Psion Teklogix 8515 Vehicle-Mount Computer User Manual xv8515
8515 USER MANUAL
CE Marking .......................................xvii
R&TTE Directive 1999/5/EC ..............................xvii
FCC Information To Users...............................xviii
Emissions Information For Canada ...........................xix
Warnings To Users....................................xx
xvi Psion Teklogix 8515 Vehicle-Mount Computer User Manual
Chapter : Approvals And Safety Summary
Psion Teklogix 8515 Vehicle-Mount Computer User Manual xvii
CE Marking
When used in a residential, commercial or light industrial environment the product and its
approved UK and European peripherals fulfil all requirements for CE marking.
R&TTE Directive 1999/5/EC
This equipment complies with the essential requirements of EU Directive 1999/5/EC (Dec-
laration available: www.psionteklogix.com).
Cet équipement est conforme aux principales caractéristiques définies dans la Directive eu-
ropéenne RTTE 1999/5/CE. (Déclaration disponible sur le site: www.psionteklogix.com).
Die Geräte erfüllen die grundlegenden Anforderungen der RTTE-Richtlinie (1999/5/EG).
(Den Wortlaut der Richtlinie finden Sie unter: www.psionteklogix.com).
Questa apparecchiatura è conforme ai requisiti essenziali della Direttiva Europea R&TTE
1999/5/CE. (Dichiarazione disponibile sul sito: www.psionteklogix.com).
Este equipo cumple los requisitos principales de la Directiva 1995/5/CE de la UE, “Equipos
de Terminales de Radio y Telecomu-nicaciones”. (Declaración disponible en: www.psion-
teklogix.com).
Este equipamento cumpre os requisitos essenciais da Directiva 1999/5/CE do Parlamento
Europeu e do Conselho (Directiva RTT). (Declaração disponível no endereço: www.psion-
teklogix.com).
Ο εξοπλισμός αυτός πληροί τις βασικές απαιτήσεις της κοινοτικής οδηγίας EU R&TTE
1999/5/EΚ. (Η δήλωση συμμόρφωσης διατίθεται στη διεύθυνση: www.psiontek-
logix.com)
Deze apparatuur voldoet aan de noodzakelijke vereisten van EU-richtlijn betreffende radio-
apparatuur en telecommunicatie-eindappa-ratuur 199/5/EG. (verklaring beschikbaar:
www.psionteklogix.com).
Dette udstyr opfylder de Væsentlige krav i EU's direktiv 1999/5/EC om Radio- og teletermi-
naludstyr. (Erklæring findes på: www.psionteklogix.com).
Dette utstyret er i overensstemmelse med hovedkravene i R&TTE-direktivet (1999/5/EC)
fra EU. (Erklæring finnes på: www.psionteklogix.com).
Utrustningen uppfyller kraven för EU-direktivet 1999/5/EC om ansluten teleutrustning och
ömsesidigt erkännande av utrustningens överensstämmelse (R&TTE). (Förklaringen finns
att läsa på: www.psionteklogix.com).
Chapter : Approvals And Safety Summary
xviii Psion Teklogix 8515 Vehicle-Mount Computer User Manual
Tämä laite vastaa EU:n radio- ja telepäätelaitedirektiivin (EU R&TTE Directive 1999/5/EC)
vaatimuksia. (Julkilausuma nähtävillä osoitteessa: www.psionteklogix.com).
Psion Teklogix tímto prohlašuje, že 8515 Vehicle-Mount Computer je ve shodě se základ-
ními požadavky a dalšími příslušnými ustanoveními směrnice 1995/5/ES (NV č. 426/2000
Sb.) a Prohlášení o shodě je k dispozici na www.psionteklogix.com.
Toto zarízení lze provozovat v České republice na základě generální licence č. GL-
12/R/2000.
Psion Teklogix týmto vyhlasuje, že 8515 Vehicle-Mount Computer spĺňa základné požia-
davky a všetky príslušné ustanovenia Smernice 1995/5/ES (NV č. 443/2001 Z.z.) a Vyhláse-
nie o zhode je k dispozícii na www.psionteklogix.com.
Toto zariadenie je možné prevádzkovat’ v Slovenskej republike na základe Všeobecného
povolenia č. VPR-01/2001.
Use of the 802.11 8515 vehicle-mount in France:
Owing to French Government restrictions, the 802.11 8515 vehicle-mounts are limited to
indoor use. They may be used outdoors, on private property, only with prior authorization
from the French Ministry of Defense.
FCC Information To Users
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential installation. This equipment gen-
erates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
L
Chapter : Approvals And Safety Summary
Psion Teklogix 8515 Vehicle-Mount Computer User Manual xix
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsi-
ble for compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Some equipment in hospitals and aircraft are not shielded from radio frequency energy. Do
not use the 8515 onboard aircraft, or in hospitals, without first obtaining permission.
Do not use near pacemakers. The product may affect the operation of some medically im-
planted devices such as pacemakers, causing them to malfunction. Avoid placing your
product next to such devices. Keep a minimum distance of 20 cm between the device and
the product to reduce the risk of interference. If you have any reason to suspect that interfer-
ence is taking place, turn off the 8515 and contact your cardiologist for assistance.
Emissions Information For Canada
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations. When using the 802.11 radio option, to prevent radio interference,
this device is intended to be operated indoors and away from windows to provide maximum
shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licens-
ing.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada. En cas d’utilisation du module radio 802.11, afin d'éviter
toute interférence radio avec le service autorisé, l'appareil doit être utilisé à l'intérieur, tout
en tant éloigné de toute fenêtre afin de garantir le maximum de protection. Si cet équipement
(ou son antenne émettrice) est installé à l'extérieur, il est alors soumis à licence.
Important:FCC Radiation Exposure Statement
Note: In August 1996 the Federal Communications Commission (FCC) of the US
adopted an updated safety standard for human exposure to radio frequency
energy emitted by FCC regulated transmitters. The design of this product com-
plies with the FCC guidelines and those standards. To maintain compliance
with the FCC RF exposure guidelines, ensure the antenna is at least 20 cm
from your body when transmitting.
Chapter : Approvals And Safety Summary
xx Psion Teklogix 8515 Vehicle-Mount Computer User Manual
Warnings To Users
RF Exposure
Do Not Remove Covers Or Open Enclosures
To avoid injury, the equipment covers and enclosures should only be removed by qualified
service personnel. Do not operate the equipment without the covers and enclosures properly
installed.
Cautions
• Use of the Vehicle Mount Computer while charging the fork truck battery is prohibited.
• Use of additional wiring and attachments not recommended or sold by the manufacturer
may result in fire, electric shock or personal injury.
• If using an AC adaptor, use only the AC adaptor recommended by manufacturer.
• Do not operate the vehicle-mount computer with a damaged cord or plug. Replace
immediately.
• Make sure the cord is positioned so that it is not stepped on, tripped over or otherwise
subjected to damage or stress.
• An extension cord should not be used unless absolutely necessary. Use of an improper
extension cord could result in fire or electric shock.
• To reduce risk of electric shock, unplug the vehicle-mount computer from the DC source
before attempting any maintenance or cleaning.
Warning: To satisfy FCC RF exposure requirements for vehicle mount transmitting
devices, a separation distance of 20 centimetres should be maintained
between the antenna of this device and persons during device operation. To
ensure compliance, operations at closer than this distance is not recom-
mended.
Warning: Physically disconnect the 8515 from the vehicle battery during battery
charging (into AC outlet).
The conditions for co-location of Murata Bluetooth device and RA2040 in 8515 are as follows:
Murata Bluetooth device has to use antenna Antenova part number 3030A5645-01
And the RA2040 should use one of the antennas listed below:
1.�Radiall/Larsen model EPA-016�
2.�Psion Teklogix Case Integrated Antenna part number 1070545�
3.�Mobile Mark model IMAG5-2400��
Use of any other configuration requires its own FCC Approval
