RMR Management Group MINI Mini User Manual
RMR Management Group Mini
User Manual
Brochure –Mini
1.Starting up ：power-on and turn on back-up battery switch on rear of unit，Voice prompt“Starting
up”， GSM module proceed to searching signal, Voice prompt “Access network successful”，
WCDMA indicate lamp flash 4 seconds, off 1 second ,signal is good：
WCDMA indicate lamp flash 1 second, off 4 seconds or always off, bad signal or no signal
2.Learning code & deleting code：
（1）Access learning code：①Long press R/T + SOS at the same time，Voice prompt：
“Access to learning code, please trigger your device”.,WCDMA indicated lamp fast
flash，RUN indicate lamp off ；
②trigger your device by press the test button of detector or the Arm button
and emergency button of remote controller at the same time，if mini panel receive
the signal from detector successful ,you can see RUN indicate lamp flash
momentarily, Voice prompt
“No.1——10 smoke detector Coding successful”
“No.1——10 panic sensor Coding successful”
“No.1——10 water sensor Coding successful”
“No.1——10 carbon monoxide detector Coding successful”.
You can finish all the device in one breath, mini panel will auto exit learning
code if didn’t receive any new signal within 40S ,voice prompt
“Exit learning code”，
③RUN indicate lamp will quickly flash when mini panel receive signal which
already exist, voice prompt“DI-DI-DI”，
（2）Delete all of codes：Long press SOS button under learning code condition, three indicate lamps will
fast flash about 3s ,delete all of codes. Voice prompt “Codes has been cleared”，return
to learning code condition.
（3）Exit learning code ：1.press R/T momentarily /didn’t receive any new signal within 40S，voice
prompt“Exit learning code”，
2.Long press R/T，voice prompt “smoke detector No.1 ……，panic sensor
No.2……，carbon monoxide detector No.1…… Exit learning code ”.Press R/T to end
of voice prompt
3.Set up report number：Editor SMS content：“TEL********”to mini panel SIM. voice prompt：
“set up number successful”
TEL1*******（SMS Report number）
TEL2******* (Two way voice number)
TEL3******* (SMS &Two way voice)
4. Delete report number:TEL1NULL
TEL2NULL
TEL3NULL
5.Operation：
Two way vo ice alarm: momentarily press SOS until you hear “DI-DI-DI”, mini panel will dialing two way
voice report number, siren mute
Release: momentarily press R/T
Manual Test: Long press R/T about 2s, voice prompts Test, send test SMS.
Repeat dialing: mini panel will auto repeat dial two way voice report number 8 times when no answer.
Call back: if two ways voice report number miss the call from mini panel after 8 times, it can call back to
mini panel within 10 minute. It will auto pick up, and you can start two way voice after hear “Monitoring
Center calling”
Note: Only accept call back from two way voice report number within 10 min. (after 8 times repeat dialing)
.SMS Code Description
Smoke：111
/IMEI/E/111/01/010(010-019)
Emergence：101
/IMEI/E/101/01/030(030-039) （Panic button）
/IMEI/E/101/00/000（SOS on mini）
Water: 154
/IMEI/E/154/01/040(040-049)
CO：162
/IMEI/E/162/01/020(020-029)
Lost contact; 102----Every 12h
Detector lost contact：/IMEI/E/102/01/010(smoke:010-019、CO:020-029、Water:040-049)
Recover from lost contact：102
Mini panel recover from lost contact：/IMEI/R/102/00/000
Detector recover from lost contact：/IMEI/R/102/01/010(010-019、020-029、040-049)
Low battery of detector：384---(Smoke≤2.60V,CO≤2.8，DIDIDI warning tone every one minute)
/IMEI/E/384/01/010(010-019、020-029、040-049)
Recover from Low battery of detector：384
/IMEI/R/384/01/010(010-019、020-029、040-049)
Mini panel low battery：302 ---- ≤3.60V（AC lamp fast flash）
/IMEI/E/302/00/000
Mini panel Recover from low battery ：302
/IMEI/R/302/00/000
Mini panel AC failure：301----Test for 1 min
/IMEI/E/301/00/000
Mini panel recover from AC failure：301---- /IMEI/R/301/00/000
Add Detector：531
/IMEI/E/531/01/010(010-019、020-029、030-039、040-049)
Delete Detector：532
/IMEI/E/532/01/000
Release alarm：406
/IMEI/E/406/00/000
Manual test;601（R/T）
/IMEI/E/601/00/000
Self-test：602(Every week)
/IMEI/E/602/00/000
Detector Test：601
/IMEI/E/601/01/010(010-019、020-029、040-049)
Change report number ：412
/IMEI/E/412/00/000
Detector anti-tamper：383
/IMEI/E/383/01/010(010-019、020-029、040-049)
Mini panel WCDMA signal failure (can’t send SMS within 10 minute)：354
/IMEI/E/354/01/001
6. Parameter
Standby current: 40mA
Alarming:160-210mA。
Charge battery voltage：4.10-4.13V
Battery voltage:4.01V，Standby current40-60mA，enter into sleep mode after 3 minute current 20-30mA，
Low battery ≤3.6V(AC indicate lamp will flash)
7.Pin setting：
1 2 3 4
1 C C C C
2 ○ C C C
3 C ○ C C
4 ○ ○ C C
5 C C ○ C
6 ○ C ○ C
7 C ○ ○ C
8 ○ ○ ○ C
9 C C C ○
10 ○ C C ○
Code
Zone
number
FCCWarning
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
This equnpment should be installed and operated with minimum distance 20cm between the
radiator &you body.
