Users Manual 1

BASIC

User’s Guide

SCX-472x Series

SCX-470x Series

BASIC

User’s Guide

This guide provides information concerning installation, basic operation and

troubleshooting on windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and

troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

1. Introduction

This chapter provides information you need to know before using the machine.

•Key benefits 3

• Features by models 5

• Useful to know 12

• About this user’s guide 13

• Safety information 14

• Machine overview 19

• Control panel overview 23

• Turning on the machine 26

• Installing the driver locally 27

• Reinstalling the driver 28

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature.

• To save paper, you can print multiple pages on one single sheet of paper

(see "Using advanced print features" on page 210).

• To save paper, you can print on both sides of the paper (double-sided

printing) (Not supported SCX-4726FN Series) (see "Using advanced print

features" on page 210).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

Fast high resolution printing

• You can print with a resolution of up to 1,200 x 1,200 dpi effective output.

• Fast, on-demand printing.

SCX-472x Series, SCX-470x Series:

- For single-side printing, 28 ppm (A4) or 29 ppm (Letter).

- For duplex printing, 14 ppm (A4) or 15 ppm (Letter).

• SCX-4726FN Series:

- For single-side printing, 26 ppm (A4) or 27 ppm (Letter).

Convenience

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 249).

• Printing Status (or Smart Panel) is a program that monitors and informs you

of the machine’s status and allows you to customize the machine’s settings

(see "Using advanced print features" on page 210).

• AnyWeb Print helps you screen-capture, preview, scrap, and print the

screen of Windows Internet Explorer more easily, than when you use the

ordinary program (see "Samsung AnyWeb Print" on page 250).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows.

Key benefits

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 103).

• Print watermark: You can customize your documents with words, such as

“Confidential” (see "Using advanced print features" on page 210).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 210).

• You can print in various operating systems (see "System requirements" on

page 106).

• Your machine is equipped with a USB interface and/or a network interface.

Features by models

Some features and optional goods may not be available depending on model or country.

Operating System

(̻: Included, Blank: Not available)

Software

Operating System

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470x ND Series

Windows Ɣ Ɣ Ɣ

Macintosh Ɣ Ɣ Ɣ

Linux Ɣ Ɣ Ɣ

Unix Ɣ Ɣ Ɣ

Software

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470x ND Series

PCL / SPL printer driver1Ɣ Ɣ Ɣ

PS printer driver

Features by models

XPS printer driver

Direct Printing Utility

Samsung Easy

Printer Manager

Scan to PC settings Ɣ Ɣ Ɣ

Fax to PC settings Ɣ Ɣ

Device settings Ɣ Ɣ Ɣ

Samsung Printer Status Ɣ Ɣ Ɣ

Smart Panel Ɣ Ɣ Ɣ

AnyWeb Print Ɣ Ɣ Ɣ

SyncThru™ Web Service Ɣ Ɣ Ɣ

SyncThru Admin Web Service Ɣ Ɣ Ɣ

Easy Eco Driver Ɣ Ɣ Ɣ

Fax Samsung Network PC

Fax

Ɣ Ɣ

Software

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470x ND Series

Features by models

(̻: Included, Blank: Not available)

Scan Twain scan driver Ɣ Ɣ Ɣ

WIA scan driver Ɣ Ɣ Ɣ

Samsung Scan Assistant Ɣ Ɣ Ɣ

SmarThru 4

SmarThru Office Ɣ Ɣ Ɣ

1. Depending on the operating system you use, the installed print driver may differ.

Software

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470x ND Series

Features by models

Variety feature

Features

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470xND Series

Hi-Speed USB 2.0 Ɣ Ɣ Ɣ

Network Interface Ethernet 10/100 Base TX

wired LAN

Ɣ Ɣ Ɣ

Network Interface 802.11b/g/n wireless LAN Ɣ

Eco printing Ɣ Ɣ Ɣ

Duplex (2-sided) printing Ɣ

(SCX-472xFD Series, SCX-472xHD

Series, SCX-472xHN Series only)

Ɣ Ɣ

USB memory interface

Touch screen

Duplex Automatic Document Feeder (DADF)

Automatic Document Feeder (ADF) Ɣ Ɣ Ɣ

Handset Ɣ

(SCX-472xHD Series, SCX-472xHN

Series only)

(SCX-472xHW Series only)

Features by models

Fax Multi-send Ɣ Ɣ

Delay send Ɣ Ɣ

Priority send Ɣ Ɣ

Duplex send

Secure receive Ɣ Ɣ

Duplex print Ɣ

(SCX-472xFD Series, SCX-472xHD

Series, SCX-472xHN Series only)

Send/ Receive

forward - fax

Ɣ Ɣ

Send/ Receive

forward - email

Send/ Receive

forward - server

Features

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470xND Series

Features by models

Scan Scanning to email

Scanning to SMB

server

Scanning to FTP

server

Duplex scan

Scan to PC Ɣ Ɣ Ɣ

Copy ID card copying Ɣ Ɣ Ɣ

Collation Ɣ Ɣ Ɣ

Poster Ɣ Ɣ Ɣ

Clone Ɣ Ɣ Ɣ

Book

Features

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470xND Series

Features by models

(̻: Included, Blank: Not available)

Copy (Continue) 2-up/ 4-up Ɣ Ɣ Ɣ

Adjust background Ɣ Ɣ Ɣ

Margin shift

Edge erase

Gray enhance

Duplex copy Ɣ

(SCX-472xFD Series, SCX-472xHD

Series, SCX-472xHN Series only)

Ɣ Ɣ

Features

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470xND Series

Useful to know

The machine does not print.

• Open the print queue list and remove the document from the list

(see "Canceling a print job" on page 55).

• Remove the driver and install it again (see "Installing the driver

locally" on page 27).

• Select your machine as your default machine in your Windows.

Where can I purchase accessories or supplies?

• Inquire at a Samsung distributor or your retailer.

• Visit www.samsung.com/supplies. Select your country/region to

view product service information.

The status LED flashes or remains constantly on.

• Turn the product off and on again.

• Check the meanings of LED indications in this manual and

troubleshoot accordingly (see "Understanding the status LED" on

page 94).

A paper jam has occurred.

• Open and close the front door.

• Check the instructions on removing jammed paper in this manual

and troubleshoot accordingly (see "Clearing paper jams" on page

89).

Printouts are blurry.

• The toner level might be low or uneven. Shake the toner cartridge.

• Try a different print resolution setting.

• Replace the toner cartridge.

Where can I download the machine’s driver?

• Visit www.samsung.com to download the latest machine’s driver,

and install it on your system.

1. Introduction

About this user’s guide

This user's guide provides information for your basic understanding of the

machine as well as detailed steps to explain machine usage.

• Read the safety information before using the machine.

• If you have a problem using the machine, refer to the troubleshooting

chapter.

• Terms used in this user’s guide are explained in the glossary chapter.

• All illustrations in this user’s guide may differ from your machine depending

on its options or model you purchased.

• The screenshots in this administrator’s guide may differ from your machine

depending on the machine’s firmware/driver version.

• The procedures in this user’s guide are mainly based on Windows 7.

Conventions

Some terms in this guide are used interchangeably, as below:

• Document is synonymous with original.

• Paper is synonymous with media, or print media.

• Machine refers to printer or MFP.

General icons

Icon Text Description

Caution Gives users information to protect the machine from

possible mechanical damage or malfunction.

Note Provides additional information or detailed

specification of the machine function and feature.

1. Introduction

Safety information

These warnings and precautions are included to prevent injury to you and

others, and to prevent any potential damage to your machine. Be sure to read

and understand all of these instructions before using the machine. After reading

this section, keep it in a safe place for future reference.

Important safety symbols

Explanation of all icons and signs used in this chapter

Operating environment

Warning

Warning Hazards or unsafe practices that may result in severe

personal injury or death.

Caution Hazards or unsafe practices that may result in minor

personal injury or property damage.

Do not attempt.

Do not use if the power cord is damaged or if the electrical outlet is

not grounded.

This could result in electric shock or fire.

Do not place anything on top of the machine (water, small metal or

heavy objects, candles, lit cigarettes, etc.).

This could result in electric shock or fire.

• If the machine gets overheated, it releases smoke, makes

strange noises, or generates an odd odor, immediately turn off

the power switch and unplug the machine.

• The user should be able to access the power outlet in case of

emergencies that might require the user to pull the plug out.

This could result in electric shock or fire.

Do not bend, or place heavy objects on the power cord.

Stepping on or allowing the power cord to be crushed by a heavy

object could result in electric shock or fire.

Do not remove the plug by pulling on the cord; do not handle the

plug with wet hands.

This could result in electric shock or fire.

Safety information

1. Introduction

Caution

Operating method

Caution

During an electrical storm or for a period of non-operation,

remove the power plug from the electrical outlet.

This could result in electric shock or fire.

Be careful, the paper output area is hot.

Burns could occur.

If the machine has been dropped, or if the cabinet appears

damaged, unplug the machine from all interface connections and

request assistance from qualified service personnel.

Otherwise, this could result in electric shock or fire.

If the machine does not operate properly after these instructions

have been followed, unplug the machine from all interface

connections and request assistance from qualified service

personnel.

Otherwise, this could result in electric shock or fire.

If the plug does not easily enter the electrical outlet, do not

attempt to force it in.

Call an electrician to change the electrical outlet, or this could

result in electric shock.

Do not allow pets to chew on the AC power, telephone or PC

interface cords.

This could result in electric shock or fire and/or injury to your pet.

Do not forcefully pull the paper out during printing.

It can cause damage to the machine.

Be careful not to put your hand between the machine and paper

tray.

You may get injured.

This machine's power reception device is the power cord.

To switch off the power supply, remove the power cord from the

electrical outlet.

Be care when replacing paper or removing jammed paper.

New paper has sharp edges and can cause painful cuts.

When printing large quantities, the bottom part of the paper

output area may get hot. Do not allow children to touch.

Burns can occur.

When removing jammed paper, do not use tweezers or sharp metal

objects.

It can damage the machine.

Safety information

1. Introduction

Installation / Moving

Warning

Caution

Do not allow too many papers to stack up in the paper output tray.

It can damage the machine.

Do not block or push objects into the ventilation opening.

This could result in elevated component temperatures which can

cause damage or fire.

Use of controls or adjustments or performance of procedures other

than those specified herein may result in hazardous radiation

exposure.

Do not place the machine in an area with dust, humidity, or water

leaks.

This could result in electric shock or fire.

Before moving the machine, turn the power off and disconnect all

cords.

Then lift the machine:

• If the machine weighs under 20 kg (44.09 lbs), lift with 1 person.

• If the machine weighs 20 kg (44.09 lbs) - 40kg (88.18 lbs), lift

with 2 people.

• If the machine weighs more than 40 kg (88.18 lbs), lift with 4 or

more people.

The machine could fall, causing injury or machine damage.

Do not place the machine on an unstable surface.

The machine could fall, causing injury or machine damage.

Use only No.26 AWG1 or larger, telephone line cord, if necessary.

Otherwise, it can cause damage to the machine.

Make sure you plug the power cord into a grounded electrical

outlet.

Otherwise, this could result in electric shock or fire.

Use the power cord supplied with your machine for safe

operation. If you are using a cord which is longer than 2 meters (6

feet) with a 110V machine, then the gauge should be 16 AWG or

larger.

Otherwise, it can cause damage to the machine, and could result

in electric shock or fire.

Safety information

1. Introduction

Maintenance / Checking

Caution

The machine should be connected tothe power level which is

specified on the label.

If you are unsure and want to check the power level you are using,

contact the electrical utility company.

Do not put a cover over the machine or place it in an airtight

location, such as a closet.

If the machine is not well-ventilated, this could result in fire.

Do not overload wall outlets and extension cords.

This can diminish performance, and could result in electric shock

or fire.

1. AWG: American Wire Gauge

Unplug this product from the wall outlet before cleaning the

inside of the machine. Do not clean the machine with benzene,

paint thinner or alcohol; do not spray water directly into the

machine.

This could result in electric shock or fire.

When you are working inside the machine replacing supplies or

cleaning the inside, do not operate the machine.

You could get injured.

Keep cleaning supplies away from children.

Children could get hurt.

Do not disassemble, repair or rebuild the machine by yourself.

It can damage the machine. Call a certified technician when the

machine needs repairing.

Keep the power cable and the contact surface of the plug clean

from dust or water.

Otherwise, this could result in electric shock or fire.

To clean and operate the machine, strictly follow the user's guide

provided with the machine.

Otherwise, you could damage the machine.

• Do not remove any covers or guards that are fastened with

screws.

• Fuser units should only be repaired by a certified service

technician. Repair by non-certified technicians could result in

fire or electric shock.

• The machine should only be repaired by a Samsung service

technician.

Safety information

1. Introduction

Supply usage

Caution

Do not disassemble the toner cartridge.

Toner dust can be dangerous if inhaled or ingested.

Do not burn any of the supplies such as toner cartridge or fuser

unit.

This could cause an explosion or uncontrollable fire.

When storing supplies such as toner cartridges, keep them away

from children.

Toner dust can be dangerous if inhaled or ingested.

When changing the toner cartridge or removing jammed paper,

be careful not to let toner dust touch your body or clothes.

Toner dust can be dangerous if inhaled or ingested.

When toner gets on your clothing, do not use hot water to wash

it.

Hot water sets toner into fabric. Use cold water.

Using recycled supplies, such as toner, can cause damage to the

machine.

In case of damage due to the use of recycled supplies, a service

fee will be charged.

1. Introduction

Machine overview

Accessories

Power cord Quick installation guide

Software CD1

1. The software CD contains the print drivers and software applications.

Handset2

2. Handset model only (see "Features by models" on page 5)

Misc. accessories3

3. Miscellaneous accessories included with your machine may vary by country of purchase and specific model.

Machine overview

1. Introduction

Front view

• This illustration may differ from your machine depending on your model.

• Some features and optional goods may not be available depending on model or country (see "Features by models" on page 5).

1Document feeder cover 7 Manual feeder tray 13 Scanner glass

2Document feeder guide cover 8 Front cover 14 Document feeder input tray

Machine overview

1. Introduction

3Document feeder output tray 9 Output tray 15 Paper width guide on a document feeder

4Control Panel 10 Output support 16 Document feeder output support

5Paper level indicator 11 Paper width guide on a manual feeder 17 Handset1

6Tray 12 Scanner lid

1. Handset model only (see "Features by models" on page 5).

Machine overview

1. Introduction

Rear view

• This illustration may differ from your machine depending on your model.

• Some features and optional goods may not be available depending on model or country (see "Features by models" on page 5).

1Network port 3Telephone line socket (Line)

(SCX-472x Series only)

5Power receptacle

2Extension telephone socket (EXT)

(SCX-472x Series only)

4USB port 6Rear cover

1. Introduction

Control panel overview

This control panel may differ from your machine depending on its model.

There are various types of control panels.

A Type (SCX-472x Series)

1Eco Turn into eco mode to reduce toner consumption

and paper usage (see"Eco printing" on page 57).

(WPS)

Configures the wireless network connection

easily without a computer (see Advanced Guide).

Darkness Adjust the brightness level to make a copy for

easier reading, when the original contains faint

markings and dark images.

3ID Copy Allows you to copy both sides of an ID card like a

driver’s license on a single side of paper (see "ID

card copying" on page 62).

4(Power/Wakeup) Turns the power on or off, or wakes up the

machine from the power save mode. If you need

to turn the machine off, press this button for more

than three seconds.

(Fax)

Switches to Fax mode.

(Copy)

Switches to Copy mode.

(Scan)

Switches to Scan mode.

(Menu)

Opens Menu mode and scrolls through the

available menus.

9Left/Right Arrows Scrolls through the options available in the

selected menu and increases or decreases values.

Control panel overview

1. Introduction

B Type (SCX-470x Series)

10 OK Confirms the selection on the screen.

(Back)

Sends you back to the upper menu level.

(Start)

Starts a job.

(Stop/Clear)

Stops an operations at any time.

14 Status LED Indicates the status of your machine (see

"Understanding the status LED" on page 94).

15 Numeric keypad Dials a number or enters alphanumeric

characters.

(On Hook Dial)

When you press this button, you can hear a dial

tone. Then enter a fax number. It is similar to

making a call using speaker phone.

17 Redial/Pause(-) Redials the last number in ready mode, or inserts

a pause(-) into a fax number in edit mode.

(Address Book)

Allows you to store frequently used fax numbers

or search for stored fax numbers.

19 Display screen Shows the current status and displays prompts

during an operation.

Control panel overview

1. Introduction

Adjusting the control panel

1Eco Turn into eco mode to reduce toner consumption

and paper usage (see"Eco printing" on page 57).

2Darkness Adjust the brightness level to make a copy for

easier reading, when the original contains faint

markings and dark images.

3ID Copy Allows you to copy both sides of an ID card like a

driver’s license on a single side of paper (see "ID

card copying" on page 62).

4Scan to Sends scanned data (see "Basic Scanning" on page

64).

5(Power/Wakeup) Turns the power on or off, or wakes up the

machine from the power save mode. If you need

to turn the machine off, press this button for more

than three seconds.

6Display screen Shows the current status and displays prompts

during an operation.

(Menu)

Opens Menu mode and scrolls through the

available menus.

8Left/Right Arrows Scrolls through the options available in the

selected menu and increases or decreases values.

9OK Confirms the selection on the screen.

(Back)

Sends you back to the upper menu level.

(Start)

Starts a job.

(Stop/Clear)

Stops an operations at any time.

13 Status LED Indicates the status of your machine (see

"Understanding the status LED" on page 94).

1. Introduction

Turning on the machine

1Connect the machine to the electricity supply first.

Turn the switch on if the machine has a power switch.

1. Introduction

Installing the driver locally

A locally connected machine is a machine directly attached to your computer

using the cable. If your machine is attached to a network, skip the following

steps below and go on to installing a network connected machine’s driver (see

Advanced Guide).

• If you are a Macintosh, Linux, or Unix OS user, refer to the Advanced

guide.

• The installation window in this User’s Guide may differ depending on the

machine and interface in use.

• Only use a USB cable no longer than 3 meters (118 inches).

Windows

1Make sure that the machine is connected to your computer and

powered on.

If the “Found New Hardware Wizard” appears during the installation

procedure, click Cancel to close the window.

2 Insert the supplied software CD into your CD-ROM drive.

Click Start > All programs > Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CD-

ROM drive and click OK.

3 Select Install Now.

(SCX-470x Series does not support the Wireless Setting and

Installation menu)

4 Follow the instructions in the installation window.

You can install necessary software in the "Select Software to Install" screen.

1. Introduction

Reinstalling the driver

If the printer driver does not work properly, follow the steps below to reinstall the driver.

Windows

1Make sure that the machine is connected to your computer and powered on.

2 From the Start menu, select Programs or All Programs > Samsung Printers > your printer driver name > Uninstall.

3 Follow the instructions in the installation window.

4 Insert the software CD into your CD-ROM drive and install the driver again (see "Installing the driver locally" on page 27).

2. Menu overview and basic

setup

This chapter provides information about the overall menu structure and the basic setup options.

• Menu overview 30

• Changing the display language 39

• Media and tray 40

• Basic printing 54

• Basic copying 60

• Basic scanning 64

• Basic faxing 65

2. Menu overview and basic setup

Menu overview

The control panel provides access to various menus to set up the machine or use

the machine’s functions.

• An asterisk (*) appears next to the currently selected menu.

• Some menus may not appear on the display depending on options or

models. If so, it is not applicable to your machine.

• Some menu names may differ from your machine depending on its

options or the models.

•SCX-470x Series does not support the fax features.

Accessing the menu

1Select the Fax, Copy, or Scan button on the control panel depending on

the feature to be used.

2 Select (Menu) until the menu you want appears on the bottom line

of the display and press OK.

3 Press the left/right arrows until the needed menu item appears and press

OK.

4 If the setting item has sub menus, repeat step 3.

5 Press the left/right arrows to access the required value.

6 Press OK to save the selection.

7 Press (Stop/Clear) to return to the ready mode.

SCX-472x Series

Items Options

Fax Feature1Darkness Light+5- Light+1

Normal

Dark+1- Dark+5

Contrast Light+5- Light+1

Normal

Dark+1- Dark+5

Resolution Standard

Fine

Super Fine

Photo Fax

Color Fax

Scan Size

Multi Send

Delay Send

Menu overview

2. Menu overview and basic setup

Fax Feature1Priority Send

Forward Fax

Secure Receive On

Off

Add Page

Cancel Job

Fax Setup1Sending Redial Times

Redial Term

Prefix Dial

ECM Mode

Send Report

Image TCR

Dial Mode 2

Items Options

Fax Setup1Receiving Receive Mode

Ring To Answer

Stamp RCV Name

RCV Start Code

Auto Reduction

Discard Size

Junk Fax Setup

DRPD Mode

Duplex Print3

Change Default Resolution

Darkness

Contrast

Scan Size

Auto Report On

Off

Copy Feature Scan Size

Reduce/Enlarge

Darkness Light+5- Light+1

Normal

Dark+1- Dark+5

Items Options

Menu overview

2. Menu overview and basic setup

Copy Feature Contrast Light+5- Light+1

Normal

Dark+1- Dark+5

Original Type Text

Text/Photo


Layout Normal

2-Up

4-Up

ID copy

Poster Copy

Clone Copy

Adjust Bkgd. Off

Auto

Enhance Lev.1

Enhance Lev.2

Erase Lev.1- Erase Lev.4

Duplex3Off

1 -> 2 Side Long

1 -> 2 SideShort

Items Options

Copy Setup Change Default Scan Size

Copies

Copy Collation

Reduce/Enlarge

Duplex3

Darkness

Contrast

Original Type

Adjust Bkgd.

Print Setup Orientation Portrait

Landscape

Duplex3Off

1 -> 2 Side Long

1 -> 2 SideShort

Copies [1-999]:1

Resolution 600dpi-Normal

1200dpi-Best

Darkness Normal

Light

Dark

Items Options

Menu overview

2. Menu overview and basic setup

Print Setup Clear Text Off

Minimum

Medium

Maximum

Auto CR LF

LF+CR

Emulation Emulation Type

Setup

Items Options

System Setup Machine Setup Machine ID

Fax Number1

Date & Time

Clock Mode

Language

Power Save

Wakeup Event

System Timeout

Job Timeout

Altitude Adj.

Auto Continue4

Paper Mismatch

Paper Substit4

PrintBlankPage

Toner Save

Eco Settings

Paper Setup Paper Size

Paper Type

Paper Source

Margin

Items Options

Menu overview

2. Menu overview and basic setup

System Setup Sound/Volume Key Sound

Alarm Sound

Speaker

Ringer

Report All Report

Configuration

Supplies Info.

Address Book

Fax Send1

Fax Sent1

Fax Received1

Schedule Jobs

Junk Fax1

Network Conf.

Usage Counter

Fax Options1

Maintenance CLR Empty Msg5

Supplies Life

Serial NO.

TonerLow Alert

Items Options

System Setup Clear Setting All Settings

Print Setup

Fax Setup1

Copy Setup

System Setup

Network Setup

Address Book

Fax Sent1

Fax Received1

Network TCP/IP (IPv4) DHCP

BOOTP

Static

TCP/IP (IPv6) IPv6 Activate

DHCPv6 Config

Ethernet Speed Automatic

10Mbps Half

10Mbps Full

100Mbps Half

100Mbps Full

Items Options

Menu overview

2. Menu overview and basic setup

SCX-470x Series

Network Clear Setting

Network Conf.

Wireless1Wi-Fi ON/OFF

WPS Setting

WLAN Setting

WLAN Default

WLAN Signal

1. SCX-472x Series Only.

2. This setting may not be available depending on your country.

3. Not supported SCX-472xFN Series.

4. This option only appears if “paper mismatch” is enabled.

5. This option only appears when small amount of toner is left in the cartridge.

Items Options

Copy Feature Scan Size

Reduce/Enlarge

Darkness Light+5- Light+1

Normal

Dark+1- Dark+5

Items Options

Copy Feature Contrast Light+5- Light+1

Normal

Dark+1- Dark+5

Original Type Text

Text/Photo


Layout Normal

2-Up

4-Up

ID copy

Poster Copy

Clone Copy

Adjust Bkgd. Off

Auto

Enhance Lev.1

Enhance Lev.2

Erase Lev.1- Erase Lev.4

Duplex1Off

1 -> 2 Side Long

1 -> 2 SideShort

Items Options

Menu overview

2. Menu overview and basic setup

Copy Setup Change Default Scan Size

Copies

Copy Collation

Reduce/Enlarge

Duplex1

Darkness

Contrast

Original Type

Adjust Bkgd

Print Setup Orientation Portrait

Landscape

Duplex1Off

1 -> 2 Side Long

1 -> 2 SideShort

Copies [1-999]:1

Resolution 600dpi-Normal

1200dpi-Best

Darkness Normal

Light

Dark

Items Options

Print Setup Clear Text Off

Minimum

Medium

Maximum

Auto CR LF

LF+CR

Emulation Emulation Type

Setup

Items Options

Menu overview

2. Menu overview and basic setup

System Setup Machine Setup Machine ID

Date & Time

Clock Mode

Language

Power Save

Wakeup Event

System Timeout

Job Timeout

Altitude Adj.

Auto Continue2

Paper Mismatch

Paper Substit2

Print Blank Page

Toner Save

Eco Settings

Paper Setup Paper Size

Paper Type

Paper Source

Margin

Items Options

System Setup Report All Report

Configuration

Supplies Info.

Scheduled Jobs

Network Conf.

Usage Counter

Maintenance CLR Empty Msg3

Supplies Life

Serial Number

Toner Low Alert

System Setup Clear Setting All Settings

Print Setup

Copy Setup

System Setup

Network Setup

Items Options

Menu overview

2. Menu overview and basic setup

Network TCP/IP (IPv4) DHCP

BOOTP

Static

TCP/IP (IPv6) IPv6 Activate

DHCPv6 Config

Ethernet Speed Automatic

10Mbps Half

10Mbps Full

100Mbps Half

100Mbps Full

Network Clear Setting

Network Conf.

1. Not supported SCX-472xFN Series.

2. This option only appears if “paper mismatch” is enabled.

3. This option only appears when small amount of toner is left in the cartridge.

Items Options

2. Menu overview and basic setup

Changing the display language

To change the language that is displayed on the control panel, follow these

steps:

1Select (Menu) > System Setup > Machine Setup > Language on

the control panel.

It may be necessary to press OK to navigate to lower-level menus for some

models.

2 Select the language you want to display on the control panel.

3 Press OK to save the selection.

2. Menu overview and basic setup

Media and tray

This chapter provides information on how to load print media into your

machine.

• Using print media that does not meet these specifications may cause

problems or require repairs. Such repairs are not covered by Samsung’s

warranty or service agreements.

• Make sure not to use the inkjet photo paper with this machine. It could

cause damage to the machine.

• Using inflammable print media can cause a fire.

• Use designated print media (see "Print media specifications" on page

103).

The use of inflammable media or foreign materials left in the printer may

lead to overheating of the unit and, in rare cases may cause a fire.

Tray overview

To change the size, you need to adjust the paper guides.

If you do not adjust the guide, it may cause paper registration, image skew,

or jamming of the paper.

1Tray extension guide

2Paper length guide

3Paper width guide

Media and tray

2. Menu overview and basic setup

The paper quantity indicator shows the amount of paper in the tray.

1 Full

2 Empty

Paper type available for duplex printing (Not

supported SCX-472xFN Series)

Depending on the power voltage your machine uses, available paper types for

duplex printing differs. Refer to the below table.

Power voltage Available paper

110V Letter, Legal, US Folio, Oficio

220V A4

Media and tray

2. Menu overview and basic setup

Loading paper in the tray

When printing using the tray, do not load paper on the manual feeder, it may cause a paper jam.

Media and tray

2. Menu overview and basic setup

Loading in manual feeder

The manual feeder can hold special sizes and types of print material, such as postcards, note cards, and envelopes (see "Print media specifications" on page 103).

Tips on using the manual feeder

• Load only one type, size and weight of print media at time in the manual feeder.

• To prevent paper jams, do not add paper while printing when there is still paper in the manual feeder.

• Print media should be loaded face up with the top edge going into the manual feeder first and be placed in the center of the tray.

• To ensure printing quality and to prevent paper jams, only load the available paper (see "Print media specifications" on page 103).

• Flatten any curl on postcards, envelopes, and labels before loading them into the manual feeder.

• When printing on special media, you must follow the loading guidelines (see "Printing on special media" on page 44).

• When papers overlap when printing using the manual feeder, open tray and remove the papers then try printing again.

• When paper does not feed well while printing, push the paper in manually until it starts feeding automatically.

• When the machine is in a power save mode, the machine does not feed paper from the manual feeder. Wake up the machine by pressing the power button before

using the manual feeder.

Media and tray

2. Menu overview and basic setup

Printing on special media

The table below shows the special media usable in each tray.

The media is also shown in the Printing Preferences. To get the higest printing quality, select the proper media type from the Printing preferences window > Paper

tab > Paper Type (see "Opening printing preferences" on page 56).

For example, if you want to print on labels, select Labels for Paper Type.

Media and tray

2. Menu overview and basic setup

• When using special media, we recommend you feed one sheet at a time

(see "Print media specifications" on page 103).

•Printing the special media (Face up)

If special media are printed out with curl, wrinkles, crease, or black bold

lines, open the rear cover and try printing again. Keep the rear cover

opened during printing.

To see for paper weights for each sheet, refer to "Print media specifications" on

page 103. (̻: Included, Blank: Not available)

Envelope

Printing successfully on envelopes depends upon the quality of the envelopes.

Types Tray Manual feeder

Plain ƔƔ

Thick ƔƔ

Thicker Ɣ

Thin ƔƔ

Bond ƔƔ

Color Ɣ

CardStock ƔƔ

Labels Ɣ

Transparency Ɣ

Envelope Ɣ

Thick Envelope Ɣ

Preprinted Ɣ

Cotton Ɣ

Recycled ƔƔ

Archive ƔƔ

Types Tray Manual feeder

Media and tray

2. Menu overview and basic setup

To print an envelope, place it as shown in the following figure.

If envelopes are printed out with wrinkles, creases, or black bold lines, open the

rear cover and try printing again. Keep the rear cover opened during printing.

• When selecting envelopes, consider the following factors:

-Weight: should not exceed 90 g/m2 otherwise; jams may occur.

-Construction: should lie flat with less than 6 mm curl and should not

contain air.

-Condition: should not be wrinkled, nicked, nor damaged.

-Temperature: should resist the heat and pressure of the machine

during operation.

• Use only well-constructed envelopes with sharp and well-creased folds.

• Do not use stamped envelopes.

• Do not use envelopes with clasps, snaps, windows, coated lining, self-

adhesive seals, or other synthetic materials.

• Do not use damaged or poorly made envelopes.

• Be sure the seam at both ends of the envelope extends all the way to the

corner of the envelope.

1Acceptable

2Unacceptable

• Envelopes with a peel-off adhesive strip or with more than one flap that

folds over to seal must use adhesives compatible with the machine’s fusing

temperature for 0.1 second about 170°C (338 °F). The extra flaps and strips

might cause wrinkling, creasing, or jams, and may even damage the fuser.

• For the best print quality, position margins no closer than 15 mm from the

edges of the envelope.

• Avoid printing over the area where the envelope’s seams meet.

Media and tray

2. Menu overview and basic setup

Transparency

To avoid damaging the machine, use only transparencies designed for use in

laser printers.

• Must withstand the machine’s fusing temperature.

• Place them on a flat surface after removing them from the machine.

• Do not leave unused transparencies in the paper tray for long. Dust and dirt

may accumulate on them, resulting in spotty printing.

• To avoid smudging caused by fingerprints, handle them carefully.

• To avoid fading, do not expose printed transparencies to prolonged

sunlight.

• Ensure that transparencies are not wrinkled, curled, or have any torn edges.

• Do not use transparencies that separate from the backing sheet.

• To prevent transparencies from sticking to each other, do not let the printed

sheets stack up as they are being printed out.

• Recommended media: Transparency for a color laser printer by Xerox, such

as 3R 91331(A4), 3R 2780 (Letter)

Media and tray

2. Menu overview and basic setup

Labels

To avoid damaging the machine, use only labels designed for use in laser

printers.

• When selecting labels, consider the following factors:

-Adhesives: Should be stable at your machine’s fusing temperature.

Check your machine’s specifications to view the fusing temperature

(about 170°C (338°F)).

-Arrangement: Only use labels with no exposed backing between them.

Labels can peel off sheets that have spaces between the labels, causing

serious jams.

-Curl: Must lie flat with no more than 13 mm of curl in any direction.

-Condition: Do not use labels with wrinkles, bubbles, or other

indications of separation.

• Make sure that there is no exposed adhesive material between labels.

Exposed areas can cause labels to peel off during printing, which can cause

paper jams. Exposed adhesive can also cause damage to machine

components.

• Do not run a sheet of labels through the machine more than once. The

adhesive backing is designed for only a single pass through the machine.

• Do not use labels that are separating from the backing sheet or are wrinkled,

bubbled, or otherwise damaged.

Media and tray

2. Menu overview and basic setup

Card stock/ Custom-sized paper

• In the software application, set the margins to at least 6.4 mm (0.25 inches)

away from the edges of the material.

Preprinted paper

When loading preprinted paper, the printed side should be facing up with an

uncurled edge at the front. If you experience problems with paper feeding, turn

the paper around. Note that print quality is not guaranteed.

• Must be printed with heat-resistant ink that will not melt, vaporize, or

release hazardous emissions when subjected to the machine’s fusing

temperature for 0.1 second (about 170°C (338°F)).

• Preprinted paper ink must be non-flammable and should not adversely

affect machine rollers.

• Before you load preprinted paper, verify that the ink on the paper is dry.

During the fusing process, wet ink can come off preprinted paper, reducing

print quality.

Media and tray

2. Menu overview and basic setup

Setting the paper size and type

After loading paper in the paper tray, set the paper size and type using the

control panel buttons.

It may be necessary to press OK to navigate to lower-level menus for some

models.

1Select (Menu) > System Setup > Paper Setup > Paper Size or

Paper Type on the control panel.

2 Select the tray and the option you want.

3 Press OK to save the selection.

• The settings set from the machine driver override the settings on the

control panel.

a To print from an application, open an application and start the print

menu.

b Open Printing Preferences (see "Opening printing preferences" on

page 56).

c Press the Paper tab and select an appropriate paper.

• If you want to use special-sized paper such as billing paper, select the

Paper tab > Size > Edit... and set Custom Paper Size Settings in the

Printing Preferences (see "Opening printing preferences" on page 56).

Preparing originals

• Do not load paper smaller than 142 x 148 mm (5.6 x 5.8 inches) or larger than

216 x 356 mm (8.5 x 14 inches).

• Do not attempt to load the following s of paper, in order to prevent paper

jam, low print quality and machine damage.

- Carbon-paper or carbon-backed paper

- Coated paper

- Onion skin or thin paper

- Wrinkled or creased paper

- Curled or rolled paper

- Torn paper

• Remove all staples and paper clips before loading.

• Make sure any glue, ink, or correction fluid on the paper is completely dry

before loading.

• Do not load originals that include different sizes or weights of paper.

• Do not load booklets, pamphlets, transparencies, or documents with other

unusual characteristics.

Media and tray

2. Menu overview and basic setup

Loading originals

You can use the scanner glass or the document feeder to load an original for

copying, scanning, and sending a fax(SCX-472x Series only).

On the scanner glass

Using the scanner glass, you can copy or scan originals. You can get the best

scan quality, especially for colored or gray-scaled images. Make sure that no

originals are in the document feeder. If an original is detected in the document

feeder, the machine gives it priority over the original on the scanner glass.

1Lift and open the scanner lid.

2 Place the original face down on the scanner glass. Align it with the

registration guide at the top left corner of the glass.

3 Close the scanner lid.

• Leaving the scanner lid open while copying may affect copy quality and

toner consumption.

• Dust on the scanner glass may cause black spots on the printout. Always

keep it clean (see "Cleaning the machine" on page 78).

• If you are copying a page from a book or magazine, lift the scanner lid

until its hinges are caught by the stopper and then close the lid. If the

book or magazine is thicker than 30 mm, start copying with the scanner

lid open.

Media and tray

2. Menu overview and basic setup

• Be careful not to break the scanner glass. You may get hurt.

• Do not put hands while closing the scanner lid. The scanner lid may fall

on your hands and get hurt.

• Do not look the light from inside of the scanner while copying or

scanning. It is harmful to eyes.

In the document feeder

Using the document feeder, you can load up to 40 sheets of paper (75 g/m2, 20

lbs bond) for one job.

1Flex or fan the edge of the paper stack to separate the pages before

loading originals.

2 Load the original face up into the document feeder input tray. Make sure

that the bottom of the original stack matches the paper size marked on

the document input tray.

Media and tray

2. Menu overview and basic setup

3 Adjust the document feeder width guides to the paper size.

• Dust on the document feeder glass may cause black lines on the

printout. Always keep the glass clean (see "Cleaning the machine" on

page 78).

• To print on both sides of the paper using the ADF, from the control panel

press (Copy) > (Menu) > Copy Feature > Duplex > 1 -> 2 Side

Long or 1 -> 2 SideShort and print on one side of the paper, then reload

the sheet to print on the other side (Not supported SCX-472xFN Series).

2. Menu overview and basic setup

Basic printing

For special printing features, refer to the Advanced Guide (see "Using

advanced print features" on page 210).

Printing

If you are a Macintosh or Linux user, refer to the "Macintosh printing" on

page 218 or "Linux printing" on page 219.

The following Printing Preferences window is for Notepad in Windows 7.

1Open the document you want to print.

2 Select Print from the File menu.

3 Select your machine from the Select Printer list.

4 The basic print settings including the number of copies and print range

are selected within the Print window.

To take advantage of the advanced printing features, click Properties or

Preferences from the Print window (see "Opening printing preferences" on

page 56).

5 To start the print job, click OK or Print in the Print window.

Basic printing

2. Menu overview and basic setup

Canceling a print job

If the print job is waiting in the print queue or print spooler, cancel the job as

follows:

• You can access this window by simply double-clicking the machine icon

( ) in the Windows task bar.

• You can also cancel the current job by pressing (Stop/Clear) on the

control panel.

Basic printing

2. Menu overview and basic setup

Opening printing preferences

• The Printing Preferences window that appears in this user’s guide may

differ depending on the machine in use.

• When you select an option in Printing Preferences, you may see a

warning mark or . An mark means you can select that certain

option but it is not recommended, and an mark means you cannot

select that option due to the machine’s setting or environment.

1Open the document you want to print.

2 Select Print from the file menu. The Print window appears.

3 Select your machine from the Select Printer.

4 Click Properties or Preferences.

You can check the machine’s current status pressing the Printer Status

button (see "Using Samsung Printer Status" on page 258).

This illustration may differ from your machine depending on your model.

Using a favorite setting

The Presets option, which is visible on each preferences tab except for the

Samsung tab, allows you to save the current preferences for future use.

To save a Presets item, follow these steps:

Basic printing

2. Menu overview and basic setup

1Change the settings as needed on each tab.

2 Enter a name for the item in the Presets input box.

3 Click (Add). When you save Presets, all current driver settings are

saved.

Select more options and click (Update), settings will be added to the

Presets you made. To use a saved setting, select it from the Presets drop-

down list. The machine is now set to print according to the settings you

have selected.To delete saved settings, select it from the Presets drop-

down list and click (Delete).

You can also restore the printer driver’s default settings by selecting

Default Preset from the Presets drop-down list.

Using help

Click the option you want to know on the Printing Preferences window and

press F1 on your keyboard.

Eco printing

The Eco function reduces toner consumption and paper usage. The Eco

function allows you to save print resources and lead you to eco-friendly printing.

If you press the Eco button from the control panel, eco mode is enabled. The

default setting of Eco mode is Double-sided printing (Long Edge) (Not

supported SCX-472xFN Series) , Multiple Pages per Side (2), Skip blank pages,

and Toner Save.

Depending on the printer driver you use, Skip blank pages may not work

properly. If Skip blank pages feature does not work properly, set the

feature from the Easy Eco Driver (see "Easy Eco Driver" on page 251).

Basic printing

2. Menu overview and basic setup

Setting Eco mode on the control panel

• The settings set from the machine’s driver override the settings on the

control panel.

• Accessing menus may differ from model to model (see "Accessing the

menu" on page 30).

• It may be necessary to press OK to navigate to lower-level menus for

some models.

1Select (Menu) > System Setup > Machine Setup > Eco Settings on

the control panel.

2 Select the option you want and press OK.

•Default Mode: Select this to turn on or off the eco mode. (Duplex

(long edge)(Not supported SCX-472xFN Series)/Toner save/2-up/

Skip blank pages)

-Off: Set the eco mode off.

-On: Set the eco mode on.

If you set the eco mode on with a password from the SyncThru™ Web

Service (Settings tab > Machine Settings > System > Eco > Settings), the

On force message appears. You have to enter the password to change the

eco mode status.

•Change Template: Follow the settings from Syncthru™ Web Service.

Before you select this item, you must set the eco function in

SyncThru™ Web Service> Settings tab > Machine Settings >

System > Eco > Settings.

3 Press OK to save the selection.

Setting eco mode on the driver

Open the Eco tab to set Eco mode. When you see the eco image ( ), that

means the eco mode is currently enabled.

Eco options

•Printer Default: Follows the settings from the machine's control panel.

•None: Disables Eco mode.

•Eco Printing: Enables eco mode. Activate the various Eco items you want to

use.

•Password: If the administrator has enabled Eco mode, you have toenter the

password to change the status.

Basic printing

2. Menu overview and basic setup

Result simulator

Result Simulator shows the results of reduced emission of carbon dioxide, used

electricity, and the amount of saved paper in accordance with the settings you

selected.

• The results are calculated on the basis that the total number of printed

paper is one hundred without a blank page when the Eco mode is disabled.

• Refers to the calculation coefficient about CO2, energy, and paper from IEA,

the index of Ministry of Internal Affairs and Communication of Japan and

www.remanufacturing.org.uk. Each model has a different index.

• The power consumption in printing mode refers to the average printing

power consupmtion of this machine.

• The actual saved or reduced amount may differ depending on the operating

system used, computing performance, application software, connection

method, media, media size, job complexity, etc.

2. Menu overview and basic setup

Basic copying

For special printing features, refer to the Advanced Guide (see "Copy menu"

on page 173).

Basic copy

1Select (copy) on the control panel.

2 Place a single document face down on the document glass, or load the

documents face up into the document feeder (see "Loading originals" on

page 51).

3 If you want to customize the copy settings including Reduce/Enlarge,

Darkness, Contrast, Original, and more by using the control panel

buttons (see "Changing the settings for each copy" on page 60).

4 Enter the number of copies using the arrow or number keypad, if

necessary.

5 Press (Start).

If you need to cancel the copying job during the operation, press (Stop/

Clear) and the copying will stop.

Changing the settings for each copy

Your machine provides default settings for copying so that you can quickly and

easily make a copy. However, if you want to change the options for each copy,

use the copy function buttons on the control panel.

• If you press (Stop/Clear) while setting the copy options, all of the

options you have set for the current copy job will be canceled and

returned to their default status. Or, they will automatically return to their

default status after the machine completes the copy in progress.

• Accessing menus may differ from model to model (see "Accessing the

menu" on page 30).

• It may be necessary to press OK to navigate to lower-level menus for

some models.

Darkness

If you have an original containing faint marking and dark images, you can adjust

the brightness to make a copy that is easier to read.

Basic copying

2. Menu overview and basic setup

1Select (copy) > (Menu) > Copy Feature > Darkness on the

control panel.

Or select Darkness button on the control panel.

2 Select the option you want and press OK.

For example, the Light+5 being the lightest, and the Dark+5 being the

darkest.

3 Press (Stop/Clear) to return to ready mode.

Contrast

The Contrast menu lets you increase or decrease the difference between the

bright and dark areas of an image.

1Select (copy) > (Menu) > Copy Feature > Contrast on the

control panel.

2 Select the option you want and press OK.Select Dark to heighten the

contrast and select Light to reduce it.

3 Press (Stop/Clear) to return to ready mode.

Original

The original setting is used to improve the copy quality by selecting the

document for the current copy job.

1Select (copy) > (Menu) > Copy Feature > Original type on the

control panel.

2 Select the option you want and press OK.

•Text: Use for originals containing mostly text.

•Text/Photo: Use for originals with mixed text and photographs.

If texts in the printout is blurry, select Text to get the clear texts.

•Photo: Use when the originals are photographs.

3 Press (Stop/Clear) to return to ready mode.

Reduced or enlarged copy

You can reduce or enlarge the size of a copied image from 25% to 400% when

you copy original documents from the scanner glass.

• This feature may not be available depending on model or optionalgoods

(see "Variety feature" on page 8).

• If the machine set to Eco mode, reduce and enlarge features are

notavailable.

Basic copying

2. Menu overview and basic setup

To select from the predefined copy sizes

1Select (copy) > (Menu) > Copy Feature > Reduce/Enlarge on

the control panel.

2 Select the option you want and press OK.

3 Press (Stop/Clear) to return to ready mode.

To scale the copy by directly entering the scale rate

1Select (copy) > (Menu) > Copy Feature > Reduce/Enlarge >

Custom on the control panel.

2 Enter the copy size you want using the numeric keypad.

3 Press OK to save the selection.

4 Press (Stop/Clear) to return to ready mode.

When you make a reduced copy, black lines may appear at the bottom of

your copy.

ID card copying

Your machine can print 2-sided originals on one sheet.

The machine prints one side of the original on the upper half of the paper and

the other side on the lower half without reducing the size of the original. This

feature is helpful for copying a small-sized item such as business card.

• The original must be placed on the scanner glass to use this feature.

• If the machine set to Eco mode, this feature is not available.

• For better image quality, Select (copy) > (Menu) > Copy

Feature > Original Type > Photo on the control panel.

1Press ID Copy on the control panel.

2 Place the front side of an original facing down on the scanner glass

where arrows indicate as shown. Then, close the scanner lid.

3 Place Front Side and Press [Start] appears on the display.

Basic copying

2. Menu overview and basic setup

4 Press Start.

Your machine begins scanning the front side and shows Place Back Side

and Press [Start].

5 Turn the original over and place it on the scanner glass where arrows

indicate as shown. Then, close the scanner lid.

6 Press Start.

• If you do not press the (Start) button, only the front side will be

copied.

• If the original is larger than the printable area, some portions may not be

printed.

2. Menu overview and basic setup

Basic scanning

For special scanning features, refer to the Advanced Guide (see "Scan

features" on page 224).

Basic Scanning

This is the normal and usual procedure for scanning originals.

This is a basic scanning method for USB-connected machine.

• It may be necessary to press OK to navigate to lower-level menus for

some models.

• if you want to scan using the network, refer to the Advanced Guide (see

"Scanning from network connected machine" on page 232).

1Place a single document face down on the document glass, or load the

documents face up into the document feeder (see "Loading originals" on

page 51).

2 Select (scan) > Scan to PC > Local PC on the control panel.

If you see Not Available message, check the port connection, or select

Enable Scan from Device Panel in Samsung Easy Printer Manager >

Switch to advanced mode > Scan to PC Settings.

3 Select the application program you want and press OK.

Default setting is My Documents.

You can add or delete the folder where the scanned file is saved in Samsung

Easy Printer Manager > Switch to advanced mode. > Scan to PC

Settings.

4 Select the option you want and press OK.

5 Scanning begins.

Scanned image is saved in computer’s C:\Users\users

name\MyDocuments. The saved folder may differ, depending on your

operatingsystem or the application you are using.

2. Menu overview and basic setup

Basic faxing

• This function is not supported for SCX-470X Series (see"Control panel

overview" on page 23).

• For special faxing features, refer to the Advanced Guide (See "Fax

features" on page 235).

• You cannot use this machine as a fax via the internet phone. For more

information ask your internet service provider.

• We recommend using traditional analog phone services (PSTN: Public

Switched Telephone Network) when connecting telephone lines to use

a fax machine. If you use other Internet services (DSL, ISDN, VolP), you can

improve the connection quality by using the Micro-filter. The Micro-filter

eliminates unnecessary noise signals and improves connection quality or

Internet quality. Since the DSL Micro-filter is not provided with the

machine, contact your Internet service provider for use on DSL Micro-

filter.

1Line port

2Micro filter

3DSL modem / Telephone line

(see "Rear view" on page 22).

•SCX-470x Series does not support the fax features.

Preparing to fax

SCX-470x Series does not support the fax features.

Before you send or receive a fax, you need to connect the supplied line cord to

your telephone wall jack (see "Rear view" on page 22). Refer to the Quick

Installation Guide how to make a connection. The method of making a

telephone connection is different from one country to another.

Sending a fax

• When you place the originals, you can use either the document feeder or

the scanner glass. If the originals are placed on both the document

feeder and the scanner glass, the machine will read the originals on the

document feeder first, which has higher priority in scanning.

•SCX-470x Series does not support the fax features.

1Place a single document face down on the document glass, or load the

documents face up into the document feeder (see "Loading originals" on

page 51).

2 Select (fax) on the control panel.

Basic faxing

2. Menu overview and basic setup

3 Adjust the resolution and the darkness to suit your fax needs (see

"Adjusting the document settings" on page 67).

4 Enter the destination fax number.

5 Press (Start) on the control panel. The machine starts to scan and

send the fax to the destinations.

• If you want to send a fax directly from your computer, use Samsung

Network PC Fax (see "Sending a fax in the computer" on page 236).

• When you want to cancel a fax job, press (Stop/Clear) before the

machine starts transmission.

• If you used the scanner glass, the machine shows the message asking to

place another page.

Sending a fax manually

Perform the following to send a fax using (On Hook Dial) on the control

panel. If your machine is a handset model, you can send a fax using the handset

(see "Features by models" on page 5).

1Place a single document face down on the document glass, or load the

documents face up into the document feeder (see "Loading originals" on

page 51).

2 Select (fax) on the control panel.

3 Adjust the resolution and the darkness to suit your fax needs (see

"Adjusting the document settings" on page 67).

4 Press On Hook Dial on the control panel or lift the handset.

5 Enter a fax number using the number keypad on the control panel.

6 Press (Start) on the control panel when you hear a high-pitched fax

signal from the remote fax machine.

Sending a fax to multiple destinations

You can use the multiple send feature, which allows you to send a fax to multiple

locations. Originals are automatically stored in memory and sent to a remote

station. After transmission, the originals are automatically erased from memory

(see "Features by models" on page 5).

You cannot send faxes with this feature if you chosen super fine as an option

or if the fax is in color.

1Place a single document face down on the document glass, or load the

documents face up into the document feeder (see "Loading originals" on

page 51).

2 Select (fax) on the control panel.

Basic faxing

2. Menu overview and basic setup

3 Adjust the resolution and the darkness to suit your fax needs (see

"Adjusting the document settings" on page 67).

4 Select (Menu) > Fax Feature > Multi Send on the control panel.

5 Enter the number of the first receiving fax machine and press OK.

You can press speed dial numbers or select a group dial number using

the (Address book) button (see Advanced Guide).

6 Enter the second fax number and press OK.

The display asks you to enter another fax number to send the document.

7 To enter more fax numbers, press OK when Yes appears and repeat

steps 5 and 6. You can add up to 10 destinations.

Once you have entered a group dial number, you cannot enter another

group dial number.

8 When you have finished entering fax numbers, select No at the Another

No.? prompt and press OK.

The machine begins sending the fax to the numbers you entered in the

order in which you entered them.

Receiving a fax

SCX-470x Series does not support the fax features.

Your machine is preset Fax mode at the factory. When you receive a fax, the

machine answers the call on a specified number of rings and automatically

receives the fax.

Adjusting the document settings

SCX-470x Series does not support the fax features.

Before starting a fax, change the following settings according to your original’s

status to get the best quality.

It may be necessary to press OK to navigate to lower-level menus for some

models.

Basic faxing

2. Menu overview and basic setup

Resolution

The default document settings produce good results when using typical text-

based originals. However, if you send originals that are of poor quality, or

contain photographs, you can adjust the resolution to produce a higher quality

fax.

1Select (fax) > (Menu) > Fax Feature > Resolution on the control

panel.

2 Select the option you want and press OK.

•Standard: Originals with normal sized characters.

•Fine: Originals containing small characters or thin lines or originals

printed using a dot-matrix printer.

•Super Fine: Originals containing extremely fine detail. Super Fine

mode is enabled only if the machine with which you are

communicating also supports the Super Fine resolution.

• For memory transmission, Super Fine mode is not available. The

resolution setting is automatically changed to Fine.

• When your machine is set to Super Fine resolution and the fax machine

with which you are communicating does not support Super Fine

resolution, the machine transmits using the highest resolution mode

supported by the other fax machine.

•Photo Fax: Originals containing shades of gray or photographs.

•Color Fax: Original with colors.

• Memory transmission is not available in this mode.

• You can only send a color fax if the machine you are communicating with

supports color fax reception and you send the fax manually.

3 Press (Stop/Clear) to return to ready mode.

Darkness

You can select the degree of darkness of the original document.

The darkness setting is applied to the current fax job. To change the default

setting (see "Fax menu" on page 180).

1Select (fax) > (Menu) > Fax Feature > Darkness on the control

panel.

2 Select a darkness level you want.

3 Press (Stop/Clear) to return to ready mode.

3. Maintenance

This chapter provides information about purchasing supplies, accessories and maintenance parts available for your

machine.

• Ordering supplies and accessories 70

• Available supplies 71

• Available maintenance parts 72

• Redistributing toner 73

• Replacing the toner cartridge 74

• Monitoring the supplies life 76

• Setting the toner low alert 77

• Cleaning the machine 78

3. Maintenance

Ordering supplies and accessories

Available accessories may differ from country to country. Contact your sales representatives to obtain the list of available supplies, and maintenance parts.

To order Samsung-authorized supplies, accessories, and maintenance parts, contact your local Samsung dealer or the retailer where you purchased your machine.

You can also visit www.samsung.com/supplies, and then select your country/region to obtain the contact information for service.

3. Maintenance

Available supplies

When supplies reach the end of their life spans, you can order the following s of supplies for your machine:

Depending on the options, percentage of image area and job mode used, the toner cartridge’s lifespan may differ.

When purchasing new toner cartridges or other supplies, these must be purchased in the same country as the machine you are using. Otherwise, new toner

cartridges or other supplies will be incompatible with your machine due to different configurations of toner cartridges and other supplies according to the specific

country conditions.

Samsung does not recommend using non-genuine Samsung toner cartridge such as refilled or remanufactured toner. Samsung cannot guarantee non-genuine

Samsung toner cartridge's quality. Service or repair required as a result of using non-genuine Samsung toner cartridges will not be covered under the machine’s

warranty.

Type Average yield1

1. Declared yield value in accordance with ISO/IEC 19752.

Part name

Standard yield toner cartridge Approx. 1,500 pages MLT-D103S

High yield toner cartridge Approx. 2,500 pages MLT-D103L

3. Maintenance

Available maintenance parts

To purchase maintenance parts, contact the source where you bought the machine. Replacing maintenance parts can be performed only by an authorized service

provider, dealer, or the retailer where you bought the machine. The warranty does not cover the replacement of any maintenance parts once it has reached its

“Average yield”.

Maintenance parts are replaced at specific intervals to avoid print quality and paper feed problems resulting from worn parts, see table below. The purpose of which

is to maintain your machine in top working condition. The maintenance parts below should be replaced when the life span of each item has been met.

Parts Average yield1

1. It will be affected by the operating system used, computing performance, application software, connecting method, media, media size and job complexity.

Document feeder rubber pad Approx. 20,000 pages

Transfer roller Approx. 100,000 pages

Fuser unit Approx. 50,000 pages

Pickup roller Approx. 50,000 pages

Retard roller Approx. 50,000 pages

Forward Roller Approx. 50,000 pages

Feed Roller Approx. 50,000 pages

3. Maintenance

Redistributing toner

When the toner cartridge is near the end of its life:

• White streaks or light printing occurs and/or density variation side to side.

• The Status LED blinks red.

If this happens, you can temporarily improve print quality by redistributing the remaining toner in the cartridge. In some cases, white streaks or light printing will still

occur even after you have redistributed the toner.

If toner gets on your clothing, wipe it off with a dry cloth and wash clothing in cold water: hot water sets toner into fabric.

Do not touch the green underside of the toner cartridge. Use the handle on the cartridge to avoid touching this area.

3. Maintenance

Replacing the toner cartridge

Click this link to open an animation about solving power problems.

• Do not use sharp objects such as a knife or scissors to open the toner cartridge package. They might scratch the drum of the cartridge.

• If toner gets on your clothing, wipe it off with a dry cloth and wash clothing in cold water. Hot water sets toner into fabric.

• Shake the toner cartridge thorougly, it will increase the initial print quality.

• Do not touch the green underside of the toner cartridge. Use the handle on the cartridge to avoid touching this area.

Replacing the toner cartridge

3. Maintenance

When a toner cartridge has reached the end of life, the machine will stop printing.

3. Maintenance

Monitoring the supplies life

If you experience frequent paper jams or printing problems, check the number of pages the machine has printed or scanned. Replace the corresponding parts, if

necessary.

It may be necessary to press OK to navigate to lower-level menus for some models.

1Select (Menu) > System Setup > Maintenance > Supplies Life on the control panel.

2 Select the option you want and press OK.

•Supplies Info: Prints the supply information page.

•Total: Displays the total number of pages printed.

•ADF Scan: Displays the number of pages printed by using the document feeder.

•Platen Scan: Displays the number of pages scanned by using scanner glass.

3 Press (Stop/Clear) to return to ready mode.

3. Maintenance

Setting the toner low alert

If the amount of toner in the cartridge is low, a message or LED informing the user to change the toner cartridge appears. You can set the option for whether or not

this message or LED appears.

1Select (Menu) > System Setup > Maintenance > Toner Low Alert on the control panel.

2 Select the option you want.

3 Press OK to save the selection.

3. Maintenance

Cleaning the machine

If printing quality problems occur or if you use your machine in a dusty environment, you need to clean your machine regularly to keep it in the best printing

condition and use your machine longer.

• Cleaning the cabinet of the machine with cleaning materials containing large amounts of alcohol, solvents, or other strong substances can discolor or distort the

cabinet.

• If your machine or the surrounding area is contaminated with toner, we recommend you use a cloth or tissue dampened with water to clean it. If you use a vacuum

cleaner, toner blows in the air and might be harmful to you.

• During the printing process, paper, toner, and dust particles can accumulate inside the machine. This buildup can cause print quality problems, such as toner

specks or smearing. Cleaning the inside of the machine clears and reduces these problems.

Cleaning the outside

Clean the machine cabinet with a soft, lint-free cloth. Dampen the cloth slightly with water, but be careful not to let any water drip onto or into the machine.

Cleaning the machine

3. Maintenance

Cleaning the inside

• Use a dry lint-free cloth to clean the machine.

• If your machine has a power switch, turn the power switch off before cleaning the machine.

• Before opening the front cover, close the output support first.

Cleaning the machine

3. Maintenance

Cleaning the pickup roller

• Before opening the front cover, close the output support first.

• If your machine has a power switch, turn the power switch before cleaning the machine.

Cleaning the machine

3. Maintenance

Cleaning the machine

3. Maintenance

Cleaning the scan unit

Keeping the scan unit clean helps ensure the best possible copies. We suggest

that you clean the scan unit at the start of each day and during the day as

needed.

1Slightly dampen a soft, lint-free cloth or paper towel with water.

2 Lift and open the scanner lid.

3 Wipe the surface of the scanner glass until it is clean and dry.

4 Wipe the underside of the scanner lid and white sheet until it is clean and

dry.

5 Close the scanner lid.

1Scanner lid

2Scanner glass

3Document feeder glass

4White bar

4. Troubleshooting

This chapter gives helpful information for what to do if you encounter an error.

• Tips for avoiding paper jams 84

• Clearing original document jams 85

• Clearing paper jams 89

• Understanding the status LED 94

• Understanding display messages 96

This chapter gives helpful information for what to do if you encounter an error. If your machine

has a display screen, check the message on the display screen first to solve the error.If you

cannot find a solution to your problem in this chapter, refer to the Troubleshooting chapter in

the Advanced User's Guide.If you cannot find a solution in the User's Guide or the problem

persists, call for service.

4. Troubleshooting

Tips for avoiding paper jams

By selecting the correct medias, most paper jams can be avoided. To avoid paper jams, refer to the following guidelines:

• Ensure that the adjustable guides are positioned correctly (see "Tray overview" on page 40).

• Do not overload the tray. Ensure that the paper level is below the paper capacity mark on the inside of the tray.

• Do not remove paper from the tray while your machine is printing.

• Flex, fan, and straighten paper before loading.

• Do not use creased, damp, or highly curled paper.

• Do not mix paper s in a tray.

• Use only recommended print media (see "Print media specifications" on page 103).

4. Troubleshooting

Clearing original document jams

When an original document jams in the document feeder, a warning message appears on the display.

To avoid tearing the document, remove the jammed document slowly and carefully.

To prevent document jams, use the scanner glass for thick, thin or mixed paper- originals.

Clearing original document jams

4. Troubleshooting

Original paper jam in front of scanner

Clearing original document jams

4. Troubleshooting

Original paper jam inside of scanner

Clearing original document jams

4. Troubleshooting

Original paper jam in exit area of scanner

1Remove any remaining pages from the document feeder.

2 Gently remove the jammed paper from the document feeder.

4. Troubleshooting

Clearing paper jams

To avoid tearing the paper, pull the jammed paper out slowly and gently.

In tray

Click this link to open an animation about solving power problems.

Clearing paper jams

4. Troubleshooting

In the manual tray

Click this link to open an animation about solving power problems.

Clearing paper jams

4. Troubleshooting

Inside the machine

Click this link to open an animation about solving power problems.

The fuser area is hot. Take care when removing paper from the machine.

Clearing paper jams

4. Troubleshooting

In the exit area

Click this link to open an animation about solving power problems.

Clearing paper jams

4. Troubleshooting

In the duplex unit area

Click this link to open an animation about solving power problems.

4. Troubleshooting

Understanding the status LED

The color of the LED indicates the machine's current status.

• Some LEDs may not be available depending on model or country.

• To resolve the error, look at the error message and its instructions from the troubleshooting part.

• You also can resolve the error with the guideline from the computers’s Printing Status or Smart Panel program window.

• If the problem persists, call a service representative.

Status Description

Status LED Off The machine is off-line.

Green Blinking When the backlight blinks, the machine is receiving or printing data.

On • The machine is on-line and can be used.

Red Blinking • A minor error has occurred and the machine is waiting for the error to be cleared. Check the display message. When

the problem is cleared, the machine resumes. For some models that does not support the display screen on the

control panel, this feature is not applicable.

• Small amount of toner is left in the cartridge. The estimated cartridge life of toner is close. Prepare a new cartridge for

replacement. You may temporarily increase the printing quality by redistributing the toner (see "Redistributing toner"

on page 73).

On • A toner cartridge has almost reached its estimated cartridge life1. It is recommended to replace the toner cartridge

(see "Replacing the toner cartridge" on page 74).

• The cover is opened. Close the cover.

• There is no paper in the tray. Load paper in the tray.

• The machine has stopped due to a major error. Check the display message (see "Understanding display messages" on

page 96).

Understanding the status LED

4. Troubleshooting

WPS LED2Blue On When the machine is connected to a wireless network, WPS LED lights on blue.

Power/

Wakeup LED

Blue On The machine is in power save mode.

Off The machine is in ready mode or machine’s power is off.

Eco button Green On Eco mode is on. Duplex3, 2-up, toner save on, skip blank page feature will automatically be applied when printing

(see"Eco printing" on page 57).

Off Eco mode is off.

1. Estimated cartridge life means the expected or estimated toner cartridge life, which indicates the average capacity of print-outs and is designed pursuant to ISO/IEC 19752. The number of pages

may be affected by operating environment, percentage of image area, printing interval, graphics, media and media size. Some amount of toner may remain in the cartridge even when red LED is

on and the printer stops printing.

2. SCX-472x Series only.

3. Not supported SCX-472xFN Series.

Status Description

4. Troubleshooting

Understanding display messages

Messages appear on the control panel display to indicate the machine’s status

or errors. Refer to the tables below to understand the messages’ and their

meaning, and correct the problem, if necessary.

• If a message is not in the table, reboot the power and try the printing job

again. If the problem persists, call a service representative.

• When you call for service, provide the service representative with the

contents of display message.

• Some messages may not appear on the display depending on the

options or models.

• [error number] indicates the error number.

• [tray type] indicates the tray number.

Paper Jam-related messages

Message Meaning Suggested solutions

•Document jam

Remove jam

The loaded original

document has

jammed in the

document feeder.

Clear the jam (see

"Clearing original

document jams" on

page 85).

•Paper Jam

in tray

Paper has jammed in

the paper feed area.

Clear the jam (see "In

tray" on page 89).

•Paper Jam

in Manual Feeder

Paper has jammed in

the manual feeder.

Clear the jam (see "In the

manual tray" on page

90).

•Paper Jam

inside machine

Paper has jammed in

the inside machine.

Clear the jam (see "Inside

the machine" on page

91).

•Paper Jam

in exit area

Paper has jammed in

the paper exit area.

Clear the jam (see "In the

exit area" on page 92).

•Paper Jam

bottom of duplex

•Paper Jam top of duplex

Paper has jammed in

the duplex area.

Clear the jam (see "In the

duplex unit area" on

page 93).

Message Meaning Suggested solutions

Understanding display messages

4. Troubleshooting

Toner-related messages

Message Meaning Suggested solutions

•Install Toner Cartridge A toner cartridge is not installed. Install a toner cartridge.

•Not Compatible

Toner cartridge

The toner cartridge you have installed is not for your machine. Install a Samsung-genuine toner cartridge, designed for your

machine.

•Prepare new cartridge Small amount of toner is left in the indicated cartridge. The

estimated cartridge life of toner is close.

Prepare a new cartridge for a replacement. You may temporarily

increase the printing quality by redistributing the toner (see

"Redistributing toner" on page 73).

Understanding display messages

4. Troubleshooting

•Replace new cartridge

•Toner Exhausted

A toner cartridge has reached its estimated cartridge life. The

machine stops printing.

Estimated cartridge life means the expected or

estimated toner cartridge life, which indicates the

average capacity of print-outs and is designed pursuant

to ISO/IEC 19752 (see "Available supplies" on page 71).

The number of pages may be affected by operating

environment, percentage of image area, printing

interval, media, percentage of image area, and media

size. Some amount of toner may remain in the cartridge

even when replace new cartridge appears and the

machine stops printing.

• You can choose Stop or Continue as shown on the control panel.

If you select Stop, the printer stops printing and you cannot print

any more without changing the cartridge. If you select Continue,

the printer keeps printing but the printing quality cannot be

guaranteed.

• Replace the toner cartridge for the best print quality when this

message appears. Using a cartridge beyond this stage can result in

printing quality issues (see "Replacing the toner cartridge" on

page 74).

Samsung does not recommend using a non-genuine

Samsung toner cartridge such as refilled or remanufactured.

Samsung cannot guarantee a non-genuine Samsung toner

cartridge's quality. Service or repair required as a result of

using non-genuine Samsung toner cartridges will not be

covered under the machine warranty.

• If the machine stops printing, replace the toner cartridge (see

"Replacing the toner cartridge" on page 74).

Message Meaning Suggested solutions

Understanding display messages

4. Troubleshooting

Tray-related messages

Network-related messages

Misc. messages

Message Meaning Suggested solutions

•Output bin full

Remove paper

The output tray is full. Remove papers from the

output tray, the printer

resumes printing.

•Paper Empty

in [tray type]

There is no paper in tray

or manual feeder.

Load paper in tray (see

"Loading paper in the tray"

on page 42, "Loading

paper in the tray" on page

42).

•Tray Paper

mismatch

•Manual Paper

mismatch

The paper size specified

in the printer properties

does not match the

paper you are loading.

Load the required size

paper.

Message Meaning Suggested solutions

•Network Problem:

IP Conflict

The network IP address

you have set is being

used by someone else.

Check the IP address and

reset it if necessary (see

Advanced Guide).

•Wireless

Network Error

Wireless module is not

installed.

Call for service.

Message Meaning Suggested solutions

•Door of scanner is

open

The document feeder

cover is not securely

latched.

Close the cover until it

locks into place.

•Error [error

number]

Turn off then on

The machine unit cannot

be controlled.

Reboot the power and try

the printing job again. If

the problem persists,

please call for service.

•Memory Full

Remove Job

The memory is full. Print or remove the

received fax job in Secure

Receive (see Advanced

Guide).

•Scanner Locked The scanner is locked. Reboot the power. If the

problem persists, please

call for service.

Message Meaning Suggested solutions

5. Appendix

This chapter provides product specifications and information concerning applicable regulations.

• Specifications 101

• Regulatory information 111

• Copyright 124

101

5. Appendix

Specifications

General specifications

The specification values listed below are subject to change without notice. See www.samsung.com for possible changes in information.

Items Description

Dimension1Width x Length x Height 406 x 338 x 384mm (15.98 x 13.30 x 15.12 inches)

Weight1Machine with consumables 10.98 Kg

Noise Level2Ready mode 26 dB (A)

Print mode Less than 50 dB (A)

Copy mode Less than 53 dB (A)

Scan mode (scanner glass) 52 dB (A)

Scan mode (document feeder) 53 dB (A)

Temperature Operation 10 to 32°C (50 to 89.6°F)

Storage (packed) -20 to 40°C (-4 to 104°F)

Humidity Operation 20 to 80% RH

Storage (packed) 10 to 90% RH

Power rating3110 volt models AC 110 - 127 V

220 volt models AC 220 - 240 V

Specifications

102

5. Appendix

Power consumption Average operating mode Less than 400W

Ready mode Less than 55 W

Power save mode Less than 3.0 W

Power off mode Less than 0.2 W (0.1 W4)

Wireless5Module T77H262

1. Dimensions and weight are measured without a handset.

2. Sound Pressure Level, ISO 7779. Configuration tested: basic machine installation, A4 paper, simplex printing.

3. See the rating label on the machine for the correct voltage (V), frequency (hertz) and of current (A) for your machine.

4. For the machine that has a power switch.

5. Wireless models only (see "Features by models" on page 5).

Items Description

Specifications

103

5. Appendix

Print media specifications

Type Size Dimensions

Print media weight/Capacity1

Tray Manual feeder2

Plain paper

Letter 216 x 279 mm (8.5 x 11 inches) 60 to 163 g/m2 (16 to 43 lbs bond)

• 250 sheets of 80 g/m2 (21 lbs bond)

60 to 220 g/m2 (16 to 59 lbs bond)

• 1 sheet of 80 g/m2 (21 lbs bond)

Legal 216 x 356 mm (8.5 x 14 inches)

US Folio 216 x 330 mm (8.5 x 13 inches)

A4 210 x 297 mm (8.27 x 11.69 inches)

Oficio 216 x 343 mm (8.5 x 13.5 inches)

JIS B5 182 x 257 mm (7.17 x 10.12 inches)

ISO B5 176 x 250 mm (6.93 x 9.84 inches)

Executive 184 x 267 mm (7.25 x 10.5 inches)

A5 148 x 210 mm (5.83 x 8.27 inches)

A6 105 x 148 mm (4.13 x 5.83 inches)

Specifications

104

5. Appendix

Envelope

Monarch

98 x 191 mm (3.87 x 7.5 inches) Not available in tray 60 to 220 g/m2 (16 to 59 lbs bond)

Envelope No. 10 105 x 241 mm (4.12 x 9.5 inches)

Envelope DL 110 x 220 mm (4.33 x 8.66 inches)

Envelope C5 162 x 229 mm (6.38 x 9.02 inches)

Envelope C6 114 x 162 mm (4.49 x 6.38 inches)

Thick paper Refer to the Plain

paper section

Refer to the Plain paper section 91 to 105 g/m2 (24 to 28 lbs bond) 91 to 105 g/m2 (24 to 28 lbs bond)

Thicker paper Refer to the Plain

paper section

Refer to the Plain paper section Not available in tray 164 to 220 g/m2 (44 to 59 lbs

bond)

Thin paper Refer to the Plain

paper section

Refer to the Plain paper section 60 to 70 g/m2 (16 to 19 lbs bond) 60 to 70 g/m2 (16 to 19 lbs bond)

Transparency Letter, A4 Refer to the Plain paper section Not available in tray 138 to 146 g/m2 (37 to 39 lbs

bond)

Labels3

Letter, Legal, US

Folio, A4, JIS B5,

ISO B5, Executive,

Refer to the Plain paper section Not available in tray 120 to 150 g/m2 (32 to 40 lbs

bond)

Type Size Dimensions

Print media weight/Capacity1

Tray Manual feeder2

Specifications

105

5. Appendix

Card stock

Letter, Legal, US

Folio, A4, JIS B5,

ISO B5, Executive,

A5,

Postcard 4x6

Refer to the Plain paper section 121 to 163 g/m2 (32 to 43 lbs bond) 121 to 163 g/m2 (32 to 43 lbs

bond)

Bond paper Refer to the Plain

paper section

Refer to the Plain paper section 106 to 120 g/m2 (28 to 32 lbs bond) 106 to 120 g/m2 (28 to 32 lbs

bond)

Minimum size (custom) •Manual feeder: 76 x 127 mm (3 x 5 inches)

•Tray: 105 x 148.5 mm (4.13 x 5.85 inches)

60 to 163 g/m2 (16 to 43 lbs bond) 4, 5

Maximum size (custom) 216 x 356 mm (8.5 x 14 inches)

1. Maximum capacity may differ depending on media weight, thickness, and environmental conditions.

2. 1 sheet for manual feeder.

3. The smoothness of the labels used in this machine is 100 to 250 (sheffield). This means the numeric level of smoothness.

4. The paper types available in the manual feeder: Plan, Thick, Thicker, Thin, Cotton, Colored, Pre-printed, Recycled, Envelope, Transparency, Labels, Cardstock, Bond, Archive

5. The paper types available in tray: Plan, Thick, Thin, Recycled, Cardstock, Bond, Archive

Type Size Dimensions

Print media weight/Capacity1

Tray Manual feeder2

Specifications

106

5. Appendix

System requirements

Microsoft® Windows®

Operating system

Requirement (recommended)

CPU RAM free HDD space

Windows® 2000 Intel® Pentium® II 400 MHz (Pentium III 933 MHz) 64 MB (128 MB) 600 MB

Windows® XP Intel® Pentium® III 933 MHz (Pentium IV 1 GHz) 128 MB (256 MB) 1.5 GB

Windows Server® 2003 Intel® Pentium® III 933 MHz (Pentium IV 1 GHz) 128 MB (512 MB) 1.25 GB to 2 GB

Windows Server® 2008 Intel® Pentium® IV 1 GHz (Pentium IV 2 GHz) 512 MB (2 GB) 10 GB

Windows Vista® Intel® Pentium® IV 3 GHz 512 MB (1 GB) 15 GB

Windows® 7 Intel® Pentium® IV 1 GHz 32-bit or 64-bit processor or higher 1 GB (2 GB) 16 GB

• Support for DirectX® 9 graphics with 128 MB memory (to enable the Aero theme).

•DVD-R/W Drive

Windows Server® 2008 R2 Intel® Pentium® IV 1 GHz (x86) or 1.4 GHz (x64) processors (2 GHz or faster) 512 MB (2 GB) 10 GB

Specifications

107

5. Appendix

• Internet Explorer 6.0 or higher is the minimum requirement for all Windows operating systems.

• Users who have administrator rights can install the software.

•Windows Terminal Services is compatible with your machine.

•For Windows 2000, Services Pack 4 or higher is required.

Macintosh

Operating system

Requirements (Recommended)

CPU RAM Free HDD space

Mac OS X 10.4 • Intel® processors

•PowerPC G4/G5

• 128 MB for a powerPC based Mac (512 MB)

• 512 MB for an Intel-based Mac (1 GB)

1 GB

Mac OS X 10.5 • Intel® processors

• 867 MHz or faster Power PC G4/G5

512 MB (1 GB) 1 GB

Mac OS X 10.6 • Intel® processors 1 GB (2 GB) 1 GB

Mac OS X 10.7 • Intel® processors 2 GB 4 GB

Specifications

108

5. Appendix

Linux

Unix

Items Requirements

Operating system Redhat® Enterprise Linux WS 4, 5 (32/64 bit)

Fedora 5 ~ 13 (32/64 bit)

SuSE Linux 10.1 (32 bit)

OpenSuSE® 10.2, 10.3, 11.0, 11.1, 11.2 (32/64 bit)

Mandriva 2007, 2008, 2009, 2009.1, 2010 (32/64 bit)

Ubuntu 6.06, 6.10, 7.04, 7.10, 8.04, 8.10, 9.04, 9.10, 10.04 (32/64 bit)

SuSE Linux Enterprise Desktop 10, 11 (32/64 bit)

Debian 4.0, 5.0 (32/64 bit)

CPU Pentium IV 2.4GHz (Intel Core™2)

RAM 512 MB (1 GB)

Free HDD space 1 GB (2 GB)

Items Requirements

Operating system Sun Solaris 9, 10 (x86, SPARC)

HP-UX 11.0, 11i v1, 11i v2, 11i v3 (PA-RISC, Itanium)

IBM AIX 5.1, 5.2, 5.3, 5.4

Specifications

109

5. Appendix

Network environment

Network and wireless models only (see "Features by models" on page 5).

You need to set up the network protocols on the machine to use it as your network machine. The following table shows the network environments supported by the

machine.

Free HDD space Up to 100 MB

Items Specifications

Network interface • Ethernet 10/100 Base-TX Wired Lan

• 802.11b/g/n Wireless LAN (SCX-472x Series only)

Network operating system • Windows 2000/Server 2003 /Server 2008/XP/Vista/7/Server 2008 R2

•Various Linux OS

• Mac OS X 10.4 ~ 10.7

• Unix

Items Requirements

Specifications

110

5. Appendix

Network protocols •TCP/IPv4

• DHCP, BOOTP

• DNS, WINS, Bonjour, SLP, UPnP

• Standard TCP/IP Printing (RAW), LPR, IPP, WSD

• SNMPv 1/2/3, HTTP, IPSec

• TCP/IPv6 (DHCP, DNS, RAW, LPR, SNMPv 1/2/3, HTTP, IPSec)

Wireless security • Authentication: Open System, Shared Key, WPA Personal, WPA2 Personal (PSK)

• Encryption: WEP64, WEP128, TKIP, AES

Items Specifications

111

5. Appendix

Regulatory information

This machine is designed for a normal work environment and certified with

several regulatory statements.

Laser safety statement

The printer is certified in the U.S. to conform to the requirements of DHHS 21

CFR, chapter 1 Subchapter J for Class I(1) laser products, and elsewhere is

certified as a Class I laser product conforming to the requirements of IEC 60825-

1 : 2007.

Class I laser products are not considered to be hazardous. The laser system and

printer are designed so there is never any human access to laser radiation above

a Class I level during normal operation, user maintenance or prescribed service

condition.

Warning

Never operate or service the printer with the protective cover removed from

laser/scanner assembly. The reflected beam, although invisible, can damage

your eyes.

When using this product, these basic safety precautions should always be

followed to reduce risk of fire, electric shock, and injury to persons:

Ozone safety

This product’s ozone emission rate is under 0.1 ppm. Because

ozone is heavier than air, keep the product in a place with good

ventilation.

Regulatory information

112

5. Appendix

Mercury Safety

Power saver

Recycling

China only

Contains Mercury, Dispose According to Local, State or Federal

Laws.(U.S.A. only)

This printer contains advanced energy conservation technology

that reduces power consumption when it is not in active use.

When the printer does not receive data for an extended period of

time, power consumption is automatically lowered.

ENERGY STAR and the ENERGY STAR mark are registered U.S.

marks.

For more information on the ENERGY STAR program see http://

www.energystar.gov

For ENERGY STAR certified models, the ENRGY STAR label will be

on your machine. Check if your machine is ENERGY STAR

certified.

Recycle or dispose of the packaging material for this product in an

environmentally responsible manner.

Regulatory information

113

5. Appendix

Correct disposal of this product (Waste electrical &

electronic equipment)

(Applicable in the european union and other

european countries with separate collection

systems)

(The United States of America only)

Dispose unwanted electronics through an approved recycler. To find the nearest

recycling location, go to our website: www.samsung.com/recyclingdirect Or

call, (877) 278 - 0799

Correct disposal of batteries in this product

(Applicable in the European Union and other

European countries with separate battery return

systems.)

This marking on the product, accessories or literature indicates that the

product and its electronic accessories (e.g. charger, headset, USB cable)

should not be disposed of with other household waste at the end of

their working life. To prevent possible harm to the environment or

human health from uncontrolled waste disposal, please separate these

items from other s of waste and recycle them responsibly to promote the

sustainable reuse of material resources.

Household users should contact either the retailer where they

purchased this product, or their local government office, for details of

where and how they can take these items for environmentally safe

recycling.

Business users should contact their supplier and check the terms and

conditions of the purchase contract. This product and its electronic

accessories should not be mixed with other commercial wastes for

disposal.

This marking on the battery, manual or packaging indicates that the

batteries in this product should not be disposed with other

household waste at the end of their working life. Where marked, the

chemical symbols Hg, Cd or Pb indicate that the battery contains

mercury, cadmium or lead above the reference levels in EC Directive

2006/66. If batteries are not properly disposed of, these substances

can cause harm to human health or the environment. To protect

natural resources and to promote material reuse, please separate

batteries from other s of waste and recycle them through your local,

free battery return system.

Regulatory information

114

5. Appendix

Taiwan only

Radio frequency emissions

FCC information to the user

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received, including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or experienced radio TV technician for help.

Change or modifications not expressly approved by the manufacturer

responsible for compliance could void the user's authority to operate the

equipment.

Regulatory information

115

5. Appendix

Canadian radio interference regulations

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus as set out in the interference-causing

equipment standard entitled “Digital Apparatus”, ICES-003 of the Industry and

Science Canada.

Cet appareil numérique respecte les limites de bruits radioélectriques

applicables aux appareils numériques de Classe B prescrites dans la norme sur le

matériel brouilleur: “Appareils Numériques”, ICES-003 édictée par l’Industrie et

Sciences Canada.

United States of America

Federal Communications Commission (FCC)

Intentional emitter per FCC Part 15

Low power, Radio LAN devices (radio frequency (RF) wireless communication

devices), operating in the 2.4 GHz/5 GHz Band, may be present (embedded) in

your printer system. This section is only applicable if these devices are present.

Refer to the system label to verify the presence of wireless devices.

Wireless devices that may be in your system are only qualified for use in the

United States of America if an FCC ID number is on the system label.

The FCC has set a general guideline of 20 cm (8 inches) separation between the

device and the body, for use of a wireless device near the body (this does not

include extremities). This device should be used more than 20 cm (8 inches)

from the body when wireless devices are on. The power output of the wireless

device (or devices), which may be embedded in your printer, is well below the

RF exposure limits as set by the FCC.

This transmitter must not be collocated or operation in conjunction with any

other antenna or transmitter.

Operation of this device is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired

operation of the device.

Wireless devices are not user serviceable. Do not modify them in any way.

Modification to a wireless device will void the authorization to use it.

Contact manufacturer for service.

Regulatory information

116

5. Appendix

FCC Statement for Wireless LAN use:

While installing and operating this transmitter and antenna combination

the radio frequency exposure limit of 1m W/cm2 may be exceeded at

distances close to the antenna installed. Therefore, the user must maintain

a minimum distance of 20cm from the antenna at all times. This device

cannot be colocated with another transmitter and transmitting antenna.

Russia only

Germany only

Turkey only

Canada only

This product meets the applicable Industry Canada technical specifications. / Le

present materiel est conforme aux specifications techniques applicables

d’Industrie Canada.

Regulatory information

117

5. Appendix

The Ringer Equivalence Number (REN) is an indication of the maximum number

of devices allowed to be connected to a telephone interface. The termination of

an interface may consist of any combination of devices subject only to the

requirement that the sum of the RENs of all the devices not exceed five. / L’indice

d’equivalence de la sonnerie (IES) sert a indiquer le nombre maximal de

terminaux qui peuvent etre raccordes a une interface telephonique. La

terminaison d’une interface peut consister en une combinaison quelconque de

dispositifs, a la seule condition que la somme d’indices d’equivalence de la

sonnerie de tous les dispositifs n’excede pas cinq.

Fax Branding

The Telephone Consumer Protection Act of 1991 makes it unlawful for any

person to use a computer or other electronic device to send any message via a

telephone facsimile machine unless such message clearly contains in a margin

at the top or bottom of each transmitted page or on the first page of the

transmission the following information:

1 the date and time of transmission

2 identification of either business, business entity or individual sending the

message; and

3 telephone number of either the sending machine, business, business entity

or individual.

The Telephone Company may make changes in its communications facilities,

equipment operations or procedures where such action is reasonably required

in the operation of its business and is not inconsistent with the rules and

regulations in FCC Part 68. If such changes can be reasonably expected to render

any customer terminal equipment incompatible with telephone company

communications facilities, or require modification or alteration of such terminal

equipment, or otherwise materially affect its use or performance, the customer

shall be given adequate notice in writing, to allow the customer an opportunity

to maintain uninterrupted service

Ringer Equivalence Number

The Ringer Equivalence Number and FCC Registration Number for this machine

may be found on the label located on the bottom or rear of the machine. In some

instances you may need to provide these numbers to the telephone company.

The Ringer Equivalence Number (REN) is a measure of the electrical load placed

on the telephone line, and is useful for determining whether you have

“overloaded” the line. Installing several s of equipment on the same telephone

line may result in problems making and receiving telephone calls, especially

ringing when your line is called. The sum of all Ringer Equivalence Numbers of

the equipment on your telephone line should be less than five in order to assure

proper service from the telephone company. In some cases, a sum of five may

not be usable on your line. If any of your telephone equipment is not operating

properly, you should immediately remove it from your telephone line, as it may

cause harm to the telephone network.

Regulatory information

118

5. Appendix

The equipment complies with Part 68 of the FCC rules and the requirements

adopted by the ACTA. On the rear of this equipment is a label that contains,

among other information, a product identifier in the format US:AAAEQ##TXXXX.

If requested, this number must be provided to the telephone company.

FCC Regulations state that changes or modifications to this equipment not

expressly approved by the manufacturer could void the user’s authority to

operate this equipment. In the event that terminal equipment causes harm

to the telephone network, the telephone company should notify the

customer that service may be stopped. However, where prior notice is

impractical, the company may temporarily cease service, providing that

they:

a promptly notify the customer.

b give the customer an opportunity to correct the equipment problem.

c inform the customer of the right to bring a complaint to the Federal

Communication Commission pursuant to procedures set out in FCC

Rules and Regulations Subpart E of Part 68.

You should also know that:

• Your machine is not designed to be connected to a digital PBX system.

• If you intend to use a computer modem or fax modem on the same phone

line as your machine, you may experience transmission and reception

problems with all the equipment. It is recommended that no other

equipment, except for a regular telephone, share the line with your

machine.

• If your area experiences a high incidence of lightning or power surges, we

recommend that you install surge protectors for both the power and the

telephone lines. Surge protectors can be purchased from your dealer or

telephone and electronic specialty stores.

• When programming emergency numbers and/or making test calls to

emergency numbers, use a non-emergency number to advise the

emergency service dispatcher of your intentions. The dispatcher will give

you further instructions on how to actually test the emergency number.

• This machine may not be used on coin service or party lines.

• This machine provides magnetic coupling to hearing aids.

You may safely connect this equipment to the telephone network by means of

a standard modular jack, USOC RJ-11C.

Replacing the Fitted Plug (for UK Only)

Important

The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug

and has a 13 amp fuse. When you change or examine the fuse, you must re-fit

the correct 13 amp fuse. You then need to replace the fuse cover. If you have lost

the fuse cover, do not use the plug until you have another fuse cover.

Contact the people from you purchased the machine.

Regulatory information

119

5. Appendix

The 13 amp plug is the most widely used in the UK and should be suitable.

However, some buildings (mainly old ones) do not have normal 13 amp plug

sockets. You need to buy a suitable plug adaptor. Do not remove the moulded

plug.

If you cut off the moulded plug, get rid of it straight away.You cannot rewire

the plug and you may receive an electric shock if you plug it into a socket.

Important warning:

If the wires in the mains lead do not match the colors marked in your plug, do

the following:

You must connect the green and yellow wire to the pin marked by the letter “E”

or by the safety ‘Earth symbol’ or colored green and yellow or green.

You must connect the blue wire to the pin which is marked with the letter “N” or

colored black.

You must connect the brown wire to the pin which is marked with the letter “L”

or colored red.

You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.

Declaration of conformity (European countries)

Approvals and Certifications

January 1, 1995: Council Directive 2006/95/EC Approximation of the laws of

the member states related to low voltage equipment.

January 1, 1996: Council Directive 2004/108/EC, approximation of the laws of

the Member States related to electromagnetic compatibility.

You must earth this machine.

The wires in the mains lead have the following color code:

•Green and Yellow: Earth

•Blue: Neutral

•Brown: Live

Hereby, Samsung Electronics, declares that this [SCX-470xND Series]

is incompliance with the essential requirements and other

relevantprovisions of Low Voltage Directive (2006/95/EC), EMC

Directive (2004/108/EC).

Hereby, Samsung Electronics, declares that this [SCX-472xFW Series,

SCX-472xHW Series, SCX-472xFD Series, SCX-472xHD Series, SCX-

472xHN Series, SCX-472xFN Series] is in compliance with the

essential requirements and other relevant provisions of R&TTE

Directive 1999/5/EC.

The declaration of conformity may be consulted at

www.samsung.com, go to Support > Download center and enter

your printer (MFP) name to browse the EuDoC.

Regulatory information

120

5. Appendix

March 9, 1999: Council Directive 1999/5/EC on radio equipment and

telecommunications terminal equipment and the mutual recognition of their

conformity. A full declaration, defining the relevant Directives and referenced

standards can be obtained from your Samsung Electronics Co., Ltd.

representative.

EC Certification

Certification to 1999/5/EC Radio Equipment & Telecommunications Terminal

Equipment Directive (FAX)

This Samsung product has been self-certified by Samsung for pan-European

single terminal connection to the analogue public switched telephone network

(PSTN) in accordance with Directive 1999/5/EC. The product has been designed

to work with the national PSTNs and compatible PBXs of the European

countries:

In the event of problems, you should contact the Euro QA Lab of Samsung

Electronics Co., Ltd. in the first instance.

The product has been tested against TBR21. To assist in the use and application

of terminal equipment which complies with this standard, the European

Telecommunication Standards Institute (ETSI) has issued an advisory document

(EG 201 121) which contains notes and additional requirements to ensure

network compatibility of TBR21 terminals. The product has been designed

against, and is fully compliant with, all of the relevant advisory notes contained

in this document.

European radio approval information (for products

fitted with EU-approved radio devices)

Low power, Radio LAN type devices (radio frequency (RF) wireless

communication devices), operating in the 2.4 GHz/5 GHz band, may be present

(embedded) in your printer system which is intended for home or office use. This

section is only applicable if these devices are present. Refer to the system label

to verify the presence of wireless devices.

The power output of the wireless device or devices that may be embedded in

you printer is well below the RF exposure limits as set by the European

Commission through the R&TTE directive.

European states qualified under wireless approvals:

EU countries

European states with restrictions on use:

In France, the frequency range is restricted to 2454-2483.5 MHz for devices

above 10 mW transmitting power such as wireless

EEA/EFTA countries

Wireless devices that may be in your system are only

qualified for use in the European Union or associated

areas if a CE mark with a Notified Body Registration

Number and the Alert Symbol is on the system label.

Regulatory information

121

5. Appendix

No limitations at this time

Israel only

Regulatory compliance statements

Wireless guidance

Low power, Radio LAN devices (radio frequency (RF) wireless communication

devices), operating in the 2.4 GHz/5 GHz Band, may be present (embedded) in

your printer system. The following section is a general overview of

considerations while operating a wireless device.

Additional limitations, cautions, and concerns for specific countries are listed in

the specific country sections (or country group sections). The wireless devices in

your system are only qualified for use in the countries identified by the Radio

Approval Marks on the system rating label. If the country you will be using the

wireless device in, is not listed, contact your local Radio Approval agency for

requirements. Wireless devices are closely regulated and use may not be

allowed.

The power output of the wireless device or devices that may be embedded in

your printer is well below the RF exposure limits as known at this time. Because

the wireless devices (which may be embedded into your printer) emit less

energy than is allowed in radio frequency safety standards and

recommendations, manufacturer believes these devices are safe for use.

Regardless of the power levels, care should be taken to minimize human contact

during normal operation.

As a general guideline, a separation of 20 cm (8 inches) between the wireless

device and the body, for use of a wireless device near the body (this does not

include extremities) is typical. This device should be used more than 20 cm (8

inches) from the body when wireless devices are on and transmitting.

This transmitter must not be collocated or operation in conjunction with any

other antenna or transmitter.

Some circumstances require restrictions on wireless devices. Examples of

common restrictions are listed below:

Radio frequency wireless communication can interfere with equipment

on commercial aircraft. Current aviation regulations require wireless

devices to be turned off while traveling in an airplane. IEEE 802.11 (also

known as wireless Ethernet) and Bluetooth communication devices are

examples of devices that provide wireless communication.

Regulatory information

122

5. Appendix

In environments where the risk of interference to other devices or

services is harmful or perceived as harmful, the option to use a wireless

device may be restricted or eliminated. Airports, Hospitals, and Oxygen

or flammable gas laden atmospheres are limited examples where use of

wireless devices may be restricted or eliminated. When in environments

where you are uncertain of the sanction to use wireless devices, ask the

applicable authority for authorization prior to use or turning on the

wireless device.

Every country has different restrictions on the use of wireless devices.

Since your system is equipped with a wireless device, when traveling

between countries with your system, check with the local Radio

Approval authorities prior to any move or trip for any restrictions on the

use of a wireless device in the destination country.

If your system came equipped with an internal embedded wireless

device, do not operate the wireless device unless all covers and shields

are in place and the system is fully assembled.

Wireless devices are not user serviceable. Do not modify them in any

way. Modification to a wireless device will void the authorization to use

it. Contact manufacturer for service.

Only use drivers approved for the country in which the device will be

used. See the manufacturer System Restoration Kit, or contact

manufacturer Technical Support for additional information.

Regulatory information

123

5. Appendix

China only

124

5. Appendix

This user’s guide is provided for information purposes only. All information included herein is subject to change without notice.

Samsung Electronics is not responsible for any direct or indirect damages, arising from or related to use of this user’s guide.

• Samsung and the Samsung logo are trademarks of Samsung Electronics Co., Ltd.

• Microsoft, Windows, Windows Vista, Windows 7, and Windows Server 2008 R2 are either registered trademarks or trademarks of Microsoft Corporation.

• True, LaserWriter, and Macintosh are trademarks of Apple Computer, Inc.

• All other brand or product names are trademarks of their respective companies or organizations.

Refer to the 'LICENSE.txt' file in the provided CD-ROM for the open source license information.

REV. 2.03

ADVANCED

User’s Guide

SCX-472x Series

SCX-470x Series

ADVANCED

User’s Guide

This guide provides information about installation, advanced configuration,

operation and troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

This guide provides information concerning installation, basic operation and troubleshooting

on windows.

1. Software Installation

This chapter provides instructions for installing essential and helpful software for use in an environment where the

machine is connected via a cable. A locally connected machine is a machine directly attached to your computer using

the cable. If your machine is attached to a network, skip the following steps below and go on to installing a network

connected machine’s driver (see "Installing driver over the network" on page 137).

• Installation for Macintosh 127

• Reinstallation for Macintosh 128

• Installation for Linux 129

• Reinstallation for Linux 131

• If you are a Windows OS user, refer to the Basic Guide for installing the machine’s driver (see

"Installing the driver locally" on page 27).

• Only use a USB cable no longer then 3 meter (118 inches).

127

1. Software Installation

Installation for Macintosh

1Make sure that the machine is connected to your computer and

powered on.

2 Insert the supplied software CD into your CD-ROM drive.

3 Double-click the CD-ROM icon that appears on your Macintosh desktop.

4 Double-click the MAC_Installer folder > Installer OS X icon.

5 Click Continue.

6 Read the license agreement and click Continue.

7 Click Agree to agree to the license agreement.

8 When the message that warns that all applications will close on your

computer appears, click Continue.

9 Click Continue on the User Options Pane.

10 Click Install. All components necessary for machine operations will be

installed.

If you click Customize, you can choose individual components to install.

11 Enter the password and click OK.

12 Installing software requires you to restart your computer. Click Continue

Installation.

13 After the installation is finished, click Restart.

14 Open the Applications folder > Utilities > Print Setup Utility.

•For Mac OS X 10.5 -10.7, open the Applications folder > System

Preferences and click Print & Fax.

15 Click Add on the Printer List.

•For Mac OS X 10.5 -10.7, click the “+” folder icon; a display window will

pop up.

16 Click Default Browser and find the USB connection.

•For Mac OS X 10.5-10.7, click Default and find the USB connection.

17 For Mac OS X 10.4, if Auto Select does not work properly, select Samsung

in Print Using and your machine name in Model.

•For Mac OS X 10.5-10.7, if Auto Select does not work properly, select

Select a driver to use... and your machine name in Print Using.

Your machine appears on the Printer List, and is set as the default

machine.

18 Click Add.

To install the fax driver:

a Open the Applications folder > Samsung > Fax Queue Creator.

b Your machine appears on the Printer List

c Select machine to use and click Create button

128

1. Software Installation

Reinstallation for Macintosh

If the printer driver does not work properly, uninstall the driver and reinstall it.

1Make sure that the machine is connected to your computer and

powered on.

2 Insert the supplied software CD into your CD-ROM drive.

3 Double-click the CD-ROM icon that appears on your Macintosh desktop.

4 Double-click the MAC_Installer folder > Uninstaller OS X icon.

5 Enter the password and click OK.

6 When the uninstall is done, click OK.

If a machine has already been added, delete it from the Print Setup Utility

or Print & Fax.

129

1. Software Installation

Installation for Linux

You need to download Linux software packages from the Samsung website to

install the printer software (http://www.samsung.com > find your product >

Support or Downloads).

Installing the Unified Linux Driver

1Make sure that the machine is connected to your computer and

powered on.

2 When the Administrator Login window appears, type “root” in the

You must log in as a super user (root) to install the machine software. If you

are not a super user, ask your system administrator.

3 From the Samsung website, download the Unified Linux Driver package

to your computer.

4 Right-click the Unified Linux Driver package and extract the package.

5 Double click cdroot > autorun.

6 When the welcome screen appears, click Next.

7 When the installation is complete, click Finish.

The installation program added the Unified Driver Configurator desktop icon

and the Unified Driver group to the system menu for your convenience. If you

have any difficulties, consult the on-screen help that is available through your

system menu or from the driver package Windows applications, such as Unified

Driver Configurator or Image Manager.

Installing the Smart Panel

1Make sure that the machine is connected to your computer and

powered on.

2 When the Administrator Login window appears, type in root in the

You must log in as a super user (root) to install the machine software. If you

are not a super user, ask your system administrator.

3 From the Samsung website, download the Smart Panel package to your

computer.

4 Right-click the Smart Panel package and extract the package.

5 Double click cdroot > Linux > smartpanel > install.sh.

Installation for Linux

130

1. Software Installation

Installing the Printer Settings Utility

1Make sure that the machine is connected to your computer and

powered on.

2 When the Administrator Login window appears, type “root” in the

You must log in as a super user (root) to install the machine software. If you

are not a super user, ask your system administrator.

3 From the Samsung website, download the Printer Settings Utility

package to your computer.

4 Right-click the Printer Settings Utility package and extract the

package.

5 Double click cdroot > Linux > psu > install.sh.

131

1. Software Installation

Reinstallation for Linux

If the printer driver does not work properly, uninstall the driver and reinstall it.

1Make sure that the machine is connected to your computer and

powered on.

2 When the Administrator Login window appears, type “root” in the

You must log in as a super user (root) to uninstall the printer driver. If you

are not a super user, ask your system administrator.

3 Click the icon at the bottom of the desktop. When the Terminal screen

appears, type in the following.

[root@localhost root]#cd /opt/Samsung/mfp/uninstall/[root@localhost

uninstall]#./uninstall.sh

4 Click Uninstall.

5 Click Next.

6 Click Finish.

2. Using a Network-

Connected Machine

This chapter gives you step-by-step instructions for setting up a network connected machine and software.

• Useful network programs 133

• Wired network setup 134

• Installing driver over the network 137

• IPv6 configuration 145

• Wireless network setup 148

Supported optional devices and features may differ according to your model (see "Features by

models" on page 5).

133

2. Using a Network-Connected Machine

Useful network programs

There are several programs available to setup the network settings easily in a

network environment. For the network administrator especially, managing

several machines on the network is possible.

• Before using the programs below, set the IP address first.

• Some features and optional goods may not be available depending on

model or country (see "Features by models" on page 5).

SyncThru™ Web Service

The web server embedded on your network machine allows you to do the

following tasks (see "Using SyncThru™ Web Service" on page 252).

• Check the supplies information and status.

• Customize machine settings.

• Set the email notification option. When you set this option, the machine

status (toner cartridge shortage or machine error) will be sent to a certain

person's email automatically.

• Configure the network parameters necessary for the machine to connect to

various network environments.

SyncThru™ Web Admin Service

Web-based machine management solution for network administrators.

SyncThru™ Web Admin Service provides you with an efficient way of managing

network devices and lets you remotely monitor and troubleshoot network

machines from any site with corporate internet access.

• Download this program from http://solution.samsungprinter.com.

SetIP wired network setup

This utility program allows you to select a network interface and manually

configure the IP addresses for use with the TCP/IP protocol.

• See "IPv4 configuration using SetIP (Windows)" on page 134.

• See "IPv4 configuration using SetIP (Macintosh)" on page 135.

• See "IPv4 configuration using SetIP (Linux)" on page 136.

• The machine that does not support the network interface, it will not be

able to use this feature (see "Rear view" on page 22).

• TCP/IPv6 is not supported by this program.

134

2. Using a Network-Connected Machine

Wired network setup

Printing a network configuration report

You can print Network Configuration Report from the machine’s control panel

that will show the current machine’s network settings. This will help you to set

up a network.

•The machine has the display screen: Press the (Menu) button on the

control panel and select Network > Network Config. (Network

Configuration).

•The machine has the touch screen: Press Setup from the Main screen >

Network > Next > Network Configuration.

•The machine does not have the display screen: Press the (Cancel or

Stop/Clear) button for more than 4~5 seconds on the control panel.

Using this Network Configuration Report, you can find your machine’s MAC

address and IP address.

For example:

• MAC Address: 00:15:99:41:A2:78

• IP Address: 192.0.0.192

Setting IP address

• The machine that does not support the network interface, it will not be

able to use this feature (see "Rear view" on page 22).

• TCP/IPv6 is not supported by this program.

First, you have to set up an IP address for network printing and managements.

In most cases a new IP address will be automatically assigned by a DHCP

(Dynamic Host Configuration Protocol) server located on the network.

IPv4 configuration using SetIP (Windows)

Before using the SetIP program, disable the computer firewall from Control

Panel > Security Center > Windows Firewall.

1Install this program from the supplied CD-ROM by double-click

Application > SetIP > Setup.exe.

2 Follow the instructions in the installation window.

3 Connect your machine to the network with a network cable.

4 Turn on the machine.

5 From the Windows Start menu, select All Programs > Samsung

Printers > SetIP > SetIP.

Wired network setup

135

2. Using a Network-Connected Machine

6 Click the icon (third from left) in the SetIP window to open the TCP/

IP configuration window.

7 Enter the machine’s new information into the configuration window as

follows. In a corporate intranet, you may need to have this information

assigned by a network manager before proceeding.

Find the machine’s MAC address from the Network Configuration Report

(see "Printing a network configuration report" on page 134) and enter it

without the colons. For example, 00:15:99:29:51:A8 becomes

0015992951A8.

8 Click Apply, and then click OK. The machine will automatically print the

Network Configuration Report. Confirm that all the settings are

correct.

IPv4 configuration using SetIP (Macintosh)

Before using the SetIP program, disable the computer firewall from System

Preferences > Security > Firewall.

The following instructions may vary from your model.

1Connect your machine to the network with a network cable.

2 Insert the Installation CD-ROM, and open the disk window, select

MAC_Installer > MAC_Printer > SetIP > SetIPapplet.html.

3 Double-click the file and Safari will automatically open, then select

Trust. The browser will open the SetIPapplet.html page that shows the

printer’s name and IP address information.

4 Click the icon (third from left) in the SetIP window to open the TCP/

IP configuration window.

5 Enter the machine’s new information into the configuration window. In

a corporate intranet, you may need to have this information assigned by

a network manager before proceeding.

Wired network setup

136

2. Using a Network-Connected Machine

Find the machine’s MAC address from the Network Configuration Report

(see "Printing a network configuration report" on page 134) and enter it

without the colons. For example, 00:15:99:29:51:A8 becomes

0015992951A8.

6 Select Apply, then OK, and OK again.

7 Quit Safari.

IPv4 configuration using SetIP (Linux)

Before using the SetIP program, disable the computer firewall from System

Preferences or Administrator.

The following instructions may vary from your model or operating systems.

1Open /opt/Samsung/mfp/share/utils/.

2 Double-click the SetIPApplet.html file.

3 Click to open the TCP/IP configuration window.

4 Enter the machine’s new information into the configuration window. In

a corporate intranet, you may need to have this information assigned by

a network manager before proceeding.

Find the machine’s MAC address from the Network Configuration Report

(see "Printing a network configuration report" on page 134) and enter it

without the colons. For example, 00:15:99:29:51:A8 becomes

0015992951A8.

5 The machine will automatically print the Network Configuration

Report.

137

2. Using a Network-Connected Machine

Installing driver over the network

• Some features and optional goods may not be available depending on

model or country (see "Features by models" on page 5).

• The machine that does not support the network interface, it will not be

able to use this feature (see "Rear view" on page 22).

Windows

1Make sure that the machine is connected to the network and powered

on. Also, your machine’s IP address should have been set (see "Setting IP

address" on page 134).

2 Insert the supplied software CD into your CD-ROM drive.

3 Select Install Now.

4 Read License Agreement, and select I accept the terms of the License

Agreement. Then, click Next.

If your machine is not found on the network or locally, an error message

appears. Select the option you want and click Next.

5 In the "Connect Printer" screen, select the "Network Connection" option

and click Next.

6 The searched machines will be shown on the screen. Select the one you

wish to use and click OK.

Installing driver over the network

138

2. Using a Network-Connected Machine

7 Follow the instructions in the installation window.

Silent installation Mode

Silent installation mode is an installation method that does not require any user

intervention. Once you start the installation, the machine driver and software

are automatically installed on you computer. You can start the silent installation

by typing /s or /S in the command window.

Command-line Parameters

Following table shows commands that can be used in the command window.

Following command-line are effective and operated when command is

used with /s or /S. But /h, /H or /? are exceptional commands that can be

operated solely.

Command- line Definition Description

/s or/S Starts silent installation. Installs machine drivers

without prompting any UIs

or user intervention.

/p”<port name>”

or/P”<port name>”

Specifies printer port.

Network Port will

be created by use

of Standard TCP/IP

Port monitor. For

local port, this port

must exist on

system before

being specified by

command.

Printer port name can be

specified as IP address,

hostname, USB local port

name or IEEE1284 port

name.

For example:

• /p”xxx.xxx.xxx.xxx” in

where, “xxx.xxx.xxx.xxx”

means IP address for

network printer. /

p”USB001”, /P”LPT1:”, /

p”hostname”

/a”<dest_path>” or/

A”<dest_path>”

Specifies destination path

for installation.

The destination

path should be a

fully qualified path.

Since machine drivers

should be installed on the OS

specific location, this

command applies to only

application software.

Command- line Definition Description

Installing driver over the network

139

2. Using a Network-Connected Machine

/i”<script

filename>” or/

I”<script filename>”

Specifies customized install

script file for custom

operation.

The script filename

should be a fully

qualified filename.

Customized script file can be

assigned for customized

silent installation. This script

file can be created or

modified through provided

installer customizing utility

or by text editor.

This customized

script file is prior than

default installer

setting in setup

package but not

prior than

command-line

parameters.

/n”<Printer name>”

or/N”<Printer

name>”

Specifies printer name.

Printer instance shall be

created as specified printer

name.

With this parameter, you can

add printer instances as your

wishes.

Command- line Definition Description

/nd or/ND Commands not to set the

installed driver as a default

machine driver.

It indicates installed machine

driver will not be the default

machine driver on your

system if there are one or

more printer drivers

installed. If there is no

installed machine driver on

your system, then this option

won’t be applied because

Windows OS will set installed

printer driver as a default

machine driver.

/x or/X Uses existing machine

driver files to create printer

instance if it is already

installed.

This command provides a

way to install a printer

instance that uses installed

printer driver files without

installing an additional

driver.

/up”<printer

name>” or/

UP”<printer

name>”

Removes only specified

printer instance and not

the driver files.

This command provides a

way to remove only specified

printer instance from your

system without effecting

other printer drivers. It will

not remove printer driver

files from your system.

Command- line Definition Description

Installing driver over the network

140

2. Using a Network-Connected Machine

Macintosh

1Make sure that the machine is connected to your network and powered

on.

2 Insert the supplied software CD into your CD-ROM drive.

3 Double-click the CD-ROM icon that appears on your Macintosh desktop.

4 Double-click the MAC_Installer folder > Installer OS X icon.

5 Click Continue.

6 Read the license agreement and click Continue.

7 Click Agree to agree to the license agreement.

8 When the message which warns that all applications will close on your

computer appears, click Continue.

9 Click Continue on the User Options Pane.

If you have not set the IP address yet, click Set IP address and refer to "IPv4

configuration using SetIP (Macintosh)" on page 135. If you want to set the

wireless setting, refer to "Setup using Macintosh" on page 158.

/d or/D Uninstalls all device drivers

and applications from your

system.

This command will remove

all installed device drivers

and application software

from your system.

/v”<share name>”

or/V”<share

name>”

Shares installed machine

and add other available

platform drivers for Point &

Print.

It will install all supported

Windows OS platform’s

machine drivers to system

and share it with specified

<share name> for point and

print.

/o or /O Opens Printers and Faxes

folder after installation.

This command will open

Printers and Faxes folder

after the silent installation.

/f”<log filename>”

or/F”<log

filename>”

Specifies log filename.The

default log file is created in

the system temp folder if

not specified.

It will create a log file to a

specified folder.

/h, /H or /? Shows Command-line Usage.

Command- line Definition Description

Installing driver over the network

141

2. Using a Network-Connected Machine

10 Click Install. All components necessary for machine operations will be

installed.

If you click Customize, you can choose individual components to install.

11 Enter the password and click OK.

12 Installing software requires you to restart your computer. Click Continue

Installation.

13 After the installation is finished, click Restart.

14 Open the Applications folder > Utilities > Print Setup Utility.

•For Mac OS X 10.5-10.7, open the Applications folder > System

Preferences and click Print & Fax.

15 Click Add on the Printer List.

•For Mac OS X 10.5-10.7, click the “+” icon. A display window will pop up.

16 For Mac OS X 10.4, click IP Printer.

•For Mac OS X 10.5-10.7, click IP.

17 Select HP Jetdirect - Socket in Protocol.

When printing a document containing many pages, printing performance

may be enhanced by choosing Socket for Printer Type option.

18 Enter the machine’s IP address in the Address input field.

19 Enter the queue name in the Queue input field. If you cannot determine

the queue name for your machine server, try using the default queue

first.

20 For Mac OS X 10.4, if Auto Select does not work properly, select Samsung

in Print Using and your machine name in Model.

•For Mac OS X 10.5-10.7, if Auto Select does not work properly, choose

Select Printer Software and your machine name in Print Using.

21 Click Add.

Your machine appears in the Printer List, and is set as the default

machine.

To install the fax driver:

a Open the Applications folder > Samsung > Fax Queue Creator.

b Your machine appears on the Printer List.

c Select machine to use and Click Create button.

Linux

You need to download Linux software packages from the Samsung website to

install the printer software (http://www.samsung.com > find your product >

Support or Downloads).

Installing driver over the network

142

2. Using a Network-Connected Machine

To install other software:

• See "Installing the Smart Panel" on page 129.

• See "Installing the Printer Settings Utility" on page 130.

Install the Linux driver and add network printer

1Make sure that the machine is connected to your network and powered

on. Also, your machine’s IP address should have been set.

2 Download the Unified Linux Driver package from the Samsung website.

3 Extract the UnifiedLinuxDriver.tar.gz file and open the new directory.

4 Double-click the Linux folder > install.sh icon.

5 The Samsung installer window opens. Click Continue.

6 The add printer wizard window opens. Click Next.

7 Select network printer and click Search button.

8 The machine’s IP address and model name appears on list field.

9 Select your machine and click Next.

10 Input the printer description and Next.

11 After the machine is added, click Finish.

12 When installation is done, click Finish.

Add a network printer

1Double-click the Unified Driver Configurator.

2 Click Add Printer.

3 The Add printer wizard window opens. Click Next.

4 Select Network printer and click the Search button.

5 The printer’s IP address and model name appears on list field.

6 Select your machine and click Next.

7 Enter the printer description and click Next.

8 After the machine is added, click Finish.

Installing driver over the network

143

2. Using a Network-Connected Machine

UNIX

• Make sure your machine supports the UNIX operating system before

installing the UNIX printer driver (see "Operating System" on page 5).

• The commands are marked with “”, when typing the commands, do not

type “”.

• Some features and optional goods may not be available depending on

model or country (see "Operating System" on page 5).

To use the UNIX printer driver, you have to install the UNIX printer driver

package first, then setup the printer. You can download the UNIX printer driver

package from the Samsung website ((http://www.samsung.com > find your

product > Support or Downloads).

Installing the UNIX printer driver package

The installation procedure is common for all variants of UNIX OS mentioned.

1From the Samsung website, download and unpack the UNIX Printer

Driver package to your computer.

2 Acquire root privileges.

“su -”

3 Copy the appropriate driver archive to the target UNIX computer.

See administration guide of your UNIX OS for details.

4 Unpack the UNIX printer driver package.

For example, on IBM AIX, use the following commands.

“gzip -d < enter the package name | tar xf -”

5 Go to the unpacked directory.

6 Run the install script.

“./install”

install is the installer script file which is used to install or uninstall the

UNIX Printer Driver package.

Use “chmod 755 install” command to give the permission to the

installer script.

7 Execute the “. /install –c” command to verify installation results.

8 Run “installprinter” from the command line. This will bring up the Add

Printer Wizard window. Setup the printer in this window referring to

the following procedures.

Installing driver over the network

144

2. Using a Network-Connected Machine

On some UNIX OS, for example on Solaris 10, just added printers may not be

enabled and/or may not accept jobs. In this case run the following two

commands on the root terminal:

“accept <printer_name>”

“enable <printer_name>”

Uninstalling the printer driver package

The utility should be used to delete the printer installed in the system.

a Run “uninstallprinter” command from the terminal.

It will open the Uninstall Printer Wizard.

The installed printers are listed in the drop-down list.

b Select the printer to be deleted.

c Click Delete to delete the printer from the system.

d Execute the “. /install –d” command to uninstall the whole package.

e To verify removal results, execute the “. /install –c” command.

To re-install it, use the command “. /install” to reinstall the binaries.

Setting up the printer

To add the printer to your UNIX system, run ‘installprinter’ from the command line. This

will bring up the Add Printer Wizard window. Setup the printer in this window

according to the following steps:

1Type the name of the printer.

2 Select the appropriate printer model from the model list.

3 Enter any description corresponding to the type of the printer in the Type field.

This is optional.

4 Specify any printer description in the Description field. This is optional.

5 Specify the printer location in the Location field.

6 Type the IP address or DNS name of the printer in the Device textbox for

network-connected printers. On IBM AIX with jetdirect Queue type, only the

DNS name is possible-numeric IP address is not allowed.

7 Queue type shows the connection as lpd or jetdirect in the corresponding list

box. Additionally, usb type is available on Sun Solaris OS.

8 Select Copies to set the number of copies.

9 Check the Collate option to receive copies already sorted.

10 Check the Reverse Order option to receive copies in the reverse order.

11 Check the Make Default option to set this printer as default.

12 Click OK to add the printer.

145

2. Using a Network-Connected Machine

IPv6 configuration

IPv6 is supported properly only in Windows Vista or higher.

• Some features and optional goods may not be available depending on

model or country (see "Features by models" on page 5 or "Menu

overview" on page 30).

• If the IPv6 network seems to not be working, set all the network setting

to the factory defaults and try again using Clear Setting.

In the IPv6 network environment, follow the next procedure to use the IPv6

address.

From the control panel

1Connect your machine to the network with a network cable.

2 Turn on the machine.

3 Print a Network Configuration Report that will check IPv6 addresses

(see "Printing a network configuration report" on page 134).

4 Select Start > Control Panel > Printers and Faxes.

5 Click Add a printer in the left pane of the Printers and Faxes windows.

6 Click Add a local printer in the Add Printer windows.

7 The Add Printer Wizard window appears. Follow the instructions in the

window.

If the machine does not work in the network environment, activate IPv6.

Refer to the next section followed by.

Activating IPv6

1Press the (Menu) button on the control panel.

2 Press Network > TCP/IP (IPv6) > IPv6 Activate.

3 Select On and press OK.

4 Turn the machine off and turn it on again.

5 Reinstall your printer driver.

IPv6 configuration

146

2. Using a Network-Connected Machine

Setting IPv6 addresses

The machine supports the following IPv6 addresses for network printing and

managements.

•Link-local Address: Self-configured local IPv6 address (Address starts with

FE80).

•Stateless Address: Automatically configured IPv6 address by a network

router.

•Stateful Address: IPv6 address configured by a DHCPv6 server.

•Manual Address: Manually configured IPv6 address by a user.

DHCPv6 address configuration (Stateful)

If you have a DHCPv6 server on your network, you can set one of the following

options for default dynamic host configuration.

1Press the (Menu) button on the control panel.

2 Press Network > TCP/IP (IPv6) > DHCPv6 Config.

3 Press OK to select the required value you want.

•DHCPv6 Addr.: Always use DHCPv6 regardless of router request.

•DHCPv6 Off: Never use DHCPv6 regardless of router request.

•Router: Use DHCPv6 only when requested by a router.

From the SyncThru™ Web Service

For models that do not have the display screen on the control panel, you

need to access SyncThru™ Web Service first using the IPv4 address and

follow the below procedure to use IPv6.

1Access a web browser, such as Internet Explorer, from Windows. Enter

the machine IP address (http://xxx.xxx.xxx.xxx) in the address field and

press the Enter key or click Go.

2 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and password.

•ID: admin

•Password: sec00000

3 When the SyncThru™ Web Service window opens, move the mouse

cursor over the Settings of the top menu bar and then click Network

Settings.

4 Click TCP/IPv6 on the left pane of the website.

5 Check the IPv6 Protocol check box to activate IPv6.

6 Check the Manual Address check box. Then, the Address/Prefix text

box is activated.

IPv6 configuration

147

2. Using a Network-Connected Machine

7 Enter the rest of the address (e.g.,:3FFE:10:88:194::AAAA. “A” is the

hexadecimal 0 through 9, A through F).

8 Choose the DHCPv6 configuration.

9 Click the Apply button.

Using SyncThru™ Web Service

1Start a web browser, such as Internet Explorer, that supports IPv6

addressing as a URL.

2 Select one of the IPv6 addresses (Link-local Address, Stateless

Address, Stateful Address, Manual Address) from Network

Configuration Report (see "Printing a network configuration report" on

page 134).

3 Enter the IPv6 addresses (e.g.,: http://[FE80::215:99FF:FE66:7701]).

Address must be enclosed in '[ ]' brackets.

148

2. Using a Network-Connected Machine

Wireless network setup

• Make sure your machine supports wireless networking. Wireless

networking may not be available depending on the model (see "Features

by models" on page 5).

• If the IPv6 network seems to not be working, set all the network settings

to the factory defaults and try again using Clear Setting.

Getting started

Understanding your network type

Typically, you can only have one connection between your computer and the

machine at a time.

Wireless network name and Network Password

Wireless networks require higher security, so when an access point is first set up,

a network name (SSID), the type of security used, and a Network Password are

created for the network. Ask your network administrator about this information

before proceeding with the machine installation.

Infrastructure mode

This is an environment generally used for homes and SOHOs

(Small Office/ Home Office). This mode uses an access point to

communicate with the wireless machine.

Ad hoc mode

This mode does not use an access point. The wireless

computer and wireless machine communicate directly.

Wireless network setup

149

2. Using a Network-Connected Machine

Introducing wireless set up methods

You can set wireless settings either from the machine or the computer. Choose the setting method from the below table.

Some wireless network installation types may not be available depending on the model or country.

If problems occur during wireless set up or driver installation, refer to the troubleshooting chapter (see "Troubleshooting" on page 167).

Set up method Connecting method Description & Reference

With Access Point

From the computer Windows User, see "Access point via USB cable" on page 154. A

Macintosh User, see "Access point via USB cable" on page 158. B

See "Using a network cable" on page 161. C

From the machine’s control panel See "Using the WPS button" on page 150. D

See "Using the menu button" on page 153. E

Without Access Point

From the computer Windows User, see "Ad hoc via USB cable" on page 156. F

Macintosh User, see "Ad hoc via USB cable" on page 159. G

Wi-Fi Direct setup See "Turning the Wi-Fi network on/off" on page 164. H

Wireless network setup

150

2. Using a Network-Connected Machine

Using the WPS button

If your machine and an access point (or wireless router) support Wi-Fi Protected

Setup™ (WPS), you can easily configure the wireless network settings by

pressing the (WPS) button on the control panel without a computer.

• If you want to use the wireless network using the infrastructure mode,

make sure that the network cable is disconnected from the machine.

Using the WPS (PBC) button or entering the PIN from the computer to

connect to the access point (or wireless router) varies depending on the

access point (or wireless router) you are using. Refer to the user's guide

of the access point (or wireless router) you are using.

• When using the WPS button to set the wireless network, security settings

may change. To prevent this, lock the WPS option for the current wireless

security settings. The option name may differ depending on the access

point (or wireless router) you are using.

Items to prepare

• Check if the access point (or wireless router) supports Wi-Fi Protected

Setup™ (WPS).

• Check if your machine supports Wi-Fi Protected Setup™ (WPS).

• Networked computer (PIN mode only)

Choosing your type

There are two methods available to connect your machine to a wireless network

using the (WPS) button on the control panel.

The Push Button Configuration (PBC) method allows you to connect your

machine to a wireless network by pressing both the (WPS) button on the

control panel of your machine and the WPS (PBC) button on a Wi-Fi Protected

Setup™ WPS-enabled access point (or wireless router) respectively.

The Personal Identification Number (PIN) method helps you connect your

machine to a wireless network by entering the supplied PIN information on a Wi-

Fi Protected Setup™ WPS-enabled access point (or wireless router).

Factory default in your machine is PBC mode, which is recommended for a

typical wireless network environment.

You can change the WPS mode in control panel ( (Menu) > Network >

Wireless > OK > WPS Setting).

Samsung Electronics Co SCX4726FN Mono Laser Multifuction Printer User Manual Batian english

Samsung Electronics Co Ltd Mono Laser Multifuction Printer Batian english

Contents

Users Manual 1

Navigation menu

Namespaces

Views

Navigation
