RM-1 GETTING STARTED GUIDE
Safety: For safety information related to your battery charger terminal, see the information included
with that product.
Product Support: For Technical Support or for help not available in this manual, contact the RGIS
Service Depot @ 1-800-874-4841.
FCC Notice (United States): This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a commercial
installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
CE Notice (European Notice): The Conformité Européne symbol found on this product
indicates compliance to the EMC Directive and the Low Voltage Directive of the European
Union. This means that the product meets the following technical standards: EN 55022
(CISPR22), EN 55024 (CISPR 24) (IEC 61000 4-2, 4-3, 4-3, 4-5, 4-6, 4-8, 4-11), EN 61000
3-2 (IEC 61000 3-2), EN 61000 3-3 (IEC 61000 3-3), EN60950 (IEC 60950 3rd Ed; 1999;
2000).
Battery Notice: The sealed batteries that work with this product comply with all applicable shipping
regulations as prescribed by industry and legal standards.
GETTING STARTED
GUIDE
RGIS RM-1 Inventory
Device
Rev 1.0
632-190001-00
RM-1 GETTING STARTED GUIDE
Warnings and Precautions
WARNING: The RM-1 is designed with adequate safeguards to protect
users from shock and other hazards when used as specified within this
documentation. If users use the RM-1 in a manner not specified by this
document, the protection provided by the RM-1 may be impaired.
Please read the documentation before using the RM-1.
WARNING: The RM-1 device is designed to function with the Tyco
battery pack number 610-180007-00 ONLY.
WARNING: The battery used in this device may present a risk of fire or
chemical burn if mistreated. DO NOT disassemble, heat above 60c,
crush or puncture, short circuit external contacts, or dispose in fire or
water.
Class 2
Laser
Products
• Complies with 21CFR1040.10 and 1040.11 except for
deviations pursuant to Laser Notice No. 50, dated July 26,
2001.
• EN60825-1:1994+A1:2002+A2:2001
• IEC60825-1: 2001-08
• Caution: Use of controls, adjustments or performance of
procedures other than those specified herein may result in
hazardous laser light exposure.
• Class 2 laser scanners use a low power, visible light diode.
As with any very bright light source, such as the sun, the
user should avoid staring directly into the light beam.
Momentary exposure to a Class 2 laser is not known to be
harmful.
• Complies with FDA standards for laser products except for
deviations under Laser Notice 50, dated 7/26/2001.
Battery
Operation
The battery voltage should be in the range 2.5V to 4.2V when
inserted into the RM-1.
User
Serviceability
Do not disassemble the RM-1 device. It contains no user-
serviceable parts. Please return to the factory for repair.
Liquids Avoid spilling liquids on the RM-1. Liquids spilled onto the RM-
1 could short circuit it. If liquids are accidentally spilled, let the
RM-1 dry before use. Rated IPX0.
Battery
Disposal
Dispose of used batteries according to the manufacturer's
instructions.
Battery
Charger
Consult the manufacturer’s operational manual for battery
charger operational procedures.
RM-1 GETTING STARTED GUIDE
Shipping Contents
■ RM-1 Inventory Device. Model Number: 610-190040
■ Rechargeable Li-ion battery packs. Part Number: 610-180007-00
■ RGIS RM-1 Getting Started Guide
Specifications
RM-1 Model: 610-1900040
Battery Model: 610-180007-00
Nominal Input Voltage Rating: 3.7 V dc nominal
Operating Ambient Temperature: 0°C to +30°C (+32°F to +90°F)
Storage Temperature: -20°C to +70°C (-4°F to +158°F)
RM-1 Operation
1. Insert battery into the RM-1, ensuring the battery pack is latched properly.
2. Press the black power button on the side of the device. The RM-1 device will
power on and display the RM-1 Inventory Menu.
3. To put the RM-1 into sleep mode, the user should “tap” the power button.
The user can return the RM-1 unit into operational mode by tapping the
power button again.
4. The user can cold boot the RM-1 unit by holding down the power button for
approximately 8 seconds.
5. It is recommended that users put the RM-1 unit in sleep mode by tapping the power
button prior to removing the battery pack.
6. Users should consult the RGIS RM-1 Users Guide for more detailed operational
instructions.
7. Users should consult the RM-1 Battery Charger Guide for detailed operational notes
for battery charging.
Lanyard Ring
Custom Serial Port
Power Button
Scanner
Trigger
SD Slot
USB
Connector
Audio
Vibration
Connector
Scanner Trigger
Laser Scanner
RM-1 GETTING STARTED GUIDE
Repair Instructions
If the RM-1 Audit device is malfunctioning or technical issues arise, contact the RGIS
Service Depot. Do not attempt to disassemble the RM-1 Audit unit without contacting the
RGIS Service Depot.
RGIS Inventory Specialist
Attention: Service Depot
2000 East Taylor Road
Auburn Hills, MI 48308-1504
USA
Contact Number:
1-800-874-4841
Strap
Brackets
Battery
Latch
Battery
Compartment
Battery
Compartment
Scanner Beam
RM-1 GETTING STARTED GUIDE
