Quixant PLC Branch QM-133BD 13.3 LCD Touch Monitor User Manual QIG for QM 151BD
Quixant PLC Taiwan Branch 13.3 LCD Touch Monitor QIG for QM 151BD
User Manual
QM-133BD User Manual © 2018 Quixant Plc Page 1 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
QM-133BD User’s Manual
Revision 1.1
QM-133BD User Manual © 2018 Quixant Plc Page 2 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
Revision History
Revision
Date
Description
By
1.0
2018/08/15
First Release
Jerry Tsai
1.1
2018/08/31
Adding wireless charging function
Jerry Tsai
QM-133BD User Manual © 2018 Quixant Plc Page 3 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
Contents
1. QM-133BD Introduction…………………………..……………………………………………….4
2. QM-133BD Specification…………………………..……………………………………………….6
3. Function Key & Input/Output…………………………………………………………………...7
4. QM-133BD Mounting Design……………………………………………..………………………8
5. QM-133BD OSD Menu…………………………………………………………..……………………9
6. Touch Function Installation……………………………………………..……………………...15
7. Wireless Charging function……………………………………………………………………...16
QM-133BD User Manual © 2018 Quixant Plc Page 4 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
1. QM-133BD Introduction
QM-133BD Includes 2 bonding types with touch panels, air and optical bonding. It’s beneficial
to slot machine designer to adapt, depending on customer request. Here’s showing drawing for
mechanical type and the photo of touch with smash hole.
1.1 QM-133BD Appearance
1.2 Safety Instruction
Strictly follow these Instructions for Use, please read these safety instructions carefully.
Remind to keep this User's Manual for later reference, and any use of the product requires
full understanding and strict observation of all portions of these instructions.
Repair of the device may also only be carried out by trained service personnel. Quixant Plc
recommends that a service contract be obtained with Quixant Service and that all repairs
also be carried out by them. Otherwise the correct functioning of the device may be
compromised.
QM-133BD User Manual © 2018 Quixant Plc Page 5 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
1.3 RF Instruction
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the authority to operate equipment.
This device and its antenna must not be co-
located or operating in conjunction with any other antenna or transmitter.
RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
QM-133BD User Manual © 2018 Quixant Plc Page 6 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
2. QM-133 Specification
LCD
Size
13.3”
Resolutions
1920x1080
Display Colors
16.7M Colors (8-bit RGB)
Brightness/Backlight
400 cd/m2 LED Backlight (270 cd/m2 Min.)
Wide View Angle
178°/178° degree (Typ.)
Contrast Ration
800:1 (600:1 Min.)
Touch
Touch Type
PCT Touch
Touch point
Multi touch points (up to 10 fingers)
Interface
USB Type B
OS Support
Win7 (HID supported)
System
I/O
1x DVI-D port, 1x DP port, 1x USB Type B, 1x Micro-
Fit (for wireless charger power input connector),
1x DC In
OSD
Menu, Left, Power, Right, Auto
Wireless Charger
15W, 1 x TX COIL (10W Min.)
Power
Input Voltage
DC In, 12 VDC ± 10%
Power Connector
ELR-02V
Power Consumption
45W Typical
Mechanical
Dimension (W x H x D)
693.4 x 249 x 42.8 mm
Mounting
N / A
Environment
Operating Temperature
0~ 50° C
Storage Temperature
-20 ~ 60° C (-4 ~ 140° F)
Humidity
20 ~ 85% @ 40° C, non-condensing
QM-133BD User Manual © 2018 Quixant Plc Page 7 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
Firmware
AD Board
V1.1
DDC/CI
Support
Touch
4561-00_test7 (for QM-133BD-OPDR03 only)
Certification
Regulation (meet
standard)
UL 60950-1, 2nd Edition, 2014-10-14
EMC (meet standard)
EN 55032:2012+AC:2013, Class B
3. Function Key & Input / Output
3.1 Function Key Introduction
QM-133BD Function keys includes 5 buttons, introducing each as below:
Number
Function
Description
1(Right)
Menu/Enter
Activates OSD main menu
2
Left (Up)
Left/Up arrow
3
Power
Power On/Off
4
Right (Down)
Right/Down arrow
5(Left)
Auto/Exit
Exit/ Return Key
LED
Blue : ON
Red : OFF
QM-133BD User Manual © 2018 Quixant Plc Page 8 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
QM-133BD User Manual © 2018 Quixant Plc Page 9 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
3.2 Input / Output
QM-133BD includes 2 connectors of display output, including DVI and DP. For touch function and
power enable, it complies with 1 connector of USB type B for touch connection, and 1 connector of
2 pin for +12V DC power in.
a. DVI & DP Signal Input
b. USB Type B & 2 Pins type Power Connector
Note: Power connector Pin definition:
Pin1
Pin2
+12V
GND
Pin 2: GND
DVI
DP
USB Type B
Power Connector
Pin 1: +12V
QM-133BD User Manual © 2018 Quixant Plc Page 10 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
4. QM-133BD Mounting Design
QM-133BD design several mounting features for customer to fit in slot machine, which provide a solid
stand onto slot machines. For details specification, please consult specification with Quixant.
QM-133BD User Manual © 2018 Quixant Plc Page 11 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
5. QM-133BD OSD Menu
5.1 OSD Menu
With advance display technology, QM-133BD OSD menu has 8 categories for user’s using. The OSD
menu contents “PICTURE, DISPLAY, COLOR, ADVANCE, INPUT, OTHER and INFORMATION”.
a. OSD Main Menu
QM-133BD User Manual © 2018 Quixant Plc Page 12 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
b. Adjusting and Saving
i. Choose a menu (for example: PICTURE), then Press “Menu” key to enter
ii. Choose an item (for example: Brightness), then Press “Menu” key to enter
QM-133BD User Manual © 2018 Quixant Plc Page 13 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
iii. Use “Left” / “Right” keys to adjust value, then Press “Menu” key to save
iv. The item of Brightness adjustment is completed.
QM-133BD User Manual © 2018 Quixant Plc Page 14 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
5.2 OSD Default Setting
QM-133BD resolution totally complies with 1920x 1080 input. The following table shows all the
adjustment menu’s items and settings.
Blue color: means this function is supportive
Green color: means this function is not supportive
Main Menu Sub-Menu Range Default Remark
Brightness 0~100 52
Contrast 0~100 51
Sharpness 0~4 2
Auto Adjustment when connecting with VGA
H Position 0~100 50
V Position 0~100 50
Pixel Clock when connecting with VGA
Phase when connecting with VGA
Gamma Off, 2.4, 2.2, 2.0, 1.8 Off
Color Temp Off, User, sRGB, 5800K, 6500K, 7500K, 9300K 6500K R=127, G=129, B=119
Color Effect Standard, Game, Movie, Photo, Vivid, User Standard
Color Demo Off Off
Color Format RGB, YUV RGB
PCM Native Native
Hue 0~100 51
Saturation 0~100 53
Aspect Ratio Full, Original, 5:4, 4:3, 16:9 Full
Overscan On, Off On
Overdrive On, Off Off
Energy Star Off Off
DDCCI On, Off On
Ultra Vivid Off, L, M, H L
Auto Select V
DP
DVI
Reset
Menu Time 0~60 30
OSD H Position 0~100 50
OSD V Position 0~100 50
Language English English
Transparency 0~7 2
Trotate On, Off Off
Input
Resolution
H-Freq
V-Freq
PCLK
HDCP Status
INFORMATION
DISPLAY
COLOR
ADVANCE
INPUT
OTHER
QM-133BD User Manual © 2018 Quixant Plc Page 15 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
6. Touch Function Installation
QM-133BD Touch function is designed to easily install. It complies with plug & play function, which allows
user to enable the touch function by only connecting QM-133BD and operation systems with USB type
B. Hence, the driver and utility is not required. If there’s any driver installation question with various
operating OS, please consult with Quixant.
QM-133BD User Manual © 2018 Quixant Plc Page 16 of 16
PRIVATE AND CONFIDENTIAL COVERED BY QUIXANT NON-DISCLOSURE AGREEMENT
While every effort has been made to ensure the accuracy of this document no liability of any kind can be accepted for any errors
or omissions that may be contained herein.
7. Wireless Charging Function
In the wireless charging area, you can charge the battery of your phone without connecting any cables
to your phone. The device is compliant with the Qi standard.
• All wireless devices may be susceptible to interference, which could affect performance.
• Only qualified personnel may install or repair the device.
Charge your phone
It’s simple: place your phone or another Qi-compatible device on the charging area to start
charging.
• Place your phone on the charging area. The indicator light is blinking while the phone charges.
• It's normal for the charging area and phone to get warm while charging.
• LED indicator is blue when standby.
Wireless
charging area
LED indicator
