User Manual

Intelligent Home Solutions

Model: iSS50

Control your SmartMonitor from anywhere with your smartphone

SMARTMONITOR

Quick Start Guide

WHAT YOU’LL NEED

Apple device running iOS 9.0 or later or Android device running Jelly Bean 4.2 or later

connected to your preferred WiFi network

WiFi network transmitting at 2.4GHz1

NOTE: If you intend to use a mix of devices (iOS AND Android), please set up the

SmartMonitor using your iOS device and then share to your Android device(s).

(Smart Console)

(this page intentionally blank)

More SmartMonitors to set up? Repeat from Step

Quick Start Setup

Download and open the iHome Control app from the App Store or Google Play.

Connect SmartMonitor to power using included cable and adapter. The icon

will start ﬂashing to indicate it is ready for setup.

Tap Add Device ... in the Devices tab and follow the on-screen directions to

complete setup.

When prompted, scan or type the Accessory Setup Code below:

Success! You should now be able to monitor your home environment using the

iHome Control app.

NOTE: when typing, dashes are not required

SmartMonitor Overview

Flashing: SmartMonitor is ready

for setup

Flashing: SmartMonitor is searching

for a Wi-Fi network

Solid with Border: SmartMonitor is connected

Motion

Indicator

Wi-Fi Status Indicator

dimmer power in reset

To dim the LCD screen, tap the

DIMMER button.

To reset the SmartMonitor, press

and hold the SETUP button for a

full 15 seconds.

(Use the iHome Control app to

reconﬁgure network settings)

Wi-Fi

Status

Sound

Indicator

Humidity

Temperature

BACK OF UNIT

Sharing

Now that you’ve successfully completed setup, you may want to gain/share access

to your SmartMonitors on dierent devices. Please follow the chart below:

Grant Access to iOS Devices

NOTE: sharing works from iOS to iOS, iOS to Android, and Android to Android

w/ dierent

iCloud accounts

w/ the same

iCloud account

Download and

launch the iHome

Control app on

other device(s)

and wait for the

SmartMonitor(s) to

appear

NOTE: If you chose

to set up an iHome

account, use the

same login on both

devices

Tap Sharing in the

Settings section

of the iHome

Control app and

follow instructions

Download and

launch the iHome

Control app on

other devices(s)

Accept invitation on

other device(s)

Grant Access to Android Devices

option 2option 1

Download and

launch the iHome

Control app on

other device(s)

and sign in with

your existing

iHome account

credentials

Tap Sharing in

the Settings

section of the

iHome Control

app and follow

instructions

Download and

launch the iHome

Control app on

other device(s)

Accept invitation

on other device(s)

Third Party Connections

We’re constantly striving to build useful integrations for iHome Control products.

Visit the Settings section of the iHome Control app for the latest information.

4More About Your SmartMonitor

Your SmartMonitor is compatible with iHome SmartPlugs2. For information about

compatible products and to purchase SmartPlugs, visit iHome.com.

Example Uses:

Set rule to automatically turn on fan or air conditioner

(connected to SmartPlug) when SmartMonitor detects

a certain temperature

Set rule to turn on lamps (connected to SmartPlug)

when SmartMonitor detects motion

And more!

HomeKit (iOS only)

The SmartMonitor is compatible with Apple HomeKit technology. Create your

own custom scenes to automatically control your home including any

HomeKit-enabled accessory. Use the Apple Home app to conﬁgure scenes and

automation.

And more!

Room temperature dropped below 65˚

SmartMonitor triggers a HomeKit-enabled thermostat

to turn on the heating system.

Movement is detected in the foyer

SmartMonitor detects motion, triggers a scene to

turn on lights.

Light sensor on SmartMonitor senses it is dark outside

Triggers user-deﬁned “Night” Scene which closes the

garage door, lowers the blinds and locks the doors.

Example Conﬁgurations

Things to Know

We recommend placing your SmartMonitor away from direct sunlight and/or air

conditioning vents. This will ensure the most accurate temperature and humidity

readings for your home environment.

The SmartMonitor will auto-calibrate to your home environment. It may take up

to 2 hours for temperature/humidity readings to be accurate.

Motion detection is dependent on room conditions and lighting. An accurate

reading occurs when a subject crosses in front of the SmartMonitor. For optimal

sensing, we recommend positioning the front of SmartMonitor in the direction

you want to cover. Detection is accurate up to 20ft but may exceed that in

certain conditions.

The SmartMonitor Sound and Light detection sensitivity thresholds can be

adjusted using the iHome Control app.

The SmartMonitor can detect “room occupancy” using Sound or Motion. To

deﬁne room occupany time thresholds, use the iHome Control app.

Use the iHome Control app to determine when you want to receive notiﬁcations

to your phone about changes in your home environment.

1 All Wi-Fi routers support 2.4GHz spectrum. If your router was deliberately set to only transmit 5GHz, then please

note that the SmartMonitor will not work properly on your network. Enterprise networks (such as in colleges and

businesses) often have more restricted security settings that may impact the performance of your SmartMonitor.

2 When using iHome SmartPlugs with the SmartMonitor, please note that the SmartPlug supports devices or

appliances up to 1800 Watts. Please consult the owner’s manual of your device. Connected device requires a

manual on/o switch.

Notes

Electrical Ratings

5V 1A

Safety Warnings

For indoor use only

Disconnect cable from SmartMonitor before cleaning with a warm damp cloth

DO NOT use solvents

DO NOT clean with liquid

DO NOT use in wet or damp areas

Keep children away from SmartMonitor

Notices

FCC

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

To assure continued FCC compliance:

1. Any changes or modiﬁcations not expressly approved by the grantee of this device could void the user's authority to

operate the equipment.

2. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment

should be installed and operated with minimum distance 20cm between the radiator & your body.

FEDERAL COMMUNICATIONS COMMISSION

INTERFERENCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

iSS50_2016_QSG_v1

For warranty information: visit https://www.ihomeaudio.com/support/

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two

conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should

be installed and operated with minimum distance 20cm between the radiator and your body.

Legal

Use of the HomeKit logo means that an electronic accessory has been designed to connect speciﬁcally to iPod, iPhone, or

iPad, respectively, and has been certiﬁed by the developer to meet Apple performance standards. Apple is not responsible

for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this

accessory with iPod, iPhone, or iPad may aect wireless performance.

Controlling HomeKit-enabled accessories, with features like Siri, away from home requires an Apple TV (3rd generation or

later) with Apple TV software 7.0 or later and an iPhone, iPad, or iPod touch with iOS 9.0 or later.

Wink is a registered trademark. Nest®, Nest Learning Thermostat and the Works with Nest logos are trademarks licensed

by Nest Labs, Inc. Amazon Echo is a trademark of Amazon.com, Inc. or its aliates.



FCC

CONFORMITÉAUXRÈGLESDELAFCC:Cetéquipementaététestéetdéclaréconformeaux

spécificationsdelaClasseBdesappareilsnumériques,conformémentauchapitre15desrègles

delaFCC.Ceslimitesontétédéfiniespourassureruneprotectionsuffisantecontreles

interférencesnuisiblesauxinstallationsdomestiques.Cetéquipementgénère,utiliseetpeut

émettredesondesradioélectriqueset,s’iln’estpasinstalléetutiliséconformémentaux

instructions,peutprovoquerdesinterférencesnuisiblesauxcommunicationsradio.Toutefois,

riennegarantitqu’uneinstallationparticulièrenesubiraaucuneinterférence.Sicetéquipement

produitdesinterférencesnuisiblesàlaréceptiondelatélévisionoudelaradio,cedontilest

possibledes’assurerenallumantetenéteignantl’équipement,ilestrecommandédetenterde

réglerleproblèmeàl’aided’uneouplusieursdessolutionssuivantes:•Réorienteroudéplacer

l’antennederéception.•Éloignerl’équipementdupostederéception.•Brancher

l’équipementsuruneprised’uncircuitdifférentdeceluisurlequelestbranchélepostede

réception.•Contacterlerevendeurdel’équipementouuntechnicienspécialistedumatériel

téléviséetradiophonique.Cetappareilestconformeauchapitre15desrèglesdelaFCC.Son

utilisationestsoumiseauxconditionssuivantes:(1)cetappareilnedoitpascauser

d'interférencesdangereuses,et(2)cetappareildoittolérerlesinterférencesreçues,ycomprisles

interférencesquipourraientendérangerlefonctionnement.REMARQUE:leschangementsou

modificationsapportésàcetappareilquinesontpasapprouvésexpressémentparleresponsable

delaconformitépeuventannulerledroitdel'utilisateuràutiliserl'équipement.INFORMATIONS



IC

RELATIVESÀL'IC:LeprésentappareilestconformeauxCNRd'IndustrieCanadaapplicablesaux

appareilsradioexemptsdelicence.L'exploitationestautoriséeauxdeuxconditionssuivantes:(1)

l'appareilnedoitpasproduiredebrouillage,et(2)l'utilisateurdel'appareildoitacceptertout

brouillageradioélectriquesubi,mêmesilebrouillageestsusceptibled'encompromettrele

fonctionnement.CANICES‐3(B)/NMB‐3(B)

Questions?

1•800•288•2792
