SMK FC012 Half-Mini Card size TransferJet module User Manual InstallationManual

InstallationManual

TJ101 Installation Manual

Image for Setup of TJ101(1/2)

Installation inside PC

Coupler:

See page 3

Cable:

See page 3

TJ101

Module

Image for Setup of TJ101(2/2)

! CAUTION !

・Electrostatic discharge (ESD) can damage electronic components. Before beginning attachment,

be sure that you are discharged of static electricity.

・To prevent damage to the TranferJet module, hold the TransferJet module by the edges only.

Do not touch the components on the TransferJet module.

PCI Express Mini card Slot

TJ101

(Top Side)

PC Printed Circuit Board

Ex.) Motherboard

Antenna Connector

(U.FL)

Screw (Option)

U.FL Coaxial Cable

To Coupler

Available Coupler and Cable

○Available Coupler

・WHA9400-1501E

・WHA9400-1631F

・WHA9400-1626F

○Available Cable

・U.FL Coaxial Cable (Min. 100mm)
