You have just purchase a D680C and we thank you for your purchase.
This product follows a strategy of continuous development. We reserve the right to make
changes without notice, modifications and improvements to the products described in
this user manual.
To operate the device safely and easily, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury to persons, please read
carefully the paragraph “R
Recommendations and safety instructions
”, page 2.
The declaration of compliance may be looked up on the w
www.sagemcom.com
website
section «Support», or can be obtained from the following address:
Sagemcom Broadband SAS
250, route de l'Empereur
92848 Rueil-Malmaison Cedex - France
Sagemcom USA LLC
14651 North Dallas Parkway
Suite 900
Dallas, TX 75254
MU 25XXXXXX-A_D680C_US.book Page 1 Dimanche, 2. septembre 2012 9:51 09
2
Recommendations and
safety instructions
For safety reasons, never put the handset in the base station without the
battery inserted or without the lid on the battery compartment as this
could cause an electric shock.
To avoid damaging your handset/base, only use certified rechargeable
batteries NiMH 1.2 V 750 mAh, never use non rechargeable batteries.
Insert the batteries in the handset/base battery compartment respecting
polarity, do not dispose of batteries in fire, they may explode, if the
handset will not be used for an extended period of time, unplug the
battery and remove it from the handset to prevent possible leakage,
keep batteries out of the reach of children
Only use the power unit supplied and connect it to the electricity mains
in accordance with the installation instructions in this user manual and
the details on the sticker regarding voltage, electrical current and
frequency. As a precaution if there is a risk of danger, the power plug can
be pulled out to disconnect the 120V power supply. Therefore the
sockets should be near the device and easily accessible.
Do not install your DECT telephone D680C in a damp environment, such
as a bathroom, washroom, kitchen etc, and not within 1.50 feet of a
source of water or outside. This device is designed for use in
temperatures of between 5 Celsius degree and 40 Celsius degree. Do
not expose the product to extreme temperatures such as areas near a
hot radiator, stove or in a hot car.
In zones where there is a risk of frequent thunder storms, we
recommend that you protect your telephone line using an electric power
surge protection device.
Avoid using the telephone during an electrical storm, there may be a
remote risk of electric shock from lightning.
Do not attempt to remove screws or open the appliance. It does not
contain any user-replaceable parts.
MU 25XXXXXX-A_D680C_US.book Page 2 Dimanche, 2. septembre 2012 9:51 09
3
Your DECT telephone has a range of approx. 50 feet indoors and up to
300 feet outdoors. The range can be affected by the proximity of metal
objects, such as a television and electrical devices.
Areas without reception may appear due to elements in the building. This
can cause brief interruptions in the conversation, caused by faulty
transmission.
Certain medical equipment and highly-sensitive machines or security
systems may be affected by the transmission power of the telephone. In
these cases we recommend adhering to the safety information.
The used battery must be disposed of in line with the recycling
regulations in this user manual.
Check with local codes for possible special disposal instructions.
Do not use the telephone to report a gas leak in the vicinity of the leak.
The base is for indoor use only, do not place or install in an outdoor
location.
Unplug this product from the wall outlet before cleaning, don't use liquid
cleaners or aerosol cleaners.
MU 25XXXXXX-A_D680C_US.book Page 3 Dimanche, 2. septembre 2012 9:51 09
4
D680C
FCC Caution
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's -authority to operate the equipment.
F
FCC ID: VW3D680C
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1
this device may not cause harmful interference, and
2
this device must accept any interference received, including interference
that may cause undesired operation.
Privacy of communications may not be ensured when using this phone.
Important note:
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
•Privacy of communications may not be ensured when using this telephone!
•This product complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
•To comply with FCC RF exposure requirements, the base unit must be installed and
operated 20 cm (8 inches) or more between the product and all person's body
(excluding extremities of hands, wrist and feet).
•This product may not be collocated or operated in conjunction with any other antenna
or transmitter
•The handset may be carried and operated with only the specific provided belt-clip.
Other non-tested belt-clips or similar body-worn accessories may not comply and
must be avoided
MU 25XXXXXX-A_D680C_US.book Page 4 Dimanche, 2. septembre 2012 9:51 09
5
D680C
C
Customer Information
1
This equipment complies with Part 68 of the FCC rules and the requirements adopted
by the ACTA. On the b
bottom
of this equipment is a label that contains, among other
information, a product identifier in the format
US:AAAEQ##TXXXX
. If requested, this
number must be provided to the telephone company.
2
An applicable certification jacks Universal Service Order Codes (USOC) for the
equipment is provided (i.e., R
RJ11C
) in the packaging with each piece of approved
terminal equipment.
3
A plug and jack used to connect this equipment to the premises wiring and telephone
network must comply with the applicable FCC Part 68 rules and requirements
adopted by the ACTA. A compliant telephone cord and modular plug is provided with
this product. It is designed to be connected to a compatible modular jack that is also
compliant. See installation instructions for details.
4
The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not
ringing in response to an incoming call. In most but not all areas, the sum of RENs
should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by the total RENs, contact the local telephone
company. [For products approved after July 23, 2001, the REN for this product is part
of the product identifier that has the format
US:AAAEQ##TXXXX
. The digits
represented by ## are the REN without a decimal point (e.g., 03 is a REN of 0.3). For
earlier products, the REN is separately shown on the label.]
5
If this equipment [US:
NS3W400BD680C
causes harm to the telephone network, the
telephone company will notify you in advance that temporary discontinuance of
service may be required. But if advance notice isn't practical, the telephone company
will notify the customer as soon as possible. Also, you will be advised of your right to
file a complaint with the FCC if you believe it is necessary.
6
The telephone company may make changes in its facilities, equipment, operations or
procedures that could affect the operation of the equipment. If this happens the
telephone company will provide advance notice in order for you to make necessary
modifications to maintain uninterrupted service.
7
Should you experience trouble with this equipment, please contact [US: NS3W400BD680C
for repair or warranty information, Service can be facilitated through our office at:
U.S. Agent Company name:
Address:
Tel:
MU 25XXXXXX-A_D680C_US.book Page 5 Dimanche, 2. septembre 2012 9:51 09
Sagemcom USA LLC
14651 N.Dallas Parkway,Suite 900 DALLAS TEXAS 75254 US
+1-972-674-4100
6
D680C
If the equipment is causing harm to the telephone network, the telephone company
may request that you disconnect the equipment until the problem is resolved.
8
8
Please follow instructions for repairing if any (e.g. battery replacement section);
otherwise do not alternate or repair any parts of device except specified.
9
Connection to party line service is subject to state tariffs. Contact the state public
utility commission, public service commission or corporation commission for
information.
10
If your home has specially wired alarm equipment connected to the telephone line,
ensure the installation of this [equipment ID] does not disable your alarm equipment.
If you have questions about what will disable alarm equipment, consult your
telephone company or a qualified installer.
11
If the telephone company requests information on what equipment is connected to
their lines, inform them of:
a) The ringer equivalence number [0.0B]
b) The USOC jack required [RJ11C]
c) Facility Interface Codes ("FIC") [02LS2]
d) Service Order Codes ("SOC 9.0Y
e) The FCC Registration Number [US: NS3W400BD680C
12
The REN is used to determine the number of devices that may be connected to a
telephone line. Excessive RENs on a telephone line may result in the devices not
ringing in response to an incoming call. In most but not all areas, the sum of RENs
should not exceed five (5.0). To be certain of the number of devices that may be
connected to a line, as determined by the total RENs, contact the local telephone
company. The REN for this product is part of the product identifier that has the format
US:AAAEQ##TXXXX. The digits represented by ## are the REN without a decimal
point. For this product the FCC Registration number is [US: XXXXXXXXX] indicates the
REN would be XX.
13
If this product is equipped with a corded or cordless handset, it is hearing aid
compatible.
FCC ID: VW3D680C
US: NS3W400BD680C
REN: 0.0B
MU 25XXXXXX-A_D680C_US.book Page 6 Dimanche, 2. septembre 2012 9:51 09
7
D680C
Contents
Discover...........................................................10
Your phone ......................................................................... 10
Unpacking............................................................................................................................................ 10
Installing the belt clip........................................................................................................................ 11
The handset ......................................................................................................................................... 12
The base ............................................................................................................................................... 13
Connecting the base......................................................................................................................... 14
Browser................................................................................................................................................. 15
Menu browsing ................................................................................................................................... 15
The screen ........................................................................................................................................... 18
Charging............................................................................. 19
Handset set-up.................................................................... 19
Replacing the batteries ....................................................... 21
Menu tree structure ........................................................................................................................... 22
Call... ...............................................................24
Managing calls .................................................................... 24
Making a call........................................................................................................................................ 24
Ending a call........................................................................................................................................ 25
Receiving a call .................................................................................................................................. 25
Choose your line................................................................................................................................. 25
Managing several calls........................................................ 26
Receiving a second call ................................................................................................................... 26
Switching from one call to the other ............................................................................................. 26
Ending one of the calls in progress .............................................................................................. 27
Talking with two contacts at the same time (3-way conference) ......................................... 27
Making a second call ........................................................................................................................ 28
Transferring calls ............................................................................................................................... 29
Options during a call ........................................................... 30
Enable/Disable loudspeaker (hands-free mode) ...................................................................... 30
Adjusting volume................................................................................................................................ 30
MU 25XXXXXX-A_D680C_US.book Page 7 Dimanche, 2. septembre 2012 9:51 09
8
D680C
Enable the mute mode...................................................................................................................... 31
Using additional handsets ................................................... 32
Calling another handset (intercom) .............................................................................................. 32
Intrusion ................................................................................................................................................ 32
Manage your contacts... ...................................33
Use the phonebook ............................................................. 33
Create an entry ................................................................................................................................... 33
Call the contact from phonebook .................................................................................................. 34
Changing an entry ............................................................................................................................. 34
Deleting an entry ................................................................................................................................ 34
Search for an entry ............................................................................................................................ 34
Delete all the entries.......................................................................................................................... 35
Speed dialing ...................................................................................................................................... 35
Voice mail Service............................................36
Modifying the Voice mail number .................................................................................................. 36
Audio adjustment... ..........................................37
Changing the ringing tone............................................................................................................... 37
Enabling/Disabling the silent mode .............................................................................................. 37
Enabling/Disabling audio alerts ..................................................................................................... 38
Setting up.........................................................39
The phone........................................................................... 39
Setting the date and the time.......................................................................................................... 39
Picking up and hanging up calls automatically......................................................................... 40
Changing the display language ..................................................................................................... 40
Adjust the brightness ........................................................................................................................ 41
Change the screen background.................................................................................................... 41
The handset ........................................................................ 42
Associating a new handset ............................................................................................................. 42
Customizing the handset’s registration ....................................................................................... 43
Defining the main base for your handset .................................................................................... 43
Modifying the country ....................................................................................................................... 44
Handset version.................................................................................................................................. 44
Resetting the handset....................................................................................................................... 44
The base ............................................................................. 45
Changing the base code.................................................................................................................. 45
MU 25XXXXXX-A_D680C_US.book Page 8 Dimanche, 2. septembre 2012 9:51 09
9
D680C
Resetting the base............................................................................................................................. 45
Base version........................................................................................................................................ 46
The line ............................................................................... 47
Change the line name ....................................................................................................................... 47
Pair the handset with a line ............................................................................................................. 47
Allow three-way communication (Intrusion) ............................................................................... 48
Changing the flash duration............................................................................................................ 48
Managing your calls .......................................................................................................................... 49
The list of handsets ............................................................. 50
Manage handsets............................................................................................................................... 50
Accessories... ..................................................51
The alarm............................................................................ 51
Programming the alarm.................................................................................................................... 51
The timer ............................................................................ 52
Program the timer .............................................................................................................................. 52
Tracking your calls...........................................53
Call logs.............................................................................. 53
Displaying the list of all calls........................................................................................................... 53
Viewing the received or dialed call log........................................................................................ 54
Consulting the missed call log ....................................................................................................... 55
Managing incoming or outgoing calls .......................................................................................... 56
The events log..................................................................... 57
Checking new events........................................................................................................................ 57
Environment..................................................... 58
Guarantee ........................................................ 59
Limited warranty................................................................................................................................. 59
Other limitations.................................................................................................................................. 61
MU 25XXXXXX-A_D680C_US.book Page 9 Dimanche, 2. septembre 2012 9:51 09
10
D680C
D
Discover...
Your phone
Unpacking
Open the box and make sure it contains the following items:
Discover...
1
ATTENTION The D680C phone is only compatible with Gateway US.
Un manuel utilisateurUn manuel utilisateurUn manuel utilisateurUn manuel utilisateurUn manuel utilisateurUn manuel utilisateurA base power adaptor
+
_
+
_
A handset
Two rechargeable
batteries
Un chargeur équipé de
son bloc
d’alimentation
One battery compartment
cover
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
Un chargeur équipé de
son bloc
d’alimentation
A handset charger
A belt clip
A base
A telephone line cord Un manuel utilisateurUn manuel utilisateurUn manuel utilisateurUn manuel utilisateurUn manuel utilisateurUn manuel utilisateurA user guide
MU 25XXXXXX-A_D680C_US.book Page 10 Dimanche, 2. septembre 2012 9:51 09
11
D680C
D
Discover...
Installing the belt clip
To install the belt clip:
1
First insert one side of the clip into the dedicated slot (A).
2
Gently press on the other side of the clip until the pin snaps into the other slot. The
"TIC" sound indicates that the belt clip is in the locked position.
To remove the belt clip:
Lift the clip by one of the sides (B) and then pull off.
1
A
2TIC
B
MU 25XXXXXX-A_D680C_US.book Page 11 Dimanche, 2. septembre 2012 9:51 09
12
D680C
Discover...
The handset
Key Description
1.
Screen
2.
Access to the main menu
/ Validation key.
3.
Browser (See "Browser"
section for details).
4.
"Answer" key or to get
dial tone (short press) /
Access to " All calls " log
(long press).
5.
Access to voice mail
(long press in standby
mode).
1
1
2
5
4
10
6
8
11
12
13
3
9
7
6
6.
Alphanumeric keyboard:
long press the numeric
buttons to initiate calls to
pre-programmed
numbers.
7.
Star key: lock / unlock
keypad (long press).
8.
R key: allows you to put a
conversation on hold by
pressing the R key or
disconnect the call in
process, by pressing the
R key followed by 7 for a
double call.
9.
Cancel key / return to
previous menu.
10.
Hang up key (short
press) / Turn off/on the
handset (long press).
11.
Sharp key:
activate/deactivate mute
mode (long press during
a call).
12.
" INT " key intercom
function. Allows you to
call other handsets which
are paired to the same
base.
13.
Microphone.
Key Description
MU 25XXXXXX-A_D680C_US.book Page 12 Dimanche, 2. septembre 2012 9:51 09
13
D680C
Discover...
The base
Caption Description
1
Indicator light
2
button Paging/Pairing:
• Short press: paging of handsets
• Long press: pairing of handsets
3
Power socket
4
Telephone socket
1
2
34
N
Note
Indicator light operation:
- Fixed: base startup.
- Fast flashing: the base is in pairing mode.
- Medium Flashing: searching for handsets paired on the base.
- Slow flashing: call in progress.
MU 25XXXXXX-A_D680C_US.book Page 13 Dimanche, 2. septembre 2012 9:51 09
14
D680C
Discover...
Connecting the base
Take the base and turn it over.
1
Plug the telephone cord into the socket.
2
Connect the other end of the cord to the Gateway.
3
Take the power adapter. Connect the power adapter cord to the underside of the
base.
4
Connect the power adapter to an electrical outlet.
2
1
3
4
Gateway
Phone
@
MU 25XXXXXX-A_D680C_US.book Page 14 Dimanche, 2. septembre 2012 9:51 09
15
D680C
Discover...
Browser
Menu browsing
To browse through menus, use the browser keys and the keys ,
and .
Legend Item Description
1
Loudspeaker (switch to hands-free mode)/disable
(switch to handset mode).
2
Enable/disable the silent mode.
3
Select key / Main menu access key.
4
Phonebook access key.
5
All log access key.
Key Corresponds to... (throughout the manual)
Up
Down
Right
Left
1
5
4
3
2
MU 25XXXXXX-A_D680C_US.book Page 15 Dimanche, 2. septembre 2012 9:51 09
16
D680C
Discover...
Pressing the corresponding sub-menu number (from 1 to 6).
DETAILED BROWSER EXAMPLE: ACCESS TO THE COMMUNICATION MENU
During a call:
1
Press the O
Options
key, S
Second call
is displayed.
2
Scroll through the options using the top or the bottom .
3
Select your choice by pressing the key.
Menu 1: Phonebook
Menu 4: Accessories
Menu 5: Melodies
Menu 3: Calls
Menu
Select Back
Menu 2: Voicemail
Menu 6: Settings
1
1
Press M
Menu
.
1
Press the top or the bottom of the navigation key .
The main menu is displayed on the screen.
2
Press the top or the bottom or (on the or ) of the browser key to
access the desired function.
3
Select your choice / Enter the menu by pressing the (O
OK
) or via the key
Select
.
4
Cancel your choice / Exit the displayed menu:
-either by pressing the key: return to previous menu.
-or by pressing the key: the home screen is displayed.
MU 25XXXXXX-A_D680C_US.book Page 16 Dimanche, 2. septembre 2012 9:51 09
17
D680C
Discover...
DETAILED BROWSER EXAMPLE: CHANGING THE RING TONE OF EXTERNAL CALLS
1
Press M
Menu
(or key).
The main menu is displayed on the screen.
1
Press the () key then press the () key.
2
Enter the M
Melodies
menu by pressing the (O
OK
) key.
3
Select E
External ringtone
using the or key. Press .
4
Select the ring tone of your choice using the keys or .
5
Adjust the ring tone volume using the keys or and press the key. The screen
displays the message "O
OK
".
MU 25XXXXXX-A_D680C_US.book Page 17 Dimanche, 2. septembre 2012 9:51 09
18
D680C
Discover...
The screen
THE ICONS DISPLAYED
In standby mode or during use, your phone screen communicates your phone’s current
state through icons, and in particular:
Legend Description
1 Status icons
:
indicates your phone's current state.
2 Information field
:
the current date MM/DD/YYYY and time HH:MM
(pm or am),
the handset's name and number.
3 Action icons
:
menus associated with programmable keys.
DECT X
10:00 pm
01/31/2013
Menu Phonebook
1
2
3
MU 25XXXXXX-A_D680C_US.book Page 18 Dimanche, 2. septembre 2012 9:51 09
19
D680C
Discover...
Charging
To charge your telephone, place the handset on its charger and make sure the charger
is connected to the power supply.
The battery charging icon moves to inform you that charging is in progress.
The icon display stops moving when the batteries are charged.
Handset set-up
1
On the back of the handset.
2
Install the new batteries one by one, noting the polarity of the batteries, and replace
the battery cover.
3
The message " SAGEMCOM
" is displayed on the screen for a few seconds.
4
The L
Language
menu is displayed.
5
Select your language using the or keys and select using the key.
6
The C
Country
menu is displayed.
Statut Description
Batteries charged.
Batteries moderately charged.
Battery charge low.
Battery charge very low.
Batteries completely discharged.
Note
The Handset operating time:
- Talk time: 10 hours.
- Standbay time: 180 hours.
Note
To ensure optimum charging, leave the handset on the base for at
least 1
15 hours
when using the phone for the first time. During
charging, the batteries may heat up. This is normal and perfectly safe.
When the batteries are low, the handset emits a beep.
MU 25XXXXXX-A_D680C_US.book Page 19 Dimanche, 2. septembre 2012 9:51 09
20
D680C
Discover...
7
Select the country using the or keys and select using the key.
8
The date and time setting menu is displayed.
9
Enter the right date. Press the key ,and enter the time.
10
Press the key . The action is confirmed by the indication "O
OK
".
SWITCH THE HANDSET OFF AND THEN ON AGAIN
To turn off the handset, hold down the red
key , the "P
Power off ?
" message is
displayed on the screen.
Press Y
Yes
to confirm.
To turn on your handset, press the red
key , the "SAGEMCOM" message is
displayed on the screen.
N
Note
If the message "P
Please Register
" appears, refer to “Associating a new
handset”, page 38.
Long press
Long press
Long
p
Long
p
Power o ?
S
agemcom
Yes No
MU 25XXXXXX-A_D680C_US.book Page 20 Dimanche, 2. septembre 2012 9:51 09
21
D680C
Discover...
Replacing the batteries
1
Turn off the handset. Turn it around so that the battery
compartment is accessible.
2
Remove the battery compartment cover.
3
Remove the old batteries, insert the new batteries,
noting the polarity of the batteries.
4
Replace the battery compartment cover.
Note
Worn out batteries must be discarded, in accordance with the
recycling instructions in chapter “R
Recommendations and safety
instructions
”, page 2.
ATTENTION To avoid damaging your handset, only use certified
rechargeable AAA batteries NiMH 1.2 V 750 mAH, never use non
rechargeable batteries.
MU 25XXXXXX-A_D680C_US.book Page 21 Dimanche, 2. septembre 2012 9:51 09
22
D680C
Discover...
Menu tree structure
Phonebook
Voicemail
List
Search
Add
Delete all
Speed Dialing
All calls
Incoming calls
Outgoings calls
Missed calls
Events
Tree structure continued on next page
Options
Second call
Intercom
Calls
Phonebook
Selec. call line
Mute
During a call
Melodies
External ringtone
Internal ringtone
Beeps
Silent
Accessories
Alarm
Timer
Calls
* Scrolling message
MU 25XXXXXX-A_D680C_US.book Page 22 Dimanche, 2. septembre 2012 9:51 09
23
D680C
Discover...
Settings
Set handset
*
*
Change code
Reset base
Base Version
Set base
Line name
Handset list
*
*
Attached HS
Configuration
Selec. call line
Advanced settings
*
*
Settings Date/time
Auto hang/pick up
Language
Display
Registration
Person.registr
Base priority
Handset Version
Reset handset
Set line
Flash time
Country
* Scrolling message
MU 25XXXXXX-A_D680C_US.book Page 23 Dimanche, 2. septembre 2012 9:51 09
24
D680C
Call...
Managing calls
Call...
2
Note
If the handset is being synchronized with the base, the "P
Please wait
"
message is displayed on the screen.
It is not possible to make or receive calls until the "P
Please wait
"
message has disappeared from the screen.
Making a call
METHOD 1 (PRE-DIALING)
1
Dial your contact’s number.
2
Press the key .
METHOD 2 (POST-DIALING)
1
Press on the green key for 3 or more
seconds.
2
Dial your contact’s number.
123456
01:30
Mute Options
MU 25XXXXXX-A_D680C_US.book Page 24 Dimanche, 2. septembre 2012 9:51 09
25
D680C
Call...
Ending a call
At the end of the call, press the handset key and put the handset back on its
charger. A sound signal is emitted.
End of call
Receiving a call
1
1
To answer a call press the key or simply pick the handset up from its base
if the automatic pick up option is activated. You can also press A
Accept
.
2
At the end of the call, press the handset key and put the handset back on
its charger. A sound signal is emitted.
N
Note
To stop the handset ringing when an incoming call is received,
press D
Dismiss
.
Choose your line
This menu allows you to select the line on which you want to make a second
outgoing call (subject to service availability).
1
1
During a call, press O
Options
.
2
Select S
Selec. call line
and press O
OK
.
3
Select your line using the keys or .
4
Press O
OK
. The action is confirmed by the indication "O
OK
".
MU 25XXXXXX-A_D680C_US.book Page 25 Dimanche, 2. septembre 2012 9:51 09
26
D680C
Call...
Managing several calls
Your phone allows you to take and manage several calls (subject to service availability)
when you are already on a call.(*)
(*) You must have first enable "Concurrent calls".
Receiving a second call
During a call, a beep indicates the arrival of a second call.
The contact details of the second caller are displayed on the screen.
Case 1:
answer the new call and put the current call on hold.
Press O
OK
.
Select R
Replace
and press O
OK
.
- OR -
Press the key.
The first caller is put on hold, and you can speak with the new caller.
Cas 2:
answer the new call and end the current call.
Press O
OK
.
Select R
Release
and press O
OK
.
The call with your first caller is ended. You can speak with the new caller.
Note
To reject a second call, press R
Release
.
Switching from one call to the other
Case 1:
•During a conversation press O
Options
.
•Select the options S
Switch
, press O
OK
.
Case 2:
•During a conversation press S
Switch
.
•The current call is put on hold in order to take the call that was previously on hold.
MU 25XXXXXX-A_D680C_US.book Page 26 Dimanche, 2. septembre 2012 9:51 09
27
D680C
Call...
Ending one of the calls in progress
•During a conversation press O
Options
.
•Choose the option R
Release
using the or keys. Press O
OK
.
The current call is ended and you resume the previous call.
Note
During the call you can hang up both calls by pressing the
key for a long time.
A short press on the red key ends the current call.
Talking with two contacts at the same time
(3-way conference)
•During a double call, press O
Options
.
•Choose the option 3
3-part conference
using the or keys. Press O
OK
.
•You can then talk with the 2 contacts at the same time and " 3
3-part conference
"
is displayed on the screen.
•To end the conference call, press the key.
MU 25XXXXXX-A_D680C_US.book Page 27 Dimanche, 2. septembre 2012 9:51 09
28
D680C
Call...
Making a second call
•During a conversation press O
Options
.
•Choose the option S
Second call
using the or keys. Press O
OK
.
•Select the number for the person you want to call in the address book by
pressing , and then O
OK
.
- OR -
•Dial the number using the keypad and select.
•The second called number appears on the screen.
A
: The order of the current call / double call.
B
: The call time.
C
: The number and/or name of the person
called.
Switch
Options
HD
A
B
C
num 1
num 2
01:30
Note
You can also select the number of the person you are calling
from your address book by pressing . For more details please
refer to section “U
Use the phonebook
”, page 33.
You can also make a second call by pressing on the key.
MU 25XXXXXX-A_D680C_US.book Page 28 Dimanche, 2. septembre 2012 9:51 09
29
D680C
Call...
Transferring calls
During a call, you can transfer it to another handset. This function can be used as
long as two handsets have been registered to the same base.
•During a conversation press O
Options
.
•Choose the option I
Intercom
.
Press
OK
.
UNANNOUNCED TRANSFER
This function allows you to transfer the current call directly to another device.
ANNOUNCED TRANSFER
This function allows you to transfer the current call to another device once it has
been picked up.
Steps Calling handset Called handset
1Press O
OK
.
2Select the handset (or all handsets)
to call.
3Press O
OK
.
4Rings: internal call.
5Press
Transfer
.
6Rings: external call. Take the call.
7Hangs up automatically.
Steps Calling handset Called handset
1Press O
OK
.
2Select the handset (or all handsets)
to call.
3Press O
OK
.
4Rings: internal call.
5
Press the key to accept the
internal call.
6The external call is put on hold.
7Press T
Transfer
.
8Hangs up automatically.
The external call is transferred.
9Call with the external caller.
NNote At the 5th step you can cancel the transfer of the call.
To do this, select C
Cancel and then select.
MU 25XXXXXX-A_D680C_US.book Page 29 Dimanche, 2. septembre 2012 9:51 09
30
D680C
Call...
Options during a call
You can use the following options during a call:
Enable/Disable loudspeaker (hands-free mode)
HANDSET LOUDSPEAKER
During the call you can activate the
hands-free mode by pressing the
key.
The icon is displayed on the
screen.
To disable the hands-free mode, press
the key again.
The icon disappears.
Mute Options
Mute Options
3021547
01:24
3021547
01:24
Note
When your battery charging icon displays the minimum, the
handsfree mode is unavailable until the next charging cycle. The
handsfree mode is optimized for speaking at 50 inches from the
handset.
Adjusting volume
FROM THE HANDSET
During a call you can increase or lower
the volume of the handset by pressing
the or keys on the browser.
A bar graph makes it possible to adjust
the volume according to 5 levels.
Mute Options
Volume :
Mute Options
Volume :
MU 25XXXXXX-A_D680C_US.book Page 30 Dimanche, 2. septembre 2012 9:51 09
31
D680C
Call...
Enable the mute mode
During a call, you can switch to mute mode and your handset's microphone will be
muted and your contact will no longer hear you.
TO ENABLE THE MUTE MODE:
•During a conversation, press O
Options
.
•Select M
Mute
,
press S
Select
. The icon is displayed at the top of the
screen.
TO DISABLE THE MUTE MODE:
•Press O
Options
.
•Select U
Unmute
,
press S
Select
. Your contact will hear you again.
KEYBOARD SHORTCUT:
During a conversation, press and hold the key to enable/disable the mute
mode.
Mute Options
555-555-555
10:12
N
Note
You can also enable/disable the mute mode by pressing M
Mute /
Unmute
during a call.
MU 25XXXXXX-A_D680C_US.book Page 31 Dimanche, 2. septembre 2012 9:51 09
32
D680C
Call...
Using additional handsets
You can associate additional handsets with your phone. You can then make and receive
outside calls or calls between these handsets.
Note You first have to pair the handsets with the base.
For further details, refer to the section “A
Associating a new handset”,
page 42.
Calling another handset (intercom)
•Press .
•Select the handset (or all handsets) you want to
call.
•Press O
OK
.
The selected handset rings.
•Take the call from the handset by pressing .
•End the call by pressing .
Menu
Handset List
Call Back
DECT1
DECT2
All handsets
Intrusion
This function allows another paired handset to join a call in progress on another
handset.
•You have a call in progress.
•Press and hold the green key from another paired handset.
Your handset will beep once and you can talk to all the contacts taking calls.
MU 25XXXXXX-A_D680C_US.book Page 32 Dimanche, 2. septembre 2012 9:51 09
33
D680C
Manage your contacts...
Use the phonebook
Manage your
contacts...
3
Your phonebook is common to all the DECT handsets recorded on the same
base.
You can also directly access the list of phonebook entries using the key.
When browsing through the phonebook, the handset displays the number of
the current entry and the total number of available entries.
You can save up to 100 entries (24 digits and 12 characters) in the
phonebook.
Create an entry
•Press M
Menu
.
•Select P
Phonebook
, press O
OK
.
•Select A
Add
using the or keys. Press O
OK
.
•Specify the required information by confirming at each step:
-
Family name
: enter your contact's last name,
-
First name
: enter your contact's first name,
-Enter the phone number(s) in the corresponding box (Home, Mobile and
Work).
-Select from one of the 7 available ring tones using the keys or to iniquely
identify this contact.
•Press O
OK
to confirm.
N
Note
To enter a text, press and hold the required key until the letter is
displayed on the screen.
MU 25XXXXXX-A_D680C_US.book Page 33 Dimanche, 2. septembre 2012 9:51 09
34
D680C
Manage your contacts...
Call the contact from phonebook
•Press M
Menu
.
•Select P
Phonebook
, press O
OK
.
•Select an entry using L
List
or S
Search
and press O
OK
.
•Select C
Call
and press O
OK
.
Changing an entry
•Press M
Menu
.
•Select P
Phonebook
, press O
OK
.
•Select an entry using L
List
or S
Search
and press O
OK
.
•Select E
Edit
and press O
OK
.
•Change the last name, first name and/or phone number by deleting characters
using the key and/or the ring tone and press O
OK
.
The action is confirmed by the "O
OK
" indication.
Deleting an entry
•Press M
Menu
.
•Select P
Phonebook
, press O
OK
.
•Select an entry using L
List
or S
Search
and press O
OK
.
•Select D
Delete
using the or keys and press O
OK
.
•For the question D
Delete ?
, press O
OK
to confirm the deletion of the entry.
Search for an entry
•Press M
Menu
.
•Select P
Phonebook
, press O
OK
.
•Select S
Search
using the or keys and press O
OK
.
•For the request F
Family name
, enter the first letter of the name, the entire name, or
part of the name and press O
OK
.
•Once the list is displayed, you can also directly enter the first few letters of the
name sought.
MU 25XXXXXX-A_D680C_US.book Page 34 Dimanche, 2. septembre 2012 9:51 09
35
D680C
Manage your contacts...
Delete all the entries
•Press M
Menu
.
•Select P
Phonebook
, press O
OK
.
•Select D
Delete all
using the or keys. Press O
OK
.
•For the question D
Delete all?
, press O
OK
to confirm the deletion of all entries.
W
Warning
This operation will erase all the files in your base. Once this is
done, you will have an empty phonebook on all the handsets
registered to the base.
Speed dialing
This function allows you to assign a keyboard shortcut to a contact in your
phonebook.
•Press M
Menu
.
•Select P
Phonebook
, press O
OK
.
•Select S
Speed Dialing
using the or keys. Press O
OK
.
•Select, using the key or , the number of the keyboard key you want to assign
to your contact (0~9).
•Press E
Edit
.
•Press P
Phonebook
, select the contact you want to assign a keypad
shortcut. Press O
OK
.
•You can also directly enter the number of your choice. Once the number is
entered, press O
OK
. To exit the menu, press B
Back
3 times in succession.
Note
To call your contact, press and hold the key assigned to the
number and the number is automatically dialed.
MU 25XXXXXX-A_D680C_US.book Page 35 Dimanche, 2. septembre 2012 9:51 09
36
D680C
Voice mail Service...
Voice mail
Service...
4
Note
The default voice mail number is *99.
Modifying the Voice mail number
This function allows you to set your voice mail number on line.
Incoming calls in your absence are redirected to your telephone line's voice mail.
•Press M
Menu
.
•Select V
Voicemail
, press O
OK
.
•The pre-stored number is displayed, and can be edited.
•Enter the voice mail number and press O
OK
. The action is confirmed by the
indication "O
OK
".
N
Note
To indicate that a new message has been received the icon
is displayed on the screen.
MU 25XXXXXX-A_D680C_US.book Page 36 Dimanche, 2. septembre 2012 9:51 09
37
D680C
Audio adjustment...
Audio
adjustment...
5
Changing the ringing tone
You can change the ringing tone of:
-outside calls,
-calls between handsets (intercom).
•Press M
Menu
.
•Select M
Melodies
, press O
OK
.
•Select E
External ringtone
to change the ringing tone for external calls.
- OR -
•Select I
Internal ringtone
to change the ringing tone for internal calls.
•Scroll through the pre-recorded ringing tones and press O
OK
.
•Adjust the ring tone volume and press O
OK
.
Enabling/Disabling the silent mode
In silent mode, the telephone ringer and keypad beeps are muted.
•Press M
Menu
.
•Select M
Melodies
, press O
OK
.
•Select S
Silent
to change the silent mode, then press O
OK
.
•The message "A
Activate silent mode ?
" is displayed on the screen.
-Press Y
Yes
to confirm the enabling of the silent mode.
-Press N
No
to cancel the enabling of the silent mode.
Note
The browser key can also be used to enable/disable the silent
mode.
When you have activated silent mode, your handset is silent for
all functions of the alarm clock and timer type.
If the silent mode is active the icon is displayed.
MU 25XXXXXX-A_D680C_US.book Page 37 Dimanche, 2. septembre 2012 9:51 09
38
D680C
Audio adjustment...
Enabling/Disabling audio alerts
Audio alerts refer to:
•pressing the keypad keys,
•putting the handset on the charger,
•low battery alert,
•others (error alerts).
•Press MMenu .
•Select MMelodies, press OOK.
•Select BBeeps to change the audio alerts, then press OOK.
•Select KKeypad and press the keys or enable or disable the keypad beeps.
- OR -
•Select CCharger and press the keys or to enable or disable the beep when the
handset is placed on the charger.
- OR -
•Select BBattery low and press the keys or to enable or disable the low battery
warning.
- OR -
•Select OOthers and press the keys or to enable or disable the alert of action
not permitted.
Note
The enabled function is marked by the symbol .
MU 25XXXXXX-A_D680C_US.book Page 38 Dimanche, 2. septembre 2012 9:51 09
39
D680C
Setting up...
The phone
Setting up...
6
Setting the date and the time
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select S
Settings
using the or keys and press O
OK
.
•Select D
Date/time
using the or keys and press O
OK
.
•The date and time setting screen is displayed, press E
Edit
.
•Set the clock mode (automatic or manual) with keys or.
•Press the key and then enter the date in MM/DD/YY format.
•Press the key and then enter the time in HH:MM format.
•Confirm your entry by pressing O
OK
. The message "O
OK
" is displayed on the
screen.
Note
The time format is 12 hours, use thekey to set am or pm.
N
Note
If the automatic clock mode is enabled, it is not possible to
change the date and time displayed on the handset.
MU 25XXXXXX-A_D680C_US.book Page 39 Dimanche, 2. septembre 2012 9:51 09
40
D680C
Setting up...
Picking up and hanging up calls automatically
This function allows you to take and end a call by simply taking the handset off or
placing it back on its charger.
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select S
Settings
using the or keys and press O
OK
.
•Select A
Auto hang/pick up
using the or keys and press O
OK
.
•Select
Auto hangup
or A
Auto pickup
using the or keys.
•Set the status (enabled or disabled) with the keys or.
•Confirm by pressing O
OK
. The action is confirmed by the "O
OK
" indication.
Changing the display language
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select S
Settings
using the or keys and press O
OK
.
•Select L
Language
using the or keys and press O
OK
.
•Select the language to be used with the keys or and press O
OK
.
•The action is confirmed by the "O
OK
" indication if the choice of language is
English.
MU 25XXXXXX-A_D680C_US.book Page 40 Dimanche, 2. septembre 2012 9:51 09
41
D680C
Setting up...
Adjust the brightness
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select S
Settings
using the or keys and press O
OK
.
•Select D
Display
using the or keys and press O
OK
.
•Select B
Brightness
using the or keys and press O
OK
.
•A bar graph is used to adjust the brightness according to 8 levels.
•Select the level you want using the keys or .
The brightness is directly visible on the screen.
•Press O
OK
. The action is confirmed by the "O
OK
" indication.
Change the screen background
This menu allows you to change your handset screen background image.
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select S
Settings
using the or keys and press O
OK
.
•Select D
Display
using the or keys and press O
OK
.
•Select W
Wallpaper
using the or keys and press O
OK
.
•Select one of the images using the keys or .
The image is displayed on the screen.
•Press O
OK
to keep this image as a screen background.
The action is confirmed by the "O
OK
" indication.
MU 25XXXXXX-A_D680C_US.book Page 41 Dimanche, 2. septembre 2012 9:51 09
42
D680C
Setting up...
The handset
Associating a new handset
The base allows you to pair other handsets with the base. You then have to pair
them so that they are recognized.
FROM THE BASE:
To enable the pairing mode, press and hold (on the bottom of the base).
FROM THE HANDSET:
Case 1:
The handset displays "P
Please Register
".
•Press O
OK
.
•The handset displays: " P
Put the base in registration & press OK
".
Case 2:
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set handset
using the or keys and press O
OK
.
•Select R
Registration
then press O
OK
.
•The handset displays: " P
Put the base in registration & press OK
".
•Place your base in pairing mode (see previous paragraph).
•On the handset, press O
OK
.
•The message "S
Search
" is displayed.
•Once the base is detected, its name is displayed on the handset screen.
•Press O
OK
to confirm.
•The message "R
Registration in progress
" is displayed.
•The message "R
Registered
" is displayed.
•You then automatically exit the pairing mode.
N
Note
The standard pairing of a new handset is automatic if the default
pin number (0000) has not been changed.
Otherwise a message E
Enter code
prompts you to enter the new
PIN number.
If an error occurs, the message R
Registration Fail
is displayed
prompting you to repeat the whole procedure.
MU 25XXXXXX-A_D680C_US.book Page 42 Dimanche, 2. septembre 2012 9:51 09
43
D680C
Setting up...
Customizing the handset’s registration
This function allows you to pair your handset with a phone base (if you have more
than one).
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set handset
using the or keys and press O
OK
.
•Select H
Handset Version
using the or keys and press O
OK
.
•Select P
Person.registr
using the or keys and press O
OK
.
FROM THE HANDSET:
1
Select the base number and confirm.
2
Enter the new base name and confirm.
3
Enter the base code.
FROM THE BASE:
4
To enable the pairing mode, press and hold (on the bottom of the base).
5
Once the handset is registered, a screen asks you to specify which position you
would attribute to the registred handset. Use keys or and press O
OK
.
The pairing mode is automatically exited.
Defining the main base for your handset
This function allows you to specify the priority base to be used for making calls.
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set handset
using the or keys and press O
OK
.
•Select B
Base priority
using the or keys and press O
OK
.
•Select the base using the or keys that the handset should use first .
Press O
OK
.
Note
Only if you have paired the same handset on several bases.
Note
In automatic mode your handset will automatically select the
most suitable base..
MU 25XXXXXX-A_D680C_US.book Page 43 Dimanche, 2. septembre 2012 9:51 09
44
D680C
Setting up...
Modifying the country
This menu allows you to select the country where you are using the telephone
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set handset
using the or keys and press O
OK
.
•Select C
Country
using the or keys and press O
OK
.
•Select the country using the or keys and press O
OK
.
Handset version
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set handset
using the or keys and press O
OK
.
•Select H
Handset Version
using the or keys and press O
OK
.
The software and EEPROM version of the D680C handset is displayed on the
screen.
Resetting the handset
When you reset your handset, all the settings are returned to their initial values
(factory settings), except for the phonebook.
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set handset
using the or keys and press O
OK
.
•Select R
Reset handset
using the or keys and press O
OK
.
•On a confirmation request "R
Reset handset ?
", press Y
Yes
.
•The action is confirmed by the "H
Handset reset
" indication.
•A list of language is displayed.
•Select the language to be used using the or keys and validate by
pressing O
OK
.
•A list of country is displayed.
•Select the country using the or keys and validate by pressing O
OK
.
•The date and time setting menu is displayed.
•Enter the right date. Press the key ,and enter the time. Press O
OK
.
•The action is validated by the "O
OK
" indication
MU 25XXXXXX-A_D680C_US.book Page 44 Dimanche, 2. septembre 2012 9:51 09
45
D680C
Setting up...
The base
Changing the base code
The base code (PIN number) is 0000 by default, but can be changed to 4 other
numbers. You will be prompted to enter it, for example, when registering a new
handset.
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set base
using the or keys and press O
OK
.
•Select C
Change code
using the or keys and press O
OK
.
•At the "O
Old code
" prompt, enter the old 4-digit code and then confirm by
pressing O
OK
.
•At the "N
New code
" prompt, enter the new 4-digit code and then confirm by
pressing O
OK
.
•At the "C
Confirm code
" prompt, enter the new code again and then confirm by
pressing O
OK
.
•The action is confirmed by the "O
OK
" indication.
Resetting the base
When you reset your base, all the settings are returned to their initial values (factory
settings), except for the phonebook.
•Press MMenu .
•Select SSettings, press OOK.
•Select AAdvanced settings using the or keys and press OOK.
•Select SSet base using the or keys and press OOK.
•Select RReset base using the or keys and press OOK.
•On a confirmation request "BBase reset ?", press OOK.
•The action is confirmed by the "OOK" indication.
MU 25XXXXXX-A_D680C_US.book Page 45 Dimanche, 2. septembre 2012 9:51 09
46
D680C
Setting up...
Base version
•Press MMenu .
•Select SSettings, press OOK.
•Select AAdvanced settings using the or keys and press OOK.
•Select SSet base using the or keys and press OOK.
•Select BBase Version using the or keys and press OOK.
•The following information is displayed:
-base software version,
-EEPROM version,
-base hardware version.
MU 25XXXXXX-A_D680C_US.book Page 46 Dimanche, 2. septembre 2012 9:51 09
47
D680C
Setting up...
The line
This menu allows you to change the settings of the lines on the base.
Important
We do not recommend that you change line settings without first
contacting your operator, as this may result in your phone line being
disconnected.
Change the line name
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set line
using the or keys and press O
OK
.
•Select L
Line name
using the or keys and press O
OK
.
•Press E
Edit
to change the line name using the alphanumeric keys.
•Enter your line name by successively pressing the corresponding keys,
press O
OK
.
Pair the handset with a line
This menu allows you to display the list of handsets paired with the line used.
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Set line
using the or keys and press O
OK
.
•Select A
Attached HS
using the or keys and press O
OK
.
•Enter the base code and press O
OK
.
•The list of paired handsets is displayed on the screen.
•Select the desired handset using the or keys.
•Press the keys or to pair/unpair the handset with/from the line used (the
paired handset is then unpaired and vice versa).
•Press O
OK
. The action is confirmed by the "O
OK
" indication.
Note
The enabled function is marked by the symbol .
MU 25XXXXXX-A_D680C_US.book Page 47 Dimanche, 2. septembre 2012 9:51 09
48
D680C
Setting up...
Allow three-way communication (Intrusion)
This intrusion function allows or prohibits a second handset registered on the same
base to share an ongoing conversation. If the intrusion mode is enabled, you will
then be able to share a call in process with another handset.
•Press MMenu .
•Select SSettings, press OOK.
•Select AAdvanced settings using the or keys and press OOK.
•Select SSet line using the or keys and press OOK.
•Select CConfiguration using the or keys and press OOK.
•Select IIntrusion using the or keys and press OOK.
•Change the status using the keys orand press OOK.
The action is confirmed by the indication "O
OK".
NNote The intrusion is inactive if the simultaneous function is enabled.
Changing the flash duration
You can configure the flash duration if you use your phone abroad or on private
PABX network, you may need to modify the flash duration in order to use your
telephone correctly with regard to the following functionalities: outgoing 2nd call,
incoming 2nd call, 3 way calling.
Please contact your service provider to obtain the correct flash duration and then
modify it by doing the following.
•Press MMenu .
•Select SSettings, press OOK.
•Select AAdvanced settings using the or keys and press OOK.
•Select SSet line using the or keys and press OOK.
•Select FFlash time using the or keys and press OOK.
•Select EEdit using the or keys and press OOK.
•Select the appropriate flash duration using the or key and press OOK.
The action is confirmed by the indication "O
OK".
MU 25XXXXXX-A_D680C_US.book Page 48 Dimanche, 2. septembre 2012 9:51 09
49
D680C
Setting up...
Call management
This menu allows you to select the line on which you want to make your first outgoing call.
Managing your calls
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select S
Selec. call line
using the or keys and press O
OK
.
•The list of lines available is displayed on the screen.
•Select your line using the keys or and press O
OK
.
The action is confirmed by the indication "O
OK
".
MU 25XXXXXX-A_D680C_US.book Page 49 Dimanche, 2. septembre 2012 9:51 09
50
D680C
Setting up...
The list of handsets
This menu displays the list of handsets registered on the same base.
Manage handsets
•Press M
Menu
.
•Select S
Settings
, press O
OK
.
•Select A
Advanced settings
using the or keys and press O
OK
.
•Select H
Handset list
using the or keys and press O
OK.
•The list of handsets registered on the base is displayed on the screen.
•Select the desired handset using the keys or and press O
OK.
•You can perform the following actions:
Change the handset name:
" Edit "
Change the handset name using the alphanumeric keys. Press C
Clear
to
delete unwanted characters. Press O
OK
.
Call the handset:
" Call "
Call the selected handset.
Remove the handset:
"
Delete
"
Remove the handset's registration.
At the confirmation prompt "D
Delete handset?
" press O
OK
. The action is confirmed by
the indication "O
OK
".
Intercept the handset:
"Interception"
Allow the handset to intercept a call.
The message "E
Enter code
" is displayed. Enter the base PIN code (0000 by default),
press O
OK
.
Then select O
On
or O
Off
and press O
OK
.
The action is confirmed by the indication "O
OK
".
MU 25XXXXXX-A_D680C_US.book Page 50 Dimanche, 2. septembre 2012 9:51 09
51
D680C
Accessories...
The alarm
Accessories...
7
Note
The alarm clock function arranges your handset to ring each day at a
specified time.
Once a time is programmed, the selected ring tone rings for 60
seconds through the handset loudspeaker and a warning screen is
displayed. To stop the warning, press any key on the handset.
Programming the alarm
In silent mode, phone the ring tone and the beeps are deactivated.
•Press MMenu .
•Select AAccessories, press OOK.
•Select AAlarm using the or keys then press OOK.
•The alarm clock setting screen is displayed, press EEdit .
•Set the alarm clock status using the keys or.
•Press the key and set the alarm clock:
-wake-up time,
-ring tone,
-ringer volume.
•Press OOK key. The action is confirmed by the "OOK" indication.
MU 25XXXXXX-A_D680C_US.book Page 51 Dimanche, 2. septembre 2012 9:51 09
52
D680C
Accessories...
The timer
Note
The timer function enables the handset to ring after a programmed
time. You can view the time countdown in minutes on the screen.
Program the timer
•Press M
Menu
.
•Select A
Accessories
, press O
OK
.
•Select T
Timer
using the or keysand press O
OK
.
•The timer setting screen is displayed, press E
Edit
.
•Set the timer status using the key or.
•Press the key to enable or disable the timer display.
•Press the key and adjust the timer settings:
-wake-up time,
-ring tone,
-ringer volume.
•Press O
OK
key. The action is validated by the "O
OK
" indication.
MU 25XXXXXX-A_D680C_US.book Page 52 Dimanche, 2. septembre 2012 9:51 09
53
D680C
Tracking your calls...
Call logs
Logs are lists of numbers or events received or sent by your phone. Depending on your
phone company and the options of your contract, the following information may be
accessed in the call logs:
•the date and time of the call.
•the contact's name and/or number.
Tracking your calls...
8
Displaying the list of all calls
•Press M
Menu
.
•Select C
Calls
, press O
OK
.
•Select A
All calls
using or keys, then press O
OK
.
•The last call is displayed with its date and time, its status (incoming, outgoing,
missed), name and/or number.
•Scroll through the numbers stored in the list using the or keys.
•Select the call you wish to view and press O
OK
.
•The following information is displayed:
-the call status (incoming/outgoing/missed),
-the contact's name,
-the contact's number,
-the call date,
-the call time.
•Press B
Back
to return to the previous menu.
Note
The numbers stored in the call log are prefixed by a symbol:
: List of incoming calls,
: List of outgoing calls,
: List of missed calls,
: List of events (missed calls, operator messages).
MU 25XXXXXX-A_D680C_US.book Page 53 Dimanche, 2. septembre 2012 9:51 09
54
D680C
Tracking your calls...
Viewing the received or dialed call log
•Press M
Menu
.
•Select C
Calls
, press O
OK
.
•Select I
Incoming calls
, (or O
Outgoings calls
) using or keys then press O
OK
.
•The last received call (or dialed number) is then displayed.
•The other calls are displayed using the keys or .
•Scroll through the numbers stored in the list using the or keys.
•Select the call you wish to view and press O
OK
.
•The following information is displayed:
-the call status (incoming/outgoing/missed),
-the contact's name,
-the contact's number,
-the call date,
-the call time.
Note
Unknown calls are not included in the received call log.
Note
The last call is only displayed at the top of the list on the first
viewing of the list after the call.
MU 25XXXXXX-A_D680C_US.book Page 54 Dimanche, 2. septembre 2012 9:51 09
55
D680C
Tracking your calls...
Consulting the missed call log
The icon is displayed if there are one or more new missed call and no viewed
calls.
•Press M
Menu
.
•Select C
Calls
, press O
OK
.
•Select M
Missed calls
using the or keys, then press O
OK
.
•The latest missed call is displayed.
•The other calls are displayed using the arrows.
•Scroll through the numbers stored in the list using the or keys.
•Select the call you wish to view and press on O
OK
.
•The following information is displayed:
-the call status (received/sent/missed),
-the contact's name,
-the contact's number,
-the call date,
-the call time.
-the number of missed calls.
•Press B
Back
to return to the previous menu.
Note
Once the missed call log has been viewed, the icon disappears
from all handsets.
MU 25XXXXXX-A_D680C_US.book Page 55 Dimanche, 2. septembre 2012 9:51 09
56
D680C
Tracking your calls...
Managing incoming or outgoing calls
•Press M
Menu
.
•Select C
Calls
, press O
OK
.
•Select A
All calls
or O
Outgoings calls
or I
Incoming calls
or M
Missed calls
then
press O
OK
.
•The list of calls (incoming/outgoing/missed) is displayed.
•Select the desired call and press O
OK
,
to view details.
•The following information is displayed:
-the call status (incoming, outgoing, missed),
-the contact's name,
-the contact's number,
-the call date,
-the call time.
-the number of missed calls.
•Press O
Options
for the actions you can perform:
-
Call
: call the displayed number,
-
Delete
: delete the stored number,
-
Store
: save the number in your phonebook,
-
Delete all
: delete all the numbers in the list.
Menu
> C
Calls
MU 25XXXXXX-A_D680C_US.book Page 56 Dimanche, 2. septembre 2012 9:51 09
57
D680C
Tracking your calls...
The events log
Note
The icon is displayed if there is one or more voice mail
messages.
Checking new events
A summary screen for the number of events that occurred in your absence is
displayed:
-number of missed calls,
-operator messages.
•Press O
OK
.
•Select E
Events
then press O
OK
.
•Select M
Missed
or
Voicemail
using the keys or and press O
OK
. The event
appears on the screen.
Menu
> C
Calls
DECT X
OK Dismiss
Missed calls: XX
Voicemail
MU 25XXXXXX-A_D680C_US.book Page 57 Dimanche, 2. septembre 2012 9:51 09
58
D680C
Environment
Environment
Environmental protection and sustainable development is an important priority for
Sagemcom. Sagemcom has a policy of using environmentally- friendly systems and
makes environmental protection an essential part of the life-cycle of its products – from
the manufacturing, to the installation, operation and disposal.
Packaging
The Cardboard used for the packaging is recyclable. Please follow the local sorting
regulations for this type of waste in order to improve recycling.
Batteries
The used batteries must be disposed of in line with the local recycling regulations.
Battery Safety Instructions
Do not burn, disassemble, mutilate, or puncture the battery. The battery contains toxic
materials that could be released, resulting in injury.
CAUTION
There is a risk of explosion if you replace the battery with an incorrect battery type. Use
only the battery pack that came with your phone or an authorized replacement
recommended by the manufacturer.
•Keep battery packs out of the reach of children.
•Remove battery packs if storing over 30 days.
•Do not dispose of battery packs in fire, which could result in explosion.
•The rechargeable battery packs that power this product must be disposed of properly
and may need to be recycled. Refer to your battery's label for battery type.
Contact your local recycling center for proper disposal methods.
The product
The crossed out dustbin displayed on the product signifies that it belongs to the
electrical and electronic equipment group. The regulations request you to carry
out your own selective recycling collection at:
• the sales outlet when you buy a similar new device.
• the collection points available in your area (recycling centres, sorting points,
etc).
This means you participate in the recycling and validation of used electric and electronic
goods which would otherwise have a negative impact on the environment and health.
MU 25XXXXXX-A_D680C_US.book Page 58 Dimanche, 2. septembre 2012 9:51 09
59
D680C
Guarantee
Guarantee
Limited warranty
What does this limited warranty cover?
Sagemcom warrants to the holder of a valid proof of purchase (“Consumer” or “you”) that
the Product and all accessories provided in the sales package (“Product”) are free from
defects in material and workmanship, pursuant to the following terms and conditions,
when installed and used normally and in accordance with the Product operating
instructions. This limited warranty extends only to the Consumer for Products purchased
and used in the United States of America.
What will Sagemcom do if the Product is not free from defects in materials and
workmanship during the limited warranty period (“Materially Defective Product”)?
During the limited warranty period, Sagemcom’s authorized service representative will
repair or replace at Sagemcom’s option, without charge, a Materially Defective Product.
If we repair the Product, we may use new or refurbished replacement parts. If we choose
to replace the Product, we may replace it with a new or refurbished Product of the same
or similar design. We will retain defective parts, modules, or equipment. Repair or
replacement of the Product, at Sagemcom’s option, is your exclusive remedy. Sagemcom
will return the repaired or replacement Products to you in working condition. You should
expect the repair or replacement to take approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for ONE (1) YEAR from the date of
purchase. If Sagemcom repairs or replaces a Materially Defective Product under the
terms of this limited warranty, this limited warranty also applies to the repaired or
replacement Product for a period of either (a) 90 days from the date the repaired or
replacement Product is shipped to you or (b) the time remaining on the original one-year
warranty; whichever is longer.
MU 25XXXXXX-A_D680C_US.book Page 59 Dimanche, 2. septembre 2012 9:51 09
60
D680C
Guarantee
What is not covered by this limited warranty?
This limited warranty does not cover:
1
Product that has been subjected to misuse, accident, shipping or other physical
damage, improper installation, abnormal operation or handling, neglect, inundation,
fire, water or other liquid intrusion; or
2
Product that has been damaged due to repair, alteration or modification by anyone
other than an authorized service representative of Sagemcom; or
3
Product to the extent that the problem experienced is caused by signal conditions,
network reliability, or cable or antenna systems; or
4
Product to the extent that the problem is caused by use with non-Sagemcom
accessories; or
5
Product whose warranty/quality stickers, product serial number plates or electronic
serial numbers have been removed, altered or rendered illegible; or
6
Product purchased, used, serviced, or shipped for repair from outside the United
States of America or Canada, or used for commercial or institutional purposes
(including but not limited to Products used for rental purposes); or
7
Product returned without a valid proof of purchase (see item 2 below); or
8
Charges for installation or set up, adjustment of customer controls, and installation or
repair of systems outside the unit.
How do you get warranty service?
To obtain warranty service in the USA, please visit our website at www.sagemcom.com.
NOTE
: Before calling for service, please review the user’s manual - a check of the
Product’s controls and features may save you a service call.
Except as provided by applicable law, you assume the risk of loss or damage during
transit and transportation and are responsible for delivery or handling charges incurred
in the transport of the Product(s) to the service location. Sagemcom will return repaired
or replaced Product under this limited warranty. Transportation, delivery or handling
charges are prepaid. Sagemcom assumes no risk for damage or loss of the Product in
transit. If the Product failure is not covered by this limited warranty, or proof of purchase
does not meet the terms of this limited warranty, Sagemcom will notify you and will
request that you authorize the cost of repair prior to any further repair activity. You must
pay for the cost of repair and return shipping costs for the repair of Products that are not
covered by this limited warranty.
MU 25XXXXXX-A_D680C_US.book Page 60 Dimanche, 2. septembre 2012 9:51 09
61
D680C
Guarantee
What must you return with the Product to get warranty service?
1
Return the entire original package and contents including the Product to the
Sagemcom service location along with a description of the malfunction or difficulty;
and
2
Include a “valid proof of purchase” (sales receipt) identifying the Product purchased
(Product model) and the date of purchase or receipt; and
3
Provide your name, complete and correct mailing address, and telephone number.
Other limitations
This warranty is the complete and exclusive agreement between you and Sagemcom. It
supersedes all other written or oral communications related to this Product. Sagemcom
provides no other warranties for this Product. The warranty exclusively describes all of
Sagemcom’s responsibilities regarding the Product. There are no other express
warranties. No one is authorized to make modifications to this limited warranty and you
should not rely on any such modification.
State/Provincial Law Rights: This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state or province to province.
Limitations:
Implied warranties, including those of fitness for a particular purpose and
merchantability (an unwritten warranty that the Product is fit for ordinary use) are limited
to one year from the date of purchase. Some states/provinces do not allow limitations on
how long an implied warranty lasts, so the above limitation may not apply to you. In no
event shall Sagemcom be liable for any indirect, special, incidental, consequential, or
similar damages (including, but not limited to lost profits or revenue, inability to use the
Product or other associated equipment, the cost of substitute equipment, and claims by
third parties) resulting from the use of this Product. Some states/provinces do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation
or exclusion may not apply to you.
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Privacy of communications may not be ensured when using this telephone!
MU 25XXXXXX-A_D680C_US.book Page 61 Dimanche, 2. septembre 2012 9:51 09
MU 25XXXXXX-A_D680C_US.book Page 1 Dimanche, 2. septembre 2012 9:51 09
Sagemcom Broadband SAS
250, route de l'Empereur - 92848 Rueil-Malmaison - France
Tél. +33(0)1 57 61 10 00 - Fax : +33(0)1 57 61 10 01
www.sagemcom.com
253546047A - 09/13
MU 25XXXXXX-A_D680C_US.book Page 2 Dimanche, 2. septembre 2012 9:51 09
