Rheem High Efficiency Air Handler
FORM NO. H11-553 REV. 1
RH1T/RH2T- Series
Constant Torque Motor (ECM)
Efficiencies up to 16 SEER
• RH1T/RH2T feature a Constant Torque motor (ECM) which
provides enhanced SEER performance with most Rheem out-
door units.
• Versatile 4-way convertible design for upflow, downflow,
horizontal left and horizontal right applications.
• Factory-installed indoor coil.
• Sturdy cabinet construction with 1.0 inch [25.4 mm] of
foil faced insulation for excellent sound and insulating
characteristics.
• Field-installed auxiliary electric heater kits provide exact heat
for indoor comfort. Kits include circuit breakers which meet
U.L. and cUL requirements for service disconnect.
•1
1/2ton [5.3 kW] through 5 ton [17.6 kW] models are between
421/2to 551/2inches [1080 to 1410 mm] tall and 22 inches
[559 mm] deep.
• All models meet or exceed 330 to 400 CFM [156 to 189 L/s]
per ton at .3 inches [.7 kPa] of external static pressure.
• Enhanced airflow up to .7" external static pressure.
• Evaporator is constructed of aluminum fins bonded to inter-
nally grooved aluminum tubing.
Air Air Handlers
RH1T/RH2T Series
Air Table of Contents
RH1T/RH2T Series
2
TABLE OF CONTENTS
Engineering Features ......................................................................................3
Model Number Identification ............................................................................4
Dimensional Data ........................................................................................5-6
Airflow Directional Data ..................................................................................7
Airflow Performance Data RH1T ..................................................................8-12
Electrical Data RH1T ................................................................................13-16
Airflow Performance Data RH2T ................................................................17-20
Electrical Data RH2T ................................................................................21-22
Electrical Wiring ............................................................................................23
Accessories ............................................................................................................23
Limited Warranty ..........................................................................................24
Air Engineering Features
RH1T/RH2T Series
3
Engineering Features
RH1T/RH2T- Series
• The most compact unit design available, all standard heat air
handler models only 421/2 to 551/2inches [1079 to 1409 mm] high.
• Attractive pre-painted cabinet exterior.
• Rugged wall steel cabinet construction, designed for added
strength and versatility.
• 1.0" foil faced insulation mechanically retained in blower
compartment for excellent thermal and sound performance.
• Four leg blower motor mount.
• Blower housing with controls, motor and blower. Slide out
design for service and maintenance convenience.
• Traditional open wire element design for heat applications.
• Field convertible for vertical downflow, horizontal left hand or
right hand air supply.
• 3 combustible floor base accessories fit all model sizes when
required for downflow installations on combustible floors.
• Indoor coil design provides low air side pressure drop, high
performance and extremely compact size.
• Expansion valve on indoor coil provides for operation with air
conditioning.
• Coils are constructed of aluminum fins bonded to internally
grooved aluminum tubing.
• Coils are tested at the factory with an extensive refrigerant
leak check.
• Coils have copper sweat refrigerant connections.
• Coils utilize chatleff metering device connections.
• Molded polymer corrosion resistant condensate drain pan is
provided on all indoor coils.
• Supply duct flanges provided as standard on air handler
cabinet.
• Provisions for field electrical, connections available from
either side or top of the air handler cabinet.
• Connection point for high voltage wiring is inside the air han-
dler cabinet. Low voltage connection is made on the outside
of the air handler cabinet.
• Concentric knockouts are provided for power connection to
cabinet. Installer may pull desired hole size up to 2 inches
[51 mm] for 11/2 inch [38 mm] conduit.
• Front refrigerant and drain connections.
[ ] Designates Metric Conversions
Air Model Number Identification
RH1T/RH2T Series
44
Available Models at 115V A Voltage
RH1T2417STANAA
RH1T3617STANAA
RH1T3621MTANAA
RH1T4821STANAA
RH1T4824STANAA
RH1T6024STANAA
Available Models at 218V J Voltage
RH1T2417STANJA
RH1T3617STANJA
RH1T3621MTANJA
RH1T4821STANJA
RH1T4824STANJA
RH1T6024STANJA
RH2T2421MTANJA
RH2T3621MTANJA
RH2T4824MTANJA
RH2T6024STANJA
R H 1 T 24 17 S T A N A A ***
Option Code (see ADS-3803)
Blank = None
Minor Series
A = First
Voltage
A = 115/1/60
D = 480V/3/60
J = 208/240/1/60
Controls
C = Communicating
N = Non-Communicating
Major Series
A = First
Metering Device
T = TEV
E = EEV
P = Piston
Coil Efficiency
S = Standard
M= Medium
H = High
Width
17 = 17.5" [431.8 mm] (600-1200 CFM)
21 = 21" [533.4 mm] (800-1600 CFM)
24 = 24.5" [609.6 mm] (1400-1800 CFM)
Nominal Capacity
24 = 18,000 [5.27 kW]-24,000 [7.03 kW] BTU/H
36 = 30,000 [8.79 kW]-36,000 [10.55 kW] BTU/H
48 = 42,000 [12.31 kW]-48,000 [14.06 kW] BTU/H
60 = 60,000 [17.58 kW] BTU/H
Motor Type
T = Constant Torque (ECM)
Stages of Air Flow
1 = Single
2 = Two Stage
Product Category
H = Air Handler
Rheem
[ ] Designates Metric Conversions
Available Models at D Voltage
RH1T6024STANDA
Air Dimensional Data
RH1T/RH2T Series
5
ELECTRICAL CONNECTIONS
MAY EXIT TOP OR EITHER SIDE
HIGH VOLTAGE CONNECTION 7/8 [22.2 mm],
13/32 [27.8 mm], 131/32 [50 mm] DIA. KNOCKOUTS.
LOW VOLTAGE CONNECTION
5/8 [15.9 mm] AND 7/8 [22.2 mm] KNOCKOUT
VAPOR LINE CONNECTION
COPPER (SWEAT)
PRIMARY DRAIN CONNECTION
3/4 [19.1 mm] FEMALE PIPE THREAD (NPT)
AUXILIARY DRAIN CONNECTION
3/4 [19.1 mm] FEMALE PIPE THREAD (NPT)
UPFLOW/DOWNFLOW APPLICATION ONLY
LIQUID LINE CONNECTION
COPPER (SWEAT)
AUXILIARY DRAIN CONNECTION
3/4 [19.1 mm] FEMALE PIPE THREAD (NPT)
HORIZONTAL APPLICATION ONLY
UPFLOW UNIT SHOWN:
UNIT MAY BE INSTALLED UPFLOW, DOWNFLOW,
HORIZONTAL RIGHT OR LEFT AIR SUPPLY.
NOTE: 24 CLEARANCE REQUIRED IN FRONT OF
UNIT FOR FILTER AND COIL MAINTENANCE.
A
W
H
191/2 [495 mm]
RETURN AIR
OPENING
2111/16
[551 mm]
105/16
[262 mm]
SUPPLY AIR
Unit Dimensions
515/16
[151 mm] 41/8
[105 mm] 31/16
[76 mm] 13/16 [48 mm] 11/8 [29 mm]
11/16
[27 mm]
13/8
[35 mm]
213/16
[71 mm] 51/4
[133 mm]
53/8
[136 mm]
UPFLOW UNIT SHOWN:
UNIT MAY BE INSTALLED UPFLOW,
DOWNFLOW, HORIZONTAL RIGHT
OR LEFT AIR SUPPLY.
Model
Cabinet Size
Return Air
Opening Width
(Inches)
Return Air Opening
Depth/Length
(Inches)
17 157/8193/4
21 193/8193/4
24 227/8193/4
Return Air Opening Dimensions
[ ] Designates Metric Conversions
( ) Designates Unit with Double Coil Cabinet
HORIZONTAL ADAPTER KIT
VAPOR LINE
CONNECTION
AUXILIARY HORIZONTAL
DRAIN CONNECTION
PRIMARY DRAIN
CONNECTION
AUXILIARY UPFLOW/DOWNFLOW
DRAIN CONNECTION
LIQUID LINE
CONNECTION
VERTICAL DRAIN PAN
Air Dimensional Data
RH1T/RH2T Series
6
[ ] Designates Metric Conversions
( ) Designates Unit with Double Coil Cabinet
Unit Dimensions & Weights
Model
Size
RH1T
Refrigerant Connections
Sweat (In.) [mm] ID Unit
Width
“W” In. [mm]
Unit
Height
“H” In. [mm]
Supply
Duct
“A” In. [mm]
Air Flow
CFM (Nom.) [L/s]
Unit Weight/Shipping Weight
(Lbs.) [kg]
Liquid Vapor Lo Hi Unit With
Coil (Max. KW)
2417ST 3/8[9.53] 3/4[19.05] 171/2[445] 421/2[1080] 161/2[406] 600 [283] 800 [378] 92/105 [42/48]
3617ST 3/8[9.53] 3/4[19.05] 171/2[445] 421/2[1080] 161/2[406] 1000 [472] 1200 [566] 96/110 [44/50]
3621MT 3/8[9.53] 7/8[22.23] 211/2[533] 501/2[1282] 191/2[495] 1000 [472] 1200 [566] 126/142 [57/64]
4821ST 3/8[9.53] 7/8[22.23] 211/2[533] 501/2[1282] 191/2[495] 1400 [661] 1600 [755] 128/144 [56/65]
4824ST 3/8[9.53] 7/8[22.23] 241/2[622] 501/2[1282] 231/2[584] 1600 [755] —142/160 [64/72]
6024ST 3/8[9.53] 7/8[22.23] 241/2[622] 551/2[1410] 231/2[584] —1800 [850] 159/176 [72/80]
*Maximum dehumidification airflow.
Unit Dimensions & Weights
Model
Size
RH2T
Refrigerant Connections
Sweat (In.) [mm] ID Unit
Width
“W” In. [mm]
Unit
Height
“H” In. [mm]
Supply
Duct
“A” In. [mm]
Air Flow
CFM (Nom.) [L/s]
Unit Weight/Shipping Weight
(Lbs.) [kg]
Liquid Vapor Lo Hi Unit With
Coil (Max. KW)
2421MT 3/8[9.53] 3/4[19.05] 211/2[533] 421/2[1080] 191/2[495] 525 [248] 700 [330] 111/126 [50/57]
3621MT 3/8[9.53] 7/8[22.23] 211/2[533] 501/2[1282] 191/2[495] 800 [377] 1050 [495] 129/145 [59/66]
4824MT 3/8[9.53] 7/8[22.23] 241/2[622] 551/2[1410] 231/2[584] 1050 [495] 1400 [660] 128/146 [58/66]
6024ST 3/8[9.53] 7/8[22.23] 241/2[622] 551/2[1410] 231/2[584] 1200 [566] 1600 [755] 161/178 [73/81]
Unit Dimensions & Weights
[ ] Designates Metric Conversions
Air Airflow Directional Data
RH1T/RH2T Series
7
UPFLOW DOWNFLOW
Airflow Directional Data
HORIZONTAL RIGHT
HAND AIRFLOW
HORIZONTAL LEFT
HAND AIRFLOW
Air Airflow Performance Data
RH1T/RH2T Series
8
Airflow Performance
Airflow performance data is based on cooling performance
with a coil and no filter in place. Select performance table for
appropriate unit size, voltage and number of electric heaters to
be used. Make sure external static applied to unit allows oper-
ation within the minimum and maximum limits shown in table
below for both cooling and electric heat operation. For opti-
mum blower performance, operate the unit in the .3 [8 mm] to
.7 inches [18 mm] W.C. external static range. Units with coils
should be applied with a minimum of .1 inch [3 mm] W.C.
external static range.
Airflow Operating Limits
Model Cabinet Width 17 17/21
Cooling BTUH x 1,000
Cooling Tons Nominal
-18
1.5
-24
2
-30
2.5
-36
3
-42
3.5
-48
4
-48
4
Heat Pump or Air Conditioning
Maximum Heat/Cool CFM [L/s]
(37.5 CFM [18 L/s]/1,000 BTUH)
(450 CFM [212 L/s]/Ton Nominal)
675
[319]
900
[425]
1125
[531]
1350
[637]
1575
[743]
1800
[850]
1800
[850]
Heat Pump or Air Conditioning
Nominal Heat/Cool CFM [L/s]
(33.3 CFM [16 L/s]/1,000 BTUH)
(400 CFM [189 L/s]/Ton Nominal)
600
[283]
800
[378]
1000
[472]
1200
[566]
1400
[661]
1600
[755]
1600
[755]
Heat Pump or Air Conditioning
Minimum Heat/Cool CFM [L/s]
(30.0 CFM [14 L/s]/1,200 BTUH)
(360 CFM [170 L/s]/Ton Nominal)
540
[255]
720
[340]
900
[425]
1080
[510]
1260
[595]
1440
[680]
1440
[680]
Maximum kW Electric Heating
& Minimum Electric Heat CFM [L/s]
13
487 [230]
13
617 [291]
18
814 [384]
18
1054 [497]
20
1171 [553]
25
1502 [709]
25
1502 [709]
Maximum Electric Heat Rise °F [°C] 80 [26.7] 63 [17.2] 66 [18.9] 51 [10.6] 49 [9.4] 50 [10] 50 [10]
24
-60
5
1930
[911]
1800
[850]
1620
[765]
30
1666 [786]
54 [12.2]
21
[ ] Designates Metric Conversions
Air Airflow Performance Data
RH1T/RH2T Series
9
External Static Pressure—Inches W.C. [kPa]
X-13 CFM [L/s] Air Delivery/RPM/Watts—115/208/240 Volts
RPM 592
Blower Size/
Motor
HP [W]
# of Speed
3617ST
No Heater
613
Tonnage
Application
656
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
719 778 — —
Watts 108 90 97 82 73 — —
10x8
1/3 HP [249]
5 Speed CFM — — — — 808 [381] 629 [297] 584 [276]
RPM
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17]
— — — — 789 842
RPM 565 587 630 692 751 — —
892
Model
No.
RH1T
2417ST
with 13 kW
Heater
2417ST
No Heat
2417ST
with 13 kW
Heater
2417ST
No Heat
Watts 95 81 88 74 66 — —
10x8
1/3 HP [249]
5 Speed
3617ST
No Heater
RPM
1.5 Ton 683/485
[322/229 L/s]
CFM — — — — 683 [322] 615 [290] 572 [270]
CFM 814 [384] 692 [326] 589 [278] 535 [252]
RPM — — — — 789 842 892
467 [220] — —
Watts — — — — 148 168 163
RPM 596 645
3617ST
with 18 kW
Heater
694 741 791
775
— —
816 846 882
Watts 105 108 116 121 130 — —
10x8
1/3 HP [249]
5 Speed CFM
926 —
— — — — 858 [276] 816 [385] 770 [363]
RPM — — — — 834 879 925
—
Watts 237 249 259 268 277
2 Ton 858/697
[405/329 L/s]
CFM 902 [426] 846 [399] 788 [372] 742 [350] 679 [320] — —
Watts — — — — 185 182 214
RPM 595 670 719 767 817 — —
Watts 113 125 124 129 197 — —
10x8
1/3 HP [249]
5 Speed CFM — — — — 833 [393] 791 [373] 746 [352]
RPM — — — — 852 898
— —
10x8
1/2 HP [373]
5 Speed CFM — —
2 Ton 683/485
[322/229 L/s]
CFM 882 [416] 827 [390] 769 [363] 723 [341] 661 [312] — —
Watts — — — — 192 189 222
RPM 671 725 764 809 852 — —
Watts 153 168 174 180 188 — —
10x8
1/2 HP [373]
5 Speed CFM — — — — 1084 [512] 1040 [491] 1001 [472]
RPM — — —
—
—
1.5 Ton
896
683/485
[322/229 L/s]
CFM 837 [395] 713 [366] 608 [287] 554 [261] 485 [229] — —
936 971
— 1275 [602] 1244 [587] 1211 [571]
Watts — — — — 140 159 155
RPM — —
2.5 Ton 935/1084 CFM
[441/512 L/s]
CFM 1093 [516] 1050 [496] 1017 [480] 977 [461] 935 [441] — —
Watts — — — — 249 257 261
RPM 711 765 804 849 892 — —
Watts 164 179 185 191 199 — —
10x8
1/2 HP [373]
5 Speed CFM — — — — 1059 [500] 1015 [479] 976 [461]
RPM — — — — 936 976 1011
— — 963 999 1029
3 Ton 1130/1275 CFM
[533/602 L/s]
2.5 Ton 910/1059 CFM
[429/500 L/s]
CFM 1068 [504] 1025 [484] 992 [468] 952 [449] 910 [429] — —
Watts — — — — 260 268 272
CFM 1270 [599] 1237 [584] 1199 [566] 1165 [550] 1130 [533] — —
Watts — — — — 338 348 363
Motor
Speed
From
Factory
5
5
5
5
5
5
5
3617ST
with 18 kW
Heater
RPM 815 856 886 922 966 — —
Watts 248 260 270 279 288 — —
10x8
1/2 HP [373]
5 Speed CFM — — — — 1250 [590] 1219 [575] 1186 [560]
RPM — — — — 1003 1039 1069
3 Ton 1105/1250 CFM
[521/590 L/s]
CFM 1245 [588] 1212 [572] 1174 [554] 1140 [538] 1105 [521] — —
Watts — — — — 349 359 374
5
Motor
Speed
2
2
4
4
4
2
2
4
3
3
5
5
3
3
5
5
115V/208V/240V/460V Airflow Performance Data—RH1T (Constant Torque (ECM) Motor)
[ ] Designates Metric Conversions
Air Airflow Performance Data
RH1T/RH2T Series
10
External Static Pressure—Inches W.C. [kPa]
PSC CFM [L/s] Air Delivery/RPM/Watts—115/208/240 Volts
RPM 637
Blower Size/
Motor
HP [W]
# of Speed
692
Tonnage
Application
746
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Motor
Speed
801 847 — —
Watts 130 142 153 165 176 — —
10x10
3/4 HP [559]
5 Speed
3
CFM — — — — 1103 1059 1000
RPM
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17]
— — — — 917 957 1001
Model
No.
RH1T
3621MT
No Heater
3621MT
with 18 kW
Heater
3621MT
No Heater
3621MT
with 18 kW
Heater
2.5 Ton 854/1103 CFM
[403/521 L/s]
2
CFM 1073 [506] 1016 [479] 963 [454] 906 [428] 854 [403] — —
Watts — — — — 262 271 285
RPM 678 734 791 844 883 — —
Watts 141 155 158 171 182 — —
10x10
3/4 HP [559]
5 Speed
3
CFM — — — — 1016 961 904
RPM — — — — 939 968 1015
2.5 Ton 828/1016 CFM
[391/479 L/s]
2
CFM 1044 [493] 988 [466] 936 [442] 880 [415] 828 [391] — —
Watts — — — — 233 243 265
RPM 724 761 814 868 900 — —
Watts 198 208 222 237 245 — —
10x10
3/4 HP [559]
5 Speed
5
CFM — — — — 1288 1244 1200
RPM — — — — 974 1012 1044
3 Ton 1070/1288 CFM
[505/608 L/s]
4
CFM 1264 [597] 1223 [577] 1171 [553] 1112 [525] 1070 [505] — —
Watts — — — — 345 362 371
RPM 759 794 845 915 933 — —
Watts 219 215 227 251 261
10x10
3/4 HP [559]
5 Speed
5
CFM — — — — 1257 1213 1169
RPM — — — — 1020 1023 1054
3 Ton 1042/1257 CFM
[492/593 L/s]
4
CFM 1233 [582] 1193 [563] 1142 [539] 1084 [512] 1042 [492] — —
Watts — — — — 355 368 376
Motor
Speed
From
Factory
4
4
4
4
Notes: Constant Torque motor speed changes.
All Constant Torque motors have 5 speed tabs. Speed tab 1 is for continuous fan. Speed tab 2 (low static) and Speed tab 3 (high static) are for lower tonnage. Speed
tab 4 (low static) and Speed tab 5 (high static) are for higher tonnage.
Constant Torque air handlers are always shipped from factory at Speed tab 5, except for -4824, which is set at Speed tab 3. For instance, (-)H1T-HM2417JA is always
shipped at high static 2-ton airflow (Speed tab 5). To change to 1.5-ton airflow, move the blue wire to Speed tab 2 or 3 on the Constant Torque motor.
The low static Speed tab 2 (lower tonnage) and 4 (higher tonnage) are used for external static below 0.5" WC. The high static Speed tab 3 (lower tonnage) and 5
(higher tonnage) are used for external static exceeding 0.5" WC. Move the blue wire to the appropriate Speed tab as required by the application needs.
• The airflow for continuous fan (Speed tab 1) is always set at 50% of the Speed tab 4.
• The above airflow table lists the airflow information for air handlers without heater and air handler with maximum heater allowed for each model.
• The following formula can be used to calculate the approximate airflow, if a smaller (N kW) than the maximum heater kit is installed.
Approximate Airflow = Airflow without heater – (Airflow without heater – Airflow with maximum heater) x (N kW/maximum heater kW)
[ ] Designates Metric Conversions
115V/208V/240V/460V Airflow Performance Data—RH1T (Constant Torque (ECM) Motor) (con’t.)
Air Airflow Performance Data
RH1T/RH2T Series
11
External Static Pressure—Inches W.C. [kPa]
PSC CFM [L/s] Air Delivery/RPM/Watts—115/208/240 Volts
RPM 660
Blower Size/
Motor
HP [W]
# of Speed
4821ST
with 20 kW
Heater
698
Tonnage
Application
734
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Motor
Speed
762 795 — —
Watts 297 311 326 340 353 — —
11x11
3/4 HP [559]
5 Speed
3
CFM — — — — 1732 [817] 1683 [794] 1630 [769]
RPM
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17]
— — — — 840 872 899
Model
No.
RH1T
4824ST
No Heater
4824ST
with 25 kW
Heater
6024ST
No Heater
6024ST
with 30 kW
Heater
RPM
4 Ton 1545/1732 CFM
[729/817 L/s]
2
CFM 1748 [825] 1669 [788] 1639 [773] 1599 [755] 1545 [729] — —
Watts — — — — 448 467 480
RPM 680 736
4821ST
No Heater
760 790 820
831
— —
875 919 954
Watts 305 330 341 350 361 — —
11x11
3/4 HP [559]
5 Speed
3
CFM
989 —
— — — — 1692 [798] 1643 [775] 1590 [750]
RPM — — — — 865 890 1014
—
Watts 277 295 313 319 325
4 Ton 1505/1692 CFM
[710/798 L/s]
2
CFM 1708 [806] 1629 [769] 1599 [755] 1559 [736] 1505 [710] — —
Watts — — — — 460 470 481
RPM 663 701 741 782 819 — —
Watts 292 309 321 343 357 — —
11x11
3/4 HP [559]
5 Speed
3
CFM — — — — 1699 [500] 1646 [776] 1601 [725]
RPM — — — — 857 895 920
— —
10x10
3/4 HP [559]
5 Speed
3
CFM — —
5 Ton 1517/1699 CFM
[715/800 L/s]
2
CFM 1705 [800] 1661 [703] 1632 [770] 1572 [741] 1517 [915] — —
Watts — — — — 447 466 473
RPM 701 739 779 820 857 — —
Watts 313 330 342 364 378 — —
11x11
3/4 HP [559]
5 Speed
3
CFM — — — — 1657 [787] 1606 [759] 1561 [735]
RPM — — —
—
— 895 933 958
— 1333 [629] 1300 [613] 1267 [598]
RPM — —
5 Ton 1477/1655 CFM
[687/785 L/s]
2
CFM 1665 [995] 1621 [965] 1592 [751] 1532 [723] 1477 [697] — —
Watts — — — — 968 487 494
RPM 781 825 867 905 949 — —
Watts 257 271 303 307 315 — —
10x10
3/4 HP [559]
5 Speed
3
CFM — — — — 1447 [683] 1433 [676] 1402 [662]
RPM — — — — 987 1034 1065
— — 1011 1046 1080
3.5 Ton 1297/1333 CFM
[612/629 L/s]
3.5 Ton 1337/1447 CFM
[631/683 L/s]
2
CFM 1473 [695] 1442 [681] 1401 [661] 1373 [648] 1337 [631] — —
Watts — — — — 394 406 405
2
CFM 1433 [676] 1402 [662] 1361 [642] 1333 [629] 1297 [612] — —
Watts — — — — 350 364 377
4821ST
No Heater
RPM 853 893 934 968 1015 — —
Watts 351 387 401 406 422 — —
10x10
3/4 HP [559]
5 Speed
5
CFM — — — — 1654 [781] 1624 [766] 1563 [738]
RPM — — — — 1036 1078 1095
4 Ton 1535/1654 CFM
[724/781 L/s]
4
CFM 1665 [786] 1631 [770] 1601 [756] 1572 [742] 1535 [724] — —
Watts — — — — 500 513 523
4821ST
with 25 kW
Heater
RPM 894 932 970 1020 1052 — —
Watts 389 400 410 430 450 — —
10x10
3/4 HP [559]
2 Speed
5
CFM — — — — 1614 [762] 1584 [748] 1523 [719]
RPM — — — — 1085 1090 1105
4 Ton 1495/1614 CFM
[706/762 L/s]
4
CFM 1625 [767] 1591 [751] 1561 [737] 1532 [723] 1495 [706] — —
Watts — — — — 514 520 530
Motor
Speed
From
Factory
3
3
4, 5
4, 5
5
5
5
5
115V/208V/240V/460V Airflow Performance Data—RH1T (Constant Torque (ECM) Motor) (con’t.)
[ ] Designates Metric Conversions
Air Airflow Performance Data
RH1T/RH2T Series
12
External Static Pressure—Inches W.C. [kPa]
X-13 CFM [L/s] Air Delivery/RPM/Watts—115/208/240 Volts
Blower Size/
Motor
HP [W]
# of Speed
Tonnage
Application
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Motor
Speed
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17]
Model
No.
RH1T
6024ST
No Heater
6024ST
with 30 kW
Heater
4RPM 712 749 787 815 856 — —
Watts 389 409 419 432 459 — —
11x11
3/4 HP [559]
5 Speed
4
CFM — — — — 1905 [899] 1866 [881] 1832 [865]
RPM — — — — 894 924 950
5 Ton 1739/1905 CFM
[821/899 L/s]
CFM 1902 [898] 1862 [879] 1809 [854] 1781 [840] 1739 [821] — —
Watts — — — — 565 570 592
RPM 750 790 810 850 880 — —
Watts 410 420 430 455 479 — —
11x11
3/4 HP [559]
5 Speed CFM — — — — 1865 [880] 1826 [862] 1792 [846]
RPM — — — — 920 945 970
5 Ton 1699/1865 CFM
[802/880 L/s]
CFM 1862 [879] 1822 [860] 1769 [835] 1741 [822] 1699 [802] — —
Watts — — — — 565 587 610
5
5
Motor
Speed
From
Factory
5
5
115V/208V/240V/460V Airflow Performance Data—RH1T (Constant Torque (ECM) Motor) (con’t.)
Notes: • All 208/240V PSC motors have voltage taps for 208 and 240 volts.
• All 208/240V PSC motors are shipped on high speed and 240 volts.
• If the application external static is less than 0.5" WC, adjust the motor speed to the low static speed as described below:
• Unplug the black motor wire off the relay on the control board and plug in the red motor wire.
• Replace the cap on the black motor wire.
• Voltage change (208/240V motors):
• Move the orange lead to transformer 208V tap from 240V tap. Replace the wire cap on 240V tap.
• Unplug the purple motor wire off the transformer and plug in the yellow motor wire.
• Replace the cap on the purple motor wire.
• The above airflow table lists the airflow information for air handlers without heater and air handler with maximum heater allowed for each model.
• The following formula can be used to calculate the approximate airflow, if a smaller (N kW) than the maximum heater kit is installed.
Approximate Airflow = Airflow without heater - (Airflow without heater - Airflow with maximum heater) x (N kW/maximum heater kW)
[ ] Designates Metric Conversions
Air Electrical Data
RH1T/RH2T Series
13
Model
RH1T Voltage Application
Phase* Hertz HP [W] RPM Speeds Circuit
Amps.
Minimum
Circuit
Ampacity
Maximum
Circuit
Protector
3617ST 1/2 [373] 300-1100 42.7 4.0 15
2417ST
208/240 1 & 3 60
1/3 [249] 300-1100 41.6 2.0 15
4821ST 3/4 [559] 300-1100 43.8 5.0 15
6024ST/4824ST 3/4 [559] 300-1100 44.6 6.0 15
6024ST 3/4 [559] 300-1100 48.4 11.0 15
3617ST 1/2 [373] 300-1100 46.8 9.0 15
160
4821ST/4824ST 3/4 [559] 300-1100 48.4 11.0 15
6024ST 3/4 [559] 300-1100 43.2 4.0 15460 360
115
3621MT 1/2 [373] 300-1100 43.8 5.0 15
Electrical Data – Blower Motor Only – No Electric Heat RH1T
* Blower motors are all single phase motors.
[ ] Designates Metric Conversions
Air Electrical Data
RH1T/RH2T Series
14
Air Handler
Model
RH1T
Heater Model No.
Heater kW
(208/240V)
(480V)
PH/HZ No. Elements
kW Per
Type Supply
Circuit Single
Circuit Multiple
Circuit
Amps.
Motor
Ampacity
Minimum
Circuit
Ampacity
Maximum
Circuit
Protector
2417ST
RXBH-1724?03J 2.25/3.0 1/60 1 - 3.0 SINGLE 10.8/12.5 1.6 16/18 20/20
RXBH-1724?05J 3.6/4.8 1/60 1 - 4.8 SINGLE 17.3/20.0 1.6 24/27 25/30
RXBH-1724?07J 5.4/7.2 1/60 2 - 3.6 SINGLE 26.0/30.0 1.6 35/40 35/40
RXBH-1724?10J 7.2/9.6 1/60 2 - 4.8 SINGLE 34.6/40.0 1.6 46/52 50/60
RXBH-1724A13J 9.4/12.5 1/60 3-4.17 SINGLE 45.1/52.1 1.6 59/68 60/70
RXBH-1724A13J 3.1/4.2 1/60 1-4.17 MULTIPLE CKT 1 15.0/17.4 1.6 21/24 25/25
6.3/8.3 1/60 2-4.17 MULTIPLE CKT 2 30.1/34.7 0.0 38/44 40/45
RXBH-1724A07C 5.4/7.2 3/60 3 - 2.4 SINGLE 15.0/17.3 1.6 21/24 25/25
RXBH-1724A10C 7.2/9.6 3/60 3 - 3.2 SINGLE 20.0/23.1 1.6 27/31 30/35
RXBH-1724A13C 9.4/12.5 3/60 3-4.17 SINGLE 26.1/30.1 1.6 35/40 35/40
3617ST
RXBH-1724?03J 2.25/3.0 1/60 1 - 3.0 SINGLE 10.8/12.5 2.8 17/20 20/20
RXBH-1724?05J 3.6/4.8 1/60 1 - 4.8 SINGLE 17.3/20.0 2.8 26/29 30/30
RXBH-1724?07J 5.4/7.2 1/60 2 - 3.6 SINGLE 26.0/30.0 2.8 36/41 40/45
RXBH-1724?10J 7.2/9.6 1/60 2 - 4.8 SINGLE 34.6/40.0 2.8 47/54 50/60
RXBH-1724A13J 9.4/12.5 1/60 3-4.17 SINGLE 45.1/52.1 2.8 60/69 60/70
RXBH-1724A13J 3.1/4.2 1/60 1-4.17 MULTIPLE CKT 1 15.0/17.4 2.8 23/26 25/30
6.3/8.3 1/60 2-4.17 MULTIPLE CKT 2 30.1/34.7 0.0 38/44 40/45
RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60 2.8 69/79 70/80
RXBH-1724A15J 3.6/4.8 1/60 1 - 4.8 MULTIPLE CKT 1 17.3/20.0 2.8 26/29 30/30
7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-1724A18J 12.8/17 1/60 3-5.68 SINGLE 61.6/70.8 2.8 81/92 90/100
RXBH-1724A18J 4.3/5.7 1/60 1 - 5.68 MULTIPLE CKT 1 20.5/23.6 2.8 30/33 30/35
8.7/11.3 1/60 2 - 5.86 MULTIPLE CKT 2 41.1/47.2 0.0 52/59 60/60
RXBH-1724A07C 5.4/7.2 3/60 3 - 2.4 SINGLE 15.0/17.3 2.8 23/26 25/30
RXBH-1724A10C 7.2/9.6 3/60 3 - 3.2 SINGLE 20.0/23.1 2.8 29/33 30/35
RXBH-1724A13C 9.4/12.5 3/60 3-4.17 SINGLE 26.1/30.1 2.8 37/42 40/45
RXBH-1724A15C 10.8/14.4 3/60 3 - 4.8 SINGLE 30.0/34.6 2.8 41/47 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-5.68 SINGLE 35.5/41.0 2.8 48/55 50/60
3621MT/
4821ST
RXBH-1724?03J 2.25/3.0 1/60 1 - 3.0 SINGLE 10.8/12.5 4.0 19/21 20/25
RXBH-1724?05J 3.6/4.8 1/60 1 - 4.8 SINGLE 17.3/20.0 4.0 27/30 30/30
RXBH-1724?07J 5.4/7.2 1/60 2 - 3.6 SINGLE 26.0/30.0 4.0 38/43 40/45
RXBH-1724?10J 7.2/9.6 1/60 2 - 4.8 SINGLE 34.6/40.0 4.0 49/55 50/60
RXBH-1724A13J 9.4/12.5 1/60 3-4.17 SINGLE 45.1/52.1 4.0 62/71 60/70
RXBH-1724A13J 3.1/4.2 1/60 1-4.17 MULTIPLE CKT 1 15.0/17.4 4.0 24/27 25/30
6.3/8.3 1/60 2-4.17 MULTIPLE CKT 2 30.1/34.7 0.0 38/44 40/45
RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60 4.0 70/80 70/80
RXBH-1724A15J 3.6/4.8 1/60 1 - 4.8 MULTIPLE CKT 1 17.3/20.0 4.0 27/30 30/30
7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-1724A18J 12.8/17 1/60 3-5.68 SINGLE 61.6/70.8 4.0 82/94 90/100
RXBH-1724A18J 4.3/5.7 1/60 1 - 5.68 MULTIPLE CKT 1 20.5/23.6 4.0 31/35 30/35
8.7/11.3 1/60 2 - 5.86 MULTIPLE CKT 2 41.1/47.2 0.0 52/59 60/60
RXBH-24A20J (4-ton only) 14.4/19.2 1/60 4-4.8 SINGLE 69.2/80 4.0 92/105 100/110
Electrical Data – With Electric Heat RH1T
Installation of the U.L. Listed original equipment manufacturer provided heater kits listed in the following table is recommended for all
auxiliary heating requirements.
• Supply circuit protective devices may be fuses or “HACR” type circuit breakers.
• Largest motor load is included in single circuit and multiple circuit 1.
• If non-standard fuse size is specified, use next size larger standard fuse size.
• J Voltage (230V) single phase air handler is designed to be used with single or three phase 230 volt electric heaters. In the case of connecting 3-phase power to the air handler terminal block
without the heater, bring only two leads to the terminal block cap, insulate and fully secure the third lead.
[ ] Designates Metric Conversions
Air Electrical Data
RH1T/RH2T Series
15
Electrical Data – With Electric Heat RH1T (Cont.)
Installation of the U.L. Listed original equipment manufacturer provided heater kits listed in the following table is recommended for all
auxiliary heating requirements.
• Supply circuit protective devices may be fuses or “HACR” type circuit breakers.
• Largest motor load is included in single circuit and multiple circuit 1.
• If non-standard fuse size is specified, use next size larger standard fuse size.
• J Voltage (230V) single phase air handler is designed to be used with single or three phase 230 volt electric heaters. In the case of connecting 3-phase power to the air handler terminal block
without the heater, bring only two leads to the terminal block cap, insulate and fully secure the third lead.
[ ] Designates Metric Conversions
Air Handler
Model
RH1T
Heater Model No.
Heater kW
(208/240V)
(480V)
PH/HZ No. Elements
kW Per
Type Supply
Circuit Single
Circuit Multiple
Circuit
Amps.
Motor
Ampacity
Minimum
Circuit
Ampacity
Maximum
Circuit
Protector
3621MT/
4821ST
RXBH-24A20J (4-ton only) 7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 1 34.6/40.0 4.0 49/55 50/60
7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-24A25J (4-ton only) 18.0/24.0 1/60 6-4.0 SINGLE 86.4/99.9 4.0 113/130 125/150
RXBH-24A25J (4-ton only)
6.0/8.0 1/60 2.4.0 MULTIPLE CKT 1 28.8/33.3 4.0 41/47 45/50
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 2 28.8/33.3 0.0 36/42 40/45
6.0/8.0 1/60 2-4.0 MULTPLE CKT 3 28.8/33.3 0.0 36/42 40/45
RXBH-1724A07C 5.4/7.2 3/60 3 - 2.4 SINGLE 15.0/17.3 4.0 24/27 25/30
RXBH-1724A10C 7.2/9.6 3/60 3 - 3.2 SINGLE 20.0/23.1 4.0 30/34 30/35
RXBH-1724A13C 9.4/12.5 3/60 3-4.17 SINGLE 26.1/30.1 4.0 38/43 40/45
RXBH-1724A15C 10.8/14.4 3/60 3 - 4.8 SINGLE 30.0/34.6 4.0 43/49 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-5.68 SINGLE 35.5/41.0 4.0 50/57 50/60
RXBH-24A20C (4-ton only) 7.2-9.6 3/60 3-3.2 SINGLE 40.0/46.2 4.0 55/63 60/70
RXBH-24A20C (4-ton only) 7.2/9.6 3/60 3 - 3.2 MULTIPLE CKT 1 20.0/23.1 4.0 30/34 30/35
7.2/9.6 3/60 3 - 3.2 MULTIPLE CKT 2 20.0/23.1 0.0 25/29 25/30
RXBH-24A25C (4-ton only) 18.0/24.0 3/60 6-4.0 SINGLE 50.0/57.8 4.0 68/78 70/80
RXBH-24A25C (4-ton only) 9.0/12.0 3/60 3-4.0 MULTIPLE CKT 1 25.0/28.9 4.0 37/42 40/45
9.0/12.0 3/60 3-4.0 MULTIPLE CKT 2 25.0/28.9 0.0 32/37 35/40
4824ST
RXBH-1724?03J 2.25/3.0 1/60 1 - 3.0 SINGLE 10.8/12.5 4.6 20/22 20/25
RXBH-1724?05J 3.6/4.8 1/60 1 - 4.8 SINGLE 17.3/20.0 4.6 28/31 30/35
RXBH-1724?07J 5.4/7.2 1/60 2 - 3.6 SINGLE 26.0/30.0 4.6 39/44 40/45
RXBH-1724?10J 7.2/9.6 1/60 2 - 4.8 SINGLE 34.6/40.0 4.6 49/56 50/60
RXBH-1724A13J 9.4/12.5 1/60 3-4.17 SINGLE 45.1/52.1 4.6 63/71 60/70
RXBH-1724A13J 3.1/4.2 1/60 1-4.17 MULTIPLE CKT 1 15.0/17.4 4.6 25/28 25/30
6.3/8.3 1/60 2-4.17 MULTIPLE CKT 2 30.1/34.7 0.0 38/44 40/45
RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60 4.6 71/81 80/90
RXBH-1724A15J 3.6/4.8 1/60 1 - 4.8 MULTIPLE CKT 1 17.3/20.0 4.6 28/31 30/35
7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-1724A18J 12.8/17 1/60 3-5.68 SINGLE 61.6/70.8 4.6 83/95 90/100
RXBH-1724A18J 4.3/5.7 1/60 1 - 5.68 MULTIPLE CKT 1 20.5/23.6 4.6 32/36 30/35
8.7/11.3 1/60 2 - 5.86 MULTIPLE CKT 2 41.1/47.2 0.0 52/59 60/60
RXBH-24A20J 14.4/19.2 1/60 4-4.8 SINGLE 69.2/80 4.6 93/106 100/110
RXBH-24A20J 7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 1 34.6/40.0 4.6 49/56 50/60
7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-24A25J 18.0/24.0 1/60 6-4.0 SINGLE 86.4/99.9 4.6 114/131 125/150
RXBH-24A25J
6.0/8.0 1/60 2.4.0 MULTIPLE CKT 1 28.8/33.3 4.6 42/48 45/50
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 2 28.8/33.3 0.0 36/42 40/45
6.0/8.0 1/60 2-4.0 MULTPLE CKT 3 28.8/33.3 0.0 36/42 40/45
RXBH-1724A07C 5.4/7.2 3/60 3 - 2.4 SINGLE 15.0/17.3 4.6 25/28 25/30
RXBH-1724A10C 7.2/9.6 3/60 3 - 3.2 SINGLE 20.0/23.1 4.6 31/35 35/35
RXBH-1724A13C 9.4/12.5 3/60 3-4.17 SINGLE 26.1/30.1 4.6 39/44 40/45
RXBH-1724A15C 10.8/14.4 3/60 3 - 4.8 SINGLE 30.0/34.6 4.6 44/49 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-5.68 SINGLE 35.5/41.0 4.6 51/57 60/60
RXBH-24A20C 7.2-9.6 3/60 3-3.2 SINGLE 40.0/46.2 4.6 56/64 60/70
Air Electrical Data
RH1T/RH2T Series
16
Air Handler
Model
RH1T
Heater Model No.
Heater kW
(208/240V)
(480V)
PH/HZ No. Elements
kW Per
Type Supply
Circuit Single
Circuit Multiple
Circuit
Amps.
Motor
Ampacity
Minimum
Circuit
Ampacity
Maximum
Circuit
Protector
4824ST
RXBH-24A20C 7.2/9.6 3/60 3 - 3.2 MULTIPLE CKT 1 20.0/23.1 4.6 31/35 35/35
7.2/9.6 3/60 3 - 3.2 MULTIPLE CKT 2 20.0/23.1 0.0 25/29 25/30
RXBH-24A25C 18.0/24.0 3/60 6-4.0 SINGLE 50.0/57.8 4.6 69/78 70/80
RXBH-24A25C 9.0/12.0 3/60 3-4.0 MULTIPLE CKT 1 25.0/28.9 4.6 37/42 40/45
9.0/12.0 3/60 3-4.0 MULTIPLE CKT 2 25.0/28.9 0.0 32/37 35/40
4824ST/
6024ST
RXBH-1724?03J 2.25/3.0 1/60 1 - 3.0 SINGLE 10.8/12.5 4.6 20/22 20/25
RXBH-1724?05J 3.6/4.8 1/60 1 - 4.8 SINGLE 17.3/20.0 4.6 28/31 30/35
RXBH-1724?07J 5.4/7.2 1/60 2 - 3.6 SINGLE 26.0/30.0 4.6 39/44 40/45
RXBH-1724?10J 7.2/9.6 1/60 2 - 4.8 SINGLE 34.6/40.0 4.6 49/56 50/60
RXBH-1724A13J 9.4/12.5 1/60 3-4.17 SINGLE 45.1/52.1 4.6 63/71 60/70
RXBH-1724A13J 3.1/4.2 1/60 1-4.17 MULTIPLE CKT 1 15.0/17.4 4.6 25/28 25/30
6.3/8.3 1/60 2-4.17 MULTIPLE CKT 2 30.1/34.7 0.0 38/44 40/45
RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60 4.6 71/81 80/90
RXBH-1724A15J 3.6/4.8 1/60 1 - 4.8 MULTIPLE CKT 1 17.3/20.0 4.6 28/31 30/35
7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-1724A18J 12.8/17 1/60 3-5.68 SINGLE 61.6/70.8 4.6 83/95 90/100
RXBH-1724A18J 4.3/5.7 1/60 1 - 5.68 MULTIPLE CKT 1 20.5/23.6 4.6 32/36 30/35
8.7/11.3 1/60 2 - 5.86 MULTIPLE CKT 2 41.1/47.2 0.0 52/59 60/60
RXBH-24A20J 14.4/19.2 1/60 4-4.8 SINGLE 69.2/80 4.6 93/106 100/110
RXBH-24A20J 7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 1 34.6/40.0 4.6 49/56 50/60
7.2/9.6 1/60 2 - 4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-24A25J 18.0/24.0 1/60 6-4.0 SINGLE 86.4/99.9 4.6 114/131 125/150
RXBH-24A25J
6.0/8.0 1/60 2.4.0 MULTIPLE CKT 1 28.8/33.3 4.6 42/48 45/50
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 2 28.8/33.3 0.0 36/42 40/45
6.0/8.0 1/60 2-4.0 MULTPLE CKT 3 28.8/33.3 0.0 36/42 40/45
RXBH-24A30J (5-ton only) 21.6/28.8 1/60 6-4.8 SINGLE 103.8/120 4.6 136/156 150/175
RXBH-24A30J (5-ton only)
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 1 34.6/40.0 4.6 49/56 50/60
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
7.2/9.6 1/60 2-4.8 MULTPLE CKT 3 34.6/40.0 0.0 44/50 45/50
RXBH-1724A07C 5.4/7.2 3/60 3 - 2.4 SINGLE 15.0/17.3 4.6 25/28 25/30
RXBH-1724A10C 7.2/9.6 3/60 3 - 3.2 SINGLE 20.0/23.1 4.6 31/35 35/35
RXBH-1724A13C 9.4/12.5 3/60 3-4.17 SINGLE 26.1/30.1 4.6 39/44 40/45
RXBH-1724A15C 10.8/14.4 3/60 3 - 4.8 SINGLE 30.0/34.6 4.6 44/49 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-5.68 SINGLE 35.5/41.0 4.6 51/57 60/60
RXBH-24A20C 7.2-9.6 3/60 3-3.2 SINGLE 40.0/46.2 4.6 56/64 60/70
RXBH-24A20C 7.2/9.6 3/60 3 - 3.2 MULTIPLE CKT 1 20.0/23.1 4.6 31/35 35/35
7.2/9.6 3/60 3 - 3.2 MULTIPLE CKT 2 20.0/23.1 0.0 25/29 25/30
RXBH-24A25C 18.0/24.0 3/60 6-4.0 SINGLE 50.0/57.8 4.6 69/78 70/80
RXBH-24A25C 9.0/12.0 3/60 3-4.0 MULTIPLE CKT 1 25.0/28.9 4.6 37/42 40/45
9.0/12.0 3/60 3-4.0 MULTIPLE CKT 2 25.0/28.9 0.0 32/37 35/40
RXBH-24A30C (5-ton only) 21.6/28.8 3/60 6-4.8 SINGLE 60.0/69.4 4.6 81/93 90/100
RXBH-24A30C (5-ton only) 10.8/14.4 3/60 3-4.8 MULTIPLE CKT 1 30.0/34.7 4.6 44/50 45/50
10.8/14.4 3/60 3-4.8 MULTIPLE CKT 2 30.0/34.7 0.0 38/44 40/45
Electrical Data – With Electric Heat RH1T (Cont.)
Installation of the U.L. Listed original equipment manufacturer provided heater kits listed in the following table is recommended for all
auxiliary heating requirements.
• Supply circuit protective devices may be fuses or “HACR” type circuit breakers.
• Largest motor load is included in single circuit and multiple circuit 1.
• If non-standard fuse size is specified, use next size larger standard fuse size.
• J Voltage (230V) single phase air handler is designed to be used with single or three phase 230 volt electric heaters. In the case of connecting 3-phase power to the air handler terminal block
without the heater, bring only two leads to the terminal block cap, insulate and fully secure the third lead.
[ ] Designates Metric Conversions
17
Model
No.
RH2T
Nominal
Cooling
Capacity
Tons
Motor
Speed
From
Factory
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Blower Size/
Motor
HP
# of Speeds
Y1, Y2
Speed
Motor
Speed
X-13 Wet Coil No Filter CFM Air Delivery/RPM/Watts-230 Volts
External Static Pressure—Inches W.C. [kPa]
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17] 0.8 [.20] 0.9 [.22] 1.0 [.25]
2421MT
No Heater 2.0 Y1 Tap 4
Y2 Tap 5
Y1=310/817 CFM
[146/385] L/s
Y2=445/951 CFM
[210/448] L/s
10X8
3/4 hp 5 speed
Y1
Low Static Tap 2
CFM 740 569 310 — — — ————
RPM 542 561 584 — — —— — — —
Watts 94 72 49 — — — —— — —
Y2
Low Static Tap 3
CFM 851 704 653 590 541 489 445 — — —
RPM 578 599 647 711 770 814 868 — — —
Watts 88 93 98 103 108 113 118 — — —
Y1
High Static Tap 4
CFM 817 699 574 515 — — —— — —
RPM 573 588 630 702 — — ————
Watts 97 88 78 69 — —————
Y2
High Static Tap 5
CFM 951 911 872 824 787 742 691 — — —
RPM 622 672 725 772 821 880 922 — — —
Watts 134 146 157 168 179 191 202 — — —
2421MT
With 13 kW
Heater
2.0 Y1 Tap 4
Y2 Tap 5
Y1=290/797 CFM
[136/376] L/s
Y2=425/931 CFM
[200/439] L/s
10X8
3/4 hp 5 speed
Y1
Low Static Tap 2
CFM 720 549 290 —— — — — ——
RPM 557 576 599 —— — ——— —
Watts 99 77 54 — — — —— — —
Y2
Low Static Tap 3
CFM 831 684 633 570 521 469 425 — — —
RPM 593 614 662 726 785 829 883 — — —
Watts 93 98 103 108 113 118 123 — — —
Y1
High Static Tap 4
CFM 797 679 554 495 — — ——— —
RPM 588 603 645 717 — —— — — —
Watts 102 93 83 74 — ———— —
Y2
High Static Tap 5
CFM 931 891 852 804 767 722 671 — — —
RPM 637 687 740 787 836 895 937 — — —
Watts 139 151 162 173 184 196 207 — — —
Airflow Performance Data RH2T
Notes: Constant Torque (ECM) motor speed changes.
All Constant Torque (ECM) motors have 5 speed tabs. Speed tab 1 is for continuous fan. Speed tab 2 (low static) and Speed tab 3 (high static) are for lower tonnage.
Speed tab 4 (low static) and Speed tab 5 (high static) are for higher tonnage.
Constant Torque air handlers are always shipped from factory at Speed tab 5, except for -4824, which is set at Speed tab 3. For instance, (-)H2T is always shipped at
high static 2-ton airflow (Speed tab 5). To change to 1.5-ton airflow, move the blue wire to Speed tab 2 or 3 on the Constant Torque (ECM) motor.
The low static Speed tab 2 (lower tonnage) and 4 (higher tonnage) are used for external static below 0.5" WC. The high static Speed tab 3 (lower tonnage) and 5
(higher tonnage) are used for external static exceeding 0.5" WC. Move the blue wire to the appropriate Speed tab as required by the application needs.
• The airflow for continuous fan (Speed tab 1) is always set at 50% of the Speed tab 4.
• The above airflow table lists the airflow information for air handlers without heater and air handler with maximum heater allowed for each model.
• The following formula can be used to calculate the approximate airflow, if a smaller (N kW) than the maximum heater kit is installed.
Approximate Airflow = Airflow without heater – (Airflow without heater – Airflow with maximum heater) x (N kW/maximum heater kW)
[ ] Designates Metric Conversions
Air Airflow Performance Data
RH1T/RH2T Series
Air Airflow Performance Data
RH1T/RH2T Series
18
Model
No.
RH2T
Nominal
Cooling
Capacity
Tons
Motor
Speed
From
Factory
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Blower Size/
Motor
HP
# of Speeds
Y1, Y2
Speed
Motor
Speed
X-13 Wet Coil No Filter CFM Air Delivery/RPM/Watts-230 Volts
External Static Pressure—Inches W.C. [kPa]
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17] 0.8 [.20] 0.9 [.22] 1.0 [.25]
3621MT
No Heater 3.0 Y1 Tap 4
Y2 Tap 5
Y1=434/1005 CFM
[204/474] L/s
Y2=703/1328 CFM
[331/626] L/s
10X10
3/4 Hp 5 speed
Y1
Low Static Tap 2
CFM 919 757 596 434 ——————
RPM 567 584 635 691 — — ————
Watts 83 79 75 71 67 62 58 54 — —
Y2
Low Static Tap 3
CFM 1128 1067 1007 946 885 824 764 703 — —
RPM 644 691 728 804 884 921 945 986 — —
Watts 131 142 153 164 175 187 — — — —
Y1
High Static Tap 4
CFM 1005 942 879 816 753 690 — — — —
RPM 597 645 700 790 830 868 ——— —
Watts 99 108 117 127 136 145 154 164 173 182
Y2
High Static Tap 5
CFM 1328 1273 1218 1164 1109 1055 1000 945 891 836
RPM 737 773 815 854 907 990 1040 1065 1085 1117
Watts 197 209 221 233 245 257 269 281 293 305
3621MT
With 18 kW
Heater
3.0 Y1 Tap 4
Y2 Tap 5
Y1=404/975 CFM
[190/460] L/s
Y2=673/1298 CFM
[317/612] L/s
10X10
3/4 Hp 5 speed
Y1
Low Static Tap 2
CFM 889 727 566 404 — —— — — —
RPM 592 609 660 716 — —— — — —
Watts 88 84 80 76 — — — — — —
Y2
Low Static Tap 3
CFM 1098 1037 977 916 855 794 734 673 — —
RPM 669 716 753 829 909 946 970 1011 — —
Watts 136 147 158 169 180 192 5 5 — —
Y1
High Static Tap 4
CFM 975 912 849 786 723 660 —— — —
RPM 622 670 725 815 855 893 ————
Watts 104 113 122 132 141 150 — — — —
Y2
High Static Tap 5
CFM 1298 1243 1188 1134 1079 1025 970 915 861 806
RPM 762 798 840 879 932 1015 1065 1090 1110 1142
Watts 202 214 226 238 250 262 274 286 298 —
Airflow Performance Data RH2T
Notes: Constant Torque (ECM) motor speed changes.
All Constant Torque (ECM) motors have 5 speed tabs. Speed tab 1 is for continuous fan. Speed tab 2 (low static) and Speed tab 3 (high static) are for lower tonnage.
Speed tab 4 (low static) and Speed tab 5 (high static) are for higher tonnage.
Constant Torque air handlers are always shipped from factory at Speed tab 5, except for -4824, which is set at Speed tab 3. For instance, (-)H2T is always shipped at
high static 2-ton airflow (Speed tab 5). To change to 1.5-ton airflow, move the blue wire to Speed tab 2 or 3 on the Constant Torque (ECM) motor.
The low static Speed tab 2 (lower tonnage) and 4 (higher tonnage) are used for external static below 0.5" WC. The high static Speed tab 3 (lower tonnage) and 5
(higher tonnage) are used for external static exceeding 0.5" WC. Move the blue wire to the appropriate Speed tab as required by the application needs.
• The airflow for continuous fan (Speed tab 1) is always set at 50% of the Speed tab 4.
• The above airflow table lists the airflow information for air handlers without heater and air handler with maximum heater allowed for each model.
• The following formula can be used to calculate the approximate airflow, if a smaller (N kW) than the maximum heater kit is installed.
Approximate Airflow = Airflow without heater – (Airflow without heater – Airflow with maximum heater) x (N kW/maximum heater kW)
[ ] Designates Metric Conversions
Air Airflow Performance Data
RH1T/RH2T Series
19
Model
No.
RH2T
Nominal
Cooling
Capacity
Tons
Motor
Speed
From
Factory
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Blower Size/
Motor
HP
# of Speeds
Y1, Y2
Speed
Motor
Speed
X-13 Wet Coil No Filter CFM Air Delivery/RPM/Watts-230 Volts
External Static Pressure—Inches W.C. [kPa]
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17] 0.8 [.20] 0.9 [.22] 1.0 [.25]
4824MT
No Heater 4.0 Y1 Tap 4
Y2 Tap 5
Y1=702/1271 CFM
[331/599] L/s
Y2=992/1673 CFM
[468/789] L/s
11X11
3/4 hp 5 speed
Y1
Low Static Tap 2
CFM 1196 1046 894 819 702 — ————
RPM 563 580 598 643 696 — ————
Watts 133 133 134 135 136 —— — — —
Y2
Low Static Tap 3
CFM 1517 1461 1405 1347 1297 1247 1195 1144 1068 992
RPM 670 704 735 767 799 832 867 894 940 984
Watts 251 265 277 287 296 310 322 335 351 365
Y1
High Static Tap 4
CFM 1271 1151 1095 1039 968 883 813 745 — —
RPM 586 610 650 691 723 774 812 841 — —
Watts 164 157 168 180 186 198 211 219 — —
Y2
High Static Tap 5
CFM 1673 1625 1576 1527 1476 1431 1381 1339 1289 1239
RPM 726 756 783 815 841 870 901 929 956 983
Watts 329 341 355 370 378 389 405 415 427 441
4824MT
With 25 kW
Heater
4.0 Y1 Tap 4
Y2 Tap 5
Y1=672/1241 CFM
[314/582] L/s
Y2=962/1643 CFM
[451/772] L/s
11X11
3/4 hp 5 speed
Y1
Low Static Tap 2
CFM 1166 1016 864 789 672 — — — — —
RPM 588 605 623 668 721 —— — — —
Watts 138 138 139 140 141 — — — — —
Y2
Low Static Tap 3
CFM 1487 1431 1375 1317 1267 1217 1165 1114 1038 962
RPM 695 729 760 792 824 857 892 919 965 1009
Watts 256 270 282 292 301 315 327 340 356 370
Y1
High Static Tap 4
CFM 1241 1121 1065 1009 938 853 783 715 — —
RPM 611 635 675 716 748 799 837 866 ——
Watts 169 162 173 185 191 203 216 224 — —
Y2
High Static Tap 5
CFM 1643 1595 1546 1497 1446 1401 1351 1309 1259 1209
RPM 751 781 808 840 866 895 926 954 981 1008
Watts 334 346 360 375 383 394 410 420 432 446
Airflow Performance Data RH2T
Notes: Constant Torque (ECM) motor speed changes.
All Constant Torque (ECM) motors have 5 speed tabs. Speed tab 1 is for continuous fan. Speed tab 2 (low static) and Speed tab 3 (high static) are for lower tonnage.
Speed tab 4 (low static) and Speed tab 5 (high static) are for higher tonnage.
Constant Torque air handlers are always shipped from factory at Speed tab 5, except for -4824, which is set at Speed tab 3. For instance, (-)H2T is always shipped at
high static 2-ton airflow (Speed tab 5). To change to 1.5-ton airflow, move the blue wire to Speed tab 2 or 3 on the Constant Torque (ECM) motor.
The low static Speed tab 2 (lower tonnage) and 4 (higher tonnage) are used for external static below 0.5" WC. The high static Speed tab 3 (lower tonnage) and 5
(higher tonnage) are used for external static exceeding 0.5" WC. Move the blue wire to the appropriate Speed tab as required by the application needs.
• The airflow for continuous fan (Speed tab 1) is always set at 50% of the Speed tab 4.
• The above airflow table lists the airflow information for air handlers without heater and air handler with maximum heater allowed for each model.
• The following formula can be used to calculate the approximate airflow, if a smaller (N kW) than the maximum heater kit is installed.
Approximate Airflow = Airflow without heater – (Airflow without heater – Airflow with maximum heater) x (N kW/maximum heater kW)
[ ] Designates Metric Conversions
Air Airflow Performance Data
RH1T/RH2T Series
20
Model
No.
RH2T
Nominal
Cooling
Capacity
Tons
Motor
Speed
From
Factory
Manufacturer
Recommended
Air-Flow Range
(Min/Max) CFM
Blower Size/
Motor
HP
# of Speeds
Y1, Y2
Speed
Motor
Speed
X-13 Wet Coil No Filter CFM Air Delivery/RPM/Watts-230 Volts
External Static Pressure—Inches W.C. [kPa]
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17] 0.8 [.20] 0.9 [.22] 1.0 [.25]
6024ST
No Heater 5.0 Y1 Tap 4
Y2 Tap 5
Y1=785/1350 CFM
[370/637] L/s
Y2=1249/1844 CFM
[589/870] L/s
11X11
3/4 hp 5 speed
Y1
Low Static Tap 2
CFM 1280 1196 1134 1080 1011 945 880 785 ——
RPM 591 620 665 710 742 781 818 853 ——
Watts 165 170 175 192 200 209 220 231 — —
Y2
Low Static Tap 3
CFM 1686 1632 1586 1538 1491 1447 1400 1352 1298 1249
RPM 733 770 801 830 863 891 922 953 982 1008
Watts 334 355 362 370 387 394 411 424 438 450
Y1
High Static Tap 4
CFM 1350 1296 1240 1188 1130 1067 1002 931 849 —
RPM 612 654 695 734 772 811 840 874 908 —
Watts 179 198 205 225 236 242 253 260 276 —
Y2
High Static Tap 5
CFM 1844 1796 1753 1702 1655 1612 1566 1520 1478 1429
RPM 794 823 852 880 908 938 968 997 1020 1044
Watts 434 448 460 470 490 502 512 530 540 553
6024ST
With 30 kW
Heater
5.0 Y1 Tap 4
Y2 Tap 5
Y1=745/1310 CFM
[353/620] L/s
Y2=1209/1804 CFM
[570/851] L/s
11X11
3/4 hp 5 speed
Y1
Low Static Tap 2
CFM 1240 1156 1094 1040 971 905 840 745 ——
RPM 621 650 695 740 772 811 848 883 — —
Watts 170 175 180 197 205 214 225 236 — —
Y2
Low Static Tap 3
CFM 1646 1592 1546 1498 1451 1407 1360 1312 1258 1209
RPM 763 800 831 860 893 921 952 983 1012 1038
Watts 339 360 367 375 392 399 416 429 443 455
Y1
High Static Tap 4
CFM 1310 1256 1200 1148 1090 1027 962 891 809 —
RPM 642 684 725 764 802 841 870 904 938 —
Watts 184 203 210 230 241 247 258 265 281 —
Y2
High Static Tap 5
CFM 1804 1756 1713 1662 1615 1572 1526 1480 1438 1389
RPM 824 853 882 910 938 968 998 1027 1050 1074
Watts 439 453 465 475 495 507 517 535 545 558
Airflow Performance Data RH2T
Air Electrical Data
RH1T/RH2T Series
21
Model
RH2T Voltage Phase* Hertz HP RPM Speeds Circuit
Amps.
Minimum
Circuit
Ampacity
Maximum
Circuit
Protector
2421MT
208/240 1 & 3 60
1/3 300-1100 4 1.6 215
3621MT 3/4 300-1100 4 3.8 515
6024ST/4824MT 3/4 300-1100 4 4.6 615
Air Handler
Model
RH2T
Heater
Model
No.
Heater kW
(208/240V)
(480V)
Ph/Hz
No.
Elements
- kW Per
Type Supply
Circuit
Single Circuit
Multiple Circuit
Circuit
Amps.
Motor
Ampacity
Minimum
Circuit
Ampacity
Maximum
Circuit
Protector
2421MT
RXBH-1724?03J 2.25/3.0 1/60 1-3.0 SINGLE 10.8/12.51.6 1.6 16/18 20/20
RXBH-1724?05J 3.6/4.8 1/60 1-4.8 SINGLE 17.3/20.0 1.6 24/27 25/30
RXBH-1724?07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 1.6 35/40 35/40
RXBH-1724?10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 1.6 46/52 50/60
RXBH-1724A13J 9.4/12.5 1/60 3-4.17 SINGLE 45.1/52.1 1.6 59/68 60/70
RXBH-1724A13J 3.1/4.2 1/60 1-4.17 MULTIPLE CKT 1 15.0/17.4 1.6 21/24 25/25
6.3/8.3 1/60 2-4.17 MULTIPLE CKT 2 30.1/34.7 0 38/44 40/45
RXBH-1724A07C 5.4/7.2 3/60 3-2.4 SINGLE 15.0/17.3 1.6 21/24 25/25
RXBH-1724A10C 7.2/9.6 3/60 3-3.2 SINGLE 20.0/23.1 1.6 27/31 30/35
RXBH-1724A13C 9.4/12.5 3/60 3-4.17 SINGLE 26.1/30.1 1.6 35/40 35/40
3621MT
RXBH-1724?05J 3.6/4.8 1/60 1-4.8 SINGLE 17.3/20.0 3.8 27/30 30/30
RXBH-1724?07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 3.8 38/43 40/45
RXBH-1724?10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 3.8 48/55 50/60
RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60.0 3.8 70/80 70/80
RXBH-1724A15J 3.6/4.8 1/60 1-4.8 MULTIPLE CKT 1 17.3/20.0 3.8 27/30 30/30
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0.0 44/50 45/50
RXBH-1724A18J 12.8/17.0 1/60 4-4.26 SINGLE 61.6-70.8 3.8 82/94 90/100
RXBH-1724A18J 6.4/8.5 1/60 2-4.26 MULTIPLE CKT 1 30.8/35.4 3.8 44/49 45/50
6.4/8.5 1/60 2-4.26 MULTIPLE CKT 2 30.8/35.4 0.0 39/45 40/45
RXBH-1724A07C 5.4/7.2 3/60 3-2.4 SINGLE 15.0/17.3 3.8 24/27 25/30
RXBH-1724A10C 7.2/9.6 3/60 3-3.2 SINGLE 20.0/23.1 3.8 30/34 30/35
RXBH-1724A15C 10.8/14.4 3/60 3-4.8 SINGLE 30.0/34.6 3.8 43/48 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-2.84 SINGLE 35.6-41.0 3.8 50/56 50/60
RXBH-1724B05J 3.6/4.8 1/60 1-4.8 SINGLE 17.3/20.0 3.8 27/30 30/30
RXBH-1724B07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 3.8 38/43 40/45
RXBH-1724B10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 3.8 48/55 60/60
* Blower motors are all single phase motors.
• ? Heater Kit Connection Type A = Breaker B = Terminal Block C = Pullout Disconnect
➀D Voltage = 480 Volts.
*Values only. No single point kit available.
NOTES:
• Electric heater BTUH - (heater watts + motor watts) x 3.414 (see airflow table for motor watts.)
• Supply circuit protective devices may be fuses or “HACR” type circuit breakers.
• If non-standard fuse size is specified, use next size larger standard fuse size.
• Largest motor load is included in single circuit or circuit 1 of multiple circuits.
• Heater loads are balanced on 3 phase models with 3 or 6 heaters only.
• No electrical heating elements are permitted to be used with A voltage (115V) air handler.
• J voltage (208/240V) single phase air handler is designed to be used with single or three phase
208/240V volt electric heaters. In the case of connecting 3 phase power to air handler terminal block
without the heater, bring only two leads to terminal block, cap, insulate and fully secure the third lead.
• Do not use 480V electrical heaters on 208/240V air handlers.
• If the kit is listed under both single and multiple circuits, the kit is shipped from factory as multiple
circuits. For single phase application, Jumper bar kit RXBJ-A21 and RXBJ-A31 can be used to convert
multiple circuits to a single supply circuit. Refer to Accessory Section for details.
[ ] Designates Metric Conversions
Electrical Data – With Electric Heat
Installation of the U.L. Listed original equipment manufacturer provided heater kits listed in the following table is recommended for all
auxiliary heating requirements.
Electrical Data – Blower Motor Only – No Electric Heat RH2T
Air Electrical Data
RH1T/RH2T Series
22
Air Handler
Model
RH2T
Heater
Model
No.
Heater kW
(208/240V)
(480V)
Ph/Hz
No.
Elements
- kW Per
Type Supply
Circuit
Single Circuit
Multiple Circuit
Circuit
Amps.
Motor
Ampacity
Minimum
Circuit
Ampacity
Maximum
Circuit
Protector
4824MT
6024ST
RXBH-1724?07J 5.4/7.2 1/60 2-3.6 SINGLE 26.0/30.0 4.6 39/44 40/45
RXBH-1724?10J 7.2/9.6 1/60 2-4.8 SINGLE 34.6/40.0 4.6 49/56 50/60
RXBH-1724A15J 10.8/14.4 1/60 3-4.8 SINGLE 51.9/60.0 4.6 71/81 80/90
RXBH-1724A15J 3.6/4.8 1/60 1-4.8 MULTIPLE CKT 1 17.3/20.0 4.6 28/31 30/35
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0 44/50 45/50
RXBH-1724A18J 12.8/17 1/60 4-4.26 SINGLE 61.8/70.8 4.6 83/95 90/100
RXBH-1724A18J 6.4/8.5 1/60 2-4.26 MULTIPLE CKT 1 30.8/35.4 4.6 45/50 45/50
6.4/8.5 1/60 2-4.6 MULTIPLE CKT 2 30.8/35.4 0 39/45 40/45
RXBH-24A20J 14.4/19.2 1/60 4-4.8 SINGLE 69.2/80 4.6 93/106 100/110
RXBH-24A20J 7.2/9.6 1/60 2-4.8 MULTIPLE CKT 1 34.6/40.0 4.6 49/56 50/60
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0 44/50 45/50
RXBH-24A25J 18.0/24.0 1/60 6-4.0 SINGLE 86.4/99.9 4.6 114/131 125/150
RXBH-24A25J
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 1 28.8/33.3 4.6 42/48 45/50
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 2 28.8/33.3 0 36/42 40/45
6.0/8.0 1/60 2-4.0 MULTIPLE CKT 3 28.8/33.3 0 36/42 40/45
RXBH-24A30J
(5-ton only) 21.6/28.8 1/60 6-4.8 SINGLE 103.8/120 4.6 136/156 150/175
RXBH-24A30J
(5-ton only)
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 1 34.6/40.0 4.6 49/56 56/60
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 2 34.6/40.0 0 44/50 56/60
7.2/9.6 1/60 2-4.8 MULTIPLE CKT 3 34.6/40.0 0 44/50 56/60
RXBH-1724A07C 5.4/7.2 3/60 3-2.4 SINGLE 15.0/17.3 4.6 25/28 25/30
RXBH-1724A10C 7.2/9.6 3/60 3-3.2 SINGLE 20.0/23.1 4.6 31/35 35/35
RXBH-1724A15C 10.8/14.4 3/60 3-4.8 SINGLE 30.0/34.6 4.6 44/49 45/50
RXBH-1724A18C 12.8/17.0 3/60 3-2.84 SINGLE 35.6-41.0 4.6 51/57 60/60
RXBH-24A20C* 14.4/19.2 3/60 3-3.2 SINGLE 40.0-46.2 4.6 56/64 60/70
RXBH-24A20C 7.2/9.6 3/60 3-3.2 MULTIPLE CKT 1 20.0/23.1 4.6 31/35 35/35
7.2/9.6 3/60 3-3.2 MULTIPLE CKT 2 20.0/23.1 0 25/29 25/30
RXBH-24A25C* 18.0/24.0 3/60 6-4.0 SINGLE 50.0/57.8 4.6 69/78 70/80
RXBH-24A25C 9.0/12.0 3/60 3-4.0 MULTIPLE CKT 1 25.0/28.9 4.6 37/42 40/45
9.0/12.0 3/60 3-4.0 MULTIPLE CKT 2 25.0/28.9 0 32/37 35/40
RXBH-24A30C*
(5-ton only) 21.6/28.8 3/60 6-4.8 SINGLE 60.0/69.4 4.6 81/93 90/100
RXBH-24A30C
(5-ton only)
10.8/14.4 3/60 3-4.8 MULTIPLE CKT 1 30.0/34.7 4.6 44/50 45/50
10.8/14.4 3/60 3-4.8 MULTIPLE CKT 2 30.0/34.7 0 38/44 40/45
• ? Heater Kit Connection Type A = Breaker B = Terminal Block C = Pullout Disconnect
➀D Voltage = 480 Volts.
*Values only. No single point kit available.
NOTES:
• Electric heater BTUH - (heater watts + motor watts) x 3.414 (see airflow table for motor watts.)
• Supply circuit protective devices may be fuses or “HACR” type circuit breakers.
• If non-standard fuse size is specified, use next size larger standard fuse size.
• Largest motor load is included in single circuit or circuit 1 of multiple circuits.
• Heater loads are balanced on 3 phase models with 3 or 6 heaters only.
• No electrical heating elements are permitted to be used with A voltage (115V) air handler.
• J voltage (208/240V) single phase air handler is designed to be used with single or three phase
208/240V volt electric heaters. In the case of connecting 3 phase power to air handler terminal block
without the heater, bring only two leads to terminal block, cap, insulate and fully secure the third lead.
• Do not use 480V electrical heaters on 208/240V air handlers.
• If the kit is listed under both single and multiple circuits, the kit is shipped from factory as multiple
circuits. For single phase application, Jumper bar kit RXBJ-A21 and RXBJ-A31 can be used to convert
multiple circuits to a single supply circuit. Refer to Accessory Section for details.
[ ] Designates Metric Conversions
Electrical Data – With Electric Heat RH2T
Installation of the U.L. Listed original equipment manufacturer provided heater kits listed in the following table is recommended for all
auxiliary heating requirements.
Air Electrical Wiring
RH1T/RH2T Series
23
Electrical Wiring
Power Wiring
• Field wiring must comply with the National Electrical Code
(C.E.C. in Canada) and any applicable local ordinance.
• Supply wiring must be 75°C minimum copper conductors only.
• See electrical data for product Ampacity rating and Circuit
Protector requirement.
Grounding
• This product must be sufficiently grounded in accordance with
National Electrical Code (C.E.C. in Canada) and any applicable
local ordinance.
• A grounding lug is provided.
RXHF-
Accessories
•Auxiliary Horizontal Overflow Pan Accessory RXBM-
•Combustible Floor Base RXHB-
•Jumper Bar Kit 3 Ckt. to 1 Ckt. RXBJ-A31 is used to convert
single phase multiple three circuit units to a single supply
circuit. Kit includes cover and screw for line side terminals.
•Jumper Bar Kit 2 Ckt. to 1 Ckt. RXBJ-A21 is used to convert
single phase multiple two circuit units to a single supply circuit.
Kit includes cover and screw for line side terminals.
•Note: No jumper bar kit is available to convert three phase
multiple two circuit units to a single supply circuit.
•Auxiliary Electric Heater Kits RXBH-
Heater Kits include circuit breakers which meet UL and cUL
requirements for service disconnect. See the Electric Heat
Electrical Data in this specification sheet for specific Heater Kit
Model numbers.
•External Filter Rack RXHF-B17, B21, B24
*Accommodates 1" filter
[ ] Designates Metric Conversions
17
21
24
RXHB-17
RXHB-21
RXHB-24
Model Cabinet Size Combustible Floor
Base Model Number
Nominal Cooling
Capacity-Tons
Auxiliary Horizontal Overflow Pan
Accessory Model Number
11/2- 3 RXBM-AC48
31/2- 5 RXBM-AC61
RXHF-B
BA
BA
11/2⬙
[38 mm]
•External Filter Base RXHF-
*Accommodates 1" or 2" filter
•Horizontal Adapter Kit RXHH-
This horizontal adapter kit is used to convert Upflow/Downflow
only models to horizontal flow. See the following table to order
proper horizontal adapter kit.
Model Cabinet Size Filter Size In. [mm]
21 20 x 20 [508 x 508]
Part Number*
RXHF-21
RXHF-2424 25 x 20 [635 x 508] 22.70
19.20
A
25.5
21.0
B
Model Cabinet Size Part Number*
RXHF-B17
RXHF-B21
Filter Size In. [mm]
RXHF-B24
24 25 x 20 [635 x 508]
17 16 x 20 [406 x 508]
21 20 x 20 [508 x 508]
A
16.90
20.40
25.00
B
20.77
20.77
21.04
•External Filter Base RXHF-
*Accommodates 1" or 2" filter
Model Cabinet Size Filter Size In. [mm]
17 16 x 20 [406 x 508]
21 20 x 20 [508 x 508]
Part Number*
RXHF-17
RXHF-21
RXHF-2424 25 x 20 [635 x 508] 22.70
19.20
15.70
A
25.5
21.0
17.5
B
Coil Model Horizontal Adapter Kit
Model Number (10-Pack Qty.)
RXHH-A01 x 10
RXHH-A02 x 10
Horizontal Adapter Kit
Model Number (Single Qty.)
RXHH-A03 x 103617/3621 RXHH-A03
2414 RXHH-A01
2417 RXHH-A02
3821/4821/4824 RXHH-A04 RXHH-A04 x 10
6024 RXHH-A05 RXHH-A05 x 10
Air Limited Warranty
RH1T/RH2T Series
24
GENERAL TERMS OF LIMITED WARRANTY*
Rheem will furnish a replacement for any part of this product
which fails in normal use and service within the applicable
periods stated, in accordance with the terms of the limited
warranty.
Conditional Parts (Registration Required) ..........Ten (10) Years
*For complete details of the Limited and Conditional Warranties, including
applicable terms and conditions, contact your local contractor or the
Manufacturer for a copy of the product warranty certificate.
Air Notes
RH1T/RH2T Series
25
Air Notes
RH1T/RH2T Series
26
Air Notes
RH1T/RH2T Series
27
The new degree of comfort.
™
Rheem Heating, Cooling & Water Heating • P.O. Box 17010
Fort Smith, Arkansas 72917 • www.rheem.com
In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.
PRINTED IN U.S.A 7/14 QG FORM NO. H11-553 REV. 1
Rheem Canada Ltd./Ltée • 125 Edgeware Road, Unit 1
Brampton, Ontario • L6Y 0P5
