WIRELESS AUDIO LINK INSTALLATION GUIDE
The Wireless Audio Link is Hi-Tech products which plays
music from any FM equipped stereo source. Wirelessly
transmits the audio using FM frequencies.
Features and Benefits
Modulation : FM
Channel : 5 Channels
Frequency : 88.1Mhz ~~88.9Mhz
Distance : 10 Meters
Supplied voltage : 5V
Supplied current : 22mA
Power requirement : USB Bus power or External Power
Weight : 10.8g
Size : L 6 cm * W 1.8 cm * H 1.4 cm
Application for : PC , Laptop, Hi-Fi stereo, TV and MP3……
Package Contents available : 1. PC or Laptop : Audio Cable
2. Hi-Fi Stereo, TV : AC/DC adapter
3. MP3 : Car power adapter
Installation for PC :
1. Adjust the frequency accord to the Control Data indicated of 5
frequency. Turn on the selection switches for selecte the using
frequency.
2. Connect this unit to a USB of PC for power, make sure the USB
port actually has power. Insert one end of the audio cable into
the unit. Only one end fits this jack, and insert the other end of
the audio cable to your audio soure’s output jack. Now the LED
will blinking, it is mean the function is working.
3. Adjust the frequency on your FM equipped audio device to match
the Wireless Audio Link. You should hear music from PC ( like CD,
Game). Turn on the volume if necessary.
Installation for Car audio, received from MP3
1. Adjust the frequency accord to the Control Data indicated of 5
frequency. Turn on the selection switches for selecte the using
frequency.
2. Insert one end of the audio cable into the car power, connect this
unit to a USB port of car power cable, insert the end of audio
cable to the unit and the other end to audio input of MP3, now the
LED will blinking, it is mean the function is working.
3. Adjust the same frequency to FM for car audio and this unit,
you should hear music of MP3 from your car audio.
Installation for Hi-Fi and TV
1. Adjust the frequency accord to the Control Data indicated of 5
frequency. Turn on the selection switches for selecte the using
frequency.
2. Connect the USB end of adapter to the unit, insert the other end
for power. Insert the the audio cable to the unit and the other
end to the Hi-Fi audio source’s output jack. Now the LED will
blinking, it is mean the function is working.
4. Adjust the same frequency for Hi-Fi and Audio Link, you should
hear music from Hi-Fi ( like CD, VCD, DVD,MD, MP3). Turn on
the volume if necessary.
If they have problem that unable to transmite, please check the
following points:
1. Is the USB port connecting correct ?
2. Are the same frequency of receiver and transmitter?
3. There are audio output from your audio device?
4. Whether your audio have adjucted to FM Channel?
5. Are there same 5 frequency as Control Date indication?
6. Is the receiving range too long?
7. Are there too much obstruction within the receiving range?
Frequency Selections:
D0(pin15) D1(pin16) D2(pin17) D3(pin18) Frequency
OFF ON OFF OFF 88.1MHZ
ON ON OFF OFF 88.3MHZ
OFF OFF ON OFF 88.5MHZ
ON OFF ON OFF 88.7MHZ
OFF ON ON OFF 88.9MHZ
MODEL: WS-WAL1
FCC ID: FK3USBCE071001
This device complies with part 15 of the FCC
Rules.Operation is subject to the following two
conditions:(1) this device may not cause harmful
interference,and (2) this device must accept any
interference received,including interference that may
cause undesired operation.
FCC INFORMATION
The Federal Communication Commission Radio Frequency Interference Statement
includes the following paragraph:
The equipment has been tested and found to comply with the limits for Class B
Digital Device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with instruction, may cause harmful interference to
radio communication. However, there is no grantee that interference will not occur in
a particular installation. If this equipment dose cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
nReorient or relocate the receiving antenna.
nIncrease the separation between the equipment and receiver.
nConnect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
nConsult the dealer or an experienced radio /TV technician for help.
The user should not modify or change this equipment without written approval from
SIIG Inc.. Modification could void authority to use this equipment.
