SECOM TWSECOMOPC0050 Access Reader User Manual 20171201 OPC0050

TAIWAN SECOM CO., LTD. Access Reader 20171201 OPC0050

User Manual

OPC0050 User Manual
Overview
This product is suitable for RFID reader, for Access Control Management System. The card
reader does not store any card information. When card is sensed, data is sent to the access
controller via the RS485 interface
Function Description：
：：
：
1) Conforms to ISO 14443A and supports MIFARE card.
2) Provides RS-485 communication interface for long distance installation.
3) LED indicator:
Normal - blue light
Card recognition is correct - green light
Card identification is invalid - red light
RS485 communication failed - blue and red light flashing alternately
4) Voice prompts:
Card recognition is correct - Beep once
Card identification is invalid / RS485 communication failed - Beeps continuously
5) There is a touch button for doorbell, press to trigger the doorbell relay action; press the
button for more than three seconds will trigger an emergency relay action.
6) 2- Relay: Used in doorbell notification and emergency notification.
7) Device Addressing Settings: Use a DIP 4-Switch method to address card readers. The
upper limit of card reader is 16.
LED indicator
DIP SW1~4
DIP SW1~4DIP SW1~4
DIP SW1~4 Device address setting :( 1: ON, 0: OFF)
:( 1: ON, 0: OFF) :( 1: ON, 0: OFF)
:( 1: ON, 0: OFF)
Address
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
DIP 1 1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
DIP 2 0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
DIP 3 0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
0
DIP 4 0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
0
8-Pin Terminal Wire
Name
NameName
Name
Wire color
Wire colorWire color
Wire color
Function Description
Function DescriptionFunction Description
Function Description
1
11
1
L+
L+L+
L+
Blue
BlueBlue
Blue
RS
RSRS
RS485 L+
485 L+485 L+
485 L+
2
22
2
L
LL
L-
--
-
White
WhiteWhite
White
RS
RSRS
RS485 L
485 L485 L
485 L-
--
-
3
33
3
+12
+12+12
+12
Red
RedRed
Red
INPUT
INPUT INPUT
INPUT 12V
12V12V
12V
4
44
4
G
GG
G
Black
BlackBlack
Black
RS485 GND
RS485 GNDRS485 GND
RS485 GND
5
55
5
C1
C1C1
C1
Yellow
YellowYellow
Yellow
RELAY1 COM
RELAY1 COMRELAY1 COM
RELAY1 COM
6
66
6
NO1
NO1NO1
NO1
Yellow
YellowYellow
Yellow
RELAY1 NO
RELAY1 NORELAY1 NO
RELAY1 NO
7
77
7
C2
C2C2
C2
Green
GreenGreen
Green
RELAY2 COM
RELAY2 COMRELAY2 COM
RELAY2 COM
8
88
8
NO2
NO2NO2
NO2
Green
GreenGreen
Green
RELAY2 NO
RELAY2 NORELAY2 NO
RELAY2 NO
Product Appearance：
：：
：
Front View Back View
:
OPC-0050 Specification
Model No. OPC0050
Read Format ISO/IEC14443A/MIFARE
Read Range 3-5cm (max )
Input Ports 1 Sensitive Touch Keypad
Output Port Relay x 2 (contact rating relay 30Vdc/1A)
LED Indicator Power / Comm.
Beep Tone Buzzer
Power Input DC 12V(10V~15V) / 1A
Current Consumption Max 100mA.
Comm. Interface RS-485
Comm. Baudrate RS-485：9,600
Operating Temp. 0° C ~ 55° C / 32° F ~ 131° F
Relative Humidity 20% ~ 90%
Dimension 115mm(L) x 70mm(W) x 28mm(H)
Weight 100g
Shell material ABS
