Samsung Electronics Co MC769N Microwave Oven User Manual
Samsung Electronics Co Ltd Microwave Oven Users Manual
Users Manual
Microwave
Oven
Owner’s Manual
MC1360WA/MC1360BA
MC1360SA
CODE NO. : DE68-01957A
^]`_jv}lyUmtGGwGXGGmSGhGZXSGYWWXGGXaX]Gwt
2
SAFETY
SAVE THESE INSTRUCTIONS
SAFETY
P
RECAUTIONS TO
A
VOID
P
OSSIBLE
E
XPOSURE TO
E
XCESSIVE
M
ICROWAVE
E
NERGY:
(a) Do not attempt to operate this oven with
the door open since open-door
operation can result in harmful
exposure to microwave energy. It is
important not to defeat or tamper with
the safety interlocks.
(b) Do not place any object between the
front face of the oven and the door or
allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) Do not operate the oven if it is
damaged. It is particularly important
that the oven door close properly and
that there is no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or
loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or
repaired by anyone except properly
qualified service personnel.
WARNING
Always observe Safety Precautions
when using your oven. Never try to
repair the oven on your own – there
is dangerous voltage inside. If the
oven needs to be repaired, call
1-800-SAMSUNG for the name of an
authorized service center near you.
IMPORTANT SAFETY
INSTRUCTIONS
When using any electrical appliance, basic
safety precautions should be followed,
including the following:
WARNING
To reduce risk of burns, electric
shock, fire, personal injury or
exposure to excessive microwave
energy:
• Read all safety instructions before using the
appliance.
• Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” on this page.
• This appliance must be grounded. Connect only
to properly grounded outlets. See “IMPORTANT
GROUNDING INSTRUCTIONS” on page 4 of this
manual.
• Install or place this appliance only in
accordance with the installation instructions
provided.
• Some items, like whole eggs and food in sealed
containers, may explode if heated in this oven.
• Use this appliance only for its intended use as
described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type
of oven is specifically designed to heat, cook, or
dry food. It is not designed for industrial or
laboratory use.
• As with any appliance, close supervision is
necessary when used by children.
^]`_zUGGwGYGGmSGhGZXSGYWWXGGXaXYGwt
SAFETY
3
SAFETY
SAVE THESE INSTRUCTIONS
Important Safety Instructions
(continued)
• Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly, or if it
has been damaged.
• This appliance should be serviced only by
qualified service personnel. Contact the nearest
authorized service facility for examination,
repair, or adjustment.
• Do not cover or block any of the openings on this
appliance.
• Do not store this appliance outdoors. Do not use
near water – for example, near a kitchen sink, in
a wet basement, or near a swimming pool, etc.
• Keep the inside of the oven clean. Food particles
or spattered oils stuck to the oven walls or floor
can cause paint damage and reduce the
efficiency of the oven.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or
counter.
• When cleaning door and oven surfaces, use only
mild, nonabrasive soaps or detergents applied
with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a. Do not overcook food. Watch appliance care-
fully if paper, plastic, or other combustible
materials are inside.
b. Remove wire twist-ties from plastic cooking
bags before placing bags in oven.
c. If materials inside the oven ignite, keep the
oven door closed, turn the oven off,
disconnect the power cord, or shut off the
power at the fuse or circuit breaker panel.
d. Do not use the oven compartment for storage
purposes. Do not leave paper products,
cooking utensils, or food in the oven when not
in use.
• Do not cook without the glass tray in place on
the oven floor. Food will not cook properly
without the tray.
• Do not defrost frozen beverages in narrow-
necked bottles. The containers can break.
• Dishes and containers can become hot. Handle
with care.
• Carefully remove container coverings, directing
steam away from hands and face.
• Remove lids from baby food before reheating.
After heating baby food, stir well and test
temperature by tasting before serving.
• A short power-supply cord is provided to reduce
the risk of becoming entangled in or tripping over
a longer cord. Longer cord sets or extension
cords are available and may be used with
caution.
• Do not operate any other heating or cooking
appliance beneath this appliance.
• Do not mount unit over or near any portion of a
heating or cooking appliance.
• Do not mount over a sink.
• Do not store anything directly on top of the
appliance when it is in operation.
• This product should be mounted at least 915mm
above the floor.
^]`_zUGGwGZGGmSGhGZXSGYWWXGGXaXYGwt
4
SAFETY
SAVE THESE INSTRUCTIONS
SAFETY
Important Grounding
Instructions
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electrical current. This appliance is equipped with a
cord that includes a grounding wire and a grounding
plug. The plug must be plugged into an outlet that is
properly installed and grounded.
Plug the three-prong power cord into a properly
grounded outlet of standard 115-120 voltage, 60 Hz.
Your oven should be the only appliance on this circuit.
WARNING
Improper use of the grounding plug can result
in a risk of electric shock. Consult a qualified
electrician or servicer if you do not understand
the grounding instructions or if you are not
sure if the appliance is properly grounded.
Use of Extension Cords
A short power-supply cord is provided to reduce the
risk of becoming entangled in or tripping over a
longer cord. Longer cord sets or extension cords are
available and may be used if care is exercised in
their use. If a long cord or extension cord is used:
1. The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance.
2. The extension cord must be a grounding-type
3-wire cord and it must be plugged into a 3-slot
outlet.
3. The longer cord should be arranged so that it will
not drape over the counter top or tabletop where it
can be pulled on by children or tripped over
accidentally. If you use an extension cord, the
interior light may flicker and the blower may vary
when the microwave oven is on. Cooking times
may be longer, too.
WARNING
Do not cut or remove the third (ground)
prong from the power cord under any
circumstances.
Note
Connect the oven to a 20A circuit. When connecting
the oven to a 15A circuit, make sure that circuit
breaker is operable
^]`_zUGGwG[GGmSGhGZXSGYWWXGGXaXYGwt
CONTENTS
5
CONTENTS
Safety.......................................................2
Your New Microwave Oven
Checking Parts ............................................. 6
Setting Up Your Microwave Oven ............ 6
Control Panel Buttons ................................. 7
Operation
Using the My Choice feature ..................... 8
Selecting the Display Weight .................... 8
Setting the Clock 12HR/24HR ..................... 9
Setting the Clock .......................................... 9
Setting the Daylight Savings Time
adjustment .................................................... 9
Using the Pause/Cancel Button ................ 9
Using the Help system .............................. 10
Using the Instant Cook Buttons ............... 10
Instant Cook Chart ..................................... 10
Using the One Minute+ Button ................ 10
Using Time Plus ......................................... 11
Setting and Using the Custom Cook
Button .......................................................... 11
Automatic Defrosting ................................ 12
Automatic Reheating ................................ 12
Auto Reheat Chart ..................................... 13
Automatic Cooking .................................... 13
Auto Cook Chart ......................................... 14
Setting Cooking Times & Power Levels . 15
One-stage Cooking ............................ 15
Multi-stage Cooking .......................... 15
Convection Cooking .................................. 16
Broiling ........................................................ 16
Combination Cooking ................................ 17
Preheating the Oven ................................. 18
Using the More or Less Button ............... 18
Adjusting the Volume ................................ 19
Using the Kitchen Timer ........................... 19
Setting the Child Protection Lock ........... 19
Demonstration Mode ................................ 20
Setting the Remind End Signal ................ 20
Setting the Word Prompting Speed ........ 20
Cooking Instructions
Cooking Utensils .........................................21
Testing Utensils ..........................................21
Cooking Techniques ..................................22
General Tips ...............................................22
GUIDE for Cooking Meat in Your
Microwave ..................................................23
GUIDE for Cooking Poultry in Your
Microwave ..................................................23
GUIDE for Cooking Seafood in Your
Microwave ..................................................24
GUIDE for Cooking Eggs in Your
Microwave ..................................................24
GUIDE for Cooking Vegetables in Your
Microwave ..................................................24
AUTO DEFROSTING GUIDE .......................25
Recipes ........................................................26
CONVECTION BAKING GUIDE .................28
BROILING GUIDE ........................................29
COMBINATION COOKING GUIDE ............30
Appendix
Troubleshooting Guide ..............................31
Care and Cleaning ......................................31
Specifications. ............................................32
Warranty
Warranty Information.................................33
Quick Reference.........................Back Cover
^]`_{vjUGGwG\GGmSGhGZXSGYWWXGGXaYZGwt
6
YOUR NEW MICROWAVE OVEN
YOUR NEW MICROWAVE OVEN
Checking Parts
Unpack your microwave oven and check to make
sure that you have all the parts shown here. If any
part is missing or broken, call your dealer.
Thank You for Choosing Samsung
Your new oven represents the latest in microwave
cooking technology. This oven is a full-featured,
easy-to-use appliance built to strict quality
standards set by Samsung — the highest in the
industry. We’re proud to offer you a product that will
provide convenient, dependable service for years to
come.
Please record the serial number from the inside or
back of your Samsung microwave oven and the date
of purchase in the space provided below.
We recommend that you keep your purchase receipt
with this manual for easy warranty service.
Model Number _________________________
Serial Number _________________________
Date Purchased _________________________
Dealer _________________________
Setting Up Your Microwave Oven
1Place the oven on a flat, sturdy surface
and plug the cord into a grounded outlet.
Once plugged in, the display on your
oven will show:
Make sure there is adequate ventilation for your
oven by leaving at least four inches of space
behind, above, and to the sides of the oven.
2Open the oven door by pulling the handle on
the right side of the door.
3Wipe the inside of the oven with a damp cloth.
4Place the pre-assembled ring in the
indentation in the center of the oven.
5Place the glass tray on top of the ring so that
the three glass tabs in the center of
the tray fit securely into the tabs on the
floor of the oven.
microwave oven
instruction manual glass tray
registration card roller guide ring
Short metal rack
Tall metal rack
^]`_UGGwG]GGmSGhGZXSGYWWXGGXaXYGwt
YOUR NEW MICROWAVE OVEN
7
YOUR NEW MICROWAVE OVEN
Control Panel Buttons
Clock p. 9
Sets current time.
Instant Cook Buttons p. 10
Instant settings to cook popular foods.
Combo p. 17
Press to cook by automatically cycling
between microwave and convection cooking.
Help p. 10
Press to see help information about the
feature you are using.
Preheat p. 18
Press to preheat at requested temperature.
Auto Cook p. 13
Press to select Auto cook and weight.
Broil p. 16
Press to brown and cook with the electric coil.
More Button p. 18
Increases cooking time.
Less Button p. 18
Decreases cooking time.
Power Level p. 15
Sets power level.
One Minute+ p. 10
Press once for every minute of cooking at
High power.
Custom Cook p. 11
Press twice to program your favorite recipe .
Press once to cook with that recipe.
Auto Defrost p. 12
Sets weight of food to be defrosted.
Auto Reheat p. 12
Shows type and quantity of food to be
reheated.
Conv. / °F p. 16
Press to brown and cook quickly with
circulated hot air.
Number/Cooking Temperature Buttons
Sets cooking times or amounts and power
levels.
Kitchen Timer p. 19
Pause/Cancel p. 9
Press to pause oven or clear instructions.
Start/Time plus p. 11
Press to start cooking. Hold down to reach the
cooking time you want max. 1minute.
My Choice p. 8
Press to set non-cooking feature.
^]`_UGGwG^GGmSGhGZXSGYWWXGGXaXYGwt
8
OPERATION
OPERATION
Using the My Choice feature
Your new microwave oven can be customized to suit
your personal taste. Simply press My Choice to set
these options. For your convenience, all the options
are summarized in the following table:
Selecting the Display Weight
You can choose between pounds(LBS)
and kilograms(KG).
1Press My Choice button and then press the 1
button. The display shows "LBS OR KG"
2Press the My Choice button repeatedly to
select the weight measurements you wish to
use.
3Press the START button.
My
Choice
options Description Operation
1 Display
Weight Weight options
are pounds or
kilograms.
Press My Choice, 1 and
select by repeatedly
pressing My Choice.
To set, press Start.
2 Adjusting
the
Volume
Volume options
include Off, Low,
Medium and
High.
Press My Choice, 2 and
select by repeatedly
pressing My Choice.
To set, press Start.
3 Remind
End
Signal
The Remind End
Signal can be
turned On and
Off.
Press My Choice, 3 and
select by repeatedly
pressing My Choice.
To set, press Start.
4Child
Protecti-
on Lock
This feature
prevents use by
unsupervised
children.
Press My Choice, 4 and
select by pressing My
Choice. To set, press
Start.
5 Clock
12H/24H The clock can
display either
12H or 24H time
modes.
Press My Choice, 5 and
select by repeatedly
pressing My Choice.
To set, press Start.
6 Word
Prompt-
ing Speed
There are five
speeds, from
Level 1 (slowest)
to Level
3(fastest).
Default is Level
3.
Press My Choice, 6 and
select by repeatedly
pressing My Choice.
To set, press Start.
7 Daylight
Savings
Time
Adjust-
ment
The time can be
advanced on
hour for DST
without
resetting the
Clock.
Press My Choice, 7 and
select by repeatedly
pressing My Choice.
To set, press Start.
8 Demon-
stration
Mode
The Demo Mode
can be turned
On and Off.
Press My Choice, 8 and
select by repeatedly
pressing My Choice.
To set, press Start.
^]`_UGGwG_GGmSGhGZXSGYWWXGGXaXYGwt
OPERATION
9
OPERATION
Setting the Clock 12HR/24HR
The time can be displayed in either 24-hour
or 12-hour format.
1Press the My Choice button and then 5. The
display shows “CLOCK 12HR/24HR OPTION”.
2Press the My Choice button repeatedly to
select either 12HR or 24HR.
3Press the START button.
Setting the Clock
1Press the Clock button. The display
will show:
2Use the number buttons to enter the current
time. You must press at least three numbers to
set the clock. For example, if the current time
is 5:00, enter 5,0,0.
3Press Clock again. A colon will appear,
indicating that the time is set.
If there is a power interruption, you will need to
reset the clock.
You can check the current time while cooking is in
progress by pressing the Clock button.
Setting the Daylight Savings Time
adjustment
1Press the My Choice button and then 7. The
Display shows “DAY LIGHT SAVING TIME”.
2Press the My Choice button to select ON.
Press again to select OFF.
3Press the START button.
Time of day will advance one hour. If OFF is
selected, time will go back one hour.
If the clock is set for standard time, this function
allows convenient time changes without needing
to reset the clock. Daylight Saving Time begins for
most of the United Sates at 2 a.m. on the first Sun-
day of April, and reverts to Standard time at 2 a.m.
on the last Sunday of October.
Using the Pause/Cancel Button
The Pause/Cancel button allows you to clear
instructions you have entered. It also allows you to
pause the oven’s cooking cycle, so that you can
check the food.
• To pause the oven during cooking: press
Pause/Cancel once. To restart, press Start.
• To stop cooking, erase instructions, and return
the oven display to the time of day:
Press Pause/Cancel twice.
• To clear instructions you have just entered:
press Pause/Cancel once, then re-enter the
instructions.
• To cancel a timer setting: press Pause/Cancel
once.
^]`_UGGwG`GGmSGhGZXSGYWWXGGXaXYGwt
10
OPERATION
OPERATION
Using the Help system
Your microwave offers helpful instructions for many
procedures.
1When you need feature information and
helpful hints, press the Help button and then
press the button that you want to get
information on.
Using the Instant Cook Buttons
1Press the Instant Cook button corresponding
to the food you are cooking (Popcorn, for
example). The display shows the first
serving size:
2Press the button repeatedly to select the
serving size you want. The display will cycle
through all available serving sizes. Once you
select the correct serving size, the microwave
will begin cooking automatically.
If you don’t need to read all the MENU options,
simply press the Start button to begin cooking.
Instant Cook Chart
Using the One Minute+ Button
This button offers a convenient way to heat food in
one-minute increments at the High power level.
1Press the One Minute+ button once for each
minute you wish to cook the food.
For example, press it twice for two minutes.
The time will display, and the oven starts
automatically.
Add minutes to a program in progress by pressing
the One Minute+ button for each minute you want
to add.
Item Weight Remarks
Popcorn 3.5 oz
3.0-3.5 oz
1.75 oz
1.5-1.75 oz
• Use one microwave-only bag
of popcorn.
• Use caution when removing
and opening hot bag from
oven.
Potato 1 EA
2 EA
3 EA
4 EA
5 EA
6 EA
• Prick each potato several
times with fork.
• Place on turntable in spoke-
like fashion.
• When the oven emits signals
and display “turn food over”,
turn potato(es) over.
• Remove from oven, wrap in
foil and let stand 3-5 min.
Fresh
Vegetables 1 cup
2 cups
3 cups
4 cups
• Place the vegetables into a
casserole and add a small
amount of water(2-4 Tbsp).
Cover during cooking and
stir before serving.
Frozen Dinner 7-10 oz
10-12 oz
12-18 oz
• Remove package from outer
wrapping and follow
package instructions for
covering and standing. After
cooking, let stand 1-3 min.
Diet Cook
Low calorie
Frozen Dinner
7-10 oz
10-12 oz
12-18 oz
^]`_UGGwGXWGGmSGhGZXSGYWWXGGXaXYGwt
OPERATION
11
OPERATION
Using Time Plus
This button offers a convenient way to heat food in
one-second increments at the High power level.
1Keep the Time Plus button held down in order
to reach the cooking time that you want.
The time will display, and the oven starts
automatically.
This button can increase heating time a
maximum of 60 seconds.
Setting and Using the Custom Cook
Button
The Custom Cook button memorizes the time and
power setting for a particular food.
Programming the Custom Cook button
1Press the Custom Cook button.
The display shows “ENTER COOKING TIME
AND POWER.”
2Use the Number buttons to enter the cooking
time. The display will show the amount of time
you have set.
3Press Power Level and use the Number
buttons to enter the power level. The display
will show the power level you have set. You
can set the power level from 0 to 9.
1 = warm 6= simmer
2 = low 7 = medium high
3 = defrost 8 = reheat
4 = medium low 9 = sauté
5 = medium 0 = high
4Press the Custom Cook button again. The
display will read “CUSTOM RECIPE SAVED.”
Using the Custom Cook button
Press the Custom Cook button after memorizing a
recipe, then press the Start button.
You can check the power level while cooking is in
progress by pressing the Power Level button.
Press the Custom Cook button twice to change the
previous Custom setting.
^]`_UGGwGXXGGmSGhGZXSGYWWXGGXaXYGwt
12
OPERATION
OPERATION
Automatic Defrosting
To thaw frozen food, set the weight of the food and
the microwave automatically sets the defrosting
time, power level and standing time.
1Press the Auto Defrost button. The display
shows “0.5 LB.”(0.2Kg if you have set your
oven for metric measure).
2To set the weight of your food, press the
Auto Defrost button repeatedly.
This increases the weight by 0.5 lb
increments, up to 6.0 lbs.
You can also use the number buttons to enter
the weight of the food directly.
The oven calculates the defrosting time and
starts automatically. Twice during defrosting,
the oven will beep and the display will read
“TURN FOOD OVER.”
3Open the oven door, and turn the food over.
4After closing the door, press the Start button
to resume defrosting.
• See page 25 for the Auto Defrosting
Guide
Automatic Reheating
To reheat food, select the type of dish and the
number of servings you want to reheat, and the
microwave automatically sets the reheating time.
1Press the Auto Reheat button repeatedly
to select the type of dish you wish to reheat.
The initial serving size for each dish is one
serving.
Plate of food
Casserole
Soup /Sauce
You can select up to four servings for
casseroles and soup. Only one serving is
available for a plate of food.
The display shows the dish and quantity you
have chosen, then “PRESS START.”
2Use the Number buttons to increase the
serving size. For example, for three servings,
press the“3” button. The display shows the
number of servings you have selected:
3Press the Start button. The display will
show “REHEAT.”
^]`_UGGwGXYGGmSGhGZXSGYWWXGGXaXYGwt
OPERATION
13
OPERATION
Auto Reheat Chart Automatic Cooking
Cooking your favorite foods is easy with the AUTO
COOK buttons (Auto Bake, Auto Broil and Auto
Roast). You simply select the type of food you want
to cook and the serving size, then the cooking time is
automatically set.
1Press the Auto Broil button repeatedly to
select of food you want to cook. (Fish, for
example)
The display shows "FISH"
2Some menu items offer several options for
better cooking results. In the case of Fish, “1”
is thin, and “2” is thick. If you choose thick,
press”2”.
The display shows "0.5-1.5 LBS, THICK"
Refer to the Auto Cook Chart next page for the
servings.
3Press START.
The display will show the type of food you
have selected as it cooks.
If you want to see the remaining cooking time,
press AUTO COOK (Auto Bake, Auto Broil,
Auto Roast).
If you want to adjust the heating time, use the
MORE or LESS button, see page 18.
If you want to check the current time while
reheating, press the CLOCK button.
Item Weight Remarks
Plate of
Food 1 serving • Cover plate with vented
plastic wrap or wax paper
• Contents
- 3-4 oz. meat, poultry or
fish (up to 6 oz. With bone)
- 1/2 cup starch (potatoes,
pasta, rice, etc.)
- 1/2 cup vegetable (about
3-4 oz.)
Casserole 1 to 4 servings
(8 oz./serving) • Cover with lid or vented
plastic wrap.
Soup/
Sauce 1 to 4 servings
(8 oz./serving) • Stir foods once before
serving.
^]`_UGGwGXZGGmSGhGZXSGYWWXGGXaXYGwt
14
OPERATION
OPERATION
Auto Cook Chart
• If foods are more underdone or overdone than desired, use the MORE or LESS buttons for personal taste.
• Use a round metal pizza pan as a "cookie sheet".
• An 8"-9" pie plate may be placed on the glasstray directly under the rack to catch any drippings.
REMARK
1) Cake - This item has 2 categories, layer and bundt/angel food cake.
2) Fish - This item has 2 categories, thin and thick.
Thick turn over at half cooking time.
FUNCTION ITEM RACK PROCEDURE
Auto Bake 1. CAKE
(1 layer cake)
Bundt
(1 bundt cake)
LOW
LOW
Pour batter into 8 or 9" round pan; place on rack. Touch
Auto Bake once, touch 1 again, touch START.
Pour batter into bundt pan, place in rack, touch Auto
Bake once, touch 2, touch START.
2. FROZEN PIZZA
(16 to 35 oz.) LOW Place unwrapped pizza directly on rack.
Touch Auto Bake twice, touch START.
3. COOKIES
(12 cookies)
CUPCAKES
(6 cupcakes)
LOW
LOW
Drop cookie dough evenly around and in center of
pizza pan. Touch Auto Bake three times, touch START.
Divide batter evenly between 6 cup metal muffin pan.
Touch Auto Bake three times, touch START.
Auto Broil 1. HAMBURGERS
(1 TO 4 patties) HIGH Spray rack with vegetable oil spray. Place burgers on
rack. Touch Auto Broil once, touch START.
2. CHICKEN PIECES
(0.5 to 2 LBS.) HIGH Spray rack with vegetable oil spray. Place chicken
pieces on rack; touch Auto Broil twice, touch START.
3. APPETIZERS
(1-12 bite-sized) HIGH Place appetizers on rack with at least 1/2 inch apart.
Touch Auto Broil three times, touch START.
4. FISH
(Thin) (0.5-1.5 lbs.)
FISH
(Thick) (0.5-1.5
lbs.)
HIGH
HIGH
Spray rack with vegetable oil spray. Touch Auto Broil
four times, touch 1, touch START.
Spray rack with vegetable oil spay. Touch Auto Broil
four times, touch 2, touch START.
Turn fish over at half the cooking time.
Auto Roast 1. ROAST MEAT
(2-5 LBS.) LOW Spray rack with vegetable oil spray. Place meat on
rack, fat side up. Touch Auto Roast once, enter number
for weight (ex: “3” for 3 pounds), touch START.
2. ROAST CHICKEN
(3-6 LBS.) LOW Spray rack with vegetable oil spray. Place chicken on
rack, breast side up. Touch Auto Roast twice, enter
number for weight, touch START.
3. CASSEROLE
(1-2 QTS) LOW Place dish in rack. Touch Auto Roast three times, touch
START. If casserole is very dense, use MORE button.
4. MEATLOAF
(1-2 LBS.) LOW Pat meatloaf mixture into oval shape in pie dish. Place
on rack, touch Auto Roast four times, touch START.
^]`_UGGwGX[GGmSGhGZXSGYWWXGGXaXYGwt
OPERATION
15
OPERATION
Setting Cooking Times & Power Levels
Your microwave allows you to set up to two different
stages of cooking, each with its own time and power
level. The power level lets you control the heating
intensity from Warm (1) to High (0).
One-stage Cooking
For simple one-stage cooking, you only need to set a
cooking time. The power level is automatically set at
High. If you want the power set at any other level,
you must use the Power Level button.
1Use the number buttons to set a cooking time.
You can set a time from one second to 99
minutes, 99 seconds. To set a time over one
minute, enter the seconds as well. For
example, to set 20 minutes, enter 2, 0, 0, 0 .
2If you want to set the power level to
something other than High, press the Power
Level button, then use the number buttons to
enter a power level.
Power Levels:
1 = warm 6 = simmer
2 = low 7 = medium high
3 = defrost 8 = reheat
4 = medium low 9 = sauté
5 = medium 0 = high
The display shows “PRESS START OR ENTER NEXT
STAGE COOKING TIME”
3Press the Start button to begin cooking.
If you want to change the power level,
press Pause/Cancel before you press Start,
and re-enter all of the instructions.
Multi-stage Cooking
Some recipes require different stages of cooking at
different temperatures. You can set multiple stages
of cooking with your microwave.
When convection is set with microwave cooking, the
convection is always followed after microwave
cooking.
1Follow steps 1 and 2 in the “One-Stage
Cooking” section on this page. The display
shows “PRESS START OR ENTER NEXT
STAGE”.
When entering more than one cooking stage, the
Power Level button must be pressed before the
second cooking stage can be entered.
To set the power level at High for a stage of
cooking, press the Power Level button twice.
2Use the Number buttons to set a second
cooking time.
3Press the Power Level button, then use the
number buttons to set the power level of the
second stage of cooking. The display shows
“PRESS START ”.
4Press Start to begin cooking.
^]`_UGGwGX\GGmSGhGZXSGYWWXGGXaXYGwt
16
OPERATION
OPERATION
Convection Cooking
The convection mode uses dry heat to cook and
brown foods. A high-speed fan circulates hot air
inside the oven to heat food quickly and evenly.
Convection cooking is ideal for foods that require
browning or crisping coupled with a short cooking
time. When cooking with the convection feature, use
the short metal rack to elevate food so that air can
circulate completely around the dish.
To cook with the convection oven,
1Use the number buttons to set a cooking time.
The display reads "PRESS START OR
FUNCTION PAD."
2Press CONV./ °F.
The display shows "ENTER DESIRED TEMP OR
PRESS START".
3To set the cooking temperature, press the
number buttons.
Temperatures in convection cooking range
from 100°F to 450°F. To maintain a constant
temperature, the oven door should be kept
closed as much as possibile while cooking.
4Press START to begin convection cooking
Broiling
You can broil in your Samsung microwave oven.
Broiling uses a heating coil to cook and brown the
food. When broiling, use the tall metal rack to raise
the food up close to the heating coil at the top of the
oven.
1Use the number buttons to set a broiling time.
The display reads "PRESS START OR
FUNCTION PAD"
2Press BROIL.
The display shows "450F" then "PRESS START".
3Press START to begin broiling.
^]`_UGGwGX]GGmSGhGZXSGYWWXGGXaXYGwt
OPERATION
17
OPERATION
Combination Cooking
The combination cooking feature allows you to cycle
automatically between microwave and convection
cooking for food that is moist as well as crisp and
brown. This type of cooking is ideal for large foods
that require a long cooking time when prepared in a
conventional oven (such as dense cakes, large
roasts, and turkeys). When combination cooking, use
the short metal rack to allow air to circulate
completely around the dish.
- To use combination cooking,
1Use the number buttons to set a cooking time.
The display reads "PRESS START OR
FUNCTION PAD."
2Press Combo-1(or Combo-2).
The display shows "350F" then " PRESS
START".
3Press START.
• Combo-1 : MWO 10% + Conv. 350°F
• Combo-2 : MWO 30% + Conv. 350°F
Combination cooking can also be set by following
the instructions below.
1Press Combo-1 (or Combo-2).
The display shows "350F" then "PRESS START
OR ENTER COOKING TIME"
2Use the number buttons to set a cooking time.
The display shows "PRESS START".
3Press START.
• Combo-1 : MWO 10% + Conv. 350°F
• Combo-2 : MWO 30% + Conv. 350°F
^]`_UGGwGX^GGmSGhGZXSGYWWXGGXaXYGwt
18
OPERATION
OPERATION
Preheating the Oven
Some recipes may call for preheating the oven
before you cook with convection, combination, or
broil cooking. To preheat the oven,
1Press Preheat, Combo or Broil.
You can set a specific preheating temperature
in convection mode. The temperature, allowed
is 100°F ~ 450°F.
2Press START.
When the oven reaches the desired
temperature, it will chime and display shows
"PREHEAT DONE, PLACE FOOD IN OVEN".
When the oven beeps, place the food inside
and follow the directions for “Convection
Baking”, "Combination Cooking," or "Broiling."
Do not put food in the oven in preheating.
Using the More or Less Button
The More or Less button allows you to adjust pre-set
cooking times. It only works with Auto Reheat, Auto
Cook the Instant-cook buttons. Use the More or Less
button only after cooking has begun.
1To ADD more time to an automatic cooking
procedure, press the 9/More button. The
word “MORE” will appear in the display.
2To REDUCE the time of an automatic cooking
procedure, press the 1/Less button. The word
“LESS” will appear in the display.
3To return to the NORMAL time set for an
automatic cooking procedure, press the
9/More or 1/Less button until the word
“NORMAL” appears in the display.
^]`_UGGwGX_GGmSGhGZXSGYWWXGGXaXYGwt
OPERATION
19
OPERATION
Adjusting the Volume
The Sound function on the microwave allows you to
adjust the volume of the microwave’s chime sound.
The sound is initially set to its medium setting. To
change the volume,
1Press the My Choice button and then press 2.
The display shows
“SOUND VOLUME CONTROLS”
2Press the My Choice button repeatedly to
select volume.
3Press Start:
The display returns to the time of day.
Using the Kitchen Timer
1Use the Number buttons to set the length of
time you want the timer to run.
2Press the Kitchen Timer button.
3The display counts down and beeps
when the time has elapsed.
Setting the Child Protection Lock
You can lock your microwave oven so it can’t be
used by unsupervised children.
1Press the My Choice button and then Press
the 4 button.
The display shows "CHILD LOCK ON/OFF."
2Press the My Choice button once to select the
ON. Press again to select OFF.
3Press the Start button. The display returns to
the time of day.
At this point, the microwave oven cannot be used
until it is unlocked. To unlock it, repeat steps 1–3
above.
^]`_UGGwGX`GGmSGhGZXSGYWWXGGXaXYGwt
20
OPERATION
OPERATION
Demonstration Mode
You can use the Demonstration Mode to see how
your microwave oven operates without the oven
heating.
1Press the My Choice button and then Press 8.
The display shows "DEMO MODE ON/OFF"
2Press the My Choice button once to select the
ON. Press again to select OFF.
3Press the Start button. The display returns to
the time of day.
To turn demo mode off, repeat steps 1–3
above.
Setting the Remind End Signal
The Remind End signal can be set On or Off.
1Press the My Choice button and then press 3.
The display shows “REMIND END SIGNAL
ON/OFF”.
2Press the My Choice button to select "ON".
3Press the START button.
The display returns to the time of day.
Setting the Word Prompting Speed
This set the scroll speed of the word display.
1Press the My Choice button and then press 6.
The display shows "WORD PROMPT SPEED".
2Press the My Choice button to select the
appropriate scroll speed.
3Press the START button.
The display returns to the time of day.
^]`_UGGwGYWGGmSGhGZXSGYWWXGGXaXYGwt
COOKING INSTRUCTIONS
21
COOKING INSTRUCTIONS
Cooking Utensils
Recommended Use
• Glass and glass-ceramic bowls and dishes —
Use for heating or cooking.
• Microwave browning dish — Use to brown the
exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with
your browning dish.
• Microwavable plastic wrap — Use to retain
steam. Leave a small opening for some steam to
escape and avoid placing it directly on the food.
• Wax paper — Use as a cover to prevent spattering.
• Paper towels and napkins — Use for short-term
heating and covering; they absorb excess
moisture and prevent spattering. Do not use
recycled paper towels, which may contain metal
and can catch fire.
• Paper plates and cups — Use for short-term
heating at low temperatures. Do not use recycled
paper, which may contain metal and can catch
fire.
• Thermometers — Use only those labeled
“Microwave Safe” and follow all directions.
Check the food in several places. Conventional
thermometers may be used once the food has
been removed from the oven.
Limited Use
• Aluminum foil — Use narrow strips of foil to
prevent overcooking of exposed areas. Using too
much foil can damage your oven, so be careful.
• Ceramic, porcelain, and stoneware — Use these if
they are labeled “Microwave Safe.” If they are not
labeled, test them to make sure they can be used
safely. Never use dishes with metallic trim.
• Plastic — Use only if labeled “Microwave Safe.”
Other plastics can melt.
• Straw, wicker, and wood — Use only for short-
term heating, as they can be flammable.
Not Recommended
• Glass jars and bottles — Regular glass is too thin
to be used in a microwave, and can shatter.
• Paper bags — These are a fire hazard, except
for popcorn bags that are designed for
microwave use.
• Styrofoam plates and cups — These can melt and
leave an unhealthy residue on food.
• Plastic storage and food containers —
Containers such as margarine tubs can melt in
the microwave.
• Metal utensils — These can damage your oven.
Remove all metal before cooking.
Testing Utensils
If you are not sure whether a dish is microwave-safe
or not, you can perform this test:
1Fill a 1 cup glass measuring cup with
water and put it inside your oven, next to
the dish you want to test.
2Press the One Minute+ button once to heat
them for one minute at High power.
The water should be warm and the dish you are
testing should be cool. If the dish is warm, then it is
absorbing microwave energy and is not acceptable
for use in the microwave.
^]`_UGGwGYXGGmSGhGZXSGYWWXGGXaXYGwt
22
COOKING INSTRUCTIONS
COOKING INSTRUCTIONS
Cooking Techniques
Stirring
Stir foods such as casseroles and vegetables while
cooking to distribute heat evenly. Food at the outside
of the dish absorbs more energy and heats more
quickly, so stir from the outside to the center.
The oven will turn off when you open the door to
stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken
pieces or chops, with the thicker, meatier parts
toward the outside of the turntable where they
receive more microwave energy. To prevent
overcooking, place thin or delicate parts toward the
center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to
prevent overcooking. Areas that need shielding
include poultry wing-tips, the ends of poultry legs,
and corners of square baking dishes. Use only small
amounts of aluminum foil. Larger amounts can
damage your oven.
Turning
Turn foods over midway through cooking to expose
all parts to microwave energy. This is especially
important with large items such as roasts.
Standing
Foods cooked in the microwave build up internal
heat and continue to cook for a few minutes after the
oven stops. Let foods stand to complete cooking,
especially foods such as roasts and whole
vegetables. Roasts need this time to complete
cooking in the center without overcooking the outer
areas. All liquids, such as soup or hot chocolate,
should be shaken or stirred when cooking is
complete. Let liquids stand a moment before serving.
When heating baby food, stir well and test the
temperature before serving.
Adding Moisture
Microwave energy is attracted to water molecules.
Food that is uneven in moisture content should be
covered or allowed to stand so that the heat
disperses evenly. Add a small amount of water to dry
food to help it cook.
General Tips
• Dense foods, such as potatoes, take longer to
heat than lighter foods. Foods with a delicate
texture should be heated at a low power level to
avoid becoming tough.
• Altitude and the type of cookware you are using
can affect cooking time. When using a new
recipe, use the minimum cooking time and check
the food occasionally to prevent overcooking.
• Foods with a non-porous skin or shell, such as
potatoes, eggs, or hot dogs, should be pierced
to prevent bursting.
• Frying with heating oil or fat is not recommended.
Fat and oil can suddenly boil over and cause
severe burns.
• Some ingredients heat faster than others.
For example, the jelly inside a jelly doughnut will
be hotter than the dough. Keep this in mind to
avoid burns.
• Home canning in the microwave oven is not
recommended because all harmful bacteria may
not be destroyed by the microwave heating
process.
• Although microwaves do not heat the cookware,
the heat is often transferred to the cookware.
Always use pot holders when removing food from
the microwave and instruct children to do the
same.
^]`_UGGwGYYGGmSGhGZXSGYWWXGGXaXYGwt
COOKING INSTRUCTIONS
23
COOKING INSTRUCTIONS
GUIDE for Cooking Meat in Your Microwave
• Place meat on a microwave-safe roasting rack in a microwave-safe dish.
• Start meat fat-side down. Use narrow strips of aluminum foil to shield any bone tips or thin meat areas.
• Check the temperature in several places before letting the meat stand the recommended time.
• The following temperatures are removal temperatures. The temperature of the food will rise during the
standing time.
GUIDE for Cooking Poultry in Your Microwave
• Place poultry on a microwave-safe roasting rack in a microwave-safe dish.
• Cover poultry with wax paper to prevent spattering.
• Use aluminum foil to shield bone tips, thin meat areas, or areas that start to overcook.
• Check the temperature in several places before letting the poultry stand the recommended time.
Food Cook Time /Power Level Directions
Roast Beef
Boneless
Up to 4 lbs.
Cooking Time:
8-11 min. / lb. for 115° F - Rare
9-13 min. / lb. for 120° F - Medium
10-15 min. / lb. for 145° F - Well Done
Power Level: High(0) for first 5 min., then Medium(5).
Place roast fat-side down on roasting
rack. Cover with wax paper. Turn over
when cooking time is half up. Let stand
10 min.
Pork
Boneless or
bone-in
Up to 4 lbs.
Cooking Time:
11-15 min. / lb. for 160° F Well Done
Power Level: High(0) for first 5 min., then Medium(5).
Place roast fat-side down on roasting
rack. Cover with vented plastic wrap.
Turn over when cooking time is half
up. Let stand 10 min.
Bacon
2-6 slices
Cooking Time:
2 slices: 1- 1 3/4 min.
4 slices: 3- 3 1/2 min.
6 slices: 4 1/2-5 1/2 min.
Power Level: High(0).
Arrange slices on roasting rack or a
dish lined with paper-towel. Cover
with paper towel. Microwave until
crisp.
Food Cook Time /Power Level Directions
Whole
Chicken
Up to 4 lbs.
Cooking Time:
5-8 min. / lb. 170° -180°F
Power Level: Medium High(7).
Place chicken breast-side down on roasting
rack. Cover with wax paper. Turn over when the
cooking time is half up. Cook until juices run
clear and meat near the bone is no longer pink.
Let stand 5-10 min.
Chicken
Pieces
Up to 11/2 lbs
Cooking Time:
5-8 min. / lb.
180°F dark meat
170°F light meat
Power Level: Medium High(7).
Place chicken bone-side down on dish, with the
thickest portions towards the outside of the dish.
Cover with wax paper. Turn over when the
cooking time is half up. Cook until juices run
clear and meat near the bone is no longer pink.
Let stand 5-10 min.
^]`_UGGwGYZGGmSGhGZXSGYWWXGGXaXYGwt
24
COOKING INSTRUCTIONS
COOKING INSTRUCTIONS
GUIDE for Cooking Seafood in Your Microwave
• Cook fish until it flakes easily with a fork.
• Place fish on a microwave-safe roasting rack in a microwave-safe dish.
• Use a tight cover to steam fish. A lighter cover of wax paper or paper towel provides less steaming.
• To avoid overcooking fish, check it at minimum cooking time.
GUIDE for Cooking Eggs in Your Microwave
• Never cook eggs in the shell, and never warm hard-boiled eggs in the shell; they can explode.
• Always pierce whole eggs to keep them from bursting.
• Cook eggs just until set; they become tough if overcooked.
GUIDE for Cooking Vegetables in Your Microwave
• Vegetables should be washed just before cooking.
Often, no extra water is needed. If dense
vegetables such as potatoes, carrots and green
beans are being cooked, add about 1/4 cup water.
• Small vegetables (sliced carrots, peas, lima
beans, etc.) will cook faster than larger ones.
• Whole vegetables, such as potatoes, acorn
squash or corn on the cob, should be arranged in
a circle on the turntable before cooking.
They will cook more evenly if turned over at half
the cooking time.
• Always place vegetables like asparagus and
broccoli with the stem ends pointing towards the
edge of the dish with the heads toward the center.
• When cooking cut vegetables, always cover the
dish with a lid or vented microwavable plastic
wrap.
• Whole, unpeeled vegetables such as potatoes,
squash, eggplant, etc., should have their skin
pricked in several spots before cooking to prevent
them from bursting.
• For more even cooking, rearrange whole
vegetables halfway through the cooking time.
• Generally, the denser the food, the longer the
standing time. (Standing time refers to the time
necessary for dense, large foods and vegetables
to finish cooking after they come out of the oven.)
A baked potato can stand on the counter for five
minutes before cooking is completed, while a dish
of peas can be served immediately.
Food Cook Time /Power Level Directions
Steaks
Up to 1.5 lbs.
Cooking Time:
6-10 min. / lb.
Power Level:
Medium High(7).
Arrange steaks on roasting rack with meaty
portions towards the outside of rack. Cover with
wax paper. Turn over and rearrange when
cooking time is half up. Cook until fish flakes
easily with a fork. Let stand 3-5 min.
Fillets
Up to 1.5 lbs.
Cooking Time:
3-7 min. / lb.
Power Level:
Medium High(7).
Arrange fillets in a baking dish, turning any thin
pieces under. Cover with wax paper. If over 1/2
inch thick, turn over and rearrange when
cooking time is half up. Cook until fish flakes
easily with a fork. Let stand 2-3 min.
Shrimp
Up to 1 lbs.
Cooking Time:
3-5 1/2 min. / lb.
Power Level:
Medium High(7).
Arrange shrimp in a baking dish without
overlapping or layering. Cover with wax paper.
Cook until firm and opaque, stirring 2 or 3 times.
Let stand 5 min.
^]`_UGGwGY[GGmSGhGZXSGYWWXGGXaXYGwt
COOKING INSTRUCTIONS
25
COOKING INSTRUCTIONS
AUTO DEFROSTING GUIDE
• Follow the instructions below when defrosting different types of food.
Notes
Check foods when the oven signals. After the final stage, small sections may still be icy; let them stand to
continue thawing.
Shielding roasts and steaks with small pieces of foil prevents the edges from cooking before the center of the
food has defrosted. Use narrow, flat, smooth strips of aluminum foil to cover the edges and thinner sections of
the food.
Food Amount Procedure
Roast Beef, Pork 2.5-5.0 lbs. Start with the food placed fat side down. After each stage, turn
the food over and shield any warm portions with narrow
strips of aluminum foil.
Steaks, Chops, Fish 0.5-3.0 lbs. After each stage, rearrange the food. If there are any warm or
thawed portions of food, shield them with narrow flat pieces of
aluminum foil. Remove any pieces of food that are nearly
defrosted. Let stand, covered, for 5-10 minutes.
Ground Meat 0.5-3.0 lbs. After each stage, remove any pieces of food that are nearly
defrosted. Let stand, covered with foil, for 5–10 minutes.
Whole Chicken 2.5-6.0 lbs. Remove giblets before freezing poultry. Start defrosting with the
breast side down. After the first stage, turn the chicken over and
shield any warm portions with narrow strips of aluminum foil. After
the second stage, again shield any warm portions with narrow
strips of aluminum foil. Let stand, covered, for 30–60 minutes in the
refrigerator.
Chicken Pieces 0.5-2.0 lbs. After each stage, rearrange or remove any pieces of food that are
nearly defrosted. Let stand for 10-20 minutes.
^]`_UGGwGY\GGmSGhGZXSGYWWXGGXaXYGwt
26
COOKING INSTRUCTIONS
COOKING INSTRUCTIONS
Recipes
Beef and Barley Stew
1 1/2 lbs. beef stew cubes, cut into 1/2-inch pieces
1/2 cup chopped onion
2 Tbs. all-purpose flour
1 Tbs Worcestershire sauce
1 can (13.75-14.5 oz.) beef broth
2 medium carrots, cut into 1/2-inch slices (about 1
cup)
1/2 cup barley
1 bay leaf
1/4 tsp. pepper
1 pkg. (9-10 oz.) frozen peas, thawed
1. In a 2-quart casserole, combine beef, onion,
flour, and Worcestershire; mix well. Cover
with lid. Cook at High for 6 to 8 minutes until
beef is no longer pink, stirring once.
2. Stir in beef broth, carrots, barley, bay leaf, and
pepper. Cover with lid. Cook at Medium for 1 to
11/2 hours until carrots and beef are tender,
stirring 2 to 3 times.
3. Stir in peas. Cover with lid. Cook at Medium
for 10 minutes. Let stand for 10 minutes.
Remove bay leaf before serving. Makes 6
servings.
Broccoli and Cheese Casserole
1/4 cup butter or margarine
1/4 cup chopped onion
1 1/2 Tbs. flour
1/2 tsp. salt
1/4 tsp. dry mustard
1/8 tsp. pepper
1 1/2 cups milk
1/4 cup chopped red pepper
8 oz. (2 cups) cheddar cheese, shredded
1 pkg. (9-10 oz.) frozen chopped broccoli, thawed
4 cups cooked spiral shaped pasta (8 oz. dry)
1. In a 2-quart casserole, cook butter and onion
at High for 1 to 2 minutes until onion is soft,
stirring once.
2. Add flour, salt, mustard, and pepper; mix well.
Cook at High for 30 to 60 seconds until mixture
boils. Stir in milk until smooth.
3. Stir in red pepper. Cook at High for 2 to 3
minutes until mixture boils and thickens
slightly, stirring twice. Stir in cheese until
melted.
4. Add broccoli and pasta, mix well. Cover with
lid. Cook at High for 4 to 6 minutes until heated
through, stirring once. Stir before serving.
Makes 6 servings.
^]`_UGGwGY]GGmSGhGZXSGYWWXGGXaXYGwt
COOKING INSTRUCTIONS
27
COOKING INSTRUCTIONS
Recipes
Warm Potato Salad
2 lbs. small red potatoes, cut into 1/2-inch pieces
4 slices bacon (uncooked), cut into 1/2-inch pieces
1/4 cup chopped onion
2 tsp. sugar
1 tsp. salt
1 tsp. flour
1/2 tsp. celery seed
1/8 tsp. pepper
2 1/2 Tbs. apple cider vinegar
1. In a 2-quart casserole, combine potatoes and
1/4 cup water. Cover with lid. Cook at High
until potatoes are tender (7-10 min.); stir twice.
Drain and set aside to cool slightly.
2. In a medium bowl, cook bacon at High until
crisp (21/2-31/2 min.); stir once. Place bacon on
a paper towel. Reserve 1 Tbs. drippings.
3. Combine drippings and onion. Cover with
plastic wrap; turn back a corner to vent steam.
Cook at High until tender (11/2-21/2 min.); stir
once.
4. Stir in sugar, salt, flour, celery seed, and
pepper. Cook at High until mixture boils (30-40
sec.). Stir in vinegar and 1/2 cup water. Cook
at High until liquid boils and thickens slightly
(1-2 min.); stir once. Add bacon to dressing.
Pour dressing over potatoes. Stir well. Makes
6 servings.
Black Bean Soup
1 cup chopped onion
1 clove garlic, minced
2 cans (15 oz. each) black beans, drained
1 can (14-16 oz.) stewed tomatoes, chopped
1 can (13.75-14.5 oz.) chicken broth
1 can (7-8.5 oz.) corn
1 can (4 oz.) chopped green chilies
1-2 tsp. ground cumin, or to taste
1. Place onion and garlic in a 3-quart casserole.
Cover with lid. Cook at High for 2 to 4 minutes
until tender.
2. Add one can of beans, mash beans with a
fork. Add remaining ingredients; mix well.
3. Cook uncovered, at High for 10 minutes; stir.
Reduce power to Medium and cook for 5
minutes. Stir before serving. Makes about 2
quarts.
^]`_UGGwGY^GGmSGhGZXSGYWWXGGXaXYGwt
28
COOKING INSTRUCTIONS
COOKING INSTRUCTIONS
CONVECTION BAKING GUIDE
• Always use the short rack for convection baking. Remove all racks from the oven when microwaving.
• Preheat oven for all convection baking.
• Use a round metal pizza pan as a "cookie sheet".
FOOD COOK TIME PROCEDURE
BREADS
YEAST
QUICK
Pan : Glass or metal loaf pan
Temperature : 350°F
Time : 40-50 min.
Pan : Glass or metal loaf pan
Temperature : 350°F
Time : 45-55 min.
Shield top of loaf with foil if too dark during baking.
Cool 10 minutes before slicing.
Cool on rack 15 minutes before removing from pan.
BISCUITS Pan : 9" round or metal pizza pan
Temperature : 375°F
Time : 11-15 min.
Grease pan. Remove from pan immediately when cooked.
CAKE
ANGEL FOOD
BUNDT
LAYER
Pan : Metal tube pan
Temperature : 350°F
Time : 40-45 min.
Pan : 12 cup Bundt pan
Temperature : 350°F
Time : 40-45 min.
Pan : 8-9" round or square
Temperature : 350°F
Time : 32-37 min.
Do not grease pan.
Hang upside down (on narrow necked bottle) for 1 1/2
hours to cool before removing from pan.
Grease pan.
Remove from pan after 10-15 minutes standing time.
Grease pan.
Cake is done when toothpick comes out clean.
COOKIES
DROP
BAR
Pan : Round pizza pan.
Temperature : 350°F
Time : 10-12 min.
Pan : 8" or 9" round or square pan
Temperature : 350°F
Time : 25-30 min.
Drop dough onto ungreased pan.
Remove from oven when centers of cookies are still soft.
Let stand on pan 1 minute before removing to cooling rack.
Grease pan. Remove from oven when toothpick placed
between edge and center comes out clean.
CUPCAKES/
MUFFINS Pan : Six portion cupcake pan
Temperature : 350°F
Time : 10-12 min.
Grease cups or use paper liners.
Done when toothpick comes out clean.
PIES Pan : Metal or glass pie dish.
Temperature : 350°F
Time : 45-55 min.
Remove from oven when filling is set and crust browned.
ROLLS Pan : 8-9" round pan or 12" pizza pan. Remove from pan immediately
Temperature : 375°F
Time : 15-19 min.
^]`_UGGwGY_GGmSGhGZXSGYWWXGGXaXYGwt
COOKING INSTRUCTIONS
29
COOKING INSTRUCTIONS
BROILING GUIDE
• Always use the high rack which has been sprayed with vegetable oil spray.
Set the rack on the glass turntable. Place the food directly on the rack.
• Foods may be brushed with butter or marinade if desired.
• An 8" or 9" pie plate may be placed on the turntable directly under the rack to catch any drippings.
FOOD COOK TIME PROCEDURE
BEEF
Steaks
Hamburgers
Broiling time :
15-17 min.- Rare
19-21 min.- Medium
22-24 min.- Well done
Broiling time :
14-16 min.- Rare
18-20 min.- Medium
21-23 min.- Well done
Place steak directly on the high rack.
Turn steak over after half the cooking time.
PORK
Pork chops
Ham steak
Broiling time :
21-23 min.- Well done
Broiling time :
17-19 min.- Well done
POULTRY
Chicken pieces
Broiling time :
35-40 min.- Well done Place chicken pieces directly on the high rack.
Thicker pieces of chicken, such as bone-in breast, may
take longer to become fully cooked than small ones.
Turn chicken over after half the cooking time.
FISH
Steaks, thick fillets
Thin fillets
(less than 1/2" thick)
Broiling time :
11-13 min.
Broiling time :
5-6 min.
Place fish directly on the high rack.
Broil until fish just flakes.
Turn over after half the cooking time.
Place fish directly on the high rack.
Broil until fish just flakes.
Turn over after half the cooking time.
APPETIZERS
Open face snacks
Broiling time :
6-8 min. Place appetizers on a round cooking sheet which
should be placed directly on the rack.
Broil until browned and bubbly.
^]`_UGGwGY`GGmSGhGZXSGYWWXGGXaXYGwt
30
COOKING INSTRUCTIONS
COOKING INSTRUCTIONS
COMBINATION COOKING GUIDE
• When roasting meats and poultry, place meat directly on the low rack, which has been placed on the
glass turntable and sprayed with vegetable cooking spray.
• When using Combination cooking, multiply the weight of the meat by the minutes per pound, factor in the
table below. After half the cooking time, turn the meat over, remove any accumulated drippings, return to
the oven, and press Start.
• Temperatures given below are removal temperatures. The meat continues to cook after removal from the
oven and the temperatures will rise.
FOOD COOK TIME PROCEDURE
BEEF
Roasts
Roasting time :
13-15 min./lb. for 115°F-Rare
15-17 min./lb. for 125°F-Medium
17-19 min./lb. for 145-150°F-Well done
Place the food directly on low rack which has been
sprayed with vegetable cooking spray.
POULTRY
Whole chicken
Roasting time :
12-17 min./lb. for 170°F-white meat
185°F-dark meat
PORK
Boneless roast
Smoked ham
Roasting time :
23-26 min./lb. for 160°F
Roasting time :
12-15 min./lb. for 130°F
CASSEROLE
Baking time :
35-40 min. Place dish on low rack.
Bake on combination at 350°F until heated though.
^]`_UGGwGZWGGmSGhGZXSGYWWXGGXaXYGwt
APPENDIX
31
APPENDIX
Troubleshooting Guide
Before you call a repair person for your oven,
check this list of possible problems and solutions.
Neither the oven’s display nor the oven operate.
• Properly insert the plug into a grounded outlet.
• If the outlet is controlled by a wall switch, make
sure the wall switch is turned on.
• Remove the plug from the outlet, wait ten
seconds, then plug it in again.
• Reset the circuit breaker or replace any blown
fuse.
• Plug another appliance into the outlet; if the other
appliance doesn’t work, have a qualified
electrician repair the outlet.
• Plug the oven into a different outlet.
The oven’s display works, but the power won’t
come on.
• Make sure the door is closed securely.
• Check to see if packing material or other material
is stuck to the door seal.
• Check for door damage.
• Press Cancel twice and re-enter all cooking
instructions.
The power goes off before the set time has elapsed.
• If there has not been a power outage, remove the
plug from the outlet, wait ten seconds, then plug it
in again. If there was a power outage, the time
indicator will display “SAMSUNG SO SIMPLE”
Reset the clock and any cooking instructions.
• Reset the circuit breaker or replace any blown fuse.
The food is cooking too slowly.
• Make sure the oven is on its own 20 amp circuit
line. Operating another appliance on the same
circuit can cause a voltage drop. If necessary,
move the oven to its own circuit.
You see sparks or arcing.
• Remove any metallic utensils, cookware, or metal
ties. If using foil, use only narrow strips and allow
at least one inch between the foil and interior
oven walls.
The turntable makes noises or sticks.
• Clean the turntable, roller ring and oven floor.
• Make sure the turntable and roller ring are
positioned correctly.
Using your microwave causes TV or radio
interference.
• This is similar to the interference caused by other
small appliances, such as hair dryers. Move your
microwave further away from other appliances,
like your TV or radio.
Care and Cleaning
Follow these instructions to clean and care for your
oven.
• Keep the inside of the oven clean. Food particles
and spilled liquids can stick to the oven walls,
causing the oven to work less efficiently.
• Wipe up spills immediately. Use a damp cloth and
mild soap. Do not use harsh detergents or
abrasives.
• To help loosen baked on food particles or liquids,
heat two cups of water (add the juice of one
lemon if you desire to keep the oven fresh) in a
four-cup measuring glass at High power for five
minutes or until boiling. Let stand in the oven for
one or two minutes.
• Remove the glass tray from the oven when
cleaning the oven or tray. To prevent the tray from
breaking, handle it carefully and do not put it in
water immediately after cooking.
Wash the tray carefully in warm sudsy water or in
the dishwasher.
• Clean the outside surface of the oven with soap
and a damp cloth. Dry with a soft cloth.
To prevent damage to the operating parts of the
oven, don’t let water seep into the openings.
• Wash the door window with very mild soap and
water. Be sure to use a soft cloth to avoid
scratching.
• If steam accumulates inside or outside the oven door,
wipe with a soft cloth. Steam can accumulate when
operating the oven in high humidity and in no way
indicates microwave leakage.
• Never operate the oven without food in it; this can
damage the magnetron tube or glass tray. You may
wish to leave a cup of water in the oven when it is
not in use to prevent damage if the oven is
accidentally turned on.
If you have a problem you cannot solve,
please call our service line:
1-800-SAMSUNG
(1-800-726-7864)
^]`_UGGwGZXGGmSGhGZXSGYWWXGGXaXYGwt
32
APPENDIX
APPENDIX
Specifications.
Model Number MC1360WA/MC1360BA/MC1360SA
Oven Cavity 1.3cuft
Controls 10 power levels, including defrost
Timer 99 minutes, 99 seconds
Power Source 120 VAC, 60 Hz
Power Output 950 Watts(MWO)
Power Consumption 1450 Watts(Mwo)/1500 Watts (Convection)
Outside Dimensions 2129/32” (W) X 1223/32” (H) X 2119/32” (D)
Oven Cavity Dimensions 141/2” (W) X 93/16” (H) X 1513/32” (D)
Net/Gross Weight 57.3/61.7 lbs
^]`_UGGwGZYGGmSGhGZXSGYWWXGGXaXYGwt
33 Warranty
Warranty
Warranty Information
Limited Warranty for Original Purchaser
This Samsung product is warranteed by Samsung
Electronics Canada, Inc. (hereafter referred to as
SECA) against manufacturing defects in material or
workmanship for the following periods:
Labor: 1 year (carry-in)
Parts: 1 year
Magnetron: 5 years
SECA further warrants that if this product fails to
operate properly within the specified warranty
period and the failure is due to improper
workmanship or defective material, SECA will repair
or replace the product at its option.
All warranty repairs or part replacements must be
performed by a SECA Authorized Service Center. (To
find the nearest SECA Service Center, call 1-800-
SAMSUNG.)
Obligation to the Original Owner
The original dated sales receipt must be retained by
the customer and is the only acceptable proof of
purchase. It must be presented to an SECA
Authorized Service Center at the time service is
requested before warranty services are rendered.
On all carry-in models, transportation to and from
the Authorized Service Center is the responsibility of
the customer.
Exclusions of the Warranty
This warranty does not cover damage due to
accident, fire, flood, and/or other Acts of God:
misuse, incorrect line voltage, improper installation,
improper or unauthorized repairs, commercial use,
or damage that occurs during shipping. Customer
adjustments which are explained in this owner’s
manual are not covered under the terms of this
warranty. This warranty will automatically be voided
for any unit found with a missing or altered serial
number. This warranty is valid only on products
purchased and used in the Canada.
SAMSUNG ELECTRONICS
Subject to the requirements, conditions, exclusions
and limitations of the Original Limited Warranty
supplied with Samsung Electronics (SAMSUNG)
products, and the requirements, conditions,
exclusions and limitations contained herein,
SAMSUNG will additionally provide Warranty Repair
Service in the United States on SAMSUNG products
purchased in Canada, and in Canada on SAMSUNG
products purchased in the United States, for the
warranty period originally specified, and to the
Original Purchaser only.
The above described warranty repairs must be
performed by a SAMSUNG Authorized Service
Center. Along with this Statement, the Original
Limited Warranty Statement and a dated Bill of Sale
as Proof of Purchase must be presented to the
Service Center. Transportation to and from the
Service Center is the responsibility of the purchaser.
Conditions covered are limited only to manufacturing
defects in material or workmanship, and only those
encountered in normal use of the product.
Excluded, but not limited to, are any original
specified provisions for, in-home or on-site services,
minimum or maximum repair times, exchanges or
replacements, accessories, options, upgrades, or
consumables.
For the locations of a SAMSUNG Authorized Service
Center in the United States and Canada, please
contact SAMSUNG at:
1-800-SAMSUNG (1-800-726-7864)
Or on-line at:
WWW.SAMSUNGUSA.COM
and
WWW.SAMSUNGCANADA.COM
NORTH AMERICAN LIMITED
WARRANTY ADDENDUM
^]`_UGGwGZZGGmSGtGYYSGYWWYGG`aY[Ght
QUICK REFERENCE
Feature Operation
Set Clock 1. Press CLOCK.
2. Use number buttons to enter time.
3. Press CLOCK again.
One Stage Cooking 1. Use number buttons to set cooking time.
2. Set power level or leave at high.
3. Press START.
One Minute+ Cooking 1. Press the ONE MINUTE + button once for each minute of cooking.
2. The time will display and the oven will start.
Instant Cook Buttons 1. Press button that corresponds to the food you are cooking
(for example, POPCORN).
2. Press the button repeatedly to select serving size.
Auto Defrost 1. Press AUTO DEFROST.
2. Enter weight of food by pressing AUTO DEFROST button repeatedly or
using the number buttons.
3. When prompted by oven display, press PAUSE/CANCEL button and turn
food over. Press START to resume defrosting cycle.
Auto Reheat 1. Press AUTO REHEAT repeatedly to select type of dish to reheat.
2. To increase serving size, press the corresponding number button.
3. Press START to begin reheating cycle.
Set Cooking Time and
Power Levels 1. Use number buttons to set cooking time.
2. To set power level at other than HIGH, press POWER LEVEL and use the
number buttons to enter the power level.
3. Press START to begin cooking.
SAMSUNG ELECTRONICS CANADA, INC.
7037 FINANCIAL DRIVE,
MISSISSAUGA,
ONTARIO, L5N 6R3
June. 2001
Printed in Korea
^]`_jv}lyUmtGGwGYGGmSGhGZXSGYWWXGGXaX]Gwt
