Quanta Computer C300 Clover Mini WiFi User Manual
Quanta Computer Inc Clover Mini WiFi
User Manual
Clover Mini
Feature Guide
v2
English
Deutsch
Español
Français
Italiano
Nederlands
Polski
#
#
#
#
#
#
#
1 Clover Mini Feature Guide English 2
We are continuously
improving our software.
To see the latest version
of this guide, visit
clover.com/setup.
In Europe, visit eu.clover.com/setup
This guide describes
Clover Mini’s hardware
and software features.
3 Clover Mini Feature Guide English 4
Clover Mini
Power adapter (US) Power adapter
(EU)
USB
SIM adapters
(only for 3G)
Hub
Receipt paper x2
Clover Mini is a powerful, exible,
easy-to-use payment terminal.
It can be used as a cash register
and more.
On your countertop, Clover Mini securely
accepts chip-and-pin and chip-and-signature
EMVcards, enables credit and debit card
transactions via swipe (MSR), insert (EMV
Chip), or tap (EMV Contactless).
Screwdriver
Ethernet
What’s included About Clover Mini
5 Clover Mini Feature Guide English 6
Paper roll release
pull tab
Reset button
Insert payment
Contactless
payment reader
Microphone
Audio jack
Speaker
Front facing
camera
Swipe payment
SIM card slot
Charging port
Switching Hub connector’s direction:
1 Turn Clover Mini over to access underside
2 Use provided screwdriver to loosen green screws
3 Switch connector to desired direction
4 Tighten green screws (be sure to not overtighten)
For more pairing options visit clover.com/setup.
Ethernet
(optional)
Type A USB
ports
Type B USB
port
Cash drawer
(optional)
Receipt door
HubClover Mini
Front
Back
Get to know Clover Mini
REVERSE SO
AUDIO AND
MIC EASIER
Green screws on Hub connector must always be tightened to
ensure reliable connection.
7 Clover Mini Feature Guide English 8
Video set up: clover.com/setup
Europe: eu.clover.com/setup
Set up your Clover Mini
(Only for 3G) Open SIM card tray by loosening green
screw with provided screwdriver. Pick the SIM card tray
size that matches with your SIM card. Place card on
tray and secure SIM door by tightening green screw.
Plug all accessories into Hub. Provided ethernet and
USB cords are optional.
Plug power adapter cable into Hub charger port .
Plug power brick into power source. Device will
automatically power on.
Payment Methods
Chip Card
Insert Card
Magnetic
Stripe Card
Swipe Card
Tap Card
34 5678 9012 3456
3
4 5678 9012 3456
1234 5678 9012 3456
1234 5678 9012 3456
1234 5678 9012 3456
1234 5678 9012 3456
1234
5678
9012
3456
1234
5678
9012
3456
1234 5678 9012 3456
1234 5678 9012 3456
1234 5678 9012 3456
1234 5678 9012 3456
1234 5678 9012 3456
1234 5678 9012 3456
Back
1
3
2
2
3
4
1
For more secure surface mounting instructions: ------- link link ----
9 Clover Mini Feature Guide English 10
Applications
Setup Wizard
Let’s Get Started
This is your guide for setting up Clover
Mobile. Your activation code is in your
welcome email.
Home
Use your Clover Home screen for quick
access to all your Clover apps. Employees
can also log in and out from here.
App Market
Custom Business Solutions
Browse and install apps to t your store’s
every need.
Taking Payments
Sale
Enter an amount and take a payment--it’s that simple.
Bar Tabs
Open tabs with a credit card, view open tabs, and close
them at the end of the night.
Auth Only
Auth a credit card, view open auths, and close them for a
nal amount.
Back of Store
Closeout
Review your sales by transaction type, card type, and
server. Close open tips and tabs and perform closeouts
at the end of the day for your device.
Tips
Enter tips from paper receipts quickly and easily.
Transactions
Your transaction history. Review recent transactions,
perform refunds, and reprint receipts.
11 Clover Mini Feature Guide English 12
Useful Resources
Web Access
Manage Your Apps
Some apps allow you to access them via
your web browser. We’ve put shortcuts to
these web pages at clover.com/home.
Please use Chrome, Safari, or Firefox.
Need Help?
Visit help.clover.com, use the Help app,
or call us anytime at the phone number
given in your welcome email.
PCI PTS security guidelines are
available in our Help app.
In Europe, visit eu.clover.com/home
13 Clover Mini Feature Guide English 14
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, (2)
This device must accept any interference received, including interference that
may cause undesired operation.
FCC Part 15 Class B-specic
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Warning
Changes or modications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
FCC exposure limit compliance statement (SAR statement)
This equipment complies with radio frequency (RF) exposure limits adopted by
the Federal Communications Commission for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20 cm
between the radiator & your body.
Industry Canada Compliance
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
The device could automatically discontinue transmission in case of absence of
information to transmit, or operational failure. Note that this is not intended to
prohibit transmission of control or signaling information or the use of repetitive
codes where required by the technology.
• The device for operation in the band 5150–5250 MHz is only for indoor
use to reduce the potential for harmful interference to co-channel mobile
satellite systems;
• The maximum antenna gain permitted for devices in the bands 5250–5350
MHz and 5470–5725 MHz shall comply with the e.i.r.p. limit; and
• The maximum antenna gain permitted for devices in the band 5725–5825
MHz shall comply with the e.i.r.p. limits specied for point-to-point and non
point-to-point operation as appropriate.
In addition, high-power radars are allocated as primary users (i.e. priority users)
of the bands 5250–5350 MHz and 5650–5850 MHz and that these radars could
cause interference and/or damage to LE-LAN devices.
This equipment complies with IC RSS-102 RF exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20 cm between the radiator & your body.
Cet équipement est conforme aux limites d’exposition aux rayonnements IC
établies pour un environnement non contrôlé. Cet équipement doit être installé
et utilisé avec un minimum de 20 cm de distance entre la source de rayonne-
ment et votre corps.
15 Clover Mini Feature Guide English 16v.4 draft 1
CE RF Exposure Compliance
This device meets the EU requirements (1999/519/EC) and the International
Commission on Non-Ionizing Radiation Protection (ICNIRP) on the limitation
of exposure of the general public to electromagnetic elds by way of health
protection.
This device is restricted to indoor use only when operating in the 5150 to 5350
MHz frequency range.
Waste Electrical and Electronic Equipment-WEEE
NOTE: This product is covered electronic equipment under the European Union’s
Waste from Electrical and Electronic Equipment (“WEEE”) Directive(2012/19/EU).
The WEEE Directive requires that covered equipment be collected and managed
separately from typical household waste in all EU member states. Please follow
the guidance of your local environmental authority or ask the shop where you
purchased the product for collection or recycling options.
Clover Mini Wi-Fi
Model: C300
FCC ID: HFS-C300
FCC information is available on the device under
Settings > About Mobile > FCC information.
EU Importer
OmniPay Ltd
Unit 9, Richview Oce Park, Clonskeagh, Dublin 14, Ireland
Clover Mini 3G
Model: C301
FCC ID: HFS-C301
