SDI Technologies HDL50 Hotel Bluetooth Universal Bedside Spesker System User Manual HDL50 QSG 0321

SDI Technologies Inc. Hotel Bluetooth Universal Bedside Spesker System HDL50 QSG 0321

users manual

HDL50
Sta Quick Start Guide
Included
• HDL50 system
• 100V-240V universal AC adaptor
Set Up
Connect AC adaptor
to DC jack/wall outlet
Remove pull tab from Backup Battery
Compartment located on bottom of the
unit. When Low Battery Icon appears on display,
replace backup battery with 1 fresh CR2450
battery. Keep unit connected to power when
replacing battery or you will lose settings.
Remove thumbscrew
and remove back cover to
access sta controls
Secure the attached Security Tether to
a wall or other permanent surface.
CAUTION: DO NOT attach to an AC
outlet or cause it to become entangled
with anything that can create a
hazardous situation.
-1 +1 auto
DST
time set time zonetime sync high low
volume level12VDC 35000mA
12V 3.5A
outlet
The unit ships with the Daylight Saving Time (DST) switch in
Auto position, and will automatically adjust when the time
changes in March and November.
Setting Clock Using Time Sync
Daylight Saving Time
a) Connect a Lightning-compatible
iPhone to the Dock
Press the Time Sync Button
on the back of the unit to instantly
set the time on the HDL50.
b
NOTE: For the fastest, most accurate time setting,
set the clock using Time Sync with
a) a docked iPhone OR
b) an iPhone connected to the USB port
iPhone time is always current because it pings off cell towers;
iPad or iPod are only accurate to the last time they were
synced to a computer.
Make sure the DST switch is in AUTO position.
If you do not have an iPhone or if time sync fails,
set the clock manually.
b) connect any iPhone to the USB port using
the USB cable that came with it
-1 +1 auto
DST
time sync
a
snooze/dimmer
function
talk
endpower iPod/USB/radio
Bluetooth/line-in
alarm
on/off
wake-to
FM
presets
alarm
set
pairing
1- place your device into “discoverable” mode
2- press and hold“pairing” button on unit for 2 sec
3- if prompted, enter code “0000”
4- your device is now paired. You can answer and
end calls by pressing “talk” and “end”
to use Bluetooth
1- press “alarm set” button
2- use </> to set desired wake-up time
3- press “alarm set” button again to conrm
4- press “wake-to” button to switch between
waking to your iPod, USB dock, radio, or buzzer
to use alarm
Or
Manual Clock Setting
Press the Time Set Button
Press the Time Set Button
Press the or button to set time
Press the or button to set year
Press the or button to set date
Press the or button to tune to
a desired station (hold to search for
next clear station)
time set
Press and hold the Time Set Button
2 SECS
time set
time set
Press and hold the
Time Set Button
2 SECS
2 SECS
time set
Press the Time Set Button
to conrm Clock Setting
time set
Beep
Beep
time set
Press the Time Set Button
to conrm Beep
Beep
Setting 12/24 Hour Time Display
FM Radio
FM Presets
To toggle time display
between 12 or 24 hours,
press alarm set button
alarm
set
Press function Button
as needed to cycle to
FM mode
function
iPod/USB/radio
Bluetooth/line-in
Press FM presets Button
to cycle to the preset
(P1- P6) you wish to set
Press FM presets
Button to conrm
Follow steps above to set all 6 FM presets
Once sta has completed setup, replace security cover on
back of unit and tighten thumbscrew.
Beep
Beep
Press the or button to
select station to preset
FM
presets
Press and hold FM presets
Button to conrm preset
number
FM
presets
HDL50 Quick Start Guide - Front
Size: 432 x 140 mm
Printing Color: Black
Mat’l: 100 gsm WF paper
Mar. 21, 13.
HDL50 Quick Start Guide - Inside
Size: 432 x 140 mm
Printing Color: Black
Mat’l: 100 gsm WF paper
Mar. 21, 13.
HDL50QSG-031913-A © 2013 HTI Industries, LLC. All rights reserved Printed in China
