User Manual

Quuppa QT1
Quuppa
Tag
Module
User
Guide
v.
DRAFT
7.12.2017
FCC ID: QE9QT1
IC: 10657A-QT1

Revision History
Version
number
Changes
Date
Person
2/10
Quuppa
QT1
User
Guide
Quuppa
Oy,
Keilaranta
1,
02150
Espoo,
Finland
©
2017
Quuppa
Oy

Contents
Introduction 4
Features 4
Using the Quuppa QT1 4
General Instructions 4
Integrating QT1 into a host device 5
QT1 Pinout 5
OEM Instructions 5
Product Information 5
Battery / power source 5
Technical Specifications 5
Care and Maintenance 6
Recycling and disposal 6
FCC and IC Regulatory Statements 7
Industry Canada Statement 7
FCC Statement 8
OEM Responsibilities 9
Japan (MIC) Regulatory 9
CE Regulatory 10
EU Declaration of Conformity 10
Bluetooth SIG Qualification 10
Copyright and other notice 10
3/10
Quuppa
QT1
User
Guide
Quuppa
Oy,
Keilaranta
1,
02150
Espoo,
Finland
©
2017
Quuppa
Oy

1. Introduction
Quuppa QT1 is a Tag Module designed to be integrated into your Tag mechanics and to be fully
compatible with the Quuppa Intelligent Locating System. Other parts of the Quuppa Intelligent Locating
System are Quuppa Locators and Quuppa Positioning Engine software. The Quuppa Intelligent Locating
System allows you to locate and track any objects equipped with Quuppa Tags in an environment
equipped with Quuppa Locators.
Read this guide carefully and watch the Quuppa Tutorial and Quuppa Academy videos before starting to
use the system. For the latest guides, additional information, and downloads related to your Quuppa
product, go to Quuppa Customer Portal at https://secure.quuppa.com/.
2. Features
3. Using the Quuppa QT1
3.1. General Instructions
Activate Quuppa QT1
Before using Quuppa QT1, you must activate it and configure it for your Quuppa Intelligent Locating
System.
1. Press the reset button for one second to activate Quuppa QT1
2. Within 30 seconds, send a configuration command to the Quuppa QT1. For details, see Quuppa
Tag configuration tutorial in the Quuppa Customer Portal.
Attaching QT1
Quuppa QT1 is not meant to be directly attached to a locatable object. It is meant to be installed into a
host product. Please follow the host product’s instruction regarding its installation to a locatable object.
IMPORTANT For optimal operation do not attach a product containing Quuppa QT1 onto a large metal
surface.
Reset to factory settings
To reset to factory settings, press and hold the reset button for 10 seconds.
4/10
Quuppa
QT1
User
Guide
Quuppa
Oy,
Keilaranta
1,
02150
Espoo,
Finland
©
2017
Quuppa
Oy

3.2. Integrating QT1 into a host device
3.3. QT1 Pinout
3.4. OEM Instructions
In order to have the same RF properties in the final product as in the QT1, a battery must not be placed
directly below the antenna.
4. Product Information
4.1. Battery / power source
Quuppa QT1 does not include a battery. [here instructions on what kind of power source to use]
WARNING RISK OF EXPLOSION IF INCORRECT POWER SOURCE IS USED. DISPOSE USED
BATTERIES ACCORDING TO LOCAL REGULATION.
4.2. Technical Specifications
Item
Description
Dimensions
26.5 mm × 24.5 mm × 1.6 mm
Weight
1.5g
Operating temp. range
−30°C ... +85°C
Storage temp. range
−30°C ... +85°C
Carrier frequencies
2401 2402 … 2408 2481 MHz
Power supply
External 3.0 V power supply (not included)
Certifications
Pending CE, FCC, IC, Japan and Korea
Functionality
Button, LED, Accelerometer, I/O pins for connecting simple
peripherals, compatible with Quuppa firmware library
5/10
Quuppa
QT1
User
Guide
Quuppa
Oy,
Keilaranta
1,
02150
Espoo,
Finland
©
2017
Quuppa
Oy

5. Care and Maintenance
6. Recycling and disposal
Always return your used electronic products, batteries, and packaging materials to dedicated collection
points. This way you help prevent uncontrolled waste disposal and promote the recycling of materials.
Disposal of Electrical and Electronic Equipment. This crossed-out wheeled-bin symbol
indicates that this product should not be treated as household waste. Instead hand it over
to the appropriate collection point for the recycling of electrical and electronic equipment in
accordance with local environmental regulations for waste disposal.
Ensuring proper product and battery disposal prevents potential negative consequences
for the environment and human health. For more information, contact your city, the place
of purchase, or support@quuppa.com.
6/10
Quuppa
QT1
User
Guide
Quuppa
Oy,
Keilaranta
1,
02150
Espoo,
Finland
©
2017
Quuppa
Oy

7. FCC and IC Regulatory Statements
Model
FCC ID
IC ID
QT1
QE9QT1
10657A-QT1
Item
Description
Radio
nRF52832 Bluetooth SoC by Nordic Semiconductor
Radio transmission
Bi-directional
Number of channels
81 channels (1 MHz) but only one at a time
Carrier frequencies
2401 2402 … 2408 2481 MHz
Modulation
GFSK
Max Output Power
2.5 mW
Antenna
Integrated printed IFA antenna with 0dBi gain
7.1. Industry Canada Statement
This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause
undesired operation.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type
and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio
interference to other users, the antenna type and its gain should be chosen so that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
Le présent appareil est conforme aux CNR d’ ISED applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
1. le dispositif ne doit pas produire de brouillage préjudiciable, et
2. ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer
un fonctionnement indésirable.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec
une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada.
Dans le but de réduire les risques de brouillage radio électrique à l'intention des autres utilisateurs, il faut
choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne
dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.
7/10
Quuppa
QT1
User
Guide
Quuppa
Oy,
Keilaranta
1,
02150
Espoo,
Finland
©
2017
Quuppa
Oy

7.2. FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference; and
2. This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
WARNING Changes or modifications not expressly approved by Quuppa could void the user's
authority to operate the equipment.
This portable transmitter with its antenna complies with FCC/IC RF exposure limits for general population
/ uncontrolled exposure.
8/10
Quuppa
QT1
User
Guide
Quuppa
Oy,
Keilaranta
1,
02150
Espoo,
Finland
©
2017
Quuppa
Oy

7.3. OEM Responsibilities
WARNING The OEM must ensure that FCC and IC labelling requirements are met. This includes a
clearly visible label on the outside of the OEM enclosure specifying the appropriate
Quuppa Oy FCC and IC identifiers for this product.
Contains
FCC
ID:
QE9QT1
Contains
IC:
10657A-QT1
or
Contains
Transmitter
Module
FCC
ID:
QE9QT1
Contains
Transmitter
Module
IC:
10657A-QT1
If the size of the end product is larger than 8x10cm, then the following FCC part 15.19
statement has to also be available visibly on outside of device:
The enclosed device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) This
device must accept any interference received, including interference that may cause
undesired
operation.
The Quuppa Tag Module (QT1) has been certified for integration into products only by OEM integrators
under the following conditions:
1. The antenna(s) must be installed such that a minimum separation distance of 5mm is maintained
between the radiator (antenna) and all persons at all times.
2. The transmitter module must not be co-located or operating in conjunction with any other antenna
or transmitter.
As long as the two conditions above are met, further transmitter testing will not be required. However, the
OEM integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed (for example, digital device emissions, PC peripheral requirements,
etc.).
IMPORTANT In the event that these conditions cannot be met (for certain configurations or co-location
with another transmitter), then the FCC and Industry Canada authorizations are no longer
considered valid and the FCC ID and IC Certification Number cannot be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating
the end product (including the transmitter) and obtaining a separate FCC and Industry
Canada authorization.
8. Japan (MIC) Regulatory
9/10
Quuppa
QT1
User
Guide
Quuppa
Oy,
Keilaranta
1,
02150
Espoo,
Finland
©
2017
Quuppa
Oy

9. CE Regulatory
10. EU Declaration of Conformity
A copy of the Declaration of Conformity can be found at: www.quuppa.com/support.
11. Bluetooth SIG Qualification
12. Copyright and other notice
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form
without the prior written permission of Quuppa is prohibited. Quuppa operates a policy of continuous
development. Quuppa reserves the right to make changes and improvements to any of the products
described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES
SHALL QUUPPA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES
HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY
APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS DOCUMENT. QUUPPA RESERVES THE RIGHT TO REVISE THIS DOCUMENT
OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
The availability of particular products may vary by region. Please check with your Quuppa dealer for
details. This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
