Users Manual
Microwave
Oven
Owner’s Manual
MS8796W /MW1666WC
CODE NO. : DE68-00212A
MS8796/9796-GB 9/27/00 3:21 AM Page 1
S
AFETY
2S
AFETY
PRECAUTIONS TO
AVOID POSSIBLE
EXPOSURE TO
EXCESSIVE
MICROWAVE ENERGY
:
(a) Do not attempt to operate this oven
with the door open since open-door
operation can result in harmful
exposure to microwave energy. It is
important not to defeat or tamper with
the safety interlocks.
(b) Do not place any object between the
front face of the oven and the door or
allow soil or cleaner residue to accu-
mulate on sealing surfaces.
(c) Do not operate the oven if it is dam-
aged. It is particularly important that the
oven door close properly and that there
is no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or
loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or
repaired by anyone except properly
qualified service personnel.
WARNING
Always observe Safety Precautions
when using your oven. Never try to
repair the oven on your own – there is
dangerous voltage inside. If the oven
needs to be repaired, call 1-800-SAM-
SUNG for the name of an authorized
service center near you.
IMPORTANT SAFETY
INSTRUCTIONS
WARNING
• Some items, like whole eggs and food in sealed
containers, may explode if heated in this oven.
• Use this appliance only for its intended use as
described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type
of oven is specifically designed to heat, cook, or
dry food. It is not designed for industrial or labo-
ratory use.
• As with any appliance, close supervision is nec-
essary when used by children.
To reduce risk of burns, electric
shock, fire, personal injury or expo-
sure to excessive microwave energy:
• Read all safety instructions before using the
appliance.
• Read and follow the specific “Precautions to
Avoid Exposure to Excessive Microwave
Energy” on this page.
• This appliance must be grounded. Connect
only to properly grounded outlets. See
“Important Grounding Instructions” on page 4
of this manual.
• Install or place this appliance only in accor-
dance with the installation instructions
provided.
SAVE THESE INSTRUCTIONS
When using any electrical appliance,
basic safety precautions should be
followed, including the following:
MS8796/9796-GB 9/27/00 3:21 AM Page 2
S
AFETY
3
S
AFETY
Important Safety Instructions,
continued
• Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly, or if it
has been damaged.
• This appliance should be serviced only by quali-
fied service personnel. Contact the nearest autho-
rized service facility for examination, repair, or
adjustment.
• Do not cover or block any of the openings on this
appliance.
• Do not store this appliance outdoors. Do not use
near water – for example, near a kitchen sink, in a
wet basement, or near a swimming pool, etc.
• Keep the inside of the oven clean. Food particles
or spattered oils stuck to the oven walls or floor
can cause paint damage and reduce the efficien-
cy of the oven.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or
counter.
• When cleaning door and oven surfaces, use only
mild, nonabrasive soaps or detergents applied
with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a.Do not overcook food. Watch appliance care
fully if paper, plastic, or other combustible
materials are inside.
b. Remove wire twist-ties from plastic cooking bags
before placing bags in oven.
c.If materials inside the oven ignite, keep the
oven door closed, turn the oven off, disconnect
the power cord, or shut off the power at the
fuse or circuit breaker panel.
d.Do not use the oven compartment for storage
purposes. Do not leave paper products, cooking
utensils, or food in the oven when not in use.
• Do not try to preheat oven or operate while empty.
• Do not cook without the glass tray in place on the
oven floor. Food will not cook properly without the
tray.
• Do not defrost frozen beverages in narrow-necked
bottles. The containers can break.
• Do not cook whole eggs in the shell.
Break egg into dish, prick yolk 2 to 3 times, cover
and microwave on 50% power until desired done-
ness.
• Dishes and containers can become hot. Handle
with care.
• Carefully remove container coverings, directing
steam away from hands and face.
• Remove lids from baby food before heating. After
heating baby food, stir well and test temperature
by tasting before serving.
• A short power-supply cord is provided to reduce
the risk of becoming entangled in or tripping over
a longer cord. Longer cord sets or extension
cords are available and may be used
with caution.
• Do not operate any other heating or cooking appli-
ance beneath this appliance.
• Do not mount unit over or near any portion of a
heating or cooking appliance.
• Do not mount over a sink.
• Do not store anything directly on top of the appli-
ance when it is in operation.
SAVE THESE INSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 3
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire
for the electrical current. This appliance is
equipped with a cord that includes a grounding
wire and a grounding plug. The plug must be
plugged into an outlet that is properly installed and
grounded. Plug the three-prong power cord into a
properly grounded outlet of standard 115-120 volt-
age, 60 Hz. Your oven should be the only appliance
on this circuit.
WARNING
Improper use of the grounding plug can result
in a risk of electric shock. Consult a qualified
electrician or servicer if you do not understand
the grounding instructions or if you are not
sure if the appliance is properly grounded.
Use of Extension Cords
A short power-supply cord is provided to reduce
the risk of becoming entangled in or tripping over a
longer cord. Longer cord sets or extension cords
are available and may be used if care is exercised
in their use. If a long cord or extension cord is
used:
1. The marked electrical rating of the cord set or
extension cord should be at least as great as
the electrical rating of the appliance.
2. The extension cord must be a grounding-type 3-
wire cord and it must be plugged into a 3-slot
outlet.
3. The longer cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on by children or tripped
over accidentally. If you use an extension cord,
the interior light may flicker and the blower
may vary when the microwave oven is on.
Cooking times may be longer, too.
WARNING
Do not cut or remove the third (ground) prong
from the power cord under any circum-
stances.
S
AFETY
4S
AFETY
Important Grounding
Instructions
SAVE THESE INSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 4
Your New Microwave Oven . . . . . .6
Checking Parts . . . . . . . . . . . . . . . . . . . .6
Setting Up Your Microwave Oven . . . .6
Control Panel Buttons . . . . . . . . . . . . . .7
Operation . . . . . . . . . . . . . . . . . . . . .8
Turning on the Power and Selecting a
Display Language . . . . . . . . . . . . . . . . . .8
Setting the Clock . . . . . . . . . . . . . . . . . .8
Using the Pause/Cancel Button . . . . . .8
Using the Help System . . . . . . . . . . . . .9
Using the Sensor Cook Buttons . . . . . .9
Using the One Minute+ Button . . . . . .10
Using the Gentle Cook Button . . . . . .10
Sensor Reheat . . . . . . . . . . . . . . . . . . .10
Defrosting Automatically . . . . . . . . . . .11
Defrosting Guide . . . . . . . . . . . . . . . . .12
Setting Cooking Times &
Power Levels . . . . . . . . . . . . . . . . . . . .13
One-stage Cooking . . . . . . . . . . . .13
Multi-stage Cooking . . . . . . . . . . .13
Using the More/Less Button . . . . . . . .14
Adjusting the Volume . . . . . . . . . . . . . .14
Using the Kitchen Timer . . . . . . . . . . .15
Setting the Child Protection Lock . . . .15
Demonstration Mode . . . . . . . . . . . . . .15
Cooking Instructions . . . . . . . . . . . .16
Cooking Utensils . . . . . . . . . . . . . . . . . .16
Testing Utensils . . . . . . . . . . . . . . . . . .16
Cooking Techniques . . . . . . . . . . . . . . .17
General Tips . . . . . . . . . . . . . . . . . . . . .17
Auto Sensor Cook . . . . . . . . . . . . . . . .18
Utensils & Cover For
Sensor Cooking . . . . . . . . . . . . . . . . . .18
Important . . . . . . . . . . . . . . . . . . . . . . . .18
Cooking Guides . . . . . . . . . . . . . . . .19-20
Sensor Cooking Guide . . . . . . . . . .21-22
Sensor Reheat Guide . . . . . . . . . . . . .22
Sensor Recipes . . . . . . . . . . . . . . . .23-24
Appendix . . . . . . . . . . . . . . . . . . . . .25
Troubleshooting Guide . . . . . . . . . . . . .25
Care and Cleaning . . . . . . . . . . . . . . . .25
Warranty Information . . . . . . . . . . . . .26
Specifications . . . . . . . . . . . . . . . . . . . .26
Guía de Consulta Rápida en
Español . . . . . . . . . . . . . . . . . . . .27-28
Manual Block Warranty
. . . . . . . . . . . . . . . . . . . . . . . . . . .29-30
Quick Guide . . . . . . . . . . . . .Back Cover
C
ONTENTS
5
C
ONTENTS
MS8796/9796-GB 9/27/00 3:21 AM Page 5
Checking Parts
Unpack your microwave oven and check to make
sure that you have all the parts shown here. If any
part is missing or broken, call your dealer.
Thank You for Choosing Samsung
Your new oven represents the latest in microwave
cooking technology. This oven is a full-featured,
easy-to-use appliance built to strict quality stan-
dards set by Samsung — the highest in the indus-
try. We’re proud to offer you a product that will
provide convenient, dependable service for years
to come.
Please record the serial number from the inside or
back of your Samsung microwave oven and the
date of purchase in the space provided below. We
recommend that you keep your purchase receipt
with this manual for easy warranty service.
Model Number _________________________
Serial Number _________________________
Date Purchased _________________________
Dealer _________________________
Setting Up Your Microwave Oven
1Place the oven on a flat, sturdy surface
and plug the cord into a grounded outlet.
Once plugged in, the display on your
oven will show:
Make sure there is adequate ventilation for your
oven by leaving at least four inches of space
behind, above, and to the side of the oven.
2Open the oven door by pressing the but-
ton below the control panel.
3Wipe the inside of the oven with a damp
cloth.
4Place the pre-assembled roller guide in
the indentation in the center of the oven.
5Place the glass tray on top of the roller
guide so that the three glass tabs in the
center of the tray fit securely into the
tabs on the floor of the oven.
Y
OUR
N
EW
M
ICROWAVE OVEN
6
Y
OUR
N
EW
M
ICROWAVE
O
VEN
microwave oven
glass tray instruction manual
registration card
roller guide
MS8796/9796-GB 9/27/00 3:21 AM Page 6
Y
OUR
N
EW
M
ICROWAVE OVEN
7Y
OUR
N
EW
M
ICROWAVE
O
VEN
Control Panel Buttons
One Minute+ p. 10
Press once for every minute of cooking at
High power.
Sensor Cook Buttons p. 9
Seneor settings to cook popular foods.
Sensor Reheat p. 10
Shows type and quantity of food to be reheat-
ed.
Help Screen p. 9
Press to see help information about the fea-
ture you are using.
Gentle Cook p. 10
Press to set gentler cooking with reduced
power
Number Buttons
Sets cooking times or amounts and power
levels other than high.
Sound Button p. 14
More/Less Button p. 14
Increases or decreases cooking time.
Kitchen Timer p. 15
Start
Press to start cooking.
Auto Defrost p. 11
Sets weight of food to be defrosted.
Power Level p. 13
Sets power to level other than high.
Clock p. 8
Sets current time.
Pause/Cancel p. 8
Press to pause oven or correct a mistake.
MS8796/9796-GB 9/27/00 3:21 AM Page 7
Turning on the Power and Selecting a
Display Language
The first time you plug the power cord into an out-
let, or after there has been an interruption in
power, the display shows “SAMSUNG SO SIMPLE”
At this point, you can select a language and weight
system for the display. You can choose from
English, French, Spanish and Portuguese and
between pounds (LBS) or kilograms (KG). To do so,
1 Press START immediately after plugging in
your Microwave. The display shows “ENG-
LISH/LBS”. If the display does not show “ENG-
LISH/LBS”, you will need to unplug the
Microwave and then plug it in again to change
the language.
2 Press START repeatedly to select the lan-
guage and weight system you wish to
use:
• ENGLISH/LBS,
• ENGLISH/KG,
• FRENCH/KG,
• SPANISH/LBS, or SPANISH/KG
• PORTUGUESE/KG.
If you continue to press START, the set-
tings will cycle in the order shown here.
When you have selected the language and weight sys-
tem you want to use, press the PAUSE/CANCEL button
to end this procedure, or press CLOCK to set the clock.
Setting the Clock
1 Press the Clock button. The display will
show:
2 Use the number buttons to enter the cur-
rent time. You must press at least three
numbers to set the clock. If the current
time is 5:00 enter, 5,0,0.
3 Press Clock again. A colon will appear,
indicating that the time is set.
If there is a power interruption, you will need to
reset the clock.
You can check the current time while cooking is in
progress by pressing the Clock button.
Using the Pause/Cancel Button
The Pause/Cancel button allows you to clear
instructions you have entered. It also allows you to
pause the oven’s cooking cycle, so that you can
check the food.
• To pause the oven during cooking: press
Pause/Cancel once. To restart, press Start.
• To stop cooking, erase instructions, and return
the oven display to the time of day: press
Pause/Cancel twice.
• To correct a mistake you have just entered:
press Pause/Cancel once, then re-enter the
instructions.
• To cancel a timer setting: press Pause/Cancel
once.
O
PERATION
8O
PERATION
MS8796/9796-GB 9/27/00 3:21 AM Page 8
Using the Help system
Your microwave offers helpful instructions for many
procedures.
1 When you need feature information and
helpful hints, press the Help Screen
button and then press the button that you
want to get information on. Help informa-
tion is available in 4 languages (English,
French, Spanish and Portuguese). The
“HELP” indicator appears in the display
while you are using this feature.
Using the Sensor Cook Buttons
By actually sensing the steam that escapes as food
heat, this feature automatically adjusts the oven’s
heating time for various types and amounts of pre-
cooked food. All food should be precooked and at
refrigerator temperature.
1 Press the Sensor Cook button corre-
sponding to the food you are cooking
(Popcorn, for example). The display
shows “POPCORN” and your microwave
oven will begin cooking automatically.
O
PERATION
9
O
PERATION
When cooking popcorn, wait at least five minutes
between each bag to avoid overheating the glass tray.
If you want to adjust the cooking time,
you can use the MORE/LESS button.
See page 14 for more information.
If you want to check the current time while cooking
is in progress, press the CLOCK button.
Serving sizes available for each button:
POPCORN
1.5 oz -3.5 oz
(If you want to use the 1.5 oz ~
1.75 oz serving size, you can
use the“LESS” key of the More/
Less button for best results.
FROZEN BREAKFAST
(Sandwich, Waffle, Egg)
2 - 8 oz
FRESH VEGETABLE
1 - 4 Cups
FISH
0.5-1.5 lbs
POTATO
6 oz -8 oz each
DIET COOK
(Low calorie frozen dinners)
7-18 oz
FROZEN DINNER
(Frozen Entree, Frozen Dinner)
7-18 oz
BABY FOOD
2.5-6.0 oz
MS8796/9796-GB 9/27/00 3:21 AM Page 9
Sensor Reheat
Heating leftovers and precooked foods is easy with
your new microwave. By actually sensing the
steam that escapes as food heat, this feature auto-
matically adjusts the oven’s heating time for vari-
ous types and amounts of precooked food. All food
should be precooked and at refrigerator tempera-
ture. To use sensor reheating.
1 Press SENSOR REHEAT.
The display will show “REHEAT”
and the oven will start automatically.
O
PERATION
10 O
PERATION
Using the One Minute+ Button
This button offers a convenient way to heat food in
one-minute increments at the High power level.
1Press the One Minute+ button once for
each minute you wish to cook the food.
For example, press it twice for two min-
utes. The time will display, and the oven
starts automatically.
Add minutes to a program in progress by pressing
the One Minute+ button for each minute you
want to add.
Using the Gentle Cook Button
This button is for slower, gentler cooking with
reduced power. It is ideal for heat sensitive foods
such as those containing egg yolks, sour cream
and mayonnaise and for simmering stews, etc.
1 Use the Number button to set a cooking
time.
For example, to set 10 minutes, enter
1,0,0,0.
2Press the Gentle Cook button. The time
will display and the oven will start auto-
matically.
If you want to adjust the heating
time, use the MORE/LESS button.
See page 14.
If you want to check the current
time while reheating, press the
CLOCK button
MS8796/9796-GB 9/27/00 3:21 AM Page 10
O
PERATION
11
O
PERATION
Defrosting Automatically
To thaw frozen food, set the weight of the food and
the microwave automatically sets the defrosting
time, power level and standing time.
1 Press the Auto Defrost button. The dis-
play shows “0.5 LB.”(0.2Kg if you have
set your oven for metric measure).
2 To set the weight of your food, press the
Auto Defrost button repeatedly. This
increases the weight by 0.5 lb incre-
ments, up to 6.0 lbs.
You can also use the number buttons to
enter the weight of the food directly.
The oven calculates the defrosting time
and starts automatically. Twice during
defrosting, the oven will beep and the
display will read “TURN THE FOOD
OVER.”
3Press the Pause/Cancel button, open the
oven door, and turn the food over.
4 Press the Start button to resume
defrosting.
• See next page for the Auto Defrosting Guide
MS8796/9796-GB 9/27/00 3:21 AM Page 11
Defrosting Guide
Follow the instructions below when defrosting dif-
ferent types of food.
Type of food: Roast beef, pork
Amount: 2.5-6.0 lbs.
Procedure: Start with the food placed fat
side down. After each stage,
turn the food over and shield
any warm portions with narrow
strips of aluminum foil.
Type of food: Steaks, chops, fish
Amount: 0.5-3.0 lbs.
Procedure: After each stage, rearrange the
food. If there are any warm or
thawed portions of food, shield
them with narrow strips of alu-
minum foil. Remove any pieces
of food that are nearly defrost-
ed. Let stand, covered, for 5-10
minutes.
Type of food: Ground meat
Amount: 0.5-3.0 lbs.
Procedure: After each stage, remove any
pieces of food that are nearly
defrosted. Let stand, covered
with foil, for 5–10 minutes.
Type of food: Chicken, whole
Amount: 2.5-6.0 lbs.
Procedure: Remove giblets before freezing
poultry. Start defrosting with the
breast side down. After the first
stage, turn the chicken over and
shield any warm portions with
narrow strips of aluminum foil.
After the second stage, again
shield any warm portions with
narrow strips of aluminum foil.
When defrost cycle is over, let
stand, covered, for 30–60 minutes
in the refrigerator.
Type of food: Chicken, pieces
Amount: 0.5-3.0 lbs.
Procedure: After each stage, rearrange or
remove any pieces of food that
are nearly defrosted. Let stand
for 10-20 minutes.
Notes
Check foods when the oven signals. After the final
stage, small sections may still be icy; let them stand
to continue thawing. Do not cook until all ice crystals
have thawed.
Shielding roasts and steaks prevents the edges from
cooking before the center of the food has defrosted.
Use narrow, flat, smooth strips of aluminum foil to
cover the edges and thinner sections of the food.
O
PERATION
12 O
PERATION
MS8796/9796-GB 9/27/00 3:21 AM Page 12
Setting Cooking Times & Power
Levels
Your microwave allows you to set up to three differ-
ent stages of cooking, each with its own time length
and power level. The power level lets you control
the heating intensity from Warm (1) to High (0).
One-stage Cooking
For simple one-stage cooking, you only need to set a
cooking time. The power level is automatically set at
High. If you want the power set at any other level,
you must set it using the Power Level button.
1Use the number buttons to set a cooking
time. You can set a time from one second
to 99 minutes, 99 seconds. To set a time
over one minute, enter the seconds too.
For example, to set 20 minutes, enter
2, 0, 0, 0 .
2 If you want to set the power level to
something other than High, press the
Power Level button, then use the number
buttons to enter a power level.
Power Levels:
1 = warm 6 = simmer
2 = low 7 = medium high
3 = defrost 8 = reheat
4 = medium low 9 = sauté
5 = medium 0 = high
The display shows “PRESS START OR ENTER NEXT
STAGE COOKING TIME”
3 Press the Start button to begin cooking.
If you want to change the power level,
press Pause/Cancel before you press
Start, and reenter all of the instructions.
Setting Cooking Times, continued
Some recipes require different stages of cooking at
different temperatures. You can set multiple stages
of cooking with your microwave.
Multi-stage Cooking
1 Follow steps 1 and 2 in the “One-Stage
Cooking” section on this page. The dis-
play shows “PRESS START OR ENTER
NEXT STAGE COOKING TIME.”
When entering more than one cooking stage, the
Power Level button must be pressed before the
second cooking stage can be entered.
To set the power level at High for a stage of cook-
ing, press the Power Level button twice.
2 Use the Number buttons to set a second
cooking time.
3 Press the Power Level button, then use
the number buttons to set the power
level of the second stage of cooking.
The display shows the power level you
have set and then “PRESS START OR
ENTER NEXT STAGE COOKING TIME.”
4 Press Start to begin cooking, or repeat
steps 2 and 3 to set a cooking time and
power level for a third stage of cooking.
When finished, press Start.
O
PERATION
13
O
PERATION
MS8796/9796-GB 9/27/00 3:21 AM Page 13
Using the More/Less Button
The More/Less button allows you to adjust pre-set
cooking times. It only works with the Sensor
Reheat , Sensor-cooking buttons(Popcorn, Potato,
etc.). Use the More/Less button only after you
have already begun cooking with one of these pro-
cedures. The More/Less key cannot be used with
the Baby Food key.
1 To ADD more time to an automatic cook-
ing procedure: Press the More/Less but-
ton once. The word “MORE” will appear
in the display.
2 To REDUCE the time of an automatic
cooking procedure: Press the More/Less
button twice. The word “LESS” will
appear in the display.
3 To return to the NORMAL time set for an
automatic cooking procedure: Press the
More/Less button until the word
“NORMAL” appears in the display.
Adjusting the Volume
The Sound button on the microwave allows you to
adjust the volume of the microwave’s chime
sound. The sound is initially set to its highest set-
ting. To change the volume:
1 Press the Sound button. The display
shows
“0-OFF 1-LOW 2-MED 3-HIGH”
2 Press “0” to turn the volume off, “1” for
low volume, “2” for medium volume, or
“3” for high volume.
The display will show the volume you
have chosen, then shows “PRESS
START”
3 Press Start:
The display returns to the time of day.
O
PERATION
14 O
PERATION
MS8796/9796-GB 9/27/00 3:21 AM Page 14
Using the Kitchen Timer
This is a timer only.
No microwave energy is generated during this
function.
1Use the Number buttons to set the length
of time you want the timer to run.
2Press the Kitchen Timer button.
3 The display counts down and beeps
when the time has elapsed.
Setting the Child Protection Lock
You can lock your microwave oven so it can’t be
used by unsupervised children.
1 Press the “0” button. The display shows
“PRESS 1-DEMO 2- CHILD LOCK.”
2Press the “2” button. The display shows
“PRESS START.”
3Press the Start button. The display
shows “LOCK” then returns to the time of
day.
At this point, the microwave oven cannot be used
until it is unlocked. To unlock it, repeat steps 1–3
above.
Demonstration Mode
You can use the Demonstration Mode to see how
your microwave oven operates without the oven
heating.
1Press the “0” button. The display shows
“PRESS 1-DEMO 2- CHILDLOCK.”
2 Press the “1” button. The display shows
“PRESS START”.
3Press the Start button. The display
shows “DEMO MODE ON”.
To turn demo mode off, repeat steps 1–3 above.
NOTE ; You can not use Demonstration Mode for
sensor cooking. If use, “E1” error will be displayed.
O
PERATION
15
O
PERATION
MS8796/9796-GB 9/27/00 3:21 AM Page 15
Cooking Utensils
Recommended Use
• Glass and glass-ceramic bowls and dishes —
Use for heating or cooking.
• Microwave browning dish — Use to brown the
exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with
your browning dish.
• Microwavable plastic wrap — Use to retain
steam. Leave a small opening for some steam to
escape and avoid placing it directly on the food.
• Wax paper — Use as a cover to prevent spatter-
ing.
• Paper towels and napkins — Use for short-term
heating and covering; they absorb excess mois-
ture and prevent spattering. Do not use recycled
paper towels, which may contain metal and can
catch fire.
• Paper plates and cups — Use for short-term
heating at low temperatures. Do not use recy-
cled paper, which may contain metal and can
catch fire.
• Thermometers — Use only those labeled
“Microwave Safe” and follow all directions.
Check the food in several places. Conventional
thermometers may be used once the food has
been removed from the oven.
Limited Use
• Aluminum foil — Use narrow strips of foil to pre-
vent overcooking of exposed areas. Using too
much foil can damage your oven, so be careful.
• Ceramic, porcelain, and stoneware — Use these
if they are labeled “Microwave Safe.” If they
are not labeled, test them to make sure they can
be used safely. Never use dishes with metallic
trim.
• Plastic — Use only if labeled “Microwave Safe.”
Other plastics can melt.
• Straw, wicker, and wood — Use only for short-
term heating, as they can be flammable.
Not Recommended
• Glass jars and bottles — Regular glass is too
thin to be used in a microwave, and can shatter.
• Paper bags — These are a fire hazard, except
for popcorn bags that are designed for
microwave use.
• Styrofoam plates and cups — These can melt
and leave an unhealthy residue on food.
• Plastic storage and food containers —
Containers such as margarine tubs can melt in
the microwave.
• Metal utensils — These can damage your oven.
Remove all metal before cooking.
Testing Utensils
If you are not sure whether a dish is microwave-
safe or not, you can perform this test:
1Fill a 1 cup glass measuring cup with
water and put it inside your oven, next to
the dish you want to test.
2Press the One Minute+ button once to
heat them for one minute at High power.
The water should be warm and the dish you are
testing should be cool. If the dish is warm, then it is
absorbing microwave energy and is not acceptable
for use in the microwave.
C
OOKING
I
NSTRUCTIONS
16 C
OOKING
I
NSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 16
Cooking Techniques
Stirring
Stir foods such as casseroles and vegetables while
cooking to distribute heat evenly. Food at the out-
side of the dish absorbs more energy and heats
more quickly, so stir from the outside to the center.
The oven will turn off when you open the door to
stir your food.
Arrangement
Arrange unevenly shaped foods, such as chicken
pieces or chops, with the thicker, meatier parts
toward the outside of the turntable where they
receive more microwave energy. To prevent over-
cooking, place thin or delicate parts toward the
center of the turntable.
Shielding
Shield food with narrow strips of aluminum foil to
prevent overcooking. Areas that need shielding
include poultry wing-tips, the ends of poultry legs,
and corners of square baking dishes. Use only
small amounts of aluminum foil. Larger amounts
can damage your oven.
Turning
Turn foods over midway through cooking to expose
all parts to microwave energy. This is especially
important with large items such as roasts.
Standing
Foods cooked in the microwave build up internal
heat and continue to cook for a few minutes after
the oven stops. Let foods stand to complete cook-
ing, especially foods such as roasts and whole
vegetables. Roasts need this time to complete
cooking in the center without overcooking the
outer areas. All liquids, such as soup or hot choco-
late, should be shaken or stirred when cooking is
complete. Let liquids stand a moment before serv-
ing. When heating baby food, stir well and test the
temperature before serving.
Adding Moisture
Microwave energy is attracted to water molecules.
Food that is uneven in moisture content should be
covered or allowed to stand so that the heat dis-
perses evenly. Add a small amount of water to dry
food to help it cook.
General Tips
• Dense foods, such as potatoes, take longer to
heat than lighter foods. Foods with a delicate
texture should be heated at a low power level to
avoid becoming tough.
• Altitude and the type of cookware you are using
can affect cooking time. When using a new
recipe, use the minimum cooking time and
check the food occasionally to prevent over-
cooking.
• Foods with a non-porous skin or shell, such as
potatoes, eggs, or hot dogs, should be pierced
to prevent bursting.
• Frying with heating oil or fat is not recommend-
ed. Fat and oil can suddenly boil over and
cause severe burns.
• Some ingredients heat faster than others. For
example, the jelly inside a jelly doughnut will be
hotter than the dough. Keep this in mind to avoid
burns.
• Home canning in the microwave oven is not
recommended because all harmful bacteria may
not be destroyed by the microwave heating
process.
• Although microwaves do not heat the cook-
ware, the heat is often transferred to the cook-
ware. Always use pot holders when removing
food from the microwave and instruct children
to do the same.
C
OOKING
I
NSTRUCTIONS
17
C
OOKING
I
NSTRUCTIONS
Keep in mind that microwaves cook from the outside to the inside, therefore the following techniques will
give the best results.
MS8796/9796-GB 9/27/00 3:21 AM Page 17
Important
• After installing the oven and plugging into an
electrical outlet, do not unplug the power cord.
The gas sensor needs time to stabilize in order
to cook satisfactorily.
• It its not advisable to use the auto sensor cook-
ing feature on a continuous cooking operation,
i.e. one cooking operation immediately after
another.
Let the oven cool 5 minutes before using Auto
Senser again.
• Install the oven in a well ventilated location for
proper cooling and airflow and to ensure the
sensor will operate accurately.
• To avoid poor results, do not use the Auto
Sensor when the room ambient temperature is
too high or too low.
• Do not use volatile detergent to clean your
oven. Gas resulting from this detergent may
affect the sensor.
• Avoid placing the oven near high moisture or
gas emitting appliances, since this will interfere
with the proper performance of the Auto
Sensor.
• Always keep the inside of the oven clean. Wipe
all spills with a damp cloth.
This oven is designed for household use only.
Auto Sensor Cook
The Auto Sensor allows you to cook your food
automatically by detecting the amount of gases
generated from the food while cooking.
• When cooking food, many kinds of gases are
generated. The Auto Sensor determines the
proper time and power level by detecting these
gases from the food, eliminating the need to set
the cooking time and power level.
• When you cover a container with its lid or plas-
tic wrap during Sensor Cooking, the Auto
Sensor will detect the gases generated after
the container has been saturated with steam.
• Shortly before cooking ends, the remaining
cooking time will begin its count down. This
will be a good time for you to rotate or stir the
food for even cooking if it is necessary.
• Before auto sensor cooking food may be sea-
soned with herbs, spices or browning sauces.
A word of caution though, salt or sugar may
cause burn spots on food so these ingredients
should be added after cooking.
• The MORE/LESS function pad is used to
increase or decrease cooking time. You should
use this function to adjust the degree of cook-
ing to suit your personal taste.
Utensils & Cover For Sensor Cooking
• To obtain good cooking results with this func-
tion, follow the directions for selecting appro-
priate containers and covers in the charts in
this book.
• Always use microwave-safe containers and
cover them with their lids or with plastic wrap.
When using plastic wrap, turn back one corner
to allow steam to escape at the proper rate.
• Always cover with the lid intended for the
utensil being used. If the utensil does not have
its own lid, use plastic wrap.
• Fill containers at least half full.
• Foods that require stirring or rotating should be
stirred or turned toward the end of the Sensor
Cook cycle, after the time has started to count
down on the display.
C
OOKING
I
NSTRUCTIONS
18 C
OOKING
I
NSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 18
GUIDE for Cooking Meat in Your Microwave
• Place meat on a microwave-safe roasting rack in a microwave-safe dish.
• Start meat fat-side down. Use narrow strips of aluminum foil to shield any bone tips or thin meat areas.
• Check the temperature in several places before letting the meat stand the recommended time.
• The following temperatures are removal temperatures. The temperature of the food will rise during the
standing time.
Roast Beef
Boneless
Up to 4 lbs.
Cook Time /Power Level Directions
Pork
Boneless or
bone-in
Up to 6 lbs.
Bacon
2-6 slices
Food
Whole
Chicken
Up to 6 lbs.
Cook Time /Power Level Directions
Chicken
Pieces
Up to 3 lbs.
Cooking Time:
5-8 min. / lb. 170°F -180°F
Power Level: Medium High(7).
Place chicken breast-side down on
roasting rack. Cover with wax paper.
Turn over when half of the cooking time
is up. Cook until juices run clear and
meat near the bone is no longer pink. Let
stand 5-10 min.
Food
Cooking Time:
5-8 min. / lb.
180°F dark meat
170°F light meat
Power Level: Medium High(7).
Place chicken bone-side down on dish,
with the thickest portions towards the
outside of the dish. Cover with wax
paper. Turn over when half of the cook-
ing time is up. Cook until juices run clear
and meat near the bone is no longer
pink. Let stand 5-10 min.
GUIDE for Cooking Poultry in Your Microwave
• Place poultry on a microwave-safe roasting rack in a microwave-safe dish.
• Cover poultry with wax paper to prevent spattering.
• Use aluminum foil to shield bone tips, thin meat areas, or areas that start to overcook.
• Check the temperature in several places before letting the poultry stand the recommended time.
Cooking Time:
8-11 min. / lb. for 115°F - Rare
9-13 min. / lb. for 120°F - Medium
10-15 min. / lb. for 145°F - Well Done
Power Level: High(10) for first 5 min., then Medium(5).
Place roast fat-side down on roast-
ing rack. Cover with wax paper.
Turn over when half of cooking
time is up. Let stand 10 min.
Cooking Time:
11-15 min. / lb. for 160° F Well Done
Power Level: High(10) for first 5 min., then Medium(5).
Place roast fat-side down on roast-
ing rack. Cover with vented plastic
wrap. Turn over when half of cook-
ing time is up. Let stand 10 min.
Cooking Time:
2 slices: 1 - 1 3/4 min.
4 slices: 3 - 3 1/2 min.
6 slices: 3 1/2 - 4 1/2 min.
Power Level: High(10).
Arrange slices on roasting rack or a
dish lined with paper-towel. Cover
with paper towel. Microwave until
crisp.
C
OOKING
I
NSTRUCTIONS
19
C
OOKING
I
NSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 19
20 C
OOKING
I
NSTRUCTIONS
Cooking Time:
3-7 min. / lb.
Power Level: Medium High(7).
Arrange fillets in a baking dish, turning
any thin pieces under. Cover with wax
paper. If fillets are over 1/2" thick, turn
over and rearrange when cooking time is
half up. Cook until fish flakes easily with a
fork. Let stand 2-3 min.
• Vegetables should be washed just before cooking.
Often, no extra water is needed. If dense vegeta-
bles such as potatoes, carrots and green beans
are being cooked, add about 1/4 cup water.
• Small vegetables (sliced carrots, peas, lima beans,
etc.) will cook faster than larger ones.
• Whole vegetables, such as potatoes, acorn
squash or corn on the cob, should be arranged in
a circle on the turntable before cooking. They will
cook more evenly if turned over after half the
cooking time.
• Always place vegetables like asparagus and broc-
coli with the stem ends pointing towards the edge
of the dish and the tips toward the center.
• When cooking cut vegetables, always cover the
dish with a lid or vented microwavable plastic
wrap.
• Whole, unpeeled vegetables such as potatoes,
squash, eggplant, etc., should have their skin
pricked in several spots before cooking to prevent
them from bursting.
• For more even cooking, stir or rearrange whole
vegetables halfway through the cooking time.
• Generally, the denser the food, the longer the
standing time. (Standing time refers to the time
necessary for dense, large foods and vegetables
to finish cooking after they come out of the oven.)
A baked potato can stand on the counter for five
minutes before cooking is completed, while a dish
of peas can be served immediately.
GUIDE for Cooking Eggs in Your Microwave
• Never cook eggs in the shell, and never warm hard-cooked eggs in the shell; they can explode.
• Always pierce whole eggs to keep them from bursting.
• Cook eggs just until set; they become tough if overcooked.
GUIDE for Cooking Vegetables in Your Microwave
GUIDE for Cooking Seafood in Your Microwave
• Cook fish until it flakes easily with a fork.
• Place fish on a microwave-safe roasting rack in a microwave-safe dish.
• Use a tight cover to steam fish. A lighter cover of wax paper or paper towel provides less steaming.
• Do not overcook fish; check it at minimum cooking time.
Steaks
Up to 3 lbs.
Cook Time /Power Level Directions
Fillets
Up to 3 lbs.
Shrimp
Up to 3 lbs.
Cooking Time:
6-10 min. / lb.
Power Level: Medium High(7).
Arrange steaks on roasting rack with
meaty portions towards the outside of
rack. Cover with wax paper. Turn over
and rearrange when half of cooking time
is up. Cook until fish flakes easily with a
fork. Let stand 3-5 min.
Food
Cooking Time:
3-5 1/2 min. / lb.
Power Level: Medium High(7).
Arrange shrimp in a baking dish without
overlapping or layering. Cover with wax
paper. Cook until firm and opaque, stir-
ring 2 or 3 times. Let stand 5 min.
C
OOKING
I
NSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 20
21
C
OOKING
I
NSTRUCTIONS
C
OOKING
I
NSTRUCTIONS
Procedure
Popcorn 1 package (3.0
to 3.5 oz.)
Use one microwave-only bag of popcorn. Pop only one bag at a time.
Use caution when removing and opening hot bag from oven.
When popping 1.5 or 1.75 oz. snack-size popcorn bags, use “Less” key
for best results. Let oven cool for at least 5 minutes before using again.
Potatoes 1 to 6 EA. Prick each potato several times with fork. Place on turntable
in spoke-like fashion. Let stand 3 -5 min.
Let oven cool for at least 5 minutes before using again.
Fresh Vegetables 1 to 4 cups Arrange fresh vegetables in microwave-safe ceramic, glass or
plastic dish and combine with 2 Tbs. water.
For even cooking, stir or turn vegetables according to
instructions. Let vegetables stand 3 minutes before serving.
Let oven cool for at least 5 minutes before using again.
Frozen Dinner 7 to 18 oz. Remove packing from outer wrapping and follow box
instructions for covering and standing.
Let oven cool for at least 5 minutes before using again.
Diet cook 7 to 18 oz. Remove package from outer wrapping and follow package
instructions for covering and standing.
Let oven cool for at least 5 minutes before using again.
Food Amount
SENSOR COOKING GUIDE
• Follow the instructions below when sensor cooking different types of food.
MS8796/9796-GB 9/27/00 3:21 AM Page 21
C
OOKING
I
NSTRUCTIONS
Procedure
Frozen Breakfast 2 to 8 oz. Follow box instruction for covering and standing. Use this pad
for frozen sandwich, breakfast entree, pancakes, waffles. etc.
Let oven cool for at least 5 minutes before using again.
Fish 0.5 to 1.5 lbs. Arrange fish in dish with thickest portions to the outside.
Overlap thin areas in center of dish. Turn thin ends under.
Cover with vented plastic wrap.
Let oven cool for at least 5 minutes before using again.
Plate of food 1 serving
(1 plate)
Use only pre-cooked, refrigerated foods.
Cover plate with vented plastic wrap or wax paper.
If food is not as hot as you prefer after heating with SENSOR
REHEAT, continue heating using time and power.
. Contents
- 3 ~ 4 oz. meat, poultry or fish(up to 6 oz.with bone)
- 1/2 cup starch (potatoes, pasta, rice, etc.)
- 1/2 cup vegetables (about 3 ~ 4 oz.)
Casseroles
Soups/Sauces 1 to 4 servings Use only refrigerated foods. Cover plate with lid or vented
plastic wrap. If food is not as hot as you prefer after heating
with SENSOR REHEAT, continue heating using time and power.
Stir foods once before serving.
Baby Food 2.5 to 6 oz. Remove lid from baby food and heat(heating time is very short).
Check temperature and stir well before serving.
The More/Less key cannot be used with the baby food key.
Food Amount
SENSOR REHEAT GUIDE
• Follow the instructions below when sensor reheating different types of food.
22 C
OOKING
I
NSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 22
Peas With Lettuce (4 servings)
2 cups fresh shelled green peas
1/3 cup thinly sliced celery
2 tablespoons water
3 cups shredded head lettuce
1 tablespoon butter or magarine
1 tablespoon all-purpose flour
1/2 teaspoon sugar
1/4 teaspoon salt
1/4 cup whipping cream
Dash pepper to taste
1 In 1 1/2-quart casserole combine peas, cel-
ery and water ; cover.
Microwave at HIGH (10) for 5 to 7 1/2 min-
utes or use Sensor Fresh Vegetable. Stir in
lettuce ; re-cover.
2 In small dish combine butter, flour, sugar, salt
and pepper.
Blend in cream. Microwave at HIGH (10) for
1 to 2 minutes or use Sensor Reheat. Stir
until smooth.
3 Drain vegetables. Add sauce to vegetables ;
toss to coat.
Stuffed Potatoes (4 servings)
4 medium potatoes, scrubbed
1/2 cup dairy sour cream
1/3 cup milk
2 tablespoons grated parmesan cheese
1 teaspoon chopped chives or parsley flakes
Salt, pepper, paprika to taste
1 Prick potatoes twice with a fork. Arrange
potatoes at least 1 inch apart on paper towel
placed on turntable. Microwave at HIGH (10)
for 10 to 12 minutes or use Sensor Potato.
Let stand 5 minutes.
2 Slice top from each potato ; scoop out cen-
ter. Mash with sour cream, milk, cheese,
chives, salt and pepper. Spoon into shells.
3 Sprinkle with paprika. Place on plate or on
paper towel in oven. Microwave at HIGH (10)
for 2 to 4 minutes or use Sensor Reheat.
Sensor Recipes
French Onion Soup (4 servings)
3 tablespoons butter or margarine
3 cups ( about 3 medium ) sliced onions
3 cups beef broth
1 cup water
1 teaspoon Worcestershire sauce
Salt, pepper, croutons, grated parmesan
cheese to taste
2 tablespoons brandy (optional)
1 Combine butter and onions in 3-quart casse-
role.
Cover with lid. Microwave at HIGH (10) for 8 to
9 minutes or use Sensor Fresh Vegetable.
2 Stir in broth, water, Worcestershire sauce, salt
and pepper ; cover.
Microwave at HIGH (10) for 5 minutes, and at
MEDIUM (5) for 5 minutes or use Sensor
Reheat. Stir in brandy.
Let stand, covered, for 5 minutes before serv-
ing.
Serve with croutons and cheese.
Snap Crackle Popcorn Balls
(10 to 15 balls)
30 square caramel candies
1 1/2 tablespoons water
1 teaspoon butter or magarine
1 pkg.( 3.5 oz.) microwave popcorn
1 Combine caramel, water and butter in 4 cup
glass bowl.
Microwave at HIGH (10) for 2 to 3 minutes until
melted.
Stir until smooth. Set aside.
2 Place popcorn on turntable. Microwave at
HIGH (10) for 2 to 3 minutes or use Sensor
Popcorn.
3 Place popcorn in bowl. Pour caramel mixture
over popcorn ; toss until completely coated
and cool enough to handle.
Using buttered hands, form into 3-inch balls.
4 Cool on waxed paper. Serve immediately.
C
OOKING
I
NSTRUCTIONS
23
C
OOKING
I
NSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 23
Vegetable Medley
(4 to 6 servings)
1 1/2 cups broccoli flowerets, 3/4 to 1 inch in
diameter
1 1/2 cups cauliflower flowerets, 3/4 to 1
inch in diameter
1 medium yellow squash, cut into 1/4 inch
diagonal slices
1 medium zucchini, cut into 1/4 inch diagonal
slices
1 medium carrot, cut into 1/8 inch diagonal
slices
1/2 small red pepper, slivered
6-7 pitted ripe olives, sliced
2-3 tablespoons butter or margarine
1/2 teaspoon dried oregano
1 teaspoon fresh lemon juice
parmesan cheese, optional to taste
1 Arrange broccoli and cauliflower alternately
around the edge of a 10 to 12 inch glass dish
with rim. Alternately place yellow squash
and zucchini in circle inside broccoli and
cauliflower, place carrots slices in center
and arrange red pepper slivers over top.
Sprinkle with 2 tablespoons water. Cover
with vented microwave plastic wrap.
2 Microwave at HIGH (10) for 7 to 9 minutes or
use Sensor Fresh Vegetable. Remove wrap
immediately, scatter olive slices attractively
over all.
3 Place butter or magarine in 1 cup glass mea-
sure and Microwave at HIGH (10) for 30 sec-
onds to 1 minute to melt. Add oregano and
lemon juice. Pour over vegetables. Sprinkle
with parmesan cheese and serve.
Franks And Beans Casserole
(4 to 6 servings)
1/2 cup chopped onions
2 tablespoons butter or margarine
1 pkg.(12 - 16 oz.) frankfurters, cut in quar-
ters
1 can (16 oz) baked beans
1 can (15 - 16 oz.) cannellini (white kidney)
beans,drained
1 can (15 - 16 oz.) red kidney beans,drained
1/3 cup brown sugar
1/4 cup catsup
1 teaspoon yellow mustard
Salt, pepper and garlic power to taste
1 Combine onions and butter in 3-quart casse-
role.
Microwave at HIGH(10) for 1 to 2 minutes or
until onions are soft.
2 Stir in all remaining ingredients, pushing
frankfurters to the bottom of dish so they are
covered with the beans.
3 Cover and microwave at HIGH (10) for 11 to
13 minutes or use Sensor Reheat. Stir until
smooth.
C
OOKING
I
NSTRUCTIONS
24 C
OOKING
I
NSTRUCTIONS
MS8796/9796-GB 9/27/00 3:21 AM Page 24
Troubleshooting Guide
Before you call a repair person for your oven,
check this list of possible problems and solutions.
Neither the oven’s display nor the oven operate.
• Properly insert the plug into a grounded outlet.
• If the outlet is controlled by a wall switch, make
sure the wall switch is turned on.
• Remove the plug from the outlet, wait ten sec-
onds, then plug it in again.
• Reset the circuit breaker or replace any blown
fuse.
• Plug another appliance into the outlet; if the
other appliance doesn’t work, have a qualified
electrician repair the outlet.
• Plug the oven into a different outlet.
The oven’s display works, but the power won’t
come on.
• Make sure the door is closed securely.
• Check to see if packing material or other materi-
al is stuck to the door seal.
• Check for door damage.
• Press Cancel twice and re-enter all cooking
instructions.
The power goes off before the set time has
elapsed.
• If there has not been a power outage, remove
the plug from the outlet, wait ten seconds, then
plug it in again. If there was a power outage, the
time indicator will display “SAMSUNG SO SIM-
PLE” Reset the clock and any cooking instruc-
tions.
• Reset the circuit breaker or replace any blown
fuse.
The food is cooking too slowly.
• Make sure the oven is on its own 20 amp circuit
line. Operating another appliance on the same
circuit can cause a voltage drop. If necessary,
move the oven to its own circuit.
You see sparks or arcing.
• Remove any metallic utensils, cookware, or
metal ties. If using foil, use only narrow strips
and allow at least one inch between the foil and
interior oven walls.
The turntable makes noises or sticks.
• Clean the turntable, roller ring and oven floor.
• Make sure the turntable and roller ring are posi-
tioned correctly.
Using your microwave causes TV or radio
interference.
• This is similar to the interference caused by
other small appliances, such as hair dryers.
Move your microwave further away from other
appliances, like your TV or radio.
Care and Cleaning
Follow these instructions to clean and care for
your oven.
• Keep the inside of the oven clean. Food parti-
cles and spilled liquids can stick to the oven
walls, causing the oven to work less efficiently.
• Wipe up spills immediately. Use a damp cloth
and mild soap. Do not use harsh detergents or
abrasives.
• To help loosen baked on food particles or liq-
uids, heat two cups of water (add the juice of
one lemon if you desire to keep the oven fresh)
in a four-cup measuring glass at High power for
five minutes or until boiling. Let stand in the
oven for one or two minutes.
• Remove the glass tray from the oven when
cleaning the oven or tray. To prevent the tray
from breaking, handle it carefully and do not put
it in water immediately after cooking. Wash the
tray carefully in warm sudsy water or in the
dishwasher.
• Clean the outside surface of the oven with soap
and a damp cloth. Dry with a soft cloth. To pre-
vent damage to the operating parts of the oven,
don’t let water seep into the openings.
• Wash the door window with very mild soap and
water. Be sure to use a soft cloth to avoid
scratching.
• If steam accumulates inside or outside the oven
door, wipe with a soft cloth. Steam can accumu-
late when operating the oven in high humidity
and in no way indicates microwave leakage.
• Never operate the oven without food in it; this
can damage the magnetron tube or glass tray.
You may wish to leave a cup of water in the
oven when it is not in use to prevent damage if
the oven is accidentally turned on.
A
PPENDIX
25
A
PPENDIX
If you have a problem you cannot solve,
please call our service line:
1-800-SAMSUNG
MS8796/9796-GB 9/27/00 3:21 AM Page 25
Obligation to the Original Owner
The original dated sales receipt must be retained
by the customer and is the only acceptable proof
of purchase. It must be presented to an SEA
Authorized Service Center at the time service is
requested before warranty services are rendered.
On all carry-in models, transportation to and from
the Authorized Service Center is the responsibility
of the customer.
Exclusions of the Warranty
This warranty does not cover damage due to acci-
dent, fire, flood, and/or other Acts of God: misuse,
incorrect line voltage, improper installation,
improper or unauthorized repairs, commercial use,
or damage that occurs during shipping. Customer
adjustments which are explained in this owner’s
manual are not covered under the terms of this
warranty. This warranty will automatically be void-
ed for any unit found with a missing or altered seri-
al number. This warranty is valid only on products
purchased and used in the United States and
Puerto Rico. Some states do not allow the exclu-
sion or limitations of incidental or consequential
damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty
gives you specific legal rights and you may also
have other rights which vary from state to state.
A
PPENDIX
26 A
PPENDIX
Warranty Information
Limited Warranty for Original Purchaser
This Samsung product is warranteed by Samsung
Electronics America, Inc. (hereafter referred to as
SEA) against manufacturing defects in material or
workmanship for the following periods:
Labor: One year (carry-in)
Parts: One year
Magnetron: Eight years
SEA further warrants that if this product fails to
operate properly within the specified warranty
period and the failure is due to improper workman-
ship or defective material, SEA will repair or
replace the product at its option.
All warranty repairs or part replacements must be
performed by a SEA Authorized Service Center. (To
find the nearest SEA Service Center, call 1-800-
SAMSUNG.)
Specifications
Model Number
Oven Cavity
Controls
Timer
Power Source
Power Output
Outside Dimensions
Oven Cavity Dimensions
Net/Gross Weight
MS8796W / MW1666WC
1.6cuft
10 power levels, including defrost
99 minutes, 99 seconds
120 VAC, 60 Hz
1100 Watts
2121/32”(W) X 135/16”(H) X 1811/32”(D)
161/2”(W) X 93/16”(H) X 179/32”(D)
44/50 lbs
MS8796/9796-GB 9/27/00 3:21 AM Page 26
Ajustando el Tiempo de Concinar y Niveles
de Potencia – Cocinando en Etapas Múltiples
• Utilice los botones numéricos 0–9 para
ajustar el tiempo de cocinar.
• Oprima el botón POWER LEVEL, y los
botones numéricos 0–9 para seleccionar la
potencia de cocinar (si es diferente a 0).
• Utilice los botones numéricos 0–9 para
ajustar el segundo tiempo de cocinar.
• Oprima el botón POWER LEVEL, y los
botones numéricos 0–9 para seleccionar la
potencia de cocinar (si es diferente a 0).
• Utilice los botones numéricos 0–9 para
ajustar el tercer tiempo de cocinar.
• Oprima el botón POWER LEVEL, y los
botones numéricos 0–9 para seleccionar la
potencia de cocinar (si es diferente a 0).
• Oprima el botón START para comenzar a
cocinar.
G
UÍA DE
C
ONSULTA
R
ÁPIDA EN
E
SPAÑOL
27
G
UÍA DE
C
ONSULTA
R
ÁPIDA EN
E
SPAÑOL
Usando el Botón PAUSE/CANCEL
• Para pausar mientras está cocinando, opri-
ma una vez al botón PAUSE/CANCEL.
• Para detener el horno y borrar las instruc-
ciones para cocinar, oprima dos veces al
botón PAUSE/CANCEL.
• Para corregir un error de programación,
oprima una vez al botón PAUSE/CANCEL y
vuelva a programr las instrucciones.
• Para cancelar un ajuste del cronómetro,
oprima una vez al botón PAUSE/CANCEL.
Encendiendo el Horno y Seleccionando el
Idioma del desPliegue
• Enchufe el horno de microondas y oprima
el botón START repetidamente hasta que
vea el idioma y sistema de medida que
desea utilizar.
Poniendo el Reloj
• Oprima una vez al botón CLOCK.
• Utilice los botones numéricos 0–9 para
seleccionar la hora correcta.
• Oprima una vez más al botón CLOCK para
fijar la hora.
Ajustando el Tiempo de Concinar y Niveles
de Potencia – Cocinando en una Etapa
• Utilice los botones numéricos 0–9 para
ajustar el tiempo de cocinar.
• Oprima el botón POWER LEVEL, y los
botones numéricos 0–9 para seleccionar la
potencia de cocinar (si es diferente a 0).
• Oprima el botón START para comenzar a
cocinar.
MS8796/9796-GB 9/27/00 3:21 AM Page 27
G
UÍA DE
C
ONSULTA
R
ÁPIDA EN
E
SPAÑOL
28 G
UÍA DE
C
ONSULTA
R
ÁPIDA EN
E
SPAÑOL
Descongelado Automático
• Oprima repetidamente al botón AUTO
DEFROST para ajustar el peso correcto de
la comida que va descongelar.
Recalentamiento Sensor
• Oprima repetidamente al botón Seneor
REHEAT para seleccionar el tipo de comi-
da.
• Utilice los botones numéricos 0-9 para pro-
gramar las porciones (si son más de una
porción).
• Oprima el botón START para comenzar a
cocinar.
Cocinando Con un Bóton
• Oprima el botón ONE MINUTE una vez para
cada minuto que desea cocinar.
Usando el Teclado de Cocina Sensor cook
• Selecione el botón “Sensor-cook” (POP-
CORN, FROZEN DINNER, etc.) apropiado
para el tipo de comida que desea cocinar,
oprima este botón repetidamente para pro-
gramar el tamaño de la porción.
Ajustando el Tiempo de Cocinado
• Si desea ajustar el tiempo de cocinado
mientras el horno está en operación, opri-
ma el botón MORE/LESS repetidamente
hasta llegar al tiempo deseado.
Usando el Cronómetro
• Oprima los botones numéricos 0–9 para
ajustar el tiempo, luego oprima el botón
KITCHEN TIMER.
Utilizando el Seguro Para Evitar que Niños
Utilicen el Horno
• Oprima los botones 0, 2 y START. Repita
para pagar el seguro.
MS8796/9796-GB 9/27/00 3:21 AM Page 28
SAMSUNG ELECTRONICS
NORTH AMERICAN LIMITED WARRANTY STATEMENT
Subject to the requirements, conditions, exclusions and limitations of
the Original Limited Warranty supplied with Samsung Electronics
(SAMSUNG) products, and the requirements, conditions, exclusions
and limitations contained herein, SAMSUNG will additionally provide
Warranty Repair Service in the United States on SAMSUNG
products purchased in Canada, and in Canada on SAMSUNG
products purchased in the United States, for the warranty period orig-
inally specified, and to the Original Purchaser only.
The above described warranty repairs must be performed by a
SAMSUNG Authorized Service Center. Along with this Statement,
the Original Limited Warranty Statement and a dated Bill of Sale as
Proof of Purchase must be presented to the Service Center.
Transportation to and from the Service Center is the responsibility of
the purchaser.
Conditions covered are limited only to manufacturing defects in
material or workmanship, and only those encountered in normal use
of the product.
Excluded, but not limited to, are any original specified provisions for,
in-home or on-site services, minimum or maximum repair times,
exchanges or replacements, accessories, options, upgrades, or
consumables.
For the locations of a SAMSUNG Authorized Service Center, please
call toll-free:
In the United States: 1-800-SAMSUNG ( 1-800-726-7864 )
In Canada: 1-800-SAMSUNG
29
MS8796/9796-GB 9/27/00 3:21 AM Page 29
SAMSUNG ELECTRONICS
GARANTIE LIMITÉE POUR L’AMÉRIQUE DU NORD
Assujettie aux exigences, conditions, exclusions et limitations
de la garantie limitée originale fournie avec les produits de
Samsung Electronics (SAMSUNG) et les exigences,
conditions, exclusions et limitations de la présente garantie,
SAMSUNG offrira en plus un service de réparation sous
garantie aux États-Unis pour les produits achetés au Canada
et un service
de réparation sous garantie au Canada pour les produits
achetés aux États-Unis pendant la période de garantie
précisée à l’origine et pour l’acheteur inital seulement.
Les réparations sous garantie décrites ci-dessus doivent
être effectuées dans un centre de réparation agréé
SAMSUNG. En plus de la présente garantie, la garantie lim-
itée originale et une facture datée en tant que preuve d’achat
doivent être présentées au centre de réparation. Le transport
de l’appareil au et à partir du centre de réparation demeure
la responsabilité de l’acheteur.
Les conditions couvertes ne sont limitées qu’aux vices de
matériaux et de fabrication dans des conditions d’utilisation
normale.
Exclues, mais non pas limitées à, sont les dispositions
précisées à l’origine pour le service à domicile ou sur place,
durées de réparation minimales et maximales, échanges ou
remplacements, accessoires, options, extensions ou
produits non durables.
Pour obtenir le nom d’un centre de réparation agréé
Samsung, appelez sans frais :
Aux États-Unis : 1-800-SAMSUNG (1-800-726-7864)
Au Canada : 1-800-SAMSUNG
30
MS8796/9796-GB 9/27/00 3:21 AM Page 30
Q
UICK
R
EFERENCE
ELECTRONICS
Operation
1. Press CLOCK.
2. Use number buttons to enter time.
3. Press CLOCK again.
1. Use number buttons to set cooking time.
2. Set power level or leave at high.
3. Press START.
1. Press the ONE MINUTE + button once for each minute of cooking.
2. The time will display and the oven will start.
1. Press button that corresponds to the food you are cooking
(for example, POPCORN).
2. The display will show the food you have chosen and the
oven will start automatically.
1. Press AUTO DEFROST.
2. Enter weight of food by pressing AUTO DEFROST button
repeatedly or using the number buttons.
3. When prompted by oven display, open oven door
and turn food over. Press START to resume defrosting cycle.
1. Press SENSOR REHEAT repeatedly to select type of dish to reheat.
2.To increase serving size, press the corresponding number button.
3. Press START to begin reheating cycle.
1. Use number buttons to set cooking time.
2. To set power level at other than HIGH, press POWER LEVEL and
use the number buttons to enter the power level.
(Example: number 5 is 50% power.)
3. Press START to begin cooking.
Feature
Set Clock
One Stage Cooking
One Minute+ Cooking
Sensor Cook Buttons
Auto Defrost
Sensor Reheat
Set Cooking Time and
Power Levels
SAMSUNG ELECTRONICS AMERICA, INC.
HEADQUARTERS
105 CHALLENGER ROAD
RIDGEFIELD PARK, NEW JERSEY 07660-0511
April. 1999
Printed in Korea
MS8796/9796-GB 9/27/00 3:21 AM Page 31
