-4-
The transmitter built-in two modes, Mode 1 &
Mode 2, in line with different customer’s usage
pattern. Keep pushing button B to right, than turn
on the transmitter power to change Mode 1 or
Mode 2.
Controller modes & instructions
MODE 1
Operating direction
Hover up and down Forward and backward
Push the throttle up or down, the
quadcopter flies upward or downward.
Push the direction lever up or down, the
quadcopter flies forward or backward.
Sideward fly
Turn Left and Right
Pull the direction lever left or right, the
quadcopter flies to left side or right side.
Pull the throttle left or right, the
quadcopter turns to left or right.
-5-
Fine-tuning operation
Turn left/right fine-tuningSideward fly fine-tuningForward/Backward fine-tuning
When the quadcopter
keeps flying forward /
backward, you can correct
it by pressing fine-tuning
button down / up.
When the quadcopter
keeps flying to left / right
side, you can correct it by
pressing the fine-tuning
button right / left.
When the quadcopter
keeps rotating to left /right,
you can correct it by
pressing the fine-tuning
button right / left.
MODE 2
Operating direction
Hover up and down Forward and backward
Push the throttle up or down, the
quadcopter flies upward or downward.
Push the direction lever up or down, the
quadcopter flies forward or backward.
Sideward fly
Turn Left and Right
Pull the throttle left or right, the
quadcopter flies to left side or right side.
Pull the direction lever left or right, the
quadcopter turns to left or right.
