S E M SDIG-X1909 RUGGED SPORT WATER BOTTLE User Manual X 1909 ENG IM QS V2 160113 lab
S.E.M. INDUSTRIES RUGGED SPORT WATER BOTTLE X 1909 ENG IM QS V2 160113 lab
S E M >
User manual
THE DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. CHANGES OR
MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR
COMPLIANCE COULD VOID THE USER'S AUTHORITY TO OPERATE THE PRODUCT.
NOTE: THIS PRODUCT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR
A CLASS B DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS
ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL
INTERFERENCE IN A RESIDENTIAL INSTALLATION. THIS PRODUCT GENERATES, USES AND
CAN RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTIONS, MAY CAUSE HARMFUL INTERFERENCE TO
RADIO COMMUNICATIONS. HOWEVER, THERE IS NO GUARANTEE THAT INTERFERENCE
WILL NOT OCCUR IN A PARTICULAR INSTALLATION. IF THE PRODUCT DOES CAUSE
HARMFUL INTERFERENCE TO RADIO OR TELEVISION RECEPTION, WHICH CAN BE
DETERMINED BY TURNING THE EQUIPMENT OFF AND ON, THE USER IS ENCOURAGED TO
TRY TO CORRECT THE INTERFERENCE BY ONE OR MORE OF THE FOLLOWING
MEASURES : -REORIENT OR RELOCATE THE RECEIVING ANTENNA. -INCREASE THE
SEPARATION BETWEEN THE PRODUCT AND RECEIVER.
-CONNECT THE PRODUCT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM THAT TO
WHICH THE RECEIVER IS CONNECTED. -CONSULT THE DEALER OR AN
EXPERIENCED RADIO/TV TECHNICIAN FOR HELP.
IM: X-1909 (EN)
SIZE: 65 (W) X 65 (H) MM (EACH PAGE)
MATERIAL: 120G WOODFREE PAPER
PRINTING COLOR: BLACK + PANTONE 187C
QUICK START
X-1909
C
THE CONNECTED SPORTS WATER BOTTLE
EN-3 EN-4 EN-5 EN-6
Insert Mirco SD Card
To play MP3 Song files,
insert your Micro-SD Card.
LED indicator /
System Reset Hole *
Power on: Blue LED light flashes
quickly.
Bluetooth® Paired: Blue LED light
flashes slowly.
Charge Status: Green LED light on.
USB charge Socket
Use a computer USB port / power
adapter to recharge speaker.
USB
* SEE SYSTEM
RESET SECTION
USB USB
AC
CHARGING
GREEN LED
Use a computer USB port / power adapter to recharge the speaker.
It will take 3 hours to fully charge the speaker.
EN-8 EN-9EN-7 EN-11EN-10
Technical specifications and design may change without notice.
- - -
Product No.: ............................. X-1909 SPRITZ
Product description: ..................
Power Supply : ............... Rechargeable Lithium 3.7V/ 1000mAh X 1 PC. (Built-in)
DC 5V , 500mA
Speaker : ....................... 2"x1
Wireless Range (BT) : .................... 10M (30 Ft.)
Max. BT Pairing Memory : ............... 4 Devices
Rugged Sport Water Bottle
Recharge Power : ..........
IM-SPRITZ-WORKOUT-X1909-4-S01-001
FRONT
BACK
PLEASE NOTE: YOU WILL FIND THE RATING LABEL FOR
THIS PRODUCT LOCATED ON THE BOTTOM OF THE UNIT.
- KEEP MINIMUM DISTANCES (5cm) AROUND THE APPARATUS FOR SUFFICIENT
VENTILATION.
- THE VENTILATION SHOULD NOT BE IMPEDED BY COVERING THE VENTILATION
OPENINGS WITH ITEMS SUCH AS NEWSPAPER, TABLE-CLOTHS, CURTAINS ETC.
- NO NAKED FLAME SOURCE SUCH AS LIGHTED CANDLES SHOULD BE PLACED
ON THE APPARATUS.
- ATTENTION SHOULD BE DRAWN TO THE ENVIRONMENTAL ASPECTS OF BATTERY
DISPOSAL.
- BATTERY SHALL NOT BE EXPOSED TO EXCESSIVE HEAT SUCH AS SUNSHINE,
FIRE OR THE LIKE.
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.
TO ASSURE THE FINEST PERFORMANCE,
PLEASE READ THIS MANUAL CAREFULLY.
KEEP IT IN A SAFE PLACE FOR FUTURE REFERENCE.
CAUTION REGARDING THE WATERPROOFING
IPX4
WATER PROOF RATING
ALTHOUGH THIS UNIT'S SPLASH-PROOF DESIGN ALLOWS IT
TO BE USED EVEN WHERE IT MAY BE EXPOSED TO A CERTAIN
AMOUNT OF RAIN, SNOW, OR WATER SPRAY, YOU SHOULD
NOTE AND OBSERVE THE FOLLOWING POINTS.
- Do not allow large amounts of water to contact this unit.
- Do not immerse or place this unit in water.
It may malfunction if it falls into water.
- If water droplets adhere to this unit, use a dry cloth to wipe
them off as soon as possible. If this unit is exposed to a large
amount of water, do not turn on the power immediately. Instead,
let this unit dry out for at least one day in a dry location before
you turn on the power.
- When using this unit in a wet or high-humidity location,
please make sure the Rubber Terminal Cover is properly closed.
DO NOT IMMERSE
CAUTION : DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE.
BATTERY REPLACEMENT MUST ONLY BE DONE BY A QUALIFIED
PROFESSIONAL TECHNICIAN.
VOL / NEXT SONG
VOL / PERVIOUS SONG
PLAY / PAUSE
POWER ON / OFF
Press quickly for next song, press
and hold to increase volume.
Press and hold for 3-5 second to
Power-Up the speaker,
press and hold 3-5second again
to switch off speaker.
Press quickly for mode switching.
Press quickly for last song,
press and hold to decrease
volume.
When music playing, press the button
to pause and play.
ON!
BT "ON" !
=
=
(SLOW)
(FAST)
SEARCHING
PAIRING
“SDIG SPRITZ”
(CODE: 0000)
(ON) =CONNECTED
...
BLUETOOTH
LED INDICATOR
In order to avoid interferences, please de-activate Wi-Fi on your device
(smartphone, tablet, etc.) when playing music using Bluetooth®
(Hold 3 sec.)
Changing Colors
Micro SD-MP3
Micro SD-MP3
Micro
SD
card
Micro SD Card Music
Insert Micro SD card with MP3 music files
into the slot, press and hold
the “Power” button to turn on speaker,
when speaker voices out
" Detected”, speaker will be in
the “ card music playback mode”.
Micro SD
Micro SD
Micro SD
Short press Power button for mode
shifting or pull out the card,
to exit card playing mode,
and shift to Bluetooth® mode.
Playing Mode
Micro SD
Micro SD
Exit Card MusicMicro SD
Short Press for Mode Switch
EN-2
System Reset*
SPRITZ has an internal protection system
which automatically activates if anything
abnormal occurs (eg. Static electricity!)
In such a case, SPRITZ may appear to be
"LOCKED" and not operating.
To resolve this, simply "RESET" SPRITZ by
inserting a paper clip wire gently into the
system reset hole (same as LED indicator
hole) on the left side of the USB charge
socket. Keep the "RESET" button (INSIDE)
pressed for 2 seconds & then Power-On as
usual.
APP
DOWNLOADS
PLAYER APP
BOTH APPS ARE AVAILABLE AT:
Spritz has 2 available Apps, which you can
download for Apple (iOS) and Android devices:
1. SPRITZ HYDRATION
ASSISTANT APP
Reminds you to drink regularly
with your choice of AUDIO
notifications
Real-Time Studio Enhancement
of your music while streaming
over Bluetooth
2. SDIGITAL MUSIC
IM-SPRITZ-MARATHON-X1909-64-S01-001
E: sales@sem.com.hk W: www.sem.com.hk
T: (852) 3761 8000
MODEL: X-1909
DATE: 06 JAN., 2016
FILE: MANUAL FOR REFERENCE
SC NO.:
JOB NO.: 00615-0038
0076/15
BRAND:
