Users Manual 2
74
CCaallll HHiissttoorryy
75
Call Duration Menu 3-5
Your phone records the amount of air time, or talk
time, used. Using this option, you can view the number
of the calls to or from your phone, and the air time for
all of the calls. You can easily erase the call time
record at any time. This option is convenient for
estimating your usage.
Note: This feature is not intended to be used for billing
purposes.
The following options are available:
Last Call: shows the time of the last call.
Total Dialled Call: shows the number of all calls you
made and the total duration of the calls since the time
counter was last set to zero by using the Reset All
option.
Total Received Call: shows the number of all calls
you received and the total duration of the calls since
the time counter was last set to zero by using the
Reset All option.
Reset All: erases all of the time measurements and
resets all of the air time counters.
Life Time: shows the number and total duration of all
calls made to or from your phone since the phone was
shipped from the factory.
Sounds
You can use the Sounds menu to customize various
sound settings, such as the:
•ringer volume, type, and tone.
•alert sounds and key tone.
•sound which plays when the phone is switched on
or off.
Ring Tones Menu 4-1
This option allows you to set the unique ringer
melodies for the following items:
Calls: allows you to set a unique ringer for incoming
voice calls.
Messages: allows you to have a distinctive ringer for
incoming text messages and voicemail messages
independently.
Schedules: allows you to have a distinctive ringer for
schedule alarm settings.
Select a unique ringer melody using the Navigation
keys. After you change it, it plays for a few seconds.
77
SSoouunnddss
76
SSoouunnddss
Alerts Menu 4-3
Your phone gives audible alerts (beeps) at a specified
time to inform you that certain things have happened.
The alerts only occur in your earpiece so that the other
person does not hear them.
The available alerts are:
Service : when this option is set to On, the phone
sounds an alert when you exit or return to a service
area.
Call Connect: when this option is set to On, the
phone sounds the connect tone when your call is
connected to the system.
Call Disconnect: when this option is set to On, the
phone sounds the disconnect tone when a call is
disconnected.
Folder Open/Closed: when this option is set to On,
the phone sounds an alert when you open or close the
folder.
Ringer Volume Menu 4-2
This menu allows you to adjust the ringer volume.
Calls: allows you to adjust the ringer volume for
incoming voice calls.
Messages: allows you to adjust the ringer volume for
incoming messages.
Alarms/Schedules: allows you to adjust the ringer
volume for alarm settings or scheduled events.
Press the Navigation keys to adjust the volume level or
select a ringer type. The following options are
available:
- Silent: the phone does not sound a ring.
- Vibrate: the phone switches to the vibration mode.
An incoming call vibrates the phone.
- 1-Beep: the phone sounds a beep.
- Level 1 ~ 8: adjust the volume level. The more bars,
the louder.
- High+Vib: the phone rings in the highest volume level
and then vibrates.
Notes:
• The options available may be different depending on
the selected ringer item.
• When “Emergency call only” appears after you end
an emergency call, the ringer volume for calls and
messages is automatically set to Level 4.
78
SSoouunnddss
79
Key Tone Menu 4-4
In this menu, you can set up the sound your phone
generates when you press a key.
The following options are available:
Volume: adjusts the volume using the Navigation keys
or the volume keys on the left side of the phone.
Note: When “Emergency call only” appears after
ending an emergency call, the key tone is
automatically set to Level 4.
Type: allows you to select the type of the key tone.
Choose one of Beep, Drum, Piano, and Lady’s
Voice.
Length: enables you to select Short or Long DTMF
(dual-tone multi-frequency) tones. DTMF tones are
sent by your phone to access teleservices, such as a
bank account. The system used by the bank or other
service determines if you need short or long DTMF
tones. If the service is digital, as most are, short DTMF
tones will almost always work.
Power On/Off Melody Menu 4-5
You can turn on or off the melody that the phone plays
when it is switched on or off.
Choose On to use the power on/off sound or Off not to
use it.
Display
The Display feature enables you to customize various
settings for the display and the light.
Language Menu 5-1
This menu allows you to change the language of voice
prompts, menus and key input.
You can choose a language, either English, Hindi,
Marathi or Gujarathi.
Service Area Menu 5-2
This menu displays the service area where you
currently are. The service area is also displayed for
about 5 seconds when your phone is registered onto a
network or when you make or receive a call.
Menu Theme Menu 5-3
This menu allows you to select the menu display style.
You can choose a style, either Nature or Camera.
80
DDiissppllaayy
81
DDiissppllaayy
Banner Menu 5-5
This option allows you to set a banner message to be
displayed at the bottom of the display in Standby
Mode.
1. If necessary, press the CLR key to delete each letter
of the old greeting. Press are hold the CLR key to
clear the display.
2. Enter your banner message.
For further information about how to enter
characters, see page xx.
3. When you finish entering the message, press the
Next soft key.
The screen allowing you to change the banner
colour appears.
4. Press the Left or Right key to change the colour for
the text font and press the Down key.
5. Press the Left or Right key to change the colour for
the text shadow and press the Save soft key.
Wallpaper Menu 5-4
You can change the background image (wall paper) to
be displayed in Standby Mode.
On the Image Wallpaper list, you can select one from
the default animation images and downloaded images.
In addition, you can choose Digital Clock, Analog
Clock or Dual Clock.
When you select Dual Clock, the phone displays the
analogue clocks for the two time zones selected in the
Set Dual Clock menu (Menu 5-7). See page xx
On the Photo Wallpaper list, you can choose from the
photos you took using the camera on your phone.
Note: To view your photos on this list, you need to set
them as a wallpaper in the Photo Wallet menu
(Menu 0-4). See page xx.
82
DDiissppllaayy
83
DDiissppllaayy
Backlight Menu 5-6
You have several options for setting how the LCD
backlight operates. Remember that backlight use
drains your battery faster.
The following options are available:
Folder open: the backlight remains on when the
folder is open.
30 seconds: the backlight switches on when you
press a key or open the folder and switches off 30
seconds after that.
8 seconds: the backlight switches on when you press
a key or open the folder and switches off 30 seconds
after that.
Dimming: the backlight is not used.
Set Dual Clock Menu 5-7
You can choose two time zones to be displayed when
you select Dual Clock for the wallpaper image; for
details, see page xx.
To select time zones for the dual clock:
1. When Location is highlighted, press the Down key.
2. Select the time zone for the first clock by pressing
the Left or Right key and press the Down key.
3. Select the time zone for the second clock by
pressing the Left or Right key.
4. Press the Save soft key to confirm the selection.
To apply the daylight saving time:
1. When Location is highlighted, press the Left or
Right to display DST. Press the Down key.
2. Select Yes to use the daylight saving time for the
first clock. Otherwise, select No.
3. Press the Down key and repeat step 2 for the
second clock.
4. Press the Save soft key to confirm the selection.
Service LED Menu 5-8
This option allows you to select whether or not the
service light on the folder is used.
85
VVooiiccee TToooollss
84
Voice Tools
In this menu, you can use the phone’s voice features,
allowing you to:
• dial a number by saying an associated name.
• record a voice memo.
• set the phone to answer a call and record the
caller’s message.
Voice Dial Menu 6-1
When your phone is in the digital mode, you can call
up to 20 stored entries by speaking the name into the
microphone. Using the voice dialling option requires
that you first program the phone to recognise the
name of the person you are calling.
Record (Menu 6-1-1)
This option allows you to record names and register
numbers for subsequent voice dialling. The phone
provides voice prompts and screen displays to guide
you through the recording process.
1. Say the name you want to program at the prompt.
The phone stores the name as a first sample.
2. Respond to the prompt by repeating the name after
the beep. The phone stores the name as a second
sample, and then prompts you to enter the phone
number.
3. Enter the phone number by pressing the number
keys and press the OK soft key.
Tips for Recording a Name
• Avoid recording similar names phonetically. If you
record a similar name to one already in the memory,
the phone requests another name.
• Speak clearly and naturally.
• The person who will use the phone should record
the name. The phone does not recognize the name if
the voice is different.
• Avoid too long or too short a name. Names with two
to five syllables are recommended.
•If this feature does not work properly, erase the
name and try again with another name.
•Practice several times to obtain the best result.
•You can record up to 20 names. If you try to record
more than that, the phone announces “Out of space
to store voice dial.”
Review (Menu 6-1-2)
When a list of your stored voice dial numbers displays,
scroll to the entry you want to review and press the
Play soft key. The recorded name plays audibly.
You can erase the selected number by pressing the
Erase soft key.
86
VVooiiccee TToooollss
87
VVooiiccee TToooollss
Erase All (Menu 6-1-3)
This option erases all of the entries on the Voice Dial
list.
When a confirming message displays, select Yes and
press the OK soft key.
Activate By (Menu 6-1-4)
Voice Dialling is always active once you have
programmed the phone to accept voice dialling entries
and the associated phone numbers.
To place a call using voice dialling, simply press and
hold the key in Standby Mode and then say the
name into the phone after you hear a prompt.
Using the Activate By menu, you can set how to
initiate a voice dialling call. The following options are
available:
[] Only: enables voice dialling only by pressing and
holding the key.
[]/ Folder: enables voice dialling by pressing and
holding the key or by opening the folder.
[] /Headset: enables voice dialling by pressing and
holding the key or he button on your ear-
microphone.
Voice Memo Menu 6-2
Note: You can quickly enter this menu by pressing the
Down key in Standby Mode.
Record (Menu 6-2-1)
You can record up to voice memos of 4 minutes total.
This feature shares the memory with the Voice Answer
feature and the amount of time for memos are
dependent on the available memory less any callers'
messages; for example, if your phone has the callers'
messages of 4 minutes total, you cannot record any
voice memo.
1. Record a memo by speaking to the microphone.
While you are recording, a timer displays to show
you the elapsed time.
You can pause recording by pressing the Left key
and then resume by pressing the Right key.
2. Press the Stop soft key to end recording. The screen
provides you with the following choices. Scroll to an
option and press the Select soft key.
• Review: allows you to review the voice memo.
The screen displays the length of the memo along
with the date and time.
• Rerecord: allows you to discard the current
memo and record another one.
• Save: allows you to save the voice memo.
89
VVooiiccee TToooollss
88
VVooiiccee TToooollss
3. When you are satisfied, select the Save option and
press the Select soft key.
4. Enter a title for the memo and press the Next soft
key.
Review (Menu 6-2-2)
When a list of your voice memos displays, scroll to the
memo you want to review and press the Play soft key.
The phone plays back the memo.
You can pause the playback by pressing the Left key
and then resume by pressing the Right key.
On the memo list, press the Options soft key to use
the following options:
Erase: erases the selected memo.
Info: shows detailed information about the memo,
such as title, length, memory size and date and time
when the memo was recorded.
Erase All (Menu 6-2-3)
This menu allows you to erase all of the voice memos.
When a confirming message displays, select Yes and
press the OK soft key.
Answer Machine Menu 6-3
If you are not able to answer an incoming call, you can
set your phone to answer a call with the default
greeting message and record the caller’s message. As
this feature shares the memory with voice memos, the
total length of messages is dependent on the available
memory less any voice memos.
Note: The voice answer feature does not work when
your phone is in the analogue mode.
On/Off (Menu 6-3-1)
This option allows you to enable or disable the voice
answer mode.
Voice Message (Menu 6-3-2)
You can listen to the callers’ messages recorded in
your phone. When you access this option, a list of the
recorded messages appears.
Note: If the phone has the callers’ messages waiting
to be checked, it displays the total number of
the messages and the date and time when the
last message was recorded. Pressing the
Play(??) soft key takes you to the Inbox.
Press the Up or Down key to scroll to a message and
press the Play soft key to play it back.
You can pause the playback by pressing the Left key
and then resume by pressing the Right key.
Cannot be checked with the
current phone.
90
VVooiiccee TToooollss
91
VVooiiccee TToooollss
On the message list, press the Options soft key to the
following options:
Erase: erases the selected message.
Info: shows detailed information about the message,
such as caller’s number if identified, elapsed time,
length, memory size and date and time when the
message was recorded.
Talk: places a call to the caller’s number, if identified.
Settings (Menu 6-3-3)
You can change the settings for the voice answer
mode. The following options are available:
Greeting: Your phone provides you with the two
default greeting messages to be played when a call
comes in. You can also record up to two own greeting
messages.
To record a greeting message:
1. Select Record and press the Select soft key.
2. Select the entry either My Message 1 or My
Message 2 by pressing the OK soft key.
3. Wait until a beeping prompt sounds and record a
greeting message by speaking into the microphone.
You can pause recording by pressing the Left key
and then resume by pressing the Right key.
4. When recording is complete, press the Save soft
key. The phone automatically saves and activates
the message.
VVooiiccee TToooollss
To play back the currently selected message, highlight
Play and press the Select soft key.
To select a greeting message:
1. Highlight Select and press the Select soft key.
2. Select My Message 1/2to use one of your
messages or Default 1/2to use one of the default
messages.
3. Press the OK soft key to save your selection.
Screening: allows you to enable or disable the
screening speaker which allows you to listen to the
caller’s message while the caller is leaving it.
Wait Time: allows you to set how long the phone
waits before answering a call with the greeting
message. Selecting Off means that the phone plays
back the message as soon as a call comes in.
92 93
OOrrggaanniisseerr
Organiser
The Organiser feature enables you to:
• keep track of important dates and events.
• create a list of things to do and memos of things you
need to remember.
• set an alarm to ring at a specific time.
• use the phone as a calculator.
• check the time in another part of the world.
Scheduler Menu 7-1
In this menu, you can keep track of your daily or monthly
schedule.
Today (Menu 7-1-1)
You can schedule up to 9 events for the current day,
indicating each event’s start and end time. You can even
have your phone's calendar alert you before an event
commences. Events scheduled for future dates
automatically appear on your Today schedule on that
day.
Scheduling a New Event
1. Enter your event contents and press the Next soft
key.
For further details about how to enter characters, see
page xx.
2. Enter the start time and date using the numeric keys.
Note: You can move through the input fields using the
Navigation keys.
3. Enter the end time and date using the number keys.
4. Select when an alarm will inform you of the event,
by pressing the Left or Right key. Selecting No
Alarm means that the phone does not ring the
alarm.
5. Press the Save soft key to store your event.
Viewing Your Today’s Schedule
The list of the events stored on the current day
displays when you select the Today menu (Menu 7-1-
1).
While viewing the schedule list, press the Up or Down
key to scroll to an event and:
• To view details, press the View soft key. To view
the Start and End time settings, use the Left or Right
keys. You can move to the previous or next event by
pressing the Left or Right key.
While viewing the event, press the Edit soft key to
change the event, or press the Erase soft key to
erase the event.
• Press the Options soft key to use the following
options:
Add New: allows you to add a new event.
Erase : allows you to erase the event.
Erase All: allows you to erase all of the events.
94
OOrrggaanniisseerr
95
OOrrggaanniisseerr
All (Menu 7-1-2)
This option allows you to view the current month, as
well as past or future months, in calendar format. On
the calendar, the current day is boldfaced and days
with scheduled events are indicated by a box inside
the calendar day.
Note: You can quickly access this menu by pressing
the Left key in Standby Mode.
Scrolling Through the Calendar
• You can move up or down by one day by pressing
the Left or Right key.
• You can move right or left by one week by pressing
the Up or Down key.
• To display the next or previous month, press the
or key.
Creating a New Schedule
You can store up to 70 events total in the scheduler,
with up to 9 events for one day.
1. Select a day on the calendar, referring to “Scrolling
Through the Calendar” on page xx and press the
Add soft key.
2. Follow the procedure in “Scheduling an Event” on
page xx.
Viewing Your Schedule
Select a day with scheduled events on the calendar,
referring to “Scrolling Through the Calendar” on page
xx and press the View soft key. The first event stored
on the selected day displays.
To view the Start and End time settings, use the Up
and Down key. You can move to the previous or next
event by pressing the Left or Right key.
While viewing the event, press the Edit soft key to
change the event, or press the Erase soft key to erase
the event.
Task List Menu 7-2
This feature allows you to enter up a list of tasks to be
done and assign both a priority and a deadline to each
task.
Creating a New Task
1. Enter the first task and press the Next soft key to
confirm.
For further details about how to enter characters,
see page xx.
2. Enter the time and date by which the task needs to
be done, by using the numeric keys.
Note: You can move through the input fields using
the Navigation keys.
96
OOrrggaanniisseerr
97
OOrrggaanniisseerr
3. Select High or Low priority using the Left or Right
key.
4. Press the Save soft key to store the task.
Viewing a Task
The list of the tasks displays when you access the
Task List menu (Menu 7-2).
While viewing the task list, press the Up or Down key
to scroll to a task and:
• To view details, press the View soft key. You can
move to the previous or next task by pressing the
Navigation keys.
While viewing the task, press the Edit soft key to
change the task, or press the Erase soft key to
erase the task.
• Press the Options soft key to use the following
options:
Add New: allows you to add a new task.
Erase : allows you to erase the selected task.
Erase All: allows you to erase all of the tasks.
Memo Pad Menu 7-3
This feature allows you to write down memos about
anything you need to remember.
Writing a New Memo
1. Enter the memo contents.
For further details about how to enter characters,
see page xx.
2. Press the Save soft key to save the memo.
Viewing a Memo
The list of your memos displays when you access the
Memo Pad menu (Menu 7-3).
While viewing the memo list, press the Up or
Down key to scroll to a memo and:
• To view details, press the View soft key. You can
move to the previous or next memo by pressing the
Navigation keys.
While viewing the memo, press the Edit soft key to
change the memo, or press the Erase soft key to
erase the memo.
• Press the Options soft key to use the following
options:
Add New: allows you to add a new memo.
Erase : allows you to erase the selected memo.
Erase All: allows you to erase all of the memos.
99
OOrrggaanniisseerr
98
OOrrggaanniisseerr
Alarm Menu 7-4
This option allows you to set up to three alarms to ring
at a specific time.
To set an alarm:
1. Select an alarm type, Daily Alarm or Weekly
Alarm, and press the Set soft key.
2. Select On by pressing the Left or Right key.
3. Press the Down key and enter the time and date for
the alarm to ring.
4. Press the Down key and select an alarm melody by
pressing the Left or Right key.
5. Press the Down key and select a repeat option by
pressing the Left or Right key.
You can choose either Daily or Once for the daily
alarm, or select a day of the week for the daily
alarm.
6. Press the Save soft key to save the alarm setting.
To stop the alarm when it rings, press the Stop soft
key. If you stop the alarm using other keys, the Snooze
function is activated and the phone rings the alarm
after 5 minutes. (Pls confirm this feature???)
To deactivate an alarm setting, access it from the
alarm list and select Off.
Calculator Menu 7-5
Using this feature, you can use the phone as a
calculator. The calculator provides you with the basic
arithmetic functions; addition, subtraction,
multiplication and division.
1. Enter the first number on the first line using the
numeric keys.
Notes:
• To erase any mistakes or clear the display, press
the CLR key.
• Use the key to enter a decimal point and the
key to change the sign of a number to a
negative (-).
2. Enter the operation for your calculation on the
second line by pressing the Navigation keys,
according to the graphic on the display.
3. Enter the second number.
4. Repeat step 2 and 3 as many times as required.
5. To view the result, press the = soft key.
6. To perform another calculation, press the CLR key to
reset the calculator and repeat from step 1.
101
OOrrggaanniisseerr
100
OOrrggaanniisseerr
World Time Menu 7-6
This menu allows you to check the current time for 24
major cities around the world.
Select the city corresponding to your time zone by
pressing the Navigation keys one or more times. The
local date and time display.
To turn the DST (Daylight Saving Time) setting on:
1. After selecting the time zone, you want to apply the
DST, press the DST soft key.
2. Select On and press the OK key.
The DST icon appears on the left of the time.
To cancel the setting, select Off.
Count Down Menu 7-7
This menu helps you know how much time it takes for
you to do something, or how many months, days, hours
and minutes until a specific day arrives. You can create
up to 9 counters using this menu.
Creating a New Counter
1. Enter the contents for your counter and press the
Next soft key.
For further details about entering characters, see
page xx.
2. Enter the time and date you want to count down
from.
Note:You can enter a year between 1980 and 2099.
3. Press the Save soft key to store the counter.
Viewing a Counter
The list of the counters displays when you access the
Count Down menu (Menu 7-7).
While viewing the counter list, press the Up or Down
key to scroll to a counter and:
• To view details, press the View soft key. You can
move to the previous or next counter by pressing the
Navigation keys.
While viewing a counter, press the Edit soft key to
edit the counter, or press the Erase soft key to
erase the counter.
• Press the Options soft key to use the following
options:
Add New: allows you to add a new counter.
Erase : allows you to erase the selected counter.
Erase All: allows you to erase all of the counters.
103
SSeettttiinnggss
102
Settings
Many different features of your phone can be
customised to suit your preferences.
Call Menu 8-1
This menu contains the suboptions for answering or
redialling a call.
Auto Redial (Menu 8-1-1)
When this menu is activated, your phone automatically
redials the call up to 10 times when a connection fails.
To activate this feature, select how often the phone
will automatically retry the call; 60 Seconds, 30
Seconds and 10 Seconds are available.
Select Off to deactivate the Auto Redial feature.
Answer Mode (Menu 8-1-2)
This menu allows you to select how to answer an
incoming call.
The following options are available:
Any Key: the phone answers when you press any key
except for the key.
Folder Open: the phone answers when you open the
folder. When the folder is already open, you can press
the key
SEND Key: the phone answers only when you press
the key.
Call Forward (Menu 8-1-3)
This menu allows you to forward your incoming calls
to another number. When the call forwarding option is
enabled, the phone does not ring or accept incoming
calls. You can still make outgoing calls without any
problems.
Note: This feature is only available when your network
operator supports it. Contact Reliance to check
its availability.
The following options are available:
Unconditional:calls are always forwarded.
When Busy:calls are forwarded when you are
already on the phone.
No Reply/Not Reachable:calls are forwarded when
you do not answer the phone or the phone is powered
off or out of the service area.
To set your forwarding options:
1. Choose the type of call forwarding by pressing the
Up or Down key and press the Select soft key.
2. Select Activate and press the OK soft key.
Select Deactivate to disable the call forwarding
option.
3. Enter a phone number to which your calls will be
forwarded and press the Save soft key.
104
SSeettttiinnggss
105
SSeettttiinnggss
Phone/System MENU 8-2
Set Time (Menu 8-2-1)
To display the correct date and time on the idle screen
or to use the Organiser features, such as Scheduler,
Task List, Count Down, Alarm and World Time,
you need to set the current time and date using this
menu.
Enter the time and date using the numeric keys. You
need to enter the time in 24-hour format. The minute,
hour, month and day each must be entered using 2
digits and the year requires all 4 digits.
Set NAM (Menu 8-2-2)
NAM stands for numerical assignment module,
essentially your phone number. Your phone can have
two NAMs. This means that you can have two phone
numbers for using your phone and can quickly and
easily switch your service back and forth between the
two numbers.
If you change the NAM, the phone turns off by itself
and back on, and then acquires service using the new
NAM setting.
Version (Menu 8-2-3)
This menu allows you to view the software and
hardware versions of your phone. This feature is
helpful if you need to the call customer care.
Once Call Forwarding is enabled, a notification text
appears to inform you that your calls will be diverted,
each time a call is forwarded or you switch the phone
on. (Pls confirm this feature???)
Call Waiting (Menu 8-1-4)
Call Waiting lets you receive a second call during a
conversation.
Select Activate to enable the call waiting feature;
otherwise Deactivate.
When Call Waiting is enabled, you can respond to an
incoming call by pressing the key while you are on
a call. This puts the first caller on hold and answers
the second call. For further details about answering a
waiting call, see page xx.
106
SSeettttiinnggss
107
SSeettttiinnggss
Security Menu 8-3
Your phone provides you with many security options,
including a user-programmable lock code and call
restriction features.
To access the Security menu, you need to enter a lock
code. The lock code is preset to “0000” at the factory.
Lock Mode (Menu 8-3-1)
When the phone is locked, you cannot operate the
phone until you enter the lock code.
The following options are available:
Never: the phone remains unlocked.
On Power-Up: the phone locks automatically the next
time you turn it on.
Now: the phone locks immediately.
To place an emergency call, enter the number and then
press the key. The phone recognises three
emergency numbers stored in the Emergency
Numbers menu (Menu 8-3-3).
To unlock the phone, press the Unlock soft key and
enter the lock code. The phone returns to Standby
Mode.
Change Code (Menu 8-3-2)
This feature allows you to change your current lock
code to a new one. The lock code is preset to “0000”
at the factory.
Enter a new, four-digit lock code and then press the
Save soft key.
Emergency Numbers (Menu 8-3-3)
Your phone provides you with the option for storing
three emergency numbers. All of these numbers can
be manually dialled at any time even when your phone
is locked.
IMPORTANT NOTICE!
Emergency calling may not be available on all wireless
networks at all times. A connection cannot always be
guaranteed, due to various transmission methods,
network parameters and user settings used to
complete a call from your wireless phone.
DO NOT depend on this phone as a primary method of
dialling 100 or for any other essential or emergency
communications.
Remember to always turn your phone on and check for
the adequate signal strength before placing a call.
To store an emergency number:
1. Press the Up or Down key to select a number
location and press the Select soft key.
109
SSeettttiinnggss
108
SSeettttiinnggss
2. If necessary, press and hold the CLR key to clear the
existing number.
3. Enter the required number.
Each emergency number can be up to 24 digits long.
4. Press the Save soft key to store the number.
To make an emergency call in the lock mode, simply
enter one of the stored emergency numbers, and then
press the key.
Voice Privacy (Menu 8-3-4)
Used only in digital networks, Voice Privacy encrypts
the voice channel so that people cannot eavesdrop on
your conversation.
The following options are available:
Standard: turns this feature off. The phone will use a
standard line for calls.
Enhanced: turns this feature on. The phone will
make and receive calls on an encrypted high security
line.
Note: This feature may not be available in all areas.
Contact Reliance for details and its availability.
Clear Phone Book (Menu 8-3-5)
This menu allows you to erase your Phonebook entries.
When a confirming message displays, select Yes and
press the OK soft key to confirm.
Reset Phone (Menu 8-3-6)
Resetting the phone restores the default settings of all
of user-selectable options.
When a confirming message displays, select Yes and
press the OK soft key to confirm. The phone reboots,
turning itself off and then back on, and returns to
Standby Mode.
111
RR WWoorrlldd
110
R World
This R World menu allows you to:
• launch the web browser.
• play the downloaded multimedia items.
• enjoy the games.
• reset the web browser.
R-Menu Menu 9-1
Your phone comes equipped with a web browser
which makes it possible for you to access the wireless
web.
The web browser allows you to access up-to-the
minute information through your phone. Browsing the
wireless web through your phone is unlike using your
computer; site providers have selected only the critical
aspects of their sites to present to wireless phone
users and they have removed most of the graphics.
Each time you start the web browser, the phone will
connect to the wireless web and the Service icon ( )
will appear on the display. Any time this icon is visible
on the display, you are connected to the wireless web
and will be billed accordingly. Rates will vary
according to your service plan.
The web browser will end the connection after a
certain period of network inactivity and will
automatically reconnect as necessary. For this reason,
you may find that you are billed for several network
connections within a single session. This is normal and
is designed to minimise your bill.
Cannot be checked with the
current phone.
Launching the Web Browser
Note: The first time you use the web browser, you will
go through a security setup process that takes 3
to 5 minutes. Please follow the on-screen
prompts to complete the security setup process.
This initial setup process occurs only the first
time you access the service.
1. Accessing the R-Menu menu (Menu 9-1) connects
your phone to the wireless web. You can also press
the key in Standby Mode.
2. Once you are connected, the home page or the last
page you visited displays.
The opening page contents may be different
according to your wireless web service provider.
3. To scroll through the screen, use the Up or Down
key.
Exiting the Web Browser
To exit the web browser, simply press the key at
any time.
112
RR WWoorrlldd
113
RR WWoorrlldd
Navigating the Web Browser
When you use the web browser, some keys on your
phone operate differently than when on a normal
phone call. These keys are explained below. The web
browser presents on-screen items in one of the
following ways:
• text or numeric input
• links (embedded in content)
• numbered options (some options may not be
numbered)
• simple text
Here’s how the keys work in the web browser:
Navigation keys: Use these keys to scroll
to and select browser options. The currently
selected option is indicated by an arrow.
You can also use them to move the cursor
when editing text.
Left soft key: This is the left soft key used
to execute the commands at the bottom left
of the browser display.
Right soft key: This is the right soft key
used to execute the commands at the bottom
right of the browser display.
Cursor keys: Use these keys to move the
cursor when editing text.
END key: This key ends the web browser
connection and returns the phone to Standby
Mode.
Clear key: This key performs two important
functions:
• Sends you back in the browser. Pressing it
once sends you back one page. Pressing
and holding this key sends you back to the
home page.
• Clears out the entered text or numbers.
When entering characters, press this key
to clear the last number, letter or symbol.
Press and hold this key to completely clear
the input field.
Numbered keys 0 - 9: If the items on a
page are numbered, you can use these keys
to select them.
Volume keys: These keys allows you to
scroll up or down by a page or change the
volume setting.
Using the Web Browser Menus
On the web browser, you can access the following
options by pressing the Menu soft key:
Reload: reloads the current web page.
Home: takes you back at any time to the homepage of
the wireless web service provider.
Bookmarks: allows you to load a bookmarked web
page directly.
~
115
RR WWoorrlldd
114
RR WWoorrlldd
Mark Site: allows you to set a bookmark for most
pages; they can be accessed directly from any web
page. Bookmarks save you time by reducing the
number of steps required to access a given page.
About Openwave: provides you with information
about Openwave and your version of the web browser.
Advanced: gives you access the following advanced
features:
- Show URL: displays the URL address of the site
where you are currently connected. It also enables
you to declare the current site as the startup
homepage.
- Homepage: allows you to change the startup
homepage manually.
- Set WAP Proxy: allows you to configure the proxy
settings required for connecting to the wireless web.
- Offline Service: Most applications are stored on a
server that cannot be accessed outside your wireless
coverage area. However, some applications can be
stored in the cache of your phone, enabling you to
use them offline. You can remove the associated site
from the cache at any time.
- Outbox: stores outgoing requests from the browser
so that they can be processed at a later date.
- Restart Browser: restarts the browser without exiting
it.
- Encryption: This option is automatically set by the
service provider. You do not need to change it.
Entering Text in the Web Browser
When prompted, you can enter letters, numbers or
symbols same way as in the phone mode. See page xx
for more information about how to enter characters.
Multimedia Menu 9-2
In this menu, you can use the multimedia files
downloaded from R-World. You can download up to 3
items.
To play back a multimedia file:
1. When the Show List highlights, press the Select
soft key.
2. When the list of the downloaded items displays,
scroll to the item you want to play by pressing the
Up or Down key.
3. Press the Select soft key to start playing the file.
4. To Press the
pause Pause soft key.
resume the playback Play softkey.
adjust the volume volume keys.
repeat the playback Loop soft key.
cancel the repeating End-Loop soft key.
mode
5. To exit the screen, press the CLR key.
117
RR WWoorrlldd
116
RR WWoorrlldd
To remove a multimedia file from the phone’s memory:
1. Select the Erase List by pressing the Up or Down
key.
2. When the list of the downloaded files displays,
scroll to the file you want to delete by pressing the
Up or Down key.
To delete all of the files, select All.
3. Press the Select soft key.
4. When a confirming message displays, select Yes
and press the OK soft key.
Games Menu 9-3
This menu allows you to play the three games; Push
Push, X-Flighter and Space War.
1. Press the Up or Down key to scroll to a game and
press the Select soft key.
The game start screen displays.
2. For Push Push, press the OK soft key and the key
helper screen appears. Press the OK soft key to
start the game.
For X-Flighter or Space War, press the
corresponding number key to select an option:
• New game: starts a new game.
• HighScore: shows you the High Score table.
• Key Info.: shows you the key helper screen.
• Continue: allows you to continue the last game
you played. This option is activated only when
you already played the game.
4. To stop the game, press the key or the CLR
key.
Reset R-Menu Menu 9-4
If the screen is not clear or it often freezes when you
are navigating the web browser, you can use this
feature to clear the problem.
When a confirming message displays, select Yes and
then press the OK soft key.
118 119
PPhhoottooss
Photos
Using the camera module built in your phone, you can
take pictures of people or events while on the move.
You can set a picture as a wall paper image or caller
image.
Camera Menu 0-1
In this menu, you can take a picture. The camera
produces JPEG pictures.
Note: When you take a picture in direct sunlight or
under too bright illumination, shading may
occurs on the picture.
To take a picture:
1. Accessing the Camera menu turns on the camera at
the top left of the phone. Or, press and hold the
key in Standby Mode.
The image to be captured appears on the display.
2. Adjust the image by rotating the camera module and
aiming it at the subject.
3. To Press the
flip the image vertically volume keys.
change the image Left or Right key.
size
change the image Up or Down key.
resolution
use the options Options soft key.
See below.
review the picture Review soft key.
stored in your Photo Album
return to the capture CLR key.
mode from the review
screen
4. Press and hold the key to take the picture.
The phone automatically saves the picture in the
Photo Album menu (Menu 0-2) and returns to the
capture mode.
5. Press the Review soft key to view the taken
picture.
If you want to use the camera options, press the
Options soft key. See page xx.
6. When you are finished, press the key to
return to Standby Mode.
120
PPhhoottooss
121
PPhhoottooss
Using the Camera options
When you press the Options soft key in the capture
mode, the following options are available for the
current shot:
Flash
You can use the flash which allows you to take a
picture of the best quality when it is dark. Select On
this Shot to use the flash only for the current shot and
Always On to use it for all of the pictures you take.
When the flash turns on, the flash icon (???) appears
on the top right of the image
Self Timer
You can set the phone to take a picture at a predefined
time. Once you set the time, the timer (???) appears on
the top right of the image. When you press and hold
the key, it counts down and turns red before 3
seconds. The phone automatically takes and saves a
picture when the specified time expires.
Brightness
You can adjust the brightness of the image. When the
brightness is selected Auto, the phone automatically
determines the setting.
Fun Frames
This option allows you to use a frame on the picture.
Press the Navigation keys to find the frame format you
want to use.
Color Tones
This options allows you to change the color tone of the
picture. Press the Navigation keys to find the tone you
want to use. Mono, Sepia, Negative, Emboss,
Sketch,UV Positive and UV Negative are available.
To set the phone to adjust the color automatically,
select Auto.
White Balance
This setting adjusts the color balance of the picture to
remove the current lighting conditions add. With this
setting, you can make your picture appear warm or
cool. Scroll to the setting you want to use by pressing
the Up or Down key. When you select Manual, you
can adjust the balance using the Navigation keys.
123
PPhhoottooss
122
PPhhoottoossPPhhoottooss
Photo Album Menu 0-2
In this menu, you can review the pictures you have
taken. By default, your phone displays them in the
thumbnail mode, which shows pictures as a small
image.
To Press the
scroll through the Navigation keys.
pictures
use the options Options soft key. For
details, see below.
view the selected Expand soft key.
picture in a large size
on the full screen
return to the Thumbnail soft key.
thumbnail mode
Using the Picture Options
Press the Options soft key while reviewing a picture,
and the following options are available:
Camera
You can switch the display to the capture mode.
Save to Wallet
This option copies the picture to the Photo Wallet
menu (Menu 0-3). See the next page.
Erase
You can erase the selected picture or all of the pictures.
Edit Caption
This option allows you to change the picture’s title
displayed on the right top of the picture in the expand
mode.
Photo Info.
This option shows you information about the current
picture, such as title, time and date when it was taken,
image size and quality.
The display scrolls the information screen automatically.
Press the Up or Down key to scroll the screen by one
item. You can also scroll by one page by pressing the
Scroll soft key.
Thumbnail/Expand
You can switch the display to the thumbnail mode or the
expand mode.
Photo Wallet Menu 0-3
Photo Wallet allows you to store the pictures
independently, like your photo album. By default, your
phone displays them in the thumbnail mode, which
shows pictures as a small image.
125
PPhhoottooss
124
PPhhoottooss
To Press the
scroll through the Navigation keys.
pictures
use the options Options soft key. For
details, see below.
view the selected Expand soft key.
picture in a large size
on the full screen
return to the Thumbnail soft key.
thumbnail mode
When you press the Options soft key while reviewing
a picture, the following options are available:
Wallpaper: copies the picture into the Photo
Wallpaper image folder. You can use it in the
Wallpaper menu (Menu 5-4).
Phonebook: allows you to set the picture as a caller
image for a Phonebook entry.
Erase: allows you to erase the selected picture or all
of the pictures from Photo Wallet.
Settings Menu 0-4
This menu allows you to set up the options for using
the camera and pictures.
Security (Menu 0-4-1)
You can lock the pictures so that a person without your
approval cannot review them.
To access the Security menu, you need to enter the
lock code. It is preset to “0000” at the factory.
Select On and press the OK soft key. Once you have
locked the pictures, you need to enter the lock code
each time you access the Photo Album and Photo
Wallet menus.
To deactivate this feature, select Off.
Camera Settings (Menu 0-4-2)
You can change the default image settings. The
following options are available:
Resolution: allows you to adjust the resolution of the
image. You can select either High:640*480,
Med:320*240 or Low:160*120.
Quality: allows you to change the image quality. You
can select either Economy, Normal or Fine.
127
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
126
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and life-time of the battery.
Always try to keep the battery at room temperature.
A phone with a hot or cold battery may temporarily
not work, even when the battery is fully charged. Li-
ion batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and – terminals of the battery (metal strips on the
battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuit.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Health and Safety
Information
Precautions When Using Batteries
Your phone is powered by a rechargeable Li-ion
standard battery.
• Never use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time, including talk time and
standby time, is noticeably shorter than normal, it is
time to buy a new battery.
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries and recharge
your battery only with Samsung-approved chargers.
When a charger is not in use, disconnect it from the
power source. Do not leave the battery connected
to a charger for more than a week, since
overcharging may shorten its life.
128
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
129
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But
an important responsibility accompanies the benefits
of wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of
a car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the many
hands-free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your voice
mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain, sleet,
snow, ice and even heavy traffic can be hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a To do list or flipping through
your phonebook takes your attention away from your
primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that you
are driving and suspend conversations that have the
potential to divert your attention from the road.
8. Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic
accident or medical emergencies.
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where lives are
in danger, call the emergency number, as you would
want others to do for you.
10. If you see a broken-down vehicle posing no serious
hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a
vehicle you know to be stolen, call roadside
assistance or any other special non-emergency
wireless number.
130
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
131
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever
it is forbidden to use it, or when it may cause
interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment are shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These
recommendations are consistent with the independent
research and recommendations of Wireless Technology
Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm (6
inches) from their pacemaker when the phone is
switched on;
• should not carry the phone in a breast pocket;
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
133
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
132
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refuelling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
135
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
134
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore, you
should never rely solely on any wireless phone for
essential communications (medical emergencies, for
example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location. Emergency numbers vary by location.
3. Press the key.
If certain features are in use (call barring, for example),
you may first need to deactivate those features before
you can make an emergency call. Consult this
document and Reliance.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
Other Important Safety Information
• Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or
service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone equipment in
your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as the
phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or in
the air bag deployment area. If wireless equipment
is improperly installed and the air bag inflates,
serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
offender, or legal action, or both.
137
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
136
HHeeaalltthh aanndd SSaaffeettyy IInnffoorrmmaattiioonn
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain
plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone’s electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device’s
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices, such
as a microwave oven, a stove or a radiator. The
phone may explode when overheated.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
138 139
GGlloossssaarryy
Glossary
Airtime - Actual time spent talking on the wireless
phone. Most carriers bill customers based on how
many minutes of airtime they use each month.
Antenna - A device for transmitting or receiving
signals. The size and shape of antennas is determined,
in part, by the frequency of the signal they receive.
Wireless phones and the base station must have
antennas.
Base Station - The fixed radio transmitter/receiver
that maintains communications with mobile radio
telephones within a given area. (Typically called a cell
or cell site)
CDMA (Code Division Multiple Access) A spread-
spectrum approach to digital transmission. With
CDMA, each conversion is digitized and then tagged
with a code. The mobile phone deciphers only a
particular code to pick the right conversation off the
air. The transmitted signal is just above noise level
across the available bandwidth.
Channel - Communications signals transmit along
paths called channels.
Codec - Compression & Decompression.
Deactivation - The process of rendering a wireless
phone inactive.
DTMF - (Dual-tone Multi-Frequency ) You send DTMF
signals when you enter numbers by pressing the digit
keys.
EVRC - (Enhanced Variable Rate Codec) EVRC is a new
global standard for compressing and decompressing
voice signals. EVRC uses a lower bit rate (the number
of bits sent per second) than existing CDMA vocoders,
while providing significant improvements in voice
quality. This technology enables your phone to provide
superb voice quality while benefiting from the ability
to process more cellular voice calls using less
bandwidth than the voice codecs in CDMA networks
today.
Frequency - A measure based on time, as one or
more waves per second, in an electrical or light wave
information signal. A signal’s frequency is stated in
cycles-per-second or Hertz (Hz).
Hands-Free - A feature that permits a driver to use a
wireless phone without lifting or holding the handset -
an important safety feature for automobiles, tractors
and most other motorized vehicles.
LCD - (Liquid Crystal Display) Commonly used to refer
to the screen display on the wireless phone.
LED - (Light Emitting Diode) Commonly used to refer to
a small light on the wireless phone or on the Desktop
Charger. The LED lights on the phone to indicate an
incoming call. The lights on the charger indicate that
battery charging is taking place.
140
GGlloossssaarryy
141
Prepend - The addition of a prefix, such as an area
code, to a phone number.
RF - Radio Frequency
Roaming - The ability to use a wireless phone to
make and receive calls in places outside of the home
service area.
Service Charge - The amount paid each month to
receive wireless service.
Standby Time - The amount of time a fully charged
wireless portable or transportable phone can be on
and idle without being in use. (See Talk Time)
Talk Time - The length of time a person can talk on a
portable or transportable wireless phone without
recharging the battery.
Vocoder - Voice Coder. A device used to convert
speech into digital signals.
Wireless - Radio-based Systems that allow
transmission of telephone or data signals through the
air without a physical connection, such as a metal wire
(copper) or fiber optic cable.
Index
A
Accessories • 9
Air time (1-5) • 55
Alarm (5-5) • 84
Alerts (7-3) • 98
Animation • 101
Auto answer (0-1) • 105
Auto retry (0-3) • 106
B
Backlight (8-4) • 102
Banner (8-3) • 102
Battery
charging • 18
installing • 17
low battery indicator • 20
removing • 18
precautions • 116
C
Calculator (5-6) • 85
Callanswer (0-2) • 105
answering • 34
emergency • 25
ending • 25
forwarding • 37
from Phone Book • 26
incoming (1-2) • 53
making • 24
missed • 36
outgoing (1-1) • 52
redialling last • 25
restriction • 111
three way • 39
waiting • 38
Caller ID • 36
Camera (#) • 114
Care • 126
Characters, entering • 40
Charging batteries • 18
Clock • 103
Connect tone • 98
Contrast (8-6) • 103
Correcting number • 25
D
Data/fax
receiving/sending • 109
Data/fax (0-7) • 108
Dialling
pause • 29
prepend • 26
speed • 27
voice • 32, 88
Disconnect tone • 98
Display
LCD • 10
external • 15
DTMF tone
length (7-6) • 99
Dual clock (8-5) • 103
E
Erasing History (1-4) • 54
Erase Msg (3-7) • 69
External Display • 15
F
Finding
phonebook • 56
G
Games (9) • 104
Greeting • 94
The index will be updated in
a later version
142
IInnddeexx
143
IInnddeexx
I
Icon description • 13
Inbox ( 3-3) • 66
In-call options • 35
Incoming calls (1-2) • 53
Installing battery • 17
K
Key Beep (7-5) • 99
Keys
description • 11
location • 10
L
Language (0-4) • 106
Last number redialling • 25
Letters, entering • 40
Listening
voicemail •65
Lock code • 111
Low battery indicator • 20
M
Maintenance • 126
Memo pad (5-4) • 83
Memory (2-5) • 61
Memory, clearing • 113
Menus
list • 49
scrolling • 47
shortcuts • 48
Messages
erasing • 69
filed • 68
greeting • 94
setup (3-8) • 70
voice • 65
Minute beep • 98
Missed calls • 36
Modes
phone • 22
text input • 40
Mute
microphone • 35
N
Names
entering • 40
find (2-1) • 56
NAM setting (0-5) • 107
Number
adding in an entry • 60
correcting • 25
my phone # (2-4)• 61
searching • 56
O
Outbox (3-4) • 67
Outgoing calls (1-1) • 52
P
Phone
layout • 10
lock • 110
my number (2-4) • 61
Phonebook (2) • 56
PINcode • 112
Planner (5) • 79
Power save mode • 23
Prepend dialling • 26
R
Redialling
auto • 106
last call • 25
Removing battery • 18
Reset phone • 113
Restrict • 111
Ring
type (7-2)• 97
volume (7-1) • 96
Roam ringer (7-4)• 99
S
Safety
batteries • 116
information • 116
precautions • 7
Schedular (5-2) • 81
Searching
phonebook • 56
Security (0-9) • 110
Service alert • 98
Service light • 16
Setting NAM (0-5) • 107
Setting system (0-6) • 107
Setting time (5-9) • 87
Setup (0) • 105
Sounds (7) • 96
Speed dialling • 27
Standby mode • 22
Switching on/off
phone • 21
T
Task List (5-3) • 82
Text, entering • 40
Today (5-1) • 79
Tone length (7-6) • 99
T9 text mode • 42
U
Unpacking • 9
V
Version (0-8) • 110
Voice answer (6-3) • 92
Voice dial (6-1) • 88
Voice memo (6-2) • 91
Voice message (3-2) • 65
Volume, adjusting
ring (7-1) • 96
key (7-5) • 99
W
Web Browser
get in web (4-1) • 73
prompt (4-2) • 78
World time (5-7) • 86
Writing new message • 62
145
Save a Number Number + Save + Select +
/ (Category) + Select +
Name + Next + If necessary,
/ + / to change
the settings or Edit to enter
information + Save
Speed dialling Enter memory location of
desired number, holding the
last digit to automatically
dial.
Phonebook Press + /
Search + / + OK or
Launch the web Press
browser
Take a picture Press +
SCH-A633 Quick Reference Card
BASIC OPERATIONS
Make a call Phone number +
End a call
Receive a call or open the phone
Adjust the key (in Standby Mode)
beep volume / on the left side
Adjust the (during a conversation)
speaker volume / on the left side
Redial the last call twice
Switch to the Hold #
vibrate mode
Voice dial Hold *or open the folder
+ Say a name
144
146
Licensed by QUALCOMM Incorporated under one or more
of the following Patents.
U.S Patent No. 4,901,307 5,056,109 5,099,204
5,101,501 5,103,459 5,107,225
5,109,390
Main Menu (To access, press the Menu soft key)
1 : Phone Book 1 : Find
2 : Add Entry
3 : Groups
4 : Memory Status
2 : Messages 1 : Write
2 : Inbox
3 : Outbox
4 : Saved
5 : Templates
6 : Erase Msgs
7 : Settings
8 : Voice Mail
3 : Call History 1 : Missed
2 : Received
3 : Dialled
4 : Erase History
5 : Call Duration
4 : Sounds 1 : Ringer Tones
2 : Ringer Volume
3 : Alerts
4 : Key Tone
5 : Power On/Off Melody
5 : Display 1 : Language
2 : Service Area
3 : Menu Theme
4 : Wallpaper
5 : Banner
6 : Backlight
7 : Set Dual Clock
8 : Service LED
6 : Voice Tools 1 : Voice Dial
2 : Voice Memo
3 : Answer Machine
7 : Organiser 1 : Scheduler
2 : Task List
3 : Memo Pad
4 : Alarm
5 : Calculator
6 : World Time
7 : Count Down
8 : Settings 1 : Call 1. Auto Redial
2. Answer Mode
3. Call Forward
4. Call Waiting
2 : Phone/System 1. Set Time
2. Set NAM
3. Version
3 : Security 1. Lock Mode
2. Change Code
3. Emergency Numbers
4. Voice Privacy
5. Clear Phone Book
6. Reset Phone
9 : R World 1 : R-Menu
2 : Multimedia
3 : Games
4 : Reset R-Menu
0 : Photos 1 : Camera
2 : Photo Album
3 : Photo Wallet
4 : Settings
LIST OF MENU FUNCTIONS
