PX3VideoPresenceSolutionQuickStartGuide

PackageContents

Cameraunitx1

Keypadunitx1

5V/3Apoweradapterx1forcameraunit

12V/2Apoweradapterx1forkeypadunit

MicroHDMIcable(typeD)x1

HDMIcable(typeA)x1

VGAcablex1

LANcablex1

Quickstartguidex1

InstallingyourPX3

1.Installcameraunit:ConnectLANcable,microHDMIcable,andpoweradapterto

cameraunitasshowedinFigure1.

2.PlacethecameraunitontopoftheTVandadjustthestandtofixPX3asshowed

inFigure3.

3.TurnonTVandswitchtothededicatedHDMIoutputchannel.WhenPX3menu

isdisplayedonTV,continuetoinstallthekeypadunit.

4.Installkeypadunit:Placethekeypadunitonthemeetingtable.Connectpower

adaptertokeypadunitasshowedinFigure2.ConnectHDMIcableorVGA

cable(dependingonthenotebookinterface)tokeypadunitifyouwanttouse

projectormodeorscreensharing.

5.WhentheLCDdisplayonthekeypadunitshows“Welcome”,yourPX3isready

foruse.



Note1:Itisimportanttoinstallthecameraunitpriortothekeypadunitto

establishwirelessconnectionbetweenthesetwoparts.

Note2:Themaximumdistancerangebetweencameraunitandkeypadunitis5

meters.AnyfartherwilldegradethefunctionalityofPX3.



Figure1cameraunitinstallation



Figure2keypadunitinstallation



Figure3cameraunitstandinstallation

GettingtoknowyourPX3

ThephotosbelowshowthedetailsofPX3cameraunitandkeypadunit.



Figure4cameraunit



Figure5keypadunitview1



Figure6keypadunitview2

5V/3Aadapter

POWER LAN TV MINI USB

Power key

OTG port

HDMI IN

Router

12V/2Aadapter

POWER VGA HDMI

Notebook

12:34

-m

QuantaComputerInc.



Keypadfunction

KeyNameFunction

Up

Inmenupage,itisusedtomovecursorupward.

Inprevieworvideocallsession,itisusedtorotate

camera’sviewangleupward.

Down

Inmenupage,itisusedtomovecursordownward.

Inprevieworvideocallsession,itisusedtorotate

camera’sviewangledownward.



Left

Inmenupage,itisusedtomovemenusorcursor

leftward.

Inprevieworvideocallsession,itisusedtorotate

camera’sviewangleleftward.



Right

Inmenupage,itisusedtomovemenusorcursor

rightward.

Inprevieworvideocallsession,itisusedtorotate

camera’sviewanglerightward.



OKItisusedtoconfirmtheselectionorpopupsoft

keyboardineditingcolumns.

AudioCallMakeaudiocalltothedialednumbers.

VideoCallMakevideocalltothedialednumbers.

EndCallInacallsession,endavideooraudiocall.

Inmenupage,returntothelastpageorstatus.

ModeswitchEnableprojectororscreensharingmode

MenuEnable/disablemenu



VolumeUpTurnvolumeup

VolumeDownTurnvolumedown



ZoomInZoomincamera

ZoomOutZoomoutcamera

MuteEnable/disablemutefunction



Numerickeys

Inanymenupage,pressanynumerickeytopopup

dialpageandinputnumbers.

Intextinputfield,itisusedtoinputthenumbers.

0Indialpageortextinputfield,press“0”for2

secondsandthenreleasetoinput“+”.

*

Inanymenupage,press“*”topopupdialpageand

input“*”.

Intextinputfieldinput“*”.

#Inanymenupage,press“#”topopupdialpageand

input“#”.Intextinputfieldinput“#”.

UsingyourPX3

• Howtosetupthenetwork

GotoSettings→NetworkSettings.SelectDHCPtoassignIPaddress.Aftersetup,

press[Save]toexit.ForfixedIPusers,pleaseunclickDHCPandspecifyanIP/DNS

address.Intextinputfield,PressOkkeytoactivatethesoftkeyboard.Press

[Done]keyonsoftkeyboardtofinisheditingeachcolumn.Press[Save]keyon

menutoexit.ReturntothemainmenubypressingtheMenubuttononthe

keypadunit.ThenetworkconnectioniconontoprightofTVscreenshould

beon.Ifyouseeiconinstead,pleasereturntonetworksettingpageto

reconfirmthesetting.Ifnetworkconnectionstillfails,contactyourMISfor

furtherassistance.

Note:PleasecheckwithyourMISfortheIP/DNSaddressinformationrequired

inthenetworksettingpage.



• HowtosetuptheSIPaccount

GotoSettings→SIPAccountforsetup.YoucanfindtheSIPsettinglabelonthe

bottomofkeypadunit.PleaseinputalltheinformationonthatlabelintotheSIP

accountsettingpage.Intextinputcolumn,pressokkeytoactivatesoftkeyboard.

Press[Done]keyonsoftkeyboardtofinisheditingeachcolumn.Aftersetup,

press[Save]toexist.ReturntothemainmenubypressingtheMenubuttonon

thekeypadunit.ThehandseticonontoprightofTVscreenwillturnwhite

whentheSIPaccountisreadyforuse.Ifyouseeinstead,pleasereturntoSIP

Accountpagetore‐confirmthesetting.

• Howtomakeavideocallwithphonenumbers

Inputphonenumberswiththekeypadonthekeypadunitandthenpressthe

Videocallkey.

• Howtomakeavideocallfromcontactlist

GotoContactsanduseLeft/Rightkeyonthekeypadunittobrowscontactlist.

PressOkkeytoselectoneofthecontactsyouwishtocall.Inthecontactinfo

window,select[Videocall]andpressOkkeyonkeypadunittomakevideocall.

• Howtomakeanaudiocallwithphonenumbers

Inputphonenumberswiththekeypadonthekeypadunitandthenpressthe

Audiocallkey.

• Howtomakeanaudiocallfromcontactlist

GotoContactsanduseLeft/Rightkeyonthekeypadunittobrowscontactlist.

PressOkkeyselectoneofthecontactsyouwishtocall.Inthecontactinfo

window,select[Audiocall]andthenthenpressOkkeyonkeypadunittomake

audiocall.

• Howtoaddanewcontact

GotoContacts.PressMenukeyonthekeypadunit.Select[Addanewcontact].

UseUp/Downkeytogotothedesiredcolumnforediting.PressOkkeyto

activatesoftkeyboardforedit.Press[Done]keyonsoftkeyboardtofinishediting.

Press[Save]keytoexit.

• Howtouseprojectormode

InanypageofPX3TVscreen,connectyournotebookorvideoplayertoPX3

keypadunitwitheitheraHDMIcableorVGAcable.PressModeswitchkeyon

thekeypadunittouseprojectormode.

• Howtousescreensharing

Duringavideocall,connectyournotebooktoPX3keypadunitwitheithera

HDMIoraVGAcableandthenpressModeswitchkeyonthekeypadunitto

sharethecontents.

• Firmwareupdate

PX3willautomaticallydownloadnewversionsoftwareifavailableonserver.Go

toSettings→FirmwareUpdatetocheckifthereisnewversioninfodisplayedat

thebottomrightofthescreen.Select[Update]ifyouwishtoupdateyourPX3

withthenewsoftware.

• HowtoshutdownPX3

Pressthepowerbuttononthecameraunit(asshowedinFigure1)for3seconds.

TheTVscreenwilldisplay“Shuttingdown”messageindicatingPX3isshutting

down.

• HowtorestartPX3

Pressthepowerbuttononthecameraunit(asshowedinFigure1)for3seconds.

TheTVscreenwilldisplay“Shuttingdown”messageindicatingPX3isshutting

down.WhentheTVscreenisoff,presspowerkeyonthecameraunitagainto

restartPX3.WhenPX3menuisdisplayedonTV,presstheresetbuttonon

keypadunitasshowedinFigure5toresetkeypadunit.WhentheLCDdisplay

onkeypadunitshowed“Welcome”,yourPX3isreadyforuse.



Note: PleasealwaysshutdownandrestartPX3bypressingthepowerbutton.

ShuttingdownPX3byunpluggingpowercorddirectlymaydamagethesystem.



Troubleshooting

• Resetkeypadunit

Ifyoucannotsetuptheconnectionbetweenthecameraunitandkeypadunit,

pleasepresstheresetbuttononkeypadunitasshowedinFigure5.

• ResetPX3

Ifunexpectedsystemfailureoccurs,pleasepressthepowerbuttononcamera

unitasshowedinFigure1for10secondstoshutdownthesystem.Pressthe

powerbuttonagaintorestartthesystem.WhenPX3menuisdisplayedonTV,

presstheresetbuttononkeypadunitasshowedinFigure5toresetkeypadunit.

WhentheLCDdisplayonkeypadunitshows“Welcome”,yourPX3isreadyfor

use.


