Primax Electronics B81301 Bluetooth Wireless Stereo Headset User Manual 1

Primax Electronics Ltd Bluetooth Wireless Stereo Headset 1

Manual

General Information
Thank you for purchasing PSH-1A Wireless Stereo Headset. Your new device is a stylish
product that enables you to communicate comfortably with compatible mobile phones that
support Bluetooth wireless technology.
WARNING:
Using a mobile phone while driving can distract you and may cause accidents.
Driving with both ears covered may violate Traffic Regulations in certain countries.
Please consult your local authorities.
Getting started
Whats included
(1) Headset (2) User Guide (3) Power adaptor** (4) USB cable**
** depends on customer require
Overview of the headset
(1) Indicator Light
Status indication with blue and red lights
(2) Volume Down button
Decreases the volume
(3) Volume Up button
Increases the volume
(4) Multifunction button
Power on/off, play/pause, answer/end a call
(5) Forward button
Forward to next song
(6) Backward button
Go back to the previous song
(7) Charger connector
Charge the headset
Before using the headset for the first time, you must charge it for approximately 3.5 hours.
When the battery is fully charged, it provides up to 12 hours of talk time, 10 hours of music
playing time and up to 350 hours of standby time. Always use the charger provided in the sales
package.
1. Connect the charger cable to the headset.
2. Plug the charger into a wall socket. The lights turn to solid red in charging status.
3. When the battery is fully charged, the red light will turn off.
Turn on / off the headset
To turn on the headset
Press the Multifunction button for more than 3 seconds. You will hear a long high tone beep
from the earpiece and see blue light on right earpiece flashing three times rapidly.
To turn off the headset
Press and hold the Multifunction button. You will hear a long high tone beep from the earpiece
and see solid red light on for 3 seconds on right earpiece.
Pair the PSH-1A headset and your mobile phone or other devices
You will need to pair your PSH-1A with Bluetooth-enabled mobile phone and/or devices before
you can use it. Your PSH-1A can be paired with up to 8 compatible phones/devices. However,
it can only be connected to one phone at a time.
To pair the headset
1. Make sure the headset is off. Press and hold the Multifunction button for more than 7
seconds, until you short low tone beeps from the earpiece and the blue and red lights
flashing alternately.
2. Refer to user guide of the phone / device and set the phone / device into pairing mode.
3. When the phone / device finds the headset, PSH-1A will be shown. Please accept and
confirm with the presskey 0000 (4 zeros).
4. Once pair and connection are succeeded, you will hear a short high tone beep and
see blue light flashing. The headset is now ready to serve.
The PSH-1A will automatically reconnect to the last-connected phone / device. If the
connection is failed due to phone / device not found, the headset will automatically enter into
pairing mode.
Connecting with two devices simultaneously
It is possible to connect the PSH-1A to two devices at the same time, so that you can listen to
the music and keep phone connectivity at the same time.
To do so, please pair with cellular phone first and keep connecting profiles on both ends. Make
the cellular phones Bluetooth service disconnected from the headset.
Then, pair the PSH-1A with MP3 player or computer. After this completed, let the cellular
phone find the headset again.
In this scenario, when there is an incoming call, the incoming call will be overriding music. Only
when the call is ended that music will be resumed.
Button general operating functions
Adjusting volume
Press the Volume Up button to increase the volume. To decrease the volume, press Volume
Down button.
Reset paired devices
To reset the pairing list on your phone, while power on, press and hold both Forward and
Backward buttons. The light will be flashing in purple. By doing this, all previous saved pairing
profile will be erased.
Reset hardware
To reset the hardware, plug the charger and press Volume Up and Volume Down buttons
simultaneously. By doing this, the headset will be reset and power will be turn off.
Play music in stereo
To Start Play
Make sure your headset is connected in Advanced Audio profile. Press Multifunction button
once to play the music.
To Pause
Press Multifunction button to pause.
Jump to next track
Press the Forward button to forward to the next song.
Jump to previous track
Press the Backward button to backward to the previous song.
Fast forward *
Press and hold Forward button to perform fast forward.
Rewind *
Press and hold the Backward button to perform rewind.
* Fast forward and rewind functions might be unavailable on some cellular phones. Those
features are phone dependant.
Phone related functions
Answer a call
You will hear a ringing tone form earpiece when the phone received a call. Press the
Multifunction button once briefly to pick up the call. You will hear a brief beep when the call is
picked up.
End a call
To end an active call, press briefly the Multifunction button once briefly to end the call. You will
hear a high tone beep when the call is ended.
Reject a call
Press and hold the Multifunction button for more than 2 seconds to reject a call you dont want
to answer. You will hear a brief beep when the call is rejected.
Redialing the last dialed number
To redial the last dialed number, press and hold the Multifunction button. You will hear a brief
beep when the call is successfully dialed.
Voice dialing (Phone dependant)
Press and hold the Volume Down button for 3 seconds to activate voice dialing feature. You
will hear a brief beep. Now you can start to perform voice dialing.
Please notice that this function is phone dependant. Please refer to the phone user guide for
more information.
What the sound means
Power on / off Long high tone beep
Pairing mode Short low tone beeps
Connection lost / fail Long low tone beep
Connection established Short high tone beep
Sound volume over range
(too loud or reaching
mute)
Descending low tones
Incoming call 7 ascending tones
(30 sec) Battery low Long low tone, repeat every 30 seconds
What the light means (all on the right earpiece)
Turning on Flashing blue light 3 times rapidly
Power on however not
engaged
Flashing short (0.2 sec) blue lights every
second
Power on and engaged Flashing long (1 sec) blue lights every 2
seconds
Pairing mode Flashing red / blue lights
Battery low Flashing red lights
Turning off Solid red light, 3 seconds
Specifications
Dimensions (L x W x T) 140 x 166 x 53 mm
Weight 78g
Bluetooth Compliance Bluetooth 1.2 specification w/ handsfree
profile & headset profile 1.1, supports
Bluetooth 1.2 A2DP, AVRCP, HSP
Paired Devices Up to 8, one at a time
Security Encrypted link
Connection Point-to-point
Operating Temperature 0°C up to 55°C
Battery Power 3.7v / 500mAh Lithium-Polymer
Talk Time Up to 8 hours*
Standby Time Up to 200 hours*
CE , FCC, BQB, RoHS compliance
* Battery endurance might be shorter in high temperatures.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
