Contents
- 1. Users Manual 1
- 2. Users Manual 2
Users Manual 2
Printing_ 76
CHANGING THE DEFAULT PRINT SETTINGS
1. Click the Windows Start menu.
2. For Windows Server 2000, select Settings >Printers.
•For Windows XP/Server 2003, select Printer and Faxes.
•For Windows Server 2008/Vista, select Control Panel > Hardware
and Sound >Printers.
•For Windows 7, select Control Panel > Devices and Printers.
•For Windows Server 2008 R2, select Control Panel > Hardware >
Devices and Printers.
3. Right-click your machine.
4. For Windows XP/Server 2003/Server 2008/Vista, press Printing
Preferences.
For Windows 7 or Windows Server 2008 R2, from context menus, select
the Printing preferences.
If Printing preferences item has a Ź mark, you can select other
printer drivers connected with the selected printer.
5. Change the settings on each tab.
6. Click OK.
If you want to change the settings for each print job, change it in
Printing Preferences.
SETTING YOUR MACHINE AS A DEFAULT
MACHINE
1. Click the Windows Start menu.
2. For Windows Server 2000, select Settings >Printers.
•For Windows XP/Server 2003, select Printer and Faxes.
•For Windows Server 2008/Vista, select Control Panel > Hardware
and Sound >Printers.
•For Windows 7, select Control Panel > Devices and Printers.
•For Windows Server 2008 R2, select Control Panel > Hardware >
Devices and Printers.
3. Select your machine.
4. Right-click your machine and select Set as Default Printer.
For Windows 7 or Windows Server 2008 R2, if Set as default
printer item has a Ź mark, you can select other printer drivers
connected with the selected printer.
PRINTING TO A FILE (PRN)
You will sometimes need to save the print data as a file. You can print the
document to a file instead of routing it directly to a printer. The document is
saved with the printer formatting, such as font selection and color
specifications, in a .prn file that can be printed on another printer.
To save a print job as a file:
1. Check the Print to file box at the Print window.
2. Click Print.
3. Type in the destination path and the file name, and then click OK. For
example c:\Temp\file name.
If you type in only the file name, the file is automatically saved in
My Documents. The saved folder may differ depending on your
operating system.
MACINTOSH PRINTING
This section explains how to print a document in a Macintosh operating
system.
Printing a document
When you print with a Macintosh, you need to check the printer driver
setting in each application you use. Follow the steps below to print from a
Macintosh.
1. Open the document you want to print.
2. Open the File menu and click Page Setup.
3. Choose your paper size, orientation, scaling or other options, and make
sure that your machine is selected.
4. Choose the number of copies you want and indicate which pages you
want to print.
5. Click Print.
Changing printer settings
You can use advanced printing features provided by your machine.
Open an application and select Print from the File menu. The machine
name, which appears in the printer properties pane may differ depending on
the machine in use. Except for the name, the composition of the printer
properties pane is similar to the following.
Printing_ 77
•The setting options may differ depending on models or Macintosh
OS versions.
•The following pane may differ depending on your operating system
or the application you are using.
The following pane is the first pane you will see when you open the printer
properties pane. Select other advanced features from the drop-down list.
Layout
The Layout dialog provides options to adjust how the document
appears on the printed page. You can print multiple pages on one sheet
of paper. Select Layout from the drop-down list to access the following
features.
•Pages per Sheet: This option determines how many pages to be
printed on one page (See "Printing multiple pages on one sheet of
paper" on page 77).
•Layout Direction: This option allows you to select the printing
direction on a page similar to the examples on the screen.
•Border: This option allows you to print a border around each page
on the sheet.
•Reverse Page Orientation: This option allows you to rotate paper
180 degrees.
Graphics
The Graphics dialog provides options for selecting Quality and Color
mode. Select Graphics from the drop-down list to access the graphic
features.
•Quality: This option allows you to select the printing resolution. The
higher setting option you choose, the better sharpness and clarity of
printed characters or images are. A higher setting will also increase
the time it takes to print a document.
•Color mode: You can set the color options. Setting to Color
typically produces the best possible print quality for color documents.
If you want to print a color document in grayscale, select Grayscale.
Paper
Set Paper Type to correspond to the paper loaded in the tray from
which you want to print. This will let you get the best quality printout. If
you load a different type of print material, select the corresponding paper
type.
Printer Features
The Printer Features dialog provides Advanced Options and Color
Adjust options. Select Printer Features from the drop-down list to
access the following features.
•Fine Edge: It allows users to emphasize edges of texts and fine
lines for improving readability and align color channel registration in
color printing mode.
•RGB Color: You can adjust the appearance of images by changing
the settings in the RGB Color option.
•Screen: This option allows you to select options to convert
continuous-tone image into printable binary image.
•Color Adjust: You can adjust the image by changing the settings in
the Color Adjust option.
Printing multiple pages on one sheet of paper
You can print more than one page on a single sheet of paper. This feature
provides a cost-effective way to print draft pages.
1. Open an application, and select Print from the File menu.
2. Select Layout from the drop-down list. In the Pages per Sheet
drop-down list, select the number of pages you want to print on one
sheet of paper.
3. Select the other options you want to use.
4. Click Print, then the machine prints the selected number of pages you
want to print on one sheet of paper.
LINUX PRINTING
Printing from applications
There are several Linux applications that allow you to print using the
Common UNIX Printing System (CUPS). You can print using any of these
applications.
1. Open an application, and select Print from the File menu.
2. Select Print directly using LPR.
3. From the LPR GUI window, select the model name of your machine from
the printer list and click Properties.
Printing_ 78
4. Change the print job properties using the following four tabs displayed at
the top of the window.
•General: This option allows you to change the paper size, the paper
type, and the orientation of the documents. It enables the duplex
feature, adds start and end banners, and changes the number of
pages per sheet.
•Text: This option allows you to specify the page margins and set the
text options, such as spacing or columns.
•Graphics: This option allows you to set image options that are used
when printing imageGfiles, such as color options, image size, or
image position.
•Advanced: This option allows you to set the print resolution, paper,
source and special print features.
If an option is grayed out, it means that the grayed out option is not
supported by your machine.
5. Click Apply to apply the changes and close the Properties window.
6. Click OK in the LPR GUI window to start printing.
7. The Printing window appears, allowing you to monitor the status of your
print job.
To abort the current job, click Cancel.
Printing files
You can print many different types of files on your machine using the
standard CUPS way, directly from the command line interface. The CUPS
LPR utility allows you to do that. But the drivers package replaces the
standard LPR tool by a much more user-friendly LPR GUI program.
To print any document file
1. Type lpr <file_name> from the Linux shell command line and press
Enter. The LPR GUI window appears.
When you type only lpr and press Enter, the Select file(s) to print
window appears first. Just select any files you want to print and click
Open.
2. From the LPR GUI window, select your machine from the list, and
change the print job properties.
3. Click OK to start printing.
Configuring Printer Properties
Using the Printer Properties window provided by the Printers
configuration, you can change the various properties for your machine.
1. Open the Unified Driver Configurator.
If necessary, switch to Printers configuration.
2. Select your machine from the available printers list and click Properties.
3. The Printer Properties window opens.
The following five tabs display at the top of the window.
•General: This option allows you to change the printer location and
name. The name entered in this tab displays on the printer list in
Printers configuration.
•Connection: This option allows you to view or select another port. If
you change the machine port from USB to parallel or vice versa
while in use, you must re-configure the machine port in this tab.
•Driver: This option allows you to view or select another machine
driver. By clicking Options, you can set the default device options.
•Jobs: This option shows the list of print jobs. Click Cancel job to
cancel the selected job and select the Show completed jobs check
box to see previous jobs on the job list.
•Classes: This option shows the class that your machine is in. Click
Add to Class to add your machine to a specific class or click
Remove from Class to remove the machine from the selected
class.
4. Click OK to apply the changes and close the Printer Properties
window.
Copying_ 79
8.copying
This chapter gives you step-by-step instructions for copying documents.
This chapter includes:
•Basic copying
•Changing the settings for each copy
•Changing the default copy settings
•ID card copying
•Using special copy features
•Deciding the form of copy output
The supported setting options may differ according to your model.
Check your model name.
BASIC COPYING
The following is the normal copy procedure for a machine without an
Automatic Document Feeder(ADF) such as CLX-3185 and CLX-3185N.
1. Place a single original face down on the scanner glass. For details about
loading an original, see "Loading originals" on page 65.
2. Enter the number of copies using the left/right arrow if necessary.
3. If you want to customize the copy settings including Reduce/Enlarge,
Darkness,Original Type and more by using the control panel buttons
(See "Changing the settings for each copy" on page 79).
4. Press Color Start to begin color copying.
Or press Black Start to begin black and white copying.
The following is the normal copy procedure for a machine with an ADF such
as CLX-3185FN and CLX-3185FW.
1. Press (Copy) on the control panel.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
(See "On the scanner glass" on page 65 or "In the document feeder
(CLX-3185FN/CLX-3185FW only)" on page 65).
3. If you want to customize the copy settings including Reduce/Enlarge,
Darkness,Original Type and more by using the control panel buttons
(See "Changing the settings for each copy" on page 79).
4. Enter the number of copies using the arrow or number keypad, if
necessary.
5. Press Color Start to begin color copying.
Or press Black Start to begin black and white copying.
If you need to cancel the copying job during the operation, press
Stop/Clear and the copying will stop.
CHANGING THE SETTINGS FOR EACH COPY
Your machine provides default settings for copying so that you can quickly
and easily make a copy. However, if you want to change the options for
each copy, use the copy function buttons on the control panel.
If you press Stop/Clear while setting the copy options, all of the
options you have set for the current copy job will be canceled and
returned to their default status. Or, they will automatically return to
their default status after the machine completes the copy in progressU
Darkness
If you have an original containing faint marking and dark images, you can
adjust the brightness to make a copy that is easier to read.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
2. Press the left/right arrow until Copy Feature appears and press OK.
3. Press the left/right arrow until Darkness appears and press OK.
4. Press the left/right arrow until the contrast mode you want appears and
press OK.
•Light: Works well with dark print.
•Normal: Works well with standard typed or printed originals.
•Dark: Works well with light print.
5. Press Stop/Clear to return to ready mode.
Original Type
The original type setting is used to improve the copy quality by selecting the
document type for the current copy job.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
2. Press the left/right arrow until Copy Feature appears and press OK.
3. Press the left/right arrow until Original Type appears and press OK.
4. Press the left/right arrow until the image mode you want appears and
press OK.
•Text/Photo: Use for originals with mixed text and photographs.
•Photo: Use when the originals are photographs.
•Magazine: Use when the originals are the form of magazine.
•Text: Use for originals containing mostly text.
5. Press Stop/Clear to return to ready mode.
Reduced or enlarged copy
You can reduce or enlarge the size of a copied image from 25% to 400%
when you copy original documents from the scanner glass.
To select from the predefined copy sizes
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control
panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and
Menu in order on the control panel.
Copying_ 80
2. Press the left/right arrow until Copy Feature appears and press OK.
3. Press the left/right arrow until Reduce/Enlarge appears and press
OK.
4. Press the left/right arrow until the size setting you want appears and
press OK.
5. Press Stop/Clear to return to ready mode.
To scale the copy by directly entering the scale rate
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control
panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and
Menu in order on the control panel.
2. Press the left/right arrow until Copy Feature appears and press OK.
3. Press the left/right arrow until Reduce/Enlarge appears and press
OK.
4. Press the left/right arrow until Custom appears and press OK.
5. Press the left/right arrow to enter the copy size you want. Pressing
and holding the button allows you to quickly scroll to the number you
want. For CLX-3185FN and CLX-3185FW, you can also use the
number keypad.
6. Press OK to save the selection.
7. Press Stop/Clear to return to ready mode.
When you make a reduced copy, black lines may appear at the
bottom of your copy.
CHANGING THE DEFAULT COPY SETTINGS
The copy options including darkness, original type, copy size and number of
copies can be set to those most frequently used. When you copy a
document, the default settings are used unless they have been changed by
using the corresponding buttons on the control panel.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
2. Press the left/right arrow until Copy Setup appears and press OK.
3. Press the left/right arrow until Change Default appears and press OK.
4. Press the left/right arrow until the setup option you want appears and
press OK.
5. Press the left/right arrow until the setting you want appears and press
OK.
6. Repeat steps 4 through 5 as needed.
7. Press Stop/Clear to return to ready mode.
While you are setting copy options, pressing Stop/Clear cancels the
changed settings and restores the defaults.
ID CARD COPYING
Your machine can print 2-sided originals on one sheet of A4-, Letter-, Folio-,
Oficio-, Executive-, B5-, A5- or A6-sized paper.
The machine prints one side of the original on the upper half of the paper
and the other side on the lower half without reducing the size of the original.
This feature is helpful for copying a small-sized item such as business card.
The original must be placed on the scanner glass to use this feature.
1. Press ID Copy on the control panel.
2. Place the front side of an original facing down on the scanner glass
where arrows indicate as shown. Then, close the scanner lid.
3. Place Front Side and Press [Start] appears on the display.
4. Press Color Start or Black Start.
Your machine begins scanning the front side and shows Place Back
Side and Press [Start].
5. Turn the original over and place it on the scanner glass where arrows
indicate as shown. Then, close the scanner lid.
6. Press Color Start to begin color copying.
Or, press Black Start to begin black and white copying.
•If you do not press the Color Start or Black Start button, only the
front side will be copied.
•If the original is larger than the printable area, some portions may
not be printed.
•If you press Stop/Clear or if no buttons are pressed for
approximately 30 seconds, the machine cancels the copy job and
returns to ready mode.
USING SPECIAL COPY FEATURES
You can use the following copy features.
2-up or 4-up copying (N-up)
Your machine can print 2 or 4 original images reduced to fit onto one sheet
of paper.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
1 2
1 2
3 4
Copying_ 81
2. Press the left/right arrow until Copy Feature appears and press OK.
3. Press the left/right arrow until Layout appears and press OK.
4. Press the left/right arrow until 2-Up or 4-Up appears and press OK to
save the selection.
5. Press Stop/Clear to return to ready mode.
You cannot adjust the copy size using Reduce/Enlarge menu for
making a 2- or 4-up copy.
Poster copying
Your machine can print an image onto 9 sheets of paper (3x3). You can
paste the printed pages together to make one poster-sized document.
This copy feature is available only when you place originals on the scanner
glass.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Copy Feature appears and press OK.
4. Press the left/right arrow until Layout appears and press OK.
5. Press the left/right arrow until Poster Copy appears, and press OK to
save the selection.
6. Press Stop/Clear to return to ready mode.
Your original is divided into 9 portions. Each portion is scanned and
printed one by one in the following order.
Clone copying
Your machine can print multiple images copies from the original document a
single page. The number of images is automatically determined by the
original image and paper size.
This copy feature is available only when you place originals on the scanner
glass.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
2. Press the left/right arrow until Copy Feature appears and press OK.
3. Press the left/right arrow until Layout appears and press OK.
4. Press the left/right arrow until Clone Copy appears and press OK to
save the selection.
5. Press Stop/Clear to return to ready mode.
You cannot adjust the copy size using Reduce/Enlarge menu while
making a clone copy.
Erasing background images
You can set the machine to print an image without its background. This
copy feature removes the background color and can be helpful when
copying an original containing color in the background such as a newspaper
or a catalog.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
2. Press the left/right arrow until Copy Feature appears and press OK.
3. Press the left/right arrow until Adjust Bkgd. appears and press OK.
4. Press the left/right arrow until the background option you want appears.
•Off: Does not use this feature.
•Auto: Optimizes the background.
•Enhance Lev. 1 - 2: The higher the number is, the more vivid the
background is.
•Erase Lev. 1 - 4: The higher the number is, the lighter the
background is.
5. Press OK to save the selection.
6. Press Stop/Clear to return to ready mode.
Gray enhance copying
When you copy the original in black and white, use this feature for the better
quality of copy-out-put. This feature is only for the copy in black and white.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
2. Press the left/right arrow until Copy Feature appears and press OK.
3. Press the left/right arrow until Gray Enhance appears and press OK.
4. Press the left/right arrow to select On or Off.
5. Press OK to save the selection.
6. Press Stop/Clear to return to ready mode.
DECIDING THE FORM OF COPY OUTPUT
You can set the machine to sort the copy job. For example, if you make 2
copies of a 3 page original, one complete 3 page document will print
followed by a second complete document.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, place a single original document
facing down on the scanner glass and press Menu on the control
panel.
•For CLX-3185FN and CLX-3185FW, place original documents facing
up in the document feeder, or you can use the scanner glass with a
single document facing down and close the scanner lid. Press
(Copy) and Menu in order on the control panel.
2. Press the left/right arrow until Copy Setup appears and press OK.
Copying_ 82
3. Press the left/right arrow until Change Default appears and press OK.
4. Press the left/right arrow until Copy Collation appears and press OK.
5. Press the left/right arrow until On appears and press OK to save the
selection.
•On: Prints output in sets to match the sequence of originals.
•Off: Prints output sorted into stacks of individual pages.
6. Press Stop/Clear to return to ready mode.
7. Enter the number of copies using the left/right arrow or numeric keypad.
8. Press Start to begin copying.
One complete document will print followed by the second complete
document.
Scanning_ 83
9.scanning
Scanning with your machine lets you turn pictures and text into digital files that can be stored on your computer.
This chapter includes:
•Basic scanning method
•Scanning originals and sending to your computer (Scan to PC)
•Scanning by a network connection (Scan to Email)
(CLX-3185FN/CLX-3185FW only)
•Changing the settings for each scan job
•Changing the default scan settings
•Setting up Address Book (CLX-3185FN/CLX-3185FW only)
•Using Samsung Scan and Fax Manager
•Scanning with TWAIN-enabled software
•Scanning using the WIA driver
•Macintosh scanning
•Linux Scanning
The maximum resolution that can be achieved depends upon various
factors, including a computer speed, available disk space, memory,
the size of the image being scanned and color bit depth settings.
Thus, depending on your system and what you are scanning, you may
not be able to scan at a certain resolution, especially using enhanced
resolution.
Supported optional devices and features may differ according to your
model. Check your model name.
(See "Features by Models" on page 28).
BASIC SCANNING METHOD
You can scan the originals with your machine via an USB cable or the
network.
•Samsung Scan and Fax Manager: Scan the originals from the control
panelU Then, the scanned data will be stored in the connected
computers My Documents folder. When you install all the software in
the supplied CD, the Samsung Scan and Fax Manager is also
automatically installed on your computer. This feature can be used via
the local connection or the network connection (See "Using Samsung
Scan and Fax Manager" on page 86).
•TWAIN: TWAIN is the one of a preset imaging applications. Scanning
an image launches the selected application, enabling you to control the
scanning process. This feature can be used via the local connection or
the network connection (See "Scanning with TWAIN-enabled software"
on page 88).
•SmarThru: This program is the accompanying software for your
machine. You can use this program to scan images or documents. This
feature can be used via the local connection or the network connection
(See "SmarThru" on page 110).
•WIA: WIA stands for Windows Images Acquisition. To use this feature,
your computer must be connected directly with the machine via an USB
cable (See "Scanning using the WIA driver" on page 88).
SCANNING ORIGINALS AND SENDING TO
YOUR COMPUTER (SCAN TO PC)
You can scan an image on the machine via the Samsung Scan and Fax
Manager program that is installed in your USB- or network-connected
computer.
For USB connected machine
This is a basic scanning method for USB-connected machine.
1. Make sure that the machine is connected to your computer and powered
on.
2. Place a single document face down on the document glass, or load the
documents face up into the ADF.
For details about loading an original, see "Loading originals" on page 65.
3. Depending on the model, the operating procedure may differ.
•For CLX-3185, CLX-3185N and CLX-3185WK, press Scan to on the
control panel.
•For CLX-3185FN and CLX-3185FW, press (Scan) on the control
panel.
4. Press the left/right arrow until Scan to PC appears and press OK.
5. Press the left/right arrow until Local PC appears and press OK.
If you see Not Available message, check the port connection.
6. Press the left/right arrow until the application program you want appears
and press OK.
Default setting is My Documents.
To add or delete the folder where the scanned file is saved, add or
delete the application program in Samsung Scan and Fax
Manager > Properties > Set Scan Button.
7. Press the left/right arrow until the setting you want appears and press
OK.
•Resolution: Sets the image resolution.
•Scan Color: Sets the color mode.
•Scan Format: Sets the file format in which the image is to be saved.
•Scan Size: Sets the image size.
•Scan Format appears only when you selected the Scan
destination to My Documents.
•If you want to scan from the default setting, press Start.
8. Scanning begins.
•Scanned image is saved in computer’s My Documents > My
Pictures > Samsung folder.
•You can use Twain driver to scan quickly in Samsung Scan
and Fax Manager program.
•You can also scan by pressing Window’s Start > Control
Panel > Samsung Scan and Fax Manager > Quick Scan.
Scanning_ 84
For network connected machine
(CLX-3185N/CLX-3185FN/CLX-3185FW only)
Make sure the printer driver is installed on your computer using the software
CD, since the printer driver includes the scan program (See "Installing wired
network-connected machine’s driver" on page 46).
1. Make sure that your machine and the computer are connected to a
network and Samsung Scan and Fax Manager is installed on the
computer.
2. Place a single document face down on the document glass, or load the
documents face up into the ADF.
For details about loading an original, see "Loading originals" on page 65.
3. Depending on the model, the operating procedure may differ.
•For CLX-3185N and CLX-3185WK, press Scan to on the control
panel.
•For CLX-3185FN and CLX-3185FW, press (Scan) on the control
panel.
4. Press the left/right arrow until Scan to PC appears and press OK.
5. Press the left/right arrow until Network PC appears and press OK.
If you see Not Available message, check the port connection.
6. Select your registered computer ID, and enter the Password if
necessary.
•ID is the same ID as the registered Computer ID for Samsung
Scan and Fax Manager.
•Password is the 4 digit number registered Password for
Samsung Scan and Fax Manager.
7. Press the left/right arrow until the application program you want appears
and press OK.
Default setting is My Documents.
To add or delete the folder where the scanned file is saved, add or
delete the application program in Samsung Scan and Fax
Manager > Properties > Set Scan Button.
8. Press the left/right arrow until the setting you want appears and press
OK.
•Resolution: Sets the image resolution.
•Scan Color: Sets the color mode.
•Scan Format: Sets the file format in which the image is to be saved.
•Scan Size: Sets the image size.
•Scan Format appears only when you selected the Scan
destination to My Documents.
•If you want to scan from the default setting, press Start.
9. Scanning begins.
•Scanned image is saved in computer’s My Documents > My
Pictures > Samsung folder.
•You can use Twain driver to scan quickly in Samsung Scan
and Fax Manager program.
•You can also scan by pressing Window’s Start > Control
Panel > Samsung Scan and Fax Manager > Quick Scan.
SCANNING BY A NETWORK CONNECTION
(SCAN TO EMAIL) (CLX-3185FN/CLX-3185FW
ONLY)
If you have connected your machine to a network and set up network
parameters correctly, you can scan and send images over the network.
Setting up an e-mail account
To scan and send an image as an email attachment. You need to set up
network parameters using SyncThru™ Web Service.
1. Enter your machine’s IP address as the URL in a browser and click Go
to access the SyncThru™ Web Service website.
2. Click Login on the upper right of the website.
The Login window appears.
3. Type in the ID and Password, and then click Login.
If it is your first time logging into SyncThru™ Web Service, type in the
below default ID and password.
•ID: admin
•Password: sec00000
4. Move the mouse cursor on the Settings of the top menu bar and then
click Network Settings.
5. Click Outgoing Mail Server(SMTP) on the left pane of the website.
6. Enter the SMTP server domain name or the IP address(dotted decimal
notation) you want to use on the SMTP Server text box.
Only alphabet letters, number(0~9), period(,) and hyphen(-) are
permitted in these text boxes.
7. Enter the server port number from 1 to 65535 on Port Number text box.
The default port number is 25.
8. Select SMTP Requires Authentication check box in the SMTP Login
Information section.
9. Enter the login ID on the Login ID text box and the password on the
Password text box.
10. Enter the password one more time on the Confirm Password to confirm
your choice.
11. Click Apply.
If the authentication method of SMTP server is POP3 before SMTP,
select the SMTP POP3 Before SMTP Authentication check box.
a) Enter the POP3 server domain name on the POP3 Server input
field and the port number from 1 to 65535 on the Port Number text
boxes respectively.
The default port number is 110.
b) Enter the login ID on the Login ID text box and the password on
the Password text box.
c) Enter the password one more time on the Confirm Password to
confirm your choice.
Scanning to Email
You can scan and send an image as an email attachment. First, you need to
set up your email account in SyncThru™ Web Service (See "Setting up an
e-mail account" on page 84).
Before scanning, you can set the scan options for your scan job (See
"Changing the settings for each scan job" on page 85).
1. Make sure that your machine is connected to a network.
2. Place a single document face down on the document glass, or load the
documents face up into the ADF.
For details about loading an original, see "Loading originals" on page 65.
Scanning_ 85
3. Press (Scan) on the control panel.
4. Press the left/right arrow until Scan to Email appears on the bottom line
of the display and press OK.
If you registered login ID (user name) and password on
SyncThru™ Web Service, My Log in ID and Password appear.
Enter the login ID and password to your machine. Go to step 6.
5. When From appears on the top line of the display, enter the sender’s
email address and press OK.
6. When DestinationEmail appears on the top line of the display, enter the
recipient’s email address and press OK.
If you have set up Address Book, you can use a speed button or a speed
email or group email number to retrieve an address from memory (See
"Setting up Address Book" on page 97).
7. To enter additional addresses, press OK when Yes appears and repeat
step 6.
To continue to the next step, press the left/right arrow to select No and
press OK.
8. If the display asks if you want to send the email to your account, press
the left/right arrow to select Yes or No and press OK.
9. Enter an email subject and press OK.
10. Press the left/right arrow until the file format you want appears and press
OK or Start (Black or Color).
The machine begins scanning and then sends the email.
11. If the machine asks if you want to log off your account, press the
left/right arrow to select Yes or No and press OK.
12. Press Stop/Clear to return to ready mode.
CHANGING THE SETTINGS FOR EACH SCAN
JOB
Your machine provides you with the following setting options to allow you to
customize your scan jobs.
•Scan Size: Sets the image size.
•Original Type: Sets the original document’s type.
•Resolution: Sets the image resolution.
•Scan Color: Sets the color mode.
•Scan Format: Sets the file format in which the image is to be saved. If
you selectGTIFF or PDF, you can select to scan multiple pages.
Depending on the selected scan type, this option may not appear.
To customize the settings before starting a scan job
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Scan) and Menu in
order on the control panel.
2. Press the left/right arrow until Scan Feature appears and press OK.
3. Press the left/right arrow until the scan type you want appears and press
OK.
4. Press the left/right arrow until the scan setting option you want appears
and press OK.
5. Press the left/right arrow until the desired status appears and press OK.
6. Repeat steps 5 and 6 to change other settings.
7. When you have finished, press Stop/Clear to return to ready mode.
CHANGING THE DEFAULT SCAN SETTINGS
To avoid having to customize the scan settings for each job, you can set up
default scan settings for each scan type.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Scan) and Menu in
order on the control panel.
2. Press the left/right arrow until Scan Setup appears and press OK.
3. Press the left/right arrow until Change Default appears.
4. Press the left/right arrow until the scan type you want appears and press
OK.
5. Press the left/right arrow until the scan setting option you want appears
and press OK.
6. Press the left/right arrow until the desired status appears and press OK.
7. Repeat steps 6 and 7 to change other settings.
8. To change the default settings for other scan types, press Back and
repeat from step 5.
9. Press Stop/Clear to return mode.
SETTING UP ADDRESS BOOK
(CLX-3185FN/CLX-3185FW ONLY)
You can set up address book with the email addresses you use frequently
via SyncThru™ Web Service and then easily and quickly enter email
addresses by entering the location numbers assigned to them in address
book.
Registering speed email numbers
1. Enter your machine’s IP address as the URL in a browser and click Go
to access SyncThru™ Web Service of your machine.
2. Click Address Book on the menu tab in the top of the website.
3. The Individual Address Book page appears on the middle pane of the
website.
4. Click Add to enter the contact information you want to register.
5. The Add windows appears.
Enter the contact information such as Name,E-mail address and Fax
Number. Also, you can specify the Speed No.
6. Click Apply.
You can also import and export your address book via SyncThru™
Web Service.
Grouping addresses in Groups Address Book
1. Turn your network-connected computer on and open the web browser.
2. Enter your machine’s IP address as the URL in a browser.
(Example: http://123.123.123.123)
3. Press Enter or click Go to access the SyncThru™ Web Service.
If necessary, you can change the language in the upper right
corner of the SyncThru™ Web Service.
4. Click Login.on the upper right of the website.
The Login window appears.
5. Type in the ID and Password, and then click Login.
If it is your first time logging into SyncThru™ Web Service, type in the
below default ID and password.
•ID: admin
Scanning_ 86
•Password: sec00000
If you do not use the SyncThru™ Web Service for five minutes, it
automatically gets logged out.
6. Click Address Book on the top of menu bar.
7. Click E-mail Groups.
8. Click Add Group. Then the Add window appears.
9. Enter the group name you want in the Group Name input area.
Specify the Speed No. from the drop-down list.
10. Select Add individual(s) after this group is created check box.
If you do not want to add individual addresses to the group
address you made, skip this step. You can add individual
addresses next time.
11. Click Apply. Then the Add window appears.
12. Check the addresses you want to add to E-mail Group Address Book
from the Individual Address Book.
13. Click the arrow in the middle. The selected addresses are added in
E-mail Group Address Book.
14. Click Apply.
Using Address Book entries
Speed email numbers
When you are prompted to enter a destination address while sending an
email, enter the speed email number at which you stored the address
you want.
•For a one-digit speed email location, press and hold the
corresponding digit button from the number keypad.
•For a two- or three-digit speed email location, press the first digit
button(s) and then hold down the last digit button.
You can search through memory for an entry by pressing Address
Book (See "Searching Address Book for an entry" on page 86“).
Group email numbers
To use a group email entry, you need to search for and select it from
memory.
When you are prompted to enter a destination address while sending an
email, press Address Book (See "Searching Address Book for an
entry" on page 86).
Searching Address Book for an entry
There are two ways to search for an address in memory. You can either
scan from A to Z sequentially or search by entering the first letters of the
name associated with the address.
Searching sequentially through memory
1. Press Address Book until Search & Send appears on the bottom
line of the display and press OK.
2. Press the left/right arrow until the number category you want
appears and press OK.
3. Press OK when All appears.
4. Press the left/right arrow until the name and address you want
appears. You can search upwards or downwards through the entire
memory in alphabetical order.
Searching with a particular first letter
1. Press Address Book until Search & Send appears on the bottom
line of the display and press OK.
2. Press the left/right arrow until the number category you want
appears and press OK.
3. Press the left/right arrow until ID appears and press OK.
4. Enter the first few letters of the name you want appears and press
OK.
5. Press the left/right arrow until the name you want appears and press
OK.
Printing Address Book
You can check your address Book settings by printing a list.
1. Press Address Book until Print appears on the bottom of the display.
2. Press OK.
3. Press the left/right arrow until the option you want appears and press
OK.
4. Press OK when Yes appears to confirm printing.
The selected information prints out.
USING SAMSUNG SCAN AND FAX MANAGER
If you have installed the printer driver, the Samsung Scan and Fax Manager
program is installed too. Start Samsung Scan and Fax Manager program to
find out about this program information and the installed scan driver's
condition. Through this program, you can change scan settings and add or
delete the folders where scanned documents are saved in your computer.
The Samsung Scan and Fax Manager program can only be used in
the Windows and Mac OS system. If you use the Macintosh, See
"Setting scan information in Scan and Fax Manager" on page 89.
1. From the Start menu, click Control Panel > Samsung Scan and Fax
Manager.
You can open Samsung Scan and Fax Manager by right clicking
the Smart Panel icon in the Windows task bar and selecting Scan
Manager.
2. Select the appropriate machine from the Samsung Scan and Fax
ManagerGwindow.
3. Press Properties.
4. The Set Scan Button tab allows you to change the file saving
destination and scan settings, to add or delete application program, and
to change the file format to be saved.
You can change the scanning machine by using the Change Port tab
(Local or Network).
5. When setting is done, press OK.
Scanning_ 87
Set Scan Button tab
Scan Destination
•Available Destination List: Shows the list of applications currently
linked to scanned images in the PC’s registry. Select the program
you want to use and click the right arrow and add to Front Panel
Destination List.
•Front Panel Destination List: Shows the list of applications to
open scanned image.
•Add Application: Allows you to add application you want to use to
Available Destination List.
•Remove Application: Allows you to remove an item added by the
user in the Available Destination List.
•File Format: Allows you to select the form of scanned data to be
saved. You can choose among BMP,JPEG,PDFGand TIFF.
Scan Property
•Computer ID: Shows the ID of your computer.
•Save Location: Allows you to choose the location of the default
saving folder.
•Resolution: Allows you to choose the scan resolution.
•Scan Color: Allows you to choose the scan color.
•Scan Size: Allows you to choose the scan size.
•ADF Duplex: Automatically scans both sides. If your model does
not support this option, it will be grayed out.
•Show Preview: Checking this box allows you to preview applied
scan options. You can modify the options before scanning.
•Default: Allows you to go back to default options.
Change Port tab
Local Scanner
Select when your machine is connected via USB port.
Network Scanner
Select when your machine is connected via network port.
•Auto detection on the network: Automatically detects your
machine.
•IP or Host name: Enter in your machine’s IP address to detect your
machine.
Scan Assistant
When you press Quick Scan in Samsung Scan and Fax Manager, the
Scan Assistant window appears. Scan Assistant allows you to adjust
scan settings and start the scanning process.
•Favorites: Allows you to save the current preferences settings for
future use. When you save Favorites, all current scan settings are
saved. To use a saved setting, select it from the Favorites drop
down list. The machine is now set to scan according to the setting
you selected. To delete saved setting, select it from the Favorites
drop down list and click Delete. To set a favorite as startup, select
the favorite you want to set as startup, then click the Set as default
button.
•Scan settings: The following scan options are available.
-Image Type: Allows you to chose the proper color settings for
image scanning.
-Resolution: Allows you to choose the image resolution.
-Document Size: Allows you to choose the proper size of the
scanned image.
-Document Source: Allows you to choose the device (document
feeder or scan glass) you want to scan with.
-Prompt for additional pages: If this check box is checked, you
can scan pages continuously. This option is useful when you
scan multi-page documents and/or when Document Source is
set to Flatbed (platen glass). In this case a sequence of scanned
images is processed as a single document.
-Pages to Scan: Allows you to specify how many pages are to be
scanned. This option is available when Document Source is set
to ADF(Document feeder).
•Preference: The following scan options are available.
-Auto crop image after preview: If this option is checked, the
Scanning_ 88
scanning area will be automatically adjusted to the image size.
-Preview on program start: If this option is checked, the
scanning area will be selected automatically as shown in the
preview.
-Blank page detection: This operation automatically detects
whether the scanned image is blank or not.
-Delete page: Blank pages will be deleted at the end of the
scanning process.
-Separate files: Blank page will work as a scan job separator.
That is, when multiple pages are scanned at once a blank
page will divide scanned image sequence into parts. Each
part will be treated as a separate document (group).
-Start from scanner: If this option is checked, scanning
process is managed using scanner touch screen rather than
from the computer. The option is not available for some
scanner models.
•Advanced: In the Advanced mode, additional options such as
Image Adjustment,Image Enhancement, and Additional
Settings are available.
-Image Adjustment: Allows you to perform some transformations
of the scanned image. These transformations include automatic
adjustment of image size, straightening and rotation.
-Image Enhancement: Allows you to remove various defects of
the image and improve its quality.
-Additional settings: Allows special processing of scanned
images. These transformations include stitching several partial
image scans into a single image, processing of scanned books
and watermark stamping.
Click the Help button from the lower-left corner of the window and
click on any option you want to know about. Then a pop up window
appears with information about that option's feature which is
provided from the Scan Assistant.
SCANNING WITH TWAIN-ENABLED SOFTWARE
If you want to scan documents using other software, you will need to use
TWAIN-compliant software such as Adobe Photoshop.
Follow the steps below to scan with TWAIN-compliant software.
1. Make sure that the machine is connected to your computer and powered
on.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass (See "Loading originals" on
page 65).
3. Open an application such as Adobe Photoshop.
4. Open the TWAIN window and set the scan options.
5. Scan and save your scanned image.
SCANNING USING THE WIA DRIVER
Your machine also supports the Windows Image Acquisition (WIA) driver for
scanning images. WIA is one of the standard components provided by
Microsoft Windows XP and works with digital cameras and scanners. Unlike
the TWAIN driver, the WIA driver allows you to scan and easily adjust
images without using additional software.
The WIA driver works only on Windows XP/Vista with a USB port.
Windows XP
1. Make sure that the machine is connected to your computer and powered
on.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
(See "Loading originals" on page 65).
3. From the Start menu, select Control Panel > Scanners and Cameras.
4. Double-click your scanner driver icon. The Scanner and Camera
wizard appears.
5. Click Next.
6. Set the option in Choose scanning preferences window and click
Preview to see how your options affect the picture.
7. Click Next.
8. Enter a picture name, and select a file format and destination to save the
picture.
9. Your picture has been successfully copied to your computer. Choose
one of the options on screen.
10. Click Next.
11. Click Finish.
Windows Vista
1. Make sure that the machine is connected to your computer and powered
on.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
(See "Loading originals" on page 65).
3. From the Start menu select Control Panel > Hardware and Sound >
Scanners and Cameras.
4. Double-click Scan a document or picture.Windows Fax and Scan
application appears.
•You can click on View scanners and cameras to view
scanners,
•If there is no Scan a document or picture, open the MS paint
program and from the File click From Scanner or Camera...
5. Click New Scan. Scan driver appears.
6. Choose your scanning preferences and click Preview to see your
preferences affect the picture.
7. Click Scan.
If you want to cancel the scan job, press the Cancel button on the
Scanner and Camera wizard.
Windows 7
1. Make sure that the machine is connected to your computer and powered
on.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass
(See "Loading originals" on page 65).
3. From the Start menu select Control Panel > Hardware and Sound >
Devices and Printers.
4. Click right button of mouse on device driver icon in Printers and Faxes
>Start Scan.New Scan application appears.
5. Choose your scanning preferences and click Preview to see your
preferences affect the picture.
6. Click Scan.
Scanning_ 89
MACINTOSH SCANNING
You can scan documents using Image Capture program. Mac OS offers
Image Capture program.
Scanning with USB
1. Make sure that the machine is connected to your computer and powered
on.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
(See "Loading originals" on page 65).
3. Start Applications and click Image Capture.
If No camera or scanner connected message appears,
disconnect the USB cable and reconnect it. If the problem persists,
refer to the Image Capture’s help.
4. Set the scan options on this program.
5. Scan and save your scanned image.
•For more information about using Image Capture, refer to the
Image Capture’s help.
•Use TWAIN-compliant software to apply more scan options.
•You can also scan using TWAIN-compliant software, such as
Adobe Photoshop.
•Scan process differ according to TWAIN-compliant software.
Please refer to the user’s guide of the software.
•If scanning does not operate in Image Capture, update Mac OS to
the latest version. Image Capture operates properly in Mac OS X
10.3.9 or higher and Mac OS X 10.4.7 or higher.
Scanning with network
1. Make sure that the machine is connected to your computer and powered
on.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass (See "Loading originals" on
page 65).
3. Start Applications and click Image Capture.
4. For Mac OS X 10.4 ~ 10.5
Click Devices and click Browse Devices.
For Mac OS X 10.6
Select your device below SHARED. Skip to step 7.
5. For Mac OS X 10.4
Select your machine in TWAIN devices option. Make sure that Use
TWAIN software check box is checked, and click Connect.
•If a warning message appears, click Change Port.. to select port.
•If TWAIN UI appears, from the Preference tab, click Change Port..
to select port.
Refer to scan manager for Change port.. use (See "Setting
scan information in Scan and Fax Manager" on page 89).
For Mac OS X 10.5
Make sure that Connected check box is checked beside your machine
in Bonjour Devices.
If you want to scan using TWAIN, refer to the Mac OS X 10.4 steps
above.
6. Set the scan options on this program.
7. Scan and save your scanned image.
•For Mac OS X 10.3, use TWAIN-compliant software.
•For more information about using Image Capture, refer to the
Image Capture’s help.
•Use TWAIN-compliant software to apply more scan options.
•You can also scan using TWAIN-compliant software, such as
Adobe Photoshop.
•Scan process differ according to TWAIN-compliant software.
Please refer to the user’s guide of the software.
•If scanning does not operate in Image Capture, update Mac OS to
the latest version. Image Capture operates properly in Mac OS X
10.4.7 or higher.
Setting scan information in Scan and Fax Manager
When you want to find out about Scan and Fax Manager program
information, to check the installed scan driver's condition, to change
scan settings and to add or delete the folders where scanned
documents to computer are saved in Scan and Fax Manager program,
follow the below steps.
1. From the Smart Panel menu on Status bar, click Scan and Fax
Manager.
2. Select the appropriate machine from the Scan and Fax Manager.
3. Press Properties.
4. Use Set Scan Button to change the file destination or scan settings,
to add or delete application programs, and to format files. You can
change the scanning machine by using Change Port (Local or
Network).
5. When done, press OK.
LINUX SCANNING
You can scan a document using the Unified Driver Configurator window.
Scanning
1. Double-click the Unified Driver Configurator on your desktop.
2. Click the button to switch to Scanners configuration.
3. Select the scanner on the list.
If you use only one machine device and it is connected to the computer
and turned on, your scanner appears on the list and is automatically
selected.
If you have two or more scanners connected to your computer, you can
select any scanner to work at any time. For example, while acquisition is
in progress on the first scanner, you may select the second scanner, set
Scanning_ 90
the device options and start the image acquisition simultaneously.
4. Click Properties.
5. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
(See "Loading originals" on page 65).
6. From the Scanner Properties window, click Preview.
The document is scanned and the image preview appears in the
Preview Pane.
7. Drag the pointer to set the image area to be scanned in the Preview
Pane.
8. Change the scan options in the Image Quality and Scan Area sections.
•Image Quality: This option allows you to select the color
composition and the scan resolution for the image.
•Scan Area: This option allows you to select the page size. The
Advanced button enables you to set the page size manually.
If you want to use one of the preset scan option settings, select the
option from the Job Type drop-down list (See "Adding Job Type
Settings" on page 90).
Click Default to restore the default setting for the scan options.
9. When you have finished, click Scan to start scanning.
The status bar appears on the bottom left of the window to show you the
progress of the scan. To cancel scanning, click Cancel.
10. The scanned image appears.
If you want to edit the scanned image, use the toolbar (See "Using the
Image Manager" on page 90).
11. When you are finished, click Save on the toolbar.
12. Select the file directory where you want to save the image and enter the
file name.
13. Click Save.
Adding Job Type Settings
You can save your scan option settings for later use.
To save a new Job Type setting
1. Change the options from the Scanner Properties window.
2. Click Save As.
3. Enter the name for your setting.
4. Click OK.
Your setting is added to the Saved Settings drop-down list.
To save a Job Type setting for the next scan job
1. Select the setting you want to use from the Job Type drop-down list.
2. The next time you open the Scanner Properties window, the saved
setting is automatically selected for the scan job.
To delete a Job Type setting
1. Select the setting you want to delete from the Job Type drop-down
list.
2. Click Delete.
The setting is deleted from the list.
Using the Image Manager
The Image Manager application provides you with menu commands and
tools to edit your scanned image.
Use the following tools to edit the image.
Scanning_ 91
For further details about the Image Manager application, refer to the on
screen help.
TOOLS NAME FUNCTION
Save Saves the image.
Undo Cancels your last action.
Redo Restores the action you canceled.
Scroll Allows you to scroll through the image.
Crop Crops the selected image area.
Zoom Out Zooms the image out.
Zoom In Zooms the image in.
Scale Allows you to scale the image size; you can
enter the size manually, or set the rate to scale
proportionally, vertically, or horizontally.
Rotate Allows you to rotate the image; you can select
the number of degrees from the drop-down list.
Flip Allows you to flip the image vertically or
horizontally.
Brightness Allows you to adjust the brightness or contrast
of the image, or to invert the image.
Properties Shows the properties of the image.
Faxing (CLX-3185FN/CLX-3185FW only)_ 92
10.faxing (clx-3185fn/clx-3185fw only)
This chapter gives you information about using your machine as a fax machine.
This chapter includes:
•Preparing to fax
•Using a fax in your computer
•Sending a fax in your machine
•Receiving a fax in your machine
•Adjusting the document settings
•Forwarding a fax to another destination
•Setting up Address Book
•Printing sent fax report automatically
•You cannot use this machine as a fax via the internet phone. For
more information ask your internet service provider.
•We recommend using traditional analog phone services (PSTN:
Public Switched Telephone Network) when connecting telephone
lines to use a fax machine. If you use other Internet services (DSL,
ISDN, VolP), you can improve the connection quality by using the
Micro-filter. The Micro-filter eliminates unnecessary noise signals
and improves connection quality or Internet quality. Since the DSL
Micro-filter is not provided with the machine, contact your Internet
service provider for use on DSL Micro-filter.
1Line port
2Micro filter
3DSL modem / Telephone line
Supported optional devices and features may differ according to your
model. Check your model name.
(See "Features by Models" on page 28).
PREPARING TO FAX
Before you send or receive a fax, you need to connect the supplied line cord
to your telephone wall jack. Refer to the Quick Installation Guide how to
make a connection. The method of making a telephone connection is
different from one country to another.
USING A FAX IN YOUR COMPUTER
You can send and receive a fax from your computer without going to the
machine.
Sending a fax (Windows)
To send a fax from your computer, the Samsung Network PC Fax program
must be installed. This program will be installed when you installed the
printer driver.
1. Open the document to be sent.
2. Select Print from the File menu.
The Print window will be displayed. It may look slightly different
depending on your application.
3. Select Samsung Network PC Fax from the Print window
4. Click Print or OK. Then, a windows like the image below will appear.
5. Enter the recipients’ number and set the options if necessary.
If you want to use a cover page, check Use cover page.
Check Notify me on delivery, when the fax is delivered to the recipient
successfully.
6. Click Send.
For the more information about Samsung Network PC Fax, click
Help.
Checking a sent fax list (Windows)
You can check a sent fax list on your computer.
From the Start menu, click Programs or All Programs > Samsung
Printers > Network PC Fax > Fax Journal. Then, the Fax Journal
appears with the fax list you have sent.
Sending a fax (Macintosh)
To send a fax from your computer, the Fax Utilities program must be
installed. This program is installed when you install the printer driver.
The following steps are based on the Mac OS X 10.5 or 10.6. Depending on
the OS version, the following steps will be different.
1. Open the document to be sent.
2. Select Print from the File menu.
The Print window will be displayed. It may look slightly different
depending on your application.
Faxing (CLX-3185FN/CLX-3185FW only)_ 93
In case of Mac OS X 10.3 or 10.4, select PDF and Fax PDF.
3. Select CLX-3180 Series fax-USB from the drop-down list in Printer.
4. Choose the number of copies you want and indicate which pages you
want to fax.
5. Choose your paper size, orientation, and scale.
6. Enter the recipients’ fax number into To’s input area. You can also use
Addresses pressing button, if you have stored frequently used fax
numbers.
7. If necessary, enter the access code in Dialing Prefix input area.
8. If necessary, you can send the fax with cover page, check Use Cover
Page.
Enter the subject and message of the fax job.
You can set more detailed options for cover page option in
Samsung Fax Cover Page. Select Samsung Fax Cover Page
from the drop-down list under Orientation.
9. Click Fax.
10. The Fax Journal icon appears on your Macintosh dock. Click the icon.
You can see the status of the fax job. You can also delete, hold, resume,
and pause the fax job.
SENDING A FAX IN YOUR MACHINE
This part explains how to send a fax and the special methods of
transmission.
When you place the originals, you can use either the document feeder
or the scanner glass (See "Loading originals" on page 65). If the
originals are placed on both the document feeder and the scanner
glass, the machine will read the originals on the document feeder first,
which has higher priority in scanning.
Setting the fax header
In some countries, you are required by law to indicate your fax number on
any fax you send.
1. Press Menu on the control panel.
2. Press the left/right arrow until System Setup appears and press OK.
3. Press the left/right arrow until Machine Setup appears and press OK.
4. Press the left/right arrow until Machine ID appears and press OK.
5. Enter your name or the company name using the number keypad. You
can enter alphanumeric characters using the number keypad, and
include special symbols by pressing the 1 button. For details on how to
enter alphanumeric characters, see "Entering characters using the
number keypad (CLX-3185FN/CLX-3185FW only)" on page 62.
6. Press OK to save the ID.
7. Press the left/right arrow until Machine Fax No. appears and press OK.
8. Enter your fax number using the number keypad and press OK.
9. Press Stop/Clear to return to ready mode.
Sending a fax
1. Press (Fax) on the control panel.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
(See "On the scanner glass" on page 65 or "In the document feeder
(CLX-3185FN/CLX-3185FW only)" on page 65).
3. Adjust the resolution and the darkness to suit your fax needs (See
"Adjusting the document settings" on page 96).
4. Enter the receiving fax machine’s number.
You can use speed dial numbers, or group dial numbers. For details
about storing and searching for a number, see "Setting up Address
Book" on page 97.
5. Press Color Start or Black Start on the control panel. The machine
starts to scan and send a fax to destinations.
•If you want to send fax directly from your computer, use Samsung
Network PC Fax (See "Sending a fax (Windows)" on page 92).
•When you want to cancel a fax job, press Stop/Clear before the
machine start transmission.
•If you used the scanner glass, the machine shows the message
asking to place another page.
Sending a fax manually
This method is sending a fax using On Hook Dial on the control panel.
1. Press (Fax) on the control panel.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
3. Adjust the resolution and the darkness to suit your fax needs (See
"Adjusting the document settings" on page 96).
4. Press On Hook Dial on the control panel or lift the handset.
5. Enter a fax number using the number keypad on the control panel.
6. Press Color Start or Black Start when you hear a high-pitched fax
signal from the remote fax machine.
When you want to cancel a fax job, press Stop/Clear at any time while
sending.
Confirming a transmission
When the last page of your original has been sent successfully, the machine
beeps and returns to ready mode.
When something goes wrong while sending your fax, an error message
appears on the display. You must treat the malfunction according to the
error messages on the display (See "Understanding display messages" on
page 122 for a list of error messages and their meanings. If you receive an
error message, press Stop/Clear to clear the message and try to send the
fax again.
You can set your machine to print a confirmation report automatically each
time sending a fax is completed (See "Printing sent fax report automatically"
on page 99).
Automatic redialing
When the number you have dialed is busy or there is no answer when you
send a fax, the machine automatically redials the number every three
minutes, up to seven times according to the factory default settings.
When the display shows Retry Redial?, press OK to redial the number
without waiting. To cancel the automatic redialing, press Stop/Clear.
To change the time interval between redials and the number of redial
attempts (See "Changing the fax setup options" on page 103).
Redialing the last number
To redial the number you called last
1. Press Redial/Pause on the control panel.
2. When an original is loaded in the document feeder, the machine
automatically begins to send.
If an original is placed on the scanner glass, select Yes to add another
page. Load another original and press OK. When you have finished,
select No at the Another Page? prompt.
Faxing (CLX-3185FN/CLX-3185FW only)_ 94
Sending a fax to multiple destinations
You can use the Multiple Send feature, which allows you to send a fax to
multiple locations. Originals are automatically stored in memory and sent to
a remote station. After transmission, the originals are automatically erased
from memory. You cannot send a color fax using this feature.
1. Press (Fax) on the control panel.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
3. Adjust the resolution and the darkness to suit your fax needs (See
"Adjusting the document settings" on page 96).
4. Press Menu on the control panel.
5. Press the left/right arrow until Fax Feature appears and press OK.
6. Press the left/right arrow until Multi Send appears and press OK.
7. Enter the number of the first receiving fax machine and press OK.
You can press speed dial numbers or select group dial number using
Address book button. For details, see "Setting up Address Book" on
page 97.
8. Enter the second fax number and press OK.
The display asks you to enter another fax number to send the document.
9. To enter more fax numbers, press OK when Yes appears and repeat
steps 7 and 8. You can add up to 10 destinations.
10. Press OK to start storing the scanned original data into memory.
Once you entered a group dial number, you cannot enter another
group dial numbers anymore.
11. When you have finished entering fax numbers, press the left/right arrow
to select No at the Another No.? prompt and press OK.
12. If an original is placed on the scanner glass, select Yes to add another
pages. Load another original and press OK.
When you have finished, select No at the Another Page? prompt.
The machine begins sending the fax to the numbers you entered in the
order in which you entered them.
Delaying a fax transmission
You can set your machine to send a fax at a later time when you will not be
present. You cannot send a color fax using this feature.
1. Press (Fax) on the control panel.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
3. Adjust the resolution and the darkness to suit your fax needs (See
"Adjusting the document settings" on page 96).
4. Press Menu on the control panel.
5. Press the left/right arrow until Fax Feature appears and press OK.
6. Press the left/right arrow until Delay Send appears and press OK.
7. Enter the number of the receiving fax machine and press OK.
You can press speed dial numbers or select group dial number using
Address book button. For details, see "Setting up Address Book" on
page 97.
8. The display asks you to enter another fax number to send the document.
9. To enter more fax numbers, press OK when Yes appears and repeat
steps 7. You can add up to 10 destinations.
Once you entered a group dial number, you cannot enter another
group dial numbers anymore.
10. When you have finished entering fax numbers, press the left/right arrow
to select No at the Another No.? prompt and press OK.
11. Enter the job name you want and press OK.
For details on how to enter alphanumeric characters, see "Entering
characters using the number keypad (CLX-3185FN/CLX-3185FW only)"
on page 62.
If you do not want to assign a name, skip this step.
12. Enter the time using the number keypad and press OK.
If you set a time earlier than the current time, the fax will be sent at
that time on the following day.
The original is scanned into memory before transmission.
13. If an original is placed on the scanner glass, select Yes to add another
pages. Load another original and press OK.
When you have finished, select No at the Another Page? prompt.
The machine returns to ready mode. The display reminds you that you
are in ready mode and that a delayed fax is set.
Adding documents to a reserved delay fax job
You can add additional documents to the delayed fax job which is saved
in memory.
1. Load the originals to be added and adjust document settings.
2. Press (Fax) on the control panel.
3. Press Menu on the control panel.
4. Press the left/right arrow until Fax Feature appears and press OK.
5. Press the left/right arrow until Add Page appears and press OK.
6. Press the left/right arrow until the fax job you want appears and
press OK.
When you have finished, select No at the Another Page? prompt.
The machine scans the original into memory.
7. Press Stop/Clear to return to ready mode.
Canceling a reserved delay fax job
You can cancel the delayed fax job which is saved in memory.
1. Press Menu on the control panel.
2. Press (Fax) on the control panel.
3. Press the left/right arrow until Fax Feature appears and press OK.
4. Press the left/right arrow until Cancel Job appears and press OK.
5. Press the left/right arrow until the fax job you want appears and
press OK.
6. Press OK when Yes appears.
The selected fax is deleted from memory.
7. Press Stop/Clear to return to ready mode.
Sending a priority fax
This function is used when a high priority fax need to be sent ahead of
reserved operations. The original is scanned into memory and immediately
transmitted when the current operation is finished. In addition, priority
transmission will interrupt a sending to multiple destinations between
stations (example, when the transmission to station A ends, before
transmission to station B begins) or between redial attempts.
1. Press (Fax) on the control panel.
2. Load originals face up into the document feeder, or place a single
original face down on the scanner glass.
3. Adjust the resolution and the darkness to suit your fax needs (See
"Adjusting the document settings" on page 96).
4. Press Menu on the control panel.
5. Press the left/right arrow until Fax Feature appears and press OK.
Faxing (CLX-3185FN/CLX-3185FW only)_ 95
6. Press the left/right arrow until Priority Send appears and press OK.
7. Enter the number of the receiving fax machine and press OK.
You can press speed dial numbers or select group dial number using
Address book button. For details, see "Setting up Address Book" on
page 97.
8. Enter the job name you want and press OK.
The original is scanned into memory before transmission.
9. If an original is placed on the scanner glass, select Yes to add another
pages. Load another original and press OK.
When you have finished, select No at the Another Page? prompt.
The machine starts to scan and send a fax to destinations.
RECEIVING A FAX IN YOUR MACHINE
This part explains how to receive a fax, and the special receiving methods
available.
Changing the receive modes
Your machine is preset to Fax mode at the factory. When you receive a fax,
the machine answers the call on a specified number of rings and
automatically receives the fax. But if you want to change the Fax mode to
another mode, follow the steps below.
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Setup appears and press OK.
4. Press the left/right arrow until Receiving appears and press OK.
5. Press the left/right arrow until Receive Mode appears and press OK.
6. Press the left/right arrow until the fax reception mode you want appears.
•Fax: Answers an incoming fax call and immediately goes into the
fax reception mode.
•Tel: Receives a fax by pressing On Hook Dial and then Start. If
your machine has a handset, you can receive a fax by picking up the
handset.
•Ans/Fax: Is for when an answering machine attached to your
machine. Your machine answers an incoming call, and the caller can
leave a message on the answering machine. If the fax machine
senses a fax tone on the line, the machine automatically switches to
Fax mode to receive the fax.
•DRPD: you can receive a call using the Distinctive Ring Pattern
Detection (DRPD) feature. Distinctive Ring is a telephone company
service which enables an user to use a single telephone line to
answer several different telephone numbers. For further details, see
"Receiving faxes using DRPD mode" on page 95.
7. Press OK to save your selection.
8. Press Stop/Clear to return to ready mode.
•To use the Ans/Fax mode, attach an answering machine to the
EXT socket on the back of your machine.
•If you do not want other people to view your received
documents, you can use secure receiving mode. In this mode,
all of the received faxes are stored in memory. For further
details, see "Receiving in secure receiving mode" on page 96.
Receiving automatically in Fax mode
Your machine is preset Fax mode at the factory. When you receive a fax,
the machine answers the call on a specified number of rings and
automatically receives the fax.
To change the number of rings, see "Fax setup (CLX-3185FN/CLX-3185FW
only)" on page 103.
Receiving manually in Tel mode
You can receive a fax call by pressing On Hook Dial and then pressing
Black Start or Color Start when you hear a fax tone from the remote
machine.
The machine begins receiving a fax and returns to ready mode when the
reception is completed.
Receiving faxes manually using an extension
telephone
This feature works best when you are using an extension telephone
connected to the EXT socket on the back of your machine. You can receive
a fax from someone you are talking to on the extension telephone, without
going to the fax machine.
When you receive a call on the extension phone and hear fax tones, press
the keys *9* on the extension phone. The machine receives the fax.
Press the buttons slowly in sequence. If you still hear the fax tone from the
remote machine, try pressing *9* once again.
*9* is the remote receive code preset at the factory. The first and the last
asterisks are fixed, but you can change the middle number to whatever you
wish. For details about changing the code, see "Changing the fax setup
options" on page 103
Receiving automatically in Answering Machine/Fax
mode
To use this mode, you must attach an answering machine to the EXT socket
on the back of your machine (See "Rear view" on page 33).
If the caller leaves a message, the answering machine stores the message
as it would normally. If your machine detects a fax tone on the line, it
automatically starts to receive the fax.
•If you have set your machine to this mode and your answering
machine is switched off, or no answering machine is connected to
EXT socket, your machine automatically goes into Fax mode after
a predefined number of rings.
•If your answering machine has a user-selectable ring counter, set
the machine to answer incoming calls within 1 ring.
•If you are in Tel mode when the answering machine is connected
to your machine, you must switch off the answering machine.
Otherwise, the outgoing message from the answering machine will
interrupt your phone conversation.
Receiving faxes using DRPD mode
Distinctive Ring is a telephone company service which enables an user to
use a single telephone line to answer several different telephone numbers.
The particular number someone uses to call you is identified by different
ringing patterns, which consist of various combinations of long and short
ringing sounds. This feature is often used by answering services who
answer telephones for many different clients and need to know which
number someone is calling in on to properly answer the phone.
Using the Distinctive Ring Pattern Detection (DRPD) feature, your fax
machine can learn the ring pattern you designate to be answered. Unless
you change it, this ringing pattern will continue to be recognized and
Faxing (CLX-3185FN/CLX-3185FW only)_ 96
answered as a fax call, and all other ringing patterns will be forwarded to the
extension telephone or answering machine plugged into the EXT socket.
You can easily suspend or change DRPD at any time.
Before using the DRPD option, Distinctive Ring service must be installed on
your telephone line by the telephone company. To set up DRPD, you will
need another telephone line at your location, or someone available to dial
your fax number from outside.
To set up the DRPD mode
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Setup appears and press OK.
4. Press the left/right arrow until Receiving appears and press OK.
5. Press the left/right arrow until Receive Mode appears and press OK.
6. Press the left/right arrow until DRPD appears and press OK.
Waiting Ring appears on the display.
7. Call your fax number from another telephone. It is not necessary to
place the call from a fax machine.
8. When your machine begins to ring, do not answer the call. The machine
requires several rings to learn the pattern.
When the machine completes learning, the display shows Completed
DRPD Setup. If the DRPD setup fails, Error DRPD Ring appears.
Press OK when DRPD appears and start over from step 6.
•DRPD must be set up again if you re-assign your fax number,
or connect the machine to another telephone line.
•After DRPD has been set up, call your fax number again to
verify that the machine answers with a fax tone. Then have a
call placed to a different number assigned to that same line to
be sure the call is forwarded to the extension telephone or
answering machine plugged into the EXT socket.
Receiving in secure receiving mode
You may need to prevent your received faxes from being accessed by
unauthorized people. You can turn on secure receiving mode to restrict
printing of received faxes when the machine is unattended. In secure
receiving mode, all incoming faxes go into memory. When the mode is
deactivated, any stored faxes are printed.
Activating secure receiving mode
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Feature appears and press OK.
4. Press the left/right arrow until Secure Receive appears and press OK.
5. Press the left/right arrow until On appears and press OK.
6. Enter a four-digit password you want to use and press OK.
You can activate secure receiving mode without setting a
password, but cannot protect your faxes.
7. Re-enter the password to confirm it and press OK.
8. Press Stop/Clear to return to ready mode.
When a fax is received in secure receiving mode, your machine stores it in
memory and shows Secure Receive to let you know that there is a fax
received.
Printing received faxes
1. Access the Secure Receive menu by following steps 1 through 4 in
“Activating secure receiving mode.”
2. Press the left/right arrow until Print appears and press OK.
3. Enter the four-digit password and press OK.
The machine prints all of the faxes stored in memory.
Deactivating secure receiving mode
1. Access the Secure Receive menu by following steps 1 through 4 in
“Activating secure receiving mode.”
2. Press the left/right arrow until Off appears and press OK.
3. Enter the four-digit password and press OK.
The mode is deactivated and the machine prints all faxes stored in
memory.
4. Press Stop/Clear to return to ready mode.
Receiving faxes in memory
Since your machine is a multi-tasking device, it can receive faxes while you
are making copies or printing. If you receive a fax while you are copying or
printing, your machine stores incoming faxes in its memory. Then, as soon
as you finish copying or printing, the machine automatically prints the fax.
ADJUSTING THE DOCUMENT SETTINGS
Before starting a fax, change the following settings according to your
original’s status to get the best quality.
Resolution
The default document settings produces good results when using typical
text-based originals. However, if you send originals that are of poor quality,
or contain photographs, you can adjust the resolution to produce a higher
quality fax.
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Feature appears and press OK.
4. Press the left/right arrow until Resolution appears and press OK.
5. Press the left/right arrow until the option you want appears and press
OK.
6. Press Stop/Clear to return to ready mode.
Recommended resolution settings for different original document types are
described in the table below.
MODE RECOMMENDED FOR
Standard Originals with normal sized characters
Fine Originals containing small characters or thin lines or
originals printed using a dot-matrix printer
Super Fine Originals containing extremely fine detail. Super Fine
mode is enabled only if the machine with which you are
communicating also supports the Super Fine resolution.
•For memory transmission, Super Fine mode is
not available. The resolution setting is
automatically changed to Fine.
•When your machine is set to Super Fine
resolution and the fax machine with which you
are communicating does not support Super
Fine resolution, the machine transmits using
the highest resolution mode supported by the
other fax machine.
Photo Fax Originals containing shades of gray or photographs
Faxing (CLX-3185FN/CLX-3185FW only)_ 97
The resolution setting is applied to the current fax job. To change the
default setting, see "Change Default" on page 104.
Darkness
You can select the degree of darkness of the original document.
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Feature appears and press OK.
4. Press the left/right arrow until Darkness appears and press OK.
5. Press the left/right arrow until the option you want appears and press
OK.
6. Press Stop/Clear to return to ready mode.
The darkness setting is applied to the current fax job. To change the
default setting, see "Change Default" on page 104.
FORWARDING A FAX TO ANOTHER
DESTINATION
You can set the machine to forward the received or sent fax to other
destination by a fax. If you are out of office but have to receive the fax, this
feature may be useful.
Forwarding a sent fax to another destination
You can set the machine to forward every fax you sent to another
destination.
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Feature appears and press OK.
4. Press the left/right arrow until Forward appears and press OK.
5. Press the left/right arrow until Fax appears and press OK.
6. Press the left/right arrow until Send Forward appears and press OK.
7. Press the left/right arrow until On appears and press OK.
8. Enter the number of the fax machine to which faxes are to be sent and
press OK.
9. Press Stop/Clear to return to ready mode.
Subsequent sent faxes will be forwarded to the specified fax machine.
Forwarding a received fax to another destination
With this feature, you can forward every fax you received to another
destination. When the machine receives a fax, a fax is stored in the memory
then, the machine sends it to the destination you have set.
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Feature appears and press OK.
4. Press the left/right arrow until Forward appears and press OK.
5. Press the left/right arrow until Fax appears and press OK.
6. Press the left/right arrow until Rcv. Forward appears and press OK.
7. Press the left/right arrow until Forward appears and press OK.
To set the machine to print out a fax when fax forwarding has been
completed, select Forward & Print.
8. Enter the number of the fax machine to which faxes are to be sent and
press OK.
9. Enter the starting time using left/right arrow or numeric keypad and
press OK.
10. Enter the ending time using left/right arrow or numeric keypad and press
OK.
11. Press Stop/Clear to return to ready mode.
Subsequent sent faxes will be forwarded to the specified fax machine.
Forwarding a sent fax to email address
You can set the machine to forward every fax you sent to another
destination.
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Feature appears and press OK.
4. Press the left/right arrow until Forward appears and press OK.
5. Press the left/right arrow until E-mail appears and press OK.
6. Press the left/right arrow until Send Forward appears and press OK.
7. Press the left/right arrow until On appears and press OK.
8. Enter the sender’s email address when From appears on the display
and press OK.
9. Enter the recipient’s email address when DestinationEmail appears on
the display and press OK.
10. Then, the setting is saved.
11. Press Stop/Clear to return to ready mode.
Subsequent sent faxes will be forwarded to the specified email address.
Forwarding a received fax to email address
With this feature, you can forward every fax you received to another
destination. When the machine receives a fax, a fax is stored in the memory
then, the machine sends it to the destination you have set.
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Feature appears and press OK.
4. Press the left/right arrow until Forward appears and press OK.
5. Press the left/right arrow until E-mail appears and press OK.
6. Press the left/right arrow until Rcv. Forward appears and press OK.
7. Press the left/right arrow until Forward appears and press OK.
To set the machine to print out a fax when fax forwarding has been
completed, select Forward & Print.
8. Enter the sender’s email address when From appears on the display
and press OK.
9. Enter the recipient’s email address when DestinationEmail appears on
the display and press OK.
10. Then, the setting is saved.
11. Press Stop/Clear to return to ready mode.
Subsequent sent faxes will be forwarded to the specified email address.
SETTING UP ADDRESS BOOK
You can set up Address Book with the fax numbers you use most
frequently. Your machine provides you with the following features for setting
up Address Book.
Before beginning to store fax numbers, make sure that your machine
is in Fax mode.
Speed dial numbers
You can store up to 240 frequently-used fax numbers in speed dial
numbers.
Faxing (CLX-3185FN/CLX-3185FW only)_ 98
Registering a speed dial number
1. Press (Fax) on the control panel.
2. Press Address Book on the control panel.
3. Press the left/right arrow until New & Edit appears and press OK.
4. Press the left/right arrow until Speed Dial appears and press OK.
5. Enter a speed dial number between 1 and 240 and press OK.
If an entry is already stored in the number you choose, the display
shows the message to allow you to change it. To start over with
another speed dial number, press Back.
6. Enter the name you want and press OK.
For details on how to enter alphanumeric characters (See "Entering
characters using the number keypad (CLX-3185FN/CLX-3185FW
only)" on page 62).
7. Enter the fax number you want and press OK.
8. Press Stop/Clear to return to ready mode.
Editing speed dial numbers
1. Press (Fax) on the control panel.
2. Press Address Book on the control panel.
3. Press the left/right arrow until New & Edit appears and press OK.
4. Press the left/right arrow until Speed Dial appears and press OK.
5. Enter the speed dial number you want to edit and press OK.
6. Change the name and press OK.
7. Change the fax number and press OK.
8. Press Stop/Clear to return to ready mode.
Using speed dial numbers
When you are prompted to enter a destination number while sending a
fax, enter the speed dial number at which you stored the number you
want.
•For a one-digit (0-9) speed dial number, press and hold the
corresponding digit button on the number keypad.
•For a two- or three-digit speed dial number, press the first digit
button(s) and then hold down the last digit button.
You can also search through memory for an entry by pressing Address
Book (See "Searching Address Book for an entry" on page 98).
Group dial numbers
If you frequently send the same document to several destinations, you can
group these destinations and set them under a group dial number. You can
then use a group dial number to send a document to all of the destinations
within the group. You can set up to 200 (1 through 200) group dial numbers
using the destination’s existing speed dial numbers.
Registering a group dial number
1. Press (Fax) on the control panel.
2. Press Address Book on the control panel.
3. Press the left/right arrow until New & Edit appears and press OK.
4. Press the left/right arrow until Group Dial appears and press OK.
5. Enter a group dial number between 1 and 200 and press OK.
If an entry is already stored in the number you choose, the display
shows the message to allow you to change it.
6. Enter the name you want and press OK.
For details on how to enter alphanumeric characters (See "Entering
characters using the number keypad (CLX-3185FN/CLX-3185FW
only)" on page 62).
7. Enter the speed dial number you want and press OK.
8. Press OK when the speed dial information appears correctly.
9. Press OK when Yes appears at the Add? prompt.
10. Press OK when Yes appears at the Another No.? prompt.
Repeat steps 7 and 10 to include other speed dial numbers into the
group.
11. When you have finished, press the left/right arrow to select No at the
Another No.? prompt and press OK.
12. Press Stop/Clear to return to ready mode.
Editing a group dial number
1. Press (Fax) on the control panel.
2. Press Address Book on the control panel.
3. Press the left/right arrow until New & Edit appears and press OK.
4. Press the left/right arrow until Group Dial appears and press OK.
5. Enter the group dial number you want to edit and press OK.
6. Enter the name you want to edit and press OK.
7. Enter the speed dial number you want to add or delete and press
OK.
8. Press OK when the speed dial information appears correctly.
If you entered a new speed dial number, Add? appears.
If you enter a speed dial number stored in the group, Delete?
appears.
9. Press OK to add or delete the number.
10. Press OK when Yes appears to add or delete more numbers and
repeat steps 7 and 8.
11. When you have finished, press the left/right arrow to select No at the
Another No.? and press OK.
12. Press Stop/Clear to return to ready mode.
Using group dial numbers
To use a group dial entry, you need to search for and select it from
memory.
When you are prompted to enter a fax number while sending a fax,
press Address Book. See below.
Searching Address Book for an entry
There are two ways to search for a number in memory. You can either scan
from A to Z sequentially, or you can search by entering the first letters of the
name associated with the number.
Searching sequentially through the memory
1. Press (Fax) on the control panel.
2. Press Address Book on the control panel.
3. Press the left/right arrow until Search & Dial appears and press OK.
4. Press the left/right arrow until the number category you want
appears and press OK.
5. Press the left/right arrow until All appears and press OK.
6. Press the left/right arrow until the name and number you want
appears.
Searching with a particular first letter through the
memory
1. Press (Fax) on the control panel.
2. Press Address Book on the control panel.
3. Press the left/right arrow until Search & Dial appears and press OK.
Faxing (CLX-3185FN/CLX-3185FW only)_ 99
4. Press the left/right arrow until the number category you want
appears and press OK.
5. Press the left/right arrow until ID appears and press OK.
6. Enter the first few letters of the name you want.
7. Press the left/right arrow until the name and number you want
appears.
Deleting a Address Book for entry
1. Press (Fax) on the control panel.
2. Press Address Book on the control panel.
3. Press the left/right arrow until Delete appears and press OK.
4. Press the left/right arrow until the number category you want
appears and press OK.
5. Press the left/right arrow until the searching method you want
appears and press OK.
Select Search All to search for an entry by scanning through all
entries in Address Book.
Select Search ID to search for an entry by the first few letters of the
name.
6. Press the left/right arrow until the name you want appears and press
OK.
Or, enter the first letters. Press the left/right arrow until the name you
want appears and press OK.
7. Press OK when Yes appears to confirm the deletion.
8. Press Stop/Clear to return to ready mode.
Printing Address Book
You can check your Address Book settings by printing a list.
1. Press (Fax) on the control panel.
2. Press Address Book on the control panel.
3. Press the left/right arrow until Print appears and press OK.
The machine begins printing.
PRINTING SENT FAX REPORT
AUTOMATICALLY
You can set the machine to print a report with detailed information about the
previous 50 communication operations, including time and dates.
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Setup appears and press OK.
4. Press the left/right arrow until Auto Report appears and press OK.
5. Press the left/right arrow until On appears and press OK.
6. Press Stop/Clear to return to ready mode.
Using USB memory device (CLX-3185N/CLX-3185FN/CLX-3185WK/CLX-3185FW only)_ 100
11.using usb memory device
(clx-3185n/clx-3185fn/clx-3185wk/clx-3185fw
only)
This chapter explains how to use a USB memory device with your machine.
This chapter includes:
•About USB memory
•Plugging in a USB memory device
•Scanning to a USB memory device
•Printing from a USB memory device
•Backing up data
•Managing USB memory
•Printing directly from a digital camera
ABOUT USB MEMORY
USB memory devices are available with a variety of memory capacities to
give you more room for storing documents, presentations, downloaded
music and videos, high resolution photographs or whatever other files you
want to store or move.
You can do the following on your machine using a USB memory device.
•Scan documents and save them on a USB memory device
•Print data stored on a USB memory device
•Restore backup files to the machine’s memory
•Format the USB memory device
•Check the available memory space
PLUGGING IN A USB MEMORY DEVICE
The USB memory port on the front of your machine is designed for USB
V1.1 and USB V2.0 memory devices. Your machine supports USB memory
devices with FAT16/FAT32 and sector size of 512 bytes.
Check your USB memory device’s file system from your dealer.
You must use only an authorized USB memory device with an A plug type
connector.
Use only a metal-shielded USB memory device.
Insert a USB memory device into the USB memory port on the front of your
machine.
•Do not remove the USB memory device while the machine is in
operation or writing to or reading from USB memory. The machine
warranty does not cover damage caused by user’s misuse.
•If your USB memory device has certain features such as security
settings and password settings, your machine may not
automatically detect it. For details about these features, see the
user’s guide of the USB memory device.
SCANNING TO A USB MEMORY DEVICE
Illustrations on this user’s guide may differ from your machine
depending on its options or models. Check your model name.
You can scan a document and save the scanned image onto a USB
memory device. There are two ways of doing this: you can scan to the
device using the default settings or you can customize your own scan
settings.
Scanning
1. Insert a USB memory device into the USB memory port on your
machine.
2. Place a single original face down on the scanner glass.
For details about loading an original, see "Loading originals" on page 65.
3. Press (Scan) on the control panel.
4. Press OK when Scan to USB appears on the bottom line of the display.
Press Color Start or Black Start when Ready to Scan to USB
appears.
Regardless of the button you press, the color mode is decided as
A B
Using USB memory device (CLX-3185N/CLX-3185FN/CLX-3185WK/CLX-3185FW only)_ 101
customized (See “"Customizing Scan to USB" on page 101).
Your machine begins scanning the original, and then asks if you want to
scan another page.
5. Press OK when Yes appears to scan more pages. Load another original
to be scanned and press Color Start or Black Start.
Regardless of the button you press, the color mode is decided as
customized (See “"Customizing Scan to USB" on page 101).
Otherwise, press the left/right arrow to select No and press OK.
After scanning is complete, you can remove the USB memory device from
the machine.
Customizing Scan to USB
You can specify image size, file format, or color mode for each scanning to
USB job.
1. Press (Scan) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Scan Feature appears and press OK.
4. Press OK when USB Feature appears.
5. Press the left/right arrow until the setting option you want appears and
press OK.
You can set the following options.
•Scan Size: Sets the image size.
•Original Type: Sets the original document’s type.
•Resolution: Sets the image resolution.
•Scan Color: Sets the color mode. If you select Mono in this option,
you cannot select JPEG in Scan Format.
•Scan Format: Sets the file format in which the image is to be saved.
When you select TIFF or PDF, you can select to scan multiple
pages. If you select JPEG in this option, you cannot select Mono in
Scan Color.
6. Press the left/right arrow until the desired status appears and press OK.
7. Repeat steps 4 and 5 to set other setting options.
8. When you have finished, press Stop/Clear to return to ready mode.
You can change the default scan settings. For details, see "Changing the
default scan settings" on page 85.
PRINTING FROM A USB MEMORY DEVICE
You can directly print files stored on a USB memory device. You can print
TIFF, BMP, JPEG and PRN files.
Files types supported by Direct Print option
•PRN: Only files created by provided driver with your machine are
compatible.
•PRN files can be created by selecting the Print to file check box when
you print a document. The document will be saved as a PRN file, rather
than printed on paper. Only PRN files created in this fashion can be
printed directly from USB memory. See "Printing to a file (PRN)" on
page 76 to learn how to create a PRN file.
•BMP: BMP Uncompressed
•TIFF: TIFF 6.0 Baseline
•JPEG: JPEG Baseline
To print a document from a USB memory device
1. Insert a USB memory device into the USB memory port on your
machine, and then press Direct USB. If one has already been inserted,
press Direct USB.
2. Press OK when USB print appears.
Your machine automatically detects the device and reads data stored on
it.
3. Press the left/right arrow until the folder or file you want appears and
press OK.
If you see [D] in the front of a folder name, there are one or more files or
folders in the selected folder.
4. If you selected a file, skip to the next step.
If you selected a folder, press the left/right arrow until the file you want
appears.
5. Press the left/right arrow to select the number of copies to be printed or
enter the number.
6. Press OK,Color Start or Black Start to start printing the selected file.
There are two types of mode as following.
•OK or Color Start: Color print
•Black Start: Black and White print
After printing the file, the display asks if you want to print another job.
7. Press OK when Yes appears to print another job, and repeat from step
2.
Otherwise, press the left/right arrow to select No and press OK.
8. Press Stop/Clear to return to ready mode.
BACKING UP DATA
Data in the machine’s memory can be accidentally erased due to power
failure or storage failure. Backup helps you protect the system settings by
storing them as backup files on a USB memory device.
Backing up data
1. Insert the USB memory device into the USB memory port on your
machine.
2. Press Menu on the control panel.
3. Press the left/right arrow until System Setup appears and press OK.
4. Press OK when Machine Setup appears.
5. Press the left/right arrow until Export Setting appears and press OK.
6. Press the left/right arrow until the option you want appears.
For CLX-3185N, Setup Data option is only available.
For CLX-3185FN/3185FW, Setup Data and Address Book options are
available.
7. Press OK to begin backing up the data.
The data is backed up to the USB memory.
Press Stop/Clear to return to ready mode.
Restoring data
1. Insert the USB memory device on which the backup data is stored in to
the USB memory port.
2. Press Menu on the control panel.
3. Press the left/right arrow until System Setup appears and press OK.
4. Press OK when Machine Setup appears.
5. Press the left/right arrow until Import Setting appears and press OK.
6. Press the left/right arrow until the data type you want appears and press
OK.
Using USB memory device (CLX-3185N/CLX-3185FN/CLX-3185WK/CLX-3185FW only)_ 102
For CLX-3185N, Setup Data option is only available.
For CLX-3185FN/3185FW, Setup Data and Address Book options are
available.
7. Press the left/right arrow until the file containing the data you want to
restore appears and press OK.
8. Press OK when Yes appears to restore the backup file to the machine.
9. Press Stop/Clear to return to ready mode.
MANAGING USB MEMORY
You can delete image files stored on a USB memory device one by one or
all at once by reformatting the device.
After deleting files or reformatting a USB memory device, files cannot
be restored. Therefore, confirm that you no longer need the data
before deleting it.
Deleting an image file
1. Insert the USB memory device into the USB memory port on your
machine.
2. Press Direct USB.
3. Press the left/right arrow until File Manage appears and press OK.
4. Press OK when Delete appears.
5. Press the left/right arrow until the folder or file you want to delete
appears and press OK.
If you see [D] in the front of a folder name, there are one or more
files or folders in the selected folder.
If you selected a file, the display shows the size of the file for about
2 seconds. Go to the next step.
If you selected a folder, press the left/right arrow until the file you want to
delete appears and press OK.
6. Press OK when Yes appears to confirm your selection.
7. Press Stop/Clear to return to ready mode.
Formatting a USB memory device
1. Insert the USB memory device into the USB memory port on your
machine.
2. Press Direct USB.
3. Press the left/right arrow until File Manage appears and press OK.
4. Press the left/right arrow until Format appears and press OK.
5. Press OK when Yes appears to confirm your selection.
6. Press Stop/Clear to return to ready mode.
Viewing the USB memory status
You can check the amount of memory space available for scanning and
saving documents.
1. Insert the USB memory device into the USB memory port on your
machine.
2. Press Direct USB.
3. Press the left/right arrow until Check Space appears and press OK.
4. The available memory space appears on the display.
Press Stop/Clear to return to ready mode.
PRINTING DIRECTLY FROM A DIGITAL CAMERA
This machine supports the PictBridge feature. You can print images directly
from any PictBridge-compatible device such as a digital camera, camera
phone and camcorder. You do not need to connect it to a computer.
1. Turn on the machine.
2. Connect your PictBridge-compatible device to the memory port on the
front of the machine using the USB cable supplied with the device.
3. Send an order to print images from the PictBridge-compatible device.
•Detailed information on how to print an image from a camera with
PictBridge feature, refer to the manual provided with your camera.
•Index printing is not support.
•Date or file name printing is not supported.
Machine status and advanced feature_ 103
12.machine status and advanced feature
This chapter explains how to browse the current status of your machine, and the method of setting for the advanced
machine setup. Read this chapter carefully in order to use your machine's diverse features.
This chapter includes:
•Fax setup (CLX-3185FN/CLX-3185FW only)
•Copy setup
•Printing a report
•Clearing memory
•Network (CLX-3185N/CLX-3185FN/CLX-3185FW only)
•Menu overview
Some menus may not appear on the display depending on options or
models. If so, it is not applicable to your machine.
FAX SETUP (CLX-3185FN/CLX-3185FW ONLY)
Changing the fax setup options
Your machine provides you with various user-selectable options for setting
up the fax system. You can change the default settings for your preferences
and needs.
To change the fax setup options:
1. Press (Fax) on the control panel.
2. Press Menu on the control panel.
3. Press the left/right arrow until Fax Setup appears and press OK.
4. Press the left/right arrow until the fax setup item you want appears and
press OK.
5. Press the left/right arrow until the option you want appears and press
OK.
6. Press the left/right arrow until the desired status appears or enter the
value for the option you have selected, and press OK.
7. Repeat steps 4 through 6 if necessary.
8. Press Stop/Clear to return to ready mode.
Sending Receiving
OPTION DESCRIPTION
Redial Times You can specify the number of redial attempts. If
you enter 0, the machine will not redial.
Redial Term Your machine can automatically redial a remote
fax machine if it was busy. You can set an
interval between attempts.
Prefix Dial You can set a prefix of up to five digits. This
number dials before any automatic dial number
is started. It is useful for accessing a PABX
exchange.
ECM Mode This mode helps with poor line quality and
makes sure any faxes you send are sent
smoothly to any other ECM-equipped fax
machine. Sending a fax using ECM may take
more time.
Send Report You can set your machine to print a confirmation
report showing whether a transmission was
successful, how many pages were sent, and
more. The available options are On,Off, and
On-Error, which prints only when a transmission
is not successful.
Image TCR This function allows users to know what fax
messages have been sent by showing sent
messages in the transmission report.
The first page of the message is turned into an
image file that is printed on the transmission
report so the users can see what messages
have been sent.
However, you can not use this function when
sending fax without saving the data in the
memory.
OPTION DESCRIPTION
Receive Mode You can select the default fax receiving mode.
For details on receiving faxes in each mode, see
"Changing the receive modes" on page 95.
Ring To Answer You can specify the number of times the
machine rings before answering an incoming
call.
Stamp RCV Name This option allows the machine to automatically
print the page number, and the date and time of
reception at the bottom of each page of a
received fax.
RCV Start Code This code allows you to initiate fax reception
from an extension phone plugged into the EXT
socket on the back of the machine. If you pick up
the extension phone and hear fax tones, enter
the code. It is preset to *9* at the factory.
OPTION DESCRIPTION
Machine status and advanced feature_ 104
Change Default
Auto Report
You can set the machine to print a report with detailed information about the
previous 50 communication operations including time and dates.
For further details, see "Printing sent fax report automatically" on page 99.
COPY SETUP
Changing the copy setup options
For copy output, you can set up several options in advance.
1. Depending on the model, the operating procedure may differ.
•For CLX-3185 and CLX-3185N, press Menu on the control panel.
•For CLX-3185FN and CLX-3185FW, press (Copy) and Menu in
order on the control panel.
2. Press the left/right arrow until Copy Setup appears and press OK.
3. Press the left/right arrow until Change Default appears and press OK.
4. Press the left/right arrow until the copy setup item you want appears and
press OK.
Auto Reduction When receiving a fax containing pages as long
as or longer than the paper loaded in the paper
tray, the machine can reduce the size of the
original to fit the size of the paper loaded in the
machine.
Turn on this feature if you want to automatically
reduce an incoming page.
With this feature set to Off, the machine cannot
reduce the original to fit onto one page. The
original will be divided and printed in actual size
on two or more pages.
Discard Size When receiving a fax containing pages as long
as or longer than the paper in your machine, you
can set the machine to discard a specific length
from the end of the received fax. The machine
will print the received fax on one or more sheets
of paper, minus the data that would have been
on the specified discard segment.
When the received fax contains pages larger
than the paper in your machine, and Auto
Reduction has been turned on, the machine will
reduce the fax to fit on the existing paper, and
nothing will be discarded.
Junk Fax Setup This setting may not be available depending on
your country. Using this feature, the system will
not accept faxes sent from remote stations
whose numbers are stored in the memory as
junk fax numbers. This feature is useful for
blocking any unwanted faxes.
When you turn on this feature, you can access
the following options to set junk fax numbers.
•Add: Allows you to set up to 10 fax numbers.
•Delete: Allows you to delete the desired junk
fax number. If you select Delete All, Allows
you to delete all junk fax numbers.
DRPD Mode This mode enables a user to use a single
telephone line to answer several different
telephone numbers. In this menu, you can set
the machine to recognize which ring patterns to
answer. For details about this feature, see
"Receiving faxes using DRPD mode" on
page 95.
OPTION DESCRIPTION
OPTION DESCRIPTION
Resolution Changing the resolution setting affects the
appearance of the received document.
•Standard: Originals with normal sized
characters.
•Fine: Originals containing small characters
or thin lines or originals printed using a
dot-matrix printer.
•Super Fine: Originals containing extremely
fine detail. Super Fine mode is enabled only
if the machine with which you are
communicating also supports the Super
Fine resolution.
•For memory transmission, Super
Fine mode is not available. The
resolution setting is automatically
changed to Fine.
•When your machine is set to Super
Fine resolution and the fax
machine with which you are
communicating does not support
Super Fine resolution, the machine
transmits using the highest
resolution mode supported by the
other fax machine.
•Photo Fax: Originals containing shades of
gray or photographs.
•Color Fax: Originals with colors. Sending a
color fax is enabled only if the machine with
which you are communicating supports color
fax reception and you send the fax manually.
In this mode, memory transmission is not
available.
Darkness You can select the default contrast mode to fax
your originals lighter or darker.
Machine status and advanced feature_ 105
5. Press the left/right arrow until the setup option you want appears and
press OK.
6. Press the left/right arrow until the setting you want appears and press
OK.
7. Repeat steps 4 through 6, as needed.
8. Press Stop/Clear to return to ready mode.
Change Default
PRINTING A REPORT
You can print a report on the machine's configuration or font list, etc.
1. Press Menu on the control panel.
2. Press the left/right arrow until System Setup appears and press OK.
3. Press the left/right arrow until Report appears and press OK.
4. Press the left/right arrow until the report or list you want to print appears
and press OK.
To print all reports and lists, select All Report.
5. Press OK when Yes appears to confirm printing.
The selected information prints out.
You can also print the machine's status information and browse status
with SyncThru™ Web Service. Open the Web browser on your
network-connected computer and type the IP address of your
machine. When SyncThru™ Web Service opens, click Information >
Print information.
CLEARING MEMORY
You can selectively clear information stored in your machine’s memory.
1. Press Menu on the control panel.
2. Press the left/right arrow until System Setup appears and press OK.
3. Press the left/right arrow until Clear Setting appears and press OK.
4. Press the left/right arrow until the item you want to clear appears and
press OK.
5. Press OK when Yes appears to confirm clearing.
6. Repeat steps 4 through 5 to clear another item.
7. Press Stop/Clear to return to ready mode.
Some menus may not appear on the display depending on options or
models. If so, it is not applicable to your machine.
OPTION DESCRIPTION
Copies You can enter the number of copies using the
number keypad.
Copy Collation You can set the machine to sort the copy job.
For further details, see "Deciding the form of
copy output" on page 81.
Reduce/Enlarge You can reduce or enlarge the size of a copied
image.
Darkness You can adjust the brightness level to make a
copy that is easier to read, when the original
contains faint markings and dark images.
Original Type You can improve the copy quality by selecting
the document type for the current copy job.
Eco Copy You can cut toner consumption and paper usage
by using this option.
OPTION DESCRIPTION
All Report You can print reports and lists about all options.
Configuration This list shows the status of the user-selectable
options. You may print this list to confirm your
changes after changing settings.
Supplies Info This list shows the current status of
consumables in your machine.
Address Book This list shows all of the fax numbers currently
stored in the machine’s memory.
Send Report This report shows the fax number, the number of
pages, the elapsed time of the job, the
communication mode, and the communication
results for a particular fax job.
You can set up your machine to automatically
print a transmission confirmation report after
each fax job (See "Sending" on page 103).
Sent Report This report shows information on the faxes you
have recently sent.
You can set the machine to automatically print
this report every 50 communications (See
"Sending" on page 103).
Fax RCV Report This report shows information on the faxes you
have recently received.
Schedule Jobs This list shows the documents currently stored
for delayed faxes along with the starting time
and type of each operation.
Junk Fax Report This list shows the fax numbers specified as junk
fax numbers. To add or delete numbers to or
from this list, access the Junk Fax Setup menu
(See "Receiving" on page 103).
Network Info. This list shows information on your machine’s
network connection and configuration.
User Auth List This list shows authorized users, who are
allowed to use the email function.
PCL Font List This list shows all the PCL fonts currently
available to your machine.
Fax Option This list shows the status of the user-selectable
options for fax. You may print this list to confirm
your changes after changing fax settings.
OPTION DESCRIPTION
All settings Clears all of the data stored in memory and
resets all of your settings to the factory default.
Fax Setup Restores all of the fax options to the factory
default.
Copy Setup Restores all of the copy options to the factory
default.
OPTION DESCRIPTION
Machine status and advanced feature_ 106
NETWORK
(CLX-3185N/CLX-3185FN/CLX-3185FW ONLY)
You may set up the network with the machine's display screen. Before doing
that, you must have the relevant information concerning the type of network
protocols and computer system you use. If you are not sure which setting to
use, contact your network administrator to configure this machine to the
network.
1. Press Menu on the control panel.
2. Press the left/right arrow until Network appears and press OK.
3. Press the left/right arrow until the setup option you want appears and
press OK.
4. Press the left/right arrow until the setting you want appears and press
OK.
5. Repeat steps 3 through 4, as needed.
6. Press Stop/Clear to return to ready mode.
MENU OVERVIEW
The control panel provides access to various menus to set up the machine
or use the machine’s functions. These menus can be accessed by pressing
Menu.
Some menus may not appear on the display depending on options or
models. If so, it is not applicable to your machine.
Scan Setup Restores all of the scan options to the factory
default.
System Setup Restores all of the system options to the factory
default.
Network Setup Restores all of the network options to the factory
default.
Address Book Clears all of the fax numbers entries stored in
memory.
Sent Report Clears all records of sent faxes.
Fax RCV Report Clears all records of received faxes.
OPTION DESCRIPTION
TCP/IP Select appropriate protocol and configure
parameters to use the network environment.
There are lots of parameters to be set. If
you are not sure, leave as is, or consult the
network administrator.
TCP/IP (IPv6) Selects this option to use the network
environment through IPv6 (See "IPv6
Configuration" on page 49).
Ethernet Speed Configure the network transmission speed.
Wireless Selects this option to use the wireless network
(See "Wireless network setup
(CLX-3185FW/CLX-3185WK only)" on page 50).
Clear Setting Reverts the network settings to the default
values.
Network Info. This list shows information on your machine’s
network connection and configuration.
OPTION DESCRIPTION
ITEMS OPTION
Fax FeaturebDarkness
Resolution
Multi Send
Delay Send
Priority Send
Forward
Secure Receive
Add Page
Cancel Job
Fax SetupbSending
Redial Times
Redial Term
Prefix Dial
ECM Mode
Send Report
Image TCR
Receiving
Receive Mode
Ring To Answer
Stamp RCV Name
RCV Start Code
Auto Reduction
Discard Size
Junk Fax Setup
DRPD Mode
Change Default
Resolution
Darkness
Auto Report
Copy Feature Reduce/Enlarge
Darkness
Original Type
Layout
Adjust Bkgd.
Gray Enhance
Eco Copy
Copy Setup Change Default
Copies
Copy Collation
Reduce/Enlarge
Darkness
Original Type
Eco Copya
Machine status and advanced feature_ 107
System Setup Machine Setup
Machine ID
Machine Fax Nob
Date & Timeb
Clock Modeb
Language
Default Mode
Power Save
Timeout
Altitude Adj.
Auto Continue
Import Setting
Export Setting
Paper Setup
Paper Size
Paper Type
Sound/Volume
Key Sound
Alarm Sound
Speakerb
Ringerb
Report
All Report
Configuration
Supplies Info
Address Bookb
Send Reportb
Sent Reportb
Fax RCV Reportb
Schedule Jobsb
Junk Fax Reportb
Network Info.c
User Auth Listc
PCL Font List
Fax Optionb
Maintenance
Supplies Life
Color
Serial Number
Clear Setting
All Settings
Fax Setupb
Copy Setup
Scan Setup
System Setup
Network Setupc
Address Bookb
Sent Reportb
Fax RCV Reportb
ITEMS OPTION
NetworkcTCP/IP
DHCP
BOOTP
Static
TCP/IP (IPv6)
IPv6 Activate
DHCPv6 Config
Ethernet Speed
Auto
10M Half
10M Full
100M Half
100M Full
Wirelessd
WLAN Setting
WLAN Default
WLAN Signal
Clear Setting
Network Info.
a. CLX-3185/CLX-3185N/CLX-3185FN only
b. CLX-3185FN/CLX-3185FW only
c. CLX-3185N/CLX-3185FN/CLX-3185FW only
d. CLX-3185WK/CLX-3185FW only
ITEMS OPTION
Management tools_ 108
13.management tools
This chapter introduces management tools provided to help you make full use of your machine.
This chapter includes:
•Introducing useful management tools
•Using SyncThru™ Web Service
(CLX-3185N/CLX-3185FN/CLX-3185FW only)
•Using the Smart Panel program
•SmarThru
•Using the Linux Unified Driver Configurator
Supported optional devices and features may differ according to your
model. Check your model name.
(See "Features by Models" on page 28).
INTRODUCING USEFUL MANAGEMENT TOOLS
The programs below help you to use your machine conveniently.
•"Using SyncThru™ Web Service
(CLX-3185N/CLX-3185FN/CLX-3185FW only)" on page 108.
•"Using the Smart Panel program" on page 109.
•"SmarThru" on page 110.
•"Using the Linux Unified Driver Configurator" on page 111.
USING SYNCTHRU™ WEB SERVICE
(CLX-3185N/CLX-3185FN/CLX-3185FW ONLY)
Internet Explorer 6.0 or higher is the minimum requirement for
SyncThru™ Web Service.
If you have connected your machine to a network and set up TCP/IP
network parameters correctly, you can manage the machine via SyncThru™
Web Service, an embedded web server. Use SyncThru™ Web Service to:
•View the machine’s device information and check its current status.
•Change TCP/IP parameters and set up other network parameters.
•Change printer preference.
•Set the email notifications advising of the machine’s status.
•Get support for using the machine.
To access SyncThru™ Web Service
1. Access a web browser, such as Internet Explorer, from Windows.
Enter the machine IP address (http://xxx.xxx.xxx.xxx) in the address
field and press the Enter key or click Go.
2. Your machine’s embedded website opens.
Logging into SyncThru™ Web Service
Before configuring options in SyncThru™ Web Service, you need to
log-in as an administrator. You can still use SyncThru™ Web Service
without logging in but you won’t have access to Settings tab and
Security tab.
1. Click Login on the upper right of the SyncThru™ Web Service
website.
A log-in page appears.
2. Type in the ID and Password then click Login.
If it’s your first time logging into SyncThru™ Web Service, type in the
below default ID and password.
•ID: admin
•Password: sec00000
SyncThru™ Web Service overview
Some tabs may not appear depending on your model.
Information tab
This tab gives you general information about your machine. You can
check things, such as remaining amount of toner. You can also print
reports such as an error report and so on.
•Active Alerts: This item allows you to check the alerts occurred in
the machine and their severity.
•Supplies: This item allows you to check how many pages are
printed and amount of toner left in the cartridge.
•Usage Counters: This item allows you to check the usage count by
print types: simplex, duplexU
•Current Settings: This item allows you to check the machine and
network information.
•Print information: This item allows you to print reports such as
system related reports, e-mail address and font reports.
Settings tab
This tab allows you to set configurations provided by your machine and
network. You need to log-in as an administrator to view this tab.
•Machine Settings tab: This tab allows you to set options provided
by your machine.
-System: You can set settings related to your machine.
-Printer: You can set settings related to printing jobs.
-E-mail Notification: You can set e-mail notificationGfeature and
e-mail address of recipients who will receive the notification.
•Network Settings tab: This tab allows you to view and change the
network environment. You can set things, such as TCP/IP, network
protocols and so on.
-SNMP: You can exchange of management information between
network devices using SNMPU
-Outgoing Mail Server(SMTP): You can set the outgoing e-mailG
serverU
-Restore Default: You can restore default network settings.
Security tab
This tab allows you to set system and network security information. You
need to log-in as an administrator to view this tab.
•System Security: You can set the systemGadministrator’s
information and also enable or disable machine featuresU
Management tools_ 109
•Network Security: You can set settings for HTTPs, IPSec,
IPv4/IPv6 filtering, 802.1x, Authentication serversU
Maintenance tab
This tab allows you to maintain your machine by upgrading firmware and
setting contact information for sending emails. You can also connect to
Samsung website or download drivers by selecting the Link menu.
•Firmware Upgrade: You can upgrade your machine’s firmware.
•Contact Information: You can view the contact information.
•Link: You can view the links to useful sites where you can download
or check information.
E-mail notification setup
You can receive emails about your machine’s status by setting this option.
By setting information such as IP address, host name, e-mail address and
SMTP server information, the machine status (toner cartridge shortage or
machine error) will be sent to a certain person's e-mail automatically. This
option may be used more frequently by a machine administrator.
1. Start a web browser, such as Internet Explorer, from Windows.
Enter the machine IP address (http://xxx.xxx.xxx.xxx) in the address
field and press the Enter key or click Go.
2. Your machine’s embedded website opens.
3. From the Settings tab, select Machine Settings > E-mail Notification.
If you haven’t configured outgoing server environment, go to
Settings > Network Settings > Outgoing Mail Server(SMTP) to
configure network environment before setting e-mail notification.
4. Select Enable check box to use the E-mail Notification.
5. Click Add button to add e-mail notification user.
Set the recipient name and e-mail address(es) with notification items
you want to receive an alert for.
6. Click Apply.
If the firewall is activated, the e-mail may not be sent successfully. In
that case, contact the a network administrator.
Setting the system administrator information
Set the system administrator information. This setting is necessary for using
the e-mail notification option.
1. Start a web browser, such as Internet Explorer, from Windows.
Enter the machine IP address (http://xxx.xxx.xxx.xxx) in the address
field and press the Enter key or click Go.
2. Your machine’s embedded website opens.
3. From the Security tab, select System Security > System
Administrator
4. Enter the name of the administrator, phone number, location and E-mail
address.
5. Click Apply.
USING THE SMART PANEL PROGRAM
The Smart Panel is a program that monitors and informs you of the machine
status, and allows you to customize the machine’s settings. For Windows
and Macintosh, Smart Panel is installed automatically when you install the
machine software. For Linux, you can download Smart Panel from the
Samsung website and install (See "Installing the SmartPanel" on page 42).
To use this program, your computer has to meet the following system
requirements:
•Windows. Check that your computer’s CPU, RAM and HDD meet
or exceed specification (See "System requirements" on page 39).
•Mac OS X 10.3 or higher. Check that your computer’s CPU, RAM
and HDD meet or exceed specification (See "System
requirements" on page 39).
•Linux. Check that your computer’s CPU, RAM and HDD meet or
exceed specification (See "System requirements" on page 39).
•Internet Explorer version 5.0 or higher for flash animation in HTML
Help.
If you need to know the exact model name of your machine, you can
check the supplied software CD.
Understanding Smart Panel
If an error occurs while operating, you can check the error from the Smart
Panel.
You can also launch Smart Panel manually. Double-click the Smart Panel
icon on the Windows task bar (in Windows), or Notification Area (in Linux).
You can also click it on the status bar (in Mac OS X).
Or, if you are a Windows user, you can launch it from the Start menu, select
Programs or All Programs > Samsung Printers > your printer driver
name > Smart Panel.
•If you have already installed more than one Samsung machine,
first select the correct machine model you want in order to access
the corresponding Smart Panel.
Right-click (in Windows or Linux) or click (in Mac OS X) the Smart
Panel icon and select your machine.
•The Smart Panel window and its contents shown in this user’s
guide may differ depending on the machine or operating system in
use.
The Smart Panel program displays the current status of the machine, the
estimated level of toner remaining in each toner cartridge, and various other
types of information. You can also change settings.
Windows Double-click this icon in Windows.
Macintosh Click this icon in Mac OS X.
Linux Click this icon in Linux.
1
Toner Level You can view the level of toner remaining in each
toner cartridge. The machine and the number of
toner cartridge(s) shown in the above window may
differ depending on the machine in use. Some
machines do not have this feature.
2Buy Now You can order replacement toner cartridge(s) from
online.
1
2
3
4
5
Management tools_ 110
Changing the Smart Panel Program Settings
Right-click (in Windows or Linux) or click (in Mac OS X) the Smart Panel
icon and select Options. Select the settings you want from the Options
window.
SMARTHRU
The supplied software CD provides you withGSmarThru. SmarThruGoffers
you convenient features to use with your machine.
Starting SmarThru
Follow the steps below to start SmarThru.
1. Make sure that your machine and computer are turned on and properly
connected to each other.
2. Once you have installed SmarThru, you will see the SmarThru icon on
your desktop.
3. Double-click the SmarThru icon.
4. The SmarThru appears.
•Scan to: Allows you to scan an image and save it to an application
or folder, email it, or publish it on a website.
•Image: Allows you to edit an image you have saved as a graphic file
and send it to a selected application or folder, email it, or publish it on
a website.
•Print: Allows you to print images you have saved. You can print
images in black and white or color mode if your machine supports it.
For more information about SmarThru, click at the top right corner
of the window. The SmarThru help window appears; you can view on
screen help supplied on the SmarThru program.
Follow the steps below to uninstall SmarThru. Before you begin the
uninstall, ensure that all applications are closed on your computer.
a) From the Start menu, select ProgramsGor All Programs.
b) Select Samsung Printers > SmarThru 4 > Uninstall SmarThru
4.
c) When your computer asks you to confirm your selection, read the
statement and click OK.
d) Click Finish.
Using SmarThru
Scanning
1. Click Scan To.
•Application: Scanning an image and placing it in an image editor
application such as Paint or Adobe Photoshop.
•E-mail: Scanning an image and emailing it. Allows you to scan
an image, preview it, and email it.
To send an image by e-mail, you must have a mail client
program, like Outlook Express, which has been set up with
your e-mail account.
•Folder: Scanning an image and saving it to a folder. Allows you
to scan an image, preview it, and save it to the folder of your
choice.
•OCR: Scanning an image and performing text recognition. Allows
you to scan an image, preview it, and send it to the OCR program
for text recognition.
-Recommended scan option for OCR.
-Resolution: 200 or 300 dpi.
-Image type: grayscale or black & white.
•Web: Scanning an image, previewing it, and publishing it on a
website, using the specified file format for the image you want to
publish.
•Settings: Customizing settings of Scan To basic functions.
Allows you to customize settings for Application,E-mail,OCR,
and Web functions.
2. Set scan settings and click Scan.
3
User’s Guide You can view the online User’s Guide.
This button changes to Troubleshooting
Guide when error occurs. You can directly
open the troubleshooting sectionGin the
user’s guide.
4
Printer
Setting
You can configure various machine settings in the
Printer Settings Utility window. Some machines do
not have this feature.
If you connect your machine to a network,
the SyncThru™ Web Service window
appears instead of the Printer Settings Utility
window.
5
Driver Setting You can set all of the machine options you need in
the Printing Preferences window. This feature is
available only for Windows (See "Opening printing
preferences" on page 72).
Management tools_ 111
Printing
1. Click Print.
2. Select the file you want to print.
3. Select the machine you want to use for printing.
4. Click Print to start the job.
USING THE LINUX UNIFIED DRIVER
CONFIGURATOR
The Unified Driver Configurator is a tool primarily intended for configuring
machine devices. You need to install Unified Linux Driver to use Unified
Driver Configurator (See "Installing the Unified Linux Driver" on page 42).
After the driver is installed on your Linux system, the Unified Driver
Configurator icon will automatically be created on your desktopU
Opening the Unified Driver Configurator
1. Double-click the Unified Driver Configurator on the desktop.
You can also click the Startup Menu icon and select Samsung Unified
Driver > Unified Driver Configurator.
2. Click each button on the left to switch to the corresponding configuration
window.
To use the on screen help, click Help.
3. After changing the configurations, click Exit to close the Unified Driver
Configurator.
Printers configuration window
Printers configuration has the two tabs: Printers and Classes.
Printers tab
View the current system’s printer configuration by clicking on the
machine icon button on the left side of the Unified Driver Configurator
window.
The printer control buttons are as follows:
•Refresh: Renews the available machines list.
•Add Printer: Allows you to add a new machines.
•Remove Printer: Removes the selected machine.
•Set as Default: Sets the current selected machine as a default
machine.
•Stop/Start: Stops/starts the machine.
•Test: Allows you to print a test page to ensure the machine is
working properly.
•Properties: Allows you to view and change the printer properties.
1Printers
Configuration
2Scanners
Configuration
3Ports
Configuration
1Switches to Printers configuration.
2Shows all of the installed machine.
3Shows the status, model name and URL of your machine.
Management tools_ 112
Classes tab
The Classes tab shows a list of available machine classes.
•Refresh: Renews the classes list.
•Add Class: Allows you to add a new machine class.
•Remove Class: Removes the selected machine class.
Scanners configuration
In this window, you can monitor the activity of scanner devices, view a list of
installed Samsung machine devices, change device properties, and scan
images.
•Properties: Allows you to change the scan properties and scan a
document.
Ports configuration
In this window, you can view the list of available ports, check the status of
each port, and release a port that is stalled in a busy state when its owner
has terminated the job for any reason.
•Refresh: Renews the available ports list.
•Release port: Releases the selected port.
Sharing Ports Between Printers and Scanners
Your machine may be connected to a host computer via a parallel port
or USB port. Since the machine device contains more than one device
(printer and scanner), it is necessary to organize proper access of
“consumer” applications to these devices via the single I/O port.
The Unified Linux Driver package provides an appropriate port sharing
mechanism that is used by Samsung printer and scanner drivers. The
drivers talk to their devices via so-called machine ports. The current
status of any machine port can be viewed via the Ports configuration.
The port sharing prevents you from accessing one functional block of
the machine device, while another block is in use.
When you install a new machine device onto your system, it is strongly
recommended you do this with the assistance of an Unified Driver
Configurator. In this case you will be asked to choose I/O port for the
new device. This choice will provide the most suitable configuration for
machine’s functionality. For machine scanners, I/O ports are being
chosen by scanner drivers automatically, so proper settings are applied
by default.
1Shows all of the machine classes.
2Shows the status of the class and the number of machines in the
class.
1Switches to Scanners configuration.
2Shows all of the installed scanners.
3Shows the vendor, model name and type of your scanner.
1Switches to Ports configuration.
2Shows all of the available ports.
3Shows the port type, device connected to the port, and status.
Maintenance_ 113
14.maintenance
This chapter provides information about maintaining your machine and the toner cartridge.
This chapter includes:
•Printing a machine report
•Adjusting the color contrast
•Finding the serial number
•Cleaning the machine
•Storing the toner cartridge
•Maintenance parts
•Tips for moving & storing your machine
PRINTING A MACHINE REPORT
You can print the machine's information and job report.
1. Press Menu on the control panel.
2. Press the left/right arrow until System Setup appears and press OK.
3. Press the left/right arrow until Report appears and press OK.
4. Press the left/right arrow until the report or list you want to print
appears.press OK.
To print all reports and lists, select All Report.
5. Press the left/right arrow to appears Yes at the Print? prompt and press
OK.
ADJUSTING THE COLOR CONTRAST
Color menu allows you to adjust the color setting.
1. Press Menu on the control panel.
2. Press the left/right arrow until System Setup appears and press OK.
3. Press the left/right arrow until Maintenance appears and press OK.
4. Press the left/right arrow until Color appears and press OK.
5. Press the left/right arrow until Custom Color appears and press OK.
6. Press the left/right arrow until the color menu you want to appears on
display and press OK.
You can adjust the contrast of each color independently. Default
optimizes the color contrast automatically. Manual Adjust allows
you to manually adjust the color contrast for each cartridge.
Default setting is recommended for getting best color quality.
7. Press Stop/Clear to return to ready mode.
If you have moved the machine, it is strongly recommended to operate
this menu manually.
FINDING THE SERIAL NUMBER
When you call for service or register as a user on the Samsung website, the
machine’s serial number by taking the following steps.
1. Press Menu on the control panel.
2. Press the left/right arrow until System Setup appears and press OK.
3. Press the left/right arrow until Maintenance appears and press OK.
4. Press the left/right arrow until Serial Number appears and press OK.
5. Check your machine’s serial number.
6. Press Stop/Clear to return to ready mode.
CLEANING THE MACHINE
If printing quality problems occur or if you use your machine in a dusty
environment, you need to clean your machine regularly to keep the most
optimum print quality.
•Cleaning the cabinet of the machine with cleaning materials
containing large amounts of alcohol, solvent or other strong
substances can discolor or distort the cabinet.
•If your machine or the surrounding area is contaminated with
toner, we recommend that you use a cloth or tissue dampened
with water to clean it. If you use a vacuum cleaner, toner blows in
the air and might be harmful if inhaled.
Cleaning the outside
Clean the machine cabinet with a soft and lint-free cloth. Dampen the cloth
slightly with water, but be careful not to let any water drip onto or into the
machine.
Cleaning the inside
During the printing process, paper, toner and dust particles can accumulate
inside the machine. This buildup can cause print quality problems such as
toner specks or smearing. Cleaning the inside of the machine clears and
reduces these problems.
1. Turn the machine off and unplug the power cord. Wait for the machine to
cool down.
2. Using the handle, completely open the front door.
Maintenance_ 114
3. Grasp the handles on the toner cartridge and pull to remove four
cartridges from the machine.
4. Pull the waste toner container out of the machine using the handle.
5. Pull the imaging unit out of the machine using the groove on the front of
the imaging unit.
Do not touch the green surface of the drum located in the imaging
unit. Use the handle on the cartridge to avoid touching this area.
6. With a dry and lint-free cloth, wipe away any dust and spilled toner from
the toner cartridges area and their cavities.
•If toner gets on your clothing, wipe it off with a dry cloth and
wash it in cold water. Hot water sets toner into fabric.
•If your machine or its surrounding is contaminated with toner,
we recommend you use a cloth or tissue dampened with water
to clean. If you use a vacuum cleaner, toner blows into the air
then might be harmful if inhaled.
After cleaning, let the machine to dry completely.
7. Holding the groove on the front of the imaging unit, push imaging unit
into the machine.
Do not touch the green surface of the drum located in the imaging
unit. Use the handle on the cartridge to avoid touching this area.
8. Insert the waste toner container into position and then push it to make
sure that it is firmly seated in place.
Maintenance_ 115
9. Slide four toner cartridges back into the machine.
10. Reinstall all the compartments into the machine and close the front door.
If the front door is not completely closed, the machine will not
operate.
11. Plug in the power cord and turn the machine on.
Cleaning the scan unit
Keeping the scan unit clean helps ensure the best possible copies. We
suggest that you clean the scan unit at the start of each day and during the
day as needed.
The procedure may differ depending on your model. Check your
model name.
The following procedure is for CLX-3185 and CLX3185N.
1. Slightly dampen a soft, lint-free cloth or paper towel with water.
2. Open the scanner lid.
3. Wipe the surface of the scanner glass until it is clean and dry.
4. Wipe the underside of the scanner lid and white sheet until it is clean
and dry.
5. Close the scanner lid.
The following procedure is for CLX-3185FN and CLX-3185FW.
1. Slightly dampen a soft, lint-free cloth or paper towel with water.
2. Open the scanner lid.
3. Wipe the surface of the scanner glass until it is clean and dry.
4. Wipe the underside of the scanner lid and white sheet until it is clean
and dry.
5. Push the ADF sheet with any tool such as tweezers carefully.
6. Hold the edge of the ADF sheet and wipe both sides of the ADF sheet
until it is clean and dry.
1Scanner lid
2Scanner glass
3ADF sheet
4White sheet
4
31
2
Maintenance_ 116
7. Push the ADF sheet back into the machine smoothly.
8. Close the scanner lid.
STORING THE TONER CARTRIDGE
Toner cartridges contain components that are sensitive to light, temperature
and humidity. Samsung suggests users follow the recommendations to
ensure the optimum performance, highest quality and longest life from your
new Samsung toner cartridge.
Store this cartridge in the same environment in which the printer will be
used. This should be in controlled office temperature and humidity
conditions. The toner cartridge should remain in its original and unopened
package until installation – If original packaging is not available, cover the
top opening of the cartridge with paper and store in a dark cabinet.
Opening the cartridge package prior to use dramatically shortens its useful
shelf and operating life. Do not store on the floor. If the toner cartridge is
removed from the printer, follow the instruction below to store the toner
cartridge properly.
•Store the cartridge inside the protective bag from the original package.
•Store lying flat (not standing on end) with the same side facing up as if it
was installed in the machine.
•Do not store consumable in any of the following conditions:
-Temperature greater than 40°C (104°F).
-Humidity range less than 20% and not greater than 80%.
-An environment with extreme changes in humidity or temperature.
-Direct sunlight or room light.
-Dusty places.
-A car for a long period of time.
-An environment where corrosive gases are present.
-An environment with salty air.
Handling instructions
•Do not touch the surface of the photoconductive drum in the cartridge.
•Do not expose the cartridge to unnecessary vibrations or shock.
•Never manually rotate the drum, especially in the reverse direction; this
can cause internal damage and toner spillage.
Use of non-Samsung and refilled toner cartridge
Samsung Electronics does not recommend or approve the use of
non-Samsung brand toner cartridges in your printer including generic, store
brand, refilled or remanufactured toner cartridges.
Samsung’s printer warranty does not cover damage to the machine
caused by the use of a refilled, remanufactured or non-Samsung
brand toner cartridge.
Estimated cartridge life
Estimated cartridge life (the life of the toner cartridge yield) depends on the
amount of toner that print jobs require. The actual print yield may vary
depending on the print density of the pages you print on, operating
environment, printing interval, media type and/or media size. For example, if
you print a lot of graphics, the consumption of the toner is high and you may
need to change the cartridge more often.
MAINTENANCE PARTS
To avoid print quality and paper feed problems resulting from worn parts,
and to maintain your machine in top working condition, the following items
will need to be replaced after the specified number of pages, or when the life
span of each item has expired.
We highly recommend that this maintenance be performed by an authorized
service provider, dealer or the retailer where you bought the machine. The
warranty does not cover the replacement of the maintenance parts after
their lifespan.
The battery inside the machine is a service component. Do not
change it by yourself.
There is risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to your local environmental
guidelines. Don’t puncture or incinerate the battery.
Checking replacables
If you experience frequent paper jams or printing problems, check the
number of pages the machine has printed or scanned. Replace the
corresponding parts, if necessary.
1. Press Menu on the control panel.
2. Press the left/right arrow until System Setup appears and press OK.
3. Press the left/right arrow until Maintenance appears and press OK.
4. Press the left/right arrow until Supplies Life appears and press OK.
5. Press the left/right arrow until the item you want appears and press OK.
•Supplies Info: Prints the supply information page.
•Total: Displays the total number of pages printed.
•ADF Scan: Displays the number of pages printed by using the ADF.
•Platen Scan: Displays the number of pages scanned by using
scanner glass.
•Imaging Unit,Transfer Belt,Fuser,Transfer Roller,Tray1 Roller:
Displays the number of pages printed by each item.
6. If you selected to print a supply information page, press OK to confirm.
ITEMS YIELD (AVERAGE)
Fuser unit Approx. 50,000 black pages or 12,500 color pages
Transfer roller Approx. 50,000 black pages or 12,500 color pages
Transfer unit (ITB) Approx. 50,000 black pages or 12,500 color pages
Pick-up roller Approx. 50,000 pages
Maintenance_ 117
7. Press Stop/Clear to return to ready mode.
TIPS FOR MOVING & STORING YOUR MACHINE
•When moving the machine, do not tilt or turn it upside down. Otherwise,
the inside of the machine may be contaminated by toner, which can
cause damage to the machine or reduce print quality.
•When moving the machine, make sure at least two people are holding
the machine securely.
Troubleshooting_ 118
15.troubleshooting
This chapter gives helpful information for what to do if you encounter an error.
This chapter includes:
•Redistributing toner
•Tips for avoiding paper jams
•Clearing original document jams (CLX-3185FN/CLX-3185FW only)
•Clearing paper jams
•Understanding display messages
•Solving other problems
REDISTRIBUTING TONER
When the toner cartridge is near the end of its life,
•White streaks or light printing occurs.
•Prepare new toner appears on the display.
•The Status LED blinks red.
If this happens, you can temporarily improve print quality by redistributing
the remaining toner in the cartridge. In some cases, white streaks or light
printing will still occur even after you have redistributed the toner.
1. Using the handle, completely open the front door.
2. Grasp the handles on the toner cartridge and pull to remove the
cartridge from the machine.
3. Thoroughly roll the cartridge five or six times to distribute the toner
evenly inside the cartridge.
If toner gets on your clothing, wipe it off with a dry cloth and wash
clothing in cold water. Hot water sets toner into fabric.
Do not touch the green underside of the toner cartridge. Use the
handle on the cartridge to avoid touching this area.
4. Make sure that the color of the toner cartridge matches the color slot and
then grasp the handles on the toner cartridge. Insert the cartridge until it
clicks into place.
5. Close the front door. Make sure the door is securely latched.
If the front door is not completely closed, the machine will not operate.
TIPS FOR AVOIDING PAPER JAMS
By selecting the correct media types, most paper jams can be avoided.
When a paper jam occurs, refer to the guidelines below: (See "Clearing
paper jams" on page 119).
•Ensure that the adjustable guides are positioned correctly (See "Loading
Troubleshooting_ 119
paper in the tray" on page 68).
•Do not overload the tray. Ensure that the paper level is below the paper
capacity mark on the inside of the tray.
•Do not remove paper from the tray while your machine is printing.
•Flex, fan, and straighten paper before loading.
•Do not use creased, damp, or highly curled paper.
•Do not mix paper types in a tray.
•Use only recommended print media (See "Setting the paper size and
type" on page 70).
•Ensure that the recommended side of the print media is facing up in the
tray.
CLEARING ORIGINAL DOCUMENT JAMS
(CLX-3185FN/CLX-3185FW ONLY)
When an original document jams in the document feeder, a warning
message appears on the display.
To avoid tearing the document, remove the jammed document slowly
and carefully.
To prevent document jams, use the scanner glass for thick, thin or
mixed paper-type originals.
1. Remove any remaining pages from the document feeder.
2. Open the document feeder cover.
3. Gently remove the jammed paper from the document feeder.
If you see no paper in this area, go to step 5.
4. Close the document feeder cover. Reload the pages you removed, if
any, in the document feeder.
5. Open the scanner lid.
6. Seize the misfeed paper, and remove the paper from the feed area by
carefully pulling it to the right using both hands.
7. Close the scanner lid. Load the removed pages back into the document
feeder.
CLEARING PAPER JAMS
When a paper jam occurs, the warning message appears on the display
screen. Refer to the table below to locate and clear the paper jam.
1scanner lid
MESSAGE LOCATION OF JAM GO TO
Paper jam
in Tray 1
In the paper feed area
and inside the machine
See "In the tray" on
page 120.
Paper jam
inside machine
Inside the machine See "In the fuser unit
area" on page 120.
Paper jam
in exit area
Inside the machine and in
the paper exit area
See "In the paper exit
area" on page 121.
1
Troubleshooting_ 120
Some messages may not appear on the display depending on options
or models.
To avoid tearing the paper, pull the jammed paper out slowly and
carefully. Follow the instructions in the following sections to clear the
jam.
In the tray
Click this link to open an animation about clearing a jam.
1. Open and close the front door. The jammed paper is automatically
ejected from the machine.
If the paper does not eject, go to the next step.
2. Pull out tray 1 out of the machine.
3. Remove the jammed paper by gently pulling it straight out.
If the paper does not eject when you pull, or if you do not see the paper
in this area, check the fuser area around the toner cartridge (See "In the
fuser unit area" on page 120).
4. Insert the tray 1 back into the machine until it snaps into place. Printing
automatically resumes.
In the fuser unit area
Click this link to open an animation about clearing a jam.
If paper is jammed in the fuser unit area, follow the next steps to release the
jammed paper.
1. Open the scan unit first and then inner cover.
Do not touch the fuser inside the inner cover. It is hot and could cause
burns! Take care when removing paper from the machine.
1. Holding the inner cover open, carefully take the jammed paper out of the
machine. The inner cover will then close automatically. Lower down the
scan unit gently until it is completely closed. Make sure that it is securely
latched. Printing automatically resumes.
Be careful not to pinch your fingers!
If you do not see the paper, lower down the scan unit gently until it is
completely closed. Go to the next step.
2. To remove the jammed paper, open the rear door.
1
2
Troubleshooting_ 121
3. Carefully remove the paper by pulling in the direction as shown below.
Most of the jammed paper can be removed in this step.
4. Close the rear door. Printing automatically resumes.
In the paper exit area
Click this link to open an animation about clearing a jam.
1. Open and close the front door. The jammed paper is automatically
ejected from the machine.
2. Gently pull the paper out the output tray.
If you do not see the jammed paper or if there is any resistance when
you pull, stop and go to the next step.
3. Open the rear door.
4. If you see the jammed paper, pull it straight up. Skip to step 10.
If you do not see the paper or if there is any resistance when you pull,
stop and go to the next step.
5. Pull up the fuser lever.
The fuser area is hot. Take care when removing paper from the
machine.
6. Open the scan unit first and then inner cover.
1
2
Troubleshooting_ 122
7. Carefully take the jammed paper out of the machine.
8. Lower down the scan unit gently and slowly until it completely closed.
Make sure that it is securely latched.
Be careful no to pinch your fingers!
9. Pull down the fuser lever.
10. Close the rear door. Printing automatically resumes.
UNDERSTANDING DISPLAY MESSAGES
Messages appear on the control panel display to indicate the machine’s
status or errors. Refer to the tables below to understand the messages’ and
their meaning, and correct the problem, if necessary.
Checking display messages
•If a message is not in the table, reboot the power and try the
printing job again. If the problem persists, call a service
representative.
•When you call for service, provide the service representative with
the contents of display message.
•Some messages may not appear on the display depending on the
options or models.
•[error number] indicates the error number.
•[tray type] indicates the tray number.
•[media type] indicates the media type.
•[media size] indicates the media size.
•[color] indicates the color of toner or imaging unit.
MESSAGE MEANING SUGGESTED
SOLUTIONS
[COMM. Error] The machine has a
communication
problem.
Ask the sender to try
again.
[Incompatible] The machine has
received a fax from
which is registered as
a junk fax.
The received fax data
will be deleted.
Reconfirm junk fax setup
(See "Changing the fax
setup options" on
page 103).
[Line Busy] The receiving fax
machine did not
answer or the line is
already engaged.
Try again after a few
minutes.
[Line Error] Your machine cannot
connect with the
receiving fax machine
or has lost contact
because of a problem
with the phone line.
Try again. If the problem
persists, wait an hour or
so for the line to clear
and try again. Or, Turn
the ECM mode on (See
"Fax setup
(CLX-3185FN/CLX-3185
FW only)" on page 103).
BOOTP problem
Auto IP Run
The IP address
assignment is failed.
This happens when
Auto IP for BOOTP is
set in SyncThru Web
Service.
Change the IP address
assignment method to
DHCP or Static. If you do
not change this option,
the BOOTP server
continually asks to
assign the IP address.
BOOTP problem
Reconfigure DHCP
The IP address
assignment is failed.
This happens when
Auto IP for BOOTP is
not set in SyncThru
Web Service.
Change the IP address
assignment method to
DHCP or Static. If you do
not change this option,
the BOOTP server
continually asks to
assign the IP address.
Troubleshooting_ 123
DHCP problem:
Auto IP Run
The IP address
assignment is failed.
This happens when
Auto IP for DHCP is
set in SyncThru Web
Service.
Change the IP address
assignment method to
BOOTP or Static. If you
do not change this
option, the DHCP server
continually asks to
assign the IP address.
DHCP problem
Reconfigure
BOOTP
The IP address
assignment is failed.
This happens when
Auto IP for DHCP is
not set SyncThru Web
Service.
Change the IP address
assignment method to
BOOTP or Static. If you
do not change this
option, the DHCP server
continually asks to
assign the IP address.
Document Jam.
Remove Jam
The loaded original
document has
jammed in the ADF.
Clear the jam (See
"Clearing original
document jams
(CLX-3185FN/CLX-3185
FW only)" on page 119).
Door Open
Close it
The front door is not
securely latched.
Close the door until it
locks into place.
Error [error number]
Call for service
A system error has
occurred.
Turn the power button off
and on. If the problem
persists, call a service
representative.
Error [error number]
Turn off then on
A system error has
occurred.
Turn the power button off
and on. If the problem
persists, call a service
representative.
Install Toner
ź
The toner cartridge is
installed improperly or
not installed.
Reinstall the toner
cartridge two or three
times to confirm it is
seated properly. If the
problem persists, the
toner cartridge is not
being detected. Contact
the service
representatives.
Memory Full
Remove Job
The memory is full. Press the left/right arrow
to highlight Cancel or
Start, then press OK. If
you select Cancel, the
machine stops the fax
job. If you select Start,
the machine only sends
scanned documents of
the fax job.
Network Problem:
IP Conflict
The IP address is
used elsewhere.
Check the IP address or
obtain a new IP address.
No Answer The receiving fax
machine has not
answered after
several redial
attempts.
Try again. Make sure
that the receiving
machine is operational.
MESSAGE MEANING SUGGESTED
SOLUTIONS
Not Compatible
[color] toner
The toner cartridge is
not suitable for your
machine.
Install the corresponding
toner cartridge with a
Samsung-genuine
cartridge (See
"Replacing the toner
cartridge" on page 136).
Not installed
Waste tank
The waste toner
container is not
installed.
Install the waste toner
container.
Not original
[color] toner
The toner cartridge is
not a
Samsung-genuine
toner cartridge.
Install the corresponding
toner cartridge with a
Samsung-genuine
cartridge (See
"Replacing the toner
cartridge" on page 136).
Output bin full
Remove media
The output tray is full.
Or the sensor is not
facing down.
Remove papers from the
output tray, the machine
resumes printing. Or
make sure the sensor is
facing down. If the
problem persists, call a
service representative.
Paper Empty
in Tray1
There is no paper in
tray 1.
Load paper in tray 1 (See
"Loading paper in the
tray" on page 68).
Paper jam
in exit area
Paper has jammed in
the paper exit area.
Clear the jam (See "In
the paper exit area" on
page 121).
Paper jam
in Tray 1
Paper has jammed in
the Tray 1 area.
Clear the jam (See "In
the tray" on page 120).
Paper jam
inside machine
Paper has jammed
inside the machine.
Clear the jam (See "In
the fuser unit area" on
page 120).
Prepare IMG unit
ź
The estimated life of
imaging unit is close.
Prepare a imaging unit
for replacement (See
"Available supplies" on
page 135).
Prepare new
Transfer belt
The estimated life of
transfer unit (ITB) is
close.
The estimated life of a
transfer unit (ITB) is
close (See "Available
maintenance parts" on
page 135).
Remove seal tape
& Install Toner
The machine cannot
detect a toner
cartridge.
Remove the sealing tape
from the toner cartridge.
Refer to the Quick
Installation Guide.
Replace new
Transfer belt
The transfer unit (ITB)
has almost reached its
estimated life.
Prepare the transfer unit
(ITB) with a new one
(See "Available
maintenance parts" on
page 135).
MESSAGE MEANING SUGGESTED
SOLUTIONS
Troubleshooting_ 124
Replace new
Transfer roller
The transfer roller has
almost reached its
estimated life.
Replace the transfer
roller with a new one
(See "Available
maintenance parts" on
page 135).
Prepare toner
ź
Small amount of toner
is left in the indicated
cartridge. The
estimated cartridge
life of toner is close.
Prepare a new cartridge
for a replacement. You
may temporarily increase
the printing quality by
redistributing the toner
(See "Redistributing
toner" on page 118).
Replace
Fuser soon
The estimated life of
fuser unit is close.
Prepare a fuser unit for
replacement (See
"Available maintenance
parts" on page 135).
MESSAGE MEANING SUGGESTED
SOLUTIONS
Replace Toner
ź
The indicated toner
cartridge has almost
reached its estimated
cartridge life. The
machine might stop
printing.
Estimated
cartridge life
means the
expected or
estimated toner
cartridge life,
which indicates
the average
capacity of
print-outs and is
designed
pursuant to
ISO/IEC 19798.
•If Stop,Continue or
Mono Only appears
in the LCD display,
choose one of them. If
you select Stop, the
machine stops printing
and you cannot print
anymore without
changing the
cartridge. If you select
Continue, the
machine keeps
printing but the
printing quality cannot
be guaranteed. If you
select Mono Only, the
machine prints the
data in black only.
Replace the toner
cartridge for the best
print quality when this
message appears.
Using a cartridge
beyond this stage can
result in printing
quality issues (See
"Replacing the toner
cartridge" on
page 136).
Samsung does not
recommend using
non-genuine
Samsung toner
cartridge such as
refilled or
remanufactured.
Samsung cannot
guarantee
non-genuine
Samsung toner
cartridge's quality.
Service or repair
required as a result
of using
non-genuine
Samsung toner
cartridges will not be
covered under the
machine warranty.
•If the machine stops
printing, replace the
toner cartridge (See
"Replacing the toner
cartridge" on
page 136).
MESSAGE MEANING SUGGESTED
SOLUTIONS
Troubleshooting_ 125
SOLVING OTHER PROBLEMS
The following chart lists some trouble conditions that may occur and the
recommended solutions. Follow the suggested solutions until the problem is
corrected. If the problem persists, contact a service representative.
Other problems include:
•See "System problems" on page 125.
•See "Power problems" on page 125.
•See "Paper feeding problems" on page 126.
•See "Printing problems" on page 127.
•See "Printing quality problems" on page 128.
•See "Common Windows problems" on page 132.
•See "Common Linux problems" on page 133.
•See "Common Macintosh problems" on page 134.
System problems
Power problems
Click this link to open an animation about solving power problems.
Replace new
Fuser unit
The fuser unit has
almost reached its
estimated life.
Replace the fuser unit
with a new one (See
"Available maintenance
parts" on page 135).
Replace IMG unit
ź
The imaging unit has
almost reached its
estimated life.
Replace the imaging unit
with a new one (See
"Replacing the imaging
unit" on page 137).
Self Diagnostics
Please wait
The engine in your
printer is checking
some problems
detected.
Please wait a few
minutes.
Toner Supply Err.
ź
The machine cannot
detect a toner
cartridge.
Remove the toner
hopper sheet from the
toner cartridge (See
"Replacing the toner
cartridge" on page 136).
Too many Faxes
Remove Job
Too many faxes are
received.
Remove received faxes.
MESSAGE MEANING SUGGESTED
SOLUTIONS
CONDITION SUGGESTED SOLUTIONS
The red error light is
on.
Turn the machine on/off. If the problem persists,
contact a service representative (See "Contact
SAMSUNG worldwide" on page 143”).
The machine is experiencing problems that
require service such as LSU error or fuser
error.
Troubleshooting_ 126
Paper feeding problems
CONDITION SUGGESTED SOLUTIONS
The machine is
not receiving
power,
or the connection
cable between the
computer and the
machine is not
connected
properly.
•Plug in the power cord and press (power) on
the control panel.
•Disconnect the machine cable and reconnect it.
-For Local Printing
-For Network Printing
(CLX-3185N/CLX-3185FN/CLX-3185FW
only)
CONDITION SUGGESTED SOLUTIONS
Paper jams during
printing.
Clear the paper jam (See "Clearing paper jams"
on page 119).
Paper sticks
together.
•Ensure there is not too much paper in the
tray. The tray can hold up to 130 sheets of
paper, depending on the thickness of your
paper.
•Make sure that you are using the correct type
of paper (See "Setting the paper size and
type" on page 70).
•Remove paper from the tray and flex or fan
the paper.
•Humid conditions may cause some paper to
stick together, replace with a new stack.
Multiple sheets of
paper do not feed.
Different types of paper may be stacked in the
tray. Load paper of only one type, size and
weight.
Paper does not feed
into the machine.
•Remove any obstructions from inside the
machine.
•Paper has not been loaded correctly. Remove
paper from the tray and reload it correctly.
•There is too much paper in the tray. Remove
excess paper from the tray.
•The paper is too thick. Use only paper that
meets the specifications required by the
machine (See "Selecting print media" on
page 66).
The paper keeps
jamming.
•There is too much paper in the tray. Remove
excess paper from the tray.
•An incorrect type of paper is being used. Use
only paper that meets the specifications
required by the machine (See "Selecting print
media" on page 66).
•There may be debris inside the machine.
Open the front door and remove any debris.
Envelopes skew or
fail to feed correctly.
Ensure that the paper guides are against both
sides of the envelopes.
CONDITION SUGGESTED SOLUTIONS
Troubleshooting_ 127
Printing problems
CONDITION POSSIBLE
CAUSE SUGGESTED SOLUTIONS
The machine
does not print.
The machine is not
receiving power.
Check the power cord
connections. Check the
power switch and the power
source.
The machine is not
selected as the
default machine.
Select your machine as your
default machine in your
Windows.
Check the machine for the following.
•The front door or rear door is not closed. Close
the door.
•Paper is jammed. Clear the paper jam (See
"Clearing paper jams" on page 119).
•No paper is loaded. Load paper (See "Loading
paper in the tray" on page 68).
•The toner cartridge is not installed. Install the
toner cartridge.
If a system error occurs, contact a service
representative.
The connection
cable between the
computer and the
machine is not
connected properly.
Disconnect the machine
cable and reconnect it.
The connection
cable between the
computer and the
machine is
defective.
If possible, attach the cable to
another computer that is
working properly and print a
job. You can also try using a
different machine cable.
The port setting is
incorrect.
Check the Windows printer
setting to make sure that the
print job is sent to the correct
port. If the computer has
more than one port, make
sure that the machine is
attached to the correct one.
The machine may
be configured
incorrectly.
Check the Printing
Preferences to ensure that
all of the print settings are
correct (See "Opening
printing preferences" on
page 72).
The printer driver
may be incorrectly
installed.
Repair the machine software
(See "Installing USB
connected machine’s driver"
on page 40).
The machine is
malfunctioning.
Check the display message
on the control panel to see if
the machine is indicating a
system error. If the error
cannot be cleared, contact a
service representative.
The machine
does not print.
The document size
is so big that the
hard disk space of
the computer is not
enough to access
the print job.
Allocate more hard disk
space on your computer for
spooling, and try printing.
The machine
selects print
materials from
the wrong paper
source.
The paper source
selection in the
printer properties
may be incorrect.
For many software
applications, the paper
source selection is found
under the Paper tab within
the printer properties. Select
the correct paper source. See
the printer driver help screen.
A print job is
extremely slow.
The job may be very
complex.
Reduce the complexity of the
page or try adjusting the print
quality settings.
Half the page is
blank.
The page
orientation setting
may be incorrect.
Change the page orientation
in your application. See the
printer driver help screen.
The paper size and
the paper size
settings do not
match.
Ensure that the paper size in
the printer driver settings
matches the paper in the tray.
Or, ensure that the paper size
in the printer driver settings
matches the paper selection
in the software application
settings you use.
The machine
prints, but the
text is wrong,
garbled or
incomplete.
The machine cable
is loose or
defective.
Disconnect the machine
cable and reconnect. Try a
print job that you have
already printed successfully.
If possible, attach the cable
and the machine to another
computer and try a print job
that you know works. Finally,
try a new printer cable.
The wrong printer
driver was selected.
Check the application’s
printer selection menu to
ensure that your machine is
selected.
The software
application is
malfunctioning.
Try printing a job from
another application.
The operating
system is
malfunctioning.
Exit Windows and reboot the
computer. Turn the machine
off and back on again.
CONDITION POSSIBLE
CAUSE SUGGESTED SOLUTIONS
Troubleshooting_ 128
Printing quality problems
If the inside of the machine is dirty or paper has been loaded improperly,
you may notice a reduction in print quality. See the table below to clear the
problem.
Pages print, but
they are blank.
The toner cartridge
is defective or out of
toner.
Redistribute the toner, if
necessary (See
"Redistributing toner" on
page 118).
If necessary, replace the
toner cartridge (See
"Replacing the toner
cartridge" on page 136).
The file may have
blank pages.
Check the file to ensure that it
does not contain blank
pages.
Some parts such as
the controller or the
board may be
defective.
Contact a service
representative.
The machine
does not print
PDF file
correctly. Some
graphics, text or
illustrations are
missing.
Incompatibility
between the PDF
file and the Acrobat
products
Printing the PDF file as an
image may solve this
problem. Turn on Print As
Image from the Acrobat
printing options.
It will take longer to
print when you print a
PDF file as an image.
The print quality
of photos is not
good. Images
are not clear.
The resolution of
the photo is very
low.
Reduce the photo size. If you
increase the photo size in the
software application, the
resolution will be reduced.
Before printing,
the machine
emits vapor near
the output tray.
Using damp paper
can cause vapor
during printing.
This is not a problem. Just
keep printing.
The printed
billing paper is
curled.
The paper type
setting does not
match.
Change the printer option and
try again. Go to Printing
Preferences, click Paper
tab, and set type to Thick
(See "Opening printing
preferences" on page 72).
CONDITION POSSIBLE
CAUSE SUGGESTED SOLUTIONS CONDITION SUGGESTED SOLUTIONS
Light or faded print If a vertical white streak or faded area appears on
the page:
•The toner supply is low. You may be able to
temporarily extend the toner cartridge life (See
"Redistributing toner" on page 118). If this
does not improve the print quality, install a
new toner cartridge.
•The paper may not meet paper specification;
for example, the paper may be too moist or
rough (See "Selecting print media" on
page 66).
•If the entire page is light, the print resolution
setting is too low or the toner save mode is on.
Adjust the print resolution and turn the toner
save mode off. See the help screen of the
printer driver.
•A combination of faded or smeared defects
may indicate that the toner cartridge needs
cleaning.
•The surface of the LSU part inside the
machine may be dirty. Clean the LSU, contact
a service representative.
Toner specks •The paper may not meet specification, for
example, the paper may be too moist or rough
(See "Selecting print media" on page 66).
•The paper path may need cleaning (See
"Cleaning the inside" on page 113).
Dropouts If faded areas, generally rounded, occur randomly
on the page:
•A single sheet of paper may be defective. Try
reprinting the job.
•The moisture content of the paper is uneven
or the paper has moist spots on its surface.
Try a different brand of paper (See "Selecting
print media" on page 66).
•The paper lot is bad. The manufacturing
processes can cause some areas to reject
toner. Try a different kind or brand of paper.
•Change the printer option and try again. Go to
Printing Preferences, click Paper tab, and
set type to Thick (See "Opening printing
preferences" on page 72).
If these steps do not correct the problem, contact
a service representative.
Troubleshooting_ 129
White Spots If white spots appear on the page:
•The paper is too rough and a lot of dirt from a
paper falls to the inner devices within the
machine, which means the transfer belt may
be dirty. Clean the inside of your machine.
Contact a service representative.
•The paper path may need cleaning. Contact a
service representative.
Vertical lines If black vertical streaks appear on the page:
•The drum inside the toner cartridge has
probably been scratched. Remove the toner
cartridge and install a new one (See
"Replacing the toner cartridge" on page 136).
If white vertical streaks appear on the page:
•The surface of the LSU part inside the
machine may be dirty. Clean the LSU, contact
a service representative.
Black background If the amount of background shading becomes
unacceptable:
•Change to a lighter weight paper (See
"Selecting print media" on page 66).
•Check the environmental conditions: very dry
(low humidity) or high humidity (higher than
80% RH) conditions can increase the amount
of background shading.
•Remove the old toner cartridge and, install a
new one (See "Replacing the toner cartridge"
on page 136).
Toner smear •Clean the inside of the machine (See "Cleaning
the inside" on page 113).
•Check the paper type and quality (See
"Selecting print media" on page 66).
•Remove the toner cartridge and then, install a
new one (See "Replacing the toner cartridge"
on page 136).
Vertical repetitive
defects
If marks repeatedly appear on the printed side of
the page at even intervals:
•The toner cartridge may be damaged. If a
repetitive mark occurs on the page, print a
cleaning sheet several times to clean the
cartridge. After the printout, if you still have the
same problems, remove the toner cartridge
and install a new one (See "Replacing the
toner cartridge" on page 136).
•Parts of the machine may have toner on them.
If the defects occur on the back of the page,
the problem will likely correct itself after a few
more pages.
•The fusing assembly may be damaged.
Contact a service representative.
CONDITION SUGGESTED SOLUTIONS
Background
scatter
Background scatter results from bits of toner
randomly distributed on the printed page.
•The paper may be too damp. Try printing with
a fresh ream of paper. Do not open packages
of paper until necessary so that the paper
does not absorb too much moisture.
•If background scatter occurs on an envelope,
change the printing layout to avoid printing
over areas that have overlapping seams on
the reverse side. Printing on seams can cause
problems.
•If background scatter covers the entire surface
area of a printed page, adjust the print
resolution through your software application or
the printer properties.
Misformed
characters
•If characters are improperly formed and
producing hollow images, the paper stock may
be too slick. Try different paper (See "Selecting
print media" on page 66).
•If characters are improperly formed and
producing a wavy effect, the scanner unit may
need service, For service, contact a service
representative.
Page skew •Ensure that the paper is loaded properly.
•Check the paper type and quality (See
"Selecting print media" on page 66).
•Ensure that the paper or other material is
loaded correctly and the guides are not too tight
or too loose against the paper stack.
Curl or wave •Ensure that the paper is loaded properly.
•Check the paper type and quality. Both high
temperature and humidity can cause paper curl
(See "Selecting print media" on page 66).
•Turn the stack of paper over in the tray. Also try
rotating the paper 180° in the tray.
CONDITION SUGGESTED SOLUTIONS
A
AaBb
C
AaBb
C
AaBb
C
AaBbC
AaBbC
c
Troubleshooting_ 130
Copying problems
Wrinkles or
creases
•Ensure that the paper is loaded properly.
•Check the paper type and quality (See
"Selecting print media" on page 66).
•Turn the stack of paper over in the tray. Also try
rotating the paper 180° in the tray.
Back of printouts
are dirty
Check for leaking toner. Clean the inside of the
machine (See "Cleaning the inside" on page 113).
Solid Color or
Black pages
•The toner cartridge may not be installed
properly. Remove the cartridge and reinsert it.
•The toner cartridge may be defective and need
replacing. Remove the toner cartridge and
install a new one (See "Replacing the toner
cartridge" on page 136).
•The machine may require repair. Contact a
service representative.
Loose toner •Clean the inside of the machine (See "Cleaning
the inside" on page 113).
•Check the paper type and quality (See
"Selecting print media" on page 66).
•Remove the toner cartridge and install a new
one (See "Replacing the toner cartridge" on
page 136).
•If the problem persists, the machine may
require repair. Contact a service
representative.
Character Voids Character voids are white areas within parts of
characters that should be solid black.
•If you are using transparencies, try another
type of transparency. Because of the
composition of transparencies, some
character voids are normal.
•You may be printing on the wrong surface of
the paper. Remove the paper and turn it over.
•The paper may not meet paper specifications
(See "Selecting print media" on page 66).
CONDITION SUGGESTED SOLUTIONS
A
A
Horizontal stripes If horizontally aligned black streaks or smears
appear:
•The toner cartridge may be installed
improperly. Remove the cartridge and reinsert
it.
•The toner cartridge may be defective. Remove
the toner cartridge and install a new one (See
"Replacing the toner cartridge" on page 136).
•If the problem persists, the machine may
require repair. Contact a service
representative.
Curl If the printed paper is curled or paper does not
feed into the machine:
•Turn over the stack of paper in the tray. Also
try rotating the paper 180° in the tray.
•Change the printer option and try again. Go to
printer properties, click Paper tab and set type
to Thin Paper (See "Opening printing
preferences" on page 72).
An unknown image
repetitively
appears on a few
sheets or loose
toner, light print, or
contamination
occurs.
Your machine is probably being used at an
altitude of 1,000 m (3,281 ft.) or above.
The high altitude may affect the print quality such
as loose toner or light imaging. You can select a
correct altitude of your machine location (See
"Altitude adjustment" on page 61).
CONDITION SUGGESTED SOLUTION
Copies are too light
or too dark.
Use Darkness in Copy feature to lighten or
darken the backgrounds of copies (See
"Changing the settings for each copy" on
page 79).
Smears, lines,
marks, or spots
appear on copies.
•If the defects are on the original, use
Darkness in Copy feature to lighten the
background of your copies (See "Changing
the settings for each copy" on page 79).
•If there are no defects on the original, clean
the scan unit (See "Cleaning the scan unit" on
page 115).
Copy image is
skewed.
•Ensure that the original is face down on the
scanner glass.
•Check that the copy paper is loaded correctly.
Blank copies print
out.
Ensure that the original is face down on the
scanner glass.
CONDITION SUGGESTED SOLUTIONS
AaBbC
AaBbC
AaBbC
AaBbC
AaBbC
Troubleshooting_ 131
Scanning problems
Fax problems
Image rubs off the
copy easily.
•Replace the paper in the tray with paper from
a new package.
•In high humidity areas, do not leave paper in
the machine for extended periods of time.
Frequent copy paper
jams occur.
•Fan the stack of paper, then turn it over in the
tray. Replace the paper in the tray with a fresh
supply. Check/adjust the paper guides, if
necessary.
•Ensure that the paper is the proper paper
weight.
•Check for copy paper or pieces of copy paper
remaining in the machine after a paper jam
has been cleared.
Toner cartridge
produces fewer
copies than
expected before
running out of toner.
•Your originals may contain pictures, solids, or
heavy lines. For example, your originals may
be forms, newsletters, books, or other
documents that use more toner.
•The scanner lid may be left open while copies
are being made.
•Turn the machine off and back on.
CONDITION SUGGESTED SOLUTIONS
The scanner does not
work.
•Make sure that you place the original to be
scanned face down on the scanner glass.
•There may not be enough available memory
to hold the document you want to scan. Try
the Prescan function to see if that works.
Try lowering the scan resolution rate.
•Check that the machine cable is connected
properly.
•Make sure that the machine cable is not
defective. Switch the cable with a known
good cable. If necessary, replace the cable.
•Check that the scanner is configured
correctly. Check scan setting in the
SmarThru or the application you want to use
to make certain that the scanner job is being
sent to the correct port (for example,
USB001).
The unit scans very
slowly.
•Check if the machine is printing received
data. If so, scan the document after the
received data has been printed.
•Graphics are scanned more slowly than text.
•Communication speed slows in scan mode
because of the large amount of memory
required to analyze and reproduce the
scanned image. Set your computer to the
ECP printer mode through BIOS setting. It
will help to increase the speed. For details
about how to set BIOS, refer to your
computer user’s guide.
CONDITION SUGGESTED SOLUTION
Message appears on
your computer
screen:
•Device can’t be
set to the H/W
mode you want.
•Port is being used
by another
program.
•Port is Disabled.
•Scanner is busy
receiving or
printing data.
When the current
job is completed,
try again.
•Invalid handle.
•Scanning has
failed.
•There may be a copying or printing job in
progress. Try your job again when that job is
finished.
•The selected port is currently being used.
Restart your computer and try again.
•The machine cable may be improperly
connected or the power may be off.
•The scanner driver is not installed or the
operating environment is not set up properly.
•Ensure that the machine is properly
connected and the power is on, then restart
your computer.
•The USB cable may be improperly
connected or the power may be off.
CONDITION SUGGESTED SOLUTIONS
The machine is not
working, there is no
display, or the
buttons are not
working.
•Unplug the power cord and plug it in again.
•Ensure that there is power being supplied to
the electrical outlet.
No dial tone. •Check that the phone line is properly
connected.
•Check that the phone socket on the wall is
working by plugging in another phone.
The numbers stored
in memory do not
dial correctly.
Make sure that the numbers are stored in
memory correctly. Print an Address Book list
(See "Setting up Address Book" on page 97).
The original does
not feed into the
machine.
•Make sure that the paper is not wrinkled and
you are inserting it in correctly. Check that the
original is the right size, not too thick or thin.
•Make sure that the document feeder is firmly
closed.
•The document feeder rubber pad may need to
be replaced. Contact a service
representative.
Faxes are not
received
automatically.
•The receiving mode should be set to fax.
•Make sure that there is paper in the tray.
•Check to see if the display shows any error
message. If it does, clear the problem.
The machine does
not send.
•Make sure that the original is loaded in the
document feeder or on the scanner glass.
•Check the fax machine you are sending to, to
see if it can receive your fax.
CONDITION SUGGESTED SOLUTIONS
Troubleshooting_ 132
Samsung Scan and Fax Manager Problem
Common Windows problems
Refer to the Microsoft Windows User’s Guide that came with your
computer for further information on Windows error messages.
The incoming fax
has blank spaces or
is of poor-quality.
•The fax machine sending you the fax may be
faulty.
•A noisy phone line can cause line errors.
•Check your machine by making a copy.
•A toner cartridge has reached its estimated
cartridge life. Replace the toner cartridge
(See "Replacing the toner cartridge" on
page 136).
Some of the words
on an incoming fax
are stretched.
The fax machine sending the fax had a
temporary document jam.
There are lines on
the originals you
sent.
Check your scan unit for marks and clean it (See
"Cleaning the scan unit" on page 115).
The machine dials a
number, but the
connection with the
other fax machine
fails.
The other fax machine may be turned off, out of
paper, or cannot answer incoming calls. Speak
with the other machine operator and ask her/him
to solve out the problem.
Faxes do not store in
memory.
There may not be enough memory space to
store the fax. If the display indicating the
memory status shows, delete any faxes you no
longer need from the memory, and then try to
store the fax again. Call a service
representative.
Blank areas appear
at the bottom of
each page or on
other pages, with a
small strip of text at
the top
You may have chosen the wrong paper settings
in the user option setting. For details about
paper settings, see "Setting the paper size and
type" on page 70.
CONDITION SUGGESTED SOLUTION
Samsung Scan and
Fax Manager does
not work.
Check your system requirements. Samsung
Scan and Fax Manager works in Windows and
Mac OS (See "System requirements" on
page 39).
CONDITION SUGGESTED SOLUTIONS
“File in Use”
message appears
during installation.
Exit all software applications. Remove all
software from the printer’s startup group, then
restart Windows. Reinstall the printer driver.
“General Protection
Fault”, “Exception
OE”, “Spool 32” or
“Illegal Operation”
messages appear.
Close all other applications, reboot Windows
and try printing again.
CONDITION SUGGESTED SOLUTIONS
“Fail To Print”, “A
printer timeout error
occurred” messages
appear.
These messages may appear during printing.
Just keep waiting until the machine finishes
printing. If the message appears in standby
mode or after printing has been completed,
check the connection and/or whether an error
has occurred.
CONDITION SUGGESTED SOLUTIONS
Troubleshooting_ 133
Common Linux problems
CONDITION SUGGESTED SOLUTIONS
The machine does
not print.
•Check if the printer driver is installed in your
system. Open Unified Driver Configurator and
switch to the Printers tab in Printers
configuration window to look at the list of
available machines. Make sure that your
machine is displayed on the list. If not, open
Add new printer wizard to set up your
device.
•Check if the machine is started. Open
Printers configuration and select your
machine on the printers list. Look at the
description in the Selected printer pane. If its
status contains Stopped string, press the
Start button. After that normal operation of
the machine should be restored. The
“stopped” status might be activated when
some problems in printing occurred. For
instance, this could be an attempt to print a
document when the port is claimed by a
scanning application.
•Ensure the port is not busy. Since functional
components of machine (printer and scanner)
share the same I/O interface (port), the
situation of simultaneous access of different
user applications to the same port is possible.
To avoid possible conflicts, only one of them
at a time is allowed to gain control over the
device. The other user will encounter “device
busy” response. You should open ports
configuration and select the port assigned to
your machine. In the Selected port pane you
can see if the port is occupied by some other
application. If this is the case, you should
either wait for completion of the current job or
press the Release port button, if you are sure
that the present application is not functioning
properly.
•Check if your application has special print
option such as “-oraw”. If “-oraw” is specified
in the command line parameter, then remove
it to print properly. For Gimp front-end, select
“print” -> “Setup printer” and edit command
line parameter in the command item.
•The CUPS (Common Unix Printing System)
version distributed with SuSE Linux 9.2
(cups-1.1.21) has a problem with ipp (Internet
Printing Protocol) printing.Use the socket
printing instead of ipp or install a later version
of CUPS (cups-1.1.22 or higher).
The machine does
not print whole
pages, and output is
printed on half the
page.
It is a known problem that occurs when a color
machine is used on version 8.51 or earlier of
Ghostscript, 64-bit Linux OS, and has been
reported to bugs.ghostscript.com as Ghostscript
Bug 688252.The problem is solved in AFPL
Ghostscript v. 8.52 or above. Download the
latest version of AFPL Ghostscript from
http://sourceforge.net/projects/ghostscript/ and
install it to solve this problem.
I cannot scan via
Gimp Front-end.
Check if Gimp Front-end has Xsane: Device
dialog on the Acquire menu. If not, you should
install Xsane plug-in for Gimp on the your
computer. You can find Xsane plug-in package
for Gimp on Linux distribution CD or Gimp home
page. For the detailed information, refer to the
Help for Linux distribution CD or Gimp Front-end
application.
If you wish to use another kind of scan
application, refer to application’s Help.
I encounter the
“Cannot open port
device file” error
when printing a
document.
Avoid changing print job parameters (via LPR
GUI, for example) while a print job is in progress.
Known versions of CUPS server break the print
job whenever print options are changed and
then try to restart the job from the beginning.
Since Unified Linux Driver locks the port while
printing, the abrupt termination of the driver
keeps the port locked and unavailable for
subsequent print jobs. If this situation occurs, try
to release the port by selecting Release port in
Port configuration window.
The machine does
not appear on the
scanners list.
•Ensure your machine is attached to your
computer, connected properly via the USB
port, and is turned on.
•Ensure the scanner driver for your machine is
installed in your system. Open Unified Linux
Driver configurator, switch to Scanners
configuration, then press Drivers. Make
sure that driver with a name corresponding to
your machine's name is listed in the window.
•Ensure the port is not busy. Since functional
components of machine (printer and scanner)
share the same I/O interface (port), the
situation of simultaneous access of different
user applications to the same port is possible.
To avoid possible conflicts, only one of them
at a time is allowed to gain control over the
device. The other user will encounter “device
busy” response. This usually happens when
starting a scan procedure. An appropriate
message box appears.
To identify the source of the problem, open
the Ports configuration and select the port
assigned to your scanner, port's symbol
/dev/mfp0 corresponds to LP:0 designation
displayed in the scanners’ options, /dev/mfp1
relates to LP:1, and so on. USB ports start at
/dev/mfp4, so scanner on USB:0 relates to
/dev/mfp4 respectively and so forth
sequentially. In the Selected port pane, you
can see if the port is occupied by another
application. If this is the case, you should
either wait for completion of the current job or
press the Release port button, if you are sure
that the present port application is not
functioning properly.
CONDITION SUGGESTED SOLUTIONS
Troubleshooting_ 134
Refer to the Linux User’s Guide that came with your computer for
further information on Linux error messages.
Common Macintosh problems
Refer to the Macintosh User’s Guide that came with your computer for
further information on Macintosh error messages.
The machine does
not scan.
•Ensure a document is loaded into the
machine, ensure your machine is connected
to the computer.
•If there is an I/O error while scanning.
CONDITION SUGGESTED SOLUTIONS
The machine does
not print PDF files
correctly. Some
parts of graphics,
text, or illustrations
are missing.
Printing the PDF file as an image may enable
the file to print. Turn on Print As Image from the
Acrobat printing options.
It will take longer to print when you print a
PDF file as an image.
The document has
printed, but the print
job has not
disappeared from
the spooler in Mac
OS X 10.3.2.
Update your Mac OS to Mac OS X 10.3.3. or
higher.
Some letters are not
displayed normally
during the cover
page printing.
Mac OS cannot create the font during the cover
page printing. The English alphabet and
numbers are displayed normally on the cover
page.
When printing a
document in Mac OS
with Acrobat
Reader 6.0 or higher,
colors print
incorrectly.
Make sure that the resolution setting in your
machine driver matches the one in Acrobat
Reader.
CONDITION SUGGESTED SOLUTIONS
Supplies and accessories_ 135
16.supplies and accessories
This chapter provides information about purchasing suppliesS accessories and maintenance parts available for your
machine.
This chapter includes:
•How to purchase
•Available supplies
•Available maintenance parts
•Checking replaceable’s lifespan
•Replacing the toner cartridge
•Replacing the imaging unit
•Replacing the waste toner container
•Illustrations on this user’s guide may differ from your machine
depending on its options or models. Check your model name.
•Available accessories may differ from country to country. Contact
your sales representativesGto obtain the list of available supplies
and maintenance parts.
HOW TO PURCHASE
To order Samsung-authorized suppliesS accessories and maintenance
parts, contact your local Samsung dealer or the retailer where you
purchased your machineUGYou can also visit www.samsung.com/supplies,
and then select your country/region to obtain the information on calling for
service.
AVAILABLE SUPPLIES
When supplies reach their lifespan, you can order the following types of
supplies for your machine.
When purchasing new toner cartridges or other supplies, these must
be purchased in the same country as the machine you are using.
Otherwise, new toner cartridges or other supplies will be incompatible
with your machine due to different configurations of toner cartridges
and other supplies according to the specific country conditions.
AVAILABLE MAINTENANCE PARTS
To avoid print quality and paper feed problems resulting from worn parts
and to maintain your machine in top working condition, the following parts
will need to be replaced after printing the specified number of pages or
when the life span of each item has expired.
To purchase maintenance parts, contact the source where you purchased
the machine.
Replacing maintenance parts can be performed only by an authorized
service provider, dealer or the retailer where you purchased the
machine. The warranty does not cover the replacement of any
maintenance parts after their lifespan.
TYPE AVERAGE YIELDa
a.Declared yield value in accordance with ISO/IEC 19798.
PART NAME
Standard yield
toner cartridge
•Average
continuous black
cartridge yield:
1,500 standard
pages (Black)
•Average
continuous black
cartridge yield:
1,000 standard
pages
(Yellow/Magenta/C
yan)
K407(CLT-K407S): Black
C407(CLT-C407S): Cyan
M407(CLT-M407S): Magenta
Y407(CLT-Y407S): Yellow
Region Ab
K4072(CLT-K4072S): Black
C4072(CLT-C4072S): Cyan
M4072(CLT-M4072S): Magenta
Y4072(CLT-Y4072S): Yellow
Region Bc
K4073(CLT-K4073S): Black
C4073(CLT-C4073S): Cyan
M4073(CLT-M4073S): Magenta
Y4073(CLT-Y4073S): Yellow
Imaging unit Approx. 24,000
imagesd
CLT-R407
Waste toner
container
Approx. 10,000
imagesd (Full color
5% image)
CLT-W409
b.Region A: Albania, Austria, Belgium, Bosnia, Bulgaria, Croatia, Cyprus,
Czech Republic, Denmark, Finland, France, Germany, Greece, Hungary,
Italy, Macedonia, Netherlands, Norway, Poland, Portugal, romania,
Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, UK.
c. Region B: China and India.
d.Image counts based on one color on each page. If you print documents
in full color (Cyan, Magenta, Yellow, Black), the life of this item will be
reduced by 25%.
ITEMS AVERAGE YIELDa
a.Yield is affected by operating system used, computing performance,
application software, connecting method, media type, media size and
job complexity.
Fuser unit Approx. 50,000 black pages or 12,500 color pages
Transfer roller Approx. 50,000 black pages or 12,500 color pages
Transfer unit (ITB) Approx. 50,000 black pages or 12,500 color pages
Pick-up roller Approx. 50,000 pages
Supplies and accessories_ 136
CHECKING REPLACEABLE’S LIFESPAN
If you experience frequent paper jams or printing problems, check the
number of pages the machine has printed. Replace the corresponding
parts, if necessary.
1. Press Menu on the control panel.
2. Press the left/right arrow until System Setup appears and press OK.
3. Press the left/right arrow until Maintenance appears and press OK.
4. Press the left/right arrow until Supplies Life appears and press OK.
5. Press the left/right arrow until the item you want appears and press OK.
•Supplies Info: Prints the supply information page.
•Total: Displays the total number of pages printed in color mode or
black and white mode.
•ADF Scan: Displays the number of pages scanned using the ADF.
•Platen Scan: Displays the number of pages scanned using the
scanner glass.
•Imaging Unit: Displays the number of pages scanned and printed.
•Transfer Belt: Displays the number of pages scanned and printed.
•Fuser: Displays the number of pages scanned and printed.
•Transfer Roller: Displays the number of pages scanned and printed.
•Tray 1 Roller: Displays the number of pages scanned and printed.
6. Press Stop/Clear to return to ready mode.
REPLACING THE TONER CARTRIDGE
The machine uses four colors and has a different toner cartridge for each
one: yellow (Y), magenta (M), cyan (C) and black (K).
The status LED and the toner-related message on the display indicate
which toner cartridge should be replaced.
At this stage, the indicated toner cartridge needs to be replaced. Before
replacing the toner cartridge, check the model number for the toner
cartridge used in your machine.
1. Turn the machine off, then wait a few minutes for the machine to cool.
2. Using the handle, completely open the front door.
3. Grasp the handles on the toner cartridge and pull to remove the
cartridge from the machine.
4. Take a new toner cartridge out of its package.
Don’t use sharp objects such as a knife or scissors to open the
toner cartridge package. You could damage the surface of the
toner cartridge.
5. Pull out the hopper sheet from a new toner cartridge.
6. Holding both handles on the toner cartridge, thoroughly rock it from side
to side to evenly distribute the toner.
7. Place the toner cartridge on a flat surface as shown below and remove
the protecting sheet.
Supplies and accessories_ 137
If toner gets on your clothing, wipe it off with a dry cloth and wash it
in cold water. Hot water sets toner into fabric.
8. Make sure that the color of the toner cartridge matches the color slot and
then grasp the handles on the toner cartridge. Insert the cartridge until it
clicks into place.
9. Close the front door. Make sure the door is securely latched and then
turn the machine on.
If the front door is not completely closed, the machine will not
operate.
REPLACING THE IMAGING UNIT
When the life span of the imaging unit has expired, the Smart Panel
program window appears on the computer, indicating the imaging unit
needs to be placed. Otherwise, your machine may stop printing.
1. If the machine is printing from the computer or warming up, wait until the
job ends. Then, turn the machine off.
2. Using the handle, completely open the front door.
3. Grasp the handles on the front cartridge and pull to remove four
cartridges from the machine.
4. Pull the waste toner container out of the machine using its handle.
5. Pull the imaging unit out of the machine using the groove on the front of
the imaging unit.
6. Take a new imaging unit out of its package. Remove the protective
devices on both sides of the imaging unit and the paper protecting the
surface of the imaging unit.
•Don’t use sharp objects such as a knife or scissors to open the
imaging unit package.
•Do not touch the drum located in the imaging unit. Use the
handle on the cartridge to avoid touching this area.
•Be careful not to scratch the surface of imaging unit.
•To prevent damage, do not expose the imaging unit to light for
more than a few minutes. Cover it with a piece of paper to
protect it if necessary.
Supplies and accessories_ 138
7. Holding the groove on the front of the imaging unit, push imaging unit in
to the machine.
8. Insert the waste toner container into position and then push it to make
sure that it is firmly seated in place.
9. Slide four toner cartridges back into the machine.
10. Close the front door firmly.
If the front door is not completely closed, the machine will not
operate. Please, make sure all toner cartridges are installed
properly. If any toner cartridge is installed improperly, the front
door do not close.
11. Turn the machine on.
It may takes few minutes for your machine to get ready.
REPLACING THE WASTE TONER CONTAINER
When the life span of the waste toner container has expired, the Smart
Panel program window appears on the computer, indicating the waste toner
container needs to be replaced. Otherwise your machine stops printing.
1. Turn the machine off, then wait a few minutes for the machine to cool.
2. Using the handle, completely open the front door.
3. Pull the waste toner container out of the machine using its handle.
Make sure that you lay the waste toner container on a flat surface
so that the toner does not spill.
4. Remove the container’s cap from the container as shown below and
then use it to close the waste toner container opening.
Do not tilt or turn over the container.
5. Take a new waste toner container out of its package.
2
1
Supplies and accessories_ 139
6. Insert the new container into position and then push it to make sure that
it is firmly seated in place.
7. Close the front door firmly.
If the front door is not completely closed, the machine will not
operate. Please, make sure all toner cartridges are installed
properly. If any toner cartridge is installed improperly, the front
door do not close.
8. Turn the machine on.
Specifications_ 140
17.specifications
This chapter covers the machine’s primary specifications.
This chapter includes:
•Hardware specifications
•Environmental specifications
•Electrical specifications
•Print media specifications
The specification values are listed below: specifications are subject to change without notice. See www.samsung.com/printer for possible changes in
information.
HARDWARE SPECIFICATIONS
ENVIRONMENTAL SPECIFICATIONS
ITEM DESCRIPTION
Dimensions Height •CLX-3185/CLX-3185N/CLX-3185WK: 308 mm (12.13 inches)
•CLX-3185FN/CLX-3185FW: 391.5 mm (15.41 inches)
Depth •CLX-3185/CLX-3185N/CLX-3185WK: 407.5 mm (16.04 inches)
•CLX-3185FN/CLX-3185FW: 407.5 mm (16.04 inches)
Width •CLX-3185/CLX-3185N/CLX-3185WK: 416 mm (16.38 inches)
•CLX-3185FN/CLX-3185FW: 416 mm (16.38 inches)
Weight Machine with consumables •CLX-3185/CLX-3185N/CLX-3185WK: 14.5 Kg (32.0 lbs)
•CLX-3185FN/CLX-3185FW: 15.4 Kg (34.0 lbs)
Package weight Paper •CLX-3185/CLX-3185N/CLX-3185WK: 1.85 Kg (4.08 lbs)
•CLX-3185FN/CLX-3185FW: 1.90 Kg (4.19 lbs)
Plastic •CLX-3185/CLX-3185N/CLX-3185WK: 0.36 Kg (0.79 lbs)
•CLX-3185FN/CLX-3185FW: 0.42 Kg (0.93 lbs)
ITEM DESCRIPTION
Noise LevelaPrinting mode Less than 46 dBA (Color printing)
Less than 48 dBA (Mono printing)
Copying mode •Mono copying
-ADF: 52 dBA
-Scan glass: 50 dBA
•Color copying
-ADF: 50 dBA
-Scan glass: 48 dBA
Standby mode Background noise Level
Sleep mode Background noise Level
Temperature Operation 10 to 32 °C (50 to 89.6 °F)
Storage (packed) -20 to 50 °C (-4 to 122 °F)
Specifications_ 141
ELECTRICAL SPECIFICATIONS
Power requirements are based on the country/region where the device is sold. Do not convert operating voltages. Doing so might damage the device and
void the product warranty.
Humidity Operation 20 to 80% RH
Storage (packed) 10 to 90% RH
a.Sound Pressure Level, ISO 7779. Configuration tested: machine basic installation, A4 paper, simplex printing.
ITEM DESCRIPTION
Power ratinga
a.See the rating label on the machine for the correct voltage (V), frequency (hertz) and type of current (A) for your machine.
110 volt models AC 110 - 127 V
220 volt models AC 220 - 240 V
Power consumption Average operating mode Less than 350 W
Ready mode Less than 60 W
Power save mode •CLX-3185/CLX-3185N: Less than 8 W
•CLX-3185WK/CLX-3185FN/CLX-3185FW: Less than 11 W
Power off mode Less than 0.45 W
ITEM DESCRIPTION
Specifications_ 142
PRINT MEDIA SPECIFICATIONS
TYPE SIZE DIMENSIONS WEIGHTa
a.If media weight is over 120 g/m2 (32 lbs), load a paper into the tray one by one.
CAPACITYb
b.Maximum capacity may differ depending on media weight, thickness, and environmental conditions.
Plain paper Letter 216 x 279 mm (8.50 x 11.00 inches) 60 to 105 g/m2 (16 to 28 lbs bond) 130 sheets of 80 g/m2 (20 lbs
bond) paper for the tray
Legal 216 x 356 mm (8.50 x 14.00 inches)
US Folio 216 x 330 mm (8.50 x 13.00 inches)
A4 210 x 297 mm (8.27 x 11.69 inches)
Oficio 216 x 343 mm (8.50 x 13.50 inches)
JIS B5 182 x 257 mm (7.17 x 10.12 inches)
ISO B5 176 x 250 mm (6.93 x 9.84 inches)
Executive 184 x 267 mm (7.25 x 10.50 inches)
Statement 140 x 216 mm (5.5 x 8.50 inches)
A5 148 x 210 mm (5.83 x 8.26 inches)
A6 105 x 148 mm (4.13 x 5.82 inches)
Envelope Envelope Monarch 98 x 191 mm (3.87 x 7.50 inches) 75 to 90 g/m2 (20 to 24 lbs bond) 5 sheets for manual feeding in
the tray
Envelope 6 3/4 92 x 165 mm (3.62 x 6.50 inches)
Envelope No. 10 105 x 241 mm (4.12 x 9.50 inches)
Envelope No. 9 98 x 225 mm (3.87 x 8.87 inches)
Envelope DL 110 x 220 mm (4.33 x 8.66 inches)
Envelope C5 162 x 229 mm (6.38 x 9.02 inches)
Envelope C6 114 x 162 mm (4.49 x 6.38 inches)
Thick paper Refer to the Plain
paper section
Refer to the Plain paper section. 90 to 105 g/m2 (24 to 28 lbs bond) 5 sheets for manual feeding in
the tray
Thin paper Refer to the Plain
paper section
Refer to the Plain paper section. 60 to 70 g/m2 (16 to 19 lbs bond)
Labelsc
c. The smoothness of the labels used in this machine is 100 to 250 (sheffield). This means the numeric level of smoothness.
Letter, A4 Refer to the Plain paper section. 120 to 150 g/m2 (37 to 40 lbs bond)
Card stock Post card 101.60 x 152.40 mm (4 x 6 inches) 105 to 220 g/m2 (28 to 43 lbs bond)
Transparencyde
d.Recommended media: Transparency for a color laser printers by Xerox 3R91331 (A4) or Xerox 3R2780 (Letter).
e.Recommended media: 0.104 to 0.124 mm (0.004094 to 0.004882 inches) thickness of transparency paper.
Letter, A4 Refer to the Plain paper section. - 1 sheet for manual feeding in the
tray
Glossy photof
f. Recommended media: Glossy paper (Letter) for this machine by HP Brochure Paper (Product: Q6611A).Glossy paper (A4) for this machine by HP Superior
Paper 160 glossy (Product: Q6616A).
Letter, A4 Refer to the Plain paper section. 111 to 220 g/m2 (30 to 58 lbs bond)
Matte photo Letter, A4, Postcard 4
x 6
Refer to the Pain paper section. 111 to 220 g/m2 (30 to 58 lbs bond)
Minimum size (custom) 76 x 160 mm (3.00 x 6.30 inches) 60 to 163 g/m2 (16 to 43 lbs bond)
Maximum size (custom) 216 x 356 mm (8.50 x 14.02 inches)
Contact SAMSUNG worldwide_ 143
contact samsung worldwide
If you have any comments or questions regarding Samsung products, contact the Samsung customer care center.
COUNTRY/REG
ION
CUSTOMER CARE
CENTER WEB SITE
ARGENTINE 0800-333-3733 www.samsung.com/ar
AUSTRALIA 1300 362 603 www.samsung.com/au
AUSTRIA 0810-SAMSUNG (7267864,
€ 0.07/min)
www.samsung.com/at
BELARUS 810-800-500-55-500 www.samsung.ua
www.samsung.com/ua_r
u
BELGIUM 02 201 2418 www.samsung.com/be
(Dutch)
www.samsung.com/be_fr
(French)
BRAZIL 0800-124-421
4004-0000
www.samsung.com/br
CANADA 1-800-SAMSUNG
(726-7864)
www.samsung.com/ca
CHILE 800-SAMSUNG (726-7864) www.samsung.com/cl
CHINA 400-810-5858
010-6475 1880
www.samsung.com/cn
COLOMBIA 01-8000112112 www.samsung.com.co
COSTA RICA 0-800-507-7267 www.samsung.com/latin
CZECH
REPUBLIC
800-SAMSUNG
(800-726786)
www.samsung.com/cz
Samsung Zrt., þeská organizaþní složka, Oasis Florenc,
Sokolovská394/17, 180 00, Praha 8
DENMARK 8-SAMSUNG (7267864) www.samsung.com/dk
ECUADOR 1-800-10-7267 www.samsung.com/latin
EL SALVADOR 800-6225 www.samsung.com/latin
ESTONIA 800-7267 www.samsung.com/ee
KAZAKHSTAN 8-10-800-500-55-500 www.samsung.com/kz_ru
KYRGYZSTAN 00-800-500-55-500
FINLAND 30-6227 515 www.samsung.com/fi
FRANCE 01 4863 0000 www.samsung.com/fr
GERMANY 01805 - SAMSUNG
(726-7864 € 0,14/min)
www.samsung.de
GUATEMALA 1-800-299-0013 www.samsung.com/latin
HONDURAS 800-7919267 www.samsung.com/latin
HONG KONG 3698-4698 www.samsung.com/hk
www.samsung.com/hk_e
n/
HUNGARY 06-80-SAMSUNG
(726-7864)
www.samsung.com/hu
INDIA 3030 8282
1800 110011
1800 3000 8282
www.samsung.com/in
INDONESIA 0800-112-8888 www.samsung.com/id
ITALIA 800-SAMSUNG (726-7864) www.samsung.com/it
JAMAICA 1-800-234-7267 www.samsung.com/latin
JAPAN 0120-327-527 www.samsung.com/jp
LATVIA 8000-7267 www.samsung.com/lv
LITHUANIA 8-800-77777 www.samsung.com/lt
LUXEMBURG 02 261 03 710 www.samsung.com/lu
MALAYSIA 1800-88-9999 www.samsung.com/my
MEXICO 01-800-SAMSUNG
(726-7864)
www.samsung.com/mx
MOLDOVA 00-800-500-55-500 www.samsung/ua
www.samsung.com/ua_r
u
NETHERLANDS 0900-SAMSUNG
(0900-7267864) (€
0,10/min)
www.samsung.com/nl
NEW ZEALAND 0800 SAMSUNG (0800 726
786)
www.samsung.com/nz
NICARAGUA 00-1800-5077267 www.samsung.com/latin
NORWAY 3-SAMSUNG (7267864) www.samsung.com/no
PANAMA 800-7267 www.samsung.com/latin
PHILIPPINES 1800-10-SAMSUNG
(726-7864)
1-800-3-SAMSUNG
(726-7864)
1-800-8-SAMSUNG
(726-7864)
02-5805777
www.samsung.com/ph
POLAND 0 801 1SAMSUNG
(172678)
022-607-93-33
www.samsung.com/pl
COUNTRY/REG
ION
CUSTOMER CARE
CENTER WEB SITE
Contact SAMSUNG worldwide_ 144
PORTUGAL 80820-SAMSUNG
(726-7864)
www.samsung.com/pt
PUERTO RICO 1-800-682-3180 www.samsung.com/latin
REP. DOMINICA 1-800-751-2676 www.samsung.com/latin
EIRE 0818 717 100 www.samsung.com/ie
RUSSIA 8-800-555-55-55 www.samsung.ru
SINGAPORE 1800-SAMSUNG
(726-7864)
www.samsung.com/sg
SLOVAKIA 0800-SAMSUNG
(726-7864)
www.samsung.com/sk
SOUTH AFRICA 0860 SAMSUNG
(726-7864)
www.samsung.com/za
SPAIN 902-1-SAMSUNG(902 172
678)
www.samsung.com/es
SWEDEN 0771 726 7864
(SAMSUNG)
www.samsung.com/se
SWITZERLAND 0848-SAMSUNG (7267864,
CHF 0.08/min)
www.samsung.com/ch
TADJIKISTAN 8-10-800-500-55-500
TAIWAN 0800-329-999 www.samsung.com/tw
THAILAND 1800-29-3232
02-689-3232
www.samsung.com/th
TRINIDAD &
TOBAGO
1-800-SAMSUNG
(726-7864)
www.samsung.com/latin
TURKEY 444 77 11 www.samsung.com/tr
U.A.E 800-SAMSUNG (726-7864)
8000-4726
www.samsung.com/ae
U.K 0845 SAMSUNG
(726-7864)
www.samsung.com/uk
U.S.A 1-800-SAMSUNG
(7267864)
www.samsung.com/us
UKRAINE 8-800-502-0000 www.samsung/ua
www.samsung.com/ua_r
u
UZBEKISTAN 8-10-800-500-55-500 www.samsung.com/kz_ru
VENEZUELA 0-800-100-5303 www.samsung.com/latin
VIETNAM 1 800 588 889 www.samsung.com/vn
COUNTRY/REG
ION
CUSTOMER CARE
CENTER WEB SITE
Glossary_ 145
glossary
The following glossary helps you get familiar with the product by
understanding the terminologies commonly used with printing as well
as mentioned in this user’s guide.
802.11
802.11 is a set of standards for wireless local area network (WLAN)
communication, developed by the IEEE LAN/MAN Standards Commit-
tee (IEEE 802).
802.11b/g/n
802.11b/g/n can share same hardware and use the 2.4 GHz band.
802.11b supports bandwidth up to 11 Mbps, 802.11n supports band-
width up to 150 Mbps. 802.11b/g/n devices may occasionally suffer
interference from microwave ovens, cordless telephones, and Bluetooth
devices.
Access point
Access Point or Wireless Access Point (AP or WAP) is a device that
connects wireless communication devices together on wireless local
area networks (WLAN), and acts as a central transmitter and receiver of
WLAN radio signals.
ADF
An Automatic Document Feeder (ADF) is a scanning unit that will auto-
matically feed an original sheet of paper so that the machine can scan
some amount of the paper at once.
AppleTalk
AppleTalk is a proprietary suite of protocols developed by Apple, Inc for
computer networking. It was included in the original Macintosh (1984)
and is now deprecated by Apple in favor of TCP/IP networking.
BIT Depth
A computer graphics term describing the number of bits used to repre-
sent the color of a single pixel in a bitmapped image. Higher color depth
gives a broader range of distinct colors. As the number of bits increases,
the number of possible colors becomes impractically large for a color
map. 1-bit color is commonly called as monochrome or black and white.
BMP
A bitmapped graphics format used internally by the Microsoft Windows
graphics subsystem (GDI), and used commonly as a simple graphics file
format on that platform.
BOOTP
Bootstrap Protocol. A network protocol used by a network client to
obtain its IP address automatically. This is usually done in the bootstrap
process of computers or operating systems running on them. The
BOOTP servers assign the IP address from a pool of addresses to each
client. BOOTP enables 'diskless workstation' computers to obtain an IP
address prior to loading any advanced operating system.
CCD
Charge Coupled Device (CCD) is a hardware which enables the scan
job. CCD Locking mechanism is also used to hold the CCD module to
prevent any damage when you move the machine.
Collation
Collation is a process of printing a multiple-copy job in sets. When colla-
tion is selected, the device prints an entire set before printing additional
copies.
Control Panel
A control panel is a flat, typically vertical, area where control or monitor-
ing instruments are displayed. They are typically found in front of the
machine.
Coverage
It is the printing term used for a toner usage measurement on printing.
For example, 5% coverage means that an A4 sided paper has about 5%
image or text on it. So, if the paper or original has complicated images or
lots of text on it, the coverage will be higher and at the same time, a
toner usage will be as much as the coverage.
CSV
Comma Separated Values (CSV). A type of file format, CSV is used to
exchange data between disparate applications. The file format, as it is
used in Microsoft Excel, has become a de facto standard throughout the
industry, even among non-Microsoft platforms.
DADF
A Duplex Automatic Document Feeder (DADF) is a scanning unit that
will automatically feed and turn over an original sheet of paper so that
the machine can scan on both sides of the paper.
Default
The value or setting that is in effect when taking a printer out of its box
state, reset, or initialized.
DHCP
A Dynamic Host Configuration Protocol (DHCP) is a client-server net-
working protocol. A DHCP server provides configuration parameters
specific to the DHCP client host requesting, generally, information
required by the client host to participate on an IP network. DHCP also
provides a mechanism for allocation of IP addresses to client hosts.
DIMM
Dual Inline Memory Module (DIMM), a small circuit board that holds
memory. DIMM stores all the data within the machine like printing data,
received fax data.
Glossary_ 146
DLNA
The Digital Living Network Alliance (DLNA) is a standard that allows
devices on a home network to share information with each other across
the network.
DNS
The Domain Name Server (DNS) is a system that stores information
associated with domain names in a distributed database on networks,
such as the Internet.
Dot Matrix Printer
A dot matrix printer refers to a type of computer printer with a print head
that runs back and forth on the page and prints by impact, striking an
ink-soaked cloth ribbon against the paper, much like a typewriter.
DPI
Dots Per Inch (DPI) is a measurement of resolution that is used for scan-
ning and printing. Generally, higher DPI results in a higher resolution,
more visible detail in the image, and a larger file size.
DRPD
Distinctive Ring Pattern Detection. Distinctive Ring is a telephone com-
pany service which enables a user to use a single telephone line to
answer several different telephone numbers.
Duplex
A mechanism that will automatically turn over a sheet of paper so that
the machine can print (or scan) on both sides of the paper. A printer
equipped with a Duplex Unit can print on both sides of paper during one
print cycle.
Duty Cycle
Duty cycle is the page quantity which does not affect printer perfor-
mance for a month. Generally the printer has the lifespan limitation such
as pages per year. The lifespan means the average capacity of
print-outs, usually within the warranty period. For example, if the duty
cycle is 48,000 pages per month assuming 20 working days, a printer
limits 2,400 pages a day.
ECM
Error Correction Mode (ECM) is an optional transmission mode built into
Class 1 fax machines or fax modems. It automatically detects and cor-
rects errors in the fax transmission process that are sometimes caused
by telephone line noise.
Emulation
Emulation is a technique of one machine obtaining the same results as
another.
An emulator duplicates the functions of one system with a different sys-
tem, so that the second system behaves like the first system. Emulation
focuses on exact reproduction of external behavior, which is in contrast
to simulation, which concerns an abstract model of the system being
simulated, often considering its internal state.
Ethernet
Ethernet is a frame-based computer networking technology for local
area networks (LANs). It defines wiring and signaling for the physical
layer, and frame formats and protocols for the media access control
(MAC)/data link layer of the OSI model. Ethernet is mostly standardized
as IEEE 802.3. It has become the most widespread LAN technology in
use during the 1990s to the present.
EtherTalk
A suite of protocols developed by Apple Computer for computer net-
working. It was included in the original Macintosh (1984) and is now dep-
recated by Apple in favor of TCP/IP networking.
FDI
Foreign Device Interface (FDI) is a card installed inside the machine to
allow a third party device such as a coin operated device or a card
reader. Those devices allow the pay-for-print service on your machine.
FTP
A File Transfer Protocol (FTP) is a commonly used protocol for exchang-
ing files over any network that supports the TCP/IP protocol (such as the
Internet or an intranet).
Fuser Unit
The part of a laser printer that fuses the toner onto the print media. It
consists of a heat roller and a pressure roller. After toner is transferred
onto the paper, the fuser unit applies heat and pressure to ensure that
the toner stays on the paper permanently, which is why paper is warm
when it comes out of a laser printer.
Gateway
A connection between computer networks, or between a computer net-
work and a telephone line. It is very popular, as it is a computer or a net-
work that allows access to another computer or network.
Grayscale
A shades of gray that represent light and dark portions of an image
when color images are converted to grayscale; colors are represented
by various shades of gray.
Halftone
An image type that simulates grayscale by varying the number of dots.
Highly colored areas consist of a large number of dots, while lighter
areas consist of a smaller number of dots.
HDD
Hard Disk Drive (HDD), commonly referred to as a hard drive or hard
disk, is a non-volatile storage device which stores digitally-encoded data
on rapidly rotating platters with magnetic surfaces.
IEEE
The Institute of Electrical and Electronics Engineers (IEEE) is an interna-
tional non-profit, professional organization for the advancement of tech-
nology related to electricity.
Glossary_ 147
IEEE 1284
The 1284 parallel port standard was developed by the Institute of Electri-
cal and Electronics Engineers (IEEE). The term "1284-B" refers to a
specific connector type on the end of the parallel cable that attaches to
the peripheral (for example, a printer).
Intranet
A private network that uses Internet Protocols, network connectivity, and
possibly the public telecommunication system to securely share part of
an organization's information or operations with its employees. Some-
times the term refers only to the most visible service, the internal web-
site.
IP address
An Internet Protocol (IP) address is a unique number that devices use in
order to identify and communicate with each other on a network utilizing
the Internet Protocol standard.
IPM
The Images Per Minute (IPM) is a way of measuring the speed of a
printer. An IPM rate indicates the number of single-sided sheets a printer
can complete within one minute.
IPP
The Internet Printing Protocol (IPP) defines a standard protocol for print-
ing as well as managing print jobs, media size, resolution, and so forth.
IPP can be used locally or over the Internet to hundreds of printers, and
also supports access control, authentication, and encryption, making it a
much more capable and secure printing solution than older ones.
IPX/SPX
IPX/SPX stands for Internet Packet Exchange/Sequenced Packet
Exchange. It is a networking protocol used by the Novell NetWare oper-
ating systems. IPX and SPX both provide connection services similar to
TCP/IP, with the IPX protocol having similarities to IP, and SPX having
similarities to TCP. IPX/SPX was primarily designed for local area net-
works (LANs), and is a very efficient protocol for this purpose (typically
its performance exceeds that of TCP/IP on a LAN).
ISO
The International Organization for Standardization (ISO) is an interna-
tional standard-setting body composed of representatives from national
standards bodies. It produces world-wide industrial and commercial
standards.
ITU-T
The International Telecommunication Union is an international organiza-
tion established to standardize and regulate international radio and tele-
communications. Its main tasks include standardization, allocation of the
radio spectrum, and organizing interconnection arrangements between
different countries to allow international phone calls. A -T out of ITU-T
indicates telecommunication.
ITU-T No. 1 chart
Standardized test chart published by ITU-T for document facsimile
transmissions.
JBIG
Joint Bi-level Image Experts Group (JBIG) is an image compression
standard with no loss of accuracy or quality, which was designed for
compression of binary images, particularly for faxes, but can also be
used on other images.
JPEG
Joint Photographic Experts Group (JPEG) is a most commonly used
standard method of lossy compression for photographic images. It is the
format used for storing and transmitting photographs on the World Wide
Web.
LDAP
The Lightweight Directory Access Protocol (LDAP) is a networking pro-
tocol for querying and modifying directory services running over TCP/IP.
LED
A Light-Emitting Diode (LED) is a semiconductor device that indicates
the status of a machine.
MAC address
Media Access Control (MAC) address is a unique identifier associated
with a network adapter. MAC address is a unique 48-bit identifier usually
written as 12 hexadecimal characters grouped in pairs (e. g.,
00-00-0c-34-11-4e). This address is usually hard-coded into a Network
Interface Card (NIC) by its manufacturer, and used as an aid for routers
trying to locate machines on large networks.
MFP
Multi Function Peripheral (MFP) is an office machine that includes the
following functionality in one physical body, so as to have a printer, a
copier, a fax, a scanner and etc.
MH
Modified Huffman (MH) is a compression method for decreasing the
amount of data that needs to be transmitted between the fax machines
to transfer the image recommended by ITU-T T.4. MH is a code-
book-based run-length encoding scheme optimized to efficiently com-
press white space. As most faxes consist mostly of white space, this
minimizes the transmission time of most faxes.
MMR
Modified Modified READ (MMR) is a compression method recom-
mended by ITU-T T.6.
Modem
A device that modulates a carrier signal to encode digital information,
and also demodulates such a carrier signal to decode transmitted infor-
mation.
MR
Modified Read (MR) is a compression method recommended by ITU-T
T.4. MR encodes the first scanned line using MH. The next line is com-
pared to the first, the differences determined, and then the differences
are encoded and transmitted.
Glossary_ 148
NetWare
A network operating system developed by Novell, Inc. It initially used
cooperative multitasking to run various services on a PC, and the net-
work protocols were based on the archetypal Xerox XNS stack. Today
NetWare supports TCP/IP as well as IPX/SPX.
OPC
Organic Photo Conductor (OPC) is a mechanism that makes a virtual
image for print using a laser beam emitted from a laser printer, and it is
usually green or rust colored and has a cylinder shape.
An imaging unit containing a drum slowly wears the drum surface by its
usage in the printer, and it should be replaced appropriately since it gets
worn from contact with the cartridge development brush, cleaning mech-
anism, and paper.
Originals
The first example of something, such as a document, photograph or text,
etc, which is copied, reproduced or translated to produce others, but
which is not itself copied or derived from something else.
OSI
Open Systems Interconnection (OSI) is a model developed by the Inter-
national Organization for Standardization (ISO) for communications. OSI
offers a standard, modular approach to network design that divides the
required set of complex functions into manageable, self-contained, func-
tional layers. The layers are, from top to bottom, Application, Presenta-
tion, Session, Transport, Network, Data Link and Physical.
PABX
A private automatic branch exchange (PABX) is an automatic telephone
switching system within a private enterprise.
PCL
Printer Command Language (PCL) is a Page Description Language
(PDL) developed by HP as a printer protocol and has become an indus-
try standard. Originally developed for early inkjet printers, PCL has been
released in varying levels for thermal, dot matrix printer, and laser print-
ers.
PDF
Portable Document Format (PDF) is a proprietary file format developed
by Adobe Systems for representing two dimensional documents in a
device independent and resolution independent format.
PostScript
PostScript (PS) is a page description language and programming lan-
guage used primarily in the electronic and desktop publishing areas. -
that is run in an interpreter to generate an image.
Printer Driver
A program used to send commands and transfer data from the computer
to the printer.
Print Media
The media like paper, envelopes, labels, and transparencies which can
be used in a printer, a scanner, a fax or, a copier.
PPM
Pages Per Minute (PPM) is a method of measurement for determining
how fast a printer works, meaning the number of pages a printer can
produce in one minute.
PRN file
An interface for a device driver, this allows software to interact with the
device driver using standard input/output system calls, which simplifies
many tasks.
Protocol
A convention or standard that controls or enables the connection, com-
munication, and data transfer between two computing endpoints.
PS
See PostScript.
PSTN
The Public-Switched Telephone Network (PSTN) is the network of the
world's public circuit-switched telephone networks which, on industrial
premises, is usually routed through the switchboard.
RADIUS
Remote Authentication Dial In User Service (RADIUS) is a protocol for
remote user authentication and accounting. RADIUS enables central-
ized management of authentication data such as usernames and pass-
words using an AAA (authentication, authorization, and accounting)
concept to manage network access.
Resolution
The sharpness of an image, measured in Dots Per Inch (DPI). The
higher the dpi, the greater the resolution.
SMB
Server Message Block (SMB) is a network protocol mainly applied to
share files, printers, serial ports, and miscellaneous communications
between nodes on a network. It also provides an authenticated Inter-pro-
cess communication mechanism.
SMTP
Simple Mail Transfer Protocol (SMTP) is the standard for e-mail trans-
missions across the Internet. SMTP is a relatively simple, text-based
protocol, where one or more recipients of a message are specified, and
then the message text is transferred. It is a client-server protocol, where
the client transmits an email message to the server.
SSID
Service Set Identifier (SSID) is a name of a wireless local area network
(WLAN). All wireless devices in a WLAN use the same SSID in order to
communicate with each other. The SSIDs are case-sensitive and have a
maximum length of 32 characters.
Glossary_ 149
Subnet Mask
The subnet mask is used in conjunction with the network address to
determine which part of the address is the network address and which
part is the host address.
TCP/IP
The Transmission Control Protocol (TCP) and the Internet Protocol (IP);
the set of communications protocols that implement the protocol stack
on which the Internet and most commercial networks run.
TCR
Transmission Confirmation Report (TCR) provides details of each trans-
mission such as job status, transmission result and number of pages
sent. This report can be set to print after each job or only after failed
transmissions.
TIFF
Tagged Image File Format (TIFF) is a variable-resolution bitmapped
image format. TIFF describes image data that typically come from scan-
ners. TIFF images make use of tags, keywords defining the characteris-
tics of the image that is included in the file. This flexible and
platform-independent format can be used for pictures that have been
made by various image processing applications.
Toner Cartridge
A kind of bottle or container used in a machine like a printer which con-
tains toner. Toner is a powder used in laser printers and photocopiers,
which forms the text and images on the printed paper. Toner can be
fused by by a combination of heat/pressure from the fuser, causing it to
bind to the fibers in the paper.
TWAIN
An industry standard for scanners and software. By using a
TWAIN-compliant scanner with a TWAIN-compliant program, a scan can
be initiated from within the program. It is an image capture API for Micro-
soft Windows and Apple Macintosh operating systems.
UNC Path
Uniform Naming Convention (UNC) is a standard way to access network
shares in Window NT and other Microsoft products. The format of a
UNC path is: \\<servername>\<sharename>\<Additional directory>
URL
Uniform Resource Locator (URL) is the global address of documents
and resources on the Internet. The first part of the address indicates
what protocol to use, the second part specifies the IP address or the
domain name where the resource is located.
USB
Universal Serial Bus (USB) is a standard that was developed by the
USB Implementers Forum, Inc., to connect computers and peripherals.
Unlike the parallel port, USB is designed to concurrently connect a sin-
gle computer USB port to multiple peripherals.
Watermark
A watermark is a recognizable image or pattern in paper that appears
lighter when viewed by transmitted light. Watermarks were first intro-
duced in Bologna, Italy in 1282; they have been used by papermakers to
identify their product, and also on postage stamps, currency, and other
government documents to discourage counterfeiting.
WEP
Wired Equivalent Privacy (WEP) is a security protocol specified in IEEE
802.11 to provide the same level of security as that of a wired LAN. WEP
provides security by encrypting data over radio so that it is protected as
it is transmitted from one end point to another.
WIA
Windows Imaging Architecture (WIA) is an imaging architecture that is
originally introduced in Windows Me and Windows XP. A scan can be
initiated from within these operating systems by using a WIA-compliant
scanner.
WPA
Wi-Fi Protected Access (WPA) is a class of systems to secure wireless
(Wi-Fi) computer networks, which was created to improve upon the
security features of WEP.
WPA-PSK
WPA-PSK (WPA Pre-Shared Key) is special mode of WPA for small
business or home users. A shared key, or password, is configured in the
wireless access point (WAP) and any wireless laptop or desktop
devices. WPA-PSK generates a unique key for each session between a
wireless client and the associated WAP for more advanced security.
WPS
The Wi-Fi Protected Setup (WPS) is a standard for establishing a wire-
less home network. If your wireless access point supports WPS, you can
configure the wireless network connection easily without a computer.
XPS
XML Paper Specification (XPS) is a specification for a Page Description
Language (PDL) and a new document format, which has benefits for
portable document and electronic document, developed by Microsoft. It
is an XML-based specification, based on a new print path and a vec-
tor-based device-independent document format.
Index_ 150
index
A
address book 34
answering machine/fax 95
authentication
printing a report 105
B
back 31, 34
booklet printing 73
booklets 73
buttons
eco copy 36
menu 31, 34, 36
power 36
print screen 36
start (black) 31, 34
start (color) 31, 34
stop/clear 31, 34
WPS (CLX-3185FW only) 31, 35
C
changing clock mode 61
cleaning
inside 113
outside 113
scan unit 115
cleaning a machine 113
control panel (CLX-3185/CLX-3185N) 31
control panel (CLX-3185FN/CLX-
3185FW) 34
convention 25
copy 34
copy setup 104
copying
basic copying 79
changing the copy setup 104
clone copy 81
collation 81
n-up copy 80
poster copy 81
reducing or enlarging copies 79
D
date and time setting 61
default settings
changing the default mode 62
setting a fax header 93
tray setting 70
direct USB 31, 34, 35
display 31, 34
document feeder 65
duplex printing (manual)
printer driver 73
E
eco copy 31
Entering
using the number keypad 62
eoc copy 34
error message 122
extension telephone 95
F
favorites settings, for printing 72
fax 34
fax receiving
activating secure receive 96
changing the receive mode 95
DRPD mode 95
extension telephone 95
in answering machine/fax 95, 96
secure receiving 96
fax sending
delay sending 94
multi sending 94
redialing the last number 93
resending automatically 93
sending a fax 93, 94
fax setup 103
faxing
address book 97
adjusting darkness 97
adjusting resolution 96
changing receiving mode 95
changing the fax setup 103
delaying a fax transmission 94
forwarding faxes 97
group dial 98
preparing to fax 92
receiving 95
receiving a fax in memory 96
receiving in Ans/Fax mode 95
receiving in Tel mode 95
receiving with an extension telephone 95
redialing the last number 93
sending 93
sending a priority fax 94
setting the fax header 93
speed dial 97
features 27
machine features 103, 140
power saving feature 63
print media feature 142
printer driver 71
supplied software 38
front view (CLX-3185/CLX-3185N) 29
front view (CLX-3185FN/CLX-3185FW) 32
G
glossary 145
I
id copy 31, 34, 80
introducing buttons 36
J
jam
clearing paper 119
tips for avoiding paper jams 118
job timeout setting 64
L
language 61
LCD display
changing the display language 61
LED
machine status 36
understanding the status LED 36
Index_ 151
left/right arrow 31, 34
Linux
common Linux problems 133
driver installation for network connected
48
driver installation for USB cable connected
41
printer properties 78
printing 77
scanning 89
supplied software 39
system requirements 40
unified driver configurator 111
using SetIP 46
loading
in the document feeder 65
originals on the scanner glass 65
special media 68
M
Macintosh
common Macintosh problems 134
driver installation for network connected
48
driver installation for USB cable connected
41
printing 76
scanning 89
sharing a machine locally 43
supplied software 39
system requirements 39
using SetIP 46, 58
maintenance parts 135
manual tray
using special media 68
memory
clearing memory 105
menu overview 106
N
network
driver installation
Linux 48
Macintosh 48
Windows 46
installing environment 44
introducing network programs 44
IPv6 configuration 49
SetIP program 45, 46, 57, 58
using a wired network 44
using a wireless network 50
network setup 106
number keypad 34
N-up copy 80
N-up printing
Macintosh 77
Windows 73
O
on hook dial 34
original document
clearing jam 119
loading
in the document feeder 65
on the scanner glass 65
output support 70
overlay printing
create 75
delete 75
print 75
P
placing a machine
adjusting the altitude 61
spacing 38
poster 73
power button 31, 34
power off
button 36
power saver
using power save mode 63
print media
card stock 69
envelope 68
glossy paper 70
guidelines 66
labels 69
letterhead paper 70
output support 142
preprinted paper 70
setting the paper size 70
setting the paper type 70
transparency 69
print resolution set
Linux 78
print resolution, set
Macintosh 77
print screen button 31
printer driver
features 71
printer preferences
Linux 78
printing
changing the default print settings 76
changing the print percentage 74
fitting your document to a selected paper
size 74
Linux 77
Macintosh 76
multiple pages on one sheet of paper
Macintosh 77
Windows 73
poster 73
printing a document
Windows 71
printing on both sides of paper
Windows 73
printing to a file 76
USB memory 101
using overlay 75
using watermarks 74
printing a document
Linux 77
Macintosh 76
problems
copying problems 130
paper feeding problems 126
power problems 125
printing quality problems 128
R
rear view (CLX-3185/CLX-3185N) 30
rear view (CLX-3185FN/CLX-3185FW) 33
redial/pause 34
regulatiory information 14
resolution
faxing 96
S
safety
information 10
symbols 10
scan to button 31
scan/email 35
scanner
glass 65
loading documents 65
scanner glass
loading documents 65
scanning
basic information 83
for local connection 83
Linux 89
Macintosh 89
TWAIN 88
USB flash memory 100
WIA 88
Index_ 152
serial number 113
service contact numbers 143
SetIP program 45, 46, 57, 58
setting
default paper 63
Smart Panel
general information 109
specifications
general 140
print media 142
start button (black) 31, 34
start button (color) 31, 34
status LED 31, 34
stop/clear button 31, 34
supplies
available supplies 135
estimated toner cartridge life 116
ordering 135
SyncThru Web Service
general information 108
T
toner cartridge
estimated life 116
handling instructions 116
non-Samsung and refilled 116
redistributing toner 118
storing 116
toner color 31, 35
tray
adjusting the width and length 66
changing the tray size 66
setting the paper size and type 70
TWAIN, scan 88
U
USB cable
driver installation 40
USB flash memory
data backup 101
managing 102
printing 101
scanning 100
using help 73
W
watermark
create 74
delete 75
edit 74
print 74
WIA
scan 88
Wi-Fi Protected Setup™ (WPS) 37
Windows
common Windows problems 132
driver installation for network connected
46
driver installation for USB cable connected
40
printing 71
scanning 83
sharing a machine locally 42
supplied software 39
system requirements 39
using SetIP 45, 57
Windows 7
scan 88
