Samsung Electronics Co SCHE159 Single-Band Cellular CDMA Phone User Manual C s and Settings Admi
Samsung Electronics Co Ltd Single-Band Cellular CDMA Phone C s and Settings Admi
Users Manual
9. Users Manual
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.
* Depending on your country, your phone and accessories may
appear different from the illustrations in this manual.
World Wide Web
http://www.samsungmobile.com
Printed in China
Code No. : GH68-XXXXXA
English. 03/2005. Rev.1.0
ELECTRONICS
PORTABLE CELLULAR
TELEPHONE
SCH-E159
User’s Manual
3
Table of contents
Important safety precautions........................... 7
Unpacking ........................................................ 9
Your phone..................................................... 10
Phone layout ........................................................... 10
Display................................................................... 13
Backlight ................................................................ 17
Camera .................................................................. 17
Getting started ............................................... 18
Using a UIM card ..................................................... 18
Using a battery........................................................ 19
Switching the phone on or off.................................... 23
Using the PIN code .................................................. 24
Using the soft keys .................................................. 25
Your phone’s modes................................................. 26
Call functions ................................................. 28
Making a call ........................................................... 28
Ending a call ........................................................... 29
Emergency dialling................................................... 29
Using the Recent calls list ......................................... 30
Making a call from Phonebook ................................... 30
Speed dialling ......................................................... 31
Voice dialling........................................................... 31
Pause dialling .......................................................... 32
Adjusting the volume during a call ............................. 34
Answering a call ...................................................... 35
Silencing the call ringer ............................................ 35
Rejecting a call........................................................ 36
Viewing missed calls ................................................ 36
Options during a call ................................................ 37
Recording your call conversation................................ 38
Call forwarding ........................................................ 38
Call waiting............................................................. 38
Three-way calling .................................................... 39
4
Entering text .................................................. 40
Changing the text input mode ................................... 41
Using Chinese Pinyin mode ....................................... 42
Using Chinese Stroke mode....................................... 46
Using 123 mode ...................................................... 49
Using Symbol mode ................................................. 49
Using ABC mode...................................................... 49
Using T9 Word mode................................................ 51
Using the menus ............................................ 53
Accessing a menu function by scrolling ....................... 53
Using shortcuts ....................................................... 54
Accessing favourite features...................................... 54
List of menu functions .............................................. 56
uni.................................................................. 61
Wap....................................................................... 61
Mail ....................................................................... 64
Magic ..................................................................... 75
Channel.................................................................. 77
Map ....................................................................... 78
Info ....................................................................... 78
Calls ............................................................... 79
Missed
(Menu 1-1)
.................................................... 79
Incoming
(Menu 1-2)
................................................ 80
Outgoing
(Menu 1-3)
................................................. 81
Air time
(Menu 1-4)
.................................................. 81
Call forward
(Menu 1-5)
............................................ 82
Call waiting
(Menu 1-6)
............................................. 83
Area code
(Menu 1-7)
............................................... 83
Call reject
(Menu 1-8)
............................................... 84
Phonebook ..................................................... 85
Find
(Menu 2-1)
....................................................... 85
Add
(Menu 2-2)
........................................................ 88
Group setting
(Menu 2-3)
.......................................... 90
Speed dial
(Menu 2-4)
............................................... 91
Name card
(Menu 2-5)
.............................................. 93
My phone #
(Menu 2-6)
............................................ 97
Memory info
(Menu 2-7)
............................................ 97
5
Camera........................................................... 98
Take photo
(Menu 3-1)
.............................................. 98
My album
(Menu 3-2)
.............................................. 105
Photo studio
(Menu 3-3)
.......................................... 107
Settings
(Menu 3-4)
................................................ 114
Display ......................................................... 115
Image box
(Menu 4-1)
............................................ 115
Banner
(Menu 4-2)
................................................. 116
Backlight
(Menu 4-3)
.............................................. 116
Menu type
(Menu 4-4)
............................................. 116
Set time
(Menu 4-5)
............................................... 117
External clock
(Menu 4-6)
........................................ 118
/Language
(Menu 4-7)
............................................. 118
Dialing font
(Menu 4-8)
........................................... 118
Message ....................................................... 119
New message
(Menu 5-1)
........................................ 119
Inbox
(Menu 5-2)
................................................... 121
Outbox
(Menu 5-3)
................................................. 123
Msg setup
(Menu 5-4)
............................................. 124
Msg wallpaper
(Menu 5-5)
....................................... 126
Memory info
(Menu 5-6)
.......................................... 126
Sounds ......................................................... 127
Ringer
(Menu 6-1)
.................................................. 127
Ringer vol./Type
(Menu 6-2)
.................................... 128
Key tone
(Menu 6-3)
............................................... 129
Alert
(Menu 6-4)
..................................................... 129
Entertainment .............................................. 132
3D game
(Menu 7-1)
............................................... 132
MP3
(Menu 7-2)
...................................................... 132
VOD
(Menu 7-3)
..................................................... 137
Melody composer
(Menu 7-4)
................................... 139
Karaoke
(Menu 7-5)
................................................ 143
Fun club
(Menu 7-6)
................................................ 144
Samsung messenger
(Menu 7-7)
.............................. 144
6
Utilities......................................................... 150
Calendar
(Menu 8-1)
............................................... 150
Alarm
(Menu 8-2)
................................................... 153
User memory
(Menu 8-3)
........................................ 154
I.Beam
(Menu 8-4)
................................................. 157
Mini dictionary
(Menu 8-5)
....................................... 161
Calculator
(Menu 8-6)
............................................. 162
Today
(Menu 8-7)
................................................... 162
To do list
(Menu 8-8)
.............................................. 163
Voice tools
(Menu 8-9)
............................................ 164
World time
(Menu 8-0)
............................................ 168
Countdown
(Menu 8-)
............................................. 168
Memo pad
(Menu 8-)
.............................................. 170
Settings........................................................ 171
Answer mode
(Menu 9-1)
........................................ 171
Roam option
(Menu 9-2)
.......................................... 172
Security
(Menu 9-3)
................................................ 173
Entry method
(Menu 9-4)
........................................ 179
Data option
(Menu 9-5)
........................................... 179
Domains preset
(Menu 9-6)
...................................... 179
Contents status
(Menu 9-7)
...................................... 180
Rotation mode
(Menu 9-8)
....................................... 180
Health and safety information ...................... 181
Exposure to Radio Freqency (RF) Signals .................. 181
For Body Operation ................................................ 182
Battery safety ....................................................... 183
Road safety .......................................................... 186
Operating environment........................................... 187
Electronic devices .................................................. 187
Potentially explosive atmospheres............................ 189
Emergency calls .................................................... 190
FCC Notice and Cautions......................................... 191
Other important safety information .......................... 191
Care and maintenance............................................ 192
Glossary ....................................................... 194
Acknowledging Special Precautions
and the FCC and Industry Canada Notice .................. 196
CERTIFICATION INFORMATION (SAR)....................... 197
Quick reference card .................................... 199
7
Important safety
precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road safety at all times
Do not use a hand-held phone while driving; park
the vehicle first.
Switching off when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switching off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switching off near all medical equipment
Switch off your phone near medical equipment.
Hospitals or health care facilities may be using
equipment that could be sensitive to external RF
energy. Follow any regulations or rules in force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Special regulations
Meet any special regulations in force in any area
and always with off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
Water resistance
Your phone is not water-resistant. Keep it dry.
Important safety precautions
8
Sensible use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency call
Key in the emergency number for your present
location, then press the key. Give all necessary
information as accurately as possible. Do not end
the call until given permission to do so.
Keeping small children away from your phone
Keep the phone and all its parts including
accessories out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories
could damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see “Health
and safety information” on page 181.
CAUTION
RISK OF EXPLOSION IF A BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
9
Unpacking
Your package contains the following items:
Note
: The illustrations above may look different from
your phone and accessories.
Handset Travel adapter
Batteries User’s manual
10
Your phone
Phone layout
The following illustrations show the main elements
of your phone:
With the phone open
Earpiece
Display
Microphone
Soft key (right)
Navigation
(right/left/up/
Down) keys
Soft key (left)
Volume keys
Power on/off/
Menu exit key
Cancel/
correct key
uni key
Dial/Menu
confirm key Alphanumeric
keys
Special
function keys
Headset jack
Your phone
11
With the phone closed
Key
(s)
Description
(soft keys)
Performs the functions indicated by the
text on the bottom line of the display.
In Standby mode; quickly enters the
following menus respectively:
• Up:
VOD
.
• Down:
I.Beam
.
• Left:
uni-Mail
.
This key accesses the
Message
menu when held down.
• Right:
Calendar
.
In Menu mode, scrolls through the
menu options.
When entering text, moves the cursor,
depending on which side you push.
Enters the
uni
menu.
Makes or answers a call.
In Standby mode, retrieves the most
recent numbers dialled, received, or
missed calls from. Redials the last
number when pressed and held.
Camera
Antenna
External display
Camera/Voice
memo key
MP3 key
Infrared port
Your phone
12
Ends a call. Also switches the phone on
and off when pressed and held.
In Menu mode, cancels your input and
returns the phone to Standby mode.
Deletes characters from the display.
In Menu mode, returns you to the
previous menu level.
Enters numbers, letters, and some
special characters.
In Standby mode, dials a number by
voice command when pressed and held.
In the text entry mode, changes the
case of letters.
In Standby mode, quickly activates or
deactivates Silent mode when pressed
and held.
In the text entry mode, inserts a space.
(on the right side of the phone)
In Standby mode, enters the
Camera
menu. Turns the camera on when
pressed and held.
In Capture mode, takes a photo.
During a call, records your conversation
when pressed and held.
Key
(s)
Description
(continued)
Your phone
13
Display
Display layout
The display has three areas:
(on the right side of the phone)
In Standby mode, enters the
MP3
menu.
During a call, activates or deactivates
the noise cancellation feature.
(on the left side of the phone)
In Standby mode, with the phone open,
adjusts the key tone volume.
During a call, adjusts the voice volume.
Key
(s)
Description
(continued)
Icons
Text an d
graphics area
Soft key function
indicators
Menu
Find
Your phone
14
Icons
Icon Description
Signal strength
: Shows the received
signal strength. The greater the number of
bars, the better the signal.
Service
: Appears when a call is in
progress.
No service
: Appears when you are
outside a service area. When it displays,
you cannot make or receive calls. Wait a
little while for a better signal or move into
an open area to regain service.
Lock mode
: Appears when your phone is
locked.
Restriction on
: Appears when any option
of the restriction feature is activated.
New e-mail notification
: Indicates that
there is a new e-mail notification waiting
to be viewed.
Retrieved Mail message
: Indicates
that there is a retrieved Mail message
waiting to be viewed.
New web alert
: Appears when a new web
message has been received.
New SMS
: Indicates that there is a new
text message waiting to be viewed.
New voice mail
: Indicates that there is a
new voice mail waiting to be viewed.
Your phone
15
Urgent SMS
: Indicates that there is an
urgent message waiting to be viewed.
Samsung messenger invite message
:
Indicates that there is a new Samsung
messenger invite message waiting to be
viewed.
Alarm mode
: Appears when you set an
alarm to ring at a specified time.
Roaming
: Appears when you are out of
your home area and have logged onto a
different network; for example, when
travelling in other countries.
Ringer on
: Appears when you set the
ringer type for calls to
Ringer only
.
Ringer off
: Appears when the ring type
for calls is set to
Silent
.
1-Beep
: Appears when you set the ringer
type for calls to
1 Beep
.
Vibration
: Appears when the ringer type
for calls is set to
Vibration
.
Vibration + ringer
: Appears when the
ringer type for calls is set to
Vib. & ringer
.
Vibration then ringer
: Appears when the
ringer type for calls is set to
Vib. then
ringer
.
Icon Description
(continued)
Your phone
16
External display
Your phone has an external display on the front of
the phone. It indicates when you have an incoming
call or a message. It also alerts you at a specified
time when you have set an alarm. The backlight
turns on and the corresponding icon appears on the
external display.
When you close the phone, the display shows the
current time in a digital clock. You can change the
clock type in the
External clock
menu (
Menu 4-
6
).
Ringer then vibration
: Appears when
the ringer type for calls is set to
Ringer
then vib
.
Silent mode
: Appears when your phone is
in Silent mode.
Battery status
: Shows the level of your
battery. The more bars you see, the more
power you have remaining.
Icon Description
(continued)
Your phone
17
Backlight
The backlight illuminates the display and the
keypad. When you press any key or open the
phone, the backlight comes on. It goes off when no
keys have been pressed within a given period of
time, depending on the setting in the
Backlight
menu (
Menu 4-3
). See page 116 for further
details.
Camera
The camera on the front of the phone allows you to
take a photo or record a video while on the move.
For further details about the camera feature, see
page 98.
18
Getting started
Using a UIM card
The UIM (User Identification Module) card contains
chips with all the information required to operate
your phone. Note the following:
• Keep all UIM cards out of the reach of small
children.
• The UIM card and its contact can be easily
damaged by scratching or bending, so be careful
when handling, inserting, or removing the card.
Installing the UIM card
1. If necessary, remove the battery by referring to
page 20.
2. Slide a card into the slot, as shown, so that it
locks the card into position.
Make sure that the metal contacts of the card
face down into the phone.
Getting started
19
Removing the UIM card
Slide the card out of the slot.
Using a battery
Your phone is powered by a rechargeable Li-ion
battery. Use only approved batteries and chargers.
Ask your local Samsung dealer for further details.
Note
: You must fully charge the battery before using
your phone for the first time. A discharged
battery recharges fully in approximately 200
minutes for a standard battery.
Installing the battery
1. Place the battery so that the tabs on the end
align with the slots at the bottom of the phone.
Getting started
20
2. Press the battery until it clicks into place.
Make sure that the battery is properly installed
before switching on the phone.
Removing the battery
1. If necessary, switch off the phone by pressing
and holding the key down until the power-off
image displays.
2. To remove the battery:
➀
Slide the battery catch lock toward the top of
the phone and hold it in that position.
➁
Lift away the battery, as shown.
➁
➀
Getting started
21
Charging the battery
A travel adapter and a battery charger are provided
for charging your batteries.
Using the travel adapter
The travel adapter allows you to use the phone
while the battery is charging, but this will cause the
battery to charge more slowly.
1. With the battery in position on the phone, plug
the connector of the travel adapter into the jack
at the bottom of the phone.
Make sure that the arrow on the connector is
facing toward the front of the phone.
2. Plug the adapter into a standard AC wall outlet.
The battery strength icon on the display shows
that the battery is charging.
Getting started
22
3. When charging is finished, unplug the adapter
from both the power outlet and the phone by
pressing the buttons on both sides of the
connector and pulling out the connector.
Note
: You must unplug the adapter before removing
the battery from the phone during charging;
otherwise, the phone could be damaged.
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
➀
➀➁
Getting started
23
Switching the phone on or off
1. Open the phone.
2. Press and hold the key for more than one
second to switch on the phone.
3. If the phone asks for a Personal Identification
Number (PIN), enter the PIN code supplied with
the card. For further details on the PIN code, see
page 24.
When the system locates services, the idle
screen appears on the display.
If the phone is out of the service area, the No
Service icon ( ) appears on the display. In this
case, you cannot place and receive calls. You
can try again later when service is available.
Note
: You can change the display language in the
/Language
menu (
Menu 4-7
). See
page 118.
4. When you want to switch off the phone, press
and hold the key for more than one second
until the power-off image displays.
Getting started
24
WARNING!
Do not switch on the phone when mobile phone use
is prohibited or when it may cause interference or
danger.
Note
: Do not touch the antenna on the phone
unnecessarily when the phone is switched on.
Contact with the antenna affects the call quality
and may cause the phone to operate at a
higher power level than otherwise needed.
Using the PIN code
The PIN code supplied with the UIM card helps you
protect the cards against unauthorised use. When
the phone asks you to enter the code, enter the
appropriate code, displayed as asterisks for
security. If you enter an incorrect PIN code three
times in succession, your card is blocked.
To unlock
the card, contact your service provider.
You can enable or disable the code using the
Card
setup
menu (
Menu 9-3-9
). For further
information, see page 178.
Getting started
25
Using the soft keys
Your phone offers a set of functions that allows you
to use and customise it. These functions are
arranged in menus and submenus, accessed using
the two soft keys, and . Each menu and the
submenu allow you to view and alter the settings of
a particular function.
The roles of the soft keys vary depending on the
current function you are using; the labels on the
bottom line of the display just above each key
indicate their current role.
Example:
Press the left soft
key to access Menu
mode.
Press the right soft
key to access the
Find
menu in the
Phonebook
menu.
Getting started
26
Your phone’s modes
Standby mode
Standby mode is the most basic state of your
phone. The phone goes into Standby mode soon
after you turn it on, or whenever you briefly press
the key. When your phone is in Standby mode,
you will typically see the current time and date. If
you enter a phone number, you can press the
key to dial it, or press the
Save
soft key to save it
in the internal Phonebook.
Press the key at any time to return to Standby
mode. Be careful; if you are on a call when you
press the key, your phone disconnects the call
and returns to Standby mode.
Talk mode
You can place and answer calls only when your
phone is turned on. During a call, the phone is in
Talk mode. While you are in Talk mode, pressing the
Menu
soft key gives you a list of options. See
page 37 for details on the options.
Power Save mode
Your phone comes with the power save feature that
automatically turns the display off when you don’t
use the phone. While this feature is active, the
phone’s battery charge is conserved.
When the phone is in Power Save mode, press any
key to reactivate the display.
Getting started
27
Lock mode
When you lock your phone using the
Phone lock
menu (
Menu 9-3-1
), you can receive messages
and calls, but you cannot place calls until you
unlock the phone.
For further details about locking and unlocking the
phone, see page 173.
Silent mode
Silent mode disables all sounds, except for the
camera shutter sound, on the phone. This feature is
best used in situations where the phone might
disturb others, such as in a meeting, in a library,
and in a theater.
To enter Silent mode, press and hold the key
until “Entering silent mode” and the Vibration icon
( ) appears.
To exit and reactive the previous sound settings,
press and hold the key until “Exit silent mode”
appears. The Vibration icon no longer displays.
28
Call functions
Making a call
To make a call:
1. In Standby mode, enter the area code, and
phone number.
While entering a phone number, press the
Pause
soft key to insert a hard pause. For more
information on pause dialling, see page 32.
Note
: If you enter four digits, the phone will
display those numbers stored in the call log
or Phonebook that contain those digits.
2. Press the key. The phone places the call to
the entered phone number.
Correcting the number
To clear Press the
the last digit
displayed
C
key.
the whole display
C
key for more than one
second.
Call functions
29
Ending a call
When you want to finish your call, press the key.
The call time, the length of the call, displays along
with the phone number of the called person. If the
number is stored in your Phonebook, the name
displays. If there is no match, you can press the
Save
soft key and store the number in Phonebook.
For further details about storing a number in
Phonebook, see page 88.
Alternatively, simply close the phone to end a call.
Emergency dialling
You can place calls to standard emergency
numbers, such as 119, 110, 120, or 3 specified
number in the Emergency # list, even if your phone
is locked or all outgoing calls are restricted. For
further details on emergency numbers, see
page 174.
You can place an emergency call to a preset
emergency number when switching on the phone
without a UIM card.
Call functions
30
Using the Recent calls list
The phone stores the most recent calls you have
dialled, received, or missed chronologically. The last
call is saved in the first position.
To recall any of these numbers:
1. If there are any characters on the display, return
to Standby mode by pressing the key.
2. Press the key. The list of recent calls
displays.
The following icons indicate the type of calls:
• : Outgoing calls
• : Incoming calls
• : Missed calls
3. Press the Navigation keys or the Volume keys on
the left side of the phone to scan through the list
until the number you want highlights.
4. Press the key to dial the displayed number.
Making a call from Phonebook
You can store the phone numbers used frequently
on the card and in the phone’s memories, which is
called “Phonebook.” You then simply recall the
number to dial. For further details about
Phonebook, see page 85.
Call functions
31
Speed dialling
You can assign your most frequently used numbers
from Phonebook to one- or two-digit speed dial
keys in the
Speed dial
menu (
Menu 2-4
). For
details, see page 91.
Then you can dial one of the speed dial entries by
pressing and holding the number keys.
Voice dialling
Using the voice dialling feature, you can dial a
number stored in your Phonebook by speaking the
associated name into the microphone. For details
about storing a number, see page 88.
Note
: Your phone can recognise only Chinese names.
To programme the phone to recognise your voice,
you need to configure the voice dialling settings in
the
Voice dialing
menu (
Menu 8-9-1
). See
page 164.
To start voice dialling:
1. Open the phone or press and hold the key,
depending on your setting in the
Set active
menu.
2. At a voice prompt, say a name into the
microphone.
The phone recognises your command and
displays the result of searching.
Call functions
32
3. When you set the phone to display one best
result for your voice command in the
Result
display
menu, skip to step 4.
If you set the phone to display three best
results, say “No” until you hear the name you
want, or select the name you want from the
display and press the
Select
soft key.
4. Say “Yes” when the prompt confirms the name
you said.
The phone dials the corresponding number.
Pause dialling
When you call an automated system, like a banking
service, you are often required to enter a password
or an account number. Instead of manually entering
the numbers each time, you can store the numbers
in your Phonebook, separated by pauses.
Storing pauses in a Phonebook entry
To store a number in your Phonebook that contains
pauses:
1. Enter the phone number you want to store, such
as a bank’s teleservice phone number.
2. Press the
Pause
soft key to insert a pause. A “P”
displays, meaning that a hard pause will occur at
that point in the dialling sequence.
The “P” stops the dialling and waits for the
teleservice to prompt you for a number. The
number following the “P” is your account
number, PIN, etc.
Call functions
33
3. Enter the digits that need to follow the pause,
such as your account number.
4. Repeat steps 2 and 3 to add more pauses and
numbers, if necessary.
5. Store the number in your Phonebook as you
normally would by pressing the
Save
soft key
and following the procedure on page 88.
Pause dialling from a stored Phonebook
entry
1. Call the number from Phonebook.
2. Wait for the appropriate prompt from the
number you are calling.
3. When prompted, press the key to send the
DTMF (Dual Tone Multi Frequency) number that
follows your pause.
“SEND DTMF” flashes on the display and the
transmitted tone sounds.
Manual pause dialling
You can enter pauses manually during the dialling
process.
1. Enter the phone number of the service you want
to call, such as a bank’s teleservice phone
number.
2. Press the
Pause
soft key to insert a pause.
The screen displays a “P” indicating a pause.
3. Enter the number to be sent after the pause by
pressing the digit keys.
Call functions
34
4. Repeat steps 2 and 3 to add more pauses and
numbers, if necessary.
5. Press the key.
6. After connecting, wait for the prompt from
teleservice. Press the key again after the
prompt to send the additional number(s).
Adjusting the volume during a call
During a call, if you want to adjust the voice
volume, use the Volume keys on the left side of the
phone.
Press the key to increase the volume level and
the key to decrease the level. The image on the
display shows all 5 levels; the more bars you see,
the higher the level is.
In Standby mode, you can also adjust the key tone
volume using these keys.
Call functions
35
Answering a call
When somebody calls you, the phone rings and
displays an incoming call image.
If the caller can be identified, the caller’s phone
number or name, if stored in Phonebook, displays.
There are many ways to answer a call, depending
on your setting in the
Answer mode
menu (
Menu
9-1
).
To end the call, press the key or close the
phone.
Note
: You can answer a call while using Phonebook or
menu features. The current operation stops.
Silencing the call ringer
You can silence the ringer when a call comes.
Press the
Silent
soft key or either of the Volume
keys.
Setting option To answer the call,
By send key press the key.
By folder open open the phone. If it is
already open, press the
key.
By any key open the phone or press any
key except the soft keys,
Volume keys, or the key.
Call functions
36
Rejecting a call
To reject an incoming call, press the
Reject
soft key
or the key. Press and hold either of the Volume
keys on the left side of the phone.
Note
: You can set up the list of numbers from which
you want to reject calls automatically in the
Call reject
menu (
Menu 1-8
). For details,
see page 84.
Viewing missed calls
If you are unable to answer a call for any reason,
the phone indicates a missed call by displaying a
text notification on the screen. Additionally, if caller
information is available, the screen displays the
phone number of the last missed call.
When the display informs you of the missed call,
press the key to call the displayed number, or
the key to clear the message and return to
Standby mode.
To view the list of the missed calls, see “Missed” on
page 79.
Call functions
37
Options during a call
Your phone provides a number of functions that you
can use during a call.
Using the In-call options
Press the
Menu
soft key during a call to access the
following options:
Mute/Quit
: allows you to switch off your phone’s
microphone, so that the other person cannot hear
you.
Example: You wish to say something to another
person in the room, but do not want the other
person to hear you.
Calls
: allows you to access the
Calls
menu (
Menu
1
). See page 79.
Phonebook
: allows you to access the
Phonebook
menu (
Menu 2
). See page 85.
Silent/Quit
: does not transmit the DTMF (Dual-
Tone Multi-Frequency) tones of the keys. It allows
you to press keys without hearing annoying key
tones during a call.
Send my
#
: sends your phone number to the
calling person or automated services.
DTMF length
: manipulates the audible DTMF
tones. You can choose either
Long
or
Normal
.
Noise cancellation
: activates or deactivates the
noise cancellation feature. This feature removes
noise from your surroundings so that the other
person on the phone can hear you more clearly.
Note
: You can quickly activate or deactivate this
feature by pressing the MP3 key during a call.
Call functions
38
Recording your call conversation
You can record your conversation during a call.
Press and hold the Camera/Voice memo key to start
recording. You can access the recorded
conversation in the
Voice memo
menu (
Menu 8-
9-2
).
Call forwarding
When you enable the
Call forward
menu (
Menu
1-5
), your phone forwards incoming calls to
another phone number, even when your phone is
turned off.
Activating this feature does not affect outgoing calls
made from the phone. For further details, see
page 82.
Call waiting
When the
Call waiting
menu (
Menu 1-6
) is
enabled, you can answer an incoming call while you
have a call in progress. For further details, see
page 83.
When a waiting call is detected, the incoming call
alerts sounds, depending on your network, and a
text notification displays.
To answer a waiting call:
1. To answer the call, press the key. The phone
connects the calling person, and places the
current call on hold.
Call functions
39
2. Press the key again to switch between the
two calls.
3. To end the call, press the key or close the
phone. All of the calls are disconnected.
Three-way calling
This feature enables you to conduct conference calls
with two separate people at the same time. The
phone records both calls in the Outgoing calls log.
You are billed airtime for each of the outgoing calls
separately. Contact your service provider to activate
Three-way Calling.
To make a three-way call:
1. During a conversation, enter the phone number
for the third person and press the key.
2. When the third person answers, press the
key again to begin your three-way call.
During a three-way call, if one of the callers hangs
up, you and the remaining caller will stay
connected. If you initiated the call and you hang up
first, all calls are disconnected.
40
Entering text
At many times when using your phone, you will
need to enter text; for example, when storing a
name in Phonebook, writing a text message, or
scheduling events in your calendar. You can enter
alphanumeric characters into your phone by using
your phone’s keypad.
Your phone has the following text input modes:
•
Pinyin
: allows you to enter a Chinese character
using its Pinyin spelling, which is a phonetic
system.
•
Stroke
: allows you to a Chinese character using
the individual strokes labelled on the keys.
•
123
: allows you to enter numbers.
•
Symbol
: allows you to enter many different
symbols and punctuation marks.
•
ABC
: allows you to enter English characters by
pressing the key labelled with the character you
want until it displays.
•
T9 word
: allows you to enter English characters
with only one keypress per character.
Note
: Pinyin, Stroke, and T9 word modes use the T9
input method. T9 mode automatically compares
your keypresses to an internal linguistic
database to determine the correct word.
Entering text
41
Changing the text input mode
Example: Writing a text message
1. In the text entry screen, press the
Mode
soft
key.
2. Scroll to the mode you want by pressing the
Navigation keys.
Note
: If you want to exit the Mode list without
changing to a new mode, press the
C
key.
You can change between
T9 word
and
ABC
modes to enter English words and choose
Pinyin
or
Stroke
to enter Chinese characters.
To include symbols or numbers,
Symbol
and
123
modes are also available.
3. Press the
Select
soft key to select the
highlighted mode.
You will find the selected text input mode
indicator on the display.
Note
: Depending on your particular UIM card, the
maximum number of characters you can
enter may differ.
Text input mode
indicator
Entering text
42
Using Chinese Pinyin mode
Pinyin is a system to write the pronunciation of a
Chinese word using the Latin alphabet. With the
Pinyin input method, you can enter Chinese
characters by keying in the Pinyin string using the
phone’s keypad. The phone automatically presents
the matching words.
This mode allows you to enter Pinyin characters
with only one key per letter.
Typing characters in Pinyin mode
1. Press the keys corresponding to the phonetic
spelling, referring to the letters printed on the
keys. Notice that the choices in the character
selection field change.
Example: Typing “ ” in Pinyin mode
You can press the Left or Right key to select
other pinyins for your keypresses.
Pinyin input field
Press the
6
key and
4
keys to enter “ni.”
The character selection field
Entering text
43
2. If you cannot find the character you want from
the display, press the Up or Down key to scroll
through the choices in the character selection
field.
When the character you are typing appears, you
may select it, without completing the Pinyin
spelling.
3. To select a character, press the
1
key to activate
the character selection field. A number from 1 to
6 is added to the beginning of a corresponding
character. When the character selection field is
activated, a normal press on the
1
to
6
keys
selects the corresponding character.
Note
: You can deactivate the character selection field
by pressing the
C
key.
Press the
1
key to select “ .”
Entering text
44
Using the tones
You can enter another character assigning a tone
for the selected Pinyin. Entering a tone for a
character is optional, but it is especially useful if the
Pinyin spelling is similar for several characters.
1. Press the keys corresponding to the letter you
need.
For example, to get “mi,” press the
6
and
4
keys. The screen shows “ni,” “mi,” and “ng.”
2. Press the key until the tone you want
displays.
Note
: You can delete a previously entered tone by
pressing the
C
key.
Press the
6
and
4
keys.
Press the
Right key.
Character sets for the
Pinyin “mi” with the
third tone.
Press the
key for the
tone.
Alternative Pinyin
by pressing the
6
and
4
keys.
Entering text
45
3. If you cannot find the character you want from
the display, press the Up or Down key to scroll
through choices in the character selection field.
4. When you find the character you want to enter,
press a key from the
1
to
6
keys, corresponding
to the character.
Rapid character entry
Rapid character entry is easy in any mode, using
the character selection field. As you enter
characters, your phone predicts the next character
you might want and presents choices in the
character selection field.
For example, when you type the word “zhong guo
( ),” enter the first character using the following
keystrokes; the
9
,
4
,
6
,
6
,
1
, and
1
keys. You do
not have to complete the Pinyin spelling to include
“guo ( ).” With no extra typing, the letter displays
conveniently in the character selection field for you
to choose.
Scrolling
To move the cursor to the left or right through your
text message, press the Left or Right key when the
character selection field is not activated.
Inserting a space
Insert a space between characters, press the key
in the text area.
Entering text
46
Clearing strokes and characters
Press the
C
key once or repeatedly to remove
strokes one by one to the left. Once the Pinyin input
field is empty, pressing the
C
key removes a letter
from the text area.
To clear all of the strokes and characters on the
display, press and hold the
C
key.
Using Chinese Stroke mode
This mode allows you to enter individual Chinese
strokes, in written order, from top to bottom, and
from left to right.
Even though there are many different strokes used
to create Chinese characters, the strokes are
classified into 5 basic categories; heng, shu, pie,
dian, and zhe. The basic strokes are printed on keys
from the
1
to
5
keys on the keypad.
To enter a stroke, press the key printed with the
stroke that most closely represents the exact stroke
you want. The table shows the stroke/key
relationship:
Entering text
47
Typing strokes and characters in Stroke
mode
1. To type a character, press the keys
corresponding to its component strokes. Press
keys in the order that you would write the
strokes, using one press per stroke.
Example: Typing “ ” in Stroke mode
2. The phone displays your strokes in the key
stroke input field and offers character choices in
the character selection field. As you enter
strokes, notice that the choices in the character
selection field change.
To scroll through the choices, press the Up or
Down key.
Note
: If you are uncertain of the order of one or more
strokes, press the
6
key in place of each
questionable stroke. Continue entering strokes
until the character displays in the character
selection field or until you finish the character.
The character selection field.
To select “ ,” press the
7
key.
Key stroke input field.
Press the
5
key to enter
“,” then the
3
key to
enter “ .”
Entering text
48
3. When the character you are typing appears in
the character selection field, you may select it
without finishing the stroke sequence for the
character. Characters displayed correspond to
keys from the
7
to key on the keypad. To
select a character and add it to your message,
press the corresponding key from the
7
to
key.
Rapid character entry
Rapid character entry is easy in any mode, using
the character selection field. As you enter
characters, your phone predicts the next character
you might want and presents choices in the
character selection field.
For example, try typing the characters “zhong guo
( )” using the following keystrokes; the
2
,
8
,
and
7
keys. Even though “guo ( )” is the twelve
stroke character pair, your phone allows you to
enter it in only three key presses.
Scrolling
To move the cursor to the left or right through your
text, press the Left or Right key.
Clearing strokes and characters
Press the
C
key once or repeatedly to remove
strokes one by one to the left. Once the key stroke
input field is empty, pressing the
C
key removes a
letter from the text area.
To clear all of the strokes and characters on the
display, press and hold the
C
key.
Entering text
49
Using 123 mode
123 mode enables you to enter numbers. Press the
keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to enter symbols.
Press the Left or Right key to display more symbols.
Press the keys corresponding to the symbol you
want.
Using ABC mode
When typing in ABC mode, you should press the
key labelled with the letter you want:
- once for the first letter
- twice for the second letter
- and so on.
This method is called Multi-tap typing.
For example, you need to press the
2
key three
times quickly to display the letter “C” and the
5
key
two times quickly to display the letter “K.”
The cursor moves to the right when you press a
different key. When entering the same letter twice
or a different letter on the same key, just wait for
about 1 second, and enter the next letter.
Entering text
50
Refer to the table below for the list of characters
assigned to each key.
(Caps Lock mode)
Changing the letter-case
To shift the case of the next letter(s) that you type,
press the key. There are three cases:
•
Abc
: Initial Capital
•
abc
: Lower Case
•
ABC
: Capitals Lock
Inserting a space
Press the key to insert a space between words.
Including a number
You can quickly include a number between letters.
Press and hold the corresponding number key.
Key Characters in the order displayed
1
2
3
4
5
6
7
8
9
0
. @ – _ / : ~ ? , 1 ;
'
( ) ! #
% & * < >
+
=
"
\ { } $ [ ]
ABC2
DEF3
GHI4
JKL5
MNO6
P Q R S 7
TUV8
W X Y Z 9
0
Entering text
51
Scrolling
To move the cursor to the left or right through your
text message, press the Navigation keys.
Clearing letters and words
Press the
C
key once or repeatedly to clear letters
one by one to the left. Press and hold the
C
key to
erase all of the letters on the display.
Using T9 Word mode
To type a word, press the keys corresponding to the
letters you need. Remember the following as you
are typing:
1. Press keys on the phone just once per letter.
For example, to enter “Hello,” press the
4
,
3
,
5
,
5
, and
6
keys.
2. The word you are typing appears on the display.
It may change with each keypress.
3. Type to the end of the word before editing or
deleting any keystrokes.
If the word doesn’t display correctly, press the
0
key once or repeatedly to display alternative
word choices for the keys you have pressed.
For example, both “of” and “me” have the
sequence of the
6
and
3
keys. The phone
displays the most commonly used choice first.
Entering text
52
4. Insert a space between words by pressing the
key.
To type words not found in T9 Word mode, you need
to change the text input mode to ABC mode.
Changing the letter-case
To shift the case of the next letter(s) that you type,
press the key. There are three cases:
•
T9 Word
: Initial Capital
•
T9 word
: Lower Case
•
T9 WORD
: Capitals Lock
Including a number
You can include a number between letters without
exiting T9 Word mode. Press and hold the
corresponding number key.
Scrolling
To move the cursor to the left or right through your
text, press the Navigation keys.
Clearing letters and words
Press the
C
key once or repeatedly to clear letters
one by one to the left. Press and hold the
C
key to
erase all of the letters on the display.
53
Using the menus
The phone offers a range of functions that allows
you to tailor it to your needs. These functions are
arranged in menus and submenus. They can be
accessed by scrolling or using the shortcuts.
You can set up a menu of your favourite features so
that you can quickly access the menus you use
frequently.
Accessing a menu function by
scrolling
1. In Standby mode, press the
Menu
soft key to
access Menu mode.
2. Scroll using the Navigation keys to reach a main
menu, for example,
Display
. Press the
Select
soft key to enter the menu.
3. Find the menu option you want, for example,
/
Language
, by scrolling using the Up or
Down key. Press the
Select
soft key to enter the
menu option.
If the menu you have selected contains
submenus, repeat this step.
4. Scroll using the Navigation keys to select the
setting of your choice.
5. Press the
Save
soft key to confirm the chosen
setting.
Notes
:
• To return to the previous menu level, press the
C
key.
• You can exit the menu without changing the menu
settings by pressing the key.
Using the menus
54
Using shortcuts
The menu items, such as menus, submenus, and
setting options, are numbered and can be accessed
quickly by using their shortcut numbers.
Note
: The numbers assigned to each menu function
are indicated on the list on page 56.
1. In Standby mode, press the
Menu
soft key to
access Menu mode.
2. Enter the first digit of the shortcut number.
Repeat this for each digit of the shortcut
number.
Example: Changing the display language
Press the
4
and
7
keys.
4
enters
Display
, and
7
selects /
Language
.
3. Scroll using the Navigation keys to select the
setting of your choice.
4. Press the
Save
soft key to confirm the chosen
setting.
Accessing favourite features
You can set up a menu of your own using your
favourite menu items, which can then be accessed
by specific number keys. Once you have set up your
favourites, you can easily and quickly access them.
Using the menus
55
Setting up favourite item access
1. In Standby mode, press and hold the
Menu
soft
key.
2. Select a location and press the
Menu
soft key.
3. Select
Register
and press the
Select
soft key.
4. Scroll to the menu you want and press the
Regist
soft key.
5. Select an icon for the item by pressing the
Navigation keys, and press the
Save
soft key.
Accessing a favourite item
1. In Standby mode, press and hold the
Menu
soft
key.
2. Scroll to the item you want and press the
Select
soft key.
You can also press the number key
corresponding to the item you want to access.
On the list of favourite items, press the
Menu
soft
key to access the following options:
Register
: allows you to assign a favourite menu to
an empty location or exchange the assigned menu
for another.
Delete
: deactivates the assignment to the selected
location.
Delete all
: deactivates all of the assignments.
Change icon
: allows you to change the item icon.
Change order
: allows you to move the item to the
position you want.
Using the menus
56
List of menu functions
The following list shows the menu structure and
indicates the number assigned to each option.
1. Calls
(see page 79)
1.1 Missed
1.2 Incoming
1.3 Outgoing
1.4 Air time
1.4.1 Last call
1.4.2 Total
1.4.3 Erase total
1.4.4 Life time
1.5 Call forward
1.5.1 Busy
1.5.2 No answer
1.5.3 Busy/No answer
1.5.4 Unconditional
1.6 Call waiting
1.7 Area code
1.7.1 Domestic
1.7.2 International
1.8 Call reject
2. Phonebook
(see page 85)
2.1 Find
2.2 Add
2.3 Group setting
2.4 Speed dial
2.5 Name card
2.5.1 Send a card
2.5.2 Name card book
2.6 My phone #
2.7 Memory info
Using the menus
57
3. Camera
(see page 98)
3.1 Take photo
3.2 My album
3.3 Photo studio
3.3.1 Wizard effect
3.3.2 Basic effect
3.3.3 Decoration
3.3.4 Photo sticker
3.3.5 Video capture
3.3.6 Composition
3.3.7 Revision
3.3.8 Flip
3.3.9 Text composition
3.4 Settings
3.4.1 Sound
3.4.2 Long camera key
3.4.3 Reset
3.4.4 Auto save
3.4.5 Album lock
4. Display
(see page 115)
4.1 Image box
4.2.1. Opening
4.2.2 Closing
4.2.3 Wallpaper
4.2 Banner
4.3 Backlight
4.4 Menu style
4.5 Set time
4.6 External clock
4.7 /Language
4.8 Dialing font
Using the menus
58
5. Message
(see page 119)
5.1 New message
5.2 Inbox
5.2.1 Phone
5.2.2 Card
5.2.3 Voice mail
5.2.4 Web alert
5.3 Outbox
5.3.1 Phone
5.3.2 Card
5.4 Msg setup
5.4.1 Scroll timer
5.4.2 Msg. reminder
5.4.3 Alert on call
5.4.4 Canned msg.
5.4.5 New message
5.5 Msg wallpaper
5.6 Memory info
6. Sounds
(see page 127)
6.1 Ringer
6.2 Ringer vol./Type
6.2.1 Voice calls
6.2.2 Message
6.2.3 Alarm
6.2.4 Scheduler
6.3 Key tone
6.4 Alert
6.4.1 Function alert
6.4.2 Hour alert
Using the menus
59
7. Entertainment
(see page 132)
7.1 3D game
7.2 MP3
7.2.1 MP3 player
7.2.2 My files
7.2.3 MP3 settings
7.3 VOD
7.3.1 VOD files
7.3.2 Connect to server
7.3.3 Settings
7.4 Melody composer
7.4.1 Compose melody
7.4.2 My melodies
7.5 Karaoke
7.6 Fun club
7.7 Samsung messenger
7.7.1 Messenger
7.7.2 History
7.7.3 Settings
8. Utilities
(see page 150)
8.1 Calendar
8.2 Alarm
8.3 User memory
8.3.1 Connect to PC
8.3.2 File manager
8.3.3 Memory info
8.3.4 Format
8.4 I.Beam
8.4.1 Remote control
8.4.2 File transfer
8.5 Mini dictionary
8.6 Calculator
8.7 Today
8.8 To do list
8.9 Voice tools
8.9.1 Voice dialing
8.9.2 Voice memo
8.0 World time
8.
Countdown
8.
Memo pad
Using the menus
60
9. Settings
(see page 171)
9.1 Answer mode
9.2 Roam option
9.3 Security
9.3.1 Phone lock
9.3.2 Change lock
9.3.3 Emergency #
9.3.4 Voice privacy
9.3.5 Restriction
9.3.6 GPS settings
9.3.7 Clear memory
9.3.8 Reset phone
9.3.9 Card setup
9.4 Entry method
9.5 Data option
9.6 Domains preset
9.7 Contents status
9.7.1 Total
9.7.2 Program
9.7.3 Melody
9.7.4 Image
9.7.5 VOD
9.8 Rotation mode
61
uni
This menu is supplied by your service provider. The
contents available in each menu option may be
different depending on the service provided. For
further details, contact your service provider.
Note
: You can quickly access this menu by pressing
the key in Standby mode.
Wap
Your phone comes equipped with a WAP (Wireless
Application Protocol) browser which makes it
possible for you to access the Wireless Web.
Selecting the
Wap
menu launches the WAP browser
and accesses the homepage of your service
provider.
Navigating the WAP browser
To Press the
scroll through
browser items
Navigation keys. You can scroll
by one page using the Volume
keys.
select an item soft key.
return to the
previous screen
C
key.
return to the
homepage
C
key.
uni
62
Entering text in the WAP browser
You can enter text in the WAP browser as you would
in normal phone mode.
For details about entering text in each mode, see
page 40.
Using the browser menu options
While navigating the web sites, you can use various
options.
To access the Browser Menu list, press the
Menu
soft key and select
Menu
. Then press the left soft
key to access the following options:
Home
: takes you back at any time to the
homepage of the WAP service provider.
History
: shows the records of your connection to
the wireless web.
Bookmarks
: shows the Bookmarks list.
PUSH Message
: shows the WAP push messages
received from the server.
Reload
: refreshes the current web page with
updated information.
Go To URL
: allows you to manually enter the URL
address of a web page. After entering an address,
select
Go
and press the soft key.
Snapshots
: takes a snapshot for the current web
page.
Save Items
: saves images on the current WAP
page.
uni
63
Show URL
: displays the URL address of the site
where you are currently connected.
Exit
: exits the WAP browser and returns to Standby
mode.
Advanced...
: provides you with the further
options.
Restart Browser: restarts the WAP browser without
exiting it.
Delete Cookies: deletes all of cookies and files. A
cookie is a piece of user’s information that is
entered when you use a website.
Homepage: allows you to change the startup
homepage. If you clears the URL, the default
homepage is restored.
Multimedia: enables or disables auto download of
the media objects, such as images or background
sound on the current page.
Scroll Mode: lets you select the scroll mode to
either
Block
or
Smooth
, or set the speed for
scrolling to the next screen to either
Fast
,
Medium
, or
Slow
.
Send Referrer: allows you to set the browser to
send HTTP referrer information to the web server
each time the browser is launched.
Connection Timeout: allows you to set how long the
phone keeps connection to the current web page
when you don’t use the web page for a specified
period. You can select
30Seconds
or
60Seconds
.
Key Press Timeout: allows you to set the keypress
speed for the cursor to move to the right in the text
entry mode. You can select
Fast
,
Medium
, or
Slow
. If you don’t want to set the timeout, select
OFF
.
uni
64
Security: displays all security-related information,
such as Secure Prompt, Authentication, and Current
Certificate.
Restore default value: allows you to restore the
default settings for the advanced feature.
Send Link
: allows you to send the URL address of
the current web page as a new e-mail.
Clear Memory
: clears information stored in the
History list, the cache, and Auto Fill form, and
cookies.
About ...
: provides you with information about
Openwave and your version of the WAP browser.
Mail
In this menu, you can use the uni-Mail service,
which allows you to send or receive e-mail
messages containing media items, such as images,
sounds, name cards, applications, photos, and SMIL
files.
Notes
:
• You can quickly access the
Mail
menu by pressing
the Left key in Standby mode.
• You can also switch to the
Message
menu (
Menu
5
) or the
Camera
menu (
Menu 3
) by pressing the
SMS
soft key or the
Camera
soft key, respectively.
New Mail
In this menu, you can create a new e-mail and send
it to one or multiple destinations.
1. When the To field highlights, press the
Edit
soft
key ( ).
uni
65
2. Press the
Edit
soft key ( ) again.
3. Enter a destination and press the
Ok
soft key.
4. If you want to send the e-mail to more than one
person, repeat steps 2 and 3.
Alternatively, on the Recipient List screen, you
can press the
Menu
soft key to access the
following options:
•
Addr Book
: allows you to find an e-mail
address stored in your Phonebook.
•
Sent History
: allows you to find an e-mail
address in the list of the e-mails to which you
have sent e-mails.
•
Addr Group
: allows you to bring up a list of
your caller groups. You can select a caller
group to access the e-mail address of a
member of that group.
•
Profiles
: enters your e-mail address
automatically.
•
Delete
: allows you to delete the recipient.
This option is available only when an e-mail
address is selected.
•
Move to To
: changes the selected address to
a To address. This option displays when you
have selected a Cc or Bcc address.
•
Move to Cc
: changes the selected address to
a Cc address. This option displays when you
have selected a To or Bcc address.
•
Move to Bcc
: changes the selected address to
a Bcc address. This option displays when you
have selected a To or Cc address.
uni
66
5. Press the
OK
soft key to return to the New Mail
screen.
6. Press the Down key to access the subject line
and press the
Edit
soft key ( ).
7. Enter the subject of your e-mail and press the
Ok
soft key.
8. Press the Down key and press the
Edit
soft key
( ) to attach files. The following options are
available:
•
Select Attach
: allows you to add an image, a
sound, a name card, an application, a photo,
or a video clip.
In each folder, select items by pressing the
Select
soft key, press the
Menu
soft key, and
then select
Add
. After selecting items, press
the
Attach
soft key to attach them to your
e-mail.
•
Select SMIL Attach
: allows you to add an
SMIL file. For more information about SMIL
files, see page 71.
•
Edit SMIL
: allows you to create and edit an
SMIL file.
9. Press the Down key to access the body of your
e-mail and press the
Edit
soft key ( ).
10. Write a mail text and press the
Ok
soft key.
Note
: When you attach an SIML file, you are
unable to write an e-mail.
11. Press the
Send
soft key.
Note
: You can save the e-mail you created by
pressing the
Menu
soft key and selecting
Save
as New
.
uni
67
Inbox
This mail box is used to store e-mails that you have
received.
Received e-mails are saved in the
Folder0
folder by
default. If you set filters (see page 68), a new e-
mail will be saved in the folder containing the filter
that corresponds the sender’s address.
When you enter this menu, the list of the folders in
which incoming e-mails are stored displays.
Viewing a received e-mail
1. Select a folder using the Up or Down key and
press the
OK
soft key ( ).
2. Scroll through the e-mail list within the folder
and press the
Disp
soft key when you find the
e-mail you want.
Items attached to the e-mail will display.
Using e-mail options
While viewing an e-mail, you can access the
following options by pressing the
Menu
soft key
().
Reply
: allows you to send a reply to the sender.
Reply All
: allows you to send a reply to all other
recipients of the e-mail, including the sender.
3.
To Press the
scroll through the
items
Pre
soft key or the
Next
soft key.
view the body of
the e-mail
OK
soft key ( ).
uni
68
Forward
: allows you to forward the e-mail to other
destinations.
Protect
: locks the e-mail to keep it from being
deleted.
Delete
: allows you to delete the e-mail.
Move to Folder
: allows you to move the e-mail to
another folder.
Show Full Addr
: shows the addresses of all
recipients of the e-mail.
Copy Mail Body
: copies the text of the e-mail. You
can paste the copied text when writing a new
e-mail.
Managing a mail folder
Your phone provides you with up to 10 mail folders
to manage your mail. You can change the folder
names or delete folders. You can also use the mail
filter feature to group your mails.
Scroll to the folder you want and press the
Menu
soft key. The following options are available:
Add Filter
: allows you to set a filter, which
arranges incoming e-mails by senders’ addresses,
for the current folder.
Edit Folder Name
: changes the folder name.
Re-Filter
: allows you to arrange immediately
incoming e-mails, according to the filter set for the
current folder.
Delete All
: deletes all of the e-mails stored in the
selected folder.
Reset Folder
: restores the default settings of the
selected folder.
uni
69
Send Box
This mail box is used to store e-mails that you have
sent or tried to send.
When you enter this menu, a list of e-mails in the
box displays, along with the time and date the
e-mails were sent, the recipients’ e-mail addresses,
and the subjects of the e-mails.
Viewing a sent e-mail
1. Scroll through the list and press the
Disp
soft
key ( ) to view the message.
Using e-mail options
On the list or mail view screen, you can access the
following options by pressing the
Menu
soft key.
Depending on the screen you are viewing, available
options vary:
Edit
: edits the currently selected e-mail.
Protect ON/OFF
: prevents the selected e-mail
from being deleted.
Delete
: deletes the currently selected e-mail.
2.
To Press the
scroll through the
items
Up
or Down key.
extract the selected
e-mail address
Select
soft key.
copy the e-mail
Copy
soft key.
view the attached
item
Play
soft key.
resend the e-mail
Send
soft key.
uni
70
Sort
: allows you to change the sort order of the
e-mail list.
Show Full Addr
: shows the addresses of all
recipients of the e-mail.
Copy Mail Body
: copies the selected text of the
e-mail. You can paste the copied text when writing
a new e-mail.
1-ln/3-ln View
: allows you to choose to display
the whole the time and date, the recipient’s e-mail
address, and the mail subject (3-line view mode) or
to display only one of them (1-line view mode). In
1-in View mode, you can change the item to be
displayed on the list by pressing the
Chg
soft key.
Check New Mail
In this menu, you can check the uni-Mail server for
new incoming e-mails and then retrieve new
e-mails, if you have, from the server.
Data Folder
In this menu, you can view downloaded and saved
contents. The files are stored in separate folders
according to data type, e.g.,
for images or
Audio
for audio clips.
Scroll through the folders until you find the one you
want. Press the
Select
soft key. The content list
displays, and you can:
• Press the
Menu
soft key to access the following
options:
Auto-Play
: shows the items stored in the
currently selected folder as a slide show. This
option is available only when you select an
image folder, such as Image, Singleshot, or
Serialshot.
uni
71
Erase
: erases the currently selected item.
Erase all
: erases all of the items stored in the
selected folder.
• Press the
Play
soft key to view the selected item.
SMIL Editor
In this menu, you can create a new SMIL file, which
is a combination of an image, text, and a sound
clip, and then send it to other people by attaching it
to an e-mail.
Creating a new SMIL file
1. When
New SMIL
highlights, press the
OK
soft
key ( ).
2. When
Add New SLIDE
highlights, press the
Edit
soft key ( ).
3. When the Image field is selected, press the
Edit
soft key ( ).
4. Select the source image category you want and
press the
Select
soft key.
5. Select the image you want and press the
OK
soft key.
6. Press the Down key to move to the Text field
and press the
Edit
soft key ( ).
7. Enter a message and press the
Ok
soft key.
8. Press the Down key to move to the Audio field
and press the
Edit
(
)
soft key.
9. Select a sound and press the
Select
soft key.
uni
72
10. Press the
OK
soft key.
11. To add more slides, repeat steps 2 to 10.
You can add up to 5 slides for an SMIL file.
12. When you have finished, press the
OK
soft key
to save the SMIL file.
Using SMIL slide options
You can use the following options by pressing the
Menu
soft key in the Image, Text, or Audio field on
a slide. Some options are available only when an
item has been added.
Set Start
: allows you to set the time delay before
the currently selected item displays when you open
the slide.
Set End
: allows you to set the length of time the
currently selected item will be displayed before the
next item automatically displays.
Layout
: shows you the layout for your SMIL slide.
Preview
: shows the SMIL file you have created.
Delete Image
/
Text
/
Audio
: allows you to delete
the image, text, or sound.
When more than one slide is added, select one of
them and press the
Menu
soft key to access the
following options:
SLIDE During
: allows you to set how long one
slide of the received message displays on the
message presentation screen. After a specified
time, the display automatically scrolls to the next
slide.
uni
73
SLIDE Move
: allows you to move the selected slide
to the position you want.
SLIDE Delete
: allows you to delete the selected
slide.
Editing SMIL files
1. Select
Open SMIL
from the SMIL Editor screen,
and press the
OK
soft key ( ).
2. Scroll to the SMIL file you want to edit and press
the
OK
soft key twice.
3. On the SLIDE List screen, press the Down key to
select the slide you want.
4. Press the
Edit
(
)
soft key.
5. Follow the procedure from step 3 on page 71 to
change the items on the slide.
Mail Settings
In this menu, you can configure various e-mail
settings that are required when you send or receive
e-mails.
Receiving & View
: allows you to change the
settings that control how e-mails are received and
viewed. The following options are available:
Auto-Rcving: you can set whether or not your
phone automatically retrieves new e-mails from
your Mail server.
Rcving Type: you can select which part of e-mails
you want to retrieve, such as the subject, sender’s
address, and body of the mail.
uni
74
Receive Atchmnt: you can set whether or not the
phone retrieves e-mails with their attachments.
Play Atchmnt: you can set whether or not the phone
first displays attached files in an e-mail and then
shows you the body of the e-mail, or shows the
body first.
Show Folders: you can set whether or not the
phone displays mail folders. When this option is set
to
OFF
, the phone shows you the list of the e-mails
you have received without mail folders.
Font Size: you can select the mail font size, either
Small
or
Large
.
Send & New Mail
: allows you to change the
settings that control how e-mails are created and
sent. The following options are available:
Quote Original: you can set whether or not the
phone includes the original mail in a reply e-mail.
Addr Group: you can add a new relation group or
change the name of a group. You can also delete a
group.
Encoding Type: You can select an encoding type,
either
GB-2312
or
UTF-8
.
Del Sent History: you can delete the list of the
e-mail addresses to which you have sent e-mails.
Register Account
: allows you to register your
e-mail account to the uni-Mail server or delete your
account from the server.
Others
: allows you to access the web site preset by
your service provider to manage your uni-Mail
service.
uni
75
View Mail Settings
: shows you the current mail
settings.
About
: shows you the software version and
copyright information of your uni-Mail service.
Magic
In this menu, you can use various Brew
applications. On the main screen of the menu, there
are 4 default applications available:
•
MobileShop
: allows you to buy and download
Brew applications from the WAP browser.
•
igogo
: takes you to the homepage of your
service provider.
•
Settings
: allows you to change the application
settings and to check the memory status.
•
Help
: gives you help for using applications.
Downloading multimedia files
1. Press the key when the
MobileShop
icon is
selected.
The following options are available:
•
Catalog
: allows you to browse and purchase
items.
•
Search
: allows you to search for an
application by entering a keyword.
•
Help
: provides you with the help information
about using the
MobileShop
menu.
uni
76
2. Press the key when the
Catalog
option is
selected.
You are accessed to the associated web site
preset by your service provider and you can
browse the available applications.
3. Select the application you want to download and
follow the instructions on the screen.
Downloaded applications will display on the
main screen of the
uni-Magic
menu.
Accessing the igogo
When you select the
igogo
icon, you can go to the
homepage of the WAP service provided by your
service provider. You can access various contents
and services.
Changing the browser settings
1. On the U-Magic main screen, select the
Settings
icon by pressing the Left or Right key
and press the key.
2. Select a setting option by using the Up or Down
key and press the key.
The following options are available:
•
Order Apps
: allows you to change the order
of the downloaded applications.
•
Move Apps
: allows you to move an
application to the other folder.
•
Manage Apps
: shows the amount of the
memory used for downloaded applications.
uni
77
•
Main Menu View
: allows you to change the
view mode of the main menu screen.
•
Screen Savers
: allows you to activate the
Screen Saver application, if downloaded.
•
View Log
: shows the records of your
browsing.
3. When you are finished, press the
C
key or the
key.
Viewing help information
1. On the uni-Magic screen, select the
Help
icon by
pressing the Left or Right key and press the
key.
2. Select a help item by using the Up or Down key
and press the key.
3. To go back to the main help screen, press the
key.
Channel
This menu allows you to access the VOD server
directly. You can view and download a variety of
video files via the VOD server.
You can also access the same web page by selecting
the
Connect to server
menu (
Menu 7-3-2
).
uni
78
Map
In this menu, you can use a location service based
on GPS positioning technology. With this service,
you can easily find friends, gas stations,
restaurants, and other locations.
For further details, contact your service provider.
Info
This menu is available only when you use a UTK
UIM card that provides additional services. For
further details, see your UTK UIM card instructions.
79
Calls
You can use the
Calls
menu to:
• view and dial the most recent missed, incoming,
or outgoing numbers.
• view the duration of calls.
• set the phone to receive the second call or to
forward incoming calls to a preset number.
• find area or country codes for dialling.
• set up the list of numbers to reject calls from
them.
Missed
(Menu 1-1)
If Caller Line Identification is available, your phone
keeps a list the most recent incoming calls that you
have failed to answer. Contact your service provider
for the availability.
1. Press the Up or Down key to find a number or
name, if saved in Phonebook.
On the call list, you can access the following
options by pressing the
Menu
soft key:
•
Erase
: allows you to erase the currently
selected call.
•
Erase all
: allows you to erase all of calls.
2. Press the
Select
soft key to select the
highlighted number.
Details about the call display.
Calls
80
When viewing an entry, press the
Menu
soft key to
access the following options:
Talk
: dials the currently selected number.
Save
: allows you to save the number in
Phonebook.
View phonebook
: allows you to view the
phonebook entry for the number, if stored in
Phonebook.
Edit
: allows you to add an area code or feature
code to the number before calling the number.
Erase
: allows you to erase the currently selected
number.
Send msg
: allows you to send a text message to
the currently selected number.
Mail
: allows you to send an e-mail to the currently
selected number.
Incoming
(Menu 1-2)
This menu lets you view the most recent calls you
have received. If Caller Line Identification is
available, you can also view the number of the
caller; contact your service provider for its
availability.
When you access this menu, a list of the incoming
calls displays. For further details, see “Missed” on
page 79.
3.
To Press the
place a call key.
view other calls Navigation keys.
Calls
81
Outgoing
(Menu 1-3)
The phone stores the most recent calls you have
dialled.
When you access this menu, a list of the outgoing
calls displays. For further details, see “Missed” on
page 79.
Air time
(Menu 1-4)
Your phone records the amount of air time, or talk
time, used. Using this option, you can view the
number of the calls to or from your phone and the
air time for all calls. You can easily erase the air
time record at any time.
Note
: This feature is not intended to be used for
billing purposes.
The following options are available:
Last call
: shows the air time of the last call.
Total
: shows the number of all voice calls and data
calls you have made to or from your phone and the
total duration of the each call since the air time
counter was last set to zero by using the
Erase
total
option.
Erase total
: erases the “Total” air time
measurement and resets the air time counter. When
a confirmation message displays, press the
Yes
soft
key.
Life time
: shows the number and total duration of
all calls you have made to or from your phone since
the phone was shipped from the factory.
Calls
82
Call forward
(Menu 1-5)
This network service allows incoming calls to be
forwarded to another number.
To set your forwarding options:
1. Select the type of call forwarding and press the
Select
soft key.
The following options are available:
•
Busy
: calls are forwarded if you are already on
the phone.
•
No answer
: calls are forwarded if you do not
answer the phone.
•
Busy/No answer
: calls are forwarded if you
are already on the phone or do not answer.
•
Unconditional
: all of the calls are forwarded
although the phone is switched off.
2. Select
Enable
and press the
Save
soft key.
3. Enter the phone number you want to forward
and press the
Send
soft key.
Once Call Forwarding has been enabled, a text
notification appears to inform you that your call will
be diverted, each time a call is forwarded or you
switch on the phone.
To deactivate a call forward setting:
1. Select the call forwarding option.
2. Select
Disable
and press the
Save
soft key.
The phone sends your setting to your network.
Calls
83
Call waiting
(Menu 1-6)
The call waiting feature alerts you of incoming calls
while you are on a call.
To enable the feature, select
Enable
by using the
Navigation keys and press the
Save
soft key. When
this feature is enabled, you can respond to an
incoming call by pressing the key while you are
on a call. This puts the first caller on hold and
answers the second call. To switch to the first caller,
press the key again.
Note
: If you press the key or close the phone, all
calls are disconnected.
To disable, select
Disable
and press the
Save
soft
key.
Area code
(Menu 1-7)
Your phone provides you with various area codes for
domestic areas and other countries to let you
quickly and easily dial phone numbers.
To find an area code:
1. Select a code type,
Domestic
or
International
,
and press the
Select
soft key.
2. Select
By country
,
By province
or
By city
pressing the Left or Right key.
3. Find a country, province or city by entering its
name or by pressing the Up or Down key, and
press the
Dial
soft key.
Calls
84
4. If you have selected a country or province,
select one of the cities that belong to the
selected area and press the
Dial
soft key.
If you have selected a city, skip this step.
5. When the area code of the selected city appears
on the Dialling mode screen, enter the rest of
the phone number you want to dial.
6. Press the
Save
soft key to save the number in
your Phonebook as you would and follow the
procedure on page 88.
To dial the number, press the key.
Call reject
(Menu 1-8)
In this menu, you can make a list of the phone
numbers that you want to reject calls from them.
When you select this menu, a list of empty input
fields displays. Fill in each field with the numbers
you want; you can enter numbers manually or
retrieve entries from the Recent calls log,
Phonebook, or speed dial list.
85
Phonebook
You can store phone numbers and their
corresponding names in the memories of your card
and the phone. The card and phone’s memories,
although physically separate, are used as if they
were a single entity, called Phonebook.
Find
(Menu 2-1)
This menu allows you to find an entry using a
person’s name, group name, or memory location.
Note
: You can quickly access this menu by pressing
the
Find
soft key in Standby mode.
To change the finding method, press the Left or
Right key until the option you want to use displays;
By name
,
By group
,
or
By storage
.
Finding an entry by name
1. If necessary, press the Left or Right key to scroll
to
By name
.
When you select this method, the whole list of
all of the Phonebook entries appears in
alphabetical order.
2. Enter the first few letters of the name you want
to find and press the
OK
soft key.
Your phone highlights the first matching name.
3. If necessary, press the Up or Down key to scroll
through the entries.
Phonebook
86
4. When the entry you want highlights, choose one
of the following options:
• Press the key to place a call to the entry’s
primary number.
When the entry has more than one number,
the default is the Mobile number or the first
saved number.
• Press the
Menu
soft key to access the
following options:
-
Edit
: edits the entry’s phone number, name,
location number, and other information.
-
Erase
: erases the entry.
-
Erase multiple
: allows you to erase the
selected entry(ies).
-
Add new
: adds a new entry to Phonebook.
For more information on how to add a
number, see page 88.
-
To name card
: saves the entry as a name
card so that you can send it using the Mail
service. See page 64.
• Press the
OK
soft key to view information
about the entry.
Using Phonebook entry options
From the entry detail view, press the
Menu
soft key
to access the following options:
Note
: Depending on the selected items,
Menu
may
not display or available options vary.
Send msg.
: allows you to send a text message.
Send Email
: allows you to send an e-mail to the
selected e-mail address.
Talk
: dials the selected number.
Phonebook
87
Copy
: allows you to copy the number to another
memory location.
Speed dial
: allows you to set the currently selected
number as a speed dial entry. For further details,
see page 91.
Edit
: allows you to change the selected item.
Erase
: erases the entry. If you select a number
item, only the number is erased.
Finding an entry by group
1. Press the Left or Right key to scroll to
By group
.
When you select this method, a list of the
Phonebook entries in a group appears.
2. Press the Down key to move to the group
selection field.
3. Press the Left or Right key to scroll through the
groups.
Each time you select a group, a list of the
associated entries displays.
4. Follow from step 3 in “Finding an entry by name”
on page 85.
Finding an entry by storage
1. Press the Left or Right key to scroll to
By
storage
.
When you select this method, a list of the
Phonebook entries in the card appears.
2. Press the Down key to move to the memory
selection field.
Phonebook
88
3. Press the Left or Right key to select a memory,
Card
or
Phone
.
Each time you select a memory, a list of the
associated entries displays.
4. Follows from step 3 in “Finding an entry by
name” on page 85.
Add
(Menu 2-2)
This menu allows you to add a new entry to your
Phonebook.
Adding a new entry
In the phone’s memory, a name can contain up to 5
numbers in a different category; Mobile, Home,
Office, Pager, and Fax. You can save only one
number with a name on the UIM card.
1. When the name input box highlights, press the
Edit
soft key.
2. Enter a name and press the
OK
soft key.
For more information on how to enter
characters, see page 40.
3. Select a memory on the Storage field,
Card
or
Phone
, by pressing the Left or Right key.
4. If you have selected
Card
, press the Down key
and enter a phone number.
If you have selected
Phone
, change the settings
or enter more information, if necessary.
•
Mobile
/
Home
/
Office
/
Pager
/
Fax
: Add a
number for each category.
Phonebook
89
•
: Press the
Edit
soft key to assign one
of the photos you took using the camera or the
default icons as a caller ID image to be
displayed when you receive a call from the
selected number.
•
E-Mail1
/
E-Mail2
: Press the
Edit
soft key to
enter an e-mail address.
•
URL
: Press the
Edit
soft key to enter an URL
address.
•
Group
: Select one of the default relation
groups, where the entry is included by
pressing the Left or Right key. To change the
group settings, see page 90.
•
Ringer
: Press the
Edit
soft key and select a
unique ringer melody for the entry. By
selecting a different tone for each entry,
incoming voice calls having a caller ID can be
distinguished from those that do not.
•
ETC
: Press the
Edit
soft key to add a memo
about the person.
5. When you finish entering the contact
information of the entry, press the
Save
soft key
to save the entry.
After storing, the phone displays the memory
status of Phonebook for a few seconds.
Saving a phone number in Standby mode
1. In Standby mode, enter the number you want to
save.
2. Press the
Save
soft key.
3. Follow the procedure in “Adding a new entry” on
page 88.
Phonebook
90
Group setting
(Menu 2-3)
This menu allows you to add a new relation group
or change the name of a group. You can also delete
a group.
Adding a new group
1. When is highlighted, press the
Add
soft
key.
Alternatively, when a group is selected, press
the
Menu
soft key. Select
New
and press the
Select
soft key.
2. Enter the group name you want and press the
OK
soft key.
For further details about entering characters,
see page 40.
3. Press the Down key and select a ringer category
you want using the Left or Right key.
4. Press the Down key and select a ringer melody
for the group.
5. Press the
Play
soft key to play the ringer
melody and then press the
Save
soft key.
Changing group settings
Note
: You are unable to change the name of .
1. On the Group set list, select the group name you
want to change using the Up or Down key and
press the
Menu
soft key.
2. Select
Edit
and press the
Select
soft key.
3. Press and hold the
C
key to clear the old group
name, if necessary.
Phonebook
91
4. Enter a new group name and press the
OK
soft
key.
5. Press the Down key and select a ringer category
you want using the Left or Right key.
6. Press the Down key and select a ringer melody
for the group.
7. Press the
Play
soft key to play the ringer
melody and then press the
Save
soft key to
save the changes.
Erasing a group
1. On the Group set list, select the group you want
to erase by pressing the Up or Down key and
press the
Menu
soft key.
2. Select
Erase
and press the
Select
soft key.
3. Press the
Yes
soft key.
Speed dial
(Menu 2-4)
Once you have stored phone numbers in
Phonebook, you can set up to 99 speed dial entries
and then dial them easily whenever you want,
simply by pressing and holding the associated
number key(s) in Standby mode.
Setting up speed dial entries
1. Select
Empty
or
All
using the Left or Right key.
Empty
lists locations available for setting up
speed dial entries.
All
lists all of the locations.
Phonebook
92
2. Enter the location number you want or scroll to
the number you want using the Up or Down key.
Note
: Entering a number lists all of the location
number containing the entered number.
3. When the location number you want highlights,
press the
Add
soft key.
4. Select an entry from the Phonebook list and
press the
OK
soft key.
5. Select a number from the entry, if it has more
than one number.
6. Press the
OK
soft key to store the speed dial
entry.
Editing speed dial entries
1. Select
Stored
or
All
from the top line of the
entry list using the Left or Right key.
Stored
lists speed dial entries you have set up.
2. Enter the location number you want to view or
scroll to the location number you want using the
Up or Down key.
3. When the location number you want highlights,
press the
Menu
soft key to access the following
options:
•
Replace number
: allows you to assign a
different number to the location.
•
Delete
: allows you to clear the setting so that
no number is assigned to the location.
•
Delete all
: allows you to clear the settings for
all keys so that no numbers are assigned to
any of the locations.
4. When you have finished, press the key.
Phonebook
93
Name card
(Menu 2-5)
In this menu, you can create your name card and
send it to other phones using the Mail service.
You
can also send a Phonebook entry as a name card
format.
Send a card
(Menu 2-5-1)
You can send a name card from the Name card
book, which stores your name card and the name
cards you have saved, or an entry from Phonebook
as a name card.
Sending a name card from Name card book
1. Select
Name card book
and press the
Select
soft key.
2. Select the name card you want to send and
press the
Select
soft key.
3. Press the
Send
soft key.
The phone switches to the New Mail screen,
allowing you to create a new e-mail.
4. When the To field highlights, press the
Edit
soft
key ( ).
5. Press the
Edit
soft key (
)
again.
6. Enter a destination and press the
Ok
soft key.
7. If you want to send the message to more than
one person, repeat steps 5 and 6.
Alternatively, on the Recipient List screen, you
can press the
Menu
soft key to access the
following options:
Phonebook
94
•
Addr Book
: allows you to find an e-mail
address stored in your Phonebook.
•
Sent History
: allows you to find an e-mail
address in the list of the e-mail messages to
which you have sent e-mails.
•
Addr Group
: allows you to bring up a list of
your caller groups. You can select a caller
group to access the e-mail address of a
member of that group.
•
Profiles
: enters your e-mail address
automatically.
•
Delete
: allows you to delete the recipient.
This option is available only when an e-mail
address is selected.
•
Move to To
: changes the selected address to
a To address. This option displays when you
have selected a Cc or Bcc address.
•
Move to Cc
: changes the selected address to
a Cc address. This option displays when you
have selected a To or Bcc address.
•
Move to Bcc
: changes the selected address to
a Bcc address. This option displays when you
have selected a To or Cc address.
8. Press the
OK
soft key to return to the New Mail
screen.
9. Press the Down key to access the Subject field
and press the
Edit
soft key ( ).
10. Enter the subject of your mail and press the
Ok
soft key.
11. Press the Down key and press the
Edit
soft key
( ) to attach more files.
Phonebook
95
12. Choose
Select Attach
and press the
OK
soft
key.
In each folder, select items by pressing the
Select
soft key, press the
Menu
soft key, and
then select
Add
. After selecting items, press
the
Attach
soft key to attach them to your e-
mail.
13. Press the Down key to access the body of your
e-mail and press the
Edit
soft key ( ).
14. Write a mail and press the
Ok
soft key.
15. Press the
Send
soft key.
Note
: You can save the e-mail you created by
pressing the
Menu
soft key and selecting
Save
as New
.
Sending a Phonebook entry
1. Select
Phonebook
from the
Send a card
menu
and press the
Select
soft key.
2. Select the Phonebook entry you want and press
the
OK
soft key.
For details about finding a Phonebook entry, see
page 85.
3. When information about the entry displays,
press the
OK
soft key.
The entry displays as a name card.
4. Press the
Send
soft key.
The phone switches to the New Mail screen,
allowing you to create a new e-mail.
5. Follow the procedure from step 4 on page 93.
Phonebook
96
Note
:
After sending, the phone automatically saves
the sent name card to the Name card book
as
Send a card.vcf
.
Name card book
(Menu 2-5-2)
In this menu, you can create and edit your name
card. You can also access the name cards you have
saved and the last name card you sent.
Creating your name card
1. When
Send a card.vcf
highlights, press the
Select
soft key.
2. Press the
Option
soft key, select
Edit
, and press
the
Select
soft key.
3. Create your name card as you would when
storing a phone number.
For further details about storing a number, see
page 88.
4. Press the
Save
soft key to save your name card.
Viewing a name card
Select the name card you want to view from the
Name card book list.
While viewing a name card, press the
Option
soft
key to access the following options:
Edit
: allows you to edit the currently selected name
card.
Send
: sends the currently selected name card as
part of an e-mail.
Phonebook
97
Add to phonebook
: saves the name card as a
Phonebook entry.
Erase
: allows you to erase the currently selected
name card. This option is only shown for the name
cards you have sent.
My phone #
(Menu 2-6)
This menu shows your phone number.
To change the phone number:
1. Press the
Edit
soft key when the number
displays.
2. Enter a new phone number and press the
Save
soft key to save it.
Memory info
(Menu 2-7)
In this menu, you can check how many entries are
stored in Phonebook, both on the card and in the
phone’s memory.
The display shows you the numbers of Total, Used,
and Free locations for Phone and Card. Press the
Navigation keys to switch back and forth between
Phone and Card information.
98
Camera
Using the camera module built into your phone, you
can take photos of people or events while on the
move. You can send photos to other people using a
message or set photos as a wallpaper image, or an
opening or closing image.
You can also record a video by using your phone as
a camcorder.
Note
: You can quickly access this menu by pressing
the Camera/Voice memo key on the right side
of the phone in Standby mode.
CAUTION
:
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are not
allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
Take photo
(Menu 3-1)
In this menu, you can take a photo in a single
image or multi-shot. You can also record a video
clip. The camera produces JPEG photos and mp4
video clips.
Notes
:
• When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
• Depending on the currently selected camera mode,
available options may vary.
Camera
99
You can rotate the display to view a wider image, as
shown below.
Note
: Depending on the setting in the
Rotation
mode
menu (
Menu 9-8
), rotating the display
will turn on the camera from any screen. For
details, see page 180.
Taking a photo
1. Accessing the
Take photo
menu turns on the
camera. You can also press and hold the
Camera/Voice memo key on the right side of the
phone in Standby mode.
The image to be captured appears on the
display.
2. Adjust the image by rotating the camera and
aiming it at the subject.
You can use the camera options by pressing the
left soft key. For details, see page 100.
You can change the image settings by using the
keypad. For details, see page 101.
3. Press the right soft key or the Camera/Voice
memo key to take a photo.
When you are taking serial shot images, the
camera takes photos successively.
Camera
100
4. Press the
Save
soft key to save the photo(s).
To discard the photo(s) and go back to Capture
mode, press the
Cancel
soft key or the
C
key.
The phone saves the photo(s) in the
My album
folder (
Menu 3-2
) and returns to Capture mode.
Using camera options in Capture mode
When you press the left soft key in Capture mode,
you can access the following options for the current
shot. Scroll to an option by pressing the Left or
Right key and change the setting by pressing the
Up or Down key.
Mode
: allows you to change the camera mode. The
following modes are available:
Single shot ( ): allows you to take a single photo.
Serial shot ( ): allows you to take a series of
action stills.
Divided shot ( ): allows you to take several stills
and save as a single image consisting of the
multiple stills taken.
Video cam ( ): allows you to record a video.
Mail ( ): allows you to take a single photo then
send the photo as an e-mail.
Size/Quality
: allows you to select an image size
and quality.
White balance
:
allows you to adjust the colour
balance of the photo to remove the current lighting
conditions add. With the setting, you can make your
photo appears warmer or cooler.
Self timer
: allows you to set a time delay before
the camera takes a photo.
Camera
101
Frame
: allows you to use a decorated frame.
Preview layout
: allows you to select a display
style in Capture mode.
Icons ( ): allows you to view the full screen with
the available option icons.
No icons ( ): allows you to view the full screen
without icons.
Guideline ( ): allows you to view the display as a
grid line.
Quick view
: goes to the
My album
folder
(
Menu
3-2
).
Using the keys in Capture mode
You can use the keypad to customise your camera
settings when you are in Capture mode.
Key Functions
Left/Right zooms in or out.
Up/Down changes the image brightness.
flips the image vertically.
shows the mirror image.
1
changes the camera mode.
2
switches the display between the full
screen view with icons ( ), no icon
view ( ), and guideline view ( ).
3
selects a time delay. This key is only
available in the icon view and actual
ratio view.
0
goes to the
My album
folder (
Menu
3-2
).
Camera
102
Recording a video
1. On the Capture screen, press the
1
key
repeatedly until the icon appears to switch to
Record mode.
The image to be captured appears on the
display.
2. Adjust the image by rotating the camera and
aiming it at the subject.
You can use the following keys to customise the
image settings.
Pressing the
Menu
soft key shows you the
current camcorder settings. To change the
settings, see the next sections.
Key Function
Left/Right zooms in or out.
Up/Down changes the image brightness.
flips the image vertically.
shows the mirror image.
1
changes the camera mode.
2
switches the display between the
full screen view with icons ( ), no
icon view ( ), and guideline view
().
3
selects a time delay.
0
goes to the
My album
folder
(
Menu 3-2
).
Camera
103
3. Press the right soft key or the Camera/Voice
memo key to start recording.
4. When you are finished, press the right soft key
or the Camera/Voice memo key again.
Otherwise, the phone will automatically stop
when the recording time expires.
5. Press the
Save
soft key.
The phone saves the video clip in the
My album
folder (
Menu 3-2
) and returns to Record mode.
Using options in Record mode
When you press the
Menu
soft key in Record mode,
you can access the following options for the current
recording. Scroll to an option by pressing the Left or
Right key and change the setting by pressing the
Up or Down key.
Mode
: allows you to change the camera mode. The
following modes are available:
Single shot ( ): allows you to take a single photo.
Serial shot ( ): allows you to take a series of
action stills.
Divided shot ( ): allows you to take several stills
and save as a single image consisting of the
multiple stills taken.
Video cam ( ): allows you to record a video.
Mail ( ): allows you to take a single photo then
send the photo as an e-mail.
Camera
104
Size/Quality
: allows you to select an image size
and quality.
White balance
:
allows you to adjust the colour
balance of the video to remove the current lighting
conditions add. With the setting, you can make your
video clip appears warmer or cooler.
Self timer
: allows you to set a time delay before
the camera records a video.
Preview layout
: allows you to select a display
style in Record mode.
Icons ( ): allows you to view the full screen with
the available option icons.
No icons ( ): allows you to view the full screen
without icons.
Guideline ( ): allows you to view the display as a
grid line.
Voice record
: allows you to select whether or not
the camcorder records voice while recording a
video.
Quick view
: goes to the
My album
folder
(
Menu
3-2
).
Camera
105
My album
(Menu 3-2)
In this menu, you can review the photos you have
taken and the videos you have recorded.
Viewing a photo
1. Select
Single
or
Multi
by pressing the Left or
Right key.
2. Enter the name of the photo or scroll to the
photo you want to view using the Up or Down
key.
Viewing a video
1. Select
Vcam
from the top line of the file list by
pressing the Left or Right key.
2. Enter the name of the video clip or scroll to the
video clip you want to view using the Up or
Down key.
3.
To Press the
access the options
Option
soft key. For
further details about the
options, see the next
sections.
view the image on
the full screen
Expand
soft key.
view thumbnail
images
Multi
soft key.
Camera
106
3. Press the
Select
soft key to play the video you
selected.
You can also press the
Option
soft key. For
further details, see the next sections.
Using album options
When you press the
Option
soft key on the file list,
you can access the following options:
Send photo mail
: allows you to send the file as
part of an e-mail. This option is only available for
photos. For details, see page 64.
Photo studio
: allows you to access the
studio
menu (
Menu 3-3
). This option is only
available for photos. For details, see page 107.
Set wallpaper
: allows you to set the file as your
wallpaper for the idle screen, or opening or closing
image.
4.
To Press the
pause or resume key.
stop
STOP
soft key.
skip forward Right key.
skip backward Left key.
view the file list Down key.
adjust the volume Volume keys.
set the video clip as
your wallpaper or
view the file info
MENU
soft key, and
select
Set wallpaper
or
File Info
option,
respectively.
Camera
107
Set phonebook
: allows you to set the file as a
caller ID image for a Phonebook entry. This option
is only available for photos.
Rename
: allows you to change the file name.
Note
: When you change a file name, do not use the
special characters, such as /, \, ?, <, >, and so
on.
File info
: allows you to view information about the
file.
Lock
: allows you to lock the file so that other
people cannot access it without your lock code.
Locked items are indicated by the
icon on the file
list.
Erase
: allows you to erase the currently selected
file.
Erase all
: allows you to erase all of the files.
Photo studio
(Menu 3-3)
Photo studio is a great tool for dealing with photos.
Using this feature, you can edit photos through
applying a special effect, resizing, conversion, and
adding comments.
Wizard effect
(Menu 3-3-1)
You can apply a special effect to a photo.
1. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
Camera
108
2. Press the Left or Right key to select a effect.
You can compare the changed photo with the
original by pressing the
Compare
soft key.
3. Press the
Save
soft key.
4. Enter a name for the photo and press the
OK
soft key.
Basic effect
(Menu 3-3-2)
You can change the colour tone of a new photo or
saved photo.
1. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
2. Press the Left or Right key to select a effect.
You can compare the changed photo with the
original by pressing the
Compare
soft key.
3. Press the
Save
soft key.
4. Enter a name for the photo and press the
OK
soft key.
Decoration
(Menu 3-3-3)
You can use a decorative frame, clip, or photo
sticker with a photo. You can also add text to the
photo.
1. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
Camera
109
2. Press the
Option
soft key to access the
following editing options:
•
Fun frame
: allows you to select a decorative
frame using the Navigation keys.
•
Clip
: allows you to select a clip and move it to
the position you want by pressing the
Navigation keys.
•
Photo sticker
: allows you to select a photo
sticker. For further details about making a
sticker, see page 110.
•
Text
: allows you to enter text. After entering
text, you can change the font style of the text
or font colour.
•
Pen
: allows you to add a drawing to the photo.
After changing the thickness and colour of the
drawn line(s), and the brightness of the colour,
press the
Select
soft key. To move the pen,
press the Navigation keys and draw using the
number keys.
Note
: Press the
Help
soft key to view the
details about moving and drawing a pen.
3. After adding decoration components, press the
Save
soft key.
4. Enter a name for the photo and press the
OK
soft key.
Camera
110
Photo sticker
(Menu 3-3-4)
You can cut a part of a photo and save the copy of
the photo as a sticker.
1. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
2. Select a sticker shape by pressing the Left or
Right key and press the
Select
soft key.
3. Change the sticker size by pressing the Left or
Right key and press the
Next
soft key.
4. Press the Navigation keys to move the sticker to
the part you want and press the
Save
soft key.
Video capture
(Menu 3-3-5)
You can save a part of the video clip as a photo.
1. Select a video clip from the
My album
folder
and press the
Select
soft key.
2. When the part of the video clip you want to
capture appears, press the
Capture
soft key.
The still image of the video clip displays.
3. Press the
Save
soft key.
4. Enter a name of the captured image and press
the
OK
soft key.
Camera
111
Composition
(Menu 3-3-6)
You can combine one photo with another photo so
that you can make a new photo.
1. Press the
Open
soft key on the Main field.
2. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
3. Press the
Open
soft key on the background
field.
4. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
5. Press the
OK
soft key to combine the two
photos.
6. Press the Left or Right key to adjust the
brightness and press the
Save
soft key.
7. Enter a name of the photo and press the
OK
soft
key.
Revision
(Menu 3-3-7)
You can change the image properties of a photo,
such as the sharpness, brightness, hue, or blur.
1. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
2. Press the
Option
soft key to access the
following options:
Camera
112
•
Sharpness
: allows you to adjust the image
sharpness. Increasing the sharpness makes
the image appear more focus.
•
Brightness
: allows you to adjust the
brightness of the image.
•
Hue
: allows you to change the colour tone of
the image.
•
Blur
: allows you to adjust of the clarity of the
image.
3. After changing the properties, press the
OK
soft
key.
You can compare the changed photo with the
original by pressing the
Compare
soft key.
4. Press the
Save
soft key to save the photo.
5. Enter a name of the photo and press the
OK
soft
key.
Flip
(Menu 3-3-8)
You can change the direction of a photo.
1. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
2. Press the Navigation keys to rotate or flip the
photo and press the
Save
soft key.
3. Enter a name of the photo and press the
OK
soft
key.
Camera
113
Text composition
(Menu 3-3-9)
You can extract text from a photo and add it to
another photo.
Note
: It may not be possible to extract text from non-
mono colour background photo.
1. Press the
Open
soft key on the Main field.
2. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
3. Press the
Open
soft key on the background
field.
4. Select
Saved photo
and select a photo from the
My album
folder, or select
New photo
and take
a new photo.
5. Press the
OK
soft key to combine the photo and
the text.
6. Press the
Save
soft key.
7. Enter a name of the photo and press the
OK
soft
key.
Camera
114
Settings
(Menu 3-4)
This menu allows you to change the default settings
for the options when using the camera.
The following options are available:
Sound
: allows you to select a sound when you
press the shutter, the right soft key or the Camera/
Voice memo key. Press the
Play
soft key to listen to
the highlighted key tone and press the
Save
soft
key.
Long camera key
: allows you to select a default
camera mode to be accessed when you press and
hold the Camera/Voice memo key.
Reset
: allows you to restore the default settings for
the camera options.
Auto save
: allows you to select whether or not the
phone automatically saves photos or videos.
Album lock
: allows you to lock photos and video
clips stored in the
My album
folder (
Menu 3-2
) so
that a person cannot view them without your
permission. Once you have locked the photos and
video clips, you need to enter the lock code each
time you access the
My album
folder.
115
Display
The display feature enables you to customise
various settings for the display and the backlight.
Image box
(Menu 4-1)
This menu allows you to change the background
image to be displayed in Standby mode or when the
phone is turned on or off. You can also select an
image when you have incoming calls.
To select an image:
1. Select an item you want and press the
Select
soft key.
The following options are available:
•
Opening
: allows you to select an image to be
displayed when you turn on the phone.
•
Closing
: allows you to select an image to be
displayed when you turn off the phone.
•
Wallpaper
: allows you to select an image or a
video to be displayed on the idle screen.
2. Select the image category you want and press
the
Select
soft key.
You can select one of the default images, ones
downloaded from the web, or photos you have
taken or video clips you have recorded.
3. Scroll through the images using the Navigation
keys.
4. Press the
Select
soft key when you find the
image you want.
Display
116
Banner
(Menu 4-2)
This menu allows you to set a banner message to
be displayed at the bottom of the display in Standby
mode.
To change the banner:
1. If necessary, press and hold the
C
key to clear
the old message.
2. Enter a new banner message using the
alphanumeric keys.
For more information about how to enter
characters, see page 40.
3. When you have finished entering the message,
press the
OK
soft key to save it.
Backlight
(Menu 4-3)
This menu allows you to select the length of time
the different display backlights remain on.
Main LCD
: allows you to select the length of time
the backlight for the main display stays on.
Sub LCD
: allows you to select whether or not the
backlight for the front display is on.
Menu type
(Menu 4-4)
In this menu, you can select the menu display style.
Choose either
33
or
Zoom
.
Display
117
Set time
(Menu 4-5)
This menu allows you to set the current time and
date or set up the time zones for the Dual Clock
wallpaper.
The following options are available:
Main clock
(Menu 4-5-1)
You can set the current time and date. When you
select this menu, the current settings, if set,
displays. In a service area, you don’t need to
change the time and date setting.
1. Enter the current time and date.
The month, day, hour, and minute must each be
entered using 2 digits and the year requires all 4
digits. You need to enter the hour in 24-hour
format.
2. When you finish, press the
Save
soft key.
Dual clock
(Menu 4-5-2)
You can choose two time zones to be displayed
when you select
Dual clock
for the wallpaper
image.
You can also set the Daylight Savings Time (DST)
for the selected time zones.
To select time zones for the dual clock:
1. Select the time zone for the top clock by
pressing the Left or Right key and press the
Down key.
Display
118
2. Select the time zone for the bottom clock by
pressing the Left or Right key.
3. Press the
Save
soft key.
Note
: You can apply the daylight savings time for
each clock. When a clock highlights, press the
DST off
soft key.
External clock
(Menu 4-6)
This menu allows you to change the type of clock to
be displayed on the external display in Standby
mode.
You can select one of 3 externall clocks.
/Language
(Menu 4-7)
You can change the language of the menu display.
Select either or
English
.
Dialing font
(Menu 4-8)
In this menu, you can select the colour type of the
font for digits to be displayed when you enter a
phone number for dialling, either
Rainbow
or
Black
.
119
Message
Your phone can receive voice mail messages, SMS
(Short Message Service) messages, and web
messages from your web server. Your phone can
also send text messages if your system supplier
provides this service.
Incoming messages are received even when your
phone is in Lock mode. To access the message, you
need to unlock the phone.
Note
: You can quickly switch to the
Mail
menu by
pressing the
Mail
soft key in this menu.
New message
(Menu 5-1)
You can create short text messages and send them
to multiple mobile phones.
1. Enter the message contents.
For more information on how to enter
characters, see page 40.
When you press the
Mode
soft key, you can
select
Canned msg.
to use one of 20 canned
messages or
Domains
to quickly enter a
domain name extension. For details about
canned messages and domain extensions, see
page 125 and page 179 respectively.
2. Press the
OK
soft key.
3. If necessary, press the Down key to set up the
following options:
•
Priority
: allows you to set the priority level of
the message from
Normal
,
Interactive
,
Urgent
, or
Emergency
.
Message
120
•
Ack
: allows you to activate or deactivate the
delivery acknowledgement feature. When this
feature is activated, the network informs you
when your message is delivered to the
recipient.
•
Save
: allows you to select one of the following
saving options:
Save & Send: allows you to save a copy of the
message and then send the message to the
required destination. You can read the
message in your Outbox.
Send only: allows you to send the message.
The message will be deleted after sending.
Save only: allows you to save the message so
that it can be sent later. You can read the
message in your Outbox.
4. Press the
Save
soft key.
5. Enter a phone number.
If you press the
Find
soft key, you can search a
number from the Recent calls list, Phonebook, or
speed dial list. For further details, see page 30
and 85 respectively.
6. To send the message to multiple destinations,
press the Down key and enter another number.
Repeat this step to add more destinations. You
can send the message to up to 10 destinations
at one time.
7. When you finish entering the numbers, press the
OK
soft key to send or save the message.
Message
121
Inbox
(Menu 5-2)
Your phone can store SMS messages and their
corresponding caller ID in your card and phone’s
memories. If your memory is full, the screen
displays a text notification and rejects additional
incoming messages until you erase the obsolete
ones.
Text messages
When the phone receives a text message, the New
Text Message icon ( ) and a text notification with
the call back number appear. Press the
Select
soft
key to view the message immediately, or the
Back
soft key to view the message later from the Inbox.
When you access the
Phone
menu (
Menu 5-2-1
)
or the
Card
menu (
Menu 5-2-2
), a list of the
received message displays. An icon displayed on
the list means the message’s status:
• : displays when you haven’t read the
message.
• : displays when you have read the message.
Note
: The red icon means that the message is urgent.
The icon next to the message icon means
that the message is stored on the card memory.
While viewing the message list, press the Up or
Down key to scroll to a message and:
• Press the
View
soft key to view the message you
selected. The phone displays the contents. If
necessary, press the Up or Down key to scan
through the message.
While viewing a message, press the
Option
soft
key to access the following options:
Message
122
Erase
: erases the currently selected message
from your Inbox.
Reply
: allows you to send a reply message to the
sender.
Forward
: allows you to send the message to
other people.
Call/Save
: shows the sender’s number of the
message. Press the key to make a call to the
sender’s phone number. Press the
Save
soft key
to save it.
Move to phone
(
card
): allows you to move the
message to the card or phone’s memory.
Copy to phone
(
card
): allows you to copy the
message to the card or phone’s memory.
• Press the
Option
soft key to access the following
options:
Erase
: allows you to erase the currently selected
message.
Erase multi
: allows you to erase the messages
you selected by pressing the
Check
soft key.
Erase all
: allows you to erase all messages on
the current list.
Voice messages
When you receive a voice mail message, the New
Voice Mail icon ( ) and a text notification
displays. Press the key, and the phone dials the
voice mail centre. Then follow the voice prompts
from the system to listen to the message.
You can also check your voice messages by
accessing the
Voice mail
menu (
Menu 5-2-3
).
For further details about the voice mail service and
its availability, contact your service provider.
Message
123
Web alert messages
When you select the
Web alert
menu (
Menu 5-2-
4
), the phone accesses your Alert Inbox on the WAP
browser, so that you can view a web message from
your web server. For details about reading a web
message, see “Text messages” on page 121.
Outbox
(Menu 5-3)
Your phone can store your outgoing SMS messages
in the card and phone’s memories.
When you access the
Phone
menu (
Menu 5-3-1
)
or the
Card
menu (
Menu 5-3-2
), you can see the
sent message list. An icon displayed on the list
means the message’s status:
• : indicates that the message was successfully
delivered.
• : indicates that the message was not sent.
Note
: The red icon means that the message is urgent.
The icon next to the message icon means
that the message is stored on the UIM card.
While viewing the message list, press the Up or
Down key to scroll to a message and:
• Press the
View
soft key to view the message you
want. The display shows the contents along with
the destination number. If necessary, press the
Up or Down key to scan through the message.
While viewing a message, press the
Option
soft
key to access the following options:
Erase
: erases the currently selected message
from your Outbox.
Resend
: allows you to resend the message to
the same recipient.
Message
124
Edit
: allows you to edit the message.
Call/Save
: shows the recipient’s number of the
message. Press the key to make a call to the
recipient’s phone number. Press the
Save
soft
key to save it.
Move to phone
(
card
): allows you to move the
message to the card or phone’s memory.
Copy to phone
(
card
): allows you to copy the
message to the card or phone’s memory.
• Press the
Option
soft key to access the following
options:
Erase
: allows you to erase the currently selected
message.
Erase multi
: allows you to erase the messages
you selected by pressing the
Check
soft key.
Erase all
: allows you to erase all messages on
the current list.
Msg setup
(Menu 5-4)
Using this menu, you can set up various options for
receiving or sending messages.
Scroll timer
(Menu 5-4-1)
If an incoming message is too long for the display,
the phone scrolls the screen automatically. You can
set the time interval in which the phone scrolls to
the next screen, 1 through 5 seconds.
When this option is set to
Off
, you need to manually
scroll to the next screen using the Up or Down key.
Message
125
Msg. reminder
(Menu 5-4-2)
When a message is received, your phone alerts you
by sounding a specified ringer. If you don’t check
the message, the phone will remind you of it. You
can set how often this will happen.
Off
: The phone does not remind you.
Once
: The phone reminds you only once.
Every 2 min
: The phone reminds you every 2
minutes.
Alert on call
(Menu 5-4-3)
This menu allows you to choose whether or not the
phone informs you when you receive a new
message during a call.
The following options are available:
On
: the phone alerts you with a beep and displays
the corresponding notification during a call.
Off
: the phone alerts you after ending a call.
Canned msg.
(Menu 5-4-4)
You can preset a maximum of 20 messages that
you most frequently use and retrieve them when
writing a message.
1. Select an empty location or the message you
want to change and press the
Select
soft key.
2. Enter a message and press the
OK
soft key to
save it.
Message
126
New message
(Menu 5-4-5)
You can set up the following options as default
settings for sending a new message:
Priority
: allows you to set the priority level of
messages from
Normal
,
Interactive
,
Urgent
, or
Emergency
.
Delivery ack
: allows you to activate or deactivate
the delivery acknowledgement feature. When this
feature is activated, the network informs you when
your message is delivered to the recipient.
Msg wallpaper
(Menu 5-5)
In this menu, you can select a background image to
be displayed on the Message screen so that
recipient can view messages with the image.
Memory info
(Menu 5-6)
You can view how many messages can be saved
and currently stored on the card and in the phone’s
memory.
Press the Navigation keys to switch back and forth
between Card and Phone information.
127
Sounds
You can use this menu to customise various sound
settings, such as the ringers, key tones, and alert
sounds.
Ringer
(Menu 6-1)
In this menu, you can set the unique ringer
melodies for calls, messages, and alarms.
To select a ringer melody:
1. Select the item you want using the Left or Right
key. The following options are available:
•
Voice calls
: allows you to select a ringer for
incoming calls.
•
Messages
: allows you to select a ringer for
incoming messages.
•
Alarm1
/
2
: allows you to select a ringer for
alarm settings.
•
Scheduler
: allows you to select a ringer for
scheduler alarms.
2. Press the Down key.
3. Select the ringer category you want using Left or
Right key and press the Down key.
You can select a ringer category containing
melodies downloaded from the wireless web or
using the PC link programme and MP3 music.
For
Messages
, skip this step.
Sounds
128
4. Select a melody and press the
Play
soft key to
listen to the selected melody.
Note
: You can listen to the selected melody in
Silent mode.
5. When you select the ringer melody you want,
press the
Save
soft key.
You can erase downloaded items by pressing the
Menu
soft key and selecting
Erase
.
Ringer vol./Type
(Menu 6-2)
In this menu, you can adjust the ringer volume or
change the ringer type for calls, messages, alarms
and scheduler.
1. Select the item for which you want to adjust the
ringer volume.
If you have selected
Voice calls
, select
Volume
or
Type
.
2. Select a volume level or ringer type. The
following items are available:
•
Level 1
~
5
: Select one of the volume levels.
•
Ringer only
: The phone sounds the ringer
selected in the
Ringer
menu.
•
Silent
: The phone nor vibrates or rings.
•
1 Beep
: The phone sound a beep.
•
Vibration
: The phone vibrates.
•
Vib. & ringer
: The phone vibrates and rings
at the same time.
•
Vib. then ringer
: The phone vibrates and
then rings.
Sounds
129
•
Ringer then vib.
: The phone rings and then
vibrates.
Note
: Depending on the selected ringer item,
available options may differ.
3. When you are finished, press the
Save
soft key
to save the selected ringer type.
For a volume level, press the
Play
soft key to
listen to the selected volume and press the
OK
soft key.
Key tone
(Menu 6-3)
This menu allows you to select a type of key tones
that the keypad generates each time you press a
key. Press the
Play
soft key to listen to the
highlighted key tone and press the
Save
soft key.
You can adjust key tone volume in Standby mode
by using volume keys.
Alert
(Menu 6-4)
This menu allows you to select an alert tone and
turn on or off each alert.
The following options are available:
Function alert
(Menu 6-4-1)
Your phone gives audible alerts (beeps) at a
specified time to inform you that certain things
have happened.
Sounds
130
The following options are available:
Themes
: allows you to select a alert tone.
Press the
Play
soft key to listen to the highlighted
key tone and press the
Save
soft key.
Alert on/off
: You can turn each alert on or off. To
use an alert, press the Check soft key to place a
check mark.
The following alerts are available:
Select/Saving: When this alert is selected, the
phone sounds an alert when you save your selection
or change a menu function.
Cancel/Warning: When this alert is selected, the
phone sounds an alert when you cancel your
selection or change when a confirmation message
appears.
Folder: When this alert is selected, the phone
sounds an alert when you open or close the phone.
Connect: When this alert is selected, the phone
sounds a connection tone when your call is
connected to the system.
Disconnect: When this alert is selected, the phone
sounds a disconnection tone when a call is
disconnected from the system.
Power on/off: when this alert is selected, the phone
sounds an alert when you turn on or off the phone.
Exit silent mode: When this alert is selected, the
phone sounds an alert when you exit Silent mode.
To turn on an alert:
1. Select an alert using the Navigation keys.
2. Press the
Check
soft key to place a check mark
in front of the alert you want to turn on.
Sounds
131
To remove the check mark, press the
Uncheck
soft key.
3. To select more alerts, repeat steps 1 and 2.
4. When you finished, press the
Save
soft key.
Hour alert
(Menu 6-4-2)
You can set your phone to sound an alert every
hour on the hour.
1. Select
On
using the Left or Right key and press
the Down key.
2. Enter the time period when the phone uses the
hour alert and press the Down key.
3. Select an alert tone using the Left or Right key.
4. Press the
Play
soft key to play the highlighted
alert tone.
5. Press the
Save
soft key.
132
Entertainment
Using the
Entertainment
menu, you can enjoy
using your phone. You can also watch VOD, listen to
MP3 music, and sing along with the files
downloaded.
3D game
(Menu 7-1)
In this menu, you can enjoy 3D games using your
phone. For further information about each games,
refer to the Help option.
MP3
(Menu 7-2)
Your phone provides you with the MP3 Player
function to enable you to enjoy MP3 music on the
phone.
Note
: You can quickly access this menu by pressing
the MP3 key on the right side of the phone in
Standby mode.
Copying MP3 music files
You need to download music files from the wireless
web, or from your computer by connecting the
phone to it using a USB cable.
For further details about connecting the phone to a
PC, see page 154.
Entertainment
133
MP3 player
(Menu 7-2-1)
You can play MP3 music files stored in your phone.
Notes
:
• You can play MP3 files by connecting a headset to the
phone in Silent mode.
• While playing MP3 files, the phone informs you of
incomming messages by vibrating, regardless of the
ringer type setting.
Creating a play list
Before playing MP3 music files, you need to add
them to the play list.
1. Access the
My files
menu (
Menu 7-2-2
).
The list of MP3 files stored in your phone
displays.
2. Scroll to the file you want to add to the play list
and press the
Add
soft key.
The selected music file is added to the play list.
3. Press the
C
key to return to the music file list.
4. To add more files to the play list, repeat steps 2
and 3.
5. To play the music files, press the
Play
soft key.
Entertainment
134
Playing MP3 music files
When you access the MP3 player menu, MP3 music
files play if the play list has been created. You can
access the following keys during playback:
Using MP3 player options
You can use MP3 player options when you press the
MENU
soft key on the MP3 player screen. The
following options are available:
Go to file list
: opens the file list.
Timer
: allows you to set the length of time the MP3
player is stays on. The timer appears to show you
the remaining time.
Set to ringer
: allows you to set the currently
selected file as your ringer for incoming calls or
alarm set, or schedule alarm.
Key Function
Plays or pauses a music file.
Up changes the repeat mode.
• : the current file repeats.
• : the files play in random order.
• : all of the files repeat.
Down opens the play list.
Left Goes back to the previous file. Moves
backward in a file when held down.
Right Skips to the next file. Skips forward in
a file when held down.
/ adjusts the volume.
A
–
B
Repeats a section of your choice.
Press this key begins a search for the
start point. To search for the end point,
press the
A
➞
B
soft key.
Entertainment
135
Visual effect
: allows you to change the equalizer
image on the MP3 player screen.
File info
: shows you information about the music
file.
Using the play list
If you want to alter the play list, you can open the
list by pressing the Down key on the MP3 player
screen.
Press the
Menu
soft key to access the following
options:
Add to play list
: allows you to add the file(s) from
the file list.
Remove
: allows you to remove the file(s) from the
play list.
Visual effect
: allows you to change the equalizer
image on the MP3 player screen.
Go to file list
: opens the file list.
File info
: shows you information about the music
file.
My files
(Menu 7-2-2)
In this menu, you can view the MP3 files stored in
your phone.
You can press the
Add
soft key to add an MP3 file to
the play list.
When you press the
Menu
soft key, you can access
the following options:
Open files
: opens and plays the selected music
file(s).
Entertainment
136
Add to play list
: allows you to add the selected
music file to the play list.
Rename
: allows you change the name of the
selected music file.
Note
: When you change a file name, do not use the
special characters, such as /, \, ?, <, >, and so on.
Sort
: allows you to change the order in which the
files are sorted.
File info
: shows you information about the selected
music file.
Set to ringer
: allows you to set the currently
selected file as your ringer for incoming calls, alarm
melody, or scheduler alarm melody.
Erase
: allows you to erase the selected music file.
Erase all
: allows you to erase all music files.
MP3 settings
(Menu 7-2-3)
In this menu, you can set up the use of the
backlight of the phone while playing MP3 files. The
following options are available:
Backlight
: allows you to change the length of time
setting for the backlight during playback.
Default: the backlight turns off after the period of
time specified in the
Backlight
menu (
Menu 4-3
).
Always on: the backlight does not turn off.
Entertainment
137
VOD
(Menu 7-3)
In the VOD (Video on demand) menu, you can
download video clips from the wireless web and
play them.
Note
: You can quickly access this menu by pressing
the Up key in Standby mode.
VOD files
(Menu 7-3-1)
When you access this menu, the list of downloaded
video files displays.
Note
: While playing VOD files, the phone informs you
of incomming calls or messages by vibrating,
regardless of the ringer type setting.
Playing video files
Scroll to a file and press the
Play
soft key. You can
access the following options during playback.
Key(s) Function
pauses or resumes play
.
Up changes the repeat mode.
• : the current file repeats.
• : the files play in random order.
• : all of the files repeat.
Down opens the file list.
Left Goes back to the previous file. Moves
backward in a file when held down.
Right Skips to the next file. Skips forward
in a file when held down.
/adjusts the volume.
STOP
stops play.
Entertainment
138
You can access media player options by pressing
the
Menu
soft key on the media player screen. The
following options are available:
Set to wallpaper
: allows you to set the file as your
wallpaper for the idle screen. This option is
available for video clips.
Set to ringer
: allows you to set the currently
selected file as your ringer for incoming calls. This
option is available for sound clips.
Visual effect
: allows you to change the equaliser
image on the media player screen. This option is
available for sound clips.
File info
: shows information about the video file.
Using video file options
You can access video file options by pressing the
Menu
soft key while viewing the video file list. The
following options are available:
Open files
: opens and plays the selected video
file(s).
Rename
: allows you to change the file name..
Note
: When you change a file name, do not use the
special characters, such as /, \, ?, <, >, and so
on.
File info
: shows information about the file.
Set to wallpaper
: allows you to set the file as your
wallpaper for the idle screen.
Erase
: allows you to erase the video file.
Erase all
: allows you to erase all video files.
Entertainment
139
Connect to server
(Menu 7-3-2)
Selecting this menu loads the web site preset by
your service provider for viewing and downloading
video files.
Settings
(Menu 7-3-3)
In this menu, you can set the time increments by
which each press of the Backward and Forward keys
moves through a file.
Note
: The keypress speed is an approximate value.
Melody composer
(Menu 7-4)
Melody composer is a great tool that allows you to
compose your own melodies using a variety of
musical components. You can set one of your
melodies as your call ringer.
Compose melody
(Menu 7-4-1)
When you access this menu, a stave screen displays
with a selection point at the first note position (Do).
Creating a melody
You can compose a melody of up to 10 pages and
you can insert 12 notes or rests onto a page.
1. Move the selection point up or down by pressing
the Up or Down key.
2. When you place the selection point correctly,
press the
Input
soft key.
Entertainment
140
3. Scroll to a note or rest and press the
Select
soft
key or press the corresponding number key to
insert it.
The note or rest is inserted onto the stave and
the selection point moves to the right on the
same line as the entered note or rest.
4. Repeat steps 1 to 3 to add more notes and rests.
Note
: You can also add the background melody,
change the tempo, or adjust the volume by
using the composer options. See the next
sections.
5. When you have completed your melody, press
the
Option
soft key to open the option list.
6. Select
Save
and press the
Select
soft key.
7. Enter a melody name and press the
OK
soft key.
Using composer options
While composing a melody, press the
Option
soft
key to access the following options:
New
: opens a new composer screen.
Open
: opens the list of your own melodies.
Play
: plays back the current melody.
Save
: saves the melody.
Save as
: allows you to save the melody as a
different name.
Instrument
: allows you to change the musical
instrument for the melody.
Entertainment
141
BGM
: allows you to use the background melody.
You can choose one of a variety of music genres,
such as Dance, Jazz, Latin, Pop, or Reggae.
Add note
: allows you to add notes in different
chord.
Tempo
: allows you to change the tempo for the
melody.
Volume
: allows you to adjust the volume level of
the main and background melodies separately.
Editing a melody
While composing a melody or after opening a saved
melody, you can edit it.
1. To change an entered note or rest, move the
selection point by pressing the Up or Down key.
2. Change the position of the note or type of the
note or rest the same as you would when
inserting it.
Press the or key to move a note to the next
semitone higher position or lower position.
You can access the following options by pressing
the
Option
soft key in Edit mode:
•
Range
: allows you to select more than one
note or rest by pressing the Left or Right key.
The selected ones are indicated in yellow.
•
Copy
: copies the selected note or rest.
•
Cut
: cuts the selected note or rest.
•
Paste
: pastes the selected note or rest to the
end of the melody.
Entertainment
142
•
Change
: allows you to change the type of the
currently selected note or rest.
•
Delete
: deletes the selected note or rest.
•
Play
: plays back the current melody.
3. After editing, press the Right key until the
selection point moves to an input position.
4. Press the
Option
soft key and select
Save
to
save the changes to the melody, or
Save as
to
save the melody as a different name.
My melodies
(Menu 7-4-2)
In this menu, you can view the list of the melodies
you have created.
Scroll to the melody you want to play and press the
Play
soft key.
You can access the following options by pressing the
Menu
soft key:
Set to ringer
: allows you to set the melody as your
call ringer, or alarm melodies.
Rename
: allows you change the name of the
selected melody.
Erase
: allows you to erase the selected melody.
Erase all
: allows you to erase all melodies.
View details
: shows the details about the selected
melody.
Entertainment
143
Karaoke
(Menu 7-5)
You can download karaoke files from the wireless
web and play and sing along with your files.
Note
: While playing files, the phone informs you of
incomming messages by vibrating, regardless
of the ringer type setting.
To p lay a son g:
1. Scroll to the song you want to play by pressing
the Up or Down key.
2. Press the
Play
soft key to play the file.
3. To return to Standby mode, press the key.
To erase a file from the phone’s memory:
1. Scroll to the file you want to play by pressing the
Up or Down key and press the
Menu
soft key.
2. Select
Erase
and press the
Select
soft key.
To delete all of the karaoke files, select
Erase
all
.
3. When a confirmation message displays, select
Yes
and press the
Save
soft key.
4.
To Press the
pause and resume left soft key.
adjust the volume Volume keys.
stop right soft key.
Entertainment
144
Fun club
(Menu 7-6)
You can access the Samsung Fun Club on the
Wireless Web and download various media items,
such as melodies and images.
Samsung Fun Club is the preset web site providing
Samsung phone users with attractive download
services. You can download:
• 4-level greyscale and color images from WAP.
• 64- or 72-polyphonic melodies from WAP.
•customer services.
• information and electronic catalogues for
Samsung Electronics products.
Samsung messenger
(Menu 7-7)
This feature allows you to have a conversation with
your friends, family, or co-workers by sending and
receiving instant messages.
Messenger
(Menu 7-7-1)
In this menu, you can start a conversation with a
person or with a group of people.
Before starting a conversation, you need to create a
buddy list of your messenger contacts.
Creating a buddy list
You can add contacts to your buddy list by entering
a name and number manually or by retrieving an
entry from Phonebook. You can also group your
contacts.
Entertainment
145
To add a contact to the buddy list:
1. On the Messenger screen, select and
press the
Select
soft key.
2. Press the
Add
soft key.
3. When a confirmation message appears, press
the
Yes
or
No
soft key.
4. If you press the
Yes
soft key, scroll to the entry
you want using the Up or Down key and press
the
Select
soft key.
If you press the
No
soft key, skip this step.
5. To enter a new name and number, press the
Edit
soft key.
If you have retrieved an entry from Phonebook
and want to use the current name and number,
skip to step 8.
6. Enter a new name, and press the
Ok
soft key.
7. Enter a number.
8. Press the
Save
soft key.
To add a group to the buddy list:
1. On the Messenger screen, press the
Add
soft
key.
2. Enter a group name and press the
Ok
soft key.
For further details about how to enter
characters, see page 40.
3. When the created group highlights, press the
Select
soft key.
4. To add entries to the group you want, follow
from steps 2 on page 145.
Entertainment
146
On the Messenger screen, select one of the groups
you have created and press the
Menu
soft key to
access the following options:
Add
: allows you to add a new messenger group.
Edit
: allows you to change the name of the
messenger group.
Erase
: allows you to erase the selected messenger
group.
Erase al
l: allows you to erase all messenger groups
you have created. The default groups are not
deleted.
Starting a conversation
Once you have created your buddy list, you can
start a conversation by sending an invitation to the
contacts with whom you want to talk. You can also
start a conversation by accepting an invitation from
another person.
To start a conversation by sending an invitation:
1. On the Messenger screen, select a group and
press the
Select
soft key.
2. Press the
Invite
soft key.
3. Select an entry and press the
Check
soft key. To
select more entries, repeat this step.
To remove a check mark, press the
UnCheck
soft key.
4. When you have finished, press the
Invite
soft
key.
5. If your buddy accept your invitation, entrance
message is appearing on the screen.
Entertainment
147
6. To send the message, press the
Send
soft key
().
While entering a message, you can access the
following options by pressing the
Option
soft
key:
•
Invite
: allows you to send an invitation to an
entry.
•
Extract
: allows you to extract the message
you made. you can view the message in
history menu. the message can be stored to
20.
•
Canned msg.
: allows you to retrieve one of
several canned messages.
•
View members
: shows the entries currently
selected.
•
Mode
: allows you to send “emoticon”and
“Theme” message.
7. To finish the conversation, press
END
soft key.
To start a conversation by accepting an invitation:
When another person sends you an invitation, a
text notification displays. Press the
Join
soft key.
Now, you can converse with the person by
message.
Unless you want to accept, press the
Reject
soft
key.
Managing the buddy list
On the Messenger screen, scroll to a group and
select an entry.
While highlighting an entry, press the
Menu
soft
key to access the following options:
Entertainment
148
View
: shows information about the entry.
Edit
: allows you to edit the entry.
Add
: allows you to add a new entry.
Erase
: allows you to erase the selected entry.
Move
: allows you to move the member to one of
the groups stored in the buddy list.
Reject
: allows you to add the entry to the Rejected
group so that you can reject messages from that
person.
To receive messages from the person, select
on the Messenger screen. Press the
Restore
soft
key when the entry you want highlights. You can
add the entry to one of the messenger groups
stored in your phone.
Erase all
: allows you to erase all of the members of
the group to which the entry belongs.
History
(Menu 7-7-2)
In this menu, you can view the records of your
conversations.
Scroll to a record and press the
Select
soft key to
view the record. To erase the record, press the
Erase
soft key. To return to the record list, press
the
Done
soft key.
While viewing a record, press the
Menu
soft key to
access the following options:
Erase
: allows you to erase the selected record.
Erase all
: allows you to erase all records.
Entertainment
149
Settings
(Menu 7-7-3)
In this menu, you can change the setting options
for using the messenger feature.
The following options are available:
Canned msg.
: allows you to add a new canned
message to use when creating an instant message
to converse with other people.
To add a new message:
1. Press the
Add
soft key.
2. Enter the message you want and press the
Save
soft key.
After adding a message, you can access the
following options by pressing the
Menu
soft key:
Add: allows you to add a new message.
Edit: allows you to edit the message.
Erase: allows you to erase the selected message.
Erase all: allows you to erase all messages.
Font size
: allows you to select the message font
size to be displayed on the messenger screen,
either
Small
or
Large
.
My nickname
: allows you to enter the nickname to
be displayed on the messenger screen.
150
Utilities
The
Utilities
menu provides you various convenient
features such as a calendar, calculator, remote
control, to do list, D-day counter, and memo pad.
Note
: When you are out of your service area, you
cannot use some of the features in this menu.
Calendar
(Menu 8-1)
This menu allows you to view the current month, as
well as the past or future months in the calendar
format. You can be alerted by the calendar function
before an event commences.
When you access this menu, today’s date is
automatically selected and the date in lunar
calendar displays on the bottom.
Note
: You can quickly access this menu by pressing
the Right key in Standby mode.
Selecting a day on the calendar
• You can move to the next or the previous day by
pressing the Left or Right key.
• You can move up or down the calendar one week
by pressing the Up or Down key.
• To display the next or previous month, use the
Volume keys on the left side of the phone.
Utilities
151
On the calendar, press the
Option
soft key to
access the following options:
View
: shows you the memo stored on that day.
Add new
: allows you to add a new event on the
selected day.
Erase events
: allows you to erase scheduled
events for a specified period.
Erase all
: allows you to erase all scheduled events.
Jump to date
: allows you to specify the date you
want to access.
View festivals
: allows you to set the list of the
national anniversaries and festivals.
Scheduling an event
You can schedule up to 9 events for one day and 20
events total.
1. Select a day from the calendar, see “Selecting a
day on the calendar” on page 150, and press the
OK
soft key.
2. Enter your event contents and press the
OK
soft
key.
For more information about how to enter
characters, see page 40.
3. Enter the time using the numeric keys and press
the Down key.
Note
: You need to enter the time in 24-hour
format.
Utilities
152
4. Enter the date using the numeric keys and press
the Down key.
5. Select when an alarm will inform you of your
event by pressing the Left or Right key.
If you select
No alarm
, the phone will not alert
you.
6. Press the
Save
soft key to save your event.
Viewing your schedule
Days with scheduled events are seen in square
brackets on the calendar when you access the
Calendar
menu. Select one of them and press the
OK
soft key. The first event of the selected day
displays. To scroll to another event for the same
day, press the Navigation keys.
On the event list or details view, press the
Menu
soft key to access the following options:
Add new
: allows you to add a new event.
Edit
: allows you to edit the selected event.
Erase
: allows you to erase the selected event.
Erase all
: allows you to erase all of the events for
the day.
Utilities
153
Alarm
(Menu 8-2)
This menu allows you to set an alarm to ring at a
specific time.
To set an alarm:
1. Select
Alarm 1
or
Alarm 2
and press the
Select
soft key.
2. Select the alarm frequency option on the Set
field by pressing the Left or Right key.
•
Once
: The alarm rings only once and is then
deactivated.
•
Daily
: The alarm rings every day at the same
time.
•
Mon-Fri
: The alarm rings from Monday to
Friday.
3. Press the Down key to move to the Time field.
4. Enter the time for the alarm to ring.
Note
: You need to enter the time in 24-hour
format.
5. Press the Down key to move to the Melody field.
6. Press the
Select
soft key to specify an alarm
ringer.
7. Press the Down key and select a ringer category
using the Left or Right key.
To listen to the highlighted melody, press the
Play
soft key.
8. Select the ringer melody you want by pressing
the Up or Down key and press the
Save
soft
key.
Utilities
154
9. Press the
Save
soft key to save the alarm set.
To stop the alarm when it rings, simply open and
close the phone or press any key.
To deactivate the alarm, select the alarm set you
want, select
Off
from the Set field and press the
Save
soft key.
User memory
(Menu 8-3)
You can use your phone as external memory disk
for your PC. This menu allows you to connect the
phone to a PC and access the file directory of your
phone’s memory.
Connect to PC
(Menu 8-3-1)
To connect your phone to a PC:
1. Connect USB cable to the jack at the bottom of
the phone and USB port of the computer.
Note
: When the phone is serving as a memory
disk, do not remove a USB cable or battery
from the phone. This could result in loss of
data.
2. Access the
Connect
to PC
menu.
3. Enter the lock code and press the
OK
soft key.
Your phone switches to External memory mode.
To access the phone’s memory, open
My Computer
on your desktop and select the corresponding disk.
After copying files from/to your phone’s memory,
press the
Disconnect
soft key to exit External
memory mode. When a confirmation message
appears, press
Yes
or
No
soft key.
Utilities
155
Notes
:
• When the phone is serving as a memory disk, all
calls and messages are blocked.
• Do not change the name of the
Camera
folder. If
you change the name, all data in the
Camera
folder
will be deleted.
File manager
(Menu 8-3-2)
You can access the folders of your phone’s memory
and manage media files. Scroll to a folder and press
the
Select
soft key to view files in the folder.
Note
:
• Items which are in unsupported sizes may not
function properly.
• When you change a file name, do not use the special
characters, such as /, \, ?, <, >, and so on.
On the file folder list, press the
Menu
soft key to
access the following options:
Folder info
: shows information about the selected
folder.
You can also access the following options by
pressing the
Menu
soft key with a file highlighted.
Some options may not be available, depending on
which type of file is selected:
Send
: sends the file as part of an e-mail.
Erase
: allows you to erase the file.
Move
: allows you to move the file to another folder.
Copy
: allows you to copy the file.
Rename
: allows you to change the name of the
file.
Utilities
156
Create folder
: allows you to add a new folder.
Erase all
: allows you to erase all files in the current
folder.
File info
: shows information about the file.
Assign
: allows you to assign the file as the power
on/off image or the wallpaper image for the idle
screen.
Set wallpaper
: allows you to set the file as your
wallpaper for the idle screen.
Set to ringer
: allows you to set the file as your
ringer melody.
Copy to pbook
: allows you to save the file as a
Phonebook entry.
Memory info
(Menu 8-3-3)
You can check the total amount of memory in the
phone, currently in use, and available for music,
images, video files, and other contents.
Press the Left or Right key to view memory
information for each folder separately.
Format
(Menu 8-3-4)
You can erase media files, such as photos, video
clips, name cards or Create folder, stored in the
phone’s memory, all at one time.
To erase all files, press the
Yes
soft key.
Utilities
157
I.Beam
(Menu 8-4)
This feature allows you to use the phone as a
remote controller for various devices, such as a
television, DVD player, or setup box. You can also
send or receive data to or from IrDA-compatible
phones or other devices via the infrared port.
Note
: You can quickly access this
menu by pressing
the Down key in Standby mode.
Remote control
(Menu 8-4-1)
Using this menu, you can set the phone to act as a
remote controller. You can also quickly access this
menu by pressing and holding the Down key in
Standby mode.
Tips for using your phone as a remote
controller
• The IrDA ports on both devices must be facing
each other within an appropriate range.
• Be sure to allow a short interval between key
presses to allow for better recognition by the
device.
• If your phone does not control the device
properly, set up the remote control function again
with a different number.
• The remote control function may not work,
depending on the type or version of your device.
• If a device has multiple functions, e.g., a VCR/
DVD combo, the remote controller may not
control both device functions.
Utilities
158
• Do not use your phone as a remote controller in
public places where it can interfere with others.
• If you cannot find the manufacturer or model
number matching your device, you can update
the remote controller data base from the WAP
browser.
Setting the phone as a remote controller
1. Align the IrDA port on the phone with the
device.
2. Select
ROOM
,
LIVING
, or
ETC
by using the Left
or Right key, and press the
Set
soft key.
You can designate the area in which device the
phone will control is located.
3. Select the device you want to control and press
the
Select
soft key.
4. Select the manufacturer of the device and press
the
Select
soft key.
5. Scroll to the model number of the item you want
to use by using the Left or Right key.
When the device corresponds to the number you
selected, the device turns on or off.
6. When you are finished, press the
Select
soft
key.
Using the remote controller
1. Align the IrDA port on the phone with the
device.
2. Select
ROOM
,
LIVING
, or
ETC
by using the Left
or Right key.
Utilities
159
3. Press the number key corresponding to the
device you are controlling.
4. While using the remote controller, you can
control another device by pressing the
Mode
soft key or Volume keys.
5. Use the keys to control the device, referring to
the image on the display.
6. To end using the remote controller, press the
key.
Deactivating the remote controller
1. Select
ROOM
,
LIVING
, or
ETC
by using the Left
or Right key and press the
Set
soft key.
2. Select the device for which you want to
deactivate the remote control and press the
Menu
soft key. The following options are
available:
•
Delete
: allows you to deactivate control of the
selected item.
•
Delete all
: allows you to deactivate control of
all of the items you have registered.
3. Press the
Select
soft key to confirm your choice.
4. When a confirmation message displays, press
the
Yes
soft key.
Note
: You can turn on or off devices you have
registered to be remotely controlled by the
phone at one time. Select the space you want
to control and press the
Power all
soft key.
Utilities
160
File transfer
(Menu 8-4-2)
Using this menu, you can send or receive
Phonebook entries or name cards.
Notes
:
• For optimal communication, the IrDA ports between
the 2 phones should be within close range of each
other.
• If the phones use conflicting IrDA protocol types, the
IrDA ports may not work properly.
• If you are interrupted by an incoming call while
transferring data, the data transfer may be
interrupted.
Receiving data
You can receive data from another phone through
the IrDA ports.
1. Select
Receive mode
and press the
Select
soft
key.
2. Select a storage location and press the
Save
soft key.
Images and name cards are always saved to the
phone’s memory
3. Align
the IrDA ports between the 2 devices, as
shown.
Utilities
161
The received data is automatically saved in the
corresponding directory of your phone’s
memory.
Sending data
You can transmit data to another phone. You can
select the following options to send data on your
phone in the
File transfer
menu:
Send name card
: sends name cards.
Send phonebook
: sends your Phonebook entries.
Send my album
: sends the photos you selected or
all photos saved in
My ablum
. You can send photos
only saved in the Single or Serial folder.
Mini dictionary
(Menu 8-5)
Your phone provides you with the English-Chinese
or Chinese-English dictionary.
Note
: Some words may not available due to limits of
the phone’s capacity.
To look up a word from the dictionary:
1. Enter the Chinese or English word you want.
For further details about how to enter
characters, see page 40.
2. Press the
Select
soft key.
The displays shows the pronunciation of the
word you entered and the corresponding English
or Chinese words.
3. To look up another word, press the
OK
soft key
and
repeat from step 1.
Utilities
162
Calculator
(Menu 8-6)
Using this feature, you can use the phone as a
calculator. The calculator provides the basic
arithmetic functions: addition, subtraction,
multiplication, and division.
To perform a calculation:
1. Enter the first number using the numeric keys.
Note
: Use the key to insert a decimal point and
the key to change the sign of a number
to a negative (-).
2. Select the operation for your calculation by
pressing the Navigation keys according to the
illustration on the display;
+
(add),
-
(subtract),
x
(multiply),
÷
(divide).
3. Enter the second number.
4. Repeat steps 2 to 3 as many times as required.
5. To get the result, press the
OK
soft key.
Note
: You can reset the calculator by pressing the
CE
soft
key.
Today
(Menu 8-7)
This menu allows you to schedule new events for
the current day, indicating each event’s start and
end time. Events scheduled for future dates
automatically appear on your Today display for that
particular day.
For further details about scheduling and viewing
events, see “Calendar” on page 150.
Utilities
163
To do list
(Menu 8-8)
This feature allows you to enter up a list of tasks
you need to do and assign both a priority and a
deadline to them.
Creating a to do item
1. Enter the task contents and press the
OK
soft
key.
For more information about how to enter
characters, see page 40.
2. Enter the time by which your task needs to be
done, using the number keys, and press the
Down key.
Note
: You need to enter the time in 24-hour
format.
3. Enter the date by which your task needs to be
done, and press the Down key.
Note
: You can enter between 1981 and 2099 for
the year.
4. Select a high or low priority using the Left or
Right key.
5. Press the
Save
soft key to save the task.
Viewing a task
When you access the
To do list
menu, the list of
tasks displays. A
!
icon next to a task means that
the task is of high priority.
Scroll to the task you want to view by pressing the
Navigation keys and press the
Select
soft key to
view details.
Utilities
164
On the to do list or details view, press the
Menu
soft key to access the following options:
Add new
: allows you to add a new task.
Edit
: allows you to edit the selected task.
Erase
: allows you to erase the selected task.
Erase all
: allows you to erase all tasks.
Voice tools
(Menu 8-9)
In this menu, you can record voice memos and
configure the voice dial settings.
Voice dialing
(Menu 8-9-1)
The voice dialling feature allows you to make phone
calls by saying one of names you have saved in
Phonebook.
Note
: Your phone can recognise only Chinese names.
The phone uses a voice recognition system
independent from speakers. This system is able to
recognise speeches of any speaker. Therefore, you
don’t have to do prior training or record voice tags.
For further details about voice dialling, see page 31.
Configuring voice recognition
By selecting
Configure
, you can configure various
settings for using the voice dialling feature.
The following configurations are available:
Set active
: allows you to set how you want to
initiate voice dialling. The following options are
available:
Utilities
165
Auto: The phone automatically switches to Voice
dialling mode when you open the phone.
Manual: You need to press and hold the
k
ey to
dial a number by your voice command.
Select sex
: allows you to select a sex to the phone
to recognise your voice.
Result display
: allows you to set how many
entries the phone displays as a result of the
recognition after searching for the best match for
your voice command.
Earmic setup
: allows you to set the phone to
activate Voice Dialling mode when you press the
button on the headset.
Note
: When using the headset, the voice dialling
feature may not work properly in noisy
environments.
Message vol
: allows you to adjust the volume of
voice prompts guiding you through the procedure
for voice dialling.
Storage
: allows you to select the default memory
for Voice Dialling mode. When you initiate the
mode, the phone recognises only the entries in the
selected memory.
Dialect
: allows you to set the phone to recognise a
local language,
Mandarin
or
Cantonese
.
Edit voice dial entries
Once you have stored Chinese names with numbers
in Phonebook, they are automatically registered as
voice dial entries.
You can cancel or set the voice dialling setting for
each names.
Utilities
166
1. From the Voice dial screen, scroll to
Edit name
and press the
Select
soft key.
2. When the list of the selectable entries in the
default memory appears, press the Up or Down
key or the key to scroll to the name you want.
3. Press the key to select or deselect the name.
The selected name can be dialled by voice
command.
4. Repeat steps 2 and 3 for other entries.
5. When you have finished, press the
C
key or the
key.
Voice memo
(Menu 8-9-2)
This menu allows you to record and play voice
memos.
Recording a voice memo
1. Record a memo by speaking into the
microphone.
While you are recording, a timer displays the
elapsed time.
You can pause recording by pressing the
Pause
soft key and then resume by pressing the
Continue
soft key.
2. Press the
Stop
soft key to end recording. The
screen provides you with the following choices:
•
Save
: allows you to save the voice memo.
Utilities
167
•
Re-record
: allows you to discard the current
memo and record another one.
•
Review
: allows you to review the voice
memo. The screen displays the length of the
memo.
3. When you are satisfied, select
Save
and press
the
Select
soft key.
4. Enter a name of the memo and press the
OK
soft key.
For further details about entering text, see
page 40.
Playing a voice memo
You can view the voice memo list on the Voice
memo screen.
To play a voice memo:
1. Scroll to the voice memo you want by pressing
the Left or Right key.
2. Press the
Play
soft key to play the memo.
You can pause playback by pressing the
Pause
soft key and resume by pressing the
Continue
soft key.
3. Press the
Stop
soft key to stop playback.
On the Voice memo screen, press the
Menu
soft
key to access the following options:
New record
: allows you to record a new voice
memo.
Play
: plays the selected voice memo.
Utilities
168
Erase
: allows you to erase the selected voice
memo.
Erase all
: allows you to erase all voice memos.
Send
: allows you to record a voice memo then
send it as an e-mail. This option is not available
when the display is rotated.
World time
(Menu 8-0)
You can use this menu to find out what time it is in
another part of the world.
Press the Navigation keys to scroll to the time zone
you want to check.
To apply daylight savings to the current time zone,
press the
DST
soft key and press the
Yes
soft key.
The icon appears next to the time and date.
Countdown
(Menu 8- )
This menu helps you know how much time it takes
for you to do something or how many days, hours,
and minutes until a specific event occurs.
Creating a countdown timer
1. Enter a name for your countdown timer and
press the
OK
soft key.
For more information about how to enter
characters, see page 40.
Utilities
169
2. Enter the time from which you want to count
down and press the Down key.
Note
: You need to enter the time in 24-hour
format.
3. Enter the date from which you want to count
down.
Note
: You can enter between 1981 and 2099 for
the year.
4. Press the
Save
soft key to save the timer.
Viewing a countdown timer
When you access the
Countdown
menu, a list of
timers you have created displays.
Scroll to the timer you want to view and press the
Select
soft key. The selected countdown timers
displays, showing the specified date and time, and
how many days, hours, and minute remains or have
passed. To scroll to another timer, press the Left or
Right key.
On the timer list or details view, press the
Menu
soft key to access the following options:
Add new
: allows you to create a new timer.
Edit
: allows you to edit the currently selected timer.
Erase
: allows you to erase the timer.
Erase all
: allows you to erase all timers.
Utilities
170
Memo pad
(Menu 8- )
This feature allows you to make memos of
important things you need to remember.
Writing a new memo
1. Enter what you need to remember.
For further details on how to enter characters,
see page 40.
2. Press the
OK
soft key to save the memo.
Viewing a memo
The list of your memos displays when you access
the
Memo pad
menu.
Scroll to the memo you want to view from the list
and press the
Select
soft key. To scroll to another
timer, press the Navigation keys.
On the memo list or details view, press the
Menu
soft key to access the following options:
Add new
: allows you to add a new memo.
Edit
: allows you to edit the currently selected
memo.
Erase
: allows you to erase the memo.
Erase all
: allows you to erase all memos.
171
Settings
Many different features of your phone can be
customised to suit your preferences.
Answer mode
(Menu 9-1)
This menu allows you to select how to answer an
incoming call.
The following options are available:
By send key
: The phone answers only when you
press the key.
By folder open
: The phone answers when you
open the phone. If the phone is already open, press
the key.
By any key
: When the phone is open, you can
press any key except for the soft keys, the Volume
keys, or the key. When the phone is closed, you
can answer the call by opening the phone.
Settings
172
Roam option
(Menu 9-2)
Roaming is a feature which is only relevant in areas
where there are at least two cellular service
providers having valid roaming agreements.
Roaming allows you to register your phone on one
of the networks, but use the facilities of the other if
your own network is not available. This system
priority feature allows you to program your phone
for optimum operation within or outside your home
service area.
You should always check your phone’s display
because it will let you know when you’re outside the
service provider network and whether your phone is
operating in another network; the roaming icon
( ) appears.
You have the following options which allows you to
control the phone’s roaming ability:
Home only
: With this setting, you cannot roam. If
your home system is not available, your call will not
be connected and the No Service indicator ( )
displays.
Automatic
: Your phone automatically search for a
first available one of all types of service according
to the Preferred Roaming List supplied by the
service provider.
Settings
173
Security
(Menu 9-3)
Your phone provides you with various security
options, including a user-programmable lock code
and emergency numbers.
To a ccess the
Security
menu, you must enter the
4- to 8-digit lock code. It is preset to “00000000” at
the factory.
Phone lock
(Menu 9-3-1)
In Lock mode, you cannot dial numbers, except for
making an emergency call, or accessing menu
options. The phone can receive incoming calls and
messages, even though the phone is in Lock mode.
The following options are available:
Off
: The phone remains unlocked.
Once
: The phone remains locked only until you
unlock the phone.
On
: The phone is automatically locked so that you
need to enter the lock code when you want to use
your phone.
To place an emergency call in Lock mode, enter a
programmed number and then press the key.
The phone recognises standard emergency
numbers, such as 119, 110, and 120 or three
numbers programmed in the
Emergency #
menu
(
Menu 9-3-3
); see page 174.
To unlock the phone, press the
Unlock
soft key and
enter the 4- to 8-digit lock code. The phone is
immediately unlocked.
Settings
174
Change lock
(Menu 9-3-2)
This feature allows you to change your current lock
code to a new one. The lock code is preset to
“00000000” at the factory.
1. Enter a new 4- to 8-digit lock code and press the
OK
soft key.
2. Enter the code once again and press the
OK
soft
key.
Note
: Your phone does not allow viewing of the lock
code for security reasons, so be sure to write
the lock code down or memorise it if you have
changed.
Emergency #
(Menu 9-3-3)
Your phone provides the option of storing three
emergency numbers. All of these numbers can be
manually dialled at any time, even if your phone is
locked or all outgoing calls are restricted.
IMPORTANT NOTICE!
Emergency calling may not be available on all
wireless networks at all times, due to the various
transmission methods, network parameters and
user settings used to complete a call from your
wireless phone. A connection cannot always be
guaranteed.
DO NOT depend on this phone as a primary method
of dialling 119 or for any other essential or
emergency communications.
Remember to always turn on your phone and check
for the adequate signal strength before placing a
call.
Settings
175
To store an emergency number:
1. Press the Up or Down key to select a location
and press the
Select
soft key.
2. Press the
C
key to clear the existing number.
3. Enter a number and press the
Save
soft key to
save the number.
Note
: 119, 110, and 120 will remain as emergency
numbers, even if you change them on the
emergency number list.
To make an emergency call in Lock mode, simply
enter one of the programmed emergency numbers
and press the key.
Voice privacy
(Menu 9-3-4)
Used only in digital networks, Voice Privacy
encrypts the voice channel so that people cannot
eavesdrop on your conversation.
The following options are available:
Standard
: The phone uses a standard line for calls.
Enhanced
: The phone makes and receives calls on
an encrypted high security line.
Note
: This feature may not be available in all areas.
Contact your service provider for details and its
availability.
Settings
176
Restriction
(Menu 9-3-5)
This feature allows you to restrict the use of your
phone.
The following options are available:
Outgoing
: restricts outgoing calls from your
phone, except emergency calls by standard
emergency numbers, such as 119, 110, and 120, or
three programmed numbers in the
Emergency #
menu (
Menu 9-3-3
).
Incoming
: restricts incoming calls.
Phonebook
: restricts access to your Phonebook.
You are not able to save a phone number, either.
When a confirmation message displays, select
Yes
to turn it on or
No
to turn it off and press the
Save
soft key.
GPS settings
(Menu 9-3-6)
Your phone supports the GPS function based on the
WAP browser (U-Map) and the Brew application. For
further details, contact your service provider.
The following options are available:
GPS lock
: allows you to set whether or not your
GPS service is locked.
Privacy alert
: allows you to set whether or not you
receive confirmation message when connecting to
the GPS service.
Settings
177
Clear memory
(Menu 9-3-7)
This menu allows you to erase Phonebook entries or
messages stored in the card and the phone’s
memory. You can also erase all of the entries or
messages at one time.
To clear a memory for Phonebook or messages:
1. Select
Phonebook
or
Messages
and press the
Select
soft key.
2. Select the memory location you want to clear,
Card
or
Phone
, and press the
Select
soft key.
To clear both memories, select
All
.
3. When a confirmation message appears, select
Yes
soft key.
Reset phone
(Menu 9-3-8)
This menu allows you to restore the default settings
of all of user-selectable options, or clear
information, such as messages, call logs, and
schedule in the phone’s memory.
The following options are available:
Functions only
: restores the default settings of all
of user-selectable options.
All
: restores default settings of all options and
clears information stored in the phone’s memory.
Note
: When you reset your phone using the
All
option, information stored on the card memory
does not reset.
Settings
178
When a confirmation message displays, press the
Yes
soft key to confirm. The phone reboots, turning
itself off and then back on, and returns to Standby
mode. Press the
No
soft key to cancel your
selection.
Card setup
(Menu 9-3-9)
In these menus, you can use the security options
for the UIM card.
PIN check
: When this feature is enabled, you must
enter the PIN assigned to your card each time you
switch on the phone. Consequently, any person who
does not have your PIN cannot use your phone
without your approval. But emergency calls are
available without the PIN code.
Note
: Before enabling or disabling the PIN check
feature, you must enter your PIN.
Change PIN
: This feature allows you to change the
PIN of the UIM card to a new one, provided that the
PIN check feature is enabled. You must enter the
current PIN before you can specify a new one. Enter
a new PIN.
UIM lock
: When this feature is enable, your phone
only works with the current UIM card.
Once you have entered the lock code, you are
asked to confirm it by entering it again.
To unlock the card, you must enter the lock code.
Settings
179
Entry method
(Menu 9-4)
This menu allows you to select the default text
input mode.
Select one of 4 input modes;
Pinyin
,
Stroke
,
T9
word
, and
ABC
.
Data option
(Menu 9-5)
You may sometimes need to switch the data mode
of the CDMA network to another, according to the
service status in your area. In this menu, you can
select the data transmission mode you prefer.
If the network is not available with the current
setting, try again after changing the option.
The following options are available:
Auto selection
: allows your phone to select an
available data transmission mode automatically.
1x only
: allows your phone to use only 1x mode.
95A only
: allows your phone to use only 95A
mode.
Domains preset
(Menu 9-6)
Your phone has domain name extensions that you
can retrieve them when writing messages or
e-mails.
You can change the default domain name
extensions, if necessary, and add more ones.
Settings
180
Contents status
(Menu 9-7)
In this menu, you can check the amount of the
memory being used or memory remaining for
downloaded contents.
Total
: shows the total space include the system,
used, and free space.
Program
: shows the list of applications
downloaded from the wireless web.
Melody
: shows the list of downloaded music files,
such as bells or melodies.
: shows the list of downloaded image files.
VOD
: shows the list of downloaded video files.
When you select an item from the list, the display
shows its memory size at the bottom.
You can erase the selected item by pressing the
Menu
soft key and selecting
Erase
or
Erase all
.
Rotation mode
(Menu 9-8)
In this menu, you can specify a feature to open
automatically when you rotate the phone display.
When you rotate the display, you can get a wide
screen view, making the phone’s entertainment
features, such as camera, 3D games, MP3 music,
and VOD, that much more enjoyable.
181
Health and safety
information
Exposure to Radio Freqency (RF)
Signals
Your wireless phone is a radio transmitter and
receiver.It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards that
were developed by independent scientific
organizations through periodic and through
evaluation of scientific sudies.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones employs
a unit of measurement known as Specific
Absorption Rate (SAR). The SAR limit recommended
by the FCC is 1.6 W/kg.
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bans. Although the SAR is
determined at the highest certified power level, the
atual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power
levels so as to use only the power required to reach
the network. In gerneral, the closer you are to a
Health and safety information
182
wireless base station antenna, the lower the power
output of the phone.
Before a new model phone is available for sale to
the public, it must be tested and certified to the FCC
that it does not exceed the limit established by the
goverment adopted requirement for safe
exposure.The tests are performed in positions and
locations(e.g., at the ear and worn on the body) as
required by the FCC for each model. While there
may be differences between the SAR levels of
various phones and at various positions, they all
meet the goverment requirement.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found
under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
For Body Operation
For body worn operation, this model phone has
been tested and meets the FCC RF exposure
guidelines when used with a Samsung-supplied or
approved accessory designated for this product or
when used with and accessory that contains no
metal and that positions the handset a minimum
from the body.
The minimum distance for this model phone is
written in the FCC certification information from the
body.None compliance with the above conditions
may violate FCC RF exposure guidelines.
Health and safety information
183
For more information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC) http://
www.fcc.gov
Cellular Telecommunications Industry Association
(CTIA):http://www.wow-com.com
U.S.Food and Drug Administration (FDA) http://
www.fda.gov/cdrh/consumer
World Health Organization (WHO) http://
www.who.int/peh-emf/en
Battery safety
Information about batteries
(fully charged battery)
* Criterion for Measuring Time:
The Talk time is measured with the +10dBm, Voice Rate Half.
Standby time will be reduced in the following
conditions:
• When you use the additional features on your
phone such as writing and storing messages,
playing games, connecting to the Internet, and so
on.
• If you are frequently out of the service area.
Standard Battery
(1000mA)
Extended Battery
(1300mA)
Talk time
up to xx minutes up to xx minutes
Standby
time
xx to xx hours xx to xx hours
Type
Time
Health and safety information
184
• If you are out of the service area for a long period
of time.
• If you use the phone out of the network’s local
service area.
• If you use the talk mode repeatedly
The battery can be charged and discharged
hundreds of times, but it will eventually wear out.
When the operation time for both talk mode and
standby mode is reduced by about half, it is time to
buy a new battery.
Precautions when using batteries
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge, the type of battery, and the
charger used. The battery can be charged and
discharged hundreds of times, but it will gradually
wear out. When the operation time (talk time and
standby time) is noticeably shorter than normal,
it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
Health and safety information
185
the battery connected to a charger for more than
a week, since overcharging may shorten its life.
• Extreme temperature will affect the charging
capacity of your battery: it may require cooling or
warming first.
Health and safety information
186
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of the
battery. Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between
the + and – terminals of the battery (metal strips
on the battery), for example when you carry a
spare battery in a pocket or bag. Short-circuiting
the terminals may damage the battery or the
object causing the short-circuiting.
• Dispose used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Road safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, make sure that you are
following the special regulations in a given area or
country.
Health and safety information
187
Operating environment
Remember to follow any special regulations in force
in any area and always switch your phone off
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it
is recommended that the equipment should only be
used in the normal operating position (held to your
ear with the antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
with the independent research and
recommendations of Wireless Technology Research.
Health and safety information
188
Persons with pacemakers:
• Should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone
is switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference
is taking place, switch your phone off immediately.
Hearing aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your hearing
aid manufacturer to discuss alternatives.
Other medical devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from external
RF energy. Your physician may be able to assist you
in obtaining this information. Switch your phone off
in health care facilities when any regulations posted
in these areas instruct you to do so. Hospitals or
health care facilities may be using equipment that
could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should
Health and safety information
189
also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially explosive atmospheres
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even
death.
Users are advised to switch off the phone while at a
refuelling point (service station). Users are
reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage
and distribution areas), chemical plants or where
blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
the areas below decks on boats, chemical transfer
or storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane), areas
where the air contains chemicals or particles, such
as grain, dust or metal powders, and any other area
where you would normally be advised to turn off
your vehicle engine.
Health and safety information
190
Emergency calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well
as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 120 or any other official
emergency number). Emergency numbers vary
by location.
3. Press the key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to give
all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not cut off the call until given
permission to do so.
Health and safety information
191
FCC Notice and Cautions
FCC Notice
• This device complies with Part 15 of the FCC
Rules.Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Cautions
• Changes or modifications made in the radio phone,
not expressly approved by Samsung, will void the
user’s authority to operate the equipment.
Other important safety information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty
installation or service may be dangerous and may
invalidate any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating
properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
Health and safety information
192
• Switch your phone off before boarding an aircraft.
The use of wireless phones in aircraft may be
dangerous to the operation of the aircraft, and is
illegal.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children’s.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals will corrode electronic
circuits.
• Do not touch the phone with a wet hand while it
is charging. Doing so may cause an electric shock
to you or damage to the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperature can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s electronic
circuit boards.
Health and safety information
193
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas or
modified accessories may damage the phone and
violate regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
194
Glossary
Air time
Actual time spent talking on the wireless phone.
Most carriers bill customers based on how many
minutes of airtime they use each month.
Call waiting
Informs you that you have an incoming call when
you are engaged on another call.
Caller Line Identification Services (Caller ID)
Services allowing subscribers to view or block the
telephone numbers of callers.
CDMA
(Code Division Multiple Access) A spread-spectrum
approach to digital transmission. With CDMA, each
conversion is digitized and then tagged with a code.
The mobile phone deciphers only a particular code
to pick the right conversation off the air. The
transmitted signal is just above noise level across
the available bandwidth.
Deactivation
The process of rendering a wireless phone inactive.
DTMF
(Dual-Tone Multi- Frequency) You send DTMF
signals when you enter numbers by pressing the
digit keys.
Glossary
195
Frequency
A measure based on time, as one or more waves
per second, in an electrical or light wave
information signal. A signal’s frequency is stated in
cycles-per-second or Hertz (Hz).
LCD
(Liquid Crystal Display) Commonly used to refer to
the screen display on the wireless phone.
Phone password
Security code used to unlock the phone when you
have selected the option to lock it automatically
each time it switches on.
PIN (Personal Identification Number)
Security code that protects the phone against
unauthorized use. The PIN is supplied by the service
provider with the SIM card. It may be a four to
eight-digit number and can be changed, as
required.
Roaming
The ability to use a wireless phone to make and
receive calls in places outside of the home service
area.
SMS (Short Message Service)
Network service sending and receiving messages to
and from another subscriber without having to
speak to the correspondent. The message created
or received can be displayed, received, edited or
sent.
Glossary
196
Soft keys
Two keys marked and on the phone, the
purpose of which:
• varies according to the function that you are
currently using.
• is indicated on the bottom line of the display just
above the corresponding key.
Standby time
The amount of time a fully charged wireless
portable or transportable phone can be on and idle
without being in use.
Voice mail
Computerised answering service that automatically
answers your calls when you are not available,
plays a greeting (optionally in your own voice) and
records a message.s
Acknowledging Special Precautions
and the FCC and Industry Canada
Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate the equipment.
FCC Compliance information
This device complies with Part 15 of FCC Rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received.
Including interference that may cause undesired operation.
Glossary
197
Information to user
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/ TV technician
for help.
CERTIFICATION INFORMATION
(SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission
limits for exposure to radio frequency(RF) energy set by
the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on safety
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial
Glossary
198
safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones employs
a unit of measurement known as the Specific Absorption
Rate(SAR). The SAR limit set by the FCC is 1.6 W/kg. SAR
Tests are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its
highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the limit established by the government-
adopted requirement for safe exposure. The tests are
performed in positions and locations(e.g., at the ear and
worn on the body) as required by the FCC for each model.
The highest SAR values for this model phone as reported to
the FCC are Head: 0.748W/Kg, Body-worn: 1.08W/Kg.
Body-worn operations are restricted to Samsung-supplied,
approved or none Samsung designated accessories that
have no metal and must provide at least 1.5cm separation
between the device, including its antenna whether
extended or retracted, and the user’s body. None
compliance to the above restrictions may violate FCC RF
exposure guidelines.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and
can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID
A3LSCHE159
Internal Phonebook
Store a new
number in
Standby mode
• On the UIM card
Enter a phone number +
Save
+
enter a name +
OK
+
Card
+
Save
• In the phone’s memory
Enter a phone number +
Save
+
enter a name +
OK
+
Phone
+
Up/Down select a category +
Save + Up/Down (Mobile/Home/
Office/Pager/Fax/Image/E-mail1/
Email2/URL/Group/Ringer/ETC)
+enter information or Left/Right
+
Save
Speed dial Speed dial location number +
hold the last digit
Scan
memories
Find
+ Left/Right + Up/Down +
OK
SCH-X839 Quick Reference Card
Basic operation
Make a call Phone number +
End a call
Receive a call or open the phone
Adjust the key tone
volume
(in Standby mode)
/ on the left side
Adjust the voice
volume
(during a call)
/ on the left side
Redial the last call twice or hold
Switch to Silent
mode
(in Standby mode)
Hold
Take a photo (in Standby mode)
Hold the Camera/Voice
memo key + Camera/Voice
memo key +
Save
Quick reference card
SCH-E159
200
Main menu
(To access, press the
Menu
soft key.)
1: Calls 1: Missed
2: Incoming
3: Outgoing
4: Air time
5: Call forward
6: Call waiting
7: Area code
8: Call reject
2: Phonebook 1: Find
2: Add
3: Group setting
4: Speed dial
5: Name card
6: My phone #
7: Memory info
3: Camera 1: Take photo
2: My album
3: Photo studio
4: Settings
4: Display 1: Image box
2: Banner
3: Backlight
4: Menu type
5: Set time
6: External clock
7: /Language
8: Dialing font
5: Message 1: New message
2: Inbox
3: Outbox
4: Msg setup
5: Msg wallpaper
6: Memory info
6: Sounds 1: Ringer
2: Ringer vol./Type
3: Key tone
4: Alert
7: Entertainment 1: 3D game
2: MP3
3: VOD
4: Melody composer
5: Karaoke
6: Fun club
7: Samsung messenger
8: Utilities 1: Calendar
2: Alarm
3: User memory
4: I.Beam
5: Mini dictionary
6: Calculator
7: Today
8: To do list
9: Voice tools
0: World time
:
Countdown
: Memo pad
9: Settings 1: Answer mode
2: Roam option
3: Security
4: Entry method
5: Data option
6: Domains preset
7: Contents status
8: Rotation mode
