Realtek Semiconductor RTL8821AE 802.11a/b/g/n/ac RTL8821AE Combo Module User Manual Y700 15 17 Spec LLW EN

Realtek Semiconductor Corp. 802.11a/b/g/n/ac RTL8821AE Combo Module Y700 15 17 Spec LLW EN

User manual_2 revised

1
Lenovo limited warranty
L505-0010-02 08/2011
This Lenovo Limited Warranty consists of the following parts:
Part 1 - General Terms
Part 2 - Country-specific Terms
Part 3 - Warranty Service Information
The terms of Part 2 replace or modify terms of Part 1 as specified for a
particular country.
Part 1 - General Terms - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
This Lenovo Limited Warranty applies only to Lenovo hardware products
you purchased for your own use and not for resale.
This Lenovo Limited Warranty is available in other languages at
www.lenovo.com/warranty.
What this Warranty Covers
Lenovo warrants that each Lenovo hardware product that you purchase is free
from defects in materials and workmanship under normal use during the
warranty period. The warranty period for the product starts on the original
date of purchase as shown on your sales receipt or invoice or as may be
otherwise specified by Lenovo. The warranty period and type of warranty
service that apply to your product are as specified in "
Part 3 - Warranty Service
Information
" below. This warranty only applies to products in the country or
region of purchase.
THIS WARRANTY IS YOUR EXCLUSIVE WARRANTY AND REPLACES ALL
OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. AS SOME STATES OR JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OF EXPRESS OR IMPLIED WARRANTIES, THE ABOVE
EXCLUSION MAY NOT APPLY TO YOU. IN THAT EVENT, SUCH
WARRANTIES APPLY ONLY TO THE EXTENT AND FOR SUCH DURATION
AS REQUIRED BY LAW AND ARE LIMITED IN DURATION TO THE
WARRANTY PERIOD. AS SOME STATES OR JURISDICTIONS DO NOT
ALLOW LIMITATIONS ON THE DURATION OF AN IMPLIED WARRANTY,
THE ABOVE LIMITATION ON DURATION MAY NOT APPLY TO YOU.
en-US
Rev. AA00
2
Lenovo limited warranty
How to Obtain Warranty Service
If the product does not function as warranted during the warranty period, you
may obtain warranty service by contacting Lenovo or a Lenovo approved
Service Provider. A list of approved Service Providers and their telephone
numbers is available at: www.lenovo.com/support/phone.
Warranty service may not be available in all locations and may differ from
location to location. Charges may apply outside a Service Provider's normal
service area. Contact a local Service Provider for information specific to your
location.
Customer Responsibilities for Warranty Service
Before warranty service is provided, you must take the following steps:
• follow the service request procedures specified by the Service Provider
• backup or secure all programs and data contained in the product
• provide the Service Provider with all system keys or passwords
• provide the Service Provider with sufficient, free, and safe access to your
facilities to perform service
• remove all data, including confidential information, proprietary
information and personal information, from the product or, if you are
unable to remove any such information, modify the information to prevent
its access by another party or so that it is not personal data under
applicable law. The Service Provider shall not be responsible for the loss or
disclosure of any data, including confidential information, proprietary
information, or personal information, on a product returned or accessed
for warranty service
• remove all features, parts, options, alterations, and attachments not
covered by the warranty
• ensure that the product or part is free of any legal restrictions that prevent
its replacement
• if you are not the owner of a product or part, obtain authorization from the
owner for the Service Provider to provide warranty service
What Your Service Provider Will Do to Correct Problems
When you contact a Service Provider, you must follow the specified problem
determination and resolution procedures.
Lenovo limited warranty
3
The Service Provider will attempt to diagnose and resolve your problem by
telephone, e-mail or remote assistance. The Service Provider may direct you to
download and install designated software updates.
Some problems may be resolved with a replacement part that you install
yourself called a "Customer Replaceable Unit" or "CRU." If so, the Service
Provider will ship the CRU to you for you to install.
If your problem cannot be resolved over the telephone; through the application
of software updates or the installation of a CRU, the Service Provider will
arrange for service under the type of warranty service designated for the
product under "
Part 3 - Warranty Service Information
" below.
If the Service Provider determines that it is unable to repair your product, the
Service Provider will replace it with one that is at least functionally equivalent.
If the Service Provider determines that it is unable to either repair or replace
your product, your sole remedy under this Limited Warranty is to return the
product to your place of purchase or to Lenovo for a refund of your purchase
price.
Replacement Products and Parts
When warranty service involves the replacement of a product or part, the
replaced product or part becomes Lenovo's property and the replacement
product or part becomes your property. Only unaltered Lenovo products and
parts are eligible for replacement. The replacement product or part provided by
Lenovo may not be new, but it will be in good working order and at least
functionally equivalent to the original product or part. The replacement
product or part shall be warranted for the balance of the period remaining on
the original product.
Use of Personal Contact Information
If you obtain service under this warranty, you authorize Lenovo to store, use
and process information about your warranty service and your contact
information, including name, phone numbers, address, and e-mail address.
Lenovo may use this information to perform service under this warranty.
We may contact you to inquire about your satisfaction with our warranty
service or to notify you about any product recalls or safety issues.
4
Lenovo limited warranty
In accomplishing these purposes, you authorize Lenovo to transfer your
information to any country where we do business and to provide it to entities
acting on our behalf. We may also disclose it where required by law. Lenovo's
privacy policy is available at www.lenovo.com/.
What this Warranty Does not Cover
This warranty does not cover the following:
• uninterrupted or error-free operation of a product
• loss of, or damage to, your data by a product
• any software programs, whether provided with the product or installed
subsequently
• failure or damage resulting from misuse, abuse, accident, modification,
unsuitable physical or operating environment, natural disasters, power
surges, improper maintenance, or use not in accordance with product
information materials
• damage caused by a non-authorized service provider
• failure of, or damage caused by, any third party products, including those
that Lenovo may provide or integrate into the Lenovo product at your
request
• any technical or other support, such as assistance with “how-to” questions
and those regarding product set-up and installation
• products or parts with an altered identification label or from which the
identification label has been removed
Limitation of Liability
Lenovo is responsible for loss or damage to your product only while it is in the
Service Provider's possession or in transit, if the Service Provider is responsible
for the transportation.
Neither Lenovo nor the Service Provider is responsible for loss or disclosure of
any data, including confidential information, proprietary information, or
personal information, contained in a product.
UNDER NO CIRCUMSTANCES, AND NOTWITHSTANDING THE
FAILURE OF ESSENTIAL PURPOSE OF ANY REMEDY SET FORTH
HEREIN, SHALL LENOVO, ITS AFFILIATES, SUPPLIERS, RESELLERS,
OR SERVICE PROVIDERS BE LIABLE FOR ANY OF THE FOLLOWING
EVEN IF INFORMED OF THEIR POSSIBILITY AND REGARDLESS OF
Lenovo limited warranty
5
WHETHER THE CLAIM IS BASED IN CONTRACT, WARRANTY,
NEGLIGENCE, STRICT LIABILITY OR OTHER THEORY OF LIABILITY:
1) THIRD PARTY CLAIMS AGAINST YOU FOR DAMAGES; 2) LOSS,
DAMAGE OR DISCLOSURE OF YOUR DATA; 3) SPECIAL, INCIDENTAL,
PUNITIVE, INDIRECT OR CONSEQUENTIAL DAMAGES, INCLUDING
BUT NOT LIMITED TO LOST PROFITS, BUSINESS REVENUE,
GOODWILL OR ANTICIPATED SAVINGS. IN NO CASE SHALL THE
TOTAL LIABILITY OF LENOVO, ITS AFFILIATESS, SUPPLIERS,
RESELLERS OR SERVICE PROVIDERS FOR DAMAGES FROM ANY
CAUSE EXCEED THE AMOUNT OF ACTUAL DIRECT DAMAGES, NOT
TO EXCEED THE AMOUNT PAID FOR THE PRODUCT.
THE FOREGOING LIMITATIONS DO NOT APPLY TO DAMAGES FOR
BODILY INJURY (INCLUDING DEATH), DAMAGE TO REAL PROPERTY
OR DAMAGE TO TANGIBLE PERSONAL PROPERTY FOR WHICH
LENOVO IS LIABLE UNDER LAW.
AS SOME STATES OR JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU.
Your Other Rights
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
HAVE OTHER RIGHTS ACCORDING TO THE APPLICABLE LAWS OF
YOUR STATE OR JURISDICTION. YOU MAY ALSO HAVE OTHER
RIGHTS UNDER A WRITTEN AGREEMENT WITH LENOVO. NOTHING
IN THIS WARRANTY AFFECTS STATUTORY RIGHTS, INCLUDING
RIGHTS OF CONSUMERS UNDER LAWS OR REGULATIONS
GOVERNING THE SALE OF CONSUMER GOODS THAT CANNOT BE
WAIVED OR LIMITED BY CONTRACT.
6
Lenovo limited warranty
Part 2 - Country-specific Terms - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Australia
"Lenovo" means Lenovo (Australia & New Zealand) Pty Limited
ABN 70 112 394 411. Address: Level 10, North Tower, 1-5 Railway Street,
Chatswood, NSW, 2067. Telephone: +61 2 8003 8200.
Email: lensyd_au@lenovo.com
The following replaces the same section in Part 1:
What this Warranty Covers:
Lenovo warrants that each hardware product that you purchase is free from
defects in materials and workmanship under normal use and conditions during
the warranty period. If the product fails due to a covered defect during the
warranty period, Lenovo will provide you a remedy under this Limited Warranty.
The warranty period for the product starts on the original date of purchase
specified on your sales receipt or invoice unless Lenovo informs you otherwise in
writing. The warranty period and type of warranty service that apply to your
product are set forth below in
Part 3 - Warranty Service Information
.
THE BENEFITS GIVEN BY THIS WARRANTY ARE IN ADDITION TO
YOUR RIGHTS AND REMEDIES AT LAW, INCLUDING THOSE UNDER
THE AUSTRALIAN CONSUMER LAW.
The following replaces the same section in Part 1:
Replacement Products and Parts:
When warranty service involves the replacement of a product or part, the
replaced product or part becomes Lenovo's property and the replacement
product or part becomes your property. Only unaltered Lenovo products and
parts are eligible for replacement. The replacement product or part provided by
Lenovo may not be new, but it will be in good working order and at least
functionally equivalent to the original product or part. The replacement product
or part shall be warranted for the balance of the period remaining on the original
product. Products and parts presented for repair may be replaced by refurbished
products or parts of the same type rather than being repaired. Refurbished parts
may be used to repair the product; and repair of the product may result in loss of
data, if the product is capable of retaining user-generated data.
Lenovo limited warranty
7
The following is added to the same section in Part 1:
Use of Personal Contact Information:
Lenovo will not be able to perform our service under this warranty if you
refuse to provide your information or do not wish us to transfer your
information to our agent or contractor. You have the right to access your
personal contact information and request correction of any errors in it pursuant
to the Privacy Act 1988 by contacting Lenovo.
The following replaces the same section in Part 1:
Limitation of Liability:
Lenovo is responsible for loss or damage to your product only while it is in the
Service Provider's possession or in transit, if the Service Provider is responsible for the
transportation.
Neither Lenovo nor the Service Provider is responsible for loss or disclosure of
any data, including confidential information, proprietary information, or
personal information, contained in a product.
TO THE EXTENT PERMITTED BY LAW, UNDER NO CIRCUMSTANCES AND
NOTWITHSTANDING THE FAILURE OF ESSENTIAL PURPOSE OF ANY
REMEDY SET FORTH HEREIN, SHALL LENOVO, ITS AFFILIATES,
SUPPLIERS, RESELLERS, OR SERVICE PROVIDERS BE LIABLE FOR ANY OF
THE FOLLOWING EVEN IF INFORMED OF THEIR POSSIBILITY AND
REGARDLESS OF WHETHER THE CLAIM IS BASED IN CONTRACT,
WARRANTY, NEGLIGENCE, STRICT LIABILITY OR OTHER THEORY OF
LIABILITY: 1) THIRD PARTY CLAIMS AGAINST YOU FOR DAMAGES;
2) LOSS, DAMAGE OR DISCLOSURE OF YOUR DATA; 3) SPECIAL,
INCIDENTAL, PUNITIVE, INDIRECT OR CONSEQUENTIAL DAMAGES,
INCLUDING BUT NOT LIMITED TO LOST PROFITS, BUSINESS REVENUE,
GOODWILL OR ANTICIPATED SAVINGS. IN NO CASE SHALL THE TOTAL
LIABILITY OF LENOVO, ITS AFFILIATESS, SUPPLIERS, RESELLERS OR
SERVICE PROVIDERS FOR DAMAGES FROM ANY CAUSE EXCEED THE
AMOUNT OF ACTUAL DIRECT DAMAGES, NOT TO EXCEED THE
AMOUNT PAID FOR THE PRODUCT.
8
Lenovo limited warranty
THE FOREGOING LIMITATIONS DO NOT APPLY TO DAMAGES FOR
BODILY INJURY (INCLUDING DEATH), DAMAGE TO REAL PROPERTY
OR DAMAGE TO TANGIBLE PERSONAL PROPERTY FOR WHICH
LENOVO IS LIABLE UNDER LAW.
The following replaces the same section in Part 1:
Your Other Rights:
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU ALSO
HAVE OTHER RIGHTS AT LAW, INCLUDING UNDER THE
AUSTRALIAN CONSUMER LAW. NOTHING IN THIS WARRANTY
AFFECTS STATUTORY RIGHTS OR RIGHTS AT LAW, INCLUDING
RIGHTS THAT CANNOT BE WAIVED OR LIMITED BY CONTRACT.
For example, our products come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a replacement or
refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the products repaired
or replaced if the products fail to be of acceptable quality and the failure does
not amount to a major failure.
New Zealand
The following is added to the same section in Part 1:
Use of Personal Information:
Lenovo will not be able to perform our service under this warranty if you refuse
to provide your information or do not wish us to transfer your information to
our agent or contractor. You have the right to access your personal information
and request correction of any errors in it pursuant to the Privacy Act 1993 by
contacting Lenovo (Australia & New Zealand) Pty Limited ABN 70 112 394 411.
Address: Level 10, North Tower, 1-5 Railway Street, Chatswood, NSW, 2067.
Telephone: 61 2 8003 8200. Email: lensyd_au@lenovo.com
Lenovo limited warranty
9
Bangladesh, Cambodia, India, Indonesia, Nepal, Philippines, Vietnam and
Sri Lanka
The following is added to Part 1:
Dispute Resolution
Disputes arising out of or in connection with this warranty shall be finally
settled by arbitration held in Singapore. This warranty shall be governed,
construed and enforced in accordance with the laws of Singapore, without
regard to conflict of laws. If you acquired the product in
India
, disputes arising
out of or in connection with this warranty shall be finally settled by arbitration
held in Bangalore, India. Arbitration in Singapore shall be held in accordance
with the Arbitration Rules of Singapore International Arbitration Center
("SIAC Rules") then in effect. Arbitration in India shall be held in accordance
with the laws of India then in effect. The arbitration award shall be final and
binding on the parties without appeal. Any award shall be in writing and set
forth the findings of fact and the conclusions of law. All arbitration
proceedings, including all documents presented in such proceedings shall be
conducted in the English language. The English language version of this
warranty prevails over any other language version in such proceedings.
European Economic Area (EEA)
The following is added to Part 1:
Customers in the EEA may contact Lenovo at the following address: EMEA
Service Organisation, Lenovo (International) B.V., Floor 2, Einsteinova
21, 851 01, Bratislava, Slovakia. Service under this warranty for Lenovo hardware
products purchased in EEA countries may be obtained in any EEA country in
which the product has been announced and made available by Lenovo.
Russia
The following is added to Part 1:
Product Service Life
The product service life is four (4) years from the original date of purchase.
10
Lenovo limited warranty
Part 3 - Warranty Service Information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Product or
machine
type
Country or region of
purchase Warranty period
Types of
warranty
service
Notebook:
80NY
80NV
80NW
80Q0
Taiwan, Korea
parts and labor - 1 year
battery pack - 1 year
3, 4
China (Hong Kong S.A.R.), China
(Macau S.A.R.), India, Indonesia,
Malaysia, Thailand, Philippines,
Vietnam, Sri Lanka, Singapore 1, 4
Argentina, Colombia, Peru,
Venezuela, Bolivia, Uruguay,
Chile, Paraguay, Ecuador, Mexico
Austria, France, Iceland, Israel,
Ireland, Italy, Latvia, Lithuania,
the United Kingdom, Canada,
United States of America 1, 3
Japan, Australia, New Zealand
Moldova
4
South Africa, Kenya, Nigeria,
Uganda, Morocco, Tunisia,
Algeria, Cote d'ivoire, Angola,
UAE, Bahrain, Jordan, Kuwait,
Lebanon, Qatar, Botswana,
Oman, Egypt, Pakistan,
Cameroon, Democratic Republic
of Congo, Djibouti, Ethiopia,
Ghana, Iraq, Malta, Mauritania,
Mauritius, Mozambique,
Namibia, Rwanda, Senegal,
Seychelles, Tanzania, Yemen,
Zambia, Zimbabwe
Brazil 5
Germany, Switzerland
parts and labor - 1 or
2years
battery pack - 1 year
1, 3
Lenovo limited warranty
11
If required, the Service Provider will provide repair or exchange service
depending on the type of warranty service specified for your product and
the available service. Scheduling of service will depend upon the time of
your call, parts availability, and other factors.
Notebook:
80NY
80NV
80NW
80Q0
Denmark, Estonia, Finland,
Norway, Portugal, Spain,
Sweden, Belgium, Luxembourg,
Netherlands
parts and labor -
2years
battery pack - 1 year
1, 3
Czech Republic, Slovakia,
Hungary, Romania, Bulgaria
Russia, Ukraine, the Republic of
Kazakhstan, Belarus, Azerbaijan,
Georgia, Armenia, Uzbekistan 4
Saudi Arabia
Bosnia-Herzegovina, Croatia,
Cyprus, Greece, Macedonia,
Slovenia, Serbia/Montenegro,
Albania, Poland
1, 4
Turkey
parts and labor -
2years
battery pack - 2 years
1, 4
(Continued)
Product or
machine
type
Country or region of
purchase Warranty period
Types of
warranty
service
12
Lenovo limited warranty
Types of Warranty Service
1
Customer Replaceable Unit (“CRU”) Service
Under CRU Service, the Service Provider will ship CRUs to you at its cost for
installation by you. CRU information and replacement instructions are
shipped with your product and are available from Lenovo at any time upon
request. CRUs that are easily installed by you are called "Self-service CRUs".
"Optional-service CRUs "are CRUs that may require some technical skill and
tools. Installation of Self-service CRUs is your responsibility. You may
request that a Service Provider install Optional-service CRUs under one of
the other types of warranty service designated for your product. An optional
service offering may be available for purchase from a Service Provider or
Lenovo under which Self-service CRUs would be installed for you. You may
find a list of CRUs and their designation in the publication that was shipped
with your product or at www.lenovo.com/CRUs. The requirement to return
a defective CRU, if any, will be specified in the instructions shipped with a
replacement CRU. When return is required: 1) return instructions, a prepaid
return shipping label, and a container will be included with the replacement
CRU; and 2) you may be charged for the replacement CRU if the Service
Provider does not receive the defective CRU from you within thirty (30) days
of your receipt of the replacement CRU.
2
On-site Service
Under On-Site Service, a Service Provider will either repair or exchange the
product at your location. You must provide a suitable working area to allow
disassembly and reassembly of the product. Some repairs may need to be
completed at a service center. If so, the Service Provider will send the product
to the service center at its expense.
3
Courier or Depot Service
Under Courier or Depot Service, your product will be repaired or exchanged
at a designated service center, with shipping at the expense of the Service
Provider. You are responsible for disconnecting the product and packing it in
a shipping container provided to you to return your product to a designated
service center. A courier will pick up your product and deliver it to the
designated service center. The service center will return the product to you at
its expense.
Lenovo limited warranty
13
4
Customer Carry-In Service
Under Customer Carry-In Service, your product will be repaired or
exchanged after you deliver it to a designated service center at your risk and
expense. After the product has been repaired or exchanged, it will be made
available to you for collection. If you fail to collect the product, the Service
Provider may dispose of the product as it sees fit, with no liability to you.
5
Mail-In Service
Under Mail-In Service, your product will be repaired or exchanged at a
designated service center after you deliver it at your risk and expense. After
the product has been repaired or exchanged, it will be returned to you at
Lenovo's risk and expense, unless the Service Provider specifies otherwise.
6
Customer Two-Way Mail-In Service
Under Customer Two-Way Mail-In Service, your product will be repaired or
exchanged after you deliver it to a designated service center at your risk and
expense. After the product has been repaired or exchanged, it will be made
available to you for return shipping at your risk and expense. If you fail to
arrange return shipment, the Service Provider may dispose of the product as
it sees fit, with no liability to you.
7
Product Exchange Service
Under Product Exchange Service, Lenovo will ship a replacement product to
your location. You are responsible for its installation and verification of its
operation. The replacement product becomes your property in exchange for
the failed product, which becomes the property of Lenovo. You must pack
the failed product in the shipping carton in which you received the
replacement product and return it to Lenovo. Transportation charges, both
ways, shall be at Lenovo’s expense. If you fail to use the carton in which the
replacement product was received, you may be responsible for any damage
to the failed product occurring during shipment. You may be charged for the
replacement product if Lenovo does not receive the failed product within
thirty (30) days of your receipt of the replacement product.
14
Product specific Notices
The notices in this appendix are specific to the product with the given MT
number. Notices that are common for most Lenovo products are included in
“Appendix A. Notices” of the Lenovo
Safety and General Information Guide
.
Energy star information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
ENERGY STAR
®
is a joint program of the U.S. Environmental Protection
Agency and the U.S. Department of Energy aimed at saving money and
protecting the environment through energy efficient products and practices.
Lenovo
®
is proud to offer our customers products with an ENERGY STAR
compliant designation. Lenovo computers of the following machine types, if
the ENERGY STAR mark is affixed, have been designed and tested to conform
to the ENERGY STAR program requirements for computers.
•80NY
•80NV
•80NW
•80Q0
By using ENERGY STAR compliant products and taking advantage of the
power-management features of your computer, you reduce the consumption of
electricity. Reduced electrical consumption contributes to potential financial
savings, a cleaner environment, and the reduction of greenhouse gas emissions.
For more information about ENERGY STAR, visit
http://www.energystar.gov.
Lenovo encourages you to make efficient use of energy an integral part of your
day-to-day operations. To help in this endeavor, Lenovo has preset the
following power-management features to take effect when your computer has
been inactive for a specified duration:
Product specific Notices
15
To awaken your computer from Sleep mode, press any key on your keyboard.
For more information about these settings, refer to your Windows Help and
Support information system.
Table 1. ENERGY STAR power-management features
Windows® 10
Power plan: Balanced (plugged in)
• Turn off the display:
After 10 minutes
• Put the computer to sleep:
After 25 minutes
• Advanced power settings:
- Turn off hard disks:
After 20 minutes
待确认
16
Product specific Notices
Electronic emissions notices - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
The following information refers to Lenovo ideapad Y700-15ACZ/Y700-15ISK/
Y700 Touch-15ISK/Y700-17ISK, machine type 80NY/80NV/80NW/80Q0.
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee the interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult an authorized dealer or service representative for help.
Properly shielded and grounded cables and connectors must be used in order
to meet FCC emission limits. Proper cables and connectors are available from
Lenovo authorized dealers. Lenovo is not responsible for any radio or
television interference caused by using other than recommended cables or
connectors or by unauthorized changes or modifications to this equipment.
Unauthorized changes or modifications could void the user’s authority to
operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
guidelines. The maximum SAR value reported is 0.492w/kg
Product specific Notices
17
Responsible party:
Lenovo (United States) Incorporated
1009 Think Place - Building One
Morrisville, NC 27560
U.S.A.
Telephone: (919) 294-5900
German Class B Compliance Statement
Deutschsprachiger EU Hinweis:
Hinweis für Geräte der Klasse B EU-Richtlinie zur Elektromagnetischen
Verträglichkeit
Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie
2004/108/EG (früher 89/336/EWG) zur Angleichung der Rechtsvorschriften
über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und
hält die Grenzwerte der EN 55022 Klasse B ein.
Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern
beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur
von der Lenovo empfohlene Kabel angeschlossen werden. Lenovo übernimmt
keine Verantwortung für die Einhaltung der Schutzanforderungen, wenn das
Produkt ohne Zustimmung der Lenovo verändert bzw. wenn
Erweiterungskomponenten von Fremdherstellern ohne Empfehlung der
Lenovo gesteckt/eingebaut werden.
This device has been tested and meets the FCC RF exposure
18
Product specific Notices
Deutschland:
Einhaltung des Gesetzes über die elektromagnetische Verträglichkeit von
Betriebsmittein
Dieses Produkt entspricht dem “Gesetz über die elektromagnetische
Verträglichkeit von Betriebsmitteln” EMVG (früher “Gesetz über die
elektromagnetische Verträglichkeit von Geräten”). Dies ist die Umsetzung der
EU-Richtlinie 2004/108/EG (früher 89/336/EWG) in der Bundesrepublik
Deutschland.
Zulassungsbescheinigung laut dem Deutschen Gesetz über die
elektromagnetische Verträglichkeit von Betriebsmitteln, EMVG vom 20.
Juli 2007 (früher Gesetz über die elektromagnetische Verträglichkeit von
Geräten), bzw. der EMV EG Richtlinie 2004/108/EC (früher 89/336/EWG), für
Geräte der Klasse B.
Dieses Gerät ist berechtigt, in Übereinstimmung mit dem Deutschen EMVG
das EG-Konformitätszeichen - CE - zu führen. Verantwortlich für die
Konformitätserklärung nach Paragraf 5 des EMVG ist die Lenovo
(Deutschland) GmbH, Gropiusplatz 10, D-70563 Stuttgart.
Informationen in Hinsicht EMVG Paragraf 4 Abs. (1) 4:
Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022
Klasse B.
Product specific Notices
19
European Union Compliance Statement Class B Compliance
European Union - Compliance to the Electromagnetic Compatibility
Directive
This product is in conformity with the protection requirements of EU Council
Directive 2004/108/EC on the approximation of the laws of the Member States
relating to electromagnetic compatibility. Lenovo cannot accept responsibility
for any failure to satisfy the protection requirements resulting from a non-
recommended modification of the product, including the installation of option
cards from other manufacturers.
This product has been tested and found to comply with the limits for Class B
Information Technology Equipment according to European Standard EN 55022.
The limits for Class B equipment were derived for typical residential
environments to provide reasonable protection against interference with licensed
communication devices.
EU Contact Address: Lenovo, Einsteinova 21, 851 01 Bratislava, Slovakia
20
Specifications
Model Name: Lenovo ideapad Y700-15ACZ/Y700-15ISK/
Y700 Touch-15ISK/Y700-17ISK
Machine Type: 80NY/80NV/80NW/80Q0
Note:
The following specifications may contain technical inaccuracies or typographical errors.
Lenovo reserves the right to improve and/or change specifications at any time without notice.
Y700-15ACZ/Y700-15ISK/
Y700 Touch-15ISK Y700-17ISK
Form Factor
Dimensions Appr. 387 mm × 277 mm ×
25.95 mm
Appr. 423 mm × 305 mm ×
27.95 mm
Weight Appr. 2.6 kg with 4 cell battery Appr. 3.5 kg with 4 cell battery
LCD size 15.6-inch LED 17.3-inch LED
Processor
View the system properties of your computer. You can do this as follows: Open the
Control Panel, and then select System and Security System.
Memory
Type and
speed DDR4-2133 MHz
Maximum
supported
capacity
16 GB
Slots SODIMM × 2
Hard disk drive
Form factor 2.5-inch
Interface SATA III
NGFF (SSD)
Display
Display
resolution
(LCD)
1,920 × 1,080 pixels FHD /
3,840 × 2,160 pixels UHD 1,920 × 1,080 pixels FHD
LCD backlight LED
Specifications
21
I/O Ports
USB USB 3.0 × 2, USB 2.0 × 1
Audio Combo audio jack × 1
Ethernet RJ-45 × 1 (1000 Mbps)
Video/Audio HDMI × 1
Card reader 4 in 1 slot × 1 (SD/SDHC/SDXC/MMC)
Battery pack
Type Li-Polymer
Cells/Capacity 4 cells, 60 Wh
AC power adapter
Input 100 - 240 V, 50 - 60 Hz AC
Output voltage 20 V DC
Power 135 W
Miscellaneous
Camera HD (720p)
Security Kensington lock slot × 1
aux appareils radio exempts de licence.
22
Trademarks
The following terms are trademarks or registered trademarks of Lenovo in
the United States, other countries, or both.
Lenovo
ideapad
Microsoft and Windows are trademarks of Microsoft Corporation in the
United States, other countries, or both.
Other company, products, or service names may be trademarks or service
marks of others.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
IC Warnings

Navigation menu
