1 USER’S MANUAL TH-518U IP Walkie-Talkie  4G LTE  SOS function  Sofeware off-line update Items in the Package
2 Carefully unpack the radio. We recommend that you identify the items listed in the following table before discarding the packing material. If any items are missing or have been damaged during shipment, file a claim with the carrier immediately. ACCESSORIES ITEM QUANTITY ANTENNA 1 CHARGER 1 ADAPTOR 1 Li-Ion BATTERY 1 BELT CLIP 1 USER’S MANUAL 1 Product Overview
3 Product controls No. Part Name No. Part Name No. Part Name 1 Antenna 7 Battery Contactor 13 Programming/Earphone jack 2 Speaker 8 SIM Card Slot 14 Micro USB charger jack 3 Indicator Light 9 Side Key 1（PF1） 4 Power and Volume Control 10 PTT 5 SOS Key 11 Side Key 2（PF2） 6 Microphone 12 Side Key 2（PF3） Basic Operation
4 N O T E Please check the following two items before using. a.Please make sure the SIM card has been activated and has started the data service. b.Please make sure the radio has been programmed withthe activated platform account and the correct APN information.If not,please contact local dealer for assistance. 1. Power on A. Insert the SIM card B. Pack the battery C. Turn the volume control clockwise to power on. 2. Power off Turn the volume control anticlockwise to power off. Caution：No removing battery directly to power off, otherwise it will lead to the data loss and the walkie-talkie damages. 3. Transmitting Press the PTT button to transmit, keep away from microphone 5cm at least. Exception & Talking Priority: If there is an advanced user starts to talk when you are transmitting, you will be forced to exit the transmitting mode. 4. Receiving The LED indicator lights blue, LCD screen displays the transmitter’s name when it is receiving. Menu Introduction
5 • Press MENU Key to enter menu • Press“▲”or“▼” Key to select items • Press BACK Key to back to the previous menu • Press MENU Key to confirm selecting Step 1 Step 2 Function Instruction Menu Choose Group Choose a group Choose Friend Shortcut to Private call (call to an active user which management platform listed from all groups) Choose User Shortcut to Private call from the working group(call to an active user which management platform listed from the working group) Network Mode Auto Select 3G according network signals automatically. 3G Only Only use 3G network. Information Group name Broadcast working group name User name Broadcast working user name Power remain Broadcast Power remain GPS Broadcast GPS positioning or positioned Version Broadcast software version Account Relogging Relog account instead of restarting radio when offline AFTERSALES SERVICE Warranty Period
6 Main Unit: Battery, Charger and Adapter: half a year from the data the radio is sold. (It’s invalid without the seal of seller.) Free Maintenance The seller provides free maintenance for the nature breakups in the warranty period. Paid Maintenance Under the following conditions, the seller will charge the maintenance fee:  When the maintenance is beyond the warranty period, the seller will charge reasonable maintenance free.  The breakups are caused by nature disasters.  The breakups are cause by customers.(Or their deliberate intentions.)  The breakups are caused by the mishandling or operation unpermitted.  The breakups are caused by using the nonstandard battery packs. Seller: Ser.No:Model: Date:
