SEIKAKU TECHNICAL GROUP WT-226CT Wireless Microphone User Manual 2
SEIKAKU TECHNICAL GROUP LIMITED Wireless Microphone 2
Users Manual
1. VHF high band wireless microphone.
2. Hand-geld dynamic microphone.
3. Wide dynamic range.
4. Over 12 hours of continuous operation with on LR6 (AA size 1.5) alkaline battery.
5. Battery replacement indicator.
6. Tone-key circuit to eliminate external interference.
7. Compander circuit for extended dynamic range.
1
Microphone element
Type of emission
Carrier frequency range
Frequency stability
Max. modulation
Tone frequency
Pre-emphasis
Spurious emissions
RF output power
Frequency response ( 3dB)
Dynamic range
Battery
Current drain
Battery life (Alkali)
Dimensions
Net weight
Condenser
FM(F3E)
160-245 MHz
0.005% at 25
40KHz Deviation
32.768 KHz
50 S
40dBc
<1 mW
50 Hz~15KHz
100 dB
1 LR6(AA Size)(1.5 Volts)
60 mA
More than 12 hours
240 mm (9.45in)
160g(0.356bbs)
2
1. This microphone has a 3-level power switch design.
2. ln using first turn on the receiver and then the transmitter.
3. New battery the power light is in "OFF".
The light is "ON" It indicates the battery
needs to be replaced.
4. Remember to turn the switch "OFF",
When the microphone is not in use in
order to save power. ln "STAND-BY"
set the switch to the center.
SMT is a design of high quality and precise technology. High quality dynamic cartridge is used to
produces HI-FI sound, which is soft, broad and deep, most suitable for KTV entertaining.
POWER LE D LIGHT
(WHEN LESS POWER THE LIGHT IS IN "ON")
NOTE: Make sure the power switch is in the "OFF" position when changing or installing new
battery. Average life on an alkaline battery is 12 hours. Be sure to use good quality long life 1.5V alkaline
battery only.
OFF
"STAND-BY" function.
SWITCH COVER
GRILLE HOLDER NECK RING SWITCH TUBE TAIL TUBE
3
4
5
CAUTION:
1. BATTERY USE DC1.5V (1 LR).
2. DO NOT DROP THE MICROPHONE BODY ON THE FLOOR.
3. PROTECT THE UNITS AGAINST HUMIDITY AND HEAT.
4. IF THE UNITS ARE TO BE PUT OUT OF OPERATION
DEFINITIVELY, BRING THEM TO TECHNICAL ENGINEER
FOR DISPOSAL.
Caution:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
