Users Manual
Microwave Oven
164D3370P162 49-40171-3 05-01 JR
JVM1840
JVM1841
JVM1842
Owner’s
Manual
Safety Information
Arcing . . . . . . . . . . . . . . . . .4
Foods . . . . . . . . . . . . . . .4, 5
Grounding
Instructions . . . . . . . . . . . .8
Microwave-Safe
Cookware . . . . . . . . . . . .6, 7
Precautions to Avoid
Possible Exposure to
Excessive Microwave
Energy . . . . . . . . . . . . . . . . .2
Safety Precautions . . . .2, 3
Vent Fan . . . . . . . . . . . . . . .9
Operating Instructions
Auto Feature . . . . . . . . . .20
Care and
Cleaning . . . . . . . . . .34, 35
Changing the
Power Level . . . . . . . . . . .13
Convenience
Features . . . . . . . . . . .21–25
Cooking Guide . . . . .15, 16
Defrosting Guide . . . . . .18
Exhaust Feature . . . .37, 38
Features of Your
Microwave Oven . . .11, 12
Microwave Terms . . . . . .33
Other Features . . . . 26–32
Replacing Bulbs . . . . . . .36
Time Features . . . . .14–19
Troubleshooting Tips
Before You Call
For Service . . . . . . . . . . . .39
Things That Are
Normal With Your
Microwave Oven . . . . . . .39
Consumer Support
Consumer
Support . . . . . .Back Cover
Optional Kits . . . . . . . . .10
Product
Registration . . . . . . .41, 42
Warranty . . . . . . . . . . . . .43
Español
For a Spanish version of this
manual, visit our Website at
www.GEAppliances.com.
Para consultar una version
en español de este manual
de instrucciones, visite
nuestro sitio de internet
www.GEAppliances.com.
www.GEAppliances.com
SpacemakerXL
Write the model and serial numbers here:
Model #
________________________
Serial #
________________________
Find these numbers on a label inside
the oven.
49-401713v01 5/1/01 1:12 PM Page 1
■Read and follow the specific
precautions in the
Precautions
to Avoid Possible Exposure to
Excessive Microwave Energy
section above.
■This appliance must be
grounded. Connect only
to a properly grounded
outlet. See the
Grounding
Instructions
section on page 8.
■Install or locate this
appliance only in accordance
with the provided Installation
Instructions.
■
Do Not Attempt
to operate
this oven with the door open
since open-door operation
can result in harmful
exposure to microwave
energy. It is important not to
defeat or tamper with the
safety interlocks.
■
Do Not Place
any object
between the oven front
face and the door or allow
soil or cleaner residue to
accumulate on sealing
surfaces.
■
Do Not Operate
the oven if it is
damaged. It is particularly
important that the oven door
close properly and that there
is no damage to the:
door (bent),
hinges and latches
(broken or loosened),
door seals and sealing
surfaces.
■
The Oven Should Not
be
adjusted or repaired by
anyone except properly
qualified service personnel.
3
2
1
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
2
For your safety, the information in this manual must be
followed to minimize the risk of fire or explosion, electric
shock, or to prevent property damage, personal injury, or
loss of life.
WARNING!
This microwave oven is UL listed for installation over
electric and gas ranges. This microwave oven is not
approved or tested for marine use.
SAFETY PRECAUTIONS
49-401713v01 5/1/01 1:12 PM Page 2
www.GEAppliances.com
3
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Use this appliance only for its intended purpose as
described in this Owner’s Manual.
■Do not mount this
appliance over a sink.
■This over-the-range oven
was designed for use over
ranges no wider than 36″.
It may be installed over
both gas and electric
cooking equipment.
■Do not operate this
appliance if it has a
damaged power cord or
plug, if it is not working
properly, or if it has been
damaged or dropped. If
the power cord is damaged,
it must be replaced by
General Electric Service
or an authorized service
agent using a power
cord available from
General Electric.
■Do not cover or block any
openings on the appliance.
■Use this appliance only
for its intended use as
described in this manual.
Do not use corrosive
chemicals or vapors in this
appliance. This microwave
oven is specifically designed
to heat, dry or cook food,
and is not intended for
laboratory or industrial use.
■Do not store this appliance
outdoors. Do not use this
product near water—
for example, in a wet
basement, near a swimming
pool or near a sink.
■Keep power cord away from
heated surfaces.
■Do not immerse power cord
or plug in water.
■To reduce the risk of fire
in the oven cavity:
— Do not overcook food.
Carefully attend appliance
if paper, plastic or other
combustible materials are
placed inside the oven
while cooking.
— Remove wire twist-ties and
metal handles from paper
or plastic containers before
placing them in the oven.
— Do not use the oven for
storage purposes. Do not
leave paper products,
cooking utensils or food in
the oven when not in use.
— If materials inside the oven
should ignite, keep the oven
door closed, turn the oven
off and disconnect the
power cord, or shut off
power at the fuse or circuit
breaker panel. If the door is
opened, the fire may spread.
■See door surface cleaning
instructions in the
Care and
cleaning of the microwave
oven
section of this manual.
■This appliance should be
serviced only by qualified
service personnel. Contact
nearest authorized service
facility for examination,
repair or adjustment.
■As with any appliance, close
supervision is necessary
when used by children.
49-401713v01 5/1/01 1:12 PM Page 3
Arcing is the microwave term
for sparks in the oven. Arcing
is caused by:
■The metal shelf not
installed correctly so it
touches the microwave wall.
■Metal or foil touching the
side of the oven.
■Foil not molded to food
(upturned edges act like
antennas).
■Metal, such as twist-ties,
poultry pins, or gold-
rimmed dishes, in the
microwave.
■Recycled paper towels
containing small metal
pieces being used in the
microwave.
■Do not pop popcorn in your
microwave oven unless in a
special microwave popcorn
accessory or unless you use
popcorn labeled for use in
microwave ovens.
■Some products such as
whole eggs and sealed
containers—for example,
closed jars—will explode
and should not be heated in
this microwave oven. Such
use of the microwave oven
could result in injury.
■Do not boil eggs in a
microwave oven. Pressure
will build up inside egg yolk
and will cause it to burst,
possibly resulting in injury.
■Operating the microwave
with no food inside for
more than a minute or two
may cause damage to the
oven and could start a fire.
It increases the heat around
the magnetron and can
shorten the life of the oven.
■Foods with unbroken outer
“skin” such as potatoes, hot
dogs, sausages, tomatoes,
apples, chicken livers and
other giblets, and egg yolks
should be pierced to allow
steam to escape during
cooking.
FOODS
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
4
WARNING!
If you see arcing, press the CLEAR/OFF pad and correct
the problem.
ARCING
49-401713v01 5/1/01 1:12 PM Page 4
www.GEAppliances.com
5
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
■
SUPERHEATED WATER
Microwaved water and other
liquids do not always bubble
when they reach the boiling
point. They can actually get
superheated and not bubble
at all.
Superheated liquid will bubble
up out of the cup when it is
moved or when something
like a spoon or tea bag is put
into it.
To prevent this from
happening and causing injury,
do not heat any liquid for
more than 2 minutes per cup.
After heating, let the cup
stand in the microwave for
30 seconds before moving it
or putting anything into it.
■Avoid heating baby food in
glass jars, even with the lid
off. Make sure all infant
food is thoroughly cooked.
Stir food to distribute the
heat evenly. Be careful to
prevent scalding when
warming formula or breast
milk. The container may
feel cooler than the milk
really is. Always test the milk
before feeding the baby.
■Don’t defrost frozen
beverages in narrow-necked
bottles (especially
carbonated beverages).
Even if the container is
opened, pressure can build
up. This can cause the
container to burst, possibly
resulting in injury.
■Spontaneous boiling—
Under certain special
circumstances, liquids may
start to boil during or shortly
after removal from the
microwave oven. To prevent
burns from splashing liquid,
we recommend the
following: before removing
the container from the oven,
allow the container to stand
in the oven for 30 to 40
seconds after the oven has
shut off. Do not boil liquids
in narrow-necked containers
such as soft drink bottles,
wine flasks and especially
narrow-necked coffee cups.
Even if the container is
opened, excessive steam
can build up and cause it
to burst or overflow.
■Hot foods and steam can
cause burns. Be careful
when opening any
containers of hot food,
including popcorn bags,
cooking pouches and
boxes. To prevent possible
injury, direct steam away
from hands and face.
■Do not overcook potatoes.
They could dehydrate and
catch fire, causing damage
to your oven.
■Cook meat and poultry
thoroughly—meat to at
least an INTERNAL
temperature of 160°F.
and poultry to at least an
INTERNAL temperature
of 180°F. Cooking to
these temperatures
usually protects against
foodborne illness.
49-401713v01 5/1/01 1:12 PM Page 5
Make sure all cookware used
in your microwave oven is
suitable for microwaving.
Most glass casseroles, cooking
dishes, measuring cups,
custard cups, pottery or china
dinnerware which does not
have metallic trim or glaze
with a metallic sheen can be
used. Some cookware is
labeled “suitable for
microwaving.”
■If you are not sure if a dish
is microwave-safe, use this
test: Place in the oven both
the dish you are testing and
a glass measuring cup filled
with 1 cup of water—set the
measuring cup either in or
next to the dish. Microwave
30–45 seconds at high. If
the dish heats, it should not
be used for microwaving.
If the dish remains cool
and only the water in the
cup heats, then the dish is
microwave-safe.
■If you use a meat
thermometer while cooking,
make sure it is safe for use in
microwave ovens.
■Do not use recycled paper
products. Recycled paper
towels, napkins and waxed
paper can contain metal
flecks which may cause
arcing or ignite. Paper
products containing nylon
or nylon filaments should
be avoided, as they may
also ignite.
■Some styrofoam trays (like
those that meat is packaged
on) have a thin strip of
metal embedded in the
bottom. When microwaved,
the metal can burn the
floor of the oven or ignite
a paper towel.
■Do not use the microwave
to dry newspapers.
■Not all plastic wrap is
suitable for use in microwave
ovens. Check the package
for proper use.
■Paper towels, waxed paper
and plastic wrap can be
used to cover dishes in
order to retain moisture
and prevent spattering.
Be sure to vent plastic wrap
so steam can escape.
■Cookware may become hot
because of heat transferred
from the heated food. Pot
holders may be needed to
handle the cookware.
MICROWAVE-SAFE COOKWARE
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
6
WARNING!
49-401713v01 5/1/01 1:12 PM Page 6
www.GEAppliances.com
7
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
■“Boilable” cooking pouches
and tightly closed plastic
bags should be slit, pierced
or vented as directed by
package. If they are not,
plastic could burst during
or immediately after
cooking, possibly resulting
in injury. Also, plastic
storage containers should
be at least partially
uncovered because they
form a tight seal. When
cooking with containers
tightly covered with plastic
wrap, remove covering
carefully and direct steam
away from hands and face.
■Use foil only as directed in
this manual. TV dinners
may be microwaved in foil
trays less than 3/4″high;
remove the top foil cover
and return the tray to the
box. When using foil in the
microwave oven, keep the
foil at least 1″away from
the sides of the oven.
■Plastic cookware—Plastic
cookware designed for
microwave cooking is very
useful, but should be used
carefully. Even microwave-
safe plastic may not be as
tolerant of overcooking
conditions as are glass or
ceramic materials and may
soften or char if subjected
to short periods of
overcooking. In longer
exposures to overcooking,
the food and cookware
could ignite.
Follow these guidelines:
Use microwave-safe
plastics only and
use
them in strict
compliance
with
the cookware
manufacturer’s
recommendations.
Do not microwave
empty containers.
Do not permit children
to use plastic cookware
without complete
supervision.
3
2
1
49-401713v01 5/1/01 1:12 PM Page 7
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
This appliance is equipped with a power cord having a
grounding wire with a grounding plug. The plug must be
plugged into an outlet that is properly installed and grounded.
Consult a qualified electrician or service technician if the
grounding instructions are not completely understood, or if
doubt exists as to whether the appliance is properly grounded.
If the outlet is a standard 2-prong wall outlet, it is your personal
responsibility and obligation to have it replaced with a properly
grounded 3-prong wall outlet.
Do not under any circumstances cut or remove the third
(ground) prong from the power cord.
Do not use an adapter plug with this appliance.
Do not use an extension cord with this appliance. If the power
cord is too short, have a qualified electrician or service technician
install an outlet near the appliance.
For best operation, plug this appliance into its own electrical
outlet to prevent flickering of lights, blowing of fuse or tripping
of circuit breaker.
GROUNDING INSTRUCTIONS
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
8
WARNING!
Improper use of the grounding plug can result in a risk of
electric shock.
49-401713v01 5/1/01 1:12 PM Page 8
www.GEAppliances.com
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
9
The fan will operate automatically under certain conditions (see
Automatic Fan feature). Take care to prevent the starting and
spreading of accidental cooking fires while the vent fan is in use.
■Clean the underside of the microwave often. Do not allow
grease to build up on the microwave or the fan filters.
■In the event of a grease fire on the surface units below the
microwave oven, smother a flaming pan on the surface unit
by covering the pan completely with a lid, a cookie sheet or
a flat tray.
■Use care when cleaning the vent fan filters. Corrosive
cleaning agents, such as lye-based oven cleaners, may damage
the filters.
■When preparing flaming foods under the microwave, turn
the fan on.
■Never leave surface units beneath your microwave oven
unattended at high heat settings. Boilovers cause smoking
and greasy spillovers that may ignite and spread if the
microwave vent fan is operating. To minimize automatic fan
operation, use adequate sized cookware and use high heat
on surface units only when necessary.
THE VENT FAN
READ AND FOLLOW THIS SAFETY
INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
49-401713v01 5/1/01 1:12 PM Page 9
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
10
Filler Panel Kits
JX52WH—White
JX52BL—Black
JX52CT—Bisque
When replacing a 36″range hood, filler panel kits fill in the
additional width to provide a custom built-in appearance.
For installation between cabinets only; not for end-of-cabinet
installation. Each kit contains two 3″-wide filler panels.
Filter Kits
JX81B—Recirculating Charcoal Filter Kit
Filter kits are used when the microwave oven cannot be vented
to the outside.
Decorative Panel Kit
JX22SS—Stainless Steel
When replacing a Hi/Low range, the decorative panel kit fills
in the area between the microwave and the range left by the
Hi/Low model.
Available at extra cost from your GE supplier.
OPTIONAL KITS
About optional kits.
49-401713v01 5/1/01 1:12 PM Page 10
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
11
About the features of your
microwave oven.
www.GEAppliances.com
Throughout this manual, features and appearance may vary from
your model.
Features of the Oven
Door Handle.
Pull to open
the door. The door must
be securely latched for
the microwave to operate.
Door Latches.
Window with Metal Shield.
Screen allows cooking to
be viewed while keeping
microwaves confined in
the oven.
Shelf.
Lets you microwave
several foods at once.
Food microwaves best
when placed directly
on the oven floor or
turntable.
Touch Control Panel.
Cooktop Lights.
Grease Filters.
Removable Turntable.
Turntable and support
must be in place when
using the oven. The
turntable may be
removed for cleaning.
NOTE: Rating plate, oven
vent(s) and oven light are
located on the inside walls
of the microwave oven.
1000 Watts
49-401713v01 5/1/01 1:12 PM Page 11
You can microwave by time or with the convenience features.
About the features of your microwave oven.
Cooking Controls
Time Features
Press Enter
TIME COOK I & II Amount of cooking time
Press once or twice
TIME DEFROST Amount of defrosting time
EXPRESS COOK Starts immediately!
ADD 30 SEC Starts immediately!
POWER LEVEL Power level 1–10
AUTO/QUICK DEFROST Food weight
Press once (Auto Defrost) up to 6 lbs.
Press twice (Quick Defrost) up to 1 lb.
Convenience Features
Press Enter Option
POPCORN Starts immediately! more/less time
Press once 3.5 oz.
Press twice 3.0 oz.
Press 3 times 1.75 oz.
BEVERAGE Starts immediately!
Press once 4 oz.
Press twice 8 oz.
Press 3 times 12 oz.
COOK Food type 1–6 + weight
REHEAT Food type 1–6 1–3 servings
VEGETABLE
Press once (fresh vegetables) Food weight
Press twice (frozen vegetables)
Press three times (canned vegetables)
SNACKS Snack type 1–6 number/weight
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
12
49-401713v01 5/1/01 1:12 PM Page 12
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
13
About changing the
power level.
www.GEAppliances.com
Variable power levels add flexibility to microwave
cooking. The power levels on the microwave oven
can be compared to the surface units on a range.
High (power level 10) or full power is the fastest
way to cook and gives you 100% power. Each power
level gives you microwave energy a certain percent
of the time. Power level 7 is microwave energy 70%
of the time. Power level 3 is energy 30% of the time.
A high setting (10) will cook faster but food may
need more frequent stirring, rotating or turning
over. Most cooking will be done on High (power
level 10). A lower setting will cook more evenly
and need less stirring or rotating of the food.
Some foods may have better flavor, texture or
appearance if one of the lower settings is used. Use
a lower power level when cooking foods that have a
tendency to boil over, such as scalloped potatoes.
Rest periods (when the microwave energy cycles off)
give time for the food to “equalize” or transfer heat
to the inside of the food. An example of this is shown
with power level 3—the defrost cycle. If microwave
energy did not cycle off, the outside of the food
would cook before the inside was defrosted.
Here are some examples of uses for various
power levels:
Power Level Best Uses
High 10
Fish, bacon, vegetables, boiling liquids.
Med-High 7
Gentle cooking of meat and poultry;
baking casseroles and reheating.
Medium 5
Slow cooking and tenderizing such as
stews and less tender cuts of meat.
Low 2 or 3
Defrosting without cooking;
simmering; delicate sauces.
Warm 1
Keeping food warm without
overcooking; softening butter.
How to Change the
Power Level
The power level may
be entered or changed
immediately after
entering the feature
time for
TIME COOK
,
TIME DEFROST, EXPRESS
COOK
or
ADD 30 SEC.
The power level may
also be changed during
time countdown.
Press
TIME COOK
or
TIME DEFROST
.
Enter cooking or
defrosting time.
Press
POWER LEVEL
.
Select desired
power level 1–10.
Press
START.
5
4
3
2
1
49-401713v01 5/1/01 1:12 PM Page 13
About the time features.
Time Cook I
Allows you to microwave for any time up to 99
minutes and 99 seconds.
Power level 10 (High) is automatically set, but you
may change it for more flexibility.
You may open the door during
TIME COOK
to check
the food. Close the door and press
START
to resume
cooking.
Time Cook II
Lets you change power levels automatically during
cooking. Here’s how to do it:
Press
TIME COOK
.
Enter the first cook time.
Change the power level if you don’t want full
power. (Press
POWER LEVEL
. Select a desired
power level 1–10.)
Press
TIME COOK
again.
Enter the second cook time.
Change the power level if you don’t want full
power. (Press
POWER LEVEL
. Select a power
level 1–10.)
Press
START
.
At the end of
Time Cook I
,
Time Cook II
counts down.
7
6
5
4
3
2
1
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
TIME
COOK
2
EXPRESS COOK
5
EXPRESS COOK
789
0
START
PAUSE
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
14
Press
TIME COOK
.
Enter cooking time.
Change power level
if you don’t want
full power. (Press
POWER LEVEL.
Select
a desired power
level 1–10.)
Press
START
.
4
3
2
1
49-401713v01 5/1/01 1:12 PM Page 14
15
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
www.GEAppliances.com
Cooking Guide for Time Cook I and Time Cook II
NOTE: Use power level High (10) unless otherwise noted.
Vegetable Amount Time Comments
Asparagus
(fresh spears) 1 lb. 6 to 9 min., In 1
1
⁄
2
-qt. oblong glass baking
Med-High (7) dish, place 1/4 cup water.
(frozen spears) 10-oz. package 5 to 7 min. In 1-qt. casserole.
Beans
(fresh green) 1 lb. cut in half 9 to 11 min. In 1
1
⁄
2
-qt. casserole, place
1/2 cup water.
(frozen green) 10-oz. package 6 to 8 min. In 1-qt. casserole, place
2 tablespoons water.
(frozen lima) 10-oz. package 6 to 8 min. In 1-qt. casserole, place
1/4 cup water.
Beets
(fresh, whole) 1 bunch 17 to 21 min. In 2-qt. casserole, place
1/2 cup water.
Broccoli
(fresh cut) 1 bunch 7 to 10 min. In 2-qt. casserole, place
(1
1
⁄
4
to 1
1
⁄
2
lbs.) 1/2 cup water.
(fresh spears) 1 bunch 9 to 13 min. In 2-qt. oblong glass baking
(1
1
⁄
4
to 1
1
⁄
2
lbs.) dish, place 1/4 cup water.
(frozen, 10-oz. package 5 to 7 min. In 1-qt. casserole.
chopped)
(frozen spears) 10-oz. package 5 to 7 min. In 1-qt. casserole, place
3 tablespoons water.
Cabbage
(fresh) 1 medium head 8 to 11 min. In 1
1
⁄
2
- or 2-qt. casserole, place
(about 2 lbs.) 1/4 cup water.
(wedges) 7 to 10 min. In 2- or 3-qt. casserole, place
1/4 cup water.
Carrots
(fresh, sliced) 1 lb. 7 to 9 min. In 1
1
⁄
2
-qt. casserole, place
1/4 cup water.
(frozen) 10-oz. package 5 to 7 min. In 1-qt. casserole, place
2 tablespoons water.
Cauliflower
(flowerets) 1 medium head 9 to 14 min. In 2-qt. casserole, place
1/2 cup water.
(fresh, whole) 1 medium head 10 to 17 min. In 2-qt. casserole, place
1/2 cup water.
(frozen) 10-oz. package 5 to 7 min. In 1-qt. casserole, place
2 tablespoons water.
49-401713v01 5/1/01 1:12 PM Page 15
About the time features.
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
16
Vegetable Amount Time Comments
Corn
(frozen kernel) 10-oz. package 5 to 7 min. In 1-qt. casserole, place
2 tablespoons water.
Corn on the cob
(fresh) 1 to 5 ears 3 to 4 min. In 2-qt. oblong glass baking
per ear dish, place corn. If corn is in
husk, use no water; if corn has
been husked, add 1/4 cup
water. Rearrange after half
of time.
(frozen) 1 ear 5 to 6 min. Place in 2-qt. oblong glass
baking dish.
2 to 6 ears 3 to 4 min. Cover with vented plastic wrap.
per ear Rearrange after half of time.
Mixed
vegetables
(frozen) 10-oz. package 5 to 7 min. In 1-qt. casserole, place
3 tablespoons water.
Peas
(fresh, shelled) 2 lbs. unshelled
9 to 12 min.
In 1-qt. casserole, place
1/4 cup water.
(frozen) 10-oz. package 5 to 7 min. In 1-qt. casserole, place
2 tablespoons water.
Potatoes
(fresh, cubed, 4 potatoes
9 to 12 min.
Peel and cut into 1 inch cubes.
white) (6 to 8 oz. each) Place in 2-qt. casserole with
1/2 cup water. Stir after half
of time.
(fresh, whole, 1 (6 to 8 oz.) 3 to 4 min. Pierce with cooking fork.
sweet or white) Place in center of the oven.
Let stand 5 minutes.
Spinach
(fresh) 10 to 16 oz. 5 to 7 min. In 2-qt. casserole, place washed
spinach.
(frozen, 10-oz. package 5 to 7 min. In 1-qt. casserole, place
chopped 3 tablespoons water.
and leaf)
Squash
(fresh, summer 1 lb. sliced 5 to 7 min. In 11⁄2-qt. casserole, place
and yellow) 1/4 cup water.
(winter, acorn 1 to 2 squash 8 to 11 min. Cut in half and remove fibrous
butternut)
(about 1 lb. each)
membranes. In 2-qt. oblong
glass baking dish, place squash
cut-side-down. Turn cut-side-up
after 4 minutes.
49-401713v01 5/1/01 1:12 PM Page 16
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
17
www.GEAppliances.com
Time Defrost
Allows you to defrost for the length of time you
select. See the Defrosting Guide for suggested times.
Power level 3 is automatically set, but you may
change this for more flexibility. You may defrost
small items more quickly by raising the power level
after entering the time. However, they will need
more frequent attention than usual.
Power level 7 cuts the total defrosting time in
about half; power level 10 cuts the total time to
approximately 1/3. Rotate or stir food frequently.
A dull thumping noise may be heard during
defrosting. This sound is normal when the oven
is not operating at High power.
Defrosting Tips
■Foods frozen in paper or plastic can be defrosted
in the package. Tightly closed packages should
be slit, pierced or vented AFTER food has
partially defrosted. Plastic storage containers
should be at least partially uncovered.
■Family-size, prepackaged frozen dinners can be
defrosted and microwaved. If the food is in a foil
container, transfer it to a microwave-safe dish.
■Foods that spoil easily, such as milk, eggs, fish,
stuffings, poultry and pork, should not be
allowed to sit out for more than one hour after
defrosting. Room temperature promotes the
growth of harmful bacteria.
■For more even defrosting of larger foods, such as
beef, lamb and veal roasts, use
Auto Defrost
.
■Be sure large meats are completely defrosted
before cooking.
■When defrosted, food should be cool but
softened in all areas. If still slightly icy, return
to the microwave very briefly, or let it stand a
few minutes.
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
2
EXPRESS COOK
5
EXPRESS COOK
789
0
START
PAUSE
TIME
DEFROST
Press
TIME DEFROST
.
Enter defrosting
time.
Press
START.
3
2
1
49-401713v01 5/1/01 1:12 PM Page 17
Defrosting Guide
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
About the time features.
18
Food Time Comments
Breads, Cakes
Bread, buns or rolls
(1 piece) 1 min.
Sweet rolls
(approx. 12 oz.) 3 to 5 min.
Fish and Seafood
Fillets, frozen
(1 lb.) 6 to 8 min.
Shellfish, small pieces
(1 lb.) 5 to 7 min. Place block in casserole. Turn over
and break up after half the time.
Fruit
Plastic pouch—1 to 2
3 to 6 min.
(10-oz. package)
Meat
Bacon
(1 lb.) 2 to 5 min. Place unopened package in oven.
Let stand 5 minutes after defrosting.
Franks
(1 lb.) 2 to 5 min. Place unopened package in oven.
Microwave just until franks can be
separated. Let stand 5 minutes, if
necessary, to complete defrosting.
Ground meat
(1 lb.) 5 to 7 min. Turn meat over after half the time.
Roast: beef, lamb, veal, pork
12 to 16 min. Use power level 1.
per lb.
Steaks, chops and cutlets
5 to 7 min. Place unwrapped meat in cooking
per lb. dish. Turn over after half the time
and shield warm areas with foil.
When finished, separate pieces and
let stand to complete defrosting.
Poultry
Chicken, broiler-fryer
15 to 19 min. Place wrapped chicken in dish.
cut up
(21⁄2to 3 lbs.) Unwrap and turn over after half
the time. When finished, separate
pieces and microwave 2 to 4
minutes more, if necessary.
Let stand to finish defrosting.
Chicken, whole
17 to 21 min. Place wrapped chicken in dish.
(21⁄2to 3 lbs.) After half the time, unwrap and
turn chicken over. Shield warm
areas with foil. Finish defrosting.
If necessary, run cold water in the
cavity until giblets can be removed.
Cornish hen
7 to 13 min. Place unwrapped hen in the oven
per lb. breast-side-up. Turn over after half
the time. Run cool water in the
cavity until giblets can be removed.
Turkey breast
(4 to 6 lbs.) 5 to 9 min. Place unwrapped breast in dish
per lb. breast-side-down. After half the
time, turn over and shield warm
areas with foil. Finish defrosting.
Let stand 1 to 2 hours in refrigerator
to complete defrosting.
49-401713v01 5/1/01 1:12 PM Page 18
www.GEAppliances.com
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
19
Express Cook
This is a quick way to set cooking time for 1–6 minutes.
Press one of the
Express Cook
pads (from 1 to 6)
for 1 to 6 minutes of cooking at
power level 10.
For example, press the
2
pad for 2 minutes of
cooking time.
The power level can be changed as time is counting
down. Press
POWER LEVEL
and enter 1–10.
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
2
EXPRESS COOK
5
EXPRESS COOK
Add 30 Seconds
You can use this feature two ways:
■It will add 30 seconds to the time counting down
each time the pad is pressed.
■It can be used as a quick way to set 30 seconds of
cooking time.
ADD
30 SEC.
49-401713v01 5/1/01 1:12 PM Page 19
About the auto feature.
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
20
Auto/Quick Defrost
The
Auto/Quick Defrost
feature gives you two ways to
defrost frozen foods. Press
AUTO/QUICK DEFROST
once for
Auto Defrost
or twice for
Quick Defrost
.
Auto Defrost
automatically sets the defrosting times
and power levels to give even defrosting results for
meats, poultry and fish weighing up to six pounds.
Quick Defrost
automatically sets the defrosting times
and power levels for foods weighing up to one pound.
■Remove meat from package and place on
microwave-safe dish.
■Twice during
Auto Defrost
or once during
Quick Defrost
, the oven signals
Turn Food Over
.
At each signal, turn the food over. Remove
defrosted meat or shield warm areas with
small pieces of foil.
■After defrosting, most meats need to stand
5 minutes to complete defrosting. Large roasts
should stand for about 30 minutes.
Conversion Guide
If the weight of food is stated in pounds and
ounces, the ounces must be converted to tenths
(.1) of a pound.
Press
AUTO/QUICK
DEFROST
once for
Auto Defrost
. Press
twice for
Quick
Defrost
.
Using the
Conversion Guide
at right, enter food
weight. For example,
press pads 1 and 2
for 1.2 pounds
(1 pound, 3 ounces).
Enter weight up to
6 pounds for
Auto
Defrost
, 1 pound for
Quick Defrost
.
Press
START
.
3
2
1
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
AUTO/QUICK
DEFROST
2
EXPRESS COOK
5
EXPRESS COOK
789
0
START
PAUSE
Weight of Enter
Food in Weight
Ounces (tenths of
a pound)
1–2 .1
3.2
4–5 .3
6–7 .4
8.5
Weight of Enter
Food in Weight
Ounces (tenths of
a pound)
9–10 .6
11 .7
12–13 .8
14–15 .9
49-401713v01 5/1/01 1:12 PM Page 20
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Popcorn
How to Use the Popcorn Feature
Follow package instructions, using
Time Cook
if the package is less than 1.75 ounces or larger
than 3.5 ounces. Place the package of popcorn
in the center of the microwave.
Press
POPCORN
. The oven starts immediately.
Tap
POPCORN
to select the bag size you are
cooking.
How to Adjust the Popcorn Program to Provide a Shorter
or Longer Cook Time
If you find that the brand of popcorn you use
underpops or overcooks consistently, you can add
or subtract 20–30 seconds to the automatic
popping time.
To add time:
After pressing
POPCORN
, press
9
within the first
30 seconds after the oven starts for an extra
20 seconds.
Press 9 again to add another 10 seconds (total
30 seconds additional time).
To subtract time:
After pressing
POPCORN
, press
1
within the first
30 seconds
after the oven starts for 20 seconds
less cooking time.
Press
1
again to reduce cooking time another
10 seconds (total 30 seconds less time).
2
1
1
EXPRESS COOK
POPCORN
9
21
Use only with prepackaged
microwave popcorn weighing
1.75 to 3.5 ounces.
About the convenience features.
www.GEAppliances.com
NOTE: Do not use the
metal shelf when using
the Popcorn feature.
49-401713v01 5/1/01 1:12 PM Page 21
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
22
About the convenience features.
1 Bread, rolls, muffins
1 to 4
2 Sandwich
1 to 2
3 Pizza (leftover slices)
1 to 4
4 Dessert toppings
1 to 4
5 Soup
8 to 40 oz.
6 Cheese dip
4 to 16 oz.
Pad Food Type Quantity or Weight
Snacks Guide
Snacks
The
Snacks
feature automatically sets the
microwaving times and power levels to warm a
variety of snack foods.
Press
SNACKS
.
Select snack type 1–6 (see the Snacks Guide
below).
Enter the number of items or the food weight
in ounces.
Press
START
.
4
3
2
1
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
SNACKS
2
EXPRESS COOK
5
EXPRESS COOK
789
0
START
PAUSE
49-401713v01 5/1/01 1:12 PM Page 22
23
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
VEGETABLE
2
EXPRESS COOK
5
EXPRESS COOK
789
0
START
PAUSE
Fresh Vegetables
4 to 20 oz. Use microwave-safe casserole or bowl.
Add 2 tablespoons water for each
serving. Cover with lid or vented
plastic wrap.
Frozen Vegetables
4 to 20 oz. Use microwave-safe casserole or bowl.
Follow package instructions for adding
water. Cover with lid or vented
plastic wrap.
Canned Vegetables
4 to 20 oz. Use microwave-safe casserole or bowl.
Cover with lid or vented plastic wrap.
Food Type Weight Comments
Vegetable Guide
Vegetable
The
Vegetable
feature automatically sets the
cooking times and power levels for fresh, frozen
or canned vegetables.
Press
VEGETABLE
once for fresh vegetables,
twice for frozen vegetables, or three times
for canned vegetables
.
Enter weight in ounces.
Press
START.
3
2
1
www.GEAppliances.com
49-401713v01 5/1/01 1:12 PM Page 23
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
About the convenience features.
24
Reheat
The
Reheat
feature reheats 1 to 3 servings of many
previously cooked foods.
Press
REHEAT
.
Select food type 1–6 for one serving (see Reheat
Guide below). The oven starts immediately.
NOTE: The serving size may be changed within the first
30 seconds. Press 1 for one serving, 2 for two servings
or 3 for three servings. Serving size can not be
changed for the PLATE selection.
2
1
Pad Food Type Comments
Reheat Guide
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
REHEAT
2
EXPRESS COOK
5
EXPRESS COOK
START
PAUSE
1 Pasta
Cover with lid or vented plastic wrap.
2 Meats, casseroles, pizza
Cover with lid or vented plastic wrap.
3 Fruits and vegetables
Cover with lid or vented plastic wrap.
4 Beverages, 8–10 oz.
Works best with wide mouth mug—do not cover.
5 Sauces and gravies
Cover with lid or vented plastic wrap.
6 Plate of leftovers
Cover with vented plastic wrap.
(2 to 3 foods, 4 oz. each)
Beverage
The
Beverage
feature heats 4–12 ounces of any
beverage.
Press
BEVERAGE
once for 4 ounces. The oven starts
immediately.
Press
BEVERAGE
a second time for 8 ounces.
Press
BEVERAGE
a third time for 12 ounces.
Drinks heated with the Beverage feature may be very
hot. Remove the container with care.
BEVERAGE
49-401713v01 5/1/01 1:12 PM Page 24
1 Potatoes
8 to 40 oz. Pierce skin with fork. Place potatoes
on oven floor or turntable.
2 Fish
4 to 16 oz. Use oblong, square or round dish.
Cover with vented plastic wrap or
wax paper.
3 Chicken Pieces
4 to 40 oz. Use oblong, square or round dish.
Cover with vented plastic wrap.
4 Ground Meat
8 to 48 oz. Use round casserole dish. Crumble
(beef, pork, turkey)
meat into dish. Cover with lid or
vented plastic wrap. Drain and stir
at signal.
5 Bacon
2 to 10 oz. Layer strips on a plate, 4 to a layer.
Cover each layer with a paper towel.
6 Pizza (frozen,
4 to 16 oz. Follow package instructions to
microwaveable)
prepare pizza for microwaving.
www.GEAppliances.com
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Cook
The
Cook
feature automatically sets the cooking
times and power levels for a variety of foods.
Press
COOK
.
Select food type 1–6 (see the Cook Guide
below).
Enter weight in ounces.
Press
START
.
4
3
2
1
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
COOK
2
EXPRESS COOK
5
EXPRESS COOK
789
0
START
PAUSE
Pad Food Type Weight Comments
Cook Guide
25
49-401713v01 5/1/01 1:12 PM Page 25
Other features your model may have.
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
26
Clock
Press to enter the time of day or to check the time
of day while microwaving.
Press
CLOCK
.
Enter time of day.
Select AM or PM.
Press
START
.
4
3
2
1
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
2
EXPRESS COOK
5
EXPRESS COOK
789
0
START
PAUSE
CLOCK
AM / PM
Timer
Timer
operates as a minute timer and can be used
at any time, even when the oven is operating.
Press
TIMER
.
Enter time you want to count down.
Press
TIMER
to start.
To pause the countdown, press
TIMER
.
When time is up, the oven will signal. To turn off
the timer signal, press
TIMER
.
NOTE:
The timer indicator will be lit while the timer
is operating.
To cancel the timer, press and hold the
TIMER
pad
for 2 seconds.
3
2
1
TIMER
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
2
EXPRESS COOK
5
EXPRESS COOK
789
0
Help
The
HELP
pad displays feature information and
helpful hints. Press
HELP
, then select a feature pad.
HELP
49-401713v01 5/1/01 1:12 PM Page 26
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
27
Reminder
The
Reminder
feature can be used like an alarm
clock, and can be used at any time, even when the
oven is operating. The
Reminder
time can be set up
to 24 hours later.
Press
REMINDER.
Enter the time you want the oven to remind
you. (Be sure the microwave clock shows the
correct time of day.)
Select AM or PM.
Press
REMINDER.
When
Reminder
signal occurs,
press
REMINDER
to turn it off. The
Reminder
time may be displayed by pressing
REMINDER.
NOTE: The REM indicator will remain lit to show that the
Reminder is set. To clear the Reminder before it occurs,
press and hold the REMINDER pad for 2 seconds.
4
3
2
1
REMINDER
CLOCK
AM / PM
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
2
EXPRESS COOK
5
EXPRESS COOK
789
0
www.GEAppliances.com
Cooking Complete Reminder
To remind you that you have food in the oven, the
oven will display
FOOD IS READY
and beep once a
minute until you either open the oven door or
press
CLEAR/OFF.
Start/Pause
In addition to starting many functions,
START/PAUSE
allows you to stop cooking without
opening the door or clearing the display.
START
PAUSE
Child Lock-out
You may lock the control panel to prevent the
microwave from being accidentally started or
used by children.
To lock or unlock the controls, press and hold
CLEAR/OFF
for about three seconds. When the
control panel is locked,
LOCKED
will be displayed.
CLEAR
OFF
49-401713v01 5/1/01 1:13 PM Page 27
Delay Start
Delay Start
allows you to set the microwave to delay
cooking up to 24 hours.
Press
DELAY START.
Select the cooking or defrosting feature you
wish to delay, then enter the cooking or
defrosting time.
Press
START
.
Enter the time you want the oven to start.
(Be sure the microwave clock shows the
correct time of day.)
Select AM or PM.
Press
START.
The start time will be displayed and will remain until
the oven automatically starts at the delayed time.
The time of day may be displayed by pressing
CLOCK.
6
5
4
3
2
1
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
28
Turntable
For best cooking results, leave the turntable on. It
can be turned off for large dishes. Press
TURNTABLE
to turn the turntable on or off.
Sometimes the turntable can become too hot to touch.
Be careful touching the turntable during and after
cooking.
TURNTABLE
Automatic Fan
An automatic fan feature protects the microwave
from too much heat rising from the cooktop below it.
It automatically turns on if it senses too much heat.
If you have turned the fan on you may find that you
cannot turn it off. The fan will automatically turn
off when the internal parts are cool. It may stay on
for 30 minutes or more after the cooktop and
microwave controls are turned off.
Other features your model may have.
49-401713v01 5/1/01 1:13 PM Page 28
www.GEAppliances.com
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
29
Surface Light
Press
SURFACE LIGHT
once for bright light, twice for
the night light or three times to turn the light off.
SURFACE
LIGHT
Vent Fan
The vent fan removes steam and other vapors from
surface cooking.
Press
VENT FAN
once for high fan speed, twice for
medium fan speed, a third time for low fan speed,
or a fourth time to turn the fan off.
Press the
VENT FAN BOOST
pad for extra fan speed.
VENT FAN
VENT FAN
BOOST
Custom
The
CUSTOM
pad allows you to save your most
frequently used settings. (Sensor cooking settings
cannot be saved).
To set and save a setting:
Press the
CUSTOM
pad.
Set the amount of cooking time.
Set the power level, if desired. (Full power will
automatically be set if you do not change it).
Press the
CUSTOM
pad.
Your custom setting will be remembered for future
one touch use.
To clear the custom setting, press and hold the
CUSTOM
pad for 2 seconds.
4
3
2
1
CUSTOM
1
EXPRESS COOK
2
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
5
EXPRESS COOK
6
EXPRESS COOK
7 8 9
0
49-401713v01 5/1/01 1:13 PM Page 29
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
30
OPTIONS
Options
Press the
OPTIONS
pad multiple times to cycle
through the available options.
Auto Nite Light
The
Auto Nite Light
can be set to come on and go off
at desired times.
To set the timer:
Press
1.
Enter the time of day for the light to come on.
Select AM or PM.
Press the
OPTIONS
pad.
Enter the time of day for the light to go off.
Select AM or PM.
Press the
OPTIONS
pad.
To review the nite light settings, press
2
after
selecting the
Auto Nite Light
option.
To turn the nite light off, press
0
after selecting
the
Auto Nite Light
option.
Beeper Volume
The beeper sound level can be adjusted. Choose
0–3 for mute to loud.
Charcoal Filter Reminder
The
Charcoal Filter Reminder
is a 180 day timer to
remind you when to change the charcoal filter.
Press
0
to turn the reminder off. Press
1
to set the
reminder. Press
2
to reset the reminder.
Display Language
The language for the scrolling display may be set
at either English or Spanish.
Press
1
for English or
2
for Spanish.
Display On/Off
You can choose to turn the clock display on or off.
Press
0
to turn the display off. Press
1
to turn the
display on.
Display Speed
The scroll speed of the display can be changed.
Select 1–5 for slowest to fastest scroll speed.
7
6
5
4
3
2
1
Other features your model may have.
CLOCK
AM / PM
1
EXPRESS COOK
3
EXPRESS COOK
4
EXPRESS COOK
6
EXPRESS COOK
2
EXPRESS COOK
5
EXPRESS COOK
7 8 9
0
49-401713v01 5/1/01 1:13 PM Page 30
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
31
www.GEAppliances.com
Shelf
Food microwaves best when placed on the
turntable or on the shelf in the lower position.
For best cooking results, remove the shelf unless
you are reheating on more than one level.
How to Use the Shelf
When Microwaving
■Make sure the shelf is
positioned properly
inside the microwave
to prevent damage to
the oven from arcing.
■Do not use a
microwave browning
dish on the shelf. The
shelf could overheat.
■Do not use the oven
with the shelf on the
microwave floor.
This could damage
the microwave.
■Use pot holders
when handling the
shelf—it may be hot.
■Do not use the
shelf when cooking
popcorn.
For best results
Uneven results
2-level reheating
49-401713v01 5/1/01 1:13 PM Page 31
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
32
Switch places after 1/2 time
Switch places after 1/2 time
Shelf and Reheating
■
To reheat on 2 levels
OR
■
To reheat 2 dishes on the lower level:
Multiply reheat time by 11
/2.
Switch places after 1/2 the time.
2
1
Other features your model may have.
49-401713v01 5/1/01 1:13 PM Page 32
33
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Microwave terms.
www.GEAppliances.com
Term Definition
Arcing
Arcing is the microwave term for sparks in the oven. Arcing is
caused by:
■the metal shelf not installed correctly so that it touches
the microwave wall.
■metal or foil touching the side of the oven.
■foil that is not molded to food (upturned edges act like
antennas).
■metal such as twist-ties, poultry pins, gold-rimmed dishes.
■recycled paper towels containing small metal pieces.
Covering
Covers hold in moisture, allow for more even heating and reduce
cooking time. Venting plastic wrap or covering with wax paper
allows excess steam to escape.
Shielding
In a regular oven, you shield chicken breasts or baked foods to
prevent over-browning. When microwaving, you use small strips
of foil to shield thin parts, such as the tips of wings and legs on
poultry, which would cook before larger parts.
Standing Time
When you cook with regular ovens, foods such as roasts or cakes
are allowed to stand to finish cooking or to set. Standing time is
especially important in microwave cooking. Note that a
microwaved cake is not placed on a cooling rack.
Venting
After covering a dish with plastic wrap, you vent the plastic wrap
by turning back one corner so excess steam can escape.
49-401713v01 5/1/01 1:19 PM Page 33
Helpful Hints
Open the oven door a few minutes after cooking to
air out the inside. An occasional thorough wiping
with a solution of baking soda and water keeps the
inside fresh.
NOTE: Be certain the power is off before cleaning any
part of this oven.
How to Clean the Inside
Walls, Floor, Inside Window, Metal and Plastic Parts
on the Door
Some spatters can be removed with a paper towel;
others may require a damp cloth. Remove greasy
spatters with a sudsy cloth, then rinse with a damp
cloth. Do not use abrasive cleaners or sharp utensils
on oven walls.
Never use a commercial oven cleaner on any part of
your microwave.
Removable Turntable and Turntable Support
To prevent breakage, do not place the turntable
into water just after cooking. Wash it carefully
in warm, sudsy water or in the dishwasher. The
turntable and support can be broken if dropped.
Remember, do not operate the oven without the
turntable and support in place.
Shelf
Clean with mild soap and water or in the
dishwasher.
Do not clean in a self-cleaning oven.
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
34
Care and cleaning of the microwave oven.
49-401713v01 5/1/01 1:13 PM Page 34
35
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
How to Clean the Outside
Do not use cleaners containing ammonia or alcohol on
the microwave oven. Ammonia or alcohol can damage
the appearance of the microwave.
Bottom
Clean off the grease and dust on the bottom often.
Use a solution of warm water and detergent.
Case
Clean the outside of the microwave with a sudsy
cloth. Rinse and then dry. Wipe the window clean
with a damp cloth.
Control Panel and Door
Wipe with a damp cloth. Dry thoroughly. Do not
use cleaning sprays, large amounts of soap and
water, abrasives or sharp objects on the panel—they
can damage it. Some paper towels can also scratch
the control panel.
Door Surface
It’s important to keep the area clean where the
door seals against the microwave. Use only mild,
non-abrasive detergents applied with a clean
sponge or soft cloth. Rinse well.
www.GEAppliances.com
49-401713v01 5/1/01 1:13 PM Page 35
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
36
Cooktop Light/Night Light
Replace the burned-out bulb with a 40-watt
incandescent bulb (WB36X10003), available from
your GE supplier.
To replace the bulb(s), first disconnect the
power at the main fuse or circuit breaker panel
or pull the plug.
Remove the screw at the outside edge of the
light cover and push on the inside edge of the
cover to open.
Be sure the bulb(s) to be replaced are cool
before removing. After breaking the adhesive
seal, remove the bulb by gently turning.
Replace the screw. Connect electrical power
to the oven.
4
3
2
1
Oven Light
Replace the burned-out bulb with a 40-watt
incandescent bulb (WB36X10003), available from
your GE supplier.
To replace the oven light, first disconnect the
power at the main fuse or circuit breaker panel
or pull the plug.
Remove the top grille by taking out the 2 screws
that hold it in place and sliding the grille to the
left (opening the door makes grille removal
easier).
Next, remove the screw located above the door
near the center of the oven that secures the
light housing.
Replace the grille and screws. Connect electrical
power to the oven.
4
3
2
1
Replacing the lightbulbs.
Screws
Remove
screws
49-401713v01 5/1/01 1:13 PM Page 36
37
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
About the exhaust feature.
www.GEAppliances.com
The Vent Fan
The vent fan has 2 metal reusable grease filters.
Models that recirculate air back into the room also
use a charcoal filter.
Reusable Grease Filters
The metal filters trap grease released by foods on
the cooktop. They also prevent flames from foods
on the cooktop from damaging the inside of the
microwave.
For this reason, the filters must ALWAYS be in
place when the hood is used. The grease filters
should be cleaned once a month, or as needed.
Removing and Cleaning the Filter
To remove,
slide it to the outside using the tab.
Pull it down and out.
To clean the grease filter,
soak it and then swish it
around in hot water and detergent. Don’t use
ammonia or ammonia products because they will
darken the metal. Light brushing can be used to
remove embedded dirt.
Rinse, shake and let it dry before replacing.
To replace,
slide the filter in the frame slot at the
outside of the opening. Pull up and in to lock
into place.
Charcoal Filter
(on some models)
Reusable Grease Filters
(on all models)
49-401713v01 5/1/01 1:13 PM Page 37
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
38
Charcoal Filter (on some models)
The charcoal filter cannot be cleaned. It must be
replaced. Order Part No. WB02X10733 from your
GE supplier.
If the model is not vented to the outside, the air will
be recirculated through a disposable charcoal filter
that helps remove smoke and odors.
The charcoal filter should be replaced when it is
noticeably dirty or discolored (usually after 6 to
12 months, depending on hood usage).
To Remove Charcoal Filter
To remove the charcoal filter, disconnect power
at the main fuse or circuit breaker panel or pull
the plug.
Remove the top grille by removing the 2 screws
that hold it in place and sliding the grille to the left
(opening the door makes grille removal easier).
Slide the filter towards the front of the oven and
remove it.
To Install Charcoal Filter
To install a new filter, remove plastic and other
outer wrapping from the new filter.
Insert the filter into the top opening of the oven as
shown. It will rest at an angle on 2 side support tabs
and in front of the right rear tab. Replace the grille
and 2 screws.
About the exhaust feature.
Remove 2 grille screws
to remove the grille.
Screws
49-401713v01 5/1/01 1:13 PM Page 38
39
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
Before you call for service.
www.GEAppliances.com
Troubleshooting Tips
Save time and money! Review the charts on the following pages
first and you may not need to call for service.
Things That Are Normal With Your Microwave Oven
■Steam or vapor escaping from around the door.
■Light reflection around door or outer case.
■Dimming oven light and change in the blower sound at power
levels other than high.
■Dull thumping sound while oven is operating.
■TV/radio interference might be noticed while using the
microwave. Similar to the interference caused by other small
appliances, it does not indicate a problem with the microwave.
Plug the microwave into a different electrical circuit, move the
radio or TV as far away from the microwave as possible, or check
the position and signal of the TV/radio antenna.
Problem Possible Causes What To Do
Oven will not start
A fuse in your home may •Replace fuse or reset
be blown or the circuit circuit breaker.
breaker tripped.
Power surge. •Unplug the microwave
oven, then plug it back in.
Plug not fully inserted •Make sure the 3-prong
into wall outlet. plug on the oven is fully
inserted into wall outlet.
Floor of the oven is warm,
The cooktop light is •This is normal.
even when the oven has
located below the oven
not been used
floor. When the light is
on, the heat it produces
may make the oven floor
get warm.
“LOCKED” appears on
The control has been •Press and hold
CLEAR/OFF
the display
locked. for about 3 seconds to
unlock the control.
You hear an unusual,
You have tried to start •Start over and enter a
low-tone beep
the Reminder without valid time of day.
a valid time of day.
You have tried to change •Many of the oven’s features
the power level when it is are preset and cannot be
not allowed. changed.
49-401713v01 5/1/01 1:13 PM Page 39
Notes.
Safety InformationOperating InstructionsTroubleshooting TipsConsumer Support
40
49-401713v01 5/1/01 1:13 PM Page 40
41
GE Service Protection Plus™
GE, a name recognized worldwide for quality and dependability,
offers you Service Protection Plus™—comprehensive protection on
all your appliances—No Matter What Brand!
Benefits Include:
• Backed by GE
• All brands covered
• Unlimited service calls
• All parts and labor costs included
• No out-of-pocket expenses
• No hidden deductibles
• One 800 number to call
You will be completely satisfied with our service protection or you may request your
money back on the remaining value of your contract. No questions asked. It’s that simple.
Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much
more—any brand! Plus there’s no extra charge for emergency service and low monthly
financing is available. Even icemaker coverage and food spoilage protection is offered.
You can rest easy, knowing that all your valuable household products are protected
against expensive repairs.
Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224
for more information.
*All brands covered, up to 20 years old, in the continental U.S.
We’ll Cover Any Appliance.
Anywhere. Anytime.*
General Electric Company
Warranty Registration Department
P.O. Box 32150
Louisville, KY 40232-2150
Please place in envelope and mail to:
Cut here
✂
49-401713v01 5/1/01 1:13 PM Page 41
Day Year
Street
Address
Consumer Product Ownership Registration
Dear Customer:
Thank you for purchasing our product and thank you for placing your confidence in us.
We are proud to have you as a customer!
Follow these three steps to protect your new appliance investment:
Complete and mail
your Consumer
Product Ownership
Registration today.
Have the peace of
mind of knowing we
can contact you in
the unlikely event of
a safety modification.
After mailing
the registration below,
store this document in
a safe place. It
contains information
you will need should
you require service.
Our service number is
800.GE.CARES
(800.432.2737).
Read your Owner’s
Manual carefully.
It will help you
operate your new
appliance properly.
123
Model Number Serial Number
Important: If you did not get a registration card with your product, detach and
return the form below to ensure that your product is registered, or
register online at www.GEAppliances.com.
First
Name
Apt. #
City
Last
Name
Zip
CodeState
Phone
Number
GE Appliances
General Electric Company
Louisville, Kentucky
www.GEAppliances.com
Mr. Ms. Mrs. Miss
E-mail Address*
* Please provide your e-mail address to receive, via e-mail,
discounts, special offers and other important communications
from GE Appliances (GEA).
■■Check here if you do not want to receive communications
from GEA’s carefully selected partners.
Consumer Product Ownership Registration
Model Number Serial Number
Important
Mail
Today!
Date Placed In Use
Month
Cut here
✂
42
49-401713v01 5/1/01 1:13 PM Page 42
GE Microwave Oven Warranty.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Information
This warranty is extended to the original purchaser and any succeeding owner for products purchased
for ordinary home use within the USA. In Alaska, the warranty excludes the cost of shipping or service
calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages so the
above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and
you may also have other rights which vary from state to state. To know what your legal rights are,
consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
For The Period Of: GE Will Replace:
One Year Any part
of the microwave oven which fails due to a
From the date of the
defect in materials or workmanship. During this
full
original purchase one-year warranty,
GE will also provide,
free of charge,
all parts and service labor to repair or replace the
defective part.
Ten Years The magnetron tube,
if the magnetron tube fails due to
For the second through
a defect in materials or workmanship. During this
the tenth year from the additional nine-year limited warranty,
you will be
date of original purchase
responsible for any labor or in-home service costs.
■Service trips to your home to teach you
how to use the product.
■Improper installation.
■Failure of the product if it is
abused, misused, or used for other
than the intended purpose or used
commercially.
■Replacement of house fuses or
resetting of circuit breakers.
■Damage to the product caused by
accident, fire, floods or acts of God.
■Incidental or consequential damage
caused by possible defects with this
appliance.
What GE Will Not Cover:
43
All warranty service provided by our
Factory Service Centers, or an authorized
Customer Care
®
technician. To schedule
service, on-line, 24 hours a day, visit
us at www.GEAppliances.com, or call
800.GE.CARES (800.432.2737).
Staple your receipt here.
Proof of the original
purchase date is needed
to obtain service under
the warranty.
49-401713v01 5/1/01 1:13 PM Page 43
Printed in Korea
Consumer Support.
GE Appliances Website
www.GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website
24 hours a day, any day of the year! For greater convenience and faster service, you can
now download Owner’s Manuals, order parts, catalogs, or even schedule service on-
line. You can also “Ask Our Team of Experts™” your questions, and so much more...
Schedule Service
www.GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule
your service at your convenience 24 hours any day of the year! Or call 800.GE.CARES
(800.432.2737) during normal business hours.
Real Life Design Studio
www.GEAppliances.com
GE supports the Universal Design concept—products, services and environments that
can be used by people of all ages, sizes and capabilities. We recognize the need to design
for a wide range of physical and mental abilities and impairments. For details of GE’s
Universal Design applications, including kitchen design ideas for people with
disabilities, check out our Website today. For the hearing impaired, please call
800.TDD.GEAC (800.833.4322).
Extended Warranties
www.GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available
while your warranty is still in effect. You can purchase it on-line anytime, or call
800.626.2224 during normal business hours. GE Consumer Home Services will
still be there after your warranty expires.
Parts and Accessories
www.GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories
sent directly to their homes (VISA, MasterCard and Discover cards are accepted).
Order on-line today, 24 hours every day or by phone at 800.626.2002 during normal
business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other
servicing generally should be referred to qualified service personnel. Caution must be
exercised, since improper servicing may cause unsafe operation.
Contact Us
www.GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website
with all the details including your phone number, or write to:
General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance
www.GEAppliances.com
Register your new appliance on-line—at your convenience! Timely product registration
will allow for enhanced communication and prompt service under the terms of your
warranty, should the need arise. You may also mail in the pre-printed registration card
included in the packing material, or detach and use the form in this Owner’s Manual.
49-401713v01 5/1/01 1:13 PM Page 44
