IEEE 802.11 b/g WLAN module
Date: 2008/01/11
Version: 1.0
Chapter 1 Functional Description
This product provides the easiest way to wireless networking.
This User Manual contains instructions in the operation of this product.
Please keep this manual for future reference.
1.1 Features
z Includes Encore signal processing for Industry-leading receive
sensitivity and extended range:
․ -71 dBm at 54Mbps
z High level of integration with direct conversion radio architecture
z Flexible support for a variety of system bus interfaces including: usb,
minicard
z Programmable data rates of 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and
54 Mbps.
z Hardware-based IEEE 802.11i encryption/decryption engine, including
64-bit/128-bit WEP, TKIP, and AES
z IEEE802.1x support.
z Dynamic Power Management under driver control.
z WHQL-certified drivers for Windows® XP/Me/2000/98SE/98
operating systems.
z Wi-Fi® compliant.
1.2 Integrated Radio Transceiver
This Mini card module includes an integrated RF transceiver that has been
optimized for use in 2.4-GHz WLAN systems. It has been designed to
provide low-power, low-cost, and robust communications for applications
operating in the globally available 2.4-GHz unlicensed ISM band. With
an external transmit power amplifier, it develops full output power per
the IEEE802.11b/g Specification.
1.3 Receiver Path
This Mini card module has a wide dynamic range, direct conversion receiver.
It employs high-order on-chip channel filtering to ensure reliable operation
in the noisy 2.4-GHz ISM band. The excellent noise figure of the receiver
makes an external LNA unnecessary.
1.4 Transmitter Path
This Mini card module includes a linear transmitter capable of delivering up
to +15 dBm while meeting the IEEE802.11g specification. The output power
is adjustable in 1-dB steps, down to 0 dBm. Base-band data is
up-converted directly to the 2.4-GHz ISM band.
1.5 Calibration
This Mini card module enables the device to be used in high-volume
applications because calibration routines are not required during
manufacturing test. These calibration routines are performed periodically
in the course of normal radio operation.
Chapter 2 Installation Driver
2.1 Driver Features
IEEE 802.11b/g
Ad-Hoc / Infrastructure
WEP 64 / 128-bit
WPA-PSK / WPA2-PSK (by WZC / Funk Client)
WPA / WPA2 (by WZC / Func Client)
802.1x – TLS / 802.1x – PEAP (by WZC / Funk Client)
LEAP (by Funk Client)
WPA-TTLS (by Funk Client)
TKIP
AES
IEEE Power Save
2.2 Installing the driver
Step1. Install Realtek utility.
Step2. Update driver ‘rtl8187B.sys’
Product Specifications
Functional Specifications
Standard IEEE 802.11b; IEEE802.11g; IEEE 802.11i draft
Bus Interface USB
Data Rate 802.11g compliant: 11, 5.5, 2, 1 (DSSS/CCK); 6, 9, 12,
18, 24, 36, 48, 54 (OFDM) Mbps data rates
Media Access Control CSMA/CA with ACK
Radio Technology 802.11g: DSSS/CCK, OFDM
Modulation Techniques OFDM/CCK
Network Architecture Ad-hoc mode (Peer-to-Peer)
Infrastructure mode
Operating Channel 802.11 b & g
11: (Ch. 1-11) – N. America, Taiwan
14: (Ch 1-14) – Japan
13: (Ch. 1-13) – Europe ETSI
Frequency Range 802.11 b & g
2.412 ~ 2.462 GHz – N. America, Taiwan
2.412 ~ 2.484 GHz – Japan
2.412 ~ 2.472 GHz – Europe ETSI
Transmit Output Power 802.11b
16 dBm
802.11g
14 dBm
Receiver Sensitivity 802.11b 802.11g
11 Mbps: -84 dBm
5.5 Mbps: -86 dBm
2 Mbps: -87 dBm
1 Mbps: -88 dBm
54 Mbps: -68 dBm
48 Mbps: -70 dBm
36 Mbps: -73 dBm
24 Mbps: -76 dBm
18 Mbps: -80 dBm
12 Mbps: -82 dBm
9 Mbps: -83 dBm
6 Mbps: -84 dBm
Security WEP/WEP2, WPA/WPA2, TKIP
Operating Voltage 3.3V
OS supported Windows 200/XP, 64bit OS will be available in Q1, 2005
Antenna Type Dual antenna connector
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This device and its antenna(s) must not be co-located or operating in conjunction with
any other antenna or transmitter.
This device is intended only for OEM integrators under the following conditions:
OEM integrator is still responsible for testing their end product for any additional
compliance requirements required with this module installed (for example, digital device
emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example
certain laptop configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID can not be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating
the end product (including the transmitter) and obtaining a separate FCC authorization.
Without Co-located
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Taiwan 警語 :
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、
加大功率或變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，
並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
本模組於取得認證後將依規定於模組本體標示審合格籤，並要求平台上標示「本產品內含射頻模
組：ID 編號」
The OEM integrator has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user manual of the end product.
The user manual which is provided by OEM integrators for end users must include the following
information in a prominent location.
“To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter
must be installed to provide a separation distance of at least 20 cm from all persons and must not be
co-located or operating in conjunction with any other antenna or transmitter.
Label for end product must include “ Contains FCC ID:FCC ID: T5U-US105”
