User Guide
SAMSUNG
Chapter 1.
Getting Started
Product Features 2
Before You Start 3
Contents 7
Safety Precautions 8
Proper Posture During Computer Use 24
Important Safety Information 27
Replacement Parts and Accessories 30
Regulatory Compliance Statements 33
WEEE SYMBOL INFORMATION 48
Overview 50
Turning the Computer On and Off 56
2
PC in Hand
Improved portability through its compact size and
lightweight design
Slim, Polished Design
Small but Powerful PC
An Intel “Atom” Processor with Low Power
Consumption and Low Heat
Extended Use Time through the use of Power-
Efcient Parts
Versatile and Convenient Use
A Camera Module for Video Chatting or
Conferencing (Optional)
Wireless LAN and Bluetooth Function (Optional)
Multi Card Slot Support (Optional)
Easy-to-Use Keyboard
Optional items may be changed or may not be
provided depending on the computer model.
Product Features
3
Before You Start
Before reading the User Guide, rst check the following information.
Optional items, some devices and software referred to in the User Guide may not
be provided and/or changed by upgrade.
Note that the computer environment referred in the User Guide may not be the
same as your own environment.
Images used in this User Guide may differ from actual product.
This guide decribes procedures for using both the mouse and the touchpad.
This manual has been written for the Windows operating system. The descriptions
and gures may differ depending on the installed operating system.
The User guide supplied with this computer may vary depending on your model.
Safety Precaution Notations
Icon Notation Description
Warning Failing to follow instructions marked with this symbol, may
cause personal injury and or fatality.
Caution Failing to follow instructions marked with this symbol, may
cause slight injury to yourself or damage your property.
4
Text Notations
Icon Notation Description
Before You Start Content included in this section includes information required
before using a function.
Caution Content included in this section includes information required
about the function.
Note Content included in this section includes helpful information to
use the function.
Copyright
© 2009 Samsung Electronics Co., Ltd.
Samsung Electronics Co., Ltd. owns the copyright of this manual.
No part of this manual may be reproduced or transmitted in any form or by any means,
electronic or mechanical, without the consent of Samsung Electronics Co., Ltd.
The information in this document is subject to change without notice due to improving
the performance of the product.
Samsung Electronics shall not be liable for any data loss. Please take care to avoid
losing any important data and backup your data to prevent any such data loss.
Precautions for Operating System Support
If a problem occurs because of the reinstallation of other operating systems(OS) or a
previous version of a OS pre-installed on this computer, or a software that does not
support the OS, the company will not provide technical support, a replacement or
refund, and if our service engineer visits you due to this problem, a service charge will
be applied.
5
Performance Restrictions
z Online games and some games(3D,2D) may not be supported and Full HD video
and some high bit rate HD video playback may be slow and stutter on this computer.
x There is one memory slot provided on this computer. It supports 2GB memory
max. To upgrade to 2GB memory, replace the current memory with a 2GB memory
module.
About the Product Capacity Representation Standard
About HDD Capacity Representation
The capacity of the storage device (HDD, SSD) of the manufacturer is calculated
assuming that 1KB=1,000 Bytes.
However, the operating system (Windows) calculates the storage device capacity
assuming that 1KB=1,024 Bytes, and therefore the capacity representation of the
HDD in Windows is smaller than the actual capacity due to the difference in capacity
calculation.
(E.g. For a 80GB HDD, Windows represents the capacity as 74.5GB,
80x1,000x1,000x1,000 byte/(1,024x1,024x1,024)byte = 74.505GB)
In addition, the capacity representation in Windows may be even smaller because some
programs such as Recovery Solution may reside in a hidden area of the HDD.
About Memory Capacity Representation
The memory capacity reported in Windows is less than the actual capacity of memory.
This is because BIOS or a video adapter uses a portion of memory or claims it for
further use.
(E.g. For 1GB(=1,024MB) memory installed, Windows may report the capacity as
1,022MB or less)
6
Recovery Solution Representation (Optional)
Q. What is a Recovery Area?
A. - Samsung computers have an additional partition to recover computers or save
backup les. (Only for models with the Samsung Recovery Solution.)
This partition is called a Recovery Area and it includes a recovery image that
comprises of the OS and application programs.
- You can either double-click the Samsung Recovery Solution icon on the desktop
or press F4 while booting the computer to enter the Recovery Area. Then you
can back up the present computer state or recover the computer from backed up
images.
- For deleting the Recovery Area, you need to use an additional Recovery Area
Removal Tool. After deleting the recovery area, you can use the newly created
partition for other uses, such as for saving personal data. Be careful that once the
recovery area is deleted, the Samsung Recovery Solutions will not work anymore.
Q. The capacity representation of the hard disk drive(HDD) in Windows is
different from the product specications.
A. - The capacity of the storage device (HDD) of the manufacturer is calculated
assuming that 1KB=1,000 Bytes. However, the operating system (Windows)
calculates the storage device capacity assuming that 1KB=1,024 Bytes, and
therefore the capacity representation of the HDD in Windows is smaller than the
actual capacity. This is due to the difference in capacity calculation and does not
mean the installed HDD is different from the product specications.
- The capacity representation in Windows may be smaller than the actual capacity
because some programs occupy a certain area of the HDD outside of Windows.
- For models with Samsung Recovery Solution, the HDD capacity representation
in Windows may be smaller than the actual capacity because Samsung Recovery
Solution uses a hidden area of about 5~20GB of the HDD to save the recovery
image, and that hidden area is not counted towards the total size available to
Windows. The size of Samsung Recovery Solution varies by models because of the
different size of applied programs.
7
Contents
Chapter 1. Getting Started
Product Features 2
Before You Start 3
Contents 7
Safety Precautions 8
Proper Posture During Computer Use 24
Important Safety Information 27
Replacement Parts and Accessories 30
Regulatory Compliance Statements 33
WEEE SYMBOL INFORMATION 48
Overview 50
Turning the Computer On and Off 56
Chapter 2. Using the Computer
Keyboard 59
Touchpad 62
External-type CD drive
(To be purchased) 68
Multi Card Slot (Optional) 70
Connecting a monitor / TV 73
Adjusting the Volume 78
Wired Network 83
Wireless Network (Optional) 87
Using HyperSpace (Optional) 90
HDD Protection Function (Optional) 98
Chapter 3. Settings and Upgrade
LCD Brightness Control 100
BIOS Setup 102
Setting a Boot Password 105
Changing the Boot Priority 108
Upgrading Memory 109
Battery 111
Using the Security Lock Port 116
Chapter 4. Troubleshooting
Using Samsung Recovery Solution 118
Reinstalling Windows 7 132
Reinstalling Windows XP 137
Questions and Answers 141
Chapter 5. Appendix
Product Specications 160
Glossary 163
Index 168
8
Safety Precautions
For your security and to prevent damage, please read the following safety instructions
carefully. Since these are commonly applied to Samsung Computers, some gures may differ
from the actual product.
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
Installation Related
Do not install the product
in places exposed
to humidity such as
bathrooms.
There is a danger of
electric shock. Use the
product within the operating
conditions specied in the
Manufacturers User Guide.
Keep the plastic bags out
of the reach of children.
There is a danger of
suffocation.
Keep a distance of 15cm
or more between the
computer and the wall
and do not place any
objects between them.
Failing to do so may
cause an increase in the
internal temperature of
the computer and result in
injury.
Do not install the
computer on a slant or a
place prone to vibrations,
or avoid using the
computer in that location
for a long time.
Failing to do so may result
in an increased risk of
malfunctions or damage to
the product.
NB Ver 2.3
9
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
Avoid exposing any part
of your body to the heat
from the computer vent
or AC adapter for a long
time when the computer
is on.
Exposing a part of your
body close to the heat from
the vent or AC adapter for
long periods of time may
cause a burn.
Avoid blocking the vent
at the bottom or side
of the computer when
using it on a bed or
cushion.
If the vent is blocked,
there is a danger of
damaging the computer or
overheating the inside of
the computer.
The power plug and
wall outlet gures may
differ depending on the
country specications
and the product model.
Do not touch the main
plug or power cord with
wet hands.
There is a danger of
electric shock.
Do not exceed the
standard capacity
(voltage/current) of a
multi-plug or power
outlet extension when
using it for the product.
This may result in electric
shock or re.
Power Related
10
If the power cord or
power outlet makes a
noise, disconnect the
power cord from the
wall outlet and contact a
service center.
This may result in electric
shock or re.
Do not use a damaged or
loose main plug or power
cord or power outlet.
This may result in electric
shock or re.
Plug the power cord
rmly into the power
outlet and AC adapter.
Failing to do so may result
in electric shock or re.
Do not unplug the power
cord out by pulling the
cable only.
If the cord is damaged, it
may result in electric shock
or re.
Do not bend the power
cord excessively or do
not place a heavy object
over the power cord. It is
especially important to
keep the power cord out
of reach of infants and
pets.
If the cord is damaged, it
may cause electric shock or
re.
Connect the power cord
to an outlet or multiple
power plug (extended
cable) with a ground
terminal.
Failing to do so may result
in electric shock.
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
11
Connect the power cord
to the AC adapter rmly.
Otherwise, there is a
danger of re due to an
incomplete contact.
Use only the AC adapter
supplied with the
product.
Using another adapter may
cause the screen to icker.
Do not place heavy
objects or step onto
the power cord or
AC adapter to avoid
damaging the power
cord or AC adapter.
If the cord is damaged,
there is a danger of electric
shock or re.
AC Adapter Usage Precautions
If any foreign substance
such as water enters
the power input jack,
AC adapter or the
computer, disconnect
the power cord and
contact the service
center.
Damage to the device
within the computer may
result in electric shock or
re hazard.
Keep the power cord or
outlet clean so that they
are not covered with
dust.
Failing to do so may result
in re.
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
12
Keep the battery out of
the reach of infants and
pets, as they could put
the battery into their
mouths.
There is a danger of electric
shock or choking.
Authorized
Parts
Use an authorized battery
and AC adapter only.
Please use an authorized
battery and adapter
approved by Samsung
Electronics.
Unauthorized batteries and
adapters may not meet the
proper safety requirements
and may cause problems or
malfunctions and result in
an explosion or re.
Do not use the computer
in a badly ventilated
location such as on
bedding, on a pillow or
cushion, etc, and do
not use it in a location
such as room with oor
heating as it may cause
the computer to be
oveerheated.
Take care that the
computer vents (on the
side or the bottom) are not
blocked especially in these
environments. If the vents
are blocked, the computer
may overheat and it may
cause a computer problem,
or even an explosion.
Battery Usage Related
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
13
Do not use the computer
in a humid location such
as a bathroom or sauna.
Please use the computer
within the recommended
temperature and humidity
range (10~32ºC, 20~80%
RH).
Power Off
Do not close the LCD
panel and put the
computer into your bag
to move it when it is still
turned on.
If you put the computer into
your bag without turning
it off, the computer may
overheat and there is a
danger of re. Shut the
computer down properly
before moving it.
Never heat the battery
or put the battery into a
re. Do not put or use the
battery in a hot location
such as a sauna, inside
a vehicle exposed to the
heat, and so on.
There is a danger of an
explosion or re.
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
14
Take care not to allow
metal objects such as a
key or clip to touch the
battery terminal (metal
parts).
If a metal object touches
the battery terminals, it
may cause excessive
current ow and it may
damage the battery, or
result in a re.
If liquid leaks out of
the battery or there is
a funny smell coming
from the battery, remove
the battery from the
computer and contact a
service center.
There is a danger of an
explosion or re.
To use the computer
safely, replace a dead
battery with a new,
authorized battery.
Please charge the
battery fully before
using the computer
for the rst time.
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
15
Disconnect all cables
connected to the
computer before cleaning
it. If you are cleaning
a notebook computer,
remove the battery.
There is a danger of electric
shock or damage to the
product.
Do not connect a phone
line connected to a digital
phone to the modem.
There is a danger of a
electric shock, re or
damage to the product.
Do not place any
container lled with water
or chemicals over or near
the computer.
If water or chemicals enter
the computer, this may
cause re or electric shock.
If the computer is broken
or dropped, disconnect
the power cord and
contact a service center
for a safety check.
Using a damaged computer
may result in electric shock
or re.
Avoid leaving the
computer exposed to
direct sunlight when the
computer is in a badly
ventilated location such
as inside a vehicle.
This may result in
overheating, re or being
stolen.
Do not use your
notebook PC for long
periods of time while
a part of your body is
making direct contact
with it. The temperature
of the product may
increase during normal
operation.
This may result in harming
or burning your skin.
Usage Related
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
16
Upgrade Related
Never disassemble the
power supply or AC
adapter.
There is a danger of electric
shock.
When removing the RTC
(Real Time Clock) battery,
keep it out of the reach
of children as they could
touch and/or swallow it.
There is a danger of
choking. If a child has
swallowed it, contact a
doctor immediately.
Use only authorized
parts (multi-plug, battery
and memory) and never
disassemble parts.
This may result in damage
to the product, electric
shock or re.
Shut down the computer
and disconnect all cables
before disassembling
the computer. If there is
a modem, disconnect
the phone line. If you
are disassembling a
notebook computer,
make sure to remove the
battery.
Failing to do so, may cause
electric shock.
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
17
Custody and Movement Related
Follow the instructions
for the relevant location
(e.g. airplane, hospital,
etc.) when using a
wireless communication
device (wireless LAN,
Bluetooth, etc.).
Avoid exposing a drive
to magnetic elds.
Security devices with
magnetic elds include
airport walk-through
devices and security
wands. The airport
security devices that
check carry-on luggage,
such as conveyor belts,
use x-rays instead of
magnetism and will not
damage a drive.
When carrying the
notebook computer with
other items, such as the
adapter, mouse, books
etc, take care not to
press anything against
the notebook computer.
If a heavy object is pressed
against the notebook
computer, a white spot or
stain may appear on the
LCD. Therefore, take care
not to apply any pressure
to the notebook.
In this case, place the
notebook computer in a
separate compartment
away from the other
objects.
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
18
Caution
Failing to follow instructions marked with this symbol may cause slight injury or damage to the
product.
Installation Related Battery Usage
Related
Do not block the ports
(holes), vents, etc. of the
product and do not insert
objects.
Damage to a component
within the computer may
cause electric shock or re.
When using the computer
with it lying on its side,
place it so that the vents
face upwards.
Failing to do so, may cause
the internal temperature of
the computer to rise and
the computer to malfunction
or halt.
Do not place a heavy
object over the product.
This may cause a problem
with the computer. In
addition, the object may
fall and cause injury, or
damage the computer.
Dispose of worn-out
batteries properly.
There is a danger of
re or explosion.
The battery disposal
method may differ
depending on your
country and region.
Dispose of the
used battery in an
appropriate way.
Do not throw or
disassemble the battery
and do not put it into
water.
This may cause an injury,
re or explosion.
19
Use only a battery
authorized by Samsung
Electronics.
Failing to do so may cause
an explosion.
Avoid contact with metal
objects such as car keys
or clips when keeping or
carrying a battery.
Contact with a metal may
cause excessive current
and a high temperature
and may damage the
battery or cause a re.
Charge the battery
according to the
instructions in the
manual.
Failing to do so, may cause
an explosion or re from
damage to the product.
Do not heat the battery
or expose it to heat (e.g.
inside a vehicle during
the summer).
There is a danger of
explosion or re.
Usage Related
Do not place a candle,
light cigar, etc. over or
on the product.
There is a danger of re.
Use a wall outlet or
multi-plug with a
grounding part.
Failing to do so may result
in electric shock.
Make sure to have the
product tested by a
safety service engineer
after repairing the
product.
Authorized Samsung
Repair Centers will carry
out safety checks after a
repair. Using a repaired
product without testing it
for safety may cause an
electric shock or re.
Caution
Failing to follow instructions marked with this symbol may cause slight injury or damage to the
product.
20
In case of lightning,
immediately turn the
system off, disconnect
the power cord from the
wall outlet and phone line
from modem. Do not use
a modem or phone.
There is a danger of electric
shock or re.
Do not use your computer
and AC-Adapter on your
lap or soft surfaces.
If the computer temperature
increases, there is a danger
of burning yourself.
Connect only permitted
devices to the connectors
or ports of the computer.
Failing to do so, may cause
electric shock and re.
Close the LCD panel
only after checking if the
notebook computer is
turned off.
The temperature may
rise and it may cause
overheating and
deformation of the product.
Do not press the Eject
Button while the Floppy
Disk/CD-ROM drive is in
operation.
You might lose data and
the disk might be suddenly
ejected and could cause an
injury.
Take care not to drop the
product while using it.
This may cause personal
injury or loss of data.
Do not touch the antenna
with electricity facility
such as the power outlet.
There is a danger of electric
shock.
When handling
computer parts, follow
the instructions on the
manual supplied with the
parts.
Failing to do so, may cause
damage to the product.
If the computer emits
smoke, or there is a
burning smell, disconnect
the power plug from the
wall outlet and contact
a service center. If your
computer is a notebook
computer, make sure to
remove the battery.
There is a danger of re.
Caution
Failing to follow instructions marked with this symbol may cause slight injury or damage to the
product.
21
Upgrade Related
Do not use a damaged or
modied CD/Floppy Disk.
There is a danger of
damaging the product or
personal injury.
Do not insert your ngers
into the PC Card Slot.
There is a danger of injury
or electric shock.
Use recommended
computer cleansing
solution when cleaning
the product and only use
the computer when it is
completely dried.
Failing to do so may cause
electric shock or re.
Emergency disk eject
method using paperclip
should not be used while
the disk is in motion.
Make sure to use the
emergency disk eject
method only when the
Optical Disk Drive is
stopped.
There is a danger of injury.
Do not place your face
close to the Optical Disk
Drive tray when it is
operating.
There is a danger of injury
due to an abrupt ejection.
Check CDs for cracks and
damage prior to use.
It may damage the disc and
cause disorder of device
and injury of user.
Take care when
touching the product or
parts.
The device may be
damaged or you may be
injured.
Take care not to throw
or drop a computer
part or device.
This may cause injury or
damage to the product.
Make sure to close the
computer cover before
connecting the power
after a reassembly.
There is a danger of
electric shock if your
body touches an internal
part.
Caution
Failing to follow instructions marked with this symbol may cause slight injury or damage to the
product.
22
Use parts authorized
by Samsung
Electronics only.
Failing to do so, may
cause re or damage the
product.
Never disassemble or
repair the product by
yourself.
There is a danger of
electric shock or re.
To connect a
device that is not
manufactured
or authorized by
Samsung Electronics,
enquire at your
service center before
connecting the device.
There is a danger of
damaging the product.
Custody and Movement Related
When moving the
product, turn the power
off and separate all
connected cables rst.
The product might be
damaged or users may trip
over the cables.
For long periods of not
using the notebook
computer, discharge the
battery and preserve as
it is detached.
The battery will be
preserved at its best
condition.
Do not operate or watch
the computer while
driving a vehicle.
There is a danger of a
trafc accident. Please
concentrate on driving.
Caution
Failing to follow instructions marked with this symbol may cause slight injury or damage to the
product.
23
Cautions on Preventing Data Loss (Hard Disk Management)
Take care not to damage the data on a
hard disk drive.
A hard disk drive is so sensitive to
external impact that an external impact
may cause loss of data on the surface
of the disk.
Take extra care, because moving the
computer or an impact on the computer
when it is turned on may damage the
data of the hard disk drive.
The company is not liable for any loss
of any data caused by a customer’s
careless usage or bad environmental
conditions.
Causes that may damage the data of a
hard disk drive and the hard disk drive
itself.
The data may be lost when an external
impact is applied to the disk while
disassembling or assembling the
computer.
The data may be lost when the
computer is turned off or reset by a
power failure while the hard disk drive is
operating.
The data may be lost and irrecoverable
due to a computer virus infection.
The data may be lost if the power is
turned off while running a program.
Moving or causing an impact to the
computer while the hard disk drive
is operating, may cause les to be
corrupted or bad sectors on the hard
disk.
To prevent data loss due to damage to the hard disk drive, please backup your
data frequently.
Caution
Failing to follow instructions marked with this symbol may cause slight injury or damage to the
product.
24
Proper Posture
Adjust the heights of desks and chairs
appropriate to your height.
The heights are to be adjusted so that
your arm forms a right angle when you
place your hand over the keyboard while
sitting down on a chair.
Adjust the height of chair so that your heel
is comfortably placed on the oor.
Do not use the computer while you
are lying down, but only while you are
sitting down.
Do not use the computer on your lap.
If the computer temperature increases,
there is a danger of burning yourself.
Work while keeping your back straight.
Use a chair with a comfortable back.
Keep the center of your leg weight not
on the chair but on your feet when you
are sitting on a chair.
To use the computer while talking over
the telephone, use a headset. Using
the computer with the phone on your
shoulder is bad for posture.
Keep frequently used items within a
comfortable work range (where you
can reach them with your hands).
Proper Posture During Computer Use
Maintaining a proper posture during computer use is very important to prevent physical
harm.
The following instructions are about maintaining a proper posture during computer use
developed through human engineering. Please read and follow them carefully when
using the computer.
Otherwise, the probability of (RSI: Repetitive Strain Injury) from repeated operations
may increase and serious physical harm may be caused.
The instructions in this manual have been prepared so that they can be applied within
the coverage of general users.
If the user is not included in the coverage, the recommendation is to be applied
according to the user’s needs.
25
Eye Position
Keep the monitor or LCD away from
your eyes by at least 50cm.
50cm
Adjust the height of the monitor and
the LCD screen so that its top height is
equal to or lower than your eyes.
Avoid setting the monitor and LCD
excessively bright.
Keep the monitor and LCD screen
clean.
If you wear glasses, clean them before
using the computer.
When entering contents printed on a
paper into the computer, use a static
paper holder so that the height of the
paper is almost equal to that of the
monitor.
Hand Position
Keep your arm at a right angle as
shown by the gure.
Keep the line from your elbow to your
hand straight.
Do not place your palm over the
keyboard while typing.
Do not hold the mouse with excessive
force.
Do not press the keyboard, touchpad or
mouse with excessive force.
It is recommended connecting an
external keyboard and mouse when
using the computer for long periods of
time.
26
Volume Control
(Headphones and Speakers)
Check your volume rst to listen to
music.
Check your
volume!!
Check if the volume is too loud before
using headphones.
It is not recommended using
headphones for long periods of time.
Any deviation from the equalizer
default setting could cause hearing
impairment.
The default setting can be changed
through software and driver updates
without your intervention. Please check
the equalizer default setting before rst
usage.
Use Time (Break Time)
Take a break for 10 minutes or more
after a 50-minute period when working
for more than one hour.
Illumination
Do not use the computer in dark
locations. The illumination level for
computer use must be as bright so for
reading a book.
Indirect illumination is recommended.
Use a curtain to prevent reection on
the LCD screen.
Operation Condition
Do not use the computer in hot and
humid locations.
Use the computer within the allowed
temperature and humidity range
specied in the User Guide.
27
Safety Instructions
Your system is designed and tested
to meet the latest standards for safety
of information technology equipment.
However, to ensure safe use of this
product, it is important that the safety
instructions marked on the product and in
the documentation are followed.
Always follow these instructions to
help guard against personal injury
and damage to your system.
Setting Up your System
Read and follow all instructions
marked on the product and in the
documentation before you operate your
system. Retain all safety and operating
instructions for future use.
Do not use this product near water or a
heat source such as a radiator.
Set up the system on a stable work
surface.
The product should be operated only
with the type of power source indicated
on the rating label.
Ensure that the electrical outlet you
are using to power your equipment is
easily accessible in case of re or short
circuit.
If your computer has a voltage selector
switch, make sure that the switch is in
the proper position for your area.
Openings in the computer case are
provided for ventilation. Do not block
or cover these openings. Make sure
you provide adequate space, at least 6
inches (15 cm), around the system for
ventilation when you set up your work
area. Never insert objects of any kind
into the computer ventilation openings.
Ensure that the fan vents on the bottom
of the casing are clear at all times.
Do not place the computer on a soft
surface, doing so will block the bottom
vents.
If you use an extension cord with this
system, make sure that the total power
rating on the products plugged into the
extension cord does not exceed the
extension cord power rating.
Important Safety Information
28
Care During Use
Do not walk on the power cord or allow anything to rest on it.
Do not spill anything on the system. The best way to avoid spills is to not eat or drink
near your system.
Some products have a replaceable CMOS battery on the system board. There is a
danger of explosion if the CMOS battery is replaced incorrectly. Replace the battery
with the same or equivalent type recommended by the manufacturer.
Dispose of batteries according to the manufacturers instructions. If the CMOS battery
requires replacement insure that a qualied technician performs the task.
When the computer is turned off, a small amount of electrical current still ows
through the computer.
To avoid electrical shock, always unplug all power cables, remove the battery and
modem cables from the wall outlets before cleaning the system.
Unplug the system from the wall outlet and refer servicing to qualied personnel if:
– The power cord or plug is damaged.
– Liquid has been spilled into the system.
– The system does not operate properly when the operating instructions are followed.
– The system was dropped or the casing is damaged.
– The system performance changes.
29
The Instruction On Safety Operation of NotePC
z When installing and operating devices please refer to safety requirements in the
user guide.
x Devices can be used only with the equipment specied in the technical
specications of the devices.
c If any smell of burning or smoke is detected from the computer the unit should
be switched off and battery removed. The unit should be checked by a qualied
technician before reuse.
v Service and repair of devices should be carried out by authorized service centers.
b Do not allow your portable computer to operate with the base resting directly on
exposed skin for extended periods of time. The surface temperature of the base
will rise during normal operation (particularly when AC Power is present). Allowing
sustained contact with exposed skin can cause discomfort or eventually a burn.
30
Battery Disposal
Do not put rechargeable batteries or products powered by non-removable
rechargeable batteries in the garbage.
Contact the Samsung Helpline for information on how to dispose of batteries that you
cannot use or recharge any longer.
Follow all local regulations when disposing of old batteries.
THERE IS A RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Replacement Parts and Accessories
Use only replacement parts and accessories recommended by manufacturer.
To reduce the risk of re, use only No. 26 AWG or larger telecommunications line cord.
Do not use this product in areas classied as hazardous. Such areas include patient
care areas of medical and dental facilities, oxygen rich environments, or industrial
areas.
31
Laser Safety
All systems equipped with CD or DVD drives comply with the appropriate safety
standards, including IEC 60825-1. The laser devices in these components are classied
as “Class 1 Laser Products” under a US Department of Health and Human Services
(DHHS) Radiation Performance Standard. Should the unit ever need servicing, contact
an authorized service location.
Laser Safety Note:
Use of controls or adjustments or performance of procedures other than those
specied in this manual may result in hazardous radiation exposure. To prevent
exposure to laser beams, do not try to open the enclosure of a CD or DVD drive.
Class 1M laser radiation when operating part is open.
Do not view directly with optical instruments.
Class 3B invisible laser radiation when open.
Avoid exposure to the beam.
Connect and Disconnect the AC adapter
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Do not unplug the power cord out by pulling the cable only.
32
Power Cord Requirements
The power cord set (wall plug, cable and AC adapter plug) you received with your
computer meets the requirements for use in the country where you purchased your
equipment.
Power cord sets for use in other countries must meet the requirements of the country
where you use the computer. For more information on power cord set requirements,
contact your authorized dealer, reseller, or service provider.
General Requirements
The requirements listed below are applicable to all countries:
All power cord sets must be approved by an acceptable accredited agency
responsible for evaluation in the country where the power cord set will be used.
The power cord set must have a minimum current capacity of 7 A and a nominal
voltage rating of 125 or 250 volts AC, as required by each country’s power system.
(USA ONLY)
The appliance coupler must meet the mechanical conguration of an EN 60 320/IEC
320 Standard Sheet C7 (or C5) connector, for mating with appliance inlet on the
computer.
33
Regulatory Compliance Statements
Wireless Guidance
(If tted with 2.4G band or 5G band)
Low power, Radio LAN type devices (radio frequency (RF) wireless communication
devices), operating in the 2.4GHz/5GHz Band, may be present (embedded) in your
notebook system. The following section is a general overview of considerations while
operating a wireless device.
Additional limitations, cautions, and concerns for specic countries are listed in the
specic country sections (or country group sections). The wireless devices in your
system are only qualied for use in the countries identied by the Radio Approval Marks
on the system rating label. If the country you will be using the wireless device in, is not
listed, please contact your local Radio Approval agency for requirements. Wireless
devices are closely regulated and using them may not be allowed.
The RF eld strength of the wireless device or devices that may be embedded in your
notebook are well below all international RF exposure limits as known at this time.
Because the wireless devices (which may be embedded into your notebook) emit less
energy than is allowed in radio frequency safety standards and recommendations,
manufacturer believes these devices are safe for use. Regardless of the power levels,
care should be taken to minimize human contact during normal operation.
Some circumstances require restrictions on wireless devices. Examples of common
restrictions are listed on the next page:
34
Radio frequency wireless communication can interfere with equipment on
commercial aircraft. Current aviation regulations require wireless devices to be
turned off while traveling in an airplane.
802.11ABGN (also known as wireless Ethernet or Wi) and Bluetooth
communication devices are examples of devices that provide wireless
communication.
In environments where the risk of interference to other devices or services is
harmful or perceived as harmful, the option to use a wireless device may be
restricted or eliminated. Airports, Hospitals, and Oxygen or ammable gas laden
atmospheres are limited examples where use of wireless devices may be restricted
or eliminated. When in environments where you are uncertain of the sanction to use
wireless devices, ask the applicable authority for authorization prior to use or turning
on the wireless device.
Every country has different restrictions on the use of wireless devices. Since your
system is equipped with a wireless device, when traveling between countries with
your system, check with the local Radio Approval authorities prior to any move or
trip for any restrictions on the use of a wireless device in the destination country.
If your system came equipped with an internal embedded wireless device, do not
operate the wireless device unless all covers and shields are in place and the
system is fully assembled.
Wireless devices are not user serviceable. Do not modify them in any way.
Modication to a wireless device will void the authorization to use it. Please contact
manufacturer for service.
Only use drivers approved for the country in which the device will be used. See the
manufacturer System Restoration Kit, or contact manufacturer Technical Support for
additional information.
35
USA and Canada Safety
Requirements and Notices
Do not touch or move antenna while the
unit is transmitting or receiving.
Do not hold any component containing
the radio such that the antenna is very
close or touching any exposed parts of
the body, especially the face or eyes,
while transmitting.
Do not operate the radio or attempt
to transmit data unless the antenna
is connected; if not, the radio may be
damaged.
Use in specic environments:
The use of wireless devices in hazardous
locations is limited by the constraints
posed by the safety directors of such
environments.
The use of wireless devices on airplanes
is governed by the Federal Aviation
Administration (FAA).
The use of wireless devices in hospitals
is restricted to the limits set forth by each
hospital.
Explosive Device Proximity
Warning
Do not operate a portable transmitter
(such as a wireless network device)
near unshielded blasting caps or in
an explosive environment unless
the device has been modied to be
qualied for such use.
Use On Aircraft Caution
Regulations of the FCC and FAA
prohibit airborne operation of radio-
frequency wireless devices because
their signals could interfere with
critical aircraft instruments.
Other Wireless Devices
Safety Notices for Other Devices in
the Wireless Network: Refer to the
documentation supplied with wireless
Ethernet adapters or other devices in the
wireless network.
The Part 15 radio device operates on
a non-interference basis with other
devices operating at this frequency.
Any changes or modication to said
product not expressly approved by
Intel could void the user’s authority to
operate this device.
United States of America
36
Unintentional Emitter per FCC Part
15
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:(1) this device
may not cause harmful interference,
and (2) this device must accept any
interference received, including
interference that may cause undesired
operation.
This equipment has been tested
and found to comply with the limits
for a Class B digital device pursuant
to Part 15 of the FCC Rules. These
limits are designed to provide
reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses, and can radiate
radio frequency energy and if not
installed and used in accordance
with the instructions may cause
harmful interference which will not
occur in a correct installation. If
this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
Reorient or relocate the receiving
antenna.
Increase the separation between
the equipment and receiver.
Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
Consult the dealer or an
experienced radio/TV technician
for help.
If necessary, the user should consult the
dealer or an experienced radio/television
technician for additional suggestions.
The user may nd the following booklet
helpful: “Something About Interference.”
This is available at FCC local regional
ofces. Our company is not responsible
for any radio or television interference
caused by unauthorized modications
of this equipment or the substitution or
attachment of connecting cables and
equipment other than those specied
by our company. The correction will be
the responsibility of the user. Use only
shielded data cables with this system.
37
Intentional emitter per FCC Part 15
(If tted with 2.4G band or 5G band)
Low power, Radio LAN type devices
(radio frequency (RF) wireless
communication devices), operating in
the 2.4GHz/5GHz Band, may be present
(embedded) in your notebook system.
This section is only applicable if these
devices are present. Refer to the system
label to verify the presence of wireless
devices.
Wireless devices that may be in your
system are only qualied for use in the
United States of America if an FCC ID
number is on the system label.
This device is restricted to indoor use
due to its operation in the 5.15 to 5.25
GHz frequency range. FCC requires
this product to be used indoors for
the frequency range 5.15 to 5.25 GHz
to reduce the potential for harmful
interference to co-channel Mobile Satellite
systems. High power radars are allocated
as primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar
stations can cause interference with and
/or damage this device.
The power output of the wireless device
(or devices), which may be embedded
in your notebook, is well below the RF
exposure limits as set by the FCC.
This transmitter must not be collocated
or operate in conjunction with any other
antenna or transmitter except the installed
Bluetooth transmitter.
Operation of this device is subject to the
following two conditions: (1) This device
may not cause harmful interference,
and (2) this device must accept any
interference received, including
interference that may cause undesired
operation of the device.
Wireless devices are not user
serviceable. Do not modify them in
any way.
Modication to a wireless device
will void the authorization to use it.
Contact manufacturer for service.
FCC Part 68
(If tted with a modem device.)
This equipment compiles with part
of the FCC rules. On the back of this
equipment is a label that contains, among
other information, the FCC registration
number and ringer equivalence number
(REN) for this equipment. If requested,
this information must be provided to the
telephone company.
This equipment uses the following USOC
jacks : RJ11C
38
An FCC compliant telephone cord
and modular plug is provided with this
equipment. This equipment is designed
to be connected to the telephone network
or promises wiring using a compatible
modular jack which is Part 68 compliant.
See Installation Instructions for details.
The REN is used to determine the
quantity of devices which may be
connected to telephone line. Excessive
RENs on the telephone line may result in
the devices not ringing in response to an
incoming call. In most, but not all areas,
the sum of RENs should not exceed
ve (5.0). To be certain of the number of
devices that may be connected to a line,
as determined by total RENs, contact the
local telephone company to determine the
maximum REN for the calling area.
If the terminal equipment causes harm
to the telephone network, the Telephone
Company will notify you in advance that
temporary discontinuance of service may
be required. But if advance notice is not
practical, the telephone company will
notify the customer as soon as possible.
Also, you will be advised of your right
to le a complaint with the FCC if you
believe it is necessary.
The telephone company may make
changes in its facilities, equipment,
operations, or procedures that could
affect the operation of the equipment. If
this happens, the telephone company
will provide advanced notice in order for
you to make necessary modications to
maintain uninterrupted service.
If trouble is experienced with this
equipment (Modem) for repair or warranty
information, please contact your local
distributor. If the equipment is causing
harm to the telephone network, the
telephone company may request that
you disconnect the equipment until the
problem is resolved.
The user must use the accessories and
cables supplied by the manufacturer
to get optimum performance from the
product.
No repairs may be done by the customer.
This equipment cannot be used on public
coin phone service provided by the
telephone company. Connection to party
line service is subject to state tariffs.
39
Unintentional Emitter per ICES-003
This digital apparatus does not exceed
the Class B limits for radio noise
emissions from digital apparatus as set
out in the radio interference regulations of
Industry Canada.
Le présent appareil numérique n’émet
pas de bruits radioélectriques dépassant
les limitesapplicables aux appareils
numériques de Classe B prescrites
dans le règlement sur le brouillage
radioélectrique édicté par Industrie
Canada.
Canada
The Telephone Consumer Protection Act
of 1991 makes it unlawful for any person
to use a computer or other electronic
device, including fax machines, to send
any message unless such message
clearly contains in a margin at the top or
bottom of each transmitted page or on
the rst page of the transmission, the date
and time it is sent and an identication
of the business or other entity, or other
individual sending the message and
the telephone number of the sending
machine or such business, other entity,
or individual. (The telephone number
provided may not be any number for
which charges exceed local or long-
distance transmission charges.)
In order to program this information
into your fax machine, refer to your
communications software user manual.
40
Intentional Emitter per RSS 210
(If tted with 2.4G band or 5G band)
Low power, Radio LAN type devices
(radio frequency (RF) wireless
communication devices), operating in
the 2.4GHz/5GHz Band, may be present
(embedded) in your notebook system.
This section is only applicable if these
devices are present. Refer to the system
label to verify the presence of wireless
devices.
Wireless devices that may be in your
system are only qualied for use in
Canada if an Industry Canada ID number
is on the system label.
When using IEEE 802.11a wireless LAN,
this product is restricted to indoor use
due to its operation in the 5.15- to 5.25-
GHz frequency range. Industry Canada
requires this product to be used indoors
for the frequency range of 5.15 GHz to
5.25 GHz to reduce the potential for
harmful interference to co-channel mobile
satellite systems. High power radar is
allocated as the primary user of the
5.25- to 5.35-GHz and 5.65 to 5.85-GHz
bands. These radar stations can cause
interference with and/or damage to this
device.
The maximum allowed antenna gain for
use with this device is 6dBi in order to
comply with the E.I.R.P limit for the 5.25-
to 5.35 and 5.725 to 5.85 GHz frequency
range in point-to-point operation.
The power output of the wireless device
(or devices), which may be embedded
in your notebook, is well below the
RF exposure limits as set by Industry
Canada.
This transmitter must not be collocated
or operate in conjunction with any other
antenna or transmitter except the installed
Bluetooth transmitter.
Operation of this device is subject to the
following two conditions: (1) This device
may not cause harmful interference,
and (2) this device must accept any
interference received, including
interference that may cause undesired
operation of the device.
To prevent radio interference to
licensed service, this device is
intended to be operated indoors
and away from windows to provide
maximum shielding. Equipment (or
its transmit antenna) that is installed
outdoors is subject to licensing.
Wireless devices are not user
serviceable. Do not modify them in
any way. Modication to a wireless
device will void the authorization
to use it. Contact manufacturer for
service.
41
Telecommunications per DOC
notice (for products tted with an
IC-compliant modem)
The Industry Canada label identies
certied equipment. This certication
means that the equipment meets certain
telecommunications network protective,
operation, and safety requirements.
The Department does not guarantee
the equipment will operate to the users’
satisfaction.
Before installing this equipment, users
should make sure that it is permissible
to be connected to the facilities of the
local telecommunications company. The
equipment must also be installed using
an acceptable method of connection. In
some cases, the inside wiring associated
with a single-line individual service may
be extended by means of a certied
connector assembly. The customer
should be aware that compliance with
the above conditions may not prevent
degradation of service in some situations.
Repairs to certied equipment should
be made by an authorized Canadian
maintenance facility designated by
the supplier. Any repairs or alterations
made by the user to this equipment, or
equipment malfunctions, may give the
telecommunications company cause
to request the user to disconnect the
equipment.
Users should make sure, for their own
protection, that the electrical ground
connections of the power utility, telephone
lines, and internal metallic water pipe
system, if present, are connected
together. This precaution may be
particularly important in rural areas.
To avoid electrical shock or
equipment malfunction do not
attempt to make electrical ground
connections by yourself. Contact the
appropriate inspection authority or an
electrician, as appropriate.
The Ringer Equivalence Number (REN)
assigned to each terminal device provides
an indication of the maximum number
of terminals allowed to be connected to
a telephone interface. The termination
on an interface may consist of any
combination of devices subject only to the
requirement that the sum of the Ringer
Equivalence Numbers of all the devices
does not exceed 5.
Brazil
Este equipamento opera em caráter
secundário, isto é, não tem direito a
proteção contra interferência prejudicial,
mesmo de estações do mesmo tipo, e
não pode causar interferência a sistemas
operando em caráter primário.
42
European Union CE Marking and
Compliance Notices
Products intended for sale within the
European Union are marked with the
Conformité Européene (CE) Marking,
which indicates compliance with the
applicable Directives and European
standards and amendments identied
below. This equipment also carries the
Class 2 identier.
The following information is only
applicable to systems labeled with the CE
mark .
European Directives
This Information Technology Equipment
has been tested and found to comply with
the following European directives:
EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
R&TTE Directive 1999/5/EC
Manufacturer Information
Samsung Electronics Co., Ltd.
416, Maetan-3Dong, Yeongtong-Gu,
Suwon-City, Gyeonggi-Do, 443-742,
Korea
Samsung Electronics Suzhou
Computer Co., Ltd.
No. 198, Fangzhou Road, Suzhou
Industrial Park, Jiangsu Province, 215021,
China
Tel:+86-512-6253-8988
For the web or the phone number of
Samsung Service Centre, see the
Warranty or contact the retailer where you
purchased your product.
European Union
43
European Radio Approval
Information (for products tted with
EU-approved radio devices)
This Product is a Notebook computer;
low power, Radio LAN type devices (radio
frequency (RF) wireless communication
devices), operating in the 2.4GHz/5GHz
band, may be present (embedded) in your
notebook system which is intended for
home or ofce use. This section is only
applicable if these devices are present.
Refer to the system label to verify the
presence of wireless devices.
Wireless devices that may be in your
system are only qualied for use in the
European Union or associated areas
if a CE mark with a Notied Body
Registration Number and the Alert
Symbol is on the system label.
The power output of the wireless device
or devices that may be embedded in you
notebook is well below the RF exposure
limits as set by the European Commission
through the R&TTE directive.
The low band 5.15 - 5.35 GHz is for
indoor use only.
See 802.11b and 802.11g restrictions
for specic countries or regions
within countries under the heading
“European Economic Area
Restrictions” below.
44
EU R&TTE Compliance Statements
Česky
[Czech]
Samsung tímto prohlašuje, že tento Notebook PC je ve shodě se
základními požadavky a dalšími příslušnými ustanoveními směrnice
1999/5/ES.
Dansk
[Danish]
Undertegnede Samsung erklærer herved, at følgende udstyr Notebook
PC overholder de væsentlige krav og øvrige relevante krav i direktiv
1999/5/EF.
Deutsch
[German]
Hiermit erklärt Samsung, dass sich das Gerät Notebook PC in
Übereinstimmung mit den grundlegenden Anforderungen und den
übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG bendet.
Eesti
[Estonian]
Käesolevaga kinnitab Samsung seadme Notebook PC vastavust
direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele
teistele asjakohastele sätetele.
English Hereby, Samsung, declares that this Notebook PC is in compliance with
the essential requirements and other relevant provisions of Directive
1999/5/EC.
Español
[Spanish]
Por medio de la presente Samsung declara que el Notebook PC
cumple con los requisitos esenciales y cualesquiera otras disposiciones
aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Samsung ΔΗΛΩΝΕΙ ΟΤΙ Notebook PC
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ
ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French]
Par la présente Samsung déclare que l’appareil Notebook PC est
conforme aux exigences essentielles et aux autres dispositions
pertinentes de la directive 1999/5/CE.
Italiano
[Italian]
Con la presente Samsung dichiara che questo Notebook PC è
conforme ai requisiti essenziali ed alle altre disposizioni pertinenti
stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian] Ar šo Samsung deklarē, ka Notebook PC atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian] Šiuo Samsung deklaruoja, kad šis Notebook PC atitinka esminius
reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
45
Nederlands
[Dutch]
Hierbij verklaart Samsung dat het toestel Notebook PC in
overeenstemming is met de essentiële eisen en de andere relevante
bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, Samsung, jiddikjara li dan Notebook PC jikkonforma mal-
ħtiāijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm d-
Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, Samsung nyilatkozom, hogy a Notebook PC megfelel a
vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb
elõírásainak.
Polski
[Polish]
Niniejszym Samsung oświadcza, Ŝe Notebook PC jest zgodny
z zasadniczymi wymogami oraz pozostałymi stosownymi
postanowieniami Dyrektywy 1999/5/EC.
Português
[Portuguese] Samsung declara que este Notebook PC está conforme com os
requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian] Samsung izjavlja, da je ta Notebook PC v skladu z bistvenimi zahtevami
in ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak] Samsung týmto vyhlasuje, že Notebook PC spĺňa základné požiadavky
a všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
Samsung vakuuttaa täten että Notebook PC tyyppinen laite on
direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin
muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar Samsung att denna Notebook PC står I
överensstämmelse med de väsentliga egenskapskrav och övriga
relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Íslenska
[Icelandic] Hér með lýsir Samsung yr því að Notebook PC er í samræmi við
grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC.
Norsk
[Norwegian] Samsung erklærer herved at utstyret Notebook PC er i samsvar med de
grunnleggende krav og øvrige relevante krav i direktiv 1999/5/EF.
Türkiye
[Türkçe] Bu belge ile, Samsung bu Notebook PC’nin 1999/5/EC Yönetmeliğinin
temel gerekliliklerine ve ilgili hükümlerine uygun olduğunu beyan eder.
To view the EU Declaration of Conformity for this product (in English only), go to: http://
www.samsung.com/uk/support/download/supportDownMain.do then search the model
number of the product. If the Declaration of Conformity for the model you are interested
in is not available on our web-site, please contact your distributor.
46
European Economic Area Restrictions
Local Restriction of 802.11b/802.11g
Radio Usage
[Note to integrator: The following
statements on local restrictions must be
published in all end-user documentation
provided with the system or product
incorporating the wireless product.]
Due to the fact that the frequencies
used by 802.11b/802.11g wireless
LAN devices may not yet be
harmonized in all countries,
802.11b/802.11g products are
designed for use only in specic
countries or regions, and are not
allowed to be operated in countries
or regions other than those of
designated use.
As a user of these products, you
are responsible for ensuring that
the products are used only in the
countries or regions for which they
were intended and for verifying
that they are congured with the
correct selection of frequency and
channel for the country or region of
use. Any deviation from permissible
settings and restrictions in the
country or region of use could be an
infringement of local law and may be
punished as such.
The European variant is intended for
use throughout the European Economic
Area. However, authorization for use is
further restricted in particular countries or
regions within countries, as follows:
General
European standards dictate maximum
radiated transmit power of 100 mW
effective isotropic radiated power (EIRP)
and the frequency range 2400 – 2483.5
MHz.
The low band 5.15 - 5.35 GHz is for
indoor use only.
Belgium
The product may be used outdoors, but
for outdoor transmissions over a distance
of 300m or more, a license from the BIPT
is required.
This restriction should be indicated in the
manual as follows:
Dans le cas d’une utilisation privée, à
l’extérieur d’un bâtiment, au-dessus d’un
espace public, aucun enregistrement n’est
nécessaire pour une distance de moins
de 300m. Pour une distance supérieure
à 300m un enregistrement auprès de
l’IBPT est requise. Pour une utilisation
publique à l’extérieur de bâtiments, une
licence de l’IBPT est requise. Pour les
enregistrements et licences, veuillez
contacter l’IBPT.
47
France
For Metropolitan departments:
2.400 - 2.4835 GHz for indoor use.
2.400 - 2.454 GHz (channels 1 to 7) for
outdoor use.
For Guadeloupe, Martinique, St Pierre et
Miquelon, Mayotte:
2.400 - 2.4835 GHz for indoor and
outdoor use.
For Reunion, Guyane:
2.400 - 2.4835 GHz for indoor use.
2.420 - 2.4835 GHz for outdoor use
(channels 5 to 13)
The low band 5.15 - 5.35 GHz is for
indoor use only.
European Telecommunication
Information (for products tted with
EU-approved modems)
Marking by the symbol indicates
compliance of this equipment to the
Radio and Telecom Terminal Equipment
Directive 1999/5/EC. Such marking is
indicative that this equipment meets or
exceeds the following technical standards:
CTR 21 - Attachment requirements for
pan-European approval for connection to
the analogue Public Switched Telephone
Networks (PSTNs) of TE (excluding TE
supporting voice telephony services) in
which network addressing, if provided, is
by means of Dual Tone Multi-Frequency
(DTMF) signaling.
Although this equipment can use
either loop disconnect (pulse) or
DTMF (tone) signaling, only the
performance of the DTMF signaling
is subject to regulatory requirements
for correct operation.
It is therefore strongly recommended
that the equipment is set to use
DTMF signaling for access to public
or private emergency services.
DTMF signaling also provides faster
call setup.
This equipment has been approved to
Council Decision 98/482/EEC - “CTR
21” for Pan-European single terminal
connection to the Public Switched
Telephone Network (PSTN).
However, due to differences between
the individual PSTNs provided in
different countries, the approval does
not, of itself, give an unconditional
assurance of successful operation on
every PSTN termination point. In the
event of problems, you should contact
manufacturer Technical Support.
48
WEEE SYMBOL INFORMATION
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate
collection systems.)
This marking on the product, accessories or literature indicates that the product and
its electronic accessories (e.g. charger, headset, USB cable) should not be disposed
of with other household waste at the end of their working life. To prevent possible harm
to the environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product,
or their local government ofce, for details of where and how they can take these items
for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should not be mixed with
other commercial wastes for disposal.
49
Correct disposal of batteries in this product
Pb
(Applicable in the European Union and other European countries with separate
battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this
product should not be disposed of with other household waste at the end of their
working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the reference levels in EC Directive
2006/66. If batteries are not properly disposed of, these substances can cause harm to
human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries
from other types of waste and recycle them through your local, free battery return
system.
USA ONLY
This Perchlorate warning applies only to primary CR (Maganese Dioxide) Lithium coin
cells in the product sold or distributed ONLY in California USA.
“Perchlorate Material- special handling may apply, See www.dtsc.ca.gov/
hazardouswaste/perchlorate.”
Contains Mercury, Dispose According to Local, State or Federal Laws.
For details see lamprecycle.org, eise.org, or call 1-800-Samsung.
50
Overview
Front View
1Camera Lens (Optional) Using this lens, you can take still pictures and record video.
2Keyboard A device to enter data by pressing the keys.
3Touchpad/Touchpad
Buttons The touchpad and touchpad buttons provide functions
similar to the mouse ball and buttons.
4Power Switch Turns the computer on or off.
5Multi Card Slot
(Optional) A card slot that supports SD Card, SDHC and MMC.
6Status Indicators Shows the operating status of the computer.
The corresponding operating LED is lit when the
corresponding function operates.
7Microphone (Optional) You can use the built-in microphone.
8LCD The screen images are displayed here.
Optional items may be changed or
may not be provided depending on
the computer model.
The actual color and appearance
of the computer may differ from the
pictures used in this guide.
1
8
2
3
6
54
7
51
Status Indicators
1Caps Lock This turns on when the Caps Lock key is pressed allowing capital
letters to be typed without holding the Shift button down.
2Hard Disk Drive Indicates that the hard disk drive is running.
3Wireless LAN This turns on when the wireless LAN is operating.
4Charge Status This shows the power source and the battery charge status.
Green: When the battery is fully charged or the battery is not
installed.
Amber: When the battery is being charged.
Off: When the computer is running on battery power without
being connected to AC adapter.
5Power This shows the computer operating status.
On: When the computer is operating.
Blinks: When the computer is in Sleep mode.
4 51 3
2
52
Right View
1Wireless LAN Switch
(Optional) In models with a wireless LAN function, rst make sure that
the wireless LAN function is turned off.
2USB Port You can connect USB devices to the USB port such as a
keyboard/mouse, digital camera, etc.
3Monitor Port A port used to connect a monitor, TV or projector
supporting a 15pin D-SUB interface.
4Security Lock Port You can connect a Kensington lock to the Security Lock
Port to prevent the computer from being stolen.
2 3 41
53
1DC Jack A jack to connect the AC adapter that supplies power to the
computer.
2Wired LAN Port Connect the Ethernet cable to this port.
3Fan Vents The internal heat of the computer is emitted through these
holes.
If the vents are blocked the computer may overheat.
Avoid blocking the vents as this may be dangerous.
4USB Port /
Chargeable USB
Port (Optional)
You can connect USB devices to the USB port such as a
keyboard/mouse, digital camera, etc. (Chargeable USB: You
can charge USB devices through the USB port even when the
computer is turned off.)
Charging a device through a Chargeable USB takes longer than using a
regular charger.
Press the F2 key when the Samsung logo appears in the booting sequence to
enter the BIOS Setup, select Advanced > USB Charge In Sleep Mode, and
set it to Enable. Then you can use the Chargeable USB Port feature even in
sleep mode.
5Microphone Jack A jack used to connect the microphone.
6Headphone Jack A jack used to connect the headphones.
Left View
21 3 4 5 6
54
Back View
1Battery This is a Lithium-Ion rechargeable battery that supplies power to
the computer.
1
55
Bottom View
1Battery Latches The latch used to remove or install the battery.
2Sub-Woofer Speaker
(Optional) A device used to produce mid and low frequency
sound louder.
3Memory Compartment Cover The main memory is installed inside the cover.
4Fan Vents The internal heat of the computer is emitted through
these holes.
If the vents are blocked the computer may overheat.
Avoid blocking the vents as this may be dangerous.
5Speaker A device used to generate sound.
1
3
5
2
4
56
Turning the Computer On and Off
Turning the computer on
1 Install the battery and connect the
AC adapter.
2 Lift the LCD panel up.
3 Slide the Power Switch to turn the
computer on.
When running the computer on
battery power, the LCD brightness
is dimmed automatically to save
battery power.
Press the Fn + key to increase
the LCD brightness.
When turning the computer on
for the rst time, the Register
Windows screen appears. You can
use the computer after registering
your user information.
Turning the computer off
Since the procedures to turn the
computer off may differ depending
on the installed operating system,
please turn the computer off
according to the procedures for the
purchased operating system.
▶ For Windows 7
1 Click the Start button on the
taskbar.
2 Click Shut down to shut
down the computer.
1 2
Save all your data before clicking on
Shut down.
57
If the model supports HyperSpace
(Optional)
If you shutdown Windows when
HyperSpace is running, HyperSpace
is also terminated automatically
when Windows is shutdown.
▶ For Windows XP
1 Click the Start button on the
taskbar.
2 Click Turn Off Computer.
3 Click Turn Off.
If the computer has not turned off
properly due to a system error,
press <Ctrl>+<Alt>+<Delete>.
When [Windows Task Manager]
dialog box appears, click Shut
Down > Turn Off to turn off the
computer. Your unsaved work may
be lost/damaged.
If <Ctrl>+<Alt>+<Delete> keys
do not operate either, press the
power button for more than 4
seconds to turn off the computer.
Your unsaved work may be lost/
damaged. The next time you turn
on your computer, a hard disk
check will be performed, before
Windows starts.
Chapter 2.
Using the computer
Keyboard 59
Touchpad 62
External-type CD drive (To be purchased) 68
Multi Card Slot (Optional) 70
Connecting a monitor / TV 73
Adjusting the Volume 78
Wired Network 83
Wireless Network (Optional) 87
Using HyperSpace (Optional) 90
HDD Protection Function (Optional) 98
59
Keyboard
Shortcut key functions and procedures are discussed in the following sections.
The keyboard is supplied according to the corresponding country.
The keyboard may differ depending on your country. The following mainly describes
the shortcut keys.
Shortcut Keys
You can use the following functions by pressing the keys below with the Fn key.
Fn+ Name Function
REST
(Sleep Mode) Switches to Sleep mode. To wake the computer up, press the
Power button.
Gauge Shows the remaining battery charge.
You can only use this function when the Easy Display Manager
program is installed.
Euro Enters the Euro monetary unit symbol.
This key may not be provided depending on the keyboard type.
CRT/LCD Switches the screen output to the LCD or external monitor when
an external monitor (or TV) is connected to the computer.
Backlight Turns the LCD backlight on or off.
Mute Mutes or cancels mute.
60
Fn+ Name Function
Samsung
Support
Center
System diagnosis, recovery and Internet consultation program,
Samsung Support Center, will be launched. (Optional)
For some models, Samsung Magic Doctor is launched.
Easy
SpeedUp
Manager
You can select operation mode when you need maximum system
performance or low-noise/low power consumption with one-click.
Silent: Low-noise and low power consumption mode
Normal: Normal Mode
Speed: Maximum performance mode. The system operates
in its maximum performance, and system resources are
allocated to the currently active program with priority for
maximum performance.
For Windows XP model, Easy SpeedUp Manager function
is provided in Magic Keyboard program.
If you reinstall Windows XP, you have to install the Magic
Keyboard program additionally using the System Software
Media in order to use this function.
(For models supplied with a System Software Media.)
If you don’t want fan noise turning ON and OFF in the
Silent mode, select the Advanced menu > Fan Silent
Mode > Low in the BIOS Setup. The fan keeps turning
ON and works in Low noise mode.
Wireless LAN Turns the wireless LAN function on or off in models with wireless
LAN capability.
Touchpad Turns the Touchpad function on or off.
When using an external mouse only, you can turn the Touchpad
off.
61
Screen Brightness Control
To adjust the LCD brightness press the
Fn + key combination or the Fn +
key combination.
The changed screen brightness is
displayed at the center of the screen for a
moment.
Volume Control
To control the volume, press the
Fn + key combination or the Fn +
key combination.
You can mute the sound or cancel the
mute function by clicking the Fn +
key combination.
Numeric Key
The numbers are printed in blue on the
numeric keys.
If Num Lock is turned on by pressing the
Fn + key combination, you can use
the numeric keys to enter digits.
Other Function Keys
Application Key
Performs the right-click mouse function
(touchpad).
Fn+ Name Function
Num Lock Turns the numeric keyboard on or off.
Scroll Lock If you turn the Scroll Lock on, you can scroll the screen up or
down without changing the cursor location in some applications.
62
Touchpad
The touchpad provides the same function as a mouse and the left and right buttons of
the touchpad plays the role of the left and right buttons of a mouse.
Use the Touchpad with your ngers. Using a sharp object may damage the
Touchpad.
If you touch the Touchpad or press the Touchpad buttons while booting up, the
Windows boot time may be extended.
Touchpad
Use to move the cursor.
Scroll Area
Plays the role of the mouse
wheel. You can scroll up
and down using the Scroll
Area.
Touchpad Left Button
You can select or run a
program using this button.
Touchpad Right Button
Plays the role of the right
mouse button.
Basic Touchpad Functions
Moving the cursor on the screen
Place your nger on the touchpad slightly
and move your nger.
The mouse cursor will move accordingly.
Move your nger in the direction you wish
to move the cursor.
63
Click Function
Place your nger on the touchpad and tap
your nger once over an item you want.
Alternatively, press the left touchpad
button once.
Tap
Click
or
Double-Click Function
Put your nger on the touchpad and
quickly tap twice with your nger on an
item you want.
Alternatively, press the left touchpad
button twice quickly.
or ClickClick
TapTap
Right Button Function
This corresponds to clicking the right
mouse button.
Press the right touchpad button once. The
corresponding pop-up menu appears.
Click
Drag Function
Dragging refers to moving an item to
another place after selecting it.
Press and hold down the left touchpad
button over an item you want to drag and
move the item to the new location.
Holding down
the left touchpad
button
Move
64
The Gesture Function of the Touchpad (Optional)
The Touchpad Gesture function may not be provided and the version of the function
may differ depending on the model. Some usage procedures may differ depending
on the version.
For detailed usage procedures, refer to the description in the Touchpad Settings
window. In addition, if you click the Show Video button of each item, you can refer
to the video descriptions.
The images in this document may differ from the actual screen images and a
different Touchpad may be provided depending on the model. In addition, since the
pictures used in this document are pictures of a representative model, they may
differ from the actual appearance of your computer.
These descriptions are written based on Windows 7, the latest operating system.
Therefore, some descriptions and gures may differ from your operating system.
But as the usage is similar to other Windows operating systems, you can use these
descriptions for reference.
The path may differ depending on the operating system.
Touchpad Scroll Function
The touchpad scroll area provides the
mouse wheel function (scroll function).
Place your nger on the touchpad’s right
edge for vertical scrolling or the bottom
edge for horizontal scrolling and then
move your nger along the edge to scroll
the screen vertically or horizontally.
65
Using the Touchpad, you can use the
following additional Gesture functions.
Scroll function using two ngers
Zoom functions using two ngers
Rotation function using two ngers.
Move function using three ngers
Conguring the Gesture Function
If the Gesture function is not activated,
you can activate it according to the
following procedures.
1 Click the Start > Control Panel
> Hardware and Sound > Mouse
> Device Settings tab > Settings
button.
2 The Touchpad Settings window
appears. Click over the corresponding
item to select the item in the Select
an item and click OK.
To cancel the Gesture function,
unselect the corresponding item in
the Touchpad Settings window and
click OK.
The Scroll Function
This function is the same as the scroll
area of the Touchpad.
If you place two ngers over the
Touchpad and move them up, down, left
or right, the screen is scrolled up, down,
left or right.
or
Zoom Functions
If you place two ngers over the
Touchpad together or apart, the current
image or text is zoomed in or out.
or
Zoom-out
Zoom-in
66
Rotation Function
If you place two ngers over the
Touchpad, and keep one nger in place
and turn the other nger in the left or right
direction, the mouse pointer changes into
the icon and the current photo or image
is rotated.
or
Move Function
When watching a photo or surng the
Internet, you can move to the previous or
next photo or Internet page without using
the mouse or buttons.
Place three ngers over the Touchpad
and slightly touch the surface of the
Touchpad with them in the left or right
direction to move to the previous or next
photo or Internet page.
For example, if you touch the Touchpad in
the left direction using three ngers while
looking at a website, the previous page is
displayed.
67
Touchpad On/Off Function
If you want to use the mouse only without
using the touchpad, you can turn the
touchpad off.
To lock the touchpad function, press the
Fn + keys.
You can set the touchpad and
touchpad button settings in the tabs
that appear when clicking Start >
Control Panel > Hardware and
Sound > Mouse.
68
External-type CD drive (To be purchased)
This computer supports an external USB CD-ROM drive (can be additionally
purchased).
Check if the interface type of the external CD-ROM drive is a USB type. For detailed
specications, refer to the catalog.
Do not insert a cracked or scratched CD.
Otherwise, the CD may break and damage the optical disk drive when the CD
rotates at a high speed.
When you clean a CD or DVD title, wipe with a soft cloth from inside to outside.
Do not eject a CD when the CD operating LED is on.
The images used for the illustration are of a representative model, therefore the
images may differ from the the actual product.
Using a CD that is not in the shape of a circle is not recommended.
Connecting the CD Drive
Connect the CD drive to the USB port.
USB port
69
Inserting and Ejecting a CD
1 Press the Eject button of the CD
drive.
Status Indicator
Eject Button
Emergency Hole
2 When the CD tray opens, insert a CD
or DVD and push the tray in until it
clicks.
3 Push the CD tray inward until it clicks.
The CD drive status indicator is turned
on.
A CD drive’s reading and writing
speed may differ depending on the
condition and type of the media.
To eject a CD when the CD drive
does not work or the computer is
off, place the end of a paper clip
() into the Emergency Hole
until the CD tray is ejected.
70
Multi Card Slot (Optional)
Using the multi card slot, you can read and write data from and to an SD card, SDHC
card, MMC.
You can use a card as a removable disk and conveniently exchange data with digital
devices such as a digital camera, digital camcorder, MP3, etc.
You have to additionally purchase a multi card with the necessary capacity
depending on your requirements.
You can use a multi card just like any data storage device. A copyright protection
function is not supported.
Since you can lose a card when moving the computer, keep the card separately.
Before use, remove the dummy card that was inserted to protect the slot.
Supported Cards: SD Card, SDHC Card, MMC
The images used for the illustration are of a representative model, therefore the
images may differ from the the actual product.
These descriptions are written based on Windows 7, the latest operating system.
Therefore, some descriptions and gures may differ from your operating system.
But as the usage is similar to other Windows operating systems, you can use these
descriptions for reference.
To Insert and Use a Memory Card
1 Insert a card into the slot according to the directions printed on the slot.
Example) SD Card
71
2 The card drive appears. Click Open
folder and view les.
If the window does not appear, click
Start > Computer.
(For Windows XP, click Start > My
Computer.)
3 You can save, move and delete data
by double-clicking the corresponding
drive.
The device name of the card drive
may differ depending on your
computer model.
You can only use the card after
formatting it.
Using a Mini SD snd RS-MMC
Since the above cards are too small,
you cannot insert the cards into the
slot directly.
Insert the card into the dedicated
adapter (available from most
electronic retailers) and then insert
the adapter into the multi card slot.
However, depending on the adapter’s
body material, some RS-MMC cards
may not be recognized properly.
Samsung recommends checking the
card is recognized correctly prior to
purchasing.
72
To remove a memory card
Take hold of the end of the card and
remove the card.
To format a memory card
When using the memory card for the rst
time, you must format the card before
using it.
Formatting a card deletes all data
saved on the card. If the card
includes data, backup the data
before formatting it.
1 Click Start > Computer.
(For Windows XP, click Start > My
Computer.)
2 Right-click over a card drive with the
touchpad and select Format.
3 Click Start to the formatting.
To use a card to exchange data
with a digital device such as a
digital camera, formatting the
data using the digital device is
recommended.
When you try to use a card, which
is formatted in the computer, in
another digital device, you may
have to format the card again in
the device.
You cannot format, write or delete
data from a SD, or SDHC card
with a write protection tab when it
is in the Lock position.
Inserting and removing a memory
card repeatedly may damage the
memory card.
73
Connecting a monitor / TV
Using an external display device is useful when you are giving a presentation or
watching a video or movie through your monitor.
You have to buy a connection cable additionally.
Due to restrictions of the operating system the DualView function is not supported
for Windows 7 Starter.
Connecting to the Monitor / TV
Connecting to the Monitor port
Connect the computer to the RGB port of the monitor or TV using a monitor cable
(15-pin).
74
Switching the Display Device using
the Shortcut Key
Press the Fn + key combination
once. Then the Easy Display Manager
screen appears in which you can select a
display device.
Whenever you press the key while
holding down the Fn key, the selected
option is changed.
Example) Selecting LCD+CRT
Dual View
LCD: Notebook Screen
CRT: External Monitor Screen
LCD+CRT Clone : Notebook+
External Monitor Screen
LCD+CRT DualView: Notebook+
External Monitor Screen in Dual
View
What is Dual View?
Dual View is a function that
enables you to view a computer
screen over two display devices.
It is convenient when you need a
wide screen.
Due to restrictions of the operating
system the DualView function
is not supported for Windows 7
Starter.
External Monitor / TV is not
supported in the DOS Command
Prompt window.
Viewing Through a Monitor / TV
You can switch the display device using the shortcut key.
75
Using Dual View to View Extended Screen
Dual View is a function that enables you to view a computer screen over two display
devices. This is convenient when needing a wide screen for work.
In Dual View mode, you can select the screen resolution and color quality for each
display device, as if there were two separate graphics cards.
Due to restrictions of the operating system the DualView function is not supported for
Windows 7 Starter.
Selecting Dual View
Check if the external display device
is properly connected and follow the
instructions below.
▶ For Windows 7
1 Click the Start > Control Panel >
Appearance and Personalization >
Adjust screen resolution.
2 Click the monitor number 2 icon and
select Extend these displays in the
Multiple displays item. Click the
Apply button and then the OK button. 3 When notebook LCD is set as the
main device, the 1 digit is displayed
over it and the 2 digit is displayed over
the auxiliary display device. Now you
can expand the Desktop screen over
2 display devices.
When using Dual View, it is
recommended setting the LCD as the
main device (number 1).
76
Adjusting the resolution of the
auxiliary display device (Monitor
Number 2)
If the resolution of the auxiliary
display device is output, you can
adjust the resolution and color quality
by clicking Start > Control Panel >
Appearance and Personalization
> Adjust screen resolution >
Monitor Number 2.
▶ For Windows XP
1 Connect the external display device
(e.g. a monitor or a projector) to the
corresponding port of the system. To
connect a TV, connect the TV to the
TV output port of the system.
2 Press touchpad right button on the
desktop, click Properties, and then
click the Settings tab.
3 Click the monitor 2 icon, select the
Extend my Windows desktop onto
this monitor check box, and then
click Apply.
4 When the conguration is complete,
click Identify on the left side of
Troubleshoot. The primary display
device(the LCD) is indicated as 1,
and the secondary display device is
indicated as 2. Now you can view the
screen through two monitors.
When you use Dual View, conguring
the LCD as the 'Primary' monitor is
recommended.
1 : Primary 2 : Secondary
77
Adjusting the resolution of the
auxiliary display device (Monitor
Number 2)
If the screen of the secondary
display device is displayed, change
the settings to the desired screen
resolution and color quality in the
[Display Properties] dialog box.
Using Window in Dual View
Click on the window title bar of the main
LCD (monitor number 1) and drag it into
the auxiliary display device (monitor
number 2) to move the window.
()
Canceling Dual View
▶ For Windows 7
1 Click the Start > Control Panel >
Appearance and Personalization >
Adjust screen resolution.
2 Click the monitor number 2 icon and
select Show Desktop on 1 only in
the Multiple displays item. Click the
Apply button and then the OK button.
▶ For Windows XP
Click the monitor 2 icon, clear the
Extend my Windows desktop onto
this monitor check box, and then
click Apply.
78
Adjusting the Volume using the
Keyboard
Press the Fn + key combination or
Fn + key combination to adjust the
volume.
Press the Fn + key combination to
turn the volume on or off.
Adjusting the Volume using the
Volume Adjustment Program
Click the Volume icon on the taskbar
and slide the volume control bar to adjust
the volume.
Mute
Windows XPWindows 7
▶ For Windows 7
Right-click over the Volume icon
and select Open Volume Mixer to
adjust the volume.
▶ For Windows XP
Double-click the Volume icon , and
adjust the volume level in the volume
control program.
Adjusting the Volume
You can adjust the volume using the keyboard and the volume control program.
Since these descriptions are written on the basis of the latest operating system,
Windows 7, some of the content and the gures of the descriptions may differ
depending on the operating system. Since the procedures for other Windows operating
systems are similar, use the computer referring to these descriptions.
79
Using SRS
The SRS function enables you to
experience more stereophonic sound by
expanding the space-perception through
the stereo speaker.
This function is available for specic
models only.
▶ For Windows 7
1 Right-click over the Volume icon in
the Taskbar and select Play Device
(P).
2 Select Speaker in the Play tab and
click Properties.
3 Select the SRS tab in the Speaker
Properties window. Select a mode
and click the Use checkbox on the
left. Click OK. You will be able to
experience a more stereophonic
sound in the selected mode.
z
x
Music: Select to listen to music.
WOW HD technology has been used.
Movie: Select to watch a movie.
TruSurround XT technology has
been used.
When using a Headphone plugged
in the Headphone jack: Some of the
setting details under each menu will
change.
CS Headphone technology has been
used.
80
The SRS function is only
supported for a computer's built-in
speakers or headphones.
It is recommended to unchecking
the SRS option before recording,
and to check it before play. It is to
prevent sound distortion because
of double application of SRS effect
when user plays the le recorded
by using stereo mix.
▶ For Windows XP
1 Click Control Panel > Sound, Voice
and Audio Device > Sound and
Audio Devices.
2 Click the audio tab, select SRS
Premium Sound in Play > Default
Device (D):, and then click the OK
button at the bottom.
In this case, although you can change
the volume in the SRS Mixer, you can
also change the volume in the Master
Volume of the Realtek HD Audio
Output Mixer.
Therefore, when SRS is selected,
you can set the Master Volume of the
Realtek HD Audio Output Mixer to
the maximum value and then set the
actual volume using the SRS Mixer.
This operation may not be required
depending on the type of SRS driver.
3 Click on Control Panel > Sound,
Voice and Audio Device > SRS
Control Panel.
Check the Enable checkbox and
select a mode. Then you can listen
to sound through the selected SRS
effect.
WOW XT (Music): Select to listen to
music.
TruSurround XT (Movie/Video):
Select to watch a movie.
The SRS function is only supported
for a computer’s built-in speakers
or headphones.
It is recommended unchecking the
SRS option before recording, and
checking it before playing sound.
This is to prevent sound distortion
due to the double application of the
SRS effect when a user plays the
recorded le by using stereo mix.
81
▶ For Windows 7
1 Connect a microphone to the
microphone jack.
You can also use the internal MIC.
2 Right-click over the Volume icon
on the taskbar and select Recording
Device.
3 Check if the microphone is set as the
default recording device.
If this is the case, it is already set as
the default device. If not, right-click
over the microphone and select Set
default.
4 Click Start > All Programs >
Accessories > Sound Recorder
and click Start recording to start a
recording.
▶ For Windows XP
1 Connect a microphone to the
microphone jack.
You can also use the internal MIC.
2 Click Start > Control Panel >
Sounds, Speech, and Audio
Devices > Sounds and Audio
Devices.
3 Click Advanced from Volume and
then, click Options > Properties.
Using Recorders
This section describes how to perform recording on a computer by using Windows
Recorder.
82
4 Select Realtek HD Audio input from
the mixer device to select Recording
from Adjust Volume for.
5 Select Mic Volume from Show the
following volume controls and click
OK.
6 When Recording Control window
appears, check the Select checkbox.
Increase the recording volume to
increase the recording sensitivity and
close the window.
7 Click Start > All Programs >
Accessories > Entertainment >
Sound Recorder.
8 Click the Record button to perform
recording.
The default recording duration of
Windows is 60 seconds. Download
a dedicated recording program from
the Internet to record audio data for a
long time.
83
1 Connect a LAN cable to the
computer’s LAN port. 2 ▶ For Windows 7
Click Start > control Panel >
Network and Internet > Network
and Sharing Center and click
Change adapter settings in the
left menu pane.
▶ For Windows XP
Click Start > Control Panel
> Network and Internet
Connections > Network
Connection.
Wired Network
A wired network is a network environment used for a company network or broadband
internet connection at home.
Since these descriptions are written on the basis of the latest operating system,
Windows 7, some of the content and the gures of the descriptions may differ
depending on the operating system. Since the procedures for other Windows operating
systems are similar, use the computer referring to these descriptions.
84
3 Select Local Area Connection and
click the right button of the touch pad
and select Properties.
The LAN Device name may differ
depending on your computer’s
Network Device.
4 ▶ For Windows 7
Select Internet Protocol Version
4 (TCP/IPv4) from the Networking
tab and click Properties.
▶ For Windows XP
Click General tab and select a LAN
driver from Connect using:. Select
Internet Protocol(TCP/IP) and click
Properties.
The displayed LAN driver may
vary depending on the LAN device
type.
Click Install to add a network
component as shown in the gure
below: You can add a client, a
service, or a protocol.
85
5 Congure IP settings.
Select Obtain an IP address
automatically when using DHCP. If
you use a static IP, select Use the
following IP address and enter the
values.
If the IP of your computer is not
automatically assigned, contact the
network administrator.
6 If all settings are made, click OK. Now
the network conguration is nished.
Using both DHCP and a xed IP
simultaneously
Using the Alternate Conguration
provided by Windows, you can set both
automatic and xed IP addresses and
then you can select to use either of them
to connect to the Internet.
1 ▶ For Windows 7
Click Start > Control Panel >
Network and Internet > Network
and Sharing Center and click on
Change adapter settings in the
left menu pane.
▶ For Windows XP
Click Start > Control Panel
> Network and Internet
Connections > Network
Connection > Local Area
Connection by using the right
button of the touch pad and click
Properties.
2 Right-click over the Local Area
Connection and select Properties.
86
3 For Windows 7, select Internet
Protocol Version 4 (TCP/IPv4)
from the Networking tab and select
Properties.
For Windows XP, select Internet
Protocol (TCP/IP) and click
Properties.
4 Select the Alternate Conguration
tab, select User congured, ll in the
corresponding elds and click the OK
button.
87
Wireless Network (Optional)
A wireless network allows computers to share resources or an internet connection
without using LAN cables between them.
This description is applied only to the models equipped with wireless LAN cards or
devices.
Some of the pictures shown in this description may vary depending on the wireless
LAN device.
To use the wireless LAN, you have to turn the wireless LAN on rst by pressing the
Fn + keys. If the wireless LAN is turned on, the Wireless LAN LED is lit.
What is Access Point (AP)?
AP is a network device that connects wired LAN to wireless LAN and corresponds to
the wireless hub of a wired network. Also, AP allows you to connect more than one
computer where wireless LAN is enabled.
Connecting to Wireless LAN
If there is an AP, you can connect to the Internet via the AP using the Wireless LAN
connection method provided by Windows.
Some processes may differ depending on the operating system version. Moreover, the
provided images may differ from the actual screen images.
88
▶ For Windows 7
1 If you click the Network Connections
icon in the system tray, a list of
available APs appears. If you select
an AP to connect to, the Connect
button appears.
AP List
2 Click Connect.
If a network key is set for the AP,
enter the network key and then click
Connect.
For the network key, please ask your
network administrator.
3 When Connected to the AP is
displayed, click the Close button.
You can access the network.
89
▶ For Windows XP
1 Click the Wireless Network
Connection icon from the Taskbar
using the right button of the touch
pad. Then, click View Available
Wireless Networks.
2 Select an AP to be connected and
click Connect.
If a network key is set in the AP, the
network key input window will appear.
Enter the network key in the input
window and click OK.
For a network key, contact the
network administrator.
3 Once Connected to AP is displayed,
you can use a wireless network.
To check the network connections
Place the mouse over the Wireless
Network Connection icon (For
Windows XP, ) from the Taskbar. Then,
the status will appear.
Windows 7
Windows XP
90
Using HyperSpace (Optional)
HyperSpace is a space that enables you to enjoy multimedia content such as the
Internet, news, music, videos, and social networking sites through fast Linux-based
booting.
For more information about the HyperSpace functions, refer to the online help that
appears when clicking Apps > Others icon > Help.
The software programs provider may vary, depending on your computer model.
In addition, some pictures may differ from actual product depending on the
computer model and software version.
Starting/Exiting
Starting Hyperspace
You can start HyperSpace as follows
when the computer is turned off or when
Windows is running.
If you do not register Windows when
running it for the rst time, you
cannot use the HyperSpace function.
Use the function after booting
Windows and registering Windows.
▶ When the computer is turned off,
1 Turn the computer on. When the
booting screen (SAMSUNG logo)
appears, press the F6 key.
Alternatively, if the booting screen
has passed, press and hold the F6
key until the HyperSpace screen
appears.
2 After a moment, the HyperSpace
Desktop screen appears.
You can now use HyperSpace.
91
▶ When Windows is running:
1 Double-click the Switch to HyperSpace icon on the Desktop and click
Boot HyperSpace Now > Restart Now.
2 When the computer is restarted, the HyperSpace screen appears.
Exiting Hyperspace
1 Click the power icon > Shutdown at the top left of the screen.
1 Sleep Mode
2 Shutdown
3 Restart
4 Windows Icon
2 HyperSpace is terminated.
When Windows is also being used, the computer is automatically switched to
Windows, Windows is shutdown rst and then HyperSpace is terminated.
92
Switching to Windows
To switch to Windows from HyperSpace, click the Windows icon .
If Windows is not currently running, it will take longer to boot up Windows.
Screen Layout
HyperSpace Desktop Screen
The HyperSpace Desktop screen is the computer’s workspace and has the following
layout.
1
6
2
5
4
3
93
1Start Menu
: Select to switch to the main screen.
: Select to show the power options.
: Select to switch to Windows.
2Notication
Area
: Select to bookmark the current screen.
: Select to setup the power settings.
: Select to setup the volume settings.
: Select to setup the wired/wireless network settings.
3My Contents You can register frequently used content and conrm the registered
content immediately.
4Apps You can directly use various application programs such as the web
browser, multimedia applications, etc.
5Shortcuts You can use mini information programs.
6Recent Shows recently used programs.
94
Window
Click Apps > Files to launch the browser.
You can view the folders and les of the HDD drives and external devices recognized
by Windows.
The items and names may differ depending on the model.
Find folders and les Notication Area
Close the
window
Minimize
the window
Icon View
Setting
Folders and
les
Menu
Toolbar
Folder and le information
95
Network Setting
Some of the procedures may differ depending on the version of the operating system.
In addition, the gures of the screens may differ from the actual screens.
Setting Up the Wired Network
1 Connect the LAN cable to the wired
LAN port.
2 Click the network icon .
3 When the Network Wizard appears,
click Advanced.
To use DHCP, click Automatic
(DHCP).
To use a static IP address, click
Manual (M), enter the IP Address,
Subnet Mask, Default Gateway, and
DNS elds and click Finish.
When DHCP is not supported, ask
your network administrator for the IP
address information.
4 When the network is connected, the
icon turns green.
Now, you can use the network.
96
Setting Up the Wireless Network
If there is an AP nearby, you can access
the Internet simply by setting up the
wireless LAN.
1 Click the network icon .
2 When the Network Setup Wizard
appears, click Advanced.
If you select the Wireless tab,
available APs are listed.
Click over an AP to connect and click
Connect.
Ask your network administrator for
the network key.
3 When the network is connected, the
icon turns green.
You can now use the wireless
network.
Using Applications
Playing Music and Video Files
You can play music and video les using
Real Player.
Click Apps > Real Player > File > Open
File to play a music or video le.
If you run it for the rst time, the setup
screen appears. Perform the setup
according to the instructions on the
screen.
For more information on how to use
Real Player, refer to the Help section.
97
Using the Internet/Chatting
After connecting to the network, click
Apps > Web to access the Internet.
In addition, you can use the video or
text chatting function by clicking Apps >
Skype.
The web browser may fail to open
some web sites that use ActiveX.
In this case, open the web site in
Windows.
Changing the Language Setting
Click Apps > Language, select a
language and click Restart Now.
The language of HyperSpace is changed
to the selected language.
98
HDD Protection Function (Optional)
The HDD Protection program provides a function to protect the HDD from external
impact while the HDD is operating.
This function is only provided for models that are shipped from the factory with this
function.
Through the icon colors, the HDD protection status can be identied. You can activate
or deactivate the function by right-clicking over the icon in the taskbar.
Icon Color Operating Status
The HDD protection function is activated.
The HDD protection function is deactivated.
The HDD has received an impact and the HDD protection function is
currently running.
If external movement (e.g. if a user moves or the vehicle carrying the computer moves)
is detected while the HDD is in operation such as watching a video or copying data,
the current operation and the HDD are stopped accordingly.
If the external movement stops, the paused operation resumes after approximately 3
seconds.
Chapter 3.3.
Settings and Upgrade
LCD Brightness Control 100
BIOS Setup 102
Setting a Boot Password 105
Changing the Boot Priority 108
Upgrading Memory 109
Battery 111
Using the Security Lock Port 116
100
LCD Brightness Control
You can adjust the LCD brightness in 8 levels.
Controlling the Brightness Using the Keyboard
Adjust the LCD brightness by pressing the Fn + key or the Fn + key.
The LCD brightness can change up to 8 levels and the brightness increases by 1 level
when pressing the Fn + key once.
Maintaining the changed LCD brightness even after turning the computer on
again
To maintain the LCD brightness set by using the brightness control keys or through
the Power Options, follow the procedures below.
1. Turn the computer on and press the F2 key when the SAMSUNG logo appears
on the screen to enter the BIOS Setup.
2. Select the Boot menu and set the Brightness Mode Control item to User
Control.
3. Press the F10 key to save the settings and exit Setup.
Saving battery power consumption
Decreases the LCD brightness when the computer is running on battery power to
save battery power consumption.
LCD bad pixels principle of laptop computer
Samsung observes the specications regarding strict quality and reliability of LCD.
But in spite of that, it is inevitable that there might be a small number of bad pixels.
A large number of bad pixels can cause problems in appearance, but a small
number of pixels doesn’t affect the computer performance.
Therefore Samsung observes and manages the following dot principles:
- Bright dot : 2 or less
- Black dot : 4 or less
- Combination of Bright and Dark : 4 or less
