Radwin RW3XMOD 3.6GHz Radio Module for Base and Fixed User Manual Manual

Radwin Ltd. 3.6GHz Radio Module for Base and Fixed Manual

Manual

AP0136450
RF Module Operating in the 3.4-3.7 GHz bands
REFERENCE GUIDE
Regulatory Compliance
FCC/IC - Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules and IC RSS standards. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RADWIN Ltd. is not responsible for any radio or communication interference caused by
using other than specified or recommended cables and battery or by unauthorized changes
or modifications to this equipment. Changes or modifications or modifications not expressly
approved by the manufacturer could void the user's authority to operate the equipment.
It is the responsibility of the installer to ensure that when using the outdoor
antenna kits, only those antennas certified with the product are used. The use
of any antenna other than those certified with the product is expressly
forbidden by FCC rules 47 CFR part 15.204 and IC RSS standards.
Il est de la responsabilité de l'installateur de s'assurer que lorsque vous
utilisez les kits d'antennes extérieures, seules les antennes certifiés avec le
produit sont utilisés. L'utilisation d'une antenne autre que ceux qui sont
certifiés avec le produit est expressément interdite par la réglementation FCC
partie 47 CFR 15.204 et IC normes RSS.
Outdoor units and antennas should be installed ONLY by experienced
installation professionals who are familiar with local building and safety codes
and, wherever applicable, are licensed by the appropriate government
regulatory authorities. Failure to do so may void the product warranty and
may expose the end user or the service provider to legal and financial
Caution liabilities. Resellers or distributors of this equipment are not liable for injury,
damage or violation of regulations associated with the installation of outdoor
units or antennas. The installer should configure the output power level of
antennas according to country regulations and antenna type.
AP0136450 Reference Guide i
Warning
Avertissement
Les unités extérieures et les antennes doivent être installés que par des
professionnels expérimentés d'installation qui sont familiers avec les normes
locales et les codes de sécurité et, si applicable, sont agréées par les autorités
gouvernementales de réglementation compétents. Ne pas le faire peut annuler
la garantie du produit et peuvent exposer l'utilisateur final ou le fournisseur de
services d'obligations juridiques et financiers.
Revendeurs ou distributeurs de ces équipements ne sont pas responsables des
blessures, des dommages ou violation des règlements liés à l'installation des
unités extérieures ou des antennes. L'installateur doit configurer le niveau de
puissance de sortie des antennes conformément aux réglementations
nationales et le type d'antenne.
This equipment should be installed and operated with a minimum distance of
57cm between
the radiator and your body when operating in the 3.65-3.7
GHz band and 110cm when operating in the 3.45-3.65 GHz band.
Warning
Cet équipement doit être installé et utilisé à une distance minimale de 57cm
entre le radiateur et votre corps lors d'opérations dans la bande de 3.65 à 3.7
GHz et 110cm quand fonctionnant dans la bande de 3,45 à 3,65 GHz
The module is granted to operate under FCC/IC certification in the 3.65-
3.70 GHz band and under IC certification in the 3.45-.365 GHz band only.
Warning
This device complies with Part 15 of the FCC rules and with Industry Canada license-
exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Cet appareil est conforme la norme d'Industrie Canada exempts de licence RSS (s). Son
fonctionnement est soumis aux deux conditions suivantes:
1. Cet appareil ne peut pas causer d'interférences, et
2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent
causer un mauvais fonctionnement de l'appareil.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numrique de la classe B est conforme la norme NMB-003 du Canada
AP0136450 Reference Guide ii
Prudence
Overview
The AP0136450 is an RF module operating in the 3.4 – 3.7 GHz frequency bands. It is a TDD
OFDM radio supporting 5 MHz, 10 MHz, 20 MHz and 40 MHz channel bandwidths.
The RF module cannot work as a stand-alone device. It can operate and be controlled only
when attached to a digital main board and altogether assembled in an enclosure suitable for
outdoor use. The assembly of the RF module attached to the digital main board is hereafter
referred to as ‘ODU’. The ODU in its various outdoor enclosures is manufactured by
RADWIN.
The RF module is certified as a limited modular approval type with the FCC ID:
Q3KRW3XMOD and IC: 5100A-RW3XMOD.
Condition of Use
The AP0136450 RF module is a proprietary radio interface and can only be connected to
digital boards manufactured by RADWIN. The ODU resides in an outdoor enclosure also
manufactured and assembled by RADWIN or its subcontractors. The RF module is not for
sale to the general public.
FCC rules and IC Regulation Restrictions
The ODU firmware is factory programmed to operate under the FCC rules and Industry
Canada regulation restrictions. The firmware is locked and inaccessible by any third party. As
a result of the above the user interface allows both the installer and the user to control the
ODU only within the boundaries of the regional restrictions.
Antennas
The AP0136450 RF module is certified with various antenna types covering both Point-to-
Point and Point-to-Multipoint systems. They are all dual pole cross polarized antennas and
they are the only ones to be used with the RF module.
AP0136450 Reference Guide 1
Certified Antennas
Following is the list of antennas certified for use with the AP0136450 RF module:
Antenna Type
Manufacturer
Model Number
Antenna Max
Gain (dBi)
Dual Pole Dish
RADWIN Ltd.
RW-9722-3338
26
External Flat Panel Dual Pole
RADWIN Ltd.
RW-9612-3338
22
Integrated Flat Panel Dual Pole
RADWIN Ltd.
MT0099910
22
Integrated Flat Panel Dual Pole
RADWIN Ltd.
MT0140780
17
Integrated Flat Panel Dual Pole
RADWIN Ltd.
AM0140450
14
Sector Dual Pole 120 Deg
RADWIN Ltd.
RW-9061-3003
15
Sector Dual Pole 90 Deg
RADWIN Ltd.
RW-9061-3001
14
Maximum Output Power
3650 – 3700 MHz band - FCC/IC
The maximum output power can be set as follows, when operating in the 3.7 GHz band,
under FCC and IC regulations.
Antenna
gain
(dBi)
CBW
(MHz)
Max output
power
(dBm)
EIRP
limit
(dBm)
14
5
23
37
10/20/40
25
39
15
5
22
37
10/20/40
25
40
17
5
20
37
10
23
40
20/40
25
42
22
5
15
37
10
18
40
20
21
43
40
24
46
24
5
13
37
10
16
40
20
19
43
40
22
46
26
5
11
37
10
14
40
20
17
43
40
20
46
AP0136450 Reference Guide 2
Declared channel bandwidths and frequency ranges
3450 – 3650 MHz band - IC
The maximum output power can be set as follows, when operating in the 3.5 GHz band,
under IC regulation.
The antenna giving the highest EIRP value is a Dual Pole 26 dBi Dish.
The declared maximum output power is 25 ± 2 dBm.
AP0136450 Reference Guide 3
Channel BW
[MHz]
Center Freq. Range
[MHz]
5
3652.5 – 3697.5
10
3655 – 3695
20
3660 – 3690
40
3670 - 3680
Channel BW
[MHz]
Center Freq. Range
[MHz]
5
3452.5 – 3697.5
10
3655 - 3695
20
3660 - 3690
40
3670 - 3680
