Operation and integration instructions
General Description
Radio frequency module encompassing two variants. This module operates as a frequency
hopping system in the 915MHz band. The variants have identical RF sections and only
differ in non-radio frequency parts loading with connectors and a USB to UART section.
Parts Affected
Model Number
Part Number
Interface
6LP SN
F005V19473
Serial
6LP GW
F005V19474
Mini PCI-E USB
Features
Operating band: 902 to 928MHz
Channels used: 917 to 927.6MHz
Number of channels: 50
Integration Manual
MCSS RF Module
Nominal power (radiated or conducted): 24.5dBm conducted
Modulation(s): 2GFSK 50KHz deviation
Nominal bandwidth: 100KHz
Frequency hopping transmitter
OEM installation only
Regulatory Information
The finished product is required to comply with all applicable FCC equipment
authorisations, regulations, requirements and equipment. We will provide guidance to the
host manufacturer for compliance with the FCC part 15B requirements.
The OEM integrator is responsible for ensuring that the end-user has no manual
instructions to remove or install module.
The module is limited to installation in mobile or fixed application.
Labelling and user information requirements
The end device must be labelled with the FCC ID. If the FCC identification number
of the module is not visible when the module is installed inside another device,
then the outside of the device into which the module is installed must also display
a label referring to the enclosed module.
This exterior label can use wording such as the following:
Any similar wording that expresses the same meaning may be used.
The user’s manual must include the following text:
RF Antennas
The transmitter can only be used with the following antennas:
Pulse W5012 2dBi half wave dipole connected by a 200mm Amphenol u.fl
to RP-SMA cable 336314-14-0200
Contains Transmitter Module FCC ID: LXP-6LPRF
or
Contains FCC ID: LXP-6LPRF
Warning: Any changes or modifications not expressively approved by (company
name) could void the user's authority to operate this equipment
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION
IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
Integration Manual
MCSS RF Module
Any connection used in the host system must use a unique antenna connection
on the outside of the device. Recommended connection is an RP-SMA type and
that is included in the module kit.
Antenna location must be selected to provide at least 20 cm between itself and
nearby persons.
RF Exposure
Calculated using MPE as the unit is designed for mobile or fixed location transmitters no
SAR has been calculated/measured. The unit is designed for >20cm distance to any person
when in use. The unit is designed for general population/uncontrolled exposure of
S<1mW/cm^2.
𝑆 = 𝑃 ∗ 𝐺
4𝜋𝑑^2
S=Power density in mW/cm^2
D=distance in cm
P=power in mW
G=numeric antenna gain = 2dB = 1.258
EUT output power = 310mW
S=0.077584mW/cm^2 which complies with the FCC requirements.
