Playback/Editing
101
Viewing photos or videos in Playback mode
Deleting multiple files
You can select multiple files, and then delete them at once.
1
In Playback mode, press [
l
].
2
When the pop-up message appears, select Multiple
Delete.
•
You can also delete multiple files in Playback mode by
pressing [
m
], and then selecting
O
Delete
Select.
3
Scroll to each file you want to delete, and then press
[
o
].
•
Press [
o
] again to cancel your selection.
4
Press [
l
].
5
When the pop-up message appears, select Yes.
Deleting files
Select files to delete in Playback mode.
Deleting a single file
You can select one file, and then delete it.
1
In Playback mode, select a file, and then press [
l
].
2
When the pop-up message appears, select Yes.
•
When viewing files in Smart Album or thumbnails view, press [
l
] to
delete a file.
•
While viewing files as a folder, press [
l
] to delete all photos in the
folder.
•
To delete a specific photo in a folder, open the folder, select a file,
and then press [
l
].
Playback/Editing
102
Viewing photos or videos in Playback mode
Viewing photos
Enlarge part of a photo or view photos as a slide show.
Enlarging a photo
In Playback mode, rotate [Zoom] to the right to
enlarge a portion of the photo. Rotate [Zoom] to the
left to zoom out.
Enlarged area
Trim
Deleting all files
You can select all files, and then delete them at once.
1
In Playback mode, press [
m
].
2
Select
O
Delete All.
3
When the pop-up message appears, select Yes.
•
All unprotected files are deleted.
Playback/Editing
103
Viewing photos or videos in Playback mode
Viewing panoramic photos
View photos captured in Panorama mode.
1
In Playback mode, rotate the navigation button or press
[
F
/
t
] to scroll to a desired panoramic photo.
•
The entire panoramic photo appears on the screen.
2
Press [
o
].
•
The camera automatically scrolls through the photo from left to
right for a horizontal panoramic photo and from top to bottom
for a vertical panoramic photo. The camera then switches to
Playback mode.
•
While playing back a panoramic photo, press [
o
] to pause
or resume.
•
After you have paused the playback of a panoramic photo,
press [
D
/
c
/
F
/
t
] to move the photo horizontally
or vertically, depending on the direction you moved when
capturing the photo.
3
Press [
m
] to return to Playback mode.
•
The camera automatically scrolls through the panoramic photo only
if the longest side of the photo is two or more times longer than the
shortest side.
•
On your camera’s display, a photo captured in 3D Panorama mode
appears as a 2D panoramic photo. To see the 3D effect, connect your
camera to a 3D TV or 3D monitor. (p. 114)
To Description
Move the enlarged area Press [
D
/
c
/
F
/
t
].
Trim the enlarged photo
Press [
o
], and then select Yes.
(The trimmed photo will be saved as a
new file. The original photo is retained in its
original form.)
When you view photos that were captured by another camera, the zoom
ratio may differ.
Playback/Editing
104
Viewing photos or videos in Playback mode
Playing a slide show
Apply effects and audio to a slide show of your photos. The slide
show function does not work for videos.
1
In Playback mode, press [
m
].
2
Select .
3
Select a slide show effect option.
•
Skip to step 4 to start a slide show with no effects.
* Default
Option Description
Start Set whether or not to repeat the slide show.
(Play, Repeat)
Images
Set the photos you want to view as a slide show.
•
All*: View all photos in a slide show.
•
Date: View photos captured on a specific date in
a slide show.
•
Select: View selected photos in a slide show.
Interval
•
Set the interval between photos.
(1 sec*, 3 sec, 5 sec, 10 sec)
•
You must set the Effect option to Off to set the
interval.
* Default
Option Description
Effect
•
Set a scene change effect between photos.
(Off*, Calm, Shine, Relax, Lively, Sweet)
•
Select Off to cancel effects.
•
When you use the Effect option, the interval
between photos will be set to 3 seconds.
Music Set background audio.
4
Select Start Play.
•
Select Repeat to loop the slide show.
5
View the slide show.
•
Press [
o
] to pause the slide show.
•
Press [
o
] again to resume the slide show.
•
Press [
o
], and then press [
F
/
t
] to stop the slide show and return
to Playback mode.
•
Rotate [Zoom] to the left or right to adjust the volume level.
Playback/Editing
105
Viewing photos or videos in Playback mode
Trimming a video
1
While viewing a video, press [
o
] at the point where you
want the trimming to begin.
2
Rotate [Zoom] to the right, and then press [
o
].
3
Press [
o
] at the point where you want the trimming to
end.
4
Rotate [Zoom] to the right.
5
When the pop-up message appears, select Yes.
•
The original video should be at least 10 seconds long.
•
The camera will save the edited video as a new file and leave the
original video intact.
Playing a video
In Playback mode, you can view a video, and then capture or trim
parts of the playing video. You can save the captured or trimmed
segments as new files.
1
In Playback mode, select a video, and then press [
o
].
2
View the video.
Current playback time/
Video length
Pause Stop
To Description
Scan backward
Press [
F
]. Each time you press [
F
],
you change the scan speed in this
order: 2X, 4X, 8X.
Pause or resume
playback Press [
o
].
Scan forward
Press [
t
]. Each time you press [
t
],
you change the scan speed in this
order: 2X, 4X, 8X.
Adjust the volume level Rotate [Zoom] to the left or right.
Playback/Editing
106
Viewing photos or videos in Playback mode
Capturing an image from video
1
While viewing a video, press [
o
] at the point where you
want to capture an image.
2
Press [
c
].
•
The resolution of the captured image will be the same as the original
video.
•
The captured image is saved as a new file.
Playback/Editing
107
Editing a photo
Learn how to edit photos.
•
The camera will save edited photos as new files.
•
When you edit photos, the camera will automatically convert them to a lower resolution. Photos that you rotate or resize manually are not automatically converted to
a lower resolution.
Rotating a photo
1
In Playback mode, select a photo, and then press
[
m
].
2
Select
e
Rotate.
3
Select an option.
Back Set
Rotate : Right 90˚
The camera will overwrite the original file.
Resizing photos
Change the size of a photo and save it as a new file.
1
In Playback mode, select a photo, and then press
[
m
].
2
Select
e
Resize.
3
Select an option.
Back Set
Resize
Rotate
Smart Filter
Image Adjust
2592X1944
1984X1488
1024X768
Available resize options differ depending on the original size of the photo.
Playback/Editing
108
Editing a photo
Applying Smart Filter effects
Apply special effects to your photos.
1
In Playback mode, select a photo, and then press
[
m
].
2
Select
e
Smart Filter.
3
Select an effect.
Back Set
Smart Filter : Normal
Icon Description
Normal: No effect
Miniature: Apply a tilt-shift effect to make the subject
appear in miniature.
Vignetting: Apply the retro-looking colors, high
contrast, and strong vignette effect of Lomo cameras.
Ink Painting: Apply a watercolor painting effect.
Icon Description
Oil Painting: Apply an oil painting effect.
Cartoon: Apply a cartoon painting effect.
Cross Filter: Add lines that radiate outward from bright
objects to imitate the visual effect of a cross filter.
Sketch: Apply a pen sketch effect.
Soft Focus: Hide facial imperfections or apply dreamy
effects.
Fish-eye: Distort close objects to imitate the visual
effect of a fisheye lens.
Old Film: Apply a vintage film effect.
Half Tone Dot: Apply a halftone effect.
Classic: Apply a black and white effect.
Retro: Apply a sepia tone effect.
Zooming Shot: Blur the edges of a photo to
emphasize the subjects in the center.
Playback/Editing
109
Editing a photo
Retouching faces
1
In Playback mode, select a photo, and then press
[
m
].
2
Select
e
Image Adjust Face Retouch.
3
Press [
c
].
4
Rotate the navigation button or press [
F
/
t
] to adjust
the skin tone.
•
As the number increases, the skin tone becomes brighter.
5
Press [
o
] to save your settings.
Adjusting your photos
Learn how to correct red-eye, adjust the skin tone, and adjust the
brightness, contrast, or saturation. The camera will save an edited
photo as a new file, but may convert it to a lower resolution.
Removing red-eye
1
In Playback mode, select a photo, and then press
[
m
].
2
Select
e
Image Adjust Red-eye Fix.
3
Press [
o
] to save your settings.
Playback/Editing
110
Editing a photo
Adjusting brightness, contrast, or saturation
1
In Playback mode, select a photo, and then press
[
m
].
2
Select
e
Image Adjust.
3
Select an adjusting option.
Icon Description
Brightness
Contrast
Saturation
4
Press [
c
].
5
Rotate the navigation button or press [
F
/
t
] to adjust
the option.
6
Press [
o
] to save your settings.
Adding noise to the photo
1
In Playback mode, select a photo, and then press
[
m
].
2
Select
e
Image Adjust Add Noise.
3
Press [
o
] to save.
Creating a print order (DPOF)
Select photos to print and save print options in the Digital Print
Order Format (DPOF). This information is saved in the MISC
folder on your memory card for convenient printing on DPOF-
compatible printers.
1
In Playback mode, press [
m
].
2
Select
O
DPOF Standard Select.
•
Select All to print all photos.
Playback/Editing
111
Editing a photo
3
Scroll to a photo you want to print, rotate [Zoom] to the
left or right to select the number of copies, and then
press [
f
].
•
If you select All, press [
D
/
c
] to select the number of
copies, and then press [
o
].
4
Press [
m
].
5
Select
O
DPOF Size Select.
•
Select All to choose the print size for all photos.
6
Scroll to a photo you want to print, rotate [Zoom] to the
left or right to select the print size, and then press [
f
].
•
If you select All, press [
D
/
c
] to select the print size, and
then press [
o
].
Printing photos as thumbnails
Print photos as thumbnails to check all the photos at once.
1
In Playback mode, press [
m
].
2
Select
O
DPOF Index.
3
When the pop-up message appears, select Yes.
•
You can take the memory card to a print shop that supports DPOF
(Digital Print Order Format) or you can print photos directly through a
DPOF-compatible printer at home.
•
Photos with dimensions that are wider than the paper may be cut off
on the left and right edges. Ensure that your photo dimensions are
compatible with the paper you select.
•
If you specify the print size, you can print photos only with
DPOF 1.1-compatible printers.
Playback/Editing
112
Viewing files on a TV, HDTV, or 3D TV
Play back photos or videos by connecting your camera to a TV with the A/V cable.
6
Turn on your TV, and then select the A/V video source
with the TV remote control.
7
Turn on your camera.
•
The camera automatically enters into Playback mode when
you connect it to a TV.
8
View photos or play videos using the camera buttons.
•
Depending on the TV model, you may see some digital noise or part
of an image may not appear.
•
Images may not be centered on the TV screen depending on your
TV settings.
1
In Shooting or Playback mode, press [
m
].
2
Select
n
Video Out.
3
Select the video signal output for your country or region.
(p. 155)
4
Turn off your camera and TV.
5
Connect your camera to your TV with the A/V cable.
VideoAudio
Playback/Editing
113
Viewing files on a TV, HDTV, or 3D TV
6
Turn on your camera.
•
If you have an Anynet+ compatible Samsung HDTV and you
have turned on your camera’s Anynet+ function, the HDTV
turns on automatically and displays the camera screen, while
the camera automatically enters Playback mode.
•
If Anynet+ is off in your camera or your TV does not have
Anynet+, the TV does not turn on automatically. Turn the TV
on manually.
7
View files using the buttons on your camera or, if the TV
has Anynet+, the remote control of your HDTV.
•
If your HDTV supports the Anynet+(CEC) profile, turn Anynet+ on in
the camera’s settings menu (p. 155) to control the camera and TV with
the TV’s remote control.
•
Anynet+ lets you control all connected Samsung A/V devices with the
TV remote control.
•
The time it takes for the camera to connect to your HDTV may vary
with the type of SD, SDHC, or SDXC card you use. A faster SD,
SDHC, or SDXC card will not necessarily result in a faster HDMI
transfer, because the main function of the card is to improve the
transfer rate during shooting.
Viewing files on an HDTV
You can view high-quality and uncompressed photos or videos
on an HDTV using the optional HDMI cable. HDMI (High Definition
Multimedia Interface) is supported by most HDTVs.
1
In Shooting or Playback mode, press [
m
].
2
Select
n
HDMI Size.
3
Select an HDMI resolution. (p. 155)
4
Turn off your camera and HDTV.
5
Connect your camera to your HDTV with the optional
HDMI cable.
Playback/Editing
114
Viewing files on a TV, HDTV, or 3D TV
Viewing files on a 3D TV
You can view photos captured in 3D Photo or 3D Panorama
mode on a 3D TV.
1
In Shooting or Playback mode, press [
m
].
2
Select
n
HDMI Size.
3
Select an HDMI resolution. (p. 155)
4
Turn off your camera and 3D TV.
5
Connect your camera to your 3D TV with the optional
HDMI cable.
6
Turn on your camera.
•
If you have an Anynet+ compatible Samsung 3D TV and you
have turned on your camera's Anynet+ function, the 3D TV
turns on automatically and displays the camera screen, while
the camera automatically enters Playback mode.
•
If Anynet+ is off in your camera or your TV does not have
Anynet+, the TV does not turn on automatically. Turn the TV
on manually.
7
Press [
c
] to switch to 3D TV Mode.
•
Press [
c
] again to switch to 2D TV Mode.
8
Turn on your TV's 3D function.
•
Refer to your TV's user manual for more details.
9
View 3D photos with the buttons on your camera or, if
the TV has Anynet+, the remote control of your 3D TV.
•
You cannot view an MPO file in 3D on TVs that do not support the
file format.
•
Use proper 3D glasses when you view an MPO file on a 3D TV.
Do not view the 3D images captured by your camera on a 3D TV or 3D
monitor for an extended period of time. It may cause unpleasant symptoms,
such as eyestrain, fatigue, nausea, and dizziness.
Playback/Editing
115
Viewing files on a TV, HDTV, or 3D TV
3
Turn on the camera.
•
The computer recognizes the camera automatically.
If you set the USB option to Select, select Computer in the pop-up
window.
4
On your computer, select My Computer
Removable Disk DCIM 100PHOTO.
5
Drag or save files to your computer.
Transferring files to your Windows computer
Transferring files by connecting the camera as a
removable disk
Connect the camera to your computer as a removable disk.
1
Turn off the camera.
2
Connect the camera to your computer with the USB
cable.
You must plug the small end of the USB cable into your camera. If the
cable is reversed, it may damage your files. The manufacturer is not
responsible for any loss of data.
Playback/Editing
116
Viewing files on a TV, HDTV, or 3D TV
Disconnecting the camera (for Windows XP)
With Windows Vista and Windows 7, the methods for
disconnecting the camera are similar.
1
If the status lamp on your camera is blinking, wait until
it stops.
2
Click on the tool bar at the bottom right of your
computer screen.
3
Click the pop-up message.
4
Click the message box that indicates the camera can be
removed safely.
5
Remove the USB cable.
The camera may not disconnect safely while Intelli-studio is running. End the
program before disconnecting the camera.
Playback/Editing
117
Using the provided programs on your PC
You can edit digital photos and videos in a variety of ways using the provided image editing programs. Programs contained on the CD are
compatible only with Windows.
Programs contained on the CD
Program Requirements
Intelli-studio Edit photos and videos.
PC Auto Backup Send the recorded files to a connected
PC via Wi-Fi.
Creative Movie Maker Easily make movies from captured still
images and videos.
Samsung RAW Converter Edit RAW format files.
•
You can download Map Download Manager, PC Auto Backup, and
Creative Movie Maker by connecting to Intelli-studio.
•
If your computer does not meet the requirements, videos may not play
correctly or it may take longer to edit videos. See page 120.
•
Install DirectX 9.0c or above before you use Intelli-studio.
The manufacturer is not responsible for any damage that results from using
unqualified computers, such as a computer you assembled yourself.
Installing software
1
Insert the installation CD in a compatible CD-ROM drive.
2
When the setup screen is appears, click Samsung
Digital Camera Installer to start installation.
3
Select a program to install, and then click Install.
4
Follow the on-screen instructions.
5
Click Exit to complete the installation, and then restart
your computer.
Playback/Editing
118
Using the provided programs on your PC
•
The requirements are recommendation only. Intelli-studio may not work
properly even when the computer meets the requirements, depending
on the condition of your computer.
•
If your computer does not meet the requirements, videos may not play
correctly or it may take longer to edit videos.
•
Install DirectX 9.0c or above before you use Intelli-studio.
•
Your computer must be running Windows XP, Windows Vista, or
Windows 7 for you to connect the camera as a removable disk.
The manufacturer is not responsible for any damage that results from using
unqualified computers such as a computer you assembled yourself.
Using Intelli-studio
Transfer files to your Windows computer, edit them with Intelli-
studio, and upload them to the web.
Requirements
Item Requirements
CPU Intel
®
Core 2 Duo 1.66 GHz or higher/
AMD Athlon™ X2 Dual-Core 2.2 GHz or higher
RAM Minimum 512 MB RAM (1 GB or more recommended)
OS* Windows XP SP2, Windows Vista, or Windows 7
(32-bit editions)
Hard disk
capacity 250 MB or more (1 GB and above recommended)
Others
•
CD-ROM drive
•
1024 X 768 pixels, 16-bit color display compatible
monitor (1280 X 1024 pixels, 32-bit color display
recommended)
•
USB 2.0 port
•
nVIDIA Geforce 7600GT or higher/
ATI X1600 series or higher
•
Microsoft DirectX 9.0c or higher
* The programs may not work properly on 64-bit editions of Windows XP,
Windows Vista, and Windows 7.
Playback/Editing
119
Using the provided programs on your PC
Using Intelli-studio
Intelli-studio is a built-in program that allows you to play back and edit files. For details, select Help Help from the program toolbar.
•
You can update the firmware of your camera by selecting Web Support Upgrade firmware for the connected device from the program toolbar.
•
If you install Intelli-studio on your computer, the program will launch more quickly. To install the program, select Tool Install Intelli-studio on PC.
•
You cannot edit files directly on the camera. Transfer files to a folder on your computer before editing.
•
Intelli-studio supports the following formats:
- Videos: MP4 (Video: H.264, Audio: AAC), WMV (WMV 7/8/9), AVI (MJPEG)
- Photos: JPG, GIF, BMP, PNG, TIFF
543
6
9
0
!
8
%
@
#
$
12
7
Playback/Editing
120
Using the provided programs on your PC
Transferring files with Intelli-studio
Intelli-studio will start automatically when you connect the camera
to your computer with the USB cable.
The battery will charge while the camera is connected to a computer with the
USB cable.
1
Turn off the camera.
2
Connect the camera to your computer with the USB
cable.
You must plug the small end of the USB cable into your camera. If the
cable is reversed, it may damage your files. The manufacturer is not
responsible for any loss of data.
No. Description
1
Open menus.
2
Display files in the selected folder.
3
Switch to the Photo edit mode.
4
Switch to the Video edit mode.
5
Switch to the Sharing mode (to send files by email or
upload files to websites, such as Flickr or YouTube).
6
Enlarge or reduce the thumbnails in the list.
7
Select a file type.
8
View files in the selected folder on your computer.
9
Show or hide files on the connected camera.
0
View files in the selected folder on the camera.
!
View files as thumbnails or on a map.
@
Browse folders stored on the camera.
#
Browse folders stored on your computer.
$
Move to the previous or next folder.
%
Print files, view files on a map, store files in My Folder, or
register faces.
Playback/Editing
121
Using the provided programs on your PC
3
Turn on the camera.
•
When the Intelli-studio installation pop-up appears on the
computer screen, follow the on-screen instructions to
complete the installation.
•
When you connect the camera to a computer with Intelli-
studio installed, the program will launch automatically.
If you set the USB option to Select, select Computer in the pop-up
window.
4
Select a destination folder on your computer, and then
select Yes.
•
New files stored on the camera will automatically transfer to
the selected folder.
•
If your camera has no new files, the pop-up window for saving
new files will not appear.
For Windows Vista and Windows 7, select Run iLinker.exe from the Auto
Play window to start Intelli-studio. If Run iLinker.exe does not appear on
the computer, click Computer Intelli-studio, and then follow the
on-screen instructions to complete the Intelli-studio installation.
Playback/Editing
122
Viewing files on a TV, HDTV, or 3D TV
2
Turn on the camera.
•
The computer recognizes the camera automatically and
displays a removable disk icon.
If you set the USB option to Select, select Computer in the pop-up
window.
3
Double-click the removable disk icon.
4
Drag or save files to your computer.
Transferring files to your Mac computer
When you connect the camera to a Macintosh computer, the
computer will automatically recognize the device. You can transfer
files directly from the camera to the computer without installing
any programs.
Mac OS 10.4 or later is supported.
1
Connect your camera to a Macintosh computer with the
USB cable.
You must plug the small end of the USB cable into your camera. If the
cable is reversed, it may damage your files. The manufacturer is not
responsible for any loss of data.
Playback/Editing
123
Viewing files on a TV, HDTV, or 3D TV
•
When using a laptop, the software may operate slowly due to the
low-power settings even if the laptop meets the recommended
specifications.
•
Depending on the 3D performance of your graphics card, the
processing speed and resolution of the movie may vary.
•
Files that have not beenrecorded with a Samsung camera or
camcorder may not play smoothly.
•
To install and use CMM, you should have the latest version of Intelli-
studio installed. You can download the latest version of Intelli-studio by
selecting Web Support Update Intelli-studio Start Update in
the Intelli-studio toolbar.
•
Creative Movie Maker can be used only with the Windows OS.
Using Creative Movie Maker
1
Install Creative Movie Maker from the provided CD.
(p. 124)
2
Connect the camera to your PC with a USB cable.
3
Copy the captured still image or video files to the PC.
4
Create the desired movie with Creative Movie Maker.
Creative Movie Maker (CMM)
Creative Movie Maker (CMM) allows you to make movies from
captured still images and recorded videos with an easy-to-use
interface. It provides background features, such as themes,
music, and resolution, so that you can customize your movies.
Requirements
To edit multiple videos and still images more smoothly, higher
system requirements may be needed.
Item Requirements
OS Windows XP SP3 / Vista / 7
CPU Intel
®
Pentium 4, AMD Athlon FX or higher
RAM 1 GB or more
Video card 250 MB or more (1 GB and above recommended)
Hard disk
capacity
GPU supporting OpenGL 2.0 or higher
(nVIDIA Geforce 7600GT or higher/
ATI X1600 series or higher)
Others
•
1024 X 768, 32bit color or higher
•
USB 2.0 port
•
Microsoft DirectX 9.0c or higher
•
OpenGL 2.0 or higher
Playback/Editing
124
Viewing files on a TV, HDTV, or 3D TV
Using Creative Movie Maker
For details, select Help Help from the program toolbar.
17
2
8
3
9
4
5
6
No. Description
1
Open menus.
2
Open/Save a project.
3
Steps to create a Creative Movie.
4
Creation Box
5
Add images and videos.
No. Description
6
PC Browser
7
Project name
8
Delete
9
Next step
Playback/Editing
125
Viewing files on a TV, HDTV, or 3D TV
Using Samsung RAW Converter
Photos captured by a camera are often transformed to jpeg
formats and stored in the memory according to the settings of the
camera at the time of shooting. RAW files are not transformed to
jpeg formats and are stored in the memory without any changes.
With Samsung RAW Converter, you can calibrate exposures,
white balances, tones, contrasts, and colors of photos.
•
You can download the Samsung RAW Converter program for
Macintosh from the Samsung website.
•
The Samsung RAW Converter program supplied on the CD-ROM is
compatible only with Windows XP and Vista.
Opening Samsung RAW Converter
On your computer, select Start All Programs Samsung
RAW Converter Samsung RAW Converter.
Playback/Editing
126
Viewing files on a TV, HDTV, or 3D TV
No. Description
3
Editing tools
4
Open/Close the fine adjustment window for the editing
tools
Using the Samsung RAW Converter Interface
For details about using Samsung RAW Converter, click Help Open software manual.
4
3
2
1
No. Description
1
Menu
2
Toolbar
Playback/Editing
127
Viewing files on a TV, HDTV, or 3D TV
Original image
p
Mode, Aperture: f=8,
Shutter Speed: 1/15 sec,
ISO=100
Changed image after correcting
the exposure
•
You can view the brightness of the image from the histogram
window.
Original image Changed image after correcting
the exposure
Editing RAW format files
If you edit the RAW format files with the Samsung RAW Converter,
you can maintain high image quality. You can also edit JPEG and
TIFF format files.
To adjust the exposure of of an image
1
Select File Open file and open a file.
2
From the editing tools, select .
3
Adjust the exposure with the scroll bar.
Playback/Editing
128
Viewing files on a TV, HDTV, or 3D TV
Original image
p
Mode, Aperture: f=8,
Shutter Speed: 1/15 sec,
ISO=100
Changed image after correcting
the contrast
To adjust the tone of an image
1
Select File Open file and open a file.
2
From the editing tools, select .
3
Adjust the tone with the scroll bar.
Playback/Editing
129
Viewing files on a TV, HDTV, or 3D TV
Saving RAW files as JPEG/TIFF formats
1
Select File Open file and open a file.
2
Select File Development.
3
Select a file format (JPEG or TIFF) and select Save.
Connecting to a WLAN and configuring
network settings
………………………… 131
Connecting to a WLAN
………………… 131
Using the login browser
………………… 132
Network connection tips
……………… 133
Entering text
…………………………… 134
Using photo or video sharing
websites
………………………………… 135
Accessing a website
…………………… 135
Uploading photos or videos
…………… 135
Sending photos or videos via email
…… 137
Changing email settings
……………… 137
Sending photos or videos via email
…… 138
Sending photos or videos to a
smart phone
……………………………… 140
Using a smart phone as a remote
shutter release
…………………………… 141
Uploading photos to a cloud server
…… 143
Using Auto Backup to send photos or
videos
…………………………………… 144
Installing the program for Auto Backup
on your PC
…………………………… 144
Sending photos or videos to a PC
…… 144
Viewing photos or videos on a
TV Link-enabled TV
……………………… 146
Sending photos using Wi-Fi Direct
…… 148
About the Wake on LAN (WOL)
feature
…………………………………… 149
Wireless network
Learn how to connect to wireless local area networks (WLANs) and use functions.
Wireless network
131
Connecting to a WLAN and configuring network settings
Learn to connect via an access point (AP) when you are in a range of a WLAN. You can also configure network settings.
Icon Description
Secured AP
WPS AP
Signal strength
Press [
t
] to open AP setting options
•
When you select a secured AP, a pop-up window appears.
Enter the required passwords to connect to the WLAN.
For
information about entering text, refer to "Entering text".
(p. 134)
•
When a login page appears, refer to "Using the login browser".
(p. 132)
•
When you select an unsecured AP, the camera will connect
to the WLAN.
•
If you select a WPS profile supported AP, select WPS PIN,
and then enter a PIN on the AP device. You can also connect
to a WPS profile supported AP by selecting WPS PBC on the
camera, and then pushing the WPS button on the AP device.
Connecting to a WLAN
1
Rotate the mode dial to
w
.
2
Select , , , , or .
3
Press [
m
], and then select AP Setting.
•
In some modes, press [
m
] or follow the on-screen
instructions until the AP Setting screen appears.
•
The camera automatically searches for available AP devices.
4
Select an AP.
AP Setting
Samsung 2
Samsung 1
Samsung 3
Samsung 4
Samsung 5
Back Select
•
Select WPS PBC to connect to a WPS AP.
•
Select Refresh to refresh connectable APs.
•
Select Add wireless network to add an AP manually.
Wireless network
132
Connecting to a WLAN and configuring network settings
Using the login browser
You can enter your login information via the login browser when
connecting to some APs, sharing sites, or cloud servers.
Button Description
[
D
/
c
/
F
/
t
]Move to an item or scroll the page.
[
o
] Select an item.
[
m
]
Access the following options:
•
Previous Page: Move to the previous page.
•
Next Page: Move to the next page.
•
Reload: Reload the page.
•
Stop: Stop loading the page.
•
Exit: Close the login browser.
[
l
] Close the login browser.
•
You cannot select some items depending on the page you connected
to. This does not indicate a malfunction.
•
The login browser may not close automatically after you log into some
pages. If this occurs, close the login browser by pressing [
l
], and
then proceed with the desired operation.
•
It may take longer to load the login page due to the page size or
network speed. If this occurs, wait until the login information input
window appears.
Setting network options
1
In the AP Setting screen, move to an AP, and then
press [
t
].
2
Select each option, and then enter the required
information.
Option Description
Authentication Select a network authentication type.
Data Encryption Select an encryption type.
Network Password Enter the network password.
IP Setting Set the IP address manually.
Manually setting the IP address
1
In the AP Setting screen, move to an AP, and then
press [
t
].
2
Select IP Setting Manual.
3
Select each option, and then enter the required
information.
Option Description
IP Enter the static IP address.
Subnet Mask Enter the subnet mask.
Gateway Enter the gateway.
DNS Server Enter the DNS address.
Wireless network
133
Connecting to a WLAN and configuring network settings
• If you cannot connect to a WLAN, try another AP from the
available AP list.
• You can also connect to free WLANs in some foreign countries.
• A login page may appear when you select free WLANs
provided by some network service providers. Enter your ID
and password to connect to the WLAN. For information about
registering or the service, contact the network service providers.
• Be cautious when you enter personal information for an AP
connection. Do not enter any payment or credit card information
on your camera. The manufacturer is not liable for any problem
caused by entering such information.
• Available network connections may differ by country.
• The WLAN feature of your camera must comply with radio
transmission laws in your region. To ensure compliance, use
the WLAN feature only in the country where you purchased the
camera.
• The process for adjusting network settings may differ,
depending on network conditions.
• Do not access a network that you are not authorized to use.
• Before you connect to a network, ensure your battery is fully
charged.
• When a DHCP server is not available you must make an autoip.
txt file and copy it to the inserted memory card to connect to
the network using Auto IP.
Network connection tips
• The quality of the network connection will be determined by
the AP.
• The further the distance between your camera and the AP, the
longer it will take to connect to the network.
• If a nearby device is using the same radio frequency signal as
your camera, it may interrupt your connection.
• If your AP name is not in English, the camera may not be able
to locate the device or the name may appear incorrectly.
• For network settings or a password, contact your network
administrator or network service provider.
• If a WLAN requires authentication from the service provider,
you may not be able to connect to it. To connect the WLAN,
contact your network service provider.
• Depending on the encryption type, the number of digits in the
password may differ.
• A WLAN connection may not be possible in all surroundings.
• The camera may display a WLAN enabled printer on the AP
List. You cannot connect to a network via a printer.
• You cannot connect your camera to a network and a TV
simultaneously. Also, you cannot view photos or videos on a TV
while connected to a network.
• Connecting to a network may incur additional charges. Costs
will vary based on the conditions of your contract.
Wireless network
134
Connecting to a WLAN and configuring network settings
Entering text
Learn how to enter text. The icons in the table below let you move
the cursor, change the case, etc. Press [D/c/F/t] to move
to a desired key, and then press [o] to enter the key.
Back Backspace
Icon Description
Delete the last letter.
Move the cursor.
In ABC mode, change the case.
Enter ".com".
Switch to Symbol mode.
Icon Description
Switch to ABC mode.
Enter a space.
o
Save the displayed text.
View the entering text guide.
•
You can use only the English alphabet, regardless of the display
language.
•
To move to
o
directly, press [
P
].
•
You can enter up to 64 characters.
Wireless network
135
Using photo or video sharing websites
Upload your photos or videos to file sharing websites. Available websites will be displayed on your camera.
Uploading photos or videos
1
Access the website with your camera.
2
Scroll to the files you want to upload, and then press
[
o
].
•
You can select up to 20 files. The total size must be 10 MB
or less.
3
Select
o
.
•
If you connected to the Facebook, select
o
Send.
•
If you connected to the Facebook, you can enter your
comments by selecting the Comment box. For information
about entering text, refer to "Entering text". (p. 134)
Accessing a website
1
Rotate the mode dial to
w
.
2
Select .
3
Select a website.
•
The camera will automatically attempt to connect to a WLAN
via the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN,
it will search for available AP devices. (p. 131)
4
Enter your ID and password, and then select Login.
•
For information about entering text, refer to "Entering text".
(p. 134)
•
To select an ID from the list, select an ID.
•
If you have previously logged in to the website, you may be
logged in automatically.
You must have an existing account on the file sharing website to use this
feature.
Wireless network
136
Using photo or video sharing websites
•
The maximum photo resolution you can upload is 2M, and the longest
video you can upload is 30 seconds at resolution or a video
recorded using . If the selected photo resolution is higher than
2M, it will be automatically resized to a lower resolution. You can
upload 10MB(total) or smaller photos or videos to social networking
services.
•
The method of uploading photos or videos may differ depending on
the selected website.
•
If you cannot access a website because of firewall or user
authentication settings, contact your network administrator or network
service provider.
•
Uploaded photos or videos may be automatically titled with the date
they were captured.
•
The speed of your internet connection may affect how quickly photos
upload or web pages open.
•
When there are no files in the camera memory, you cannot use this
feature.
•
You can also upload photos or videos to file sharing websites in
Playback mode by pressing [
m
], and then selecting Share(Wi-Fi)
a desired website.
Wireless network
137
Sending photos or videos via email
You can change settings in the email menu, and send photos or videos stored on the camera via email.
6
Select the Email box, enter your email address, and
then select
o
.
7
Select OK to save your changes.
•
To delete your information, select Reset.
Setting an email password
1
Rotate the mode dial to
w
.
2
Select .
3
Press [
m
].
4
Select Setting Password On.
•
To deactivate the password, select Off.
5
When the pop-up appears, press [
o
].
•
The pop-up disappears automatically even if you do not
press [
o
].
6
Enter a 4-digit password.
7
Enter the password again.
8
When the pop-up appears, press [
o
].
•
The pop-up disappears automatically even if you do not
press [
o
].
Changing email settings
In the email menu, you can change settings for storing your
information. You can also set or change the email password. For
information about entering text, refer to "Entering text". (p. 134)
Storing your information
1
Rotate the mode dial to
w
.
2
Select .
3
Press [
m
].
4
Select Sender Setting.
5
Select the Name box, enter your name, and then
select
o
.
Name
Email
Back
OK Reset
Sender Setting
Wireless network
138
Sending photos or videos via email
If you lost your password, you can reset it by selecting Reset on the
password setting screen. When you reset the information, previously saved
user’s setting information, email address, and recently sent email list will be
deleted.
Changing the email password
1
Rotate the mode dial to
w
.
2
Select .
3
Press [
m
].
4
Select Change Password.
5
Enter your current 4-digit password.
6
Enter a new 4-digit password.
7
Enter the new password again.
8
When the pop-up appears, press [
o
].
•
The pop-up disappears automatically even if you do not
press [
o
].
Sending photos or videos via email
You can send photos or videos stored on the camera via email.
For information about entering text, refer to "Entering text". (p. 134)
1
Rotate the mode dial to
w
.
2
Select .
•
The camera will automatically attempt to connect to a WLAN
via the most recently connected AP device and send the
email.
•
If the camera has not previously been connected to a WLAN, it
will search for available AP devices. (p. 131)
3
Select the Name(Email) box, enter your email address,
and then select
o
.
•
If you have previously saved your information, it will be inserted
automatically. (p. 137)
4
Select the Receiver box, enter an email address, and
then select
o
.
•
To use an address from the list of previous recipients, select
an address.
•
Select to add additional recipients. You can input up to
30 recipients.
•
Select to delete an address from the list.
Wireless network
139
Sending photos or videos via email
•
Even if a photo appears to have transferred successfully, errors with
the recipient’s email account may cause the photo to be rejected or
recognized as spam.
•
You may not be able to send an email if no network connection is
available or if your email account settings are incorrect.
•
The maximum photo resolution you can send is 2M and the longest
video you can upload is 30 seconds at resolution or a video
recorded using . If the selected photo resolution is higher than
2M, it will be automatically resized to a lower resolution. You can send
7MB (total) or smaller of photos and videos via email.
•
If you cannot send an email because of firewall or user authentication
settings, contact your network administrator or network service
provider.
•
When there are no files in the camera memory, you cannot use this
feature.
•
You can also send an email in Playback mode by pressing [
m
],
and then selecting Email.
5
Select
o
.
6
Scroll to files to send, and then press [
o
].
•
You can select up to 20 files. The total size must be 10 MB
or less.
7
Select
o
.
8
Select the Comment box, enter your comments, and
then select
o
.
9
Select Send.
Wireless network
140
Sending photos or videos to a smart phone
The camera connects to a smart phone that supports the MobileLink feature via a WLAN. You can easily send photos or videos to your
smart phone.
•
The MobileLink feature is supported by Galaxy S smart phones with the Android 2.2 OS or higher. If your smart phone uses the Android 2.1 OS, upgrade your
smart phone to Android 2.2 or higher. This feature is also supported by the 7 and 10.1 inch Galaxy Tab. This feature may be supported by other devices with
Android 2.2 or higher, but Samsung makes no guarantee of its functionality.
•
You should install the Samsung MobileLink application on your phone or device before using this feature. You can download the application from Samsung Apps or
Android market.
•
When there are no files in the camera memory, you cannot use this feature.
•
You can view up to 1,000 files and send up to 100 files at a time.
4
On the smart phone, turn on the Samsung MobileLink
application.
•
Read the on-screen instructions carefully to select and
connect to your camera.
•
The smart phone can connect to only one camera at a time.
5
On the camera, select OK.
6
On the smart phone, select files to send from the camera
to the smart phone.
7
On the smart phone, select Copy.
•
The camera will send the files.
1
On the camera, rotate the mode dial to
w
.
2
On the camera, select .
•
If the pop-up message that prompts you to download the
application appears, select OK.
3
On the camera, select NETWORK_MSG_A_5 or
NETWORK_MSG_A_6 to select files to share with the
smart phone.
•
Only the selected files will be displayed on the smart phone.
•
If you selected NETWORK_MSG_A_6, select NETWORK_
BUTTON_SHARE on the camera after selecting files to share.
Wireless network
141
Using a smart phone as a remote shutter release
The camera connects to a smart phone via a WLAN. Use the smart phone as a remote shutter release with the Remote Viewfinder feature.
The captured photo will display on the smart phone.
•
The Remote Viewfinder feature is supported by Galaxy S smart phones with the Android 2.2 OS or higher. If your smart phone uses the Android 2.1 OS, upgrade
your smart phone to Android 2.2 or higher. This feature is also supported by the 7 and 10.1 inch Galaxy Tab. This feature may be supported by other devices with
Android 2.2 or higher, but Samsung makes no guarantee of its functionality.
•
You should install the Remote Viewfinder application on your phone or device before using this feature. You can download the application from Samsung Apps or
Android market.
4
On the smart phone, set the following shooting options.
Icon Description
Flash option
Timer option
Photo size
•
While using this feature, some buttons are not available on
your camera.
•
The zoom button and the shutter button on your smart phone
will not function when using this feature.
•
Remote Viewfinder mode supports the and photo
sizes only.
1
On the camera, rotate the mode dial to
w
.
2
On the camera, select .
•
If the pop-up message that prompts you to download the
application appears, select OK.
3
On the smart phone, turn on the Remote Viewfinder
application.
•
Read the on-screen instructions carefully to select and
connect to your camera.
•
The smart phone can connect to only one camera at a time.
Wireless network
142
Using a smart phone as a remote shutter release
5
On the smart phone, touch and hold to focus.
•
The focus is automatically set to multi-AF.
6
Release to capture the photo.
•
The photo will be saved in your camera.
•
Touch the photo in the bottom of the screen to save it to the
smart phone. The photo will be resized to 640 X 360.
•
When you use this feature, the ideal distance between the camera
and the smart phone may vary, depending on your surroundings.
•
The smart phone must be within 23 ft/7 m of the camera to use this
feature.
•
It will take some time to capture the photo after you release on the
smart phone.
•
The Remote Viewfinder function will deactivate when:
- there is an incoming call on the smart phone
- either the camera or the smart phone turn off
- the memory is full
- either device loses its connection to the WLAN
- the Wi-Fi connection is poor or unstable
Wireless network
143
Uploading photos to a cloud server
You can upload your photos to SkyDrive. To upload photos, you must visit the Microsoft website and register before connecting your
camera.
4
Login with your ID and password.
•
For information about entering text, refer to "Entering text".
(p. 134)
•
If you connected to SkyDrive, refer to
"Using the login browser". (p. 132)
5
Scroll to the photos you want to upload, and then
press [
o
].
6
Select
o
.
•
You can also upload photos to a cloud server in Playback mode by
pressing [
m
], and then selectig a cloud server.
•
When there are no photos in the camera memory, you cannot use this
feature.
1
Rotate the mode dial to
w
.
2
Select .
3
Select SkyDrive.
•
If the pop-up message that prompts you to create an account
appears, select OK.
•
The camera will attempt to connect to a WLAN via the most
recently connected AP.
•
If the camera has not previously been connected to a WLAN,
it will search for available AP devices. (p. 131)
Wireless network
144
Using Auto Backup to send photos or videos
You can send photos or videos that you captured with the camera to a PC wirelessly. The Auto Backup feature works only with the
Windows OS.
Sending photos or videos to a PC
1
Rotate the mode dial to
w
.
2
Select .
•
If the guide message appears, press [
o
].
3
Press [
m
] to set options.
•
To turn off your PC automatically after the transfer is complete,
select Shut down PC after backup On.
4
Press [
o
] to start the backup.
•
To cancel sending, press [
o
].
•
You cannot select individual files to backup. This function
backs up only new files on the camera.
•
The backup's progress will be shown on the PC monitor.
•
When the transfer is completed, the camera will turn off
automatically in approximately 30 seconds. Select Cancel
to return to the previous screen and prevent the camera from
turning off automatically.
Installing the program for Auto Backup on
your PC
1
Install Intelli-studio and on the PC. (p. 120)
2
Connect the camera to the PC with the USB cable.
•
The camera stores information about the PC, so that the
camera can send files to the PC.
Before installing the program, ensure that the PC is connected to a network.
If no internet connection is available, you must install the program from the
provided CD.
Wireless network
145
Using Auto Backup to send photos or videos
•
If the PC supports the Wake on LAN (WOL) feature, you can turn on
the PC automatically by searching for the PC from your camera.
(p. 149)
•
When you connect the camera to the WLAN, select the AP that is
connected to the PC.
•
The camera will search for available access points even if you are
connecting to the same access point again.
•
If you turn off the camera or remove the battery while sending files, the
file transfer will be interrupted.
•
While you are using this feature, only [POWER] and [
o
] is available
on your camera.
•
You can connect only one camera to the PC at a time for sending
files.
•
The backup may be canceled due to network conditions.
•
Photos or videos can be sent to a PC one time only. Files cannot be
sent again even if you reconnect your camera to another PC.
•
When there are no files in the camera memory, you cannot use this
feature.
•
You must turn off Windows Firewall and any other firewalls before
using this feature.
•
You can send up to 1,000 files.
•
On the PC software, the server name must be entered in the Latin
alphabet and can contain no more than 48 characters.
Wireless network
146
Viewing photos or videos on a TV Link-enabled TV
TV Link is a technology for sharing media files between a camera and TV connected to the same AP device. With this technology, you can
view your photos or videos on a widescreen TV.
4
On the TV, search for the camera and browse the shared
photos or videos.
•
For information about searching for the camera and browsing
the photos or videos on the TV, refer to the TV user manual.
•
Videos may not play smoothly depending on the type of TV
or network condition. If this happens, re-record the video
in or quality and play it again. If videos do not
play smoothly on your TV over the wireless connection, try
connecting the camera to the TV with an A/V cable.
AP
1
Rotate the mode dial to
w
.
2
Select .
•
If the guide message appears, press [
o
].
•
The camera will automatically attempt to connect to a WLAN
via the most recently connected AP device.
•
If the camera has not previously been connected to a WLAN,
it will search for available AP devices. (p. 131)
3
Connect your TV to a wireless network via an AP device.
•
Refer to your TV’s user manual for more information.
Wireless network
147
Viewing photos or videos on a TV Link-enabled TV
•
You can share up to 1,000 photos or videos.
•
On a TV screen, you can view only photos or videos captured with
your camera.
•
The range of the wireless connection between your camera and a TV
may vary depending on the specifications of the AP.
•
If the camera is connected to 2 TVs, playback may be slower.
•
Photos or videos will be shared in their original sizes.
•
You can use this feature only with TV Link-enabled TVs.
•
Shared photos or videos will not be stored on the TV, but they can be
stored in the camera to meet the TV's specifications.
•
Transferring photos or videos to the TV may take some time
depending on the network connection, the number of files to be
shared, or sizes of the files.
•
If you power off the camera abnormally while viewing photos or videos
on a TV (for example, by removing the battery), the TV considers the
camera to still be connected.
•
The order of photos or videos on the camera may be different than
on the TV.
•
Depending on the number of photos or videos you want to share, it
may take some time to load your photos or videos and complete the
initial set-up process.
•
While viewing photos or videos on the TV, continuously using the TV
remote or performing additional operations on the TV may prevent this
feature from working properly.
•
If you reorder or sort files on the camera while viewing them on a TV,
you must repeat the initial set-up process to update the list of files
on the TV.
•
When there are no files in the camera memory, you cannot use this
feature.
Wireless network
148
Sending photos using Wi-Fi Direct
When the camera connects via a WLAN to a device that supports the Wi-Fi Direct function, you can send photos to the device. This feature
may not be supported on some devices.
5
On the device, allow the camera to connect to the
device.
•
The photo will be sent to the device.
•
When there are no photos in the camera memory, you cannot use
this feature.
•
If you cancel the connection attempt before it is complete, the camera
may not be able to reconnect to the device. In this case, update your
device with the latest firmware.
1
On the device, turn on the Wi-Fi Direct option.
2
On the camera, in Playback mode, scroll to a photo.
3
Press [
m
], and then select Share(Wi-Fi)
Wi-Fi Direct.
•
When in the single image view, you can send only one photo
at a time.
•
When in thumbnails view, you can select multiple photos by
scrolling to thumbnails, and then pressing [
o
]. Select
o
when you are finished selecting photos.
4
Select the device from the camera’s list of Wi-Fi Direct
devices.
•
Ensure that the device's Wi-Fi Direct option is turned on.
•
You can also select your camera from the device's list of Wi-Fi
Direct devices.
Wireless network
149
About the Wake on LAN (WOL) feature
With the WOL feature, you can automatically turn on or wake up a PC with your camera. This feature has been available for Samsung
desktop PCs for the last 5 years (not available for all-in-one PCs).
Any changes to your PC’s BIOS settings other than the ones described below may damage your PC. The manufacturer is not responsible for damage caused by your changing
your PC’s BIOS settings.
Setting the PC to wake up from sleep mode
1
Click Start, and then open the Control Panel.
2
Configure the network connection.
•
Windows 7:
Click Network and Internet Network and Sharing
Center Change adapter settings.
•
Windows Vista:
Click Network and Internet Network and Sharing
Center Manage network connections.
•
Windows XP:
Click Network and Internet Connection Network
Connection.
3
Right click Local Area, and then click Properties.
4
Click Configure the Power manage tab Allow this
device to wake the computer.
5
Click OK.
6
Restart the PC.
Wireless network
150
About the Wake on LAN (WOL) feature
Setting the PC to turn on
1
Turn on the PC, and then press F2 while the PC is
booting.
•
The BIOS setting menu will appear.
2
Select Advanced tab Power management Setup.
3
Select Resume on PME Enabled.
4
Press F10 to save your changes, and then continue
booting.
5
Click Start, and then open the Control Panel.
6
Configure the network connection.
•
Windows 7:
Click Network and Internet Network and Sharing
Center Change adapter settings.
•
Windows Vista:
Click Network and Internet Network and Sharing
Center Manage network connections.
•
Windows XP:
Click Network and Internet Connection Network
Connection.
7
Select the drivers for the network adapter.
8
Click the Advanced tab, and then set the WOL menus.
•
You cannot use this feature across a firewall or if a security program has
been installed.
•
To turn on the PC with the WOL feature, the PC must have an active
connection to the LAN. Ensure that the indicator light on the PC’s LAN
port is on indicating that the LAN connection is active.
•
Depending on your PC model, the camera may only be able to wake
the PC.
•
Depending on your PC’s OS or drivers, the names of the WOL setting
menu may vary.
- examples of setting menu names: Enable PME, Wake on LAN, etc.
- examples of setting menu values: Enable, Magic packet, etc.
Settings
152
Settings menu
Learn to configure your camera's settings.
3
Select an option.
Back Set
Volume
Start Sound
Shutter Sound
Beep Sound
AF Sound
Off
Low
Medium
High
On
4
Press [
m
] to return to the previous screen.
Accessing the settings menu
1
In Shooting or Playback mode, press [
m
].
2
Select
n
an item.
Exit Move
Medium
Off
On
On
On
Volume
Start Sound
Shutter Sound
Beep Sound
AF Sound
Settings
153
Settings menu
Using the settings menu
* Default
Item Description
Volume Set the volume of all sounds.
(Off, Low, Medium*, High)
Start Sound Set to emit a sound when you turn on your
camera. (Off*, On)
Shutter Sound Set to emit a sound when you press the shutter
button. (Off, On*)
Beep Sound Set to emit a sound when you press the buttons
or switch modes. (Off, On*)
AF Sound Set to emit a sound when you half-press the
shutter button. (Off, On*)
Function
Description
Display a brief description of an option a menu.
(Off, On*)
Grid Line Select a guide to help you compose a scene.
(Off*, 3 X 3, 2 X 2, Cross, Diagonal)
Date/Time
Display
Set whether or not to display the date and time on
the camera's display. (Off*, On)
Display
Brightness
Adjust the brightness of the screen.
(Auto*, Dark, Normal, Bright)
Normal is fixed in Playback mode even if you have
selected Auto.
* Default
Item Description
Quick View
Set the duration for reviewing a captured image
before returning to the Shooting mode.
(Off, 1 sec*, 3 sec)
Power Save
If you perform no operations for 30 seconds, the
camera automatically switches to Power save
mode. (Off, On*)
•
In Power save mode, press any button other
than [POWER] to resume using the camera.
•
Even if you do not set the Power save mode,
the screen will dim 30 seconds after the last
operation to save power.
Device
Information
See the Mac address and serial number of your
camera.
Language Set a language for the display text.
Time Zone
Set the time zone for your location. When you
travel to another country, select Visit, and then
select the appropriate time zone. (Home*, Visit)
Date/Time Set Set the date and time.
Date Type
Set a date format. (YYYY/MM/DD*,
MM/DD/YYYY, DD/MM/YYYY)
The default date type may differ depending on the
language selected.
Settings
154
Settings menu
* Default
Item Description
File No.
Specify how to name files.
•
Reset: Set the file number to start from 0001
when you insert a new memory card, format a
memory card, or delete all files.
•
Series*: Set the file number to resume from
the previous file number when you insert a new
memory card, format a memory card, or delete
all files.
•
The default name of the first folder is 100PHOTO
and the default name of the first file is
SAM_0001.
•
The file number increases one at a time from
SAM_0001 to SAM_9999.
•
The folder number increases one at a time from
100PHOTO to 999PHOTO.
•
The maximum number of files that can be stored
in one folder is EX2_FILENO_MAXIMUM.
•
The camera defines file names according to
the Design rule for Camera File system (DCF)
standard. If you intentionally change file names,
the camera may not play back the files.
* Default
Item Description
Auto Power Off
Set the camera to automatically turn off when you
perform no operations for a specified period.
(Off, 1 min, 3 min*, 5 min, 10 min)
•
Your settings will not change when you replace
the battery.
•
The camera will not automatically turn off when
the camera is connected to a computer or printer,
and when you are playing a slide show or videos.
Smart Link (Wi-Fi
Button)
Set a Wi-Fi function to launch when you press
[
t
]. (MobileLink*, Remote Viewfinder,
Social Sharing, Email, SkyDrive,
Auto Backup, TV Link)
AF Lamp Set a light to automatically turn on in dark places
to help you focus. (Off, On*)
EX2_
CONVERSION_
LENS
Set to use optional conversion lens. (Off*, On)
Settings
155
Settings menu
* Default
Item Description
Format
Format the memory card. Formatting will delete all
files, including protected files. (No, Yes)
Errors can occur if you use a memory card formatted by
another brand of camera, a memory card reader, or a
computer. Please format memory cards in the camera
before using them to capture photos.
Reset
Reset menus and shooting options. Date and
time, language, and video output settings will not
be reset. (No, Yes)
Anynet+ (HDMI-
CEC)
Turn on to control the camera with a TV remote
control when you connect it to an HDTV that
supports the Anynet+(CEC) profile.
•
Off: View files without using an HDTV remote
control.
•
On*: Control the camera with an HDTV remote
control.
* Default
Item Description
HDMI Size
Set the resolution of photos when the camera
plays back files on an HDTV via the HDMI cable.
(NTSC: 1080i*, 720p, 480p/
PAL: 1080i*, 720p, 576p)
•
If the HDTV does not support the selected
resolution, the HDTV automatically selects the
next lower resolution.
•
If you select 480p or 576p, the playback menus
and Smart Album will not be available when you
connect the camera to a TV.
Video Out
Set the video signal output for your region.
•
NTSC: USA, Canada, Japan, Korea, Taiwan,
Mexico
•
PAL (supports only BDGHI): Australia, Austria,
Belgium, China, Denmark, England, Finland,
Germany, Italy, Kuwait, Malaysia, Netherlands,
New Zealand, Norway, Singapore, Spain,
Sweden, Switzerland, Thailand
Error messages
……………………………………… 157
Camera maintenance
………………………………… 159
Cleaning your camera
……………………………… 159
Using or storing the camera
………………………… 160
About memory cards
……………………………… 162
About the battery
…………………………………… 165
Using optional accessories
………………………… 169
Using optional flash units
…………………………… 169
Using an optional optical viewfinder
………………… 169
Using an optional conversion lens
…………………… 170
Using the shutter release
…………………………… 171
Using the zoom microphone
………………………… 171
Before contacting a service center
………………… 172
Camera specifications
……………………………… 175
Glossary
……………………………………………… 179
FCC notice
…………………………………………… 184
Declaration sentence in official languages
………… 187
Index
…………………………………………………… 189
Appendix
Get information about error messages, specifications, and
maintenance.
Appendix
157
Error messages
When the following error messages appear, try these remedies.
Error message Suggested remedies
Connection failed.
•
The camera cannot connect to the network
using the selected access point. Select
another AP and try again.
•
The camera has failed to connect to the other
camera. Try connecting again.
File system not
supported.
Your camera does not support the FAT file
structure of the inserted memory card. Format
the memory card on the camera.
Card not
supported.
The inserted memory card is not supported
by your camera. Insert a SD, SDHC, or SDXC
memory card.
File Error Delete the damaged file or contact a service
center.
Memory Full Delete unnecessary files or insert a new memory
card.
Transfer failed.
•
The camera has failed to send a photo to the
other camera. Try sending again.
•
The camera has failed to send an email or
transfer a photo to a TV Link device. Check
the network connection and try again.
Error message Suggested remedies
Card Error
•
Turn off your camera, and then turn it on
again.
•
Remove your memory card, and then insert
it again.
•
Format your memory card.
Low Battery Insert a charged battery or recharge the battery.
Invalid password.
The password for transferring files to another
camera is wrong. Enter the correct password
again.
Photo reception
failed.
The camera has failed to receive a photo from
the sending camera. Ask the other person to
send the file again.
No Image File Capture photos or insert a memory card that
contains some photos.
Photo transfer
failed.
Network connection disconnected while
transferring photos. Try turning on the TV Link
feature again.
Device
disconnected.
Network connection disconnected while
transferring photos. Select a TV Link device
again.
Appendix
158
Error messages
Error message Suggested remedies
Initialization failed.
•
Turn on TV Link enabled devices on the
network.
•
The camera has failed to locate a TV
Linkenabled device.
Card Locked
You can lock an SD, SDHC, or SDXC card to
prevent files from being deleted. Unlock the card
when shooting.
DCF Full Error
File names do not match the DCF standard.
Transfer the files from the memory card to your
computer and format the card. Then, open the
Settings menu and select File No. Reset.
(p. 154)
Appendix
159
Camera maintenance
Camera body
Wipe gently with a soft, dry cloth.
•
Never use benzene, thinners, or alcohol to clean the device. These
solutions can damage the camera or cause it to malfunction.
•
Do not press on the lens cover or use a blower brush on the lens
cover.
Cleaning your camera
Camera lens and display
Use a blower brush to remove dust and wipe the lens gently with
a soft cloth. If any dust remains, apply lens cleaning liquid to a
piece of lens cleaning paper and wipe gently.
Appendix
160
Camera maintenance
Using on beaches or shores
• Protect your camera from sand and dirt when you use it on
beaches or in similar areas.
• Your camera is not waterproof. Do not handle the battery,
adapter, or memory card with wet hands. Operating the camera
with wet hands may cause damage to your camera.
Storing for extended period of time
• When you store the camera for an extended period, place it in a
sealed container with an absorbent material, such as silica gel.
• Remove the batteries from your camera when storing it for an
extended period. Installed batteries may leak or corrode over
time and cause serious damage to your camera.
• Over time, unused batteries will discharge and must be
recharged before use.
• The present date and time can be initialized when the camera
is turned on after the camera and battery have been separated
for over 40 hours.
Using or storing the camera
Inappropriate places to use or store the camera
• Avoid exposing the camera to very cold or very hot
temperatures.
• Avoid using your camera in areas with extremely high humidity,
or where the humidity changes drastically.
• Avoid exposing the camera to direct sunlight and storing it in
hot, poorly-ventilated areas, such as in a car during summer
time.
• Protect your camera and the display from impact, rough
handling, and excessive vibration to avoid serious damage.
• Avoid using or storing your camera in dusty, dirty, humid, or
poorly-ventilated areas to prevent damage to moving parts and
internal components.
• Do not use your camera near fuels, combustibles, or flammable
chemicals. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the camera or
its accessories.
• Do not store the camera where there are mothballs.
Appendix
161
Camera maintenance
• Never place cameras, batteries, chargers, or accessories near,
on, or in heating devices, such as microwave ovens, stoves, or
radiators. These devices may be deformed and can overheat
and cause a fire or explosion.
• Do not expose the lens to direct sunlight, as this may discolor
the image sensor or cause it to malfunction.
• Protect the lens from fingerprints and scratches. Clean the lens
with a soft, clean, debris-free lens cloth.
• The camera may turn off if struck or dropped. This is to protect
the memory card. Turn on the camera to use it again.
• While you use the camera, it may heat up. This is normal and
should not affect your camera’s lifespan or performance.
• When you use the camera in low temperatures, it may take
some time to turn on, the color of the display may be changed
temporarily, or after-images may appear. These conditions are
not malfunctions and they will correct themselves when the
camera is returned to milder temperatures.
• Paint or metal on the outside of the camera may cause
allergies, itchy skin, eczema, or swelling for people with
sensitive skin. If you experience any of these symptoms, stop
using the camera immediately and consult a doctor.
• Do not insert foreign objects into any of your camera’s
compartments, slots, or access points. Damage due to
improper use may not be covered by your warranty.
• Do not allow unqualified personnel to service the camera or
attempt to service the camera yourself. Any damage that results
from unqualified service is not covered by your warranty.
Using the camera with caution in humid environments
When you transfer the camera from a cold environment to a warm
one, condensation can form on the lens or internal components
of the camera. In this situation, turn off the camera and wait for at
least 1 hour. If condensation forms on the memory card, remove
the memory card from the camera and wait until all moisture has
evaporated before reinserting it.
Other cautions
• Do not swing your camera by the strap. This may cause injury
to yourself or others or damage to your camera.
• Do not paint your camera, as paint can clog moving parts and
prevent proper operation.
• Turn off the camera when not using it.
• Your camera contains delicate parts. Avoid impacts to the
camera.
• Protect the display from external force by keeping it in the case
when not in use. Protect the camera from scratches by keeping
it away from sand, sharp implements, or loose change.
• Do not use the camera if the screen is cracked or broken.
Broken glass or acrylic could cause injury to your hands and
face. Take the camera to a Samsung service center to have it
repaired.
Appendix
162
Camera maintenance
About memory cards
Supported memory cards
Your camera supports SD, SDHC, or SDXC memory cards.
Terminal
Write-protect switch
Label (front)
You can prevent files from being deleted by using the
write-protect switch on an SD, SDHC, or SDXC card. Slide the
switch down to lock or slide it up to unlock. Unlock the card
when capturing photos and videos.
Memory card
Memory card adapter
To use micro memory cards with this product, a PC, or a memory
card reader, insert the card into an adapter.
Memory card capacity
The memory capacity may differ depending on shooting scenes
or shooting conditions. These capacities are based on a 2 GB
SD card:
Size Super Fine Fine Normal
277 313 503
254 349 558
286 392 623
335 457 721
333 456 719
512 691 1,060
819 1,081 1,588
1,095 1,418 2,009
2,165 2,610 3,284
Appendix
163
Camera maintenance
Video
Size 480fps 240fps 120fps 30fps
1920 X 1080 ---
Approx.
19' 05"
1280 X 720 ---
Approx.
29' 38"
640 X 480 ---
Approx.
57' 16"
For Sharing ---
Approx.
716' 50"
640 X 480 --
Approx.
24' 52" -
384 X 288 -Approx.
32' 49" --
192 X 144
Approx.
26' 02" ---
* The figures above are measured without using the zoom function. Available
recording time may vary if you use the zoom. Several videos were recorded
in succession to determine the total recording time.
Size RAW RAW +
S.Fine RAW + Fine RAW +
Normal
73 51 59 69
74 54 61 71
76 57 64 73
78 60 67 75
78 60 67 75
83 69 74 80
87 77 81 85
89 81 84 87
91 87 88 90
Appendix
164
Camera maintenance
• Prevent memory cards from making contact with liquids, dirt, or
foreign substances. If dirty, wipe the memory card clean with a
soft cloth before you insert the memory card in your camera.
• Do not allow liquids, dirt, or foreign substances to come in
contact with memory cards or the memory card slot. Doing so
may cause memory cards or the camera to malfunction.
• When you carry a memory card, use a case to protect the card
from electrostatic discharges.
• Transfer important data to other media, such as a hard disk,
CD, or DVD.
• When you use the camera for an extended period, the memory
card may become warm. This is normal and does not indicate
a malfunction.
The manufacturer is not responsible for any loss of data.
Cautions when using memory cards
• Avoid exposing memory cards to very cold or very hot
temperatures (below 0 °C/32 °F or above 40 °C/104 °F).
Extreme temperatures can cause memory cards to malfunction.
• Insert a memory card in the correct direction. Inserting a
memory card in the wrong direction may damage your camera
and memory card.
• Do not use memory cards that have been formatted by other
cameras or by a computer. Reformat the memory card with
your camera.
• Turn off the camera when you insert or remove the memory
card.
• Do not remove the memory card or turn off your camera while
the lamp is blinking, as this may damage your data.
• When the lifespan of a memory card has expired, you cannot
store any more photos on the card. Use a new memory card.
• Do not bend, drop, or subject memory cards to heavy impact
or pressure.
• Avoid using or storing memory cards near strong magnetic
fields.
• Avoid using or keeping memory cards in areas with high
temperature, high humidity, or corrosive substances.
Appendix
165
Camera maintenance
Battery life
Average shooting time/
Number of photos
Test conditions (when the battery is fully
charged)
Photos
Approximately
XXX min/
Approximately
XXX photos
The battery life was measured under
the following conditions: in
p
mode, in
darkness, resolution, Fine quality,
OIS on.
1. Set the flash option to Fill in, take a
single shot, and zoom in or out.
2. Set the flash option to Off, take a
single shot, and zoom in or out.
3. Perform steps 1 and 2, waiting
30 seconds between each step.
Repeat the process for 5 minutes,
and then turn off the camera for
1 minute.
4. Repeat steps 1 to 3.
Videos Approximately
XXX min
Record videos at resolution and
30 FPS.
•
The figures above are measured by Samsung’s standards. Your results may
differ, depending on your actual usage.
•
Several videos were recorded in succession to determine the total recording
time.
•
When using network functions, the battery will be depleted more quickly.
About the battery
Use only Samsung-approved batteries.
Battery specifications
Specification Description
Model SLB-10A
Type Lithium-ion battery
Cell capacity 1030 mAh
Voltage XXX V
Charging time* (when the camera is
switched off) Approximately 240 min
* Charging the battery by connecting it to a computer may take longer.
Appendix
166
Camera maintenance
Low battery message
When the battery has fully discharged, the battery icon will turn
red and the "Low Battery" message will appear.
Notes about using the battery
• Avoid exposing batteries to very cold or very hot temperatures
(below 0 °C/32 °F or above 40 °C/104 °F). Extreme
temperatures can reduce the charging capacity of your
batteries.
• When you use the camera for an extended period, the area
around the battery chamber may become warm. This does not
affect the normal use of the camera.
• Do not pull the power supply cord to disconnect the plug from
the power outlet, as this may cause a fire or electric shock.
• In temperatures below 0 °C/32 °F, battery capacity and battery
life may decrease.
• Battery capacity may decrease in low temperatures but will
return to normal in milder temperatures.
Cautions about using the battery
Protect batteries, chargers, and memory cards from
damage
Prevent batteries from making contact with metal objects, as this
can create a connection between the + and – terminals of your
battery and lead to temporary or permanent battery damage and
may cause a fire or electric shock.
Notes about charging the battery
• If the indicator light is off, make sure that the battery is inserted
correctly.
• If the camera is on while charging, the battery may not fully
charge. Turn off the camera before charging the battery.
• Do not use your camera when you charge the battery. This may
cause a fire or electric shock.
• Do not pull the power supply cord to disconnect the plug from
the power outlet, as this may cause a fire or electric shock.
• Let the battery charge for at least 10 minutes before turning on
the camera.
• If you connect the camera to an external power source while
the battery is depleted, using some high energy-consuming
functions will cause the camera to turn off. To use the camera
normally, recharge the battery.
Appendix
167
Camera maintenance
• If you reconnect the power cable when the battery is fully
charged, the status lamp turns on for approximately 30 minutes.
• Using the flash or recording videos depletes the battery quickly.
Charge the battery until the red status lamp turns off.
• If the status lamp blinks in red, reconnect the cable, or remove
the battery and insert it again.
• If you charge the battery when the cable is overheated or
the temperature is too high, the status lamp may blink in red.
Charging will start when the battery cools down.
• Overcharging batteries may shorten battery life. After charging is
finished, disconnect the cable from your camera.
• Do not bend or place heavy objects on the AC cable. Doing so
may damage the cable.
Notes about charging with a computer connected
• Use only the provided USB cable.
• The battery may not charge when:
-
you use a USB hub
-
other USB devices are connected to your computer
-
you connect the cable to the port on the front side of your
computer
-
the USB port of your computer does not support the power output
standard (5 V, 500 mA)
Handling and disposing of batteries and chargers
with care
• Never dispose of batteries in a fire. Follow all local regulations
when you dispose of used batteries.
• Never place batteries or cameras on or in heating devices,
such as microwave ovens, stoves, or radiators. Batteries may
explode when they are overheated.
Appendix
168
Camera maintenance
•
Do not disassemble or puncture the battery with any
sharp object.
•
Avoid exposing the battery to high pressure or crushing
forces.
•
Avoid exposing the battery to major impacts, such as
dropping it from high places.
•
Do not expose the battery to temperatures of
60 °C (140 °F) or above.
•
Do not allow the battery to come in contact with moisture
or liquids.
•
Do not expose the battery to sources of excessive heat
such as sunshine, fire or the like.
Disposal guidelines
•
Dispose of the battery with care.
•
Do not dispose of the battery in a fire.
•
Disposal regulations may differ by country or region.
Dispose of the battery in accordance with all local and
federal regulations.
Guidelines for charging the battery
Charge the battery only by the method described in
this user manual. The battery can ignite or explode if
not charged properly.
Personal injury or death can occur if the battery is
handled carelessly or improperly. For your safety,
follow these instructions for proper battery handling:
•
The battery can ignite or explode if not handled properly. If
you notice any deformities, cracks, or other abnormalities
in the battery, immediately discontinue use of the battery
and contact a service center.
•
Use only authentic, manufacturer-recommend battery
chargers and adapters and charge the battery only by the
methods described in this user manual.
•
Do not place the battery near heating devices or expose
it to excessively warm environments, such as the inside
of an enclosed car in the summertime.
•
Do not place the battery in a microwave oven.
•
Avoid storing or using the battery in hot, humid places,
such as spas or shower enclosures.
•
Do not rest the device on flammable surfaces, such as
bedding, carpets, or electric blankets for a prolonged
period.
•
When the device is switched on, do not leave it in any
confined space for a prolonged period.
•
Do not allow battery terminals to come in contact with
metallic objects, such as necklaces, coins, keys, or
watches.
•
Use only authentic, manufacturer-recommended, Lithium-
ion replacement batteries.
Appendix
169
Using optional accessories
Using an optional optical viewfinder
Attach an optional optical viewfinder to the camera accessory
shoe. Remove the accessory shoe cover and mount the optical
viewfinder on the accessory shoe.
Using optional flash units
Attach an optional flash unit to the camera accessory shoe.
Remove the accessory shoe cover and mount the flash unit on
the accessory shoe.
•
For details about the flash unit, see the manual provided with the
flash unit.
•
Your camera is compatible with the following types of flash units:
SEF220A, SEF42A
•
When the optional flash unit is attached, do not pop the default flash
up.
Appendix
170
Using optional accessories
2
Mount the conversion lens by turning it clockwise until it
locks into place.
3
In Shooting or Playback mode, press [
m
].
4
Select
n
Conversion lens On.
•
After setting to use the conversion lens, the optical and digital zooms
are not available.
•
If you do not set Conversion lens to On after attaching the conversion
lens, rotating [Zoom] left or right will turn your camera off.
Using an optional conversion lens
You can increase your camera’s range and depth of field by
attaching an optional conversion lens designed only for Samsung
cameras.
1
Remove the stock camera ring by turning it counter-
clockwise.
Appendix
171
Using optional accessories
Using the shutter release
Use an optional shutter release to minimizes camera shake and
allow you to capture clearer photos at slower shutter speeds. For
details about the shutter release, see the manual provided with
the shutter release.
Using the zoom microphone
Use an optional zoom microphone to reduce noise surroundings.
For details about the zoom microphone, see the manual provided
with the zoom microphone.
Appendix
172
Before contacting a service center
If you are having trouble with your camera, try these troubleshooting procedures before you contact a service center. If you have attempted
the suggested remedy and are still having problems with your device, contact your local dealer or service center.
When you leave your camera at a service center, be sure to also leave the other components that may have contributed to the malfunction, such as the memory card and battery.
Situation Suggested remedies
Cannot capture photos
•
There is no space on the memory card.
Delete unnecessary files or insert a new
card.
•
Format the memory card.
•
The memory card is defective. Get a new
memory card.
•
Make sure that the camera is switched
on.
•
Charge the battery.
•
Make sure that the battery is inserted
correctly.
The camera freezes Remove the battery and insert it again.
The camera heats up
While you use the camera, it may heat up.
This is normal and should not affect your
camera’s lifespan or performance.
The flash does not
work
•
The flash option may be set to Off.
(p. 69)
•
You cannot use the flash in some modes.
Situation Suggested remedies
Cannot turn on the
camera
•
Ensure that the battery is inserted.
•
Ensure that the battery is inserted
correctly. (p. 22)
•
Charge the battery.
The power turns off
suddenly
•
Charge the battery.
•
Your camera may be in Power save
mode. (p. 153)
•
The camera may turn off to prevent the
memory card from being damaged due
to an impact. Turn on your camera again.
The camera is losing
battery power quickly
•
The battery may lose power more quickly
in low temperatures (below 0 °C/32 °F).
Keep the battery warm by putting it into
your pocket.
•
Using the flash or recording videos
depletes the battery quickly. Recharge
if needed.
•
Batteries are consumable parts that must
be replaced over time. Get a new battery
if the battery life is diminishing quickly.
Appendix
173
Before contacting a service center
Situation Suggested remedies
The flash fires
unexpectedly
The flash may fire due to static electricity.
The camera is not malfunctioning.
The date and time are
incorrect
Set the date and time in the display settings.
(p. 153)
The display or buttons
do not work Remove the battery, and then insert it again.
The camera display
responds poorly
If you use your camera at very low
temperatures, it may cause the camera
screen to malfunction or discolor. For better
performance of your camera screen, use
your camera in moderate temperatures.
The memory card has
an error
•
Turn off your camera, and then turn it
on again.
•
Remove your memory card, and then
insert it again.
•
Format your memory card.
See “Cautions when using memory cards”
for more detail. (p. 164)
Cannot play back files
If you change the name of a file, your
camera may not play the file (the name of
the file should meet the DCF standard). If
you encounter this situation, play back the
files on your computer.
Situation Suggested remedies
The photo is blurry
•
Make sure that the focus option you set
is suitable for close-up shots. (p. 72)
•
Make sure that the lens is clean. If not,
clean the lens. (p. 159)
•
Make sure that the subject is within range
of the flash. (p. 176)
The colors in the photo
do not match the actual
scene
An incorrect White Balance can create
unrealistic color. Select the proper White
Balance option to suit the light source.
(p. 84)
The photo is too bright
Your photo is overexposed.
•
Turn off the flash. (p. 69)
•
Adjust the ISO sensitivity. (p. 71)
•
Adjust the exposure value. (p. 82)
The photo is too dark
Your photo is underexposed.
•
Turn on the flash. (p. 69)
•
Adjust the ISO sensitivity. (p. 71)
•
Adjust the exposure value. (p. 82)
The TV does not
display your photos
•
Make sure that the camera is correctly
connected to the TV with the A/V cable.
•
Make sure that your memory card
contains photos.
Appendix
174
Before contacting a service center
Situation Suggested remedies
Your computer does
not recognize your
camera
•
Make sure that the USB cable is
connected correctly.
•
Make sure that your camera is switched
on.
•
Make sure that you are using a supported
operating system.
Your computer
disconnects the
camera while
transferring files
The file transmission may be interrupted by
static electricity. Disconnect the USB cable
and connect it again.
Your computer cannot
play videos
Videos may not play on some video player
programs. To play video files captured with
your camera, install and use the Intelli-studio
program on your computer. (p. 120)
Intelli-studio is not
functioning properly
•
End Intelli-studio and restart the program.
•
You cannot use Intelli-studio on
Macintosh computers.
•
Depending on your computer's
specifications and environment, the
program may not launch automatically. In
this case, click Start My Computer
Intelli-studio iStudio.exe on your
computer.
Situation Suggested remedies
Your TV or computer
cannot display photos
and videos that are
stored on an SDXC
memory card.
SDXC memory cards use the exFAT file
system. Ensure that the external device is
compatible with the exFAT file system before
connecting the camera to the device.
Your computer does
not recognize an SDXC
memory card.
SDXC memory cards use the exFAT file
system. To use SDXC memory cards on
a Windows XP computer, download and
update the exFAT file system driver from the
Microsoft website.
Cannot set the DPOF
for RAW files You cannot set the DPOF for RAW files.
Cannot lock the
exposure value by
pressing [
L
]
You cannot lock the exposure value in some
shooting modes.
External flash or zoom
microphone does not
work
Ensure that the external device is properly
mounted and turned on.
Appendix
175
Camera specifications
Range
Wide (W) Tele (T)
Normal (AF) 40 cm-infinity 100 cm-infinity
Macro 1–40 cm 40–100 cm
Auto Macro 1 cm-infinity 40 cm-infinity
Manual Focus 1 cm-infinity 40 cm-infinity
Shutter speed
•
Auto: 1/8-1/2,000 sec.
•
Program: 1-1/2,000 sec.
•
Manual: 16-1/2,000 sec.
•
Night: 8-1/2,000 sec.
Exposure
Control Program AE, Shutter AE, Aperture Priority AE,
Manual Exposure
Metering Multi, Spot, Center-weighted, Face Detection
Compensation ±2EV (1/3 EV Step)
ISO equivalent
•
1 Step: Auto, ISO 80, ISO 100, ISO 200, ISO 400,
ISO 800, ISO 1600, ISO 3200, ISO 6400*,
ISO 12800*
•
1/3 Step: ISO 80, ISO 100, ISO 125, ISO 160,
ISO 200, ISO 250, ISO 320, ISO 400, ISO 500,
ISO 640, ISO 800, ISO 1000, ISO 1250, ISO
1600, ISO 2000, ISO 2500, ISO 3200, ISO 6400*,
ISO 12800*
* Available only when ISO Extend is activated.
Image sensor
Type 1/1.7 (Approximately 10.9 mm) CMOS
Effective pixels Approximately 12.4 mega-pixels
Total pixels Approximately 12.76 mega-pixels
Lens
Focal length Schneider-KREUZNACH Lens f = 5.2–17.2 mm
(35 mm film equivalent: 24–80 mm)
F-stop range F1.4 (W)–F2.7 (T)
Digital zoom Still image mode: 1.0–3.0X (Smart zoom: 4.4)
Display
Type TFT LCD
Feature 3.0" (7.62 cm) VGA, Rotating
Focusing
Type
TTL auto focus (Multi AF, Center AF, Selection AF,
Manual Focus, Face Detection AF, Tracking AF,
Smart Face Recognition AF)
Appendix
176
Camera specifications
Flash
Mode Auto, Red-eye, Fill in, Slow Sync, Off, Red-eye Fix
Range
•
Wide: 0.3–3.5 m (ISO Auto)
•
Tele: 0.5–1.9 m (ISO Auto)
Recharging time Approximately 4 sec.
Shake reduction
DUAL IS [Optical Image Stabilization (OIS) + Digital Image Stabilization (DIS)]
Effect
Photo Shooting
mode
•
Smart Filter: Normal, Miniature, Vignetting,
Soft Focus, Old Film, Half Tone Dot, Sketch,
Fish-eye, Classic, Retro, Oil Painting, Cartoon,
Ink Painting, Cross Filter, Zooming Shot
•
Image Adjust: Contrast, Sharpness, Saturation
Video Shooting
mode
Smart Filter: Normal, Palette Effect 1, Palette Effect 2,
Palette Effect 3, Palette Effect 4, Miniature, Vignetting,
Half Tone Dot, Sketch, Fish-eye, Classic, Retro
White Balance
Auto WB, Daylight, Cloudy, Fluorescent_H, Fluorescent_L, Tungsten,
Custom Set, Color Temp.
Date Imprinting
Date & Time, Date, Off
Shooting
Photos
•
Modes: Smart Auto (Portrait, Night Portrait,
Backlight Portrait, Night, Backlight, Landscape,
White, Natural Green, Blue Sky, Sunset, Macro,
Macro text, Macro Color, Tripod, Action, Fireworks,
Candle, Spotlight, Spotlight (Macro), Spotlight
(Portrait)), Program, Aperture Priority, Shutter Priority,
Manual, DUAL IS, Scene (3D Photo, HDR, Magic
Frame, Beauty Shot, Night, Landscape, Text,
Sunset, Dawn, Backlight, Beach & Snow, Zooming
Shot), Panorama (Live Panorama, Action Panorama,
3D Panorama)
•
Burst: Single, High-speed (10fps, 5fps, 3fps),
Precapture, Bracket (WB, AE), Timer
•
Timer: 10 Sec, 2 Sec
•
ND Filter effect : On, Off
Videos
•
Modes: Smart Scene Detection (Landscape,
Blue Sky, Natural Green, Sunset), Movie, Magic
Plus (Picture in Picture, Movie Filter)
•
Format: MP4 (H.264) (Max recording time: XXX min)
•
Size: 1920X1080, 1280X720, 640X480,
320 X 240
•
High-speed: 192 X 144, 384 X 288, 640 X 480
•
Sound Alive: Sound Alive On, Sound Alive Off,
Mute
•
Image Stabilizer: Off, OIS, DUAL IS
•
Video editing (embedded): Pause during recording,
Still image capture
Appendix
177
Camera specifications
Playback
Photos
•
Type: Single image, Thumbnails, Multi Slide Show
with Music and Effect, Movie clip, Smart Album*,
Creative Movie Maker
* Smart Album category: Type, Date, Week, Face
•
Edit: Resize, Rotate, Image Adjust, Smart Filter, Trim
•
Effect: Image Adjust (Red-eye Fix, Face Retouch,
Brightness, Contrast, Saturation, Add Noise),
Smart Filter (Normal, Miniature, Vignetting,
Soft Focus, Old Film, Half Tone Dot, Sketch,
Fish-eye, Classic, Retro, Oil Painting, Cartoon,
Ink Painting, Cross Filter, Zooming Shot)
Videos Edit: Creative Movie Maker, Still image capture, Time
trimming
Storage
Media
External memory (Optional): SD card (1-2 GB
guaranteed), SDHC card (up to 32 GB guaranteed),
SDXC card (up to 64 GB guaranteed)
File format
•
Still Image: JPEG (DCF), EXIF 2.21, DPOF 1.1,
PictBridge 1.0
•
Movie Clip: MP4 (Video: MPEG-4.AVC/H.264,
Audio: AAC)
Image size
For 2 GB SD: Number of photos
Super Fine Fine Normal
4000 X 3000 277 313 503
4000 X 2672 254 349 558
4000 X 2248 286 392 623
3264 X 2448 335 457 721
2832 X 2832 333 456 719
2592 X 1944 512 691 1,060
1984 X 1488 819 1,081 1,588
1920 X 1080 1,095 1,418 2,009
1024 X 768 2,165 2,610 3,284
RAW RAW +
S.Fine
RAW +
Fine
RAW +
Normal
4000 X 3000 73 51 59 69
4000 X 2672 74 54 61 71
4000 X 2248 76 57 64 73
3264 X 2448 78 60 67 75
2832 X 2832 78 60 67 75
2592 X 1944 83 69 74 80
1984 X 1488 87 77 81 85
1920 X 1080 89 81 84 87
1024 X 768 91 87 88 90
These figures are measured under Samsung’s
standard conditions. Your results may vary depending
on the shooting conditions and camera settings.
Appendix
178
Camera specifications
Wireless network
Social Sharing, Auto Backup, Remote Viewfinder, Allshare play, TV Link,
Samsung Mobile Link, Email, Cloud, Wi-Fi Direct
Interface
Digital output
connector USB 2.0
Audio input/output Internal speaker (Mono), Microphone (Stereo)
Video output
•
A/V: NTSC, PAL (selectable)
•
HDMI 1.4: NTSC, PAL (selectable)
DC power input
connector 4.2 V
Power source
Rechargeable
battery Lithium-ion battery (SLB-10A, 1030 mAh)
Connector type Micro USB (7 pin)
The power source may differ depending on your region.
Dimensions (W X H X D)
111.9 X 62.0 X 28.9 mm (without protrusions)
Weight
294.3 g (without battery and memory card)
Operating Temperature
0–40 °C °C (32-104 °F)
Operating Humidity
5–85 %
Software
Intelli-studio, Creative Movie Maker, Samsung Raw Converter
Specifications may change without notice to improve performance.
Appendix
179
Glossary
DCF (Design rule for Camera File system)
A specification to define a file format and file system for digital
cameras created by the Japan Electronics and Information
Technology Industries Association (JEITA).
Depth of field
The distance between the nearest and farthest points that can
be acceptably focused in a photograph. Depth of field varies with
lens aperture, focal length, and distance from the camera to the
subject. Selecting a smaller aperture, for example, will increase
the depth of field and blur the background of a composition.
Digital zoom
A feature that artificially increases the amount of zoom available
with a zoom lens (Optical zoom). When using the Digital zoom,
the image quality will deteriorate as the magnification increases.
DPOF (Digital Print Order Format)
A format for writing printing information, such as selected images
and number of prints, on a memory card. DPOF-compatible
printers, sometimes available at photo shops, can read the
information from the card for convenient printing.
AEB (Auto Exposure Bracket)
This feature automatically captures several images at different
exposures to help you capture a properly-exposed image.
AF (Auto Focus)
A system that automatically focuses the camera lens on the
subject. Your camera uses the contrast to focus automatically.
Aperture
The aperture controls the amount of light that reaches the
camera’s sensor.
Camera shake (Blur)
If the camera is moved while the shutter is open, the entire image
may appear blurred. This occurs more often when the shutter
speed is slow. Prevent camera shake by raising the sensitivity,
using the flash, or using a faster shutter speed. Alternately, use a
tripod, the DIS or OIS function to stabilize the camera.
Composition
Composition in photography means arranging objects in a photo.
Usually, abiding by the rule of thirds leads to a good composition.
Appendix
180
Glossary
Focal length
The distance from the middle of the lens to its focal point (in
millimeters). Longer focal lengths result in narrower angles of view
and the subject is magnified. Shorter focal lengths result in wider
angles of view.
Histogram
A graphical representation of the brightness of an image. The
horizontal axis represents the brightness and the vertical axis
represents the number of pixels. High points at the left (too dark)
and right (too bright) on the histogram indicate a photo that is
improperly exposed.
H.264/MPEG-4
A high-compression video format established by international
standard organizations ISO-IEC and ITU-T and developed by the
Joint Video Team (JVT). This codec is capable of providing good
video quality at low bit rates.
Image sensor
The physical part of a digital camera that contains a photosite for
each pixel in the image. Each photosite records the brightness of
the light that strikes it during an exposure. Common sensor types
are CCD (Charge-coupled Device) and CMOS (Complementary
Metal Oxide Semiconductor).
EV (Exposure Value)
All the combinations of the camera’s shutter speed and lens
aperture that result in the same exposure.
EV Compensation
This feature allows you to quickly adjust the exposure value
measured by the camera, in limited increments, to improve the
exposure of your photos. Set the EV compensation to -1.0 EV to
adjust the value one step darker and 1.0 EV to one step brighter.
Exif (Exchangeable Image File Format)
A specification to define an image file format for digital cameras
created by the Japan Electronic Industries Development
Association (JEIDA).
Exposure
The amount of light allowed to reach the camera’s sensor.
Exposure is controlled by a combination of the shutter speed, the
aperture value, and ISO sensitivity.
Flash
A speed light that helps to create adequate exposure in low-light
conditions.
Appendix
181
Glossary
Metering
The metering refers to the way in which the camera measures the
quantity of light to set the exposure.
MJPEG (Motion JPEG)
A video format which is compressed as a JPEG image.
MPO (Multi Picture Object)
An image file format that contains multiple images in a file. An
MPO file provides a 3D effect on MPO-compatible displays, such
as 3D TVs or 3D monitors.
Noise
Misinterpreted pixels in a digital image that may appear as
misplaced or random, bright pixels. Noise usually occurs when
photos are shot with a high sensitivity or when a sensitivity is
automatically set in a dark place.
OIS (Optical Image Stabilization)
This feature compensates in real-time for shaking and vibrating
while shooting. There is no image degradation compared to
Digital Image Stabilization feature.
Optical zoom
This is a general zoom which can enlarge images with a lens and
does not deteriorate quality of images.
ISO sensitivity
The sensitivity of the camera to light, based on the equivalent film
speed used in a film camera. At higher ISO sensitivity settings,
the camera uses a higher shutter speed, which can reduce blur
caused by camera shake and low light. However, images with
high sensitivity are more susceptible to noise.
JPEG (Joint Photographic Experts Group)
A lossy method of compression for digital images. JPEG images
are compressed to reduce their overall file size with minimal
deterioration of the image resolution.
LCD (Liquid Crystal Display)
A visual display commonly used in consumer electronics. This
display needs a separate backlight, such as CCFL or LED, to
reproduce colors.
Macro
This feature allows you to capture close-up photos of very small
objects. When using the macro feature, the camera can maintain
a sharp focus on small objects at a near life-size ratio (1:1).
Appendix
182
Glossary
Vignetting
A reduction of an image’s brightness or saturation at the periphery
(outer edges) compared to the center of the image. Vignetting
can draw interest to subjects positioned in the center of an
image.
White balance (color balance)
An adjustment of the intensities of colors (typically the primary
colors red, green, and blue), in an image. The goal of adjusting
the white balance, or color balance, is to correctly render the
colors in an image.
Quality
An expression of the rate of compression used in a digital image.
Higher quality images have a lower rate of compression, which
usually results in a larger file size.
Resolution
The number of pixels present in a digital image. High resolution
images contain more pixels and typically show more detail than
low resolution images.
Shutter speed
Shutter speed refers to the amount of time it takes to open and
close the shutter, and it is an important factor in the brightness of
a photo, as it controls the amount of light which passes through
the aperture before it reaches the image sensor. A fast shutter
speed allows less time to let light in and the photo becomes
darker and more easily freezes subjects in motion.
Smart zoom
Smart zoom lets you zoom in with less degradation of picture
quality than the optical zoom and digital zoom.
Appendix
183
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European
countries with separate collection systems)
This marking on the product, accessories or literature indicates that
the product and its electronic accessories (e.g. charger, headset, USB
cable) should not be disposed of with other household waste at the
end of their working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources. Household users
should contact either the retailer where they purchased this product,
or their local government office, for details of where and how they can
take these items for environmentally safe recycling. Business users
should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should
not be mixed with other commercial wastes for disposal.
PlanetFirst represents Samsung Electronics'
commitment to sustainable development and social
responsibility through eco-driven business and
management activities.
Correct disposal of batteries in this product
(Applicable in the European Union and other European
countries with separate battery return systems)
This marking on the battery, manual or packaging indicates that
the batteries in this product should not be disposed of with other
household waste at the end of their working life. Where marked, the
chemical symbols Hg, Cd or Pb indicate that the battery contains
mercury, cadmium or lead above the reference levels in EC Directive
2006/66. If batteries are not properly disposed of, these substances
can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please
separate batteries from other types of waste and recycle them through
your local, free battery return system.
This Class [B] digital apparatus complies with Canadian
ICES-003.
Dispose unwanted electronics through an approved recycler.
To find the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect Or call, (877) 278 - 0799
Appendix
184
FCC notice
Caution:
Any changes or modifications in construction of this device which are not
expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
- Reorientate, or relocate, the receiving antenna.
- Increase the distance between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
•
Declaration of Conformity
Trade Name : Samsung Electronics America, Inc.
Model No. : Samsung EX2F
Responsible Party : Samsung Electronics America, Inc.
Address : 85 Challenger Road, Ridgefield Park,
NJ 07660
Telephone No. : 1-800-SAMSUNG (726-7864)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
FCC ID:A3LEX2F
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
RF exposure statements:
This device is for handheld operation only. The antenna(s) used for this
transmitter must be installed to provide a separation distance of at least 20 cm
from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.
Appendix
185
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Caution:
Any changes or modifications to the equipment not expressly
approved by the party responsible for compliance could void
user’s authority to operate the equipment.
IC: 649E-EX2F
Complies with
IDA Standards
DA100790
Approved by PTA,
year 2011
TA-2011/1257
APPROVED
No.: ESD-1105767C
This equipment may be operated in all EU countries.
In France, this equipment may only be used indoors.
938
NO-L-14041/01/2011/ETA/2011
1577/2011/WRLO
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
Appendix
186
Declaration of Conformity
and the Eco-Design Directive (2009/125/EC) implemented by
Regulations (EC) No 278/2009 for external power supplies.
Representative in the EU
Samsung Electronics Euro QA Lab.
Blackbushe Business Park
Saxony Way, Yateley, Hampshire
GU46 6GG, UK
(YEAR TO BEGIN AFFIXING CE MARKING 2011)
21 October, 2011
(Place and date of issue)
Joong-Hoon Choi / Lab. Manager
(Name and signature of authorized person)
* This is not the address of Samsung Service Centre. For the
address or the phone number of Samsung Service Centre, see
the warranty card or contact the retailer where you purchased
your product.
Product details
For the following
Product : DIGITAL CAMERA
Model(s) : EX2F
Declaration & Applicable standards
We hereby declare that the product(s) above is(are) in
compliance with the essential requirements and other provisions
of the R&TTE Directive (1999/5/EC), the Low Voltage Directive
(2006/95/EC) and the Electromagnetic Compatibility Directive
(2004/108/EC) by application of:
EN 60950-1:2006+A1:2010 EN 55024:1998+A1:2001+A2:2003
EN 55022:2006+A1 :2007
EN 61000-3-2:2006 +A1:2009 +A2:2009
EN 61000-3-3:2008 EN 300 328 v1.7.1
EN 301 489-1 v1.8.1 EN 301 489-17 V2.1.1
EN62311 :2008
Appendix
187
Declaration sentence in official languages
Nation Declaration
Cesky
Samsung Electronics tímto prohlašuje, že tento digitální fotoaparát je ve shodě se základními požadavky a dalšími
příslušnými ustanoveními směrnice 1999/5/ES.
Dansk Samsung Electronics erklærer herved, at digitale kameraer overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/
EF.
Deutsch Hiermit erklärt Samsung Electronic, dass sich die Digitalkamera in Übereinstimmung mit den grundlegenden Anforderungen und den
übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti Käesolevaga kinnitab Samsung Electronics digitaalkaamera vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist
tulenevatele teistele asjakohastele sätetele.
English Hereby, Samsung Electronics declares that this digital camera is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC.
Español Por medio de la presente Samsung Electronics declara que la cámara digital cumple con los requisitos esenciales y cualesquiera
otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ η Samsung Electronics ΔΗΛΩΝΕΙ ΟΤΙ η ψηφιακή φωτογραφική μηχανή ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français Par la présente Samsung Electronic déclare que l'appareil photo numérique est conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 1999/5/CE.
Italiano Con la presente Samsung Electronicsdichiara che questa fotocamera digitale è conforme ai requisiti essenziali e alle altre disposizioni
stabilite dalla Direttiva 1999/5/CE.
Latviski Ar šo Samsung Electronics deklarē, ka digitālā kamera atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem
noteikumiem.
LietuviųŠiuo Samsung Electronics deklaruoja, kad šis skaitmeninis fotoaparatas, atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos
nuostatas.
Nederlands Hierbij verklaart Samsung Electronics dat de digitale camera in overeenstemming is met de essentiële eisen en de andere relevante
bepalingen van richtlijn 1999/5/EG.
Appendix
188
Declaration sentence in official languages
Nation Declaration
Malti Hawnhekk, Samsung Electronics, tiddikjara li din il-kamera diġitali hi konformi mar-rekwiżiti essenzjali u ma' dispożizzjonijiet rilevanti
oħrajn ta' Direttiva 1999/5/KE.
Magyar A Samsung Electronics kijelenti, hogy ez a digitális fényképezőgép megfelel az 1999/5/EK irányelv alapvetõ követelményeinek és
egyéb vonatkozó elõírásainak.
Polski Niniejszym firma Samsung Electronics oświadcza, że ten aparat cyfrowy jest zgodny z zasadniczymi wymogami oraz pozostałymi
stosownymi postanowieniami Dyrektywy 1999/5/WE.
Português Samsung Electronics declara que esta câmera digital está conforme os requisitos essenciais e outras disposições da Directiva
1999/5/CE.
Slovensko Samsung Electronics izjavlja, da je ta digitalni fotoaparat v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive
1999/5/ES.
Slovensky Samsung Electronics týmto vyhlasuje, že tento digitálny fotoaparát spĺňa základné požiadavky a všetky príslušné ustanovenia
Smernice 1999/5/ES.
Suomi Samsung Electronics vakuuttaa täten että tämä digitaalikamera on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien
direktiivin muiden ehtojen mukainen.
Svenska Härmed intygar Samsung Electronicsatt dessa digitalkameror står i överensstämmelse med de väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Български С настоящото Samsung Electronics декларира, че този цифров фотоапарат е в съответствие със съществените изисквания и
другите приложими разпоредби на Директива 1999/5/ЕК.
RomânăPrin prezenta, Samsung Electronics, declară că această cameră foto digitală este în conformitate cu cerinţele esenţiale şi alte
prevederi relevante ale Directivei 1999/5/CE.
Norsk Samsung Electronicserklærer herved at dette digitalkameraet er i samsvar med de grunnleggende krav og øvrige relevante krav i
direktiv 1999/5/EF.
Türkiye Bu belge ile, Samsung Electronics bu dijital kameranın 1999/5/EC Yönetmeliginin temel gerekliliklerine ve ilgili hükümlerine uygun
olduğunu beyan eder.
Íslenska Hér með lýsir Samsung Electronics því yfir að þessi stafræna myndavél sé í samræmi við grunnkröfur og önnur ákvæði tilskipunar
1999/5/EB.
Appendix
189
Index
A
AF-assist light
Location 16
Settings 154
AF Lamp 154
AF Sound 153
Anynet+ 155
Aperture Priority mode 45
Aperture value 44
Auto Backup 144
A/V port 17
B
Battery
Caution 166
Charging 23
Inserting 22
Beauty Shot mode 49
Blink Detection 78
Brightness
Playback mode 110
Shooting mode 82
Burst modes
Bracket 88
High-speed 87
Precapture 88
C
Camera maintenance 159
Camera specifications 175
Capturing an image from
video 106
Charging 23
Cleaning
Camera body 159
Display 159
Lens 159
Connecting to a computer
Mac 122
Windows 118
Contrast
Playback mode 110
Shooting mode 93
D
Date/Time Set 153
Deleting files 101
Digital Print Order Format
(DOF) 110
Digital zoom 35
Disconnecting the
camera 116
Display brightness 153
Display type 32
E
Editing photos 107
Editing videos
Capturing 106
Trimming 105
Enlarging 102
Error messages 157
Exposure 82
F
Face Detection 77
Flash
Auto 69
Fill in 69
Intensity 70
Off 69
Red-eye 69
Red-eye Fix 69
Slow Sync 69
Appendix
190
Index
Focus area
Center AF 76
Multi AF 76
Selection AF 76
Tracking AF 76
Formatting 155
Function button 18
G
Grid Line 153
H
Half-press shutter 38
HDMI Size 155
HDR mode 57
HDTV 113
I
Icons
Playback mode 96
Shooting mode 26
Image Adjustment
Add Noise 110
Brightness
Playback mode 110
Shooting mode 82
Contrast
Playback mode 110
Shooting mode 93
Red-eye 109
Saturation
Playback mode 110
Shooting mode 93
Sharpness 93
Image quality 66
Image Stabilization 37
Intelli-studio 119
ISO sensitivity 71
L
Language settings 153
M
Macro
Auto Macro 73
Macro 73
Manual Focus 73
Magic Frame mode 53
Magic Plus mode
Artistic Brush 56
Picture in Picture 54
Manual mode 47
Memory card
Caution 164
Insert 22
Menu button 18
Metering
Center-weighted 84
Multi 84
Spot 84
Movie mode 60
My star
Cancelling 98
Ranking 97
Registering 80
O
Optional accessories 15
P
Panorama
3D Panorama 50
Action Panorama 52
Live Panorama 50
Playback button 18
Playback mode 96
Power button 16
Power save mode 153
Program mode 43
Protecting files 100
Appendix
191
T
Thumbnails 100
Timer
Shooting mode 67
Timer lamp 16
Time settings 24
Time zone settings 24, 153
Transferring files
Auto Backup 144
Email 137
Mac 122
Windows 118
Tripod mount 16
TV Link 146
U
Unpacking 15
USB port 17
Shutter Priority mode 46
Slide show 104
Smart Album 99
Smart Auto mode 41
Smart Face Recognition 79
Smart Filter
Playback mode 108
Smart Scene Detection
mode 63
Smart zoom 36
Smile Shot 78
Sound settings 33
Status lamp 17
S
Saturation
Playback mode 110
Shooting mode 93
Scene mode 48
Self portrait 77
Service center 172
Sharpness 93
Shooting portraits
Beauty Shot mode 49
Blink Detection 78
Face Detection 77
Red-eye 69
Red-eye fix 69
Self portrait 77
Smart Face Recognition 79
Smile Shot 78
Shutter button 16
Q
Quick view 153
R
Red-eye
Playback mode 109
Shooting mode 68
Remote Viewfinder 141
Reset 155
Resolution
Playback mode 107
Shooting mode 65
Retouching faces
Playback mode 109
Shooting mode 49
Rotating 107
Index
Appendix
192
V
Video
Playback mode 105
Shooting mode 60
Video out 155
Viewing files
Folder 98
Slide show 104
Smart Album 99
Thumbnails 100
TV 112
W
Website
Accessing 135
Uploading photos or
videos 135
White Balance 84
Wireless network 131
Z
Zoom
Using the zoom 35
Zoom button 17
Zoom sound settings 60
3
3D Photo mode 50
3D TV 114
Index
