Samsung Electronics Co SCHN415 Single-Mode Cellular Phone (CDMA) User Manual SCH N213 FCC
Samsung Electronics Co Ltd Single-Mode Cellular Phone (CDMA) SCH N213 FCC
Users Manual
* Some of the contents of this manual may differ from your phone,
depending on the software installed or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in KOREA
Code No.: GH68-XXXXX
English. 08/2004. Rev.1.0
ELECTRONIC
S
PORTABLE CELLULAR
TELEPHONE
SCH-N415
User’s Manual
Please read this manual before operating your
phone, and keep it for future reference.
3
Table of contents
Important safety precautions .......................6
Unpacking.....................................................8
Your phone ...................................................9
Phone layout....................................................... 9
Display.............................................................. 12
Service light ...................................................... 14
Getting started............................................15
Using the battery................................................ 15
Switching on or off the phone............................... 19
Using the soft keys............................................. 20
Your phone’s modes............................................ 21
Call functions ..............................................23
Making a call...................................................... 23
Ending a call...................................................... 24
Emergency dialing .............................................. 24
Using the recent call logs..................................... 25
Making a call from Contacts ................................. 25
Prepend dialing .................................................. 26
Speed dialing..................................................... 26
4-digit dialing..................................................... 28
Pause dialing ..................................................... 28
Voice dialing ...................................................... 31
Adjusting the volume during a call........................ 33
Answering a call................................................. 34
Silencing a call ringer.......................................... 35
Viewing missed calls ........................................... 35
Options during a call........................................... 36
Using caller ID ................................................... 37
Call forwarding................................................... 37
Call waiting........................................................ 38
Three-way calling............................................... 39
Entering text...............................................40
Table of contents
4
Changing the text input mode.............................. 41
Using T9 (English) mode...................................... 42
Using Alphabet mode .......................................... 44
Using Symbol mode............................................ 46
Using Number mode ........................................... 46
Using the menus .........................................48
Accessing a menu function by scrolling.................. 48
Using shortcuts .................................................. 49
List of menu functions......................................... 50
Downloads ..................................................54
Downloading multimedia files............................... 54
Changing the browser settings ............................. 55
Viewing help information ..................................... 56
WAP............................................................57
About the WAP browser....................................... 57
Get In WAP
(Menu 2-1)
........................................ 58
Prompt
(Menu 2-2)
.............................................. 62
Push SL Option
(Menu 2-3)
................................... 62
Voice Mail ...................................................63
Voice Mail
(Menu 3-1)
.......................................... 63
Voice Mail#
(Menu 3-2)
........................................ 63
Voice Portal ................................................64
Voice Portal
(Menu 4-1)
....................................... 64
Voice Portal#
(Menu 4-2)
..................................... 64
Messaging..................................................65
Messenger
(Menu 5-1)
......................................... 65
Chat
(Menu 5-2)
................................................. 66
Torpedo SMS
(Menu 5-3)
..................................... 66
E-mail
(Menu 5-4)
............................................... 67
Torpedo SMS...............................................68
New Msg
(Menu 6-1)
........................................... 68
Voice
(Menu 6-2)
................................................ 70
Inbox
(Menu 6-3)
................................................ 71
Sent
(Menu 6-4)
................................................. 72
Draft
(Menu 6-5)
................................................. 73
Saved
(Menu 6-6)
............................................... 73
Table of contents
5
Web Alert
(Menu 6-7)
.......................................... 73
Erase Msg
(Menu 6-8)
.......................................... 74
Msg Setting
(Menu 6-9)
....................................... 74
Calls............................................................77
Outgoing
(Menu 7-1)
........................................... 77
Incoming
(Menu 7-2)
........................................... 78
Missed
(Menu 7-3)
............................................... 79
Erase History
(Menu 7-4)
..................................... 79
Air Time
(Menu 7-5)
............................................ 80
Contacts......................................................81
Find
(Menu 8-1)
.................................................. 81
Add New Entry
(Menu 8-2)
................................... 84
Group Setting
(Menu 8-3)
..................................... 87
My Phone#
(Menu 8-4)
........................................ 88
Memory
(Menu 8-5)
............................................. 88
Other Functions ..........................................89
Planner
(Menu 9-1)
............................................. 89
Display
(Menu 9-2)
............................................ 102
Sounds
(Menu 9-3)
............................................ 105
Voice Dial
(Menu 9-4)
........................................ 109
Setup
(Menu 9-5)
.............................................. 110
Voice command.........................................119
Health and safety information...................120
Exposure to radio frequency (RF) signals ............. 120
Road safety ..................................................... 124
Operating environment ..................................... 125
Electronic devices............................................. 125
Potentially explosive environment....................... 127
Emergency calls............................................... 128
Other important safety information..................... 129
Care and maintenance ...................................... 130
Acknowledging special precautions and the FCC and in-
dustry canada notice......................................... 131
Glossary....................................................150
6
Important safety
precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road safety at all times
Do not use a hand-held phone while driving; park
the vehicle first.
Switching off when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switching off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switching off in near all medical equipment
Switch off your phone near medical equipment.
Hospitals and health care facilities may be using
equipment that could be sensitive to external RF
energy. Follow any regulations or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their performance.
Special regulations
Follow any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger (in a hospital for example).
Water resistance
Your phone is not water-resistant. Keep it dry.
Important safety precautions
7
Sensible use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency call
Key in the emergency number for your present
location, then press . Give all necessary
information as accurately as possible. Do not end
the call until given permission to do so.
Keeping small children away from your
phone
Keep the phone and all its parts including
accessories out of reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories
could damage your phone and may be dangerous.
Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see “Health
and safety information” on page 120.
CAUTION
RISK OF EXPLOSION IF A BATTERY IS
REPLACED BY AN INCORRECT TYPE.
DISPOSE USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
8
Unpacking
Your package contains the following items. The
illustrations below may look different from your
phone and accessories:
In addition, you can obtain the following
accessories for your phone from your local
Samsung dealer:
Handset Battery
Travel adapter Hand strap
• Headset • Travel adapter
• Standard battery • Cigarette lighter
adapter
• Hands-free car kit • Data cable
Headset
User’s manual
9
Your phone
Phone layout
The following illustrations show the main elements
of your phone.
With the phone open
Earpiece
Display
Microphone
Soft key (left)
Send key
Soft key (right)
Power on/off/
Menu exit key
Alphanumeric
keys
Special
function keys
Cancel/clear
key
Navigation (Up/
Down/Left/
Right) keys
Volume/menu
browse keys
OK key
Headset jack
Your phone
10
Tecla
Key
(s)
Description
(soft keys)
Performs the functions indicated by
the text above them, on the bottom
line of the display.
(Navigation
keys)
In Menu mode, scrolls through menu
options.
In Standby mode, quickly enters
favorite menu options directly. For
further details about shortcuts, see
page 103.
In Menu mode, selects the current
menu or option or confirms your
input.
Makes or answers a call.
In Standby mode, retrieves the most
recent numbers dialed, received, or
missed. Redials the last number when
pressed and held.
Ends a call. Also switches the phone
on and off when pressed and held.
In Menu mode, cancels your input and
returns the display to Standby mode.
Deletes characters from the display.
In Menu mode, returns the display to
the previous menu level.
Enters numbers, letters, and some
special characters.
Your phone
11
In Standby mode, initiates the Voice
Command feature when pressed and
held.
In the text entry mode, changes case
of letters.
In Standby mode, quickly enters or
exits Silent mode when pressed and
held.
In the text entry mode, inserts a
space.
(on the left side of the phone)
Adjusts the ringer volume when the
phone is ringing and the earpiece
volume during a call.
In Standby mode, adjusts the key
tone volume.
Key
(s)
Description
(continued)
Your phone
12
Display
Layout
The display has three areas; the top line of icons,
the text and graphic area, and the bottom line of
soft key indicators.
Icons
Icon Description
Signal strength
: Shows the received
signal strength. The greater the number
of bars, the better the signal.
Service
: Appears when a call is in
progress.
No service
: Appears when you are
outside a service area. When it displays,
you cannot make or receive calls. Wait a
little while for a better signal or move
into an open area to regain service.
Icons
Text and
graphics area
Soft key function
indicators
Menu
Contacts
Your phone
13
New text message
: Appears when a
new text message received.
New voice mail
: Appears when a new
voice mail is received.
New text message and voice mail
:
Appears when there are new text
messages and voice mails received.
Alarm mode
: Appears when you set an
alarm to ring at a specified time.
Roaming
: Appears when you are out of
your home area and have logged onto a
different network; for example, when
traveling in other countries.
Ringer on
: Appears when you set the
ringer volume for calls to one from
Level 1
to
Level 8
or to
1-Beep
.
Ringer off
: Appears when you set the
ringer volume for calls to
Silent
.
Vibration mode
: Appears when the
ringer volume for calls is set to
Vibrate
or
High+Vib
, or when your phone is in
Silent mode.
Digital mode
: Indicates when the
phone is logged onto a digital network.
Analog mode
: Indicates when the
phone is logged onto an analog network.
1x mode
: Indicates when the phone is
in 1x mode.
Icon Description
(continued)
Your phone
14
Service light
The service light on the top right corner of the
phone, flashes to indicate an incoming call,
message, or alarm and flashes for a few seconds
when you turn on or off the phone.
It blinks while the battery is charging with the
travel adapter; it lights when the battery is fully
charged.
To make the service light turn on, set the
Service
LED
menu; see page 104 for further details.
Battery status
: Shows the level of your
battery. The more bars you see, the
more power you have remaining.
Icon Description
(continued)
15
Getting started
Using the battery
Your phone is powered by a rechargeable Li-ion
battery. Use only approved batteries and
chargers. Ask your local Samsung dealer for
further details.
Note
: You must fully charge the battery before using
your phone for the first time. A discharged
battery is fully recharged in approximately
180 minutes for a standard battery.
Installing the battery
1. Place the battery so that the tabs on the end
align with the slots at the bottom of the phone.
Getting started
16
2. Press the battery until it clicks into place. Make
sure that the battery is properly installed
before switching the phone on.
Removing the battery
1. If necessary, switch off the phone by pressing
and holding until the power-off image
displays.
2. Slide the battery lock toward the top of the
phone and lift away the battery, as shown.
Charging the battery
A travel adapter is provided for charging your
batteries. The travel adapter allows you to use the
phone while the battery is charging, but this will
cause the battery to charge more slowly.
➀➁
Getting started
17
1. With the battery in position on the phone, plug
the connector of the travel adapter into the
jack at the bottom of the phone.
Make sure that the arrow on the connector is
facing up, as is the phone.
2. Plug the adapter into a standard AC wall outlet.
The battery strength icon on the display shows
that the battery is charging.
3. When charging is finished, unplug the adapter
from both the power outlet and the phone by
pressing the buttons on both sides of the
connector and pulling the connector out.
Note
: You must unplug the charger before removing
the battery from the phone during charging;
otherwise, the phone could be damaged.
Low battery indicator
➀
➀
➁
Getting started
18
When the battery is weak and only a few minutes
of talk time remain, a warning tone sounds and a
“Low Battery! Recharge Soon” message repeats at
regular intervals on the display. In this case, the
phone turns off the backlight of the display to
conserve battery power.
When the battery becomes too weak for the phone
to operate, it switches off automatically.
Getting started
19
Switching on or off the phone
1. Open the phone.
2. Press and hold until the power-on image
displays to switch on the phone.
The service light on the phone flashes and an
alert sounds. When the system locates
services, the greeting message displays along
with the time and date. You can now place and
receive calls.
If the phone is out of service, the No Service
icon ( ) appears on the display. In this case,
you cannot place and receive calls. You can try
again later when service is available.
Note
: You can change the display language in
the
Language
menu (
Menu 9-5-5
). For
further details, see page 112.
3. When you wish to switch off the phone, press
and hold for more than two seconds until
the power-off image displays.
WARNING!
Do not switch on the phone when mobile phone
use is prohibited or when it may cause
interference or danger.
Note
: As with any other radio-transmitting device,
do not touch the antenna unnecessarily when
the phone is switched on. Contact with the
antenna affects the call quality and may cause
the phone to operate at a higher power level
than otherwise needed.
Getting started
20
Using the soft keys
Your phone offers a set of functions that allows
you to customize it. These functions are arranged
in menus and submenus, accessed using the two
soft keys, and . Each menu and submenu
allows you to view and alter the settings of a
particular function.
The roles of the soft keys vary depending on the
current function you are using; the labels on the
bottom line of the display just above each key
indicate their current role.
Example:
Menu Contacts
VIVO ao VIVO
9:43ATue May 04
Press the left soft
key to access Menu
mode.
Press the right soft
key to access the
Contacts
menu.
Getting started
21
Your phone’s modes
Standby mode
Standby is the most basic state of your phone.
The phone goes into Standby mode after you turn
it on or whenever you briefly press . When your
phone is in Standby mode, you will typically see
the greeting message and the current time and
date. If you enter a phone number, you can press
to dial it or press the
Save
soft key to save it
in Contacts.
Press at any time to return to Standby mode.
Be careful; if you are on a call when you press ,
the call disconnects and the phone returns to
Standby mode.
Talk mode
You can place and answer calls only when your
phone is turned on. During a call, the phone is in
Talk mode. While you are in Talk mode, pressing
the
Menu
soft key gives you a list of options. See
page 36 for details.
Power Save mode
Your phone comes with a Power Save feature that
is automatically activated if your phone is unable
to find a signal after 15 minutes of searching.
While this feature is active, the phone’s battery
charge is conserved. The phone automatically
rechecks for a signal periodically. To manually
force the phone to recheck for a signal, press any
key.
9:43A Tue May 04
Getting started
22
Lock mode
When you lock your phone using the
Lock Phone
menu (
Menu 9-5-0-1
) in the
Security
menu,
you cannot use the phone. In Lock mode, you can
receive messages and calls, but you cannot place
an outgoing call until you unlock the phone.
To unlock the phone, you need to enter the lock
code.
For details about locking and unlocking your
phone, see page 115.
Silent mode
Silent mode disables all sounds on the phone. This
feature is best used in situations where the phone
might disturb others, such as in a meeting, in a
library, or in a theater. Your phone can be set to
Silent mode with a press of a key in Standby
mode.
In Standby mode, press and hold until “Enter!
Silent mode” and the Vibration icon ( ) display.
To exit and reactivate the previous sound settings,
press and hold until “Exit! Silent mode”
appears. The Vibration icon no longer displays.
Call functions
23
Call functions
Making a call
In Standby mode, enter the area code and phone
number and press .
Note
: When you have activated the
Auto Retry
menu (
Menu 9-5-4
), the phone will
automatically retry to make the call if no one
answers or the line is busy. See page 112 for
further details.
While entering a number, press the
Save
soft key
or to save the number in Contacts. Press the
Menu
soft key to access the following options:
4-digit Dial
: allows you to use the 4-digit Dialing
feature. This option is only available when you
enter 4 digits. For details, see page 28.
Speed Dial
: allows you to use the Speed Dialing
feature. This option is only available when you
enter a number corresponding to a location in
contacts. For details, see page 26.
Talk
: places a call to the number.
Save
: saves the number to Contacts.
Find
: finds a number from Contacts.
Hard Pause
: enters a hard pause.
2sec Pause
: enters a 2-second pause.
24
Correcting the number
Ending a call
When you want to end your call, press .
The length of the call displays along with the
phone number of the called person. If the number
is stored in your Contacts, the name displays. If
there is no match, you can press and store the
number in Contacts. For further details about
storing the number in Contacts, see page 84.
Alternatively, simply close the phone to end a call.
Emergency dialing
You can place calls to standard emergency
numbers, such as 190, 192, 193, and three
specified numbers on the Emergency # list, even
if your phone is locked or all of the outgoing calls
are restricted.
For further details about emergency numbers, see
page 117.
To clear the Press
last digit displayed .
whole display and hold it for more
than one second.
Call functions
25
Using the recent call logs
The phone stores up to 30 of the calls you have
dialed, received, or missed chronologically. The
last call is saved in the first position.
To recall any of these numbers:
1. If there are any characters on the display,
return to Standby mode by pressing .
2. Press . The list of recent calls displays.
The following icons indicate the types of calls:
• : Outgoing calls
• : Incoming calls
• : Missed calls
3. Press the Navigation keys or the Volume keys
on the left side of the phone until you find the
number you want.
4. Press to dial the highlighted number.
Making a call from Contacts
You can store the phone numbers you called
regularly in the phone’s memory, which is called
“Contacts”. You then simply recall the number to
dial.
For further details about the Contacts feature, see
page 81.
Call functions
26
Prepend dialing
The Prepend option lets you add digits, such as
area codes and network feature activation codes,
to a phone number that is in your call logs or
Contacts.
To prepend a phone number stored in your phone:
1. Access a call log in the Call logs list by pressing
. Or access Contacts by pressing the
Contacts
soft key.
2. Select the item you want using the Navigation
keys and press .
The display shows the details of the number.
3. Press the
Menu
soft key to access the menu
pop-up list.
4. Press to select the
Prepend
option.
5. Enter the area code or network feature code.
6. Press to dial the number.
Speed dialing
Once you have stored phone numbers in Contacts,
you can dial them easily with a few presses of the
keys.
Note
: When several numbers are saved in one name
entry, the first number you entered is
automatically specified as a speed dial
number. To change the speed dial number,
use
Speed dial
of the Contacts options; see
page 85.
One-touch dial
Call functions
27
Memory locations 001 through 009 are special
one-touch locations. You can dial the phone
numbers stored in Contacts from 001 through 009
simply by pressing one key.
Press and hold the third digit of the memory
location.
For example: Location no. 009
Press and hold .
The number (and name) stored displays, and then
dials.
Two-touch dial
Memory locations 010 through 099 are special
one-touch locations.
Press the second digit(s) briefly, then hold down
the last digit of the memory location.
For example: Location no. 023
Press briefly and hold down
.
The number (and name) stored displays, and then
dials.
Three-touch dial
Memory locations 100 through 500 are special
three-touch locations.
Press the first two digit(s) briefly, then hold down
the third digit of the memory location.
For example: Location no. 123
Press and briefly, then
hold down .
The number (and name) stored displays, and then
dials.
Call functions
28
4-digit dialing
You can quickly dial a phone number in Contacts
by entering its last 4 consecutive digits. This
feature is convenient if you have the number
memorized, but you have forgotten where the
number is stored in your Contacts.
1. Enter the last 4 digits of the phone number you
want to dial.
2. Press the
Menu
soft key and select the
4-digit
Dial
option. The phone displays the phone
number that matches the four digits.
If the phone found more than one number that
contains those four digits, it displays the first
number. Scroll through the numbers using
or to select a number.
3. Press to dial the number.
Pause dialing
When you call an automated system, like a
banking service, you are often required to enter a
password or account number. Instead of manually
entering the numbers each time, you can store
the numbers in your Contacts, separated by
pauses.
There are two kinds of pauses that can be entered
on your phone:
Call functions
29
•
Hard pause
: A hard pause stops the dialing
sequence until you press .
•
2-sec pause
: A 2-second pause stops the
dialing sequence for 2 seconds and then
automatically sends the remaining digits.
Note
: Multiple two second pauses can be entered to
extend the length of a pause. Keep in mind
that pauses count as digits towards the 32
digit dialing maximum.
Storing pauses in a Contacts entry
To store a number in your Contacts that contains
pauses:
1. Enter the phone number you want to store,
such as the bank’s teleservice phone number.
2. Press the
Menu
soft key to access the options.
3. Select the required pause type and press .
• Press for
Hard Pause
. The letter “P”
displays, meaning that a hard pause will
occur at that point in the dialing sequence.
• Press for
2sec Pause
. The letter “T”
displays, meaning that a 2-second pause will
occur at that point in the dialing sequence.
Call functions
30
4. Enter the digits that need to follow the pause,
such as your account number.
5. Repeat steps 2 through 4 to add more pauses
and numbers, if necessary.
6. Store the number in your Contacts as you
normally would by pressing or the
Save
soft
key and following from step 2 on page 84.
Pause dialing from a stored Contacts
entry
1. Dial the number of the service from Contacts.
2. If you stored the number using a hard pause,
wait for the appropriate prompt from the
number you are calling. When prompted, press
to send the DTMF (Dual tone multi-
frequency) number that follows the pause.
If you stored the number using a 2-second
pause, your phone transmits the number that
follows the “T” pause two seconds after the
connection.
3. “Sending DTMF” flashes on the display and the
transmitted tone sounds.
4. Repeat from step 2, if necessary.
Manual pause dialing
You can enter pauses manually during the dialing
process.
1. Enter the phone number of the service you
want to call, such as a bank’s teleservice
number.
2. Press the
Menu
soft key to access the options.
Call functions
31
3. Select the required pause type and press .
• Press for
Hard Pause
. The letter “P”
displays, meaning that a hard pause will
occur at that point in the dialing sequence.
• Press for
2sec Pause
. The letter “T”
displays, meaning that a 2-second pause will
occur at that point in the dialing sequence.
4. Enter the number to be sent after the pause
and then press to dial the first number.
5. For a hard pause, press again at the
prompt to send the additional number after
connecting.
If you enter the number using a 2-second
pause(s), the phone sends the number that
follows the pause two seconds after the
connection.
Voice dialing
Once you have stored a phone number in
Contacts, you can dial it simply by saying the
associated name or the number.
Before using the Voice Dial feature, you first need
to program your phone to recognize your voice
Call functions
32
and pronunciation in the
Voice Dial
menu (
Menu
9-4
). For details, see page 109.
To begin voice dialing:
1. In Standby mode, open the phone or press and
hold , depending on the setting in the
Set
Active
menu (
Menu 9-4-3
).
For details about the menu, see page 109.
2. At a prompt, say
Name Dial
or
Digit Dial
.
3. Say a name or a phone number to the
microphone.
4. When the phone confirms the name or number
you said, say “Yes” to place a call.
Alternatively, say “No” to cancel.
Call functions
33
Adjusting the volume during a call
During a call, if you want to adjust the voice
volume, use the Volume keys on the left side of
the phone.
Press to increase the volume level and to
decrease the level. The image on the display
shows all eight levels; the more bars you see, the
higher the level is.
In Standby mode, you can also adjust the keypad
tone volume using these keys.
Call functions
34
Answering a call
When somebody calls you, the phone alerts you
by ringing and blinking the service light.
If the caller can be identified, the caller’s phone
number, or name if stored in your Contacts,
displays.
There are three ways to answer a call depending
on your setting in the
Call Answer
menu (
Menu
9-5-3
):
To end the call, close the phone or press .
Note
: You can answer a call while using Contacts or
menu functions. The current operation stops.
If you select To answer the call,
Any Key open the phone or press any
key, except and the
Volume keys.
Send Key press .
Folder Open open the phone or press
.
Call functions
35
Silencing a call ringer
You can silence the ringer when a call comes in by
pressing one of the Volume keys on the left side of
the phone. If the phone is open, you can also
press .
The “Ringer Silenced” message appears and the
phone does not ring.
Viewing missed calls
If you fail to answer a call for any reason, the
phone indicates the missed call by displaying a
text notification on the screen. Additionally, if
caller information is available, a Missed entry is
created and the screen displays the phone number
of the last missed call.
When the display informs you of the missed call,
press to dial the number, or to clear the
message and return to Standby mode.
To view missed calls, access the
Missed
menu
(
Menu 7-3
). For details, see page 79.
Call functions
36
Options during a call
Your phone provides a number of functions that
you can use during a call. As many of these
options are network services, you may not be able
to use all of them at all times.
Press the
Menu
soft key during a call to access
the following options:
Contacts
: allows you to access the
Contacts
menu. See page 81 for details.
Mute/Quit
: allows you to switch your phone’s
microphone off, so that the other person on the
phone cannot hear you.
Example: You wish to say something to a person
in the room, but do not want the other person on
the phone to hear you.
Silent/Quit
: does not sound the key tones. It
allows you to press keys without hearing annoying
key tones during a call.
Send Tel#
: sends your telephone number to the
other person’s phone.
Calls
: allows you to access the
Calls
menu. For
details, see page 77.
Messages
: allows you to use the
Torpedo SMS
menu. For details, see page 68.
Planner
: allows you to access the
Planner
menu.
For details, see page 89.
Voice Privacy
: allows you to access the
Voice
Privacy
menu. For details, see page 118.
Call functions
37
Using caller ID
This feature tells you who is calling you by
displaying the caller’s number when the phone
rings. If the number is stored in your Contacts,
the corresponding name is also displayed. If you
call someone who has this feature, your phone
number displays on her/his phone.
Note
: Contact your service provider to set up the
Caller Line Identification service.
Call forwarding
This network feature allows you to forward
incoming calls to another phone number, even
while your phone is turned off. Activating Call
forwarding does not affect outgoing calls made
from your phone.
Note
: Contact your service provider to activate Call
forwarding.
Call functions
38
Call waiting
Call Waiting lets you receive a second call during a
conversation. Your phone notifies you of a waiting
call by beeping and displaying “Call Waiting.”
Your network provides you with the option of
turning the Call Waiting feature on and off, if you
have subscribed to the service. Call Waiting is on
by default in the phone. If you choose to have a
undisturbed conversation, simply turn off the
feature for the current call.
Note
: Contact your service provider to activate the
Call Waiting service.
To answer a waiting call during a call:
1. When you hear a beep telling that you have a
waiting call, press . The phone connects the
calling person and places the current call on
hold.
2. Press again to switch between the two
calls.
Note
: If you do not respond to a call waiting
notification, the phone will forward the call to
the voice mail server or another number that
you have set up. Contact your service
provider for more information.
Call functions
39
Three-way calling
This feature enables you to conduct conference
calls with two separate people at the same time.
The phone records both of them into the Outgoing
call log and you are billed air time for each of
outgoing calls separately. Contact your service
provider to activate Three-way calling.
To place a Three-way call:
1. During a conversation, press . The phone
places the other person on hold.
2. Enter the phone number for the third person,
and then press . The phone dials the third
person.
3. When you are connected to the person, press
again to begin your Three-way call.
If one of the callers (not you) hangs up, you and
the remaining caller stay connected. If you initiate
the call and hang up first, all three participants are
disconnected.
40
Entering text
At many times when using your phone, you will
need to enter text, such as when storing a name
in Contacts, creating your personal greeting, or
scheduling events on your calendar. You can enter
alphanumeric characters into your phone using
your phone’s keypad.
Your phone has the following text input modes:
•
T9(English) mode
: This mode allows you to
enter words with only one keystroke per letter.
Each key on the keypad has more than one
letter; for example, pressing can enter J, K,
or L. However, T9 mode automatically compares
the series of keystrokes you make with an
internal linguistic dictionary to determine the
most likely word, thus requiring far fewer
keystrokes than the traditional Alphabet
mode.
•
Alphabet mode
: This mode allows you to enter
letters by pressing the key labeled with the
letter you want. Press the key once, twice, three
or four times until it displays.
•
Symbol mode
: This mode allows you to enter
various symbols and punctuation marks.
•
Number mode
: This mode allows you to enter
numbers.
Note
: The T9 mode supplies an appropriate
language database as your language setting
menu (
Menu 9-5-5
).
Entering text
41
Changing the text input mode
When you are in a field that allows characters to
be entered, you will notice the text input mode
indicator on the display.
Example: Entering a name for a Contacts entry
To change to another text input mode:
1. Press the
Menu
soft key.
2. Scroll to the mode you want by pressing the
Navigation keys.
3. To select the highlighted mode, press . If you
want to exit the menu without changing to a
new mode, press .
The selected text input mode indicator appears
on the display.
Menu Back
Text input
mode indicator
Entering text
42
Using T9 (English) mode
T9 is a predictive text input mode that allows you
to key in any character using single keystrokes.
This text input mode is based on a built-in
dictionary.
To enter a word in T9 mode:
1. Press the keys on the phone just once per
desired letter. For example, to enter “Hello”,
press , , , , and .
2. The word that you are typing appears on the
display. It may change with each key that you
press.
3.
Type to the end of the word before editing or
deleting any keystrokes.
4. Put a space between each word by pressing
.
If the word doesn’t display correctly, press
repeatedly to display alternative word choices
for the keys that you have pressed.
Example: Both “of” and “me” use and
. The phone displays the most
commonly used choice first.
5. Continue entering the next word.
Note
: To type words not found in T9 mode, you need
to change the text input mode to Alphabet
mode.
Smart punctuation
Entering text
43
Periods, hyphens, and apostrophes are available
by pressing . T9 mode applies rules of
grammar to insert the correct punctuation. Notice
that is used twice in this example to display
two punctuation marks:
Changing the letter case
To shift case of the next letter(s) that you type,
press . There are three cases:
• Initial Capital (
T9Word
)
• Capitals Lock (
T9WORD
)
•Lower Case (
T9word
)
Inserting a space
Press to insert a space between words.
Including a number
You can include a number between letters without
exiting T9 mode. Press and hold the
corresponding number key.
Scrolling
To move the cursor to the left or right through
your text, press or .
Clearing letters and words
Press once or repeatedly to clear letters one
by one to the left. Press and hold to erase all
of the letters on the display.
L e t s e a t .
Entering text
44
Using Alphabet mode
When typing in Alphabet mode, you need to press
the keys labeled with the letter you want:
- once for the first letter
- twice for the second letter
- and so on
This method is called multi-tap typing.
For example, you press three times to display
the letter “C” and two times to display the
letter “K.”
The cursor moves to the right when you press a
different key. When entering the same letter twice
or a different letter on the same key, just wait for
a few seconds for the cursor to move to the right
automatically, and then enter the next letter.
Refer to the table below for the list of characters
assigned on each key.
(Caps Lock mode)
Key Characters in the Order Displayed
. @ ? ! - , & : ’ 1
AB C 2
DE F 3
GH I 4
JKL 5
MN O 6
PQR S 7
TU V 8
WX Y Z 9
0
Entering text
45
Changing the letter case
To shift case of the next letter(s) that you type,
press . There are three cases:
• Initial Capital (
Abc
)
• Capitals Lock (
ABC
)
•Lower Case (
abc
)
Inserting a space
Press to insert a space between words.
Including a number
You can quickly include a number between letters.
Press and hold the corresponding number key.
Scrolling
To move the cursor to the left or right through
your text message, press or .
Clearing letters and words
Press once or repeatedly to clear letters one
by one to the left. Press and hold to erase all
of the letters on the display.
Entering text
46
Using Symbol mode
Symbol mode enables you to enter symbols into
your text.
Press or to display more symbol sets.
Press the keys corresponding to the symbol you
want, then the phone automatically switches back
to the text input mode used just prior to selecting
Symbol mode.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you
want to enter and manually switch back to the
text input mode of choice. For details about
changing the mode, see page 41.
MENU
Entering text
47
48
Using the menus
This phone offers a range of functions that allow
you to tailor the phone to your needs. These
functions are arranged in menus and submenus.
The menus and submenus can be accessed by
scrolling or by using the shortcuts.
Accessing a menu function by
scrolling
1. In Standby mode, press the
Menu
soft key to
access Menu mode.
2. Scroll using the Navigation keys to reach the
main menu; for example,
Other Functions
.
Press to enter the menu.
3. If the menu contains any submenus, for
example,
Setup
, find the one you want by
scrolling using the Navigation keys. Press to
enter the submenu.
If the menu you have selected contains
submenus, for example,
Language
, repeat
this step.
4. Scroll using the Navigation keys to select the
setting of your choice.
5. Press to confirm the chosen setting.
Notes
:
• You can return to the previous menu level by
pressing .
• You can exit the menu without changing the menu
settings by pressing .
Using the menus
49
Using shortcuts
The menu items, such as menus, submenus, and
setting options, are numbered and can be
accessed quickly by using their shortcut numbers.
Note
: The numbers assigned to each menu function
are indicated on the list on page 50.
1. In Standby mode, press the
Menu
soft key to
access Menu mode.
2. Enter the first digit of the shortcut number.
Repeat this for each digit of the shortcut
number.
Example: Accessing the
Language
menu
Press , , and
.
selects
Other functions
,
selects
Setup
, and
selects
Language
.
3. Scroll using the Navigation keys to select the
setting of your choice.
4. Press to confirm the chosen setting.
Using the menus
50
List of menu functions
The following list shows the menu structure and
indicates the number assigned to each option.
1. Downloads
(see page 54)
2. WAP
(see page 57)
2.1 Get In WAP
2.2 Prompt
2.3 Push SL Option
3. Voice Mail
(see page 63)
3.1 Voice Mail
3.2 Voice Mail#
4. Voice Portal
(see page 64)
4.1 Voice Portal
4.2 Voice Portal#
5. Messaging
(see page 65)
5.1 Messenger
5.1.1 Messenger
5.1.2 Messenger #
5.2 Chat
5.2.1 Chat
5.2.2 Chat #
5.3 Torpedo SMS
5.4 E-mail
5.4.1 E-mail
5.4.2 E-mail #
Using the menus
51
6. Torpedo SMS
(see page 68)
6.1 New Msg
6.2 Voice
6.3 Inbox
6.4 Sent
6.5 Draft
6.6 Saved
6.7 Web Alert
6.8 Erase Msg
6.8.1 Voice
6.8.2 Old Inbox
6.8.3 New Inbox
6.8.4 Sent
6.8.5 Draft
6.8.6 Saved
6.8.7 All Messages
6.9 Msg Setting
6.9.1 Scroll Timer
6.9.2 Msg Reminder
6.9.3 Auto Erase
6.9.4 New Msg
6.9.5 Canned Msg
7. Calls
(see page 77)
7.1 Outgoing
7.2 Incoming
7.3 Missed
7.4 Erase History
7.4.1 Outgoing
7.4.2 Incoming
7.4.3 Missed
7.4.4. All Calls
7.5 Air Time
7.5.1 Last Call
7.5.2 Total
7.5.3 Life Time
7.5.4 Erase Total
Using the menus
52
8. Contacts
(see page 81)
8.1 Find
8.2 Add New Entry
8.3 Group Setting
8.4 My Phone#
8.5 Memory
9. Other Functions
(see page 89)
9.1 Planner
9.1.1 Voice Memo
9.1.2 Today
9.1.3 Scheduler
9.1.4 Task List
9.1.5 Memo Pad
9.1.6 Alarm
9.1.7 Calculator
9.1.8 World Time
9.1.9 Count Down
9.1.0 Set Time
9.2 Display
9.2.1 Menu Style
9.2.2 Wallpaper
9.2.3 Backlight
9.2.4 Banner
9.2.5 Launch Pad
9.2.6 Dual Clock
9.2.7 Contrast
9.2.8 Service LED
9.3 Sounds
9.3.1 Ringer Volume
9.3.2 Ringer Type
9.3.3 Keytone
9.3.4 Alerts
9.3.5 Roam Ringer
9.3.6 Tone Length
9.3.7 Power On/Off
Using the menus
53
9.Other Functions
(continued)
9.4 Voice Dial
9.4.1 Adapt Digits
9.4.2 Reset Digits
9.4.3 Set Active
9.4.4 Choice List
9.4.5 Help
9.5 Setup
9.5.1 Auto CSP
9.5.2 Auto Answer
9.5.3 Call Answer
9.5.4 Auto Retry
9.5.5 Language
9.5.6 Select NAM
9.5.7 Set System
9.5.8 Data/Fax
9.5.9 Version
9.5.0 Security
9.5.0.1 Lock Phone
9.5.0.2 Change Lock
9.5.0.3 Restriction
9.5.0.4 Emergency #
9.5.0.5 Erase Contacts
9.5.0.6 Reset Phone
9.5.0.7 Voice Privacy
54
Downloads
This menu allows you to download various
multimedia files from the wireless web.
Downloading multimedia files
1. Press when the
Download Center
icon is
selected.
The following options are available:
•
Catalog
: allows you to browse and purchase
applications.
•
Search
: allows you to search for an
application by entering a keyword.
•
About Download
: provides you with the
help information about using the
Download
Center
menu.
2. Press when the
Catalog
option is selected.
You are accessed to the associated web site
preset by your service provider and you can
browse the available applications.
Note
: When the
Airtime warnings
option is set to
All enabled
, a confirmation message
appears. Select Yes and press to access
the web.
3 . Se le ct the ap pl ica ti on you wa n t t o d own lo ad a nd
follow the instructions on the screen.
Downloads
55
Changing the browser settings
1. Select the
Settings
icon using or and
press .
2. Select a setting option using or and
press .
The following options are available:
•
Order Apps
: allows you to change the order
of the downloaded applications.
•
Move Apps
: allows you to move an
application to the other folder.
•
Manage Apps
: shows the amount of the
memory used for downloaded applications.
•
Main Menu View
: allows you to change the
view mode of the main menu screen.
•
Airtime Warnings
:
allows you to select
whether or not your phone gives you a
confirmation message each time you access
the web to download applications.
•
View Log
: shows the records of your
browsing.
3. When you have finished, press or .
Downloads
56
Viewing help information
1. Select the
Help
icon using or and press
.
2. Select a help item by using or and
press .
3. Press or to scroll through the
information.
4. To go back to the main help screen, press or
.
57
WAP
About the WAP browser
Your phone comes equipped with a WAP (Wireless
Application Protocol) browser which makes it
possible for you to access the wireless web.
The WAP browser allows you to access up-to-the
minute information through your phone. Browsing
the WAP through your phone is unlike using your
computer; site providers have selected only the
critical aspects of their sites to present to wireless
phone users and they have removed most of the
graphics.
Each time you start the WAP browser, the phone
will connect to the WAP and the Service icon ( -
packet service,
- circuit service) will appear on
the display. Any time this icon is visible on the
display, you are connected to the web and will be
billed accordingly. Rates will vary according to
your service plan.
The WAP browser will end the connection after a
certain period of network inactivity and will
automatically reconnect as necessary. For this
reason, you may find that you are billed for
several network connections within a single
session. This is normal and is designed to
minimize your bill.
Note
: Changing the language (
Menu 9-5-5
)
doesn't affect the display language in the WAP
browser.
WAP
58
Get In WAP
(Menu 2-1)
When a new WAP push message comes in, the
display shows the Push Message icon ( ).
1. Accessing the
Get In WAP
menu (
Menu 2-1
)
connects your phone to the WAP.
2. If a reminder appears depending on your
setting in the
Prompt
menu (
Menu 2-2
),
simply answer the
Yes
or
No
by pressing
or .
3. Once you are connected, the home page or the
last page you visited displays.
The opening page contents may be different
according to your WAP service provider.
4. To scroll through the screen, use or .
Exiting the WAP browser
To exit the WAP browser, simply press at any
time.
If the
To End
or
Both
option is set in the
Prompt
menu (
Menu 2-2
), you will be prompted whether
you want to end the browser call. Simply answer
the
Yes
or
No
by pressing or .
Using the WAP browser soft keys
At the bottom of the WAP browser display is a
solid bar which contains browser commands.
or is used to execute the commands. These
two keys are called soft keys because their
functions change depending on where you are in
the WAP browser software.
WAP
59
Navigating the WAP browser
When you use the WAP browser, some keys on
your phone operate differently than when on a
normal phone call.
Here’s how the keys work in the WAP browser:
Up/Down Navigation keys
: allow you
to scroll up or down to select browser
options. You can also use these keys to
move the cursor when editing text.
Left/Right cursor key
: allows you to
move the cursor to the left or right in a
text entry.
End key
: allows you to exit the Web
Browser and return the phone to
Standby mode.
Clear/Back key
: performs two
important functions:
• Sends you back in the browser.
Pressing it once sends you back one
page. Pressing and holding this key
sends you back to the home page.
• Removes entered text or numbers.
When entering text, press this key to
clear the last number, letter, or
symbol. Press and hold this key to
completely clear the input field.
Numbered keys 1 ~ 0
: If the items on
a page are numbered, you can use
these keys to select them.
Volume keys
: allows you to scroll up
or down one page.
WAP
60
Using the browser menus
On the WAP browser, you can access the following
options by pressing and holding the
Menu
soft
key:
Home
: takes you back at any time to the
homepage of the WAP service provider.
Forward
: goes to the previous screen.
Bookmarks
: allows you to directly load a
bookmarked WAP page.
Go To URL
: allows you to manually enter the URL
address of a web page. After entering an address,
press the
Go
soft key.
Show URL
: displays the URL address of the site
where you are currently connected.
History
: shows the records of your connection to
the wireless web.
Search
: allows you to use the Web Search
features of your service provider.
Reload
: reloads the current WAP page.
Snapshots
: takes a snapshot for the current web
page.
Advanced
: gives you access the following
advanced features:
Restart browser: restarts the browser without
exiting it.
Delete Cookies: deletes all of the cookies and files.
A cookie is a piece of user’s information that is
entered when you use a web site.
WAP
61
Multimedia: enables or disables auto download of
the media objects, such as images or background
sound on the current page.
Scroll Mode: lets you select the scroll mode to
either
Block
or
Smooth
, or set the speed for
scrolling to the next screen to either
Fast
,
Medium
, or
Slow
.
Send Referrer: allows you to set the browser to
send HTTP referrer information to the web server
each time the browser is launched.
Connection Timeout: allows you to set how long
the phone keeps connection to the current web
page when you don’t use the web page for a
specified period. You can select
30secods
or
60seconds
.
Key Press Timeout: allows you to set how long the
phone waits after you have pressed a key before
moving the cursor right in a text input mode. You
can select
Fast
,
Medium
, or
Slow
. If you don’t
want to set the timeout, select
Off
.
Security: displays all security-related information,
such as Secure Prompt, Authentication, and
Current Certificate.
About
: provides you with information about
Openwave and your version of the WAP browser.
Entering text in the WAP browser
When prompted, you can enter letters, numbers
or symbols same way as in Phone mode. See page
41 for further details about how to enter
characters.
WAP
62
Prompt
(Menu 2-2)
Your phone can give you a prompt to confirm your
browser session. You can set the phone to display
the prompt or not to display.
The following options are available:
None
: You do not receive a prompt.
To Start
: You will see the prompt when you enter
the browser, but not when you exit it.
To End
: You will see the prompt only when you
exit the browser.
Both
: You will be prompted when you enter or
exit the browser.
Push SL Option
(Menu 2-3)
This menu allows you to set what happens if a
new WAP push message is received from the web
server.
The following options are available:
Permit
: The phone automatically receives a new
WAP push message from the server without
notification.
Ask
: The phone asks you if you want to access a
new WAP push message each time it is arrived.
Deny
: The phone rejects any WAP push
messages.
63
Voice Mail
This menu allows you to access your voice
mailbox, if your network supports this service.
Voice Mail
(Menu 3-1)
Accessing this menu places a call to the voice mail
server to allow you to access your voice mailbox.
Note
: For further information about options during a
call, see page 38.
Voice Mail#
(Menu 3-2)
This menu allows you to view or change the voice
mail server number, if necessary.
Note
: Voice mail is a network feature. Please
contact your service provider for further
details.
64
Voice Portal
Voice Portal is a service that enables you to get
Voice contents over your mobile phone.
Note
: Voice Portal is a network feature. Please
contact your service provider for further
details.
Voice Portal
(Menu 4-1)
This menu allows you to access your service
provider’s voice-activated service. You can get
headline news, get information on movies, the
weather, finance, traffic, or restaurants in many
cities, plus other features; it's similar to the kind
of content that's available on a Web portal.
1. Access the
Voice Portal
menu (
Menu 4-1
).
2. Press .
You are accessed to the voice service preset by
your service provider.
3. Follow the voice prompts.
Voice Portal#
(Menu 4-2)
This menu allows you the view the voice portal
service number.
65
Messaging
In this menu, you can use various messaging
services, such as:
• Messenger
•Chat
• Torpedo SMS (Short Message Service)
•E-mail
Messenger
(Menu 5-1)
You can use the instant messenger service from
the WAP browser.
Messenger
(Menu 5-1-1)
Selecting this menu loads the WAP browser and
then gives you access to the messenger service
supplied by your service provider.
For further details about the service, contact the
service provider.
Messenger #
(Menu 5-1-2)
You can check or change the URL address of the
messenger service page.
Messaging
66
Chat
(Menu 5-2)
You can use the chatting service from the WAP
browser.
Chat
(Menu 5-2-1)
Selecting this menu loads the WAP browser and
then gives you access to the chatting service
supplied by your service provider.
For further details about the service, contact the
service provider.
Chat #
(Menu 5-2-2)
You can check or change the URL address of the
chatting service page.
Torpedo SMS
(Menu 5-3)
Your phone can receive and send text messages
and numeric pages using Short Message Service
(SMS). You can also manage voice mails and web
alert messages.
For details about this menu, see page 68.
Messaging
67
E-mail
(Menu 5-4)
You can use the e-mail service from the WAP
browser.
E-mail
(Menu 5-4-1)
Selecting this menu loads the WAP browser and
then gives you access to the e-mail service
supplied by your service provider.
For further details about the service, contact the
service provider.
E-mail #
(Menu 5-4-2)
You can check or change the URL address of the e-
mail service page.
68
Torpedo SMS
Your phone can receive voice mail notifications,
text messages, and web messages from your web
server. Your phone can also send text messages, if
your service provider supports this service.
Incoming messages are received even when your
phone is in Lock mode. However, the screen does
not display information about the message. To
access the message, you need to unlock the
phone.
If you receive an incoming message during a call
conversation, your phone sounds an alert tone,
depending on your sound settings.
New Msg
(Menu 6-1)
You can create a short text message and send it to
other mobile phones.
Note
: Message transmission is available only when
your phone is operating in a digital network
and if service is supported by your service
provider.
Writing and sending a text message
1. Enter a destination number using the numeric
keys and press the
Next
soft key or .
If you press the
Menu
soft key and select
Contacts
, you can search Contacts for a
number.
Torpedo SMS
69
2. To send your message to multiple destination,
press and enter another number. Repeat
this step, as needed.
3. Enter the message contents.
For further details about how to enter text, see
page 40.
You can use up to 30 canned messages by
pressing the
Menu
soft key and selecting
Canned MSG
. For details, see page 76.
4. When you have finished entering the message,
press .
5. To select an option, press or .
The following options are available:
•
Send to
: Press to change the destination
number. You can also add more destination
numbers by pressing .
•
Msg
: Press to change the message
contents you’ve already entered.
•
CB #
: Press to change the callback
number.
•
Options
: Press to access the following
setting options. Scroll to an option using
or and change the setting using or .
- Priority: Select the message priority.
- Delivery Ack: Turn the delivery
acknowledgement feature on or off. When
this is activated, the network informs you
whether or not your message has been read
by the recipient.
Torpedo SMS
70
- Message Save: Set whether or not the
phone saves the message in the Outbox
after sending. When you select
Prompt
Save
, the phone asks if you want to save
the message.
•
Draft
: Press to saves the message in the
Draft
(
Menu 6-5
) for later use.
6. Repeat step 4 to set the message options.
7. After changing the setting options, press or
the
Send
soft key to send the message.
Note
: Closing the phone or pressing before the
message is sent stops the transmission.
Voice
(Menu 6-2)
When you access this menu, the display shows the
latest voice mail notification. If there are more
than one notification, scroll to the one you want
by pressing the Navigation keys.
Press the
Call
soft key to access the voice mail
server to listen to the message.
Torpedo SMS
71
Inbox
(Menu 6-3)
Your phone can store SMS messages and their
corresponding Caller ID in the phone’s memory.
When the phone receives a text message, the New
Message icon ( ) and a text notification with the
call back number appear. Press to view the
message immediately. Alternatively, press to
access the message from the Inbox at a later
time.
When you access the
Inbox
menu (
Menu 6-3
),
the list of messages you have received displays.
The icons on the left tell you the status of
messages:
• : Messages that have been opened.
• : Messages that have not been opened.
• : Urgent messages. The red one means that
the message has not been opened and the
blue one means that the message has been
opened.
To view a message, press the Navigation keys to
scroll to the message you want and press . The
phone displays the contents. If necessary, press
or to scan through the message.
While viewing a message:
•Press the
Menu
soft key to use the following
options:
Reply
: allows you to send a reply message to the
sender.
Forward
: allows you to forward the message to
another person.
Delete
: deletes the currently selected message
from the Inbox.
Torpedo SMS
72
Talk
: places a call to the callback number.
Save
: allows you to save the sender’s phone
number to contacts.
Move
: allows you to move the message from the
Inbox to the Saved box.
Extract #’s
: allows you to extract phone numbers
from the message text.
Extract Email
: allows you to extract e-mail
addresses from the message text.
Extract URL
: allows you to extract URL addresses
from the message text.
•Press the
Reply
soft key to send a reply
message to the sender. For further details about
sending a message, see page 68.
Sent
(Menu 6-4)
Your phone can store your outgoing messages.
When you access this menu, the list of the
messages you have sent appears. The icon on the
left tell you the status of messages:
• : Messages that have been sent.
• : Messages that your phone couldn’t send.
• : Messages that is waiting to be sent.
To view a message, press the Navigation keys to
scroll to the message you want and press . If
necessary, press or to scan through the
message. You can move to the next or previous
message by pressing or .
While reviewing a message:
Torpedo SMS
73
•Press the
Menu
soft key to access the following
options:
Resend
: allows you to resend the message.
Delete
: deletes the message from the Outbox.
•Press the
Resend
soft key to resend the
currently selected message. For further details
about sending a message, see page 68.
Draft
(Menu 6-5)
After creating a text message, you can store it in
this message box to be sent at a later time.
For further details about viewing a message, see
“Sent” on page 72.
Saved
(Menu 6-6)
In this menu, you can view the message you have
sent from the Inbox to this message box.
For further details about viewing a message, see
“Sent” on page 72.
Web Alert
(Menu 6-7)
When you receive a new web message from the
web server, your phone alerts you and the
following options display:
View
: allows you to access the Web Inbox to
display the web message.
Clear
: exits the notification. Select this option if
you do not wish to read the message at this time.
You can press .
Torpedo SMS
74
To select an option, scroll to it and press . If
you select
Clear
, the message is stored in the
Web Alerts
menu.
When you access the
Web Alert
menu (
Menu 6-
7
), a list of the received web message displays.
Press or to scroll to the message you want
to view and press . The phone starts the WAP
browser and displays the message contents. If
necessary, press or to scan through the
contents.
Erase Msg
(Menu 6-8)
Using this menu, you can erase all of the
messages in each message box. You can also
erase all of the messages at one time by selecting
All Messages
.
When a confirmation message appears, select
Yes
and press .
Msg Setting
(Menu 6-9)
In this menu, you can preset several options for
receiving or sending messages.
Scroll Timer
(Menu 6-9-1)
If an incoming message is too long for the display,
the phone displays it by scrolling the screen
automatically. You can set the time interval the
phone scrolls to the next screen from 1 to 5
seconds.
When you select
Off
, you need to manually scroll
to the next screen using the Navigation keys.
Torpedo SMS
75
Msg Reminder
(Menu 6-9-2)
When a new message is received, the phone alerts
you by sounding the selected ringer. You can set
how often this will happen.
The following options are available:
Off
: The phone alerts you just once at the time of
its receipt.
Once
: The phone alerts you just once when you
receive an incoming message.
Every 2 min
: The phone alerts you every 2
minutes until you open the message.
Auto Erase
(Menu 6-9-3)
You can set whether or not the phone will
automatically erase the oldest message when the
phone’s memory is full and a new message is
received.
The following options are available:
On
: The phone automatically erases the oldest
message to receive a new message when the
phone’s memory is full.
Off
: The phone displays a warning message when
the phone’s memory is full. Any new incoming
messages will be unable to be saved.
New Msg
(Menu 6-9-4)
You can set up the following options as default
settings when creating a new message. The
following options are available:
Torpedo SMS
76
Callback #
: allows you to set the call back
number. It is preset to your phone number at the
factory.
Save Message
: allows you to set whether or not
sent messages are saved in the Sent box.
Do Not Save: The phone does not save the
message.
Prompt Save: The phone asks you whether or not
you want to save the message.
Auto Save: The phone automatically saves the
message.
Entry Method
: allows you to select the text input
mode between
T9 Word
(T9 English) and
Alphabet
.
Delivery Ack
: allows you to activate or deactivate
the delivery acknowledgement. When this option
is activated, the network informs you when your
message is delivered to the recipient.
Canned Msg
(Menu 6-9-5)
This menu allows you to edit 10 canned messages
and make up to 20 new canned messages. You
can use the messages when writing a message.
1. Select an empty location or the message you
want to change using or .
2. Press the
Edit
soft key.
3. Clear the existing message using , if
necessary, and enter a new message.
For further details about entering characters,
see page 41.
4. Press the
Save
soft key or to save the
message.
77
Calls
You can use the
Calls
menu to:
• view and dial the most recent outgoing,
incoming, or missed numbers.
• erase the numbers in the call log memory.
• view the duration of calls.
Outgoing
(Menu 7-1)
The phone stores up to 10 of the most recent
numbers you have dialed. When you access this
menu, a list of the outgoing calls displays.
1. Press the Navigation keys to find a number or
name, if it is saved in Contacts.
2. Press to confirm the highlighted number.
The dialed number or name, if it is saved in
Contacts, displays along with the time and
date the call was made.
3.
To Press
place a call to the
selected number .
use the menu
options the
Menu
soft key. For
details, see the next
page.
view other calls the Navigation keys.
return to Standby
mode .
Calls
78
When you press the
Menu
soft key on the call log
screen, the following options are available:
Talk
: dials the number.
Save
: (shown when the number is not stored in
Contacts) allows you to save the number in
Contacts.
Show Entry
: (shown when the number is stored
in contacts) displays the phone number and
memory location number.
Prepend
: allows you to add an area code or
feature code to the number before dialing the
number. See page 26 .
Erase
: allows you to erase the selected number.
Send Msg:
allows you to send messages to the
phone number.
Incoming
(Menu 7-2)
This menu lets you view up to 10 of the most
recent calls you have received if you are
subscribed to the Caller Line Identification service.
Contact your service provider for further details
about this service. When you access this menu, a
list of the incoming calls displays.
For more information about scrolling through the
list and accessing the call logs, see “Outgoing” on
page 77.
Calls
79
Missed
(Menu 7-3)
If Caller Line Identification is available, your
phone keeps a list of the most recent 10 incoming
calls that you have failed to answer. Contact your
service provider for the availability.
For more information about scrolling through the
list and accessing the call log, see “Outgoing” on
page 77.
Erase History
(Menu 7-4)
In this menu, you can erase the entries stored in
each of the 3 call logs; outgoing, incoming, and
missed calls. You can also erase all of your call log
entries at one time by selecting
All Calls
.
When a confirmation message displays, select
Yes
to erase the logs. If you want to cancel the
selection, select
No
. Press to confirm the
selection.
Calls
80
Air Time
(Menu 7-5)
Your phone records the amount of air time, or talk
time used. Using this option, you can view the
number of the calls to or from your phone, and the
air time for all of the calls. You can easily erase
the air time record at any time, except
Life Time
.
This menu is convenient for estimating your
usage.
Note
: This feature is not intended to be used for
billing purposes.
The following options are available:
Last Call
: shows the time of the last call.
Total
: shows the number of all calls you have
made or received and the total duration of the
calls since the air time counter was last set to zero
by using the
Erase Total
option.
Life Time
: shows the number and total duration
of all calls you have made or received from your
phone since the phone was shipped from the
factory.
Erase Total
: erases the last call time and total
call time and resets the air time counter.
81
Contacts
Contacts allows you to store frequently used
phone numbers and the associated names in your
personal directory to make it easy for you to make
a call without having to remember or enter the
phone number. You can store up to 500 entries
including E-mail and URL addresses.
Find
(Menu 8-1)
This menu allows you to find an entry using a
person’s name, entry number, or group name in
your Contacts.
To change the finding method, press or until
the option you want displays;
By Name
,
By
Entry
, or
By Group
.
Note
: You can quickly access this menu by pressing
the
Contacts
soft key in Standby mode.
Finding an entry by name
When you select this method, all of the Contacts
entries appear in alphabetical order.
1. If necessary, press or to scroll to
By
Name
.
2. If necessary, press to highlight the name
input box.
3. Enter the first few letters of the name you
want to find.
Contacts
82
4. If necessary, press or to scroll through
the entries.
5. When an entry highlights:
• Press to place a call to the entry’s speed
dial number.
• Press or right soft key to select the entry.
Information about the entry displays. Move
to each item by pressing or .
Press the
Menu
soft key to access one of the
following options:
-
Talk
: dials the number labeled as speed-
dial number.
-
Edit
: allows you to change the selected
item.
-
Prepend
: allows you to add digits, such as
area codes, ahead of the selected number
before dialing. see page 26.
-
Erase
: erases the entry. If you select one
of numbers for the entry, only the number
is erased.
• Press to return to the previous screen.
• Press to exit the menu.
Contacts
83
Finding an entry by entry number
When you select this method, the whole list of all
of the Contacts entries appears in numeric order.
1. Press or to scroll to
By Entry
.
2. Press to highlight the number input box.
3. Enter the location number of the entry you
want to find.
4. Follow the procedure from step 4 on page 82.
Finding an entry by group
When you select this method, a list of the
Contacts entries in a group appears.
1. Press or to scroll to
By Group
.
2. Press to move the group selection field.
3. Press or to select the group you want.
Each time you select a group, a list of the
associated entries displays.
4. Follow the procedure from step 4 on page 82.
Contacts
84
Add New Entry
(Menu 8-2)
This menu allows you to add a new entry to your
Contacts.
A name can contain up to 6 numbers in different
categories; Home, Work, Mobile, Pager, Fax and
No label. You can save only one number with a
name in the phone’s memory.
To add a new entry:
1. Enter a phone number and press .
For further details about entering characters,
see page 31.
2. When
Add New Entry
highlights, press .
3. Select an icon to identify the category of the
number to be stored using the Navigation keys
and press .
4. Enter a name and press .
For further details about entering characters,
see page 40.
5. To select an option, scroll to it by pressing
or .
The following options are available:
•
Name
: allows you to enter a name in this
step if one has not already been entered.
•
Entry
: The first available location displays. If
necessary, enter the entry number using the
number keys.
Contacts
85
•
Home
/
Work
/
Mobile
/
Pager
/
Fax
/
No label
:
allows you to store more numbers for each
category.
•
Speed dial
: allows you to select one of the
stored numbers to be used for speed dialing.
•
E-mail
: allows you to store an e-mail
address.
•
URL
: allows you to store a URL address.
•
Group
: allows you to assign the entry to a
caller group. To remove the entry from a
group, select
No Group
.
•
Caller Ringer
: allows you to select the
unique ringer to be used for alerting you to
an incoming call from the person.
•
Birthday
: allows you to save the date of the
person’s birthday.
•
Secret
: allows you to prevent a number from
being displayed when it is accessed or dialed
by unauthorized users. When this option is
set to
Secret-ON
, only people with your
phone’s lock code can view the secret
number.
•
: allows you to select an image to be
used for alerting you to an incoming call from
the person.
6. If necessary, press the
Edit
soft key and enter
information or use or to change the
setting.
7. When you have finished, press .
8. When a confirmation message displays, select
Yes
and press .
After storing, the phone displays the memory
status of Contacts for a few seconds.
Contacts
86
Storing a phone number from Standby
mode
1. In Standby mode, enter a number you want to
save.
2. Press the
Save
soft key or .
3. To complete storing the number, follow the
procedure from step 2 in “Add New Entry” on
page 84.
Adding a number into an existing entry
You can store up to 6 numbers for a name saved
in the phone’s memory by assigning them to the
different types.
1. After accessing the
Add New entry
menu
(
Menu 8-2
), enter a number and press .
2. Scroll to the entry to which you want to add
the number by pressing or .
3. Press .
4. To complete storing the number, follow the
procedure from step 3 in “Add New Entry” on
page 84.
Contacts
87
Group Setting
(Menu 8-3)
This menu allows you to change the settings for
the caller groups.
To change the name of a caller group:
1. On the Group Edit list, select the group you
want to edit using or .
2. Press the
Menu
soft key or .
3. Select the
Rename
option and press .
4. Clear the old name using .
5. Enter the name you want and press .
To change the ringer melody of a caller group:
1. On the Group Edit list, select the group you
want to edit using or .
2. Press the
Menu
soft key or .
3. Select the
Ringer
option and press .
4. Select the ringer category you want using or
and press .
5. Select the ringer you want using or .
6. Press to save.
Contacts
88
My Phone#
(Menu 8-4)
This menu shows your phone number.
After viewing, press to return to the previous
screen.
Memory
(Menu 8-5)
This menu shows you how many Contacts
locations are used or empty.
After viewing, press to return to the previous
screen.
89
Other Functions
Planner
(Menu 9-1)
The Planner feature enables you to:
• record voice memos.
• keep track of important dates and events.
• create a list of things to do and memos.
• set an alarm to ring at a specified time.
• use the phone as a calculator.
• check the current time in another part of the
world.
• count down to a specific day.
• set the current time and date.
Voice Memo
(Menu 9-1-1)
This menu allows you to record voice memos.
Recording a voice memo
You can record up to 10 voice memos of up to 1
minutes.
1. Select
Record
and press .
2. Record a memo by speaking into the
microphone.
When you are recording, a timer displays to
show you the elapsed time.
Other Functions
90
You can pause by pressing the
Pause
soft key
and then resume by pressing the
Resume
soft
key.
3. Press to end recording. The voice memo
automatically saves.
After recording the voice memo, you can
access the following options by pressing the
Menu
soft key:
Re-record
: allows you to discard the current
memo and record another one.
Erase
: allows you to erase the current memo.
Edit Caption
: allows you to change the name
of the memo.
Information
: allows you to show information
about the memo.
Reviewing a voice memo
1. Select
Review
and press .
The list of voice memos appears.
2. Scroll to the memo you want and press .
The phone plays the memo.
Erasing all of the voice memos
1. Select
Erase All
and press .
2. When a confirmation message appears, press
the
Yes
soft key.
3.
To Press the
pause
Menu
soft key.
resume
Menu
soft key again.
finish
OK
soft key.
Other Functions
91
Today
(Menu 9-1-2)
You can schedule up to 9 events for the current
day, indicating each event’s starting and ending
time. You can even have your phone's calendar
alert you before an event commences. Events
scheduled for future dates automatically appear
on your Today schedule on that day.
Scheduling a new event
1. Enter your event contents and press .
For further details about entering characters,
see page 40.
2. Enter the starting time and date using the
numeric keys.
Notes
:
• You need to enter the time in 12-hour
format. Press the
2
key for
A
(AM) or the
7
key for
P
(PM).
• You can move through the input fields using the
Navigation keys.
3. Enter the ending time and date using the
number keys.
4. Select when an alarm alerts you to the event,
by pressing or . When you select
No
Alarm
, the phone does not ring the alarm.
5. Press to store your event.
Other Functions
92
Viewing your today’s schedule
The list of the events stored on the current day
displays when you select the
Today
menu (
Menu
9-1-2
).
While viewing the event list, press the Navigation
keys to scroll to an event and:
• Press to view the event information. To view
the Start time and End time settings, use or
. You can move to the previous or next event
by pressing or .
While viewing the event, press the
Menu
soft
key to access the following options:
Edit
: allows you to edit the currently selected
event.
Erase
: allows you to erase the currently
selected event.
Add New
: allows you to add a new event.
•Press the
Menu
soft key to access the following
options:
Add New
: allows you to add a new event.
Erase
: allows you to erase the currently
selected event.
Erase All
: allows you to erase all of events.
Scheduler
(Menu 9-1-3)
This menu allows you to view the current month,
as well as past or future months in calendar
format.
On the calendar, the current day is indicated by a
colored box and the selected day is underlined.
Days with scheduled events are indicated by a box
inside the calendar day.
Other Functions
93
Selecting a day on the calendar
• You can move to the next or the previous by
pressing or .
• You can move up or down the calendar by week
by pressing or .
• You can view the next or previous month by
using the Volume keys on the left side of the
phone.
On the calendar, press the
Menu
soft key to
access the following options:
View
: allows you to view scheduled events of the
selected day.
Add New
: allows you to add a new event for the
selected day.
Erase All
: allows you to erase all of events.
Jump to date
: allows you to directly go to the
specific date you want.
Scheduling an event
You can schedule up to 9 events for one day and
70 events total.
1. Select a day on the calendar, referring to
“Selecting a day on the calendar” on page 93
and press .
2. Enter your event information and press .
For further details about entering letters, see
page 40.
3. Enter the starting time and date using the
numeric keys.
Other Functions
94
Notes
:
• You need to enter the time in 12-hour
format. Press the
2
key for
A
(AM) or the
7
key for
P
(PM).
• You can move through the input fields using the
Navigation keys.
4. Enter the ending time and date using the
number keys.
5. Select when an alarm alerts you to your event,
by pressing or .
When you select
No Alarm
, the phone does
not ring the alarm.
6. Press to store your event.
Viewing your schedule
Days with scheduled events are indicated by a
blue box on the calendar when you access the
Scheduler
menu (
Menu 9-1-3
). Select one of
them and press . The list of the events displays.
While viewing the event list, press the Navigation
keys to scroll to an event and:
• Press to the event information. To view the
Start time and End time settings, use or .
You can move to the previous or next event by
pressing or .
While viewing the event, press the
Menu
soft
key to access the following options:
Other Functions
95
Edit
: allows you to edit the currently selected
event.
Erase
: allows you to erase the currently
selected event.
Add New
: allows you to add a new event.
•Press the
Menu
soft key to access the following
options:
Add New
: allows you to add a new event.
Erase
: allows you to erase the currently
selected event.
Erase All
: allows you to erase all of events.
Task List
(Menu 9-1-4)
This feature allows you to enter a list of tasks you
need to be done and assign both priority and a
deadline to them. You can store up to 9 tasks.
Creating a new task
1. Enter the task contents and press .
For further details about how to enter
characters, see page 40.
2. Enter the time and date by which the task
needs to be done by using the numeric keys.
Notes
:
• You need to enter the time in 12-hour
format. Press the
2
key for
A
(AM) or the
7
key for
P
(PM).
• You can move through the input fields using the
Navigation keys.
3. Select a priority level, either
High
or
Low
,
using or and then press .
Other Functions
96
Viewing a task
The list of the tasks displays when you access the
Task List
menu (
Menu 9-1-4
).
While viewing the task list, press the Navigation
keys to scroll to a task and:
• Press to view details. You can move to the
previous or next task by pressing the Navigation
keys.
While viewing the task, press the
Menu
soft key
to access the following options:
Edit
: allows you to edit the currently selected
task.
Erase
: allows you to erase the currently
selected task.
Add New
: allows you to add a new task.
•Press the
Menu
soft key to access the following
options:
Add New
: allows you to add a new task.
Erase
: allows you to erase the currently
selected task.
Erase All
: allows you to erase all of tasks.
Other Functions
97
Memo Pad
(Menu 9-1-5)
This feature allows you to make memos of
important things you need to remember.
Writing a new memo
1. Enter what you need to remember.
For further details about how to enter
characters, see page 40.
2. Press to save the memo.
Viewing a memo
The list of your memos displays when you access
the
Memo Pad
menu (
Menu 9-1-5
).
While viewing the memo list, press the Navigation
keys to scroll to a memo and:
• Press to view details. You can move to the
previous or next task by pressing the Navigation
keys.
While viewing the memo, press the
Menu
soft
key to access the following options:
Edit
: allows you to edit the currently selected
memo.
Erase
: allows you to erase the currently selected
memo.
Add New
: allows you to add a new memo.
•Press the
Menu
soft key to access the following
options:
Add New
: allows you to add a new memo.
Erase
: allows you to erase the currently selected
memo.
Erase All
: allows you to erase all of memos.
Other Functions
98
Alarm
(Menu 9-1-6)
This menu allows you to set the alarm to ring at a
specified time.
To set an alarm:
1. Select an alarm,
Alarm #1
through
Alarm
#3
, and press .
2. Select
On
by pressing or .
3. Press and enter the time for the alarm to
ring by using the numeric keys.
Notes
:
• You need to enter the time in 12-hour
format. Press the
2
key for
A
(AM) or the
7
key for
P
(PM).
• You can move through the input fields using the
Navigation keys.
4. Select an alarm melody by pressing or .
5. Press and select an alarm frequency option,
either
Daily
,
Once
,
Mon to Fri
, or
Sat & Sun
,
by pressing or .
6. Press to save the alarm setting.
To stop the alarm when it rings, open and close
the phone or press any key.
To deactivate an alarm setting, access the
Alarm
menu and select
Off
. Press .
.
Other Functions
99
Calculator
(Menu 9-1-7)
Using this feature, you can use the phone as a
calculator. The calculator provides you with the
basic arithmetic functions; addition, subtraction,
multiplication, and division.
To perform a calculator:
1. Enter the first number on the first line using
the numeric keys.
Note
: Use to enter a decimal point and
to change the sign of a number to a
negative (-).
2. Enter the operation for your calculation by
pressing the Navigation keys, according to the
graphic on the display;
+
(add),
-
(subtract),
x
(multiply),
÷
(divide).
3. Enter the second number.
4. To view the result, press or the
Cal.
soft
key.
5. Repeat steps 2 and 4 as many times as
required.
World Time
(Menu 9-1-8)
You can use this menu to find out what time it is in
another part of the world.
Select the city corresponding to your time zone by
pressing the Navigation keys once or repeatedly.
The local time and date display.
To turn the DST (Daylight Saving Time) setting on:
Other Functions
100
1. After selecting the time zone you want to apply
the DST, press the
Menu
soft key.
2. When
DST Setting
highlights, press .
3. Select
On
and press . The DST icon appears
between the time and the date.
To cancel the setting, select
Off
.
Count Down
(Menu 9-1-9)
This menu helps you know how much time it takes
for you to do something, or how many days,
hours, and minutes until a specific day arrives.
You can create up to 9 counters using this menu.
Creating a countdown timer
1. Enter a name for your Countdown timer and
press .
For further details about entering text, see
page 40.
2. Enter the time and date you want to count
down from.
Notes
:
• You need to enter the time in 12-hour format.
Press for AM or for PM.
• You can move through the input fields using the
Navigation keys.
• You can enter a year between 1900 and 2099.
3. Press to store the timer.
Viewing a countdown timer
The list of the countdown timer displays when you
access the
Count Down
menu (
Menu 9-1-9
).
Other Functions
101
While viewing the counter list, press the Navigation
keys to scroll to a counter and:
• Press to view details. You can move to the
previous or next counter using the Navigation
keys.
While viewing a timer, press the
Menu
soft key to
access the following options:
Edit
: allows you to edit the currently selected
counter.
Erase
: allows you to erase the currently selected
counter.
Add New
: allows you to add a new counter.
•Press the
Menu
soft key to access the following
options.
Add New
: allows you to add a new counter.
Erase
: allows you to erase the currently selected
counter.
Erase All
: allows you to erase all of counters.
Set Time
(Menu 9-1-0)
To display the correct time and date on the idle
screen or to use the Planner features, such as
Today
,
Scheduler
,
Task List
,
Count Down
,
Alarm
, and
World Time
, you need to set the
current time and date using this menu.
Enter the time and date using the numeric keys.
The minute, hour, month, and day each must be
entered using 2 digits and the year requires all 4
digits. You need to enter the hour in 12-hour format.
To select AM or PM, press the
2
key for
A
(AM) or
the
7
key for
P
(PM).
Other Functions
102
Display
(Menu 9-2)
In this menu, you can customize various settings
for the display, the lights, and menu shortcuts.
Menu Style
(Menu 9-2-1)
This menu allows you to select the menu display
style. You can choose either
Icon
or
Nature
.
Wallpaper
(Menu 9-2-2)
You can select the background image (wallpaper)
to be displayed in Standby mode.
The following image categories are available:
Embedded Images
: allows you to select one of
default images.
Note: When you select
Dual Clock
, the phone
displays the analog clocks for the two time
zones selected in the
Dual Clock
menu
(
Menu 9-2-6
). See page 104.
My Images
: allows you to select one of the
images downloaded from the wireless web.
Backlight
(Menu 9-2-3)
In this menu, you can select the length of time the
backlight is on. The backlight turns on when you
press a key, when you open the phone, or when
you receive a call or message, and remains on for
the specified length of time.
The following options are available:
Main Display
: you can specific the length of time
backlight of the main display turns on.
Keypad
: you can specify the length of time the
backlight of keypad turns on.
Pwr Save Mode
: you can select whether or not
the phone use backlight.
Other Functions
103
Banner
(Menu 9-2-4)
This menu allows you to set a banner message to
be displayed at the bottom of the display in
Standby mode.
1. If necessary, press and hold to clear the
characters.
2. Enter a new banner message.
For further details about how to enter
characters, see page 40.
3. When you have finished entering the message,
press or the
Save
soft key.
Launch Pad
(Menu 9-2-5)
The Navigation keys can be used as shortcut keys.
In Standby mode, they allow you to access
specific menu directly. Using this menu, you can
change the shortcut assignments of the keys.
To assign a shortcut to a key:
1. Select the key to be used as a shortcut key by
pressing or , and then press .
2. Select the menu to be assigned to the key by
pressing the Navigation keys.
3. Press to save the selection.
Note
: This
Launch Pad
menu can’t be used by
pressing the Navigation keys during a call.
Other Functions
104
Dual Clock
(Menu 9-2-6)
You can choose two time zones to be displayed
when you select
Dual Clock
for the wallpaper
image (
Menu 9-2-2
); for details, see page 102.
To select time zones for the dual clock:
1. When
Location
highlights, press .
2. Select the time zone for the left clock by
pressing or and press the Down key.
3. Select the time zone for the right clock by
pressing or .
4. Press to confirm the selection.
To apply the daylight saving time:
1. When
Location
highlights, press or to
display
DST
and Press .
2. Select
On
to use the daylight saving time for
the left clock. Otherwise, select
Off
.
3. Press and repeat step 2 for the right clock.
4. Press to confirm the selection.
Contrast
(Menu 9-2-7)
This option allows you to see the LCD screen
better in different lighting conditions. Scroll
through the contrast settings to make the screen
Service LED
(Menu 9-2-8)
The service light on the front of the phone, blinks
to indicate the service status. In this menu, you
can activate or deactivate the feature of the
service light.
Other Functions
105
Sounds
(Menu 9-3)
You can use the
Sounds
menu to customize
various sound settings, such as the:
• ringer volume and type.
• key tone and alert sounds.
• tones that sound while using the phone’s
functions.
Ringer Volume
(Menu 9-3-1)
This menu allows you to adjust the ringer volume
for the following the items:
Calls
: allows you to adjust the ringer volume for
incoming calls.
Messages
: allows you to adjust the ringer volume
for incoming messages.
Alarm/Schedule
: allows you to adjust the ringer
volume for alarm settings and scheduler alarm.
Press the Navigation keys to adjust the volume
level or select a ringer type. The following options
are available:
Silent: the phone does not sound a ringer.
Vibrate: the phone switches to Vibration mode. An
incoming call vibrates the phone.
1-Beep: the phone sounds a beep.
Level 1 ~ 8: adjust the volume level. The graphic
shows the volume level; more bars, the louder the
volume.
High+Vib: the phone rings in the highest volume
level and then vibrates.
Other Functions
106
Notes
:
• The options available may vary, depending on the
selected ringer item.
• When “Emergency call only” appears after you end
an emergency call, the ringer volume for calls and
messages is automatically set to Level 4.
Ringer Type
(Menu 9-3-2)
This menu allows you to set the unique ringer
melodies for incoming calls, messages, and
schedule settings:
To select a ringer type:
1. Select the item you want and press .
The following items are available:
•
Voice Calls
: allows you to set a unique
ringer for incoming calls.
•
Messages
: allows you to have a distinctive
ringer for incoming voice mail, numeric page,
and text messages independently.
•
Data/Fax In
: allows you to be alerted with
a distinctive ringer when you receive data or
fax calls through the phone. This feature may
not be available depending on your network.
•
Schedule
: allows you to have a distinctive
ring for alarm settings.
2. If you select the
Messages
menu, select the
message type you want and press .
3. Select the ringer category you want using
or and press .
4. Select the melody you want using or and
press to save it.
Other Functions
107
Keytone
(Menu 9-3-3)
Using this menu, you can set up the keypad tone
that the phone sounds when you press a key.
The following options are available:
Type
: allows you to select a tone that the phone
sounds when you press a key. Choose one of
DTMF
,
Harmony
,
Chord
and
Piano
.
Volume
: allows you to adjust the volume of the
keypad tone using the Navigation keys or the
Volume keys on the left side of the phone.
Alerts
(Menu 9-3-4)
Your phone gives audible alerts (beeps) at a
specified time to inform you that certain things
have happened. The alerts only occur in your
earpiece so that the other person does not hear
them.
The following alerts are available:
Minute Beep
: When this option is set to
On
, the
phone sounds an alert 10 seconds before each
elapsed minute to remind you of the length of the
current call.
Service Alert
: When this option is set to
On
, the
phone sounds an alert when you exit a service
area or when you return to a service area.
Connect
: When this option is set to
On
, the
phone sounds the connect tone when your call is
connected to the system.
Disconnect
: When this option is set to
On
, the
phone sounds the disconnect tone when a call is
disconnected.
Other Functions
108
Fade
: When this option is set to
On
, the phone
sounds an alert when a dropped call occurs during
conversation in response to a signal fade.
Roam
: When this option is set to
On
, the phone
sounds an alert when your phone starts roaming.
Roam Ringer
(Menu 9-3-5)
You can set the phone to sound a distinctive ring
when your phone start roaming.
Choose
Distinctive
to use a distinctive ringer or
Normal
to use a normal ringer.
Tone Length
(Menu 9-3-6)
This menu enables you to select
Short
or
Long
DTMF (dual-tone multi-frequency) tones. DTMF
tones are sent by your phone to access
teleservices, such as a bank account. The system
used by the bank or other service determines if
you need short or long DTMF tones. If the service
is digital, as most are, short DTMF tones will
almost always work.
Power On/Off
(Menu 9-3-7)
You can turn on or off the tone that the phone
sounds when it is switched on or off.
Choose
On
to use the power on/off sound or
Off
not to use it.
Other Functions
109
Voice Dial
(Menu 9-4)
Once you have stored a phone number with a
name in Contacts (see page 84), you only need to
say the associated name or the number into the
microphone to dial the number. For more
information about voice dialing, see page 31.
In the
Voice Dial
menu, you can configure your
phone to recognize your voice command.
Adapt Digits
(Menu 9-4-1)
This menu allows you to adapt your phone to
recognize your voice and pronunciation for each
digit.
Follow the voice prompts to adapt the phone.
Reset Digits
(Menu 9-4-2)
This menu allows you to reset the adaptation you
performed using the
Adapt Digits
menu.
Set Active
(Menu 9-4-3)
In this menu, you can set how you want to initiate
voice dialing. The following options available:
[
*
] Only
: enables voice dialing only by pressing
and holding . This is the default setting
.
[
*
]/Folder
: enables voice dialing by pressing and
holding or by opening the phone.
[
*
]/EarMic
: enables voice dialing by pressing
and holding or the button on the headset, if
connected to the phone.
Other Functions
110
Choice List
(Menu 9-4-4)
In this menu, you can set the phone display the
list of the best choices for your voice command,
when you use the
Digit Dial
,
Name Dial
, or
Contacts
commands.
Help
(Menu 9-4-5)
Selecting this menu opens the screen that gives
you help for using the Voice Dial menu.
Setup
(Menu 9-5)
Many different features of your phone can be
customized to suit your preferences.
Auto CSP
(Menu 9-5-1)
This menu allows the phone to automatically add
the CSP (Carrier Selection Code) of your long-
distance call service to the entered number when
making a call.
On/Off
This menu allows you to enable or disable the
Auto CSP feature.
Select
Enable
to activate this feature or
Disable
to deactivate it.
Code Setting
This menu allows you to set the 2-digit carrier
code to be added to the phone number.
Other Functions
111
Notes
:
• Before setting the carrier code, you should enable
the
On/Off
menu first.
• The code is added only when the phone number has
6, 7, 10, or 11 digits and starts with 0XX, for
example, 012 or 015.
Auto Answer
(Menu 9-5-2)
This feature works only when the phone is
connected to the headset or an optional hand-free
car kit. With this menu activated, the phone
automatically answers calls after a specified time.
This feature is useful while driving, for instance.
To activate this feature, set how long the phone
waits before answering an incoming call. Select one
from
After 1 sec
,
After 3 sec
, or
After 5 sec
.
To deactivate this feature, select
Off
.
Call Answer
(Menu 9-5-3)
This menu allows you to select how to answer an
incoming call.
The following options are available:
Any Key
: The phone answers when you press any
key except for , and Volume keys. When the
phone is closed, you can answer the call by opening
the phone.
Send Key
: The phone answers only when you
press .
Folder Open
: The phone answers when you open
the phone. If the phone is already open, press .
Other Functions
112
Auto Retry
(Menu 9-5-4)
When this menu is activated, your phone
automatically redials the number up to 10 times
when a connection fails.
To activate this feature, select how often the
phone will automatically retry the call;
10
seconds
,
30 seconds
, and
60 seconds
are
available.
To deactivate this feature, select
Off
.
Depending on your location, the number of times
your phone automatically redials the number may
vary.
Language
(Menu 9-5-5)
This menu allows you to change the language of
voice prompts, menu display, and key input.
You can choose either
English
,
Spanish
, or
Portuguese
.
Select NAM
(Menu 9-5-6)
NAM stands for numerical assignment module,
essentially your phone number. Your phone can
have two NAMs. This means that you can have
two phone numbers for using your phone and can
quickly and easily switch your service back and
forth between the two numbers.
If you change the NAM, the phone turns off by
itself and back on and acquires service using the
new NAM setting.
Other Functions
113
Set System
(Menu 9-5-7)
The system selection feature which is only
relevant in areas where there are at least two
cellular service providers having valid roaming
agreements. Roaming allows you to register your
phone on one of the networks, but use the
facilities of the other if your own network is not
available. This system priority feature allows you
to program your phone for optimum operation
within or outside your home service area.
You should always check your phone’s display
because it will let you know when you’re outside
the service provider network and whether your
phone is operating in another network; the
roaming icon ( ) appears.
You have the following options which allows you to
control the phone’s roaming ability:
Home Only
: You cannot roam. When your home
system is not available, your call is not be
connected and the No Service icon ( ) displays.
In some service areas, an operator may come on
line asking you how you would like to pay for the
call.
Standard
: This option allows you to be provided
the best system automatically.
Other Functions
114
Data/Fax
(Menu 9-5-8)
Your phone is capable of sending and receiving
digital data and fax call when connected to a
computing device (laptop, desktop, handheld,
palmtop, etc.) running Windows 95, Windows 98,
Windows NT or later versions. The phone functions
just like a typical modem on your PC, enabling you
to use wireless data involving a wide variety of
Windows software applications.
To use digital data or fax services with your
phone, you will need to obtain a digital data/fax
kit from your service provider. This kit contains
the necessary cables, software, and user’s guide
required for you to connect and use your phone
with your computing device.
Note
: The phone must be on a digital network to
receive or send faxes and data.
The following options are available:
Voice Call Only
: Your phone receives voice calls
only.
Fax in Only
: Your phone receives fax calls only.
Data in Only
: Your phone receives data calls only.
Receiving a fax or data file
To receive a fax or data, ensure that your phone is
connected to your PC and is powered on. Select
one of the Data/Fax options.
When you receive a fax call, set up the
Answer
mode in the fax program on your PC and click on
Receive
and select one of the following options:
• Automatic receive (recommended)
• Manual receive
Other Functions
115
Sending a fax or data file
When connected to a computing device, your
phone allows wireless fax and data transmissions.
Your computing device software initiates the call
to the destination phone number. The phone
functions as a wireless modem to send the fax or
data file to the number designated by your PC
software.
Version
(Menu 9-5-9)
This menu allows you to view the software and
hardware versions of your phone. This feature is
helpful if you need to the call customer care.
Security
(Menu 9-5-0)
Your phone provides you with various security
options, including a user-programmable lock code
and special number features.
To access the
Security
menu, you must enter the
4-digit lock code. It is preset to “0000” at the
factory.
Lock Phone
In this menu, you can lock your phone from being
used by unauthorised people.
When the phone is locked, you cannot dial
numbers, except for making an emergency call, or
access menu options. The phone can receive
incoming calls and messages, even though the
phone is in Lock mode.
Other Functions
116
The following options are available:
Unlocked
: The phone remains unlocked.
On Power-up
: The phone locks automatically the
next time you turn on phone.
Lock Now
: The phone locks immediately.
To place an emergency call in Lock mode, enter a
programmed number and then press . The
phone recognizes three standard emergency
numbers stored in the
Emergency
#
menu
(
Menu 9-5-0-4
); see page 117.
To unlock the phone, press one of the soft keys,
Volume keys, Navigation keys, , or and then
enter the 4-digit lock code. The phone is
immediately unlocked.
Change Lock
This feature allows you to change your current
lock code to a new one. The lock code is preset to
“0000” at the factory.
Enter a new, 4-digit lock code and press . Enter
it again to confirm your change and press .
Note
: Your phone does not allow viewing of the lock
code for security reasons. Be sure to write the
lock code down or memorize it if you have
changed.
Restriction
This feature allows you to restrict all of the
outgoing calls.
Select
On
to restrict the calls, or
Off
to deactivate
the restriction.
Other Functions
117
Emergency #
Your phone provides you with the option of storing
three emergency numbers. All of these numbers
can be manually dialed at any time even if your
phone is locked or outgoing calls are restricted.
IMPORTANT NOTICE!
Emergency calling may not be available on all
wireless networks at all times. A connection
cannot always be guaranteed, due to various
transmission methods, network parameters and
user settings used to complete a call from your
wireless phone.
DO NOT depend on this phone as a primary
method of dialing 190 or for any other essential or
emergency communications.
Remember to always turn your phone on and
check for the adequate signal strength before
placing a call.
To store an emergency number:
1. Press or to select a location and press
.
2. If necessary, press and hold to clear the
old number.
3. Enter the new number you want.
Each emergency number can be up to 32 digits
long.
4. Press to store the number.
To make an emergency call in Lock mode, simply
enter a programed number, and then press .
Other Functions
118
Erase Contacts
This feature allows you to clear all of the entries in
Contacts.
When a confirmation message displays, select
Yes
and press .
Reset Phone
Resetting the phone cancels all of your selection in
the user-selectable setting options and returns
them to the factory default settings except for the
Contacts entries and SMS messages.
When a confirmation message displays, select
Yes
and press . The phone reboots, turning itself off
and back on, and returns to Standby mode.
Voice Privacy
Used only in digital networks, Voice Privacy
encrypts the voice channel so that people cannot
eavesdrop on your conversation.
The following options are available.
Standard
: The phone uses a standard line for
calls.
Enhanced
: The phone makes and receive calls on
an encrypted high security line.
Note
: This feature may not be available in all areas.
Contact your service provider for details and
availability.
119
Voice command
Your phone performs some functions or access
specific menus by your voice command. You only
need to say the command into the microphone.
You can:
• dial a number by saying an associated name
(
Name Dial
) or the number (
Digit Dial
).
• record a voice memo (
Voice Memo
).
• open the Contacts list (
Contacts
).
•access the
Voice Mail
menu and the
Voice
Portal
menu.
To use the voice command feature:
1. In Standby mode, press and hold .
2. At a voice prompt followed by a short beep,
say a command you want.
120
Health and safety
information
Exposure to radio frequency (RF)
signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on the safety standards that
were developed by independent scientific
organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones
employs a unit of measurement known as Specific
Absorption Rate (SAR). The SAR limit set by the
FCC is 1.6W/kg.
*
* In the U.S. and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give
additional protection for the public and to account
for any variations in measurements.
Health and safety information
121
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is
determined at the highest certified power level,
the actual SAR level of the phone while operating
can be well below the maximum value. This is
because the phone is designed to operate at
multiple power levels so as to use only the power
required to reach the network. In general, the
closer you are to a wireless base station antenna,
the lower the power output of the phone.
Before a new model phone is available for sale to
the public, it must be tested and certified to the
FCC that it does not exceed the limit established
by the government-adopted requirement for safe
exposure. The tests are performed in positions
and locations (e.g., at the ear and worn on the
body) as required by the FCC for each model.
While there may be differences between the SAR
levels of various phones and at various positions,
they all meet the government requirement.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this
model phone is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model phone
is attached separation paper.
Health and safety information
122
For body operation
SAR compliance for body-worn operating configurations
is limited to the specific belt-clip/holster supplied or
approved by SAMSUNG, if available. The use of
accessories that do not satisfy these requirements
may not comply with FCC RF exposure compliance
and should be avoided.
Non-compliance with the above conditions may
violate FCC RF exposure guidelines.
For more Information concerning exposure to
radio frequency signals, see the following
websites:
Federal Communications Commission (FCC)
http://www.fcc.gov/oet/rfsafety
Cellular Telecommunications Industry Association
(CTIA): http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Health and safety information
123
Precautions when using batteries
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby
time are greatly affected by the signal strength
on the cellular network and the parameters set
by the network operator.
• Battery charging time depends on the remaining
battery charge, the type of battery, and the
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably
shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in
use, disconnect it from the power source. Do
not leave the battery connected to a charger for
more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
Health and safety information
124
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of
the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold
battery may temporarily not work, even when
the battery is fully charged. Li-ion batteries are
particularly affected by temperatures below 0
°C (32 °F).
• Do not short-circuit the battery. Accidental
short- circuiting can occur when a metallic
object (coin, clip or pen) causes a direct
connection between the + and – terminals of
the battery (metal strips on the battery), for
example when you carry a spare battery in a
pocket or bag. Short-circuiting the terminals
may damage the battery or the object causing
the short-circuiting.
• Dispose of used batteries in accordance with
local regulations. Always recycle. Do not dispose
of batteries in a fire.
Road safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, make sure that you are
following the special regulations in a given area or
country.
Health and safety information
125
Operating environment
Remember to follow any special regulations in
force in any area and always switch your phone off
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and for
the safety of personnel, it is recommended that
the equipment should only be used in the normal
operating position (held to your ear with the
antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded
from radio frequency (RF) signals. However,
certain electronic equipment may not be shielded
against the RF signals from your wireless phone.
Consult the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are
consistent with the independent research and
Health and safety information
126
recommendations of Wireless Technology
Research.
Persons with pacemakers:
• Should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the
phone is switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that
interference is taking place, switch your phone off
immediately.
Hearing aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss alternatives.
Other medical devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from
external RF energy. Your physician may be able to
assist you in obtaining this information. Switch
your phone off in health care facilities when any
regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may be
using equipment that could be sensitive to
external RF energy.
Health and safety information
127
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially explosive environment
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury
or even death.
Users are advised to switch the phone off while at
a refueling point (service station). Users are
reminded of the need to observe restrictions on
the use of radio equipment in fuel depots (fuel
storage and distribution areas), chemical plants or
where blasting operations are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
the areas below decks on boats, chemical transfer
or storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane), areas
where the air contains chemicals or particles, such
as grain, dust or metal powders, and any other
area where you would normally be advised to turn
off your vehicle engine.
Health and safety information
128
Emergency calls
This phone, like any wireless phone, operates
using radio signals, wireless and landline networks
as well as user-programed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may
not be possible on all wireless phone networks or
when certain network services and/or phone
features are in use. Check with local service
providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location. Emergency numbers vary by location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to
give all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not end the call until given
permission to do so.
Health and safety information
129
Other important safety information
• Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases
or explosive materials in the same compartment
as the phone, its parts or accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with great
force. Do not place objects, including both
installed or portable wireless equipment in the
area over the air bag or in the air bag
deployment area. If wireless equipment is
improperly installed and the air bag inflates,
serious injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phones in an
aircraft may be dangerous to the operation of
the aircraft, and is illegal.
• Failure to observe these instructions may lead
to the suspension or denial of telephone
services to the offender, or legal action, or both.
Health and safety information
130
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care.
The suggestions below will help you fulfill any
warranty obligations and allow you to enjoy this
product for many years.
• Keep the phone and all its parts and accessories
out of the reach of small children’s.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode
electronic circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage
to the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s
electronic circuit boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents
or strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
Health and safety information
131
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas or
modified accessories may damage the phone
and violate regulations governing radio devices.
• If the phone, battery, charger or any accessory
is not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
Acknowledging special precautions
and the FCC and industry canada
notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
FCC compliance information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference.
Health and safety information
132
(2) This device must accept any interference
received. Including interference that may
cause undesired operation.
Information to user
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off
and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Health and safety information
133
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT ’S
REQUIREMENTS FOR EXPOSURE TO RADIO
WAVES. Your wireless phone is a radio transmitter
and receiver. It is designed and manufactured not
to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on safety standards that
were developed by independent scientific
organizations through periodic and thorough
evaluation of scientific studies. The standards
include a substantial safety margin designed to
assure the safety of all persons, regardless of age
and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the
Specific Absorption Rate(SAR). The SAR limit set
by the FCC is 1.6 W/kg. SAR Tests are conducted
using standard operating positions accepted by
the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the
maximum value. This is because the phone is
designed to operate at multiple power levels so as
to use only the power required to reach the
network. In general, the closer you are to a
wireless base station antenna, the lower the
power output.
Before a new model phone is available for sale to
the public, it must be tested and certified to the
Health and safety information
134
FCC that it does not exceed the limit established
by the government-adopted requirement for safe
exposure. The tests are performed in positions
and locations (e.g.,at the ear and worn on the
body) as required by the FCC for each model.
The highest SAR values for this model phone as
reported to the FCC are Head:1.31W/Kg, Body-
worn:1.06W/Kg.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this
model phone is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
A3LSCHN415.
Health and safety information
135
Appendix B: GUIDE TO SAFE AND
RESPONSIBLE WIRELESS PHONE USE
Cellular Telecommunications & Internet
Association
“Safety is the most important call you will ever
make.”
A Guide to Safe and Responsible Wireless Phone
Use
TENS OF MILLIONS OF PEOPLE IN THE U.S.
TODAY TAKE ADVANTAGE OF THE UNIQUE
COMBINATION OF CONVENIENCE, SAFETY AND
VALUE DELIVERED BY THE WIRELESS
TELEPHONE. QUITE SIMPLY, THE WIRELESS
PHONE GIVES PEOPLE THE POWERFUL ABILITY TO
COMMUNICATE BY VOICE-ALMOST ANYWHERE,
ANYTIME-WITH THE BOSS, WITH A CLIENT, WITH
THE KIDS, WITH EMERGENCY PERSONNEL OR
EVEN WITH THE POLICE. EACH YEAR, AMERICANS
MAKE BILLIONS OF CALLS FROM THEIR
WIRELESS PHONES, AND THE NUMBERS ARE
RAPIDLY GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must
uphold. When driving a car, driving is your first
responsibility. A wireless phone can be an
invaluable tool, but good judgment must be
exercised at all times while driving a motor
vehicle-whether on the phone or not.
The basic lessons are ones we all learned as
teenagers. Driving requires alertness, caution and
courtesy. It requires a heavy dose of basic
common sense-keep your head up, keep your
eyes on the road, check your mirrors frequently
and watch out for other drivers. It requires
Health and safety information
136
obeying all traffic signs and signals and staying
within the speed limit. It means using seatbelts
and requiring other passengers to do the same.
But with wireless phone use, driving safely means
a little more. This brochure is a call to wireless
phone users everywhere to make safety their first
priority when behind the wheel of a car. Wireless
telecommunications is keeping us in touch,
simplifying our lives, protecting us in emergencies
and providing opportunities to help others in need.
When it comes to the use of wireless phones,
safety is your most important call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and
using a wireless phone which should be easy to
remember.
1. Get to know your wireless phone and its
features such as speed dial and redial. Carefully
read your instruction manual and learn to take
advantage of valuable features most phones offer,
including automatic redial and memory. Also, work
to memorize the phone keypad so you can use the
speed dial function without taking your attention
off the road.
2. When available, use a hands free device. A
number of hands free wireless phone accessories
are readily available today. Whether you choose
an installed mounted device for your wireless
phone or a speaker phone accessory, take
advantage of these devices if available to you.
3. Position your wireless phone within easy reach.
Make sure you place your wireless phone within
easy reach and where you can grab it without
removing your eyes from the road. If you get an
Health and safety information
137
incoming call at an inconvenient time, if possible,
let your voice mail answer it for you.
4. Suspend conversations during hazardous
driving conditions or situations. Let the person you
are speaking with know you are driving; if
necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow
and ice can be hazardous, but so is heavy traffic.
As a driver, your first responsibility is to pay
attention to the road.
5. Do not take notes or look up phone numbers
while driving. If you are reading an address book
or business card, or writing a °×to do°± list while
driving a car, you are not watching where you are
going. It’scommon sense. Don°Øt get caught in a
dangerous situation because you are reading or
writing and not paying attention to the road or
nearby vehicles.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan your calls before
you begin your trip or attempt to coincide your
calls with times you may be stopped at a stop
sign, red light or otherwise stationary. But if you
need to dial while driving, follow this simple tip-
dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Stressful or
emotional conversations and driving do not mix-
they are distracting and even dangerous when you
are behind the wheel of a car. Make people you
are talking with aware you are driving and if
necessary, suspend conversations which have the
potential to divert your attention from the road.
Health and safety information
138
8. Use your wireless phone to call for help. Your
wireless phone is one of the greatest tools you can
own to protect yourself and your family in
dangerous situationswith your phone at your side,
help is only three numbers away. Dial 9-1-1 or
other local emergency number in the case of fire,
traffic accident, road hazard or medical
emergency. Remember, it is a free call on your
wireless phone!
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you a
perfect opportunity to be a “Good Samaritan” in
your community. If you see an auto accident,
crime in progress or other serious emergency
where lives are in danger, call 9-1-1 or other local
emergency number, as you would want others to
do for you.
10. Call roadside assistance or a special wireless
nonemergency assistance number when
necessary. Certain situations you encounter while
driving may require attention, but are not urgent
enough to merit a call for emergency services. But
you still can use your wireless phone to lend a
hand. If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor
traffic accident where no one appears injured or a
vehicle you know to be stolen, call roadside
assistance or other special nonemergency wireless
number. Careless, distracted individuals and
people driving irresponsibly represent a hazard to
everyone on the road.
Since 1984, the Cellular Telecommunications
Industry Association and the wireless industry
have conducted educational outreach to inform
wireless phone users of their responsibilities as
safe drivers and good citizens. As we approach a
Health and safety information
139
new century, more and more of us will take
advantage of the benefits of wireless telephones.
And, as we take to the roads, we all have
aresponsibility to drive safely.
“The wireless industry reminds you to use your
phone safely when driving”
Cellular Telecommunications & Internet
Association. For more information, please call 1-
888-901-SAFE.
For updates: http://www.wowcom.com/
consumer/issues/driving/articles.cfm?ID=85
Health and safety information
140
Appendix C: Consumer Update on
Wireless Phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often
called cell, mobile, or PCS phones. These types of
wireless phones can expose the user to
measurable radiofrequency energy (RF) because
of the short distance between the phone and the
user s head. These RF exposures are limited by
Federal Communications Commission safety
guidelines that were developed with the advice of
FDA and other federal health and safety agencies.
When the phone is located at greater distances
from the user, the exposure to RF is drastically
lower because a person°Øs RF exposure
decreases rapidly with increasing distance from
the source. The socalled “cordless phones,” which
have a base unit connected to the telephone
wiring in a house, typically operate at far lower
power levels, and thus produce RF exposures well
within the FCC’s compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show
that any health problems are associated with
using wireless phones. There is no proof, however,
that wireless phones are absolutely safe. Wireless
phones emit low levels of radiofrequency energy
(RF) in the microwave range while being used.
They also emit very low levels of RF when in the
stand-by mode. Whereas high levels of RF can
produce health effects (by heating tissue),
exposure to low level RF that does not produce
Health and safety information
141
heating effects causes no known adverse health
effects. Many studies of low level RF exposures
have not found any biological effects. Some
studies have suggested that some biological
effects may occur, but such findings have not been
confirmed by additional research. In some cases,
other researchers have had difficulty in
reproducing those studies, or in determining the
reasons for inconsistent results.
3. What is FDA’s role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as
wireless phones before they can be sold, as it does
with new drugs or medical devices. However, the
agency has authority to take action if wireless
phones are shown to emit radiofrequency energy
(RF) at a level that is hazardous to the user. In
such a case, FDA could require the manufacturers
of wireless phones to notify users of the health
hazard and to repair, replace or recall the phones
so that the hazard no longer exists.
Although the existing scientific data do not justify
FDA regulatory actions, FDA has urged the
wireless phone industry to take a number of steps,
including the following:
Support needed research into possible
biologicaleffects of RF of the type emitted by
wireless phones; Design wireless phones in a way
that minimizes any RF exposure to the user that is
not necessary for device function; and Cooperate
in providing users of wireless phones with the best
possible information on possible effects of wireless
phone use on human health.
Health and safety information
142
FDA belongs to an interagency working group of
the federal agencies that have responsibility for
different aspects of RF safety to ensure
coordinated efforts at the federal level. The
following agencies belong to this working group:
National Institute for Occupational Safety and
Health Environmental Protection Agency
FederalCommunications Commission Occupational
Safety and Health Administration National
Telecommunications and Information
Administration
The National Institutes of Health participates
insome interagency working group activities, as
well. FDA shares regulatory responsibilities for
wireless phones with the Federal Communications
Commission (FCC). All phones that are sold in the
United States must comply with FCC safety
guidelines that limit RF exposure. FCC relies on
FDA and other health agencies for safety
questions about wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While these
base stations operate at higher power than do the
wireless phones themselves, the RF exposures
that people get from these base stations are
typically thousands of times lower than those they
can get from wireless phones. Base stations are
thus not the primary subject of the safety
questions discussed in this document.
4. What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around
the world to ensure that high priority animal
studies are conducted to address important
Health and safety information
143
questions about the effects of exposure to
radiofrequency energy (RF).
FDA has been a leading participant in the World
Health Organization International Electromagnetic
Fields (EMF) Project since its inception in 1996. An
influential result of this work has been the
development of a detailed agenda of research
needs that has driven the establishment of new
research programs around the world. The Project
has also helped develop a series of public
information documents on EMF issues.
FDA and the Cellular Telecommunications &
Internet Association (CTIA) have a formal
Cooperative Research and Development
Agreement (CRADA) to do research on wireless
phone safety. FDA provides the scientific
oversight, obtaining input from experts in
government, industry, and academic
organizations. CTIA-funded research is conducted
through contracts to independent investigators.
The initial research will include both laboratory
studies and studies of wireless phone users. The
CRADA will also include a broad assessment of
additional research needs in the context of the
latest research developments around the world.
5. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
If there is a risk from these products.and at this
point we do not know that there is.it is probably
very small. But if you are concerned about
avoiding even potential risks, you can take a few
simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key
factor in how much exposure a person receives,
reducing the amount of time spent using a
wireless phone will reduce RF exposure.
Health and safety information
144
If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna Again, the scientific data do not
demonstrate that wireless phones are harmful.
But if you are concerned about the RF exposure
from these products, you can use measures like
those described above to reduce your RF exposure
from wireless phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower
exposure to radiofrequency energy (RF), the
measures described above would apply to children
and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the
distance between the user and the RF source will
reduce RF exposure. Some groups sponsored by
other national governments have advised that
children be discouraged from using wireless
phones at all. For example, the government in the
United Kingdom distributed leaflets containing
such a recommendation in December 2000. They
noted that no evidence exists that using a wireless
phone causes brain tumors or other ill effects.
Their recommendation to limit wireless phone use
by children was strictly precautionary; it was not
based on scientific evidence that any health
hazard exists.
7. Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Health and safety information
145
Since there are no known risks from exposure to
RF emissions from wireless phones, there is no
reason to believe that hands-free kits reduce
risks. Handsfree kits can be used with wireless
phones for convenience and comfort. These
systems reduce the absorption of RF energy in the
head because the phone, which is the source of
the RF emissions, will not be placed against the
head. On the other hand, if the phone is mounted
against the waist or other part of the body during
use, then that part of the body will absorb more
RF energy. Wireless phones marketed in the U.S.
are required to meet safety requirements
regardless of whether they are used against the
head or against the body. Either configuration
should result in compliance with the safety limit.
8. Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to
RF emissions from wireless phones, there is no
reason to believe that accessories that claim to
shield the head from those emissions reduce risks.
Some products that claim to shield the user from
RF absorption use special phone cases, while
others involve nothing more than a metallic
accessory attached to the phone. Studies have
shown that these products generally do not work
as advertised. Unlike “hand-free” kits, these so-
called “shields”may interfere with proper
operation of the phone. The phone may be forced
to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the
Federal trade Commission (FTC) charged two
companies that sold devices that claimed to
protect wireless phone users from radiation with
making false and unsubstantiated claims.
Health and safety information
146
According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
9. What about wireless phone interference with
medical equipment?
Radiofrequency energy (RF) from wireless phones
can interact with some electronic devices. For this
reason, FDA helped develop a detailed test
method to measure electromagnetic interference
(EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test
method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000.
This standard will allow manufacturers to ensure
that cardiac pacemakers and defibrillators are safe
from wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop
avoluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance
requirements for hearing aids and wireless phones
so that that no interference occurs when a person
uses a compatible phone and a compatible hearing
aid at the same time. This standard was approved
by the IEEE in 2000.
FDA continues to monitor the use of wireless
phones for possible interactions with other
medical devices. Should harmful interference be
found to occur, FDA will conduct testing to assess
the interference and work to resolve the problem.
10. What are the results of the research done
already?
Health and safety information
147
The research done thus far has produced
conflicting results, and many studies have
suffered from flaws in their research methods.
Animal experiments investigating the effects of
radiofrequency energy (RF) exposures
characteristic of wireless phones have yielded
conflicting results that often cannot be repeated in
other laboratories. A few animal studies, however,
have suggested that low levels of RF could
accelerate the development of cancer in
laboratory animals. However, many of the studies
that showed increased tumor development used
animals that had been genetically engineered or
treated with cancercausing chemicals so as to be
pre-disposed to develop cancer in the absence of
RF exposure. Other studies exposed the animals
to RF for up to 22 hours per day. These conditions
are not similar to the conditions under which
people use wireless phones, so we don t know
with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been
published since December 2000. Between them,
the studies investigated any possible association
between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland,
leukemia, or other cancers. None of the studies
demonstrated the existence of any harmful health
effects from wireless phone RF exposures.
However, none of the studies can answer
questions about long-term exposures, since the
average period of phone use in these studies was
around three years.
11. What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
Health and safety information
148
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data
that are needed. Lifetime animal exposure studies
could be completed in a few years. However, very
large numbers of animals would be needed to
provide reliable proof of a cancer promoting effect
if one exists. Epidemiological studies can provide
data that is directly applicable to human
populations, but 10 or more years follow-up may
be needed to provide answers about some health
effects, such as cancer. This is because the
interval between the time of exposure to a cancer-
causing agent and the time tumors develop - if
they do - may be many, many years. The
interpretation of epidemiological studiesis
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless
phones. Many factors affect this measurement,
such as the angle at which the phone is held, or
which model of phone is used.
12. Which other federal agencies have
responsibilities related to potential RF health
effects?
Additional information on the safety of RF
exposures from various sources can be obtained
from the following organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s
(OSHA):
http://www.oshaslc.
Health and safety information
149
gov/SLTC/radiofrequencyradiation/index.html
National Institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
Updated 4/3/2002: US Food and Drug
Administration
http://www.fda.gov/cellphones
150
Glossary
Airtime
- Actual time spent talking on the
wireless phone. Most carriers bill customers based
on how many minutes of airtime they use each
month.
Antenna
- A device for transmitting or receiving
signals. The size and shape of antennas is
determined, in part, by the frequency of the signal
they receive. Wireless phones and the base
station must have antennas.
Base station
- The fixed radio transmitter/
receiver that maintains communications with
mobile radio telephones within a given area.
(Typically called a cell or cell site)
CDMA
- (Code Division Multiple Access) A spread-
spectrum approach to digital transmission. With
CDMA, each conversion is digitized and then
tagged with a code. The mobile phone deciphers
only a particular code to pick the right
conversation off the air. The transmitted signal is
just above noise level across the available
bandwidth.
Channel
- Communications signals transmit along
paths called channels.
Codec
- Compression & Decompression.
Deactivation
- The process of rendering a
wireless phone inactive.
DTMF
- (Dual-tone Multi-Frequency) You send
DTMF signals when you enter numbers by
pressing the digit keys.
Glossary
151
EVRC
- (Enhanced Variable Rate Codec) EVRC is a
new global standard for compressing and
decompressing voice signals. EVRC uses a lower
bit rate (the number of bits sent per second) than
existing CDMA vocoders, while providing
significant improvements in voice quality. This
technology enables your phone to provide superb
voice quality while benefiting from the ability to
process more cellular voice calls using less
bandwidth than the voice codecs in CDMA
networks today.
Frequency
- A measure based on time, as one or
more waves per second, in an electrical or light
wave information signal. A signal’s frequency is
stated in cycles-per-second or Hertz (Hz).
Hands-free
- A feature that permits a driver to
use a wireless phone without lifting or holding the
handset - an important safety feature for
automobiles, tractors and most other motorized
vehicles.
LCD
- (Liquid Crystal Display) Commonly used to
refer to the screen display on the wireless phone.
LED
- (Light Emitting Diode) Commonly used to
refer to a small light on the wireless phone or on
the Desktop Charger. The LED lights on the phone
to indicate an incoming call. The lights on the
charger indicate that battery charging is taking
place.
Prepend
- The addition of a prefix, such as an
area code, to a phone number.
RF
- Radio Frequency
Roaming
- The ability to use a wireless phone to
make and receive calls in places outside of the
home service area.
Glossary
152
Service charge
- The amount paid each month to
receive wireless service.
Soft keys
- Two keys and on the phone,
the purpose of which:
• varies according to the function that you are
currently using.
• is indicated on the bottom line of the display
just above the corresponding key.
Standby time
- The amount of time a fully
charged wireless portable or transportable phone
can be on and idle without being in use. (See Talk
time.)
Talk time
- The length of time a person can talk
on a portable or transportable wireless phone
without recharging the battery.
Vocoder
- Voice coder. A device used to convert
speech into digital signals.
Wireless
- Radio-based Systems that allow
transmission of telephone or data signals through
the air without a physical connection, such as a
metal wire (copper) or fiber optic cable.
