Qiaohua D WIRELESS DOORBELL(TRANSMITTER) User Manual
SHENZHEN QIAOHUA INDUSTRIES LIMITED WIRELESS DOORBELL(TRANSMITTER) Users Manual
Qiaohua >
User Manual
D UserManual
QH-1085
Can be hung on the wal through the nail hole on the
back side.
2X1.5V AA batter operated
keep the code-matching button on the receiver pushed, and
push the button of the transmitter at the same time. Release
the code-matching button on the receiver as soon as the bell
rings, and then release the button of the transmitter
accordingly. In this case, the code matching of the doorbell
set is finished.
LED FLASHING INDICATOR
TUNES SELECTION SWITCH (16 tunes
selectalbe)
VOLUME SWITCH (low,medium
or high)
RING OPTION SWITCH:ring only,or LED
flash only,or combination of ring and flash
High Quality Loudspeaker
Can be put on the bable with the]
click-in base
Water proof push button with LED Indicator
Name plate
Wireless Digital Doorchimes
1.5V AA alkaline battery
Receiver
Load in battery and replace the cover
Battery
Battery
cover
Steel Nail
Wall
Hang on the wall
FCC NOTE
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received,including interference that may cause undesired
operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS OR
CHANGE
TO THIS EQUIPMENT. SUCH MODIFICATIONS OR CHANGE COULD
VOID AND
CHANGE ANNTENA WHICH THE MANUFACTURER PROVIDES.
IT IS THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
This equipment has been tested and found to comply with the limits for a
Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to
provide reasonable protection against harmful interference in a resi
dential installation.
This equipment generates, uses and can radiate radio frequenc y energy
and, if not
installed and used in accordance with the in structions, may cause harmful
interference
to radio communications. However, there is no guarantee that
interference will not
occur in a particular insta llation. If this equipment does cause harmful
interference to
radio or television reception, which can be determined by turning the
equipment off
and on, the user is encouraged to try to corr ect the interference by one or
more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the
receiver is connected.
-- Consult the dealer or an experien ced radio/TV technician for help.
To maintain compliance with FCC’s RF exposure guidelines, this
equipment should be
installed and operated with a minimum distance of 20cm between the
radiator and your
body.
:
Use double sided tape to fix the unit-
.to the desired place
Use a minus driver to carefully
open the top cover of the unit.
Set a battery into the battery compartment in
correct polarity direction.
Set the fastening tab of the top
cover into the slot of the base
Press here by hand to fix the top
cover onto the base.
