1. Users Manual revised
2. Users Manual

Users Manual revised

TelematicsWirelessProprietary

FCCID:NTAT210A 

IC:4732A‐T210A

Page1of8



17JULY2016



Model:TNET210

UserManual

Rev1.0



TelematicsWirelessProprietary

FCCID:NTAT210A 

IC:4732A‐T210A

Page2of8



Moduledescription

TheTNET210AisaRFmoduletobeinsertedinTelematicsWirelessstreetlight

controlproducts.TheTNET210Acanbeconfiguredtobeagatewayoranodein

TelematicsWirelessproprietymeshnetwork.



LEDindicators

Txmode D2redLEDislitwhentransmittingdata.

Rxmode D1greenLEDislitwhenreceivingmodeisenable.

RFSpecification

Frequencyband 902‐928MHz

Modulation  2GFSK

Outputpower  27dBmmax

BitRate  110kbps



TelematicsWirelessProprietary

FCCID:NTAT210A 

IC:4732A‐T210A

Page3of8



Powerconsumption

Txmode  420mA,3.6V

Rxmode  40mA,3.6V

Physicaldescription

DimensionLxWxH 52.5x28.3x8.6mm

Weight10gram

Environment

OperatingTemperature‐40to+85deg.C

Certifications

Radio  47CFRFCCPart15subpartCsection15.247/RSS‐247

EMC  47CFRFCCPart15subpartB/RSS‐Genissue4,ICES‐003Issue6



AntennaSpecification

Frequencyrange 902‐928MHz

Gain+2dBi

Polarization  Vertical

Impedance  50ohm

VSWR2:1

Radiation   omnidirectional





TelematicsWirelessProprietary

FCCID:NTAT210A 

IC:4732A‐T210A

Page4of8



RegulatoryInformation

FCCPart15RegulationClassBdevice

Thedigitalcircuitofthisdevicehasbeentestedandfoundtocomplywiththelimits

foraClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsare

designedtoprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.Thisequipmentgeneratesusesandcanradiateradio

frequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,

maycauseharmfulinterferencetoradiocommunications.However,thereisno

guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis

equipmentdoescauseharmfulinterferencetoradioortelevisionreception,which

canbedeterminedbyturningtheequipmentoffandon,theuserisencouragedto

trytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

‐Reorientorrelocatethereceivingantenna.

‐Increasetheseparationbetweentheequipmentandreceiver.

‐Connecttheequipmentintoanoutletonacircuitdifferentfromthatto

whichthereceiverisconnected.

‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



IndustryCanadaClassBNotice

ThisdevicecomplieswithIndustryCanada’slicence‐exemptRSSs.Operationis

subjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseinterference;and

(2)Thisdevicemustacceptanyinterference,includinginterferencethatmaycause

undesiredoperationofthedevice.

LeprésentappareilestconformeauxCNRd’IndustrieCanadaapplicablesaux

appareilsradioexemptsdelicence.L’exploitationestautoriséeauxdeuxconditions

suivantes:

(1)l’appareilnedoitpasproduiredebrouillage;

(2)l’utilisateurdel’appareildoitacceptertoutbrouillageradioélectriquesubi,même

silebrouillageestsusceptibled’encompromettrelefonctionnement.



TelematicsWirelessProprietary

FCCID:NTAT210A 

IC:4732A‐T210A

Page5of8



FCCinterferenceNotice

Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothe

followingtwoconditions:

(1)Thisdevicemaynotcauseinterference;and

(2)Thisdevicemustacceptanyinterference,includinginterferencethatmaycause

undesiredoperationofthedevice.



FCCandIndustryCanadaRadiationHazardWarning

Theantennausedforthistransmittermustbeinstalledtonormallyprovide

minimumseparationdistanceofatleast20cmfromallpersons.

Ledispositifdoitêtreplacéàunedistanced'aumoins20cmàpartirdetoutesles

personnesaucoursdesonfonctionnementnormal.Lesantennesutiliséespource

produitnedoiventpasêtresituésouexploitésconjointementavecuneautre

antenneoutransmetteur.

RequirementsfortheantennawithregardstoFCC/ICcompliance

Thisradiotransmitter(IC:4732A‐T210A)hasbeenapprovedbyIndustryCanadato

operatewiththeantennatypeslistedbelowwiththemaximumpermissiblegain

indicated.Antennatypesnotincludedinthislist,havingagaingreaterthanthe

maximumgainindicatedforthattype,arestrictlyprohibitedforusewiththisdevice.

Leprésentémetteurradio(IC:4732A‐T210A)aétéapprouvéparIndustrieCanada

pourfonctionneraveclestypesd'antenneénumérésci‐dessousetayantungain

admissiblemaximal.Lestypesd'antennenoninclusdanscetteliste,etdontlegain

estsupérieuraugainmaximalindiqué,sontstrictementinterditspourl'exploitation

del'émetteur.

AntennamanufacturerModelno.Gain

V.torchVTGSMA‐70 2dBi





TelematicsWirelessProprietary

FCCID:NTAT210A 

IC:4732A‐T210A

Page6of8



OEMIntegratorsNotices

ThisdeviceisintendedonlyforOEMintegratorsunderthefollowingconditions:

1)Theantennamustbeinstalledsuchthat20cmismaintainedbetweenthe

antennaandusers,and

2)Thetransmittermodulemaynotbeco‐locatedwithanyothertransmitteror

antenna.

Aslongas2conditionsabovearemet,furthertransmittertestwillnotberequired.

However,theOEMintegratorisstillresponsiblefortestingtheirend‐productforany

additionalcompliancerequirementsrequiredwiththismoduleinstalled.

IMPORTANTNOTE:Intheeventthattheseconditionscannotbemet(forexample

certainlaptopconfigurationsorco‐locationwithanothertransmitter),thentheFCC

authorizationisnolongerconsideredvalidandtheFCCIDcannotbeusedonthe

finalproduct.Inthesecircumstances,theOEMintegratorwillberesponsibleforre‐

evaluatingtheendproduct(includingthetransmitter)andobtainingaseparateFCC

orauthorization.

EndProductLabeling

Thistransmittermoduleisauthorizedonlyforuseindevicewheretheantennamay

beinstalledsuchthat20cmmaybemaintainedbetweentheantennaandusers(for

example:wirelessAP,wirelessRouter).

Thefinalendproductmustbelabeledinavisibleareawiththefollowing:“Contains

TXFCCID:NTAT210A;IC:4732A‐T210A”.

OEMManualInformationThatMustbeIncluded

TheOEMintegratorhastobeawarenottoprovideinformationtotheenduser

regardinghowtoinstallorremovethisRFmoduleintheusersmanualoftheend

productwhichintegratethismodule.

TheusersmanualforOEMintegratorsmustincludethefollowinginformationina

prominentlocation:

“IMPORTANTNOTE:TocomplywithFCCRFexposurecompliancerequirements,the

antennausedforthistransmittermustbeinstalledtoprovideaseparationdistance

ofatleast20cmfromallpersonsandmustnotbeco‐locatedoroperatingin

conjunctionwithanyotherantennaortransmitter."



TelematicsWirelessProprietary

FCCID:NTAT210A 

IC:4732A‐T210A

Page7of8



InstallationInstruction

Warning:TheuserandInstallershouldbeawarethatchangesormodificationsto

thisequipmentnotexpresslyapprovedbyTelematicsWirelesscouldvoidwarranty

andtheuser’sauthoritytooperatetheequipment.



Professionallytrainedpersonnelshouldinstalltheequipment.



InstallationinDCU2PROEhost

1.ConnecttheTNET210moduleonboard



2.ConnecttheSOMonboard.



TelematicsWirelessProprietary

FCCID:NTAT210A 

IC:4732A‐T210A

Page8of8



3.ClosetheinternalcoveroftheDCU2PROE.



4.ClosetheexternalcoveroftheDCU2PROE.



5.TheDCU2mustbeequippedwithapermanentlyaffixedlabelshowingthemodule

identificationasfollows:



Contains:

FCCID:NTAT210A

IC:4732A‐T210A


