Product Specification
Model:XHT-BT06H
Thank you for purchasing this device USB BLUETOOTH DONGLE 4.0!
The dongle used bluetooth chip BCM20705
The BCM20705 Bluetooth 4.0 Dual-Mode Smart Ready (BLE) USB Adapter
The BCM20705 Bluetooth 4.0 Dual-Mode Smart Ready (BLE) USB Adapter combines Classic Bluetooth
2.0, 2.1 and 3.0 EDR standards along with the Bluetooth Low Energy (BLE) SMART standard, enabling
the adapter to communicate with both traditional Bluetooth Classic and Bluetooth Low-Energy (BLE)
SMART-enabled devices.
The BCM20705 utilises a Broadcom IC and can be supplied with or without Widcomm Windows drivers,
which support a wide-range of Bluetooth profiles such as: HFP, A2DP, OPP, FTP, DUN, PAN, SPP, HCRP,
SYNC, BTLE etc. The adapter will plug-and-play with Windows' own Bluetooth Stack when used with
Windows XP, VISTA, Windows 7 and Windows 8.
USB BLUETOOTH DONGLE 4.0 Technical Overview
The XHT-BT06H is a ROM-based HCI adapter and as such requires a PC or external host running a
compatible stack. BLUETOOTH Technologies has been able to reduce the overall footprint and
package-size the LM506 Bluetooth 4.0 BLE USB adapter, achieving a small Form Factor of 19.5mm x
16.0mm x 8.1 mm. The Bluetooth 4.0 BLE USB Adapter will support a data rate of 3 Mbps in Bluetooth
Classic EDR Mode and up to 250 Kbps in BLE Mode.
The Bluetooth 4.0 BLE USB adapter is a Class 2 adapter with a maximum distance of 110m in open
space. The Bluetooth 4.0 BLE USB Adapter has an output of 6dbm, which exceeds the Class 2
requirements set forth in the Bluetooth SIG standards, which state that any device with an output
above 4dBm is categorised as a Class 2 device.
Features
1. Bluetooth 4.0 USB Adapter with Bluetooth Low Energy (BLE) support
2. 80 m range in open space
3. Small Size Nano Adapter : 19.47(L) x 16(W) x 8.1(H) mm
4. Stereo audio supported. VoIP calls over Bluetooth also supported
5. Supports up to 7 ACL link and 3 SCO links
6.Downloadable Windows Driver, Widcomm Software support for Windows XP, VISTA, 7. BlueZ support on Linux
Manufacturer
Chipset
Broadcom BCM20705
Power Classification
Class 2
Adapter Type
USB Adapter
Interface
USB 2.0
Bluetooth
Specification
Core 4.0 backward compatible with BT3.0/BT2.1 and BT2.0 + EDR
Frequency
2402 – 2480 MHz ISM Band
Modulation Method
GFSK for 1 Mbps, π/4-DQPSK for 2 Mbps, 8-DPSK for 3 Mbps
Spread Spectrum
FHSS (Frequency Hopping Spread Spectrum)
Operating
Temperature
0°C to +60°C
Storage
Temperature
-10°C to +70°C
Humidity
5~90% non-condensing
Data Transfer Rates
(Max)
3 Mbps enhanced data rate, 250 Kbps Low Energy mode data rate
Range
Maximum 80 m in open space
Tx Power
Class 2 (+4dBm)
Input Voltage
DC 5V (via USB port)
Antenna
Internal
Rx Sensitivity
< -82 dBm at <0.1 % BER
LED Indicator
Power/Active (BLUE)
OS Support
Windows XP/VISTA/7/8, Linux (Bluez 4.98 and above)
Default Firmware
Broadcom HCI ROM Firmware
Software
6. Broadcom Widcomm software and BlueZ support on Linux
Size
22(L) x 15(W) x 6(H) mm
Weight
2g
Bluetooth Profile
GAP,SPP,HSP, HFP, DUN, FTP, FAX, PAN, LAN, HID, SYNC, HCRP, A2DP, AVRCP, BIP, GOEP,
SDAP, OPP, Bluetooth Low Energy, Bluetooth Proximity Profile
USB VID/PID
VID: 0X0A5C PID”0X21E8
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatetheequipment.
