 G3L-1900-54/G3L-1900-54-A Installation & Service Manual
 Copyright Powerwave Technologies, Inc., April 2003. All rights reserved
All specifications are subject to change without notice. Contact the factory for complete performance data.
044-05135 Rev. A A-1  April 2003
Appendix A.   Specifications
Table A-1   G3L-1900-54/54-A Wideband Multicarrier Cellular Amplifier Functional
Specifications
Frequency Range  1930 - 1990 MHz (60 MHz Bandwidth)
Instantaneous Bandwidth  20 MHz *
Total Typical / Maximum Input Power  -15.7 - +4.8 / +5.8 dBm
Total Output Power  54 W (47.3 dBm)
Adjacent Channel Leakage Power
Ratio (ACLR) Spectrum Analyzer set-
tings: 30 KHz RBW, 300 KHz VBW,
True RMS detector
ACLR1 <-46dBc@f=fc ±5 MHz
ACLR2 <-51dBc@f=fc ±10 MHz
RF Gain   40 dB +0.5 dB
Gain Flatness  ±0.5 dB
Output Protection  Mismatch Protected
Input Port Return Loss  18 dB min
Harmonics  Better than -50 dBc
Out of Band Spurious  Better than -60 dBc
Duty Cycle  Continuous
DC Input Power:
G3L-1900-54
-48 Vdc nominal, 6.5 amps typical (15 amps max)
Operational -57 Vdc to -60 Vdc (Po derated outside
normal operating range)
AC Input Power:
G3L-1900-54-A
230 Vac nominal, 50/60 Hz, 1.9 amps typical (3 amps
max)
Operational 264 Vac to 300 Vac (Po derated outside
normal operating range)
Operating Temperature  -10 ºC to +50 ºC
Storage Temperature  -40 ºC to +85 ºC
Operating Humidity  0 % to 80 % Relative Humidity (noncondensing)
Storage Humidity  0 % to 100 % Relative Humidity (noncondensing)
AC, DC Input, Summary Alarm, Base
Station Communication TLCI Bus
Elcon Modular Flatpaq tm
RF Input Connector  SMA Female
RF Output Connector  Type N-Female
Power Consumption  DC Version: 310 Watts @ Po = 30 W average power
AC Version: 325 Watts @ Po = 30 W average power
Weight 28 lbs.
Dimensions  3.125” High, 16.75” Wide, 14.125” Deep, 15.75” Deep
including connector guides
 * The command received from the base station includes the operating band and based on that
band, the pilot frequency sets to 10 MHz lower than the lowest carrier in the operating band.
