Samsung Electronics Co SCX4725FN Multi Function Printer User Manual SCX 4725 User

Samsung Electronics Co Ltd Multi Function Printer SCX 4725 User

Users Manual

SCX-4725F

SCX-4725FN

This manual is provided for information purposes only. All information included herein is subject to change without notice. Samsung Electronics is not

responsible for any direct or indirect damages, arising from or related to use of this manual.

• SCX-4725F and SCX-4725FN are model names of Samsung Electronics Co., Ltd.

• Samsung and Samsung logo are trademarks of Samsung Electronics Co., Ltd.

• Centronics is a trademark of Centronics Data Computer Corporation.

• PCL and PCL 6 are trademarks of Hewlett-Packard company.

• Microsoft, Windows, Windows 98, Windows Me, Windows 2000, Windows XP(32/64bit), and Windows 2003(32/64bit) are registered trademarks of

Microsoft Corporation.

• PostScript 3 is a trademark of Adobe System, Inc.

• UFST® and MicroType™ are registered trademarks of Monotype Imaging Inc.

• TrueType, LaserWriter and Macintosh are trademarks of Apple Computer, Inc.

• All other brand or product names are trademarks of their respective companies or organizations.

CONTACT SAMSUNG WORLD WIDE

If you have any comments or questions regarding Samsung products,

contact the Samsung customer care center.

Country Customer Care Center Web Site

ARGENTINE 0800-333-3733 www.samsung.com/ar

AUSTRALIA 1300 362 603 www.samsung.com/au

BELGIUM 02 201 2418 www.samsung.com/be

BRAZIL 0800-124-421 www.samsung.com/br

CANADA 1-800-SAMSUNG

(7267864)

www.samsung.com/ca

CHILE 800-726-7864 (SAMSUNG) www.samsung.com/cl

CHINA 800-810-5858

010- 6475 1880

www.samsung.com.cn

COSTA RICA 0-800-507-7267 www.samsung.com/latin

CZECH

REPUBLIC

844 000 844 www.samsung.com/cz

DENMARK 38 322 887 www.samsung.com/dk

ECUADOR 1-800-10-7267 www.samsung.com/latin

EL SALVADOR 800-6225 www.samsung.com/latin

FINLAND 09 693 79 554 www.samsung.com/fi

FRANCE 08 25 08 65 65

( 0,15/min)

www.samsung.com/fr

GERMANY 01805 - 121213

( 0,12/min)

www.samsung.de

GUATEMALA 1-800-299-0013 www.samsung.com/latin

HONG KONG 2862 6001 www.samsung.com/hk

HUNGARY 06 40 985 985 www.samsung.com/hu

INDIA 3030 8282

1600 1100 11

www.samsung.com/in

INDONESIA 0800-112-8888 www.samsung.com/id

ITALIA 199 153 153 www.samsung.com/it

JAMAICA 1-800-234-7267 www.samsung.com/latin

JAPAN 0120-327-527 www.samsung.com/jp

LUXEMBURG 02 261 03 710 www.samsung.lu

MALAYSIA 1800-88-9999 www.samsung.com/my

MEXICO 01-800-SAMSUNG

(7267864)

www.samsung.com/mx

NETHERLANDS 0900 20 200 88

( 0,10/min)

www.samsung.com/nl

NORWAY 231 627 22 www.samsung.com/no

PANAMA 800-7267 www.samsung.com/latin

PHILIPPINES 1800-10-SAMSUNG

(7267864)

www.samsung.com/ph

POLAND 0 801 801 881 www.samsung.com/pl

PORTUGAL 80 8 200 128 www.samsung.com/pt

PUERTO RICO 1-800-682-3180 www.samsung.com/latin

REP. DOMINICA 1-800-751-2676 www.samsung.com/latin

RUSSIA 8-800-200-0400 www.samsung.ru

SINGAPORE 1800-SAMSUNG (7267864) www.samsung.com/sg

SLOVAKIA 0850 123 989 www.samsung.com/sk

SOUTH AFRICA 0860 7267864 (SAMSUNG) www.samsung.com/za

SPAIN 902 10 11 30 www.samsung.com/es

SWEDEN 08 585 367 87 www.samsung.com/se

TAIWAN 0800-329-999 www.samsung.com/tw

THAILAND 1800-29-3232

02-689-3232

www.samsung.com/th

TRINIDAD &

TOBAGO

1-800-7267-864 www.samsung.com/latin

U.A.E 800SAMSUNG (7267864) www.samsung.com/mea

U.K 0870 242 0303 www.samsung.com/uk

U.S.A 1-800-SAMSUNG

(7267864)

www.samsung.com

UKRAINE 8-800-502-0000 www.samsung.com/ur

VENEZUELA 1-800-100-5303 www.samsung.com/latin

VIETNAM 1 800 588 889 www.samsung.com/vn

Country Customer Care Center Web Site

CONTENTS

1. Introduction

Special features ...................................................................................................................................................... 1.1

Printer overview ...................................................................................................................................................... 1.2

Finding more information ........................................................................................................................................ 1.4

Selecting a location ................................................................................................................................................. 1.4

2. System setup

Menu overview ........................................................................................................................................................ 2.1

Changing the display language ............................................................................................................................... 2.2

Changing the country .............................................................................................................................................. 2.2

Setting the date and time ........................................................................................................................................ 2.2

Changing the clock mode ........................................................................................................................................ 2.2

Setting sounds ........................................................................................................................................................ 2.2

Entering characters using the number keypad ........................................................................................................ 2.3

Using the save modes ............................................................................................................................................. 2.3

3. Software overview

Supplied software .................................................................................................................................................... 3.1

Printer driver features .............................................................................................................................................. 3.2

System requirements .............................................................................................................................................. 3.2

4. Network setup (SCX-4725FN only)

Introduction ............................................................................................................................................................. 4.1

Supported operating systems ................................................................................................................................. 4.1

Configuring TCP/IP ................................................................................................................................................. 4.1

Configuring EtherTalk ............................................................................................................................................. 4.2

Restoring the network configuration ........................................................................................................................ 4.2

Printing a network configuration page ..................................................................................................................... 4.2

Resetting the network interface ............................................................................................................................... 4.2

5. Loading originals and print media

Loading originals ..................................................................................................................................................... 5.1

Selecting print media ............................................................................................................................................... 5.2

Loading paper ......................................................................................................................................................... 5.5

Setting the paper size and type ............................................................................................................................... 5.7

Verifying an output location ..................................................................................................................................... 5.7

6. Copying

Selecting the paper tray .......................................................................................................................................... 6.1

Copying ................................................................................................................................................................... 6.1

Changing the settings for each copy ....................................................................................................................... 6.1

Changing the default copy settings ......................................................................................................................... 6.2

Using special copy features .................................................................................................................................... 6.2

Setting copy timeout ................................................................................................................................................ 6.4

7. Basic printing

Printing a document ................................................................................................................................................ 7.1

Canceling a print job ............................................................................................................................................... 7.1

8. Scanning

Scanning basics ...................................................................................................................................................... 8.1

Scanning to an application ...................................................................................................................................... 8.1

9. Faxing

Setting the fax header ............................................................................................................................................. 9.1

Adjusting the document settings ............................................................................................................................. 9.1

Sending a fax automatically .................................................................................................................................... 9.2

Sending a fax manually ........................................................................................................................................... 9.2

Confirming a transmission ....................................................................................................................................... 9.3

Automatic redialing .................................................................................................................................................. 9.3

Redialing the last number ....................................................................................................................................... 9.3

Selecting the paper tray .......................................................................................................................................... 9.3

Changing receiving modes ...................................................................................................................................... 9.3

Receiving automatically in Fax mode ..................................................................................................................... 9.4

Receiving manually in Tel mode ............................................................................................................................. 9.4

Receiving manually using an extension telephone ................................................................................................. 9.4

Receiving automatically in Ans/Fax mode .............................................................................................................. 9.4

Receiving faxes using DRPD mode ........................................................................................................................ 9.4

Receiving in secure receiving mode ....................................................................................................................... 9.5

Receiving faxes in memory ..................................................................................................................................... 9.5

Sending a fax to multiple destinations ..................................................................................................................... 9.6

Sending a delayed fax ............................................................................................................................................. 9.6

Sending a priority fax .............................................................................................................................................. 9.7

10. Fax setup

Changing the fax setup options ............................................................................................................................. 10.1

Using the advanced fax features ........................................................................................................................... 10.2

Printing sent fax report automatically .................................................................................................................... 10.2

Using the toll save mode ....................................................................................................................................... 10.2

Setting up Phone Book ......................................................................................................................................... 10.3

11. Ordering supplies and accessories

Toner cartridges .................................................................................................................................................... 11.1

How to purchase ................................................................................................................................................... 11.1

12. Maintenance

Printing reports ...................................................................................................................................................... 12.1

Clearing memory ................................................................................................................................................... 12.1

Cleaning your machine ......................................................................................................................................... 12.2

Maintaining the toner cartridge .............................................................................................................................. 12.3

Clearing the Toner Empty Replace Toner message ............................................................................................. 12.6

Maintenance parts ................................................................................................................................................. 12.6

Managing your machine from the website

(SCX-4725FN only) ............................................................................................................................................. 12.7

13. Troubleshooting

Clearing document jams ....................................................................................................................................... 13.1

Clearing paper jams .............................................................................................................................................. 13.1

Understanding display messages ......................................................................................................................... 13.3

Toner cartridge-related messagesG UUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUUGXZU\

Solving other problems ......................................................................................................................................... 13.5

14. Specifications

General specifications ........................................................................................................................................... 14.1

Printer specifications ............................................................................................................................................. 14.1

Scanner and copier specifications ........................................................................................................................ 14.2

Facsimile specifications ........................................................................................................................................ 14.2

Index

Important Precautions and Safety Information

When using this machine, these basic safety precautions should always be followed to

reduce risk of fire, electric shock and injury to people:

1 Read and understand all instructions.

2 Use common sense whenever operating electrical appliances.

3 Follow all warnings and instructions marked on the machine and in the literature

accompanying the machine.

4 If an operating instruction appears to conflict with safety information, heed the

safety information. You may have misunderstood the operating instruction. If you

cannot resolve the conflict, contact your sales or service representative for

assistance.

5 Unplug the machine from the AC wall socket and/or telephone jack before

cleaning. Do not use liquid or aerosol cleaners. Use only a damp cloth for

cleaning.

6 Do not place the machine on an unstable cart, stand or table. It may fall, causing

serious damage.

7 Your machine should never be placed on, near or over a radiator, heater, air

conditioner or ventilation duct.

8 Do not allow anything to rest on the power. Do not locate your machine where the

cords will be abused by persons walking on them.

9 Do not overload wall outlets and extension cords. This can diminish performance,

and may result in the risk of fire or electric shock.

10 Do not allow pets to chew on the AC power, telephone or PC interface cords.

11 Never push objects of any kind into the machine through case or cabinet

openings. They may touch dangerous voltage points, creating a risk of fire or

shock. Never spill liquid of any kind onto or into the machine.

12 Your machine may have a heavy cover for optimal pressure on the document for

the best scanning and/or faxing (usually the flatbed-type machine). In this case,

replace the cover after placing document on the scan glass, by holding and

moving it down slowly until it seats on its location.

13 To reduce the risk of electric shock, do not disassemble the machine. Take it to a

qualified service technician when repair work is required. Opening or removing

covers may expose you to dangerous voltages or other risks. Incorrect reassembly

could cause electric shock when the unit is subsequently used.

14 Unplug the machine from the telephone jack, PC and AC wall outlet and refer

servicing to qualified service personnel under the following conditions:

• When any part of the power cord, plug or connecting cable is damaged or frayed.

• If liquid has been spilled into the machine.

• If the machine has been exposed to rain or water.

• If the machine does not operate properly after instructions have been followed.

• If the machine has been dropped, or the cabinet appears damaged.

• If the machine exhibits a sudden and distinct change in performance.

15 Adjust only those controls covered by the operating instructions. Improper

adjustment of other controls may result in damage, and may require extensive

work by a qualified service technician to restore the machine to normal operation.

16 Avoid using this machine during a lightning storm. There may be a remote risk of

electric shock from lightning. If possible, unplug the AC power and telephone cord

for the duration of the lightning storm.

17 The Power cord supplied with your machine should be used for safe operation. If

you are using a cord which is longer than 2 m with 110 V machine, then it should

be 16 AWG

or bigger.

18 Use only No.26 AWG

or larger telephone line cord.

19 SAVE THESE INSTRUCTIONS.

Laser Safety Statement

The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR,

chapter 1 Subchapter J for Class I(1) laser products, and elsewhere is certified as a

Class I laser product conforming to the requirements of IEC 825.

Class I laser products are not considered to be hazardous. The laser system and printer

are designed so there is never any human access to laser radiation above a Class I level

during normal operation, user maintenance or prescribed service condition.

WARNING

Never operate or service the printer with the protective cover removed from Laser/

Scanner assembly. The reflected beam, although invisible, can damage your eyes.

When using this product, these basic safety precautions should always be followed to

reduce risk of fire, electric shock, and injury to persons:

Ozone Safety

During normal operation, this machine produces ozone. The ozone

produced does not present a hazard to the operator. However, it is

advisable that the machine be operated in a well ventilated area.

If you need additional information about ozone, please request your

nearest Samsung dealer.

1 AWG: American Wire Gauge

Mercury Safety

LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE

RECYCLED OR DISPOSED OF ACCORDING TO LOCAL, STATE OR

FEDERAL LAWS. For details see lamprecycle.org, eiae.org, or call 1-800-

Samsung

Power Saver

This printer contains advanced energy conservation technology that reduces power

consumption when it is not in active use.

When the printer does not receive data for an extended period of time, power

consumption is automatically lowered.

Recycling

Please recycle or dispose of the packaging material for this product

in an environmentally responsible manner.

Correct Disposal of This Product (Waste Electrical &

Electronic Equipment)

(Applicable in the European Union and other European countries with

separate collection systems)

This marking shown on the product or its literature, indicates that it

should not be disposed with other household wastes at the end of its

working life. To prevent possible harm to the environment or human

health from uncontrolled waste disposal, please separate this from

other types of wastes and recycle it responsibly to promote the

sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product,

or their local government office, for details of where and how they can take this item for

environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the

purchase contract. This product should not be mixed with other commercial wastes for

disposal.

Radio Frequency Emissions

FCC Information to the User

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or experienced radio TV technician for help.

AUTION

Change or modifications not expressly approved by the manufacturer

responsible for compliance could void the user's authority to operate the equipment.

Canadian Radio Interference Regulations

This digital apparatus does not exceed the Class B limits for radio noise emissions from

digital apparatus as set out in the interference-causing equipment standard entitled

“Digital Apparatus”, ICES-003 of the Industry and Science Canada.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux

appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur:

“Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.

Fax Branding

The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to

use a computer or other electronic device to send any message via a telephone

facsimile machine unless such message clearly contains in a margin at the top or bottom

of each transmitted page or on the first page of the transmission the following

information:

(1) the date and time of transmission

(2) identification of either business, business entity or individual sending the message;

and

(3) telephone number of either the sending machine, business, business entity or

individual.

The Telephone Company may make changes in its communications facilities,

equipment operations or procedures where such action is reasonably required in the

operation of its business and is not inconsistent with the rules and regulations in FCC

Part 68. If such changes can be reasonably expected to render any customer terminal

equipment incompatible with telephone company communications facilities, or require

modification or alteration of such terminal equipment, or otherwise materially affect its

use or performance, the customer shall be given adequate notice in writing, to allow the

customer an opportunity to maintain uninterrupted service.

Ringer Equivalence Number

The Ringer Equivalence Number and FCC Registration Number for this machine may

be found on the label located on the bottom or rear of the machine. In some instances

you may need to provide these numbers to the telephone company.

The Ringer Equivalence Number (REN) is a measure of the electrical load placed on the

telephone line, and is useful for determining whether you have “overloaded” the line.

Installing several types of equipment on the same telephone line may result in problems

making and receiving telephone calls, especially ringing when your line is called. The

sum of all Ringer Equivalence Numbers of the equipment on your telephone line should

be less than five in order to assure proper service from the telephone company. In some

cases, a sum of five may not be usable on your line. If any of your telephone equipment

is not operating properly, you should immediately remove it from your telephone line, as

it may cause harm to the telephone network.

iii

WARNING:

FCC Regulations state that changes or modifications to this equipment not expressly

approved by the manufacturer could void the user’s authority to operate this equipment.

In the event that terminal equipment causes harm to the telephone network, the

telephone company should notify the customer that service may be stopped. However,

where prior notice is impractical, the company may temporarily cease service, providing

that they:

a) promptly notify the customer.

b) give the customer an opportunity to correct the equipment problem.

c) inform the customer of the right to bring a complaint to the Federal Communication

Commission pursuant to procedures set out in FCC Rules and Regulations Subpart E

of Part 68.

You should also know that:

• Your machine is not designed to be connected to a digital PBX system.

• If you intend to use a computer modem or fax modem on the same phone line as

your machine, you may experience transmission and reception problems with all the

equipment. It is recommended that no other equipment, except for a regular

telephone, share the line with your machine.

• If your area experiences a high incidence of lightning or power surges, we

recommend that you install surge protectors for both the power and the telephone

lines. Surge protectors can be purchased from your dealer or telephone and

electronic specialty stores.

• When programming emergency numbers and/or making test calls to emergency

numbers, use a non-emergency number to advise the emergency service dispatcher

of your intentions. The dispatcher will give you further instructions on how to actually

test the emergency number.

• This machine may not be used on coin service or party lines.

• This machine provides magnetic coupling to hearing aids.

• You may safely connect this equipment to the telephone network by means of a

standard modular jack, USOC RJ-11C.

Declaration of Conformity (European Countries)

Approvals and Certifications

The CE marking applied to this product symbolizes Samsung

Electronics Co., Ltd. Declaration of Conformity with the following

applicable 93/68/EEC Directives of the European Union as of the

dates indicated:

January 1, 1995

: Council Directive 73/23/EEC Approximation of the laws of the

member states related to low voltage equipment.

January 1, 1996

: Council Directive 89/336/EEC (92/31/EEC), approximation of the laws

of the Member States related to electromagnetic compatibility.

March 9, 1999

: Council Directive 1999/5/EC on radio equipment and

telecommunications terminal equipment and the mutual recognition of their conformity.

A full declaration, defining the relevant Directives and referenced standards can be

obtained from your Samsung Electronics Co., Ltd. representative.

EC Certification

Certification to 1999/5/EC Radio Equipment & Telecommunications

Terminal Equipment Directive (FAX)

This Samsung product has been self-certified by Samsung for pan-European single

terminal connection to the analogue public switched telephone network (PSTN) in

accordance with Directive 1999/5/EC. The product has been designed to work with the

national PSTNs and compatible PBXs of the European countries:

In the event of problems, you should contact the Euro QA Lab of Samsung Electronics

Co., Ltd. in the first instance.

The product has been tested against TS103 021. To assist in the use and application of

terminal equipment which complies with this standard, the European

Telecommunication Standards Institute (ETSI) has issued an advisory document (EG

201 121) which contains notes and additional requirements to ensure network

compatibility of TS103 021 terminals. The product has been designed against, and is

fully compliant with, all of the relevant advisory notes contained in this document.

Replacing the Fitted Plug (for UK Only)

MPORTANT

The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and has

a 13 amp fuse. When you change or examine the fuse, you must re-fit the correct 13

amp fuse. You then need to replace the fuse cover. If you have lost the fuse cover, do

not use the plug until you have another fuse cover.

Please contact the people from you purchased the machine.

The 13 amp plug is the most widely used type in the UK and should be suitable.

However, some buildings (mainly old ones) do not have normal 13 amp plug sockets.

You need to buy a suitable plug adaptor. Do not remove the moulded plug.

ARNING

If you cut off the moulded plug, get rid of it straight away.

You cannot rewire the plug and you may receive an electric shock if you plug it

into a socket.

MPORTANT WARNING

You must earth this machine.

The wires in the mains lead have the following color code:

• Green and Yellow: Earth

• Blue: Neutral

•Brown: Live

If the wires in the mains lead do not match the colors marked in your plug, do the

following:

You must connect the green and yellow wire to the pin marked by the letter “E” or by the

safety ‘Earth symbol’ or colored green and yellow or green.

You must connect the blue wire to the pin which is marked with the letter “N” or colored

black.

You must connect the brown wire to the pin which is marked with the letter “L” or colored

red.

You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.

1.1 <

Introduction>

1 Introduction

Thank you for purchasing this Samsung multifunctional product. Your

machine provides printing, copying, scanning, and faxing functions.

This chapter includes:

• Special features

• Printer overview

• Finding more information

• Selecting a location

Special features

Your new machine is equipped with special features that improve print

quality. You can:

Print with excellent quality and speed

• You can print with a resolution of up to 1200 dpi [Best].

See the Software Section.

• Your machine prints A4-sized paper at up to 24 ppm1

and letter-sized paper at up to 24 ppm.

Handle paper flexibly

•The manual tray supports letterhead, envelopes,

labels, transparencies, custom-sized media, postcards,

and heavy paper. The manual tray holds 1 sheet of

paper.

•The 250-sheet tray supports plain paper in various

sizes.

Create professional documents

•Print Watermarks. You can customize your documents

with words, such as “Confidential”. See the Software

Section.

•Print Posters. The text and pictures of each page of

your document are magnified and printed across the

sheet of paper and can then be taped together to form

a poster. See the Software Section.

Save time and money

• You can print multiple pages on one single sheet of paper to save

paper.

• You can use preprinted forms and letterhead with plain paper. See the

Software Section.

• This machine automatically conserves electricity by substantially

reducing power consumption when not in use.

250

Print in various environments

• You can print with Windows 98/Me/2000/XP(32/64bit

2003(32/64bit

• Your machine is compatible with a variety of Linux systems.

• Your machine is compatible with a variety of Macintosh systems

(SCX-4725FN only).

• Zoran IPS Emulation* compatible with PostScript 3 (PS) enables PS

printing (SCX-4725FN only).

* Zoran IPS Emulation compatible with PostScript 3

rights reserved. Zoran, the Zoran logo, IPS/PS3, and

OneImage are trademarks of Zoran Corporation.

* 136 PS3 fonts

Contains UFST and MicroType from Monotype Imaging Inc.

Machine features

The table below lists a general overview of features supported by your

machine.

(I: Installed, NA: Not Available)

Features SCX-4725F SCX-4725FN

IEEE 1284 Parallel NA NA

USB 2.0 I I

PostScript Emulation NA I

Network Interface

(Ethernet 10/100 Base TX)

NA I

Duplex Printing

1. Printing on both sides of paper.

NA NA

Macintosh Driver NA I

1. pages per minute

1.2 <

Introduction>

Printer overview

These are the main components of your machine:

Front view

ADF (automatic

document feeder)1

1. Automatic document feeder is used as ADF in this user’s guide.

8front cover

document width guides 9tray

document input tray 10 output support

scanner lid 11 scanner glass

document output tray 12 manual tray

control panel 13 toner cartridge

output tray 14 manual tray paper width

guides

* The figure above shows an SCX-4725FN.

Rear view

1rear cover

telephone line socket

(LINE)

2power switch

network port1

1. SCX-4725FN only.

3power receptacle

USB port

4extension telephone

socket (EXT)

* The figure above shows an SCX-4725FN.

1.3 <

Introduction>

Control panel overview

Darkness

: Adjusts the document brightness for the current copy

job.

Start

: Starts a job.

No. of Copies

: Enters the number of copies. 12

Stop/Clear

: Stops an operation at any time. In Standby mode,

clears/cancels the copy options, such as the darkness, the

document type setting, the copy size, and the number of copies.

Original Type

: Selects the document type for the current copy job. 13

Number keypad

: Dials a number or enters alphanumeric

characters.

Reduce/Enlarge

: Makes a copy smaller or larger than the original. 14

Resolution

: Adjusts the document resolution for the current fax job.

Favorite Copy

: Allows you to use one of the special copy features,

such as Clone, Copy Collate, Autofit, ID Card Copy, 2/4 Up and

Poster.

Broadcasting

: Allows you to send a fax to multiple destinations.

Display

: Shows the current status and prompts during an operation. 16

Phone Book

: Allows you to store frequently used fax numbers in

memory or search for stored fax numbers. Also allows you to print a

Phone Book

list.

7Scroll buttons: Scroll through the options available in the selected

menu, and increase or decrease values.

Redial/Pause

: In Standby mode, redials the last number, or in Edit

mode, inserts a pause into a fax number.

Enter

: Confirms the selection on the display. 18

On Hook Dial

: Engages the telephone line.

: Enters Menu mode and scrolls through the available menus. 19

Scan To

: Allows you to access a list of the PC software programs

that an image can be scanned to.

Upper Level

: Sends you back to the upper menu level. 20

Toner Save

: Allows you to save on toner by using less toner in

printing.

1.4 <

Introduction>

Finding more information

You can find information for setting up and using your machine from the

following resources, either printed or onscreen.

Quick Install

Guide

Provides information on setting up your

machine and, therefore, be sure to follow

the instructions in the guide to get the

machine ready.

Online User’s

Guide

Provides you with step-by-step

instructions for using your machine’s full

features, and contains information for

maintaining your machine,

troubleshooting, and installing

accessories.

This user’s guide also contains the

Software Section

providing you with

information on how to print documents

with your machine on various operating

systems, and how to use the supplied

software utilities.

Note

You can access the user’s guides

in other languages from the

Manual folder on the printer

software CD.

Network Printer

User’s Guide

Contained on the

network utilities CD

provides you with information on setting

up and connecting your machine to a

network.

Printer Driver

Help

Provides you with help information on

printer driver properties and instructions

for setting up the properties for printing. To

access a printer driver help screen, click

Help

from the printer properties dialog

box.

Website If you have Internet access, you can get

help, support, printer drivers, manuals,

and order information from the Samsung

website, www.samsungprinter.com.

Selecting a location

Select a level, stable place with adequate space for air circulation. Allow

extra space for opening covers and trays.

The area should be well-ventilated and away from direct sunlight or

sources of heat, cold, and humidity. Do not set the machine close to the

edge of your desk or table.

Clearance space

•Front: 482.6 mm (enough space so that the tray and cover can be

opened)

•Back: 100 mm (enough space for ventilation)

•Right: 100 mm (enough space for ventilation)

•Left: 100 mm (enough space for ventilation)

2.1 <

System setup>

2 System setup

This chapter gives you an overview of menus available on your machine

and step-by-step instructions for setting up the machine’s systems.

This chapter includes:

• Menu overview

• Changing the display language

• Changing the country

• Setting the date and time

• Changing the clock mode

• Setting sounds

• Entering characters using the number keypad

• Using the save modes

Menu overview

The control panel provides access to various menus to set up the

machine or use the machine’s functions. These menus can be accessed

by pressing Menu. Refer to the following diagram.

Fax Feature

DelayFax

Priority Fax

Add Page

Cancel Job

Fax Setup

Receive Mode

Ring to Answer

Darkness

Redial Term

Redials

MSG Confirm

Auto Report

Auto Reduction

Discard Size

RCV Start Code

DRPD Mode

Copy Setup

Default Change

Timeout

Advanced Fax

Toll Save

Junk Fax Setup

Secure Receive

Prefix Dial

Stamp RCV Name

ECM Mode

Network Setup

Reset Network

Config Network

Set To Default

Print Net CFG

Menus in the colored characters are available only with SCX-4725FN.

Paper Setting

Copy Tray

Fax Tray

Paper Size

Paper Type

Machine Setup

Machine ID

Date & Time

Clock Mode

Language

Select Country

Power Save

Scan PWR Save

Ignore Toner

Sound/Volume

Speaker

Ringer

Key Sound

Alarm Sound

Maintenance

Clean Drum

Auto Cleaning

CLR Empty Msg.

Notify Toner

Clear Memory

Reports

Phone Book

Sent Report

RCV Report

System Data

Scheduled Jobs

MSG Confirm

Junk Fax List

2.2 <

System setup>

Changing the display language

To change the language that appears on the control panel, follow these

steps:

1Press Menu until Machine Setup appears on the top line of the

display.

2Press the Scroll buttons until Language appears and press Enter.

3Press the Scroll buttons until the language you want appears and

press Enter.

4Press Stop/Clear to return to Standby mode.

Changing the country

You can select your country.

1Press Menu until Machine Setup appears on the top line of the

display.

2Press the Scroll buttons until Select Country appears and press

Enter.

3Press the Scroll buttons until your country appears and press

Enter.

4Press Stop/Clear to return to Standby mode.

Note

Changing the country clears the setting in memory.

Setting the date and time

The current date and time are shown on the display when your machine

is on and ready to work. All of your faxes will have the date and time

printed on them.

Note

If power to the machine is cut off, you need to reset the correct

time and date once the power has been restored.

1Press Menu until Machine Setup appears on the top line of the

display.

2Press the Scroll buttons until Date & Time appears and press

Enter.

3Enter the correct time and date using the number keypad.

Day = 01 to 31

Month = 01 to 12

Year = requires four digits

Hour = 01 to 12 (12-hour mode)

00 to 23 (24-hour mode)

Minute = 00 to 59

Note

The date format may differ from country to country.

You can also use the Scroll buttons to move the cursor under the

digit you want to correct and enter a new number.

4To change AM or PM for 12-hour time format, press the or

button or any number button.

When the cursor is not under the AM or PM indicator, pressing the

or button immediately moves the cursor to the indicator.

You can change the clock mode to 24-hour time format (e.g. 01:00

PM as 13:00). For details, see the next section.

5Press Enter to save the time and date.

When you enter a wrong number, Unavailable Date & Time

appears and the machine does not proceed to the next step. If this

happens, simply reenter the correct number.

6Press Stop/Clear to return to Standby mode.

Changing the clock mode

You can set your machine to display the current time using either a

12-hour or 24-hour time format.

1Press Menu until Machine Setup appears on the top line of the

display.

2Press the Scroll buttons until Clock Mode appears and press

Enter.

3Press the Scroll buttons to select the other mode and press Enter.

4Press Stop/Clear to return to Standby mode.

Setting sounds

You can control the following sounds:

•Speaker: Turns on or off the sounds from the telephone line through

the speaker, such as a dial tone or a fax tone. With this option set to

Comm which means “Common,” the speaker is on until the remote

machine answers.

You can adjust the speaker volume level using On Hook Dial.

•Ringer: Adjusts the ringer volume. For the ringer volume, you can

select Off,Low,Med, and High.

•Key Sound: Turns the key sound on or off. With this option set to On,

a tone sounds each time a key is pressed.

•Alarm Sound: Turns the alarm sound on or off. With this option set to

On, an alarm tone sounds when an error occurs or fax communication

ends.

2.3 <

System setup>

Speaker, ringer, key sound, and alarm sound

1Press Menu until Sound/Volume appears on the top line of the

display.

2Press the Scroll buttons until the sound option you want appears

and press Enter.

3Press the Scroll buttons until the desired status or volume for the

sound you have selected appears and press Enter.

4If necessary, repeat steps 2 through 3 to set other sounds.

5Press Stop/Clear to return to Standby mode.

Speaker volume

1Press On Hook Dial. A dial tone sounds from the speaker.

2Press the Scroll buttons until you hear the volume you want.

3Press On Hook Dial to save the change and return to Standby

mode.

Note

You can adjust the speaker volume only when the telephone

line is connected.

Entering characters using the number keypad

As you perform various tasks, you may need to enter names and

numbers. For example, when you set up your machine, you enter your

name or your company’s name, and the fax number. When you store fax

numbers in memory, you may also enter the corresponding names.

Entering alphanumeric characters

1When you are prompted to enter a letter, locate the button labeled

with the character you want. Press the button until the correct letter

appears on the display.

For example, to enter the letter O, press 6, labeled with MNO.

Each time you press 6, the display shows a different letter, M,N,O,

and finally 6.

You can enter special characters, such as space, plus sign, and etc.

For details, see the next section.

2To enter additional letters, repeat step 1.

If the next letter is printed on the same button, move the cursor by

pressing the right Scroll button and then press the button labeled

with the letter you want. The cursor will move to the right and the

next letter will appear on the display.

You can enter a space by pressing 1 twice.

3When you have finished entering letters, press Enter.

Keypad letters and numbers

Correcting numbers or names

If you make a mistake while entering a number or name, press the left

Scroll button to delete the last digit or character. Then enter the correct

digit or character.

Inserting a pause

With some telephone systems, you must dial an access code (9, for

example) and listen for a second dial tone. In such cases, you must insert

a pause in the telephone number. You can insert a pause while you are

setting up speed dial numbers.

To insert a pause, press Redial/Pause at the appropriate place while

entering the telephone number. A - appears on the display at the

corresponding location.

Using the save modes

Toner Save mode

Toner Save mode allows your machine to use less toner on each page.

Activating this mode extends the life of the toner cartridge beyond what

one would experience in the normal mode, but it reduces print quality.

To turn this mode on or off, press Toner Save.

Note

When PC-printing, you can also turn on or off Toner Save mode

in the printer properties. See the Software Section.

Key Assigned numbers, letters, or characters

1Space

ABC2

DEF3

GHI4

JKL5

MNO6

PQRS7

TUV8

WXYZ9

+ -,.‘/*#&0

2.4 <

System setup>

Power Save mode

Power Save mode allows your machine to reduce power consumption

when it is not in actual use. You can select a length of time for which the

machine waits after a job is printed before it switches to a reduced power

state.

1Press Menu until Machine Setup appears on the top line of the

display.

2Press the Scroll buttons until Power Save appears and press

Enter.

3Press the Scroll buttons until the time setting you want appears and

press Enter.

4Press Stop/Clear to return to Standby mode.

Scan Power Save mode

Scan Power Save mode allows you to save power by turning off the scan

lamp. The scan lamp under the scanner glass automatically turns off

when it is not in actual use to reduce power consumption and extend the

life of the lamp. The lamp automatically wakes up after some warm-up

time when you start scanning.

You can set the length of time for which the scan lamp waits after a scan

job is completed before it switches to the power save mode.

1Press Menu until Machine Setup appears on the top line of the

display.

2Press the Scroll buttons until Scan PWR Save appears and press

Enter.

3Press the Scroll buttons until the time setting you want appears and

press Enter.

4Press Stop/Clear to return to Standby mode.

3.1 <

Software overview>

3 Software overview

This chapter gives you an overview of the software that comes with your

machine. Further details about installing and using the software are

explained in the Software Section.

This chapter includes:

• Supplied software

• Printer driver features

• System requirements

Supplied software

You must install the printer and scanner software using the supplied CDs

after you have set up your machine and connected it to your computer.

Each CD provides you with the following software:

CD Contents

Printer

software CD

Windows • Printer driver: Use this driver to

take full advantage of your printer’s

features.

•Scanner driver: TWAIN and

Windows Image Acquisition (WIA)

drivers are available for scanning

documents on your machine.

•Smart Panel: This program allows

you to monitor the machine’s status

and alerts you when an error occurs

during printing.

•SmarThru1: This is the

accompanying Windows-based

software for your multifunctional

machine.

•User’s Guide in PDF

Linux • Printer driver: Use this driver to run

your machine from a Linux computer

and print documents.

•SANE: Use this driver to scan

documents.

PostScript

printer driver

(SCX-4725FN

only)

Windows • Postscript Printer Description

(PPD) file: Use the PostScript driver

to print documents with complex

fonts and graphics in the PS

language.

•User’s Guide in PDF

Macintosh • Postscript Printer Description

(PPD) file: Use this file to run your

machine from a Macintosh computer

and print documents.

•Scan driver: TWAIN driver is

available for scanning documents on

your machine.

Network

utilities CD

(SCX-4725FN

only)

Windows • SyncThru™ Web Admin Service:

Use this web-based program to

remotely manage, monitor, and

troubleshoot network printers.

•Set IP: Use this program to set your

machine’s TCP/IP addresses.

•Network Printer User’s Guide in

PDF

1. Allows you to edit a scanned image in many ways using a powerful image

editor and to send the image by email. You can also open another image editor

program, like Adobe Photoshop, from SmarThru. For details, please refer to the

onscreen help supplied on the SmarThru program.

CD Contents

3.2 <

Software overview>

Printer driver features

Your printer drivers support the following standard features:

• Paper source selection

• Paper size, orientation and media type

• Number of copies

In addition, you can use various special printing features. The following

table shows a general overview of features supported by your printer

drivers:

Feature

PCL 6 PostScript

(SCX-4725FN only)

Windows Windows Macintosh Linux

Toner save O O XO

Print quality

option

OOOO

Poster

printing

OX X X

Multiple

pages per

sheet (N-up)

OOOO

(2, 4)

Fit to page

printing

OOO

Scale printing O O O X

Watermark O X X X

Overlay O X X X

System requirements

Before you begin, ensure that your system meets the following

requirements:

Windows

Note

For Windows 2000/XP(32/64bit)/2003(32/64bit), users who

have an administrator right can install the software.

Item Requirements Recommended

Operating

system

Windows 98/Me/2000/XP(32/64bit)/2003(32/64bit)

CPU Windows 98/

Me/2000

Pentium II

400 MHz or

higher

Pentium III

933 MHz

Windows

XP(32/64bit)/

2003(32/64bit)

Pentium III

933 MHz or

higher

Pentium IV

1GHz

RAM Windows 98/

Me/2000

64 MB or more 128 MB

Windows

XP(32/64bit)/

2003(32/64bit)

128 MB or more 256 MB

Free disk

space

Windows 98/

Me/2000

300 MB or more 1 GB

Windows

XP(32/64bit)/

2003(32/64bit)

1GB or more 5GB

Internet

Explorer

5.0 or higher

3.3 <

Software overview>

Linux

Macintosh (SCX-4725FN only)

Item Requirements

Operating system • Red Hat 8.0 ~ 9.0

• Fedora Core 1 ~ 4

• Mandrake 9.2 ~ 10.1

• SuSE 8.2 ~ 9.2

CPU Pentium IV 1 GHz or higher

RAM 256 MB or higher

Free disk space 1 GB or higher

Software • Linux Kernel 2.4 or higher

• Glibc 2.2 or higher

• CUPS

• SANE (for MFP device only)

Notes

• It is necessary to claim swap partition of 300 MB or larger for

working with large scanned images.

• The Linux scanner driver supports the optical resolution at

maximum.

Item Requirements

Operating system Macintosh 10.3 ~ 10.4

RAM 128 MB

Free disk space 200 MB

Connection USB interface, Network interface

4.1 <

Network setup (SCX-4725FN only)>

4 Network setup (SCX-4725FN only)

Connecting your machine to a network is available only on the

SCX-4725FN. This chapter gives you step-by-step instructions for setting

up your machine for network connections.

This chapter includes:

• Introduction

• Supported operating systems

• Configuring TCP/IP

• Configuring EtherTalk

• Restoring the network configuration

• Printing a network configuration page

• Resetting the network interface

Introduction

Once you have connected your machine to a network with an RJ-45

Ethernet cable, you can share the machine with other network users.

You need to set up the network protocols on the machine to use it as your

network printer. Protocols can be set up by the following two methods:

Via network administration programs

You can configure your machine’s print server settings and manage the

machine via the following programs that came with your machine:

•SyncThru™ Web Admin Service: A web-based printer management

solution for network administrators. SyncThru™ Web Admin Service

provides you with an efficient way of managing network devices and

lets you remotely monitor and troubleshoot network printers from any

site with corporate intranet access.

•SyncThru™ Web Service: A web server embedded to your network

print server, which allows you to:

- Configure the network parameters necessary for the machine to

connect to various network environments.

- Customize printer, copy, and fax settings.

•SetIP: A utility program allowing you to select a network interface and

manually configure the addresses for use with the TCP/IP protocol.

For further details, refer to the user’s guide on the network utilities CD that

came with your machine.

Via the control panel

You can set up the following basic network parameters through the

machine’s control panel:

• Configure TCP/IP

• Configure EtherTalk

Supported operating systems

The following table shows the network environments supported by the

machine:

• TCP/IP: Transmission Control Protocol/Internet Protocol

• DHCP: Dynamic Host Configuration Protocol

• BOOTP: Bootstrap Protocol

Configuring TCP/IP

Your machine can be set up with a variety of TCP/IP network information,

such as an IP address, a subnet mask, and a gateway. There are several

ways in which your machine can be assigned a TCP/IP address,

depending on your network.

• Static addressing: A TCP/IP address is assigned manually by the

system administrator.

• Dynamic addressing via BOOTP/DHCP (default): A TCP/IP address is

assigned automatically by the server.

Note

Before configuring TCP/IP, you need to set the network protocol

to TCP/IP.

Item Requirements

Network interface • 10/100 Base-TX

Network operating

system

• Windows 98/Me/2000/XP(32/64bit)/

2003(32/64bit)

• Various Linux OS

• Macintosh OS 10.3~10.4

Network protocols • TCP/IP on Windows

•EtherTalk

Dynamic addressing

server

• DHCP, BOOTP

4.2 <

Network setup (SCX-4725FN only)>

Static addressing

To enter a TCP/IP address from your machine’s control panel, take the

following steps:

1Press Menu until Network Setup appears on the top line of the

display.

2Press the Scroll buttons until Config Network appears and press

Enter.

3Press Enter when TCP/IP appears.

4Press Enter when Manual appears.

5Press Enter when IP Address appears.

6Enter a byte between 0 and 255 using the number keypad and

press the Scroll buttons to move between bytes.

Repeat this to complete the address from the 1st byte to the 4th

byte.

7When you have finished, press Enter.

8Repeat steps 6 and 7 to configure the other TCP/IP parameters:

subnet mask and gateway address.

9Press Stop/Clear to return to Standby mode.

Dynamic addressing (BOOTP/DHCP)

To have a TCP/IP address assigned automatically by the server, take the

following steps:

1Press Menu until Network Setup appears on the top line of the

display.

2Press the Scroll buttons until Config Network appears and press

Enter.

3Press Enter when TCP/IP appears.

4Press the

Scroll

buttons until

DHCP

BOOTP

appears and press

Enter.

5Press Stop/Clear to return to Standby mode.

Configuring EtherTalk

EtherTalk is AppleTalk used in an Ethernet network. This protocol is

widely used in Macintosh network environments. To use EtherTalk, take

the following steps:

1Press Menu until Network Setup appears on the top line of the

display.

2Press the Scroll buttons until Config Network appears and press

Enter.

3Press the Scroll buttons until EtherTalk appears and press Enter.

4Press the Scroll buttons until On appears and press Enter.

5Press Stop/Clear to return to Standby mode.

Restoring the network configuration

You can return the network configuration to its default settings.

1Press Menu until Network Setup appears on the top line of the

display.

2Press the Scroll buttons until Set To Default appears and press

Enter.

3Press Enter when Yes appears to restore the network configuration.

4Power the machine off and back on.

Printing a network configuration page

The network configuration page shows how the network interface on your

machine is configured.

1Press Menu until Network Setup appears on the top line of the

display.

2Press the Scroll buttons until Print Net CFG appears and press

Enter.

3Press Enter when Yes appears.

The network configuration page prints out.

Resetting the network interface

You can reset the embedded network interface when a network problem

occurs.

1Press Menu until Network Setup appears on the top line of the

display.

2Press Enter when Reset Network appears.

The machine resets the network interface.

5.1 <

Loading originals and print media>

5 Loading originals and print

media

This chapter introduces you to how to load originals and print media into

your machine.

This chapter includes:

• Loading originals

• Selecting print media

• Loading paper

• Setting the paper size and type

• Verifying an output location

Loading originals

You can use the scanner glass or ADF to load an original for copying,

scanning, and sending a fax.

On the scanner glass

Make sure that no originals are in the ADF. If an original is detected in the

ADF, the machine gives it priority over the original on the scanner glass.

To get the best scan quality, especially for colored or gray-scaled images,

use the scanner glass.

1Lift and open the scanner lid.

2Place the original face down on the scanner glass and align it with

the registration guide at the top left corner of the glass.

3Close the scanner lid.

In the ADF

Using the ADF, you can load up to 30 sheets of paper (75 g/m2) for one

job.

When you use the ADF:

• Do not load paper smaller than 142 x 148 mm or larger than

216 x 356 mm.

• Do not attempt to load the following types of paper:

- carbon-paper or carbon-backed paper

- coated paper

- onion skin or thin paper

- wrinkled or creased paper

- curled or rolled paper

- torn paper

• Remove all staples and paper clips before loading.

• Make sure any glue, ink, or correction fluid on the paper is completely

dry before loading.

• Do not load originals that include different sizes or weights of paper.

• Do not load booklets, pamphlets, transparencies, or documents

having other unusual characteristics.

Notes

• Leaving the scanner lid open while copying may affect copy

quality and toner consumption.

• Dust on the scanner glass may cause black spots on the

printout. Always keep it clean.

5.2 <

Loading originals and print media>

To load an original into the ADF:

1Load the original face up into the ADF. Make sure that the bottom of

the original stack matches the paper size marked on the document

input tray.

2Adjust the document width guides to the paper size.

Note

Dust on the ADF glass may cause black lines on the printout.

Always keep it clean.

Selecting print media

You can print on a variety of print media, such as plain paper, envelopes,

labels, and transparencies. Always use print media that meet the

guidelines for use with your machine. Print media that does not meet the

guidelines outlined in this user’s guide may cause the following problems:

• Poor print quality

• Increased paper jams

• Premature wear on the machine.

Properties, such as weight, composition, grain, and moisture content, are

important factors that affect the machine’s performance and the output

quality. When you choose print materials, consider the following:

• Desired outcome: The print media you choose should be appropriate

for your project.

• Size: You can use any size media that fits easily within the paper

adjusters of the paper tray.

• Weight: Your machine supports print media weights as follows:

- 60 to 90 g/m2 bond for the tray

- 60 to 165 g/m2 bond for the manual tray

• Brightness: Some print media are whiter than others and produce

sharper, more vibrant images.

• Surface smoothness: The smoothness of the print media affects how

crisp the printing looks on the paper.

Caution

Using print media that does not meet these specifications may

cause problems, requiring repairs. Such repairs are not covered

by Samsung’s warranty or service agreements.

Notes

• Some print media may meet all of the guidelines in this section

and still not produce satisfactory results. This may be the result

of improper handling, unacceptable temperature and humidity

levels, or other variables over which Samsung has no control.

• Before purchasing large quantities of print media, ensure that it

meets the requirements specified in this user’s guide.

5.3 <

Loading originals and print media>

Supported print media types and sizes

Type Size Dimensions Weight1

1. If media weight is over 90 g/m2, use the manual tray.

Capacity2

2. Maximum capacity may differ depending on media weight, thickness, and environmental conditions.

Plain paper Letter 216 x 279 mm (8.5 x 11 inches) • 60 to 90 g/m2 (16 to 24 lb

bond) for the tray

• 60 to 165 g/m2 (16 to 43 lb

bond) for the manual tray

• 250 sheets of 75 g/m2

(20 lb bond) paper for the

tray

• 1 sheet for the manual tray

Legal 216 x 356 mm (8.5 x 14 inches)

Folio 216 x 330.2 mm (8.5 x 13 inches)

Oficio 216 x 343 mm (8.5 x 13.5 inches)

A4 210 x 297 mm (8.27 x 11.69 inches)

JIS B5 182 x 257 mm (7.18 x 10.12 inches)

ISO B5 176 x 250 mm (6.93 x 9.84 inches)

Executive 184.2 x 266.7 mm (7.25 x 10.5 inches)

A5 148.5 x 210 mm (5.85 x 8.27 inches)

A6 105 x 148.5 mm (4.13 x 5.85 inches)

Envelope Envelope B5 176 x 250 mm (6.93 x 9.84 inches) 75 to 90 g/m2(20 lb to 24 lb

bond)

1 sheet for the manual tray

Envelope Monarch 98.4 x 190.5 mm (3.88 x 7.5 inches)

Envelope COM-10 105 x 241 mm (4.12 x 9.5 inches)

Envelope DL 110 x 220 mm (4.33 x 8.66 inches)

Envelope C5 162 x 229 mm (6.38 x 9.02 inches)

Envelope C6 114 x 162 mm (4.49 x 6.38 inches)

Transparency Letter, A4 Refer to the Plain paper section 138 to 146 g/m2(37 to 39 lb

bond)

1 sheet for the manual tray

Labels Letter, Legal, Folio,

A4, JIS B5, ISO B5,

Executive, A5, A6

Refer to the Plain paper section 120 to 150 g/m2(32 to 40 lb

bond)

1 sheet for the manual tray

Card stock Letter, Legal, Folio,

A4, JIS B5, ISO B5,

Executive, A5, A6

Refer to the Plain paper section 60 to 165 g/m2(16 to 43 lb

bond)

1 sheet for the manual tray

Minimum size (custom) 76 x 127 mm (3 x 5 inches) 60 to 165 g/m2(16 to 43 lb

bond)

1 sheet for the manual tray

Maximum size (custom) 215.9 x 356 mm (8.5 x 14 inches)

5.4 <

Loading originals and print media>

Media sizes supported in each mode

Guidelines for selecting and storing print media

When selecting or loading paper, envelopes, or other print materials,

keep these guidelines in mind:

• Always use print media that conform with the specifications listed on

page 5.3.

• Attempting to print on damp, curled, wrinkled, or torn paper can cause

paper jams and poor print quality.

• For the best print quality, use only high quality copier grade paper

specifically recommended for use in laser printers.

• Avoid using the following media types:

- Paper with embossed lettering, perforations, or a texture that is too

smooth or too rough

- Erasable bond paper

- Multi-paged paper

- Synthetic paper and thermally reactive paper

- Carbonless paper and tracing paper

Use of these types of paper could result in paper jams, chemical

smells, and damage to your machine.

• Store print media in its ream wrapper until you are ready to use it.

Place cartons on pallets or shelves, not on the floor. Do not place

heavy objects on top of the paper, whether it is packaged or

unpackaged. Keep it away from moisture or other conditions that can

cause it to wrinkle or curl.

• Store unused print media at temperatures between 15 °C and 30 °C.

The relative humidity should be between 10% and 70%.

• Store unused print media in a moisture-proof wrap, such as a plastic

container or bag, to prevent dust and moisture from contaminating

your paper.

• Load special media types one sheet at a time through the manual tray

to avoid paper jams.

• To prevent print media, such as transparencies and label sheets, from

sticking together, remove them as they print out.

Caution

If you print 20 envelopes in succession, the surface of the rear

cover may become hot. Please exercise caution.

Mode Size Source

Copy mode Letter, A4, Legal, Folio,

Executive, ISO B5, JIS

B5, A5, A6

•tray

• manual tray

Print mode All sizes supported by

the machine

•tray

• manual tray

Fax mode Letter, A4, Legal • tray

• manual tray

Guidelines for special print media

Media type Guidelines

Envelopes • Successful printing on envelopes depends upon

the quality of the envelopes. When selecting

envelopes, consider the following factors:

- Weight: The weight of the envelope paper

should not exceed 90 g/m2 or jamming may

occur.

- Construction: Prior to printing, envelopes

should lie flat with less than 6 mm curl, and

should not contain air.

- Condition: Envelopes should not be wrinkled,

nicked, or otherwise damaged.

- Temperature: You should use envelopes that

are compatible with the heat and pressure of

the machine during operation.

• Use only well-constructed envelopes with sharp

and well creased folds.

• Do not use stamped envelopes.

• Do not use envelopes with clasps, snaps,

windows, coated lining, self-adhesive seals, or

other synthetic materials.

• Do not use damaged or poorly made envelopes.

• Be sure the seam at both ends of the envelope

extends all the way to the corner of the

envelope.

• Envelopes with a peel-off adhesive strip or with

more than one flap that folds over to seal must

use adhesives compatible with the machine’s

fusing temperature of 180 °C for 0,1 second.

The extra flaps and strips might cause wrinkling,

creasing, or jams, and may even damage the

fuser.

• For the best print quality, position margins no

closer than 15 mm from the edges of the

envelope.

• Avoid printing over the area where the

envelope’s seams meet.

Acceptable

Unacceptable

5.5 <

Loading originals and print media>

Transparencies • To avoid damaging the machine, use only

transparencies designed for use in laser printers.

• Transparencies used in the machine must be

able to withstand 180 °C, the machine’s fusing

temperature.

• Place them on a flat surface after removing them

from the machine.

• Do not leave them in the paper tray for long

periods of time. Dust and dirt may accumulate

on them, resulting in spotty printing.

• To avoid smudging caused by fingerprints,

handle them carefully.

• To avoid fading, do not expose printed

transparencies to prolonged sunlight.

• Ensure that transparencies are not wrinkled,

curled, or have any torn edges.

Labels • To avoid damaging the machine, use only labels

designed for use in laser printers.

• When selecting labels, consider the following

factors:

- Adhesives: The adhesive material should be

stable at 180 °C, the machine’s fusing

temperature.

- Arrangement: Only use labels with no

exposed backing between them. Labels can

peel off sheets that have spaces between the

labels, causing serious jams.

- Curl: Prior to printing, labels must lie flat with

no more than 13 mm of curl in any direction.

- Condition: Do not use labels with wrinkles,

bubbles, or other indications of separation.

• Make sure that there is no exposed adhesive

material between labels. Exposed areas can

cause labels to peel off during printing, which

can cause paper jams. Exposed adhesive can

also cause damage to machine components.

• Do not run a sheet of labels through the machine

more than once. The adhesive backing is

designed for only a single pass through the

machine.

• Do not use labels that are separating from the

backing sheet or are wrinkled, bubbled, or

otherwise damaged.

Card stock or

custom-sized

materials

• Do not print on media smaller than 98 mm wide

or 148 mm long.

• In the software application, set margins at least

6,4 mm away from the edges of the material.

Media type Guidelines

Loading paper

In the tray

Load the print media you use for the majority of your print jobs in the tray.

The tray can hold a maximum of 250 sheets of 75 g/m2 plain paper.

1Open the tray. Squeeze the paper length guide and pull it out to

extend the tray.

2If you are using paper, flex or fan the edge of the paper stack to

separate the pages before loading.

Preprinted

paper

• Letterhead must be printed with heat-resistant

ink that will not melt, vaporize, or release

hazardous emissions when subjected to the

machine’s fusing temperature of 180 °C for

0,1 second.

• Letterhead ink must be non-flammable and

should not adversely affect printer rollers.

• Forms and letterhead should be sealed in a

moisture-proof wrapping to prevent changes

during storage.

• Before you load preprinted paper, such as forms

and letterhead, verify that the ink on the paper is

dry. During the fusing process, wet ink can come

off preprinted paper, reducing print quality.

Media type Guidelines

1tray

2paper length guide

5.6 <

Loading originals and print media>

3Load the paper with the side to be printed on facing up.

4Squeeze the paper width guide and adjust it to the width of the

paper.

5Squeeze the paper length guide and adjust it to the length of the

paper.

6After loading paper, set the paper type and size for the tray. See

page 5.7 for copying and faxing or the Software Section for PC-

printing.

Notes

• Do not push the paper width guide far enough to cause

the materials to warp.

• If you do not adjust the paper width guide, it may cause

paper jams.

In the manual tray

The manual tray can hold special size and type of print material, such as

transparency, postcard, note card, and envelope. The manual tray can

hold 1 sheet of paper.

To load paper in the manual tray:

1Load the paper with the side to be printed on facing up.

2Adjust the manual tray paper width guides to the width of the paper.

Do not force too much, or the paper will be bent, which will result in

a paper jam or skew.

Notes

• If you experience problems with paper feed, place one sheet at

a time in the manual tray.

• You can load previously printed paper. The printed side should

be facing down with an uncurled edge at the front. If you

experience problems with paper feed, turn the paper around.

Note that print quality is not guaranteed.

Notes

Depending on the media type you are using, keep the following

loading guidelines:

• Envelopes: Flap side down and with the stamp area on the top

left side.

• Transparencies: Print side up and the top with the adhesive

strip entering the machine first.

• Labels: Print side up and top short edge entering the machine

first.

• Preprinted paper: Design side up with the top edge toward the

machine.

• Card stock: Print side up and the short edge entering the

machine first.

• Previously printed paper: Previously printed side down with an

uncurled edge toward the machine.

5.7 <

Loading originals and print media>

3After loading paper, set the paper type and size for the manual tray.

See the next section for copying and faxing or the Software

Section for PC-printing.

Note

The settings made from the printer driver override the

settings on the control panel.

Tips on using the manual tray

• Load only one sheet of print media at a time in the manual tray.

• To prevent paper jams, do not add paper when there is still paper in

the manual tray. This also applies to other types of print media.

• Print media should be loaded face up with the top edge going into the

manual tray first and be placed in the center of the tray.

• Always load only the print media specified in page 5.2 to avoid paper

jams and print quality problems.

• Flatten any curl on postcard, envelope, and label before loading it into

the manual tray.

Setting the paper size and type

After loading paper in the paper tray, you need to set the paper size and

type using the control panel buttons. These settings will apply to Copy

and Fax modes. For PC-printing, you need to select the paper size and

type in the application program you use on your PC.

1Press Menu.Paper Setting appears on the top line of the display.

2Press the Scroll buttons until Paper Size appears and press Enter.

3Press the Scroll buttons until the paper tray you want appears and

press Enter.

4Press the Scroll buttons until the paper size you are using appears

and press Enter.

5Press upper level to return to the upper level.

6Press the Scroll buttons until Paper Type appears and press Enter.

7Press the Scroll buttons until the paper type you are using appears

and press Enter.

8Press Stop/Clear to return to Standby mode.

Verifying an output location

The machine has a paper output location which holds 50 sheets of paper.

The output tray collects printed paper face down, in the order in which

the sheets were printed.

Note

Pull the output support not to drop the printed paper.

1output tray

6.1 <

Copying>

6 Copying

This chapter gives you step-by-step instructions for copying documents.

This chapter includes:

• Selecting the paper tray

• Copying

• Changing the settings for each copy

• Changing the default copy settings

• Using special copy features

• Setting copy timeout

Selecting the paper tray

After loading the print media for copy output, you must select the paper

tray you will use for copy jobs.

1Press Menu.Paper Setting appears on the top line of the display.

2Press Enter when Copy Tray appears.

3Press the Scroll buttons until the paper tray you want appears and

press Enter.

4Press Stop/Clear to return to Standby mode.

Copying

1Load originals face up into the ADF, or place a single original face

down on the scanner glass.

For details about loading an original, see page 5.1.

2If you want to customize the copy settings including darkness,

original type, the number of copies, and copy size, by using the

control panel buttons, see the next section.

If necessary, you can use special copy features, such as poster

copying, 2- or 4-up copying. See page 6.2.

3Press Start to begin copying.

Note

You can cancel the copy job during an operation. Press Stop/

Clear, and the copying will stop.

Changing the settings for each copy

Your machine provides default settings for copying so that you can

quickly and easily make a copy. However, if you want to change the

options for each copy, use the copy function buttons on the control panel.

Note

If you press Stop/Clear while setting the copy options, all of the

options you have set for the current copy job will be canceled

and returned to their default status. Or, they will automatically

return to their default status after the machine completes the

copy in progress.

Darkness

If you have an original containing faint markings and dark images, you

can adjust the brightness to make a copy that is easier to read.

To adjust the darkness of copies, press Darkness. Each time you press

the button, the following modes are available:

•Light: Works well with dark print.

•Normal: Works well with standard typed or printed originals.

•Dark: Works well with light print or faint pencil markings.

Original Type

The original type setting is used to improve the copy quality by selecting

the document type for the current copy job.

To select the document type, press Original Type. Each time you press

the button, the following modes are available:

•Text: Use for originals containing mostly text.

•Text/Photo: Use for originals with mixed text and photographs.

•Photo: Use when the originals are photographs.

Number of copies

You can select the number of copies from 1 to 99.

To change the number of copies:

1Press No. of Copies.

2Enter the value using the number keypad.

3Press Enter to save the selection.

6.2 <

Copying>

Reduced or enlarged copy

By using the Reduce/Enlarge button, you can reduce or enlarge the size

of a copied image from 25% to 400% when you copy original documents

from the scanner glass, or from 25% to 100% from the ADF.

To select from the predefined copy sizes:

1Press Reduce/Enlarge.

2Press Reduce/Enlarge or the Scroll buttons until the size setting

you want appears and press Enter.

To scale the copy by directly entering the scale rate:

1Press Reduce/Enlarge.

2Press Reduce/Enlarge or the Scroll buttons until Custom appears

and press Enter.

3Enter the scale rate and press Enter to save the selection.

Note

When you make a reduced copy, black lines may appear at the

bottom of your copy.

Changing the default copy settings

The copy options, including darkness, original type, copy size, and

number of copies, can be set to those most frequently used. When you

copy a document, the default settings are used unless they have been

changed by using the corresponding buttons on the control panel.

1Press Menu until Copy Setup appears on the top line of the display.

2Press Enter when Default Change appears.

3Press the Scroll buttons until the setup option you want appears

and press Enter.

4Press the Scroll buttons until the setting you want appears and

press Enter.

5Repeat steps 3 through 4, as needed.

6Press Stop/Clear to return to Standby mode.

Note

While you are setting copy options, pressing Stop/Clear

cancels the changed settings and restores the defaults.

Using special copy features

You can use the following copy features:

Clone copying

Collation

Your machine can print multiple image copies from the

original document on a single page. The number of

images is automatically determined by the original

image and paper size.

This copy feature is available only when you place

originals on the scanner glass.

1Place a single original face down on the scanner

glass.

For details about loading an original, see

page 5.1.

2Press Favorite Copy until Clone appears on the

bottom line of the display and press Enter.

3Press Start to begin copying.

Note

You cannot adjust the copy size using the

Reduce/Enlarge button while making a

clone copy.

You can set the machine to sort the copy job. For

example, if you make 2 copies of a 3 page original,

one complete 3 page document will print followed by a

second complete document.

This copy feature is available only when you load

originals into the ADF.

1Load originals face up into the ADF.

For details about loading an original, see

page 5.1.

2Enter the number of copies using the number

keypad.

3Press Favorite Copy until Copy Collate appears

on the bottom line of the display and press Enter.

4Press Start to begin copying.

One complete document will print followed by the

second complete document.

6.3 <

Copying>

Auto fit

ID card copying

Your machine can automatically reduce or enlarge the

original image to fit on the paper currently loaded in

the machine.

This copy feature is available only when you place

originals on the scanner glass.

1Place a single original face down on the scanner

glass.

For details about loading an original, see

page 5.1.

2Press Favorite Copy until Autofit appears on

the bottom line of the display and press Enter.

3Press Start to begin copying.

Note

You cannot adjust the copy size using the

Reduce/Enlarge button while making a Auto

fit copy.

Your machine can print 2-sided originals on one sheet

of A4-, Letter-, Legal-, Folio-, Executive-, B5-, A5-, or

A6-sized paper.

When you copy using this feature, the machine prints

one side of the original on the upper half of the paper

and the other side on the lower half without reducing

the size of the original. This feature is helpful for

copying a small-sized item, such as a name card.

This copy feature is available only when you place

originals on the scanner glass.

1Place a single original face down on the scanner

glass.

For details about loading an original, see

page 5.1.

2Press Favorite Copy until ID Card Copy

appears on the bottom line of the display and

press Enter.

2-up or 4-up copying

3Press Start to begin copying.

Your machine begins scanning the front side and

shows Set BackSide.

4Open the scanner lid and turn the original over.

Note

If you press Stop/Clear or if no buttons

are pressed for approximately

30 seconds, the machine cancels the

copy job and returns to Standby mode.

5Press Start to begin copying.

Note

If the original is larger than the printable area,

some portions may not be printed.

Your machine can print 2 or 4 original images reduced

to fit onto one sheet of paper.

This copy feature is available only when you load

originals into the ADF.

1Load originals face up in the ADF.

For details about loading an original, see

page 5.1.

2Press Favorite Copy until 2 UP or 4 UP appears

on the bottom line of the display and press Enter.

3Press Start to begin copying.

Note

You cannot adjust the copy size using the

Reduce/Enlarge button while making a 2- or

4-up copy.

1 2

3 4

1 2

2-up copying

4-up copying

6.4 <

Copying>

Poster copying

Setting copy timeout

You can set the time the machine waits before it restores the default copy

settings, if you do not start copying after changing them on the control

panel.

1Press Menu until Copy Setup appears on the top line of the display.

2Press the Scroll buttons until Timeout appears and press Enter.

3Press the Scroll buttons until the time setting you want appears.

Selecting Off means that the machine does not restore the default

settings until you press Start to begin copying, or Stop/Clear to

cancel.

4Press Enter to save your selection.

5Press Stop/Clear to return to Standby mode.

Your machine can print an image onto 9 sheets of

paper (3x3). You can paste the printed pages together

to make one poster-sized document.

This copy feature is available only when you place

originals on the scanner glass.

1Place a single original face down on the scanner

glass.

For details about loading an original, see

page 5.1.

2Press Favorite Copy until Poster appears on

the bottom line of the display and press Enter.

3Press Start to begin copying.

Note

You cannot adjust the copy size using the

Reduce/Enlarge button while making a

poster copy.

Your original is divided into

9 portions. Each portion is scanned

and printed one by one in the

following order:

7.1 <

Basic printing>

7 Basic printing

This chapter explains common printing tasks.

Printing a document

Your machine allows you to print from various Windows, Macintosh1, or

Linux applications. The exact steps for printing a document may vary

depending on the application you use.

For details about printing, see the Software Section.

Canceling a print job

If the print job is waiting in a print queue or print spooler, such as the

printer group in Windows, delete the job as follows:

1Click the Windows Start menu.

2For Windows 98/2000/Me, select Settings and then Printers.

For Windows XP(32/64bit)/2003(32/64bit), select Printers and

Faxes.

3Double-click the Samsung SCX-4725 Series icon.

4From the Document menu, select Cancel Printing (Windows 98/

Me) or Cancel (Windows 2000/XP(32/64bit)/2003(32/64bit).

Note

You can also access this window by simply double-clicking the

printer icon at the bottom right corner of the Windows desktop.

You can also cancel the current job by pressing Stop/Clear on the control

panel.

1.SCX-4725FN only

8.1 <

Scanning>

8 Scanning

Scanning with your machine lets you turn pictures and text into digital files

that can be stored on your computer. Then you can fax or email the files,

upload them to your website, or use them to create projects that you can

print.

Scanning basics

Your machine offers the following ways to scan an image:

• Via one of the preset imaging applications. Scanning an image

launches the selected application, enabling you to control the

scanning process. See the next section.

• Via the SmarThru™ program supplied with your machine. Scanning

an image launches SmarThru™ and enables you to control the

scanning process.

• Via the Windows Images Acquisition (WIA) driver. See the Software

Section.

Scanning to an application

1Make sure that your machine and computer are turned on and

properly connected to each other.

2Load originals face up into the ADF, or place a single original face

down on the scanner glass.

For details about loading an original, see page 5.1.

3Press Scan To.Application appears on the top line of the display.

4Press the Scroll buttons until the application you want to use

appears and press Enter.

•Microsoft Paint: Sends the scanned image to Microsoft Paint.

•Email: Sends the scanned image to your default email program on

your computer. A new message window opens with the image

attached.

•My Documents: Saves the scanned image in the default folder,

My Documents, on your computer.

•SmarThru: Sends the scanned image to SmarThru™, installed

with the printer driver.

Note

You can add more TWAIN-compliant software for scanning,

such as Adobe Photoshop Deluxe, or Adobe Photoshop,

from the Printer Settings Utility. See the Software

Section.

5On the selected application, adjust the scan settings and begin

scanning. For details, please refer to the application user's guide.

9.1 <

Faxing>

9 Faxing

This chapter gives you information about using your machine as a fax

machine.

This chapter includes:

Sending a fax

• Setting the fax header

• Adjusting the document settings

• Sending a fax automatically

• Sending a fax manually

• Confirming a transmission

• Automatic redialing

• Redialing the last number

Receiving a fax

• Selecting the paper tray

• Changing receiving modes

• Receiving automatically in Fax mode

• Receiving manually in Tel mode

• Receiving manually using an extension telephone

• Receiving automatically in Ans/Fax mode

• Receiving faxes using DRPD mode

• Receiving in secure receiving mode

• Receiving faxes in memory

Other ways to fax

• Sending a fax to multiple destinations

• Sending a delayed fax

• Sending a priority fax

Sending a fax

Setting the fax header

In some countries, you are required by law to indicate your fax number

on any fax you send. The Machine ID, containing your telephone number

and name or company name, will be printed at the top of each page sent

from your machine.

1Press Menu until Machine Setup appears on the top line of the

display.

2Press Enter when Machine ID appears.

3Enter your fax number using the number keypad and press Enter.

4Enter your name or the company name using the number keypad.

You can enter alphanumeric characters using the number keypad,

and include special symbols by pressing the 0 button.

For details on how to enter alphanumeric characters, see page 2.3.

5Press Enter to save the ID.

Adjusting the document settings

Before starting a fax, change the following settings according to your

original’s status to get the best quality.

Resolution

The default document settings produce good results when using typical

text-based originals. However, if you send originals that are of poor

quality, or contain photographs, you can adjust the resolution to produce

a higher quality Fax.

1Press Resolution.

2Press Resolution or the Scroll buttons until the option you want

appears.

3Press Enter to save your selection.

9.2 <

Faxing>

Recommended resolution settings for different original document types

are described in the table below:

Note

The resolution setting is applied to the current fax job.

Darkness

You can select the default contrast mode to fax your originals lighter or

darker.

1Press Menu until Fax Setup appears on the top line of the display.

2Press the Scroll buttons until Darkness appears and press Enter.

3Press the Scroll buttons until the option you want appears and

press Enter.

4Press Stop/Clear to return to Standby mode.

Note

The darkness setting is applied to the current fax job.

Mode Recommended for:

Standard Originals with normal sized characters.

Fine Originals containing small characters or thin lines or

originals printed using a dot-matrix printer.

Super Fine Originals containing extremely fine detail. Super

Fine mode is enabled only if the machine with

which you are communicating also supports the

Super Fine resolution.

Photo Fax Originals containing shades of gray or photographs.

Color Fax Originals with colors. Sending a color fax is enabled

only if the machine with which you are

communicating supports color fax reception and

you send the fax manually. In this mode, memory

transmission is not available.

Sending a fax automatically

1Load originals face up into the ADF, or place a single original face

down on the scanner glass.

For details about loading an original, see page 5.1.

2Adjust the resolution and the darkness to suit your fax needs. See

page 9.1.

3Enter the receiving fax machine’s number.

You can use speed dial numbers, or group dial numbers. For details

about storing and searching for a number, see page 10.3.

4Press Start.

5If an original is placed on the scanner glass, load another original

and press 1 to add another page.

6When you have finished, press 2 at the Another Page ? prompt.

After the number is dialed, the machine begins sending the fax

when the receiving fax machine answers.

Note

When you want to cancel a fax job, press Stop/Clear at any

time while sending.

Sending a fax manually

1Load originals face up into the ADF, or place a single original face

down on the scanner glass.

For details about loading an original, see page 5.1.

2Adjust the resolution and the darkness to suit your fax needs. See

page 9.1.

3Press On Hook Dial. You hear a dial tone.

4Enter the receiving fax machine’s number.

You can use speed dial numbers, or group dial numbers. For details

about storing and searching for a number, see page 10.3.

5Press Start when you hear a high-pitched fax signal from the

remote fax machine.

Note

When you want to cancel a fax job, press Stop/Clear at any

time while sending.

Notes

• For memory transmission, Super Fine

mode is not available. The resolution

setting is automatically changed to Fine.

• When your machine is set to Super Fine

resolution and the fax machine with

which you are communicating does not

support Super Fine resolution, the

machine transmits using the highest

resolution mode supported by the other

fax machine.

9.3 <

Faxing>

Confirming a transmission

When the last page of your original has been sent successfully, the

machine beeps and returns to Standby mode.

When something goes wrong while sending your fax, an error message

appears on the display. For a list of error messages and their meanings,

see page 13.3. If you receive an error message, press Stop/Clear to

clear the message and try to send the fax again.

You can set your machine to print a confirmation report automatically

each time sending a fax is completed. For further details, see page 10.1.

Automatic redialing

When the number you have dialed is busy or there is no answer when you

send a fax, the machine automatically redials the number every three

minutes, up to seven times according to the factory default settings.

When the display shows Retry Redial?, press Enter to redial the number

without waiting. To cancel the automatic redialing, press Stop/Clear.

To change the time interval between redials and the number of redial

attempts. See page 10.1.

Redialing the last number

To redial the number you called last:

1Press Redial/Pause.

2When an original is loaded in the ADF, the machine automatically

begins to send.

3If an original is placed on the scanner glass, load another original

and press 1 to add another page.

When you have finished, press 2 at the Another Page ? prompt.

Receiving a fax

Selecting the paper tray

After loading the print media for fax output, you have to select the paper

tray you will use for the fax reception.

1Press Menu.Paper Setting appears on the top line of the display.

2Press the Scroll buttons until Fax Tray appears and press Enter.

3Press the Scroll buttons until the paper tray you want appears and

press Enter.

4Press Stop/Clear to return to Standby mode.

Changing receiving modes

1Press Menu until Fax Setup appears on the top line of the display.

2Press Enter when Receive Mode appears.

3Press the Scroll buttons until the fax reception mode you want

appears.

•In Fax mode, the machine answers an incoming fax call and

immediately goes into the fax reception mode.

•In Tel mode, you can receive a fax by pressing On Hook Dial and

then Start. You can also pick up the handset of the extension

phone and then press the remote receive code. See page 9.4.

•In Ans/Fax mode, an answering machine attached to your

machine answers an incoming call, and the caller can leave a

message on the answering machine. If the fax machine senses a

fax tone on the line, the machine automatically switches to Fax

mode to receive the fax. See page 9.4.

•In DRPD mode, you can receive a call using the Distinctive Ring

Pattern Detection (DRPD) feature. Distinctive Ring is a telephone

company service which enables an user to use a single telephone

line to answer several different telephone numbers. For further

details, see page 9.4.

4Press Enter to save your selection.

5Press Stop/Clear to return to Standby mode.

Notes

• When the memory is full, the printer can no longer receive any

incoming fax. Secure free memory to resume by removing data

stored in the memory.

• To use the Ans/Fax mode, attach an answering machine to the

EXT socket on the back of your machine.

• If you do not want other people to view your received

documents, you can use secure receiving mode. In this mode,

all of the received faxes are stored in memory. For further

details, see page 9.5.

9.4 <

Faxing>

Receiving automatically in Fax mode

Your machine is preset to Fax mode at the factory. When you receive a

fax, the machine answers the call on a specified number of rings and

automatically receives the fax.

To change the number of rings, see page 10.1.

Receiving manually in Tel mode

You can receive a fax call by pressing On Hook Dial and then pressing

Start when you hear a fax tone from the remote machine.

The machine begins receiving a fax and returns to Standby mode when

the reception is completed.

Receiving manually using an extension

telephone

This features works best when you are using an extension telephone

connected to the EXT socket on the back of your machine. You can

receive a fax from someone you are talking to on the extension telephone

without going to the fax machine.

When you receive a call on the extension phone and hear fax tones,

press the keys 9 on the extension phone. The machine receives the

fax.

Press the buttons slowly in sequence. If you still hear the fax tone from

the remote machine, try pressing 9 once again.

9 is the remote receive code preset at the factory. The first and the

last asterisks are fixed, but you can change the middle number to

whatever you wish. For details about changing the code, see page 10.1.

Receiving automatically in Ans/Fax mode

To use this mode, you must attach an answering machine to the EXT

socket on the back of your machine.

If the caller leaves a message, the answering machine stores the

message as it would normally. If your machine detects a fax tone on the

line, it automatically starts to receive the fax.

Notes

• If you have set your machine to Ans/Fax mode and your

answering machine is switched off, or no answering machine is

connected to EXT socket, your machine automatically goes

into Fax mode after a predefined number of rings.

• If your answering machine has a user-selectable ring counter,

set the machine to answer incoming calls within 1 ring.

• If you are in Tel mode (manual reception) when the answering

machine is connected to your machine, you must switch off the

answering machine, or the outgoing message from the

answering machine will interrupt your phone conversation.

Receiving faxes using DRPD mode

Distinctive Ring is a telephone company service which enables an user

to use a single telephone line to answer several different telephone

numbers. The particular number someone uses to call you is identified by

different ringing patterns, which consist of various combinations of long

and short ringing sounds. This feature is often used by answering

services who answer telephones for many different clients and need to

know which number someone is calling in on to properly answer the

phone.

Using the Distinctive Ring Pattern Detection (DRPD) feature, your fax

machine can learn the ring pattern you designate to be answered by the

fax machine. Unless you change it, this ringing pattern will continue to be

recognized and answered as a fax call, and all other ringing patterns will

be forwarded to the extension telephone or answering machine plugged

into the EXT socket. You can easily suspend or change DRPD at any

time.

Before using the DRPD option, Distinctive Ring service must be installed

on your telephone line by the telephone company. To set up DRPD, you

will need another telephone line at your location, or someone available to

dial your fax number from outside.

To set up the DRPD mode:

1Press Menu until Fax Setup appears on the top line of the display.

2Press the Scroll buttons until DRPD Mode appears and press

Enter

3Press the Scroll buttons until Set appears and press Enter.

Waiting Ring appears on the display.

4Call your fax number from another telephone. It is not necessary to

place the call from a fax machine.

5When your machine begins to ring, do not answer the call. The

machine requires several rings to learn the pattern.

When the machine completes learning, the display shows End

DRPD [Setup].

If the DRPD setup fails, DRPD Ring Error appears. Press Enter

when DRPD Mode appears and start over from step 3.

6Press Stop/Clear to return to Standby mode.

When the DRPD feature is set up, the DRPD option is available for the

receiving mode setting. To receive faxes in DRPD mode, you need to set

the menu to DRPD.

Notes

• DRPD must be set up again if you re-assign your fax number,

or connect the machine to another telephone line.

• After DRPD has been set up, call your fax number again to

verify that the machine answers with a fax tone. Then have a

call placed to a different number assigned to that same line to

be sure the call is forwarded to the extension telephone or

answering machine plugged into the EXT socket.

9.5 <

Faxing>

Receiving in secure receiving mode

You may need to prevent your received faxes from being accessed by

unauthorized people. You can turn on secure receiving mode to restrict

printing of received faxes when the machine is unattended. In secure

receiving mode, all incoming faxes go into memory. When the mode is

deactivated, any stored faxes are printed.

Activating secure receiving mode

1Press Menu until Advanced Fax appears on the top line of the

display.

2Press the Scroll buttons until Secure Receive appears and press

Enter.

3Press the Scroll buttons until On appears and press Enter.

4Enter a four-digit password you want to use and press Enter.

Note

You can activate secure receiving mode without setting a

password, but cannot protect your faxes.

5Re-enter the password to confirm it and press Enter.

6Press Stop/Clear to return to Standby mode.

When a fax is received in secure receiving mode, your machine stores it

in memory and shows Secure Receive to let you know that there is a fax

received.

Printing received faxes

1Press Menu until Advanced Fax appears on the top line of the

display.

2Press the Scroll buttons until Secure Receive appears and press

Enter.

3Press the Scroll buttons until Print appears and press Enter.

4Enter the four-digit password and press Enter.

The machine prints all of the faxes stored in memory.

Deactivating secure receiving mode

1Press Menu until Advanced Fax appears on the top line of the

display.

2Press the Scroll buttons until Secure Receive appears and press

Enter.

3Press the Scroll buttons until Off appears and press Enter.

4Enter the four-digit password and press Enter.

The mode is deactivated and the machine prints all faxes stored in

memory.

5Press Stop/Clear to return to Standby mode.

Receiving faxes in memory

Since your machine is a multi-tasking device, it can receive faxes while

you are making copies or printing. If you receive a fax while you are

copying or printing, your machine stores incoming faxes in its memory.

Then, as soon as you finish copying or printing, the machine

automatically prints the fax.

9.6 <

Faxing>

Other ways to fax

Sending a fax to multiple destinations

You can use the Broadcasting button, which allows you to send a fax to

multiple locations. Originals are automatically stored in memory and sent

to a remote station. After transmission, the originals are automatically

erased from memory.

1Load originals face up into the ADF, or place a single original face

down on the scanner glass.

For details about loading an original, see page 5.1.

2Adjust the document resolution and darkness to suit your fax needs.

See page 9.1.

3Press Broadcasting.

4Enter the number of the first receiving fax machine and press Enter.

You can use speed dial numbers. For details, see page 10.3.

The display asks you to enter another fax number to send the

document.

5To enter more fax numbers, press 1 and enter another number. You

can add up to 209 destinations.

Note

You cannot use group dial numbers for another fax number.

6When you have finished entering fax numbers, press 2 at the

Another No. prompt.

The original is scanned into memory before transmission. The

display shows memory capacity and the number of pages being

stored in memory.

7If an original is placed on the scanner glass, load another original

and press 1to add another pages.

When you have finished, press 2 at the Another Page ? prompt.

The machine begins sending the fax to the numbers you entered in

the order in which you entered them.

Sending a delayed fax

You can set your machine to send a fax at a later time when you will not

be present.

1Load originals face up into the ADF, or place a single original face

down on the scanner glass.

For details about loading an original, see page 5.1.

2Adjust the document resolution and darkness to suit your fax needs.

See page 9.1.

3Press Menu until Fax Feature appears on the top line of the display.

4Press Enter when DelayFax appears.

5Enter the number of the receiving machine using the number

keypad and press Enter.

You can use speed dial numbers, or group dial numbers. For details,

see page 10.3.

The display asks you to enter another fax numbers.

6To enter more fax numbers, press 1 to select Yes.

7When you have finished entering fax numbers, press 2 to select No

at the Another Page ? prompt.

8Enter the job name you want and press Enter.

For details on how to enter alphanumeric characters, see page 2.3.

If you do not want to assign a name, skip this step.

9Enter the time using the number keypad and press Enter.

Note

If you set a time earlier than the current time, the fax will be

sent at that time on the following day.

The original is scanned into memory before transmission. The

display shows memory capacity and the number of pages being

stored in memory.

10 If an original is placed on the scanner glass, load another original

and press 1 to add another page.

When you have finished, press 2 at the Another Page ? prompt.

The machine returns to Standby mode. The display reminds you

that you are in Standby mode and that a delayed fax is set.

Adding pages to a delayed fax

You can add pages to the delayed transmissions previously reserved in

your machine’s memory.

1Load the originals to be added and adjust document settings.

2Press Menu until Fax Feature appears on the top line of the display.

3Press the Scroll buttons until Add Page appears and press Enter.

4Press the Scroll buttons until the fax job you want appears and

press Enter.

5If an original is placed on the scanner glass, load another original

and press 1 to add another page.

When you have finished, press 2 at the Another Page ? prompt.

The machine scans the original into memory and shows the total

number of pages and the number of the added pages.

9.7 <

Faxing>

Canceling a delayed fax

1Press Menu until Fax Feature appears on the top line of the display.

2Press the Scroll buttons until Cancel Job appears and press Enter.

3Press the Scroll buttons until the fax job you want appears and

press Enter.

4Press 1 to select Yes.

The selected fax job is deleted from memory.

Sending a priority fax

Using the Priority Fax feature, a high priority fax can be sent ahead of

reserved operations. The original is scanned into memory and

immediately transmitted when the current operation is finished. In

addition, priority transmission will interrupt a broadcasting operation

between stations (i.e., when the transmission to station A ends, before

transmission to station B begins) or between redial attempts.

1Load originals face up into the ADF, or place a single original face

down on the scanner glass.

For details about loading an original, see page 5.1.

2Adjust the document resolution and darkness to suit your fax needs.

See page 9.1.

3Press Menu until Fax Feature appears on the top line of the display.

4Press the Scroll buttons until Priority Fax appears and press

Enter.

5Enter the number of the receiving machine using the number

keypad and press Enter.

You can use speed dial numbers. For details, see page 10.3.

6Enter the job name you want and press Enter.

The original is scanned into memory before transmission. The

display shows memory capacity and the number of pages being

stored in memory.

7If an original is placed on the scanner glass, load another original

and press 1 to add another page.

When you have finished, press 2 at the Another Page ? prompt.

The machine shows the number being dialed and begins sending

the fax.

10.1 <

Fax setup>

10 Fax setup

This chapter gives you information on setting up your machine for

receiving and sending faxes.

This chapter includes:

• Changing the fax setup options

• Using the advanced fax features

• Printing sent fax report automatically

• Using the toll save mode

• Setting up Phone Book

Changing the fax setup options

Your machine provides you with various user-selectable options for

setting up the fax system. You can change the default settings for your

preferences and needs.

To change the fax setup options:

1Press Menu until Fax Setup appears on the top line of the display.

2Press the Scroll buttons until the menu item you want appears and

press Enter.

3Press the Scroll buttons until the desired status appears or enter

the value for the option you have selected, and press Enter.

4If necessary, repeat steps 2 through 3.

5Press Stop/Clear to return to Standby mode.

Fax setup options

Option Description

Receive

Mode

You can select the default fax receiving mode. For

details on receiving faxes in each mode, see page

9.3.

Ring to

Answer

You can specify the number of times the machine

rings before answering an incoming call.

Darkness You can select the default contrast mode to fax your

documents lighter or darker.

•Light works well with dark print.

•Normal works well with standard typed or printed

documents.

•Dark works well with light print or faint pencil

markings.

Redial Term Your machine can automatically redial a remote fax

machine if it was busy. You can set an interval

between attempts.

Redials You can specify the number of redial attempts. If you

enter 0, the machine will not redial.

MSG

Confirm

You can set your machine to print a report showing

whether a transmission was successful, how many

pages were sent, and more. The available options

are On,Off, and On-Err, which prints only when a

transmission is not successful.

Auto

Report

This produces a report with detailed information

about the previous 50 communications operations,

including time and dates. The available options are

On or Off.

Auto

Reduction

When receiving a fax containing pages as long as or

longer than the paper loaded in the paper tray, the

machine can reduce the size of the original to fit the

size of the paper loaded in the machine. Turn on this

feature if you want to automatically reduce an

incoming page.

With this feature set to Off, the machine cannot

reduce the original to fit onto one page. The original

will be divided and printed in actual size on two or

more pages.

Discard

Size

When receiving a fax containing pages as long as or

longer than the paper in your machine, you can set

the machine to discard a specific length from the end

of the received fax. The machine will print the

received fax on one or more sheets of paper, except

the data that would have been on the specified

discard segment.

When the received fax contains pages larger than the

paper in your machine, and Auto Reduction has

been turned on, the machine will reduce the fax to fit

on the existing paper, and nothing will be discarded.

RCV Start

Code

This code allows you to initiate fax reception from an

extension phone plugged into the EXT socket on the

back of the machine. If you pick up the extension

phone and hear fax tones, enter the code. It is preset

to 9 at the factory.

DRPD

Mode1This mode enables a user to use a single telephone

line to answer several different telephone numbers.

In this menu, you can set the machine to recognize

which ring patterns to answer. For details about this

feature, see page 9.4.

1.Distinctive Ring Pattern Detection

Option Description

10.2 <

Fax setup>

Using the advanced fax features

To use the advanced fax options:

1Press Menu until Advanced Fax appears on the top line of the

display.

2Press the Scroll buttons until the menu item you want appears and

press Enter.

3Press the Scroll buttons until the desired status appears or enter

the value for the option you have selected, and press Enter.

4If necessary, repeat steps 2 through 3.

5Press Stop/Clear to return to Standby mode.

Advanced fax options

Option Description

Toll Save You can set you machine to store your faxes into

the memory and send them at the specified toll-

saving time. For further details about setting this

mode, see the next column.

Junk Fax Setup Using this feature, the system will not accept

faxes sent from remote stations whose numbers

are stored in the memory as junk fax numbers.

This feature is useful for blocking any unwanted

faxes.

When you turn on this feature, you can access

the following options to set junk fax numbers.

•Setup: allows you to set up to 10 fax numbers.

•All Delete: allows you to delete all junk fax

numbers.

Secure Receive You can keep your received faxes from being

accessed by unauthorized people. For further

details about setting this mode, see page 9.5.

Prefix Dial You can set a prefix of up to five digits. This

number dials before any automatic dial number is

started. It is useful for accessing a PABX

exchange.

Stamp RCV

Name

This option allows the machine to automatically

print the page number, and the date and time of

reception at the bottom of each page of a

received fax.

ECM Mode1

1. Error Correction Mode

This mode helps with poor line quality and makes

sure any faxes you send are sent smoothly to any

other ECM-equipped fax machine. Sending a fax

using ECM may take more time.

Printing sent fax report automatically

You can set the machine to print a report with detailed information about

the previous 50 communication operations, including time and dates.

1Press Menu until Fax Setup appears on the top line of the display.

2Press the Scroll buttons until Auto Report appears and press

Enter.

3Press the Scroll buttons until On appears and press Enter.

4Press Stop/Clear to return to Standby mode.

Using the toll save mode

You can set your machine to send the original stored in the memory

during preset time slots, when call charges are lower. This toll save mode

helps you to take advantage of lower long distance rates.

1Press Menu until Advanced Fax appears on the top line of the

display.

2Press Enter when Toll Save appears.

3Press Enter when Start Time appears.

4Enter the starting time and press Enter.

5Press the Scroll buttons until End Time appears and press Enter.

6Enter the ending time and press Enter.

7Press Stop/Clear to return to Standby mode.

Subsequent sent faxes will be stored into the memory and be sent

at the preset time.

10.3 <

Fax setup>

Setting up Phone Book

You can set up Phone Book with the fax numbers you use most

frequently. Your machine provides you with the following features for

setting up Phone Book:

• Speed dial numbers

• Group dial numbers

Speed dial numbers

You can store up to 200 frequently-used fax numbers in speed dial

numbers.

Registering a speed dial number

1Press Phone Book until Store/Edit appears on the bottom line of

the display and press Enter.

2Press Enter when Speed Dials appears.

3Enter a speed dial number between 0 and 199 and press Enter.

If an entry is already stored in the number you choose, you can edit

the entry. To start over with another speed dial number, press Upper

Level.

4Enter the fax number you want and press Enter.

5Enter the name you want and press Enter.

For details on how to enter alphanumeric characters, see page 2.3.

6Press Stop/Clear to return to Standby mode.

Editing speed dial numbers

1Press Phone Book until Store/Edit appears on the bottom line of

the display and press Enter.

2Press Enter when Speed Dials appears.

3Enter the speed dial number you want to edit and press Enter.

4Change the fax number and press Enter.

5Change the name and press Enter.

6Press Stop/Clear to return to Standby mode.

Using speed dial numbers

When you are prompted to enter a destination number while sending a

fax, enter the speed dial number at which you stored the number you

want.

• For a one-digit (0-9) speed dial number, press and hold the

corresponding digit button on the number keypad.

• For a two- or three-digit speed dial number, press the first digit

button(s) and then hold down the last digit button.

Group dial numbers

If you frequently send the same document to several destinations, you

can group these destinations and set them under a group dial number.

You can then use a group dial number to send a document to all of the

destinations within the group. You can set up to 199 group dial numbers

using the destination’s existing speed dial numbers.

Registering a group dial number

1Press Phone Book until Store/Edit appears on the bottom line of

the display and press Enter.

2Press the Scroll buttons until Group Dials appears and press

Enter.

3Press Enter when New appears.

4Enter a group dial number between 0 and 199 and press Enter.

5Enter a speed dial number and press Enter.

6Press Enter.

7Repeat steps 5 and 6 to include other speed dial numbers into the

group.

8When you have finished, press Upper Level.

9Enter the group name you want and press Enter.

10 Press Stop/Clear to return to Standby mode.

Editing a group dial number

You can delete a specific entry from a group or add a new number to the

selected group.

1Press Phone Book until Store/Edit appears on the bottom line of

the display and press Enter.

2Press the Scroll buttons until Group Dials appears and press

Enter.

3Press the Scroll buttons until Edit appears and press Enter.

4Enter the group dial number you want to edit and press Enter.

5Enter the speed dial number you want to add or delete and press

Enter.

If you enter a new speed dial number, Add? appears.

If you enter a speed dial number stored in the group, Delete?

appears.

6Press Enter to add or delete the number.

7Repeat from step 5 to add or delete more numbers.

8When you have finished, press Upper Level.

9Edit the group name and press Enter.

10 Press Stop/Clear to return to Standby mode.

10.4 <

Fax setup>

Using group dial numbers

When you are prompted to enter a destination number while sending a

fax, enter the group dial number at which you stored the number you

want.

• For a one-digit (0-9) group dial number, press and hold the

corresponding digit button on the number keypad.

• For a two- or three-digit group dial number, press the first digit

button(s) and then hold down the last digit button.

Searching Phone Book for an entry

You can search for a number in memory.

1Press Phone Book until Search&Dial appears on the bottom line of

the display and press Enter.

2Press the Scroll buttons until the name and number you want

appears and press Enter.

The machine dials to the selected number.

Printing Phone Book

You can check your Phone Book settings by printing a list.

1Press Phone Book until Print appears on the bottom line of the

display.

2Press Enter. A list showing speed dial and group dial entries prints

out.

11.1 <

Ordering supplies and accesso-

11 Ordering supplies and

accessories

This chapter provides information on purchasing toner cartridge available

for your machine.

Toner cartridges

When the toner runs out, you can order the following types of toner

cartridge for your machine:

How to purchase

To order Samsung-authorized supplies or accessories, contact your local

Samsung dealer or the retailer where you purchased your machine, or

visit www.samsungprinter.com and select your country/region for

information on calling for technical support.

Type Yield1

1. ISO 19752 5% coverage

Part number

High yield 3,000 pages SCX-D4725A

12.1 <

Maintenance>

12 Maintenance

This chapter provides information for maintaining your machine and the

toner cartridge.

This chapter includes:

• Printing reports

• Clearing memory

• Cleaning your machine

• Maintaining the toner cartridge

• Clearing the Toner Empty Replace Toner message

• Maintenance parts

• Managing your machine from the website (SCX-4725FN only)

Printing reports

Your machine can provide various reports with useful information you will

need. The following reports are available:

Report/List Description

Phone Book This list shows all of the fax numbers stored in

the machine’s memory.

Sent Report This report shows information on the faxes you

have recently sent.

You can set the machine to automatically print

this report every 50 communications. See

page 10.2.

RCV Report This report shows information on the faxes you

have recently received.

System Data This list shows the status of the user-selectable

options. You may print this list to confirm your

changes after changing any settings.

Scheduled

Jobs

This list shows the documents currently stored

for delayed faxes along with the starting time and

type of each operation.

MSG Confirm This report shows the fax number, the number of

pages, the elapsed time of the job, the

communication mode, and the communication

results for a particular fax job.You can set up your

machine to automatically print a message

confirmation report after each fax job.

Junk Fax List This list shows the fax numbers specified as junk

fax numbers. To add or delete numbers to or

from this list, access the Junk Fax Setup menu.

Printing a report

1Press Menu until Reports appears on the top line of the display.

2Press the Scroll buttons until the report or list you want to print

appears and press Enter.

The selected information prints out.

Other available reports

Your machine prints the following reports automatically.

•Multi-communication Report: prints automatically after sending

faxes for more than one location.

•Power Failure Report: prints out automatically when power is

restored after a power failure if any data loss occurs due to the power

failure.

Clearing memory

You can selectively clear information stored in your machine’s memory.

Caution

Before clearing the memory, make sure that all fax jobs have

been completed, or you will lose those jobs.

1Press Menu until Maintenance appears on the top line of the

display.

2Press the Scroll buttons until Clear Memory appears and press

Enter.

3Press the Scroll buttons until the item you want to clear appears

and press Enter.

Options Description

All Settings Clears all of the data stored in memory and

resets all of your settings to the factory default.

Paper Setting Restores all of the paper settings to the factory

default.

Copy Setup Restores all of the copy options to the factory

default.

Fax Setup Restores all of the fax options to the factory

default.

Fax Feature Cancels all of the scheduled fax jobs in the

machine’s memory.

Advanced Fax Restores all of the advanced fax options to the

factory default.

Sent Report Clears all records of sent faxes.

RCV Report Clears all records of received faxes.

12.2 <

Maintenance>

4Repeat step 3 to clear another item.

5Press Stop/Clear to return to Standby mode.

Cleaning your machine

To maintain print and scan quality, follow the cleaning procedures below

each time the toner cartridge is replaced or if print and scan quality

problems occur.

Caution

Cleaning the cabinet of the machine with cleaning materials

containing large amounts of alcohol, solvent, or other strong

substances can discolor or distort the cabinet.

Cleaning the outside

Clean the cabinet of the machine with a soft lint-free cloth. You can

dampen the cloth slightly with water, but be careful not to let any water

drip onto or into the machine.

Cleaning the inside

During the printing process, paper, toner, and dust particles can

accumulate inside the machine. This buildup can cause print quality

problems, such as toner specks or smearing. Cleaning the inside of the

machine clears or reduces these problems.

1Turn the machine off and unplug the power cord. Wait for the

machine to cool down.

2Open the front cover and pull the toner cartridge out. Set it on a

clean flat surface.

Phone Book Clears all of the fax numbers stored in

memory.

Options Description

3Pull the manual tray out.

4With a dry lint-free cloth, wipe away any dust and spilled toner from

the toner cartridge area and the toner cartridge cavity.

Caution

While cleaning the inside of the machine, be careful not to touch

the transfer roller, located underneath the toner cartridge. Oil

from your fingers can cause print scan quality problems.

Cautions

• To prevent damage to the toner cartridge, do not expose it to

light for more than a few minutes. Cover it with a piece of

paper, if necessary.

• Do not touch the green surface underside of the toner

cartridge. Use the handle on the cartridge to avoid touching

this area.

12.3 <

Maintenance>

5Locate the long strip of glass (LSU) inside the top of the cartridge

compartment, and gently swab the glass to see if dirt turns the white

cotton black.

6Push the manual tray back into the machine.

7Reinsert the toner cartridge and close the front cover.

8Plug in the power cord and turn the machine on.

Cleaning the scan unit

Keeping the scan unit clean helps ensure the best possible copies. We

suggest that you clean the scan unit at the start of each day and during

the day, as needed.

1Slightly dampen a soft lint-free cloth or paper towel with water.

2Open the scanner lid.

3Wipe the surface of the scanner glass and ADF glass until it is clean

and dry.

4Wipe the underside of the scanner lid and white sheet until it is

clean and dry.

5Close the scanner lid.

Maintaining the toner cartridge

Toner cartridge storage

To get the most from the toner cartridge, keep the following guidelines in

mind:

• Do not remove the toner cartridge from its package until ready for use.

• Do not refill the toner cartridge. The machine warranty does not cover

damage caused by using a refilled cartridge.

• Store toner cartridges in the same environment as your machine.

• To prevent damage to the toner cartridge, do not expose it to light for

more than a few minutes.

Expected cartridge life

The life of the toner cartridge depends on the amount of toner that print

jobs require. When printing text at ISO 19752 5% coverage, a new toner

cartridge lasts an average of either 3,000 or 1,500 pages. (The original

toner cartridge supplied with the machine lasts an average of 1,500

pages.) The actual number may also be different depending on the print

density of the pages you print on, and the number of pages may be

affected by operating environment, printing interval, media type, and

media size. If you print a lot of graphics, you may need to change the

cartridge more often.

1white sheet

2ADF glass

3scanner lid

4scanner glass

12.4 <

Maintenance>

Redistributing toner

When the toner cartridge is near the end of its life:

• White streaks or light printing occurs.

•Toner Low appears on the display.

If this happens, you can temporarily reestablish print quality by

redistributing the remaining toner in the cartridge. In some cases, white

streaks or light printing will still occur even after you have redistributed the

toner.

1Open the front cover.

2Pull the toner cartridge out.

3Thoroughly roll the cartridge 5 or 6 times to distribute the toner

evenly inside the cartridge.

Note

If toner gets on your clothing, wipe it off with a dry cloth and

wash clothing in cold water. Hot water sets toner into fabric.

Caution

Do not touch the green underside of the toner cartridge.

Use the handle on the cartridge to avoid touching this area.

4Hold the toner cartridge by the handle and slowly insert the cartridge

into the opening in the machine.

Tabs on the sides of the cartridge and corresponding grooves within

the machine will guide the cartridge into the correct position until it

locks into place completely.

5Close the front cover. Make sure that the cover is securely closed.

Replacing the toner cartridge

When the toner cartridge is completely empty:

•Toner Empty Replace Toner appears on the display.

• The machine stops printing. Incoming faxes are saved in memory.

At this stage, the toner cartridge needs to be replaced. For order

information for toner cartridges, see page 11.1.

12.5 <

Maintenance>

Note

You can set the machine to disregard the Toner Empty

Replace Toner message and to continue printing. See page

12.6.

1Open the front cover.

2Pull the toner cartridge out.

3Remove the new toner cartridge from its bag.

4Remove the packing tape and roll the cartridge 5 or 6 items to

distribute the toner.

Thoroughly roll the cartridge to assure maximum copies per

cartridge. Save the box and the plastic bag for shipping.

Note

If toner gets on your clothing, wipe it off with a dry cloth and

wash clothing in cold water. Hot water sets toner into fabric.

Caution

Do not touch the green underside of the toner cartridge.

Use the handle on the cartridge to avoid touching this area.

5Hold the toner cartridge by the handle and slowly insert the cartridge

into the opening in the machine.

Tabs on the sides of the cartridge and corresponding grooves within

the machine will guide the cartridge into the correct position until it

locks into place completely.

6Close the front cover. Make sure that the cover is securely closed.

Cleaning the drum

If there are streaks or spots on your print, the OPC drum of the toner

cartridge may require cleaning.

1Before starting the cleaning procedure, make sure that paper is

loaded in the machine.

2Press Menu until Maintenance appears on the top line of the

display.

3Press Enter when Clean Drum appears.

4Press Enter when Yes appears.

The machine prints out a cleaning page. Toner particles on the drum

surface are affixed to the paper.

If the problem remains, repeat steps 1 through 4.

Cleaning the drum automatically

You can set your machine to print a cleaning page automatically every

600 pages.

1Press Menu until Maintenance appears on the top line of the

display.

2Press the Scroll buttons until Auto Cleaning appears and press

Enter.

3Press the Scroll buttons until On appears and press Enter.

4Press Stop/Clear to return to Standby mode.

Sending new toner notification

You can set your machine to automatically send a fax to your service

company or dealer to notify them that your machine requires a new toner

cartridge when the toner cartridge needs to be replaced. The fax number

needs to be set by your dealer prior to using this feature, otherwise the

machine cannot send a notification even though you turn this service on.

1Press Menu until Maintenance appears on the top line of the

display.

2Press the Scroll buttons until Notify Toner appears and press

Enter.

3Press the Scroll buttons until On appears and press Enter.

4Press Stop/Clear to return to Standby mode.

Once this feature has been enabled, you need to enter the password

each time you disable or enable it.

12.6 <

Maintenance>

Printing continuously when the Toner Empty

Replace Toner message appears

When the toner cartridge is nearly empty, the machine shows the Toner

Empty Replace Toner message and stops printing. You can set the

machine to disregard this message when it appears and to continue

printing, even though print quality is not optimal.

1Press Menu until Machine Setup appears on the top line of the

display.

2Press the Scroll buttons until Ignore Toner appears and press

Enter.

3Press the Scroll buttons until On appears and press Enter.

If you select Off, the received fax cannot be printed until you install

a new toner cartridge. However, faxes can be received into memory

as long as it allows.

4Press Stop/Clear to return to Standby mode.

Clearing the Toner Empty Replace Toner

message

When the Toner Empty Replace Toner message appears you can

configure not to see this message again not to disturb you.

1Press Menu until Maintenance appears on the top line of the

display.

2Press the Scroll buttons until CLR Empty Msg. appears and press

Enter.

3Press the Scroll buttons until On appears and press Enter.

4Now the Toner Empty Replace Toner message does not appear

but the Replace Toner message will remain for reminding you that

the new cartridge needs to be installed for quality.

Caution

Once you have selected On, this setting will be permanently

written to the memory of the toner cartridge, and this menu will

be disappeared from the Maintenance menu.

Maintenance parts

To avoid print quality and paper feed problems resulting from worn parts

and to maintain your printer in top working condition, the following items

will need to be replaced at the specified number of pages or when the life

span of each item has expired.

Samsung highly recommends that an authorized service provider, dealer

or the retailer where you bought printer performs this maintenance

activity.

Replacing the ADF rubber pad

You will need to replace the ADF rubber pad when there seems to be a

consistent problem with paper pickup or when its specified yield is

reached.

1Open the ADF cover.

2Remove the ADF rubber pad from the ADF, as shown.

3Insert a new ADF rubber pad into place.

4Close the ADF cover.

Items Yield (Average)

ADF rubber pad Approx. 20,000 pages

Transfer roller Approx. 50,000 pages

Fuser unit Approx. 50,000 pages

Pickup roller Approx. 50,000 pages

1ADF rubber pad

12.7 <

Maintenance>

Managing your machine from the website

(SCX-4725FN only)

If you have connected your machine to a network and set up TCP/IP

network parameters correctly, you can manage the machine via

Samsung’s SyncThru™ Web Service, an embedded web server. Use

SyncThru™ Web Service to:

• View the machine’s device information and check its current status.

• Change TCP/IP parameters and set up other network parameters.

• Change the printer properties.

• Set the machine to send email notifications to let you know the

machine’s status.

• Get support for using the machine.

To access SyncThru™ Web Service:

1Start a web browser, such as Internet Explorer, from Windows.

2Enter the machine IP address (http://xxx.xxx.xxx.xxx) in the address

field and press the Enter key or click Go.

Your machine’s embedded website opens.

13.1 <

Troubleshooting>

13 Troubleshooting

This chapter gives helpful information for what to do if you encounter an

error.

This chapter includes:

• Clearing document jams

• Clearing paper jams

• Understanding display messages

• Toner cartridge-related messages

• Solving other problems

Clearing document jams

When an original jams while passing through the ADF, Document Jam

appears on the display.

Input Misfeed

1Remove any remaining pages from the ADF.

2Open the ADF cover.

3Pull the jammed paper gently out of the ADF.

1ADF cover

Note

If you do not see the paper in this area, refer to Exit Misfeed.

See the next section.

4Close the ADF cover. Then load the removed pages, if any, back into

the ADF.

Note

To prevent document jams, use the scanner glass for thick, thin, or

mixed paper-type originals.

Exit Misfeed

1Remove any remaining pages from the ADF.

2Open the ADF cover.

3Pull the jammed paper gently out of the document output tray.

4Close the ADF cover. Then load the removed pages, if any, back into

the ADF.

Clearing paper jams

When a paper jam occurs, Paper Jam appears on the display. Refer to the

table below to locate and clear the paper jam.

Message Location of jam Go to

[Paper Jam 0]

Open/Close Door

In the paper feed area (tray or

manual tray)

the next

section and

page 13.2

[Paper Jam 1]

Open/Close Door

In the fuser area or around the

toner cartridge

page 13.2

[Paper Jam 2]

Check Inside

In the paper exit area page 13.2

13.2 <

Troubleshooting>

Caution

To avoid tearing the paper, pull out the jammed paper gently

and slowly. Follow the instructions in the following sections to

clear the jam.

In the tray

1Open and close the front cover. The jammed paper is automatically

ejected from the machine.

If the paper does not exit, go to the next step.

2Remove the jammed paper by gently pulling it straight out.

If the paper does not move when you pull, or if you do not see the

paper in this area, check the fuser area around the toner cartridge.

See page 13.2.

3Open and close the front cover to resume printing.

In the manual tray

1If the paper is not feeding properly, pull the paper out of the

machine.

2Open and close the front cover to resume printing.

In the fuser area or around the toner cartridge

Note

The fuser area is hot. Take care when removing paper from the

machine.

1Open the front cover and pull the toner cartridge out.

2If necessary, pull the manual tray out.

3Remove the jammed paper by gently pulling it straight out.

4If necessary, push the manual tray back into the machine.

5Replace the toner cartridge and close the front cover. Printing

automatically resumes.

In the paper exit area

1Open and close the front cover. The jammed paper is automatically

ejected from the machine.

If the paper does not exit, go to the next step.

2Gently pull the paper out of the output tray.

If you do not see the jammed paper or if there is any resistance

when you pull, stop and go to the next step.

13.3 <

Troubleshooting>

3Open the rear cover.

4Pull the jammed paper out.

Caution

Inside of the machine is very hot. Take care when removing paper

from the machine.

5Close the rear cover. Printing automatically resumes.

Tips for avoiding paper jams

By selecting the correct media types, most paper jams can be avoided.

When a paper jam occurs, follow the steps outlined on page 13.1.

• Follow the procedures on page 5.5. Ensure that the adjustable guides

are positioned correctly.

• Do not overload the tray.

• Do not remove paper from the tray while your machine is printing.

• Flex, fan, and straighten paper before loading.

• Do not use creased, damp, or highly curled paper.

• Do not mix paper types in a tray.

• Use only recommended print media. See page

5.7

• Ensure that the recommended print side of print media is facing up in the

tray or manual tray.

Understanding display messages

Messages appear on the Smart Panel program window or the control panel

display to indicate the machine’s status or errors. Refer to the tables below

to understand the messages’ meaning and correct the problem if necessary.

Messages and their meanings are listed in alphabetical order.

Note

When you call for service, it is very convenient to tell the service

representative the display message.

Message Meaning Suggested solutions

[COMM. Error] The machine has a

communication

problem.

Ask the sender to try

again.

[Front or Rear]

[Cover Open]

The front cover or

rear cover is not

securely latched.

Close the cover until it

locks into place.

[Hsync Error] There is a serious

problem in your

machine.

Turn the machine off and

back on. If the problem

persists, please call for

service.

[Incompatible] The machine has

received a fax from

which is registered

as a junk fax.

The received fax data will

be deleted.

Reconfirm junk fax setup,

see page 10.2.

[Line Error] Your machine

cannot connect with

the receiving fax

machine or has lost

contact because of a

problem with the

phone line.

Try again. If the problem

persists, wait an hour or

so for the line to clear

and try again.

Or, turn the ECM mode

on. See page 10.2.

13.4 <

Troubleshooting>

[Low Heat Error] There is a problem

in the fuser unit.

Unplug the power cord

and plug it back in. If the

problem persists, please

call for service.

[LSU Error] A problem has

occurred in the LSU

(Laser Scanning

Unit).

Unplug the power cord

and plug it back in. If the

problem persists, please

call for service.

[No Answer] The receiving fax

machine has not

answered after

several redial

attempts.

Try again. Make sure that

the receiving machine is

operational.

[No Paper]

Add Paper

The paper in the tray

has run out.

Load paper in the tray.

See page 5.5.

[Over Heat] There is a problem

in the fuser unit.

Unplug the power cord

and plug it back in. If the

problem persists, please

call for service.

Open Heat Error There is a problem

in the fuser unit.

Unplug the power cord

and plug it back in. If the

problem persists, please

call for service.

[Paper Jam 0]

Open/Close Door

Paper has jammed

in the feeding area

of the tray.

Clear the jam. See page

13.2 and page 13.2.

[Paper Jam 1]

Open/Close Door

Paper has jammed

in the fuser area.

Clear the jam. See page

13.2.

[Paper Jam 2]

Check Inside

Paper has jammed

in the paper exit

area.

Clear the jam. See page

13.2.

[Stop Pressed] Stop/Clear has

been pressed during

a fax transmission.

Try again.

Add Paper &

Press Start

You have selected

Manual Feeder for

Source in the printer

properties.

Load a sheet of paper

into the manual tray and

press Start to start

feeding.

If you have multiple

pages to be printed, this

message appears again.

Load the next sheet and

press Start.

Message Meaning Suggested solutions

Cancel?

1:Yes 2:No

Your machine’s

memory has

become full while

trying to store an

original into memory.

To cancel the fax job,

press 1 to select Yes.

If you want to send those

pages that have been

successfully stored,

press 2 to select No. You

should send the

remaining pages later,

when memory is

available.

Document Jam The loaded original

has jammed in the

ADF.

Clear the jam. See page

13.1.

Enter Again You entered an

unavailable data.

Enter the correct data

again.

Group Not

Available

You have tried to

select a group dial

number where only

a single location

number can be

used.

Use a speed dial number

or dial a number

manually using the

number keypad.

Line Busy The receiving fax

machine did not

answer or the line is

already engaged.

Try again after a few

minutes.

Load Document You have attempted

to set up a copy or

fax operation with no

document loaded

into the ADF.

Load a document into the

ADF and try again.

Memory Dial Full The fax jobs queue

in the memory is full.

Cancel unnecessary fax

jobs in the memory.

Memory Full The memory is full. Delete unnecessary fax

jobs and retransmit after

more memory becomes

available. Alternatively,

split the transmission into

more than one operation.

Not Assigned The speed dial

number you tried to

use has no number

assigned to it.

Enter the number

manually using the

number keypad.

Operation Not

Assigned

You are in the Add

Page/Cancel Job

operation, but there

are no jobs stored.

Check the display to see

if there are any

scheduled jobs.

Message Meaning Suggested solutions

13.5 <

Troubleshooting>

Toner cartridge-related messages

Power Failure Power has turned off

then on and the

machine’s memory

has not been back

up.

The job which you were

trying to do before the

power failure must be

completely re-done.

Retry Redial? The machine is

waiting for a

specified time

interval to redial a

previously busy

station.

You can press Enter to

immediately redial, or

Stop/Clear to cancel the

redial operation.

Scanner locked The scanner module

is locked.

Unlock the scanner and

press Stop/Clear.

Unavailable

Date & Time

The current date and

time you entered is

not correct.

Enter the correct date

and time.

Message Meaning Suggested solutions

Install Toner A toner cartridge is

not installed.

Install a toner cartridge.

Invalid Toner The toner cartridge

you have installed in

not for your

machine.

Install a Samsung-

genuine toner cartridge,

designed for your

machine.

NonGenuine Toner

Replace Toner

The toner cartridge

installed is not a

genuine cartridge.

Install the genuine toner

cartridge.

Replace Toner The toner in the

cartridge has run

out.

This message appears

when you turned off the

Toner Empty Replace

Toner message.

Install a new genuine

toner cartridge.

You can keep printing but

the quality cannot be

guaranteed, and the

product support is no

longer provided.

Message Meaning Suggested solutions

Solving other problems

The following chart lists some conditions that may occur and the

recommended solutions. Follow the suggested solutions until the problem is

corrected. If the problem persists, please call for service.

Paper feeding problems

Toner Empty

Replace Toner

The toner in the

cartridge has run

out.

Install a new genuine

toner cartridge.

You can keep printing but

the quality cannot be

guaranteed, and the

product support is no

longer provided.

You can configure not to

see the Toner Empty

Replace Toner

message.

Toner Exhausted

Replace Toner

The lifespan of the

toner cartridge is

reached.

Install the genuine toner

cartridge.

Toner Low The toner cartridge

is almost empty.

Take out the toner

cartridge and thoroughly

shake it. By doing this,

you can temporarily

reestablish printing

operations.

Condition Suggested solutions

Paper is jammed

during printing.

Clear the paper jam. See page 13.1.

Paper sticks

together.

• Ensure that there is not too much paper in the tray.

The tray can hold up to 250 sheets of paper,

depending on the thickness of your paper.

• Make sure that you are using the correct type of

paper. See page 5.7.

• Remove paper from the tray and flex or fan the

paper.

• Humid conditions may cause some paper to stick

together.

Multiple sheets of

paper do not

feed.

• Different types of paper may be stacked in the tray.

Load paper of only one type, size, and weight.

• If multiple sheets have caused a paper jam, clear

the paper jam. See page 13.1.

Message Meaning Suggested solutions

13.6 <

Troubleshooting>

Paper does not

feed into the

machine.

• Remove any obstructions from inside the machine.

• Paper has not been loaded correctly. Remove

paper from the tray and reload it correctly.

• There is too much paper in the tray. Remove

excess paper from the tray.

• The paper is too thick. Use only paper that meets

the specifications required by the machine. See

page 5.7.

• If an original does not feed into the machine, the

ADF rubber pad may require to be replaced. See

page 12.6.

The paper keeps

jamming.

• There is too much paper in the tray. Remove

excess paper from the tray. If you are printing on

special materials, use the manual tray.

• An incorrect type of paper is being used. Use only

paper that meets the specifications required by the

machine. See page 5.7.

• There may be debris inside the machine. Open the

front cover and remove the debris.

• If an original does not feed into the machine, the

ADF rubber pad may require to be replaced. See

page 12.6.

Transparencies

stick together in

the paper exit.

Use only transparencies specifically designed for

laser printers. Remove each transparency as it exits

from the machine.

Envelopes skew

or fail to feed

correctly.

Ensure that the paper guides are against both sides

of the envelopes.

Condition Suggested solutions Printing problems

Condition Possible cause Suggested solutions

The

machine

does not

print.

The machine is not

receiving power.

Check the power cord

connections. Check the

power switch and the power

source.

The machine is not

selected as the

default printer.

Select Samsung SCX-4725

Series PCL 6 as your default

printer in your Windows.

Check the machine for the following:

• The front cover is not closed. Close the cover.

• Paper is jammed. Clear the paper jam. See

page 13.1.

• No paper is loaded. Load paper. See page 5.5.

• The toner cartridge is not installed. Install the toner

cartridge.

If a system error occurs, contact your service

representative.

The connection cable

between the

computer and the

machine is not

connected properly.

Disconnect the printer cable

and reconnect it.

The connection cable

between the

computer and the

machine is defective.

If possible, attach the cable

to another computer that is

working properly and print a

job. You can also try using a

different printer cable.

The port setting is

incorrect.

Check the Windows printer

setting to make sure that the

print job is sent to the correct

port. If the computer has

more than one port, make

sure that the machine is

attached to the correct one.

The machine may be

configured

incorrectly.

Check the printer properties

to ensure that all of the print

settings are correct.

The printer driver

may be incorrectly

installed.

Repair the printer software.

See the

Software Section

The machine is

malfunctioning.

Check the display message

on the control panel to see if

the machine is indicating any

system errors.

13.7 <

Troubleshooting>

The

machine

selects print

materials

from the

wrong

paper

source.

The paper source

selection in the

printer properties

may be incorrect.

For many software

applications, the paper

source selection is found

under the Paper tab within

the printer properties. Select

the correct paper source.

See the printer driver help

screen.

A print job

is extremely

slow.

The job may be very

complex.

Reduce the complexity of the

page or try adjusting the print

quality settings.

If you are using

Windows 98/Me, the

Spool Setting may be

set incorrectly.

From the Start menu, choose

Settings and then Printers.

Right-click the Samsung

SCX-4725 Series PCL 6

machine icon, choose

Properties, click the Details

tab, and then choose the

Spool Settings button.

Select the desired spool

setting.

Half the

page is

blank.

The page orientation

setting may be

incorrect.

Change the page orientation

in your application. See the

printer driver help screen.

The paper size and

the paper size

settings do not

match.

Ensure that the paper size in

the printer driver settings

matches the paper in the

tray.

Or, ensure that the paper

size in the printer driver

settings matches the paper

selection in the software

application settings you use.

Condition Possible cause Suggested solutions

The

machine

prints, but

the text is

wrong,

garbled, or

incomplete.

The printer cable is

loose or defective.

Disconnect the printer cable

and reconnect. Try a print job

that you have already printed

successfully. If possible,

attach the cable and the

machine to another computer

and try a print job that you

know works. Finally, try a

new printer cable.

The wrong printer

driver was selected.

Check the application’s

printer selection menu to

ensure that your machine is

selected.

The software

application is

malfunctioning.

Try printing a job from

another application.

The operating system

is malfunctioning.

Exit Windows and reboot the

computer. Turn the machine

off and then back on again.

Pages print,

but are

blank.

The toner cartridge is

defective or out of

toner.

Redistribute the toner, if

necessary. See page 12.4.

If necessary, replace the

toner cartridge.

The file may have

blank pages.

Check the file to ensure that

it does not contain blank

pages.

Some parts, such as

the controller or the

board, may be

defective.

Contact a service

representative.

The

illustrations

incorrectly

in Adobe

Illustrator.

The setting in the

software application

is wrong.

Select Download as

Bitmap in the TrueType

Options window of the

graphic properties and print

the document again.

The printer

does not

print PDF

file correctly.

Some parts

of graphics,

text or

illustrations

are missing.

Incompatibility

between the PDF file

and the Acrobat

products.

Printing the PDF file as an

image may solve this problem.

Turn on

Print as Image

from

the Acrobat printing options.

Note:

It will take longer to print

when you print a PDF file as

an image.

Condition Possible cause Suggested solutions

13.8 <

Troubleshooting>

Printing quality problems

If the inside of the machine is dirty or paper has been loaded improperly, you

may notice a reduction in print quality. See the table below to clear the

problem.

Condition Suggested solutions

Light or faded print

If a vertical white streak or faded area appears

on the page:

• The toner supply is low. You may be able to

temporarily extend the toner cartridge life. See

page 12.4. If this does not improve the print

quality, install a new toner cartridge.

• The paper may not meet paper specifications;

for example, the paper is too moist or too

rough. See page 5.7.

• If the entire page is light, the print resolution

setting is too low or the toner save mode is on.

Adjust the print resolution and turn the toner

save mode off. See the help screen of the

printer driver and page 2.3, respectively.

• A combination of faded or smeared defects

may indicate that the toner cartridge needs

cleaning. See page 12.5.

• The surface of the LSU part inside the

machine may be dirty. Clean the LSU. See

page 12.2.

Toner specks

• The paper may not meet specifications; for

example, the paper is too moist or too rough.

See page 5.7.

• The transfer roller may be dirty. Clean the

inside of your machine. See page 12.2.

• The paper path may need cleaning. See page

12.2.

Dropouts

If faded areas, generally rounded, occur

randomly on the page:

• A single sheet of paper may be defective. Try

reprinting the job.

• The moisture content of the paper is uneven

or the paper has moist spots on its surface.

Try a different brand of paper. See page 5.7.

• The paper lot is bad. The manufacturing

processes can cause some areas to reject

toner. Try a different kind or brand of paper.

• If these steps do not correct the problem,

contact a service representative.

AaBbCc

Vertical lines

If black vertical streaks appear on the page:

• The drum inside the toner cartridge has

probably been scratched. Remove the toner

cartridge and install a new one. See

page 12.4.

If white vertical streaks appear on the page:

• The surface of the LSU part inside the

machine may be dirty. Clean the LSU. See

page 12.2.

Gray background

If the amount of background shading becomes

unacceptable:

• Change to a lighter weight paper. See

page 5.7.

• Check the machine’s environment: very dry

(low humidity) or high humidity (higher than

80% RH) conditions can increase the amount

of background shading.

• Remove the old toner cartridge and install a

new one. See page 12.4.

Toner smear

• Clean the inside of the machine. See

page 12.2.

• Check the paper type and quality. See

page 5.7.

• Remove the toner cartridge and install a new

one. See page 12.4.

Vertical repetitive

defects

If marks repeatedly appear on the printed side of

the page at even intervals:

• The toner cartridge may be damaged. If a

repetitive mark occurs on the page, print a

cleaning sheet several times to clean the

cartridge; see page 12.5. After the printout, if

you still have the same problems, remove the

toner cartridge and install a new one. See

page 12.4.

• Parts of the machine may have toner on them.

If the defects occur on the back of the page,

the problem will likely correct itself after a few

more pages.

• The fusing assembly may be damaged.

Contact a service representative.

Condition Suggested solutions

13.9 <

Troubleshooting>

Background scatter

Background scatter results from bits of toner

randomly distributed on the printed page.

• The paper may be too damp. Try printing with

a different batch of papers. Do not open

packages of paper until necessary so that the

paper does not absorb too much moisture.

• If background scatter occurs on an envelope,

change the printing layout to avoid printing

over areas that have overlapping seams on

the reverse side. Printing on seams can cause

problems.

• If background scatter covers the entire surface

area of a printed page, adjust the print

resolution through your software application or

the printer properties.

Misformed

characters

• If characters are improperly formed and

producing hollow images, the paper stock may

be too slick. Try a different paper. See page

5.7.

• If characters are improperly formed and

producing a wavy effect, the scanner unit may

need service. For service, contact a service

representative.

Page skew

• Ensure that the paper is loaded properly.

• Check the paper type and quality. See

page 5.7.

• Ensure that the paper or other material is

loaded correctly and the guides are not too

tight or too loose against the paper stack.

Curl or wave

• Ensure that the paper is loaded properly.

• Check the paper type and quality. Both high

temperature and humidity can cause the

paper to curl. See page 5.7.

• Turn over the stack of paper in the tray. Also

try rotating the paper 180° in the tray.

Condition Suggested solutions

AaBbCc

Wrinkles or creases

• Ensure that the paper is loaded properly.

• Check the paper type and quality. See

page 5.7.

• Turn over the stack of paper in the tray. Also

try rotating the paper 180° in the tray.

Back of printouts

are dirty

Check for leaking toner. Clean the inside of the

machine. See page 12.2.

Black pages

• The toner cartridge may not be installed

properly. Remove the cartridge and reinsert it.

• The toner cartridge may be defective and

need replacing. Remove the toner cartridge

and install a new one. See page 12.4.

• The machine may require to be repaired.

Contact a service representative.

Loose toner

• Clean the inside of the machine. See

page 12.2.

• Check the paper type and quality. See

page 5.7.

• Remove the toner cartridge and install a new

one. See page 12.4.

• If the problem persists, the machine may

require repair. Contact a service

representative.

Character Voids

Character voids are white areas within parts of

characters that should be solid black:

• If you are using transparencies, try another

type of transparency. Because of the

composition of transparencies, some

character voids are normal.

• You may be printing on the wrong surface of

the paper. Remove the paper and turn it

around.

• The paper may not meet paper specifications.

See page 5.7.

Condition Suggested solutions

13.10 <

Troubleshooting>

Horizontal stripes

If horizontally aligned black streaks or smears

appear:

• The toner cartridge may be installed

improperly. Remove the cartridge and reinsert

it.

• The toner cartridge may be defective. Remove

the toner cartridge and install a new one. See

page 12.4.

• If the problem persists, the machine may

require repair. Contact a service

representative.

Curl

If the printed paper is curled or paper does not

feed into the machine:

• Turn over the stack of paper in the tray. Also

try rotating the paper 180° in the tray.

An unknown image

repetitively appears

on a next few

sheets or loose

toner, light print, or

contamination

occurs.

Your printer is probably being used at an altitude

of 2,500 m (8,200 ft) or above.

The high altitude may affect the print quality

such as loose toner or light imaging. You can set

this option through the Printer tab in printer

driver's properties. Refer to the Software

Section for details.

Condition Suggested solutions

AaBbCc

Copying problems

Condition Suggested solutions

Copies are too light

or too dark.

Use Darkness to darken or lighten the

background of the copies.

Smears, lines,

marks, or spots

appears on copies.

• If defects are on the original, press Darkness

to lighten the background of your copies.

• If no defects are on the original, clean the scan

unit. See page 12.3.

Copy image is

skewed.

• Ensure that the original is face down on the

scanner glass or face up in the ADF.

• Check that the copy paper is loaded correctly.

Blank copies print

out.

Ensure that the original is face down on the

scanner glass or face up in the ADF.

Image rubs off the

copy easily.

• Replace the paper in the tray with paper from a

new package.

• In high humidity areas, do not leave paper in

the machine for extended periods of time.

Frequent copy

paper jams occur.

• Fan the stack of paper, then turn it over in the

tray. Replace the paper in the tray with a fresh

supply. Check/adjust the paper guides, if

necessary.

• Ensure that the paper is the proper paper

weight. 75 g/m2 bond paper is recommended.

• Check for copy paper or pieces of copy paper

remaining in the machine after a paper jam has

been cleared.

Toner cartridge

produces fewer

copies than

expected before

running out of

toner.

• Your originals may contain pictures, solids, or

heavy lines. For example, your originals may

be forms, newsletters, books, or other

documents that use more toner.

• The machine may be turned on and off

frequently.

• The scanner lid may be left open while copies

are being made.

13.11 <

Troubleshooting>

Scanning problems

Condition Suggested solutions

The scanner does

not work.

• Make sure that you place the original to be

scanned face down on the scanner glass, or

face up in the ADF.

• There may not be enough available memory

to hold the document you want to scan. Try

the Prescan function to see if that works. Try

lowering the scan resolution rate.

• Check that the USB cable is connected

properly.

• Make sure that the USB cable is not

defective. Switch the cable with a known

good cable. If necessary, replace the cable.

• Check that the scanner is configured

correctly. Check scan setting in the

SmarThru

Configuration

or the application you want to

use to make certain that the scanner job is

being sent to the correct port.

The unit scans very

slowly.

• Check if the machine is printing received

data. If so, scan the document after the

received data has been printed.

• Graphics are scanned more slowly than text.

• Communication speed slows in scan mode

because of the large amount of memory

required to analyze and reproduce the

scanned image. Set your computer to the

ECP printer mode through the BIOS setting.

It will help to increase the speed. For details

about how to set BIOS, refer to your

computer user’s guide.

Message appears on

your computer

screen:

• “Device can't be

set to the H/W

mode you want.”

• “Port is being used

by another

program.”

• “Port is Disabled.”

• “Scanner is busy

receiving or

printing data.

When the current

job is completed,

try again.”

• “Invalid handle.”

• “Scanning has

failed.”

• There may be a copying or printing job in

progress. When that job is complete, try your

job again.

• The selected port is currently being used.

Restart your computer and try again.

• The printer cable may be improperly

connected or the power may be off.

• The scanner driver is not installed or the

operating environment is not set up properly.

• Ensure that the machine is properly

connected and that the power is on, Then

restart your computer.

• The USB cable may be improperly connected

or the power may be off.

Fax problems

Condition Suggested solutions

The machine is not

working, there is no

display and the

buttons are not

working.

• Unplug the power cord and plug it in again.

• Ensure that there is power to the electrical

outlet.

No dial tone

sounds.

• Check that the phone line is connected

properly.

• Check that the phone socket in the wall is

working by plugging in another phone.

The numbers

stored in memory

do not dial

correctly.

Make sure that the numbers are stored in

memory correctly. Print a

Phone Book

list,

referring to page 10.4.

The original does

not feed into the

machine.

• Make sure that the paper is not wrinkled and

you are putting it in correctly. Check that the

original is the right size, not too thick or thin.

• Make sure that the ADF is firmly closed.

• The ADF rubber pad may need to be replaced.

See page 12.6.

Faxes are not

received

automatically.

• The receiving mode should be set to Fax.

• Make sure that there is paper in the tray.

• Check to see if the display shows any error

messages. If it does, clear the problem.

The machine does

not send.

• Make sure that the original is loaded in the ADF

or on the scanner glass.

•Sending should show up on the display.

• Check the fax machine you are sending to, to

see if it can receive your fax.

The incoming fax

has blank spaces

or is of poor-

quality.

• The fax machine sending you the fax may be

faulty.

• A noisy phone line can cause line errors.

• Check your machine by making a copy.

• The toner cartridge may be empty. Replace the

toner cartridge, referring to page 12.4.

Some of the words

on an incoming fax

are stretched.

The fax machine sending you the fax had a

temporary document jam.

There are lines on

the originals you

send.

Check your scan unit for marks and clean it. See

page 12.3.

The machine dials

a number, but a

connection with the

other fax machine

fails.

The other fax machine may be turned off, out of

paper, or cannot answer incoming calls. Speak

with the other machine operator and ask her/him

to sort out the problem.

13.12 <

Troubleshooting>

Common Windows problems

Note

Refer to Microsoft Windows 98/Me/2000/XP(32/64bit)/2003

(32/64bit) User’s Guide that came with your PC for further

information on Windows error messages.

Faxes do not store

in memory.

There may not be enough memory space to store

the fax. If the display shows the Memory Full

message, delete from memory any faxes you no

longer need and then try again to store the fax.

Blank areas

appear at the

bottom of each

page or on other

pages, with a small

strip of text at the

top.

You may have chosen the wrong paper settings

in the user option setting. For details about paper

settings, see page 5.7.

Condition Suggested solutions

“File in Use”

message appears

during installation.

Exit all software applications. Remove all

software from the StartUp Group, then restart

Windows. Reinstall the printer driver.

“Error Writing to

LPTx” message

appears.

• Ensure that the cables are connected correctly,

and that the machine is switched on.

• If bi-directional communication is not turned on

in the driver, it will also cause this message.

“General

Protection Fault”,

“Exception OE”,

“Spool32”, or

“Illegal Operation”

messages appear.

Close all other applications, reboot Windows and

try printing again.

“Fail To Print”, “A

printer timeout

error occurred.”

messages appear.

These messages may appear during printing.

Just keep waiting until the machine finishes

printing. If the message appears in standby mode

or after printing has been completed, check the

connection and/or whether an error has occurred.

Condition Suggested solutions Common PostScript problems (SCX-4725FN only)

The following situations are PS language specific and may occur when

several printer languages are being used.

Note

To receive a printed or screen-displayed message when PostScript

errors occur, open the Print Options window and click the desired

selection next to the PostScript errors section.

Problem Possible cause Suggested solutions

PostScript file

cannot be

printed.

The PostScript

driver may not be

installed correctly.

• Install the PostScript driver,

referring to the

Software

Section

• Print a configuration page

and verify that the PS version

is available for printing.

• If the problem persists,

contact a service

representative.

“Limit Check

Error” message

appears.

The print job was

too complex.

You might need to reduce the

complexity of the page or install

more memory.

A PostScript

error page

prints.

The print job may

not be PostScript.

Make sure that the print job is a

PostScript job. Check to see

whether the software

application expected a setup or

PostScript header file to be

sent to the machine.

When print a

document in

Macintosh with

Acrobat

Reader 6.0 or

higher, colors

incorrectly.

The resolution

setting in the

printer driver may

not be matched

with that in

Acrobat Reader.

Make sure that the resolution

setting in your printer driver

matches that in Acrobat

Reader.

13.13 <

Troubleshooting>

Common Linux problems

Problem Possible cause and solutions

The machine does not

print.

• Check if the printer driver is installed in your

system. Open Unified Driver configurator

and switch to the Printers tab in Printers

configuration window to look at the list of

available printers. Make sure that your

machine is displayed on the list. If not,

please, invoke Add new printer wizard to

set up your device.

• Check if the printer has started. Open

Printers configuration and select your

machine on the printers list. Look at the

description in the Selected printer pane. If

its status contains “(stopped)” string,

please, press the Start button. After that

normal operation of the printer should be

restored. The “stopped” status might be

activated when some problems in printing

occurred. For instance, this could be an

attempt to print a document when a port is

claimed by a scanning application.

• Check if the port is not busy. Since

functional components of MFP (printer and

scanner) share the same I/O interface

(port), the situation of simultaneous access

of different “consumer” applications to the

same port are possible. To avoid possible

conflicts, only one of them at a time is

allowed to gain control over the device. The

other “consumer” will encounter “device

busy” response. You should open ports

configuration and select the port assigned

to your printer. In the Selected port pane

you can see if the port is occupied by some

other application. If this is the case, you

should wait for completion of the current job

or should press Release port button, if you

are sure that the present owner is not

functioning properly.

• Check if your application has special print

option such as “-oraw”. If “-oraw” is

specified in the command line parameter

then remove it to print properly. For Gimp

front-end, select “print” -> “Setup printer”

and edit command line parameter in the

command item.

The machine does not

appear on the

scanners list.

• Check if your machine is attached to your

computer. Make sure that it is connected

properly via the USB port and is turned on.

• Check if the scanner driver for your

machine is installed in your system. Open

Unified Driver configurator, switch to

Scanners configuration, then press

Drivers. Make sure that driver with a name

corresponding to your machine's name is

listed in the window. Check if the port is not

busy. Since functional components of MFP

(printer and scanner) share the same I/O

interface (port), the situation of

simultaneous access of different

“consumer” application to the same port is

possible. To avoid possible conflicts, only

one of them at a time is allowed to gain

control over the device. The other

“consumer” will encounter “device busy”

response. This can usually happen while

starting scan procedure, and appropriate

message box appears.

• To identify the source of the problem, you

should open ports configuration and select

the port assigned to your scanner. port's

symbol /dev/mfp0 corresponds to LP:0

designation displayed in the scanners’

options, /dev/mfp1 relates to LP:1 and so

on. USB ports start at /dev/mfp4, so

scanner on USB:0 relates to /dev/mfp4

respectively and so forth sequentially. In the

Selected port pane you can see if the port

is occupied by some other application. If

this is the case, you should wait for

completion of the current job or you should

press Release port button, if you are sure

that the present port's owner is not

functioning properly.

The printer does not

print PDF file correctly.

Some parts of graphics,

text or illustrations are

missing.

Incompatibility between the PDF file and the

Acrobat products:

Printing the PDF file as an image may solve this

problem. Turn on

Print as Image

from the

Acrobat printing options.

Note:

It will take longer to print when you print a

PDF file as an image.

Problem Possible cause and solutions

13.14 <

Troubleshooting>

The machine does not

scan.

• Check if a document is loaded into the

machine.

• Check if your machine is connected to the

computer. Make sure if it is connected

properly if an I/O error is reported while

scanning.

• Check if the port is not busy. Since

functional components of MFP (printer and

scanner) share the same I/O interface

(port), the situation of simultaneous access

of different “consumer” application to the

same port is possible. To avoid possible

conflicts, only one of them at a time is

allowed to gain control over the device. The

other “consumer” will encounter “device

busy” response. This can usually happen

while starting scan procedure, and

appropriate message box will be displayed.

To identify the source of the problem, you

should open ports configuration and select

the port assigned to your scanner. port’s

symbol /dev/mfp0 corresponds to LP:0

designation displayed in the scanners’

options, /dev/mfp1 relates to LP:1 and so

on. USB ports start at /dev/mfp4, so

scanner on USB:0 relates to /dev/mfp4

respectively and so forth sequentially. In the

Selected port pane you can see if the port

is occupied by some other application. If

this is the case, you should wait for

completion of the current job or should

press the Release port button, if you are

sure that the present port’s owner is not

functioning properly.

I cannot scan via Gimp

Front-end.

• Check if Gimp Front-end has

“Xsane: Device dialog.” on the “Acquire”

menu. If not, you should install Xsane plug-

in for Gimp on the your computer. You can

find Xsane plug-in package for Gimp on

Linux distribution CD or Gimp home page.

For the detail information, refer to the Help

for Linux distribution CD or Gimp Front-end

application.

If you wish to use other kind of scan

application, refer to the Help for application.

Problem Possible cause and solutions

Common Macintosh problems (SCX-4725FN only)

I encounter error

“Cannot open port

device file” when

printing a document.

Please avoid changing the print job

parameters (via LPR GUI, for example) while

a print job is in progress. Known versions of

CUPS server break the print job whenever

print options are changed and then try to

restart the job from the beginning. Since

Unified Linux Driver locks port while printing,

the abrupt termination of the driver keeps the

port locked and therefore unavailable for

subsequent print jobs. If this situation

occurred, please, try to release the port.

Problem Suggested solutions

The printer does not print

PDF file correctly. Some

parts of graphics, text or

illustrations are missing.

Incompatibility between the PDF file and

the Acrobat products:

Printing the PDF file as an image may

solve this problem. Turn on Print as

Image from the Acrobat printing options.

Note: It will take longer to print when

you print a PDF file as an image.

The document has

printed, but the print job

has not disappeared from

the spooler in

Mac OS 10.3.2.

Update your Mac OS to OS 10.3.3. or

higher.

Some letters are not

displayed normally

during the Cover page

printing.

This problem is caused because Mac

OS can not create the font during the

Cover page printing. English alphabet

and numbers are displayed normally at

the Cover page.

Problem Possible cause and solutions

14.1 <

Specifications>

14 Specifications

This chapter includes:

• General specifications

• Printer specifications

• Scanner and copier specifications

• Facsimile specifications

General specifications

Item Description

ADF Up to 30 sheets (75 g/m2)

ADF document size Width: 142 to 216 mm

Length: 148 to 356 mm

Paper input capacity Tray: 250 multi-pages for plain paper

(75 g/m2)

Manual tray: 1 sheet of paper

(60 to 165 g/m2)

Paper output

capacity

Output tray: 50 sheets (face down)

Consumables 1-piece toner cartridge system

Power rating 110 - 127 VAC, 50/60 Hz, 5.5 A

220 - 240 VAC, 50/60 Hz, 3 A

Power consumption Average: Less than 400 W

Power save mode: Less than 13.5 W

Noise level1Standby mode: Less than 35 dBA

Printing: Less than 50 dBA

Copying mode: Less than 55 dBA

Warm up: Less than 49 dBA

Warm-up time Less than 15 seconds (from sleep mode)

Operating

environment

Temperature: 10 °C to 32 °C

Humidity: 20% to 80% RH

Display 16 characters x 2 lines

Toner cartridge life21,500 or 3,000 pages at ISO 19752 5%

coverage

Memory 32 MB

External dimension

(W x D x H)

17.2 X 14.7 X 15.2 inches (438 x 374 x 387 mm)

Printer specifications

Weight (including

consumables)

11.2 Kg

Package weight Paper: 1.3 Kg, Plastic: 0.5 Kg

Duty cycle Monthly print: Up to 10,000 pages

1. Sound Pressure Level, ISO 7779

2. The number of pages may be affected by operating environment, printing

interval, media type, and media size.

Item Description

Printing method Laser Beam Printing

Printing speed1

1. Print speed will be affected by operating system used, computing performance,

application software, connecting method, media type, media size, and job

complexity.

Up to 24 ppm in A4 (24 ppm in Letter)

First print out time 10 seconds (from ready)

Print resolution Up to 1,200 x 1,200 dpi effective output

Printer language PCL 6, PS 3 (SCX-4725FN only),

SPL (for Linux only)

OS Compatibility2

2. Please visit www.samsungprinter.com to download the latest software version.

Windows 98/Me/2000/XP(32/64bit)/

2003(32/64bit)

Various Linux OS (USB only)

Macintosh 10.3 ~ 10.4 (SCX-4725FN only)

Interface High Speed USB 2.0

Ethernet 10/100 Base TX (SCX-4725FN only)

Item Description

14.2 <

Specifications>

Scanner and copier specifications

Item Description

Compatibility TWAIN standard/WIA standard

Scanning method ADF and Flat-bed Color CIS (Contact Image

Sensor) module

Resolution Optical: 600 x 600 dpi (mono and color)

Enhanced: 4,800 x 4,800 dpi

Effective scanning

length

Scanner glass: 297 mm

ADF: 356 mm

Effective scanning

width

Max 208 mm

Color bit depth 24 bit

Mono bit depth 1 bit for Black & White mode

8 bit for Gray mode

Copy speed1

1. Copy Speed is based on Single Document Multiple Copy.

Up to 24 ppm in A4 (24 ppm in Letter)

Copy resolution Scan: up to 600 x 300 (text, text/photo)

up to 600 x 600 (photo using platen)

up to 600 x 300 (photo using ADF)

Print: up to 600 x 600 (text, text/photo, photo)

Zoom rate Scanner glass: 25 to 400%

ADF: 25 to 100%

Multiple copies 1 to 99 pages

Grayscale 256 levels

Facsimile specifications

Item Description

Compatibility ITU-T Group 3

Applicable line Public Switched Telephone Network (PSTN)

or behind PABX

Data coding MH/MR/MMR/JBIG/JPEG/ECM (Error

Correction Mode)

Modem speed 33.6 Kbps

Transmission

speed

Approx. 3 seconds/page1

1. Transmission time applies to memory transmission of text data with ECM

compression using only ITU-T No.1 Chart.

Maximum

document length

Scanner glass: 297 mm

Automatic document glass: 356 mm

Resolution Standard: 203 x 98 dpi

Fine: 203 x 196 dpi

Super Fine: 300 x 300 dpi

Photo: 203 x 196 dpi

Color: 200 x 200 dpi

Memory 4 MB

Halftone 256 levels

Auto dialer Group dialing (up to 209 numbers)

INDEX

Numerics

2/4-up, special copy 6.3

accessories, order information 11.1

ADF 1.2

ADF rubber pad, replace 12.6

ADF, load 5.1

alarm sound 2.3

Ans/Fax mode, receiving mode 9.4

auto fit, special copy 6.3

broadcast faxes 9.6

characters, enter 2.3

cleaning

drum 12.5

inside 12.2

LSU 12.3

outside 12.2

scan unit 12.3

clock mode 2.2

clone, special copy 6.2

collation, special copy 6.2

component location 1.2

control panel 1.3

copying

2/4-up 6.3

auto fit 6.3

clone 6.2

collation 6.2

6.3

default setting, change 6.2

ID card copy 6.3

poster 6.4

time out, set 6.4

date and time, set 2.2

delayed fax 9.6

display language, change 2.2

DRPD (Distinctive Ring Pattern Detection)

mode, receiving mode 9.4

drum, clean

automatically 12.5

manually 12.5

error messages 13.3

fax header, set 9.1

Fax mode, receiving mode 9.4

fax number, set 9.1

faxing

broadcast faxes 9.6

delayed faxes 9.6

fax setup 10.1

original settings 9.1

priority faxes 9.7

receiving faxes 9.3

sending faxes 9.2

Group dial numbers, set 10.3

high altitude 13.10

ID card, special copy 6.3

jam, clear

document 13.1

paper 13.1

key sound 2.3

Linux problems 13.13

loading originals

ADF 5.1

scanner glass 5.1

loading paper

manual tray 5.6

tray 5.5

machine ID, set 9.1

Macintosh problems 13.14

manual tray, load paper 5.6

memory, clear 12.1

network configuration

print 4.2

restore 4.2

network interface, reset 4.2

network setup

EtherTalk 4.2

operating systems 4.1

TCP/IP 4.1

new toner notification, send 12.5

n-up (multiple pages per sheet)

copying 6.3

originals

jam, clear 13.1

loading 5.1

output location 5.7

output tray 5.7

paper guidelines 5.4

paper jam, clear

fuser area or around toner cartridge

13.2

manual tray 13.2

paper exit area 13.2

tray 13.2

paper load

manual tray 5.6

tray 5.5

paper size

setting 5.7

specifications 5.3

paper tray, set

copy 6.1

fax 9.3

paper type

setting 5.7

specifications 5.3

Phone Book

group dial numbers 10.3

speed dial numbers 10.3

poster, special copy 6.4

PostScript problems 13.12

power save mode 2.4

print quality problems, solve 13.8

printing

network configuration page 4.2

reports 12.1

priority fax 9.7

problem, solve

copying 13.10

error messages 13.3

faxing 13.11

Linux 13.13

Macintosh 13.14

paper feeding 13.5

PostScript errors 13.12

printing 13.6

printing quality 13.8

scanning 13.11

Windows 13.12

receiving a fax

in Ans/Fax mode 9.4

in DRPD mode 9.4

in Fax mode 9.4

in Secure Receiving mode 9.5

in Tel mode 9.4

receiving modes, change 9.3

redialing

automatically 9.3

manually 9.3

replacement parts 12.6

replacing

ADF rubber pad 12.6

toner cartridge 12.4

reports, print 12.1

ringer 2.3

scan power save mode 2.4

scanner glass

cleaning 12.3

loading documents 5.1

scanning, to application 8.1

secure receiving mode 9.5

sending a fax

automatically 9.2

manually 9.2

sounds, set 2.2

speaker sound 2.3

speaker volume 2.3

special copy features 6.2

special print media, guidelines 5.4

specifications

facsimile 14.2

general 14.1

paper 5.3

printer 14.1

scanner and copier 14.2

speed dial numbers, set 10.3

supplies, order information 11.1

system requirements

Linux 3.3

Macintosh 3.3

Windows 3.2

Tel mode, receiving mode 9.4

toll save mode, use 10.2

toner cartridge

cleaning 12.5

maintaining 12.3

redistributing 12.4

replacing 12.4

toner save mode, use 2.3

tray, load paper 5.5

volume, adjust

ringer 2.3

speaker 2.3

Windows problems 13.12

Samsung Printer

Software section

SOFTWARE SECTION

CONTENTS

Chapter 1:

INSTALLING PRINTER SOFTWARE IN WINDOWS

Installing Printer Software ........................................................................................................ 4

Installing Software for Local Printing ................................................................................. 4

Installing Software for Network Printing ............................................................................. 7

Reinstalling Printer Software ................................................................................................... 10

Removing Printer Software ..................................................................................................... 11

Chapter 2:

BASIC PRINTING

Printing a Document .............................................................................................................. 12

Printing to a file (PRN) .......................................................................................................... 12

Printer Settings ..................................................................................................................... 13

Layout Tab .................................................................................................................. 13

Paper Tab .................................................................................................................... 14

Graphics Tab ............................................................................................................... 15

Extras Tab ................................................................................................................... 16

About Tab ................................................................................................................... 16

Printer Tab .................................................................................................................. 16

Using a Favorite Setting ................................................................................................ 17

Using Help ................................................................................................................... 17

Chapter 3:

ADVANCED PRINTING

Printing Multiple Pages on One Sheet of Paper (N-Up Printing) ..................................................... 18

Printing Posters ..................................................................................................................... 19

Printing a Reduced or Enlarged Document ................................................................................ 19

Fitting Your Document to a Selected Paper Size ......................................................................... 19

Using Watermarks ................................................................................................................. 20

Using an Existing Watermark ......................................................................................... 20

Creating a Watermark ................................................................................................... 20

Editing a Watermark ..................................................................................................... 20

Deleting a Watermark ................................................................................................... 20

Using Overlays ...................................................................................................................... 21

What is an Overlay? ...................................................................................................... 21

Creating a New Page Overlay ......................................................................................... 21

Using a Page Overlay .................................................................................................... 21

Deleting a Page Overlay ................................................................................................ 21

Chapter 4:

USING WINDOWS POSTSCRIPT DRIVER

(SCX-4725FN OLNY)

Printer Settings ..................................................................................................................... 22

Advanced

.................................................................................................................. 22

Using Help ................................................................................................................... 22

Chapter 5:

SHARING THE PRINTER LOCALLY

Setting Up a Host Computer ................................................................................................... 23

Setting Up a Client Computer .................................................................................................. 23

Chapter 6:

USING SMART PANEL

Understanding Smart Panel .................................................................................................... 24

Opening the Troubleshooting Guide ......................................................................................... 24

Using Printer Settings Utility ................................................................................................... 25

Using Onscreen Help File ............................................................................................... 25

Changing the Smart Panel Program Settings ............................................................................. 25

Chapter 7:

SCANNING

Scanning Using Samsung SmarThru ......................................................................................... 26

Uninstalling Samsung SmarThru ..................................................................................... 26

Using Samsung SmarThru ............................................................................................. 27

Using Onscreen Help File ............................................................................................... 28

Scanning Process with TWAIN-enabled Software ........................................................................ 28

Scanning Using the WIA Driver ................................................................................................ 28

Chapter 8:

USING YOUR PRINTER IN LINUX

Getting Started ..................................................................................................................... 29

Installing the Unified Linux Driver ............................................................................................ 29

Installing the Unified Linux Driver ................................................................................... 29

Uninstalling the Unified Linux Driver ............................................................................... 30

Using the Unified Driver Configurator ....................................................................................... 31

Opening the Unified Driver Configurator .......................................................................... 31

Printers Configuration ................................................................................................... 31

Scanners Configuration ................................................................................................. 32

Ports Configuration ....................................................................................................... 32

Configuring Printer Properties ................................................................................................. 33

Printing a Document .............................................................................................................. 33

Printing from Applications .............................................................................................. 33

Printing Files ................................................................................................................ 34

Scanning a Document ............................................................................................................ 34

Using the Image Manager .............................................................................................. 35

Chapter 9:

USING YOUR PRINTER WITH A MACINTOSH

(SCX-4725FN OLNY)

Installing Software for Macintosh ............................................................................................. 37

Setting Up the Printer ............................................................................................................ 38

For a Network-connected Macintosh ................................................................................ 38

For a USB-connected Macintosh ..................................................................................... 38

Printing ................................................................................................................................ 39

Printing a Document ..................................................................................................... 39

Changing Printer Settings .............................................................................................. 39

Printing Multiple Pages on One Sheet of Paper .................................................................. 40

Scanning .............................................................................................................................. 41

Installing Printer Software in Windows

1Installing Printer

Software in Windows

This chapter includes:

• Installing Printer Software

• Reinstalling Printer Software

• Removing Printer Software

Installing Printer Software

You can install the printer software for local printing or network

printing. To install the printer software on the computer,

perform the appropriate installation procedure depending on

the printer in use.

A printer driver is software that lets your computer

communicate with your printer. The procedure to install drivers

may differ depending on the operating system you are using.

All applications should be closed on your PC before beginning

installation.

Installing Software for Local Printing

A local printer is a printer directly attached to your computer

using the printer cable supplied with your printer, such as a USB

or parallel cable. If your printer is attached to a network, skip

this step and go to “Installing Software for Network Printing” on

page 7.

You can install the printer software using the typical or custom

method.

NOTE

: If the “New Hardware Wizard” window appears during

the installation procedure, click in the upper right corner of

the box to close the window, or click

Cancel

Typical Installation

This is recommended for most users. All components necessary

for printer operations will be installed.

Make sure that the printer is connected to your computer

and powered on.

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run, and an installation

window appears.

If the installation window does not appear, click

Start

and

then

Run

. Type

X:\Setup.exe

, replacing “

” with the

letter which represents your drive and click

Click

• If necessary, select a language from the drop-down list.

•

View User’s Guide

: Allows you to view the User’s

Guide. If your computer doesn’t have Adobe Acrobat,

click on this option and it will automatically install Adobe

Acrobat Reader for you.

Select

Typical installation for a local printer

. Click

Installing Printer Software in Windows

NOTE

: If your printer is not already connected to the

computer, the following window will appear.

• After connecting the printer, click

• If you don’t want to connect the printer at this time, click

, and

on the following screen. Then the installation

will start and a test page will not be printed at the end of the

installation.

• The installation window that appears in this User’s

Guide may differ depending on the printer and

interface in use.

After the installation is finished, a window asking you to

print a test page appears. If you choose to print a test

page, select the checkbox and click

Otherwise, just click

and skip to step 7.

If the test page prints out correctly, click

Yes

If not, click

to reprint it.

To register yourself as a user of Samsung Printers in order

to receive information from Samsung, select the checkbox

and click

Finish

. You are now sent to the Samsung web

site.

Otherwise, just click

Finish

NOTE

: After setup is complete, if your printer driver doesn’t

work properly, reinstall the printer driver. See “Reinstalling

Printer Software” on page 10.

Custom Installation

You can choose individual components to install.

Make sure that the printer is connected to your computer

and powered on.

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run, and an installation

window appears.

If the installation window does not appear, click

Start

and

then

Run

. Type

X:\Setup.exe

, replacing “

” with the

letter which represents your drive and click

Installing Printer Software in Windows

Click

• If necessary, select a language from the drop-down list.

•

View User’s Guide

: Allows you to view the User’s

Guide. If your computer doesn’t have Adobe Acrobat,

click on this option and it will automatically install Adobe

Acrobat Reader for you.

Select

Custom installation

. Click

Select your printer and click

NOTE

: If your printer is not already connected to the

computer, the following window will appear.

• After connecting the printer, click

• If you don’t want to connect the printer at this time, click

, and

on the following screen. Then the installation

will start and a test page will not be printed at the end of the

installation.

• The installation window that appears in this User’s

Guide may differ depending on the printer and

interface in use.

Select the components to be installed and click

NOTE

: You can change the desired installation folder by

clicking [

Browse

Installing Printer Software in Windows

After the installation is finished, a window asking you to

print a test page appears. If you choose to print a test

page, select the checkbox and click

Otherwise, just click

and skip to step 9.

If the test page prints out correctly, click

Yes

If not, click

to reprint it.

To register yourself as a user of Samsung Printers in order

to receive information from Samsung, select the checkbox

and click

Finish

. You are now sent to the Samsung web

site.

Otherwise, just click

Finish

Installing Software for Network

Printing

When you connect your printer to a network, you must first

configure the TCP/IP settings for the printer. After you have

assigned and verified the TCP/IP settings, you are ready to

install the software on each computer on the network.

You can install the printer software using the typical or custom

method.

Typical Installation

This is recommended for most users. All components necessary

for printer operations will be installed.

Make sure that the printer is connected to your network

and powered on. For details about connecting to the

network, see the supplied printer’s User’s Guide.

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run, and an installation

window appears.

If the installation window does not appear, click

Start

and

then

Run

. Type

X:\Setup.exe

, replacing “

” with the

letter which represents your drive and click

Click

• If necessary, select a language from the drop-down list.

•

View User’s Guide

: Allows you to view the User’s

Guide. If your computer doesn’t have Adobe Acrobat,

click on this option and it will automatically install Adobe

Acrobat Reader for you.

Select

Typical installation for a network printer

. Click

Installing Printer Software in Windows

The list of printers available on the network appears.

Select the printer you want to install from the list and then

click

• If you do not see your printer on the list, click

Update

refresh the list, or select

Add TCP/IP Port

to add your

printer to the network. To add the printer to the

network, enter the port name and the IP address for the

printer.

To verify your printer’s IP address or the MAC address,

print a Network Configuration page.

• To find a shared network printer (UNC Path), select

Shared Printer [UNC]

and enter the shared name

manually or find a shared printer by clicking the

Browse

button.

NOTE

: To search the network printer, the firewall disabled.

After the installation is finished, a window appears asking

you to print a test page and to register yourself as a user

of Samsung Printers in order to receive information from

Samsung. If you so desire, select the corresponding

checkbox(es) and click

Finish

Otherwise, just click

Finish

NOTE

: After setup is complete, if your printer driver doesn’t

work properly, reinstall the printer driver. See “Reinstalling

Printer Software” on page 10.

Custom Installation

You can choose individual components to install and set a

specific IP address.

Make sure that the printer is connected to your network

and powered on. For details about connecting to the

network, see the supplied printer’s User’s Guide.

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run, and an installation

window appears.

If the installation window does not appear, click

Start

and

then

Run

. Type

X:\Setup.exe

, replacing “

” with the

letter which represents your drive and click

Click

• If necessary, select a language from the drop-down list.

•

View User’s Guide

: Allows you to view the User’s

Guide. If your computer doesn’t have Adobe Acrobat,

click on this option and it will automatically install Adobe

Acrobat Reader for you.

Installing Printer Software in Windows

Select

Custom installation

. Click

The list of printers available on the network appears.

Select the printer you want to install from the list and then

click

• If you do not see your printer on the list, click

Update

refresh the list, or select

Add TCP/IP Port

to add your

printer to the network. To add the printer to the

network, enter the port name and the IP address for the

printer.

To verify your printer’s IP address or the MAC address,

print a Network Configuration page.

• To find a shared network printer (UNC Path), select

Shared Printer [UNC]

and enter the shared name

manually or find a shared printer by clicking the

Browse

button.

NOTE

: To search the network printer, the firewall disabled.

TIP

: If you want to set a specific IP address on a specific

network printer, click the

Set IP Address

button. The Set IP

Address window appears. Do as follows:

a. Select a printer to be set with a specific IP address from the

list.

b. Configure an IP address, subnet mask, and gateway for the

printer manually and click

Configure

to set the specific IP

address for the network printer.

c. Click

Select the components to be installed. After selecting the

components, the following window appears. You can also

change the printer name, set the printer to be shared on

the network, set the printer as the default printer, and

change the port name of each printer. Click

To install this software on a server, select the

Setting up

this printer on a server

checkbox.

Installing Printer Software in Windows

After the installation is finished, a window appears asking

you to print a test page and to register yourself as a user

of Samsung Printers in order to receive information from

Samsung. If you so desire, select the corresponding

checkbox(es) and click

Finish

Otherwise, just click

Finish

NOTE

: After setup is complete, if your printer driver doesn’t

work properly, reinstall the printer driver. See “Reinstalling

Printer Software” on page 10.

Reinstalling Printer Software

You can reinstall the software if installation fails.

Start Windows.

From the

Start

menu select

Programs

All Programs

your printer driver name

o

Maintenance

Select

Repair

and click

The list of printers available on the network appears.

Select the printer you want to install from the list and then

click

• If you do not see your printer on the list, click

Update

refresh the list, or select

Add TCP/IP Port

to add your

printer to the network. To add the printer to the

network, enter the port name and the IP address for the

printer.

• To find a shared network printer (UNC Path), select

Shared Printer [UNC]

and enter the shared name

manually or find a shared printer by clicking the

Browse

button.

You will see a component list so that you can reinstall any

item individually.

Installing Printer Software in Windows

NOTE

: If your printer is not already connected to the

computer, the following window will appear.

• After connecting the printer, click

• If you don’t want to connect the printer at this time, click

, and

on the following screen. Then the installation

will start and a test page will not be printed at the end of the

installation.

• The reinstallation window that appears in this User’s

Guide may differ depending on the printer and

interface in use.

Select the components you want to reinstall and click

If you installed the printer software for local printing

and

you select

your printer driver name

, the window

asking you to print a test page appears. Do as follows:

a. To print a test page, select the check box and click

b. If the test page prints out correctly, click

Yes

If it doesn’t, click

to reprint it.

When the reinstallation is done, click

Finish

Removing Printer Software

Start Windows.

From the

Start

menu select

Programs

All Programs

your printer driver name

o

Maintenance

Select

Remove

and click

You will see a component list so that you can remove any

item individually.

Select the components you want to remove and then click

When your computer asks you to confirm your selection,

click

Yes

The selected driver and all of its components are removed

from your computer.

After the software is removed, click

Finish

Basic Printing

2Basic Printing

This chapter explains the printing options and common printing

tasks in Windows.

This chapter includes:

• Printing a Document

• Printing to a file (PRN)

• Printer Settings

- Layout Tab

- Paper Tab

- Graphics Tab

- Extras Tab

- About Tab

- Printer Tab

- Using a Favorite Setting

- Using Help

Printing a Document

OTES

• Your printer driver

Properties

window that appears in this

User’s Guide may differ depending on the printer in use.

However the composition of the printer properties window is

similar.

• Check the Operating System(s) that are compatible

with your printer. Please refer to the OS Compatibility

section of Printer Specifications in your Printer User’s

Guide.

• If you need to know the exact name of your printer, you can

check the supplied CD-ROM.

The following procedure describes the general steps required

for printing from various Windows applications. The exact steps

for printing a document may vary depending on the application

program you are using. Refer to the User’s Guide of your

software application for the exact printing procedure.

Open the document you want to print.

Select

from the

File

menu. The Print window is

displayed. It may look slightly different depending on your

application.

The basic print settings are selected within the Print

window. These settings include the number of copies and

print range.

Select

your printer driver

from the

Name

drop-down

list.

To take advantage of the printer features provided by your

printer driver, click

Properties

Preferences

in the

application’s Print window. For details, see “Printer

Settings” on page 13.

If you see

Setup

Printer

, or

Options

in your Print

window, click it instead. Then click

Properties

on the next

screen.

Click

to close the printer properties window.

To start the print job, click

in the Print

window.

Printing to a file (PRN)

You will sometimes need to save the print data as a file for your

purpose.

To create a file:

Check the

Print to file

box at the

window.

Select the folder and assign a name of the file and then

click OK.

Make sure that your

printer is selected.

Basic Printing

Printer Settings

You can use the printer properties window, which allows you to

access all of the printer options you need when using your

printer. When the printer properties are displayed, you can

review and change the settings needed for your print job.

Your printer properties window may differ, depending on your

operating system. This Software User’s Guide shows the

Properties window for Windows XP.

Your printer driver

Properties

window that appears in this

User’s Guide may differ depending on the printer in use.

If you access printer properties through the Printers folder, you

can view additional Windows-based tabs (refer to your

Windows User’s Guide) and the Printer tab (see “Printer Tab” on

page 16).

OTES

• Most Windows applications will override settings you specify

in the printer driver. Change all print settings available in the

software application first, and change any remaining settings

using the printer driver.

• The settings you change remain in effect only while you are

using the current program.

To make your changes

permanent

, make them in the Printers folder.

• The following procedure is for Windows XP. For other

Windows OS, refer to the corresponding Windows User's

Guide or online help.

1. Click the Windows

Start

button.

2. Select

Printers and Faxes

3. Select your printer driver icon.

4. Right-click on the printer driver icon and select

Printing Preferences

5. Change the settings on each tab, click OK.

Layout Tab

The

Layout

tab provides options to adjust how the document

appears on the printed page. The

Layout Options

includes

Multiple Pages per Side

and

Poster Printing

. See “Printing

a Document” on page 12 for more information on accessing

printer properties.

Paper Orientation

allows you to select the direction in which

information is printed on a page.

•

Portrait

prints across the width of the page, letter style.

•

Landscape

prints across the length of the page, spreadsheet

style.

•

Rotate

allows you to rotate the page the selected degrees.

Layout Options

allows you to select advanced printing options.

You can choose

Multiple Pages per Side

and

Poster Printing

•

For details, see

“Printing Multiple Pages on One Sheet of Paper

(N-Up Printing)” on page 18.

•

For details, see

“Printing Posters” on page 19

Landscape

Portrait

Basic Printing

Paper Tab

Use the following options to set the basic paper handling

specifications when you access the printer properties. See

“Printing a Document” on page 12 for more information on

accessing printer properties.

Click the

Paper

tab to access various paper properties.

Copies

allows you to choose the number of copies to be printed.

You can select 1 to 999 copies.

Size

allows you to set the size of paper you loaded in the tray.

If the required size is not listed in the

Size

box, click

Custom

When the

Custom Paper Setting

window appears, set the paper

size and click

. The setting appears in the list so that you can

select it.

Source

Make sure that

Source

is set to the corresponding paper tray.

Use

Manual Feeder

when printing on special materials like

envelopes and transparencies. You have to load one sheet at a

time into the Manual Tray or Multi-Purpose Tray.

If the paper source is set to

Auto Selection

, the printer

automatically picks up print material in the following tray order:

Manual Tray or Multi-Purpose Tray, Tray n.

Type

Set

Type

to correspond to the paper loaded in the tray from

which you want to print. This will let you get the best quality

printout. If not, print quality may not be acheived as you want.

Cotton

: 20 lb to 24 lb (75~90 g/m2) cotton paper such as Gilbert

25 % and Gilbert 100 %.

Plain Paper

: Normal plain paper. Select this type if your printer is

monochrome and printing on the 16 lb (60 g/m2) cotton paper.

Recycled Paper

: 20 lb to 24 lb (75~90 g/m2) recycled paper.

Color Paper

: 20 lb to 24 lb (75~90 g/m2) color-backgrounded

paper.

Scaling Printing

allows you to automatically or manually scale

your print job on a page. You can choose from

None

Reduce/

Enlarge

, and

Fit to Page

•

For details, see

“Printing a Reduced or Enlarged Document” on

page 19.

•

For details, see

“Fitting Your Document to a Selected Paper

Size” on page 19.

Basic Printing

Graphics Tab

Use the following Graphic options to adjust the print quality for

your specific printing needs. See “Printing a Document” on

page 12 for more information on accessing printer properties.

Click the

Graphic

tab to display the properties shown below..

Resolution

The Resolution options you can select may vary

depending on your printer model.

The higher the setting,

the sharper the clarity of printed characters and graphics. The

higher setting also may increase the time it takes to print a

document.

Image Mode

The available options are Normal and Text Enhance.

Some

printers do not support this feature.

•

Printer Setting

: If you select this option, this feature is

determined by the setting you’ve made on the control panel of

the printer.

•

Normal

: This setting is for normal documents.

•

Text Enhance

: Image Mode allows the user to enhance

printouts.

Toner Save Mode

Selecting this option extends the life of your toner cartridge and

reduces your cost per page without a significant reduction in print

quality.

Some printers do not support this feature.

•

Printer Setting

: If you select this option, this feature is

determined by the setting you’ve made on the control panel of

the printer.

•

: Select this option to allow the printer to use less toner on

each page.

•

Off

: If you don’t need to save toner when printing a document,

select this option.

Advanced Options

You can set advanced settings by clicking the

Advanced

Options

button.

•

TrueType Options

: This option determines what the driver

tells the printer about how to image the text in your document.

Select the appropriate setting according to the status of your

document.

This option may be available only in

Windows 9x/Me, depending on your particular printer

model.

Download as Outline

: When this option is selected, the

driver will download any TrueType fonts that are used in your

document not already stored (resident) on your printer. If,

after printing a document, you find that the fonts did not print

correctly, choose Download as bit image and resubmit your

print job. The Download as bit image setting is often useful

when printing Adobe.

This feature is available only

when you use the PCL printer driver.

Download as Bit Image

: When this option is selected, the

driver will download the font data as bitmap images.

Documents with complicated fonts, such as Korean or

Chinese, or various other fonts, will print faster in this setting.

Print as Graphics

: When this option is selected, the driver

will download any fonts as graphics. When printing documents

with high graphic content and relatively few TrueType fonts,

printing performance (speed) may be enhanced in this

setting.

•

Print All Text To Black

: When the

Print All Text To Black

option is checked, all text in your document prints solid black,

regardless of the color it appears on the screen.

Basic Printing

Extras Tab

You can select output options for your document. See “Printing

a Document” on page 12 for more information about accessing

the printer properties.

Click the

Extras

tab to access the following feature:

Watermark

You can create a background text image to be printed on each

page of your document.

For details, see

“Using Watermarks” on

page 20.

Overlay

Overlays are often used to take the place of preprinted forms and

letterhead paper.

For details, see

“Using Overlays” on page 21.

Output Options

•

Print Subset

: You can set the sequence in which the pages

print. Select the print order from the drop-down list.

Normal (1,2,3)

: Your printer prints all pages from the first

page to the last page.

Reverse All Pages (3,2,1)

: Your printer prints all pages

from the last page to the first page.

Print Odd Pages

: Your printer prints only the odd numbered

pages of the document.

Print Even Pages

: Your printer prints only the even

numbered pages of the document.

•

Use Printer Fonts

: When Use Printer Fonts is checked, the

printer uses the fonts that are stored in its memory (resident

fonts) to print your document, rather than downloading the

fonts used in your document. Because downloading fonts takes

time, selecting this option can speed up your printing time.

When using Printer fonts, the printer will try to match the fonts

used in your document to those stored in its memory. If,

however, you use fonts in your document that are very different

from those resident in the printer, your printed output will

appear very different from what it looks like on the screen.

This feature is available only when you use the PCL

printer driver.

About Tab

Use the

About

tab to display the copyright notice and the

version number of the driver. If you have an Internet browser,

you can connect to the Internet by clicking on the web site icon.

See “Printing a Document” on page 12 for more information

about accessing printer properties.

Printer Tab

If you access printer properties through the

Printers

folder,

you can view the

Printer

tab. You can set the printer

configuration.

The following procedure is for Windows XP. For other Windows

OS, refer to the corresponding Windows User's Guide or online

help.

Click the Windows

Start

menu.

Select

Printers and Faxes

Select

your printer driver

icon.

Right-click on the printer driver icon and select

Properties

Click the

Printer

tab and set the options.

Basic Printing

Using a Favorite Setting

The

Favorites

option, which is visible on each properties tab,

allows you to save the current properties settings for future

use.

To sa ve a

Favorites

item:

Change the settings as needed on each tab.

Enter a name for the item in the

Favorites

input box.

Click

Save

When you save

Favorites

, all current driver settings are

saved.

To use a saved setting, select the item from the

Favorites

drop

down list. The printer is now set to print according to the

Favorites setting you selected.

To delete a Favorites item, select it from the list and click

Delete

You can also restore the printer driver’s default settings by

selecting

Printer Default

from the list.

Using Help

Your printer has a help screen that can be activated by clicking

the

Help

button in the printer properties window. These help

screens give detailed information about the printer features

provided by the printer driver.

You can also click from the upper right corner of the window,

and then click on any setting.

Advanced Printing

3Advanced Printing

This chapter explains printing options and advanced printing

tasks.

OTE

• Your printer driver

Properties

window that appears in this

User’s Guide may differ depending on the printer in use.

However the composition of the printer properties window is

similar.

• If you need to know the exact name of your printer, you can

check the supplied CD-ROM.

This chapter includes:

• Printing Multiple Pages on One Sheet of Paper (N-Up

Printing)

•Printing Posters

• Printing a Reduced or Enlarged Document

• Fitting Your Document to a Selected Paper Size

•Using Watermarks

•Using Overlays

Printing Multiple Pages on One

Sheet of Paper (N-Up Printing)

You can select the number of pages to print on a single sheet

of paper. To print more than one page per sheet, the pages will

be reduced in size and arranged in the order you specify. You

can print up to 16 pages on one sheet.

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

From the

Layout

tab, choose

Multiple Pages per Side

the

Layout Type

drop-down list.

Select the number of pages you want to print per sheet

(1, 2, 4, 6, 9, or 16) in the

Pages per Side

drop-down

list.

Select the page order from the

Page Order

drop-down

list, if necessary.

Check

Print Page Border

to print a border around each

page on the sheet.

Click the

Paper

tab, select the paper source, size, and

type.

Click

and print the document.

1 2

3 4

Advanced Printing

Printing Posters

This feature allows you to print a single-page document onto 4,

9, or 16 sheets of paper, for the purpose of pasting the sheets

together to form one poster-size document.

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

Click the

Layout

tab, select

Poster Printing

in the

Layout Type

drop-down list.

Configure the poster option:

You can select the page layout from

Poster<2x2>

Poster<3x3>

, or

Poster<4x4>

. If you select

Poster<2x2>

, the output will be automatically stretched

to cover 4 physical pages.

Specify an overlap in millimeters or inches to make it

easier to pasting the sheets together.

Click the

Paper

tab, select the paper source, size, and

type.

Click

and print the document. You can complete the

poster by pasting the sheets together.

0.15 inches

Printing a Reduced or Enlarged

Document

You can change the size of a page’s content to appear larger or

smaller on the printed page.

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

From the

Paper

tab, select

Reduce/Enlarge

in the

Printing Type

drop-down list.

Enter the scaling rate in the

Percentage

input box.

You can also click the or button.

Select the paper source, size, and type in

Paper Options

Click

and print the document.

Fitting Your Document to a

Selected Paper Size

This printer feature allows you to scale your print job to any

selected paper size regardless of the digital document size. This

can be useful when you want to check fine details on a small

document.

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

From the

Paper

tab, select

Fit to Page

in the

Printing

Type

drop-down list.

Select the correct size from the

Output size

drop-down

list.

Select the paper source, size, and type in

Paper Options

Click

and print the document.

Advanced Printing

Using Watermarks

The Watermark option allows you to print text over an existing

document. For example, you may want to have large gray

letters reading “DRAFT” or “CONFIDENTIAL” printed diagonally

across the first page or all pages of a document.

There are several predefined watermarks that come with the

printer, and they can be modified, or you can add new ones to

the list.

Using an Existing Watermark

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

Click the

Extras

tab, and select the desired watermark

from the

Watermark

drop-down list. You will see the

selected watermark in the preview image.

Click

and start printing.

OTE

: The preview image shows how the page will look when

it is printed.

Creating a Watermark

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

Click the

Extras

tab, and click the

Edit

button in the

Watermark

section. The

Edit Watermarks

window

appears.

Enter a text message in the

Watermark Message

box.

You can enter up to 40 characters. The message displays

in the preview window.

When the

First Page Only

box is checked, the watermark

prints on the first page only.

Select watermark options.

You can select the font name, style, size, or grayscale level

from the

Font Attributes

section and set the angle of the

watermark from the

Message Angle

section.

Click

Add

to add a new watermark to the list.

When you have finished editing, click

and start

printing.

To stop printing the watermark, select

(No Watermark)

from

the

Watermark

drop-down list.

Editing a Watermark

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

Click the

Extras

tab and click the

Edit

button in the

Watermark

section. The

Edit Watermarks

window

appears.

Select the watermark you want to edit from the

Current

Watermarks

list and change the watermark message and

options.

Click

Update

to save the changes.

Click

until you exit the Print window.

Deleting a Watermark

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

From the

Extras

tab, click the

Edit

button in the

Watermark section. The

Edit Watermarks

window

appears.

Select the watermark you want to delete from the

Current

Watermarks

list and click

Delete

Click

until you exit the Print window.

Advanced Printing

Using Overlays

What is an Overlay?

An overlay is text and/or images stored in the computer hard

disk drive (HDD) as a special file format that can be printed on

any document. Overlays are often used to take the place of

preprinted forms and letterhead paper. Rather than using

preprinted letterhead, you can create an overlay containing the

exact same information that is currently on your letterhead. To

print a letter with your company’s letterhead, you do not need

to load preprinted letterhead paper in the printer. You need only

tell the printer to print the letterhead overlay on your

document.

Creating a New Page Overlay

To use a page overlay, you must create a new page overlay

containing your logo or image.

Create or open a document containing text or an image for

use in a new page overlay. Position the items exactly as

you wish them to appear when printed as an overlay.

To save the document as an overlay, access printer

properties. See “Printing a Document” on page 12.

Click the

Extras

tab, and click

Edit

button in the

Overlay

section.

In the Edit Overlay window, click

Create Overlay

In the Create Overlay window, type a name of up to eight

characters in the

File name

box. Select the destination

path, if necessary. (The default is C:\Formover).

Click

Save

. The name appears on the

Overlay List

box.

Click

Yes

to finish creating.

The file is not printed. Instead it is stored on your

computer hard disk drive.

OTE

: The overlay document size must be the same as the

documents you print with the overlay. Do not create an overlay

with a watermark.

WORLD BEST

Dear ABC

Regards

WORLD BEST

Using a Page Overlay

After an overlay has been created, it is ready to be printed with

your document. To print an overlay with a document:

Create or open the document you want to print.

To change the print settings from your software

application, access printer properties. See “Printing a

Document” on page 12.

Click the

Extras

tab.

Select the desired overlay from the

Overlay

drop-down

list box.

If the overlay file you want does not appear in the

Overlay

list, click

Edit

button and

Load Overlay

, and

select the overlay file.

If you have stored the overlay file you want to use in an

external source, you can also load the file when you access

the

Load Overlay

window.

After you select the file, click

Open

. The file appears in the

Overlay List

box and is available for printing. Select the

overlay from the

Overlay List

box.

If necessary, click

Confirm Page Overlay When

Printing

. If this box is checked, a message window

appears each time you submit a document for printing,

asking you to confirm your wish to print an overlay on your

document.

If this box is not checked and an overlay has been

selected, the overlay automatically prints with your

document.

Click

Yes

until printing begins.

The selected overlay downloads with your print job and

prints on your document.

OTE

: The resolution of the overlay document must be the

same as that of the document you will print with the overlay.

Deleting a Page Overlay

You can delete page overlays that you no longer use.

In the printer properties window, click the

Extras

tab.

Click the

Edit

button in the

Overlay

section.

Select the overlay you want to delete from the

Overlay

List

box.

Click

Delete Overlay

When a confirming message window appears, click

Yes

Click

until you exit the Print window.

Using Windows PostScript Driver (SCX-4725FN Olny)

4Using Windows

PostScript Driver

(SCX-4725FN Olny)

If you want to use the PostScript driver provided with your

system CD-ROM to print a document.

PPDs, in combination with the PostScript driver, access printer

features and allow the computer to communicate with the

printer. An installation program for the PPDs is provided on the

supplied software CD-ROM.

This chapter includes:

Printer Settings

You can use the printer properties window, which allows you to

access all of the printer options you need when using your

printer. When the printer properties are displayed, you can

review and change the settings needed for your print job.

Your printer properties window may differ, depending on your

operating system. This Software User’s Guide shows the

Properties window for Windows XP.

Your printer driver

Properties

window that appears in this

User’s Guide may differ depending on the printer in use.

OTES

• Most Windows applications will override settings you specify

in the printer driver. Change all print settings available in the

software application first, and change any remaining settings

using the printer driver.

• The settings you change remain in effect only while you are

using the current program.

To make your changes

permanent

, make them in the Printers folder.

• The following procedure is for Windows XP. For other

Windows OS, refer to the corresponding Windows User's

Guide or online help.

1. Click the Windows

Start

button.

2. Select Printers and Faxes.

3. Select your printer driver icon.

4. Right-click on the printer driver icon and select

Printing Preferences.

5. Change the settings on each tab, click OK.

Advanced

You can use advanced settings by clicking the

Advanced

button.

•

Paper/Output

this option allows you to select the size of the

paper loaded in the tray.

•

Graphic

this option allows you to adjust the print quality for

your specific printing needs.

•

Document Options

this options allow you to set the PostScript

options or printer features.

Using Help

You can click from the upper right corner of the window, and

then click on any setting.

Sharing the Printer Locally

5Sharing the Printer

Locally

You can connect the printer directly to a selected computer,

which is called “host computer,” on the network.

The following procedure is for Windows XP. For other Windows

OS, refer to the corresponding Windows User's Guide or online

help.

OTES

• Check the Operating System(s) that are compatible with

your printer. Please refer to the OS Compatibility section of

Printer Specifications in your Printer User’s Guide.

• If you need to know the exact name of your printer, you can

check the supplied CD-ROM.

Setting Up a Host Computer

Start Windows.

From the

Start

menu select

Printers and Faxes

Double-click

your printer driver icon

From the

Printer

menu, select

Sharing

Check the

Share this printer

box.

Fill in the

Shared Name

field, and then click

Setting Up a Client Computer

Right-click the Windows

Start

button and select

Explorer

Open your network folder in the left column.

Click the shared name.

From the

Start

menu select

Printers and Faxes

Double-click

your printer driver icon

From the

Printer

menu, select

Properties

From the

Ports

tab, click

Add Port

Select

Local Port

and click

New Port

Fill in the

Enter a port name

field with the shared name.

Click

and click

Click

Apply

and click

Using Smart Panel

6Using Smart Panel

Smart Panel is a program that monitors and informs you of the

status of the printer, and allows you to customize the printer’s

settings.

Smart Panel

is installed automatically when you

install the printer software.

OTES

• To use the this program, you need:

- Windows 98 or higher (Windows NT 4.0 can be used only

for network-supported printers.) To check for Operating

System(s) that are compatible with your printer, refer to

Printer Specifications in your Printer User’s Guide.

- Internet Explorer version 5.0 or higher for flash animation

in HTML Help.

• If you need to know the exact name of your printer, you can

check the supplied CD-ROM.

Understanding Smart Panel

If an error occurs while printing, Smart Panel appears

automatically, showing the error. You can also launch Smart

Panel manually from the Windows task bar. Double-click the

Smart Panel icon on the Windows task bar.

Or, from the

Start

menu, select

Programs

All Programs

o

your printer driver name

o

Smart Panel

OTES

• If you have already installed more than one Samsung

printer, first select the printer model you want in order to

use the corresponding Smart Panel. Right-click the Smart

Panel icon on the Windows task bar and select

your printer

name

• The Smart Panel window and its contents shown in this

Software User’s Guide may differ depending on the printer in

use.

Double click this icon.

The Smart Panel program displays the current status of the

printer, various information, lets you change settings and the

level of toner remaining in the toner cartridge(s).

Toner Level

You can view the level of toner remaining in the toner

cartridge(s). The printer and the number of the toner cartridge(s)

shown above window may differ depending on the printer in use.

Buy Now

You can order replacement toner cartridge online.

Troubleshooting Guide

You can view Help to solve problems.

Printer Setting

You can configure various printer settings in the Printer Settings

Utility window.

OTES

If you connect your printer to a network, the

SyncThru Web Service

window appears instead of the

Printer Settings Utility window.

Driver Setting

You can use the printer properties window, which allows you to

access all of the printer options you need for using your

printer.

For details,

See “

Printer Settings” on page 13.

Opening the Troubleshooting

Guide

Using the troubleshooting guide, you can view solutions for

error status problems.

Right-click the Smart Panel icon on the Windows task bar and

select

Troubleshooting Guide

Using Smart Panel

Using Printer Settings Utility

Using the Printer Settings Utility, you can configure and check

print settings.

Right-click the Smart Panel icon on the Windows task bar

and select

Printer Setting

Change the settings.

To send the changes to the printer, click the

Apply(or Send)

button.

OTES

If you connect your printer to a network, the

SyncThru Web Service

window appears instead of the

Printer Settings Utility window.

Using Onscreen Help File

Use the help feature by refering the window which appears

when you click the

Help

button at the bottom.

Changing the Smart Panel

Program Settings

Right-click the Smart Panel icon on the Windows task bar and

select

Options

The following window opens.

•

Display when job is finished for network printer

: The

computer shows the Smart Panel popup window or

balloon when your job is complete.

(Only for a network

supported printer.)

•

Display when error occurs during printing

: The

computer shows the Smart Panel popup window or

balloon when an error occurs during printing.

•

Display with

: You can select how the computer shows

you a message. If you select

Popup window (smart

panel)

, the message appears in the Smart Panel pop

window.

•

Launch Job Monitor when the job is saved in the

printer

: If you store print jobs on the printer’s hard disk,

the computer opens the Job Monitor window.

(Only for a

network supported printer with a built-in hard disk.)

•

Schedule an automatic status checking every

: The

computer updates the printer status regularly. Setting the

value close to 1 second causes the computer to check the

printer status more frequently, thereby allowing a faster

response to any printer error.

Scanning

7Scanning

Scanning with your machine lets you turn pictures and text into

digital files on your computer. Then you can fax or e-mail the

files, display them on your web site or use them to create

projects that you can print using Samsung SmarThru software

or the WIA driver.

This chapter includes:

• Scanning Using Samsung SmarThru

• Scanning Process with TWAIN-enabled Software

• Scanning Using the WIA Driver

OTES

• Check the Operating System(s) that are compatible

with your printer. Please refer to the OS Compatibility

section of Printer Specifications in your Printer User’s

Guide.

• You can check your printer name in the supplied CD-

ROM.

• The maximum resolution that can be achieved

depends upon various factors, including computer

speed, available disk space, memory, the size of the

image being scanned, and bit depth settings. Thus,

depending on your system and what you are scanning,

you may not be able to scan at certain resolutions,

especially using enhanced dpi.

Scanning Using Samsung

SmarThru

Samsung SmarThru is the accompanying software for your

machine.

Uninstalling Samsung SmarThru

OTE

: Before beginning uninstallation, ensure that all

applications are closed on your computer.

From the

Start

menu, select

Programs

Select

SmarThru 4

, and then select

Uninstall SmarThru

When your computer asks you to confirm, click

Click

Finish

You may be prompted to restart your computer. In this

case you must shut the computer down and then restart it

before the changes will be saved.

Scanning

Using Samsung SmarThru

Follow these steps to start scanning using the SmarThru:

Make sure that your machine and computer are turned on

and properly connected to each other.

Place your photograph or page on the document glass

or ADF.

Once you have installed Samsung SmarThru, you will see

the

SmarThru 4

icon on your desktop. Double-click the

SmarThru 4

icon.

The SmarThru 4 window opens.

•Scan To

Allows you to scan an image and save it to an application

or folder, email it, or publish it on a web site.

•Image

Allows you to edit an image you have saved as a graphic

file and send it to a selected application or folder, email it,

or publish it on a web site.

•Copy

Allows you to produce professional quality copies. You can

make black and white or color copies of an image if your

machine supports it, and customize the copy settings.

•Print

Allows you to print images you have saved. You can print

images in black and white or color mode if your machine

supports it.

•Fax

Allows you to fax images or files you have saved on your

computer. This is available when your machine supports

the fax feature.

Double-click this icon.

Make sure that your

printer is selected.

Click

Scan To

. The

Scan To

menu bar appears on the

SmarThru 4 window.

Scan To

lets you use the following services:

•Application

Scanning an image and placing it in an image editor

application, such as Paint or Adobe Photoshop.

•E-mail

Scanning an image and emailing it. Allows you to scan an

image, preview it, and email it.

OTE

: To send an image by e-mail, you must have a mail

client program, like Outlook Express, which has been set up

with your e-mail account.

•Folder

Scanning an image and saving it to a folder. Allows you to

scan an image, preview it, and save it to the folder of your

choice.

•OCR

Scanning an image and performing text recognition.

Allows you to scan an image, preview it, and send it to the

OCR program for text recognition.

- Recommended Scan Option for OCR

- Resolution: 200 or 300 dpi

- Image Type: Grayscale or Black & White

•Web

Scanning an image, previewing it, and publishing it on a

web site, using the specified file format for the image you

want to publish.

Adjust the

scan settings.

Scan To

menu bar

Click to start

scanning.

Scanning

•Settings

Customizing settings of

Scan To

basic functions. Allows

you to customize settings for

Application

E-mail

OCR

and

Web

functions.

Click the service icon according to your job.

SmarThru 4

opens for the selected service. Adjust the

scan settings.

To start scanning, click

Scan

OTE

: If you want to cancel the scan job, click

Cancel

Using Onscreen Help File

For more information about SmarThru, click at the top right

corner of the window. The SmarThru Help window opens and

allows you to view onscreen help supplied on the SmarThru

program.

Scanning Process with TWAIN-

enabled Software

If you want to scan documents using other software, you will

need to use TWAIN-compliant software, such as Adobe

PhotoDeluxe or Adobe Photoshop. The first time you scan with

your machine, select it as your TWAIN source in the application

you use.

The basic scanning process involves a number of steps:

Make sure that your machine and computer are turned on

and properly connected to each other.

Load the document(s) face up into the ADF.

Place a single document face down on the document

glass.

Open an application, such as PhotoDeluxe or Photoshop.

Open the TWAIN window and set the scan options.

Scan and save your scanned image.

OTE

: You need to follow the program’s instructions for

acquiring an image. Please refer to the user’s guide of the

application.

Scanning Using the WIA Driver

Your machine also supports the Windows Image Acquisition

(WIA) driver for scanning images. WIA is one of the standard

components provided by Microsoft

£

Windows

£

XP and works

with digital cameras and scanners. Unlike the TWAIN driver, the

WIA driver allows you to scan and easily manipulate images

without using additional software.

OTE

: The WIA driver works only on Windows XP with USB

port.

Load the document(s) face up into the ADF.

Place a single document face down on the document

glass.

From the

Start

menu on your desktop window, select

Settings

Control Panel

, and then

Scanners and

Cameras

Double click

your scanner driver

icon. The Scanner and

Camera Wizard launches.

Choose your scanning preferences and click

Preview

see how your preferences affect the picture.

Click

Enter a picture name, and select a file format and

destination to save the picture.

Follow the on-screen instructions to edit the picture after it

is copied to your computer.

OTE

: If you want to cancel the scan job, press the Cancel

button on the Scanner and Camera Wizard.

Using Your Printer in Linux

8Using Your Printer in

Linux

You can use your machine in a Linux environment.

This chapter includes:

• Getting Started

• Installing the Unified Linux Driver

• Using the Unified Driver Configurator

• Configuring Printer Properties

• Printing a Document

• Scanning a Document

Getting Started

The supplied CD-ROM provides you with Samsung’s Unified

Linux Driver package for using your machine with a Linux

computer.

Samsung’s Unified Linux Driver package contains printer and

scanner drivers, providing the ability to print documents and

scan images. The package also delivers powerful applications

for configuring your machine and further processing of the

scanned documents.

After the driver is installed on your Linux system, the driver

package allows you to monitor a number of machine devices via

fast ECP parallel ports and USB simultaneously.

The acquired documents can then be edited, printed on the

same local or network machine devices, sent by e-mail,

uploaded to an FTP site, or transferred to an external OCR

system.

The Unified Linux Driver package is supplied with a smart and

flexible installation program. You don't need to search for

additional components that might be necessary for the Unified

Linux Driver software: all required packages will be carried onto

your system and installed automatically; this is possible on a

wide set of the most popular Linux clones.

Installing the Unified Linux

Driver

Installing the Unified Linux Driver

Make sure that you connect your machine to your

computer. Turn both the computer and the machine on.

When the Administrator Login window appears, type in

root

in the Login field and enter the system password.

OTE

: You must log in as a super user (root) to install the

printer software. If you are not a super user, ask your system

administrator.

Insert the printer software CD-ROM. The CD-ROM will

automatically run.

If the CD-ROM does not automatically run, click the

icon at the bottom of the desktop. When the Terminal

screen appears, type in:

If the CD-ROM is secondary master and the location to

mount is /mnt/cdrom,

[root@localhost root]#mount -t iso9660 /dev/hdc /mnt/

cdrom

[root@localhost root]#cd /mnt/cdrom/Linux

[root@localhost root]#./install.sh

OTE

: The installation program runs automatically if you

have an autorun software package installed and configured.

When the welcome screen appears, click

Using Your Printer in Linux

When the installation is complete, click

Finish

The installation program has added the Unified Driver

Configurator desktop icon and Samsung Unified Driver

group to the system menu for your convenience. If you

have any difficulties, consult the onscreen help that is

available through your system menu or can otherwise be

called from the driver package windows applications,

such as

Unified Driver Configurator


Manager

Uninstalling the Unified Linux Driver

When the Administrator Login window appears, type in

root

in the Login field and enter the system password.

OTE

: You must log in as a super user (root) to install the

printer software. If you are not a super user, ask your system

administrator.

Insert the printer software CD-ROM. The CD-ROM will

automatically run.

If the CD-ROM does not automatically run, click the

icon at the bottom of the desktop. When the Terminal

screen appears, type in:

If the CD-ROM is secondary master and the location to

mount is /mnt/cdrom,

[root@localhost root]#mount -t iso9660 /dev/hdc /mnt/

cdrom

[root@localhost root]#cd /mnt/cdrom/Linux

[root@localhost root]#./uninstall.sh

OTE

: The installation program runs automatically if you

have an autorun software package installed and configured.

Click

Uninstall

Click

Finish

Using Your Printer in Linux

Using the Unified Driver

Configurator

Unified Linux Driver Configurator is a tool primarily intended for

configuring Printer or MFP devices. Since an MFP device

combines the printer and scanner, the Unified Linux Driver

Configurator provides options logically grouped for printer and

scanner functions. There is also a special MFP port option

responsible for the regulation of access to an MFP printer and

scanner via a single I/O channel.

After installing the Unified Linux driver, the Unified Linux Driver

Configurator icon will automatically be created on your desktop.

Opening the Unified Driver

Configurator

Double-click

Unified Driver Configurator

on the

desktop.

You can also click the Startup Menu icon and select

Samsung Unified Driver

and then

Unified Driver

Configurator

Press each button on the Modules pane to switch to the

corresponding configuration window.

You can use the onscreen help by clicking

Help

After changing the configurations, click

Exit

to close the

Unified Driver Configurator.

Printers Configuration button

Scanners Configuration button

Ports Configuration button

Printers Configuration

Printers configuration has the two tabs:

Printers

and

Classes

Printers Tab

You can see the current system’s printer configuration by

clicking on the printer icon button on the left side of the Unified

Driver Configurator window.

You can use the following printer control buttons:

•

Refresh

: renews the available printers list.

•

Add Printer

: allows you to add a new printer.

•

Remove Printer

: removes the selected printer.

•

Set as Default

: sets the current printer as a default

printer.

•

Stop

Start

: stops/starts the printer.

•

Test

: allows you to print a test page to check if the

machine is working properly.

•

Properties

: allows you to view and change the printer

properties. For details, see page 33.

Shows all of the

installed printer.

Switches to Printer

configuration.

Shows the status,

model name and

URI of your printer.

Using Your Printer in Linux

Classes Tab

The Classes tab shows a list of available printer classes.

•

Refresh

: Renews the classes list.

•

Add Class... :

Allows you to add a new printer class.

•

Remove Class :

Removes the selected printer class.

Scanners Configuration

In this window, you can monitor the activity of scanner devices,

view a list of installed Samsung MFP devices, change device

properties, and scan images.

•

Properties...

: Allows you to change the scan properties

and scan a document. See page 34.

•

Drivers... :

Allows you to monitor the activity of the scan drivers.

Shows the status of the

class and the number of

printers in the class.

Shows all of the

printer classes.

Switches to

Scanners

configuration. Shows all of the

installed scanners.

Shows the vendor,

model name and type

of your scanner.

Ports Configuration

In this window, you can view the list of available ports, check

the status of each port and release a port that is stalled in busy

state when its owner is terminated for any reason.

•

Refresh

: Renews the available ports list.

•

Release port :

Releases the selected port.

Sharing Ports Between Printers and Scanners

Your machine may be connected to a host computer via the

parallel port or USB port. Since the MFP device contains more

than one device (printer and scanner), it is necessary to

organize proper access of “consumer” applications to these

devices via the single I/O port.

The Samsung Unified Linux Driver package provides an

appropriate port sharing mechanism that is used by Samsung

printer and scanner drivers. The drivers address their devices

via so-called MFP ports. The current status of any MFP port can

be viewed via the Ports Configuration. The port sharing

prevents you from accessing one functional block of the MFP

device, while another block is in use.

When you install a new MFP device onto your system, it is

strongly recommended you do this with the assistance of an

Unified Driver Configurator. In this case you will be asked to

choose I/O port for the new device. This choice will provide the

most suitable configuration for MFP’s functionality. For MFP

scanners I/O ports are being chosen by scanner drivers

automatically, so proper settings are applied by default.

Switches to

ports

configuration.

Shows the port type,

device connected to

the port and status

Shows all of the

available ports.

Using Your Printer in Linux

Configuring Printer Properties

Using the properties window provided by the Printers

configuration, you can change the various properties for your

machine as a printer.

Open the Unified Driver Configurator.

If necessary, switch to Printers configuration.

Select your machine on the available printers list and click

Properties

The Printer Properties window opens.

The following five tabs display at the top of the window:

•

General

: allows you to change the printer location and

name. The name entered in this tab displays on the

printer list in Printers configuration.

•

Connection

: allows you to view or select another port. If

you change the printer port from USB to parallel or vice

versa while in use, you must re-configure the printer port

in this tab.

•

Driver

: allows you to view or select another printer

driver. By clicking

Options

, you can set the default

device options.

•

Jobs

: shows the list of print jobs. Click

Cancel job

cancel the selected job and select the

Show completed

jobs

check box to see previous jobs on the job list.

•

Classes

: shows the class that your printer is in. Click

Add to Class

to add your printer to a specific class or

click

Remove from Class

to remove the printer from the

selected class.

Click

to apply the changes and close the Printer

Properties Window.

Printing a Document

Printing from Applications

There are a lot of Linux applications that you are allowed to

print from using Common UNIX Printing System (CUPS). You

can print on your machine from any such application.

From the application you are using, select

from the

File

menu.

Select

directly using

lpr

In the LPR GUI window, select the model name of your

machine from the Printer list and click

Properties

Change the printer and print job properties.

Click.

Using Your Printer in Linux

The following four tabs display at the top of the window.

•

General

- allows you to change the paper size, the paper

type, and the orientation of the documents, enables the

duplex feature, adds start and end banners, and changes

the number of pages per sheet.

•

Text

- allows you to specify the page margins and set the

text options, such as spacing or columns.

•

Graphics

- allows you to set image options that are used

when printing images/files, such as color options, image

size, or image position.

•

Device

: allows you to set the print resolution, paper

source, and destination.

Click

Apply

to apply the changes and close the Properties

window.

Click

in the LPR GUI window to start printing.

The Printing window appears, allowing you to monitor the

status of your print job.

To abort the current job, click

Cancel

Printing Files

You can print many different types of files on the Samsung

machine device using the standard CUPS way - directly from

the command line interface. The CUPS lpr utility allows you do

that. But the drivers package replaces the standard lpr tool by

a much more user-friendly LPR GUI program.

To print any document file:

Type

lpr <file_name>

from the Linux shell command

line and press

Enter

. The LPR GUI window appears.

When you type only

lpr

and press

Enter

, the Select

file(s) to print window appears first. Just select any files

you want to print and click

Open

In the LPR GUI window, select your printer from the list,

and change the printer and print job properties.

For details about the properties window, see page 33.

Click

to start printing.

Scanning a Document

You can scan a document using the Unified Driver Configurator

window.

Double-click the Unified Driver Configurator on your

desktop.

Click the button to switch to Scanners Configuration.

Select the scanner on the list.

When you have only one MFP device and it is connected

to the computer and turned on, your scanner appears on

the list and is automatically selected.

If you have two or more scanners attached to your

computer, you can select any scanner to work at any

time. For example, while acquisition is in progress on the

first scanner, you may select the second scanner, set the

device options and start the image acquisition

simultaneously.

Click

Properties

Load the document to be scanned face up into the ADF

(Automatic Document Feeder) or face down on the

document glass.

Click

Preview

in the Scanner Properties window.

Click your

scanner.

Using Your Printer in Linux

The document is scanned and the image preview appears

in the Preview Pane.

Change the scan options in the Image Quality and Scan

Area sections.

•

Image Quality

: allows you to select the color

composition and the scan resolution for the image.

•

Scan Area

: allows you to select the page size. The

Advanced

button enables you to set the page size

manually.

If you want to use one of the preset scan option settings,

select from the Job Type drop-down list. For details about

the preset Job Type settings, see page 35.

You can restore the default setting for the scan options

by clicking

Default

When you have finished, click

Scan

to start scanning.

The status bar appears on the bottom left of the window

to show you the progress of the scan. To cancel scanning,

click

Cancel

The scanned image appears in the new Image Manager

tab.

If you want to edit the scanned image, use the toolbar.

For further details about editing an image, see page 35.

Drag the pointer to

set the image area

to be scanned.

When you are finished, click

Save

on the toolbar.

Select the file directory where you want to save the image

and enter the file name.

Click

Save

Adding Job Type Settings

You can save your scan option settings to retrieve for a later

scanning.

To save a new Job Type setting:

Change the options from the Scanner Properties window.

Click

Save As

Enter the name for your setting.

Click

Your setting is added to the Saved Settings drop-down

list.

To save a Job Type setting for the next scan job:

Select the setting you want to use from the Job Type drop-

down list.

The next time you open the Scanner Properties window,

the saved setting is automatically selected for the scan

job.

To delete a Job Type setting:

Select the setting you want to delete from the Job Type

drop-down list.

Click

Delete

The setting is deleted from the list

Using the Image Manager

The Image Manager application provides you with menu

commands and tools to edit your scanned image.

Use these tools to

edit the image.

Using Your Printer in Linux

You can use the following tools to edit the image:

For further details about the Image Manager application, refer

to the onscreen help.

Tools Function

Saves the image.

Cancels your last action.

Restores the action you canceled.

Allows you to scroll through the image.

Crops the selected image area.

Zooms the image out.

Zooms the image in.

Allows you to scale the image size; you can

enter the size manually, or set the rate to

scale proportionally, vertically, or

horizontally.

Allows you to rotate the image; you can

select the number of degrees from the drop-

down list.

Allows you to flip the image vertically or

horizontally.

Allows you to adjust the brightness or

contrast of the image, or to invert the

image.

Shows the properties of the image.

Using Your Printer with a Macintosh (SCX-4725FN Olny)

9Using Your Printer with

a Macintosh

(SCX-4725FN Olny)

Your machine supports Macintosh systems with a built-in USB

interface or a 10/100 Base-TX network interface card. When

you print a file from a Macintosh computer, you can use the

PostScript driver by installing the PPD file.

OTE

Some printers do not support a network

interface. Make sure that your printer supports a

network interface by referring to Printer Specifications

in your Printer User’s Guide.

This chapter includes:

• Installing Software for Macintosh

• Setting Up the Printer

•Printing

•Scanning

Installing Software for

Macintosh

The PostScript driver CD-ROM that came with your machine

provides you with the PPD file to use the PS driver, Apple

LaserWriter driver, for printing on a Macintosh computer.

Also, it provides you with the Twain driver for scanning on a

Macintosh computer.

Install the Printer driver

Connect your machine to the computer using the USB

cable or the Ethernet cable.

Turn on your computer and the machine.

Insert the PostScript driver CD-ROM which came with your

machine into the CD-ROM drive.

Double-click the

Samsung MFP

on your Macintosh

desktop.

Double-click the

MAC_Installer

folder.

Double-click the

MAC_Printer

folder.

Double-click the

Samsung MFP Installer OSX

icon.

Click

Continue

Click

Install

After the installation is finished, click

Quit

Uninstalling the Printer driver

Uninstall is required if you are upgrading the software, or if

installation fails.

Insert the PostScript driver CD-ROM which came with your

machine into the CD-ROM drive.

Double-click the

Samsung MFP

on your Macintosh

desktop.

Double-click the

MAC_Installer

folder.

Double-click the

MAC_Printer

folder.

Double-click the

Samsung MFP Installer OSX

icon.

Click

Continue

Select

Uninstall

and then click

Uninstall

When the uninstallation is done, click

Quit

Using Your Printer with a Macintosh (SCX-4725FN Olny)

Install the Scan driver

Make sure that you connect your printer to the computer.

Turn on your computer and printer.

Insert the CD-ROM which came with your printer into the

CD-ROM drive.

Double-click

CD-ROM icon

that appears on your

Macintosh desktop.

Double-click the

MAC_Installer

folder.

Double-click the

MAC_Twain

folder.

Double-click the

Samsung ScanThru Installer

icon.

Enter the password and click

Click

Continue

Click

Install

Click

Continue

After the installation is finished, click

Quit

Uninstalling the Scan driver

Insert the CD-ROM which came with your printer into the

CD-ROM drive.

Double-click

CD-ROM icon

that appears on your

Macintosh desktop.

Double-click the

MAC_Installer

folder.

Double-click the

MAC_Twain

folder.

Double-click the

Samsung ScanThru Installer

icon.

Enter the password and click

Click

Continue

Select

Uninstall

from the Installation Type and then Click

Uninstall

Click

Continue

When the uninstallation is done, click

Quit

Setting Up the Printer

Set up for your printer will be different depending on which

cable you use to connect the printer to your computer—the

network cable or the USB cable.

For a Network-connected Macintosh

OTE

Some printers do not support a network

interface. Before connecting your printer, make sure

that your printer supports a network interface by

referring to Printer Specifications in your Printer User’s

Guide.

Follow the instructions on “Installing Software for

Macintosh” on page 37 to install the PPD file on your

computer.

Open

Print Center

Printer Setup Utility

from the

Utilities folder.

Click

Add

on the Printer List.

Select the

AppleTalk

tab.

The name of your machine appears on the list. Select

SEC000xxxxxxxxx

from the printer box, where the

xxxxxxxxx

varies depending on your machine.

Click

Add

If Auto Select does not work properly, select

Samsung

Printer Model

and

your printer name

Model Name

Your machine appears on the Printer List and is set as the

default printer.

For a USB-connected Macintosh

Follow the instructions on “Installing Software for

Macintosh” on page 37 to install the PPD file on your

computer.

Open

Print Center

Printer Setup Utility

from the

Utilities folder.

Click

Add

on the Printer List.

Select the

USB

tab.

Select

your printer name

and click

Add

If Auto Select does not work properly, select

Samsung

Printer Model

and

your printer name

Model Name

Your machine appears on the Printer List and is set as the

default printer.

Printing

OTES

• The Macintosh printer’s properties window that appears in

this User’s Guide may differ depending on the printer in use.

However the composition of the printer properties window is

similar.

• You can check your printer name in the supplied CD-

ROM.

Printing a Document

When you print with a Macintosh, you need to check the printer

software setting in each application you use. Follow these steps

to print from a Macintosh.

Open a Macintosh application and select the file you want

to print.

Open the

File

menu and click

Page Setup

(

Document

Setup

in some applications).

Choose your paper size, orientation, scaling, and other

options and click

Open the

File

menu and click

Choose the number of copies you want and indicate which

pages you want to print.

Click

when you finish setting the options.

▲

Mac OS 10.3

Make sure that your

printer is selected.

Changing Printer Settings

You can use advanced printing features when using your

printer.

From your Macintosh application, select

from the

File

menu. The printer name which appears in the printer properties

window may differ depending on the printer in use. Except for

the name, the composition of the printer properties window is

similar.

Layout Setting

The

Layout

tab provides options to adjust how the document

appears on the printed page. You can print multiple pages on

one sheet of paper.

Select

Layout

from the

Presets

drop-down list to access the

following features. For details, see “Printing Multiple Pages on

One Sheet of Paper” on the next column.

▲

Mac OS 10.3

Printer Features Setting

The

Printer Features

tab provides options for selecting the

paper type and adjusting print quality.

Select

Printer Features

from the

Presets

drop-down list to

access the following features:

Image Mode

Image Mode allows the user to enhance printouts. The available

options are Normal and Text Enhance.

Fit to Page

This printer feature allows you to scale your print job to any

selected paper size regardless of the digital document size. This

can be useful when you want to check fine details on a small

document.

Paper Type

Set

Type

to correspond to the paper loaded in the tray from

which you want to print. This will let you get the best quality

printout. If you load a different type of print material, select the

corresponding paper type.

Resolution(Quality)

The Resolution options you can select may vary

depending on your printer model.

You can select the

printing resolution. The higher the setting, the sharper the clarity

of printed characters and graphics. The higher setting also may

increase the time it takes to print a document.

▲

Mac OS 10.3

Printing Multiple Pages on One Sheet

of Paper

You can print more than one page on a single sheet of paper.

This feature provides a cost-effective way to print draft pages.

From your Macintosh application, select

from the

File

menu.

Select

Layout

Select the number of pages you want to print on one sheet

of paper on the

Pages per Sheet

drop-down list.

Select the page order from the

Layout Direction

option.

To print a border around each page on the sheet, select

the option you want from the

Border

drop-down list.

Click

, and the printer prints the selected number of

pages on one side of each page.

▲

Mac OS 10.3

Scanning

If you want to scan documents using other software, you will

need to use TWAIN-compliant software, such as Adobe

PhotoDeluxe or Adobe Photoshop. The first time you scan with

your machine, select it as your TWAIN source in the application

you use.

The basic scanning process involves a number of steps:

• Place your photograph or page on the document glass or

ADF.

• Open an application, such as PhotoDeluxe or Photoshop.

• Open the TWAIN window and set the scan options.

• Scan and save your scanned image.

OTE

: You need to follow the program’s instructions for

acquiring an image. Please refer to the User’s Guide of the

application.

SOFTWARE SECTION

INDEX

advanced printing, use

canceling

scan

document, print

Macintosh

Windows

Extras properties, set

favorites settings, use

Graphics properties, set

help, use

17,22

install

printer driver

Macintosh

Windows

installing

Linux software

Layout properties, set

Macintosh

Windows

Linux

driver, install

printer properties

printing

scanning

Macintosh

driver

install

uninstall

printing

scanning

setting up the printer

MFP driver, install

Linux

n-up printing

Macintosh

Windows

orientation, print

Windows

overlay

create

delete

Paper properties, set

paper size, set

paper source, set

Windows

paper type, set

Macintosh

poster, print

PostScript driver

installing

document

fit to page

from Macintosh

from Windows

N-up

Macintosh

Windows

overlay

poster

PRN

scaling

watermark

print resolution

printer driver, install

Linux

printer properties

Linux

printer properties, set

Macintosh

Windows

13,22

printer resolution, set

Macintosh

Windows

printer software

install

Macintosh

Windows

uninstall

Macintosh

Windows

printing

from Linux

resolution

printing

scanning

Linux

SmarThru

TWAIN

WIA driver

scanning from Macintosh

setting

darkness

favorites

image mode

resolution

Macintosh

Windows

toner save

true-type option

software

install

Macintosh

Windows

reinstall

Windows

system requirements

Macintosh

uninstall

Macintosh

Windows

status monitor, use

toner save, set

TWAIN, scan

uninstall, software

Macintosh

Windows

uninstalling

MFP driver

Linux

watermark

create

delete

edit

WIA, scan
