sect 1
044-05079 Rev. A 1-1
GENERAL DESCRIPTION
1-1. INTRODUCTION
This manual contains information and procedures for installation, operation, and maintenance of
Powerwave’s model NTGY81AA multichannel power amplifier (MCPA). The manual is organized
into six sections as follows:
Section 1. General Description
Section 2. Installation
Section 3. Operating Instructions
Section 4. Principles of Operation
Section 5. Maintenance
Section 6: Troubleshooting
1-2. GENERAL DESCRIPTION
The NTGY81AA is a linear, multichannel power amplifier that operates in the 60 MHz frequency
band from 1930 MHz to 1990 MHz. It is designed to be mounted in an enclosure with EMI
containment. Its flat base plate allows for mounting on a flat thermal-absorbing surface to provide
adequate heat dissipation.
Each amplifier module has a power, alarm, and control connector that allows the host system to
monitor the amplifier module performance. Primary power for the amplifier is +26 Vdc.
1-3. FUNCTIONAL AND PHYSICAL SPECIFICATIONS
Functional and physical specifications for the amplifier are listed in table 1-1.
Section
1
044-05079 Rev. A 1-2
Table 1-1. NTGY81AA Multichannel Power Amplifier Functional Specifications
Frequency Range 1930-1990 MHz (60 MHz Bandwidth)
Maximum Average Input Power 13 dBm
Continuous Average Output Power 50 Watts
Spurious Emissions @ Maximum
Rated Output Power
(50 W / 47 dBm)
Frequency Offset Requirement Meas. Bandwidth
Max. Min.
0.885-1.25 MHz -47 dBc 30 kHz
1.25-1.98 MHz -16.5 dBm 37.5 kHz
1.98-2.25 MHz -58 dBc 30 kHz
>2.25 MHz -15 dBm 1 MHz
RF Gain 47 ±2 dB
Gain Flatness: ± 0.2 dB for any 1.25-MHz band within frequency range.
Output Protection: Mismatch Protected
Input Port Return Loss: VSWR 2:1 Max.
Out of Band Spurious: Less than -15 dBm / 1 MHz
DC Input Power: +26 ± 0.5 Vdc, 260 mV p-p max. ripple, ≤500 watts
Operating Temperature: -15 ºC. to +85 ºC. (heatsink temperature)
Storage Temperature: -40 ºC. to +85 ºC.
Operating Humidity: 5 % - 95 % Relative Humidity (Noncondensing)
Storage Humidity: 5 % - 95 % Relative Humidity (Noncondensing)
Interface Connectors:
RF Input ---------------------------------------
RF Output-------------------------------------
+26 Vdc Power and Ground------------
Alarms and Sensing ----------------------
Differential IIC Clock, Rcv., Xmit.-----
IIC, Power, Alarms, Controls-----------
IIC, RS485, Power, Other Signals ---
SMA Female
SMA Female
3W3 D-Sub (Connector P1)
14-Position Micro-Fit 3.0 (Connector P2)
6-Position Micro-Fit 3.0 (Connector P3)
26-Position High Density D-Sub (Connector P4)
18-Position Micro-Fit 3.0 (Connector P5)
Dimensions (inches): 11.00 x 14.50; height: 1.70
044-05079 Rev. A 1-3
P1
P4
P5
P3
P2
044-05079 Rev. A 1-4
RF OUT RF IN
Figure 1-1. NTGY81AA Multichannel Power Amplifier
