Samsung Electronics Co GTB7610 Cellular/PCS GSM/EDGE Phone with WLAN and Bluetooth User Manual C0CCB8A7BEF8C0BD32
Samsung Electronics Co Ltd Cellular/PCS GSM/EDGE Phone with WLAN and Bluetooth C0CCB8A7BEF8C0BD32
Users Manual
Some of the contents in this manual may differ from your phone depending on the software
of the phone or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English (EU). 04/2008. Rev. 1.0
GT-B7610
user manual
Draft 01
2009. 03. 27
SW : B7610BUIC1
2
Read me first!
When you need information, instructions, and tips to learn more about
your device, you have several options available:
•
Windows Help System
(on your device) - your device includes
Windows Mobile Help, which you can access by tapping Menu >
Help. This embedded, searchable help system explains how to use
various Microsoft programs and features.
•
Extended Usage Guide
(online) - on the Samsung website, you will
find the Extended Usage Guide in Adobe Acrobat (.pdf) format. You
can either view the guide online or download and print the file for
your convenience. The Extended Usage Guide contains advanced
usage tips and more details about particular functions of your
device. To view the file, you must have Adobe Reader or Adobe
Acrobat installed-you can download Adobe Reader free from
Adobe's website (www.adobe.com).
•
User Manual
(printed) - this user manual has been specially
designed to guide you through the functions and features of your
device. It contains extensive information about Samsung software
and features and tips for using and maintaining the device. For any
topics not covered in this manual, please refer to the embedded
help as described above.
3
Instructional Icons
Before you start, familiarise yourself with the icons you will see in this
manual:
Warning
– situations that could cause injury to yourself
or others
Caution
– situations that could cause damage to your
device or other equipment
Note
– notes, usage tips, or additional information
X
Refer to
– pages with related information;
for example:
X
p. 12 (represents "see page 12")
>
Followed by
– the order of options or menus you must
select to perform a step; for example: Tap
S
tart >
Messaging
(represents
Start
, followed by
Messaging
)
[ ]
Square brackets
– device keys; for example: [ ]
(represents the End/Power key)
4
Copyrights and trademarks
Rights to all technologies and products that comprise this device are
the property of their respective owners:
• This product includes software licensed from MS,
an affiliate of the Microsoft Corporation. Microsoft
and software bearing the Microsoft name are
registered trademarks of the Microsoft
Corporation.
• Java™ is a trademark of Sun Microsystems, Inc.
• Bluetooth
®
is a registered trademark of the Bluetooth SIG, Inc.
worldwide. Bluetooth QD ID: B0xxxxx
•Wi-Fi
®
, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are registered
trademarks of the Wi-Fi Alliance.
•DivX
®
is a registered trademark of DivX, Inc., and is
used under license.
5
ABOUT DIVX VIDEO
DivX
®
is a digital video format created by DivX, Inc. This is an official
DivX Certified device that plays DivX video. Plays DivX
®
video up to
320x240.
ABOUT DIVX VIDEO-ON-DEMAND
This DivX
®
Certified device must be registered with DivX in order to
play DivX Video-on-Demand (VOD) content. First generate the DivX
VOD registration code for your device and submit it during the
registration process. [Important: DivX VOD content is protected by a
DivX DRM (Digital Rights Management) system that restricts playback
to registered DivX Certified devices. If you try to play DivX VOD
content not authorised for your device, the message "Authorization
Error" will be displayed and your content will not play.] Learn more at
http://vod.divx.com.
6
Contents
Introducing your device ................................................. 9
Unpack ............................................................................... 9
Get to know your device ................................................... 10
Assemble and prepare your device ................................... 16
Turn on your device for first time ....................................... 20
Customise your device ...................................................... 24
Use Widgets ..................................................................... 27
Communication ............................................................ 31
Working with contacts ....................................................... 31
Calling ............................................................................... 37
Enter text .......................................................................... 40
Messaging ........................................................................ 47
Multimedia ................................................................... 51
Camera ............................................................................. 51
Touch Player ..................................................................... 61
Photo Album ..................................................................... 65
7
Digital Frame ..................................................................... 66
FM Radio .......................................................................... 68
Video Editor ...................................................................... 70
Games .............................................................................. 74
Java .................................................................................. 74
Personal productivity ................................................... 75
Work with applications ...................................................... 75
ActiveSync ........................................................................ 77
Clock ................................................................................ 82
Touch Calendar ................................................................ 85
Life Diary ........................................................................... 87
Notes ................................................................................ 90
Smart Memo ..................................................................... 92
Audio Note ........................................................................ 92
Tasks ................................................................................ 95
Calculator .......................................................................... 96
Smart Converter ................................................................ 97
8
Web applications ......................................................... 98
Streaming Player ............................................................... 98
Midomi .............................................................................. 99
RSS Reader .................................................................... 102
Podcast .......................................................................... 104
QIK ................................................................................. 106
Communities ................................................................... 109
Application Download ..................................................... 113
Connectivity ............................................................... 114
Connect to the internet or your network .......................... 114
Bluetooth ........................................................................ 117
Wi-Fi ............................................................................... 121
Connected Home ............................................................ 124
Troubleshooting ......................................................... 127
Safety and usage information .................................... 132
Index .......................................................................... 144
9
Introducing your device
Unpack
Your package contains the following items:
• Handset
•Battery
• Travel adapter (charger)
•CD-ROM
*
• Stereo headset
•PC data cable
• User manual
* The CD-ROM contains Microsoft ActiveSync software, add-on
software, and other applications.
The items supplied with your device and available accessories may
be different depending on your region or service provider.
10
Get to know your device
Front view
Front camera lens
Earpiece
Touch screen
Volume key
Talk/
speakerphone key
End/Power key
Proximity sensor
Microphone for video
calls and speakerphone
Mode switch key
Mouthpiece for
voice calls
Back key
11
Rear view
Headset (3.5 mm)/
TV out jack
Multifunction jack
Hold key
Camera key
Flashbulb
Battery cover
Rear camera lens
Internal antenna
Speaker
12
Inside view
Delete key
Alt key Enter key
Shift key
Space key
OK key
Right-click key
13
Keys
Key Function
Open the dialling screen; Make or answer a call; Activate the
speakerphone during a call (press and hold)
Delete characters or items in an application
Turn the device on or off (press and hold); End a call; Return
to the Today screen
Adjust the volume; Switch to Zoom mode (press and hold);
During a call, adjust the voice volume; During an incoming
call, mute the call ringer
Switch between the Work mode screen and the Life mode
screen (press and hold)
Activate Sleep mode; Lock the external keys and the touch
screen (press and hold)
Activate the camera (press and hold); In Camera mode, take
a photo or record a video
14
Icons
Icon Function
UMTS network
available
UMTS connected
HSDPA network
available
HSDPA connected
ActiveSync in progress
Battery level
Low battery
Battery charging
No battery
Attempt to access via
Bluetooth
Receiving data via
Bluetooth
Bluetooth stereo
headset connected
Call on hold
Call forwarding
activated
Connected to a
computer
Data call in progress
EDGE network
available
EDGE network
connected
GPRS network
available
GPRS network
connected
Icon Function
15
Searching for a signal
Missed call
More status icons
available (tap the icon
to see them)
New text message
New email message
New multimedia
message
New voice mail
message
No signal
No SIM or USIM card
Pending alarm
Radio off
Ringer on
Ringer set to vibrate
Icon Function
Roaming (outside of
normal service area)
Signal strength
Synchronisation error
Urgent notification (tap
the icon to see the
message)
Voice call in progress
Wi-Fi activated
Wi-Fi data call in
progress
Icon Function
16
Assemble and prepare your device
Before you can use your device, you must install the SIM or
USIM card, install the battery, and charge the battery. Installing
a SIM or USIM card is optional, but may be required to fully
utilise some applications and store media files.
Insert the SIM or USIM card and battery
1
Remove the battery cover.
2
Insert the SIM or USIM card.
Insert the SIM or USIM card with the
gold-coloured contacts facing the
device.
17
3
Insert the battery.
4
Replace the battery cover.
18
Charge battery
1
Open the cover to the multifunction
jack on the top of the device.
2
Plug the small end of the travel
adapter into the device.
3
Plug the large end of the travel
adapter into a power outlet.
4
When charging is finished, unplug the travel adapter from
the power outlet.
5
Remove the travel adapter from the device.
Although a charger cable is connected,
• The battery may not charge in some situations to protect the
device.
• The battery level may remain low if the device is using a large
amount of power.
19
Insert a memory card (optional)
By inserting a memory card, you can store multimedia files and
messages or back up your important information. Your device
accepts microSD™‚ memory cards up to x GB (depending on
memory card manufacturer and type).
Attach a hand strap (optional)
1
Remove the battery cover.
2
Insert a memory card with the label
side facing up.
3
Replace the battery cover.
1
Remove the battery cover.
2
Slide a hand strap through the slot
and hook it over the small
projection.
20
Turn on your device for first time
1
Press and hold [ ] to turn on your device.
2
Follow the on-screen instructions. Your device will
automatically connect to the cellular network.
Activate Sleep mode
You can activate Sleep mode to save power when you do not
use your device.
To activate Sleep mode, press the Hold key. Your device will
turn off the screen. To deactivate Sleep mode, press the Hold
key again.
Lock external keys and touch screen
You can lock the external keys and the touch screen to prevent
any unwanted device operations from accidentally pressing any
of the keys and the screen.
21
To lock the keys and the screen, press and hold the Hold key.
To unlock, drag your finger or stylus
from the top right corner of the screen
to the bottom left corner of the screen.
Use the touch screen
You can perform the following actions on your device's touch
screen:
• Tap: Touch the screen once to select commands or launch
applications.
• Tap-and-hold: Tap and hold an item to see a list of available
actions. Tap the action you want to perform on the pop-up
menu.
For the optional use of the touch screen remove the screen
protection film before using your device.
22
• Drag: Tap-and-hold a scroll bar or text and then drag it to
move the bar or select text.
Disable wireless functions
1
Ta p
Start > Settings
.
2
On the
Connection
tab, tap
Wireless Manager
.
3
Ta p
On
next to
Phone
.
• Your device will show on the Today screen.
To enable wireless functions, repeat steps 1-3 above.
If your device does not respond accurately to your screen taps,
realign your touch screen. To realign the screen, tap
Start > Settings
>
System
tab
>
Screen> Align> Align screen
.
23
Reset the device
If your device freezes or hangs, you may
need to close programs or reset the
device to regain functionality. If your
device is still responsive but a program
is frozen, close the program via Task
Manager.
X
p. 76
If your device is frozen and
unresponsive, use a small object, such
as a toothpick, to press the reset
button.
24
Customise your device
Learn to change themes and background images, add or
remove items, and adjust the system volume from the Today
screen.
Change your theme or background image
1
Ta p
Start > Settings
.
2
On the
Personal
tab, tap
Display
.
3
Ta p
Theme
or
Wallpaper
and select the desired option to
customise the display.
4
When you are finished, tap
ok
.
Add or remove items on the Today screen
1
Ta p
Start > Settings
.
2
On the
Personal
tab, tap
Display
.
25
3
Ta p
Items on Today
.
4
Ta p
Menu > Edit
.
5
Tap the check boxes next to each item to add or remove
items.
6
Ta p
Done
.
7
When you are finished, tap
Done
.
Adjust the system volume
To adjust the system volume, press the Volume key up or
down.
Some items are not compatible with Samsung widgets. If you
choose to add
Samsung WidgetPlus
, the only other items that will
work simultaneously are
Windows Live
and
Windows Live Search
.
26
Activate Etiquette pause
You can temporarily pause the music player or mute event
alarms by placing the device face down when Etiquette pause
is activated. To activate Etiquette pause,
1
Ta p
Start > Settings
.
2
On the
System
tab, tap
Motion Sensor
>
Etiquette
.
3
Ta p
Off
next to
Enable etiquette pause
.
4
Ta p
Done
or
ok
.
27
Use Widgets
Use widgets on the Today screen. Widgets are user friendly
shortcuts to commonly used applications allowing you to
customise the Today screen.
Open the toolbar
Tap the arrow at the bottom left of the Today screen to open
the toolbar. You can rearrange widgets on the toolbar or move
them to the Today screen.
Depending on your region or service provider, available widgets may
vary.
Widget Function
View the current day and date
View the current time
View the current time
View the time in other cities or countries
28
View the calendar
View or set an countdown timer
Receive notifications when you have new messages or
missed calls
Browse your photos and set a photo as the wallpaper
Listen to music via the mini player
Listen to the FM radio
Monitor your wireless connections
Change the current sound profile
Create and view smart memos
Create and listen to audio notes
Add application shortcuts to the Today screen
View the network connection status
Widget Function
29
Move the widgets to the Today screen
1
Tap the arrow at the bottom left of the Today screen to
open the widget toolbar.
2
Touch and drag a widget from the toolbar to the Today
screen. You can position the widget anywhere on the
screen.
Get the latest weather updates from AccuWeather
*
Get news updates from CNN*
Search the web with Google*
Get updates from Yahoo! Finance*
Search the web with Yahoo!*
* These widgets require a connection to the internet, which may
result in additional charges.
Widget Function
30
Customise widgets
1
Tap the arrow at the bottom left of the Today screen to
open the widget toolbar.
2
Tap at the top of the toolbar.
3
Tap the check boxes next to items that you want to appear
on the Today screen.
4
When you are finished, tap
Done
.
31
Communication
Working with contacts
Learn to use contact cards and groups to store personal
information, such as names, phone numbers, and addresses.
Create a new Outlook or SIM contact card
1
Ta p
Start > Phonebook > New > Save to outlook
or
Save to SIM
.
2
Enter contact information.
3
When you are finished entering information, tap
Done
or
ok
to save the contact card.
Search for a contact card
1
Ta p
Start > Phonebook
.
2
Ta p .
32
3
Tap a few letters of the contact's name.
• As you enter letters, the screen will show contacts that
match your input.
4
Tap a contact to open it.
Copy or move contact cards
To copy or move contact cards from your device's memory to
a SIM or USIM card and vice versa,
1
Ta p
Start > Phonebook
.
2
To copy contacts, tap
Menu > Copy >
a copy option. Refer to
step 4.
3
To move contacts, tap
Menu > Move >
a move option.
4
Tap the check boxes next to the contacts that you want to
copy or move.
5
Ta p
Done
.
33
Organise your contacts into categories
1
Ta p
Start > Phonebook
.
2
Tap a contact.
3
Ta p
Edit
.
4
Scroll down and tap the categories field.
5
Tap the check boxes next to the desired categories.
6
Ta p
Done
.
7
Ta p
Done
to save the contact card.
34
Assign a speed dial number to a contact card
To assign a speed dial number to one of your contacts,
1
Ta p
Start > Phonebook
.
2
Ta p .
3
Ta p
New
and select a contact.
4
Select the contact's phone number to use for speed
dialling.
5
Select a speed dial location.
35
Assign an image to a contact card
1
Ta p
Start > Phonebook
.
2
Tap a contact.
3
Ta p
Edit
.
4
Tap the picture icon at the top left of
the contact card.
5
Ta p
Take a new picture
or
Select a
picture in photo Al...
6
Tap a thumbnail to select an image
or capture a photo.
7
Ta p
Done
to save the contact card.
36
Assign a ringtone to a contact card
1
Ta p
Start > Phonebook
.
2
Tap a contact.
3
Ta p
Edit
.
4
Scroll down and tap
Add field
.
5
Scroll down and tap the ringtone field.
6
Select a ringtone.
7
Ta p
Done
.
8
Ta p
Done
to save the contact card.
37
Calling
Learn to make and receive calls, reject calls, and adjust the call
volume.
Make a call
1
Press [
]
.
2
Enter an area code and phone number.
3
Ta p o r pr e ss [ ].
• For a video call, tap
Menu
>
Video Call
.
4
To end the call, press [ ].
Make a call from Phonebook
1
Ta p
Start > Phonebook
.
2
Tap a contact.
3
Tap the number you want to dial.
38
Make a call from the Call Log
1
Ta p
Start > Main Menu > Call Log
(1/5).
2
Select one of the following filters for your call log results:
3
Tap an entry in the call log.
4
Tap the number you want to dial.
Answer a call
1
Press
[]
.
2
For a video call, tap
Show me
to allow the caller to see you.
3
To end the call, press [ ].
Icon Function
All calls
Incoming calls
Outgoing calls
Missed calls
39
Reject a call
Press [ ]. When you reject a call, the caller will hear a busy
tone.
Adjust the call volume
To adjust the call volume, press the Volume key up or down
during a call.
Call an international number
1
Press
[]
.
2
Ta p
Keypad
(if necessary).
3
Tap and hold to insert the
+
character (this replaces the
international access code).
4
Tap the number keys to enter the complete number you
want to dial (country code, area code, and phone number),
and then tap or press [ ] to dial.
5
To end the call, press [ ].
40
Enter text
When you need to enter text, tap the default input panel icon
() at the bottom of the screen. Tap the arrow next to the icon
and select one of the following input methods for entering text:
• Block Recognizer
•Keyboard
• Letter Recognizer
• Samsung Keypad
•Transcriber
You can tap the input panel icon at any time to show or hide
the input panel.
41
Enter text with Block Recognizer
Write individual letters and numbers in the writing area in the
Palm Graffiti style.
1
Tap the input panel icon.
2
Tap the arrow next to the input panel
icon and select
Block Recognizer
.
3
Write each character in the writing
area at the bottom of the screen:
• Write letters on the left side of the
writing area.
• Write numbers on the right side of
the writing area.
Drag your finger upward to change
the case (
ABC
,
Abc
, or
abc
). Tap once
on the screen to enter symbols (
123
or
abc
will change to the icon). To
view demonstrations of how to enter
characters, refer to the embedded
help system.
42
Enter text with the keyboard
1
Tap the input panel icon.
2
Tap the arrow next to the input panel icon and select
Keyboard
.
3
Tap characters to enter your text:
• To switch to numbers and symbols, tap .
• To access special characters, tap .
43
Enter text with Letter Recognizer
Write individual letters and numbers on the touch screen.
1
Tap the input panel icon.
2
Tap the arrow next to the input panel
icon and select
Letter Recognizer
.
3
Write each character in the writing
area at the bottom of the screen:
• Write upper-case letters in the
ABC
column on the left side of the writing
area.
• Write lower-case letters in the
abc
column in the middle of the writing
area.
• Write numbers and symbols in the
123
column on the right side of the
writing area.
To view demonstrations of how to
write characters, refer to the
embedded help system.
44
Enter text with Samsung Keypad
1
Tap the input panel icon.
2
Tap the arrow next to the input panel icon and select
Samsung Keypad
.
3
Tap characters to enter your text:
• To enter the text in T9 mode, tap
XT9
. The dot by
XT9
turns
green. Tap the appropriate keys to enter an entire word.
• To enter the text in ABC mode, tap
XT9
. The dot by
XT9
turns off. Tap the appropriate key to enter a character.
• To enter numbers, tap and hold the appropriate key to enter
a number.
• To enter symbols, tap and hold the appropriate key to enter
a symbol.
45
Enter text with Transcriber
With Transcriber, you can write anywhere on the screen. Unlike
Letter Recognizer or Block Recognizer, you can use cursive
(joined-up) handwriting to write complete words.
1
Tap the input panel icon.
2
Tap the arrow next to the input panel
icon and select
Transcriber
.
3
Write legibly anywhere on the
screen.
4
Pause and allow Transcriber to
convert your writing to text.
46
You can access the following tools from the Transcriber
toolbar:
Tap To
Change Transcriber options
View demonstrations of how to write characters
Open the list of punctuation marks, symbols, and numbers
Change the input mode to
A
,
a
, or
123
Insert a space
Start a new line
Move the cursor to the left
Move the cursor to the right
Clear your input
Open the embedded help
47
Messaging
Learn to use messaging functions. For instructions on entering
text, see the previous section.
Send a text message
1
Ta p
Start > Messaging
.
2
Ta p
SMS
/
MMS
.
3
Tap any of the folders under the
SMS/MMS
heading.
4
Ta p .
5
Enter a contact name in the To field or tap
Menu > View
Recipient List >
to search for contacts.
• When searching for contacts, you can either leave the To
field blank or enter a few letters of your contact's name to
narrow your search.
6
Tap the message field and enter your message text.
7
Ta p
Send
to send the message.
48
Send a multimedia message
1
Ta p
Start > Messaging
.
2
Ta p
SMS
/
MMS
.
3
Tap any of the folders under the
SMS
/
MMS
heading.
4
Ta p .
5
Enter a contact name in the To field or tap
Menu > View
Recipient List >
to search for contacts.
• When searching for contacts, you can either leave the To
field blank or enter a few letters of your contact's name to
narrow your search.
6
Tap the message field and enter your message text.
7
Ta p
Menu > Toolbar
(if necessary).
8
Tap one of the following icons to add an attachment:
Tap To
Attach a photo
Attach a music file
49
9
Ta p
Menu > Attach >
an option to attach other types of files
(if necessary).
10
Ta p
Send
to send the message.
Send an email message
1
Ta p
Start > Messaging
.
2
Tap the name of an email account.
3
Tap any of the folders under the email account heading.
4
Ta p .
5
Enter the recipient's address in the To field or tap
Menu >
Add Recipient...
to select a contact.
Attach a video
Capture and attach a photo
Record and attach a voice memo
Record and attach a video
Tap To
50
6
Tap the subject field and enter a message subject.
7
Tap the message field and enter your message text.
8
To add an attachment, tap
Menu > Attach >
an attachment
type.
9
Ta p
Send
to send the message.
View messages
You can access message folders for all your messaging
accounts (email, SMS, and MMS) in one location.
To view messages,
1
Ta p
Start > Messaging
.
2
Tap the name of an account (
SMS/MMS
or one of the email
accounts).
3
Ta p
Inbox
.
4
Tap a message to view it.
51
Multimedia
Learn to capture photos and videos, listen to music, and take
advantage of your device's multimedia features.
Camera
Your device allows you to take digital photos (jpg format) or
record videos (3gp format).
Capture a photo
1
Press and hold the Camera key.
2
Rotate the device anti-clockwise to the landscape
orientation.
52
3
Aim the lens at the subject and make any adjustments.
X
p. 53
4
Press the Camera key to capture the photo.
5
Ta p
ok
to save the photo and return to the viewfinder.
View a photo
1
From the viewfinder, tap .
2
Scroll to the photo you want.
The camera interface
appears only in the
landscape
orientation.
53
Adjust Camera modes and settings
From the viewfinder, tap an icon and then tap a mode or
setting.
Icon Function
Mode (switch to camcorder)
Change the shooting mode:
• : Single shot
• : Continuous shooting
• : Mosaic shot
• : Panoramic shot
• : Smile shot
Change the scene mode:
•: Normal
• : Portrait
• : Landscape
• : Sports
• : Indoor
• : Snow or Beach
• : Sunset or Sunrise
•: Dusk
•: Fall
• : Night Shot
• : Firework
•: Text
•: Candle
• : Backlight
• : Window
54
Image size
Camera settings
Change the flash setting:
•: Off
•: On
•: Auto
Change the auto focus setting:
• : Auto focus
• : Macro
•: Off
Adjust the brightness
Quick view
Icon Function
55
Record a video
1
Press and hold the Camera key.
2
Rotate the device anti-clockwise to the landscape
orientation.
3
Ta p
>
Camcorder
to launch the camcorder.
4
Aim the lens at the subject and make any adjustments.
X
p. 56
5
Press the Camera key to begin recording.
The camera interface
appears only in the
landscape
orientation.
56
6
When you are finished, tap or press the Camera key to
stop recording.
7
Ta p
ok
to save the video and return to the viewfinder.
Play a video
1
From the viewfinder, tap .
2
Scroll to the video you want.
3
Tap to play the video.
Adjust Camcorder settings
From the viewfinder, tap an icon and then tap a setting.
Icon Function
Mode (switch to camera)
Change the recording mode:
•: Normal
• : MMS
•: Slow
57
Capture photos in Smile shot mode
1
Press and hold the Camera key.
2
Rotate the device anti-clockwise to the landscape
orientation.
3
Ta p
>
.
Video resolution
Video settings
Change the auto focus setting:
• : Auto focus
• : Macro
•: Off
Adjust the brightness
Quick view
Icon Function
58
4
Aim the camera lens at your subject and press the Camera
key.
• The device recognises faces in an image and detects when
your subjects smile. When all your subjects are smiling, the
camera will automatically capture the photo.
In some cases, you may have to disable smile shot to capture a
photo of your subject, even if he or she is smiling.
59
Capture panoramic photos
1
Press and hold the Camera key.
2
Rotate the device anti-clockwise to the landscape
orientation.
3
Ta p
>
.
4
Aim the camera lens at your subject and press the Camera
key to capture the first shot.
5
Slowly move the device to a direction. The device captures
the next photo automatically.
6
Repeat step 5 to capture the rest of the shots. When you
are captured three shots, the camera will automatically
combine them into one panoramic photo.
60
Create a photo mosaic
1
Press and hold the Camera key.
2
Rotate the device anti-clockwise to the landscape
orientation.
3
Ta p
>
.
4
Select a mosaic type.
5
Aim the camera lens at your subject and press
the Camera
key
to capture the first shot.
6
Repeat step 5 to capture the rest of the shots. When you
are captured all the shots necessary for the mosaic, the
camera will automatically combined them into one photo.
61
Touch Player
Your device is equipped with Touch Player, as well as Windows
Media Player. The procedures that follow explain how to use
Touch Player. For information about Windows Media Player,
refer to embedded help system.
Add music files to your device
Use any of the following methods to add music files to your
device:
• Copy files to a memory card and insert the card into the
device
X
p. 19
• Download files from the wireless web (refer to the embedded
help system)
• Receive via Bluetooth
X
p. 120
• Synchronise with ActiveSync
®
X
p. 79
62
Update the library
1
Ta p
Start > Main Menu > Touch Player
(1/5).
2
Ta p
Menu > Update
.
3
Ta p
Search
to locate and add new files to the Touch Player
library.
4
When the library is updated, tap
Done
.
Play music or video files
1
Ta p
Start > Main Menu > Touch Player
(1/5).
2
Tap to open the currently playing list (if necessary).
3
Tap to view the library.
4
Tap a file.
63
5
During playback, use the following controls:
Create a playlist
1
Ta p
Start > Main Menu > Touch Player
(1/5).
2
Tap to open the currently playing list (if necessary).
Icon Function
Adjust the volume
Skip to the previous file; Scan backward in a file (tap
and hold)
Pause playback
Resume playback
Skip to the next file; Scan forward in a file (tap and
hold)
Set repeat or shuffle option:
• : play all files in the library once
• : repeat all files in the library
• : repeat the current file
• : shuffle all files in the library
64
3
Tap to view the library.
4
Ta p .
5
Ta p
Menu > New Playlist
.
6
Enter a title for your new playlist.
7
Select a photo for your playlist (if necessary).
8
Ta p
Done
.
Add files to a playlist
1
Open a file.
X
p. 62
2
While the file is playing, tap .
3
Tap to view the library.
4
Tap and hold a file and select
Add to Nowplaying
.
5
Select files and tap
Done
.
65
Customise Touch Player
1
Ta p
Start > Main Menu > Touch Player
(1/5).
2
Ta p
Menu > Options
.
3
Set playback and other options for Touch Player.
4
Ta p
Done
.
Photo Album
Learn to view photos and slideshows.
View a photo
1
Ta p
Start > Main Menu > Photo Album
(1/5).
2
Tap a folder or tap
Folder
to view all folders.
3
Tap a thumbnail to view the photo.
66
Start a slideshow
1
Ta p
Start > Main Menu > Photo Album
(1/5).
2
Tap a folder or tap
Folder
to view all folders.
3
Ta p
Menu > Slide show
.
4
To end the slideshow, tap .
Digital Frame
With Digital Frame, you can view slideshows with background
music.
View slideshows with background music
1
Ta p
Start > Main Menu > Digital Frame
(2/5).
2
Rotate the device anti-clockwise to the landscape
orientation.
3
Ta p .
67
4
Select a folder of photos to use and set transition effects.
5
Ta p
Off
next to
Enable Background Sound
.
6
Tap the sound field.
7
Tap the check boxes next to music files.
8
Ta p
Select > Done
.
9
To begin the slideshow, tap .
10
During playback, use the following controls:
Icon Function
Change the layout of the display
End the slideshow
Skip to the previous photo
Skip to the next photo
Change the style of the date and time on the screen
Change the slideshow settings
Exit Digital Frame
68
FM Radio
You can listen to your favourite stations with FM radio.
Listen to the FM radio
1
Plug a headset into the multifunction jack or the headset
jack.
2
Ta p
Start > Main Menu > FM Radio
(1/5)
.
3
Tap to turn on the radio.
4
Tap or to scan through available radio stations.
5
To adjust the volume, tap .
Save radio stations by automatic tuning
1
From the radio screen, tap
Scan
.
2
When the scan is complete, tap
Done
.
69
Save radio stations manually
1
From the radio screen, scroll to the radio station you want
to save.
2
Tap one of the symbols near the bottom of the screen.
Select a station
1
From the radio screen, tap
FM1
or
FM2
.
2
Tap the station you want from the
area near the bottom of the screen.
Record the FM radio
1
From the radio screen, tap
Menu > Record
to record the
current station.
2
When you are finished, tap
Stop
. The recorded file is saved
in your device.
70
Video Editor
With Video Editor, you can edit or make videos by combining
photos or videos.
Auto-crop a video
1
Ta p
Start > Main Menu > Video Editor
(2/5).
2
Select
Auto Cut
.
3
Select a style and tap : (the names & descriptions for
these styles don't make sense; therefore, I am uncertain if
the list below is correct -
the names and descriptions should be
changed
)
•
Landscape
: select clips in landscape orientation
•
Motion Object
: select clips
•
Portrait
: select clips in portrait orientation
4
Tap the check boxes on images to add and tap .
5
Tap to preview the video.
71
6
Tap to save the video.
7
Ta p .
Add pre-recorded audio to a video
1
Ta p
Start > Main Menu > Video Editor
(2/5).
2
Select
Music Movie
.
3
Select a style: (the names & descriptions for these styles
don't make sense; therefore, I am uncertain if the list below
is correct -
the names and descriptions should be changed
)
•
Blackboard
: frame your clips with a blackboard
•
Color flow
: cycle your clips through colour effects
•
Flip
: reveal your images as if flipping through pages in a
photo album
•
Motion
: scroll through your images with a newspaper
background and flower overlays
•
Old film
: show your images with a grainy film effect
•
Running
: cycle through your images over a background of
stars
72
•
Slippage
: scroll through your images over a background of a
cloudy sky
•
Spin
: cycle through your images over a background of a
sandy beach
•
Splash
: reveals your images by splashing them on the
screen
•
Sunshine
: cycles through your images over various beach
backgrounds
4
Ta p .
5
Tap the check boxes on images to add.
6
Tap to add the selected images.
7
Delete images or tap to change how they are displayed
(if necessary).
8
Tap to select an audio file.
9
Tap to preview the video.
10
Tap to save the video.
73
Create a storyboard
1
Ta p
Start > Main menu > Video Editor
(2/5).
2
Ta p
Storyboard
.
3
Tap the check boxes on each thumbnail image (videos or
images) you want to add to the storyboard. To select all, tap
(to deselect all, tap ).
4
Ta p .
5
Customise the storyboard as desired by tapping the
following icons (refer to the Extended Usage Guide for more
information about customising storyboards):
• : add audio files
• : delete clips
• : edit viewable duration, dub clips (record audio), add
subtitles, edit transitions, and add effects
• : create a text slide
6
Ta p .
7
Tap to preview the video.
74
8
Tap to save the video.
9
Ta p
ok
.
Games
Play fun games, such as Bubble Breaker and Solitaire. You can
also download and play Java games on your device. To access
games, tap
Start > Main Menu >
a game
(2/5)
.
Java
Your device supports applications and games built on the Java
platform. To download Java-based applications,
1
Ta p
Start > Main Menu > Java
(3/5).
2
Ta p
Download Applications...
to launch the Opera browser
and go to the Samsung Mobile website.
3
Follow the directions on the website to download new
Java-based applications.
75
Personal productivity
Work with applications
Learn to open applications or folders and switch between open
applications.
Open applications or folders
1
Ta p
Start > Main Menu
.
2
To open an application, tap the application icon.
3
To open a folder, tap
File Manager
(1/5) and navigate to the
desired folder.
Switch applications
Your device allows you to multi-task by running multiple
applications at the same time.
To switch from one active application to another,
76
1
Ta p
Start > Main Menu > Task Switcher
(5/5).
• Task Switcher shows thumbnail images of all open
programs.
2
Tap a thumbnail to switch to the corresponding application.
Close applications
To send the current application to the background, tap
x
or
ok
.
To close an application,
1
Ta p
Start > Main Menu > Task Manager
(5/5).
2
Tap an application name.
3
Ta p
End Task
.
Search for files or folders
1
Ta p
Start > Main Menu > Search
(5/5).
2
Use the input panel to enter a keyword.
3
Ta p
Search
.
77
ActiveSync
With ActiveSync, you can synchronise your device with a
computer and back up and restore your data.
Install ActiveSync on your computer
Before you can synchronise your data, you must install
ActiveSync, either from the supplied CD-ROM or the Microsoft
website (http://www.microsoft.com).
To install ActiveSync from the supplied CD-ROM,
1
Insert the CD-ROM into your computer.
2
Follow the on-screen instructions to complete the setup.
3
When installation is complete, follow the on-screen
instructions in the Synchronisation Setup Wizard to connect
your device to the computer and create a data sharing
partnership.
78
Connect your device to a computer
1
Ta p
Start
>
Settings
.
2
From the
Connection
tab, tap
USB Connection Mode
>
Active
Sync
.
3
Ta p
Done
.
4
Connect one end (mini-USB) of the PC data cable to the
multifunction jack on your device and the other end to the
USB port on your computer.
79
Synchronise your data
When you connect your device to a computer, ActiveSync
should begin synchronising your data automatically. You can
begin the synchronisation manually by tapping
Sync
. To stop a
synchronisation in progress, tap
Stop
.
You can also manually find and copy files from your device to a
computer and vice versa. From the Microsoft ActiveSync
window, tap
Explore
.
For more information on synchronising your data, refer to the
embedded help system.
If you format the My Storage folder by using a connected computer,
the writing speed to the My Storage folder may be reduced. Format
the My Storage folder only from the device to avoid this situation.
80
Add an Exchange server
1
Ta p
Start > Main Menu > ActiveSync
(5/5).
2
Ta p
Menu > Add Server Source...
3
Enter an email address.
4
Ta p
Next
.
5
Enter your Exchange user name, password, and domain
name.
6
Ta p
Next
.
7
Enter a server address. To establish a secure connection,
tap the check box that reads
This server requires an encrypted
(SSL) connection
.
8
Ta p
Next
.
9
Select the types of data to synchronise.
10
When you are finished, tap
Finish
.
81
Change the synchronisation schedule
If you routinely synchronise your data via an Exchange server,
you can configure settings for both peak and off-peak
schedules.
To change the synchronisation schedules,
1
Ta p
Start > Main Menu> ActiveSync
(5/5).
2
Ta p
Menu > Schedule...
3
Set the following options:
•
Peak times
: set the frequency of synchronisations during
peak hours
•
Off-peak times
: set the frequency of synchronisations during
off-peak hours
•
Use above settings when roaming
: set to use the
synchronisation schedules even when roaming
•
Send/receive when I click Send
: set to synchronise when you
tap
Send
in Messaging
4
When you are finished, tap
ok
.
82
Clock
Learn to set and control alarms, reminders, and world clocks.
You can also use the stopwatch.
Set an alarm
1
Ta p
Start > Main Menu > Clock
(1/5).
2
On the
Alarm & Morning call
tab, tap .
3
Set the alarm options.
4
When you are finished, tap
Done
.
Stop an alarm
When an alarm without snooze sounds, tap
Dismiss
. When an
alarm with snooze sounds, tap
Dismiss
to stop it or
Snooze
to
delay the alarm for the length of time you specified. Alarms with
snooze will repeat according the number of times you specify in
the settings or until you tap
Dismiss
.
83
Schedule an anniversary
1
Ta p
Start > Main Menu > Clock
(1/5).
2
On the
Anniversary
tab, tap .
3
Set the anniversary options.
4
When you are finished, tap
Done
.
Create a world clock
1
Ta p
Start > Main Menu > Clock
(1/5).
2
On the
World Clock
tab, tap .
3
Tap to open a list of cities.
4
Ta p a ci t y.
5
Ta p
Done
.
Ta p
Name
or
Time
to sort the list by name or time zone.
84
6
Ta p
Set as 2nd clock
to display this time in addition to the
local time (in widgets that support dual times).
7
Ta p
Done
.
Use the stopwatch
1
Ta p
Start > Main Menu > Clock
(1/5).
2
On the
Stop watch
tab, tap
Start
.
3
Ta p
Lap
to record lap times.
4
When you are finished, tap
Stop
.
5
Ta p
Reset
to clear the recorded times.
85
Touch Calendar
Use Touch Calendar to keep track of appointments, birthdays,
or other events.
Create a calendar event
1
Ta p
Start > Touch Calendar
.
2
Ta p .
3
Complete the fields and adjust the settings for your event.
4
When you are finished, tap
Done
.
In the month view, a small underscore will appear under dates
with scheduled appointments.
86
Change the calendar view
1
Ta p
Start > Touch Calendar
.
2
Tap a tab to change the calendar view:
• : a full month in one view
• : hourly blocks for the days in one full week (Sunday to
Saturday)
• : hourly blocks for one full day
• : a list of scheduled appointments
Stop an event reminder
When the reminder alarm sounds for a calender event, tap
Dismiss
.
87
Life Diary
Life Diary is an online service where you can record your
memories. With Life Diary, you can view your daily events, such
as photos, videos, call logs, messages, appointments, and
tasks. You can also upload photos, videos, and blog posts to
the Life Diary website or other popular websites. For more
information, visit the Life Diary website for your country or
region (http://www.lifediary.XX).
View and upload daily events
1
Ta p
Start > Main Menu > Life Diary
(5/5).
2
Ta p
My Memories
.
3
Tap or to scroll to a date or tap the date bar and
select a date from the calendar.
4
Tap an event to view details.
5
Ta p
Publish
to upload an event to the Life Diary website.
88
Read updates on the Life Diary website
1
Ta p
Start > Main Menu > Life Diary
(5/5).
2
Ta p
LifeDiary Web
.
3
View updates:
• Select
My Life
to view your Life Diary entries.
• Select
My Networks
to view your friends' latest entries.
• Select
Explore
to view popular entries on the Life Diary
website.
4
Tap an item to view details.
5
While viewing, tap
Comment
to add your comment to an
entry.
89
Create and upload a new blog post
1
Ta p
Start > Main Menu > LifeDiary
(5/5).
2
Ta p
Diary Editor
.
3
Ta p
New
to create a new blog post.
4
Enter details and tap
Menu > Add >
an item.
5
Select
Publish to external blog
to upload the post to other
registered websites.
6
Ta p
Publish
to upload the post to the Life Diary website.
Synchronise items with the Life Diary website
1
Ta p
Start > Main Menu > Life Diary
(5/5).
2
Ta p
Web Sync
.
3
Select items on your device to synchronise with the Life
Diary website and tap
Sync Now
.
90
Notes
Use Notes to create memos, sketches, and recordings.
Create a note
1
Ta p
Start > Main Menu > Notes
(5/5).
2
Ta p
New
to create a new note.
3
Enter your note with the input panel.
• To create sketches,
X
p. 91
• To create recordings, tap
Menu > View Recording Toolbar
.
4
When you are finished, tap
ok
.
Send a note
1
Ta p
Start > Main Menu > Notes
(5/5).
2
Tap and hold the name of a note you want to send.
91
3
Tap an option to send the file:
• To send as a multimedia message, select
Send...
• To send via a Bluetooth wireless connection, select
Beam
File...
Create a sketch
1
Ta p
Start > Main Menu > Notes
(5/5).
2
Ta p
New
.
3
Make a stroke that crosses at least
three ruled lines to start a drawing a
frame. Sketches that do not cross
three ruled lines will be treated as
writing.
4
Continue your sketch with strokes.
5
To edit the sketch, tap
Menu > Draw
.
Tap and hold the sketch until the selection handles appear.
You can then use the handles to drag or resize the sketch or
tap
Menu
to access other options.
92
Smart Memo
Use Smart Memo to create memos that combine text and
freehand drawing. To create a smart memo:
1
Ta p
Start > Main Menu > SmartMemo
(4/5).
2
Ta p
New
.
3
Create your memo with the drawing tools and input panel.
4
When you are finished, tap
Save
.
5
Ta p
OK
.
Audio Note
Use Audio Notes to record, listen to, and send voice memos.
Record a voice memo
1
Ta p
Start > Main Menu > AudioNote
(4/5).
2
Ta p
Record
.
93
3
Set recording volume and tap to begin the recording.
4
Record your voice memo.
5
When you are finished, tap .
6
Ta p
OK
.
Listen to a voice memo
1
Ta p
Start > Main Menu > File Manager
(1/5)
> My Storage >
Audio Note
.
2
Tap a memo. Playback will begin automatically.
3
During playback, use the following controls:
Icon Function
Adjust the volume
Skip to the previous file; Scan backward in a file
(tap and hold)
Pause playback
94
Send a voice memo
1
Ta p
Start > File Manager
(1/5)
> My Storage > Audio Note
.
2
Ta p
Menu
>
Send
and select a sending option:
•
as MMS
: send via a multimedia message
•
as Mail
: send via an email message
•
via Bluetooth
: send via a Bluetooth wireless connection
Resume playback
Skip to the next file; Scan forward in a file (tap and hold)
Set repeat or shuffle option:
• : shuffle all files in the library
• : play all files in the library once
• : repeat the current file
• : repeat all files in the library
Icon Function
95
Tasks
Use Tasks to create to-do lists and reminders.
Create a task
1
Ta p
Start > Main Menu > Tasks
(4/5).
2
Ta p
Menu > New Task
.
3
Enter details for the task.
4
When you are finished, tap
ok
.
Mark a task as completed
After completing a task, tap
Start > Main Menu > Tasks
(4/5)
and
tap the check box next to the task name. Once you have
marked a task complete, you will no longer receive any
scheduled reminders for that task.
To set a reminder for the task, tap the due field and set a due
date. Next, tap the reminder field, select
Remind me
, and then
specify the time and date of the reminder.
96
Calculator
Use the calculator to perform basic mathematical calculations.
To perform a calculation,
1
Ta p
Start > Main Menu > Calculator
(4/5).
2
Enter the first number using the calculator buttons on the
screen.
• To clear the displayed numbers, tap .
• To clear the last digit entered in a multi-digit entry, tap .
3
Tap the appropriate math function.
4
Enter the second number.
5
To view the result, tap .
You can use the following buttons while performing
calculations:
• : clear the number you entered
• : clear any value that is stored in the calculator's memory
• : recall the stored value from memory and inserts it into
the current calculation
97
• : add the current number to the value stored in the
calculator's memory
Smart Converter
Use Smart Converter to convert one unit of measure to
another. To perform a conversion,
1
Ta p
Start > Main Menu > Smart Converter
(4/5).
2
Select a type of measurement from the tabs at the top of
the screen:
• : Length
• : Weight
•: Area
•: Volume
• : Temperature
3
Select the unit of measure to convert.
4
Enter the base amount. The device displays the conversion
result.
98
Web applications
Streaming Player
Use Streaming Player to watch videos or listen to audio files
directly from the internet.
Stream media from the internet
1
Ta p
Start > Main Menu > Streaming Player
(3/5).
2
Ta p .
3
Enter the URL of a streaming media file.
4
Ta p
Connect
.
5
During playback, use the following controls:
Icon Function
Adjust the volume
Pause playback
99
Midomi
Use the Midomi web service to identify songs either by singing
or humming the song into your device or using your device to
grab the song from the radio or other audio source.
Search for song information by singing or
humming the song
1
Ta p
Start
>
Main Menu
>
Midomi
(3/5).
2
Ta p t h e
Sing
tab (if necessary).
Resume playback
Stop playback
Search for streaming media files
Icon Function
100
3
Tap the area of the screen that reads
Tap and sing or hum
and begin singing
or humming the song.
4
When you are finished singing or
humming, tap the area that reads
RECORDING
. The Midomi service will
search for a match and return the
results.
Try to sing or hum at least 10
seconds of the song for best results.
101
Search for song information by grabbing the song
from an audio source
1
Ta p
Start > Main Menu > Midomi
(3/5).
2
Ta p t h e
Grab
tab (if necessary).
3
Tap the area of the screen that reads
Tap and hold to a speaker
and place
the device near the audio source.
4
When you are finished, tap the area
that reads
RECORDING
. The Midomi
service will search for a match and
return the results.
Try to grab at least 10 seconds of the
song for best results.
102
RSS Reader
Learn to use RSS reader to get the latest news and information
from your favourite websites.
Subscribe to RSS feeds
1
Ta p
Start > Main Menu > RSS Reader
(2/5).
2
Ta p
Default
.
3
Ta p
Add Feed
.
4
Ta p
Add RSS/ATOM URL
.
5
Enter the address of an RSS feed and tap
Done
.
6
Enter the name of the RSS feed and tap a feed category.
7
Ta p
Add
.
103
Read RSS feeds
1
Ta p
Start > Main Menu > RSS Reader
(2/5).
2
Tap a feed category
>
a feed.
3
Ta p
Update
.
• Your device will attempt to connect to the internet. If
necessary, activate your internet connection.
Customise feed options
1
Ta p
Start > Main Menu > RSS Reader
(2/5).
2
Tap a feed category.
3
Ta p
Menu > Option
.
4
Tap a feed.
5
Set options to specify when feeds are deleted.
6
When you are finished, tap
Done
.
104
Podcast
Use Podcast to search for, download, and listen to podcasts.
Search for and subscribe to podcasts
1
Ta p
Start > Main Menu > Podcast
(2/5).
2
Ta p
Menu > Search Podcast
.
3
Use the input panel to enter a keyword and tap . Your
device searches for related podcasts and displays the
results.
4
Tap the podcast you want to subscribe to and tap
Add > ok
.
Play downloaded podcasts
1
Ta p
Start > Main Menu > Podcast
(2/5).
2
Tap a podcast.
3
Ta p
Menu > Download
.
105
4
Tap podcasts you want to play.
5
Ta p
Done
to download the podcasts.
6
When you are finished, tap
ok
.
Update your podcast library
Once you have subscribed to podcasts (
X
p. 104), you can
easily update your library to listen to the latest episodes. To
update your podcast library,
1
Ta p
Start > Main Menu > Podcast
(2/5).
2
Ta p
Update
.
3
Tap podcasts you want to update.
4
Ta p
Done > ok
.
106
QIK
QIK allows you to easily broadcast live videos over the internet.
You can share your live video with others or store the video so
your friends and family can view it later.
Sign up for a new account
1
Ta p
Start > Main Menu > QIK
(3/5).
2
Ta p
NEW_USER
.
3
Enter user information.
4
Ta p
SIGN_UP
.
5
Follow the on-screen instructions.
107
Sign in to QIK
1
Ta p
Start > Main Menu > QIK
(3/5).
2
Ta p
EXISTING_USER
.
3
Enter your login ID and password.
4
Ta p
SIGN_IN
.
5
Follow the on-screen instructions.
Stream live video to your friends and family
1
Sign in to the QIK website.
2
Ta p .
Your video will stream live via the QIK website. To see the live
video, visit your personalised webpage: http://qik.com/
username
.
108
While streaming, you can control the streaming video with the
following controls (tap the viewfinder to display or hide the
controls):
You can also zoom in or zoom out by pressing the Volume key
up or down.
Icon Function
Change the resolution
Make the stream private (accessibly only by logging in to the
QIK website) or public (accessible to anyone)
Turn the audio on or off
Change settings
Add a title and description to the video
Post the video to YouTube or another website or send a link
to the video via Twitter or text message
Start or stop the video stream
109
Communities
Communities is a convenient feature that allows you post your
photos to websites and blogs.
Upload photos
Use Communities to upload photos directly to your website or
blog. To upload photos,
1
Ta p
Start > Main Menu > Communities
(1/5).
2
Tap a blog or website.
3
Ta p
Upload
.
4
Enter your user name and password.
5
Ta p
Done
.
6
Enter a title for your image and tap
Tap to Add
.
7
Navigate to an image and tap the file name.
8
Select other options (if necessary).
110
9
Ta p
Done
.
• The image will be uploaded to the website or blog.
10
When the upload is complete, you can go to the website,
view the upload details, or return to the list of sites by
tapping the appropriate button.
Upload photos at a later time (Upload reservation)
With the Upload reservation feature of Communities, you can
set a specific date and time to upload your photos to a website
or blog. To create an upload reservation,
1
Ta p
Start > Main Menu > Communities
(1/5).
2
Ta p
Menu > Options > Upload reservation
.
3
Ta p
New
.
4
Tap a website or blog.
5
Enter a title for your image and tap
Tap to Add
.
6
Navigate to an image and tap
Tap to Add
.
111
7
Select other options, as necessary.
8
Ta p t h e
Date
drop-down menu and select a date for the
upload reservation.
9
Ta p t h e
Time
drop-down menu and set a time for the upload
reservation.
10
Ta p
Done
.
Change image resizing settings
Communities will automatically resize your photos before
uploading them, according to your settings. To change the
image resizing settings,
1
Ta p
Start > Main Menu > Communities
(1/5).
2
Ta p
Menu > Options > Upload settings
.
3
Ta p t h e
Image resize (default)
drop-down menu.
4
Select a size from the list or tap
Original
to upload images
without resizing them.
5
Ta p
Done
.
112
Delete a website or blog from the Preferred blog list
Communities automatically adds websites or blogs that you
use frequently to the Preferred blog list. To remove a website or
blog from this list,
1
Ta p
Start > Main Menu > Communities
(1/5).
2
Ta p
Menu > Options > Preferred Sites settings
.
3
Tap the website or blog you want to delete from the list.
4
Ta p
Delete
.
113
Application Download
Application Download allows you to find and add new
applications to your device. With Application Download, you
can search, browse, preview, buy, and download new
applications directly to your mobile device. Available
applications depend on your network operator and service
provider.
1
Ta p
Start > Main menu > Application Download
(3/5).
2
When prompted to allow the connection to the server, tap
Yes
.
3
Tap one of the following tabs to view available applications:
• : Recommended applications
• : Popular applications
• : Applications sorted by category
4
Ta p
Refresh
to update the list of available applications (if
necessary).
5
Tap an application.
6
Ta p
Download
.
114
Connectivity
Connect to the internet or your
network
You can connect to your Internet Service Provider (ISP) and
use the connection to send and receive email messages and to
browse the internet. You can also connect to any private
network, such as a corporate network you use at work.
Connect to the internet
1
Obtain the following information from your internet service
provider: phone number for your ISP server, user name,
and password.
2
Ta p
Start > Settings
.
3
On the
Connection
tab, tap
Connections
.
4
In
My
Internet
, tap
Add a new modem connection
.
115
5
Create a modem connection. To view detailed information
for any screen while changing the settings, tap the icon.
6
When the connection is successfully configured, run
Opera
Browser
or
Internet Explorer
to begin browsing the internet.
Your device will automatically attempt to connect.
Connect to work
1
Obtain the following information from your network
administrator: server phone number, user name, and
password.
2
Ta p
Start > Settings
.
3
On the
Connection
tab, tap
Connections
.
4
In
My Work Network
, set up a modem, VPN server
connection, or proxy server. To view detailed information for
any screen while changing the settings, tap the icon.
To set up a network card or wireless network connection to your
ISP, add a new connection under
My Work Network
.
116
5
When the connection is successfully configured, run
Opera
Browser
or
Internet Explorer
to begin browsing the internet.
Your device will automatically attempt to connect.
End a connection
• When connected via dial-up or VPN, tap the icon on your
status bar, and then tap
Disconnect
.
• When connected via ISP, tap
Start > Settings > Connection
tab
> Wireless Manager
. Then tap
Menu > Disconnect Cellular Data
.
• When connected via a cable, detach your device from the
computer by disconnecting the cable.
• When connected via a modem or a network (Ethernet) card,
remove the card from your device.
You can select an authentication method for GPRS connections
by using
GPRS Authentications
.
117
Find the active network connection
The icons at the top of the display will show active connections.
Tap any connectivity icon to view the active connection. A
small window will display the connection information.
Bluetooth
You can connect with other Bluetooth-enabled wireless
devices with in a range. Walls or other obstacles between
devices may block or impair the wireless connection.
Turn on the Bluetooth wireless feature
1
Ta p
Start > Settings
.
2
On the
Connection
tab, tap
Wireless Manager
.
3
Ta p
Off
next to
Bluetooth
and tap
Done
.
Wi-Fi and data connections can be active at the same time. When
both connections are active, the device will use Wi-Fi as the default
internet connection.
118
4
To allow other devices to find and connect to your device,
tap
Bluetooth > Device Info
, and check
On
next to
Enable to
make this device visible to other devices
.
5
Ta p
Save
.
Change Bluetooth device names
You can alter the name that your device will display to other
Bluetooth-enabled devices. To change the device name,
1
Ta p
Start > Settings
.
2
On the
Connection
tab, tap
Bluetooth > Device Info
.
3
Enter a device name.
4
Ta p
Save
.
119
Search for and pair with a Bluetooth-enabled
device
1
Ta p
Start > Settings
.
2
On the
Connection
tab, tap
Bluetooth > Connection
.
3
Ta p
Search
.
• Your device will search for and display the list of Bluetooth-
enabled devices.
4
Drag a device icon into the centre.
5
Enter the 1- to 16-digit Bluetooth PIN for the device you are
trying to connect to and tap
Next
.
6
Select services and tap
Done
.
To pair with another Bluetooth-enabled device, both devices
must use the same passcode. Headsets or hands-free car kits
may use a fixed passcode, such as
0000
.
120
Send data via the Bluetooth wireless feature
1
Locate an item or file to send.
2
Select a sending option.
3
Tap a device from the list.
Receive data via the Bluetooth wireless feature
1
Enter the PIN for the Bluetooth wireless feature and tap
ok
(if necessary).
2
When prompted to allow incoming data, tap
Yes
to save the
data to your device.
121
Wi-Fi
Your device features wireless networking capabilities that allow
you to connect to wireless local area networks (WLANs).
Activate the Wi-Fi connection
1
Ta p
Start > Settings
.
2
On the
Connection
tab, tap
Wi-Fi
.
3
Ta p
Connection
.
4
Ta p
WiFi Turn off
.
122
Search for and connect to a WLAN
1
Ta p
Start > Settings
.
2
On the
Connection
tab, tap
Wi-Fi
.
3
Ta p
Connection
.
4
Ta p
Search
.
• The device will display available
WLAN connections.
5
Drag a network icon to the device
icon in the middle of the screen.
• The device will attempt to connect
to the WLAN.
6
Enter a password (if necessary).
123
Create a new Wi-Fi connection
1
Ta p
Start > Settings
.
2
On the
Connection
tab, tap
Wi-Fi
.
3
Ta p
Connection
.
4
Ta p
Add New
.
5
Enter a network name and configure connection settings.
6
When you are finished, tap
Next
.
7
Enter network authentication settings and tap
Next
.
8
Set the IEEE 802.1x access option and the extensible
authentication protocol (EAP) type (if necessary).
9
Ta p
Finish
.
• The new Wi-Fi network will appear on the Wi-Fi screen. To
connect to the network, drag the network icon to the device
icon in the middle of the screen.
124
Connected Home
The connected home application allows you to share media
files between devices in your home. You can access and play
files from devices that support the Digital Living Network
Alliance (DLNA) standard.
Locate and play files from another device
1
Ta p
Start > Main Menu > Connected
Home
(2/5).
2
Authorise the device to connect to a
Wi-Fi connection (if necessary).
3
Select a server or computer from the
device interface.
4
Select a folder and locate files.
5
Ta p
Open
.
6
Select a file and tap
Open
.
125
7
During playback, use the following controls:
Download files to your device
1
Ta p
Start > Main Menu > Connected Home
(2/5).
2
Authorise the device to connect to a Wi-Fi connection
(if necessary).
3
Select a server or computer from the device interface.
4
Select a folder and locate files.
5
Ta p
Download
.
6
Select a file and tap
Download
.
• The file will downloaded to your device.
Icon Function
Adjust the volume
Pause playback
Resume playback
Skip to the previous file
Skip to the next file
126
Delete files
You can delete files from the now playing list to prevent them
from being played on your device. This will not delete the file
from the server-only from your device.
127
Troubleshooting
If you have trouble with your device, try these procedures before you
contact a service professional.
When you turn on your device, the following messages may
appear:
Message Try this to solve the problem:
The SIM card is
missing.
Ensure that the SIM or USIM card is installed
correctly.
Enter PIN.
When using the device for the first time or when
the PIN requirement feature is enabled, you must
enter the PIN supplied with the SIM or USIM card.
To disable the PIN requirement feature, tap
Start >
Settings > Personal
tab
> Phone > Security > SIM PIN
,
and then tap
On
next to
Require PIN when phone is
used
.
SIM card
blocked.
Your SIM or USIM card is blocked, usually as a
result of entering your PIN incorrectly several
times. You must enter the PUK supplied by your
service provider.
128
Your device does not show a signal (no bars next to the network
icon)
• If you just turned on the device, wait about 2 minutes for your
device to find the network and receive a signal.
• You may not be able to receive a signal in tunnels or elevators.
Move to an open area.
• You may be between service areas. You should receive a signal
when you enter a service area.
You forgot a security code, PIN, or PUK
If you forget or lose this or another code, contact the seller or your
service provider.
Your display shows white lines
The display may show white lines if you have turned the device on
after a long period of disuse or if you removed the battery without first
turning off the device. The display should correct itself in a short time.
You enter a number, but the call is not dialled
• Ensure that you have pressed [ ].
• Ensure that you have accessed the right cellular network.
• Ensure that you have not set call barring for the phone number.
129
You select a contact to call, but the call is not dialled
• Ensure that the correct number is stored in the contact information.
• Re-enter and save the number (if necessary).
Another caller cannot hear you speaking
• Ensure that you are not blocking the built-in microphone.
• Move the built-in microphone closer to your mouth.
• If using a headset, ensure that it is properly connected.
The sound quality of a call is poor
• Ensure that you are not blocking the internal antenna and the
Bluetooth antenna. The internal antenna and the Bluetooth antenna
are located at the bottom of the device.
• When you are in areas with weak signals, you may lose reception.
Move to another area and try again.
130
The battery does not charge properly or sometimes your device
turns itself off while charging
• Disconnect the device from the charger, remove and reinstall the
battery, and try charging again.
• The battery terminals may be dirty. Wipe both gold-coloured
contacts with a clean and soft cloth and try charging the battery
again.
• If the battery no longer charges completely, dispose of the old
battery properly and replace it with a new battery.
Your device is hot to the touch
When you use several applications at once, your device requires more
power and may heat up. This is normal and should not affect your
device’s lifespan or performance.
Your device cannot connect to the internet
• Ensure that you have entered valid settings for your internet service
provider.
• Ensure that you have activated the wireless connection to your
mobile service provider and that the signal is not obstructed.
• Ensure that you have entered the correct user name and password.
131
You cannot find a Bluetooth-enabled device
• Ensure that both devices have activated the Bluetooth wireless
feature.
• Ensure that the distance between the devices is not more than 10
metres and that they are not separated by walls or other obstacles.
• Ensure that the settings for each device allow them to be visible to
other devices.
• Ensure that both devices are compatible with Bluetooth wireless
technology.
• Ensure that the correct PIN has been entered on both devices.
You cannot listen to music on a remote Bluetooth headset
• Ensure that your device is connected to the headset.
• Ensure that the music format you are trying to listen to is supported
by the headset.
• Ensure that the distance between the headset and device is not
more than 10 metres and that they are not separated by walls or
other obstacles.
132
Safety and usage information
Comply with the following precautions to avoid dangerous or illegal
situations and ensure peak performance of your device.
Safety warnings
Keep your device away from small children and pets
Keep your device and all accessories out of the reach of small
children or animals. Small parts may cause choking or serious injury if
swallowed.
Protect your hearing
Install mobile devices and equipment with caution
Ensure that any mobile devices or related equipment installed in your
vehicle are securely mounted. Avoid placing your device and
accessories near or in an air bag deployment area. Improperly
installed wireless equipment can cause serious injury when air bags
inflate rapidly.
Listening to a headset at high volumes can damage your
hearing. Use only the minimum volume setting necessary to
hear your conversation or music.
133
Handle and dispose of batteries and chargers with care
• Use only Samsung-approved batteries and chargers specifically
designed for your device.
Incompatible batteries and chargers can cause serious injuries or
damage to your device.
• Never dispose of batteries or devices in a fire. Follow all local
regulations when disposing of used batteries or devices.
• Never place batteries or devices on or in heating devices, such as
microwave ovens, stoves, or radiators. Batteries may explode when
overheated.
• Never crush or puncture the battery. Avoid exposing the battery to
high external pressure, which can lead to an internal short circuit
and overheating.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between mobile devices and
pacemakers to avoid potential interference, as recommended by
manufacturers and the independent research group, Wireless
Technology Research. If you have any reason to suspect that your
device is interfering with a pacemaker or other medical device, turn off
the device immediately and contact the manufacturer of the
pacemaker or medical device for guidance.
134
Turn off the device in potentially explosive environments
Do not use your device at refuelling points (service stations) or near
fuels or chemicals. Turn off your device whenever directed by warning
signs or instructions. Your device could cause explosions or fire in and
around fuel or chemical storage and transfer areas or blasting areas.
Do not store or carry flammable liquids, gases, or explosive materials
in the same compartment as the device, its parts, or accessories.
Reduce the risk of repetitive motion injuries
While using your device, hold the device with a relaxed grip, press the
keys lightly, use special features that reduce the number of keys you
have to press (such as templates and predictive text), and take
frequent breaks.
Safety precautions
Drive safely at all times
Avoid using your device while driving and obey all regulations that
restrict the use of mobile devices while driving. Use hands-free
accessories to increase your safety when possible.
135
Follow all safety warnings and regulations
Comply with any regulations that restrict the use of a mobile device in
a certain area.
Use only Samsung-approved accessories
Using incompatible accessories may damage your device or cause
injury.
Turn off the device near medical equipment
Your device can interfere with medical equipment in hospitals or
health care facilities. Follow all regulations, posted warnings, and
directions from medical personnel.
Turn off the device or disable the wireless functions when in an
aircraft
Your device can cause interference with aircraft equipment. Follow all
airline regulations and turn off your device or switch to a mode that
disables the wireless functions when directed by airline personnel.
136
Protect batteries and chargers from damage
• Avoid exposing batteries to very cold or very hot temperatures
(below 0° C/32° F or above 45° C/113° F). Extreme temperatures
can reduce the charging capacity and life of your batteries.
• Prevent batteries from contacting metal objects, as this can create
a connection between the + and - terminals of your batteries and
lead to temporary or permanent battery damage.
• Never use a damaged charger or battery.
• Risk of explosion if a battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Handle your device carefully and sensibly
• Do not allow your device to get wet—liquids can cause serious
damage. Do not handle your device with wet hands. Water damage
to your device can void your manufacturer’s warranty.
• Avoid using or storing your device in dusty, dirty areas to prevent
damage to moving parts.
• Your device is a complex electronic device—protect it from impacts
and rough handling to avoid serious damage.
• Do not paint your device, as paint can clog moving parts and
prevent proper operation.
137
• If your device has a camera flash or light, avoid using it close to the
eyes of children or animals.
• Your device may be damaged by exposure to magnetic fields. Do
not use carrying cases or accessories with magnetic closures or
allow your device to come in contact with magnetic fields for
extended periods of time.
Avoid interference with other electronic devices
Your device emits radio frequency (RF) signals that may interfere with
unshielded or improperly shielded electronic equipment, such as
pacemakers, hearing aids, medical devices, and other electronic
devices in homes or vehicles. Consult the manufacturers of your
electronic devices to solve any interference problems you experience.
Important usage information
Use your device in the normal position
Avoid contact with your device’s internal antenna.
Allow only qualified personnel to service your device
Allowing unqualified personnel to service your device may result in
damage to your device and will void your warranty.
138
Ensure maximum battery and charger life
• Avoid charging batteries for more than a week, as overcharging
may shorten battery life.
• Over time, unused batteries will discharge and must be recharged
before use.
• Disconnect chargers from power sources when not in use.
• Use batteries only for their intended purpose.
Handle SIM cards and memory cards with care
• Do not remove a card while the device is transferring or accessing
information, as this could result in loss of data and/or damage to
the card or device.
• Protect cards from strong shocks, static electricity, and electrical
noise from other devices.
• Frequent writing and erasing will shorten the life span of memory
cards.
• Do not touch gold-coloured contacts or terminals with your fingers
or metal objects. If dirty, wipe the card with a soft cloth.
Safety and usage information
10
Ensure access to emergency services
Emergency calls from your device may
not be possible in some areas or
circumstances. Before travelling in
remote or undeveloped areas, plan an
alternate method of contacting
emergency services personnel.
Specific Absorption Rate (SAR)
certification information
Your wireless phone is a radio transmitter
and receiver. It is designed and
manufactured not to exceed the emission
limits for exposure to radio frequency
(RF) energy set by the Federal
Communications Commission (FCC) of
the U.S. government. These FCC
exposure limits are derived from the
recommendations of two expert
organizations, the National Counsel on
Radiation Protection and Measurement
(NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both
cases, the recommendations were
developed by scientific and engineering
experts drawn from industry,
government, and academia after
extensive reviews of the scientific
literature related to the biological effects
of RF energy.
The exposure limit set by the FCC for
wireless mobile phones employs a unit of
measurement known as the Specific
Absorption Rate (SAR). The SAR is a
measure of the rate of absorption of RF
energy by the human body expressed in
units of watts per kilogram (W/kg). The
FCC requires wireless phones to comply
with a safety limit of 1.6 watts per
kilogram (1.6 W/kg). The FCC exposure
limit incorporates a substantial margin of
safety to give additional protection to the
public and to account for any variations
in measurements.
11
Safety and usage information
SAR tests are conducted using standard
operating positions accepted by the FCC
with the phone transmitting at its highest
certified power level in all tested
frequency bands. Although the SAR is
determined at the highest certified power
level, the actual SAR level of the phone
while operating can be well below the
maximum value. This is because the
phone is designed to operate at multiple
power levels so as to use only the power
required to reach the network. In
general, the closer you are to a wireless
base station antenna, the lower the
power output.
Before a new model phone is available for
sale to the public, it must be tested and
certified to the FCC that it does not
exceed the exposure limit established by
the FCC. Tests for each model phone are
performed in positions and locations (e.g.
at the ear and worn on the body) as
required by the FCC.
The highest SAR values for this model
phone as reported to the FCC are [GSM
850] Head : 0.219 W/Kg, Body-worn:
0.619 W/Kg ,[GSM1900] Head: 0.198 W/kg,
Body-worn: 0.634 W/Kg.
For body worn operation, this model
phone has been tested and meets the
FCC RF exposure guidelines when used
with a Samsung accessory designated for
this product or when used with an
accessory that contains no metal and
that positions the handset a minimum of
1.5 cm from the body. Non-compliance
with the above restrictions may result in
violation of FCC exposure guidelines.
Safety and usage information
12
The FCC has granted an Equipment
Authorization for this mobile phone with
all reported SAR levels evaluated as in
compliance with the FCC RF exposure
guidelines.
The FCC has granted an Equipment
Authorization for this model phone with
all reported SAR levels evaluated as in
compliance with the FCC RF exposure
guidelines. SAR information on this
model phone is on file with the FCC and
can be found under the Display Grant
section of http://www.fcc.gov/oet/fccid
after searching on FCC ID A3LGTB7610.
FCC Notice and Cautions
FCC Notice
• This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions: (1) this
device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
• This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursusant to
part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. Howerver, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful
13
Safety and usage information
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
The phone may cause TV or radio
interference if used in close proximity to
receiving equipment. The FCC can
require you to stop using the phone if
such interference cannot be eliminated.
Vehicles using liquefied petroleum gas
(such as propane or butane) must
comply with the National Fire Protection
Standard (NFPA-58). For a copy of this
standard, contact the National Fire
Protection Association, One Battery
march Park, Quincy, MA 02269, Attn:
Publication Sales Division.
Safety and usage information
14
Cautions
Changes or modifications made in the
radio phone, not expressly approved by
Samsung, will void the user’s authority to
operate the equipment.
Only use approved batteries, antennas
and chargers. The use of any
unauthorized accessories may be
dangerous and void the phone warranty if
said accessories cause damage or a
defect to the phone.
Although your phone is quite sturdy, it is
a complex piece of equipment and can be
broken. Avoid dropping, hitting, bending
or sitting on it.
140
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European
countries with separate collection systems)
This marking on the product, accessories or literature
indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other
household waste at the end of their working life. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and
recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for details of
where and how they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
141
Correct disposal of batteries in this product
(Applicable in the European Union and other European
countries with separate battery return systems)
This marking on the battery, manual or packaging indicates
that the batteries in this product should not be disposed of with other
household waste at the end of their working life.
Where marked, the chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the reference levels
in EC Directive 2006/66. If batteries are not properly disposed of,
these substances can cause harm to human health or the
environment.
To protect natural resources and to promote material reuse, please
separate batteries from other types of waste and recycle them
through your local, free battery return system.
142
Disclaimer
Some content and services accessible through this device belong to
third parties and are protected by copyright, patent, trademark and/or
other intellectual property laws. Such content and services are
provided solely for your personal noncommercial use. You may not
use any content or services in a manner that has not been authorised
by the content owner or service provider. Without limiting the
foregoing, unless expressly authorised by the applicable content
owner or service provider, you may not modify, copy, republish,
upload, post, transmit, translate, sell, create derivative works, exploit,
or distribute in any manner or medium any content or services
displayed through this device.
“THIRD PARTY CONTENT AND SERVICES ARE PROVIDED "AS IS."
SAMSUNG DOES NOT WARRANT COTENT OR SERVICES SO
PROVIDED, EITHER EXPRESSLY OR IMPLIEDLY, FOR ANY
PURPOSE. SAMSUNG EXPRESSLY DISCLAIMS ANY IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. SAMSUNG DOES NOT GUARANTEE THE ACCURACY,
VALIDITY, TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY
CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE
AND UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE,
SHALL SAMSUNG BE LIABLE, WHETHER IN CONTRACT OR TORT,
143
FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR
ANY OTHER DAMAGES ARISING OUT OF, OR IN CONNECTION
WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF
THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY THIRD
PARTY, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES."
Third party services may be terminated or interrupted at any time, and
Samsung makes no representation or warranty that any content or
service will remain available for any period of time. Content and
services are transmitted by third parties by means of networks and
transmission facilities over which Samsung has no control. Without
limiting the generality of this disclaimer, Samsung expressly disclaims
any responsibility or liability for any interruption or suspension of any
content or service made available through this device.
Samsung is neither responsible nor liable for customer service related
to the content and services. Any question or request for service
relating to the content or services should be made directly to the
respective content and service providers.
144
Index
ActiveSync
Exchange server,
80
installing,
77
schedule,
81
synchronise,
79
alarm
setting,
82
stopping,
82
Application Download
113
Audio Note
92
background image
see Today Screen
Bluetooth
activating,
117
connecting to other devices,
119
receiving data,
120
sending data,
120
calculator
96
calendar
see Touch Calendar
calls
from Call Log,
38
international number,
39
camera
51
Communities
109
Connected Home
124
contacts
assigning images,
35
assigning ringtones,
36
assigning speed dial
numbers,
34
copying and moving contact
cards,
32
creating contacts,
31
145
searching for contacts,
31
converter
see Smart Converter
Digital Frame
66
Etiquette pause
26
Exchange Server
see ActiveSync
FM radio
68
Games
74
Java
74
Life Diary
87
Messaging
email,
49
multimedia,
48
text,
47
viewing,
50
Midomi
99
notes
audio, see Audio Note
creating,
90
sending,
90
Photo Album
starting slideshows,
66
viewing photos,
65
Podcast
104
QIK
106
reset
23
RSS Reader
102
sketches
91
Smart Converter
97
Smart Memo
92
Streaming Player
98
Task Manager
76
146
Task Switcher
76
Tasks
creating,
95
marking as completed,
95
text input
Block Recognizer,
41
keyboard,
42
Letter Recognizer,
43
Samsung Keypad,
44
Transcriber,
45
themes
see Today Screen
Today screen
adding or removing items,
24
changing themes or
background images,
24
Touch Calendar
changing views,
86
creating events,
85
stopping event alarms,
86
Touch Player
creating a playlist,
63
playing files,
62
updating the library,
62
Widgets
customise widgets,
30
moving to the Today screen,
29
open the toolbar,
27
Wi-Fi
121
Declaration of Conformity (R&TTE)
We, Samsung Electronics
declare under our sole responsibility that the product
GSM Mobile Phone : B7610
to which this declaration relates, is in conformity with the following standards and/or other
normative documents.
Position only
SAFETY EN
EMC EN
EN
EN
EN
SAR EN
EN
RADIO EN
EN
EN
EN
We hereby declare that [all essential radio test suites have been carried out and that] the above
named product is in conformity to all the essential requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and detailed in Annex[IV] of
Directive 1999/5/EC has been followed with the involvement of the following Notified Body(ies):
BABT, Balfour House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD, UK*
Identification mark: 0168
The technical documentation kept at :
Samsung Electronics QA Lab.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab. Blackbushe Business Park,
Saxony Way, Yateley, Hampshire, GU46 6GG, UK*
Yong-Sang Park / S. Manager
(place and date of issue) (name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone number of Samsung Service
Centre, see the warranty card or contact the retailer where you purchased your phone.
