SMD Funksteuerungs SMD-53200TXX Remote Control Transmitter User Manual 363766
SMD-Funksteuerungs GmbH Remote Control Transmitter 363766
User Manual
TST FFS10
manual radio transmitter 433 MHz - AM
TST FFS10-B 10- channel transmitter
Remote-controlled opening and closing of industrial doors and barriers
Special features:
• remote control radio transmitters in compact case
• frequency range AM 433 MHz
• LED display
Technical data
dimensions: W x H x D: 130 x 60 x 23 mm
Mains voltage: 9V block battery
Current consumption: approx. 35 mA
Operating frequency: 433,920 MHz
Modulation method. AM
degree of modulation: min. 95%
Transmission power: typical <10 mW
Construction:
main frequency selection
(DIP switches, inside):
ON
123456
channel selection
(selector switch, outside):
0
activator
activation
signal
up channel selector down
FCC ID:
Q
V2-SMD-53200TXX
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the
party responsible for compliance could avoid the user's
authorit
y
to o
p
erate the e
q
ui
p
ment.
jb/vk 07/03 errors and technical changes remain reserved!
Distributed by FEIG ELECTRONIC GmbH
