SKYRC Technology NC2600 AA/AAA Charger Analyzer User Manual 1

SKYRC Technology Co., Ltd. AA/AAA Charger Analyzer 1

User manual

2016 SkyRC Technology Co., Ltd. All Rights Reserved.
Manufactured by
SKYRC TECHNOLOGY CO., LTD.
www.skyrc.com
INSTRUCTION MANUAL
Version 1.0 7504-0361-03
RoHS
AA/AAANiMH BATTERY
Multi Functions Charger & Analyzer
NC2600
multi functions
INDEX
02
NC2600
Thank you for purchasing the SKYRC NC2600 Charger-Analyzer which enables quick and optimum
charging of “AA” and “AAA” rechargeable batteries. With charging ,discharging, refresh & analyze,
break-in and cycle functions as well as individual LCD displays for charging status; this charging unit
is reliable, user-friendly and ideal for use in the home, office or on a trip. Please read these
instructions carefully and thoroughly before operating this unit.
THE CHARGER IS RESTRICTED TO CHARGING NICD AND NIMH RECHARGEABLE BATTERIES ONLY.
NEVER ADOPT THIS CHARGER TO OTHER TYPES OF BATTERIES SUCH AS ALKALINE, LITHIUM,
CARBON ZINC OR OTHER TYPES THAT ARE NOT SPECIFIED.
OPERATING THIS PRODUCT INCORRECTLY CANCAUSE FIRE AND DAMAGE TO THE BATTERIES.
READ MANUAL COMPLETELY BEFORE USE.
INTRODUCTION
WARNING
GENERAL PRECAUTIONS
Do not charge battery cells other than NiMH or NiCd. Please check with the battery
manufacturer to ensure it can accept the programmed charging and discharging rates. Do not
expose the unit to rain or moisture due to the risk of fire.
Do not operate the charger if it appears damaged in any way.
Always place the battery cells with positive tip facing the top. Incorrect polarity may cause fire
or explosion. Observe polarity diagrams located on the charger.
Do not allow the unit to be exposed to direct sunlight. Operate in well-ventilated area. Do not
place unit on the carpet.
Do not allow the battery terminals to become shorted.
Use only the supplied adapter or optional car adapter.
The rechargeable batteries may become hot during charging(especially when high charging
current is chosen). User shall take extra care when taking out the batteries after charging.
Unplug the charging unit from the power source when not in use.
12V DC Plug
TiltStand
Smart
Ventilation Fan
01 NC2600
INTRODUCTION & GENERAL PRECAUTIONS
Introduction
General Precautions
Features
Specification
InformationDisplayOnCharger &SmartPhone
General Battery Knowledge
Modes Of Operation
Operations Steps
Display Information
Operation with iPHONE
Operation with Android Phone
Liability Exclusion
Warranty And Service
Charging Time with Various Charging Current
02
02
03
03
04
04
05
06
08
09
11
13
14
14
Anti Skid
Rubber
Bluetooth
Indicator
USB Power
5V/1A
Enter Button
Down
Button
Up
Button
LCD Display
Slot Number Button
Battery
Bays
Battery Capacity(mAh):
Milliamp hours: mAh is the capacity of the battery or the amount of charge added to a battery.
What is 0.1C, 0.2C, etc?
“C” stands for the battery capacity and the number in front of it is the fraction of the battery capacity. For
example, 0.1C means 0.1 times the capacity for the battery. For a 2700mAh battery, 0.1C would be 0.1
times 2700mAh which equals 270mA.
Choosing the right charging & discharging rate
Charging at a rate below 0.33C and above 1.0C is not recommended. Charging too slow may prevent the
charger from terminating correctly.
Charging too fast may damage the battery.
Typically speaking, slower charging rate will yield better battery performance but requires longer time.
Faster charging rate may not charge as fully and battery temperature can be higher.
Battery Matching
In most devices, usually two or more batteries are used together. When batteries are used in a series, the
performance is limited by the worst one. In other words, one poorly performing battery can significantly
reduce the device runtime.
Battery matching refers to grouping batteries with similar “actual” capacity. To perform this, use the Refresh
& Analyze mode to determine the battery capacity. Group batteries with capacity within about +/- 5% of the
rated capacity.
Battery “Forming”
New batteries and those stored for extended period become chemically deactivated. Battery forming is a
charge-discharge-charge cycle which forces a full charge into the battery at a very slow rate. This process
activates the battery. In certain cases, it needs to be repeated two or three times.
Battery forming can be performed using the Break-In mode.
Trickle charging
After the rechargeable battery is fully charged in any of the operating modes, the charger will give a small
amount of current to the rechargeable batteries to maintain the fully charged level. This mode is
automatically launched after rechargeable batteries are fully charged and kept in the charging unit. The
signal ― will be displayed on the LCD.
Batteries are getting warm.
It is common for batteries to get warm while charging. The charger has a built in temperature sensor which
will stop the charging cycle if it has become too hot. Charging may resume when the battery has cooled.
Allow batteries to cool before placing into a product to be used.
GENERAL BATTERY KNOWLEDGE
04
NC2600
03 NC2600
Charge/Discharge Mode
Charge/Discharge Time
Charger Status
Charge/Discharge Capacity
Charge/Discharge Current
Battery Voltage
Battery Temperature
Battery Internal Resistance
Battery Voltage Graphic
Stand Alone Mode
Yes
Yes
Yes
Yes
Yes
Yes
Not Available
Not Available
Not Available
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
INFORMATIONDISPLAYONCHARGER &SMARTPHONE
Smart Phone Control Mode
GENERAL BATTERY KNOWLEDGE
FEATURES
Four independent slots
There are four independent charger-analyzers for AA and AAA NiMH/NiCd batteries.
Larger LCD display with backlit for easy reading.
Digitally display various modes during operation. Also the charging current (in mA),
accumulated charging capacity (in mAh), the voltage (in Volt) and time elapsed (in hh:mm)
Seven buttons for easy programming and operation
Four Slot Number Buttons (SNB) to display individual slot operation data during the various
operation mode, and other three buttons for programming and operation.
Five modes of operation: Charge, Refresh & Analyze, Break-In, Discharge and Cycle.
Turbo fast charging - 60 minutes to charge up 2600 mAh battery
Charging current from 200mA to 2600mA.
Discharging current from 100mA to 1000mA.
USB ports, 5V 2.1A for charging iPad, smart phone, MP3 and digital camera
Smart cooling fan
Worldwide voltage AC adaptor (12V / 2.5A)
Damaged battery detection: To ensure safety, the charger performs an “impedance check” at the
beginning of the program. If the NiMH batteries are totally damaged (no voltage), there will be
no display in the screen. If the NiMH batteries are with large resistance, it will display R000 for 2
seconds, and then the charger will start working.
Built-In PTC thermistor to avoid over heat and independent negative delta V eliminates over and
undercharging.
Firmware is ungradable via smart phone.
Smart phone control-support both APPLE iPhone and Android smart phone
Negative delta peak value adjustment via smart phone
Battery internal resistance and voltage graphic can be displayed via smart phone
SPECIFICATIONS ARE SUBJECT TO CHANGE.
Charging Current
Discharging Termination Voltage
Battery Capacity Range
No. of Cycle
Top off Charging Current
Maintenance Charging Current (Trickle)
Temperature Protection
Input Power
USB Power
Weight
Dimensions(LxWxH)
Discharging Current:
SPECIFICATION
Stand Alone Mode Smart Phone Control Mode
Delta Peak
12V/2.5A
0.2-2.6A
5mV
0.1-1.0A
0.9V
500mAh-3500mAh
1-12
100mA
30mA
55℃
5V/2.1A
380g
154x104x50mm
0.2-2.6A
3-15mV
0.1-1.0A
0.5-1.0V
500mAh-3500mAh
1-12
100mA
30mA
55-70℃
FEATURES & SPECIFICATION
MODES OF OPERATION
OPERATIONS STEPS
Connect the power adapter DC connector to the charger and then plug the power adapter into
outlet (100-240V AC, 50/60Hz).
Insert AA or AAA battery
When a new battery is inserted and detected, the battery sign and “CHARGE” in correspond
slot will blinking. Use the UP and DOWN arrow buttons to toggle the desired mode. Press
ENTER to make the selection. If no button is pressed within five seconds, the charger will
proceed to the default mode which is charging with 1000mA rate for AA battery and 400mA rate
for AAA battery.
Inserting AA Batteries Inserting AAA Batteries
1.
2.
3.
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
DisCharge Rate DisCharge Rate DisCharge Rate
DONE
mAh mAh mAh
DISCHARGE DISCHARGE DISCHARGE
REFRESHIST. REFRESHIST. REFRESHIST.
BREAK-INO. BREAK-INO. BREAK-INO.
REST CYCLE REST CYCLE REST CYCLE
Capacity
Volt Time Capacity
Volt Time
Capacity
Volt Time
Capacity
Volt Time
If CHARGE mode is selected. The charger will prompt for the charging rate by flashing “Charge
Rate”. Use the UP and DOWN button to choose the desired current. Press ENTER to confirm the
selection. Refer to the “General Battery Knowledge” section for choosing an appropriate rate.
4.
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Dis RateCharge
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Press ENTER to
start charging
Default charging rate
for AA battery is 1000mA
for AAA battery is 400mA
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
ENTER
06
NC2600
05 NC2600
OPERATIONS STEPS
MODES OF OPERATION
This section explains various modes and when to use them. To enable each mode, refer to the
“Operation” section.
Charge:
Charge the battery at the selected rate. Suitable for batteries used frequently.
Discharge:
Discharges the batteries at the selected rate.
Refresh & Analyze:
Suitable for batteries stored for more than two weeks but less than 3 months or the batteries
showing poor performance. This mode can also determine the battery capacity for battery
matching. In most devices, usually two or more batteries are used together. When batteries are
used in a series, the performance is limited by the worst one. In other words, one poorly
performing battery can significantly reduce the runtime. Battery matching refers to grouping
batteries with similar “actual” capacity. To perform this, use the Refresh & Analyze mode to
determine the battery capacity. Group batteries with capacity within about +/- 5%of the rated
capacity.
The charger will charge battery to full and rest for one hour, discharge, rest one hour again then
recharge. You can select charging and discharging rate.
Break-In (Battery Forming):
New batteries and those stored for more than 3 months extended period become chemically
deactivated. Battery forming is a charge-discharge-charge cycle which forces a full charge into
the battery at a very low rate. This process activates the battery. In certain case, it needs to be
repeated two or three time.
Charges battery at 0.1C for 16 hours, rest for one hour, discharges battery at 0.2C, then
recharges again at 0.1C for 16 hours.
Cycle:
Performs charge-discharge cycle for up to 12 times. Cycle mode can remove memory effect of
rechargeable batteries. This mode will recharge battery after final cycle.
1.
2.
3.
4.
5.
Battery Rescue Steps
For batteries that do not perform favorably after using the mode recommended above, the following
sequence can be applied.
Cycle for one to three times.
If capacity is still low, use Break-In mode.
If the step 1 to step 2 shows some capacity improvement (> 10%), repeat Break-In mode for one
to three times. If no significant improvement, battery probably at end of useful life.
NiMH batteries that have been used
frequently (at least once every two weeks) Charge
Batteries in storage for more than two
weeks but less than 3 month Refresh & Analyze
Batteries in storage for more than 3 month Break-In
Batteries showing poor performance Cycle for two to three times.
Battery Condition Mode
1.
2.
3.
OPERATIONS STEPS
08
NC2600
07 NC2600
LCD backlit will turn off after 10 minutes if no buttons are pressed. You can turn on LCD backlit
again by press any button.
The display information will cycle automatically. Press Slot Number Button will make display
information static. Please and hold Slot Number Button more than 5 seconds will make the display
information cycle automatically again.
Slot Number button (1~4)
Press and release the Slot Number button to toggle display between: accumulated capacities (in
mAh), charging current (in mA), time elapsed (in hh:mm),andthe voltage (in Volt) .
The following information is displayed on the screen:
Capacity:
This is the number followed by the unit “mAh.” This is the accumulated charging or discharging
capacity. If it is charging capacity, “CHARGE” in battery box will be shown. If it is discharging
capacity, “DISCHARGE” in battery box will be shown.
Note the charging capacity is usually higher than the actual capacity of the battery owing to some
energy lost as heat. Charging capacity cannot be used to judge the performance the battery. Instead,
it can only be used to determine the progress of the charger.
Dis RateCharge
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Dis Charge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Dis RateCharge
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Dis RateCharge
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Slot
Number
Button
Slot
Number
Button
Slot
Number
Button
Slot
Number
Button
DISPLAY INFORMATION
Time:
This is the number followed by the unit “Time.” This is the time elapsed for the particular routine such
as charging, discharging or rest in the program.
Voltage:
This is the number followed by the unit “Volt.” It represents the offline battery voltage.
Current:
Thisisthenumberfollowedbytheunit“mA.”  Thisisthe approximatechargingordischarging
current.Notethatthisnumber willgoupanddownduetothepulsecharging.
DISPLAY INFORMATION
If REFRESH & ANALYZE mode is selected: The charger will prompt for the charging rate by
flashing “Charge Rate”. Use the UP and DOWN button to choose the desired current. Press
ENTER to make confirmation. Then it will prompt from the discharging rate by flashing “DisCharge
Rate”. Use the UP and DOWN button to choose the desired current. Press ENTER to make the
selection.
If DISCHARGE mode is selected: The charger will prompt for discharging rate by flashing
“DisCharge Rate”. Use UP and DOWN button to choose the desired current. Press ENTER to
make the selection.
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
5.
Default discharging rate
for AA battery is 1000mA
for AAA battery is 500mA
Press ENTER to
start charging
Increase
discharge
rate
Decrease
discharge
rate
6.
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
ENTER
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Dis RateCharge
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Press ENTER to
start REFRESH
ENTER ENTER
ENTER ENTER
If BREAK-IN mode is selected: The charger will prompt for the battery capacity in order to
calculate the charging and discharging rate automatically. “mAh” will flash. Use the UP and DOWN
button to choose the battery capacity. Press ENTER to make selection.
7.
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Dis RateCharge
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
Dis RateCharge
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
1 Second
start BREAK-IN
0.1C Charging
Increase
battery
capacity
Decrease
battery
capacity
ENTER ENTER
If CYCLE mode is selected: The charger will prompt for the charging rate and discharging rate
similar to the other modes. In addition, it will also prompt for the number of cycle to be performed
by flashing “No. Cycle”. Use the UP and DOWN buttons to choose the desired cycles. Press
ENTER to make the selection.
8.
ForCYCLEmode,thedischargecapacityofcycleis displayed. “HIST. CYCLE”iconwillalsobe
shown.UsetheSlotNumber Buttontoaccessdischargecapacityforallthecycles performed. The
capacityinformationwillbestoredaslongasthebatteryis insertedinthecharger.Itwillbelostupon
removalofthebattery.
UseSNBtorecalldischargecapacityforallthecyclesperformed.
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
SNB
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
SNB SNB SNB SNB
Cycle:
10
NC2600
09 NC2600
Useful Notes And Tips
You can only connect your NC2600 charger with one device at a time.
Touch slot number button(1-4) to change operation mode and current.
Operation with Your iPhone
Whentheprogramforaslotiscompleted, DONE willdisplayed. Withthe
exceptionofDISCHARGE mode,top offchargeandtricklecharge(continuous)
willbeapplied.ForCHARGEmode,thetotalchargedcapacitywillbedisplayed.
ForREFRESH&ANALYZE,BREAK-IN,DISCHARGEmode,the totaldischarge
capacitywillbedisplayed.
DisCharge Rate
mAh
DISCHARGE
REFRESHIST.
BREAK-INO.
REST CYCLE
Capacity
Volt Time
OPERATION WITH iPHONE
NC2600 comes with Bluetooth 4.0. When the Bluetooth in device is ON, it will connect to the charger
automatically when the APP starts.
Connect the power adapter DC connector to the charger and then plug the power adapter into
outlet (100-240V AC, 50/60Hz).
Insert AA or AAA battery
Inserting AA or AAA Batteries
1.
2.
When a new battery is inserted and detected, the
battery sign and “CHARGE” in correspond slot will
blinking. Please wait five seconds, the charger will
proceed to the default mode which is charging.
3. Select the Bluetooth menu from your iPhone or iPad
and ensure the Bluetooth is turned on.
4.
5. The Bluetooth indicator, located on the right side of charger remains steadily on. The charger name
display in Bluetooth list is “BLE Charger”.
OPERATION WITH iPHONE OPERATION WITH iPHONE
Factory default
setting
Touch systemsetting icon to change value of temperature protection, voltage protection,
discharge cut-off voltage and negative delta V.
Start your NC2600 APP, that you have downloaded
from the APP Store. Your charger will connect to your
device automatically.
NC2600 comes with Bluetooth 4.0. When the Bluetooth in device is ON, it will connect to the charger
automatically when the APP starts.
Connect the power adapter DC connector to the charger and then plug the power adapter into
outlet (100-240V AC, 50/60Hz).
Insert AA or AAA battery
Inserting AA or AAA Batteries
1.
2.
When a new battery is inserted and detected, the
battery sign and “CHARGE” in correspond slot will
blinking. Please wait five seconds, the charger will
proceed to the default mode which is charging.
3. Select the Bluetooth menu from your Android Phone or
other Android devices and ensure the Bluetooth is turned on.
4.
5. The Bluetooth indicator, located on the right side of charger remains steadily on. The charger name
display in Bluetooth list is “BLE Charger”.
Start your NC2600 APP, that you have downloaded
from the Google Play store. Your charger will connect to your
device automatically.
12
NC2600
11 NC2600
Touch systemsetting icon to change value of temperature protection, voltage protection,
discharge cut-off voltage and negative delta V.
Touch “Details” icon to show voltage graphic and battery internal resistance.
OPERATION WITH ANDROID PHONE
Touch “Details” icon to show voltage graphic and battery internal resistance.
OPERATION WITH ANDROID PHONE OPERATION WITH ANDROID PHONE
Factory default
setting
WARRANTY AND SERVICE
13 NC2600
We guarantee this product to be free of manufacturing and assembly defects for a period of one
year from the time of purchase. The warranty only applies to material or operational defects, which
are present at the time of purchase. During that period, we will repair or replace free of service
charge for products deemed defective due to those causes.
You will be required to produce proof of purchase (invoice or receipt). This warranty is not valid for
any damage or subsequent damage arising as a result of misuse, modification or as a result of
failure to observe the procedures outlined in this manual.
WARRANTY AND SERVICE
Size of battery Battery Capacity Charging current (mA) Estimated charging time
2600
2300
2000
1800
1500
1000
700
500
200
2000
1800
1500
1000
700
500
200
1000
800
700
500
200
AA
AA
AAA
2600mAh
2000mAh
1000mAh
~60 min
~65 min
~70 min
~80 min
~100min
~2 hr 30min
~3 hr 30 min
~5 hr
~12 hr
~60 min
~70 min
~80 min
~2 hr
~3 hr
~4 hr
~10 hr
~60 min
~65 min
~70 min
~1 hr 40min
~4 hr
CHARGING TIME WITH VARIOUS CHARGING CURRENT
CHARGING TIME WITH VARIOUS CHARGING CURRENT
14
NC2600
This charger is designed and approved exclusively for use with the NiMH/NiCd battery. SKYRC
accepts no liability of any kind if the charger is used for any purpose other than that stated.
We are unable to ensure that you follow the instructions supplied with the charger, and we have no
control over the methods you employ for using, operating and maintaining the device. For this
reason we are obliged to deny all liability for loss, damage or costs which are incurred due to the
incompetent or incorrect use and operation of our products, or which are connected with such
operation in any way. Unless otherwise prescribed by law, our obligation to pay compensation,
regardless of the legal argument employed, is limited to the invoice value of those SKYRC products
which were immediately and directly involved in the event in which the damage occurred.
LIABILITY EXCLUSION
CONFORMITYDECLARATION
Conform
Conform
Conform
Conform
CE-R&TTE
FCC FCC SubPart C Intentional
Radiators section 15.247
Assessment of the compliance of low power electronic and
electrical equipment with the basic restrictions related to human
exposure to electromagnetic fields (10 MHz to 300 GHz) article
3.1(a) Safety
Electromagnetic compatibility and Radio spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment
and services. Part 17:Specific conditions for Broadband Data
Transmission Systems article 3.1(a) Health requirements
Electromagnetic compatibility and Radio spectrum Matters (ERM);
ElectroMagnetic Compatibility (EMC) standard for radio equipment
and services. Part 1: Common technical requirements
Wideband transmission systems; Data transmission equipment
operating in the 2,4 GHz ISM band and using wide band
modulation techniques article 3.1(b) EMC requirements
EN 300328
EN 301489-1
Test Standards Title Result
SKYRC NC2600 satisfies all relevant and mandatory CE directives and FCC SubPart C Intentional
Radiators section 15.247
The product has been tested to meet the following technical standards:
Operation within the bands 902 - 928 MHz, 2400 -
2483.5 MHz, and 5725 - 5850 MHz.
Conform
EN 301489-17
EN 62479
FCC Note
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE
USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
To maintain compliance with FCC's RF exposure guidelines, this equipment should be installed and
operated with a minimum distance of 20cm between the radiator and your body.
Hereby, SKYRC Technology Co.,Ltd. declares that this [type of equipment AA/AAA NiMH/NiCd BATTERY
CHARGER & ANALYZER is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
This symbol means that you must dispose of electrical devices from the General household
waste when it reaches the end of its useful life. Take your charger to your local waste collection
point or recycling centre. This applies to all countries of the European Union, and to other
European countries with a separate waste collection system.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Note: This equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’s RF Exposure guidelines, This equipment
should be installed and operated with minimum distance between 20cm the radiator
your body: Use only the supplied antenna.

Navigation menu
