SDI Technologies HDL50A Hotel Bluetooth Universal Speaker System for iPad, iPhone and iPod User Manual

SDI Technologies Inc. Hotel Bluetooth Universal Speaker System for iPad, iPhone and iPod

User Manual

-1 +1 auto
DST
time set time zonetime sync
DC 12V 3.5A
HDL50A
Sta Quick Start Guide
Included
• HDL50A system
• 100V-240V universal AC adaptor
Set Up
Connect AC adaptor
to DC jack/wall outlet
Remove pull tab from Backup Battery
Compartment located on bottom of the
unit. When Low Battery Icon appears on display,
replace backup battery with 1 fresh CR2450
battery. Keep unit connected to AC power when
replacing battery or you will lose settings.
Remove thumbscrew
and remove back cover
to access sta controls
Secure the attached Security Tether to
a wall or other permanent surface.
CAUTION: DO NOT attach to an AC
outlet or cause it to become entangled
with anything that can create a
hazardous situation.
12V 3.5A
outlet
The unit ships with the Daylight Saving Time (DST) switch in
Auto position, and will automatically adjust when the time
changes in March and November.
Setting Clock Using Time Sync
Daylight Saving Time
a) Connect a Lightning-compatible
iPhone to the Dock
Press the Time Sync Button
on the back of the unit to instantly
set the time on the HDL50A.
b
NOTE: For the fastest, most accurate time setting,
set the clock using Time Sync with
a) a docked iPhone OR
b) an iPhone connected to the USB port
iPhone time is always current because it pings off cell towers;
iPad or iPod are only accurate to the last time they were
synced to a computer.
Make sure the DST switch is in AUTO position.
If you do not have an iPhone or if time sync fails,
set the clock manually.
b) connect any iPhone to the USB port using
the USB cable that came with the iPhone
-1 +1 auto
DST
time sync
a
snooze/dimmer
function
talk
endpower iPod/USB/radio
Bluetooth/line-in
alarm
on/o
wake-to
FM
presets
alarm
set
pairing
1- place your device into “discoverable” mode
2- press and hold“pairing” button on unit for 2 sec
3- if prompted, enter code “0000”
4- your device is now paired. You can answer and
end calls by pressing “talk” and “end”
to use Bluetooth
1- press “alarm set” button
2- use </> to set desired wake-up time
3- press “alarm set” button again to conrm
4- press “wake-to” button to switch between
waking to your iPod, USB dock, radio, or buzzer
to use alarm
Or
Manual Clock Setting
Press the Time Set Button
Press the Time Set Button
Press the or button to set time
Press the or button to set year
Press the or button to set date
Press the or button to tune to
a desired station (hold to search for
next clear station)
time set
Press and hold the Time Set Button
to enter clock setting mode 2 SECS
time set
2 SECS
time set
Press the Time Set Button
to conrm Clock Setting
time set
Beep
Beep
FM Radio
FM Presets
Maintenance
alarm
set
Press function Button
as needed to cycle to
FM mode
function
iPod/USB/radio
Bluetooth/line-in
Press FM presets Button
to cycle to the preset
(P1- P6) you wish to set
Press FM presets
Button to conrm
Follow steps above to set all 6 FM presets
Extend FM antenna for best reception
Once sta has completed setup, replace security cover on
back of unit and tighten thumbscrew.
Beep
Beep
Press the or button to
select station to preset
FM
presets
Press and hold FM
presets Button to
conrm preset
number
FM
presets
FM
presets
HDL50A Quick Start Guide - Front
Size: 432 x 140 mm
Printing Color: Black
Mat’l: 100 gsm WF paper
May 30, 13. (For Finemost)
HDL50A Quick Start Guide - Inside
Size: 432 x 140 mm
Printing Color: Black
Mat’l: 100 gsm WF paper
May 30, 13. (For Finemost)
HDL50AQSG-053013-A © 2013 HTI Industries, LLC. All rights reserved Printed in China
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other
protective material should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as
thinner or similar materials can damage the surface of the unit.
WARNING: Lithium batteries can explode or cause burns if
disassembled, shorted, recharged, exposed to water, re, or
high temperatures. Do not place loose batteries in a pocket,
purse, or other container containing metal objects, mix with
used or other battery types, or store with hazardous or
combustible materials. Store in cool, dry, ventilated area. Follow
applicable laws and regulations for transport and disposal.
NOTE: Time display can be set to 12 or 24 hours at any time
during clock setting
To toggle time display
between 12 or 24 hours,
press the alarm set button
during clock setting
Clock Setting
