SACKit ApS TOUCHIT TOUCHit Wireless active noise cancellation headphones User Manual
SACKit ApS TOUCHit Wireless active noise cancellation headphones Users Manual
User manual
TOUCHit Wireless active noise cancellation headphones
Model: TOUCHit
User manual
Thank you for purchasing this TOUCHit Wireless active noise cancellation headphones.
Please read the instructions and warnings carefully before use to ensure safe and
satisfactory of this product.
Caution
Please charge your battery if you can’t turn on the headphone
Please turn off your headphone after use to keep a longer battery life
Please use USB cable included in the package for battery charging
Please don’t change any other battery
Please don’t keep headphone in a wet place
Do not exposure or toss headphone into fire. It will probably cause an accident
Please don’t try to disassemble the headphone
Description of the appliance
Specifications
Bluetooth Solution: CSR
Bluetooth version: V4.0
Support agreement: A2DP, AVRCP, HFP, HSP
Operating distance: 10M
Battery: 500mAh
Charging time: about 3 hours
Charging current: 220mA
Music playing time:
about 16 hours
(Bluetooth on, ANC on)
22 hours
(Bluetooth on, ANC off)
Call time: 25 hours
ANC working time: up to 12 hours
ANC solution: MAX
Noise reduction performance: up to 20dB
Driver Unit: Ø40mm
Frequency Range: 20Hz-20 KHz
Impedance: ANC_OFF:80Ω ANC_ON:110Ω
Battery charging
Battery: rechargeable Polymer Lithium-Ion Battery，DC: 3.7V/500mAh
Power: USB DC5V, Please use the USB cable included in the package for charging
Charging Time: first time please be sure the battery be charged more than 4 hours to
be fully charged. After the first time, charging time is about 3 hours.
When the red light is on, the headphone is in charge mode. The red light will turn off
when the battery is fully charged.
Noise Cancellation function
When you press the ANC button one time, the green indicator will turn on, then you can
enjoy the headphone in Noise cancellation mode. When you don’t need the Noise
cancellation function, please press the ANC button one more time and green LED turn off.
Pair headphone with Bluetooth devices
Turn the headphone on by holding down the button with CROSS “X” on the surface
until you hear the prompt (To turn off, hold down the same button until you hear the off
prompt.
Please keep the headphone and mobile phone in the range of 1 meter when paring and
make sure your headphone is on
Press and hold the MFB button for 10 seconds to put the headphone in paring mode (If
successful the LED light will flash red and blue)
Go into the Bluetooth settings on your device and search for new Bluetooth devices and
select TOUCHit.
The LED light will blink blue once the headphone is successfully paired.
.
Notes: If the pairing is not successful, please turn the headphone off and on and then try to
pair again.
Making calls with the headset
Functions
Status of headphone
Operation
Redial Last number
Standby mode
Short press MFB twice
quickly
Volume up
Conversation mode
Hold Volume + button
Volume down
Conversation mode
Hold Volume - button
Answering calling
Ringing
Press MFB button
Reject calling
Ringing
Press and hold MFB button
for one second, and release
until you hear indication
sound
Notes:
Not all the mobile phones support all the functions listed above. Please refer to the
instruction of your mobile phone.
Some functions and indication tones may vary with mobile phones
Playing Music
When the headphone connects with the mobile phone or Bluetooth transmitter, you can
enjoy music through headphone wireless.
Function
Status of headset
Operation
Pause
Playing music
Press MFB button
Play
Pausing
Press MFB button
Next track
Playing music
Press volume + button
Previous track
Playing music
Press volume –button
Volume +
Playing music
Hold volume +button
Volume -
Playing music
Hold volume – button
Notes:
For some mobile phones, the music will transmit to the speaker of mobile phone
instead of the headphone, If that is the case, you have to choose TRANSMIT THE
SOUND THROUGH BLUETOOTH in the SETTINGS of the music play interface on
your mobile phone and then choose TOUCHit in the device list, so the music will be
transmitted to the headphone. Please refer to the instruction of your mobile phone for
further information.
In order to use the remote control, your mobile phone or Bluetooth transmitter must
support AVRCP
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
