Wholesale Australia Pty Ltd
17-21 Parramatta Road
Lidcombe NSW 2141
Australia
www.costco.com.au
Imported by:
Costco Wholesale UK Ltd /
Costco Online UK Ltd
Hartspring Lane
Watford, Herts
WD25 8JS
United Kingdom
01923 213113
www.costco.co.uk
Importado por:
Costco Wholesale Spain S.L.U.
Polígono Empresarial Los
Gavilanes
C/ Agustín de Betancourt, 17
28906 Getafe (Madrid) España
NIF: B86509460
900 111 155
www.costco.es
![](/img.php?id=4194316&img=bg5.png)
Page: 5 of 6
CUSTOMER SERVICE FOR CHRISTMAS TREES
For any questions, assistance, or missing parts, DO NOT RETURN YOUR TREE TO PLACE OF PURCHASE. Please
contact us via: call (US & Canada only) 1-888-919-0070 (English, Spanish, French) at 10am-6pm, Mon-Fri, Eastern
Time, email: warranty@polygroup.com, or visit www.polygroupstore.com.
TREE ID# IS LOCATED ON END PANEL OF BOX. TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT
PARTS.
Customer Name:
Address (No P.O. boxes):
City & State:
Zip Code:
Day Phone:
Date Purchased:
Tree ID#:
Tree UPC#:
Store Purchased:
Specify Problem:
![](/img.php?id=4194316&img=bg6.png)
FCC notices:
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Polygroup Trading Limited
Unit 606, Fairmont House, 8 Cotton Tree Drive, Central, Hong Kong
www.polygroupstore.com
This device complies with ISEDC
Operation is subject to the following two
(2) this device must accept any interference,
undesired operation of the device.
ISEDC Statement
Le présent appareil est conforme aux CNR
radio exempts de licenceou standard.
L'exploitation est autorisée aux deux conditions
(2) l'utilisateur de l'appareil doit accepter tout
Déclaration de l’ISEDC
d'ISEDC applicables aux appareils
Équipement ICES-003 du brouilleur.
suivantes :
(1) l'appareil ne doit pas produire de brouillage,et
brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre
le fonctionnement.
licence-exempt RSS standards or Interference
caussing Equipment standard ICES-003.
conditions:
(1) this device may not cause interference, and
including interference that may cause
The device is compliance with RF exposure
guidelines, users can obtain Canadian informa-
tion on RF exposure and compliance. Après examen de ce matériel aux conformité ou
aux limites d’intensité de champ RF, les utilisateurs
peuvent sur l’exposition aux radiofréquences et la
conformité and compliance d’acquérir les informa-
tions correspondantes.
Page: 6 of 6
