owner's manual
18272692 Williams Legato III Keyboard Manual V2.indd 1 6/29/18 2:05 PM
2
OWNER'S MANUAL
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
IMPORTANT SAFETY INSTRUCTIONS
Do not use near water.
Clean only with a soft, dry cloth.
Do not block any ventilation openings.
Do not place near any heat sources such as radiators, heat registers, stoves, or any other apparatus
(including ampliers) that produces heat.
Protect the power cord from being walked on or pinched.
Only use the included attachments/accessories.
Unplug this apparatus during lightning storms or when unused for a long period of time.
Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
FCC STATEMENTS
1) Caution: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
2) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
18272692 Williams Legato III Keyboard Manual V2.indd 2 6/29/18 2:05 PM
3
LEGATO III DIGITAL PIANO
WILLIAMSPIANOS.COM
INTRODUCTION
Congratulations! You have just purchased a state-of-the-art digital piano that provides remarkable acoustic
sound and feel. We recommend that you read through this owner's manual carefully, so you can get the most
enjoyment from your new piano.
Features:
• 88-key touch-sensitive piano keyboard
• 10 piano & keyboard sounds
• Metronome feature with variable tempo to facilitate practice or recording
• 10 Demo songs corresponding to each voice
• USB MIDI connections
• Stereo/mono line out jacks
• Bluetooth MIDI
• Music rest
• Battery operation (6 x D-cell 1.5V batteries are not included)
• AC Adapter
• Sustain Pedal
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and
any use of such marks by Williams is under license. Other trademarks and trade names are those of their
respective owners.
iPad is a registered trademark of Apple, Inc.
BEFORE YOU GET STARTED
Shipment
Your piano was carefully packed at the factory, and the packaging was designed to protect the unit from
rough handling. Nevertheless, we recommend that you carefully examine the packaging and its contents for
any signs of physical damage that may have occurred during transit.
• If the unit is damaged, notify us immediately at 1-888-241-1582.
• Always use the original packing carton to prevent damage during storage or transport.
• Make sure that no children are left unsupervised with the piano or its packaging.
• Please ensure proper disposal of all packing materials.
INITIAL OPERATION / QUICK START
• Set the piano on a secure, at surface at a comfortable height for playing.
• Insert the AC adapter into the back panel. Then plug in the power cord into a 110V supply.
• Plug the sustain pedal into the Sustain jack on the back panel of the piano.
• Insert the supplied music rest into the two slots on the top panel.
• Press the power switch on the left side of the front panel. The LED on the button will light.
• NOTE: Set the volume control at minimum level when you connect the unit to power.
• Press the Voice Select button for the desired voice.
• Adjust the volume control.
18272692 Williams Legato III Keyboard Manual V2.indd 3 6/29/18 2:05 PM
4
OWNER'S MANUAL
IMPORTANT SAFETY INSTRUCTIONS ............. 2
INTRODUCTION ................................................. 3
BEFORE YOU GET STARTED ............................ 3
INITIAL QUICK START ........................................ 3
TAKING CARE OF YOUR DIGITAL PIANO ........ 5
TOP PANEL ......................................................... 6
BACK PANEL ....................................................... 6
BOTTOM PANEL ................................................. 6
DEMO SONGS ..................................................... 7
OPERATIONS ...................................................... 7
TUNING ................................................................ 8
MENUS AND BUTTONS ..................................... 9
ADVANCED FUNCTIONS ................................. 10
Factory Reset ................................................ 10
Velocity Curves .............................................. 10
MIDI ............................................................... 11
MIDI Channels ............................................... 11
Local ON/OFF ............................................... 11
Multitimbral Mode ......................................... 11
MIDI Channel Mode ...................................... 11
MIDI Panic Reset ........................................... 11
Auto Power On/Off ....................................... 12
Memory Autosave ......................................... 12
SPECIFICATIONS .............................................. 12
KEYBOARD SHORTCUTS ................................ 13
PARAMETER VALUES ...................................... 14
WARRANTY ....................................................... 15
TABLE OF CONTENTS
18272692 Williams Legato III Keyboard Manual V2.indd 4 6/29/18 2:06 PM
5
LEGATO III DIGITAL PIANO
WILLIAMSPIANOS.COM
TA K I NG CARE OF YOUR DIGITAL PIANO
This Williams Legato III digital piano will supply you with years of musical enjoyment if you follow the
suggestions listed below.
Product Servicing
This product should be serviced by qualied service personnel when:
• The power supply cord or the plug has been damaged.
• Liquid has been spilled into the unit or it has been exposed to rain.
• The instrument does not appear to operate normally or exhibits a marked change in performance.
• The instrument has been dropped or the cabinet has been damaged.
• Please contact support@williamspianos.com or call 888-241-1582 for parts and service information.
Handling and Transport
• Never apply excessive force to the controls, connectors or other parts of the instrument.
• Always unplug cables by gripping the plug rmly, not by pulling on the cable.
• Disconnect all cables before moving the instrument.
• Physical shocks caused by dropping, bumping, or placing heavy objects on the instrument can result
in supercial or operational damage.
• Carefully check the volume control before playing. Excessive volume can cause permanent hearing loss.
Cleaning
• Clean the cabinet and panel with a soft, dry cloth. Do not use paint thinner or petrochemical-
based polishes.
• To maintain the luster of the keys and buttons, wipe with a clean, lightly dampened cloth, and then
polish with a soft, dry cloth.
Location
• To avoid deformation, discoloration, or more serious damage, do not expose the instrument to
the following conditions: Direct sunlight, high temperatures, excessive humidity, excessive dust,
strong vibration.
• Leave enough space around the piano for proper ventilation.
• This instrument contains digital circuitry and may cause or be susceptible to interference if placed
too close to radio, television receivers, or mobile phones. If interference occurs, move the instrument
further away from the affected equipment.
• Avoid placing vinyl objects on top of the instrument, vinyl can stick to and discolor the surface.
Power
• Turn the power off when the instrument is not in use.
• To avoid damage to the instrument and other devices to which it is connected, turn the power
switches of all related devices off prior to connection or disconnection of MIDI cables.
• Turn the power off if the main cable is damaged, or the instrument has been exposed to liquid.
• Do not switch the unit on and off in quick succession, as this places an undue load on the
electronic components.
• Unplug the DC power adapter during an electrical storm.
• Avoid plugging the DC power adapter into the same AC outlet as appliances with high power
consumption, such as electric heaters or ovens.
18272692 Williams Legato III Keyboard Manual V2.indd 5 6/29/18 2:06 PM
6
OWNER'S MANUAL
TOP PANEL
Power On/Off
Press the [POWER] button in the upper left corner of the front panel. The LED light in the button will stay on
when the piano is on.
Volume Knob
Controls the overall output volume of the piano.
Function Button Group
Reverb Button, Chorus Button, Metronome Button, Bluetooth Button
Voice Select Buttons
Piano, Electric Piano, Organ, Synth, Bass
Split
Divides the keyboard into two zones with different voices
BACK PANEL
USB Input
For computer connection, the USB connection supports Class Compliant MIDI Drivers to use with MIDI
Sequencer applications.
Sustain Input
The sustain pedal will function in a similar method as an acoustic piano sustain pedal. Using this pedal will
allow the piano key sounds to decay slowly. Plug in the included sustain pedal here. The jack will auto-detect
the polarity of the sustain pedal, making it compatible with most sustain pedal brands and models.
Outputs
Stereo/ Mono Line Out ¼” Jacks. The output jacks supply a line-level signal for external amplication. Use
both jacks for stereo or just the Left jack for mono.
Headphone
The headphone jack disables the speakers when headphones are connected.
Power Input
Connection for the Included DC power adapter.
BOTTOM PANEL
Battery Compartment
The product can either be powered via a power supply or battery. If batteries are inserted while the
unit is powered from a power supply, no power will be drawn from the batteries. The piano requires
six D-cell 1.5V batteries.
18272692 Williams Legato III Keyboard Manual V2.indd 6 6/29/18 2:06 PM
7
LEGATO III DIGITAL PIANO
WILLIAMSPIANOS.COM
DEMO SONGS
There are 10 demo songs in the Legato III
piano. Each demo song plays in a style to t the
selected sound.
Demo Song Voice
1 Grand Piano
2 Tine Electric Piano
3 Perc. Organ
4 String Pad
5 Acoustic Bass
6 Bright Piano
7 Reed Electric Piano
8 Full Drawbar Organ
9 Synth Pad
10 Electric Bass
The demo songs may be selected by pressing
and holding the Metronome and Bluetooth
buttons together for 5 seconds, then selecting a
sound to play.
OPERATIONS
Function Mode allows you to change
parameters for Voices, Voice Volume Level,
Layer Mode, Layer Volume Level, Split Mode,
Split Volume, Split Point and Tuning.
To enter Function Mode, press and hold the
Chorus and Reverb buttons together.
Parameter values are entered using the
keyboard, which is scaled so that the keys in
the lower octaves provide low values and the
keys in the upper octaves provide high values.
C7=127 Press and hold data entry functions
should activate after 1.5 seconds.
See Appendix on pg. 13-14.
Voices
The Legato III piano has 10 built-in voices.
Each voice may be selected by pressing one of
the Voice Select buttons on the front panel. If
the button is pressed a second time, the LED
turns orange and the Variation sound is heard.
Voices can be layered to produce two voices
at once, or assigned to the left or right hands
in the split mode.
Voices include: Piano, Electric Piano, Organ,
Synth and Bass, with a variation of each.
To select a voice, press the Voice Select
button that relates to the sound listed above
the button.
The button will light and the LED will indicate
the selection.
Changing the Voice Volume Level
The Voice Volume can be adjusted from the
keyboard. You should only want to do this if you
are layering or splitting the keyboard, otherwise
simply adjust the volume from the knob on the
front panel.
1. Press and hold the Chorus and Reverb
Buttons together to enter the Function mode.
2. Pressing C#0 activates the voice
volume menu.
3. The volume can be changed in 88 note
steps from 0-127 by pressing a key on the
keyboard. (Higher keys make the voice
louder, lower keys make it softer.)
4. Release the Reverb and Chorus Buttons to
exit Function mode.
Layer Mode
In Layer mode two voices may be played
simultaneously.
1. To layer two sounds, press the
corresponding voices simultaneously.
For example, hold the Piano button while
pressing Electric Piano. Both LEDs will light
up while layered.
2. To turn Layer Mode off, select a single voice
button and the other Voice will be turned off.
18272692 Williams Legato III Keyboard Manual V2.indd 7 6/29/18 2:06 PM
8
OWNER'S MANUAL
3. If you want to layer a variation sound, press
the second voice button twice.
To Change the Layer Volume Level
1. Press the Chorus and Reverb Buttons
together to enter Function mode.
2. Pressing D#0 activates the layer volume
menu. The volume can be changed in 88
note steps from 0-127 where C7=127 and
A-1=0.
3. Pressing a key will play C3 of the currently
selected layered sound at the volume
corresponding to the key value.
4. Release the Reverb and Chorus Buttons to
exit the Function mode.
Split Mode
Split Mode allows the keyboard to be divided
into two sections so that different voices may
be played with the left and right hands. The
volume may be independently adjusted for each
voice, the Split Point (the highest note played
with the left hand) may be adjusted and the
Split Voice may be changed as desired.
To Enter Split Mode
Press the [SPLIT] button to enter Split mode.
Press it again to disable Split mode.
The Split (left hand) voice will be Acoustic Bass
and the Split Point will be B2.
To Change the Split Volume
1. Press the Chorus and Reverb Buttons
together to enter Function mode.
2. Pressing D#2 activates the Split Volume
menu. (See Appendix on Pg 13.)
3. The volume can be changed in 88 note
steps from 0-127 where C7=127 and A-1=0.
4. Release the Chorus and Reverb Buttons to
exit Function mode.
To Change the Split (Left Hand) Voice
Press and hold the [SPLIT] button while
depressing the desired Voice Select button.
To select a variation sound, press the voice
button twice.
To Change the Split Point
1. Press and hold the Split button.
2. Press the key that you want to be the top note
of the bottom split.
3. Release the Split button.
TUNING
To change the tuning of the piano (at
or sharp):
1. Press the Chorus and Reverb Buttons
together to enter Function mode.
2. Press the A#-1 key to activate the tuning
menu. The keyboard will now play middle
C piano 1 voice (C3) on every note across
the keyboard. Playing middle C (C3) sets
for standard tuning, playing keys above and
below tune the piano sharp or at up to a
semitone. (See Appendix Pg 13.)
3. Release the Chorus and Reverb Buttons
to exit Function mode.
To transpose the keyboard:
1. Press the Chorus and Reverb Buttons
together to enter the Function mode.
2. Press the C#2 key
3. Play a key on the keyboard to set the
transpose in relation to middle C (C3.) If you
would like to transpose up an octave, play C4
an octave above middle C. If you would like
to transpose down a fourth, play G2. You can
transpose the keyboard up to two octaves up
or down.
4. Release the Chorus and Reverb buttons
when you are nished selecting the transpose.
18272692 Williams Legato III Keyboard Manual V2.indd 8 6/29/18 2:06 PM
9
LEGATO III DIGITAL PIANO
WILLIAMSPIANOS.COM
5. To disable transposition, either select
Function + C#2 again or turn the power off
and on.
MENUS &
BUTTONS
There are 4 function buttons on the Legato
III that control various functions. These are
Metronome, Bluetooth, Chorus and Reverb.
Reverb and Chorus Buttons
The Reverb and Chorus effects may be applied
to each voice individually and will be retained
even when the power is turned off.
To apply the effect, press either button. The
button will light and the effect will be heard
when the piano is played.
To turn off the effect, press the button of the
desired effect again and the LED light will go off.
To modify the depth of the effects
1. Press and hold the effect button
2. While this function is active the LED should
blink. You can then release the button and
press a key on the keyboard corresponding
to the setting you want for the reverb
depth. It's possible to change the setting by
pressing multiple keys after each other until
the right setting is found.
3. Set the reverb or chorus depth by pressing
a key on the keyboard to select the value.
See the Appendix for the value ranges.
4. The keyboard should still play the sound
originally selected so the user can hear the
new setting with the sound selected.
5. To exit, press the Reverb or Chorus
button again.
Reverb and Chorus settings are set per
Instrument and retained over power cycling.
Mod FX
There is an additional, hidden effect called
“Mod FX.” On the organ sounds, this creates
a rotary speaker effect with speed controlled
by the sustain pedal. On Electronic Pianos, it
creates a Tremolo effect. It is switched off for
most sounds except for the organ. To switch
Mod FX on or off, press Function (Chorus
+ Reverb together) and press A#2 on the
keyboard.
Metronome Button
1. Press the METRONOME button to activate
the metronome function. You can hear the
click in headphones or speakers. When on,
the button LED is lit.
2. To set the level of the metronome click, hold
the Function keys (Chorus + Reverb) and
press F#0 on the keyboard.
3. You can then select the level by pressing a
key on the keyboard. Higher keys make the
metronome louder.
4. Press the Metronome button again to
disable the metronome.
Metronome Tempo
Follow these steps to change the speed of
the metronome.
1. To change the tempo, press and hold the
Metronome button. If the Metronome is off,
no sound will be heard.
2. Press any white key on the keyboard to
select a tempo. The LED will blink to the
new value.
3. To exit, release the Metronome button.
See the Appendix on page 14 for a chart of
metronome tempos.
The tempo defaults to 120 and the tempo
setting is retained when powered off. 120BPM
is selected by pressing C3 (Middle C.)
See the Appendix for a chart of Metronome
settings.
18272692 Williams Legato III Keyboard Manual V2.indd 9 6/29/18 2:06 PM
10
OWNER'S MANUAL
Changing the Time Signature
Pressing the Chorus and Reverb buttons allows
the user to change the time signature for the
metronome. When this menu is selected the
metronome starts playing at the current tempo
setting. Pressing Function (Chorus and Reverb
together) then G#0 toggles through the time
signature options starting with the current
setting. The default time signature is 4/4 and
the following options are also available: 2/4, 3/4,
4/4, 5/4, 6/8, 9/8, 12/8.
Bluetooth
The Legato III includes Bluetooth wireless MIDI
for connection to apps like the Williams App
for iOS. To connect the piano to your tablet,
smartphone, or computer:
1. Press the Bluetooth button. If you have
not yet paired a device, the LED will
ash quickly.
2. Open the Bluetooth MIDI settings in your
app and select the Legato III.
NOTE: The Legato III will not show up in the
“Bluetooth” device list on your phone. Your
app needs to support Bluetooth MIDI to work
with the Legato III. If the app doesn't support
Bluetooth MIDI, you can still use it with a
USB adapter
3. The Bluetooth button LED should stop
ashing once it is paired with a device.
To disable Bluetooth, press the button again so
that the LED switches off. Bluetooth MIDI allows
you to connect with piano learning apps on a
variety of devices.
Williams App
Download the Williams iOS app for iPhone,
iPad, and iPod Touch to access advanced
features of your Legato III. Visit williamspianos.
com to learn more.
ADVANCED
FUNCTIONS
Advanced Function Mode
To enter Advanced Function Mode, press
and hold the Chorus and Reverb buttons
simultaneously. The keyboard does not play
a sound at this point but is used for menu
selection as per the information below.
To accept a menu setting release the Chorus
and Reverb buttons. This will exit the Edit menu
and then you will have to re-enter the Edit menu
to make changes to other settings.
Factory Reset
Performing a Factory Reset will clear all battery
backed memory and restore all functions to
factory defaults.
1. Turn the Power Off.
2. Hold down the [REVERB] and [CHORUS]
buttons while powering on the piano (The
LED Display will light ALL segments and all
LEDs on the device will light).
3. Release the [REVERB] and
[CHORUS] buttons.
Velocity Curves
You can change the way the keyboard
responds to your playing by adjusting the
Velocity curve settings
1. Press the Chorus and Reverb Buttons
together to enter the Function mode.
2. Press F#1, G#1 and A#1 to select between
Low, Normal and High velocity curves.
When selecting F#1 low, Piano 1 C3 will
play at velocity value 30. When G#1 Normal
is selected, Piano 1 C3 will play at velocity
value 70. When A#1 High is selected, Piano
1 C3 will play at velocity value 127 and the
piano will exit Function Mode automatically.
18272692 Williams Legato III Keyboard Manual V2.indd 10 6/29/18 2:06 PM
11
LEGATO III DIGITAL PIANO
WILLIAMSPIANOS.COM
Velocity Curve Table
F#1 Low Velocity
G#1 Normal Velocity
A#1 High Velocity
MIDI
The Musical Instrument Digital Interface
(MIDI) is an industry-standard protocol that
enables electronic musical instruments such as
keyboards, computers, drum machines, etc. to
communicate, control and synchronize with each
other. MIDI transmissions consist of electronic
codes that communicate notes to be played, the
instrument, pitch or intensity that notes are to
be played with, and the controlling codes such
as volume, vibrato, cues and clock signals. MIDI
data can be transmitted and received either
through the USB jack or a Bluetooth connection.
The Legato III has several functions that facilitate
its use as a MIDI device or controller.
MIDI Channels
The Legato III has 16 channels numbered from
1-16. Each of the channels is responsible for
a voice. When the instrument receives MIDI
information from an external device, the active
channel is determined by the control message.
The transmission channels are xed as follows:
Channel 1 Master voice (keyboard)
Channel 2 Split voice (keyboard)
Channel 3 Layer voice (keyboard)
Local On/Off
Turning the Local On/Off function to “Off” will
disconnect the keyboard from the internal
sound engine of the piano. The Legato III may
then be used as a MIDI controller to control
other MIDI devices or virtual instrument
software running on a computer, without
playing the sounds on the piano. Additionally,
it may be desirable to turn local playing off for
other requirements such as when using MIDI
sequencing software on your computer.
1. Press the Chorus and Reverb Buttons
together to enter the Function mode.
2. Pressing D#1 allows the user to switch
local on or off. When D#1 is rst pressed
the current setting is conrmed by Piano 1
C3 playing once for on and twice for off.
Pressing D#1 again will change the setting
playing Piano 1 C3 the amount of times
equivalent to the new setting.
3. Release the Chorus and Reverb Buttons
Multitimbral Mode
The Legato III is able to receive MIDI information
on up to 16 channels simultaneously. If you
plan to use your piano with a multitrack MIDI
recording system, you can record up to 16
different parts using the Williams Legato
III voices, each played back individually
on different MIDI channels. To ensure your
recorded part is played back with the correct
voice, make sure to press the voice button rst
and play your part second.
NOTE: Because the Legato III is receiving
playback information via MIDI, the currently
selected voice on the piano may not correspond
to the voice being played back.
MIDI Channel Modes
1. Press and hold the Chorus and Reverb
Buttons together to enter the Function mode.
2. Pressing A#0 allows you to change the MIDI
channel. The main piano sound will play
Piano 1 C3 the amount of times equivalent
to the current value. So if MIDI channel 5 is
selected it will play 5 times. You then press
A#0 ve times to select channel 10. Piano 1
C3 will play the amount of times equivalent
to the current setting, after 2 seconds of
inactivity. Once 16 is reached, pressing one
more time will select 1.
3. Release the Chorus and Reverb Buttons to
exit the Function mode.
18272692 Williams Legato III Keyboard Manual V2.indd 11 6/29/18 2:06 PM
12
OWNER'S MANUAL
MIDI Panic Reset
1. Press the Chorus and Reverb Buttons
together to enter the Function mode.
2. Pressing C#1 allows the user to activate
Panic, which send out general MIDI reset
messages such as all note off, etc. Once
Panic reset has been completed, Piano will
automatically exit Edit mode.
Auto Power On/Off
1. Press the Chorus and Reverb Buttons
together to enter the Function Mode.
2. Pressing F#2 allows the user to switch auto
Power On or Off. When F#2 is rst pressed,
the current setting is conrmed by Piano 1
C3 playing once for On and twice for Off.
Pressing F#2 again will change the setting
playing Piano 1 C3 the amount of times
equivalent to the new setting.
3. Release the Chorus and Reverb buttons to
exit the Function Mode.
NOTE: If this function is switched on, the
unit will automatically power o after 30
minutes if there is no operation, unless the
demo is playing.
Memory Autosave
When modifying the settings of the Williams
Legato III the following settings will be saved
after you turn off the keyboard — Reverb,
Chorus (for each voice), Main Volume, Layer
Volume, Split Volume, MIDI Channel, Velocity
Curve, Split point and Auto Power On/Off.
SPECIFICATIONS
Value
Keyboard 88-key touch-sensitive piano keyboard
Voices 10
Polyphony 64
Voice Control Layer, Touch, Split, Metronome
Demo Songs 10
MIDI Transmit Settings Local Control
Connectors USB, Sustain Pedal, 1/4” Line Out (L/R), Phones
Speakers 2x10W @ 8Ω, low freq driver
2x10W @ 8Ω, high freq driver
Dimensions 127 cm X 27.6 cm X 90 mm
Weight 8.5 kg
Supplied Owners Manual, Music Stand, Power Supply, Sustain Pedal
18272692 Williams Legato III Keyboard Manual V2.indd 12 6/29/18 2:06 PM
13
LEGATO III DIGITAL PIANO
WILLIAMSPIANOS.COM
A#-1
Tuning
C#0
Voice Volume
D#0
Layer Volume
F#0
Metronome Volume
G#0
Time Signature
A#0
MIDI Channel
C#1
MIDI Panic
D#1
Local On/Off
F#1
Soft Velocity
G#1
Normal Velocity
A#1
Hard Velocity
C#2
Transpose
F#2
Auto Power
On/Off
D#2
Split Volume
C3
Middle C
A#2
Mod FX
On/Off
KEYBOARD
SHORTCUTS
FUNCTION MODE:
To enter Advance Function Mode, press Metronome and Tempo buttons
simultaneously. The keyboard does not play a sound at this point but is
used for menu selection as per the information below.
To accept a menu setting, press the Metronome and Tempo buttons
simultaneously again. This will exit the Edit menu and then you will have
to re-enter the Edit menu to make changes to other settings.
18272692 Williams Legato III Keyboard Manual V2.indd 13 6/29/18 2:06 PM
14
OWNER'S MANUAL
TEMPO MAP
PARAMETER VALUES
BY KEY RANGE
TEMPO
VOLUME, REVERB, CHORUS
VALUE
C0 – 32 0
127
C1 – 70
C2 – 96
C3 – 120
C4 – 144
C5 – 168
C6 – 210
C7 – 280
18272692 Williams Legato III Keyboard Manual V2.indd 14 6/29/18 2:06 PM
10506404-V2.0
15
LEGATO III DIGITAL PIANO
WILLIAMSPIANOS.COM
WARRANTY
Williams provides the following limited warranty, to the original purchaser: this piano is warranted to
be free from electronic and/or structural defects in materials and workmanship for a period of one
(1) year from the date of original purchase. If this Williams piano is defective, at its option during the
warranty period, subject to the terms of this limited warranty and upon proof of purchase, Williams
will either repair or replace the listed piano with a same or similar model of equal age or newer. Any
repairs or modications must be completed by Williams and/or an authorized agent of Williams.
The warranty obligations as set forth herein shall be performed free of charge with the exception of
all delivery and shipping expenses. This limited warranty will not apply to this product in the case
of misuse, abuse, neglect, alterations, normal wear and tear or other circumstance not directly
attributed to electronic and/or structural defects in materials or workmanship. Without limiting the
foregoing, this limited warranty will also be inapplicable to products that have not been maintained
or replaced in accordance with the manufacturer’s instruction, or to products from which the serial
number has been removed or altered. If covered defects are found, contact your authorized Williams
dealer with regard to the alleged defect within ten (10) days of discovery of the problem.
The foregoing repair or replacement obligation for defective products shall be the sole and exclusive
remedy of this limited warranty. All warranties including, but not limited to, the express warranty and
the implied warranties of merchantability and tness for a particular purpose are limited to the one (1)
year warranty period. Some states do not allow limitation on how long an implied warranty lasts, so
the above limitation may not apply to you. There are no express warranties beyond those stated here.
In the event that applicable law does not allow the limitation of the duration of the implied warranties
to the warranty period, then the duration of the implied warranties shall be limited to as long as is
provided by applicable law. No warranties apply after that period. Retailer and manufacturer shall not
be liable for damages based upon inconvenience, loss of use of product, loss of time, interrupted
operation or commercial loss or any other incidental or consequential damages including but not
limited to lost prots, downtime, goodwill, damage to or replacement of equipment and/or property.
1-Year Parts & Labor Warranty
Visit us online at www.williamspianos.com
18272692 Williams Legato III Keyboard Manual V2.indd 15 6/29/18 2:06 PM
1806-18272692
18272692 Williams Legato III Keyboard Manual V2.indd 16 6/29/18 2:06 PM
