Samsung Electronics Co GTP1010 Mini-Tablet with WLAN and Bluetooth User Manual i987 P1
Samsung Electronics Co Ltd Mini-Tablet with WLAN and Bluetooth i987 P1
Users Manual
ANDROID TABLET
User Manual
Please read this manual before operating your
device, and keep it for future reference.
GT-P1010_XXJI5_WB_093010_D1
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to
the SAMSUNG tablet, including but not limited to, accessories, parts, or software relating there to (the “tablet”), is proprietary to Samsung
and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and
other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree
that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise
attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable
rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.
Samsung Telecommunications America (STA), LLC
Headquarters: Customer Care Center:
1301 E. Lookout Drive 1000 Klein Rd.
Richardson, TX 75082 Plano, TX 75074
Toll Free Tel: 1.888.987.HELP (4357)
Internet Address:
http://www.samsungusa.com
©2010 Samsung Telecommunications America, LLC is a registered trademark of Samsung Electronics America, Inc. and its related
entities.
Do you have questions about your Samsung Android Tablet?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:
www.samsungtelecom.com/support
T9 Text Input is licensed by Tegic Communications and is covered by U.S. Pat. 5,818,437; U.S. Pat. 5,953,541; U.S. Pat. 6,011,554 and
other patents pending.
ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other countries.
The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are registered
trademarks and are wholly owned by the Bluetooth SIG.
microSD™ and the microSD logo are Trademarks of the SD Card Association.
Openwave® is a registered Trademark of Openwave, Inc.
and are trademarks of SRS Labs, Inc. CS Headphone and WOW HD technologies are incorporated under license from
SRS Labs, Inc.
Google, the Google logo, Android, the Android logo, Android Market, Gmail, Google Mail, Google Apps, Google Calendar, Google Checkout,
Google Earth, Google Latitude, Google Maps, Google Talk, Picasa, and YouTube are trademarks of Google Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
Swype and the Swype logos are trademarks of Swype, Inc. © 2010 Swype, Inc. All rights reserved.
Open Source Software
Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser General
Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered under the open
source licenses, please visit:
http://opensource.samsung.com/category/mobile/mobile-phone/
.???
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY
PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE
WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE
PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF
THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.
4
Section 1: Getting Started
This section explains how to start using your tablet by configuring
your hardware and activating your service.
Setting Up Your Tablet
Prior to use it is necessary to install the memory card into their
corresponding compartments.
Warning!:
Please note that a touch screen responds best to a light touch
from the pad of your finger. Using excessive force or a metallic
object when pressing on the touch screen may damage the
tempered glass surface and void the warranty. For more
information, refer to “Standard Limited Warranty” on page 147.
Installing the Memory Card
Your device lets you use a microSD™ (SD) or microSDHC™ card
to expand available memory space. This secure digital card
enables you to exchange images, music, and data between
SD-compatible devices. This type of memory card is designed for
use with this tablet and other devices.
1. Push the microSD card into the slot until it clicks (as
shown).
2. Make sure the microSD’s gold contact pins face downward
and the card is securely inserted.
Note:
Your tablet has been tested to support up to a 16GB memory card.
For more information on Memory Cards, see “Memory Card” on
page 26.
Getting Started 5
Charging the Battery
Your tablet is powered by a rechargeable Li-ion battery. The
Travel Adapter that is used to charge the battery, is included with
your tablet.
Note:
Long backlight settings, searching for service, vibrate mode, browser
use, and other variables may reduce the battery’s talk and standby
times.
Although you can use the device while the battery is charging,
doing so will require additional charging time.
Note:
You must fully charge the battery before using your tablet for the first
time. A discharged battery recharges fully in approximately 4 hours.
Using the Travel Adapter
To use the travel adapter to charge your battery, follow these
steps:
1. Carefully slide the Outlet Connector into the Charging Head
(1). Make sure the connection is secure.
2. Connect the USB cable to the Charging Head (2).
3. Insert the USB cable into the device’s Charger/Accessory
jack.
Correct
Incorrect
Correct
Incorrect
6
4. Plug the charging head into a standard AC power outlet.
Low Battery Indicator
When the battery is weak and only a few minutes of talk time
remain, the battery icon ( ) blinks and the device sounds a
warning tone at regular intervals. In this condition, your tablet
conserves its remaining battery power, not by turning off the
backlight, but by entering the dimming mode. For a quick check
of your battery level, glance at the battery charge indicator
located in the upper-right corner of your device’s display. Solid
color ( ) indicates a full charge.
When the battery level becomes too low, the tablet automatically
turns off.
Switching the Tablet On or Off
1. Press and hold (on the upper right side of the
tablet) until the tablet switches on.
2. Sweep your finger across the glass to unlock the tablet.
Note:
The display language is preset to English at the factory. To change the
language, use the Language menu. For more information, refer to
“Changing Your Settings” on page 70.
3. To switch off the tablet, press and hold , until
the
Device options
screen displays.
4. Tap
Power off
.
5. At the
Power off
prompt, tap
Yes
to turn off your tablet.
Getting Started 7
Locking and Unlocking the Touch Screen
1. Press (located on the right side of the tablet) to
lock the touch screen.
2. Press again to display the main screen then
sweep your finger across the glass to unlock the touch
screen.
Creating a New Google Account
In order to utilize your device to the fullest extent, you will need
to create a Google™ Account when you first use your device.
With a Google Account, Google applications will always be in
sync between your tablet and computer.
After you start your tablet for the first time, follow these steps:
1. From the Home screen, tap
Applications
➔
Google
Mail
.
The
Add a Google Account
screen displays.
2. Tap
Next
to continue.
3. Follow the on-screen instructions to create a Google
Account.
Note:
If you already have a Google account, you only need to sign in.
8
Retrieving your Google Account Password
A Google account password is required for Google applications. If
you misplace or forget your Google Account password, follow
these instructions to retrieve it:
1. From your computer, use an Internet browser to navigate
to
http://google.com/accounts
.
2. Once the URL loads, click on the
Can’t access your
account?
link.
3. From the
Please select your issue
section, select
I forgot my
password
.
4. Select
Reset your password here
, then follow the password
recovery procedure.
Understanding Your Tablet 9
Section 2: Understanding Your Tablet
This section outlines some key features of your tablet and
describes the screen and the icons that appear when the tablet is
in use. It also shows how to navigate through the tablet and
provides information on using a memory card.
Features of Your Tablet
Your tablet is lightweight, easy-to-use and offers many useful
features. The following list outlines a few of the included
features.
•
Touch screen provides quick response to a variety of menus and
options including applications and five home screens
•
Solid Android platform
•
Ready access to the Internet
•
Readers Hub application for reading books, newspapers, and
magazines
•
Built-in Bluetooth and Wi-Fi technology
•
Brilliant wide-screen AMOLED display
•
3.2 Megapixel camera and camcorder
•
Google Maps Navigation functionality provides real-time navigation
•
microSD card compatibility for use in data storage and access
•
Up to 16GB expandable memory slot
•
Sync and update social network applications
Front View of Your Tablet
7
3
2
4
5
8 96
1
10
11
10
1. Indicator icons: shows the information needed to operate
your tablet, such as the received signal strength, battery
level, time, unread Emails, etc.
2.
Home screen indicator
: shows which of 5 different Home
screens is presently displayed.
3. Google Quick Search bar: a shortcut to Google Search
that allows you to search for items on the internet.
4. Application icons: you can place shortcuts to your
favorite applications on the Home screen and delete
default icons you don’t want.
5. Primary shortcuts: allows quick access to Browser,
Menu, and Email. For more information, refer to “Primary
Shortcuts” on page 12.
6. Menu key: allows you to access sub-menus with
additional options for different features and applications.
7. Home key: allows you to return to the main Home screen
from any Home screen or menu.
8. Back key: allows you step backwards when navigating a
menu or web page.
9. Search key: allows you to access the Google Search
feature where you can search for items on the internet.
10.
Light sensor
: this sensor uses the ambient light level to
adjust both screen brightness/contrast and keypad access.
•
In a bright light condition (outdoors), the sensors cause the phone to
increase the brightness and contrast for better viewing.
•
In a dark light condition (while talking on the phone) the sensors
detect talk activity and lock the keypad to prevent accidental key
presses.
11.
Front Camera
: this camera allows you to take pictures or
videos of yourself and use the video chat application.
Understanding Your Tablet 11
Side Views of Your Tablet
1.
3.5mm Headset jack
: allows you to plug in headphones.
2.
Microphone
: used for speech applications.
3. Power/Accessory Interface connector: allows you to
connect a Travel Charger or other optional accessories
such as a USB/data cable or a hands-free headset for
convenient, hands-free conversations.
4.
Memory Card port
: your tablet has an external memory port
for a microSD™ (SD) or microSDHC™ (SD) card.
5.
Volume keys
: allow you to adjust the ringer volume while in
standby mode or adjust the voice volume during a call.
When receiving an incoming call, briefly press down either
volume key ( ) to mute the ring tone. Press and
hold either volume key to reject the call and send it directly
to voicemail. Adjusts text size when reading a message or
using the browser in the Applications folder.
6. Lock key: ( ) lets you lock or unlock the touch
screen. For more information on locking your tablet, see
“Locking and Unlocking the tablet” on page 20.
1
2
3
4
5
6
12
Rear View of Your Tablet
1.
Camera lens
: is used to take pictures and shoot videos.
2.
External speaker
: allows you to hear when the
Speakerphone is turned on.
Display Layout
Your display screen provides a wealth of information about the
tablet’s status and options, as well as providing access to
application icons. For more information, refer to “Front View of
Your Tablet” on page 9.
Primary Shortcuts
There are four non-movable Application Shortcuts that appear at
the bottom of all Home screens. The default shortcuts are:
•
Browser
for surfing the Internet.
•
Menu
for accessing the applications on your tablet.
•
Email
for creating and viewing Email.
While viewing the Applications Menu, the Menu shortcut changes
to
Home
, which returns you to the main Home screen.
Indicator Icons
This list identifies the symbols you’ll see on your tablet’s display
and Indicator area:
1
2
Displays your current signal strength. The greater the
number of bars, the stronger the signal.
Indicates that the Airplane Mode is active. You cannot
send or receive any messages or emails or access
online information.
Displays when there is a system error or alert.
Displays your battery charge level. Icon shown is fully
charged.
Understanding Your Tablet 13
Displays when your battery is charging. Also displays
battery charge level.
Device Power Critical – Shows your current battery
only has three percent power remaining and will
immediately shutdown.
Displays when an external microSD memory card is
detected.
Displays when an external microSD memory card is
removed.
Displays when an external microSD memory card is
full.
Displays when the tablet is connected to a computer
via a supported USB cable connection.
Displays when a new text or multimedia message is
received. The number of new messages is indicated
inside of the circle.
Displays when Email is received.
1
Displays when you set an alarm to ring at a specified
time. For more information, refer to “Alarm Clock” on
page 105.
Displays when the Sound profile is set to silent or the
volume has been manually lowered below level 1.
Displays when the Sound profile is set to vibrate.
Displays when Bluetooth is activated.
Displays when a Bluetooth device has been paired
with the tablet.
Displays when Wi-Fi is connected, active, and
communicating with a Wireless Access Point (WAP).
Displays when Wi-Fi is active but there is a
communication issue with the target Wireless Access
Point (WAP).
Displays when GPS is acquiring a signal.
Displays when GPS is active.
14
For more details on configuring your tablet’s settings, see
“Changing Your Settings” on page 70.
Application Icons
The Application menu provides quick access to the items you use
most frequently.
The following table contains a description of each application. If
the application is already described in another section of this
user manual, then a cross reference to that particular section is
provided.
For information on navigating through the Applications icons, see
“Navigating Through the Application Menus” on page 21.
1. From the Home screen, tap , then tap one of the
application icons.
2. Follow the on-screen instructions.
3. To return to the Home screen, press .
The following applications are available:
Alarm Clock
: The Alarm Clock application allows you to
set an alarm to ring at a specific time. For more
information, refer to “Alarm Clock” on page 105.
AllShare
: AllShare allows your tablet to stream photos,
music and videos from its memory to other Digital Living
Network Alliance (DLNA) certified devices. Your tablet can
also play digital content streamed from other DLNA
certified devices. For more information, refer to “AllShare”
on page 106.
Browser
:
Open the browser to start surfing the web. The browser is
fully optimized and comes with advanced functionality to
enhance the Internet browsing feature on your tablet. For
more information, refer to “Browser” on page 90. This
icon only displays in the Applications menu when
Browser has been removed as a primary shortcut.
Calendar
:
With the Calendar feature, you can consult the calendar by
day, week, or month, create events, and set an alarm to act
as a reminder, if necessary. For more information, refer to
“Calendar” on page 108.
Camera
:
Use your 5.0 megapixel camera feature to produce
photos in a JPEG format. For more information, refer to
“Camera” on page 51.
Understanding Your Tablet 15
Contacts
:
You can manage your daily contacts by storing their name
and number in your Address Book. Address Book entries
can be sorted by name, entry, or group. You can also
synchronize your tablet Contact List, the network backup
service. For more information, refer to “Contacts and Your
Address Book” on page 35.
Daily Briefing
:
With Daily Briefing, you can monitor the weather, financial
information, news, and your schedule from one convenient
location. For more information, refer to “Daily Briefing” on
page 109.
Digital Frame
:
With the Digital Frame application, you can set your
screen to display a slideshow of your pictures. You can
also set it to display a clock and play music. For more
information, refer to “Digital Frame” on page 110.
eBook:
For more information, refer to “eBook” on page 107.
Email
:
Email enables you to review and create email using AIM®,
AOL®, Yahoo!® Mail, Hotmail, Windows Live, NetZero,
SBC Yahoo! and several other email services. You can also
receive email from Exchange server accounts. For more
information, refer to “Using Email” on page 66.
Gallery
:
The Gallery is where you view photos and play back
videos. For photos, you can also perform basic editing
tasks, view a slideshow, set photos as wallpaper or contact
image, and share as a picture message. For more
information, refer to “Gallery” on page 49.
Gmail
:
Gmail is a web-based email service. Gmail is configured
when you first set up your tablet. Depending on your
synchronization settings, Gmail can automatically
synchronize with your Gmail account on the web. For more
information, refer to “Using Gmail” on page 68.
Google Search
:
The Google Search Bar provides you an on-screen
Internet search engine powered by Google™. For more
information, refer to “Google Search Bar” on page 18.
16
Latitude
:
With Google Latitude, you can see the location of all of
your friends on a map or on a list. You can also share or hide
your location. For more information, refer to “Latitude” on
page 112.
Maps
:
Depending on your location, you can view basic, custom,
and satellite maps and local business information,
including locations, contact information, and driving
directions. You can also post public messages about a
location and track your friends. For more information, refer
to “Maps” on page 114.
Market
:
Android Market provides access to downloadable
applications and games to install on your tablet. Android
Market also allows you to provide feedback and comments
about an application, or flag an application that might be
incompatible with your tablet. For more information, refer
to “Market” on page 116.
Media Hub:
Samsung Media Hub is your one stop for the hottest movie
and TV content. You can rent or purchase your favorite
content and watch from the convenience of anywhere. For
more information, refer to “Media Hub” on page 43.
Memo
:
This feature allows you to create a memo. For more
information, refer to “Memo” on page 116.
Music
:
Music allows you to play music files that you have stored
on your microSD card. You can also create playlists. For
more information, refer to “Music Player” on page 46.
My Files
:
My Files allows you to manage your sounds, images,
videos, bluetooth files, Android files, and other memory
card data in one convenient location. For more
information, refer to “My Files” on page 117.
Understanding Your Tablet 17
Navigation
:
Navigation is an internet-connected GPS navigation
system with voice guidance. You can type or speak your
destination. For more information, refer to “Navigation” on
page 152.
News and Weather
:
Select from any of the available tabs: Weather, Top
Stories, U.S., Sports, and Entertainment.
Places
:
Places is an application that uses Google Maps and your
location to help you find Restaurants, Coffee, Bars,
Hotels, Attractions, ATMs, and Gas Stations. You can also
add your own locations. For more information, refer to
“Places” on page 121.
Quick Office
:
The ThinkFree Office application allows you to create and
save Microsoft Word and Excel documents. You can also
view existing Powerpoint presentations and PDFs.
Settings
:
This icon navigates to the sound and phone settings for
your phone. It includes such settings as: display, security,
memory, and any extra settings associated with your
phone. For more information, refer to “Changing Your
Settings” on page 70.
Talk
:
Google Talk is a free Windows and web-based application
for instant messaging offered by Google. Conversation
logs are automatically saved to a Chats area in your Gmail
account. This allows you to search a chat log and store
them in your Gmail accounts. For more information, refer
to “Google Talk” on page 69.
Task Manager
:
The Task Manager application provides information about
the processes and programs running on your tablet, as
well as the memory status. It can also be used to terminate
processes and applications. For more information, refer to
“Task Manager” on page 122.
18
Tip:
To open applications quickly, add the icons of frequently-used
applications to the Home screen or to the folders you created. For
details, see “Customizing Your Home Screen” on page 22.
Google Search Bar
The Google Search Bar provides you an on-screen Internet
search engine powered by Google™.
1. From the main home screen, tap the Google Search bar
.
2. Use the on-screen keypad to enter the item you want to
search for, then tap
Go
.
3. Tap to narrow your search results. Tap
All
,
Web
, or
Apps
to only search in those areas.
4. Tap to use Google Voice Search. For more
information, refer to “Voice Search” on page 123.
Feeds and Updates
This application allows you to have feeds and updates from
Facebook, MySpace, and Twitter displayed on your tablet.
1. Press to activate the Home screen.
2. Navigate to a desired empty Home screen.
3. Touch and hold on an empty area of the screen.
Video
:
The Video application plays video files stored on your
microSD card. For more information, refer to “Video
Player” on page 48.
Voice Search
:
The Voice Search feature is a voice-activated application
that allows you to tell the phone what to search for and then
the phone activates a Google search based on what you
said. For more information, refer to “Voice Search” on
page 123.
World clock
:
World Clock allows you to view the time of day or night in
other parts of the world. World Clock displays time in
hundreds of different cities, within all 24 time zones
around the world. For more information, refer to “World
Clock” on page 123.
YouTube
:
YouTube is a video sharing website on which users can
upload and share videos, and view them in MPEG-4 format.
For more information, refer to “YouTube” on page 124.
Understanding Your Tablet 19
4. From the
Add to Home screen
window tap
Widgets
.
5. Tap
Feeds and Updates
. The Feeds and Updates screen will
be displayed on the selected Home screen.
6. Tap on the
Tap here to add account
field.
7. Select the Social networks that you would like to have
added to your Feeds and Updates. Select
Facebook
,
MySpace
, and/or
Twitter
.
8. You must first sign in to the social networks that you would
like to have feeds and updates displayed on your tablet.
Enter
Email
and
Password
and tap
Log in
.
9. The Feeds and Updates screen will be updated with the
latest feeds and updates from your social networks.
10. Tap in the top right corner of the screen to
automatically refresh your social networking feeds and
content.
11. Tap to display the following settings:
•Auto refresh
: this option allows you to set how often your social
networks are updated. Choose None, Every 30 minutes, Every 1
hour, Every 4 hours, Every 8 hours, or Once a day.
• Select service
: this option allows you to turn the Feeds and
Updates to your different social networks on or off. Tap the social
networks to toggle the green arrows on and off. The green arrow
indicates that the Feeds and Updates are on.
FPO
20
Menu Navigation
You can tailor the tablet’s range of functions to fit your needs
using both menus and widgets. Menus, sub-menus, and features
can be accessed by scrolling through the available on-screen
menus. Your tablet has five home screens.
Locking and Unlocking the tablet
To unlock your phone:
1. Press the lock button located on the upper right
side of your tablet.
2. Sweep the touch screen in any direction.
3. The Home screen will display as shown above.
Home Screen Overview
The main home screen is the starting point for many applications
and functions, and it allows you to add items like application
icons, shortcuts, folders, or Google widgets to give you instant
access to information and applications. This is the default page
and accessible from any menu by pressing .
Navigating Through the Home Screens
Your tablet has five home screens. If you like, you can place
different applications on each of the home screens.
䊳
From the main Home screen, sweep the screen with your
finger to the left or the right. The main Home Screen is
located in the middle with two screens on each side of it.
FPO
FPO
Understanding Your Tablet 21
Navigating Through the Application Menus
There are two Application Menus available. Follow these steps to
navigate through the Application Menus:
1. At the Home screen, tap . The first Application Menu
will be displayed.
2. Sweep the screen to access the other menu.
3. Tap one of the application icons.
Navigating Using Sub-Menus
Sub-menus are available when you are at any Home screen or
have selected a feature or application such as Email, Contacts,
Messaging, or Browser.
To access a sub-menu:
1. Tap .
A sub-menu will appear at the bottom of the screen.
2. Tap any option.
Accessing Recently-Used Applications
1. Press and hold from any screen to open the
recently-used applications window.
2. Tap an icon to open the selected application or tap
Task
Manager
to access the Task Manager. For more
information, refer to “Task Manager” on page 122.
Customizing Your Home Screen
You can customize your Home screen by doing the following:
•
Creating Shortcuts
•
Adding and Removing Widgets on the Home Screen
•
Repositioning Widgets
•
Creating Folders
•
Changing the Wallpaper
22
Creating Shortcuts
Shortcuts are different than the current Home screen Widgets
that only launch an application. Shortcuts activate a feature,
action, or launch an application.
Note:
To move a shortcut from one screen to another, it must first be deleted
from its current screen. Navigate to the new screen, then add the
shortcut.
Adding a shortcut from the Applications tab
1. Press to activate the Home screen.
2. Navigate to the desired Home Page.
3. Tap to display your current applications.
4. Scroll through the list and locate your desired application.
5. Touch and hold the on-screen icon. This creates an
immediate shortcut of the selected icon and closes the
Applications tab. The new shortcut then appears to hover
over the Home screen.
6. While still holding the on-screen icon, position it on the
current page. Once complete, release the screen to lock
the new shortcut into its new position on the current
screen.
Adding a shortcut via the Add to Home screen
1. Press to activate the Home screen.
2. Touch and hold on an empty area of the Home screen.
3. From the
Add to Home screen
window tap
Shortcuts
.
4. Tap a selection from the available list:
•
Applications
•
Bookmark
•
Contact
•
Directions & Navigation
•
Google Mail label
•
Latitude
•
Settings
5. Follow the on-screen instructions to add the new shortcut
to your current Home screen.
Deleting a shortcut
1. Press to activate the Home screen.
2. Touch and hold the desired shortcut. This unlocks it from
its location on the current screen.
3. Drag the icon over the Delete tab and release it.
Understanding Your Tablet 23
As you place the shortcut into the Trash, the shortcut turns
red.
Note:
This action does not delete the shortcut application, it just removes the
shortcut icon from the current screen.
Adding and Removing Widgets
Widgets are self-contained applications that reside in either your
Applications tab or on the main or extended Home screens.
Unlike a shortcut, the Widget appears as an on-screen
application.
Note:
To move a Widget from one screen to another, it must first be deleted
from its current screen. Activate the new screen, then add the Widget.
Adding a Widget
1. Press to activate the Home screen.
2. Navigate to the desired Home Page.
3. Touch and hold on an empty area of the screen.
4. From the
Add to Home screen
window tap
Widgets
.
5. Tap an available Widget to place it on your current screen.
Removing an Android Widget or Samsung Widget
1. Touch and hold a Widget until you can move it around on
the screen.
2. Drag the Widget over the Delete tab and release it.
As you place the Widget into the Trash, the widget turns
red.
Note:
This action does not actually delete the Widget, it just removes it from
the current Home screen.
Moving Icons in the Applications Menu
1. Press to activate the Home screen.
2. Tap to display your current applications.
3. Press ➔
Edit
.
4. Scroll through the list and locate the icon you wish to
move.
5. Touch and drag the icon to the position that you want. To
move to a different page, drag the icon to the edge of the
page until the page scrolls to the desired page.
6. Press ➔
Save
.
7. Press to return to the Home screen.
24
Creating and Managing Folders
Folders are located on any of the seven available Home screens
and can contain both files (such as data and images) and Contact
information or entries.
To create a folder on-screen follow these steps:
1. Press to activate the Home screen.
2. Navigate to the desired Home Page.
3. Touch and hold on an empty area of the screen.
4. From the
Add to Home screen
window tap
Folders
.
5. Tap an available folder type to place it on your current
screen.
•
Choices include New folder, All contacts, Contacts with phone
numbers, Received list from Bluetooth, and Starred contacts.
Note:
Starred contacts are those Contact entries tagged as very important.
Changing the Wallpaper
You can change the Wallpaper (background) of your home
screens by following these steps:
1. Press to activate the Home screen.
2. Touch and hold on an empty area of the screen.
3. From the
Add to Home screen
window tap
Wallpapers
.
4. Tap one of the following options:
• Gallery
: select a wallpaper from photographs you have taken with
your camera.
• Live wallpapers
: select an animated wallpaper.
• Wallpaper gallery
: select from many still-life wallpapers.
5. Select a wallpaper and tap the
Set wallpaper
icon.
Notification Bar
The Notification Bar includes a pull-down list to show information
about processes that are running, recent notifications, and alerts.
To display the Status indicator:
䊳
On the Home screen, tap the Notification Bar until the pull-
down displays, then drag down vertically.
Understanding Your Tablet 25
Clearing Notifications
To clear all notifications from the Notification panel:
1. From the Home screen, tap the Notification Bar until the
pull-down displays, then drag down vertically.
2. Tap the
Clear
button.
The notifications are cleared and the panel closes.
Memory Card
Your device lets you use a microSD™ (SD) or microSDHC™ card
to expand available memory space. This secure digital card
enables you to exchange images, music, and data between
SD-compatible devices. This section addresses the features and
options of your device’s SD functionality. The device has a USB
SD card mode.
Using the SD Card
There are several methods for using the SD card:
1. Connecting to your PC to store files (such as music, videos,
or other types of files and media).
2. To activate the camera, video, music player, and other
dependant media or applications.
Important!:
The Camera, Audio Postcard, Music Player, and Video
functionality is all dependant on a mounted SD card. Your device
can support SDHC cards up to 16GB capacity.
SD Card Overview
After mounting an SD card in the device you can use your
computer to access and manage the SD card.
Important!:
If access to the external SD card is not available, download and
install the USB drivers.
Mounting the SD Card
To store photos, music, videos, and other applications. You must
mount (install) the SD card prior to use. Mounting the SD card
establishes a USB connection with your computer.
Important!:
You must disable USB storage to mount the SD card.
To mount the SD card:
1. Insert the SD card into the external, SD card slot. For more
information, refer to “Installing the Memory Card” on
page 4.
2. Your SD card is scanned to see the available information
on it.
26
Unmounting the SD card
Unmounting the SD card prevents corruption and damage to the
SD card while removing it from the slot.
1. From the Home screen, tap ➔
Settings
➔
SD card and
phone storage
.
2. Tap
Unmount SD card
.
3. When the “
External SD card safe to remove
” message
displays at the top of your display, open the phone and
remove the SD card. For more information, refer to
“Installing the Memory Card” on page 4.
SD card Available Memory Status
To view the memory allocation for your external SD card:
1. From the Home screen, tap ➔ Settings ➔
SD card
and phone storage
.
2. The available memory displays under the
Total space
and
Available space
headings.
Erasing Files from the SD card
You can erase files from the SD card using the tablet.
1. Ensure the SD card is mounted. For more information,
refer to “Mounting the SD Card” on page 27.
2. From the Home screen, tap ➔
Settings
➔
SD card and
phone storage
.
3. Tap
Unmount SD card
.
4. Tap
Format SD card
.
5. At the
Format SD Card
confirmation prompt, Tap
Format SD
Card
.
Warning!:
Performing the next step erases all data stored on the SD card.
6. Tap
Erase everything
to format or to cancel.
30
Section 3: Entering Text
This section describes how to select the desired text input
method when entering characters into your tablet. This section
also describes the predictive text entry system that reduces the
amount of key strokes associated with entering text.
Your tablet comes equipped with an orientation detector that can
tell if the tablet is being held in an upright (Portrait) or sideways
(Landscape) orientation. This is useful when entering text.
Your tablet also provides several on-screen keypad text entry
options to make the task of text entry that much easier.
Text Input Methods
There are two text input methods available:
•
Swype
: a new way to enter text on touch screens. Instead of
tapping each key, use your finger to trace over each letter of a
word.
•
Samsung Keypad (default)
: an on-screen QWERTY keypad that
can be used in both portrait and landscape orientation.
The on-screen QWERTY keypad works the same in both portrait
and landscape mode.
Entering Text Using the Samsung QWERTY
Keypad
From a screen where you can enter text, rotate your tablet
counterclockwise to a Landscape orientation. The on-screen
QWERTY keypad will display.
New
Paragraph
Text Input Mode Keypad Settings
Shift
Key
Delete
Key
Space Bar
Hide Keypad
Send
Key
Entering Text 31
Changing the Text Input Mode - Keypad
There are two main keypad layout keys that will change the on-
screen keys within the QWERTY keypad.
The available Text Input modes are:
Sym
and
Abc
.
Note:
When in
Abc
mode, the
Sym
button will appear. When in
Sym
mode, the
Abc
/
ABC
/
abc
button will appear.
Using Abc Mode
1. If desired, rotate your tablet counterclockwise to a
Landscape orientation.
2. The following screen displays:
3. Tap the desired alphabetic characters.
4. The screen initially opens in Abc mode. After typing the
first letter, the shift key ( )will change to and
following letters will be lowercase.
5. Tap to input another upper-case letter or tap
twice to switch to ABC mode. The shift key will change to
in ABC mode. All following letters will be uppercase
until you tap the shift key again.
6. Tap to send the message or press for more
options. For more information, refer to “Creating and
Sending Messages” on page 61.
Symbol/Numeric Mode
: activates the number,
symbol, and emoticon keys.
Abc Mode
: activates the default alphabet keys. Can
also be set to
ABC
or
abc
by using the shift ( ) key.
123
ABC
32
Using Symbol/Numeric Mode
Use Symbol/Numeric Mode to add numbers, symbols, or
emoticons.
1. Rotate your tablet counterclockwise to a Landscape
orientation.
2. Tap at the bottom of the screen. The following screen
displays:
3. Tap the desired number, symbol, or emoticon characters.
4. Tap the button to cycle through additional pages.
5. Tap to return to Abc mode.
Using XT9 Predictive Text
XT9 is a predictive text system that has next-letter prediction and
regional error correction, which compensates for users pressing
the wrong keys on QWERTY keyboards.
1. Rotate your tablet counterclockwise to a Landscape
orientation.
2. Tap at the bottom of the screen. The
Samsung keypad
settings
screen displays.
3. Tap the
XT9
field. A green checkmark will appear next to
the field.
4. Tap the
XT9 advanced settings
field to modify XT9
associated settings. For more information, refer to
“Samsung Keypad settings” on page 85.
Note:
The XT9 option is available only when Abc mode has been selected.
123
1/3
ABC
Entering Text 33
5. Begin typing a word. A list of word options is displayed.
Tap one of the words to replace the word that has already
been typed or tap for more word choices.
6. Continue typing your message. Tap to send the
message or tap for more options. For more
information, refer to “Creating and Sending Messages” on
page 61.
Note:
You can also use XT9 mode in the portrait orientation.
Entering Text Using Swype
Swype™ is a text input method that allows you to enter a word by
sliding your finger or stylus from letter to letter, lifting your finger
between words. Swype uses error correcting algorithms and a
language model to predict the next word. Swype also includes a
tapping predictive text system.
Enabling and Configuring Swype
The Samsung keypad is the default text input method, so to use
Swype, you must first change the default keyboard setting.
To enable Swype:
1. From the Home screen, tap
Menu
➔
Settings
➔
Locale and text
➔
Select input method
.
2. Tap the
Swype
option.
3. Tap to return to the previous menu.
Swype Settings
For information on the Swype settings, see “Swype Settings” on
page 85.
Swype Text Entry Tips
You can access the SwypeTips application and watch a video or
tutorial on using Swype. You can also use the following Swype
text entry tips.
•
Create a squiggle (like an S shape) to create a double letter (such as pp
in apple).
•
Touch and hold a key to view the punctuation menu then make a
selection.
•
Move your finger or stylus over the apostrophe to enter contractions.
34
•
Double-tap on the word you want to change to correct a misspelled
word, then tap the delete key to erase one character. Touch and hold
the delete key to erase an entire word.
Contacts 35
Section 4: Contacts
This section allows you to manage your daily contacts by storing
their name and number in your Contacts List. Address Book
entries can be sorted by name, entry, or group.
Adding a New Contact
Use the following procedure to store a new contact to your
Address Book.
Saving a Number from the Home screen
1. From the Home screen, tap ➔
Contacts
➔
.
2. At the
Save contact to
prompt, tap
Tablet
or
Google
.
3. Tap the image icon and assign a picture to the new entry
by choosing one of three options:
•Album
to retrieve a previously stored image from your Pictures
folder and assign it to this entry. Tap an image to assign the image
to the contact, then tap
Save
.
•Take photo
to use the camera to take a new picture and assign it to
this entry.
4. Tap the
First name
and
Last name
fields and use the on-
screen keypad to enter names for each entry. For more
information, refer to “Entering Text” on page 30.
5. Tap next to the
Last name
field to display additional
name fields.
6. Tap the
Phone number
field.
The numerical keypad is displayed.
The
Mobile
button initially displays next to the
Phone number
field. If you want to add a phone number
that is not a mobile number, tap the
Mobile
button and
select from Mobile, Home, Work, Work fax, Home Fax,
Pager, Assistant, Other, or Custom (add your own label).
7. Enter the phone number.
Tap to add another Phone number field or tap to
delete a field.
8. Tap the
Email address
field.
The keypad is displayed.
Mobile
36
The
Work
button initially displays next to the
Email
address
field. If you want to add an Email address that is
not a Home email address, tap the
Home
button and select
from Work, Home, Mobile, Other, or Custom (add your own
label).
9. Enter the Email address.
Tap to add another Email address field or tap to
delete a field.
10. Tap the
Instant msg
field.
The QWERTY keypad is displayed.
The
Google Talk
button initially displays next to the
Instant msg
field. If you want to add an instant message
address that is not
Google Talk
, tap the
Google Talk
button
and select from Google Talk, AIM, Windows Live, Yahoo,
Skype, QQ, ICQ, Jabber, or Custom (add your own label).
11. Enter the Instant msg address.
Tap to add another Instant msg address field or tap
to delete a field.
12. Tap any of the following fields that you want to add to your
new contact:
• Groups
: assign the contact to Family, Friends, or Work group.
• Postal address
: used to assign a physical postal address for this
entry.
•Organization
: used to identify your contact’s organization.
•Job Title
: adds a Job Title field for this entry.
•More:
Tap
to add the following fields
:
–
Note
: adds a note filed.
–
NickName
: adds a field that can be used to enter a nickname for the
entry. The NickName is not displayed when calls are made to or
received from the contact.
–
Web address
: adds a field for the contact’s Web site URL.
–
Birthday
: adds a field for the contact’s birthday.
13. Tap
Save
to save the edited information.
Editing an Existing Contact
When editing an existing contact, you can tap a field and change
or delete the information, or you can add additional fields to the
contact’s list of information.
1. From the Home screen, tap ➔
Contacts
. Tap the
Contact that you want to edit.
2. Tap
Edit
.
Home
Google Talk
Contacts 37
3. Tap to add a new field and tap to delete a field.
4. Tap any of the fields to add, change, or delete information.
5. Tap
Done
to save the edited information.
Using Contacts
Finding an Address Book Entry
You can store phone numbers and their corresponding names
onto your Tablet or to Google memory. The two locations are
physically separate but are used as a single entity, called
Contacts
1. From the Home screen, tap ➔
Contacts
.
2. Within the Contacts list (sorted alphabetically), tap a letter
on the left side of the display to quickly jump to the
contacts beginning with that letter.
3. Tap the contact you wish to call or message.
4. Tap the phone number you wish to message.
The Messaging screen is displayed.
For more information, refer to “Creating and Sending
Messages” on page 61.
Joining Contacts
Joining Contact Information
Many people now maintain multiple email accounts, social
networking logins, and other similar account information. For
example, a Facebook account login name might differ from a
corporate email account login because they are maintained
separately and for different groups of people.
This device can synchronize with multiple accounts such as
Facebook, Twitter, MySpace, Corporate email, and Google. When
you synchronize your phone with these accounts, each account
creates a separate contact entry in the Contacts list.
If one of your contacts (Amy Smith, for example) has a regular
email account that you maintain in Gmail, but also has a
Facebook account under her maiden and married name, as well
as a Yahoo! chat account, when you merge these accounts into
your Contacts list you can link all of her entries and view the
information in one record.
The next time you synchronize your phone with your accounts,
any updates that contacts make to email account names, email
addresses, etc. automatically update in your contacts list.
For more information about synchronizing accounts, see
“Synchronizing Accounts” on page 40.
1. From the Home screen, tap ➔
Contacts
.
38
2. Tap a contact name (the name you want to link to another
entry).
Note
: typically this is the same contact with a
different name or account information.
3. Press ➔
More
➔
Join contact
.
4. Tap the second contact entry (the entry in which to link).
The second contact is now linked with the first and the
account information is merged into one screen.
Note:
The information is still maintained in both entries, but displays in one
record for easier viewing when you link the contacts.
5. Tap the linked contacts to view the contact information you
joined. The contacts and information displays with an icon
next to the contact name to indicate what type of account
information is contained in the entry.
Unjoining a Contact
1. From the Home screen, tap ➔
Contacts
.
2. Tap a contact name (the account name from which you
want to unlink an entry).
Note
: typically this is the same
contact with a different name or account information.
3. Tap
<number> Joined contacts
from the Joined Contacts
area.
4. Tap the minus sign next to entry in which you want to
unjoin. The contact is now “unjoined” and no longer
displays in the merged record screen.
Marking a Contact as Default
When you use messaging type applications, the application
needs to know which information is primary (default) in a contact
entry list. For example, you may have three different contact
records for John Smith, so the application will be looking for the
“default” number or entry.
1. From the Home screen, tap ➔
Contacts
.
2. Tap a Contact name.
3. Press ➔
More
➔
Set as default
. The Mark as default
screen displays radio buttons next to the contact names or
phone numbers of all the linked contacts. The radio button
next to the default contact will be green.
4. To change the default contact, tap the radio button next to
another entry that you want to be the default. The radio
button will turn green, then tap
Save
.
Contacts 39
Synchronizing Accounts
From the Accounts menu you decide if you want applications to
synchronize, send, and receive data at any given time, or if you
want the applications to synchronize automatically. After
determining how you want the accounts to synchronize, indicate
which account to synchronize with your Contacts list.
5. From the Home screen, tap ➔
Settings
➔
Accounts
and sync
.
6. From the General sync settings section, tap one of the
following options:
• Background data
: allows your phone to use data in the
background.
• Auto-sync
: automatically synchronizes your data with the phone.
7. Under the Manage accounts heading, tap next to the
account you want to synchronize with your tablet.
8. Tap
Add account
to create a new account.
9. Tap an account type to add.
10. Follow the on-screen instructions. The selected account
type synchronizes with your Contacts list.
Contacts Options
You can access Contacts options while at the main Contacts List
page or while in the details page for a specific entry.
Options in Contacts
1. From the Home screen, tap ➔
Contacts
➔ .
2. The following options display:
• Get friends
: allows you to get contacts from your friends on
Facebook, Twitter, or MySpace. You can also get contacts from
Corporate or Google accounts. Tap
Add account
and then follow
the on-screen instructions. For more information, refer to
“Synchronizing Accounts”
on page 40.
• Delete contacts
: allows you to tap on each contact that you want
to delete. Tap Delete when finished.
• My profile:
allows you to set up a profile for yourself. The information will
be the same that you can add for a new contact. For more information,
refer to “Adding a New Contact” on page 56.
•
Set default
: when you have multiple contacts linked together, you can
mark one of them as default (only displays when contact is saved to the
phone). For more information, refer to “Marking a Contact as Default” on
page 61.
•More
: the following additional options are displayed:
–
Join contact
: allows you to link contacts with other contacts.
–
Send email
: allows you to send an email using your Google account.
40
–
Settings
: allows you to select where your contacts will be saved to and
also access Service numbers.
Groups
Creating New Group
1. From the Home screen, tap ➔
Contacts
➔
Groups
➔ .
2. Tap the
Group name
field and use the on-screen
keypad to enter a new group name. For more information,
refer to “Entering Text” on page 30.
3. Tap
Done
to store the new Group category.
Adding an Entry to a Group
1. From the Home screen, tap ➔
Contacts
.
2. Press and hold a contact entry.
3. Tap
Add to group
.
4. Tap the group you want to add the contact to. The contact
is added to the group.
Removing an Entry From a Group
1. From the Home screen, tap ➔
Contacts
➔
Groups
.
2. Tap a group entry.
3. Tap the contact you want to remove from this group.
4. When the contact information is displayed, tap
Delete
.
The contact is removed from the group.
??? Not working correctly - this totally deletes contact
Editing a Caller Group
To edit a Group entry, there must be at least one member as part
of the selected group.
1. From the Home screen, tap ➔
Contacts
➔
Groups
.
2. Tap a group entry.
3. Press ➔
Edit group
.
4. Make modifications to the
Group Name
or
Edit member
. For
more information, refer to “Creating New Group” on
page 42.
5. Tap to store your changes.
Contacts Favorites
Once you have stored phone numbers in the Address Book, you
can add them to your Favorites list.
Save
Contacts 41
Adding Favorites to your Contacts
1. From the Home screen, tap ➔
Contacts
.
2. Within the Contacts list, touch and hold a contact that you
want to add to your favorites list.
3. Tap
Add to favorites
on the displayed list.
4. A star will appear next to the contact in the Contacts list.
Removing Favorites from your Contacts
1. From the Home screen, tap ➔
Contacts
.
2. Within the Contacts list, touch and hold a contact that you
want to remove from your favorites list.
3. Tap
Remove from favorites
on the displayed list.
4. The star will no longer appear next to the contact in the
Address Book.
Deleting Contact Entries
You can delete entries from your phone’s memory.
1. From the Home screen, tap ➔
Contacts
.
2. Within the Contacts list, tap a contact that you want to
delete.
3. Tap
Delete
on the displayed screen.
4. At the
Delete
prompt, tap
OK
to delete the contact or
Cancel
to exit.
Multimedia 45
Section 5: Multimedia
This section explains how to use the multimedia features of your
phone, including Media Hub, Music Player, Video Player, Gallery,
Camera, and Camcorder.
Media Hub
Samsung Media Hub is your one stop for the hottest movie and
TV content. With hundreds of titles available at your fingertips,
entertaining yourself or your kids on the go has never been
easier. You can rent or purchase your favorite content and watch
from the convenience of anywhere. Featuring the stunning
viewing quality Samsung is known for, Samsung Media Hub is
your gateway to mobile video like you've never experienced it
before.
Note:
Media Hub usage is based on service availability.
Using Media Hub
1. Sign on to your Google account. For more information,
refer to “Signing into Your Gmail” on page 68.
2. Tap ➔
Media Hub
.
3. Read the End-User License Agreement (EULA) and tap
Accept
to continue or
Decline
to exit.
The Media Hub screen displays.
4. In order to rent or buy media, you must first create an
account. Press ➔
My Account
.
5. Tap
CREATE ACCOUNT
and use the keypad to enter the
required information.
6. At the Media Hub screen, the following options appear:
• New in store
: shows recently added media that you can rent or
purchase.
•My Media
: allows you to view all of the media that you have
purchased or rented. Tap a media entry to view it.
•Movie Store
: displays movies that are available for rent or
purchase. Scroll through the movie categories at the top of the
screen. Tap a category and then movies of that type will be
displayed below. Major categories include Paramount, Action,
Romance, Sci-Fi, Family, Comedy, Thriller, Sony Pictures, and
Drama.
• TV Store
: displays TV shows that are available for purchase. Scroll
through the movie categories at the top of the screen. Tap a
category and then TV shows of that type will be displayed below.
Major categories include Action, Drama, and Comedy.
46
7. Scroll through the media listings and tap on an item you
would like to purchase or rent.
8. Information concerning the media displays. Tap
WATCH
PREVIEW
to watch a short preview or tap
Rent
or
Own
.
9. Choose a payment method and then follow the on-screen
instructions.
10. Your purchase is stored in the My Media section.
Music Player
The Music Player is an application that can play music files. The
music player supports files with extensions AAC, AAC+, eAAC+,
MP3, WMA, 3GP, MP4, and M4A. Launching the Music Player
allows you to navigate through your music library, play songs,
and create playlists (music files bigger than 300 KB are
displayed).
Playing Music
1. Tap ➔
Music
.
2. Tap a library category at the top of the screen (Songs,
Playlists, Albums, Artists, or Genres) to view the available
music files.
3. Scroll through the list of songs and tap an entry to begin
playback.
4. The following Music Player controls are available:
Note:
The 5.1 channel sound effect works in earphone mode only.
Pause the song.
Start the song after being paused.
Press and hold to rewind the song. Tap to go to
previous song.
Press and hold to fast-forward the song. Tap to go
to next song.
Volume control.
Repeat one: repeats the currently playing song.
Repeat all: replays the current list when the list ends.
Play All: plays the current song list once.
Shuffle On: the current list of songs are randomly
shuffled for playback.
Shuffle Off: songs play in order and are not shuffled.
Displays your list of songs.
List
Multimedia 47
Music Options
To access additional options, follow these steps:
1. While in the Music, press .
2. The follow options are available:
• Add to playlist:
allows you to add the current music file to a
selected playlist.
• Delete
: allows you to delete any song.
•Share Via
: allows you to share the music using Bluetooth or Gmail.
• Settings
: allows you to change the following settings:
–
Equalizer
: set a type of equalization. Selections are: Auto, Normal, Pop,
rock, Jazz, Dance, Classic, Live, or Custom.
–
Effect
: configure the music effects. Selections are: Normal, Wide,
Concert Hall, Music clarity, Bass enhancement, or Externalization.
–
Music menu
: this menu allows you to select which categories you
want to display. Choices are: Albums, Artists, Genres, Composers,
Years, Most played, Recently played, or Recently added. Tap each item
that you want to display in the Music menu.
Using Playlists
Playlists are used to assign songs to a list of preferred media
which can then be grouped into a list for later playback. These
Playlists can be created via either the handset’s Player options
menu or from within a 3rd party music application (such as
Windows Media Player) and then downloaded to the handset.
Creating a Playlist
1. From the Home screen, tap ➔
Music
.
2. Tap the
Playlists
tab.
3. Press ➔
New playlist
.
4. Type a name for this playlist in the field and tap
OK
.
Adding Music to a Playlist
To add files to the playlist:
1. From the Home screen, tap ➔
Music
.
2. Tap the
Playlists
tab.
3. Tap the playlist name in which to add music.
4. Press ➔
Add songs
.
5. Tap a music file, or tap
Select all
to add all the music tracks
to this playlist then tap
Add
.
Removing Music from a Playlist
To remove music files from a playlist:
1. From the Home screen, tap ➔
Music
.
2. Tap the
Playlists
tab.
3. Tap the playlist name in which to delete music.
48
4. Press ➔
Remove
.
5. Tap the checkbox to the right of each track you want to
remove from this playlist, or tap
Select all
to remove all the
music tracks from this playlist, then tap
Remove
.
Editing a Playlist
Besides adding and removing music files in a playlist, you can
also rename the playlist.
To edit a playlist:
1. From the Home screen, tap ➔
Music
.
2. Tap
Playlists
.
3. Tap a playlist name to edit.
4. Press ➔
Rename
.
5. Tap the
Name
field for the selected playlist, enter a new
name for the playlist then tap
OK
.
For information on downloading music for your phone, see
“Market” on page 116.
Video Player
The Video Player application plays video files stored on your
microSD card.
1. Tap ➔
Video
.
2. All videos that you have on your memory card will be
displayed. Tap the video that you want to play.
3. The video will begin to play.
4. The following video controls are available:
Note:
The 5.1 channel sound effect works in earphone mode only.
For more information on downloading videos for your phone, see
“Market” on page 116.
Pause the video.
Start the video after being paused.
Rewind the video.
Fast-forward the video.
Volume control.
Full-screen view.
Medium-screen view.
Minimum-screen view.
Multimedia 49
Gallery
The Gallery is where you view photos and play back videos. For
photos, you can also perform basic editing tasks, view a
slideshow, set photos as wallpaper or contact image, and share
as a picture message.
1. Tap ➔
Gallery
.
All of the Albums that hold your pictures and videos will be
displayed with folder name and number of files.
2. Tap an Album and thumbnails of the contents will be
displayed.
Note:
If your device displays that the memory is full when you access Gallery,
delete some of the files by using
My Files
or other file management
applications and try again. For more information, refer to “My Files”
on page 117.
Viewing Pictures
1. Tap a thumbnail to view the picture.
Note:
If no control icons are displayed on the screen in addition to the
picture, tap anywhere on the screen to display them.
2. Tap
Slideshow
to see a slideshow of all the pictures in the
folder.
3. Tap
Menu
for the following options:
•Share
: allows you to share the picture via Picasa, AllShare,
Messaging, Gmail, Bluetooth, or Online Locker.
• Delete
: allows you to delete the picture. Tap
Confirm deletions
and
the picture will be deleted.
•More
: displays the following additional options:
–
Details
: provides details about the picture such as Title, Type, Date
taken, name of the Album it is in, Latitude and Longitude (GPS
coordinates), Size, and Resolution.
–
Set as
: allows you to set the picture as Wallpaper or as a Contact icon.
–
Crop
: allows you to crop the picture. Tap the orange box and move it to
the desired location and tap
Save
. The area within the orange box will
be the area cropped and will be saved in place of the old picture.
–
Rotate left
: rotates the picture to the left.
–
Rotate right
: rotates the picture to the right.
Viewing Videos
Note:
If no control icons are displayed on the screen in addition to the
picture, tap anywhere on the screen to display them.
1. Tap ➔
Gallery
.
2. Touch and hold a video to select it. An arrow will appear on
the thumbnail.
3. The following options are available:
50
•Share via
: allows you to share the picture via YouTube, AllShare,
Messaging, Gmail, Bluetooth, or Online Locker.
• Subtitles
: allows you to see subtitles for a video if available.
• Details
: provides details about the picture such as Name, Size,
Resolution, Duration, Format, and Date Taken.
4. Tap a thumbnail to play the video.
For video player controls, see “Video Player” on page 48.
Camera
This section explains how to use the camera on your phone. You
can take photographs and shoot video by using the built-in
camera functionality. Your 5 megapixel camera produces photos
in JPEG format.
Important!:
Do not take photos of people without their permission.
Do not take photos in places where cameras are not allowed.
Do not take photos in places where you may interfere with
another person’s privacy.
Using the Camera
Taking Photos
Taking pictures with your device’s built-in camera is as simple as
choosing a subject, pointing the camera, then pressing the
camera key.
Note:
When taking a photo in direct sunlight or in bright conditions, shadows
may appear on the photo.
1. From the Home screen, tap ➔
Camera
to
activate the camera mode.
2. Using the phone’s main display screen as a viewfinder,
adjust the image by aiming the camera at the subject.
3. Before you take a picture, use the
Up
and
Down
Volume
keys to zoom in or out. You can magnify the picture up to
x4 (400 percent).
4. If desired, before taking the photo, you can tap on-screen
icons to access various camera options and settings.
5. You can also tap the screen to move the focus to the area
you tap.
6. Press the Camera key until the shutter sounds. (The
picture is automatically stored within your designated
storage location. If no microSD is installed, all pictures are
stored on the Phone.) For more information, refer to
“Camera and Camcorder Options” on page 52.
Multimedia 51
Note:
The number of JPEG pictures remaining on the selected media appears
in the upper-right of the screen. This is an approximate number of total
pictures that can be taken at the current image size.
7. While viewing a picture, after you have taken it, tap to
zoom in or to zoom out.
– or –
Tap each side of the picture and swipe outward or inward
to zoom in or out.
You can magnify the picture up to x4.
8. Press to return to the viewfinder.
Camera and Camcorder Options
Options are represented by icons across both sides of the screen.
Note:
The options disappear after a few seconds. Tap the screen to make
them reappear.
Display Image
Resolution
Settings
Pictures Remaining
Current Configurations
Camera
Key
Viewer
Mode
Camera / Camcorder Mode
: allows you to take a photo in
various modes. Move the slider, located on the top right of
the display to the up position to use the Camera or the
down position to use the Camcorder.
Recording mode
: allows you to set the recording mode to
either: Normal, which is limited only by available space on
the destination location, or Limit for MMS, which is limited
by MMS size restrictions. Recording mode is only available
in Camcorder mode.
52
Shooting mode
: allows you to set the shooting mode.
Options are:
•
Single shot
: takes a single photo and view it before
returning to the shooting mode.
•
Continuous
: takes a succession of consecutive photos
by pressing and holding the Camera key.
•
Panorama
: takes a landscape photo by taking an
initial photo and then adding additional images to
itself. The guide box lets you view the area where the
second part of the panoramic picture should fall
within.
•
Smile shot
: the camera focuses on the face of your
subject. Once the camera detects the person’s smile,
it takes the picture.
•
Self shot
: allows you to take a picture with the camera
located on the front of the tablet.
Scene mode
: allows you to set the Scene to help take the
best pictures possible. Options include None, Portrait,
Landscape, Night, and Sports. Helpful tips are shown for
each scene mode at the bottom of the display screen.
Exposure value
: allows you to adjust the brightness level
by moving the slider across the page.
Settings
: allows you to customize your camera and
camcorder settings. Choose from the following options:
Camera and Camcorder
:
•
Outdoor visibility
: allows you to take better pictures
when outdoors.
•
Timer
: allows you to set a timer for how long to wait
before taking a picture. Options include: Off, 2
Seconds, 5 Seconds, and 10 Seconds.
•
White balance
: allows you to set this option to one of
the following choices: Auto, Daylight, Cloudy,
Incandescent, or Fluorescent.
•
Effects
: allows you to change the color tone or apply
special effects to the photo. Options include: Normal,
Negative, Black and White, or Sepia.
•
Adjust
: allows you to adjust Contrast, Saturation, and
Sharpness.
Multimedia 53
Camera
:
•
Resolution
: allows you to set the image size to either:
5M (2560x1920), W4M (2560x1536),
3.2M (2048x1536), W2.4M (2048x1232),
2M (1600x1200), W1.5M (1600x960),
0.3M (640x480), or W0.4M(800x480).
•
Focus mode
: allows you to set this option to Auto
focus, Macro, or Face detection. Use Macro mode to
take close-up pictures. Face detection causes the
camera to automatically recognize if there is a face in
the shot. It then optimizes the focus and exposure the
face. Use Auto focus for all others.
•
ISO
: ISO determines how sensitive the light meter is
on your digital camera. Choose from Auto, 100, 200,
400, or 800. Use a lower ISO number to make your
camera less sensitive to light, a higher ISO number to
take photos with less light, or Auto to let the camera
automatically adjust the ISO for each of your shots
•
Metering
: allows you to set how the camera measures
or meters the light source: Centre-weighted, Spot, or
Matrix.
•
Anti-Shake
: reduces image blur due to the movement
of the subject of the photo or hand movement.
•
Auto contrast
: provides a clear image even under
backlight circumstances where intensity of
illumination can vary excessively.
•
Blink detection
: detects the blinking of human eyes
and give you a warning.
•
Image quality
: allows you to set the image quality to:
Superfine, Fine, or Normal.
Camcorder
:
•
Resolution
: allows you to set the video size to either:
1280x720, 720x480, 640x480, 320x240, or
176x144.
•
Video quality
: allows you to set the video quality to:
Superfine, Fine, or Normal.
54
Accessing Pictures
When you take a picture, the file is saved in the Camera folder.
You can view your pictures immediately or view them anytime in
the Camera folder.
1. From the Home screen, tap ➔
My Files
➔
DCIM
➔
Camera
.
2. Tap a photo file to open it in the Image viewer.
Touch and drag a picture to the left to see the next picture or to
the right to see the previous picture.
Before you select a picture, press in the Camera folder to
see the following options:
•
Share
: lets you share selected pictures with Picasa, AllShare,
Messaging, Gmail, Bluetooth, or YouTube.
Additional Camera and Camcorder Settings
:
The following are additional camera and camcorder
settings.
•
Guidelines
: allows you to turn the guidelines On or Off.
•
Audio recording
: allows you to record audio while
recording video. Selecting Off, temporarily mutes the
microphone and records only video. (Only available in
Camcorder mode).
•
Review
: allows you to activate the instant review
feature where images are displayed immediately after
review (On or Off, or 2 seconds for Camera mode).
•
GPS
: allows you to turn GPS On or Off (also known as
Geotagging). The location of where the picture is
taken is attached to the picture. (Only available in
Camera mode.)
•
Shutter Sound
: allows you to set the Shutter sound to
3 different shutter sounds. Or, you can turn it off.
(Only available in Camera mode).
•
Storage
: allows you to configure the default storage
location for images or videos as either Phone or
Memory card (if inserted).
•
Reset
: allows you to reset all camera or camcorder
settings.
Multimedia 55
•
Delete
:
allows you to delete selected pictures. Tap the checkmark, to turn
it green, next to any file or folder you want to delete, then tap
Delete
.
•
More
: provides you with the additional options: Move, Copy, Rename,
Bluetooth visibility, and Settings.
–
Details:
allows you to view the Title, Type, Date taken, Album, and
Location.
–
Set as:
allows you to set the picture as Wallpaper or a Contact icon.
–
Crop:
allows you to move a square to the portion of the picture to be
cropped. Press and hold on the side of the square to enable arrows to
resize the cropping area. Press
Save
.
–
Print:
allows you to send the picture to a selected printer.
–
Rotate left:
allows you to rotate the picture to the left.
–
Rotate right:
allows you to rotate the picture to the right.
Selecting and Using the Pictures
From the Image viewer, you have access to both macro functions
(zoom, crop, and rotate) and menu options. For more information,
refer to “Pictures and Videos Image Viewer Options” on page 56.
Editing a Photo
1. From the Home screen, tap ➔
My Files
➔
DCIM
➔
Camera
➔
<image>
.
2. Tap
Menu
➔
More
to access the following editing options:
•Crop
: allows you to crop the image. Tap and drag the sides of the
crop box to create the crop area, then tap
Save
. Tap
Discard
to
stop without cropping the picture.
•Rotate left
: allows you to rotate the picture counterclockwise 90
degrees.
• Rotate right
: allows you to rotate the picture clockwise 90 degrees.
Assigning an Image to an Address Book Entry
1. From the Home screen, tap ➔
My Files
➔
DCIM
➔
Camera
➔
<image>
.
2. Tap
Menu
➔
More
➔
Set as
➔
Contact icon
. Tap a contact
entry and tap Save.
– or –
Tap
Menu
➔
More
➔
Set as
➔
Contact icon
➔
Create contact
to create a new Address Book entry with the image already
assigned. For more information, refer to “Contacts” on
page 35.
Assigning an Image as a Wallpaper
1. From the Home screen, tap ➔
My Files
➔
DCIM
➔
Camera
➔
<image>
.
2. Tap
Menu
➔
More
➔
Set as
➔
Wallpaper
.
56
3. Touch and drag the crop box anywhere on the picture.
Touch and drag the sides of the crop box to zoom in or out
to create a cropped area.
4. Tap
Save
to assign the wallpaper image. Tap
Discard
to
stop without updating the wallpaper image.
Using the Camcorder
In addition to taking photos, the camera also doubles as a
camcorder that also allows you to record, view, and send videos.
Note:
The camera may not be able to properly record videos to a memory
card with a slow transfer speed.
Shooting Video
Tip:
When shooting video in direct sunlight or in bright conditions, it is
recommended that you provide your subject with sufficient light by
having the light source behind you.
1. From the Home screen, tap ➔
Camera
to
activate the camera mode.
2. Tap the Camera mode icon ( ) to switch to Camcorder
mode ( ).
3. Using the phone’s main display screen as a viewfinder,
adjust the image by aiming the camcorder at the subject.
4. Press the Video key ( ) to begin shooting video.
5. Tap to pause the recording or tap to stop the
recording and save the video file to your Camera folder.
6. Once the file has been saved, tap to play your video
for review.
7. Press to return to the viewer.
Camcorder Options
Camcorder options are represented by icons across both sides of
the screen.
For more information, refer to “Camera and Camcorder Options”
on page 52.
Camcorder Options after a Video is Taken
After you shoot a video, you can access various options from the
Pictures and Videos Image Viewer
䊳
The following options are available:
•
Share
: offers several ways to share your video. Options are: AllShare,
Bluetooth, Gmail, Messaging, and YouTube.
•
Play
: allows you to play the video.
Multimedia 57
•
Delete
: allows you to delete the current video. Tap
OK
to delete or
Cancel
.
Accessing Videos
When you shoot a video, the file is saved in the Camera folder.
You can view your videos immediately or view them anytime in
the Camera folder.
1. From the Home screen, tap ➔
My Files
➔
DCIM
➔
Camera
.
2. Tap a video file to open it in the viewer and initiate
playback.
3. To pause the video, tap . To play the video, tap .
Before you select a video to play, press in the Camera folder
to see the following options:
•
Share
: lets you share the selected videos with Picasa, AllShare,
Messaging, Gmail, Bluetooth, or YouTube.
•
Create folder
: create a new sub-folder in the current folder. Can be on
either the Phone or Memory Card.
•
Delete
:
allows you to delete selected videos. Tap the checkmark, to turn
it green, next to any file or folder you want to delete, then tap Delete.
•
View by
: allows you to view the contents of the current folder as a list,
as a list and details, or as thumbnails.
•
List by
: allows you to view the contents of the current folder sorted by
Time, Type, Name, or Size.
•
More
: provides you with the additional options: Move, Copy, Rename,
Bluetooth visibility, and Settings.
–
Move
: allows you to move one or more videos to a different folder.
–
Copy
: allows you to copy one or more videos to a different folder.
–
Rename
: allows you to rename one or more video files.
–
Bluetooth visibility
: allows you to make one or more videos visible to
Bluetooth devices.
–
Settings
: lets you set several general folder options:
• Show hidden files
: causes files and folders that would normally be
hidden to be displayed.
• Show file extension
: causes file extensions to be displayed. For
example, 3gp.
• Set Home Directory
: allows you to choose and set the Home
directory.
• Delete licenses
: allows you to delete licenses for all files in the
folder.
Once you have selected a video to play, press to display the
following options:
•
Share video
: to share the current video by way of YouTube, AllShare,
Messaging, Gmail, Bluetooth, or Online Locker.
•
Details
: displays file information such as file name, format, resolution,
and file size.
•
Add bookmark
: adds this video to the Bookmarks list.
58
•
Bookmarks
: display Bookmarks. To remove Bookmarks tap
Remove
,
tap each Bookmark you want to remove, and tap
Done
.
•
Via Bluetooth
: scans for a Bluetooth device on which to play the video.
While viewing a video, you can also adjust the display mode.
Display mode allows you to select Original Size, Full-Screen, or
Full-Screen in Ratio to view your video.
•
Original Size
: the Original Size icon ( ) displays when the video is
being played in its original size.
•
Full-Screen View
: the entire screen is used, which may cause some
minor distortion. Tap the Full-Screen View icon (
)
to return to the
original size.
•
Full-Screen in Ratio View
: the video is enlarged as much as possible
without becoming distorted. Tap the Full-Screen in Ratio View icon
( ) to return to the original size.
•
Pause/Resume
: tap
to pause
the video being played. Tap
to
resume playing.
•
Previous/Next
:
tap
to jump to the previously played video or tap
to jump to
the next video file in the Camera folder.
•
Exit
: press to go back to the videos list.
Messaging 61
Section 6: Messaging
This section describes how to send and receive different types of
messages. It also includes the features and functionality
associated with messaging.
Types of Messages
Your phone provides the following message types:
•
Multimedia (Picture, Video, and Audio) Messages
•
Email and Gmail Messages
•
Google Talk
Options while composing a message
1. While composing a message, press to reveal
additional messaging options.
• Send:
allows you to send the message.
• Save as draft:
allows you to save the message as a draft.
• Add/Remove Cc/Bcc
: allows you to copy or blind copy other
numbers. You may manually enter a number or choose from
Recent, Contacts, or Group. You may also delete existing Cc/Bcc
numbers.
• Attach
: allows you to attach the following:
–
Pictures
: allows you to tap an existing image from your Pictures list to
add it to your message.
•
•Discard
: allows you to delete the message without saving it to your
Drafts folder.
Using Email
Email enables you to review and create email using AIM®, AOL®,
Yahoo!® Mail, Comcast, Compuserve, Earthlink, Gmail, HotPOP,
Juno, Mac, NetZero, SBC Yahoo!, Verizon and several other email
services. You can also receive text message alerts when you
receive an important email.
Signing into Your Email
1. From the Home screen, tap
Email
.
Your accounts screen displays with an Email setup screen
displayed.
2. Enter you email address in the
Email
address
field.
3. Enter your password in the
Password
field, press
Next
then
press
OK
.
4. Tap
Next
at the
Your accounts
screen.
5. Tap
Exchange email
or
Other email
.
6. Tap
Next
several times to go through the ActiveSync
tutorial.
62
7. Input your
Server URL
and
Domain
information.
8. Select a security type from the
Security type
drop-down
list.
9. Press
Next
.
Important!:
Only some “Plus” accounts include POP access allowing this
program to connect. If you are not able to sign in with your
correct email address and password, you may not have a paid
“Plus” account. Launch the Web browser to access your
account.
Synchronizing a Corporate Email Account
Use the following procedure to configure your phone to
synchronize with a corporate email account.
1. From the Home screen, tap
Email
.
Your accounts screen displays with an Email setup screen
displayed.
2. Press
Next
.
3. From the Set up email screen, tap the
Exchange email
field
and enter your corporate email address.
4. Tap the
Password
field and enter your password.
Important!:
Only some “Plus” accounts include POP access allowing this
program to connect. If you are not able to sign in with your
correct email address and password, you may not have a paid
“Plus” account. Launch the Web browser to access your
account.
5. Tap
Skip
to manually set up the account, or tap
Next
to
read the tutorial.
6. Enter all the Exchange server information, Username and
Password, then tap
Next
.
7. At the Certificate prompt tap
Yes
.
8. Enter your Account name.
Wait for the Inbox to synchronize before use.
9. Press ➔
Advanced Settings
to change the
synchronization timing, frequency, and other options.
Using Gmail
Gmail is Google’s web-based email. When you first setup the
phone, Gmail is configured. Depending on the synchronization
settings, Gmail is automatically synchronized with your Gmail
account.
Signing into Your Gmail
1. From the Home screen, tap ➔
Gmail
.
Messaging 63
Note:
You must sign in to your Gmail account in order to access Gmail.
2. Sign in if you have a Google account, or tap
Create an
account
and tap
OK
.
The Inbox loads conversations and email.
Refreshing Gmail
䊳
Press ➔
Refresh
to send and receive new emails and
synchronize your email with the Gmail account.
Creating a Gmail Message
1. From the Gmail Inbox, press ➔
Compose
.
2. Enter the recipients Email address in the
To
field.
Separate multiple recipient email addresses with a
comma.
3. Press and select
Add Cc/Bcc
to add a carbon or blind
copy.
4. Enter the subject of this message in the
Subject
field.
5. Tap the
Compose Mail
field and begin composing your
message.
6. Tap
Send
when you are done.
Viewing an Gmail Message
1. From the Gmail Inbox, tap a message to view it. The
following options are available:
•Archive
: archives the selected Email.
• Delete
: deletes the Email.
•Older
: displays older Emails.
2. Press to select one of the following additional options:
• Change labels
: changes the label on the email or conversation.
• Add/Remove star
: click a message's star to add or remove the
star (just like clicking flags in Outlook).
• Mark unread
: Unread messages or threads with unread messages
display in boldface text in the Inbox.
• Go to Inbox
: returns you to your Gmail Inbox.
•
Mute
: mutes the conversation.
•More
:
–
Report spam
: reports the Email message as spam.
–
Select text:
allows you to press on text and it temporarily copies to be
pasted.
–
Settings:
allows you to review the General settings: Signature, Confirm
actions, Auto-advance, Message text size, Batch operations, Clear
search history.
–
Help:
launchs the Google Mobile Help screen for additional help.
64
Google Talk
Google Talk is a free Windows and web-based application for
instant messaging offered by Google. Conversation logs are
automatically saved to a Chats area in your Gmail account. This
allows you to search a chat log and store them in your Gmail
accounts.
1. From the Home screen, tap ➔
Talk
.
2. Press
Next
to set up a Google account or to Sign in.
3. Tap
Create
to create a new Google account.
– or –
Tap
Sign in
if you have an existing Google account.
4. After entering your user name and password, press the
Down
Navigation key.
5. Tap
Sign in
.
6. Begin using Google Talk.
Note:
The Network confirms your login and processes. This could take up to
5 minutes to complete.
70
Section 7: Changing Your Settings
This section explains the sound and phone settings for your
phone. It includes such settings as: display, security, memory,
and any extra settings associated with your phone.
Wireless
Flight mode
Flight mode allows you to use many of your phone’s features,
such as Camera, Games, and more, when you are in an airplane
or in any other area where making or receiving calls or data is
prohibited.
Important!:
When your phone is in Airplane Mode, it cannot send or receive
any calls or access online information or applications.
Activating Wi-Fi
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Wi-Fi settings
.
2. Tap
Wi-Fi
. A check mark displayed indicates Wi-Fi is
active.
For more information, refer to “Wi-Fi” on page 96.
Network Notification
By default, when Wi-Fi is on, you receive notifications in the
Status bar anytime your phone detects an available Wi-Fi
network. You can deactivate this feature if you do not want to
receive notifications.
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Wi-Fi settings
.
2. Tap
Network notification
. A check mark displayed next to
the feature indicates Network notification
is active.
3. Tap
Network notification
again to remove the checkmark
and deactivate this feature.
WPS Button Connection
The WPS (Wi-Fi Protected Setup) button is a standard for easy
and secure wireless network set up and connections. To use
WPS, the connecting device must support WPS and be
compatible with Wi-Fi Protected Access (WPA) security. WPS can
automatically set up a random network name and WPA wireless
security for wireless Wi-Fi phones, routers, access points,
computers, adapters, and other electronic devices.
Changing Your Settings 71
WPS allows you to push buttons instead of entering a network
name and wireless security PIN.
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Wi-Fi settings
.
2. Tap
WPS button connection
.
3. Press the WPS button on your Wi-Fi access point within 2
minutes.
Bluetooth settings
In this menu you can activate Bluetooth, view or assign a device
name, activate your phone so other Bluetooth devices can
discover it, or scan for other, available Bluetooth devices with
which to pair.
Activating Bluetooth
䊳
From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Bluetooth settings
and tap
Bluetooth
to turn
it on.
Device Name
1. Activate Bluetooth. For more information, refer to “Turning
Bluetooth On and Off” on page 99.
2. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Bluetooth settings
and tap
Device name
.
The assigned device name displays.
3. Press to erase the current device name and enter a
new name for this device using the keyboard.
4. Press
OK
to confirm your setting.
Visible
䊳
From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Bluetooth settings
and tap
Visible
.
The phone is now activated for discovery for 119 seconds
so you can pair with another device. After 119 seconds the
phone becomes undiscoverable again.
Scan Devices
This option allows you to scan for active Bluetooth devices so you
can pair with them.
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Bluetooth settings
and tap
Scan devices
.
Your phone begins scanning and lists any discovered
devices in the Bluetooth devices section.
2. Tap a device name to pair with the device.
72
Important!:
Some Bluetooth devices are secured and require a PIN number to
confirm and pair with them.
3. Enter a PIN to pair with the device, if one is required, and
tap
OK
.
USB Settings
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
USB settings
.
2. Select one of the following USB settings:
• Kies (Firmware update)
: a software suite that allows you to search
and download applications directly from a PC. The applications are
then installed onto a mobile device when synced with a PC,
providing instant back up and peace of mind for application
downloads. For more information, refer to
“Connecting with
Kies”
on page 103.
•Media player
: connects your device to a PC in order to synchronize
files with Windows Media Player. For more information, refer to
“Synchronizing with Windows Media Player”
on
page 136.
• Mass storage
: allows you to use the onboard storage capacity of
the phone to store and upload files. This option allows your
computer to detect the phone as a removable storage drive. For
more information, refer to
“Connecting as a Mass Storage
Device”
on page 136.
• Ask on connection
: allows you to make a USB setting selection as
soon as the USB cable from your phone is connected with a PC.
Note:
To use any downloaded market application that requires a USB
connection between your tablet and your PC, you should first set the
USB setting to
Mass storage
.
Sound Settings
From this menu you can control the sounds on the phone as well
as configure the display settings.
䊳
From the Home screen, tap ➔
Settings
➔
Sound
settings
.
The following options display:
Silent mode
Silent mode is convenient when you wish to stop the tablet from
making noise, in a theater for example. In Silent Mode the
speaker is muted and the tablet only vibrates to notify you of
incoming calls, or other functions that normally have a defined
tone or sound as an alert.
1. From the Home screen, tap ➔
Settings
➔
Sound
settings
.
2. Tap
Silent mode
.
– or –
Changing Your Settings 73
From the Home screen, press the
Lock
key until
Phone
options
displays.
3. Tap
Silent mode
to activate or deactivate this mode (the
current mode displays).
Vibrate
Vibrate mode allows your tablet to vibrate instead of a tone.
1. From the Home screen, tap ➔
Settings
➔
Sound
settings
➔
Vibrate
.
2. Tap
Always
,
Never
,
Only in silent mode
,
or Only when not in
silent mode
.
Volume
There are multiple ways to adjust the ringer volume.
1. From the Home screen, press the
Down
Volume key.
– or –
From the Home screen, tap ➔
Settings
➔
Sound
settings
.
2. Tap
Volume
.
3. Touch and drag the sliders to adjust the sound for the
Media
,
Alarm
,
System
,
and Notification
.
4.
Tap
OK
.
Notification ringtone
1. From the Home screen, tap ➔
Settings
➔
Sound
settings
➔
Notification ringtone
.
2. Tap a ringtone and tap
OK
.
Audible Tone Settings
The Audible touch tones and Audible selection options are used
when you use the dialing pad or making a screen selection. Each
time you press a key or make a selection the selected tone
sounds.
1. From the Home screen, tap ➔
Settings
➔
Sound
settings
.
2. Tap
Audible touch tones
or
Audible selection
. A check mark
displayed next to these features indicates active status.
Screen lock sounds
This option plays a sound when you lock or unlock your screen.
1. From the Home screen, tap ➔
Settings
➔
Sound
settings
.
2. Tap
Screen lock sounds
. A check mark displayed next to
the feature indicates the option is active.
74
Haptic feedback
This option allows your tablet to vibrate when pressing softkeys
and on certain user interface interactions.
1. From the Home screen, tap ➔
Settings
➔
Sound
settings
.
2. Tap
Haptic feedback
to make a checkmark.
Vibration intensity
This option allows you to set your touch feedback vibration
intensity.
1. From the Home screen, tap ➔
Settings
➔
Sound
settings
➔
Vibration intensity
.
2. Move the slider with your finger to set the Vibration
intensity, then tap
OK
.
Display Settings
In this menu, you can change various settings for the display
such as the font, brightness, color densities, animation, screen
timeout, power saving mode, and tv out settings.
䊳
From the Home screen, tap ➔
Settings
➔
Display
settings
.
The following options display:
• Font style
: allows you to set the font for your tablet display.
• Brightness
: configures the LCD Brightness levels. Tap Automatic
brightness to allow the phone to self-adjust and tap OK.
• White color density
: allows you to set the density of the white color
using a slider bar. Tap
OK
when finished.
• Black color density
: allows you to set the density of the black color
using a slider bar. Tap
OK
when finished.
• Saturation
: allows you to set the color saturation using a slider bar.
Tap
OK
when finished.
•Animation
: determines whether some or all of the window
elements animate. Selections are: No animations, Some
animations, and All animations.
• Screen timeout
: adjusts the delay time before the screen
automatically turns off. Selections are: 15 seconds, 30 seconds, 1
minute, 2 minutes, 10 minutes, and 30 minutes.
• Power saving mode
: this mode allows you to save power because
the phone analyzes the displayed screen image and adjusts the
LCD brightness.
•TV out
: This feature allows you to connect your phone to your
television. For more information, refer to
“Location and
Security”
on page 79.
TV out
This feature allows you to connect your phone to your television
via an optional phone to RGB cable and view any locally stored
Changing Your Settings 75
image or video directly on your television. The two available
options include: TV out or TV system (NTSC).
Note:
The TV system (NTSC) option is used if you are connecting to an older,
analog NTSC system.
To use the TV out feature:
1. From the Home screen, tap ➔
Settings
➔
Display
settings
➔
TV out
.
2. Tap
TV system
.
3. Tap
PAL
or
NTSC
.
Note:
PAL is usually used in Europe.
Location and Security
The Location and Security settings allow you to set up how the
phone will determine your location and the security settings for
your phone.
Use Wireless Networks
Before you use applications such as Google Maps and find your
location or search for places of interest, you must enable the Use
wireless networks option or enable the GPS satellites.
1. From the Home screen, tap ➔
Settings
➔
Location
and security
.
2. Tap
Use wireless networks
to enable location information
using the wireless network.
Use GPS satellites
1. From the Home screen, tap ➔
Settings
➔
Location
and security
.
2. Tap
Use GPS satellites
to enable the GPS satellite.
Set screen lock
Creating a screen unlock pattern increases security on the
phone.
1. From the Home screen, tap ➔
Settings
➔
Location
and security
.
2. Tap
Set screen lock
and select one of the following options:
•None
: disables screen unlock security.
• Pattern
: requires that you draw a pattern on the screen to unlock it.
Follow the onscreen instructions.
•PIN
: requires that you enter a numeric PIN number to unlock the
screen. Enter a PIN number, confirm it, then tap OK.
•Password
: requires that you enter a password to unlock the
screen. Enter a password, confirm it, then tap OK. Password must
contain at least one letter.
76
Set up/Change password
Use this option to set up your password when one is first required
or change your current password.
1. From the Home screen, tap ➔
Settings
➔
Location
and security
➔
Set up/Change password
.
2. Enter a new password and tap
Confirm
.
3. Enter the new password again and tap
Confirm
.
Visible passwords
When you create a phone password you can also configure the
phone to display the password as you type it instead of using an
asterisk (*).
1. From the Home screen, tap ➔
Settings
➔
Location
and security
.
2. Tap
Visible passwords
to activate this feature.
Select device administrators
???? Need explanation. Not sure what this is ????
1. From the Home screen, tap ➔
Settings
➔
Location
and security
.
2. Tap
Select device administrators.
3. Tap an application, such as Email for example, to allow the
application to perform administrative operations.
4. Tap
Activate
.
Credential storage
This option allows certain applications to access secure
certificates and other credentials. Certificates and credentials
can be installed to the SD card and password protected.
1. From the Home screen, tap ➔
Settings
➔
Location
and security
.
2. Tap
Use secure credentials
to activate this feature. A check
mark displayed next to the feature indicates secure
credentials is active.
3. Tap
Install encrypted certificates from SD card
to install
encrypted certificates from the memory (SD) card.
4. Tap
Set password
to set or change the credential storage
password.
5. Tap
Clear storage
to clear the storage (SD card or phone
memory) of all contents and reset the credentials
password.
Changing Your Settings 77
Applications
This device can be used for Android development. You can write
applications in the SDK and install them on this device, then run
the applications using the hardware, system, and network. This
feature allows you to configure the device for development.
Warning!:
Android Dev Phone 1 devices are not intended for non-developer
end-users. Because the device can be configured with system
software not provided by or supported by Google or any other
company, end-users operate these devices at their own risk.
Unknown sources
Allows you to install applications from the non-Market store.
Manage Applications
This feature allows you to manage installed applications. You can
view and control currently running services, or use the device for
application development. Using the Samsung Apps option the
device notifies you when you are using Wi-Fi or Packet data for
Samsung applications.
You can also view the amount of memory or resources used as
well as the remaining memory and resources for each of the
applications on your phone and clear the data, cache, or defaults.
䊳
From the Home screen, tap ➔
Settings
➔
Applications
➔
Manage applications
.
Clearing application cache and data
Important!:
You must have downloaded applications installed to use this
feature.
1. From the Home screen, tap ➔
Settings
➔
Applications
➔
Manage applications
.
2. Tap an application in which to clear the cache or data.
3. Tap
Uninstall updates
,
Clear cache
,
Clear defaults
,
Force
stop
, or
View Permissions
.
Uninstalling third-party applications
Important!:
You must have downloaded applications installed to use this
feature.
1. From the Home screen, tap ➔
Settings
➔
Applications
➔
Manage applications
.
2. Tap the application you want to uninstall and tap
Uninstall
.
3. At the prompt, tap
OK
to uninstall the application.
4. At the
Uninstall finished!
prompt, tap
OK
.
78
Running services
The Running services option allows you to view and control
currently running services such as Daily Briefing, DataService,
Google Talk, SNS (messaging), Swype, and more.
To stop a service from running on your phone:
1. From the Home screen, tap ➔
Settings
➔
Applications
➔
Running Services
.
2. Tap a service.
3. At the
Stop service?
prompt, tap
Stop
to stop the service
from running on your phone.
Development
䊳
From the Home screen, tap ➔
Settings
➔
Applications
➔
Development
.
Important!:
These features are used for development purposes only.
USB debugging
This feature is used for development purposes only.
Stay awake
To share this devices internet with your laptop or computer
through the USB port, you must use a screen saver to keep the
device awake. Without a screen saver, the phone will disconnect
from a Wi-Fi, 2G (Edge), or 3G connection. Use the Stay awake
option to keep the phone awake so you can share the internet.
This feature is used for Android application development.
Note:
The phone will not go into sleep mode while charging when this
feature is activated.
Allow mock locations
This feature is used for development purposes only.
If you are a developer who is testing a GPS applications using
this device, you can tell the device that the phone is at different
GPS locations. In other words, the phone is allowed to “mock”
the coordinates.
Samsung Apps
This option allows you to set notification for updates in Samsung
Apps.
1. From the Home screen, tap ➔
Settings
➔
Applications
➔
Samsung Apps
.
2. Tap
Off
,
Wi-Fi only
, or
Mobile data and Wi-Fi
.
Accounts and Synchronization
1. Sign in to your Google account.
Changing Your Settings 79
2. From the Home screen, tap ➔
Settings
➔
Accounts
and sync
.
3. From the General sync settings section, tap one of the
following options:
• Background data
: allows your phone to use data in the
background.
• Auto-sync
: automatically synchronizes your data with the phone.
4. Under the Manage accounts heading, tap to
synchronize the account with your tablet.
5. Tap
Add account
to create a new one.
Privacy
The Privacy option allows you to backup your setting
configurations, restore your saved settings, and perform a factory
data reset.
Mobile backup and restore
1. From the Home screen, tap ➔
Settings
➔
Privacy
.
2. Tap
Backup my settings
. A green checkmark will appear
next to the feature and your current settings will be saved
for future use.
3. Tap
Automatic restore
when your settings have changed
and you want to restore them to what you saved before. A
green checkmark will appear next to the feature and
Factory data reset
From this menu you can reset your phone and sound settings to
the factory default settings.
1. From the Home screen, tap ➔
Settings
➔
Privacy
.
2. Tap
Factory data reset
.
3. Tap
Reset phone
.
4. Tap
Erase everything
.
Warning!:
Performing a Factory data reset will erase all data from your
phone, including your Google account, system and application
data and settings, and downloaded applications. It will not erase
current system software and bundled applications or files on your
SD card such as music or photos.
SD card and phone storage
From this menu you can view the memory allocation for the
memory card as well as mount or unmount the SD card.
For more information about mounting or unmounting the SD card,
see “Memory Card” on page 25.
To view the memory allocation for your external SD card:
80
䊳
From the Home screen, tap ➔ Settings ➔ SD card
and phone storage.The available memory for external SD
card and internal memory displays under the Total space
and Available space headings.
For information on mounting and unmounting SD cards, see
“Memory Card” on page 25.
Search Settings
Use the search settings to configure parts of Google Web search
(for example, whether Google makes suggestions below the
Quick Search Box as you type), and what phone features you
want to include in the searches.
1. From the Home screen, tap ➔
Settings
➔
Search
.
2. Tap one of the following search settings:
• Google search
: displays the Google search preferences settings.
–
Show web suggestions
: includes search matches from Google’s
online search engine.
–
Use My Location
: allows search applications to use your GPS location.
–
Search history
: determines whether to include personalized search
history results in the list.
–
Manage search history
: manages the personalized search history
associated with your Google account.
• Searchable items
: displays a screen to select search categories
included in the device searches such as: Browser, Apps, Contacts,
YouTube, Music Player, and Phone.
• Clear shortcuts
: erases the history for recently selected search
results.
Locale and Text Settings
This setting allows you to configure the language in which to
display the menus. You can also set onscreen keyboard options.
䊳
From the Home screen, tap ➔
Settings
➔
Locale and
text
.
Select locale
To set the language that the menus display on the phone:
1. From the Home screen, tap ➔
Settings
➔
Locale and
text
➔
Select locale
.
2. Tap on a language and region from the list.
Select input method
There are two input methods available: Swype and Samsung
keypad. Samsung keypad is the default text input method.
1. From the Home screen, tap ➔
Settings
➔
Locale and
text
➔
Set default keyboard
.
Changing Your Settings 81
2. Select either Swype or Samsung keypad and follow the
instructions below.
Swype Settings
To configure Swype settings:
1. From the Home screen, tap ➔
Settings
➔
Locale and
text
➔
Swype
.
2. Tap one of the following Swype settings to activate the
setting:
• Language
: allows you to select the current text input language.
Default language is US English.
•Word Prediction
: uses a built-in word database to predict words
while entering text in Swype.
• Audio Feedback
: turns off sounds generated by the Swype
application.
• Vibrate on keypress
: activates a vibration sensation as you enter
text using the keypad.
• Enable Tip Indicato
r: turns on an on-screen flashing indicator that
provides helpful user information.
•Auto-spacing
: automatically inserts a space between words.
When you finish a word, just lift your finger or stylus and start the
next word.
• Auto-capitalization
: automatically capitalizes the first letter of a
sentence.
• Show complete Trace
: select to display the complete Swype path.
• Word Choice Window
: select how often the Word Choice window
displays.
• Speed vs. Accuracy
: select how quickly Swype responds to input.
•Swype Help
: allows you to view the on-line user manual for Swype.
•Tutorial
: a short tutorial that helps you to get started using Swype.
•Version
: lists the Swype version number.
Samsung Keypad settings
From this menu you can set Samsung keypad options.
1. From the Home screen, tap ➔
Settings
➔
Locale and
text
➔
Samsung keypad
.
2. Tap the
Input language
field and tap the desired language.
3. To use XT9 Predictive text method, tap
XT9
. For more
information, refer to “Using XT9 Predictive Text” on
page 32.
4. If you are using XT9 Predictive text method, tap
XT9
advanced settings
. For more information, refer to “XT9
Advanced Settings” on page 86.
5. Tap
Automatic full stop
if you want to have a period
automatically inserted when you double-tap the space bar.
82
6. Tap the
Auto-capitalization
field to enable automatic
capitalization.
7. Tap
Voice input
to activate the Voice input feature. Voice
input is an experimental feature using Google’s networked
speech recognition application.
8. Tap
Tutorial
for a short tutorial on using the Samsung
keypad.
XT9 Advanced Settings
The following XT9 Advanced settings are only available if the
XT9
field has been selected.
1. From the Home screen, tap ➔
Settings
➔
Locale and
text
➔
Samsung keypad
➔
XT9 Advanced settings
.
2. Tap the
Word completion
field to enable word completion.
Your phone will predict how to complete the word you have
started.
3. Tap the
Word completion point
field to set how many letters
should be entered before a prediction is made.
4. Tap the
Spell correction
field. This option corrects
typographical errors by selecting from a list of possible
words that reflect the characters of the keys you touched
as well as the characters of nearby keys.
5. Tap the
Next word prediction
field to enable word prediction
for the next word.
6. Tap the
Auto-append
field to automatically add predictions
to the word you are typing.
7. Tap the
Auto-substitution
field to automatically replace
words that you are typing. This option will help for
accidental misspellings.
8. Tap the
Regional correction
field. This option sets the
device to automatically correct mistyped words according
to normal spelling for your region.
9. Tap the
Recapture
field. This option sets the device to re-
display the word suggestion list when you select the wrong
word from the list.
Changing Your Settings 83
10. To add a new word to the T9 dictionary:
Tap the
XT9 my words
field, then press ➔
Add
. Enter
the new word in the
Register to XT9 my words
field, then
tap
Done
.
11. To add words to your XT9 dictionary, tap
XT9 my words
.
Enter the words to add using the keypad and tap
Add
.
12. To add words to substitute (for example youve becomes
you’ve) tap
XT9 auto-substitution
.
13. A list of substitutions is displayed. If you don’t see the
substitution you want, press ➔
Add
, and then input
the Shortcut word and Substitution word. Tap
Done
.
Voice Input and Output
This feature allows the device to provide a verbal readout of
onscreen data such as messages and incoming caller
information.
1. From the Home screen, tap ➔
Settings
➔
Voice input
and output
.
2. Tap
Voice recognition settings
to access the following
options:
• Language
: allows you set the language you will be using for your
voice input and output.
•SafeSearch
: allows you to filter explicit images when performing
voice searches. You can set to Off, Moderate, or Strict.
• Block offensive words
: allows you to hide recognized offensive
words.
3. Tap
Text-to-speech settings
to access the following
options:
• Listen to an example
: plays a short example of what the text-to-
speech feature sounds like on your device when activated.
• Always use my settings
: accepts an override of application
settings with personal configurations for this text-to-speech settings
screen. If enabled, your device defaults to using the text-to-speech
feature.
• Default engine
: displays the default engine used for voice
recognition.
• Install voice data
: confirms the installation of necessary data
required for voice synthesis.
• Speech rate
: adjusts the rate at which onscreen text is spoken by
the device. Choose from:
Very slow
,
Slow
,
Normal
,
Fast
, and
Very
fast
.
• Language
: assigns the language used for verbal readout. Choose
from American English or Spanish.
•Pico TTS
: allows you to modify settings for the Pico TTS default
engine.
84
Accessibility Settings
??? Doesn’t work ??? Download from Android Market ?????
This service is able to collect all the text you type, including
personal data credit card numbers except passwords. It may also
log your user interface interactions. It comes from the
applications such as KickBack, SoundBack, and TalkBack.
1. From the Home screen, tap ➔
Settings
➔
Accessibility
.
2. Tap
Accessibility
to activate the feature, then select the
services for which you want data to log.
Date and time
This menu allows you to change the current time and date
displayed.
1. From the Home screen, tap ➔
Settings
➔
Date &
time
.
2. Tap
Automatic
to allow the network set the date and time.
Important!:
Deactivate
Automatic
to manually set the rest of the options.
3. Tap
Set date
and use the plus or minus icons to set the
Month
,
Day
, and
Year
then tap
Set
.
4. Tap
Select time zone
, then tap a time zone.
5. Tap
Set time
and use the plus or minus icons, set
Hour
, and
Minute
. Tap
PM
or
AM
, then tap
Set
.
6. Optional: Tap
Use 24-hour format
. If this is not selected the
phone automatically uses a 12-hour format.
7. Tap
Select date format
and tap the desired date format
type.
About Tablet
This menu contains legal information, system tutorial
information, and other phone information such as the model
number, firmware version, baseband version, kernal version, and
software build number.
To access phone information:
䊳
From the Home screen, tap ➔
Settings
➔
About
phone
. The following information displays:
• Status
:
displays the battery status, the level of the battery
(percentage), the phone number for this device, the network
connection, signal strength, mobile network type, service state,
roaming status, mobile network state, IMEI number, IMEI SV, Wi-Fi
MAC address, Bluetooth address, and Up time.
• Battery use
: displays the applications or services (in percentages)
that are using battery power.
Changing Your Settings 85
• Legal information
: This option displays information about Open
source licenses as well as Google legal information. This
information clearly provides copyright and distribution legal
information and facts as well as Google Terms of Service, Terms of
Service for Android-powered Phones, and much more pertinent
information as a reference.
Read the information and terms, then press
to return to the
Settings menu.
• System tutorial
: provides a quick, online tutorial that walks you
through basic phone features. Read the on-screen information and
follow the system prompts.
• Model number
: displays the phone’s model number.
• Firmware version
: displays the Android version loaded on this
handset.
• Baseband version
: displays the baseband version loaded on this
handset.
• Kernel version
: displays the kernel version loaded on this handset.
• Build number
: displays the software, build number.
90
Section 8: Connections
This section describes the various connections your phone can
make including accessing the Internet with your Browser, Wi-Fi,
Bluetooth, and Connecting your PC.
Browser
Your phone is equipped with Google, your access to the mobile
web. This section explains how to navigate att.my.yahoo and
introduces you to the basic features.
Accessing the Mobile Web
To access the Browser:
䊳
At the Home screen, tap
Browser
.
Google Homepage
When you access the Browser, the homepage displays. The
green bar at the top of the display will disappear when the page
is fully loaded. The Google homepage contains the following
items:
•
My Main Tab
: The Main Tab is the att.my.yahoo homepage.
•
New Tab
: This option allows you to create a new page that you can
customize. You can name it, personalize it, and drag and drop content
from other tabs.
•
Add Content
: This option allows you to add content to your webpage.
You can add things like Facebook, TV Listings, Yahoo! Mail Preview,
etc.
•
Change Appearance
: This option allows you to choose and customize
a theme, change the layout, and set the font size of your webpage.
•
More Options
:
–
My Yahoo! Reader
: The Reader lets you view articles without leaving
My Yahoo! when feed publishers have provided the full articles. If you
prefer to read articles on the publisher’s site, you can turn the Reader
off for all feeds.
–
Article Preview
: When sweep over headlines you can read a snippet of
the article without leaving My Yahoo!. If you prefer not to see the article
preview, you can turn it off for all web pages.
–
Article Timestamps
: This setting allows you to show or hide the
timestamps that are placed after headlines on your page to indicate
when articles were published.
–
Auto Refresh
: This option reloads your tabs automatically to get the
latest information. If you prefer to refresh your tabs manually, you can
turn this feature off.
–
Search Assist
: This option offers relevant keywords in real-time as you
type. You can choose them by scrolling through the list.
Connections 91
–
Reset Homepage
: This setting allows you to start over and reset your
homepage to the default settings. You will lose any customization,
including content added, tabs created, and themes selected.
•
Web Search
: The Web Search box allows you to search the web by
entering a word or words and then tapping Web Search.
Navigating with the Browser
1. To select an item, tap an entry.
2. To scroll through a website, sweep the screen with your
finger in an up or down motion.
3. Sweep the screen left to right to move laterally across a
web page.
4. To return to the previous page, press .
Zooming in and out on the Browser
There are several ways to Zoom in and out on your browser:
•
Double tap the web page to zoom in or out.
•
When you sweep the screen in any direction the icon
displays. Press to zoom in or to zoom out.
•
Sweep in opposite directions at the same time to zoom in or out. See
diagram below.
Zoom In Zoom Out
92
Browser Options
1. From the home page, press to access the following
options:
• New window
: displays a new window so you can browse multiple
URLs. For more information, refer to
“Adding and Deleting
Windows”
on page 93.
• Add RSS feeds
: allows you to add RSS (Really Simple Syndication)
feeds. RSS is a family of web feed formats used to publish
frequently updated works, such as blog entries, news headlines,
audio, and video.
• Windows
: displays a list of the windows you have open.
•Refresh
: reloads the current page.
•Forward
: forwards the browser to another web page.
•More
: displays the following additional options:
–
Add bookmark
: allows you to add a URL to your bookmark list.
–
Find on page
: allows you to search in the current page.
–
Select text
: touch and slide your finger across text you want to copy
and paste to the clipboard. The text highlights as you select it.
–
Page info
: displays information about the selected page.
–
Share page
: allows you to share the page using Gmail or as a
message.
–
Downloads
: displays the download history.
–
Settings
: allows you to change the way you view your web pages by
changing these options. See
“Browser Settings”
on page 95.
–
Brightness Setting
: allows you to adjust the brightness of your display.
Enter a URL
You can access a website quickly by entering the URL. Websites
are optimized for viewing on your phone.
To enter a URL and go to a particular website, follow these steps:
1. Tap the URL field at the top of your screen.
2. Enter the URL using the on-screen keypad and tap
Go
.
The website displays.
Search the Internet
To perform an internet search using keywords, follow these
steps:
1. From the att.my.yahoo homepage, tap the
Web
Search
field.
2. Enter the keyword(s) to search using the on-screen keypad
and tap
Web Search
.
3. A list of search results displays.
4. Tap a link to view the website.
Connections 93
Adding and Deleting Windows
You can have up to eight Internet windows open at one time. To
add a new window, follow these steps:
1. From your browser, press ➔
New Window
.
2. A new browser window is opened.
3. Press ➔
Windows
to see a list of all open windows.
4. Tap a window listing to open up that Internet window.
5. Tap next to the listing to delete the window.
Using Bookmarks
While navigating a website, you can bookmark a site to quickly
and easily access it at a future time. The URLs (website
addresses) of the bookmarked sites are displayed in the
Bookmarks page. From the Bookmarks page you can also view
your Most visited websites and view your History.
1. From the Home webpage, tap .
The Bookmarks page is displayed.
2. Press to display the following options:
• Bookmark last-viewed page
: Creates a new bookmark for the
last webpage that you viewed.
• List/Thumbnail view
: You can select
Thumbnail view
(default) to
see a thumbnail of the webpage with the name listed, or you can
select
List view
to see a list of the bookmarks with Name and URL
listed.
3. Tap a bookmark to view the webpage, or touch and hold a
bookmark for the following options:
•Open
: Opens the webpage of the selected bookmark.
• Open in new window
: Opens the webpage in a new window.
• Edit bookmark
: Allows you to edit the name or URL of the
bookmark. For more information, refer to
“Editing Bookmarks”
on page 94.
• Add shortcut to Home
: Adds a shortcut to the bookmarked
webpage to your phone’s Home screen.
• Share link
: Allows you to share a URL address via Bluetooth,
Gmail, or Messaging.
• Copy link URL
: Allows you to copy the URL address to use in a
message.
• Delete bookmark
: Allows you to delete a bookmark. For more
information, refer to
“Deleting Bookmarks”
on page 94.
• Set as homepage
: Sets the bookmark to your new homepage.
94
Adding Bookmarks
1. From the Home webpage, tap ➔
Add
if you are in
Thumbnail view. Tap
Add bookmark..
if you are in List view.
2. Use the on-screen keypad to enter the name of the
bookmark and the URL.
3. Tap
OK
.
4.
Saved to bookmarks
will appear at the bottom of the page.
Editing Bookmarks
1. From the Bookmarks page, touch and hold the bookmark
you want to edit.
2. Tap
Edit bookmark
.
3. Use the on-screen keypad to edit the name of the
bookmark or the URL.
4. Tap
OK
.
Deleting Bookmarks
1. From the Bookmarks page, touch and hold the bookmark
you want to delete.
2. Tap
Delete bookmark
.
3. At the Delete confirmation window, tap
OK
.
Emptying the Cookies
A cookie is a small file which is placed on your phone by a
website during navigation. In addition to containing some site-
specific information, it can also contain some personal
information (such as a username and password) which can pose
a security risk if not properly managed. You can clear these
cookies from your phone at any time.
1. From the Home webpage, press ➔
More
➔
Settings
➔
Clear all cookie data
.
2. At the
All cookies will be deleted
prompt, tap
OK
to delete
the cookies or tap
Cancel
to exit.
Using your History
The History list provides you with a list of the most recently
visited websites. These entries can be used to return to
previously unmarked web pages.
1. From the Home webpage, tap ➔
History
.
A list of your most recently visited websites is displayed
with Name and URL address.
2. Tap any entry to display the webpage.
3. Press ➔
Clear history
to delete the History list.
History
Connections 95
Using Most Visited
The Most visited list provides you with a list of the most visited
websites that you have bookmarked. These entries can be used
to return to previously unmarked web pages.
1. From the Home webpage, tap ➔
Most visited
.
A list of your most visited webpages is displayed with
Name and URL address. The webpages that have been
visited the most will appear at the top.
2. Tap any entry to display the webpage.
Browser Settings
To make adjustments in your browser settings, follow these
steps:
1. From the Home screen, tap
Browser
➔ ➔
More
➔
Settings
.
2. The following options are available:
•Text size
: Adjusts the current onscreen text size. Options include
Tiny, Small, Normal, Large, or Huge.
• Default zoom
: Adjusts the zoom feature. Set to Far, Medium, or
Close.
• Open pages in overview
: Shows an overview of newly opened
web pages.
• Text encoding
: Adjusts the current text encoding.
• Block pop-up windows
: Prevents popup advertisement or
windows from appearing onscreen. Remove the checkmark to
disable this function.
•Load images
: Allows web page images to be loaded along with the
other text components of a loaded website.
• Auto-fit pages
: Allows web pages to be resized to fit as much of
the screen as possible.
• Landscape-only display
: Displays the browser in only the
horizontal position.
• Enable JavaScript
: Enables javascript for the current Web page.
Without this feature, some pages may not display properly. Remove
the checkmark to disable this function.
• Enable plug-ins
: Allows the download of plug-ins such as Adobe
Flash.
• Open in background
: New pages are launched in a separate page
and displayed behind the current one. Remove the checkmark to
disable this function.
• Set home page
: Sets the current home page for the Web browser.
• Default storage
: Allows you to set your default storage to Phone or
Memory Card.
• Clear cache
: Deletes all currently cached data. Tap
OK
to complete
the process.
•Clear history
: Clears the browser navigation history. Tap
OK
to
complete the process.
Most visited
96
• Accept cookies
: Allows sites, that require cookies, to save and
read cookies from your device.
• Clear all cookie data
: Deletes all current browser cookie files.
• Remember form data
: Allows the device to store data from any
previously filled out forms. Remove the checkmark to disable this
function.
• Clear form data
: Deletes any stored data from previously filled out
forms. Tap OK to complete the process.
• Enable location
: Allows websites to request access to your
location.
• Clear location access
: Clears location access for all websites. Tap
OK
to complete the process.
• Remember passwords
: Stores usernames and passwords for
visited sites. Remove the checkmark to disable this function.
• Clear passwords
: Deletes any previously stored usernames or
passwords. Tap
OK
to complete the process.
• Show security warnings
: Notifies you if there is a security issue
with the current website. Remove the checkmark to disable this
function.
• Website settings
: View advanced settings for individual websites.
• Reset to default
: Clears all browser data and resets all settings to
default.
Wi-Fi
About Wi-Fi
Wi-Fi (short for "wireless fidelity") is a term used for certain
types of Wireless Local Area Networks (WLAN). These device
types use an 802.11 wireless specification to transmit and
receive wireless data. Wi-Fi communication requires access to
an existing and accessible Wireless Access Point (WAP). These
WAPs can either be Open (unsecured) as within most Hot Spots,
or Secured (requiring knowledge of the Router name and
password).
Turning Wi-Fi On
By default, your device’s Wi-Fi feature is turned off. Turning Wi-Fi
on makes your device able to discover and connect to compatible
in-range WAPs.
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Wi-Fi settings
.
2. Tap the
Wi-Fi
field to activate the feature. A green
checkmark indicates that Wi-Fi is active. The device will
scan for available in-range wireless networks and display
them under Wi-Fi networks on the same screen.
Connections 97
Connect to a Wi-Fi Network
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Wi-Fi settings
.
The network names and security settings (Open network or
Secured with WEP) of detected Wi-Fi networks are
displayed in the Wi-Fi networks section.
2. Tap the network you want to connect to.
Note:
When you select an open network, you will be automatically connected
to the network.
3. Enter a wireless password if necessary.
Manually add your new network connection
1. Tap
Add Wi-Fi network
.
2. Enter the
Network SSID
. This is the name of your Wireless
Access Point.
3. Tap the
Security
field and select a security option. This
must match the current security setting on your target
WAP.
4. If secured, you will also need to enter your WAP’s
password.
5. Tap
Save
to store the new information and connect to your
target WAP.
Note:
The next time your device connects to a previously accessed or
secured wireless network, you are not prompted to enter the WAP key
again, unless you reset your device back to its factory default settings.
Turning Wi-Fi Off
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Wi-Fi settings
.
2. Tap the
Wi-Fi
field to deactivate the feature. The green
checkmark will be removed.
Note:
Use of wireless data connections such as Wi-Fi and Bluetooth can
cause an added drain to your battery and reduce your use times.
Manually Scan for a Wi-Fi Network
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Wi-Fi settings
.
2. Press ➔
Scan
.
98
Wi-Fi Status Indicators
The following icons show your Wi-Fi connection status at a
glance:
Displays when Wi-Fi is connected, active, and
communicating with a Wireless Access Point (WAP).
Displays when Wi-Fi is active but there is a
communication issue with the target Wireless Access
Point (WAP).
Wi-Fi Advanced Settings
The Wi-Fi settings - Advanced menu allows you to set
up many of your device’s Wi-Fi service, including:
•
Setting your Wi-Fi sleep policy
•
Viewing your device’s MAC Address
•
Configuring use of either a DHCP or Static IP
To access the Bluetooth Settings menu:
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Wi-Fi settings
.
2. Press ➔
Advanced
.
For more information, refer to “Network Notification” on
page 70.
Hot Spots
At Hot Spots, you have unlimited Wi-Fi access on the Hot Spot
Network throughout the world.
Hot Spots provide a reliable wireless Internet connection with
broadband speed, so you can check your email, instant message,
watch videos or listen to music.
With this application you can find thousands of locations around
the country - and around the world - in coffeehouses,
restaurants, hotels, airports, and more.
To use the Hotspot Locator, follow these steps:
1. From the Home screen, tap ➔
Hot Spots
.
2. At the Hotspot Locator screen, select a venue. Tap the
drop-down list box and select from All Venues, Starbucks,
Barnes & Noble, McDonald’s, Airports, Hotels, or
Convention Centers.
3. Select a Service Type. Tap the drop-down list box and
select Basic (Only) or Premier (Includes Basic).
4. Enter a Zip or City and State and tap
Search
.
The nearest Hotspots are displayed.
5. Select the location you want and tap
maps & directions
.
Connections 99
A map is displayed. You can also enter information for
driving directions.
Bluetooth
About Bluetooth
Bluetooth is a short-range communications technology that
allows you to connect wirelessly to a number of Bluetooth
devices, such as headsets and hands-free car kits, and
Bluetooth-enabled handhelds, computers, printers, and wireless
devices. The Bluetooth communication range is usually up to
approximately 30 feet.
Turning Bluetooth On and Off
To turn Bluetooth on:
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Bluetooth settings
.
2. Tap the
Bluetooth
field to activate the feature (checkmark
indicates active). When active, appears within the
Status area.
To turn Bluetooth off:
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Bluetooth settings
.
2. Tap the
Bluetooth
field to deactivate the feature. The green
checkmark will be removed.
Bluetooth Status Indicators
The following icons show your Bluetooth connection status
at a glance:
Displays when Bluetooth is active.
Displays when Bluetooth is connected (paired) and
communicating.
Displays when Bluetooth is disabled (default status).
Bluetooth Settings
The Bluetooth settings menu allows you to set up many of the
characteristics of your device’s Bluetooth service, including:
•
Entering or changing the name your device uses for Bluetooth
communication and description
•
Setting your device’s visibility (or “discoverability”) for other Bluetooth
devices
•
Displaying your device’s Bluetooth address
[no icon]
100
To access the Bluetooth Settings menu:
1. From the Home screen, tap ➔
Settings
➔
Wireless
and network
➔
Bluetooth settings
.
2. Verify your Bluetooth is active.
3. Tap the
Device name
,
Discoverable
, and
Scan for devices
fields to set the options.
To change your Bluetooth name:
1. Verify your Bluetooth is active.
2. From the Bluetooth settings page, tap
Device name
.
3. Tap the
Device name
field and enter a new name.
4. Tap
OK
to complete the rename process.
To make your device visible:
1. Verify your Bluetooth is active.
2. From the Bluetooth settings page, tap
Discoverable
.
•
Making your device visible allows it to be detected by other devices
for pairing and communication.
Note:
Your device is visible for up to 120 seconds (2 minutes). This value
appears as a countdown within this field.
To scan for Bluetooth devices:
1. Verify your Bluetooth is active.
2. From the Bluetooth settings page, tap
Scan devices
to
search for visible external Bluetooth-compatible devices
such as headsets, devices, printers, and computers.
Pairing Bluetooth Devices
The Bluetooth pairing process allows you to establish trusted
connections between your device and another Bluetooth device.
When you pair devices, they share a passkey, allowing for fast,
secure connections while bypassing the discovery and
authentication process.
To pair your device with another Bluetooth device:
1. Verify your Bluetooth is active.
2. Tap
Scan devices
. Your device will display a list of
discovered in-range Bluetooth devices.
3. Tap a device from the list to initiate pairing.
4. Enter the passkey or PIN code, if needed, and tap
OK
.
Connections 101
5. The external device will then have to also accept the
connection and enter your device’s PIN code.
Once successfully paired to an external device,
appears within the Status area.
Note:
Due to different specifications and features of other Bluetooth-
compatible devices, display and operations may be different, and
functions such as transfer or exchange may not be possible with all
Bluetooth compatible devices.
Note:
Pairing between two Bluetooth devices is a one-time process. Once a
pairing has been created, the devices will continue to recognize their
partnership and exchange information without having to re-enter a
passcode again.
To disconnect a paired device:
Disconnecting a paired device breaks the connection between
the device and your phone, but retains the knowledge of the
pairing. At a later point when you wish to reconnect the device,
there is no need to setup the connection information again.
1. Verify your Bluetooth is active.
2. From the Bluetooth settings page, tap the previously paired
device (from the bottom of the page).
3. Tap
OK
to confirm disconnection.
– or –
From the Bluetooth settings page, touch and hold the
name of the previously paired device, and select
Disconnect
.
Note:
Disconnections are manually done but often occur automatically if the
paired device goes out of range of your phone or it is powered off.
To delete a paired device (unpair):
Deleting a device from your list removes its “connection record”
and upon reconnection would require that you re-enter all the
previous pairing information.
1. Verify your Bluetooth is active.
2. From the Bluetooth settings page, touch and hold the
name of the previously paired device (from the bottom of
the page). This opens the connected device’s menu
options.
3. Tap
Unpair
to delete the paired device.
102
Sending Contacts via Bluetooth
Depending on your paired devices’ settings and capabilities, you
may be able to send pictures, Contact information, or other items
using a Bluetooth connection.
Note:
Prior to using this feature, Bluetooth must first be enabled, and the
recipient’s device must be visible.
1. Verify your Bluetooth is active.
2. From the Home screen, tap ➔
Contacts
.
3. Press ➔
More
➔
Send via bluetooth
.
4. Tap each contact that you would like to send via Bluetooth.
A green checkmark will appear next to each entry you
select.
5. Tap
Send
.
6. Select the paired device to send the contacts to.
Note:
The external Bluetooth device must be visible and communicating for
the pairing to be successful.
7. A Bluetooth share notification will appear in your
notifications list.
PC Connections
You can connect your device to a PC using an optional PC data
cable using various USB connection modes. When you connect
the device to a PC, you can synchronize files with Windows
Media Player, transfer data to and from your device directly, or
use the Samsung Kies program and use you device as a wireless
modem for a PC.
What is Kies?
Kies is a software suite that allows you to search and download
applications directly from a PC. The applications are then
installed onto a mobile device when synced with a PC, providing
instant back up and peace of mind for application downloads.
To learn more about Samsung Kies and Samsung applications,
browse featured applications and download Kies at
www.samsungapps.com
.
Connections 103
Connecting with Kies
Ensure that Samsung Kies is installed on your PC. You can
download the program from the Samsung website
(www.samsungmobile.com).
1. From the Home screen, tap
➔
Settings
➔
Wireless
and network
➔
USB settings
➔
Kies
.
2. Press to return to the Home screen.
3. Using an optional PC data cable, connect the multifunction
jack on your device to a PC.
4. Run Samsung Kies and use wireless connections or copy
data and files. Refer to Samsung Kies help for more
information.
Synchronizing with Windows Media Player
Ensure that Windows Media Player is installed on your PC.
1. From the Home screen, tap
➔
Settings
➔
Wireless
and network
➔
USB settings
➔
Media player
.
2. Press to return to the Home screen.
3. Using an optional PC data cable, connect the multifunction
jack on your device to a PC with Windows Media Player
installed. A pop-up window displays on the PC when
connected.
4. Open
Windows Media Player
to synchronize music files.
5. Edit or enter your device’s name in the pop-up window.
6. Select and drag the music files you want to the sync list
and begin synchronizing.
Connecting as a Mass Storage Device
You can connect your device to a PC as a removable disk and
access the file directory. If you insert a memory card in the
device, you can also access the files directory from the memory
card by using the device as a memory card reader.
Note:
The file directory of the memory card displays as a removable disk,
separate from the internal memory.
Note:
To use any downloaded market application that requires a USB
connection between your phone and your PC, you should first set the
USB setting to
Mass storage
.
104
1. Insert a memory card into the device to transfer files from
or to the memory card.
2. From the Home screen, tap
➔
Settings
➔
Wireless
and network
➔
USB settings
➔
Mass storage
.
3. Press to return to the Home screen.
4. Connect the multifunction jack on your device to a PC
using an optional PC data cable.
A pop-up window displays on the PC when connected.
5. Open the folder to view files.
6. Copy files from the PC to the memory card.
Applications 105
Section 9: Applications
This section contains a description of each application that is
available in the Applications Menu, its function, and how to
navigate through that particular application. If the application is
already described in another section of this user manual, then a
cross reference to that particular section is provided.
Tip:
To open applications quickly, add the icons of frequently-used
applications to one of the Home screens. For details, see “Customizing
Your Home Screen” on page 21.
Alarm Clock
The Alarm Clock application allows you to set an alarm to ring at
a specific time.
1. From the Home screen, tap ➔
Alarm Clock
.
The clock displays showing the current time and any
previous alarms that have been set.
2. Tap the checkbox on an existing alarm to set it, or press
➔
Add alarm
to set a new alarm.
3. Tap on the following fields to set a new alarm:
•Time
: tap the (
+
)
or (
-
)
to set the new time for the event, at which
time an alarm will sound. When finished, tap
Set
.
•Ringtone
: sets the ringtone that will sound when the alarm is
activated. Tap a ringtone and then tap
OK
.
•Repeat
: use this option to set the repeating status for the alarm by
tapping the days you would like to use for the current alarm. A
checkmark will appear on the selected days. Tap
OK
.
•Label
: allows you to use a specific name for the alarm. The name
will appear on the display when the alarm activates.
4. Tap
Done
to store the alarm details.
Turning Off an Alarm
䊳
To stop an alarm when it rings, tap
Dismiss
on the display.
– or –
Tap
Snooze
to delay the alarm for ten minutes.
Deleting Alarms
To delete an alarm
1. From the Home screen, tap ➔
Alarm Clock
.
2. Press and hold the alarm you want to delete.
3. Tap
Delete alarm
.
The alarm is removed from the Alarm Clock screen.
106
Disabling Alarms
1. From the Home screen, tap ➔
Alarm Clock
.
2. A green checkmark will appear next to each alarm that is
enabled. Tap the alarm or alarms you wish to disable. The
checkmark will be removed but the alarm will remain on
the Alarm Clock screen. Tap the alarm again to enable.
Alarm Options
To modify your alarm options, follow these steps:
1. From the Home screen, tap ➔
Alarm Clock
➔
➔
Settings
.
2. The following options are displayed:
• Alarm in silent mode
: allows the alarm to sound even when the
tablet is in silent mode.
• Alarm volume
: allows you to adjust the volume of your alarms.
• Snooze duration
: allows you to set the Snooze time before the
alarm resounds.
• Side button behavior
: allows you to set the side button behavior to
None, Snooze, or dismiss.
• Set default ringtone
: allows you to set the ringtone that will sound
when the alarm goes off.
AllShare
AllShare allows your phone to stream photos, music and videos
from its memory to other Digital Living Network Alliance (DLNA)
certified devices. Your phone can also play digital content
streamed from other DLNA certified devices.
Note:
To view more information about DLNA certified products visit
http://
www.dlna.org/home
.
1. Connect to a Wi-Fi network. For more information, refer to
“Connect to a Wi-Fi Network” on page 97.
2. From the Home screen, tap ➔
AllShare
.
3. Tap
Settings
to configure the following settings:
• Media server name
: defaults to your phone. Use the keypad to
enter a new Media server if desired, and tap
Save
.
• Share media
: allows you to restrict what is shared from your
phone. Tap the items you want to share and tap
OK
.
• Access point network
: is the Wi-Fi network that you are
connected to. Tap
Add Wi-Fi network
to select another network.
• Upload from other devices
: allows you set the phone to select
how uploads from other devices are started. Select
Always accept
,
Always ask
, or
Always reject
and tap
OK
.
• Default memory
: allows you to have media saved to your
Phone
or
Memory Card
. Select an option and tap
OK
.
Applications 107
Depending on the setting you changed, a pop-up screen
may display to restart AllShare. Tap
Yes
to continue.
4. Tap one of the following options:
• Play file from my phone on another player
: You can enjoy
multimedia content saved on your mobile phone on your TV or
Hi-Fi. You can then use your mobile phone like a remote control.
• Play file from server on my phone
: You can enjoy multimedia
content saved on other devices, such as your PC or laptop, on your
phone.
• Play file from server on another player via my phone
: You can
enjoy multimedia content saved on your PC or laptop using other
devices like your TV or Hi-Fi. You can then use your mobile phone
like a remote control.
5. Follow the on-screen instructions.
Browser
Open the browser to start surfing the web. The browser is fully
optimized and comes with advanced functionality to enhance the
Internet browsing feature on your phone. For more information,
refer to “Browser” on page 90.
Calculator
With this feature, you can use the phone as a calculator. The
calculator provides the basic arithmetic functions; addition,
subtraction, multiplication, and division. The Calculator also
keeps a history of recent calculations.
1. From the Home screen, tap ➔
Calculator
.
2. Enter the first number using the on-screen numeric keys.
3. Enter the operation for your calculation by tapping the
corresponding on-screen arithmetic function key.
4. Enter the second number.
5. To view the result, tap equals (
=
).
6. To use scientific functions, press ➔
Advanced panel
or, sweep your screen to the left.
7. To clear the calculator history, press ➔
Clear history
.
Calendar
With the Calendar feature, you can consult the calendar by day,
week, or month, create events, and set an alarm to act as a
reminder, if necessary.
To access the Calendar:
1. From the Home screen, tap ➔
Calendar
.
2. The following tabbed options are available:
•Day
: the calendar displays the selected day with any events
highlighted.
108
• Week
: the calendar displays the selected week with today’s time
and date highlighted.
•Month
: the calendar displays the selected month with today’s date
highlighted. At the bottom of the calendar, scheduled events display
in the order that they occur.
•List
: The Event List displays all events that you have added for all
dates in the order that they appear.
3. To add an event, tap on a day and then tap .
4. Enter the desired information and tap
Done
.
Calendar Options
1. From any Calendar view, press to display the
following options:
•Go to
: allows you to go to any date on your calendar.
•Today
: takes you to today’s date, if you are not already there.
• Delete
: displays the event list, where you can select events to
delete.
• Settings
: displays the following calendar settings:
–
Calendars
: displays all calendars they you have created.
–
Calendar sync
: allows you to sync your calendar with other accounts
such as email or social accounts.
–
Default view
: allows you to set the default view to Month, Week, Day,
or List.
–
First day of week
: allows you to set the first day of the week to Sunday
or Monday. This will affect how the Month view calendar is displayed.
–
Hide declined events
: will not display events you have received from
others if you have declined them.
2. Tap
Today
to go directly to today’s date on the calendar.
3. Tap to add an event to the calendar.
Events List
The Event List displays all events that you have added for all
dates in the order that they appear.
1. From the Calendar, tap the
List
tab.
Calendar View
Event List
Current Day
Day with event
Events for
Selected Day
Next yearPrevious year
Go to month
Go to today
Applications 109
2. Touch and hold any event to display it.
3. A pop-up displays with the following options:
• Send via
: allows you to send event information via Bluetooth or
Messaging.
•Edit
: allows you the change the Event name, date, time, location,
participants, alarm, alarm details, and description. Tap
Save
.
•
:
allows you to delete the event. Tap
OK
at the prompt.
Camera
Use your 5.0 megapixel camera feature to produce photos in a JPEG
format. Your phone also functions as a Camcorder to take videos.
For more information, refer to “Camera” on page 50.
Contacts
You can manage your daily contacts by storing their name and
number in your Address Book. Address Book entries can be
sorted by name, entry, or group.
For more information, refer to “Contacts” on page 35.
Daily Briefing
With Daily Briefing, you can monitor the weather, financial
information, news, and your schedule from one convenient
location.
1. From the main Home screen, scroll one Home screen to
the left. This is where Daily Briefing appears by default.
– or –
Tap ➔
Daily Briefing
.
2. Tap the
Tap to add city
field.
3. Scroll through the list of cities to find the city you want to
add, or tap the Search bar and use the keypad to enter a
city to search for.
4. Tap the city you want to add and tap
Save
.
5. Sweep the screen to the left and tap the
Tap to add stock
field.
6. In the search bar, type a company name or stock symbol
and tap .
7. Stocks will be displayed. Tap the stocks you want to track,
and a green checkmark will appear next to the stock. Tap
Save
.
8. Sweep the screen to the left and tap the
Tap to get news
field. The AP Mobile news for the city will appear.
9. Tap the
Tap to add schedule
field.
The Create event screen is displayed. For more
information, refer to “Calendar” on page 108.
110
10. Tap the
Calendar
field.
11. Select a default calendar to use on Daily Briefing. Select
My calendar
to use the calendar on your phone or select an
email account if you have added email accounts to your
phone.
12. Tap
OK
.
13. Tap
Save
.
14. Tap to select default weather, finance, and news.
15. Press
➔
Create alarm
to add an alarm to your Daily
Briefing.
Note:
After Daily Briefing has been setup, tap on any field to display that
information. Sweep your finger to the left or right to scroll through the
Daily Briefing pages.
Digital Frame
With the Digital Frame application, you can set your screen to
display a slideshow of your pictures. You can also set it to display
a clock and play music.
1. From the Home screen, tap ➔
Digital Frame
.
A Clock displays on the screen.
2. Press and hold anywhere on the screen. The following
options appear at the bottom of the display:
•Clock
: displays a clock on your screen. You can also set different
clock styles.
• Slideshow
: allows you to see a slideshow of the pictures you have
on your tablet.
•Music
: allows you to play the music on your tablet. You can also set
up music to play while a slideshow is in progress.
Modifying the Clock
1. From the Digital Frame screen, press
➔
Clock style
.
2. Tap on one of the four styles then tap
OK
.
The clock style that you choose will be displayed.
Adding Pictures to the Slideshow
1. From the Digital Frame screen, press and hold anywhere
on the screen.
2. Tap
Slideshow
at the bottom of the screen.
3. Tap
Add to slideshow
.
The pictures that you have on your tablet are displayed.
4. Tap on all of the pictures that you want to add to your
slideshow. A green checkmark will appear.
Applications 111
5. Tap
Done
.
The pictures that you added will appear in a slideshow. A
new picture will appear every five seconds
6. Press to display the following Slideshow options:
• Add to slideshow
: displays the pictures on your tablet so you can
select additional pictures to include in the slideshow.
• Slideshow effects
: allows you to add special effects to the
slideshow. Tap an effect to see how it works, then tap
OK
when you
find one you like.
•Duration
: allows you to set the duration that each picture will be
displayed in the slideshow.
•Go to music
: takes you to the music that you have on your tablet so
you can set the music to play during the slideshow. Select the
music you want to play then press to return to the slideshow.
•Timeout
: allows you to set how long the slideshow will display on
your screen.
• Screen Brightness
: allows you to set the brightness setting for
your display.
7. To leave the slideshow, press and hold the screen and then
tap
Clock
or
Music
.
– or –
Press to return to the Home screen.
Adding Music
1. From the Digital Frame screen, press and hold anywhere
on the screen.
2. Tap
Music
at the bottom of the screen.
All of the music that you have stored on your tablet is
displayed in the Music Player.
3. Tap on a song to play. You can also press to return to
the previous Digital Frame page.
For additional information on using the Music Player, see
“Music Player” on page 46.
Email
Email enables you to review and create email using AIM®,
AOL®, Yahoo!® Mail, Comcast, Compuserve, Earthlink, Gmail,
HotPOP, Juno, Mac, NetZero, SBC Yahoo! and several other email
services. You can also receive text message alerts when you
receive an important email. For more information, refer to “Using
Email” on page 61.
Gallery
The Gallery is where you view photos and play back videos. For
photos, you can also perform basic editing tasks, view a
slideshow, set photos as wallpaper or contact image, and share
112
as a picture message. For more information, refer to “Gallery”
on page 49.
Gmail
Gmail is a web-based email service. Gmail is configured when
you first set up your phone. Depending on your synchronization
settings, Gmail can automatically synchronize with your Gmail
account on the web. For more information, refer to “Using Gmail”
on page 62.
Google Search
The Google Search Bar provides you an on-screen Internet
search engine powered by Google™. For more information, refer
to “Google Search Bar” on page 18.
Latitude
With Google Latitude, you can see the location of all of your
friends on a map or on a list. You can also share or hide your
location.
You must first set up your tablet to use wireless networks to help
pinpoint your location. Also, Latitude works best when Wi-Fi is
enabled.
1. From the Home screen, tap ➔
Settings
➔
Location and security
.
2. Tap
Use wireless networks
. A green checkmark indicates
the feature is enabled.
3. Press ➔
Wireless and network
➔
Wi-Fi settings
.
4. Tap
Wi-Fi
to turn Wi-Fi on.
5. Log on to your Google account. For more information, refer
to “Creating a New Google Account” on page 7.
6. Press ➔ ➔
Latitude
.
Your location is displayed on the map, accurate to 1700
meters.
Sharing your Location with Friends
1. From the Latitude map screen, tap to display your
Latitude friends. At first, only your name is displayed.
2. Press
➔
Add friends
.
3. Tap
Select from Contacts
or
Add via email address
.
4. Tap a contact or enter an email address and tap
Add
friends
.
5. At the
Send sharing requests
prompt, tap
Yes
.
Your friend will receive an email or text message with your
location marked on a map. They will also receive instructions on
Applications 113
how to view your location from the web or use Latitude on their
phone or tablet provided it is available. Once they acknowledge
your request, their location will display on your tablet. They can
share their location from their computer, phone, or tablet.
For more information, go to
http://www.google.com/latitude
.
Latitude Options
䊳
Press to display the following options:
•Search
: allows you to search for a place of interest.
•Directions
: displays navigation directions to a location from a
starting point.
•Layers
: are additional items that you can have displayed on your
map. They include:
–
Traffic
: displays real-time traffic conditions so you can plan the fastest
route.
–
Satellite
: allows you to see you map as a satellite image.
–
Terrain
: allows you to see terrain features such as hills and mountains.
–
Buzz
: allows you post public messages and photos at a location for
everyone to see.
–
Latitude
: allows you to see your friend’s locations and share your
location with them.
–
More Layers
: allows you to add additional layers such as My Maps,
Bicycling, Wikipedia, Transit Lines, and Favorite Places.
–
Clear Map
: allows you to remove all layers from the map.
• My Location
: when selected, the location displays on the map with
a blinking blue dot.
• Latitude
: lets you and your friends share locations and status
messages with each other. It also lets you send instant messages
and emails, make phone calls, and get directions to your friends’
locations.
•More
: allows you to select the following additional options:
–
Clear Map
: after viewing or following directions, this option resets the
map.
–
Starred Items
: allows you to see locations you have marked as a
favorite such as restaurants, museums, parks, etc.
–
Labs
: this is a testing ground for experimental features that aren’t ready
for primetime. They may change, break or disappear at any time. Click
on a Lab to enable or disable it.
–
Help
: displays the Google Mobile Help web page where you can receive
help on Google Maps.
–
Terms, Privacy & Notices
: displays the Terms and Conditions, Privacy
Policy, o r Legal Notices information. Select the desired information from
the pop-up menu.
–
About
: displays general information about Google maps such as
Version, Platform, Locale, Total data sent, Total data received, Free
memory, etc.
114
Maps
Depending on your location, you can view basic, custom, and
satellite maps and local business information, including
locations, contact information, and driving directions. You can
also post public messages about a location and track your
friends.
Important!:
Before using Google Maps you must have an active data (3G)
connection. The Maps application does not cover every country
or city.
Enabling a Location Source
Before you use Google Maps and find your location or search for
places of interest, you must enable a location source. To enable
the location source you must enable the wireless network, or
enable the GPS satellites.
1. From the Home screen, tap ➔
Settings
➔
Location and security
.
2. Tap the
Use GPS satellites
field. A green checkmark will
display next to the field.
Note:
Selecting
Use GPS satellites
allows you to locate places of interest at
the street-level. However, this also requires a clear view of the sky and
uses more battery power.
Using Maps
1. From the Home screen, tap ➔
Maps
.
2. The
What’s new in Maps?
screen will display. Tap
OK
.
A map will display with your location in the very center.
3. Press to display the following options:
•Search
: allows you to search for a place of interest.
• Directions
: displays navigation directions to a location from a
starting point.
•Layers
: are additional items that you can have displayed on your
map. They include:
–
Traffic
: displays real-time traffic conditions so you can plan the fastest
route.
–
Satellite
: allows you to see you map as a satellite image.
–
Buzz
: allows you post public messages and photos at a location for
everyone to see.
–
Latitude
: allows you to see your friend’s locations and share your
location with them.
–
More Layers
: allows you to add additional layers such as My Maps,
Wikipedia, Transit Lines, Watch the World Cup, and Favorite places.
• My Location
: when selected, the location displays on the map with
a blinking blue dot.
• Join Latitude
: lets you and your friends share locations and status
messages with each other. It also lets you send instant messages
Applications 115
and emails, make phone calls, and get directions to your friends’
locations.
•More
: allows you to select the following additional options:
–
Clear Map
: after viewing or following directions, this option resets the
map.
–
Starred Items
: allows you to see locations you have marked as a
favorite such as restaurants, museums, parks, etc.
–
Labs
: this is a testing ground for experimental features that aren’t ready
for primetime. They may change, break or disappear at any time. Click
on a Lab to enable or disable it.
–
Help
: displays the Google Mobile Help web page where you can receive
help on Google Maps.
–
Terms, Privacy & Notices
: displays the Terms and Conditions, Privacy
Policy, o r Legal Notices information. Select the desired information from
the pop-up menu.
–
About
: displays general information about Google maps such as
Version, Platform, Locale, Total data sent, Total data received, Free
memory, etc.
116
Market
Android Market provides access to downloadable applications
and games to install on your phone. Android Market also allows
you to provide feedback and comments about an application, or
flag an application that might be incompatible with your phone.
Before using the Android Market you must have a Google
Account. For more information, refer to “Using Gmail” on
page 62.
1. From the Home screen, tap ➔
Market
.
2. Sign in to your Google account.
3. The first time you sign in, the Android Market Terms of
Service will be displayed. Tap
Accept
to continue or
Decline
to exit.
4. Tap
Apps
or
Games
to download or purchase games or
applications. You can also download updates to existing
applications.
5. Follow on the on-screen instructions.
Note:
To use any downloaded market application that requires a USB
connection between your phone and your PC, you should first set the
USB setting to
Mass storage
. For more information, refer to “USB
Settings” on page 72.
Media Hub
Samsung Media Hub is your one stop for the hottest movie and
TV content. You can rent or purchase your favorite content and
watch from the convenience of anywhere.
For more information, refer to “Media Hub” on page 45.
Memo
This feature allows you to create a memo and send it via
Bluetooth or Messaging.
1. From the Home screen, tap ➔
Memo
➔
Create
memo
.
2. Type your Memo using the keypad and tap
Save
.
The memo will display in the memo list.
3. To send a Memo, tap and hold the Memo in the Memo list.
4. Tap
Bluetooth
or
Messaging
.
5. Enter the recipient information and tap
Send
. For more
information, refer to “Message Options” on page 62.
6. To modify a Memo, tap the pencil icon in the top left corner
of the Memo. Edit the Memo then tap
Save
.
7. You can change the color or your Memo by simply tapping
a color sample at the bottom of the display.
Applications 117
8. Press
to display the following options:
•Create
: allows you to create a new memo.
•Maximize/Minimize
: in the Memo list, allows you to see the entire
contents of your memos. Otherwise, only the first line will be
displayed for each memo in your list.
• Delete
: allows you to delete one or all of your memos.
Messaging
The Messaging feature allows you to send text messages and
multimedia messages to other phones and email addresses. For
more information, refer to “Creating and Sending Messages” on
page 61.
Music
Music allows you to play music files that you have stored on your
memory card. You can also create playlists. For more
information, refer to “Music Player” on page 46.
My Files
My Files allows you to manage your sounds, images, videos,
bluetooth files, Android files, and other memory card data in one
convenient location.
1. From the Home screen, tap ➔
My files
.
2. The following folders display:
•DCIM
: this is the default location for pictures and videos taken by
the device. Tap
DCIM
➔
Camera
to view the picture or video files.
For more information, refer to
“Accessing Pictures”
on
page 54. Also, see
“Accessing Videos”
on page 57.
• Android
: the Android folder stores files that are used in Android
applications.
•sd
: this folder displays all of the files that you have on your memory
card.
• Bluetooth
: this folder stores files sent via a Bluetooth device.
3. To add a new folder, press
➔
New folder
.
4. Enter a name for the new folder and tap
Done
.
Navigation
Navigation is an internet-connected GPS navigation system with
voice guidance. You can type or speak your destination.
Note:
For voice-guided navigation, you need to install text-to-speech support
from the Android Market.
Launching Navigation
1. From the Home screen, tap ➔
Navigation
.
2. Read the Navigation information page and tap
Accept
to
continue or
Don’t Accept
to exit.
The
Choose Destination
screen displays.
118
3. Select one of the following options:
• Speak Destination
: allows you to speak your destination.
• Type Destination
: allows you to use the keypad to enter your
destination.
•Contacts
: displays a list of all of your contacts that have addresses
listed.
• Starred Items
: allows you to keep a list of favorite destinations,
locations, restaurants, etc. Just tap a starred item to get directions.
• Recent Destinations
: allows you to access information on previous
destinations you have used.
Navigation Options
After the map displays, press for the following options:
•Search
: allows you to speak or type a destination, place, or service
to search for.
• Route Info
: provides an onscreen view of your start and destination
points along with distance in miles and approximate driving time in
minutes.
•Layers
: are additional items that you can have displayed on your
map. They include:
–
Traffic view
: displays real-time traffic conditions so you can plan the
fastest route.
–
Satellite
: allows you to see you map as a satellite image.
–
Parking
: allows you to
–
Gas Stations
: allows you to
–
ATMs & Banks
: allows you to
–
Restaurants
: allows you to
•Mute/Unmute
: allows you to mute or unmute your navigation
tones.
• Exit Navigation
: exits the Navigation application and returns you to
the Application Menu screen.
•More
: includes the following options:
–
Directions List
: displays the directions for your most recent
destination.
–
Set Destination
: displays the Choose Destination screen where you
can speak or type your destination.
–
Help
: takes you to the Google Mobile Help web page.
–
Terms, Privacy & Notices
: displays Terms and Conditions for Google
mobile products, the Google Privacy Policy, and Google legal notices.
Obtaining Driving Directions
Your phone’s built-in GPS hardware allows you to get real-time
driving directions to selected locations or establishments based
on your current location.
Using a Physical Address
1. From the Home screen, tap ➔
Navigation
.
2. Tap either
Speak Destination
or
Type Destination
.
Applications 119
3. If typing in the address, enter the address, City, and State
using the keypad. As you type, possible addresses will be
displayed. Tap on one when you see the address you want.
The route will be displayed.
4. The Voice guidance screen is displayed. For voice-guided
navigation you need to install text-to-speech support from
the Android Market. Tap
Install
to install the application or
tap
Skip
to exit.
Note:
You will need to be signed on to your Google account before
downloading applications from the Android Market. For more
information, refer to “Creating a New Google Account” on page 9.
5. As you drive the route display will be updated and you will
receive voice-guided navigation directions.
Nook
With the nook application, you can read best sellers, news
releases, favorite newspapers, and emagazines all delivered to
your device via 3G wireless or Wi-Fi.
Getting Started
To use the nook application, you will need to create a Barnes &
Noble account. To get started, follow these steps:
1. From the Home screen, tap ➔
nook
.
The nook main page displays.
2. Tap
get started
.
3. Enter the required information using the keypad and tap
Next
.
4. Select a security question from the drop-down list box and
enter the answer using the keypad.
5. Tap
Create Account
.
The nook main screen displays with your library. You are
now ready to use nook.
Shop Books
1. From the nook main page, tap
shop books
at the top of the
display.
2. Scroll thru the list to select an eBook by category, or enter
a title, subject, or author in the search bar and tap
Go
.
3. The eBook or a list of eBooks is displayed. Tap on
BUY NOW
to buy or tap
Get Free Sample
to get a small portion of the
eBook that you can sample.
4. Follow the onscreen instructions.
120
Reading
To read an ebook that you have purchased or a sample, follow
these steps:
1. From the nook main page, tap on an ebook.
2. Sweep the screen to the left to move to the next page.
3. Sweep the screen to the right to go back a page
4. Tap in the upper-right corner to make a bookmark.
5. Press ➔
Go To
then tap on the
Bookmarks
tab to go to
a previously set bookmark.
6. Press ➔
Library
to return to your library.
Nook Options
Options from the main page
1. From the nook main page, press .
2. The following options are available:
•Sort
: allows you to sort your Library contents by Recent, Title, or
Author.
•Filter
: allows you to display your Library, My Documents, or
Archive.
•Sync
: allows you to synchronize your library and the Barnes &
Noble catalog with your device.
•Shop
: allows you to shop for eBooks, magazines, and newspapers
from the Barnes & Noble eBookstore.
• My Account
: allows you to see the email address that you are
logged in as. Tap Log Out to log out of your account.
Options from within a document
While reading a document, press for the following options:
• Font Options
: allows you to set the font size and style.
• All Settings
: allows you to set page and text settings.
•Go To
: allows you to go to any item located in the table of contents.
You can also go to bookmarks that have been created.
• Details
: allows you to view a synopsis of the book and information
on the author.
•Sync
: allows you to synchronize the connection with the nook
website.
•Library
: allows you to view all of the reading material in your library.
Nook Settings
To modify settings for the nook application, follow these steps:
1. While in a document, press ➔
All Settings
.
2. The following options are available:
• Page Theme
: allows you to set the background color of the
document you are reading.
• Animated Page Turns
: you can set the pages to turn with
animation or you can have them slide to the next page.
Applications 121
• Lock Page Orientation
: allows you to set the page orientation to
Automatic, Portrait, or Landscape. Automatic sets the page
orientation depending on how our hold your device.
• Hide Status Bar
: allows you to hide the status bar which shows
time and battery life.
• Margins
: allows you to set the margin size of the document you are
reading.
• Line Spacing
: allows you to set the size of the line spacing for the
document you are reading.
• Justification
: allows you to set the text justification to the left or the
right.
• Adjust Brightness
: allows you to adjust the brightness on your
display.
Places
Places is an application that uses Google Maps and your location
to help you find Restaurants, Coffee, Bars, Hotels, Attractions,
ATMs, and Gas Stations. You can also add your own locations.
The Places application allows you to find the best sources for
business information across the web, including business listing
details, reviews, photos, nearby public transit, and other related
information. Business owners can provide additional details, like
photos, hours of operation, and coupons.
1. From the Home screen, tap ➔
Places
.
2. Tap on one of the business categories or tap on
Find places
to search for a particular business.
All of the businesses that are close to you will be
displayed.
3. Tap on a business that you want to see the details for.
4. The business details are displayed along with the following
options:
•Reviews
: allows you to read reviews that other customers have
made.
• Buzz about this place
: allows you to read public comments or see
pictures people have posted about this business.
• Share this place
: allows you to share the business information with
others by using Messaging, Bluetooth, or Gmail.
• Add as a contact
: allows you to save the business as a contact on
your tablet or your Google account.
•Report a problem
: allows you to report problems concerning
accessing the business’ information.
•More info
: allows you to access more detailed information on
location, phone number, menu, reviews, and business web site if
available.
122
5. From the Places main page, tap
Add
to add your own
business category.
Quickoffice
The Quickoffice application allows you to create and save
Microsoft Word and Excel documents. You can also view existing
Powerpoint presentations and PDFs.
1. Tap the
Name
field, then use the key pad to enter your
name.
2. Tap the
E-mail Address
field, then use the keypad to enter
your E-mail address.
3. Tap
Register No
w.
The Quickoffice screen is displayed.
4. The following Quickoffice applications are available:
•Quickword
: allows you to create and save Word documents on
your tablet. you can also access Word documents from your SD
card and your Recent Documents folder.
• Quicksheet
: allows you to create and save Excel spreadsheet
documents.
• Quickpoint
: allows you to view existing Powerpoint documents
from your SD card and your Recent Documents folder.
•QuickPDF
: allows you to view existing PDF documents from your
SD card and your Recent Documents folder.
5. Select an option and follow the on-screen instructions.
6. Press for additional options.
Settings
This widget navigates to the sound and phone settings for your
phone. It includes such settings as: display, security, memory,
and any extra settings associated with your phone. For more
information, refer to “Changing Your Settings” on page 70.
Talk
Google Talk is a free Windows and web-based application for
instant messaging offered by Google. Conversation logs are
automatically saved to a Chats area in your Gmail account. This
allows you to search a chat log and store them in your Gmail
accounts. For more information, refer to “Google Talk” on
page 64.
Task Manager
The Task Manager application provides information about the
processes and programs running on your tablet, as well as the
memory status. It can also be used to terminate processes and
applications.
To access the Task Manager, follow these steps:
1. From the Home screen, tap ➔
Task Manager
.
Applications 123
2. The Task Manager options are located at the top of the
screen. The following options are available:
• Active applications
: displays all of the applications that are
presently running on your tablet. Tap End to end an application, or
tap End all to end all running applications.
•Package
: displays the size of the application program package.
•Summary
: displays a summary of the tablet’s memory usage.
•Help
: displays tips on how to extend your battery life.
Video
The Video Player application plays video files stored on your
memory card. For more information, refer to “Video Player” on
page 48.
Voice Search
The Voice Search feature is a voice-activated application that
allows you to tell the phone what to search for and then the
phone activates a Google search based on what you said.
1. From the Home screen, tap ➔
Voice Search
.
– or –
From the main Home screen, tap on the right side of
the Google Search bar.
2. The
Speak now
screen will display. Speak clearly into the
microphone.
3. The
Working
screen will display as it searches for you.
4. Results will display on the screen. Tap a link to view the
information.
– or –
The
No matches found
screen will display if Voice Search
was not able to find a match. Tap
Try again
or
Cancel
.
World Clock
World Clock allows you to view the time of day or night in other
parts of the world. World Clock displays time in hundreds of
different cities, within all 24 time zones around the world.
1. From the Home screen, tap ➔
World clock
. The
clock for your location is displayed.
2. Tap to add another city to the World Clock.
– or –
Press
➔
Add city
.
3. Scroll through the list of cities to find the city you want to
add, or tap the Search bar and use the keypad to enter a
city to search for.
4. Tap the city you want to add. The clock for that city will
display.
124
5. To set Daylight Savings time, press
➔
DST settings
.
6. Tap the sun symbol next to the city to add or remove
Daylight Savings Time. Tap once to add 1 hour, and twice
to add 2 hours. If Daylight Savings Time is selected, the
sun symbol will appear orange with a 1 or 2.
Deleting a World Clock Entry
1. From the Home screen, tap ➔
World clock
➔
➔
Remove
.
2. Tap the city clocks you wish to delete. A checkmark will
appear.
3. Tap
Remove
.
YouTube
YouTube™ is a video sharing website on which users can upload
and share videos. The site is used to display a wide variety of
user-generated video content, including movie clips, TV clips,
and music videos, as well as video content such as video
blogging, informational shorts and other original videos.
Note:
YouTube is a data-intensive feature. It is recommended that you
upgrade to an unlimited data plan to avoid additional data charges.
1. From the Home screen, tap ➔
YouTube
.
2. Tap the search field to search for specific videos,
scroll down to browse through the main page thumbnails,
or scroll to the bottom to explore additional options.
3. To view a video, tap an available preview thumbnail or tap
the title link.
4. Press to access the following options:
•Search
: allows you to search YouTube.
•Upload
: allows you to upload your videos to YouTube.
• My account
: allows you to sign-in to your YouTube account.
•Categories
: allows you to narrow down the videos that are
displayed on your screen. Tap a category.
• Settings
: allows you to view videos in High Quality, change the font
size, clear search history, block restricted content, and view the
terms of service.
Note:
It is not necessary to sign in to the YouTube site to view content.
However, if you wish to sign in to access additional options, tap
➔
My account
, enter your YouTube or Google username and
password, and tap
Sign in
.
51
Exposure to Radio Frequency (RF) Signals
Your wireless device is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are derived
from the recommendations of two expert organizations,
the National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical
and Electronics Engineers (IEEE). In both cases, the
engineering experts drawn from industry, government,
The exposure limit set by the FCC for wireless mobile
devices employs a unit of measurement known as the
the rate of absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg). The FCC
requires wireless devices to comply with a safety limit
of 1.6 watts per kilogram (1.6 W/kg). The FCC exposure
limit incorporates a substantial margin of safety to give
additional protection to the public and to account for
any variations in measurements.
SAR tests are conducted using recommendedoperating
positions accepted by the FCC with the GALAXY
tested frequency bands. Although the SAR is determined
of the GALAXY while operating can be well below the
maximum value. This is because the GALAXY is designed
to operate at multiple power levels so as to use only the
power required to reach the network. In general, the
closer you are to a wireless base station antenna, the
lower the power output.
Before a new model device is available for sale to the
it does not exceed the exposure limit established by
the FCC. Tests for each model GALAXY are performed in
positions and locations (e.g. near the body) as required
by the FCC.
Health and safety information
For typical operations, this model GALAXY has been
tested and meets the FCC exposure guidelines.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
SAR information on this and other model GALAXYs can
be viewed on-line at http://www.fcc.gov/oet/ea/fccid/.
This site uses the FCC ID number A3LGTP1010
You can check the FCC ID on the rear case.
Once you have the FCC ID number for a particular GALAXY,
follow the instructions on the website and it should
provide values for typical or maximum SAR for
a particular GALAXY
SAR information can also be obtained at www.fcc.gov/
cgb/sar.
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your GALAXY
forbidden to use it, or when it may cause interference or
danger. When connecting the GALAXY or any accessory to
another device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
FCC Notice and Cautions
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The GALAXY may cause TV or radio interference if used in close proximity to
receiving equipment. The FCC can require you to stop using the GALAXY if such
interference cannot be eliminated. Vehicles using petroleum gas (such as
propane or butane) must comply with the National Fire Protection Standard
(NFPA-58). For a copy of this standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA 02269, Attn: Publication Sales
Division.
Cautions
Changes or modifications made in the radio device, not expressly
approved by Samsung, will void the user’s authority to operate the
equipment.
Only use approved batteries, antennas and chargers. The use of any
unauthorized accessories may be dangerous and void the device warranty
if said accessories cause damage or a defect to the device.
Although your device is quite sturdy, it is a complex piece of equipment
and can be broken. Avoid dropping, hitting, bending or sitting on it.
Within the 5.15–5.25 GHz band, UNII devices will be restricted to indoor
operations to reduce any potential for harmful interference to co-channel
MSS operations.
