SDI Technologies IBT74 Color Changing Rechargeable Bluetooth Speaker with Speakerphone User Manual iBT74 EN IB 0213
SDI Technologies Inc. Color Changing Rechargeable Bluetooth Speaker with Speakerphone iBT74 EN IB 0213
User Manual
Thank you for purchasing the iHome iBT74. This product is designed to provide high quality wireless
sound for your iPad, iPhone, iPod, computer, PDA or other Bluetooth audio device.
This instruction booklet explains the basic operation and care of the unit. Please read them carefully and
keep for future reference.
Maintenance
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other
protective material should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents,
such as benzene, thinner or similar materials can damage the surface of the unit.
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects
in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original
purchase.
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects
in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original
purchase. Should this product fail to function in a satisfactory manner, it is best to first return it to the store where it was originally
purchased. Should this fail to resolve the matter and service still be required by reason of any defect or malfunction during
the warranty period, SDI will repair or, at its discretion, replace this product without charge. This decision is subject to
verification of the defect or malfunction upon delivery of this product to the Factory Service Center authorized by Customer
Service.
If service is required, please call Customer Service at 1-800-288-2792 to obtain a Return Authorization Number and shipping
instructions.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i) products
which have been damaged by negligence or willful actions, misuse or accident, or which have been modified or repaired
by unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage to digital media
players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory Service Center and its return
to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product other than to the
original purchaser. In no event will SDI or any of its affiliates, contractors, resellers, their officers, directors, shareholders,
members or agents be liable to you or any third party for any consequential or incidental damages, any lost profits, actual,
exemplary or punitive damages. (Some states do not allow limitations on implied warranties or exclusion of consequential
damages, so these restrictions may not apply to you.) This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
Your acknowledgement and agreement to fully and completely abide by the above mentioned disclaimer of warranty is
contractually binding to you upon your transfer of currency (money order, cashier's check, or credit card) for purchase of your
SDI product.
© 2015 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects
in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original
purchase.
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants this product to be free from defects
in workmanship and materials, under normal use and conditions, for a period of one (1) year from the date of original
purchase. Should this product fail to function in a satisfactory manner, it is best to first return it to the store where it was originally
purchased. Should this fail to resolve the matter and service still be required by reason of any defect or malfunction during
the warranty period, SDI will repair or, at its discretion, replace this product without charge. This decision is subject to
verification of the defect or malfunction upon delivery of this product to the Factory Service Center authorized by Customer
Service.
If service is required, please call Customer Service at 1-800-288-2792 to obtain a Return Authorization Number and shipping
instructions.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was designed. It does not cover (i) products
which have been damaged by negligence or willful actions, misuse or accident, or which have been modified or repaired
by unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii) damage to digital media
players, CD’s or tape cassettes (if applicable); (iv) the cost of shipping this product to the Factory Service Center and its return
to the owner.
This warranty is valid only in the United States of America and does not extend to owners of the product other than to the
original purchaser. In no event will SDI or any of its affiliates, contractors, resellers, their officers, directors, shareholders,
members or agents be liable to you or any third party for any consequential or incidental damages, any lost profits, actual,
exemplary or punitive damages. (Some states do not allow limitations on implied warranties or exclusion of consequential
damages, so these restrictions may not apply to you.) This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
Your acknowledgement and agreement to fully and completely abide by the above mentioned disclaimer of warranty is
contractually binding to you upon your transfer of currency (money order, cashier's check, or credit card) for purchase of your
SDI product.
© 2015 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
Limited 1 Year Warranty
iBT74 EN-IB -
Size: 214mm x 336mm
Printing color: Black
Feb 13, 2015-r
100gsm2 WF (書紙)
9
Consumer Product Safety Guide
8
When used in the directed manner, this unit has been designed and manufactured to ensure
your personal safety. However, improper use can result in potential electrical shock or fire
hazards. Please read all safety and operating instructions carefully before installation and use,
and keep these instructions handy for future reference. Take special note of all warnings listed
in these instructions and on the unit.
1. Water and Moisture – DO NOT immerse unit in water. Make sure the seal and surrounding
surfaces are completely dry before opening seal to prevent moisture from damaging the
internal electronics. Keep seal free of dirt, sand, or other objects that can interfere with proper
sealing. If for any reason the seal is not making a tight seal, water may enter the unit.
2. Ventilation – The unit should be situated so that its location or position does not interfere
with its proper ventilation. For example, it should not be situated on a bed, sofa, rug or
similar surface that may block ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers,
stoves or other appliances (including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described
in the operating instructions or as marked on the appliance.
5. Cleaning – The unit should be cleaned only using a warm damp cloth. Do not use solvents,
etc.
6. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are
not spilled into any openings or vents located on the product.
7. Attachments – Do not use attachments not recommended by the product manufacturer.
8. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect
the antenna or cable system during a lightning storm or when it is left unattended and unused
for long periods of time. This will prevent damage to the product due to lightning and
power-line surges.
9. Overloading – Do not overload wall sockets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
10. Damage Requiring Service – The unit should be serviced by qualified service personnel
when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as
a month or longer, fully charge the unit before storing.
13. Servicing – The user should not attempt to service the unit beyond those methods described
in the user’s operating instructions. Service methods not covered in the operating instructions
should be referred to qualified service personnel.
Questions? Visit www.ihome.com
or call 1-800-288-2792 Toll Free
IMPORTANT SAFETY INSTRUCTIONS
Internal Rechargeable Lithium-ion Battery
This device uses an internal rechargeable lithium-ion battery that should last the lifetime of the device. If you
suspect your battery may be dead, try charging it several times. If the battery does not recharge, please contact
us for repair information.
WARNING/DISPOSAL OF UNIT
Please do NOT attempt to change the battery yourself. If the battery has died and you do not want us to replace
your battery, you should follow the disposal instructions below:
• Never dispose of used batteries/electronics with ordinary solid wastes, since they contain toxic substances.
• Always dispose of used batteries/electronics in accordance with the prevailing community regulations that apply
to the disposal of batteries/electronics. If there are no local regulations concerning battery/electronics disposal,
please dispose of the device in a waste bin for electronic devices.
• Many electronics retailers now recycle batteries and other electronic components at no charge. Check to see
which ones in your area do so.
CAUTION
The battery used in this device may present a risk of fire, explosion or chemical burn if
mistreated
• Never use or charge the battery if it appears to be leaking, discolored, deformed, or in any way abnormal.
• Never disassemble the unit or attempt to remove battery as that could cause leakage of alkaline solution or other
electrolytic substance.
• Always confirm that the temperature is 5°C – 35° C (41° - 95° Fahrenheit) before you charge the battery.
Leakage or deterioration of the battery may occur if this warning is not heeded.
• Never expose the battery to any liquid.
• Never expose the battery to excessive heat such as direct sunlight or fire. Never use the battery pack in an
unventilated vehicle where excessive internal temperatures may be encountered.
• Always keep the battery out of the reach of infants and small children.
Introduction
iBT74-150213-B (EN) Printed in China
Color Changing Rechargeable
Bluetooth Speaker
with Speakerphone
instruction manual
Model: iBT74
CHARGE
BEFORE
USE
iBT74
FCC Information
This device complies with Part 15 of the FCC Rules, operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
This Device complies with RSS-210 of the IC Rules; Operation is subject to the following two
conditions:
(1) This device may not cause interference and
(2) This device must accept any interference received, including interference that may cause
undesired operation
• Warning: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
• NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3(B)
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and
compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure
and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS
102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne
sur l'exposition et la conformité de rf.
FCC ID: EMOIBT74
IC: 986B-IBT74
Declaration ID D024962
iBT74 EN-IB
Size: 214mm x 336mm
Printing color: Black
Feb 03, 2015-r
100gsm2 WF (書紙)
What’s Included
• iBT74 speaker
• Combination micro USB to USB charging cable/audio in cable
• carry strap
iBT74 carry strap
8
6
7
5
1
2
3
iBT74
Meet Your iBT74
Pairing with a Different Device
When you power ON the speaker, it will automatically link with the previously paired Bluetooth device
as long as that device is still within range (approx. 30 feet). To pair with a different device follow steps
1 - 4 under ”Pairing Your Device” on previous page.
Playing Audio Via Bluetooth
1. Slide the Power On/Off Switch to ON to turn on the unit. The Bluetooth status indicator will glow
solid blue when a linked device is in range and detected. You can then listen to audio streamed
wirelessly from your paired Bluetooth device.
2. Use controls on your Bluetooth device to play, pause and navigate tracks.
3. Press t
he – or + Button to adjust
the iBT74 volume. You can also adjust volume on your device.
4. When done listening,
slide the Power On/Off Switch to OFF turn the unit OFF
.
Remember to turn
off your device, too.
Speakerphone Operation
NOTE: The unit must be powered on and linked to a Bluetooth phone to receive a call.
1. When a call is received, playing music is muted to hear the ring tone and the cabinet lights flash
green. Press thexxxBluetooth/Speakerphone Button to answer the call. For call waiting function,
press the button again to answer the second call, and once more to return to the original call.
2. When a call is completed, press the Bluetooth/Speakerphone Button to end the call and resume
previous function.
Unit doesn’t respond (no power)
• Make sure unit is completely charged.
• Check that all connections are correct and properly plugged in.
• Make sure your device is properly paired with the iBT74.
• Make sure the unit is on
Unit doesn’t respond (locked up/ “frozen”)
If the unit does not respond, try resetting the unit. Press and hold bothe the “+” and “–” Buttons at the same
time for about 10 seconds. Note that doing so will clear settings, and any Bluetooth devices will need to
be re-paired.
Trouble pairing device with iBT74
Bluetooth implementation varies depending on your device’s hardware and operating system. Please see
our website for updates on pairing.
• When you power ON the speaker, it will automatically link with the last previously paired Bluetooth
device if the device is still within range (approx. 30 feet). To pair with a different device you must turn
off Bluetooth capability on the already paired device, or take it out of range.
• If your device does not auto-link when within range, re-pair the device. To do so, first delete the iBT74
from your Bluetooth devices menu.
• Make sure your device is working properly. Check your device’s manual for details on Bluetooth pairing
and linking.
For further information and to see the latest instructions, visit www.ihome.com/support
84
Troubleshooting
Combination
micro USB to USB cable/audio cable
Bottom
Top
Power On/Off Switch
Carry Strap Channel
(lantern mode)
Charging/Bluetooth
Status Indicator Light
o on
Back
Bluetooth/
Speakerphone
Button
Color Mode Button
(press and hold for
Battery Review) Lower/Raise
Volume Buttons
Charging/
Aux-in
USB port
Carry Strap Channel
Getting Started: Carry Strap
The iBT74 has two channels to attach the included carry strap,
one on the bottom to hang the unit like a lantern, and one on the lower
back of the unit. To attach the carry strap, form a small loop in one end of the
carry strap. Insert this loop through the desired channel, then pull the
loop back through the larger loop formed in the carry strap to tighten.
Charging the Unit
CHARGE UNIT BEFORE USE/KEEP UNIT OFF FOR FASTER CHARGING
1. Connect the micro USB plug on the included combination cable to
the micro USB Charging/Aux-in USB Port on the side of the unit.
2. Connect the standard USB plug end of the cable to a power USB port on a computer, a USB AC
adaptor or other USB charging device. For first time use, charge unit for about 4 hours. The status
indicator LED on top of the unit turns solid red while charging and turns off once unit is fully charged.
iHome iBT74 USB port iHome iBT74 USB port
Charge via computer USB port, USB AC adaptor or other powered USB port
Computer USB port
Computer
connected to
working outlet
USB AC adaptor
(not included)
USB AC adaptor
connected to working outlet
o on
Pairing is the set-up process to introduce your Bluetooth-capable device to the iBT74. Once your device is
paired, the iBT74 can recognize it and you can play your audio through it.
1. Turn on your Bluetooth device and make it “discoverable” by turning on Bluetooth
mode (check in Options or Settings).
2. Slide the Power On/Off Switch to ON to turn on the iBT74. The first time the unit is
powered on, it will enter auto-pairing mode and attempt to connect to a Bluetooth
device (if so, skip to step 4). Otherwise, follow step 3 to begin pairing.
3. Press and hold the Bluetooth/Speakerphone Button for 2 seconds. The iBT74 will
beep and the Bluetooth status indicator light on top of the unit will flash quickly.
If Color Mode is on, the cabinet lights will flash blue and red.
4. “iHome iBT74” should appear in your device’s Bluetooth menu. If “Not Paired”, “Not Connected” or similar
message appears, select “iHome iBT74” to connect it. If prompted for a passcode, enter “1234” on your
device’s keypad.
Using the iBT74iBT74
5. If pairing is successful, 1 beep will sound and the Bluetooth status indicator light will appear solid blue (in
Color Mode, cabinet will flash blue twice), indicating the iBT74 is ready to play music. There should also
be an indication on your device. If no device is successfully paired within 3 minutes the iBT74 will default
to previous mode. Once the iBT74 is paired to a device, it will attempt to autolink when the device is
within range (about 30 feet).
Pairing Your Device
For iPhone
iHome iBT74 iHome iBT74
iHome iBT74 iHome iBT74
For other
Playing Audio via Aux In
1. Connect micro USB charging/audio cable to the Charging/Aux-in USB Port
on the side of the unit and connect the 3.5mm audio plug end to the
headphone or line-out jack on your audio device.
2. Slide the Power On/Off Switch to ON turn the unit ON.
3. Power on the audio device and use the controls on the device to play or pause
audio and to navigate tracks.
4. Press the – or + Button to adjust the system volume. You can also adjust
volume on your device.
5. When done listening, slide the Power On/Off Switch to OFF turn the unit OFF.
Remember to turn off your device, too.
Using Color Modes
There are six color modes, which you cycle through in this order:
a. Slow Fade (colors slowly fade from one into the next b. Fast Change (colors change rapidly)
c. One Color (select a favorite color) d. Pulse to Music (lights flash to the beat of the music)
e. Preset Pulsing (each light array pulses through its own preset pattern of colors)
f. Off (no display)
1. Slide the Power On/Off Switch to ON turn the unit ON.
2. Press the Color Mode Button repeatedly to cycle to the desired color mode. For One Color mode, first cycle
to Fast Change mode and press the Color Mode Button when the desired color appears. For Pulse to Music,
make sure the volume on your connected Bluetooth device is above 30%.
3. When done, slide the Power On/Off Switch to OFF turn the unit OFF.
Mobile Phone Game Devices iPod Laptop
PC/Tablet MP3/MP4
OR
Front
Microphone
TIP: On some iOS (Apple) devices,
you can view the iBT74 battery
status on your deviceʼs screen.
When device is paired and
connected, look for a vertical
battery icon next to
the Bluetooth icon on
the upper right corner
of the deviceʼs screen.
3. To review the charging status of the unit while it is charging, press and hold the Color Mode
Button. The cabinet lights will flash for 5 seconds to show charge level.
Reviewing Battery Charge Level (Charger is Disconnected)
1. Press and hold the Color Mode Button when unit is not
charging to enter Battery Review Mode. The cabinet lights
will blink and built-in voice will announce the current battery
level.
LowVery Low
RED GREEN
Good High
Feb 13, 2015
Feb 13, 2015
