Radio Shack 120496 Universal FM Transmitter User Manual
RadioShack Corporation Universal FM Transmitter
User Manual
What’s Included
FM Transmitter 1/8” to 3/32” Adapter
12VDC Plug User’s Guide
RF Emissions
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the headset is connected.
• Consult your local RadioShack store or an experienced radio/TV technician
for help.
If you cannot eliminate the interference, the FCC requires that you stop using your
equipment. Changes or modifications not expressly approved by RadioShack
may cause interference and void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Limited Warranty
RadioShack warrants this product against defects in materials and workmanship
under normal use by the original purchaser for one (1) year after the date of
purchase from a RadioShack-owned store or an authorized RadioShack
franchisee or dealer. RADIOSHACK MAKES NO OTHER EXPRESS WARRANTIES.
This warranty does not cover: (a) damage or failure caused by or attributable to
abuse, misuse, failure to follow instructions, improper installation or maintenance,
alteration, accident, Acts of God (such as floods or lightning), or excess voltage
or current; (b) improper or incorrectly performed repairs by persons who are
not a RadioShack Authorized Service Facility; (c) consumables such as fuses
or batteries; (d) ordinary wear and tear or cosmetic damage; (e) transportation,
shipping or insurance costs; (f) costs of product removal, installation, set-up service,
adjustment or reinstallation; and (g) claims by persons other than the original
purchaser.
Should a problem occur that is covered by this warranty, take the product and the
RadioShack sales receipt as proof of purchase date to any RadioShack store
in the U.S. RadioShack will, at its option, unless otherwise provided by law: (a)
repair the product without charge for parts and labor; (b) replace the product with
the same or a comparable product; or (c) refund the purchase price. All replaced
parts and products, and products on which a refund is made, become the property
of RadioShack. New or reconditioned parts and products may be used in the
performance of warranty service. Repaired or replaced parts and products are
warranted for the remainder of the original warranty period. You will be charged
for repair or replacement of the product made after the expiration of the warranty
period.
RADIOSHACK EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDITIONS NOT
STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE
IMPOSED BY LAW, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY
AND, IF APPLICABLE, THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR
PURPOSE, SHALL EXPIRE ON THE EXPIRATION OF THE STATED WARRANTY
PERIOD.
EXCEPT AS DESCRIBED ABOVE, RADIOSHACK SHALL HAVE NO LIABILITY
OR RESPONSIBILITY TO THE PURCHASER OF THE PRODUCT OR ANY OTHER
PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE
CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT
OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT
LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE AND ANY LOSS
OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT AND ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RADIOSHACK HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some States do not allow limitations on how long an implied warranty lasts or
the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This warranty gives you specific legal
rights, and you may also have other rights which vary from State to State. You may
contact RadioShack at:
RadioShack Customer Relations
300 RadioShack Circle, Fort Worth, TX 76102 04/08
Thank you for purchasing your Wireless FM Transmitter. Please read this
user’s guide before installing, setting up and using your new product.
www.radioshack.com
©2008. RadioShack Corporation. All rights reserved.
Gigaware is a trademark and RadioShack is a registered trademark used by RadioShack Corporation.
09A08
12-496
Printed in China
P/N: AO0314AAA1
Universal Wireless FM Transmitter 12-496
Installing Optional Batteries
You can power your transmitter with
2 AAA batteries (not
supplied). Remove the
battery cover and insert
the batteries according to
polarity (+ or –) markings.
Protect the environment by recycling used electronics.
Go to www.ecyclingcentral.com to find a recycle location near you.
Low frequency: 88.1, 88.3, 88.7, 88.9 MHz
High frequency: 107.1, 107.3, 107.7, 107.9 MHz
Performance Tips
• Connect your transmitter to your car and audio
device before operating your vehicle.
• Bass boost modes may cause distorted sound.
• The FCC regulates and limits your transmitter’s
strength.
• FM channels may experience environmental
interference or be occupied by local radio stations.
Try using a different frequency.
• Certain vehicles may experience more difficulty
receiving clear signals because of the location of the
vehicle’s antenna, metallic film on the windows, or
other external factors.
HIGH-LOW BAND
frequency switch
Step 1
Connect the 12VDC plug into your car’s power
port. Conect the other end to the 5V DC jack
on the transmitter.
Step 3
Turn on your transmitter and audio device.
Select one frequency on the transmitter
and set the radio in the car to the same
frequency. Use the volume controls on your
radio or audio device to adjust the volume. For
best performance, select a frequency that is
not occupied by a strong local FM station.
Step 2
Insert the 3.5mm stereo plug into the 3.5mm
headphone jack of any portable audio device. If
your audio device (LG, Sanyo, Motorola mobile
cell) comes with 2.5mm headphone jack,
connect the 3.5mm plug to the supplied 1/8”
to 3/32” adapter first.
Battery Notes
• Dispose of batteries promptly and properly. Do not
burn or bury them.
• Use only fresh batteries of the required size and
type.
• Do not mix old and new batteries, different types of
batteries (standard, alkaline, or rechargeable), or
rechargeable batteries of different capacities.
• If you do not plan to use the wireless transmitter for
a long period of time, remove the battery. Batteries
can leak chemicals that can damage electronic
parts.
Recycle Rechargeable
Batteries
Placing rechargeable batteries in the trash can be
harmful to the environment. Instead, recycle old
rechargeable batteries at your local RadioShack
store free of charge. RadioShack participates in the
RBRC© battery recycling program, and is committed
to preserving the environment and conserving natural
resources. Call 1-800-THE-SHACK (1-800-843-7422)
for more information.
5V DC jack
1/8” to 3/32” Adapter
1/8” (3.5 mm) stereo plug
2.5 mm plug
G
Turn on/off the
transmitter. The blue LED lights
when powers on.
Connect to the
3.5 mm plug.
12-496.082008.indd 1 08/27/2008 14:37:52
